Hisense Electric LCDX0006 NETWORK MEDIA PLAYER User Manual W9HLCDX0006

Hisense Electric Co., Ltd. NETWORK MEDIA PLAYER W9HLCDX0006

W9HLCDX0006_user Manual

Getting Started
www.hisense-usa.com
service@hisense-usa.com
English
ES-G124008
GX1200V
2
Contents
Warning...................................... ...........................................3
FCC/IC Statement .................................................................7
Important Safety Instructions ............................................... 10
Precautions..........................................................................12
Remote . ..............................................................................15
Pairing the Remote .............................................................. 19
Home ...................................................................................21
Google Chrome ...................................................................22
All Apps................................................................................23
Google Play ........................................................................24
Media Player .......................................................................25
Picture-in-Picture ................................................................26
System Settings ..................................................................27
Video Input .........................................................................28
Specifications .....................................................................31
Additional Information ......................................................... 33
3
To reduce the risk of re or electric shock, do not expose this apparatus
to rain or moisture.
To avoid electric shock, do not open the cabinet. Refer servcing to
qualied personnel only.
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the presence
of uninsulated dangerous voltage within the product's
enclosure that may be of sufcient magnitude to constitute a
risk of electric shock.
Warning
4
Batteries or batteries installed apparatus shall not be exposed to
excessive heat such as sunshine, re or the like.
This graphical symbol is located on the bottom of the unit.
Precautions
To prevent re or shock hazard, do not place objects lled with
liquids, such as vases, on the apparatus.
The player is not disconnected from the AC power source (mains) as
long as it is connected to the wall outlet, even if the player itself has
been turned off.
Install this unit so that AC power cord can be unplugged from the wall
socket immediately in the event of trouble.
The nameplate is located on the bottom of the player.
Installation
Do not install this player in a conned space, such as a bookshelf or
similar unit.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
Warning
5
Warning
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a class B digital Device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is en-
couraged to try to correct the interference by one or more of the follow-
ing measures:
Reorient or relocate the receiving antenna.
6
Warning
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifi-
cations could void the user’s authority to operate the equipment.
7
FCC/IC Statement
Industry Canada Notice
This device complies with industry Canada license-exempt RSS
standards(s).Operation is subject to the following two conditions:(1)this
device may not cause interference,and (2)this device must accept any
interference ,including interferernce that may cause undesired opera-
tion of the device.
Le présent appareil est conforme aux CNR d’lndustrie Canada appli-
cables aux appareils radio exempts de licence. L’exploitation est auto-
risée aux deux conditions suivantes: (1) I’appareil ne doit pas produire
de brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouil-
lage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Under industry Canada regulations,this radio transmitter may only
operate using an antenna of a type and maximum(or lesser)gain ap-
proved for the transmitter by industry Canada. To reduce potential radio
interference to other users,the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power(e.i.r.p.) is not
more than that necessary for successful communication.
8
FCC/IC Statement
Conformément à la réglementation d’lndustrie Canada, le présent
émetteur radio peut fonctionner avec une antenne d’un type et d’un
gain maximal (ouinférieur) approuvé pour l’ émetteur par Industrie Can-
ada. Dans le but de réduire les risques de brouillage radioélectrique à
l’intention des autres utilisateurs, il faut choisir le type d’antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.)
ne dépasse pas l’intensité nécessaire à l’ établissement d’une commu-
nication satisfaisante.
FCC RF Safety Caution Statement
To satisfy FCC RF exposure requirements for mobile and base station
transmission devices, a separation distance of 20 cm or more should
be maintained between the antenna of this device and persons during
operation. To ensure compliance, operation at closer than this distance
is not recommended. The antenna(s) used for this transmitter must not
be co-located or operating in conjunction with any other antenna or
transmitter.
RF Exposure Statement for Canada
Notice: To satisfy IC RF exposure requirements for mobile and base
9
FCC/IC Statement
station transmission devices, a separation distance of 20 cm or more
should be maintained between the antenna of this device and persons
during operation, To ensure compliance, operation at closer than this
distance is not recommended. The antenna(s) used for this transmitter
must not be co-located or operating in conjunction with any other an-
tenna or transmitter.
Avis: Pour répondre à la IC d’exposition pour les besoins de base et
mobiles dispositits de transmission de la station, sur une distance
de séparation de 20 cm ou plus do it être maintenue entre I’antenne
de cet appareil et les personnes en cours de fonctionnement. Pour a
ssurer le respect, I’exploitation de plus près à cette distance n’est pas
recommandée. L’antenne (s) utilisé pour cet émetteur ne doit pas être
co-localisés ou fonctionner conjointement avec une autre antenne ou
transmetteur.
10
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
11
Important Safety Instructions
from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been dropped.
12
Placement
Place the player in a location with adequate ventilation to prevent
heat build-up in the player.
Do not place the player on a soft surface such as a rug that might
block the ventilation holes.
Do not place the player in a location near heat sources, or in a place
subject to direct sunlight, excessive dust, or mechanical shock.
Do not place the player outdoors, in vehicles, on ships, or on other
vessels.
If the player is brought directly from a cold to a warm location, or is
placed in a very damp room, moisture may form on the outer surface
and on interior of the player.
Should this occur, the player may not operate properly. In this case,
leave the player turned on for about half an hour until the moisture
evaporates.
Do not install the player in an inclined position. It is designed to be
operated in a horizontal position only.
Do not place metal objects in front or on the both sides of the player.
It may limit reception of radio waves.
Precautions
13
Do not place the player in a place where medical equipment is in
use. It may cause a malfunction of medical instruments.
If you are a pacemaker or other medical device, consult your physi-
cian or the manufacturer of your medical device before using the
wireless LAN function.
Do not place heavy or unstable objects on the player.
Disconnect the AC power cord and all other cables from the player
when you move the player.
Power
Disconnect the player from the wall outlet if you are not going to use
the player for a long time. To disconnect the AC power cord, grasp
the plug itself; never pull the cord.
Observe following points to prevent the AC power cord being dam-
aged, Do not use the AC power cord if it is damaged, as doing so
may result in an electric shock or fire.
- Do not pinch the AC power cord between the player and wall, shelf,
etc.
- Do not put anything heavy on the AC power cord or pull on the AC
power cord itself.
Precautions
14
Adjusting the volume
Use caution when adjusting the volume if there is no audio input or the
input is at a low level to prevent damage to your ears or the speakers
when the audio input level is high.
Cleaning
Clean the cabinet, panel, and controls with a soft cloth. Do not use any type
of abrasive pad, scouring powder or solent such as alcohol or benzene.
Replacement parts
In the event the product undergoes repair, observe proper disposal or
recycling procedures.
HDMI connections
Improper handing may damage the HDMI jack and the connector.
Carefully align the HDMI jack on the rear of the player and the HDMI
connector by checking their shapes. Make sure the connector is not
upside down or titled.
Be sure to disconnect the HDMI cable when moving the player.
Hold the HDMI connector straight when connecting or disconnecting
the HDMI cable. Do not twist or force the HDMI connector into the
HDMI jack.
Precautions
15
Remote
1
3
10
11
2
4
5
6
7
8
9
12
Navigation Function
A D-Pad (directional
pad) with Up | Down |
Left | Right and OK is
found on both the front
and back side of the
remote control.
16
Remote
1. Getting Started-ON/STANDBY: Turns the player on or off.
2. ON/STANDBY(BD/EXT): Turns on or off the TV/AV receiver.
3. Hi-Media: Launch the Multi-Media player.
YouTube: Launch the YouTube application.
Web: Launch the web browser.
Discover: Browse TV and Movies on live TV.
NETFLIX: Launch the Netflix application.
Live TV: Displays the live TV.
4. Touch pad with mouse cursor and click.
5. Scroll vertically for web browser.
6. Opens the home screen.
7. Displays special options associated with each feature.
8. Returns to the previous display, or exits the application.
9. Selects the next/previous channel.
Available only when the player is connected to a set top
box.
10. Turns the volume up or down
11. Displays the TV program guide.
12. Multi-Media control functions for playing videos, music or
pictures.
17
Using the QWERTY key board:
Type your query in
the Quick Search
Box, and the player
will suggest content
from various media
sources.
GUIDE and TV are available only when the player is connected to a
Set Top Box.
DVR is available only when the player is connected to a Set Top
Box with the DVR function.
Displays the
DVR(Digital
Video Record-
er) menu.
Displays
Live TV.
NOTES
Functions keys
printed in orange are
accessed by press-
ing the 'Fn' (Function)
button.
Remote
18
Remote
Green LED indicator
The LED on the remote control will blink with each key press
and while the touchpad is in use.
In pairing mode, the LED will light continuously for ~60-sec-
onds.
When pairing is complete, the LED will flash three times.
The LED light will blink continuously when the battery is low.
Sleep ModeTo conserve battery life, the remote control will
automatically go into sleep mode thirty seconds after the last
key press. Any movement or key press will immediately wake
up the remote.
19
Pairing the Remote
After connecting the Pulse to your TV and turning on the power,
press and hold the red color “A” and “OK” remote control keys simul-
taneously for 3 seconds. When the green LED lights, release the
keys and wait for the Pulse to pair with the remote. The green LED
on the remote control will ash three times when the pairing is suc-
cessfully completed.
If the remote failed to automatically pair with the Pulse, you can
manually pair the devices by following the steps below:
1) Press Home key
2) Use left (<) or right (>) arrow keys to highlight All Apps and press
OK key
3) Use down (\/), left (<) or right (>) arrow key to highlight Settings
and press OK key
4) Use up (/\) or down (\/) arrow keys to highlight Network and press
+
20
Pairing the Remote
OK key
5) Use up (/\) or down (\/) arrow keys to highlight Bluetooth settings
and press OK key
6) Use up (/\) or down (\/) arrow keys to highlight Hisense Pulse Re-
mote Control (if the remote had been previously paired) or Find
nearby devices (if the remote has not previously been paired) and
press OK key
The green LED must be on during Find nearby devices (follow in-
structions at the top of the page if the LED is not illuminated and
repeat step 7 above)
NOTES
21
You can access various content and applications from the Home
screen. The home screen contains Notications, All Apps, and short-
cuts to select applications and websites.
The Home screen can be customized to suit your preferences. You can
arrange the Home menu, add widgets to the Home screen, and change
the wall paper by pressing the MENU key.
Home Access Pulse features from here
22
Google Chrome
The Pulse uses Google ChromeTM as its web browser. You can access
all your favorite websites with the Google Chrome web browser.
Websites can be bookmarked, and you can access bookmarks from
the browser menu. You can also add a shortcut of a website to All Apps
by pressing the MENU key while using the Chrome browser.
Internet browser
press
select
or
or
23
All Apps
You can access various content and applications installed on your
Pulse from the All Apps list. You can launch any installed application
from here using either the touchpad or D-Pad to navigate and make
your selection.
Applications or bookmarks in the All Apps list can be uninstalled, hid-
den, or removed using the Menu Options.
select
Access installed applications
select
or
press
24
Google Play
select
App Store
Google PlayTM can provide you with additional favorite applications.
You can download applications and instantly use them on your Pulse.
Downloaded applications are stored in All Apps.
You can check the progress of downloads by checking in Notications.
select select
or
press
25
Hi-Media Play it. See it. Hear it. Control it.
You can play audio, video and image les stored on a USB device, us-
ing Twonky for Google TV.
You can select a device and change its settings.
select select
select select
or
press
26
Picture-in-Picture
PIP (Picture-in-Picture) is a feature that allows you to display the TV
screen in an inset window. For example, you can browse the internet
on the full screen, while watching a TV program in the inset window at
the same time.
Press and hold the PIP key to access the Picture-in-Picture settings
and controls.
NOTES
The image displayed in the PIP window is from the HDMI input on the
Pulse.
Multi-task while
watching TV
27
System Settings
You can change various settings for your player from the Settings
menu.
You can also access the Settings menu from the menu that appears
when the Home screen is displayed.
select select
Customizing your Pulse
28
Video Input
select OK
select Generic video source
NOTES
Please make sure you have connected the IR Blaster cable to the
Pulse.
Enter the Settings menu and then select Video Input.
Use the generic video source to view video from devices that are not
controllable by Google TV.
29
Video Input
select NEXT
select Add device manually
select the type of the device connected
If you want to control this video source by your Pulse controller,
follow the steps below:
30
Video Input
select NEXT
Select Send Power to check if the
controller could control the device
connected
Input the manufacturer, Model
Number and Command Set
31
Input/output jacks
HDMI IN HDMI 19-pin standard connector
Video: 480i, 480p, 720p, 1080i, 1080p
(24fps & 60fps)
Audio: Linear PCM , Dolby Digital
HDMI OUT HDMI 19-pin standard connector
Video: 720p, 1080i, 1080p (24fps &
60fps)
Audio: Linear PCM , Dolby Digital
LAN 100BASE - TX Terminal
USB USB jack type A
IR Blaster Mini jack (for connecting the IR blaster
cable)
Power and others
Power requirements 120V AC, 60Hz
Power consumption 15W
Dimensions 114x114x38.5 (mm)
Weight 0.32kg
Operating temperature 5C - 35C (41F - 95F)
Operating humidity 25% - 80%
Specications
32
Specications
Wireless
Wireless LAN standard IEEE 802.11b/g/n
Frequency range 2.4 GHz band: Channel 1-11
Modulation DS-SS Modem and OFDM Modem
Accessories
Supplied accessories Remote control -1
Size AAA batteries - 3
Power Adapter - 1
Quick Setup Guide - 1
Getting Started - 1
IR Blaster cable -1
33
Additional Information
About wireless LAN security
Since communication via the wireless LAN function is established by
radio waves, the wireless signal may be susceptible to interception. To
protect wireless communication, this player supports various security
functions. Be sure to correctly congure the security settings in accord-
ance with your network environment.
No Security
With an unsecured (open) home network, anyone can intercept wire-
less communication or intrude into your wireless network, even without
any sophisticated tools. Keep in mind that there is a risk of unauthor-
ized access or interception of data.
WEP
WEP applies securtiy to communications to prevent outsiders from
intercepting communications or intruding into your wireless network.
WEP is a legacy security technology that enables older devices, which
do not support TKIP/AES, to be connected.
WPA-PSK(TKIP), WPA2-PSK(TKIP)
TKIP is a security technology developed to correct for the deciencies
34
Additional Information
of WEP. TKIP assures a higher security level than WEP.
WPA-PSK(AES, WPA2-PSK(AES)
AES is a security technology that uses an advanced security method
that is distinct from WEP and TKIP.
AES assures a higher security level than WEP or TKIP.
印刷条码
Imported by Hisense USA Corp.
7310 McGinnis Ferry Rd, Suwanee, GA 30024, USA
1-678-318-9060
http://www.hisense-usa.com
Email: info@hisense-usa.com
All rights reserved. Hisense is a trademark of Hi-
sense Electronic registered in some countries. All
other products and brand names are trademarks of
their respective owners.

Navigation menu
