X1TXP1UC 2.4GHz Module User Manual.
Horizon Hobby, LLC
4105 Fieldstone Rd
Champaign, IL 61822
1. Features
2.4GHz Frequency Hopping Spread Spectrum (FHSS) radio transceiver module
Operates in the unlicensed worldwide ISM band (2.4 GHz to 2.483.5GHz) band
Fully integrated power regulation with a wide input unregulated operating range 3V to
10V.
Fully integrated local oscillator and 12MHz 20ppm reference crystal
200mA operating current
Transmit power - 100mW EIRP
Receive sensitivity up to -95dBm
DSSS data rates up to 250kbps
1 mile operating range
Full packet assembling and disassembling
Auto transaction sequencer
Fully buffered digital interface with high voltage tolerant inputs
2. Pin description
Pin Number Name Descri
p
tion
1 GND Module Ground
2 VCE Power control monitoring
3 VIN Module DC Power
4 P21 Baseband CPU digital port P2.1
5 P33 Baseband CPU digital port P3.3
6 P17 Baseband CPU digital port P1.7
7 P32 Baseband CPU digital port P3.2
8 GND Module Ground
9 P30 Baseband CPU digital port P3.0
10 XRES Baseband CPU reset input
11 P11 Baseband CPU digital port P1.1
12 P10 Baseband CPU digital port P1.0
Page 2 of 4
3. Specifications
Parameter Value Units
Storage Temp -65 to 105 Degrees Celsius
VDD 2.4 to 3.6 Volts
Receive Sensitivity -95 dBm
Transmit power (conducted) 18.5 dBm MAX
Transmit power (radiated) 20 dBm MAX
Idle current 1 mA
Receive current 22 mA
Transmit current 200 mA
4. Module User Requirements
4.1 This module must be integrated into a device where the user cannot access the antenna
connector.
4.2 Only a 2.0dBi antenna can be used with this module. The antenna must meet and not exceed
the gain and pattern of the supplied folded dipole antenna.
4.3 The device must contain the following permanent labeling on the exterior of the device as
follows:
Contains FCC ID: BRWX1TXP1UC
4.4 The user manual of the device must contain the following paragraph:
Page 3 of 4
FCC Information
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IC Information
This device complies with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Caution:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
4.5 This module meets the requirements for a mobile device that may be used at separation
distances of more than 20cm from the human body. It may be used in hand-held controllers that
provide a separation distance of at least 5cm between the antenna and the body (excluding
hands/wrists). The instructions to the user for the host device must include information requiring
the product be used in a manner to ensure the appropriate separation (20cm or 5cm) between
antenna and body and requiring that the transmitter not be collocated with another transmitter.
FCC Information to OEM integrator
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user manual of the end product.
The user manual which is provided by OEM integrators for end users must include the following
information in a prominent location.
1.To comply with FCC RF exposure compliance requirements, the antenna used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons
and must not be co‐located or operating in conjunction with any other antenna or transmitter,
except in accordance with FCC multi‐transmitter product procedures.
2. Only those antennas with same type and lesser gain filed under this FCC ID number can be
used with this device.
Page 4 of 4
3. The regulatory label on the final system must include the statement: “Contains FCC ID:
BRWX1TXP1UC” or using electronic labeling method as documented in KDB 784748.
4. The final system integrator must ensure there is no instruction provided in the user manual or
customer documentation indicating how to install or remove the transmitter module except such
device has implemented two‐ways authentication between module and the host system
IC Information to OEM integrator
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user manual of the end product.
The user manual which is provided by OEM integrators for end users must include the following
information in a prominent location.
1. To comply with IC RF exposure compliance requirements, the antenna used for this transmitter
must be installed to provide a separation distance of at least 20 cm from all persons and must not
be co‐located or operating in conjunction with any other antenna or transmitter, except in
accordance with IC multi‐transmitter product procedures.
2. Only those antennas with same type and lesser gain filed under this IC number can be used with
this device.
3. The regulatory label on the final system must include the statement: “Contains IC: 6157A-
BRWX1TXP1UC “.
4. The final system integrator must ensure there is no instruction provided in the user manual or
customer documentation indicating how to install or remove the transmitter module except such
device has implemented two‐ways authentication between module and the host system.
CE Information
This product contains a radio transmitter with wireless technology
which has been tested and found to be compliant with the applicable
regulations governing a Class 1 wideband radio transmitter in the 2.400 GHz to 2.4835 GHz
frequency range.
