OneWireless Starter Kit
Get started quickly on the road to a more efficient and safer
plant with Honeywell’s universal, simple, and efficient
OneWireless™ network. Honeywell’s OneWireless Starter Kit
provides you with an introduction to Honeywell’s OneWireless
solutions. Within 20 minutes, you can set up a multi-functional
wireless plant network that can grow to include additional
devices and 802.11 handheld devices, such as Honeywell’s
IntelaTrac PKS and Mobile Station.
Honeywell’s OneWireless multi-functional wireless mesh
network supports wireless-enabled applications within a single
wireless network to optimize plant productivity and reliability,
improve safety and security, and ensure regulatory
compliance. Supporting both Honeywell’s XYR™ wireless
transmitters, and offering an open yet secure backbone to
802.11-enabled equipment , this network delivers a global
solution with robust security, predictable power management
and multi-speed monitoring. This is the only wireless network
you’ll need for your industrial plant.
This kit includes two Honeywell XYR 6000 wireless
transmitters, enabling automated monitoring in areas where
traditional hard-wired transmitters are too costly, difficult or
time-consuming to implement. If you would like to add
additional sensors to the transmitters included in the kit, the
XYR 6000 transmitter family includes devices for accurately
monitoring gauge pressure, absolute pressure, differential
pressure, temperature, and corrosion. The line also includes
an analog input interface for adding wireless capabilities to 4-
20 ma devices. The devices wirelessly transmit their
measurements to a gateway or to multiple communication
nodes, called Multinodes. The starter kit includes one
multinode/gateway to wirelessly communicate to the sensors
forming a managed, secure and redundant wireless network.
The multinode/gateway also interfaces with Honeywell’s PC-
based Wireless Server Software, which offers configuration
capabilities and communications with your control system. The
multinode/gateway and each associated mutlinode you may
subsequently add is also an 802.11 b/g wireless access point
providing flexible remote communications.
Honeywell’s OneWireless network provides a universal,
simple, and efficient network with these features:
• One strategic network that supports multiple uses
(sensors and 802.11 Wi-Fi devices), providing one
infrastructure for simple network management
• Scales from a few field instruments to thousands to get
started now but still prepare for future
• Operates in noisy radio frequency environments for
reliable communication that functions safely as required
and when needed
• Provides predictable power management to ensure uptime
and optimize maintenance
• End-to-end industrial security to protect plant information
and ensure safety
• Open architecture and protocol integration to provide
choices for standard and cost-effective solutions
• Backwards compatible to previous Honeywell solutions
and forward migratable to protect your investment
OneWireless Starter Kit
More Information
To learn more about Honeywell’s wireless
solutions, visit www.honeywell.com/ps/wireless
or contact your Honeywell account manager.
Automation & Control Solutions
Process Solutions
Honeywell
2500 W. Union Hills Dr.
Phoenix, AZ 85027
Tel: +1.602.313.6665 or 877.466.3993
www.honeywell.com/ps
Details
Network Architecture
• Integrated multi-functional 802.11 mesh network supporting handheld and field sensor devices, including XYR 5000 and XYR 6000
wireless transmitters, IntelaTrac PKS, Mobile Station, real-time location applications and other 3rd-party devices
• Control ready with built-in redundancy and managed message routes
Network Security Management
End-to-end security: WPA2, AES-based, device authentication, FIPS 140-2 based encryption
Network Communications
• Frequency hopping spread spectrum
• Built-in sensor redundancy for assured communication
• Integrated 802.11 high-speed, self-organizing mesh network
• Class 1, Div 2 for general plant deployment
• Full performance, flexible channel allocation for plant
wireless governance
• Up to 6 miles (10 km) multinode to multinode
communication(with optional antennas); sensor to multinode
designed for over 2,000 ft (.6 km)
• Built-in read-write messaging for configuration and priority
alarms - optimized performance for all functionality
• Radio receivers with high selectivity for co-existence
• Protocol tolerant to missing packets with automatic repeat
requests
• Multi-speed monitoring – 1 second reporting with latency
control and the ability to configure sensors on the same
network at different rates
Network Protocols
• 2.4 GHz-based for use in facilities worldwide • Open protocol - connects to any system
Network Sizing
• Minimum: One sensor
• For control or high-speed sensing:
- Up to 1,000 sensors per network (@ 1 sec updates)
• For general purpose sensing:
- Up to 10,000 sensors per network (@ 10 sec updates)
- Up to 30,000 sensors per network (@ 30 sec updates)
• For other applications: 54Mbps max mesh link speed (9Mbps effective throughput)
Sensor Power Management
Self-contained and predictable power management designed for 10-year sensor battery life (rain or shine)
Kit Contains
One (1) XYR 6000 HLAI Transmitter
One (1) XYR 6000 Temperature Transmitter (STTW400)
One (1) Multinode/Gateway (WNMN) with Integral Antennas
One (1) 120/240 VAC to 24 VDC 30 W
One (1) Authentication device
One (1) Serial IR Port
One (1) OneWireless Server Tools Software
One (1) TCP-IP Serial Converter
PN-07-16-ENG
May 2007
© 2007 Honeywell International Inc.
OneWireless and XYR are trademarks and Experion is
a registered trademark of Honeywell International Inc.
IntelaTrac is a registered trademark of SAT
Corporation.
