1.
WWAN antennas (select models)
13.
Touchpad
2.
WLAN antennas
14.
Touchpad pick buttons
3.
Dual-microphone array
*
15.
Touchpad on/off button with LED indicator
4.
Webcam LED indicator (with optional webcam)
16.
Stereo microphone in
5.
Optional 720p HD webcam
17.
Stereo headphone/line out
6.
Stereo speakers
18.
Media Card Reader
7.
HP QuickWeb button with LED indicator
19.
Hard drive activity LED indicator
8.
Wireless on/off button with LED indicator
20.
Power button with LED indicator
9.
Optical drive (select models)
21.
HP Power Assistant function key
10.
Optional RJ-11/modem port
22.
Volume mute function key
11.
(2) USB 2.0 ports
23.
Volume down function key
12.
Optional HP Fingerprint Sensor
24.
Volume up function key
* Models without optional webcam have single integrated microphone.
1.
Battery charging LED indicator
6.
RJ-45/Ethernet port
2.
HDMI port
7.
VGA/external monitor connector
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Overview
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 1
3.
USB 2.0 port
8.
Vent
4.
USB 2.0 port
9.
Power connector
5.
ExpressCard/34 slot
10.
Security lock slot
1.
Battery and access cover release latches
4.
Vents
2.
Battery bay
5.
Hard drive bay
3.
SIM card slot (select units, located inside battery bay)
HP ProBook 4530s Notebook PC
HP ProBook 4730s Notebook PC
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Overview
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 2
1.
WWAN antennas (select models)
14.
Touchpad
2.
WLAN antennas
15.
Touchpad pick buttons
3.
Dual-microphone array
*
16.
Touchpad on/off button with LED indicator
4.
Webcam LED indicator (with optional webcam)
17.
Stereo microphone in
5.
Optional 720p HD webcam
18.
Stereo headphone/line out
6.
Stereo speakers
19.
Media Card Reader
7.
HP QuickWeb button with LED indicator
20.
Hard drive activity LED indicator
8.
Wireless on/off button with LED indicator
21.
Power button with LED indicator
9.
Optical drive (select models)
22.
HP Power Assistant function key
10.
Numeric keypad
23.
Volume mute function key
11.
Optional RJ-11/modem port
24.
Volume down function key
12.
(2) USB 2.0 ports
25.
Volume up function key
13.
Optional HP Fingerprint Sensor
1.
Battery charging LED indicator
6.
RJ-45/Ethernet port
2.
HDMI port
7.
VGA/external monitor connector
3.
USB 2.0 port
8.
Vent
4.
USB 2.0 port
9.
Power connector
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Overview
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 3
5.
ExpressCard/34 slot
10.
Security lock slot
1.
Battery and access cover release latches
4.
Vents
2.
Battery bay
5.
Hard drive bay
3.
SIM card slot (select units, located inside battery bay)
At A Glance
Genuine Windows 7 versions, Genuine Windows Vista Home Basic, SUSE Linux, or FreeDOS
Thin, lightweight design with brushed aluminum finish for durability and style, wear-resistant HP DuraFinish
Full-sized spill-resistant keyboard; full separate numeric keypad on HP ProBook 4530s and 4730s
Larger Touchpad with gestures support, on/off button with LED indicator
Enhanced security features including HP ProtectTools, HP Face Recognition, optional HP Fingerprint Sensor, and
optional HP Privacy Filter
Optional HD webcam with dual-microphone array for video conferencing
HDMI port for connecting to high-resolution displays; USB 2.0 ports
ArcSoft TotalMedia Suite for playing, creating, and editing video and audio files
SRS Premium Sound optimized for high fidelity audio
Widescreen LED-backlit HD display with 16:9 aspect ratio
HP ProBook 4330s: 13.3-inch diagonal HD, BrightView optional
HP ProBook 4430s: 14.0-inch diagonal HD, BrightView optional
HP ProBook 4530s: 15.6-inch diagonal HD, BrightView optional, or HD+
HP ProBook 4730s: 17.3-inch diagonal HD+
Choice of 2nd generation Intel® Core™ i7, i5 and i3 processors, and Intel Celeron processor
HP QuickWeb for convenient online access without long boot-up times
Flexible wireless connectivity options controlled by HP Connection Manager:
Integrated HP Mobile Broadband Module
*
Integrated 802.11 b/g/n wireless LAN module
Integrated 802.11 a/b/g/n or b/g/n with Bluetooth 3.0 High Speed (HS) combo card
**
HP DayStarter for calendar display during startup
HP Power Assistant to conserve power, increase battery run-time, monitor power needs, report workforce power
consumption
BFR/PVC-free***, ENERGY STAR qualified and EPEAT TBD registered in the U.S. EPEAT status varies by
country- please see epeat.net.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Overview
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 4
* Available only on HP ProBook 4330s and 4530s with integrated graphics.
** Available on select models.
*** This notebook is brominated flame retardant and polyvinyl chloride-free (BFR/PVC-free) on notebooks that are non-
WWAN; meeting the evolving definition of 'BFR/PVC-free' as set forth in the "iNEMI Position Statement on the 'Definition
of Low-Halogen' Electronics (BFR/CFR/PVC-Free)'". Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source
is from BFRs] and < 1000 ppm (0.1%) of chlorine [if the Cl source is from CFRs or PVC or PVC copolymers]. Power
supply and power cords are not BFR/PVC-free. Service parts after purchase may not be BFR/PVC-free.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Overview
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 5
Processors
2
nd
Generation Intel Core i7 Processors
Intel Core i7-2630QM Processor (2.0 GHz, 6 MB L3 cache, 4 cores/8 threads, 45W)* †
Up to 2.9 GHz with Intel Turbo Boost Technology
Intel Core i7-2620M Processor (2.70 GHz, 4 MB L3 cache, 2 cores/4 threads, 35W)
*
Up to 3.40 GHz with Intel Turbo Boost Technology
2
nd
Generation Intel Core i5 Processors
Intel Core i5-2540M Processor (2.60 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W)
*
Up to 3.30 GHz with Intel Turbo Boost Technology
Intel Core i5-2520M Processor (2.50 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W)
*
Up to 3.20 GHz with Intel Turbo Boost Technology
Intel Core i5-2410M Processor (2.30 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W)
*
Up to 2.90 GHz with Intel Turbo Boost Technology
2
nd
Generation Intel Core i3 Processors
Intel Core i3-2310M Processor (2.10 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W)*
Intel Celeron Processor
Intel B810 Processor (1.60GHz, 2MB L3 Cache, 2 threads, 35W)*
NOTE:
Processor speed denotes maximum performance mode; processors will run at lower
speeds in battery optimization mode.
* Intel's numbering is not a measurement of higher performance.
† Only available on HP ProBook 4530s and 4730s with discrete graphics.
Operating System
Preinstalled
Genuine Windows 7 Professional 32
*
Genuine Windows 7 Professional 64
*
Genuine Windows 7 Home Premium 32
*
Genuine Windows 7 Home Premium 64
*
Genuine Windows 7 Home Basic 32
*
(select countries)
Genuine Windows 7 Starter
*
(select countries and configurations)
Genuine Windows Vista Home Basic 32
**
SuSE Linux Enterprise Desktop 11
FreeDOS
Supported
Genuine Windows XP Professional 32
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to
install the Windows 7 software and take full advantage of Windows 7 functionality.
See:
http://www.microsoft.com/windows/windows-7/
for details.
** Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
and
http://www.microsoft.com/windowsvista/getready/capable.mspx
for details. Windows Vista
Upgrade Advisor can help you determine which features of Windows Vista will run on your
computer. To download the tool, visit:
http://www.windowsvista.com/upgradeadvisor
.
Chipset
Mobile Intel HM65 Express Chipset
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 6
Graphics
Models with integrated graphics (not an option on HP 4730s):
Intel HD Graphics 3000
Microsoft DirectX 10.1 (Shader Model 4.1) and OpenGL 3.0 capable
NOTE:
Intel HD Graphics for configurations with Celeron processor
Models with discrete graphics (not available at product introduction)
*
:
AMD Radeon™ HD 6490M with 512 MB or 1 GB dedicated DDR3 video memory
Microsoft DirectX 11 (Shader Model 5.0) and OpenGL 4.0 capable
* Because the HP ProBook 4730s comes only with discrete graphics, it will become available
after initial product introduction. Discrete graphics is planned to be available on all of these
models in May 2011.
Display
Internal
HP ProBook 4330s:
13.3-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
13.3-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)
HP ProBook 4430s:
14.0-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
14.0-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)
HP ProBook 4530s:
15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
15.6-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)
15.6-inch diagonal LED-backlit HD+ WVA anti-glare (1600 x 900
resolution)
HP ProBook 4730s:
17.3-inch diagonal LED-backlit HD+ anti-glare (1600x900 resolution)
Optional HP Privacy Filter
External
Up to 32-bit per pixel color depth
VGA
port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz.
HDMI
port supports direct connection to high-definition displays with
up to 1920 x 1080 resolution and 7-channel audio with one
convenient cable (not included).
NOTE:
Resolutions are dependent upon monitor capability, and
resolution and color depth settings.
Memory
Standard
DDR3 PC3-10600 SDRAM (1333 MHz)
Two SODIMM slots supporting dual-channel memory
1 GB, 2 GB, and 4 GB SODIMMs
Maximum
Upgradeable to 8 GB with 4 GB SODIMMs
in slots 1 and 2
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same
size and speed in both memory slots.
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we
recommend HP branded memory to ensure compatibility. If you mix memory speeds, the
system will perform at the lower memory speed. Full availability of 4 GB or more of memory
requires Windows Vista Business 64-bit or Linux. With Windows 32-bit operating systems, the
amount of usable memory is dependent upon your configuration, so that above 3 GB all
memory may not be available due to system resource requirements.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 7
Communications
Realtek Ethernet (10/100/1000 NIC)
*
Optional 56K V.92 modem
**
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard
802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-
speed transmission, connection to a Gigabit Ethernet server and network infrastructure is
required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable
download transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
Modem availability is subject to country regulatory approval.
Wireless Devices
Support for a broad range of secure, integrated wireless options featuring support for the latest
industry standards.
Mobile Broadband
options
Mobile Broadband (WWAN) requires a Windows operating system
and is available in select countries as a factory configurable feature
for the HP ProBook 4330s and 4530s with integrated graphics only.
Two 850/900/1575/1700/1800/1900/2100 MHz antennas integrated in
the top of the display panel support current and future WWAN
technologies.
NOTE:
Separately purchased mobile network operator service is
required.
HP lc2010 HSPA
Mobile Broadband
Module
Integrated mobile broadband module that provides connectivity to
UMTS (HSPA) networks.
HP un2430 EV-
DO/HSPA Mobile
Broadband Module
(not available at product
introduction)
Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and
UMTS (HSPA) networks. It also provides GPS functionality for various
mapping applications and security applications such as Computrace
Pro for HP ProtectTools.
802.11 integrated
wireless LAN options
Wi-Fi certified*
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS,
PEAP-GTC, PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure
Realtek 8188GN 802.11
b/g/n 1x1 WiFi Adapter
Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Intel Centrino
Advanced-N 6230
802.11 a/b/g/n 2x2
WiFi and Bluetooth
2.1+EDR Combo
Adapter
Integrated support for 802.11 a, b, g, and n
Up to 300 mbps data rate
Bluetooth Specification 2.1+EDR compliant
Works with a wide range of Bluetooth devices
Ralink 3592BC8 802.11
a/b/g/n 2x2 WiFi and
Bluetooth 3.0+HS
Combo Adapter*
Integrated support for 802.11 a, b, g, and n
Up to 300 mbps data rate
Bluetooth Specification 3.0 High Speed (HS)* and 2.1 compliant
Works with a wide range of Bluetooth devices
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 8
Atheros 9285GN
802.11 b/g/n
1x1 WiFi and 3011
Bluetooth 3.0+HS
Combo Adapter*
Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Bluetooth Specification 3.0 High Speed (HS)* and 2.1 compliant
Works with a wide range of Bluetooth devices
* Bluetooth 3.0+HS support requires a Windows operating system.
Keyboard
The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard
and a drain system that funnels fluid through a hole in the bottom of the notebook. This
minimizes the risk of damage to sensitive components underneath. The 101/102-key
compatible keyboard features a full-pitch key layout with desktop keyboard features, such as
editing keys, both left and right control and alt keys, and function keys. US and International
key layouts are available. The HP ProBook 4530s and 4730s include a separate numeric
keypad.
Launch Buttons and
Function Keys
Separate launch buttons provide easy access to wireless on/off and HP QuickWeb. Function
keys provide control of features including: standby mode, display brightness, external display,
HP Power Assistant, volume mute, volume down, volume up, and media control.
Pointing device
Touchpad with gestures support, on/off button with LED indicator, two-way scroll, two pick
buttons
Expansion card slots
ExpressCard/34 slot
Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes
Media Card Reader
Supports High Speed SD 3.0 (Secure Digital), MMC (MultiMedia
Card), Memory Stick, Memory Stick Pro, Memory Stick Pro Duo*, SD
Micro, MMC Micro
* Memory Stick Pro Duo Adapters are required and sold separately. Inserting a Memory Stick
Pro Duo Card directly into your notebook could damage the memory card and/or notebook.
Internal Storage
Hard drives
250/320/500/750 GB 7200 rpm SMART SATA II
250/320/500/640 GB 5400 rpm SMART SATA II
NOTE:
Up to 15 GB is reserved for the system recovery software.
HP 3D DriveGuard
(Windows models only)
The hard drive is mounted directly to the notebook frame, reducing
the transmission of shock to the hard drive. Uses three-axis digital
motion detection with intelligent sensitivity to help protect the hard
drive during normal use from shock and vibration. The digital
accelerometer temporarily halts all data transfer and parks the hard
drive when abrupt motion is detected.
Removable Storage
Fixed optical drives
Blu-ray R/RE DVD+/-RW SuperMulti DL Drive*
Blu-ray ROM DVD+/-RW SuperMulti DL Drive*
DVD+/-RW SuperMulti DL Drive
DVD-ROM Drive
Weight saver
* Blu-ray drives not available on configurations with an Intel Celeron
processor.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 9
Interfaces
VGA
One
HDMI
One
Stereo microphone in
One
Stereo headphone/line
out
One
Power connector
One
RJ-11/modem
(optional)
One
RJ-45/Ethernet
One
USB 2.0
Four
LED status indicators
Nine
Audio/Visual
SRS Premium Sound™
Integrated stereo speakers
Integrated microphone (dual-microphone array when equipped with optional webcam)
Function keys for volume mute, volume up, volume down; play, rewind, and fast-forward of
video and audio files
Stereo headphone/line out
Stereo microphone/line in
Optional 720p HD webcam
HD format (widescreen)
Supports videoconferencing and still image capture
High quality fixed focus lens
Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
M-JPEG compression supports higher frame rates for video capture and
videoconferencing
Improved low light sensitivity
Improved dynamic range
Software
Preinstalled software
with Windows
Operating System
HP Recovery Manager
HP Support Assistant
HP ProtectTools Security Manager
HP ProtectTools for Central Management
HP Hotkey Support
HP QuickWeb
HP Power Assistant
HP Connection Manager 4.0
HP DayStarter
Microsoft Office 2010 preloaded (purchase of a Product
Key required to activate a full Office 2010 suite)
*
Norton Internet Security 2011
**
PDF Complete Special Edition
***
ArcSoft Total Media Suite
HP Webcam Software (select models)
Skype
Additional software
available from the web
HP SoftPaq Download Manager
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 10
* Microsoft Office 2010 Preloaded includes reduced functionality versions of Word and Excel.
Purchase of Product Key required to activate full Office 2010 suite available at participating
resellers/retailers and
http://www.office.com
.
** Norton Internet Security 2011 includes 60 days of complimentary live updates; subscription
required for live updates thereafter. Internet access required to receive updates.
*** PDF Complete Special Edition 60 day trial; purchase license afterwards for full functionality.
HP Recovery Manager
Models shipped with Windows 7 or Windows Vista include HP Recovery Manager. HP
Recovery Manager enables fast recovery of the factory preinstalled image if the system
becomes corrupted or if important system files are accidentally deleted. Up to 20 GB of the
hard drive is reserved for the system recovery software.
Security
Standard Features
HP ProtectTools Security Manager (standard modules include)
Credential Manager
Computrace *
Pro
Device Access Manager
Drive Encryption
Face Recognition (webcam configurations only)
File Sanitizer
Privacy Manager
Embedded Security
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
Security lock slot
Support for Intel AT
**
Optional Features
HP Fingerprint Sensor
HP Privacy Filter
* The Computrace agent is shipped turned off, and must be activated by customers when they
purchase a subscription with terms ranging from one to five years.
For more information on HP security solutions refer to:
http://www.hp.com/products/security
.
** Intel AT security requires a separately purchased Absolute Computrace service subscription
and must be activated and configured. Check with Absolute for availability in your country. Intel
and HP assume no liability for lost or stolen data and/or systems or any other damages
resulting therefrom. See
http://www.intel.com/technology/anti-theft/
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 11
HP ProtectTools
Security Manager with
Central Management
HP ProtectTools Security Manager is the security platform for business notebooks and
desktops. The HP ProtectTools Security Manager is an extensible client security console that
delivers enhanced security capabilities through add-on software modules. The ProtectTools
modules are available on the hard drive (also downloadable from the web) and can be
configured in Software Setup.
HP ProtectTools is centrally manageable with the capability to manage notebooks from a single
point. HP ProtectTools is management ready out of the box, in partnership with Digital
Persona. Features address requirements that customers expect from a centrally managed
security solution such as user provisioning, credential reset, and credential revocation.
HP ProtectTools provides two separate management solutions, targeted at the enterprise and
the SMB:
Digital Persona Pro AD: Designed for the enterprise customer. Integrates with Active
Directory and gives IT Managers the ability to provision users, create login policies based
on passwords, biometrics or smartcards. Management features also include remote
credential recovery in case the user forgets the password, loses the smartcard or cannot
use the fingerprint reader for any reason. In addition, advanced auditing capabilities are
also built in. Digital Persona Pro AD is available now.
Digital Persona Pro Workgroup: Designed for the small business customer. Provides
features similar to the Active Directory version, but for workgroups. Workgroup activation
is built into HP ProtectTools, and activation of up to 5 seats is completely free.
For more information on Central Management for HP ProtectTools, refer to:
http://www.hp.com/products/security
.
Power Supply
Models with integrated graphics: External 65-watt Smart AC adapter
Models with discrete graphics: External 90-watt Smart AC adapter
6-foot (1.8-meter) power cord included; total length including external AC adapter is 12 feet
(3.66 meter)
HP Fast Charge
*
* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off.
HP Fast Charge does not apply to the HP 9-cell battery.
Battery
Primary battery
HP ProBook 4330s, 4430s, and 4530s:
HP 9-cell (93 WHr) Li-Ion battery
HP 6-cell (47 WHr) Li-Ion battery
HP ProBook 4730s:
HP 8-cell (73 WHr) Li-Ion battery
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 12
Battery Life
Configurations with integrated graphics
HP ProBook 4330s
9-cell battery
Up to 12 hours 15 minutes
6-cell battery
Up to 6 hours
HP ProBook 4430s
9-cell battery
Up to TBD
6-cell battery
Up to TBD
HP ProBook 4530s
9-cell battery
Up to 12 hours 45 minutes
6-cell battery
Up to 6 hours 15 minutes
HP ProBook 4730s
8-cell battery
Up to TBD
NOTE:
Battery life will vary depending on the product model, configuration, loaded
applications, features, use, wireless functionality and power management settings. The
maximum capacity of the battery will naturally decrease with time and usage. See
MobileMark07 battery benchmark
www.bapco.com/products/mobilemark2007
for additional
details.
System Standby Time
Up to 1 week
Power Conservation
Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum
Performance Mode, or Automatic mode)
ATI PowerPlay technology
Hibernation
Standby
ACPI compliance
Service and Support
HP Services offers limited 3-year, 1-year and 90-day warranty options depending on country;
1-year limited warranty on primary battery. Warranty upgrades are also available. HP Care
Pack Services extend service contracts beyond the standard warranties. To choose the right
level of service for your HP product, use the HP Care Pack Services Lookup Tool at:
http://www.hp.com/go/lookuptool
. Additional HP Care Pack Services information by product is
available at:
http://www.hp.com/hps/carepack
.
NOTE:
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for
details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 13
Memory
HP 1 GB (DDR3 1333 MHz) SODIMM
AT911AA#xxx
HP 2 GB (DDR3 1333 MHz) SODIMM
AT912AA#xxx
HP 4 GB (DDR3 1333 MHz) SODIMM
AT913AA#xxx
Storage
HP 250 GB Pocket Media Drive
FE477AA
HP Mobile USB DVD
XQ543AA
HP Mobile USB DVDRW
BU516AA
HP Mobile Blu-ray USB DVDRW
XQ546AA
Power
HP 90W Smart AC Adapter
ED495AA#xxx
HP 90W Smart AC/Auto/Air Combo Adapter
AJ652AA#xxx
HP 90W Smart Auto/Truck Adapter
ED493AA
HP 65W Slim Adapter
AX727AA#xxx
HP 90W Slim Adapter
BT796AA#xxx
Carrying Cases
HP Basic Carrying Case
AJ078AA
HP Business Nylon Case
BP848AA
HP Professional Slim Top Load Case
AY530AA
Security
HP Notebook Combo Lock
AY475AA#xxx
HP Keyed Cable Lock
BV411AA
HP 13.3-inch Display Privacy Filter
AU649AA#xxx
HP 14.0-inch Display Privacy Filter
AU100AA#xxx
HP 15.6-inch Display Privacy Filter
AU103AA#xxx
HP 17.3-inch Display Privacy Filter
AU650AA#xxx
Input/Output Devices
HP USB Optical Travel Mouse
RH304AA
HP USB/PS2 Optical 2-Button Scroll Mouse
DC369A
HP USB Keyboard & Mouse Bundle
RC465AA#xxx
HP Notebook Projection Companion
AX325AA#xxx
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Options (availability may vary by country)
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 14
System Unit
Dimensions
(HxWxD)
HP ProBook 4330s:
1.10 in (at front) x 12.99 in x 9.28 in
2.79 cm (at front) x 33.0 cm x 23.5 cm
HP ProBook 4430s:
1.11in (at front) x 13.in x 9.26 in
2..81 cm (at front) x 33.9 cm x 23.5 cm
HP ProBook 4530s:
1.13 in (at front) x 14.76 in x 10.1 in
2.87 cm (at front) x 37.4 cm x 25.6 cm
HP ProBook 4730s:
1.15 in (at front) x 16.29 in x 11.00 in
2.9 cm (at front) x 41.4 cm x 27.9 cm
Weight
HP ProBook 4330s:
Starting at 4.41 lb (2.0 kg) without optical drive
or 4.7 lb (2.13 kg) with optical drive
HP ProBook 4430s:
Starting at 4.51 lb (2.04 kg) without optical drive
or 4.83 lb (2.218 kg) with optical drive
HP ProBook 4530s:
Starting at 5.22 lb (2.36 kg) without optical drive
or 5.55 lb (2.51 kg) with optical drive
HP ProBook 4730s:
Starting at 6.44 lb (2.92 kg) without optical drive
or 6.72 lb (3.05 kg) with optical drive
NOTE:
Height varies depending upon where on the notebook the measurement is made. Weight
varies by configuration and components.
Stand-Alone Power
Requirements
(AC Power)
Nominal Operating
Voltage
18.5 V
Average Operating
Power
with integrated graphics: TBD W
with discrete graphics: TBD W
Max Operating Power
< 90 W or < 65W
Temperature
Operating*
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet
bulb temperature
Shock
Operating
125 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude
(unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Planned
Industry Standard
Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 15
ENERGY STAR®
Select models
**
EPEAT
Registered TBD in United States
***
ICES
Yes
Australia / NZ A-Tick
Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
KCC
Yes
BSMI
Yes
CE Marking Compliance
Yes
* At temperatures above 86° F (30° C), the Intel Core i3-2310M Processor may not run at
maximum clock speed.
** Configurations of the HP ProBook 4330s, HP Probook 4430s, HP ProBook 4530s, and HP
Probook 4730s that are ENERGY STAR qualified are identified as HP ProBook 4330s ENERGY
STAR, HP ProBook 4430s ENERGY STAR, HP ProBook 4530s ENERGY STAR, and HP
Probook 4730s ENERGY STAR on HP websites and on
www.energystar.gov
.
*** EPEAT registration varies by country. See
www.epeat.net
for registration status by country.
EPEAT status listed above applies to U.S.
NOTE:
For accessibility information on HP products, please visit:
http://www.hp.com/accessibility
.
Audio
SRS Premium Sound
Hardware
Implementation
IDT 92HD87 High Definition CODEC
Touch-Sensitive
Volume Controls
Volume up, volume down, and mute
Full Duplex
Yes
Microphone In
Stereo
Headphone/Line Out
Stereo
Integrated Microphone
Yes, dual digital microphone array when equipped with optional webcam
Audio Output Quality
Frequency Response
20 Hz – 20 kHz
Signal to Noise Ratio
>85 dB
Total Harmonic
Distortion
0.01%
Noise Floor
–110 dB
Play/Record Sampling
Rate
(s)
8 kHz – 48kHz
DAC
16, 20 or 24-bit
ADC
16 or 20-bit
Integrated Stereo
Speakers
Power Rating
2 Watts
Impedance
4 Ohms
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 16
Power
HP 90W Smart AC
Adapter
Dimensions
5.00 x 1.97 x 1.1 in (12.7 x 5.0 x 2.9 cm)
Weight
0.82 lb (370 g)
Input
100 to 240 VAC
Input Efficiency
87% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.5 A at 90 VAC, 0.75 A at 180 VAC PFC
Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC
Version
Output
Output power
90W
DC output
19.0V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide
safety standards - IEC60950, EN60950, UL60950, Class1, SELV;
Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF- over
200,000 hours at 25°C ambient condition.
HP 65W Smart AC
Adapter
Dimensions
4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight
0.62 lb (280 g)
Input
100 to 240 VAC
Input Efficiency
87% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC, 0.85 A at 180 VAC
Output
Output power
65W
DC output
18.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 17
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide
safety standards - IEC60950, EN60950, UL60950, Class1, SELV;
Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF - over
200,000 hours at 25°C ambient condition.
9-Cell (93 WHr)
Lithium-Ion battery
Dimensions
(H x W x L)
0.8 x 2.9 x 8.3 in (2.0 x 7.3 x 21.0 cm)
Weight
1.07 lb (0.488 kg)
Cells/Type
9-cell Lithium-Ion
Energy
Watt-hour Capacity
93 WHr
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
System in OFF mode or
Standby
3 to 4 hours
System ON
4 to 6 hours (depending on system power
consumption)
8-Cell (73 Whr) Lithium-
Ion Primary battery
Dimensions
(HxWxL)
0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)
Weight
0.980 lb (0.445 kg)
Cells/Type
8-cell Lithium-Ion
Energy
Watt-hour Capacity
73 Wh
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (-10° to 60° C)
Non-operating
-4° to 140° F (-20° to 60° C)
Battery Re-Charge
Time
System in OFF mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Technology
Charges the battery up to 90% within 1.5
hours when system is OFF
6-Cell (62 WHr)
Lithium-on battery
Dimensions
(HxWxL)
0.8 x 2.0 x 8.3 in (2.0 x 5.1 x 21.1 cm)
Weight
0.72 lb (0.325 kg)
Cells/Type
6-cell Lithium-Ion
Energy
Watt-hour Capacity
62Wh
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
System in OFF Mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
Internal Storage
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 18
750 GB 7200 rpm SATA
Hard Drive
Drive Weight
0.25 lbs (115g)
Capacity
750 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
1.5 ms
Average
11 ms
Maximum
22 ms
Rotational Speed
7200 rpm
Logical Blocks
1,465,149,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
500 GB 7200 rpm SATA
Hard Drive
Drive Weight
0.25 lbs (115g)
Capacity
500 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
1.5 ms
Average
11 ms
Maximum
22 ms
Rotational Speed
7200 rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
320 GB 7200 rpm SATA
Hard Drive
Drive Weight
0.25 lbs (115 g)
Capacity
320 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
1.5 ms
Average
11 ms
Maximum
22 ms
Rotational Speed
7200 rpm
Logical Blocks
625,142,448
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 19
250 GB 7200 rpm SATA
Hard Drive
Drive Weight
0.25 lbs (115g)
Capacity
250 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
1.5 ms
Average
11 ms
Maximum
22 ms
Rotational Speed
7200 rpm
Logical Blocks
488,397,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
750 GB 5400 rpm SATA
Hard Drive
Drive Weight
0.27 lb (125 g) or 0.22 lb (101 g)
Capacity
750 GB
Height
0.50 in (12.7 mm) or 0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
1,465,149,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
640 GB 5400 rpm SATA
Hard Drive
Drive Weight
0.22 lb (101 g)
Capacity
640 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
1,250,263,728
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 20
500 GB 5400 rpm SATA
Hard Drive
Drive Weight
0.22 lb (101 g)
Capacity
500 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
250 GB 5400 rpm SATA
Hard Drive
Drive Weight
0.22 lb (101 g)
Capacity
250 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate
Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
488,397,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security
Optical Drives
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 21
DVD-ROM Drive
Access Times
Random
< 140 ms CD (typical)
< 160 ms DVD (typical)
Max Data Transfer Rate
24X CD-ROM
8X-DVD
Transfer Mode
UDMA Mode 5
Interface
Gen 1 SATA
Supported Media
(read)
CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I,
CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-
EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-
RAM
Supported Media
(write)
None
Max Media Capacity
(read)
8.5GB
Transport
Tray Loading
DVD+/-RW SuperMulti
DL Drive
Access Times
Random
<140ms CD (typical)
< 160 ms DVD (typical)
Max Data Transfer Rate
24X CD-ROM
8X DVD
24X CD-R
24X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
6X - DVD+R Dual Layer
6X - DVD-R Dual Layer
5X DVD-RAM
Transfer Mode
UDMA Mode 5
Interface
Gen 1 SATA
Supported Media
(read)
CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I,
CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-
EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-
RAM
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM,
DVD+R DL, DVD-R DL
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
8.5 GB
Transport
Tray Loading
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 22
Blu-ray ROM DVD+/-RW
SuperMulti DL Drive
Access Times
Random
<190 ms CD-ROM (typical)
< 180ms DVD-ROM (typical)
<230 ms BD-ROM (typical)
Max Data Transfer Rate
24X CD-ROM
8X DVD-ROM
24X CD-R
16X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
4X - DVD+R Dual Layer
4X - DVD-R Dual Layer
5X DVD-RAM
6X BD-ROM
Transfer Mode
UDMA Mode 5
Interface
Gen 1 SATA
Supported Media
(read)
CD-DA, , CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I,
CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-
EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW. DVD-
RAM, BD-ROM, BD-R, BD-RE
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL,
DVD-RW, DVD-RAM
Max Media Capacity
(read)
50.0 GB
Max Media Capacity
(write)
8.5GB
Transport
Tray Loading
Blu-ray R/RE DVD+/-
RW SuperMulti DL
Drive
Access Times
Random
<165 ms CD-ROM (typical)
<185 ms DVD-ROM (typical)
<205 ms BD-ROM (typical)
Max Data Transfer Rate
24X CD-ROM
8X DVD-ROM
24X CD-R
16X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
6X DVD+R Dual Layer
6X DVD-R Dual Layer
5X DVD-RAM
6X BD-ROM
6X BD-R
2X BD-RE
Transfer Mode
UDMA Mode 5
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 23
Interface
Gen 1 SATA
Supported Media
(read)
CD-DA, , CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I,
CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-
EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW. DVD-
RAM, BD-ROM, BD-R, BD-RE
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL,
DVD-RW, DVD-RAM, BD-R, BD-RE
Max Media Capacity
(read)
50.0 GB
Max Media Capacity
(write)
50.0 GB
Transport
Tray Loading
Security
HP Fingerprint Sensor
(optional)
Mobile Voltage
Operation
3.0V-3.6V Single Supply
Operating Temperature
32° – 158°F (0° – 70°C)
Current Consumption
@ 3.3V
Less than 70 mA peak imaging and scrolling
Less than 25 mA hardware finger detection
Advanced Power Management
High-Rate Image
Capture
Up to 240 image frames /sec
ESD Resistance
IEC 61000-4-2 Level 4 (±15KV)
Detection Matrix
192 x 16 Pixels
9.7 mm x 0.81 mm
500 ppi High-Resolution Images
Communications
Integrated Realtek
RTL8153EH-CG
10/100/1000 NIC
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-
14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses
21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses
40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and
100 Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)
Jumbo Frame 9K
Auto MDI/MDIX Crossover cable detection
Power
Management
ACPI compliant - multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power
consumption
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 24
Performance
Features
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and
Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB
(802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Interface
PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ
NIC Device Driver
Name
Realtek PCIe GBE Ethernet Family Controller
V.92 56K Data/Fax
Modem
Form Factor
MDC 1.5 Daughtercard
Power Management
Support
APM Revision 1.2, ACPI
Approvals/
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC
Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian
ACA, CE Mark, Other Countries
Data Mode Capabilities
V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates
:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates
:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
Fax Mode Capabilities
TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
T.31
Command Set
V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 25
Data compression: +DS, +DR
V.251
HP un2430
EV-DO/HSPA Mobile
Broadband Module
Technology/Operating
Bands
GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS),
1900MHz (PCS)
UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I),
1900MHz (UTRA FDD Band II), AWS (UTRA FDD Band IV),
900MHz(UTRA FDD Band VIII), 850MHz (UTRA FDD Band V)
1xEVDO/1xRTT with receive diversity: 850MHz (Band Class0-Cell),
1900MHz (Band Class1-PCS)
Wireless Protocol
Standards
GSM/GPRS/EDGE: Class A, Multi-slot class 10 operation, coding
schemes CS1 - CS4 and MSC1 - MSC9.
UMTS/WCDMA: Release 99 and Release 6
CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-856, IS-
2000
Wireless Parametric
Standards
Meets or exceeds TIA/EIA IS-98-D
Maximum Data Rates
UMTS (HSPA) - 14.4 Mbps (Download ), 5.76Mbps (Upload)
CDMA (EVDO Release A) - 3.1 Mbps (Download), 1.8Mbps (Upload)
GPS
Standalone GPS enabled
gpsOneXTRATM™
GPS Bands
L1 - 1575.42 MHz
Maximum Output
Power
GSM/GPRS/EDGE: 32dBm (+/-1)
WCDMA: 24dBm (+0.7/-2.3)
CDMA: 24dBm (+0.7/-2)
Maximum Power
Consumption
2750mA (peak); 1100mA (average)
Power Consumption,
Idle Not Connected
20 mA
Power Management
USB selective suspend
Integrated notebook wireless button
Antenna Type
Dual high efficiency 5 band antennae with spatial diversity, mounted in
the display enclosure
Form Factor
PCI-Express MiniCard, USB 2.0 interface
Weight
11.5 g
Dimensions
(Length x
Width x Thickness)
2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)
Voltage, Operating
3.3v +/- 10%
Temperature,
Operating
(from
TIA/EIA/IS-98-D)
-22° to 158° F (-30° to 70° C) (full RF performance)
-22° to 167° F (-30° to 75° C) (reduced RF performance)
Temperature, Non-
operating, 96 hours
(from MIL-STD 202
Method 108)
-40° to 185° F (-40° to 85° C)
Humidity, Non-
operating
95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
Configuration Utilities
HP Connection Manager
LED Activity
LED Off - Radio Off;
Solid LED On - Radio On
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 26
HP lc2010 Mobile
Broadband Module
Technology/Operating
Bands
GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS),
1900MHz (PCS)
UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I),
900Mhz(UTRA FDD Band VIII)
Wireless Protocol
Standards
GSM/GPRS/EDGE: Class B, Multi-slot class 10 operation, coding
schemes CS1 - CS4 and MSC1 - MSC9.
UMTS/WCDMA: Release 99 and Release 6
Wireless Parametric
Standards
Complies with 3GPP specifications
Maximum Data Rates
UMTS (HSPA) - 7.2 Mbps (Download ), 2.0Mbps (Upload)
GPS
n/a
GPS Bands
Maximum Output
Power
GSM/GPRS/EDGE: 32dBm (+/-1)
WCDMA: 23dBm (+/-1)
Maximum Power
Consumption
2000mA (peak); 600mA (average)
Power Consumption,
Sleep Mode
5 mA
Power Management
USB selective suspend
Integrated notebook wireless button
Antenna Type
Dual high efficiency 5 band antennae with spatial diversity, mounted in
the display enclosure
Form Factor
PCI-Express MiniCard, USB 2.0 interface
Weight
< 10 g
Dimensions
(Length x
Width x Thickness)
2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)
Voltage, Operating
3.3v +/- 10%
Temperature,
Operating
14° to 149° F (-10° to 65° C) (full RF performance)
14° to 167° F (-10° to 75° C) (reduced RF performance)
Temperature, Non-
operating, 96 hours
(from MIL-STD 202
Method 108)
-22° to 185° F (-30° to 85° C)
Humidity, Non-
operating
85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
Configuration Utilities
HP Connection Manager
LED Activity
LED Off - Radio Off;
Solid LED On - Radio On
Intel Centrino
Advanced-N 6230 WiFi
and Bluetooth Combo
Adapter
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliantwith Microsoft
Windows Vista and XP (details at:
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz and 5GHz
Data Rates
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 66 possible data rates, ranging from 6 Mbps to 300 Mbps,
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 27
depending on the combination of Bandwidth, Modulation Coding
Scheme, and Guard Interval used, as defined in IEEE 802.11n
specification
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4) with Microsoft Windows Vista and XP
only.
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for CCK
and OFDM)
2
17 dBm , nominal
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm , nominal
Power Consumption
Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit: 2.0 W (max)
Receive: 2.0 W (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
54 Mbps: -71 dBm, 11 Mbps: -85 dBm , 1 Mbps: -95 dBm
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Form Factor
PCI-Express Half-MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
14° to 149° F (-10° to 65° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
4
Microsoft Windows XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 28
Cisco Compatible Extensions.
LED Activity
LED Off - Radio OFF; Solid LED On - Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
3.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows XP. WLAN may also be compatible with certain third-party software
supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions
support for Microsoft Windows Vista.
4.
Bluetooth 2.1 and 3.0
Wireless Technology
Bluetooth Specification
2.1+EDR and 3.0+HS Compliant
Dimensions
1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
79 (1 MHz) available channels
Data Rates and
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric
Transmit Power
Max 5.5 dBm (Bluetooth Class I)
Receiver Sensitivity
Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Average 165mW
Sleep <1 mW
Antenna
Internally integrated within module
Range
Up 33 ft (10 m)
Electrical Interface
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
Bluetooth Software
Supported
Broadcom Bluetooth for Windows
Microsoft Windows Bluetooth Software
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
Full support of Bluetooth Security Provisions
Power Management
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Temperature
Operating
Non-operating
-4° to 158° F (-20° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90%
5% to 95%
Altitude
Operating
Non-operating
15,000 ft (4,572 m)
40,000 ft (12,192 m)
Bluetooth Profiles
Supported
Serial Port Profile (SPP)
1
Service Discovery Applicaton Profile (SDAP)
Dial-Up Networking (DUN)
1,2
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 29
Generic Object Exchange Profile (GOEP)
1,2
Object Push Profile (OPP)
1,2
File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)
1,2
Personal Area Networking Profile (PAN)
1,2
Human Interface Device Profile (HID)
1,2,3
FAX Profile (FAX)
Basic Imaging Profile (BIP)
2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
indicates the profile is supported by Microsoft Windows XP SP2
1.
indicates the profile is part of Windows Vista
2.
Atheros 9285GN
802.11b/g/n + BT 3.0 HS
Combo Adapter
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability
Wi-Fi certified
Frequency Band
2.4 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: many possible data rates, ranging from 6 Mbps to 300 Mbps,
depending on the combination of Bandwidth, Modulation Coding
Scheme, and Guard Interval used, as defined in IEEE 802.11n
specification
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST.
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for CCK
and OFDM)
2
17 dBm, nominal
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm, nominal
Power Consumption
Transmit: 1.5 W (max)
Receive: 1.0 W (max)
Associated to Access Point, Idle: 300 mW nominal
Wireless Button Off: 75 mW nominal
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
54 Mbps: -75 dBm, 11 Mbps: -88 dBm , 1 Mbps: -93 dBm
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 30
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Form Factor
PCI-Express Half-MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 149° F (-10° to 65° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Off - Radio OFF; Solid LED On - Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
3.
Ralink 3592BC8
802.11a/b/g/n 2x2 WiFi
and Bluetooth 3.0+HS
Combo Adapter
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliantwith Microsoft
Windows Vista and XP (details at:
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz and 5GHz
Data Rates
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: from 6 Mbps to 300 Mbps, depending on the combination of
Bandwidth, Modulation Coding Scheme, and Guard Interval used, as
defined in IEEE 802.11n specification
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4) with Microsoft Windows Vista and XP
only.
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for CCK
and OFDM)
2
17 dBm , nominal
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 31
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm , nominal
Power Consumption
Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit: 2.0 W (max)
Receive: 2.0 W (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
54 Mbps: -71 dBm, 11 Mbps: -85 dBm , 1 Mbps: -95 dBm
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Form Factor
PCI-Express Half-MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
14° to 149° F (-10° to 65° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
4
Microsoft Windows XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support
Cisco Compatible Extensions.
LED Activity
LED Off - Radio OFF; Solid LED On - Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
3.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows XP. WLAN may also be compatible with certain third-party software
supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions
support for Microsoft Windows Vista.
4.
Bluetooth 2.1 and 3.0
Wireless Technology
Bluetooth Specification
2.1+EDR and 3.0+HS Compliant
Dimensions
1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
79 (1 MHz) available channels
Data Rates and
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 32
Transmit Power
-6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity
Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Peak (Tx) 175 mW
Peak (Rx) 160 mW
Sleep <1 mW
Antenna
Internally integrated within module
Range
Up 33 ft (10 m)
Electrical Interface
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
Bluetooth Software
Supported
Broadcom Bluetooth for Windows
Microsoft Windows Bluetooth Software
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
Full support of Bluetooth Security Provisions
Power Management
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Temperature
Operating
Non-operating
-4° to 158° F (-20° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90%
5% to 95%
Altitude
Operating
Non-operating
15,000 ft (4,572 m)
40,000 ft (12,192 m)
Bluetooth Profiles
Supported
Serial Port Profile (SPP)
1
Service Discovery Applicaton Profile (SDAP)
Dial-Up Networking (DUN)
1,2
Generic Object Exchange Profile (GOEP)
1,2
Object Push Profile (OPP)
1,2
File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)
1,2
Personal Area Networking Profile (PAN)
1,2
Human Interface Device Profile (HID)
1,2,3
FAX Profile (FAX)
Basic Imaging Profile (BIP)
2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
indicates the profile is supported by Microsoft Windows XP SP2
1.
indicates the profile is part of Windows Vista
2.
Realtek 8188GN
802.11b/g/n 1x1 WiFi
Adapter
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 33
Interoperability
Wi-Fi certified
Frequency Band
2.4 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: many possible data rates, ranging from 6 Mbps to 150 Mbps,
depending on the combination of Bandwidth, Modulation Coding
Scheme, and Guard Interval used, as defined in IEEE 802.11n
specification
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST.
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CCK)
2
17 dBm, nominal
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm, nominal
Power Consumption
Transmit: 1.5 W (max)
Receive: 1.0 W (max)
Associated to Access Point, Idle: 152 mW nominal
Wireless Button Off: 33 mW nominal
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
54 Mbps: -73 dBm, 11 Mbps: -82 dBm , 1 Mbps: -93 dBm, MCS7_HT20:
-69dBm , MCS7_HT40: -67dBm
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Form Factor
PCI-Express Half-MiniCard
Weight
0.007 lb (3 g)
Dimensions
0.14 x 1.06 x 1.18 in (3.5 x 26.8 x 30 mm)
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 149° F (-10° to 65° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Off - Radio OFF; Solid LED On - Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g/n (OFDM modulation).
3.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 34
Environmental Data
Eco-Label
Certifications
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
US ENERGY STAR®
IT ECO declaration
EPEAT - Gold where HP registers commercial notebook products.
See
http://www.epeat.net
for registration status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise
Emissions data for the Convertible Mini tower Desktop model is based
on a "Typically Configured Notebook"
HP ProBook 4330s Notebook PC
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
9.75W
10.19 W 10.32 W
Sleep (Energy Star low
power mode)
1.24 W
1.4 W
1.24 W
Off
0.57 W 0.66 W 0.56 W
Heat Dissipation
*
115 VAC 230 VAC 100 VAC
Normal Operation
33 BTU/hr 35 BTU/hr 35 BTU/hr
Sleep
4 BTU/hr 5 BTU/hr 4 BTU/hr
Off
2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
3.5
31.6
Fixed Disk
(random writes)
3.6
32.9
System fan is usually off except when charging the battery
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
The battery type and chemistry used in the product is:
CR2032 (coin cell), Li-ion
6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Additional
information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 35
This product is in compliance with the IEEE 1680 (EPEAT) standard at
the Gold level, see
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
This product contains 0% post consumer recycled plastic (by wt.)
This product is greater than 93.9% recycle-able when properly disposed
of at end of life.
Packaging Materials
External:
Corrugated Carton 385 g
Corrugated 115 g
CANON bags - Several layers 5 g
Internal:
Polyethylene low density 15 g
Molded Pulp 180 g
The Corrugated Carton packaging material is made from 80%
recycled content.
The Corrugated packaging material is made from 80% recycled
content.
The CANON bags - Several layers packaging material is made
from 80% recycled content.
The Polyethylene low density packaging material is made from
60% recycled content.
The Molded Pulp packaging material is made from 60% recycled
content.
HP follows these guidelines to decrease the environmental impact of
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 36
HP ProBook 4430s Notebook PC
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
9.75W
10.19 W 10.32 W
Sleep (Energy Star low
power mode)
1.24 W
1.4 W
1.24 W
Off
0.57 W 0.66 W 0.56 W
Heat Dissipation
*
115 VAC 230 VAC 100 VAC
Normal Operation
33 BTU/hr 35 BTU/hr 35 BTU/hr
Sleep
4 BTU/hr 5 BTU/hr 4 BTU/hr
Off
2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
3.5
32.2
Fixed Disk
(random writes)
3.8
35.4
System fan is usually off except when charging the battery
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
The battery type and chemistry used in the product is:
CR2032 (coin cell), Li-ion
6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Additional
information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at
the Gold level, see
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
This product contains 0% post consumer recycled plastic (by wt.)
This product is greater than 94.4% recycle-able when properly disposed
of at end of life.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 37
Packaging Materials
External:
Corrugated Carton 385 g
Corrugated 115 g
CANON bags - Several layers 5 g
Internal:
Polyethylene low density 15 g
Molded Pulp 180 g
The Corrugated Carton packaging material is made from 80%
recycled content.
The Corrugated packaging material is made from 80% recycled
content.
The CANON bags - Several layers packaging material is made
from 80% recycled content.
The Polyethylene low density packaging material is made from
60% recycled content.
The Molded Pulp packaging material is made from 60% recycled
content.
HP follows these guidelines to decrease the environmental impact of
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
HP ProBook 4530s Notebook PC
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
9.29 W
10.44 W
9.23 W
Sleep (Energy Star low
power mode)
1.18 W 1.08 W 1.16 W
Off
0.51 W 0.64 W 0.51 W
Heat Dissipation
*
115 VAC 230 VAC 100 VAC
Normal Operation
31.7 BTU/hr 35.7 BTU/hr 31.5 BTU/hr
Sleep
4.03 BTU/hr
4 BTU/hr 4 BTU/hr
Off
2 BTU/hr
2.1 BTU/hr
2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 38
System Fan Off
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
3.5
32.1
Fixed Disk
(random writes)
4.1
37.8
System fan is usually off except when charging the battery
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
The battery type and chemistry used in the product is:
CR2032 (coin cell), Li-ion
6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Additional
information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at
the Gold level, see
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
This product contains 0% post consumer recycled plastic (by wt.)
This product is greater than 95.1% recycle-able when properly disposed
of at end of life.
Packaging Materials
External:
Corrugated 115 g
Corrugated Carton 455 g
Canon bag 5 g
Internal:
Polyethylene low density 15g
Molded pulp 190g
The Corrugated carton packaging material is made from 80%
recycled content.
The Corrugated packaging material is made from 80% recycled
content.
The Canon Bag packaging material is made from 80% recycled
content.
The Polyethylene low density packaging material is made from
60% recycled content.
The Molded Pulp packaging material is made from 60% recycled
content.
HP follows these guidelines to decrease the environmental impact of
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 39
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
Material Usage
This product does not contain any of the following substances in excess
of regulatory limits (for reference of these limits please refer to the HP
General Specification of the Environment:
(
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/
gen_specifications.html
):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Nickel finishes that release greater than 0.5 µgrams/cm2/week,
measured according to EN 1811:1998, are not used on any product
surface designed to be frequently handled or touched by users.
End-of-life
Management and
Recycling
Hewlett-Packard offers end-of-life HP product return and recycling
programs in many geographic areas. To recycle your product, please go
to:
http://www.hp.com/go/reuse-recycle
or contact your nearest HP sales
office. Products returned to HP will be recycled, recovered or disposed
of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to
provide treatment information for each product type for use by treatment
facilities. This information (product disassembly instructions) is posted
on the Hewlett Packard web site at:
http://www.hp.com/go/recyclers
.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 40
These instructions may be used by recyclers and other WEEE treatment
facilities as well as HP OEM customers who integrate and re-sell HP
equipment.
Hewlett-Packard
Corporate
Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Environment website
http://www.hp.com/environment
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/
ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/
envmanagement.html
Copyright © 2011 Hewlett-Packard Development Company, L.P.
All rights reserved. Microsoft, Windows, Windows 7, Windows Vista and Windows XP are registered trademarks or
trademarks of Microsoft Corporation in the U.S. and/or other countries. Intel, Core, and Celeron are registered trademarks
or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG,
Inc., in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective
companies.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind.
The warranties for HP products are set forth in the express limited warranty statements accompanying such products.
Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
HP ProBook 4330s Notebook PC, HP ProBook
4430s Notebook PC, HP ProBook 4530s Notebook
PC and HP ProBook 4730s Notebook PC
Technical Specifications
DA - 13948 Worldwide QuickSpecs — Version 4 — 4.1.2011
Page 41

Navigation menu
