Hitachi Owners Guide 49E30 LR

49E30/49E301/49E30A

49” Class (48.50” Diag.)

Serial No.

Model:

Thank you for purchasing this Hitachi product.

Please read these instructions carefully.

For additional assistance please call Toll Free 800.HITACHI (800.448.2244)

or visit our website at www.hitachi.us/tv.

Keep this Owner’s Guide for future reference.

Record the model name and serial number of your LCD Television for future reference.

This information is located on the back of the television.

CONGRATULATIONS

OWNER’S GUIDE

OG_49E30A_062317

LED LCD HDTV

EN 2

The lightning ash with arrowhead symbol, within an

equilateral triangle is intended to alert the user to the

presence of uninsulated dangerous voltage within the

product's enclosure that may be of sucient magnitude to

constitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER

(OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY FROM THIS PRODUCT AT

ALL TIMES.

CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS TELEVISION’S AC PLUG WITH AN EXTENSION CORD,

RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE

EXPOSURE

LEAD NOTICE

This product contains lead. Dispose of this product in accordance with applicable environmental laws. For product recycling and disposal

information, contact your local government agency or www.eRecycle.org (in California), the Electronic Industries Alliance at www.

ecyclingcentral.com (in the U.S.) or the Electronic Product Stewardship Canada at www.epsc.ca (in Canada).

This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a

safety connection to electrical earth.

Location of the required Marking

The rating sheet and the safety caution are on

the rear of the unit.

WARNING:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modications not expressly approved by the party responsible for compliance with the FCC Rules could void

the user’s authority to operate this equipment.

This Television receiver will display television closed captioning, ( or ), and provides text-to-speech audio, in accordance with

FCC rules.

This The examples used throughout this manual are based on the 49E30 model. 49E301 have identical features except where noted

where noted in this manual.

Declaration of Conformity

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference and (2)This device must accept any interference received, including interference that

may cause undesired operation.

For questions regarding this declaration, contact:

2420 Fenton Street, Suite 200

Chula Vista, CA 91914-3556

ATTN: Customer Relations

Hitachi America, Ltd.

3 EN

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers)

that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

11) Only use attachments/accessories specied by the manufacturer.

12) Use only with cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen

into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been

dropped.

15) Apparatus should not be exposed to dripping or splashing, and objects lled with liquids, such as vases, should not

be placed on the apparatus.

16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power

circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care

should be taken to keep from touching such power lines or circuits, as contact with them might be fatal.

17) Do not overload wall outlets and extension cords, as this can result in a risk of re or electric shock.

18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts

that could result in re or electric shock. Never spill or spray any type of liquid into the unit.

19) If an outside antenna or cable system is connected to the unit, be sure the

antenna or cable system is grounded to provide some protection against

voltage surges and built-up static charges, Section 810 of the National

Electrical Code, ANSI/NFPA 70, provides information with respect to

proper grounding of the mast and supporting structure, grounding of the

lead-in wire to an antenna discharge unit, size of grounding conductors,

location of antenna discharge unit, connection to grounding electrodes, and

requirements for the grounding electrode.

20) When replacement parts are required, be sure the service technician uses replacement parts specied by the

manufacturer or those that have the same characteristics as the original part.

Unauthorized substitutions may result in re, electric shock or other hazards.

21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to

determine that the unit is in proper operating condition.

22) When you connect the product to other equipment, turn o the power and unplug all of the equipment from the wall

outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other

equipment carefully and follow the instructions when making any connections.

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

ANTENNA

LEAD IN WIRE

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

GROUND

CLAMP

ELECTRIC SERVICE

EQUIPMENT

NEC-NATIONAL

ELECTRICAL CODE

S2898A

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

IMPORTANT SAFETY INSTRUCTIONS

EN 4

23) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker overheating

and re.

24) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides

guidelines for proper grounding and, in particular, species that the cable ground shall be connected to the grounding

system of the building, as close to the point of cable entry as practical.

25) The mains plug is used as the disconnect and shall remain readily operable.

Power source

This television is designed to operate on 120 volts 60 Hz, AC current. Insert the power cord into a 120 volts 60 Hz outlet.

To prevent electric shock, do not use the television’s (AC) plug with an extension cord, receptacle, or other outlet unless the blades

can be fully inserted to prevent blade exposure.

Never connect the television to direct current or anything other than the specied volatage.

Warning

To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.

Caution

Never remove the back cover of the television as this can expose you to very high voltages and other hazards. If the television does

not operate properly, unplug the television and call your authorized dealer or service center.

Adjust only those controls that are covered in the instructions, as improper changes or modications not expressly approved by

Hitachi could void the user’s warranty.

IMPORTANT SAFETY INSTRUCTIONS (continued)

CONDENSATION

Moisture will form in the operating section of the unit if the unit is brought from cool surroundings into a warm room or if the temperature

of the room rises suddenly. When this happens, unit's performance will be impaired. To prevent this, let the unit stand in its new

surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually.

Condensation may also form during the summer if the unit is exposed to the breeze from an air conditioner. In such cases, change the

location of the unit.

HOW TO HANDLE THE LCD PANEL

• Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.

• If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inammation.

If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your eyes or touches your

skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

Possible Adverse Eects on LCD Panel: If a xed (non-moving) pattern remains on the LCD Panel for long periods of time, the image

can become permanently engrained in the LCD Panel and cause subtle but permanent ghost images. This type of damage is NOT

COVERED BY YOUR WARRANTY. Never leave your LCD Panel on for long periods of time while it is displaying the following formats or

images:

• Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.

• Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on a normal (4:3) display (black

bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen (16:9) display (black bars on left and right

sides of screen).

The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any responsibility for

these symptoms.

• LCD Panels are manufactured using an extremely high level of precision technology, however sometimes parts of the screen may be

missing picture elements or have luminous spots.

This is not a sign of a malfunction.

• Do not install the LCD Panel near electronic equipment that produces electromagnetic waves. Some equipment placed too near this

unit may cause interference.

• Eect on infrared devices – There may be interference while using infrared devices such as infrared cordless headphones.

WARNING: Never place a television set in an unstable location. A television set may fall and cause, serious personal injury or death.

Many injuries, particularly to children, can be avoided by taking simple precautions such as:

- Use cabinets or stands recommended by the manufacturer of the television set.

- Only use furniture that can safely support the television set.

- Ensure the television set is not overhanging the edge of the supporting furniture.

- Do not place the television set on tall furniture (for example, cupboards of bookcases) without anchoring both the furniture

and the television set to a suitable support.

- Do not place the television set on cloth or other materials that may be located between the television set and supporting

furniture.

- Educete children about the dangers of climbing on furniture to reach the television set or its controls.

If your existing television set is being retained and relocated, observe the above precautions.

5 EN

CHILD SAFETY NOTICE

EN 6

The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block

ventilation holes, or set up near radiators. Do not place in direct sunlight. When placing on a shelf leave 4 inches (10 cm) free space

around the entire unit.

Notes when mounting the TV on a wall

If the unit is to be mounted on the wall, contact the retailer where you purchased the TV for advice, and have the equipment professionally

installed. Incomplete or improper installation may cause injury to you, and/or damage to the TV.

The screws M6 thread type should be used. The insertion length must be within 10-12 mm.

If the insertion length is less than 10 mm the weight can not be maintained.

If the insertion length is more than 12 mm a space is created between the Wall Mount Bracket and the Television.

(Insertion Length) = (Screw Length) - (Washers Thickness) - (Mounting Bracket Thickness)

Securing to a Wall

1 Use metallic wire, screw and clamp (not provided) on the rear of the TV as shown below.

2 Keep the TV 4 inches away from the wall, except when mounted using the wall mount bracket, and secure to the wall as shown below:

Wire

Clamp

Screw

Wire

4 inches

NOTICE FOR TV CABINET

If the unit is placed on a cabinet smaller than the length of the unit, it could result in instability and the unit may tumble over, making a risk

of personal, possibly fatal injury. Also, this would seriously damage the product. Accordingly, Hitachi accepts no responsibility or liability

for any injuries or property damage resulting from the improper installation.

NO !!YES !!

SAFETY PRECAUTIONS

4 inches

Y(VIDEO)

4 inches

Y(VIDEO)

4 inches

Y(VIDEO)

7 EN

How to attach the stand

NOTE:

• Assure the AC cord is not connected to an AC outlet.

• Before beginning this process, make sure that you have a clean, safe, and cushioned space to work at to avoid any damage to the

unit.

• Do not touch or press the LCD screen, the glass might break under pressure.

1 Carefully place the TV screen face-down on a clean, cushioned surface.

2 Insert and secure the stands (R and L) with 2 screws (supplied) each side as shown in Figure 1.

• Be sure to follow the above instructions. Insucient tightening or incorrect installation of the stand will not support your TV correctly,

and could result in damage or injury from tip-over.

Figure 1

Stands

L

R

Screws

How to remove the stand

When you transport this product, remove the stand and pack it at against the back of the unit in the carton. To remove the stand,

perform the above steps in reverse order.

When you mount the TV on the wall, remove both stands (R and L).

To disconnect the stand remove the screws from the bottom of TV.

Stands

L

R

EN 8

Contents

Chapter 1: Introduction

Precautions ........................................................................................................................................................................... 2

IMPORTANT SAFETY INSTRUCTIONS ...............................................................................................................................3

CHILD SAFETY NOTICE ...................................................................................................................................................... 5

SAFETY PRECAUTIONS .....................................................................................................................................................6

How to attach the stand ....................................................................................................................................................... 7

How to remove the stand .....................................................................................................................................................7

Location of controls ............................................................................................................................................................... 9

Remote Control Functions .................................................................................................................................................. 10

Features .............................................................................................................................................................................. 11

Battery Precautions ............................................................................................................................................................ 12

Antenna connections ..........................................................................................................................................................13

Cable TV connections ......................................................................................................................................................... 13

Chapter 2: TV Operation

Starting setup .....................................................................................................................................................................14

TV operation ....................................................................................................................................................................... 14

Quick guide for menu operation .......................................................................................................................................... 15

Convenience functions ....................................................................................................................................................... 16

Channels setup ................................................................................................................................................................... 19

Labeling channels ............................................................................................................................................................... 20

Setting the Parental Control ................................................................................................................................................ 20

Closed Caption ................................................................................................................................................................... 22

CC options .......................................................................................................................................................................... 23

Aspect Switching ................................................................................................................................................................ 23

JPEG Viewer .......................................................................................................................................................................24

Chapter 3: Addition Information

Reception disturbances ...................................................................................................................................................... 25

Troubleshooting .................................................................................................................................................................. 26

Specications ..................................................................................................................................................................... 27

LIMITED WARRANTY ........................................................................................................................................................28

9 EN

Chapter 1 Introduction

TV Control Keys

The TV control keys are multi-function buttons that help navigate or operate the TV without a remote control.

1. / MENU button

A. Press to power ON the TV from Stand by mode.

B. When the TV is ON:

1. Press to display the control menu OSD (On-screen Display).

2. Press to select OK.

3. Press and hold for more than 2 seconds to set the TV to standby.

2. CH.+ / CH.- buttons

A. Press to change the channel.

B. Press to navigate up / down while in the OSD.

3. VOL.+ / VOL.- buttons

A. Press to change the volume level.

B. Press to navigate right / left while in the OSD.

CH.

-

CH.+

EN 10

Remote control

4



Press to turn the TV’s power on/o.

INPUT Calls the input source selection menu.

(Numeric buttons) Use to enter channel numbers.

Use to enter a digital channel with a sub-channel. Enter the main

channel, then press dash ( ), enter the sub-channel, and then

press OK to conrm your entry.

Press to display the electric program guide.

Press to call the main menu OSD or press to return to the previous

menu.

Press to exit the On-Screen menu.

(Cursor Up/Down/Left/Right buttons) Use to navigate and select

menu functions.

Press to conrm or select functions for the On-Screen menu.

Press to call the ASPECT selection OSD.

Repeatedly press to set the sleep timer from 5 to 240 minuets. To

cancel the sleep timer, press SLEEP until “O” appears.

Press to call the Picture Mode on-screen display menu.

RETURN Return to the previous channel in TV mode.

(Volume UP/DOWN) Increase or decrease the TV’s volume.

Press to display information about the TV status.

MUTE (MUTE) Reduces the TV’s volumes to its minimum level. Press

again to restore the volume.

Press to change the channel of the TV.

Press to access the Favorite Channel list.

Press to go to the Multimedia page.

Press to change the audio language.

C.C. Press to set Closed Caption to “CC O”, “CC On Mute” or “CC On”.

(Previous) Press to select the previous chapter

(Play/Pause) Press to start, pause or resume viewing.

(Stop) Press to stop viewing.

(Next) Press to select the next chapter.

11 EN

Features

HDTV

Unique space saving design LED LCD HDTV.

Picture Performance

• Long Life LED Backlight

Convenience

• USB Input (JPEG Photo Viewer, Software Updates)

• Sleep Timer (5-240 min)

Audio Performance

• Dolby® Digital/MTS Stereo/SAP

* The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of

HDMI Licensing LLC in the United States and other countries.

* Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby

Laboratories.

HDMI 1/2/3

AIR/CABLE

OPTICAL

LINE OUT

USB

This input can be used to connect a USB device.

HDMI1 /HDMI2/HDMI3 (ARC)

The HDMI inputs receives digital audio and video from an HDMI device.

AV (VIDEO) IN

This input is used to connect a range of equipment such as DVD players, or

satellite receivers to the AV input. To use the AV input connect the device’s

video output to the TV’s Video input.

The AUDIO IN (L & R) input use RCA audio cables to connect the audio output

for the AV input to the TV.

LINE OUT (Fixed)

Use a 3.5mm stereo to RCA audio cable to connect your TV to a compatible

audio receiver.

DIGITAL AUDIO OUT: OPTICAL

This output can be used to connect a compatible digital audio receiver.

AIR/CABLE IN

This input is used to connect to an external antenna (AIR) or to a cable

(CABLE) output.

Inputs / Outputs

EN 12

HOW TO INSTALL BATTERIES

1. Open the battery compartment cover.

2. Install two “AAA” batteries (supplied).

3. Replace the battery compartment cover.

BATTERY PRECAUTIONS

These precautions should be followed when using batteries.

• Use only the size and type of batteries specied.

• Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment. Reversed batteries may

cause damage to the device.

• Do not mix dierent types of batteries together (e.g. Alkaline, Carbon-zinc or Rechargeable) or old batteries with fresh ones.

• If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.

• Do not try to recharge batteries not intended to be recharged; they can overheat and rupture. (Follow battery manufacturer’s

directions.)

• Please use caution when inserting batteries to avoid battery damage. If the spring terminal in the remote control remains in contact

with a side of a damaged battery it can cause a short circuit. Never use damaged batteries as they can become very hot and are

dangerous.

Before using the remote control, batteries must rst be installed.

Use two “AAA” size batteries. The batteries may last approximately one year depending on how much the remote control is used. For best

performance, it is recommended that batteries should be replaced on a yearly basis or when the remote operation becomes erratic. Do

not mix old and new batteries or batteries of dierent types.

WARNING: The batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, re or the like.

: Attention should be drawn to environmental aspects of battery disposal. Dispose of the batteries in accordance with local

environmental laws.

13 EN

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you

are using a Cable TV service, see Cable TV connections.

Combination VHF/UHF Antenna (Single 75 ohm cable)

Connect the 75 ohm cable from the combination VHF/UHF antenna to the Antenna

Jack.

75 ohm

Coaxial

Cable

Antenna

Jack

Cable TV connections

For basic Cable TV service not requiring a Converter/Descrambler box, connect the

75 ohm Coaxial Cable directly to the Antenna Jack on the back of the TV.

For subscribers to scrambled Cable TV service

If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the incoming 75 ohm Coaxial

Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack of the Converter/Descrambler

box to the Antenna Jack on the TV. Follow the connections shown below. Set the TV to the output channel of the Converter/Descrambler

box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.

For subscribers to unscrambled Cable TV service with scrambled premium channels

If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require the use of a Converter/

Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from the Cable TV company or an electronics

supply store). Follow the connections shown below. With the switch in the “B” position, you can directly tune any non-scrambled channels

on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and

use the Converter/Descrambler box to tune scrambled channels.

This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some

cable companies oer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal

viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

For subscribers to basic Cable TV service

Incoming 75 ohm Cable TV Cable 75 ohm Cable to TV

Antenna

Jack

Converter/

Descrambler

Splitter B

A

Incoming

75 ohm

Cable TV

Cable A/B Switch 75 ohm Cable to TV

Converter/

Descrambler Antenna

Jack

75 ohm

Coaxial Cable

Antenna

Jack

75 ohm

Coaxial Cable

Antenna

Jack

75 ohm

Coaxial Cable

Antenna

Jack

EN 14

Starting setup

The Setup Wizard appears the rst time you turn on the

TV, and assists you to specify the Air/Cable setting, and

program your channels automatically.

IMPORTANT: Make sure that the antenna or cable TV system

connection is made.

1To turn on the TV, press . It may take approx. 10 seconds for

a picture to appear on screen. The Initial Setup Wizard begins.

2

3Select your “TV Mode” by pressing ◀ or ▶ to select “Home”

or “Store”.

NOTE:

Home mode will remember customized user settings in TV.

Store mode is intended for in-store display and resets user

settings each time TV is turned o.

4Press ▶ or OK to go to the next step.

5Press ◀ or ▶ to select your menu language, then press ▼

or OK.

Press ▶ or OK to go to the next step.

6Press ◀ or ▶ to select your time zone, then press ▼ or OK.

• In the rare event that you live within broadcast range

of two stations in two dierent time zones, the TV may

recognize the wrong station for the auto clock set.

7Press ◀ or ▶ to select daylight saving time on or o, then

press ▼ or OK.

8Press ◀ or ▶ to your desired time format, then press ▼ or

OK.

9Press ▶ or OK to go to the next step.

10 Press ◀ or ▶ to select the signal type that you using, then

press ▼ or OK.

11 Press ▶ or OK to go to the next step.

12 Auto Channel Scan will begin. After the scan is completed,

a TV channel appears on the screen.

• Depending on the reception condition, it may take up to

30 minutes to complete scanning channels. Please allow

the process to complete without interruption.

NOTE:

• If you press EXIT during the “Auto Channel Scan” process,

the Auto Channel Scan will stop and the TV will change to the

normal view.

When you make a menu selection, your changes

occur immediately. You do not have to press EXIT to see your

changes.

TV operation

1To turn on the TV, press . It may take approx.10 seconds for a

picture to appear on screen.

2Adjust the volume level by pressing VOL (VOLUME) + or – .

The volume level will be indicated on the screen by a volume

bar.

If the volume increases, the number of bars also increases.

If the volume decreases, the number of bars also decreases.

3Set the Source option to the appropriate selection (see “Air/

Cable selection” on page 19).

4Press the Direct Channel Selection Buttons (0-9, –) to

select the channel.

TO SELECT ANALOG CHANNELS

1-9: Press 1-9 as needed. Example, to select channel 2,

press 2, then press OK.

10-99: Press the 2 digits in order. Example, to select

channel 12, press 1, 2, then press OK.

100-135: Press the 3 digits in order. Example, to select

channel 120, press 1, 2, 0, then press OK.

TO SELECT DIGITAL CHANNELS

Press the rst digits, then press the – button followed by the

remaining number.

Example: To select channel 15-1, press 1, 5, –, 1, then press

OK.

• I

f a channel is selected with only audio content, “Audio Only”

will be displayed on the screen.

• If a channel is selected with a weak digital signal, “No Signal”

will be displayed on the screen.

• The same program may be available on either an analog

channel or a digital channel. You may choose to watch

either format.

VHF/UHF/CABLE CHANNELS

Air Cable

VHF

2-13

VHF

2-13

UHF

14-69

STD/HRC/IRC

14-36 (A) (W)

37-59 (AA) (WW)

60-85 (AAA) (ZZZ)

86-94 (86) (94)

95-99 (A-5) (A-1)

100-135 (100) (135)

01 (4A)

NOTE:

• If a channel with no broadcast is selected, the sound will

automatically be muted.

• It may take a few seconds for a digital channel picture to appear

on screen after being selected.

• To direct tune to a digital channel that is not stored in the

channel list enter the rst digits followed by - and press OK. For

example if you want to select channel 15-2, press

1, 5, - then press OK.

To select the video input source

To view a signal from another device connected to your TV, such

as a VCR player, press INPUT, then press ▲ or ▼ to select the

desired input, then press OK.

CH /

Press and release CH / . The TV automatically stops at the

next channel.

For proper operation, before selecting channels, they should be

set into the memory. See “Channels setup” on page 19.

Chapter 2 TV Operation

15 EN

Quick guide for menu

operation

Example: Select Menu Language.

1Press INPUT to select TV mode.

2Press MENU. The TV menu screen will appear.

3Press ◀ or ▶ to select “Setup”, then press ▼.

4Press ▲ or ▼ to select “Menu Language”, then press ◀ or ▶

to select the desired language.

5Press EXIT to return to the normal screen.

NOTE:

• On the following pages, the menu can be called in the same way

described above, by pressing the MENU button.

• If no buttons are pressed for more than about 15 seconds

(depending on your setting), the TV will return to normal viewing

automatically.

• During TV or external input mode, if there is no signal reception,

the TV will change to standby after approx. 15 minutes.

INFO

Press INFO to display the current information on the screen.

When the TV receives a digital signal, the digital information will

appear.

• Channel number • DTV Signal condition

• Channel label (if preset)

• Broadcast program name

• Parental Control

• Close Caption Display

• Program guide • Current date and time

• Resolution • Audio language

Press INFO again to clear the display.

MUTE

Press MUTE to switch o the sound. The TV’s sound will be

silenced and MUTE icon will appear on the screen. The sound can

be switched back on by pressing this button again or by pressing

the VOL (VOLUME ) + or – buttons.

SLEEP

To set the TV to turn o automatically after a preset amount of

time, press SLEEP on the remote control. The clock will change

for each press of the SLEEP button (O, 5 min, 10 min, ..., 240

min).

To conrm the sleep timer setting, press SLEEP and the remaining

time will be displayed for a few seconds. To cancel the sleep timer,

press SLEEP repeatedly.

EN 16

Convenience functions

You can change the default settings by pressing the MENU button on your remote, then select the one of the icons at the top of the

menu - follow the On-Screen prompts to set your preferences.

Icon Selected Items Setup hint

Video

Picture Mode

Standard Standard picture quality

Dynamic Bright and dynamic picture

Movie Soft edge picture setting

ECO Setting optimized to save energy.

Custom Your personal preferences

Brightness You can adjust the picture quality to your preference.

• Available only when you selected “Custom”.

Contrast

Color

Tint

Sharpness

Color Temperature Cool (Bluish) / Standard (Neutral) / Warm (Reddish)

Advanced Settings

Aspect Ratio See page 23.

Noise Reduction Set the level of decreasing noise included in the video signal.

O/Low/Middle / High

Dynamic contrast Use this feature to change the black level automatically according to the

brightness of an image. The black level will become dark in a dark scene.

O / On

HDMI Mode Select Video mode for general use (i.e. with a STB, BD Player, DVD Player, or

Game Console). Select Graphic mode for use with a PC.

Auto/Video/Graphic

17 EN

Icon Selected Items Setup hint

Audio

Sound Mode

Standard / Music / Movie

/ Sports/ Custom

You can choose a basic sound mode to your preference.

Treble This function controls the high frequency audio to the speakers.

• Available only when you selected “Custom”.

Bass This function controls the low frequency audio to the speakers.

• Available only when you selected “Custom”.

Balance Adjust the left and right sound channel volume.

MTS The multi-channel TV sound (MTS) feature provides high-delity stereo sound. MTS

also can transmit a second audio program (SAP) containing a second language or

other audio information. This item is valid only when the analog broadcast.

Stereo / SAP / Mono

Audio Language When two or more audio languages are included in a digital signal, you can select

one of the audio languages. (This function is available only for digital broadcasts.)

English / French /

Spanish

Digital Output Select the format for your digital audio output If you have connected an amplier /

receiver to the digital audio jack on your TV.

Raw / PCM

Surround Sound

The dynamic presence and sound created oers a thoroughly

enjoyable listening

experience.

O / On

Perfect Volume Volume level is adjusted automatically to lower volume of loud scenes and to raise

volume of quieter scenes.

O / On

Time

Sleep Timer Sleep Timer switches the TV to standby after a dened period of time.

To cancel the Sleep Timer, set to “O”.

O / 5 / 10 / 15 / 30 / 60 /

90 / 120 / 180 / 240 min

Time Zone Select your local time zone for auto clock feature.

You can select Newfoundland, Atlantic, Eastern, Central, Mountain, Pacic, Alaska

and Hawaii.

Daylight Savings If you want to activate Daylight Saving Time, select “On”.

O / On

Time Format Select the time format.

12-hour / 24-hour

Auto Clock The Auto Clock function will automatically set the built-in clock (Year, Month, Day and

Time) when the TV is connected to an antenna or cable TV system and it is turned o.

As the TV searches for a receivable station in your area and it receives a broadcast

signal for Auto Clock, the Auto Clock needs several minutes to set itself.

On/O

Clock Use the ▲/▼/◀/▶ buttons to set the clock.

• Available only when you selected “Time Mode” to “On”.

Convenience functions

EN 18

Icon Selected Items Setup hint

Setup

Menu Language

English / Español You can choose from two dierent languages English and Español (Spanish) for the

OSD (on-screen displays).

Select the language you prefer rst, then proceed with the other menu options.

OSD Timeout

5 / 15 / 30 / 45 / 60 Sec. You can set the display time of OSD Menu.

Closed Caption See page 22.

Input Label The Input Label feature allows you to label each input source for your TV.

You can select a label from a default value or input by yourself

with ▲/▼ (alphabet

select) / ◀/▶ (select character / position).

Default / Antenna / Cable /

Satellite / DTV / DVD / Blu-ray /

HD-DVD / XBOX / Wii / PS3 /

Game / Computer / VCR / DV /

Custom (10 characters)

Other Settings

Audio Only You can turn o the picture on your TV and listen to the programs audio only.

To exit audio only mode, press any buttons (except VOL (VOLUME) +/-, MUTE and

POWER) on your remote control or unit.

O / On

TV Location Select location of TV, “Home” or “Store”.

Home / Store

About Your TV Display customer support information.

Reset Select “Yes”, then press SELECT. Restore Video, Audio (except “Audio Language”),

Time (Sleep Timer, Time Format and Auto Sleep only) and Setup (except “Menu

Language”) settings to the default factory settings.

No / Yes

Setup Wizard See page 14.

HDMI - CEC

CEC Enable Select “On” to enable CEC features.

Device Auto Power O When the user turns o the TV, all active CEC enabled devices on the HDMI input

will go to Standby.

TV Auto Power On Pushing the “Play” button on the CEC enabled device will command the device to

play , turn the TV on, and the HDMI input, that the device is connected to, will become

the active input device for the TV.

ARC To enable the audio through an AV receiver using HDMI (ARC)

Device Lists Display devices that are connected to TV.

Connect To make a connection to a device shown on the device list.

Root Menu To access the device menu.

Voice Guidance

Voice Guidance Select “On” to enable Voice Guidance features.

Volume Select your preferred volume. (Low/Middle/High)

Speed Select your preferred speed. (Low/Middle/High)

Pitch Select your preferred pitch. (Low/Middle/High)

Video Description Video Description enables audio-narrated descriptions of key visual elements of the

program. Turn “On” to enable this feature.

Note: This feature is only available for the TV input and is only available on select

programs.

Lock See page 20.

Channels See page 19. (Only accessible in theTV input.)

Convenience functions

19 EN

Channels setup

This TV is equipped with a Channel List feature which allows

channels to skip up or down to the next channel set into the

Channel List, skipping over unwanted channels.

Before selecting channels, they must be scanned into the

TV’s Channel List.

Air/Cable selection

1Select “Channels” ⇒ “Source”.

2Press ◀ or ▶ to select “Air” or “Cable”.

Air - VHF/UHF channels

Cable - CABLE TV channels

NOTE:

• It may take a few seconds for a digital channel picture to appear

on screen after being selected.

Auto Channel Scan

1Select “Channels” ⇒ “

Auto Channel Scan

”, then press ▶ or

OK.

2In the conrmation window, press ▶ to select “Yes”, then

press OK. The TV will begin scanning all the channels

available in your area.

• It may take from 15 minutes to 30 minutes to complete

channel scan.

• Depending on the reception condition the progress bar may

not advance for several minutes, please be patient.

• If you press MENU while scanning, the channel scan will

stop.

NOTE:

• If you are unsure of the digital channels available in your area,

you may visit www.antennaweb.org to receive a list based on your

address or zip code. If you require further assistance you may call

our toll-free customer service line at 800.HITACHI (800.448.2244)

(USA/CANADA).

• New channels may be added to your area periodically,

it is

recommended to perform the “Auto Channel Scan”

procedure

regularly.

3The new channels will be added into the channel list.

Channel Manager

You can select the channel that you want to skip.

1Select “Channels” ⇒ “View/Skip”, then press ▶ or OK.

2Press ▲ or ▼ to select the channel that you want to skip.

3Press OK to assign 3 mark for unwanted channel.

4Repeat steps 2 - 3 for other channels you want to

skip

.

No

EN 20

Labeling channels

Channel labels appear with the channel number display

each time you turn on the TV, select a channel, or press

DISPLAY.

You can choose any 7 characters to identify a channel.

To create channel labels

1Select “Channels” ⇒ “Channel Label”.

2Press ◀ or ▶ to select a channel you want to label, then press

▼ to select “Channel Label”. Then press ▶ or OK.

3Press ▲ or ▼ repeatedly until the character you want appears

in the rst space.

If the character which you desire appears, press ▶.

You can move back or forward by pressing the ◀ or ▶.

Repeat this step to enter the rest of the characters, then press

OK

.

4Repeat steps 2-3 for other channels. You can assign a label to

each channel.

5When you nish inputting the label name, press EXIT to return

to

normal viewing.

NOTE:

• The channel labels will be reset after “Auto Channel Scan” on

page 19.

Setting the Parental Control

An age limitation can be set to restrict children from viewing

or hearing violent scenes or pictures that you may choose to

exclude. The restriction applies to “TV”, “Movie”, “Canada English

Rating” and “Canada French Rating” if this data is transmitted.

You may set this restriction separately. To use the Parental

Control function, you must register a password.

To enter a password

1Select “Lock”, then press ▼.

2Press 0000 using Direct Channel Selection Buttons (0-9).

(This is default password.)

“ ” appears instead of the number.

NOTE:

• If you forget your password, use the factory password 7777, you

can then gain access to change your password if necessary.

• To avoid forgetting the password, write it down and keep in a

safe place.

How to enter the Parental Control menu

1Select “Lock” menu, then press ▼.

2Use Direct Channel Selection Buttons (0-9) to enter your

password.

To Lock the connected devices

1

In the Locks menu, press ▲ or ▼ to select “Parental Control”,

then press ◀ or ▶ to set to “On”.

2Press ▲ or ▼ to select “Input Block”, then press ▶ or OK.

3Press ▲ or ▼ to select which input will be blocked, then press

◀ or ▶ to select “Block”.

21 EN

To set the Parental Control

1In the Lock menu, press ▲ or ▼ to select “Parental Control”

then press ◀ or ▶ to set to “On”.

2Press ▲ or ▼ to select “US Rating”, then press ▶ or OK.

3Press ▲ or ▼ to select which rating will be used, then press

◀/▶ or OK. Each rating below will appear.

TV

You can set the rating using age level and genre.

Age:

T V-Y : All children

TV-Y7 : 7 years old and above

TV-G : General audience

TV-PG : Parental guidance

TV-14 : 14 years old and above

TV-MA : 17 years old and above

Genre:

FV : Fantasy Violence

D : Dialogue

L : Language

S : Sex

V : Violence

Press ▲/▼ to select the desired rating, then press SELECT.

Movie

O : None

G : All ages

PG : Parental guidance

PG-13 : Parental guidance

less than 13 years old

R : Under 17 years old parental guidance

suggested

NC-17 : 17 years old and above

X : Adult only

Press ◀/▶ to select the desired rating.

4

Press EXIT to return to normal viewing.

Parental Control function is activated now.

Canada English ratings

You can set the rating using age level.

O : Exempt

C : Programming intended for children under age 8

C8+ : Programming generally considered acceptable for

children 8 years and over to watch on their own

G : General Audience

PG : Parental Guidance

14+ : Programming contains themes or content which

may not be suitable for viewers under the age of 14

18+ : Adult

Canada French ratings

O : Exempt programming

G : General: All ages and children, contains minimal

direct violence, but may be integrated into the plot in

a humorous or unrealistic manner.

8ans+ : General but inadvisable for young children: May be

viewed by a wide public audience, but could contain

scenes disturbing to children under 8 who cannot

distinguish between imaginary and real situations.

Recommended for viewing with parent.

13ans+ : Over 13 years: Could contain scenes of frequent

violent scenes and therefore recommended for

viewing with parent.

16ans+ : Over 16 years: Could contain frequent violent scenes

and intense violence.

18ans+ : Over 18 years: Only for adult viewing. Could contain

frequent violent scenes and extreme violence.

4

Press EXIT to return to normal viewing.

Parental Control function is activated now.

NOTE:

• The Parental Control function is activated only on programs and

input sources that include a rating signal.

Canadian rating systems

1In the Lock menu, press ▲ or ▼ to select “Parental Control”

then press ◀ or ▶ to set to “On”.

2Press ▲ or ▼ to select “Canada Rating”, then press ▶ or OK.

3Press ▲ or ▼ to select “Canada English” or “Canada French”,

then press ◀ or ▶ to select the desired rating.

EN 22

To change the password

1In the Lock menu, press ▲ or ▼ to select “Change Password”,

then press ▶ or OK.

2Enter your old password using Direct Channel Selection

Buttons (0-9).

3Enter your new password using Direct Channel Selection

Buttons (0-9).

4Enter the new password again to conrm.

Your new password is now registered.

Downloading the additional Parental Control rating system

(Region 5)

As a supplement to the standard Parental Control rating system,

your television is able to download an additional rating system, if

such a system becomes available in the future.

To download the additional Parental Control rating system

(when available)

1In the Lock menu, press ▲ or ▼ to select “Parental Control”

then press ◀ or ▶ to set to “On”.

2Press ▲ or ▼ to select “Region 5”, then press ▶ or OK.

3If the TV is not storing the additional rating system, the TV

will begin downloading it, which may take some time to be

completed.

4Set your preferred content rating limits for the additional rating

system.

NOTE:

• The TV can download an additional rating system only when

receiving a digital signal that carries the Region 5 rating

information.

• When you download the additional rating system, it may take

some time for the download to occur.

• The Parental Control rating information and system are not

determined or controlled by the TV.

• The standard Parental Control rating system is available

whether your TV is receiving a digital signal or not, and will block

both analog and digital programs.

To set the restriction level using the standard Parental Control

rating system, select “US Rating” in step 2.

• The downloadable Parental Control rating system is an evolving

technology, and availability, content, and format may vary.

To clear the Region 5

1In the Lock menu, press ▲ or ▼ to select “ Parental Control”

then press ◀ or ▶ to set to “On”.

2Press ▲ or ▼ to select “Reset Region 5”, then press ▶ or OK.

The conrmation window will appear.

3Press ▶ to select “Yes”, then press OK.

Your Region 5 will clear.

Closed Caption

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display Closed

Captioned television programs. Closed Captioning will display text

on the screen for hearing impaired viewers.

Captions: This Closed Caption mode will display text on the

screen in English or another language. Generally, Closed

Captions in English are transmitted on CC1 and Closed Captions

in other languages are transmitted on CC2.

Text: The Text Closed Caption mode will usually ll 1/2 of the

screen with a programming schedule or other information.

1Select “Setup” ⇒ “Closed Caption”, then press ▶ or OK.

2Press ◀ or ▶ to set “CC Mode” to “CC On” or “CC On Mute”.

CC On: Captions will be displayed on the screen.

CC On Mute: Only when you press MUTE, captions will be

displayed.

CC O: Captions will not be displayed on the screen.

3Press ▲ or ▼ to select “Analog CC” or “Digital CC”.

When you select “Analog CC”, you can choose from CC1~4,

Text1~4.

When you select “Digital CC”, you can choose from

Service1~6 and O.

4Press ◀ or ▶ to select the desired Closed

Caption mode for

both Digital and Analog Captions.

NOTE:

• Depending on the broadcast signal, some Analog Captions

will function with a Digital broadcast signal. This prevents

two types of captions from overlapping.

NOTE:

• If text is not available in your viewing area, a black rectangle

may appear on-screen. If this happens, set the CC Setting to

“CC O”.

• When selecting Closed Captions, the captioning will appear

after approx. 10 seconds.

• Misspellings or unusual characters may occasionally appear

during Closed Captioning.

This is normal with Closed Captioning, especially with live

programs. This is because during live programs, captions are

also entered live. These transmissions do not allow time for

editing.

• When Captions are being displayed, on-screen displays, such

as volume may be seen but may interfere with Closed Captions.

• Some cable systems and copy protection systems may interfere

with the Closed Captioned signal.

• If using an indoor antenna or if TV reception is very poor, the

closed caption may not appear or may appear with strange

characters or misspelled words. In this case, adjust the antenna

for better reception or use an outdoor antenna.

23 EN

Aspect Switching

You can change the picture size being displayed — Wide,

Cinema, Normal and Point to Point.

Selecting the picture size

1Select “Video” ⇒ “

Advanced Settings” ⇒ “Aspect

”.

2

Press

◀ or ▶

to select the desired aspect ratio, as described

below.

NOTE:

• Selectable aspect ratios may vary depending on the input

source or broadcast signal.

• You can select the desired size of the picture being displayed by

pressing ZOOM +/- on the remote control.

Wide

Displays the picture at the maximum size.

Cinema (for letter box programs)

The entire picture is uniformly enlarged—it is stretched the same

amount both wider and taller (retains its original proportion).

The top and bottom edges of the picture may be hidden.

Normal

Displays the picture according to the incoming signal.

Point to Point (for Graphic Mode only)

Detects the resolution of the signal of the image and it will be

shown on the screen with same amount of pixels.

CC options

When you have selected “Custom” as the display method,

you can adjust the various setting listed below.

This feature is designed to customize Digital Caption only.

1Select “Setup” ⇒ “Closed Caption”, then press ▶ or OK.

2Press ◀ or ▶ to set “CC Mode” to “CC On” or “CC On Mute”.

3Select “Option”, then press ▶ or OK.

4Press ▲ or ▼ to select “Mode”, then press ▶ or OK.

5Press ◀ or ▶ to set the “Mode” Preset to “Custom”.

6Press ▲ or ▼ to select the desired item, then press ◀ or ▶ to

change the setting.

You can select from among the following items

and parameters.

Font: Style

Select display font style.

Font Size:

Select display font size.

Font Edge Style.

Select display font edge style.

Font Edge Color:

Select display font edge color.

FG Color:

Select foreground color.

BG Color:

Select background color.

FG Opacity:

Select foreground opacity level.

BG Opacity:

Select background opacity level.

NOTE:

• You cannot set both “FG Color” and “BG Color” as the same

color.

• You cannot set both “FG Opacity” and “BG Opacity”

to “Transparent”.

EN 24

Playback les

1

Press

OK

to select Photo.

2Press OK to select “C”.

3Select a folder or le using the ▲/▼/◀/▶buttons and then start

photo viewing with OK.

JPEG Viewer

You can enjoy viewing pictures from your USB storage

device.

1Connect the USB storage device into the USB Input terminal.

2

Press INPUT and press

▲ or ▼

to select “USB”, then press

OK

.

NOTE:

• Do not disconnect a USB storage device while it is being

accessed. Doing so can damage the device or the les stored

on the device. You can safely connect or disconnect the USB

storage device when the TV is not in USB mode.

• Back up all the data in the USB storage device in case if data

was lost due to unexpected accident. We do not assume any

liability for the losses by misuse or malfunction.

• Not all USB storage devices are compatible with this TV.

• The character that exceeds the display area is not displayed.

• Do not use a USB extension cable.

• Playable les are JPEG (.jpg/.jpeg).

USB Browser

File Selection

NOTE:

• The content will change in accordance with each

media setting screen.

25 EN

Reception disturbances

IGNITION NOISE:

Black spots or horizontal streaks may appear, picture may utter or drift. Usually caused by interference

from automobile ignition systems, neon lamps, electrical drills, and other electrical appliances.

GHOSTS:

Ghosts are caused by the television signal following two paths. One is the direct path and the other

is reected from tall buildings, hills or some other objects. Changing the direction or position of the

antenna may improve reception. Ghosting may also be caused by defects in the antenna system such

as unshielded leads or connecting several sets to the same antenna without using multiple antenna

couplers.

SNOW:

If your receiver is located in the fringe area of a television station where the signal is weak, your

picture may be marred by the appearance of small dots. When the signal is extremely weak, it may be

necessary to install a special antenna to improve the picture.

RADIO FREQUENCY INTERFERENCE:

The interference produces moving ripples or diagonal streaks, and in some cases, causes loss of

contrast in the picture.

• Keep the television away from Radio.

• Adjust Radio antennas in order for the television not to receive interference.

• The antenna cable of Radio should be kept away from the television.

• Use a coaxial cable for antenna.

• You can check if this television inuences Radio receivers by turning o all other equipment other

than the television. If you nd a problem receiving Radio when using the television, check the

instructions mentioned above.

BLOCK NOISE or FREEZE (DIGITAL INPUT):

Fuzzy blocks may appear in some area or the whole area of the screen. This is usually caused by

interference from automobile ignition systems, neon lamps, electrical drills, ghosting of the image and

lost or weak receiving signals.

NOTE:

• The TV set can generate sound distortion in external devices such as a radio. Please separate radio equipment from the TV set to a

considerable distance.

Chapter 3 Addition Information

EN 26

SYMPTOMS POSSIBLE SOLUTIONS

Digital

broadcasting

screen

problem.

• Check digital signal strength.

No CATV

reception.

• Check all Cable TV connections.

• Set Source menu option to the Cable mode.

• Station or Cable TV system problems, try

another station.

Horizontal

or diagonal

bars on

screen.

• Check antenna connections, adjust or re-

direct antenna.

• Check for sources of possible interference.

No reception

above

channel 13.

• Make sure the appropriate Source (Air or

Cable) has been selected.

• If using antenna, check UHF antenna

connections.

No Remote

operation.

• Batteries are weak, dead or inserted incorrectly.

• Remote is out of range, move closer to TV

(within 15 feet).

• Make sure Remote is aimed at sensor.

• Conrm there are no obstructions between the

Remote and the TV.

• Make sure the power cord is plugged in.

TV shuts o. • Sleep Timer is set.

• Power interrupted.

Closed

Caption is

not activated.

• TV station experiencing problems or program

tuned is not closed captioned. Try another

channel.

• Check Cable TV connection or VHF/UHF

antenna, reposition or rotate antenna.

• Set Closed Caption Decoder in the menu.

TV is not

shown in your

language.

• Select proper language in the menu options.

Use the following checklist for troubleshooting if you have problems with your TV. Consult your local dealer or service outlet if problems

persist. Be sure all connections are properly made when using with other units.

SYMPTOMS POSSIBLE SOLUTIONS

TV does not

operate.

• Make sure the power cord is plugged in.

• Try another AC outlet.

• Power is o, check fuse or circuit breaker.

• Unplug unit for an hour, then plug it back in.

Poor sound

or no sound.

• Station or Cable TV experiencing problems,

tune to another station.

• Check sound adjustments (Volume or Mute).

• Check for sources of possible interference.

• Check for audio language setting.

Poor picture

or no picture.

• Station or Cable TV experiencing problems,

tune to another station.

• Make sure channels are set into memory.

• Check antenna or Cable TV connections,

adjust antenna.

• Check for sources of possible interference.

• Check picture control adjustments.

Poor

reception on

some

channels.

• Station or Cable TV experiencing problems,

tune to another station.

• Make sure channels are set into memory.

• Station is weak, adjust antenna to receive

desired station.

• Check for sources of possible interference.

Poor color or

no color.

• Station or Cable TV experiencing problems,

tune to another station.

• Make sure channels are set into memory.

• Check picture control adjustments.

• Check antenna or Cable TV connections,

adjust antenna.

• Check for sources of possible interference.


wobbles or

drifts.

• Station or Cable TV experiencing problems,

tune to another station.

• Make sure channels are set into memory.

• Cable TV company is scrambling signal.

• Adjust antenna.

If the problem cannot be solved with the suggested procedures,

contact 800.HITACHI (800.448.2244).

For your safety, never try to repair the product yourself.

Troubleshooting

27 EN

Model 49E30 / 49E301 / 49E30A

Panel size

49” class / 48.50” Diagonal (1232.0 mm)

Display method Transmission TFT color LCD panel

Number of Pixels 1920 (H) × 1080 (V)

Broadcasting system US system M

ATSC standard (8VSB), QAM

Receiving channels VHF 2-13

UHF 14-69

CATV 14-36 (A)-(W)

37-59 (AA)-(WW)

60-85 (AAA)-(ZZZ)

86-94 (86)-(94)

95-99 (A-5)-(A-1)

100-135 (100)-(135)

01 (4A)

Tuner type Frequency synthesized

Inputs Video: 1.0 V (p-p),75 ohms

Audio: 2Vrms Max.

HDMI: HDMI compliant (type A connector)

HDCP compliant

E-EDID compliant

Suggested scan rates: 480i, 480p, 720p, 1080i, 1080p

HDMI Audio: 2-channel PCM

32/44.1/48 kHz sampling frequency

16/20/24 bits per sample

Antenna: VHF/UHF In 75 ohms coaxial

Outputs Audio: 0.2 V (p-p), 75 ohms terminated

Digital audio: Optical

Speakers Integrated speakers (Bottom side)

Audio output power 8.0W + 8.0W (THD 10%)

Power supply AC 120V, 60Hz

Power consumption Operation: 120W

Standby: ≤0.5W

Weight 24.3 lbs (11.0kg)

Dimensions Width: 43 11/16” (1108.4mm)

Height: 27 3/16” (690.4mm)

Depth: 8 5/8” (218.7 mm)

Operating temperature 5˚C - 40˚C

Operating humidity Less than 80% RH

Accessories Remote control

Batteries (AAA) × 2

Stand x 2 (R, L), Stand Screws x 4

Owner’s Guide

Quick Start Guide

• Designs and specications are subject to change without notice.

• For information on our other products, please visit our website at www.hitachi.us

Specications

EN 28

800.HITACHI

(800.448.2244)

Monday ~ Friday

9:00 am - 6:00 pm EST

www.hitachi.us/tv

HITACHI AMERICA, LTD., DIGITAL MEDIA DIVISION

HITACHI has made every effort to assure you enjoy trouble free operation from your Hitachi

product. Should you require service assistance with OPERATIONAL, HOOK UP, TECHNICAL

ASSISTANCE OR WARRANTY SERVICE SUPPORT, please contact one of our knowledgeable

Customer Service Advocates at 800.HITACHI (800.448.2244).

Please be prepared to submit proof of purchase and/or delivery receipts to your 800.HITACHI

Customer Service Representative. Warranty coverage will be provided in accordance with the

provisions of your Limited Warranty (see the Limited Warranty page in this operating guide).

Pour de plus amples renseignements sur le service durant la periode couverte par la garantie,

sur le fonctionnement ou pour de l'assistance techniquie communiquez avec:

Au Canada: 800.HITACHI (800.448.2244)

Lundi ~ Vendredi 9:00 am - 6:00 pm HNE

Hitachi America, Ltd., Digital Media Division

Customer Service Support

P.O. Box 99652

Troy, MI 48099

customerservice.ce@hal.hitachi.com

29 EN

Congratulations on your purchase of a new Hitachi display product!

LIMITED WARRANTY:

Hitachi America, Ltd. warrants this Hitachi display product (the “Product”) in accordance with the following terms and conditions:

Limited Parts and Labor Warranty: The Product is warranted to be free from defects in materials and workmanship beginning on the date of purchase

by the original end user purchaser (the “Purchaser”) and continuing for the duration of the applicable time periods specified below. If the Product is

found to be defective, Hitachi will repair or replace (at Hitachi’s option) defective parts at no charge, subject to the conditions of this Limited Warranty.

If the Purchaser rejects, refuses or otherwise does not accept Hitachi’s offer to repair or replace such defective parts under this Limited Warranty, this

Limited Warranty shall be void and of no further force or effect. This Limited Warranty extends to the Purchaser only and is not transferable, and such

Purchaser must provide a dated sales receipt his or her evidencing the purchase of the Product to qualify for parts or service under this Limited

Warranty. The original owner must notify Hitachi of a defect claim by calling 800-HITACHI during the applicable Limited Warranty period for this

Limited Warranty to be effective. This Limited Warranty is valid only in the U.S.A., Canada and Puerto Rico.

PARTS: The Limited Warranty period for parts is 1 year from the date of original purchase. During the Limited Warranty period for parts, Hitachi will

replace defective parts with new or rebuilt parts (at Hitachi’s option) at no charge for such parts. Any replacement part will be warranted for the

remainder of the original warranty period applicable to the part replaced. LABOR: The Limited Warranty period for labor is 1 year from the date of

original purchase. During the Limited Warranty period for labor, Hitachi will repair or replace (at Hitachi’s option) defective parts without charge for

labor. SERVICE LOCATION: In-home warranty service, which includes either in-home repair or free pick-up and delivery (at Hitachi’s option),

applies to all Hitachi products except: (i) 43-inch and smaller LCD Flat Panel Televisions; (ii) Products located outside the U.S.A., Canada or Puerto

Rico; and (iii) Products located more than seventy-five (75) driving miles from Hitachi’s nearest Authorized Service Facility. If the foregoing clauses (i),

(ii), or (iii) apply, then the Purchaser will be responsible for bringing/delivering the Product to a Hitachi Authorized Service Facility and, following

warranty service, retrieving the Product from such Authorized Service Facility.

IMPORTANT: Before using or installing your Product, please complete this form and attach your sales receipt and retain them for your records. This

will help facilitate proper warranty coverage.

MODEL NO.: SERIAL NO.:

DEALER NAME: DATE OF PURCHASE:

DEALER ADDRESS:

CITY: STATE / PROVINCE:

WARRANTY LIMITATIONS. This Hitachi Limited Warranty DOES NOT COVER: A. Any Product that has been modified or repaired in a manner

not previously authorized by Hitachi in writing. B. Any Product, whose serial number has been removed, altered, replaced, defaced or rendered illegible.

C. Any defect, malfunction, or failure caused by or resulting from improper or unauthorized service, maintenance or repair. D. Damage resulting from

abuse, misuse, mishandling, neglect or damage caused by exposure to hostile operating environments such as areas containing dust and/ or smoke. E.

Damage caused by power surges, accidents, natural disasters or any other events or circumstances outside Hitachi’s control. F. Any Product used in any

manner inconsistent with the acceptable set-up, usage, safety or installation configurations identified in the Product’s Operating Guide. G. Any Product

used for purposes or applications, or subjected to operating conditions, other than those identified as acceptable in the Product’s Operating Guide. H.

Product repairs (including any product whose case has been opened), or part replacements provided or installed, by any person other than an Authorized

Hitachi Service Facility Representative. I. Improper uncrating, set-up or installation or any mis-adjustments caused by user-operated controls. J. Any

labor or costs associated with removing the Product from a custom cabinet or other specialized product installation that impedes direct and immediate

removal of the Product from the owner’s premises (must be arranged and paid by the owner). K. Product cabinets, cabinet parts, knobs, batteries,

accessories, or any third party's branded hardware or peripheral devices, including any software incorporated therein, whether or not included within the

Product's original packaging. L. Product screens that have been cleaned by any method other than as specified in the Product’s Operating Guide. M.

Normal usage, degraded brightness caused by backlight aging and/or cell defects or ordinary wear and tear, including, without limitation, scratches or

marks on the Product’s screen, cabinet or the appearance of bright or dark screen pixels. N. Any Product returned for service that is damaged due to

improper packaging, mishandling or shipping. (IMPORTANT: When shipping any Product to a Hitachi Authorized Service Facility, Product owner

must package it securely in the original shipping container or its equivalent to prevent damage. The Product must be returned with the shipping charges

prepaid and proof of purchases included in the shipping container. Failure to properly package such product during such shipment will void all

warranties.) O. Any Product purchased or serviced outside the U.S.A., Canada and Puerto Rico. P. Any Product that has been used for commercial

purposes.

NO PERSON, AGENT, DISTRIBUTOR, DEALER, SERVICE FACILITY, OR COMPANY IS AUTHORIZED TO CHANGE, MODIFY OR

AMEND THE TERMS OF THIS LIMITED WARRANTY IN ANY MANNER WHATSOEVER. EXCEPT AS PROVIDED IN THIS LIMITED

WARRANTY, HITACHI MAKES NO EXPRESS WARRANTY REGARDING THIS HITACHI PRODUCT. FURTHER, ALL IMPLIED

WARRANTIES RELATING TO ANY PORTION OF THIS PRODUCT, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY ARE HEREBY EXPRESSLY DISCLAIMED BY HITACHI TO THE MAXIMUM

EXTENT PREMITTED BY APPLICABLE LAW. HITACHI SHALL NOT BE LIABLE TO THE PURCHASER OR TO ANY OTHER PERSON

FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS OF PROFIT OR PRODUCT RESULTING FROM ANY DEFECT IN, OR

MALFUNCTION OR FAILURE OF, THIS HITACHI PRODUCT. BECAUSE SOME JURISDICTIONS DO NOT ALLOW LIMITATIONS OR

EXCLUSIONS OF CERTAIN IMPLIED WARRANTIES, OR THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE

ABOVE LIMITATIONS MAY NOT APPLY TO YOU. THIS LIMITED WARRANTY CONFERS SPECIFIC LEGAL RIGHTS, INCLUDING

CERTAIN OTHER RIGHTS THAT MAY VARY DEPENDING ON YOUR JURISDICTION. THIS LIMITED WARRANTY SHALL BE

GOVERNED BY AND CONSTRUED IN ACCORDANCE WITH THE LAWS OF THE JURISDICATION OF THE PRODUCT OWNER’S

RESIDENCE.

................................................................................................................................................................

Memo

................................................................................................................................................................

Memo

Hitachi Owners Guide 49E30 LR

Navigation menu

Versions of this User Manual:

Views

Navigation
