HP recommends Windows Vista
®
Business
1.
Dual-band Wireless LAN Antennas*
6.
Optical Drive
2.
Wireless On/Off Button with LED*
7.
Touchpad with Scroll Zone
3.
Power Button with LED
8.
Secure Digital (SD) slot
4.
Speaker
9.
Microphone Jack
5.
Kensington Lock Slot
10.
Headphone Jack
1.
Battery Charging LED
5.
Power Connector
2.
ExpressCard/54 slot
6
VGA/external monitor connector
3.
Three USB 2.0 ports
7.
RJ-11/modem port
4.
RJ-45/Ethernet port
QuickSpecs
HP Compaq 6720s Notebook PC
Overview
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 1
At A Glance
Genuine Windows Vista Business 32, Genuine Windows Vista Home Basic 32, FreeDOS,
or Red Flag Linux (PRC only)
Thin, lightweight design starting at 5.5 lb/2.49 kg and 1.27-inch/32.3 mm thin at front
Widescreen 15.4-inch diagonal display with optional BrightView
Flexible wireless connectivity options:
Integrated 802.11 a/b/g/draft-n, a/b/g, or b/g wireless LAN module
Bluetooth®
Intel® Core™2 Duo processor or Intel Celeron® processor
Device Access Manager for HP ProtectTools
Integrated optical drive
Up to 160-GB 5400 rpm user-removable hard drive with HP DriveGuard protection
Secure Digital (SD) slot
Up to 4 GB of 533-MHz or 667-MHz DDR2 SDRAM, dual channel memory support
Mobile Intel Graphics Media Accelerator X3100, with up to 384-MB shared system memory
Intel 10/100 Ethernet Controller
Touchpad with scroll zone
QuickSpecs
HP Compaq 6720s Notebook PC
Overview
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 2
Processors
Intel Core 2 Duo Processor T7700 (2.40-GHz, 800-MHz FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7500 (2.20-GHz, 800-MHz FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7300 (2.00-GHz, 800-MHz FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7100 (1.80-GHz, 800-MHz FSB, 2-MB L2 cache)*
Intel Core 2 Duo Processor T5550 (1.83-GHz, 800-MHz FSB, 2-MB L2 cache)*
Intel Core 2 Duo Processor T5470 (1.60-GHz, 800-MHz FSB, 2-MB L2 cache)* (select models)
Intel Core 2 Duo Processor T5450 (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)* (select models)
Intel Celeron Processor 540 (1.86-GHz, 533-MHz FSB, 1-MB L2 cache)*
* Intel's numbering is not a measurement of higher performance.
NOTE:
Processor speed denotes maximum performance mode; processors will run at lower
speeds in battery optimization mode.
Operating System
Preinstalled
Genuine Windows Vista Business 32*
Genuine Windows Vista Home Basic 32*
FreeDOS
RedFlag Linux (PRC only)
*
Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
and
http://www.microsoft.com/windowsvista/getready/capable.mspx
for details. Windows Vista
Upgrade Advisor can help you determine which features of Windows Vista will run on your
computer. To download the tool, visit
http://www.windowsvista.com/upgradeadvisor
.
Chipset
Mobile Intel GM965 or GL960
Graphics
Mobile Intel Graphics Media Accelerator X3100, up to 384-MB shared system memory
Microsoft DirectX 9 capable
Display
Internal
15.4-inch diagonal WXGA anti-glare (1280 x 800 resolution)
15.4-inch diagonal WXGA BrightView (1280 x 800 resolution)
External
Up to 32-bit per pixel color depth
VGA
port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE:
Resolutions are dependent upon monitor capability, and
resolution and color depth settings.
Memory
Standard
512-MB, 1024-MB, 2048-MB, or 4096-MB* 533-MHz or 667-MHz DDR2
SDRAM total memory; two SODIMM slots supporting dual channel
memory
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same
size and speed in both memory slots.
*with Mobile Intel GM965 chipset only
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we
recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system
will perform at the lower memory speed.
QuickSpecs
HP Compaq 6720s Notebook PC
Standard Features
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 3
Communications
Intel Fast Ethernet Integrated Controller (10/100 NIC)
56K V.92 modem*
* Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem
availability is subject to country regulatory approval.
Wireless Devices
Support for a broad range of secure, integrated wireless LAN options featuring support for the
latest industry standards. Integrated Bluetooth is also available (factory configurable only) and can
be combined with any of the supported wireless LAN options.
All 802.11a/b/g
integrated wireless
LAN options
Wi-Fi certified
Cisco Compatible Extensions support (Version 4.0) with Microsoft
Windows XP
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-
GTC, PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi certified for WPA2, WMM
Dual antennas integrated in the display enclosure
Intel Wireless WiFi Link
4965AGN*
Integrated support for 802.11a, b, g, and draft-n
Up to 243-mbps data rate
Intel Wireless WiFi Link
4965AG*
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Intel PRO/Wireless
3945ABG Network
Connection*
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Intel PRO/Wireless
3945BG Network
Connection*
Integrated support for 802.11 b and g
Up to 54-mbps data rate
Broadcom 4311AG
802.11a/b/g
WiFi Adapter
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Broadcom 4311BG
802.11b/g
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54-mbps data rate
HP Integrated Module
with Bluetooth
Wireless Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
* Requires Intel Core 2 Duo processor
Keyboard
The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with
desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both
left and right control and alt keys, and 12 function keys. US and International key layouts are
available. Other features include an integrated numeric keypad, hotkeys for instant access to
power conservation, brightness, and other features, 19-mm x 19-mm key pitch (center-to-center
spacing), 2.5-mm stroke, and comfort-dished keycaps.
Pointing device
Touchpad with scroll zone, two pick buttons
QuickSpecs
HP Compaq 6720s Notebook PC
Standard Features
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 4
Expansion card slots
ExpressCard/54 slot
Supports ExpressCard/54 and ExpressCard/34
Secure Digital slot
Supports SD (Secure Digital), MMC (MultiMedia Card)
Storage
Hard drives
80/120/160-GB 5400 rpm SMART SATA
NOTE:
These hard drives are customer removable and will withstand multiple insertion/removal
cycles. Up to 10 GB is reserved for the system recovery software.
HP DriveGuard
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive.
Fixed optical drives
DVD/CD-RW Combo Drive
DVD+/-RW SuperMulti DL Drive
DVD+/-RW SuperMulti DL LightScribe Drive
Interfaces
ExpressCard/54
Supports ExpressCard/54 and ExpressCard/34
External monitor
One – VGA
Stereo microphone in
One
Stereo headphone/line
out
One
Power connector
One
RJ-11/modem
One
RJ-45/Ethernet
One
USB 2.0
Three
LED status indicators
Six
Audio
High Definition Audio support
Integrated mono speaker
Stereo headphone/line out
Stereo microphone in
Software
Preinstalled software
with Windows Vista
PDF Complete
HP Backup and Recovery Manager
HP Help and Support Center
HP Universal Print Driver
HP ProtectTools Security Manager:
Device Access Manager for HP ProtectTools
HP Wireless Assistant
Microsoft Office Ready with 60-day Office Professional 2007 Trial
Edition (select models)
Roxio Creator 9 (for optional DVD+/-RW and DVD/CDRW drives)
Synaptics Touchpad Driver
Symantec Norton Internet Security with complimentary 60-day live
update
Intervideo WinDVD – DVD Player
Additional software
available from the web
HP Client Manager
Java Card Security for HP ProtectTools
QuickSpecs
HP Compaq 6720s Notebook PC
Standard Features
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 5
HP Backup and
Recovery Manager
Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager
can provide data and system file protection for HP business PCs to enable fast recovery if the
system becomes corrupted or if important information is accidentally deleted. HP Backup and
Recovery Manager can perform scheduled or manual backups of the entire drive or individual files
and folders. Up to 10 GB of the hard drive is reserved for the system recovery software. HP
Backup and Recovery Manager can also create software recovery CDs or DVDs (requires optional
hardware).
SMBIOS Version 2.4
System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
Security
Standard Features
Device Access Manager for HP ProtectTools
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
HP DriveGuard
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased
separately)
For more information on HP security solutions refer to
http://www.hp.com/go/security
.
Power Supply
External 65-watt AC adapter, 6-foot (1.8-meter) power cord included.
Total length including external AC adapter is 12 feet (3.66 meter).
Battery
Primary battery
6-cell (47 WHr) Lithium-Ion battery
Battery Life
Primary battery
TBD
NOTE:
The listed battery life measurements were taken on models running Microsoft Windows
Vista. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used
by the customer. As with all batteries, the maximum capacity of this battery will decrease with time
and usage.
System Standby Time
Up to 1 week
Power Conservation
Supports enhanced Intel SpeedStep technology with Intel Core 2 Duo processors (allows Battery
Optimized Mode, Maximum Performance Mode, or Automatic mode)
Intel Display Power Saving technology
Hibernation
Standby
ACPI compliance
Service and Support
HP Services offers limited 1-year warranty. On-site service and warranty upgrades are also
available. For HP Care Pack services see
http://www.hp.com/go/lookuptool
.
NOTE:
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for
details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
.
QuickSpecs
HP Compaq 6720s Notebook PC
Standard Features
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 6
Memory
HP 512-MB (DDR2 667 MHz) SODIMM
EM993AA
HP 1-GB (DDR2 667 MHz) SODIMM
EM994AA
HP 2-GB (DDR2 667 MHz) SODIMM
EM995AA
Other Storage
HP Notebooks USB Diskette Drive
DC361B
Power
HP 65W Smart AC Adapter
ED494AA#xxx
HP 65W AC/Auto/Air Combo Smart Adapter
ED993AA#xxx
Carrying Cases
HP Value Nylon Case
RR314AA
HP Universal Nylon Case
RR315AA
HP Executive Leather Case
RR316AA
HP Deluxe Nylon Backpack
RR317AA
HP Deluxe Roller Case
GD405AA
Security
HP/Kensington MicroSaver Security Lock
PC766A
Input/Output Devices
HP PS/2 Keyboard & Mouse Bundle
RC464AA#xxx
HP USB Optical Travel Mouse
RH304AA
QuickSpecs
HP Compaq 6720s Notebook PC
Options
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 7
Up to 4096 MB* of 533-MHz or 667-MHz DDR2 SDRAM
Two DIMM slots
DIMM sizes supported: 512 MB, 1024 MB, and 2048 MB
Standard Memory
512 MB (512 MB x 1)
1024 MB (1024 MB x 1 or 512 MB x 2)
2048 MB (2048 MB x 1 or 1024 MB x 2)
Optional Memory
Upgrades
Both memory slots are user accessible. Please refer to the Hardware and Software Guide for
installation procedures. Maximized dual-channel performance requires SODIMMs of the same size
and speed in both memory slots.
Up to
Slot 1 Slot 2
1024 MB 1024 MB
Empty
1024 MB
512 MB 512 MB
1536 MB 1024 MB
512 MB
2048 MB 1024 MB 1024 MB
4096 MB*
2048 MB 2048 MB
NOTE:
This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some
third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If
you mix memory speeds, the system will perform at the lower memory speed.
*with Mobile Intel GM965 chipset only
Memory Upgrades
HP 512-MB (DDR2 667 MHz) SODIMM
EM993AA
HP 1024-MB (DDR2 667 MHz) SODIMM
EM994AA
HP 2048-MB (DDR2 667 MHz) SODIMM
EM995AA
QuickSpecs
HP Compaq 6720s Notebook PC
Memory
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 8
Removable Media Drive Support
Quantity Supported
Drive Bay
DVD/CD-RW Combo Drive
One
Fixed optical drive bay
DVD+/-RW SuperMulti DL Drive
One
Fixed optical drive bay
DVD+/-RW SuperMulti DL
LightScribe Drive
One
Fixed optical drive bay
Hard Drive Support
Quantity Supported
Drive Bay
Primary Hard Drives
160-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
120-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
80-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
QuickSpecs
HP Compaq 6720s Notebook PC
Storage
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 9
System Unit
Dimensions
(HxWxD)
1.27 in (at front) x 14.1 in x 10.5 in
32.3 mm (at front) x 358 mm x 266.8 mm)
Weight
Starting at 5.5 lb (2.49 kg)
NOTE:
Height varies depending upon where on the notebook the measurement is made. Weight
varies by configuration and components. Weight includes 6-cell battery, 80-GB hard drive, and
optical drive. Weight varies by configuration and components.
Stand-Alone Power
Requirements
(AC
Power)
Nominal Operating
Voltage
18.5 V
Average Operating
Power
12.5 W
Max Operating Power
< 65 W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating
–4° to 140° F (–20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet
bulb temperature
Shock
Operating
125 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude
(unpressurized)
Operating
–50 to 10,000 ft (–15.24 to 3,048 m)
Non-operating
–50 to 40,000 ft (–15.24 to 12,192 m)
Industry Standard
Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR
®
4.0
Yes
ICES
Yes
GS*
Yes
Australia / NZ A-Tick
Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
MIC
Yes
BSMI
Yes
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian
Compliance (ICCP)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
For accessibility information on HP products, please visit
http://www.hp.com/accessibility
.
* This device is not intended for use at visual display workplace in compliance with BildscharbV. If
this product is used in an Office Environment where the VDU Directive 90/270/EEC is applicable
(Bildschirmarbeitsverordnung), an external monitor and external keyboard are recommended to
avoid potential reflections.
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 10
HP 65W AC Adapter
Dimensions
4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight
0.62 lb (280 g)
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC, 0.85 A at 180 VAC
Output
Output power 65W
65W
DC output
18.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide
safety standards – IEC60950, EN60950, UL60950, Class1, SELV;
Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over
200,000 hours at 25°C ambient condition.
6-Cell (47WHr) Lithium-
Ion battery
Dimensions
(H x W x L)
0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight
0.715 lb (0.325 kg)
Cells/Type
6-cell Lithium-Ion
Energy
Watt-hour Capacity
47Wh
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
System in OFF Mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 11
15.4-inch WXGA anti-
glare
Active Area
(W x H)
13.0 x 8.1 in (33.1 x 20.7 cm)
Diagonal Size
15.4 in (39.1 cm)
Surface Treatment
Anti-glare
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
200 nit (typical)
Pixel Resolution
Pitch
0.259 mm
Format
1280x800
Configuration
RGB Stripe
Backlight
CCFL
PPI
98
Viewing Angle
±30° Horizontal, ±10° Vertical (minimum)
15.4-inch WXGA
BrightView
Active Area
(W x H)
13.0 x 8.1 in (33.1 x 20.7 cm)
Diagonal Size
15.4 in (39.1 cm)
Surface Treatment
BrightView
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
200 nit (typical)
Pixel Resolution
Pitch
0.259 mm
Format
1280x800
Configuration
RGB Stripe
Backlight
CCFL
PPI
98
Viewing Angle
±30° Horizontal, ±10° Vertical (minimum)
Hard Drives
160-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
160 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
312,581,808
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 12
120-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
120 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
234,441,648
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
80-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
80 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
156,301,488
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
Removable Storage Drives
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 13
DVD/CD-RW Combo
Drive
Access Times
Random
<110 ms CD
<130 ms DVD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
24X CD-RW
3,600 KB/s
Transfer Mode
Multiword DMA Mode 2
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,
DVD+R, DVD+RW
Supported Media
(write)
CD-R, CD-RW
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
700 MB
Transport
Tray loading
DVD+/-RW SuperMulti
DL Drive
Access Times
Random
<175 ms CD
<230 ms DVD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
16X CD-RW
2,400 KB/s
8X DVD+R
10,800 KB/s
4X DVD+RW
5,400 KB/s
8X DVD-R
10,800 KB/s
4X DVD-RW
5,400 KB/s
2.4X DVD+R(9)
2,700 KB/s
5X DVD-RAM
6,750 KB/s
Transfer Mode
Multiword DMA Mode
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,
DVD+R, DVD+RW, DVD-RAM
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
8.5 GB
Transport
Tray Loading
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 14
DVD+/-RW SuperMulti
DL LightScribe Drive
Access Times
Random
<175 ms CD
<230 ms DVD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
16X CD-RW
2,400 KB/s
8X DVD+R
10,800 KB/s
4X DVD+RW
5,400 KB/s
8X DVD-R
10,800 KB/s
4X DVD-RW
5,400 KB/s
2.4X DVD+R(9)
2,700 KB/s
5X DVD-RAM
6,750 KB/s
Transfer Mode
Multiword DMA Mode
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,
DVD+R, DVD+RW, DVD-RAM
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM,
LightScribe
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
8.5 GB
Transport
Tray Loading
Audio
Hardware
Implementation
ADI1981HD High Definition CODEC
Full Duplex
Yes
Sound Blaster Pro
compatible
Yes
Microphone In
Stereo
Headphone/Line Out
Stereo
Audio Output Quality
Frequency Response
20 Hz – 20 kHz
Signal to Noise Ratio
>85 dB
Total Harmonic
Distortion
0.01%
Noise Floor
-110 dB
Play/Record Sampling
Rate
(s)
8 kHz – 48kHz
DAC
16, 20 or 24-bit
ADC
16 or 20-bit
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 15
Integrated Mono
Speaker
Power Rating
2 Watts
Impedance
4 Ohms
Communications
V.92 56K Data/Fax
Modem
Form Factor
MDC 1.5 Daughtercard
Power Management
Support
APM Revision 1.2, ACPI
Approvals/
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC
Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian
ACA, CE Mark, Other Countries
Data Mode Capabilities
V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
Fax Mode Capabilities
TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
Command Set
V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
Intel PRO/Wireless
3945ABG Network
Connection
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 16
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft
Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
15 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode
3
: 150 mW (nominal)
Sleep mode: 30 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna Connections
2 U.FL type connectors, 50 ohm nominal impedance
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3V +/- 9%, 1.5V +/- 5%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 17
Configuration Utility
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for
Cisco Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party
software supplicants.
5.
Intel PRO/Wireless
3945BG Network
Connection
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft
Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
15 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode
3
: 150 mW (nominal)
Sleep mode: 30 mW (max)
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 18
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna Connections
2 U.FL type connectors, 50 ohm nominal impedance
Range
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3V +/- 9%, 1.5V +/- 5%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for
Cisco Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party
software supplicants.
5.
Intel Wireless WiFi Link
4965AGN
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft 1.02)
Interoperability
Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with
Microsoft Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Tested with wireless access points from several major manufacturers
(details at
http://www.hp.com/go/notebooks/WLAN/
draft-n)
Frequency Band
2.4 GHz and 5 GHz
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 19
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (draft): 66 possible data rates, ranging from 6 Mbps to 300
Mbps, depending on the combination of Bandwidth, Modulation Coding
Scheme, and Guard Interval used, as defined in IEEE 802.11n (draft)
specification
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES (support for key sizes of 128, 192, and 256 bits), 802.1x
authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4) with Microsoft Windows 2000 and XP
only.
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
15 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 2.3 Watts (average, with two spatial streams)
Receive: 1.9 Watts (average with three receive chains)
Idle mode
3
: 30 mW (average)
Radio off: 20 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
300 Mbps: -68 dBm, 54 Mbps: -74 dBm, 6 Mbps: -90 dBm
Antenna Connections
3 U.FL type connectors, 50 ohm nominal impedance
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3V +/- 9%, 1.5V +/- 5%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 90% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 20
Configuration Utility
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for
Cisco Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode and on battery power.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party
software supplicants.
5.
Intel Wireless WiFi Link
4965AG
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft
Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz and 5 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES (support for key sizes of 128, 192, and 256 bits), 802.1x
authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4) with Microsoft Windows 2000 and XP
only.
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
15 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 21
Power Consumption
Transmit: 1.6 Watts (average)
Receive: 1.1 Watts (average)
Idle mode
3
: 30 mW (average)
Radio off: 20 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -74 dBm, 6 Mbps: -90 dBm
Antenna Connections
2 U.FL type connectors, 50 ohm nominal impedance
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3V +/- 9%, 1.5V +/- 5%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 90% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for
Cisco Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode and on battery power.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party
software supplicants.
5.
Broadcom 4311AG
802.11a/b/g WiFi
Adapter
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft
Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz and 5 GHz
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 22
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
17.5 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.026 lb (12 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 23
Configuration Utility
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party
software supplicants.
5.
Broadcom 4311BG
802.11b/g WiFi Adapter
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft
Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
17.5 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 24
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.026 lb (12 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party
software supplicants.
5.
HP Integrated Module
with Bluetooth
Wireless Technology
Bluetooth Specification
2.0 Compliant
Dimensions
1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
79 (1 MHz) available channels
Data Rates and
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric
Transmit Power
-6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity
Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Peak (Tx) 264 mW
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 25
Peak (Rx) 231 mW
Sleep <1 mW
Antenna
Internally integrated within module
Range
Up 33 ft (10 m)
Electrical Interface
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
OS Support
Genuine Windows Vista
Genuine Windows XP
Genuine Windows 2000
Bluetooth Software
Supported
Broadcom Bluetooth for Windows
Microsoft Windows XP Bluetooth Software
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
Full support of Bluetooth Security Provisions
Power Management
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Temperature
Operating
-4° to 158° F (-20° to 70° C)
Non-operating
-40° to 176° F (-40° to 80° C)
Humidity
Operating
10% to 90%
Non-operating
5% to 95%
Altitude
Operating
15,000 ft (4,572 m)
Non-operating
40,000 ft (12,192 m)
Bluetooth Profiles
Supported
(with Bluetooth for Windows 4.0 software)
Serial Port Profile (SPP)*
Dial-Up Networking (DUN)*
Generic Object Exchange Profile (GOEP)
Object Push Profile (OPP)*
File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)*
Personal Area Networking Profile (PAN)*
Human Interface Device Profile (HID)*
FAX Profile (FAX)
Basic Imaging Profile (BIP)
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
*
indicates the profile is also supported by Microsoft Windows XP SP2
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 26
Environmental Data
Eco-Label
Certifications
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
ENERGY STAR 4.0
US Federal Energy Management Program (FEMP)
ECO declaration
Taiwan Green Mark
China Energy Certification Program (CECP)
Korean Eco Label
EPEAT Silver Rating
System Configuration
The configuration used for the Energy Consumption and Declared Noise
Emissions data is based on a “Typically Configured Notebook”
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
18.6 W 18.9 W 18.8 W
Sleep (Energy Star low
power mode)
1 W
1.1 W
0.99 W
Off
0.9 W
1.01 W
0.9 W
Heat Dissipation*
115 VAC 230 VAC 100 VAC
Normal Operation
63.463 BTU/hr 64.486 BTU/hr 64.145 BTU/hr
Sleep
3.412 BTU/hr 3.753 BTU/hr 3.377 BTU/hr
Off
3.07 BTU/hr
3.446 BTU/hr
3.07 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
This product is in compliance with US executive order 13221, WOL
(wake on LAN) disabled.
Declared Noise
Emissions
(in accordance with ISO
7779 and ISO 9296)
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
3.4
27.3
Operating mode (HDD)
3.4
27.4
Batteries
This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000 ppm by weight.
The battery type and chemistry used in the product is:
CR2032 (coin cell), Lithium
6 cell rechargeable Lithium-Ion battery
Additional
information:
This product is in compliance with the EU Restrictions of Hazardous
Substances (RoHS) Directive – 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 27
ISO/IEC 15412
Input devices of this product comply with ISO 9241, part 9.
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
This product contains 0% recycled materials (by wt.)
This product is greater than 96% recyclable when properly disposed of
at end of life.
Packaging Materials
External:
Corrugated / Paper – 2.25 lb (1019 g)
Internal:
EPE Foam – 0.15 lb (70 g)
LDPE Bag – 0.043 lb (19.44 g)
The corrugated paper packaging materials contains at least 40%
recycled content.
HP follows these guidelines to decrease the environmental impact of
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
Material Usage
This product does not contain any of the following substances in excess
of regulatory limits (for reference of these limits please refer to the HP
General Specification of the Environment
(
http://www.hp.com/hpinfo/globalcitizenship/
environment/supplychain/gen_specifications.html
):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as
flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface
designed to be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 28
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
End-of-life
Management and
Recycling
HP offers our customers several other options for handling their aging
computers while also minimizing the impact on the
environment—including product trade-in and leasing services-in
addition to recycling services.
Please go to:
http://www.hp.com/recycle
or contact your nearest HP sales office. Products returned to HP will be
recycled, recovered or disposed of in a responsible manner.
Hewlett-Packard
Corporate
Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Environment website
http://www.hp.com/environment
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/
environment/productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/
environment/operations/envmanagement.html
Copyright © 2007 Hewlett-Packard Development Company, L.P.
All rights reserved. Microsoft, Windows and Windows XP are registered trademarks or trademarks of Microsoft Corporation in
the U.S. and/or other countries. Core 2 Duo and Celeron are registered trademarks or trademarks of Intel Corporation in the
U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All
other product names mentioned herein may be trademarks of their respective companies.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing
herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or
omissions contained herein.
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 29

Navigation menu
