Document 800-02089 Rev B 06/08

HRDP DVR

Performance Series

Digital Recording and Transmission System

User Guide

Warnings and Safeguards

______________________________________________________________________________________________

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 3

06/08

Revisions

Issue Date Revisions

A 05/08 Initial Release

B 06/08 Updated remote control image

Warnings and Safeguards

______________________________________________________________________________________________

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 5

06/08

Warnings and Safeguards

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

EN 55022 Class A Notice

WARNING

This is a class A product. In a domestic environment this product may cause radio interference in which

case the user may be required to take adequate measures.

Warnings and Safeguards

______________________________________________________________________________________________

Important Safeguards

1. Read Owner’s Manual – After unpacking this product, read the owner’s manual carefully, and

follow all the operating and other instructions.

2. Power Sources – This product should be operated only from the type of power source indicated

on the label. If not sure of the type of power supply to your home or business, consult product

dealer or local power company

3. Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable

operation of the product and to protect it from overheating, and these openings must not be

blocked or covered. The product should not be placed in a built-in installation such as a

bookcase or rack unless proper ventilation is provided or Honeywell’s instructions have been

adhered to.

4. Heat – The product should be situated away from heat sources such as radiators, heat registers,

stoves, or other products that produce heat.

5. Water and Moisture – Do not use this product near water. Do not exceed the humidity

specifications for the product as detailed in this manual

6. Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or

aerosol cleaners. Use a damp cloth for cleaning.

7. Power Cord Protection – Power-supply cords should not be routed so that they are likely to be

walked on or pinched by items placed against them, paying particular attention to cords at plugs,

receptacles, and the point where they exit the product.

8. Overloading – Do not overload wall outlets; extension cords, or integral convenience receptacles

as this can result in a risk of fire or electrical shock.

9. Lightning – For added protection for this product during storm, or when it is left unattended and

unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the

product due to lightning and power line surges.

10. Object and Liquid Entry Points – Never insert foreign objects into the DVR, other than the media

types approved by Honeywell, as they may touch dangerous voltage points or short-out parts that

could result in a fire or electrical shock. Never spill liquid of any kind on the product.

11. Accessories – Do not place this product on an unstable cart, stand, tripod, bracket, or table. The

product may fall, causing serious personal injury and serious damage to the product.

12. Disc Tray – Keep fingers well clear of the disc tray as it is closing. Neglecting to do so may cause

serious personal injury.

13. Burden – Do not place a heavy object on or step on the product. The object may fall, causing

serious personal injury and serious damage to the product.

14. Disc – Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may

cause serious personal injury and product malfunction.

15. Fuses - CAUTION: For continued protection against risk of fire, replace only with same type and

rating of fuse.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 7

06/08

16. Replaceable Batteries - CAUTION: Risk of Risk of Explosion if Battery is replaced by an Incorrect

Type. Dispose of Used Batteries According to the Instructions

17. Grounded Outlet - This equipment shall be connected to a properly grounded outlet."

18. Outlet Location – This equipment must be installed within six feet of an easily accessible outlet.

19. Damage Requiring Service – Unplug the unit from the outlet and refer servicing to qualified

service personnel under the following conditions:

When the power-supply cord or plug is damaged.

If liquid has been spilled, or objects have fallen into the unit.

If the unit has been exposed to rain or water.

If the unit does not operate normally by following the operating instructions. Adjust only those

controls that are covered by the operating instructions as an improper adjustment of other

controls may result in damage and will often require extensive work by a qualified technician to

restore the unit to its normal operation.

If the unit has been dropped or the enclosure has been damaged.

When the unit exhibits a distinct change in performance - this indicates a need for service.

20. Servicing – Do not attempt to service this product. Opening or removing covers may expose the

user to dangerous voltage or other hazards. Refer all servicing to qualified personnel.

21. Replacement Parts – When replacement parts are required, be sure the service technician has

used replacement parts specified by Honeywell. Unauthorized substitutions may result in fire,

electric shock or other hazards.

22. Safety Check – Upon completion of any service or repairs to this unit, ask the service technician

to perform safety checks to determine that the unit is in proper operating condition.

Warnings and Safeguards

______________________________________________________________________________________________

Notes on Handling

Please retain the original shipping carton and/or packing materials supplied with this product. To ensure

the integrity of this product when shipping or moving, repackage the unit as it was originally received

from Honeywell.

Do not use volatile liquids, such as aerosol spray, near this product. Do not leave rubber or plastic

objects in contact with this product for long periods of time. They will leave marks on the finish.

The top and rear panels of the unit may become warm after long periods of use. This is not a

malfunction.

Notes on Locating

Place the unit on a level surface. Do not use it on a shaky or unstable surface such as a wobbling table

or inclined stand.

If this unit is placed next to a TV, radio, or VCR, the playback picture may become poor and the sound

may be distorted. If this happens, place the DVR away from the TV, radio, or VCR.

Notes on Cleaning

Use a soft dry cloth for cleaning.

For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to

wipe it dry. Do not use any type of solvent, such as thinner and benzene, as they may damage the

surface of the DVR.

If using a chemical saturated cloth to clean the unit, follow that product’s instructions.

Notes on Maintenance

This DVR is designed to last for long periods of time. To keep the DVR always operational we

recommend regular inspection maintenance (cleaning parts or replacement). For details contact the

nearest dealer.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 9

06/08

Notes on Moisture Condensation

Moisture condensation could damage the DVR. Read the following information carefully.

Moisture condensation might occur under the following circumstances:

When this product is brought directly from a cool location to a warm location.

When this product is moved to a hot and humid location from a cool location.

When this product is moved to a cool and humid location from a warm location.

When this product is used in a room where the temperature fluctuates.

When this product is used near an air-conditioning unit vent

When this product is used in a humid place.

Do not use the DVR when moisture condensation may occur.

If the DVR is used in such a situation, it may damage discs and internal parts. Remove any CD discs,

connect the power cord of the DVR to the wall outlet, turn on the DVR, and leave it for two to three hours.

After two to three hours, the DVR will warm up and evaporate any moisture. Keep the DVR connected to

the wall outlet and moisture will seldom occur.

Safety Instructions – Rack Mount

A) Elevated Operating Ambient – If installed in a closed or multi-unit rack assembly, the operating

ambient temperature of the rack environment may be greater than room ambient. Therefore,

consideration should be given to installing the equipment in an environment compatible with the

maximum ambient temperature (Tma) specified by the manufacturer.

B) Reduced Air Flow – Installation of the equipment in a rack should be such that the amount of air flow

required for safe operation of the equipment is not compromised.

C) Mechanical Loading – Mounting of the equipment in the rack should be such that a hazardous

condition is not achieved due to uneven mechanical loading.

D) Circuit Overloading - Consideration should be given to the connection of the equipment to the supply

circuit and the effect that overloading of the circuits might have on overcurrent protection and supply

wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this

concern.

E) Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular

attention should be given to supply connections other than direct connections to the branch circuit (e.g.

use of power strips)."

Warnings and Safeguards

______________________________________________________________________________________________

WARNING

TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE.

DO NOT OPEN THE CABINET.

REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 11

06/08

Contents

1 Warnings and Safeguards .............................................................................................................. 5

2 Contents ........................................................................................................................................ 11

3 Introduction ................................................................................................................................... 15

Product Description .......................................................................................................... 15

Features ............................................................................................................................ 16

PTZ Compatibility List ....................................................................................................... 17

Quick Start Guide .............................................................................................................. 18

Logging In for the First Time ............................................................................................. 18

4 Installation ..................................................................................................................................... 19

Front Panel Controls ......................................................................................................... 19

Rear Panel Connectors ..................................................................................................... 20

4 Channel ................................................................................................................... 20

8 Channel ................................................................................................................... 21

16 Channel ................................................................................................................. 21

Remote Control ................................................................................................................. 22

Connection Guide ............................................................................................................. 23

Connecting the Monitor ............................................................................................. 23

Video Inputs and Looping Outputs ........................................................................... 23

Connecting to a Network ........................................................................................... 23

Connecting Audio ...................................................................................................... 23

Connecting a PTZ Camera ........................................................................................ 24

Connecting to a Sensor Input ................................................................................... 24

Connecting to a Relay Output ................................................................................... 24

Installing the Rackmount Kit (optional) ............................................................................ 25

Turning on the DVR........................................................................................................... 25

5 Setup ............................................................................................................................................. 27

Setup Menus ..................................................................................................................... 27

System .............................................................................................................................. 28

System Configuration ................................................................................................ 28

Setup Wizard ............................................................................................................. 29

Disk Configuration ..................................................................................................... 30

Contents

______________________________________________________________________________________________

Format ................................................................................................................ 30

Overwrite ............................................................................................................ 31

Check ................................................................................................................. 31

SMART Check .................................................................................................... 32

User Configuration ..................................................................................................... 33

Server ................................................................................................................. 33

Client ................................................................................................................... 34

Configuration ............................................................................................................. 35

Shutdown ................................................................................................................... 35

Camera .............................................................................................................................. 35

Camera Configuration ............................................................................................... 35

Color Setup (Adjust) ........................................................................................... 36

PTZ Configuration ...................................................................................................... 36

Spot / Sequence Configuration ................................................................................. 37

Monitor Configuration ................................................................................................ 38

Record ............................................................................................................................... 39

Record Configuration ................................................................................................ 39

Frame.................................................................................................................. 39

Schedule ............................................................................................................. 40

Audio .................................................................................................................. 40

Instant Recording ............................................................................................... 41

Using Instant Recording ............................................................................. 41

Motion/Event Configuration ....................................................................................... 42

Input .................................................................................................................... 42

Setting Up Motion Detection Recording ............................................................ 43

Sensor ................................................................................................................ 44

Action .................................................................................................................. 45

Alarm Monitor ..................................................................................................... 45

Network ............................................................................................................................. 46

Network Configuration ............................................................................................... 46

Serial Configuration ................................................................................................... 47

Client Configuration ................................................................................................... 48

E-mail Configuration .................................................................................................. 49

Information ........................................................................................................................ 50

System Log View ....................................................................................................... 50

Status View ................................................................................................................ 50

Version View .............................................................................................................. 51

6 Operation ....................................................................................................................................... 52

Search ............................................................................................................................... 52

Searching Recorded Data ......................................................................................... 52

Search Methods ........................................................................................................ 53

Express Search .................................................................................................. 53

Event Search ...................................................................................................... 53

Daylight Savings Search .................................................................................... 53

Go To First .......................................................................................................... 54

Go To Last .......................................................................................................... 54

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 13

06/08

Go To Jump ........................................................................................................ 54

Search Details ............................................................................................................ 54

Search Popup Menu .................................................................................................. 54

Monitoring ......................................................................................................................... 55

Select Channel .......................................................................................................... 55

Live Popup Menu ....................................................................................................... 56

Backup (Export) ................................................................................................................ 57

Manual Export ............................................................................................................ 57

Play Back Backup Image .................................................................................................. 58

S/W Upgrade..................................................................................................................... 58

Save Settings .................................................................................................................... 59

Save Settings ............................................................................................................. 59

Import Settings .......................................................................................................... 59

PTZ Camera Control ......................................................................................................... 60

Create PTZ Preset Position ....................................................................................... 60

7 Remote Software ........................................................................................................................... 62

Set Up a Remote Connection ........................................................................................... 62

Configuring the DVR .................................................................................................. 62

Configuring a Remote PC .......................................................................................... 63

Default Remote Software Log In Information ..................................................... 63

Access Remote Connection ............................................................................................. 64

Using the Remote Software .............................................................................................. 64

Setting the Time and Date ......................................................................................... 64

Live View Screen ....................................................................................................... 65

Camera View ...................................................................................................... 66

Screen Division Buttons ..................................................................................... 67

Setup Overview .......................................................................................................... 68

Setup Screen Overview ...................................................................................... 68

Camera Setup .................................................................................................... 68

Camera Setup ............................................................................................. 68

PanTilt Setup ............................................................................................... 68

Sequence Setup ......................................................................................... 69

SPOT Setup ................................................................................................ 69

Record Setup ..................................................................................................... 69

Time Setup .................................................................................................. 69

Schedule Setup ........................................................................................... 70

Audio Setup ................................................................................................ 70

Motion / Event Input .................................................................................... 70

HDD Setup .................................................................................................. 71

Sensor Setup ...................................................................................................... 71

Sensor ......................................................................................................... 71

System Setup ..................................................................................................... 72

User Management....................................................................................... 72

Firmware Upgrade ...................................................................................... 72

Contents

______________________________________________________________________________________________

Search Overview ........................................................................................................ 73

Play Controls ...................................................................................................... 74

Performing a Basic Search ................................................................................ 74

Adjust the Brightness of an Image ..................................................................... 74

Zooming in on an Image .................................................................................... 74

Zooming in on a Portion of an Image ................................................................ 75

Printing an Image ............................................................................................... 75

Save Clip ............................................................................................................ 75

Saving a Video Clip ..................................................................................... 76

Status Search ............................................................................................................ 77

Performing a Status Search ............................................................................... 77

PTZ Overview ............................................................................................................. 78

Accessing PTZ Menus ....................................................................................... 78

Controlling a PTZ Camera .................................................................................. 78

Using the Graphical PTZ Controller ................................................................... 79

Using the On-screen Compass .......................................................................... 80

Web Viewer Overview ....................................................................................................... 81

Connecting to a DVR Using Web Viewer .................................................................. 82

Closing the Web Viewer ............................................................................................ 82

Digital Verifier Overview .................................................................................................... 83

Using the Digital Verifier ............................................................................................ 83

8 Appendix ....................................................................................................................................... 84

DVR FAQ ........................................................................................................................... 84

General ...................................................................................................................... 84

Live Monitoring .......................................................................................................... 84

Recording .................................................................................................................. 84

Searching and Playing Video .................................................................................... 85

Backup ....................................................................................................................... 85

Network ...................................................................................................................... 85

Miscellaneous ............................................................................................................ 85

Troubleshooting ................................................................................................................ 86

Specifications (HRDP) ...................................................................................................... 87

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 15

06/08

Introduction

Product Description

Honeywell’s HRDP Performance Series DVR is a powerful, yet affordable, video

management solution designed for easy installation and operation.

Preconfigured for continuous recording, with no additional setup required, the

Performance Series DVR offers quick search, setup, and backup features.

The Honeywell Embedded DVR comes ready for fast and seamless integration

within your existing IT infrastructure. The HRDP offers unparalleled stability,

security, and ease of use in a 2U chassis. Accordingly, your security

investment has never been easier to maintain. Multiple users may connect

through digital networks such as LANs and WANs for simultaneous live

viewing, and digital search. This powerful software enables users to view live

video, perform searches, and operate PTZ cameras. It also provides system

users and administrators with additional capabilities such as establishing

recording schedules, and creating motion detection zones. With the latest

advancements in the Performance Series DVR software, searching and

indexing your video archive has never been easier.

Introduction

______________________________________________________________________________________________

Features

The Honeywell Performance Series DVRs include the following features:

• 4 /8 / 16 Composite Video Input Connectors

• Compatible with Color (NTSC or PAL) and B&W Video Sources

• Multiple Search Methods (Date/Time, Calendar, Event)

• Records 120 NTSC Images Per Second / 100 PAL Images Per Second

• Live Real Time Video Display (480 NTSC Images Per Second / 400 PAL

Images Per Second)

• 4 /8 / 16 Looping Video Outputs

• Auto Termination (75 Ohm) on Looping Outputs

• Continuous Recording with Disk Overwrite Mode

• Continuous Recording on Archiving, Transmitting to Remote, and

Playback

• Motion Based Recording Uniquely Configurable for Each Channel

• Customizable Motion Detection Grids Uniquely Configurable for Each

Channel

• Multiple Recording Modes (Manual / Schedule / Event)

• Audio (Mono) Recording and Playback

• 4 / 8 / 16 Built in Sensor Inputs (Normally Open or Normally Closed)

• 1 / 4 (16 Channel DVR only) Built in Relay Outputs (Normally Open or

Normally Closed)

• Remote Access via Ethernet and/or Modem

• PTZ Camera Control

• Internal DVD-RW supports CD-RW and DVD-RW media

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 17

06/08

PTZ Compatibility List

The Honeywell Performance Series DVRs support a wide selection of PTZ

camera protocols:

Honeywell MAXPRO

Honeywell VCL

Honeywell (GC-655P)

Honeywell (HSD-250)

Honeywell (HSD-251)

American Dynamics

OpenEye 500

OpenEye 510

OpenEye – Pelco D

AcutVista

AlfaVision

KalatelDome

Cynix Speed Dome

CoVi EVQ-1000

CRR-1600I

DMP23-H2

Dongyang

DRX-500

DRX-502A

DS120

DSC-230/240

DY-255RXB

DynaColor

ERNA Tech

EyeView Dome

FastraxII

FilTech (DSC-230/PT-201)

Focvision

Ganz-PT

HMC-250

HSCP

Inter-M (VRX-2101)

Inter-M (VSD-640)

LG (LPT-A100L)

LG (LVC-A70x s)

LG SpeedDome

Merit Li-Lin

Merit Li-Lin V6

NVCC-Z42N

NICE CAM

NIKO

Pelco-D

Pelco-P

PIH-7600

SAE

Samsung (SCC-C420X)

Samsung (DVR-502A)

Samsung (MRX-1000)

Samsung (SCC-641)

Samsung (SPD-1600)

Sensormatic

Sungjin

Tamron

Toshiba

ViconSpeedDome

Visiontech

WONWOO

WSD-7425D

Introduction

______________________________________________________________________________________________

Quick Start Guide

1. Turn on the DVR. See the Turning on the DVR section for more details.

2. Log in -- Use the number buttons to enter the password when prompted –

The password is <none> – Press ENTER.

3. Complete System Configuration to set up the date, time and system ID.

See the System Configuration section for more details.

4. Complete Sensor Configuration to enable any external devices connected

to sensor inputs or relay outputs. See the Motion/Event Configuration

section for more details.

5. Complete Disk Configuration to set overwrite options and enable SMART

Check. See the Disk Configuration section for more details.

6. Complete User Configuration to change the Admin password and add

additional users. See the System >User Configuration section for more

details.

7. Complete Camera Configuration for all attached cameras. See the Camera

Configuration section for more detail.

8. Complete PTZ Configuration for any attached Pan / Tilt / Zoom cameras.

See the PTZ Configuration section for more details.

9. Create a recording schedule. See the Record section for more details.

10. Complete Motion/Event Configuration to trigger recording on an event:

motion, sensor, video loss. See the Motion/Event Configuration section for

more details.

11. The DVR is now configured to record, search and playback video. See the

Operations section in this manual for more information on using the DVR.

Logging In for the First Time

The default administrative log in information:

ID: admin

Password: <none>

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 19

06/08

Installation

Front Panel Controls

USB Ports LED Lights

• Power

• HDD

• Record

• Network

• Fan

DVD Drive Numeric Keypad

rrow Buttons

Live Display

Setup Menu

Lock (logout)

Search Mode

Backup Menu

Rotate

Instant Record

Installation

______________________________________________________________________________________________

Rear Panel Connectors

The rear panel of the DVR contains virtually all of the connectors you will be

using. The diagrams below outline the location and description of each

connector:

4 Channel

OUT

Spot Monitor Outputs

Power Switch

AC Power Input

Network Port RS-232 Input

VGA Output

Audio Input / Output

ideo In Ports

Video Out Ports

Relay Output

Sensor Input

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 21

06/08

8 Channel

16 Channel

OUT

Primary and Spot Monitor Outputs

AC Power Input

Power Switch

Network Port RS-232 Input

VGA Output

Audio Input

S-Video Output

Audio Output

Video In Ports

Video Out Ports

Relay Output

Sensor Input

OUT

Spot Monitor Outputs

Power Switch

AC Power Input

Network Port RS-232 Input

VGA Output

Audio Input / Output

Video In Ports

Video Out Ports

Relay Output

Sensor Input

Installation

______________________________________________________________________________________________

Remote Control

ROTATE ALARM OSD PTZ

EXIT

REPL AY

ENTER

ZOOM FOCUS IRIS

PTZ

PRESET

+10

LIVE

BACKUP

SETUP

7 8 9

4 5 6

2 3

REC

-30 +30

Record Toggle

ID Select*

rrow / Panorama

rrow

Rewind

Pause

X Arrow

Display Options

Play

Fast Forward

Log Off (Lock)

PTZ Controls

*The ID Select button allows you

to use one remote control for

several DVRs.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 23

06/08

Connection Guide

Connecting the Monitor

There are three available monitor outputs on the Performance Series DVR.

• Composite Monitor output for CCTV monitor – BNC (Marked MAIN)

• VGA output for VGA monitor – Mini-Sub D15

• S-Video output - Mini-Din 4 (16 Channel only)

Video Inputs and Looping Outputs

The Performance Series DVR comes with up to 16 BNC video inputs on the

rear of its chassis. Each video input has a corresponding looping BNC output

beneath it for passing the video signal to another monitoring/recording device.

Connecting to a Network

Use the RJ45 jack or RS232 port, if using a serial modem, on the rear of the

DVR when connecting to a network.

Connecting Audio

To record audio on the DVR connect the audio source to the Audio In Port

(White) on the back of the chassis.

To listen to live or recorded audio connect the Audio Out Port (Red) to an

amplified speaker system.

Note The DVR audio output is a line level source which requires an

amplified speaker system. The audio input can be from an amplified

source or directly from a microphone.

RJ45

RS232

Installation

______________________________________________________________________________________________

Connecting a PTZ Camera

The RS485 connector can be used to control Pan / Tilt / Zoom

(PTZ) cameras. See the PTZ camera manufacturer’s manual

for configuring the RS485 connection.

Note Use the RS485 connector for external control

systems such as a control keyboard. Connect

RX-/TX- and RX+/TX+ of the control system to the

TX-/RX- and TX+/RX+ (respectively) of the DVR.

Connecting to a Sensor Input

To make connections on the Alarm Connector Strip, press and hold the button

and insert the wire into the hole above the button. To disconnect the wire press

and hold the button below the wire and pull out

Alarm In

Use external devices to send a signal

to the DVR when an event occurs.

Mechanical or electrical switches can

be wired to the Alarm In and Ground

(GND) connectors.

Note All connectors marked GND are common. Connect the ground side

of the alarm input and/or alarm output to the GND connector.

Connecting to a Relay Output

To make connections on the Alarm Connector Strip, press and hold the button

and insert the wire into the hole above the button. To disconnect the wire press

and hold the button below the wire and pull out.

Alarm Out

The DVR can activate external

devices such as buzzers or lights.

Connect the external device to the

Alarm Out and Ground (GND)

connectors. See Sensor

Configuration in the manual for more

details.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 25

06/08

Installing the Rackmount Kit (optional)

Caution There must be a minimum 1U space between the DVR and any other

items in the rack.

1. Attach the rackmount brackets with the screws provided on each side of

the DVR. Do not remove the plastic edge guards.

2. Mount the DVR in your rack.

Turning on the DVR

1. Connect the power cable.

2. Connect camera cables.

3. Connect a network cable and a monitor cable.

4. Switch the power switch on the back of the DVR to the ON position and

wait until the main screen is displayed on the connected monitor; this

process will take approximately two minutes.

Tip See the Connection Guide section for more details

Installation

______________________________________________________________________________________________

NOTES:

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 27

06/08

Setup

Setup Menus

Use the setup menus to configure all of the DVR settings, schedule recording,

networking and shutdown.

Press the Setup key on the front of the DVR or remote control to enter the

setup menus and log in. See the Quick Start Guide section if entering setup for

the first time. Use the S and T keys on the front of the DVR or remote control

to navigate individual menus, and use the W and X keys to select a new setup

menu.

NETWORK CONFIGURATION

SERIAL CONFIGURATION

CLIENT CONFIGURATION

E-MAIL CONFIGURATION

Setup

______________________________________________________________________________________________

System

System Configuration

To enter System Configuration, press the Setup key on the front of the DVR

and press ENTER to select System Configuration. Use the arrow buttons on the

front panel of the DVR or the remote control to navigate the display. Select

Save and press ENTER to update settings.

Video Format - NTSC / PAL.

Language - ENGLISH / SPANISH [User Selectable].

System ID - Required for the operation of multiple units using the supplied IR

remote control. Each system must have a unique ID to function properly.

Date Format - US (MM-DD-YYYY) / EURO (DD-MM-YYYY) / ASIA (YYYY-MM-

DD) – [User Selectable].

Date - Press ENTER to select the Date and use the number keys and/or arrow

buttons to set the date. Press ENTER again to deselect.

Time - Press ENTER to select the Time and use the number keys and/or arrow

buttons to set the time. Press ENTER again to deselect.

Time Zone - Press ENTER to open the Time Zone window. Use the arrow keys

to navigate the list and press ENTER to make selection. Select Exit and press

ENTER to close the window.

Note The date and time must be set manually; changing the time zone will

not automatically change the Time/Date display.

NTSC

ENGLISH

MM-DD-YYYY

11/06/2006

10:44:48

GMT-08:00..

OFF

VIDEO FORMAT

LANGUAGE

DVR ID

DATE FORMAT

DATE

TIME

TIME ZONE

USE DST

NTP

KEYPAD BEEP

AUTO LOG OFF

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 29

06/08

System Configuration Continued

Use DST – After completing the Time Zone setup, highlight USE DST and

press ENTER to turn Daylight Saving Time ON / OFF.

NTP – Highlight NTP (Network Time Protocol) and press ENTER to SYNC the

DVR with the Network Time.

Keypad Beep - ON / OFF [Enables / Disables Audible keypad touch

confirmation].

Auto Log Off – OFF or 1-10 Minutes [This feature will close the Configuration

Menu after XX minutes of inactivity. This is a security feature.]

Setup Wizard

The Setup Wizard allows you to define global recording settings for an easy

and custom recording schedule on the DVR.

Global Resolution – 352 x240 / 704 × 240 / 704 × 480.

Motion/Continuous – Motion / Continuous.

Average Days to Record – [The estimated days of recording determined by

resolution, IPS (Images Per Second), Picture Quality, and available storage

size.]

Average IPS – 1-8 [Maximum varies with resolution.]

Average Picture Quality – Low / Normal / High / Ultra.

352X240

CONTINUOUS

8.1 DAYS

1 IPS

LOW

GLOBAL RESOLUTION

MOTION/CONTINUOUS

AVERAGE DAYS TO RECORD

AVERAGE IPS

AVERAGE PICTURE QUALITY

Setup

______________________________________________________________________________________________

Disk Configuration

Format

Shows installed Hard Disk Drives and the status of other attached storage

devices.

To format a device use the arrow keys to select the appropriate device and

press ENTER. Select OK to confirm formatting and press ENTER.

To refresh the list of connected USB devices select USB Reset and press

ENTER.

Note Upon formatting a drive, all video and other data stored on that drive

will be permanently erased and cannot be recovered.

SIZE

249GB

NONE

STATUS

REC

EMPTY

FORMAT

ERASE

FORMAT

TYPE

HDD1

CD-RW

HDD2

HDD3

FORMAT ALL USB RESET

FORMAT OVERWRITE CHECK SMART

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 31

06/08

Overwrite

Sets options for overwriting data when the Hard Disk Drive becomes full.

Enable HDD Overwrite to allow the DVR to write over previously recorded

data, starting with the oldest date, when the HDD is full. If set to Off the DVR will

not record any new data once the HDD becomes full. (Default)

Enable Disk Full Warning for notification when the HDD becomes full and

HDD Overwrite is disabled.

Check

Checks the HDD for errors or failure.

HDD OVERWRITE

DISK-FULL WARNING

REMAIN TIME

USED SPACE

DISK-FULL ALARM

DISK-FULL BUZZER

DISK FULL MESSAGE

FORMAT OVERWRITE CHECK SMART

ENABLE

30 MIN

90%

OFF

Setup

______________________________________________________________________________________________

SMART Check

SMART = Self Monitoring Analysis & Reporting Technology.

Enable SMART Check to detect signs of HDD failure.

1. Select SMART Enable and press ENTER to Enable or Disable.

2. Set a check interval between 1 and 24 hours.

3. Define a temperature threshold and select Celsius or Fahrenheit.

Note The recommended upper optimum operating temperature for the

HDD is between 104F to 122F (40C to 50C).

4. Select a warning to be activated when the HDD reaches the defined

threshold.

5. Select Save and press ENTER to save settings.

Tip Select HDD INFORMATION and press ENTER to view the current

HDD, DVD, and USB drive information.

FORMAT OVERWRITE CHECK SMART

ENABLE SMART

CHECK INTERVAL

TEMP. THRESHOLD

S.M.A.R.T.WARNING

CHECK NOW

HDD INFORMATION

ENABLE

1 HOUR

60 C

POPUP

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 33

06/08

User Configuration

Use the User Configuration to Add or Delete users.

Server

Use the Server menu to manage users that access the DVR locally.

To add a new user:

1. Select the authorization level to display the names of the users in that level

(Admin, SuperUser, User) by selecting the user type at the top of the

screen and pressing ENTER to cycle to the next level.

User SuperUser Admin

Live View

Replay

PTZ

User Privileges

Backup

SuperUser Privileges

Setup

2. Select ADD/CHANGE on an unused row and press ENTER.

3. Use the on-screen keyboard to input the user name.

4. Select OK.

5. Set the user password using the onscreen keypad or the key buttons on

the front panel or remote control. Repeat the password to confirm.

6. Repeat the above steps to set up more users at appropriate authorization

levels.

7. Select Save and press ENTER to save settings.

SERVER CLIENT

AUTHORIZATION ADMIN

admin

NONE

ADD/CHANGE

DEL

Setup

______________________________________________________________________________________________

Client

Use the Client menu to manage users that access the DVR remotely. Remote

users must be defined on this page. Only the users defined here can access

the DVR remotely. Add up to 18 users in addition to the two Admin users.

To add a new user:

1. Select a Login ID and press ENTER to change the Login ID.

2. Use the on-screen keyboard to input the user name.

3. Set the user password using the onscreen keypad or the number buttons

on the front panel or remote control. Repeat the password to confirm.

4. Set the user permissions.

Playback - ON/OFF

Backup - ON/OFF

Health Check - ON/OFF

Live View – 1~16, ALL, OFF

PTZ Control – 1~16, ALL, OFF

5. Repeat the above steps to set up additional users.

6. Select Save and press ENTER to save settings.

SERVER CLIENT

ADMIN1

ADMIN2

USER1

USER2

USER3

USER4

USER5

USER6

USER7

USER8

admin1

admin2

user1

user2

user3

user4

user5

user6

user7

user8

PERMISSIONS

PASSWORD

****

PAGE1 PAGE2

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 35

06/08

Configuration

Import and Export current settings. See details in the Save Settings Section.

Shutdown

Use Shutdown to safely shutdown the system.

1. Select System > Shutdown.

2. Select OK to confirm and press ENTER to safely shutdown the system.

3. Turn the power off when shutdown is complete using the toggle switch on

the back of the DVR.

Note Improper shut down of the system can cause data loss and system

corruption.

Camera

Camera Configuration

CH –Camera Channels

NAME – Use the on-

screen keyboard to enter

a camera name [user

defined]

ENABLE – On / Off

HIDDEN (from Main

Monitor) – Off / On

ADJUST –Detailed

camera display settings

CHT

NAME

ENABLE

HIDDEN

OFF

ADJUST

9CH-16CH

Setup

______________________________________________________________________________________________

Color Setup (Adjust)

Camera – 1 ~ 16 [camera to apply color settings to]

Screen Mode – Live / Record

Bright - -25 ~ 25

Contrast- -25 ~ 25

Saturation - -25 ~ 25

Hue - -25 ~ 25

Position - S T W X [position of video from this camera on the screen]

Apply All – Apply current color settings to all cameras

PTZ Configuration

CH – Camera Channels

PORT –Sets the port information for the connected camera. [Consult the

documentation provided by the camera manufacturer to obtain this

information.]

ID – Sets the PTZ ID from 1-255

PROTOCOL –Select a PTZ protocol

CAMERA

SCREEN MODE

BRIGHT

CONTRAST

SATURATION

HUE

POSITION

APPLY ALL

LIVE

STWX

CHT

9CH-16CH

PORT

4800-8N1

PROTOCOL

NONE

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 37

06/08

Spot / Sequence Configuration

Spot

Sequence - On/Off [Sequence through selected cameras].

Camera - Select cameras to include in sequence.

Interval – 1 ~ 60 seconds [Set the sequence interval time].

Current – Camera 1 ~ Camera 16 [Set current camera].

Sequence

Page Dwell Time - 0 ~ 100 seconds [Set the sequence interval time for full

page].

Camera Dwell Time - 0 ~ 100 seconds [Set the sequence interval time for

individual cameras].

Custom Select - 1 ~ 16 / All [Select cameras to display in on Spot Monitor].

NO.

SEQUENCE

OFF

CAMERA

ALL

INTERVAL

2 SEC

SPOT

SEQUENCE

CURRENT

CAM 1

PAGE DWELL TIME 2 SEC

CAMERA DWELL TIME

CUSTOM SELECT

2 SEC

ALL

Setup

______________________________________________________________________________________________

Monitor Configuration

Date/Time – On / Off [On-screen Date/Time display].

Camera Label Options – All / Name / Number / Off.

Border Color - Black / White / Grey [Set the border color of the grid for the

main channel display].

Transparency Setup – 0 ~ 20 [Set the transparency of the setup windows].

CCTV Type – VGA / Analog [Set the Display Monitor type].

VGA Resolution – Set monitor resolution.

Screen Position – Adjust the screen position of the main channel display.

VGA Adjustment – Set brightness, contrast, saturation and position.

DATE/TIME

CAMERA LABEL OPTIONS

BORDER COLOR

TRANSPARENCY SETUP

CCTV TYPE

VGA RESOLUTION

SCREEN POSITION

VGA ADJUSTMENT

ALL

BLACK

VGA

1024X768 60Hz

STWX

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 39

06/08

Record

Record Configuration

Use Record Configuration to configure the recording schedule and frame

capture rate. In Schedule Setup, users can define the recording schedules:

• Day

• Night

• Weekend

Frame

Configure the FPS for each schedule – Day / Night / Weekend.

Size – 352 × 240 / 704 × 240 / 704 × 480. [Resolution]

R-Mode - C / M / C+M / N/A. [Recording Mode](Default is C+M)

C: Continuous

M: Motion / Event

C-FPS – 1-30 [Continuous Recording FPS]

M-FPS – 1-30 [Motion Recording FPS]

Quality – Low / Normal / High / Ultra

Post-A – 5-100 seconds [Post Alarm Recording]

CHT

FRAME SCHEDULE AUDIO INSTANT

DAY

SIZE

704X240

R-MODE

C+M

QUALITY

HIGH

POST-A

5 SEC

(Used FPS) C: 128/128 M: 64/128

C: CONTINUOUS, M: MOTION/EVENT

C-FPS

M-FPS

INFORMATION

9CH-16CH

Setup

______________________________________________________________________________________________

Schedule

Night – Set nighttime (ex. If 18:00 to 6:00 is defined as nighttime, 6:00 to 18:00

is defined as daytime).

Weekend –Define weekend.

Audio

1. Specify volume level and audio settings for recording according to preset

schedules and live or search mode.

2. Select Enable/Disable for each schedule mode.

3. Select Enable/Disable for live/search mode.

4. Set the audio Volume.

FRAME SCHEDULE AUDIO INSTANT

FROM

00:00:00

N/A

00:00:00

N/A

NIGHT

WEEKEND

INFORMATION

BY DEFAULT DAYTIME IS 24/7. TO SET UP A 

DIFFERENT SCHEDULE FOR NIGHTTIME OR WEEKENDS

ADJUST THE NIGHTIME AND WEEKEND OPTIONS

ABOVE.

FRAME SCHEDULE AUDIO INSTANT

DISABLE

DAY

NIGHT

WEEKEND

LIVE

VOLUME

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 41

06/08

Instant Recording

Configure the recording settings for Instant Recording to use when it is

activated.

FPS – Set the FPS (recording rate per camera).

Quality –Set the picture quality (affects file size).

Size – Set the resolution of the video image.

Using Instant Recording

To activate Instant Recording on the DVR:

1. Press the button with the red dot on the front panel of the DVR or remote

control.

2. Select OK to Force Continuous Recording.

3. Press ENTER. The screen will display the Instant Record message.

To cancel Instant Recording on the DVR:

1. Press the button with the red dot on the front panel of the DVR or remote

control.

2. Select OK Resume Scheduled Recording.

3. Press ENTER.

FRAME SCHEDULE AUDIO INSTANT

NORMAL

352X240

FPS

QUALITY

SIZE

Setup

______________________________________________________________________________________________

Motion/Event Configuration

Motion / Event Configuration has four sections; Input, Sensor, Action, and

Alarm Monitor. When an event comes in (Input) the DVR records the image

according to its settings (Camera Configuration) and triggers an alarm (Action).

Input

CH – S Channels 1-8 / T Channels 9-16

MOTION – On/Off [Specify whether to use motion input or not.]

SENS (Sensitivity) – Low / Normal / High / Highest

AREA – Define the motion detection area.

SENSOR – Associate a sensor with the camera channel.

V-LOSS (Video Loss) – Select a channel to report video loss on.

TEXT-IN – On / Off

INPUT SENSOR ACTION ALARM MONITOR

CHT

9CH-16CH

MOTION

SENS

NORMAL

V-LOSS

OFF

TEXT-IN

AREA

SENSOR

OFF

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 43

06/08

Setting Up Motion Detection Recording

To record data only when motion is detected:

1. Press Setup on the front of the DVR or remote control.

2. Select Record > Motion/Event Configuration and set MOTION to On.

3. Set SENS level. [Normal / High / Highest / Low].

4. Select AREA and press ENTER to set a motion area (global setting;

each channel can be configured individually).

5. Use the arrow buttons and the numeric buttons 1, 2 and 3 to navigate

the motion area grid. (Selected motion areas are highlighted green on

the grid.)

1 = Set Mode 2 = Clear Mode 3 = Move Mode

a. Press 3 on the front of the DVR or remote control.

b. Use the arrow buttons to move the cursor to the desired location on

the screen.

c. Press 1 on the front of the DVR or remote control.

d. Use the arrow buttons to highlight the desired motion detection area.

e. Repeat the steps above to create additional motion detection areas.

6. When finished selecting motion areas press ENTER on the front of the

DVR or remote control to save changes.

7. Repeat as necessary for each channel.

8. When motion area setup is complete select SAVE to save settings and

exit setup.

INPUT SENSOR ACTION ALARM MONITOR

CHT

9CH-16CH

MOTION

SENS

NORMAL

V-LOSS

OFF

TEXT-IN

AREA

SENSOR

OFF

Setup

______________________________________________________________________________________________

Sensor

Sensor Setup

1. Use the arrow buttons to select Sensor 1 and press ENTER to change

to N/O (Normally Open) or N/C (Normally Closed).

2. Repeat for all sensors.

3. Select SAVE and press ENTER to save settings and exit Sensor Setup.

Relay Setup

1. Use the arrow buttons to select Relay 1 and press ENTER to turn OFF

or ON.

2. Repeat for all relays.

3. Select SAVE and press ENTER to save settings exit Sensor Setup.

INPUT SENSOR ACTION ALARM MONITOR

NO.

SIGNAL

SET CLEAR

NO.T

TYPE

N/O

9CH-16CH

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 45

06/08

Action

CH – S Channels 1~8 / T Channels 9~16

Alarm – OFF / 1~4 [Associate an alarm relay with a channel].

Delay – 0~100 Seconds [Delay time before relay activates].

Duration – 0~100 Seconds [Time that the relay is active].

Preset – 0~100 [Enable PTZ camera to move to a preset position when an

event occurs. See PTZ Control for more information.]

Event Popup – ON / OFF [Displays channel associated with event].

Alarm Monitor

Send event information to a remote client using the Alarm Monitor software.

1. Select Enable and press ENTER to select ON.

2. Enter the IP Address of the remote client.

3. Enter the Port Number.

INPUT SENSOR ACTION ALARM MONI TOR

ALARM

OFF

PRESET

OFF

CHT

DELAY

OFF

DURATION

OFF

EVENT POPUP OFF

9CH-16CH

INPUT SENSOR ACTION ALARM MONI TOR

IP ADDRESS

0 . 0 . 0 . 0

PORT

2001

NO.

SEND TO ALARM MONITOR ON

Setup

______________________________________________________________________________________________

Network

Network Configuration

Configure network settings.

DHCP Select – System gets IP address from DHCP server.

Clear – User must manually define a static IP address. Contact the

network administrator for this information.

Host Name – The DVR name.

IP Address – DHCP or Static. Contact your network administrator for this

information.

DDNS Server – The current DDNS server.

ID – Username for the DDNS server account.

Password – Password for the DDNS server account.

Host Name – Hostname for the DDNS server account.

HOST NAME dvr

000.000.000.000

DDNS SERVER

PASSWORD

HOST NAME

ROUTER IP

STATUS

HWddns.com

user

****

host

OFF

CHECK UNCHECKED

DHCP

IP ADDRESS

SUBNET MASK

GATEWAY

DNS

DDNS

NETWORK

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 47

06/08

Serial Configuration

Configure connected serial devices.

Type – None / External Controller / Text-In

External Controller

Model – Select appropriate model from the supported list.

Port – [Baud Rate / Data Bit / Parity / Stop Bit]

Text-In

Target – [User Defined]

Port – [Baud Rate / Data Bit / Parity / Stop Bit]

Supported External Controller Models:

• Honeywell HJZTP

• Hitron HID2404CEN

• Hunt HKB-300

• 7323 DKB-06

• 05-255

• WC-2500/3000J

• WTX-1500/2000

RS485

RS232

EXTERNAL CONTROLLER

NONE

9600-8N1

TYPE

TARGET

PORT

TEXT-IN

NONE

9600-8N1

TYPE

MODEL

PORT

Setup

______________________________________________________________________________________________

Client Configuration

Configure general remote access.

Remote Port – Use this port number when configuring remote access

software. The default port is 2000 but can be changed.

Web Port – Used for remote connections using a web browser. This port

should be open on the router. Default web port is 80.

Remote Config – Enable to allow an administrator to change configurations

using remote access software.

Max Transfer Speed – Set network bandwidth. If the network is low speed, set

this value as the network (aka. Bandwidth Throttling).

2000

ENABLE

100 Mbps

REMOTE PORT

WEB PORT

REMOTE CONFIG

MAX TRANSFER SPEED

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 49

06/08

E-mail Configuration

The DVR can send an email notification to up to six defined e-mail addresses

when an event happens.

E-mail Server – DVR/SMTP [Configure the DVR to use selected e-mail server.]

Schedule – On/Off [Enable to send e-mail notifications only for events that

occur within a specified range of time.]

Time – Define the time of day to send e-mail notification of events (example:

19:00-6:00 – after business hours).

Option –Define the type of event that will trigger an e-mail notification.

Pic – Enable to send a picture of the event.

E-mail Address – Enter the e-mail address.

SMTP SERVER

USERNAME

email@ddnsdvr.com

ddnsdvr.com

USERID

****

MAIL SERVER

USER NAME

USER E-MAIL

SERVER

PORT

PASSWORD

19:00:00 ~ 08:00:00

SCHEDULE

TIME

E-MAIL SERVER

OPTION

SET

NO.

PIC.

OFF

E-MAIL ADDRESS

email@ddnsdvr.com

MOTION

SENSOR

VIDEO LOSS

TEXT-IN

POWER

SETUP

DISK FULL

SMART

Setup

______________________________________________________________________________________________

Information

System Log View

Displays system log information.

Status View

Displays status screens for:

Disk

Record

Audio

USB-EXPORTPREV NEXT

NO.

0317

0316

0315

0314

0313

0312

0311

0310

0309

BEGIN DATE

07/17 12:00:21

07/17 12:00:11

07/17 10:33:14

07/17 10:32:45

07/17 10:22:41

07/17 10:21:12

07/17 10:11:07

07/17 10:11:01

07/17 10:01:00

SYSTEM LOG

Logout

STATUS DISK

CONTENT

RECORDING START

RECORDING END

DISK CAPACITY

USED SPACE

AVAILABLE SPACE

HDD OVERWRITE

STATUS

07/06/07 12:55:47

07/11/06 13:05:00

249GB

533MB (0%)

249GB (100%)

ENABLE

STATUS RECORD

CAM

FPS

10/15

4/4

4/2

4/0

RESOLUTION

352X240

QUALITY

NORMAL

STATUS AUDIO

NO.

RECORD

OFF

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 51

06/08

Version View

Displays system information and software version information for the DVR.

VIDEO FORMAT

DVR PROGRAM

PTZ MODULE

DRIVER MODULE

FIRMWARE

MAC ADDRESS

VIDEO MUX

VIDEO CODEC

VIDEO I/O

NTSC

2.5.5.H15

2.0

7.01-16-N

6.02.21

00:19:19:01:04:8D

51005.0

60115.0

40618.0

Operation

______________________________________________________________________________________________

Operation

Searching Recorded Data

Search recorded video on the DVR to find a specific time or event.

1. Press the Search key on the front of the DVR or the remote control to enter

Search Mode.

2. Select Target media (HDD, DVD-RW, USB)

3. Select the desired search method.

4. Select Exit to return to Live Mode.

EXPRESS SEARCH

EVENT SEARCH

JUMP TO FIRST SAVED DATA

JUMP TO LAST SAVED DATA

DAY.LIGHT SAVINGS SEARCH

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 53

06/08

Search Methods

Express Search

Users can select a specific date and time of recorded data to search.

1. Select Express Search.

2. Select a Date from the list and press ENTER.

3. Define time by using the arrow buttons to move the bar across the grid

(Highlighted time blocks represent recorded data). Press ENTER to go

from the desired hour to the minutes selection.

4. Select Play.

5. Use the play controls on the front of the DVR or remote control to search

video.

Event Search

Define a search based on event recorded data.

1. Select Event Search.

2. Define the date and time to search.

3. Define the type of event occurrences to include in search.

4. Define cameras to include in search or select All cameras.

Daylight Savings Search

Daylight Savings Search is used to find recorded data after switching the time

at the end of Daylight Savings Period. The System will record data with the

same time stamp for two hours when they are repeated. If any overlapped time

data exists the system will display the times on this page.

PREV NEXT

NO.

DATE

2007 / 7 / 17

2007 / 7 / 16

2007 / 7 / 15

2007 / 7 / 14

2007 / 7 / 13

2007 / 7 / 12

2007 / 7 / 11

2007 / 7 / 10

2007 / 7 / 09

2007 / 7 / 08

Operation

______________________________________________________________________________________________

Go To First

View the earliest recorded data

Go To Last

View the most recent recorded data

Go To Jump

View video from a 24 hour period

Note When DVD-RW is selected as the target media, only Express Search,

Go To First Recorded Data and Go To Last Recorded Data Search

options are available.

Search Details

In Search Mode users can access the Popup Menu for extended options; see

the Popup Menu section.

Search Popup Menu

Use to access display options in Search Mode.

1. Press ENTER to highlight a channel box.

2. Use the arrow keys to select the desired channel.

3. Press ENTER again to open the Popup Menu.

Time Selection – Change the

Date/Time to search.

Live Cam Change – Change the

channel box to display the selected

live channel.

Play Cam Change – Change the

channel box to display the selected

playback channel.

Save JPEG – (disabled)

TIME SELECTION

LIVE CAM CHANGE

PLAY CAM CHANGE

SAVE JPEG

EXIT

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 55

06/08

Monitoring

Select Channel

• Use the number keys on the front of the DVR or remote control to select

specific channels for full screen display.

(ex. Press 1 to display channel 1)

• Press the LIVE key to change the display mode. Display switches in the

following order when the LIVE key is pressed successively.

• Press the ROTATE key to rotate through to the remaining channels within the

display mode or rotate the display configuration.

Operation

______________________________________________________________________________________________

Live Popup Menu

Use to access display options in Live Mode.

1. Press ENTER to highlight a channel box.

2. Use the arrow keys to select the desired channel.

3. Press ENTER again to open the Popup Menu.

Hide Live View – On/Off [Hide live

display of the selected camera]

Record Change – Change the

record settings for that channel

including FPS, quality, and

resolution.

Sequence – Start/Cancel camera

sequence.

HIDE LIVE VIEW - ON

RECORD CHANGE

SEQUENCE

EXIT

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 57

06/08

Backup (Export)

Manual Export

Back up recorded data on a CD-RW, DVD-RW or connected USB device.

1. Press the Backup key on the front panel or remote control and log in.

2. Select TARGET media.

3. Set FROM and TO date and time.

4. Select CHANNELS to include in backup.

5. Insert media.

6. Select ESTIMATE to display estimated data size and free space available.

7. Select WRITE to start backup.

Warning Do not shutdown the system during the backup process.

ESTIMATE WRITE HELP

TYPE

TARGET

FROM

CHANNEL

RECORDING START TIME

2007/07/05 10:00:00

RECORDING END TIME

2007/07/17 09:59:59

REQUIRED SPACE

FREE SPACE

MANUAL EXPORT

DVD-RW

07/05/2007 12:55:47

07/17/2007 13:30:03

ALL

0.00MB

NONE

Operation

______________________________________________________________________________________________

Play Back Backup Image

Play recorded video on a PC using the proprietary media player included with

every backup file.

1. Insert CD, DVD or connect external USB device to the PC.

2. Navigate to the files on the CD, DVD, or USB drive.

3. Double-click the DvrPlayer application.

4. Click the Open Video File icon and select the file to view from the desired

date folder.

S/W Upgrade

If you are running a Performance Series OS version 2.5.1.X or later, obtain the

latest software release and save the file to a CD, DVD or USB Device. Please

check the product web site at www.honeywellvideo.com or contact Technical

Support for the latest software. See back cover for contact information.

1. Insert a CD/DVD or USB Drive containing the update files.

2. Select System > Shutdown and select Restart.

3. Select OK to confirm Restart. The DVR will restart and automatically find

the update files.

4. Select Start when the upgrade window appears.

5. Remove the upgrade media and select OK when the Upgrade Success

window appears.

6. Restart the DVR.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 59

06/08

Save Settings

Use the System Configuration menu to export and import saved or factory

default system settings.

Save Settings

1. Press the Setup key on the front of the DVR or remote control to log in.

2. Select System > Configuration and log in.

3. Select an empty Profile and define a name for the settings configuration.

To save settings to a USB device, select Export.

4. Select Save and confirm to continue the export process.

Import Settings

1. Press the Setup key on the front of the DVR or remote control.

2. Select System > Configuration and log in.

3. Select a previously saved Profile and select Load. To import a profile

saved on a USB device, select Import.

4. Select the types of settings to import (CAMERA – RECORD – SYSTEM –

NETWORK).

5. Select OK and press ENTER on the front of the DVR to complete the

import process.

PROFILE

DEFAULT

NONE

SAVE DATE

NONE

EXPORT IMPORT

SAVE

LOAD

DEL

Operation

______________________________________________________________________________________________

PTZ Camera Control

To control a PTZ camera:

1. Press the PTZ key to enter PTZ Mode.

2. Press SETUP to open the PTZ SETUP screen.

Speed Setup – 1-8 [Set the speed that PTZ cameras move.]

Preset Setup – Move/Set [Create preset PTZ camera positions.]

Preset Tour – [Create a tour of preset PTZ camera positions.]

Pattern Setup - [Create a custom PTZ Pattern]

Pattern Tour - [Create a Pattern (mimic) tour]

Auto Focus – [Modify Auto Focus settings]

Power – ON/OFF

Light – ON/OFF

Create PTZ Preset Position

1. Set up a PTZ camera in Camera > PTZ Configuration.

2. Press the Exit key to exit Setup.

3. Press the PTZ key to enter PTZ Mode.

4. Select a PTZ enabled camera.

5. Press the Setup button to display the PTZ setup menu.

6. Select Preset Setup.

7. Select MOVE to move the camera to the preset position.

8. Select a PTZ Preset ID number and select OK to save.

SPEED SETUP

PRESET SETUP

PRESET TOUR

PATTERN SETUP

PATTERN TOUR

AUTO FOCUS

POWER

LIGHT

EXIT SETUP

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 61

06/08

NOTES:

Remote Software

______________________________________________________________________________________________

Remote Software

Set Up a Remote Connection

The administrator and up to eighteen additional users (four simultaneously)

can access the DVR remotely using software installed on a personal computer.

Configuring the DVR

1. Press the Setup key on the front of the DVR or remote control to log in.

2. Select Network > Client Configuration (See the Client Configuration

section of this manual for more details).

3. Change port settings or write down current port settings.

4. Select Save to save current settings.

5. Select Network Configuration (see the Network Configuration section of

this manual for more details).

6. Enable or clear DHCP depending on the network (Ask the network

administrator for assistance).

7. If DHCP is cleared - define the IP address and additional network

information.

8. If DHCP is enabled - write down the IP address supplied by the DVR

system.

Note If the DVR does not display the IP Address after setting DHCP to ON,

Select Save to change the network and open Network Configuration

again.

9. Select Save to save current settings.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 63

06/08

Configuring the DVR Continued

1. Go to System > User Configuration> Client to add remote users.

Note Only users defined in System > User Configuration > Client will be

able to access the system remotely.

2. Select Save to save current settings.

Configuring a Remote PC

1. Install the Remote Software on a PC using the disk provided with your

DVR.

2. Open the Remote Software. The Local Setup window will open

automatically.

3. Click New.

4. Select HRDP Performance Series as the Site Type.

5. Enter a name for the system in the Site Name box.

6. Enter the IP address of the DVR - found in Network > Network

Configuration on the DVR.

7. Enter the Port number found in Network Client Configuration on the DVR

system (default is 4000).

8. Click OK.

9. Enter the user name and password of an authorized remote user as

defined in System > User Configuration > Client on the DVR.

Note User Name and Password are both case sensitive.

10. Click Connect.

Default Remote Software Log In Information

The default administrative log in information for the remote software:

User Name: admin1

Password: <none>

Remote Software

______________________________________________________________________________________________

Access Remote Connection

1. Open the Remote Software.

2. Click on the icon of the server as defined previously.

3. Enter the user name and password of an authorized remote user as

defined in the System > User Configuration > Client menu on the DVR.

Note User Name and Password are both case sensitive.

4. Click Connect.

Using the Remote Software

Setting the Time and Date

The Remote Software uses the system time of the PC. If the system time is not

correct, follow the steps below to change it.

1. Exit to Windows by clicking the Exit button on the Live View screen and

selecting Restart in Windows Mode.

2. Open Windows Explorer. Do this by right-clicking the My Computer Icon

(located on the top left hand corner of the Desktop) and select Explore.

3. Click Control Panel to open it. If you do not see Control Panel listed, click

My Computer to expand the folder tree.

4. Double-click Date and Time inside Control Panel.

5. Adjust the Date and Time.

6. When finished, close all open windows and restart the PC. Do this by

clicking Start (located on the lower left hand side of the Desktop) and

selecting Shut Down.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 65

06/08

Live View Screen

Each time the software is restarted, the program defaults to the Live View

screen. The following diagram outlines the buttons and features used on the

Live View screen. It is important to be familiar with these options as this is the

screen displayed the majority of the time.

Camera Display Buttons

Current Date & Time

Displays

Connected Users

Status of/Activates

Control Outputs

Status of/Activates

larm Sensors

Menu Buttons

Remote Software

______________________________________________________________________________________________

Camera View

The Camera status for each camera is displayed on the upper right corner of

the video display area.

Recording Status Indicator

The following are the different states for each camera:

Recording Displayed when the camera is currently being

recorded to the DVR.

Motion Detection Displayed when a camera (set up for motion

detection) detects motion.

Display Displayed when the video from the camera is

currently not being recorded to the DVR.

Camera No. and Name

Current Recordin

Status

Special Recording Status

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 67

06/08

Screen Division Buttons

The Screen Division buttons allow you to view cameras in groups such as two

by two, three by three and four by four. The button options are shown below.

1st Four Cameras View – Displays cameras 1-4 in the Video

Display Area. To return to a different Multi-Camera View, select a

different Screen Division option from the Screen Division Menu.

2nd Four Cameras View – Displays cameras 5-8 in the Video

Display Area. To return to a different Multi-Camera View, select a

different Screen Division option from the Screen Division Menu.

3rd Four Cameras View – Displays cameras 9-12 in the Video

Display Area. To return to a different Multi-Camera View, select a

different Screen Division option from the Screen Division Menu.

4th Four Cameras View – Displays cameras 13-16 in the Video

Display Area. To return to a different Multi-Camera View, select a

different Screen Division option from the Screen Division Menu.

16 Camera View – Displays cameras 1-16 in the Video Display

Area. To return to a different Multi-Camera View, select a different

Screen Division option from the Screen Division Menu.

Full Screen – The Full Screen Option allows you to view the Video

Display Area using the entire viewable area on the monitor. When

this is selected, no menu options are visible. You can activate the

Full Screen Option by clicking Full Screen within the Screen

Division Menu. You can deactivate Full Screen mode by right-

clicking on the screen.

Auto Sequence – Sequences through the Screen Divisions sets.

For example, selecting the 1A and then the Loop button will

sequence through 1A, 2A, 3A, 4A and then repeat.

Remote Software

______________________________________________________________________________________________

Setup Overview

The Setup options allow the user to optimize the DVR by adjusting things like

camera names, alarm setup, recording schedules and more. It is extremely

important that the DVR is set up correctly for several reasons.

Recording

Schedules

Increase the amount of pertinent recorded video that is saved

on the DVR by optimizing the recording schedule.

Camera

Naming

Name each camera so the location can be easily identified

and include any other pertinent information that may be

helpful when viewing it on the Video Display Area.

Event Input Optimize the type or recording by configuring the system to

begin recording or trigger an alarm when a motion or sensor

event occurs.

Setup Screen Overview

This is an expandable list with multiple levels. Click the + box next to HRDP

Performance Series Setup to expand the menu tree and access the Camera,

Record, Sensor Setup and System Setup details. Many of the setup options are

the same in the remote software and in the DVR system. Click Apply after

changing any settings.

Camera Setup

The Camera Setup display allows the user to define camera names, power on

and off cameras and define specific cameras as hidden.

Title - Enter camera name - up to seven characters.

Enable - ON/OFF [Enable individual cameras.]

Hidden –On/Off - On will hide the camera from logged out users.

PanTilt Setup

The PanTilt (PTZ) Setup display allows the user to define the appropriate

protocol for connected cameras with PTZ capabilities. Since setup varies

between different PTZ cameras, refer to the instructions supplied by the

camera’s manufacturer to complete setup.

ID – 1 ~ 255 [Set the PTZ ID]

PROTOCOL –Select a PTZ protocol

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 69

06/08

Sequence Setup

The Sequence Setup display allows the user to set the parameters for:

Page Dwell Time - 1 ~ 100 seconds [Set the sequence interval time for full

screen on Main Display]

Camera Dwell Time - 1 ~ 100 seconds [Set the sequence interval time for

individual cameras on Main Display]

Channel - 1 ~ 16 / All [Select cameras to display in Main Display]

SPOT Setup

The SPOT Setup display allows the user to define the sequence display for

individual Spot Monitors. This allows users to use different Spot Monitors to

display only the video necessary for the person watching the Spot Monitor.

Sequence - On/Off [sequences through selected cameras]

Interval – 1 ~ 60 seconds [Set the sequence interval time].

Channel - Select cameras to include in sequence.

Record Setup

Time Setup

Day/Night/Weekend – Adjust the FPS and picture quality for each schedule

individually.

[C] FPS – 0 ~25 [Define a global FPS setting for continuous recording or set

individually for each channel.]

[M] FPS – 0 ~25 [Define a global FPS setting for motion/event recording or set

individually for each channel.]

Record Mode – Continuous / Motion Event / C/M/E[ALL] /N/A

Quality – Low / Normal / High / Ultra [Define a global quality setting or set

individually for each channel.]

Post Recording – 0 99 seconds [Recording time after event.]

Continuous Frame –Displays the actual FPS / maximum FPS for continuous

recording

Event Frame – Displays the actual FPS / maximum FPS for event recording.

Remote Software

______________________________________________________________________________________________

Schedule Setup

Night – Set night time (ex. If 18:00 to 6:00 is defined as night time, 6:00 to

18:00 is defined as day time)

Weekend –Define weekend days

Audio Setup

Specify volume level and audio settings for recording according to preset

schedules and live or playback mode.

Audio Day - Enable/Disable

Audio Night - Enable/Disable

Audio Weekend - Enable/Disable

Audio Live - Enable/Disable

Audio Playback - Enable/Disable

Volume – 0 ~14

Motion / Event Input

Motion / Event Setup allows you to enable recording or relay response on

Motion, Sensor Event, and Video Loss

Motion

Enable– On/Off [Enable Event Input]

Sensitivity – 1~5 [Define Motion sensitivity level. 1=least sensitive]

Area – Red=selected, White=clear. Click to select/clear boxes.[Create or clear

the motion area on the camera]

Sensor

Sensor – ON / OFF [Enable recording on sensor event.]

Sensor Detail – All / 1~16 / All Channel [Associate sensors with channels.

Select the All check box to associate all sensors used to activate recording for

that channel; Select the All Channel check box to associate the selected

sensors with all channels.]

Video Loss

VideoLoss – ON / OFF [Enable event on video loss.]

Video Loss Detail - All / 1~16 / All Channel [Associate video loss “V” alert with

specific viewed channels. Select the All check box to prompt all channels with

video loss to provide a “V” alert to the viewed channel; Select the All Channel

check box to associate the selected channels to report a “V” alert when video

loss occurs.]

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 71

06/08

HDD Setup

Disk Overwrite – Enable / Disable [Select the check box to enable the DVR to

write over old data when the hard drive is full.]

Disk Full Warning – Enable/Disable [Enable Disk Full Warning for notification

when the HDD becomes full and HDD Overwrite is disabled.]

Remain Time – 0~60 [Define the amount of remaining recording time to

trigger the Disk Full Warning.]

Used Space – 80~99 [Define the percentage HDD used that triggers the Disk

Full Warning.]

Disk Full Alarm – 0~8 [Define the relay that will trigger when the HDD is full.]

Disk Full Buzzer – Enable/Disable [Enable a continuous buzzer to sound for

Disk Full Warning.]

Disk Full Message– Enable/Disable [Enable a popup message to display for

Disk Full Warning.]

Sensor Setup

Sensor

Sensor – N/O / N/C [Set sensors to Normally Open or Normally Closed]

Alarm Out – Off / On [Set Relay switches to Off or On]

Note For more information, see the

Record > Motion/Event Configuration > Sensor section.

Remote Software

______________________________________________________________________________________________

System Setup

User Management

ID – Type a new user name. (Available for user1 through user18.)

Password – Type a password for each user.

Permissions - Enable / Disable

Live

PTZ

Playback

Backup

Health

Live Authorization – Enable live access for specific channels.

PTZ Authorization – Enable PTZ control for specific channels.

Firmware Upgrade

The HRDP Performance Series DVR can be remotely upgraded with the latest

firmware. Download the firmware file to your PC, locate the file on the Firmware

Upgrade screen and click Upgrade.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 73

06/08

Search Overview

Note Audio Channel buttons are only viewable when one camera is

selected.

Screen Division Buttons

Options

Play Controls

ctual Date/Time

Date/Time

Hour Minute Control

Calendar Button

Select Cameras

Remote Software

______________________________________________________________________________________________

Play Controls

Back Frame Moves video back one frame

Rewind Rewinds video

Stop Stops video playback

Play Plays video

Forward Frame Moves video forward one frame

Performing a Basic Search

1. Select a date using the Calendar button on the Date Display.

2. Select a time using the hour and minute control bars.

3. Select one or more cameras.

4. Click Play. (Video can be played forwards, backwards, or frame-by-frame.)

Adjust the Brightness of an Image

1. Pause the video and select an image to adjust by double-clicking the

desired image. (Multiple images cannot be adjusted at one time.)

2. Move the Bright slide bar to the right or left to adjust the brightness.

3. Reset the Brightness by moving the slider back to the center of the bar.

Zooming in on an Image

1. Pause the video and select an image to adjust by double-clicking on the

desired image. (Multiple images cannot be adjusted at one time.)

2. Move the Zoom slide bar to the right or left to zoom in or out of an image.

3. Reset the Zoom by moving the slider back to its original position on the

bar.

Rewind

Stop

Play

Back Frame Forward Frame

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 75

06/08

Zooming in on a Portion of an Image

1. Using the mouse pointer, point to the area of interest on the image and

click the right mouse button.

2. Keep clicking the right mouse button to zoom in further.

3. Continue clicking the right mouse button and the image zoom will cycle

back to the original size.

Printing an Image

1. Using the Search screen, locate a frame to print and double-click the

image.

Note Only one camera can be selected at a time for this function to work.

2. Click the Print button. (A Print Preview window appears. Depending on the

printer being used, there may be several printing options available. Refer

to the printer manual for more information.)

3. Click the Page Option button to add a memo to the printout and set the

paper size and orientation.

4. Click the Print button to print the selected images.

Note The message “NO DEFAULT PRINTERS INSTALLED” will display if

no printer is installed.

Save Clip

The DVR can export single images in the .JPG file format, save video clips in

the .AVI format, or output to a VCR using the s-video port. The .JPG and .AVI

file formats are extremely common with universal computer support making

them ideal formats to use. A digital signature is also attached to every .JPG and

.AVI file exported by the DVR for use with the bundled Digital Verifier

application. This function is unique to the DVR and its verification software and

should not interfere with viewing the files using other applications.

JPG: The format (.JPG) is optimized for compressing full-color or grayscale

photographic images. .JPG images are 24-bit (16.7 million color)

graphics. .JPG is used to export a single image or frame.

AVI: .AVI image data can be stored uncompressed, but it is typically

compressed using a Windows-supplied or third party compression

and decompression module called a codec. .AVI files save a video

clip.

Remote Software

______________________________________________________________________________________________

Saving a Video Clip

1. Perform a basic search to locate the desired clip.

2. Click Save to open the Export Wizard.

3. Click JPEG or AVI to select the desired file type.

AVI File

a. Select Mark Digital Signature.

b. Select an Audio Channel if

available.

c. Select a Compression

Codec. Each codec provides

different levels of quality,

compatibility and file-size.

d. Enter the duration (seconds)

to record. Although 50 is the

longest time displayed, a longer

recording may be entered

manually.

e. Select Quality - 50>100.

When size is not an issue, set

quality to 100.

JPEG File

a. Select Mark Digital Signature.

4. Click Next.

5. Define the file name in the Export Name box.

6. Define the location to save the file by using menu tree below Export Path.

7. Click Next.

8. A message displays to confirm that the save was successful.

9. Click OK. The Export Wizard will display the name, location and size of the

file.

10. Click Finish.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 77

06/08

Status Search

The Status Search option displays a timeline in graph format. Scroll through

multiple cameras and easily locate hours with recorded video.

Performing a Status Search

1. In Search mode, click Status.

2. Click the Date button to open the calendar and select a date.

3. Click along the orange recorded video block to select a desired camera or

time frame.

4. After locating the desired video, close the Status Search window and use

the playback controls to play forward, reverse or frame-by-frame.

Cameras

24 Hours (0-23) AM & PM

Recorded video displayed in Orange

Remote Software

______________________________________________________________________________________________

PTZ Overview

Accessing PTZ Menus

Some protocols support the ability to access the Internal PTZ Onscreen Menu.

Click PAN/TILT on the remote software Live View screen to open the graphical

PTZ controller.

Some protocols support the ability to access the

Internal PTZ Onscreen Menu.

Since every PTZ camera is different, the functions of

these options can vary slightly.

The Performance Series DVR provides an easy way

to access the cameras options. For explanations of

what those options are please refer to the manual

that came with the camera.

Note Use the arrow buttons on the PTZ

controller move through the PTZ Menu

options and/or highlight options.

Controlling a PTZ Camera

• The first method is to use the graphical PTZ Controller that appears when

PAN/TILT is clicked on the Live View screen.

• The second method is to use the mouse to control the camera directly

from the live video display.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 79

06/08

Using the Graphical PTZ Controller

• Use the Arrow buttons to control the direction of the PTZ camera.

• To select a new camera, click the video display of a different camera on

the Live View screen.

Note Eight directions are available only for select protocols. Only four of

the PTZ Control buttons work for all protocols (UP, DOWN, LEFT,

RIGHT).

Activate

Corresponding

Preset Position

Current

Camera

Arrow Buttons

Remote Software

______________________________________________________________________________________________

Using the On-screen Compass

1. Click PAN/TILT on the Live View screen.

2. Control the PTZ by dragging the mouse on the screen in the desired

direction.

A green line will appear to show the direction the PTZ will move. The

shorter the line the less the PTZ will move. The longer the line the more the

PTZ will travel in the specified direction.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 81

06/08

Web Viewer Overview

The DVR allows access to the video using Microsoft® Internet Explorer®

browser 6+.

To log in to the DVR server from the Web Viewer, a user account must be made

for the user. This ensures that only authorized users are allowed to log in. In

addition, each user can be assigned different privileges that allow or deny

access to different functions.

Activate Commands

Enable/Disable Camera Display

Screen Division Buttons

Remote Software

______________________________________________________________________________________________

Connecting to a DVR Using Web Viewer

1. Open Microsoft Internet Explorer.

2. Enter the IP address of the DVR into the Address bar.

3. When attempting this for the first time you will be asked to accept an

Active X installation. Click Yes.

Note If you receive a message saying Internet Explorer security settings do

not allow you to download Active X components then you will need to

adjust the browser security settings. Add the IP address of the DVR

to the trusted sites list inside Internet Explorer settings. Contact the

System administrator for additional help with adjusting Internet

Explorer settings.

4. When the Web Viewer finishes loading, select one or more cameras (or

select a screen division button).

5. Click GO!

6. A login window will appear. Enter the Username and Password of an

authorized user.

7. The cameras will now display.

Closing the Web Viewer

To exit the Web Viewer close Internet Explorer.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 83

06/08

Digital Verifier Overview

.JPG images and .AVI video files that are exported from the Digital Video

Recorder are automatically embedded with a digital signature. Digital

Signatures are a way to verify the authenticity of the images to ensure that they

have not been tampered with or edited in any way. Included on the Software

Installation DVD, supplied with the DVR, is the Digital Signature Verification

program. This program can be installed on any computer and loads an image

in question.

Using the Digital Verifier

1. Open the Digital Verification program by selecting Start > Programs >

HRDP > Digital Verifier > Digital Signature Verifier.

2. Click the Browse button to load the .JPG image.

3. Enter the Site Code of the DVR that the image was originally extracted

from. (The Site Code is specified in the System Configuration Menu)

4. Click Verify to continue or Close to close the window without verifying.

If the image has not been tampered

with, a blue square will appear around

the image with the message “Original

image file.”

If the image has been tampered with,

a red square will appear around the

image with the message “Entire

image changed or wrong SITE

CODE.”

Appendix

______________________________________________________________________________________________

Appendix

DVR FAQ

General

Q. What does Embedded Linux mean?

A. Embedded Linux means that the operating system of the DVR has been

imprinted into the CPU (Central Processing Unit). This means that the

system response time is faster, more stable, and that the core of the DVR

is protected against external factors, such as virus.

Q. Is the DVR upgradeable by CD or network?

A. Yes.

Q. How can I reset the DVR to the factory default settings?

A. Load the factory default settings from the System Configuration Menu.

Live Monitoring

Q. Is it possible to monitor the live video of specific cameras?

A. You can set the camera sequence through Spot/Sequence Configuration

or by connecting to one of the 3 spot monitor outputs on the rear of the

DVR unit.

Recording

Q. How do you record?

A. For information on this topic view the Recording Configuration section of

this manual.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 85

06/08

Recording Continued

Q. What is Time Recording?

A. Time recording is recording scheduled to occur regardless of whether a

motion or alarm event occurs.

Q. What is Event Recording?

A. Event Recording is recording which is activated when an event (motion or

alarm) occurs.

Searching and Playing Video

Q. How do I play back recorded video?

A. For more information on this topic, see the Search section of this manual.

Q. Is it possible to back up recorded video?

A. Yes, for more information on this topic see the Backup section of this

manual.

Backup

Q. Is it possible to back up to DVD media?

A. Yes, you have DVD-RW installed in your DVR.

Q. Can I back up to a USB memory stick?

A. Yes, for more information on this topic view the Backup section of this

manual.

Network

Q. Does it support dynamic IP?

A. Yes. Enable DHCP in Network Configuration.

Q. Mail is not sent out.

A. Please check all the settings in the Network E-Mail Configuration.

Miscellaneous

Q. What types of cameras can be used?

A. The Honeywell Performance Series DVR supports either NTSC or PAL

analog cameras. Both standards may not be used simultaneously.

Appendix

______________________________________________________________________________________________

Troubleshooting

Problem Possible Solutions

No Power

Check the power cord connections

Check power at the outlet

No Live Video

Check camera video cable and connections

Check monitor video cable and connections

Check camera power

Check camera lens setting

Live Video Too Bright If a cable is attached to the video channels looping

output, make sure that it is properly terminated.

DVR has stopped

recording

The HDD is full, delete video or set the DVR Overwrite

Mode to On in Disk Configuration > Overwrite.

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 87

06/08

Specifications (HRDP)

Specification 4 Channel 8 Channel 16 Channel

Video

Inputs • 4 Channel Composite • 8 Channel Composite • 16 Channel Composite

Outputs

• CCTV Monitor

(NTSC/PAL),

• CRT(VGA) Monitor

• CCTV Monitor

(NTSC/PAL),

• CRT(VGA) Monitor

• CCTV Monitor

(NTSC/PAL),

• CRT(VGA) Monitor

• S-Video (NTSC/PAL)

• 4 CH Looping

Composite

• 1 Spot CCTV Monitor

(NTSC/PAL)

• 8 CH Looping

Composite

• 1 Spot CCTV Monitor

(NTSC/PAL)

• 16 CH Looping

Composite

• 3 Spot CCTV Monitor

(NTSC/PAL)

Monitoring

Display • NTSC : 120 fps

• PAL : 100 fps

• NTSC : 480 fps

• PAL : 400 fps

Screen split • 1/4 • 1/4/7/9 • 1/4/7/9/10/13/16

Recording

Performance • NTSC: CIF(120 fps), 2CIF(60 fps), 4CIF (30 fps)

• PAL: CIF(100 fps), 2CIF (50 fps), 4CIF(25 fps)

Resolution • NTSC: CIF(352x240), 2CIF(704x240), 4CIF (704x480)

• PAL: CIF(352x288), 2CIF (704x288), 4CIF(704x576)

Compression • Enhanced MPEG-4

Mode • Motion detection, Sensor, Schedule

• Variable compression rates, recording frame, motion sensitivity

Recording

Storage media • Internal 2 x HDD (Option) • USB

Audio • 1 Channel, G.726 Compression

Playback

Mode • Multi-channel playback (Max 16ch), Simultaneous/Panorama/Smart

playback

Searching • By Channel, Time, Date, Motion Detection, Sensor Events

Remote Monitoring S/W • Remote Software / Web based viewer

Alarm • 1 • 1 • 4

Sensor • 4 • 8 • 16

Camera Control • Pan/Tilt, Zoom, Focus, Iris

Back-up • DVD+/-RW • USB

Hardware

Spec.

Size • 15.75" (W) x 3.46" (H) x 15.75" (D) (400 mm x 88 mm x 400 mm)

Weight • 15 lb (6.8 kg)W/O Packing

Power • Input Voltage is 110-230V ~ 47/63Hz 1.75-.85A

UPS • External UPS recommended

Appendix

______________________________________________________________________________________________

Performance Series DVR User Guide

______________________________________________________________________________________________

Document 800-02089 Rev B 89

06/08

NOTES:

28785AC

Honeywell Video Systems (Head Office)

2700 Blankenbaker Pkwy, Suite 150

Louisville, KY 40299, USA

www.honeywellvideo.com

℡ +1.800.796.2288

Honeywell Security UK

Aston Fields Road, Whitehouse Ind Est

Runcorn, Cheshire, WA7 3DL, UK
