Overview
Standard Features
Options
Memory
Storage
Technical Specifications

HP recommends Windows Vista

Business

Volume mute button with LED indicator

14.

Touchpad with scroll zone

Volume scroll zone with up/down LED indicators

15.

Touchpad buttons, three

Calculator button

16.

Hard drive / optical drive activity / HP 3D DriveGuard

LED

RJ-45/Ethernet port

17.

Battery charging LED

RJ-11/modem port

18.

Power/standby LED

Optical drive

19.

Wireless on/off LED

Full numeric keypad

20.

Power button with LED

4 USB 2.0 ports

21.

HP Info / HP QuickLook button with LED indicator

Stereo microphone in

22.

Wireless on/off button with LED indicator

10.

Stereo headphone/line out

23.

HP Presentation button with LED indicator

11.

HP Fingerprint Sensor

24.

Ambient Light Sensor

12.

Pointstick

25.

Three WLAN antennas (with WLAN option)

13.

Pointstick buttons, three

26.

Integrated microphone

QuickSpecs

HP Compaq 8710w Mobile Workstation

Overview

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 1

Kensington Lock slot

PC Card eject button

Power connector

10.

Integrated stereo speakers

HDMI port

11.

Media Card Reader

VGA/external monitor connector

12.

Hard drive activity / HP 3D DriveGuard LED

2 USB 2.0 ports

13.

Battery charging LED

1394a port

14.

Power/standby LED

Integrated Smart Card Reader

15.

Wireless on/off LED

Type I/II PC Card slot

QuickSpecs

HP Compaq 8710w Mobile Workstation

Overview

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 2

At A Glance

Genuine Windows Vista Business*, Genuine Windows XP Professional, or FreeDOS

NVIDIA Quadro FX 1600M graphics with up to 512 MB dedicated memory

DirectX 10 support and Dual Link DVI (available through optional docking) provides faster rendering capabilities and

support for ultra-high resolution monitors

Intel® Centrino® Pro processor technology capable, with Intel Core™2 Duo processors

HDMI high definition video/audio port

Optional Blu-Ray DVD+/-RW SuperMulti DL Drive

Designed to travel, with weight starting at 7.5 lb/3.4 kg and 1.3-inch/33 mm thin at front

Widescreen 17.0-inch diagonal display with wide-viewing angle (select models), BrightView (select models), Ambient

Light Sensor and HP Privacy Filter support

Integrated Media Card Reader

Full-sized keyboard with separate numeric keypad

Enhanced reliability with HP DuraKeys, HP DuraFinish, and magnesium alloy support structures

Enhanced security features including integrated Smart Card Reader, Drive Encryption for HP ProtectTools, HP

Fingerprint Sensor, TPM 1.2**

HP QuickLook on Windows Vista models for instant access to email, calendar, and contact information

Flexible wireless connectivity options:

Integrated 802.11 a/b/g/draft-n, a/b/g, or b/g wireless LAN module

Bluetooth®

Up to 160-GB 7200 rpm user-removable hard drive with HP 3D DriveGuard protection or 64-GB Solid State Drive

Touch-sensitive controls for HP Info Center, HP QuickLook, wireless on/off, HP Presentation button, volume up,

volume down, and mute

Up to 4GB of 667-MHz DDR2 SDRAM, dual channel memory support

Integrated Intel Gigabit Network Connection (10/100/1000 NIC)

Enhanced dual pointing devices (touchpad with scroll zone and pointstick)

* At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version will be deleted.

** TPM module disabled where not permitted by law (for example, Russia and China).

QuickSpecs

HP Compaq 8710w Mobile Workstation

Overview

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 3

Processors

Intel Core 2 Duo Processor T7800 (2.60-GHz, 800-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7700 (2.40-GHz, 800-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7500 (2.20-GHz, 800-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7300 (2.00-GHz, 800-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7250 (2.00-GHz, 800-MHz FSB, 2-MB L2 cache)*

Intel Core 2 Duo Processor T7100 (1.80-GHz, 800-MHz FSB, 2-MB L2 cache)*

* Intel's numbering is not a measurement of higher performance.

NOTE:

Processor speed denotes maximum performance mode; processors will run at lower

speeds n battery optimization mode.

Operating System

Preinstalled

Genuine Windows Vista Business

†

Genuine Windows XP Professional

FreeDOS

Supported

Genuine Windows Vista Enterprise*

Genuine Windows 2000

Certified

SuSE Linux Enterprise Desktop 10

†

At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other

version will be deleted.

* Certain Windows Vista product features require advanced or additional hardware. See

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

and

http://www.microsoft.com/windowsvista/getready/capable.mspx

for details. Windows Vista

Upgrade Advisor can help you determine which features of Windows Vista will run on your

computer. To download the tool, visit

http://www.windowsvista.com/upgradeadvisor

Chipset

Mobile Intel PM965 with 800-MHz front side bus

Intel Centrino Pro

processor technology

capable

Intel Centrino Pro processor technology is a selectable feature that is available on units configured

with an Intel Wireless WiFi Link 4965AGN or 4965AG. It provides advances in remote

manageability, security, energy efficient performance, and wireless connectivity. Intel Active

Management Technology (AMT) offers built-in manageability and proactive security for networked

notebook PCs, even when they are powered off* or when the operating system is inoperable. It

can help identify threats before they reach the operating system, isolate infected systems, and

update PCs regardless of their power state.

*Requires a Windows operating system, network hardware and software, connection with a power

source, and a direct (non-VPN) corporate network connection which is either cable or wireless

LAN.

NOTE:

Some functionality of Intel Centrino Pro, such as Intel AMT and Intel Virtualization

technology, requires additional 3rd party software in order to run. Availability of future "virtual

appliances" applications for Centrino Pro processor technology is dependant on 3rd party software

providers. Compatibility of this generation of Centrino Pro technology-based hardware with future

"virtual appliances" and Microsoft Windows Vista operating system is to be determined.

Graphics

NVIDIA Quadro FX 1600M graphics with 512 MB dedicated video memory

Microsoft DirectX 10 support

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 4

Display

Internal

17.0-inch diagonal WXGA+ anti-glare (1440 x 900 resolution)

17.0-inch diagonal WSXGA+ anti-glare wide-viewing angle (1680 x 1050

resolution)

17.0-inch diagonal WSXGA+ wide-viewing angle BrightView (1680 x

1050 resolution)

17.0-inch diagonal WUXGA wide-viewing angle anti-glare (1920 x 1200

resolution)

Ambient light sensor

Integrated lid switch

HP Privacy Filter support

External

Up to 32-bit per pixel color depth

VGA

port supports resolutions up to 2048 x 1536 at 75 Hz, and lower

resolutions at up to 100 Hz

HDMI

1.2 port supports direct connection to high-definition displays with

up to 1920 x 1080 resolution and 7-channel audio with one convenient

cable (not included).

DVI

port in optional HP Docking Station (sold separately)

supports resolutions up to 1920 x 1200 for single-link DVI monitors and

up to 2560 x 1600 for dual-link DVI monitors.

NOTE:

Resolutions are dependent upon monitor capability, and

resolution and color depth settings.

Memory

Standard

512-MB, 1024-MB, 2048-MB, or 4096-MB 667-MHz DDR2 SDRAM; two

SODIMM slots supporting dual channel memory

Maximum

Upgradeable to 4096-MB with 2048-MB SODIMM in slots 1 and 2

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same

size and speed in both memory slots.

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we

recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system

will perform at the lower memory speed. Above 3-GB, all memory may not be available due to

system resource requirements.

Communications

Integrated Intel Gigabit Network Connection (10/100/1000 NIC)*

56K V.92 modem**

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab

for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed

transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download

transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem

availability is subject to country regulatory approval.

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 5

Wireless Devices

Support for a broad range of secure, integrated wireless LAN options featuring support for the

latest industry standards. Wireless LAN is factory configurable or available as an option to be

added later. Integrated Bluetooth is also available (factory configurable only) and can be

combined with any of the supported wireless LAN options.

All 802.11a/b/g

integrated wireless

LAN options

Wi-Fi certified

Cisco Compatible Extensions support (Version 4.0) with Microsoft

Windows XP

Wired Equivalent Privacy (WEP) support up to 128-bit keys

Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-

GTC, PEAP-MSCHAPv2, and LEAP

Advanced Encryption Standard (AES) support

WiFi certified for WPA2, WMM

Three antennas integrated in the display enclosure

Intel Wireless WiFi Link

4965AGN

Integrated support for 802.11a, b, g, and draft-n

Up to 300-mbps data rate

Intel Wireless WiFi Link

4965AG

Integrated support for 802.11 a, b and g

Up to 54-mbps data rate

Intel PRO/Wireless

3945BG Network

Connection

Integrated support for 802.11 b and g

Up to 54-mbps data rate

Broadcom 4311AG

802.11a/b/g

WiFi Adapter

Integrated support for 802.11 a, b and g

Up to 54-mbps data rate

Broadcom 4311BG

802.11b/g

WiFi Adapter

Integrated support for 802.11 b and g

Up to 54-mbps data rate

HP Integrated Module

with Bluetooth

Wireless Technology

Bluetooth Specification v2.0 compliant

Works with a wide range of Bluetooth devices

Keyboard

The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with

desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both

left and right control and alt keys, and 12 function keys. US and International key layouts are

available. Other features include a full numeric keypad, hotkeys for instant access to power

conservation, brightness, and other features, 19.05-mm x 19.05-mm key pitch (center-to-center

spacing), 3.0-mm stroke, and comfort-dished keycaps.

HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish

and the printed characters on the keys.

HP DuraFinish helps protect the finish on the keyboard deck, graphics, and icons from normal

wear and tear.

Touch-sensitive

controls

Touch-sensitive controls provide easy access to the following features: HP Info Center, HP

QuickLook, wireless on/off, HP Presentation button, volume up, volume down, mute, and

calculator button

Pointing device

Enhanced dual pointing devices (touchpad with scroll zone and pointstick, both with three pick

buttons)

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 6

Expansion card slots

1 Type I/II PC Card slot

Supports 32-bit CardBus and 16-bit PC Cards

Integrated Smart Card

Reader

Compatible with ISO 7816 compliant Smart Cards

PC/SC interface support

Secure Digital slot

Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,

Memory Stick Pro, Memory Stick Duo*, xD-Picture card

* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo

Card directly into your notebook could damage the memory card and/or notebook.

Storage

Primary Storage Device

80/120/160-GB 5400 rpm SMART SATA Hard Drive

80/100/120/160-GB 7200 rpm SMART SATA Hard Drive

64-GB Solid State Drive

NOTE:

Hard drives are customer removable and will withstand multiple insertion/removal cycles.

Up to 10 GB is reserved for the system recovery software.

HP 3D DriveGuard

The hard drive is mounted directly to the notebook frame, reducing the

transmission of shock away from the hard drive. Uses three-axis digital

motion detection with intelligent sensitivity to help protect the hard drive

during normal use from shock and vibration. The digital accelerometer

temporarily halts all data transfer and parks the hard drive when abrupt

motion is detected.

Optical drives

DVD-ROM Drive

DVD/CD-RW Combo Drive

DVD+/-RW SuperMulti DL Drive

DVD+/-RW SuperMulti DL LightScribe Drive

Blu-Ray Disc DVD+/-RW SuperMulti DL Drive

NOTE:

Optical drive is user replacable with HP option. Requires single screw removal.

Interfaces

PC Card slot

One Type I/II PC Card slot

Smart Card Reader

One

Media Card Reader

One

External monitor

One – VGA

1394a

One – 4-pin connector

Stereo microphone in

One

Stereo headphone/line

out

One

Power connector

One

RJ-11/modem

One

RJ-45/Ethernet

One

HDMI

One – 1.2 compliant

USB 2.0

Six

Docking connector

One

Secondary battery

connector

One

LED status indicators

Sixteen

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 7

Audio

High Definition Audio support w/24-bit DAC

Integrated stereo speakers

Integrated microphone

Touch-sensitive controls for volume up, volume down, and mute

Stereo headphone/line out

Stereo microphone in

Software

Preinstalled software

with Windows Vista or

Windows XP

PDF Complete

HP Backup and Recovery Manager

HP Help and Support Center

HP QuickLook (Windows Vista only)

HP OpenView Radia Management Agent

HP Performance Tuning Framework

HP Universal Print Driver

HP ProtectTools Security Manager:

BIOS Configuration for HP ProtectTools

Credential Manager for HP ProtectTools

Device Access Manager for HP ProtectTools

Drive Encryption for HP ProtectTools

Embedded Security for HP ProtectTools

HP Quick Launch Buttons

HP Wireless Assistant

Microsoft Office Ready with 60-day Office Professional 2007 Trial

Edition (select models)

Roxio Creator 9 (for optional DVD+/-RW and DVD/CDRW drives)

Synaptics Touchpad Driver

Symantec Norton Internet Security with complimentary 60-day live

update

Intervideo WinDVD – DVD/Blu-Ray Disc Player

Software provided on

disc

Roxio Creator 9 (for optional Blu-Ray Disc drives)

Additional software

available from the web

HP Client Manager

Java Card Security for HP ProtectTools

Workstation ISV

Certifications

MCAD

(Mechanical

CAD/Architectural

Engineering and

Construction)

AutoDesk AutoCAD

AutoDesk Inventor

AutoDesk Revit

Bentley Microstation

Dassault Catia V5

UGS I-DEAS NX 10

UGS I-DEAS NX 11

UGS/PLM Unigraphics NX, NX2, NX3

PTC Pro/E 2001 Mechanica

PTC Pro/E Wildfire Mechanica

MSC.Patran

UGS Solidedge

Solidworks

ICEM Surf

CoCreate OneSpace Designer

SensAble

PTC DV Mockup

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 8

DCC

(Digital Content

Creation)

Discreet 3DS MAX/Combustion

Alias Maya

Alias Studio Tools

Avid SoftImage XSI/3D

Avid Express Pro

Adobe Premiere/After Effects

GIS

(Geographic Information

Systems)

ESRI ArcGIS 9

Oil and Gas

SMT

Landmark/GeoGrpahix

EDS

Roxar

Schlumberger/Petrel

HP Performance

Tuning Framework

HP Performance Tuning Framework (PTF) enables optimal configuration of HP Mobile

Workstations delivering stability and best performance. HP PTF will guide your system setup

allowing a "custom" configuration that best matches the workstation to user requirements.

HP Backup and

Recovery Manager

Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager

can provide data and system file protection for HP business PCs to enable fast recovery if the

system becomes corrupted or if important information is accidentally deleted. HP Backup and

Recovery Manager can perform scheduled or manual backups of the entire drive or individual files

and folders. Up to 10 GB of the hard drive is reserved for the system recovery software. HP

Backup and Recovery Manager can also create software recovery CDs or DVDs (requires optional

CD-RW or DVD+/-RW hardware).

SMBIOS Version 2.4

System Management BIOS, previously known as DMI BIOS, is used to store system management

information.

HP ProtectTools

Security Manager

HP ProtectTools Security Manager is the security platform for business notebooks and desktops.

The HP ProtectTools Security Manager is an extensible client security console that delivers

enhanced security capabilities through add-on software modules. Modules currently available are:

BIOS Configuration for HP ProtectTools

Credential Manager for HP ProtectTools

Device Access Manager for HP ProtectTools

Drive Encryption for HP ProtectTools

Embedded Security for HP ProtectTools

Java Card Security for HP ProtectTools

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 9

Security

Standard Features

HP ProtectTools Security Manager

HP Fingerprint Sensor

Integrated Smart Card Reader

Configuration Control Hardware

Memory Change Alert

Ownership Tag

Setup Password

Power-On Password

TPM 1.2 Embedded Security Chip*

TPM Enhanced DriveLock*

HP Disk Sanitizer

HP 3D DriveGuard

Kensington Lock Slot

Support for Computrace / LoJack for Laptops (must be purchased

separately)

Optional Features

HP Privacy Filter

Narrows viewing area so that screen data is

visible only to persons directly in front of the

monitor

* TPM module disabled where use is restricted by law; for example, Russia and China.

For more information on HP security solutions refer to

http://www.hp.com/go/security

Power Supply

External 120-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.

Total length including external AC adapter is 12 feet (3.66 meter).

HP Fast Charge*

*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast Charge does not

apply to 12-cell Ultra-Capacity batteries.

Battery

Primary battery

8-cell (73 WHr) Lithium-Ion battery

Optional HP Extended

Life Battery

8-cell (52 WHr) high capacity Lithium-Ion battery

Optional HP Ultra-

Capacity Battery

12-cell (95 WHr) high capacity Lithium-Ion battery

Battery Life

Primary battery

Up to 4 hours

Primary battery and

optional HP Extended

Life Battery

Up to 7 hours

Primary battery and

optional HP Ultra-

Capacity Battery

Up to 9 hours

NOTE:

The listed battery life measurements were taken on models running Microsoft Windows XP

Professional. Battery life will vary depending on the product configuration, product model,

applications loaded on the product, power management settings of the product, and the product

features used by the customer. As with all batteries, the maximum capacity of this battery will

decrease with time and usage.

System Standby Time

Up to 2 weeks

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 10

Power Conservation

NVIDIA PowerMizer 7.0 technology

Hibernation

Standby

ACPI compliance

Docking and Stands

HP 3-in-1 NAS Docking Station

HP Advanced Docking Station

HP Docking Station

HP Standard Monitor Stand

HP Adjustable Notebook Stand

HP External MultiBay II

HP's shared docking solutions provide simple and convenient port replication and cable

management. Features include Gigabit NIC pass through, modem pass through, legacy parallel

and serial ports, S-video TV out, composite video, Dual Link DVI-D, USB 2.0 ports, integrated

security mechanism*, integrated MultiBay II and ExpressCard** slots. These docking solutions are

compatible across multiple Business Notebook platforms enabling a lower total cost of ownership.

* HP/Kensington Cable Lock required (purchased separately)

** HP 3-in-1 NAS Docking Station and HP Advanced Docking Station only

Service and Support

HP Services offers limited 3- year, 1-year and 90-day warranty options depending on country;

1-year limited warranty on primary battery. On-site service and warranty upgrades are also

available. For HP Care Pack services see

http://www.hp.com/go/lookuptool

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for

details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

QuickSpecs

HP Compaq 8710w Mobile Workstation

Standard Features

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 11

Memory

HP 512-MB (DDR2 667 MHz) SODIMM

EM993AA

HP 1-GB (DDR2 667 MHz) SODIMM

EM994AA

HP 2-GB (DDR2 667 MHz) SODIMM

EM995AA

MultiBay II Storage

(9.5-mm)

NOTE:

Requires HP 3-

in-1 NAS Docking

Station, HP Advanced

Docking Station, or HP

External MultiBay II

HP MultiBay II DVD-ROM Drive

PA849A

HP MultiBay II DVD/CD-RW Combo Drive

PA850A

HP MultiBay II DVD+/-RW SuperMulti DL Drive

PA851A

HP 80-GB 5400rpm MultiBay II Hard Drive

PH357A

Other Storage

HP 80-GB 5400rpm Primary SATA Hard Drive

ET354AA

HP 120-GB 5400rpm Primary SATA Hard Drive

RT080AA

DVD+/-RW SuperMulti DL LightScribe Drive

ET353AA

HP Notebooks USB Diskette Drive

DC361B

Communications

Intel Wireless WiFi Link 4965AGN option kit

RT081AA#xxx

Expansion Solutions

HP Docking Station with Smart Adapter

EN488AA#xxx

HP Advanced Docking Station with Smart Adapter

EN489AA#xxx

HP 3-in1 NAS Docking Station with Smart Adapter

EM537AA#xxx

HP Standard Monitor Stand

PA507A

HP Adjustable Notebook Stand

PA508A

HP External MultiBay II

PA509A#xxx

Power

HP 2-Bay Battery Charging Station (North America)

DT533A#xxx

HP 2-Bay Battery Charging Station (rest of world)

EW424AA#xxx

HP 10-Bay Battery Charging Station (North America)

DT534A#ABA

HP Battery Adapter Kit

PK402A

HP 135W Smart AC Adapter

ED519AA#xxx

HP 90W Smart AC Adapter

ED495AA#xxx

HP 90W Smart Auto Adapter

ED493AA

HP 65W AC/Auto/Air Combo Smart Adapter

ED993AA#xxx

HP 8-Cell Li-Ion Primary Battery

PB992A

HP 8-cell Extended Life Battery

PB993A

HP 12-cell Ultra-Capacity Battery

EJ092AA

QuickSpecs

HP Compaq 8710w Mobile Workstation

Options

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 12

Carrying Cases

HP Value Nylon Case

RR314AA

HP Universal Nylon Case

RR315AA

HP Executive Leather Case

RR316AA

HP Deluxe Nylon Backpack

RR317AA

HP Universal Messenger Bag

GD404AA

HP Deluxe Roller Case

GD405AA

Security

HP PC Card Smart Card Reader with Java Card

EL347AA

HP ProtectTools Java Card – 10 units

EL348AA

HP/Kensington MicroSaver Security Lock

PC766A

Input/Output Devices

HP PS/2 Keyboard & Mouse Bundle*

RC464AA#xxx

HP USB Keyboard & Mouse Bundle

RC465AA#xxx

HP USB/PS2 Optical 2-Button Scroll Mouse

DC369A

HP USB Optical Travel Mouse

F2100A

HP Bluetooth PC Card Mouse

RJ316AA

* Requires HP Docking Station, HP Advanced Docking Station, or HP 3-in-1 NAS Docking Station

QuickSpecs

HP Compaq 8710w Mobile Workstation

Options

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 13

667-MHz DDR2 SDRAM

Two DIMM slots supporting dual channel memory

DIMM sizes supported: 512 MB, 1024 MB, 2048 MB

Standard Memory

512 MB (512 MB x 1)

1024 MB (1024 MB x 1 or 512 MB x 2)

2048 MB (2048 MB x 1 or 1024 MB x 2)

4096 MB (2048 MB x 2)

Optional Memory

Upgrades

Support for up to 4096 MB of memory with the installation of optional DDR2 SDRAM memory kits.

Both memory slots are user accessible. Please refer to the Hardware and Software Guide for

installation procedures. Maximized dual-channel performance requires SODIMMs of the same size

and speed in both memory slots.

Up to

Slot 1 Slot 2

1024 MB 1024 MB

Empty

1024 MB

512 MB 512 MB

1536 MB 1024 MB

512 MB

2048 MB 1024 MB 1024 MB

4096 MB 2048 MB 2048 MB

NOTE:

This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some

third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If

you mix memory speeds, the system will perform at the lower memory speed. Above 3-GB, all memory may not be available

due to system resource requirements.

Memory Upgrades

HP 512-MB (DDR2 667 MHz) SODIMM

EM993AA

HP 1024-MB (DDR2 667 MHz) SODIMM

EM994AA

HP 2048-MB (DDR2 667 MHz) SODIMM

EM995AA

QuickSpecs

HP Compaq 8710w Mobile Workstation

Memory

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 14

Optical Drive Support

Quantity Supported

Drive Bay

DVD-ROM Drive

One

Fixed optical drive bay

DVD/CD-RW Combo Drive

One

Fixed optical drive bay

DVD+/-RW SuperMulti DL Drive

One

Fixed optical drive bay

DVD+/-RW SuperMulti DL

LightScribe Drive

One

Fixed optical drive bay

Blu-Ray Disc DVD+/-RW

SuperMulti DL Drive

One

Fixed optical drive bay

Primary Storage Device

Quantity Supported

Drive Bay

Hard Drives

160-GB 5400 rpm SMART SATA

Hard Drive

One

Dedicated hard drive bay

120-GB 5400 rpm SMART SATA

Hard Drive

One

Dedicated hard drive bay

80-GB 5400 rpm SMART SATA

Hard Drive

One

Dedicated hard drive bay

160-GB 7200 rpm SMART SATA

Hard Drive

One

Dedicated hard drive bay

120-GB 7200 rpm SMART SATA

Hard Drive

One

Dedicated hard drive bay

100-GB 7200 rpm SMART SATA

Hard Drive

One

Dedicated hard drive bay

80-GB 7200 rpm SMART SATA

Hard Drive

One

Dedicated hard drive bay

Solid State Drive

64-GB Solid State Drive

One

Dedicated hard drive bay

QuickSpecs

HP Compaq 8710w Mobile Workstation

Storage

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 15

System Unit

Dimensions

(HxWxD)

1.3 in (at front) x 15.5 in x 10.8 in

33 mm (at front) x 393 mm x 275 mm

Weight

Starting from 7.5 lb (3.4 kg)

NOTE:

Height varies depending upon where on the notebook the measurement is made. Starting

weight includes 8-cell battery, hard drive, 512-MB memory, 802.11 wireless communications

module, Bluetooth, and optical drive. Weight varies by configuration and components.

Stand-Alone Power

Requirements

(AC

Power)

Nominal Operating

Voltage

18.5 V

Average Operating

Power

12.5 W

Max Operating Power

< 120 W

Temperature

Operating

32° to 95° F (0° to 35° C) (not writing optical)

41° to 95° F (5° to 35° C) (writing optical)

Non-operating

–4° to 140° F (–20° to 60° C)

Relative Humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet

bulb temperature

Shock

Operating

125 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random Vibration

Operating

0.75 grms

Non-operating

1.50 grms

Altitude

(unpressurized)

Operating

–50 to 10,000 ft (–15.24 to 3,048 m)

Non-operating

–50 to 40,000 ft (–15.24 to 12,192 m)

Industry Standard

Certifications

Yes

CSA

Yes

FCC Compliance

Yes

ICES

Yes

Australia / NZ A-Tick

Compliance

Yes

CCC

Yes

Japan VCCI Compliance

Yes

MIC

Yes

BSMI

Yes

CE Marking Compliance

Yes

BNCI or BELLIS

Yes

CIT

Yes

GOST

Yes

Saudi Arabian

Compliance (ICCP)

Yes

SABS

Yes

UKRSERTCOMPUTER

Yes

For accessibility information on HP products, please visit

http://www.hp.com/accessibility

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 16

HP 120W Smart AC

Adapter

Weight

1.52 lb (0.69 kg) (adapter)

0.29 lb (0.13 kg) (power cord)

Dimensions

6.65 x 2.56 x 1.50 in (16.9 x 6.5 x 3.8 cm)

Input

Operating Input Voltage

100 to 240 VAC

Operating Input Current

PFC Version:

2.20 A at 90 VAC

1.10 A at 180 VAC

Non-PFC Version:

2.5 A at 110 VAC

1.25 A at 180 VAC

Operating Frequency

Range

47 to 63 Hz AC

Efficiency

83% minimum at 115 VAC

Output

Output power

120 W

DC Output Voltage

18.5 V

Environmental Design

Operating Temperature

32° to 104° F (0° to 35° C)

Non-operating (storage)

Temperature

–4° to 149° F (–20° to 65° C)

Altitude

0 to 10,000 ft (0 to 3,048 m)

Humidity

20% to 80%

Storage Humidity

10% to 90%

EMI and Safety

Certifications

CE Mark: full compliance with LVD and EMC directives

Worldwide safety standards: IEC60950, EN60950, UL60950, Class2,

SELV

Agency approvals: C-UL-US, NORDICS, DENAN, EN55022 Class B,

FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE, S-Mark,

Australian Electric Permit, PSB, eK, BSMI, BNCI, KONCAR, GS,

GOST, SASO, SABS, UKRSERTCOMPUTER

NOTE:

Approvals in italics apply to PFC version only.

MTBF

Over 200,000 hours at 25°C ambient condition

Optional HP Ultra-

Capacity Battery

Dimensions

(H x W x L)

1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)

Weight

1.77 lb (0.803 kg)

Cells/Type

12-cell Lithium-Ion

Energy

Watt-hour Capacity

95Wh

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 140° F (–10° to 60° C)

Non-operating

–4° to 140° F (–20° to 60° C)

Battery Re-Charge

Time

Smart Adapter

3 to 4 hours

System ON

4 to 5 hours (depending on system power

consumption)

Fuel Gauge

When pressed, LEDs light indicating level of charge remaining on

battery

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 17

Optional HP Extended

Life Battery

Dimensions

(H x W x L)

1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)

Weight

1.00 lb (0.455 kg)

Cells/Type

8-cell Lithium-Ion

Energy

Watt-hour Capacity

52Wh

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 140° F (–10° to 60° C)

Non-operating

–4° to 140° F (–20° to 60° C)

Battery Re-Charge

Time

System in OFF mode or

Standby

3 hours

System ON

3 to 5 hours (depending on system power

consumption)

HP Fast Charge

Charges the battery up to 90% within 90

minutes when system is OFF

Fuel Gauge

When pressed, LEDs light indicating level of charge remaining on

battery

8-Cell (73WHr) Lithium-

Ion battery

Dimensions

(H x W x L)

0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)

Weight

0.980 lb (0.445 kg)

Cells/Type

8-cell Lithium-Ion

Energy

Watt-hour Capacity

73Wh

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 140° F (–10° to 60° C)

Non-operating

–4° to 140° F (–20° to 60° C)

Battery Re-Charge

Time

System in OFF mode or

Standby

2.5 hours

System ON

3 to 5 hours (depending on system power

consumption)

HP Fast Charge

Charges the battery up to 90% within 1.5

hours when system is OFF

17.0-inch WXGA+ anti-

glare

Active Area

(W x H)

14.5 x 9.0 in (36.7 x 22.9 cm)

Diagonal Size

17.0 in (43.2 cm)

Surface Treatment

Anti-glare

Contrast Ratio

300:1 typical

Refresh Rate

60 Hz

Brightness

200 nit typical

Pixel Resolution

Pitch

0.255 mm

Format

1440 x 900

Configuration

RGB Stripe

Backlight

CCFL

PPI

100

Viewing Angle

±30° Horizontal, ±10° Vertical (minimum)

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 18

17.0-inch WSXGA+

wide-viewing angle,

anti-glare

Active Area

(W x H)

14.5 x 9.0 in (36.7 x 22.9 cm)

Diagonal Size

17.0 in (43.2 cm)

Surface Treatment

Anti-glare

Contrast Ratio

300:1 typical

Refresh Rate

60 Hz

Brightness

200 nit typical

Pixel Resolution

Pitch

0.219 mm

Format

1680 x 1050

Configuration

RGB Stripe

Backlight

CCFL

PPI

116

Viewing Angle

±60° Horizontal, ±50° Vertical (minimum)

17.0-inch WSXGA+

wide-viewing angle

BrightView

Active Area

(W x H)

14.5 x 9.0 in (36.7 x 22.9 cm)

Diagonal Size

17.0 in (43.2 cm)

Surface Treatment

BrightView

Contrast Ratio

300:1 typical

Refresh Rate

60 Hz

Brightness

200 nit typical

Pixel Resolution

Pitch

0.219 mm

Format

1680 x 1050

Configuration

RGB Stripe

Backlight

CCFL

PPI

116

Viewing Angle

±60° Horizontal, ±50° Vertical (minimum)

17.0-inch WUXGA wide-

viewing angle, anti-

glare

Active Area

(W x H)

14.5 x 9.0 in (36.7 x 22.9 cm)

Diagonal Size

17.0 in (43.2 cm)

Surface Treatment

Anti-glare

Contrast Ratio

300:1 typical

Refresh Rate

60 Hz

Brightness

200 nit typical

Pixel Resolution

Pitch

0.191 mm

Format

1920 x 1200

Configuration

RGB Stripe

Backlight

CCFL

PPI

133

Viewing Angle

±60° Horizontal, ±50° Vertical (minimum)

Hard Drives

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 19

160-GB 7200 rpm SATA

Drive Weight

0.25 lb (113 g)

Capacity

160 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous

(maximum)

100 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

1 ms

Average

10 ms

Maximum

18 ms

Rotational Speed

7200 rpm

Logical Blocks

312,581,808

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

120-GB 7200 rpm SATA

Drive Weight

0.25 lb (113 g)

Capacity

120 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous

(maximum)

100 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

1 ms

Average

10 ms

Maximum

18 ms

Rotational Speed

7200 rpm

Logical Blocks

234,441,648

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

100-GB 7200 rpm SATA

Drive Weight

0.25 lb (113 g)

Capacity

100 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous

(maximum)

100 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

1 ms

Average

10 ms

Maximum

18 ms

Rotational Speed

7200 rpm

Logical Blocks

195,371,568

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 20

80-GB 7200 rpm SATA

Drive Weight

0.25 lb (113 g)

Capacity

80 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous

(maximum)

100 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

1 ms

Average

10 ms

Maximum

18 ms

Rotational Speed

7200 rpm

Logical Blocks

156,301,488

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

160-GB 5400 rpm SATA

Drive Weight

0.22 lb (101 g)

Capacity

160 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous

(maximum)

100 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

3 ms

Average

13ms

Maximum

24 ms

Rotational Speed

5400 rpm

Logical Blocks

312,581,808

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

120-GB 5400 rpm SATA

Drive Weight

0.22 lb (101 g)

Capacity

120 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous

(maximum)

100 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

3 ms

Average

13ms

Maximum

24 ms

Rotational Speed

5400 rpm

Logical Blocks

234,441,648

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 21

80-GB 5400 rpm SATA

Drive Weight

0.22 lb (101 g)

Capacity

80 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous

(maximum)

100 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

3 ms

Average

13 ms

Maximum

24 ms

Rotational Speed

5400 rpm

Logical Blocks

156,301,488

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

Optical Drives – Fixed

DVD-ROM Drive

Access Times

Random

<116 ms CD

<125 ms DVD

Max Data Transfer Rate

24X CD-ROM

3,600 KB/s

8X-DVD

10,800 KB/s

Transfer Mode

Multiword DMA Mode 2

Interface

EIDE

Supported Media

(read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED

MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD

(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,

DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,

DVD+R, DVD+RW

Supported Media

(write)

None

Max Media Capacity

(read)

4.7 GB

Transport

Tray Loading

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 22

DVD/CD-RW Combo

Drive

Access Times

Random

<110 ms CD

<130 ms DVD

Max Data Transfer Rate

24X CD-ROM

3,600 KB/s

8X DVD

10,800 KB/s

24X CD-R

3,600 KB/s

24X CD-RW

3,600 KB/s

Transfer Mode

Multiword DMA Mode 2

Interface

EIDE

Supported Media

(read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED

MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD

(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,

DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,

DVD+R, DVD+RW

Supported Media

(write)

CD-R, CD-RW

Max Media Capacity

(read)

8.5 GB

Max Media Capacity

(write)

700 MB

Transport

Tray loading

DVD+/-RW SuperMulti

DL Drive

Access Times

Random

<175 ms CD

<230 ms DVD

Max Data Transfer Rate

24X CD-ROM

3,600 KB/s

8X DVD

10,800 KB/s

24X CD-R

3,600 KB/s

16X CD-RW

2,400 KB/s

8X DVD+R

10,800 KB/s

4X DVD+RW

5,400 KB/s

8X DVD-R

10,800 KB/s

4X DVD-RW

5,400 KB/s

2.4X DVD+R(9)

2,700 KB/s

5X DVD-RAM

6,750 KB/s

Transfer Mode

Multiword DMA Mode

Interface

EIDE

Supported Media

(read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED

MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD

(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,

DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,

DVD+R, DVD+RW, DVD-RAM

Supported Media

(write)

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM

Max Media Capacity

(read)

8.5 GB

Max Media Capacity

(write)

8.5 GB

Transport

Tray Loading

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 23

DVD+/-RW SuperMulti

DL LightScribe Drive

Access Times

Random

<175 ms CD

<230 ms DVD

Max Data Transfer Rate

24X CD-ROM

3,600 KB/s

8X DVD

10,800 KB/s

24X CD-R

3,600 KB/s

16X CD-RW

2,400 KB/s

8X DVD+R

10,800 KB/s

4X DVD+RW

5,400 KB/s

8X DVD-R

10,800 KB/s

4X DVD-RW

5,400 KB/s

2.4X DVD+R(9)

2,700 KB/s

5X DVD-RAM

6,750 KB/s

Transfer Mode

Multiword DMA Mode

Interface

EIDE

Supported Media

(read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED

MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD

(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,

DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,

DVD+R, DVD+RW, DVD-RAM

Supported Media

(write)

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM,

LightScribe

Max Media Capacity

(read)

8.5 GB

Max Media Capacity

(write)

8.5 GB

Transport

Tray Loading

Blu-Ray Disc

DVD+/-RW SuperMulti

DL Drive

Access Times

Random

<140 ms CD-ROM

<160 ms DVD-ROM

<300 ms BD-ROM

Max Data Transfer Rate

24X CD-ROM

3,600 KB/s

8X DVD-ROM

10,800 KB/s

8X CD-R

1,200 KB/s

8X CD-RW

1,200 KB/s

8X DVD+R

10,800 KB/s

4X DVD+RW

5,400 KB/s

8X DVD-R

10,800 KB/s

4X DVD-RW

5,400 KB/s

2.4X DVD+R(9)

2,700 KB/s

5X DVD-RAM

6,750 KB/s

1X BD-ROM

4,500 KB/s

1X BD-R

4,500 KB/s

1X BD-RE

4,500 KB/s

Transfer Mode

Multiword DMA Mode

Interface

EIDE

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 24

Supported Media

(read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED

MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD

(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,

DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,

DVD+R, DVD+RW. DVD-RAM, BD-ROM, BD-R, BD-RE

Supported Media

(write)

CD-R, CD-RW, DVD+R, DVD+R(9), DVD+RW, DVD-R, DVD-R(9),

DVD-RW, DVD-RAM, BD-R, BD-RE

Max Media Capacity

(read)

50.0 GB

Max Media Capacity

(write)

50.0 GB

Transport

Tray Loading

Security

HP Fingerprint Sensor

Mobile Voltage

Operation

3.0V–3.6V Single Supply

Operating Temperature

32° – 158°F (0° – 70°C)

Current Consumption

@ 3.3V

Less than 70 mA peak imaging and scrolling

Less than 25 mA hardware finger detection

Advanced Power Management

High-Rate Image

Capture

Up to 240 image frames /sec

ESD Resistance

IEC 61000-4-2 Level 4 (±15KV)

Detection Matrix

192 x 16 Pixels

9.7 mm x 0.81 mm

500 ppi High-Resolution Images

Audio

Hardware

Implementation

ADI1981HD High Definition CODEC

Touch-Sensitive

Volume Controls

Volume up, volume down, and mute

Full Duplex

Yes

Sound Blaster Pro

compatible

Yes

Microphone In

Stereo

Headphone/Line Out

Stereo

Integrated Microphone

Yes

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 25

Audio Output Quality

Frequency Response

20 Hz – 20 kHz

Signal to Noise Ratio

>85 dB

Total Harmonic

Distortion

0.01%

Noise Floor

-110 dB

Play/Record Sampling

Rate

(s)

8 kHz – 48kHz

DAC

16, 20 or 24-bit

ADC

16 or 20-bit

Integrated Stereo

Speakers

Power Rating

2 Watts

Impedance

4 Ohms

Communications

Integrated Intel Gigabit

Network Connection

(10/100/1000 NIC)

Ethernet Features

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-

14)

100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses

21-30)

1000 Mbit/s operation (1000BASE-T; IEEE 802.3z and 802.3ab; IEEE

802.3 clauses 34-42)

Auto-Negotiation (Automatic Speed Selection)

Full Duplex Operation at all Speeds, Half Duplex operation at 10 and

100 Mbit/s

IEEE 802.1p QoS (Quality of Service) Support

IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)

Power Management

ACPI compliant -- multiple power modes

Situation-sensitive features reduce power consumption

Performance Features

TCP/IP/UDP Checksum Offload (configurable)

Manageability

Wake-on-LAN from standby and hibernation (Magic Packet and

Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)

PXE 2.1 Remote Boot

Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB

(802.3x, clause 30))

Comprehensive diagnostic and configuration software suite

Intel Advanced Management Technology (iAMT)

Interface

PCI Express x1

NIC Device Driver

Name

Intel 82566MM Gigabit Network Connection

Drivers Available

Microsoft Windows Vista

Microsoft Windows XP

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 26

V.92 56K Data/Fax

Modem

Form Factor

MDC 1.5 Daughtercard

Power Management

Support

APM Revision 1.2, ACPI

Approvals/

Certifications

UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC

Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian

ACA, CE Mark, Other Countries

Data Mode Capabilities

V.92 data

V.8bis

V.80

V44, V.42bis, MNP5 (Compression)

V.42 (LAPM, MNP2-4) (Error Correction)

Optional symbol rates:

2800, 3429

Asymmetric Symbol rates

Synchronous primary channel data signaling rates:

3600, 31200

Automatic rate re-negotiation

V.34

V.32bis

V.32

V.23

V.22bis

V.22

V.21

Bell 212A

Bell 103J

Fax Mode Capabilities

TIA/EIA-578-B (Class 1)

T.30, T.4 (Group 3)

V.17

V.29

V.27ter

V.21 Channel 2

Command Set

V.250 (Partial)

TIA-602

Identification: +GMI, +GMM, +GMR

Port control: +IPR, +ICF, +IFC, +ILRR

Modulation: +MS, +MR, +MA

Error control: +ES, +ER, +EB, +ESR, +ETBM

Data compression: +DS, +DR

V.251

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 27

Intel PRO/Wireless

3945BG Network

Connection

Wireless LAN

Standards

IEEE 802.11b

IEEE 802.11g

Interoperability

Wi-Fi certified

Cisco Compatible Extensions Program compliant with Microsoft

Windows 2000 and XP (details at

http://www.hp.com/go/notebooks/WLAN

)

Frequency Band

2.4 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Modulation

Direct Sequence Spread Spectrum

DBPSK, DQPSK, CCK, OFDM

Security

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated

AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,

PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.

Support for Cisco Security Features (proven compatibility with Cisco

Aironet infrastructure products through the Cisco Compatible

Extensions Program Version 4).

Sub-channels

Multinational support with frequency bands and channels compliant to

local regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture

Models

Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for

CKK)

15 dBm

Output Power

(for

OFDM; power varies by

data rate)

15 dBm

Power Consumption

Transmit: 1.8 Watts (max)

Receive: 1.4 Watts (max)

Idle mode

: 150 mW (nominal)

Sleep mode: 30 mW (max)

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna Connections

2 U.FL type connectors, 50 ohm nominal impedance

Range

802.11 b – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

802.11 g – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

Form Factor

PCI-Express MiniCard

Weight

0.013 lb (6 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3V +/- 9%, 1.5V +/- 5%

Temperature

Operating

Non-operating

32° to 176° F (0° to 80° C)

–40° to 176° F (–40° to 80° C)

Humidity

Operating

Non-operating

10% to 90% (non-condensing)

5% to 95% (non-condensing)

Altitude

Operating

Non-operating

0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 28

Configuration Utility

Microsoft Windows 2000 or XP

Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager

Intel PROSet for Microsoft Windows 2000 or XP (required for

Cisco Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager

LED Activity

LED Off – Radio OFF; Solid LED On – Radio ON

Check latest software/driver release for updates on supported security features.

Maximum output power may vary by country according to local regulations.

In Power Save Polling mode.

Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

and a packet error rate of 10% for 802.11a/g (OFDM modulation).

WLAN supplier's client utility is required for Cisco Compatible Extensions support with

Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party

software supplicants.

Intel Wireless WiFi Link

4965AG

Wireless LAN

Standards

IEEE 802.11a

IEEE 802.11b

IEEE 802.11g

Interoperability

Wi-Fi certified

Cisco Compatible Extensions Program compliant with Microsoft

Windows 2000 and XP (details at

http://www.hp.com/go/notebooks/WLAN

)

Frequency Band

2.4 GHz and 5 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Modulation

Direct Sequence Spread Spectrum

DBPSK, DQPSK, CCK, OFDM

Security

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated

AES (support for key sizes of 128, 192, and 256 bits), 802.1x

authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-

MSCHAPv2, LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco

Aironet infrastructure products through the Cisco Compatible

Extensions Program Version 4) with Microsoft Windows 2000 and XP

only.

Sub-channels

Multinational support with frequency bands and channels compliant to

local regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture

Models

Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for

CKK)

15 dBm

Output Power

(for

OFDM; power varies by

data rate)

15 dBm

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 29

Power Consumption

Transmit: 1.6 Watts (average)

Receive: 1.1 Watts (average)

Idle mode

: 30 mW (average)

Radio off: 20 mW (max)

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

54 Mbps: -74 dBm, 6 Mbps: -90 dBm

Antenna Connections

2 U.FL type connectors, 50 ohm nominal impedance

Range

802.11 a – Typical

(@6 Mbps)

600 feet – Outdoor Open Area

150 feet – Indoor, Office environment

802.11 b – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

802.11 g – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

Form Factor

PCI-Express MiniCard

Weight

0.013 lb (6 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3V +/- 9%, 1.5V +/- 5%

Temperature

Operating

Non-operating

32° to 176° F (0° to 80° C)

–40° to 176° F (–40° to 80° C)

Humidity

Operating

Non-operating

10% to 90% (non-condensing)

5% to 90% (non-condensing)

Altitude

Operating

Non-operating

0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

Configuration Utility

Microsoft Windows 2000 or XP

Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager

Intel PROSet for Microsoft Windows 2000 or XP (required for

Cisco Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager

LED Activity

LED Off – Radio OFF; Solid LED On – Radio ON

Check latest software/driver release for updates on supported security features.

Maximum output power may vary by country according to local regulations.

In Power Save Polling mode and on battery power.

Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

and a packet error rate of 10% for 802.11a/g (OFDM modulation).

WLAN supplier's client utility is required for Cisco Compatible Extensions support with

Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party

software supplicants.

Intel Wireless WiFi Link

4965AGN

Wireless LAN

Standards

IEEE 802.11a

IEEE 802.11b

IEEE 802.11g

IEEE 802.11n (draft 1.02)

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 30

Interoperability

Wi-Fi certified (802.11abg only)

Cisco Compatible Extensions Program compliant (802.11abg only) with

Microsoft Windows 2000 and XP (details at

http://www.hp.com/go/notebooks/WLAN

)

Tested with wireless access points from several major manufacturers

(details at

http://www.hp.com/go/notebooks/WLAN/

draft-n)

Frequency Band

2.4 GHz and 5 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (draft): 66 possible data rates, ranging from 6 Mbps to 300

Mbps, depending on the combination of Bandwidth, Modulation Coding

Scheme, and Guard Interval used, as defined in IEEE 802.11n (draft)

specification

Modulation

Direct Sequence Spread Spectrum

DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Security

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated

AES (support for key sizes of 128, 192, and 256 bits), 802.1x

authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-

MSCHAPv2, LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco

Aironet infrastructure products through the Cisco Compatible

Extensions Program Version 4) with Microsoft Windows 2000 and XP

only.

Sub-channels

Multinational support with frequency bands and channels compliant to

local regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture

Models

Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for

CKK)

15 dBm

Output Power

(for

OFDM; power varies by

data rate)

15 dBm

Power Consumption

Transmit: 2.3 Watts (average, with two spatial streams)

Receive: 1.9 Watts (average with three receive chains)

Idle mode

: 30 mW (average)

Radio off: 20 mW (max)

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

300 Mbps: -68 dBm, 54 Mbps: -74 dBm, 6 Mbps: -90 dBm

Antenna Connections

3 U.FL type connectors, 50 ohm nominal impedance

Range

802.11 a – Typical

(@6 Mbps)

600 feet – Outdoor Open Area

150 feet – Indoor, Office environment

802.11 b – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

802.11 g – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

Form Factor

PCI-Express MiniCard

Weight

0.013 lb (6 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3V +/- 9%, 1.5V +/- 5%

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 31

Temperature

Operating

Non-operating

32° to 176° F (0° to 80° C)

–40° to 176° F (–40° to 80° C)

Humidity

Operating

Non-operating

10% to 90% (non-condensing)

5% to 90% (non-condensing)

Altitude

Operating

Non-operating

0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

Configuration Utility

Microsoft Windows 2000 or XP

Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager

Intel PROSet for Microsoft Windows 2000 or XP (required for

Cisco Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager

LED Activity

LED Off – Radio OFF; Solid LED On – Radio ON

Check latest software/driver release for updates on supported security features.

Maximum output power may vary by country according to local regulations.

In Power Save Polling mode and on battery power.

Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

and a packet error rate of 10% for 802.11a/g (OFDM modulation).

WLAN supplier's client utility is required for Cisco Compatible Extensions support with

Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party

software supplicants.

Broadcom 4311AG

802.11a/b/g WiFi

Adapter

Wireless LAN

Standards

IEEE 802.11a

IEEE 802.11b

IEEE 802.11g

Interoperability

Wi-Fi certified

Cisco Compatible Extensions Program compliant with Microsoft

Windows 2000 and XP (details at

http://www.hp.com/go/notebooks/WLAN

)

Frequency Band

2.4 GHz and 5 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Modulation

Direct Sequence Spread Spectrum

DBPSK, DQPSK, CCK, OFDM

Security

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated

AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,

PEAP-MSCHAPv2, LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco

Aironet infrastructure products through the Cisco Compatible

Extensions Program Version 4).

Sub-channels

Multinational support with frequency bands and channels compliant to

local regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture

Models

Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for

CKK)

17.5 dBm

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 32

Output Power

(for

OFDM; power varies by

data rate)

15 dBm

Power Consumption

Transmit: 2.0 W (max)

Receive: 1.5 W (max)

Idle mode

: 390 mW (nominal)

Sleep mode: 20 mW (max)

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna type

High efficiency dual band antenna with spatial diversity, mounted in the

display enclosure

Range

802.11 a – Typical

(@6 Mbps)

600 feet – Outdoor Open Area

150 feet – Indoor, Office environment

802.11 b – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

802.11 g – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

Form Factor

PCI-Express MiniCard

Weight

0.026 lb (12 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating

Non-operating

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating

Non-operating

10% to 90% (non-condensing)

5% to 95% (non-condensing)

Altitude

Operating

Non-operating

0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

Configuration Utility

Microsoft Windows 2000 or XP

Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager

Broadcom Wireless Configuration Utility (required for Cisco

Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager

LED Activity

LED Off – Radio OFF; Solid LED On – Radio ON

Check latest software/driver release for updates on supported security features.

Maximum output power may vary by country according to local regulations.

In Power Save Polling mode.

Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

and a packet error rate of 10% for 802.11a/g (OFDM modulation).

WLAN supplier's client utility is required for Cisco Compatible Extensions support with

Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party

software supplicants.

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 33

Broadcom 4311BG

802.11b/g WiFi Adapter

Wireless LAN

Standards

IEEE 802.11b

IEEE 802.11g

Interoperability

Wi-Fi certified

Cisco Compatible Extensions Program compliant with Microsoft

Windows 2000 and XP (details at

http://www.hp.com/go/notebooks/WLAN

)

Frequency Band

2.4 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Modulation

Direct Sequence Spread Spectrum

DBPSK, DQPSK, CCK, OFDM

Security

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated

AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,

PEAP-MSCHAPv2, LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco

Aironet infrastructure products through the Cisco Compatible

Extensions Program Version 4).

Sub-channels

Multinational support with frequency bands and channels compliant to

local regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture

Models

Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for

CKK)

17.5 dBm

Output Power

(for

OFDM; power varies by

data rate)

15 dBm

Power Consumption

Transmit: 2.0 W (max)

Receive: 1.5 W (max)

Idle mode

: 390 mW (nominal)

Sleep mode: 20 mW (max)

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna type

High efficiency dual band antenna with spatial diversity, mounted in the

display enclosure

Range

802.11 b – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

802.11 g – Typical

(@1 Mbps)

1200 feet – Outdoor Open Area

300 feet – Indoor, Office environment

Form Factor

PCI-Express MiniCard

Weight

0.026 lb (12 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating

Non-operating

32° to 176° F (0° to 80° C)

–40° to 176° F (–40° to 80° C)

Humidity

Operating

Non-operating

10% to 90% (non-condensing)

5% to 95% (non-condensing)

Altitude

Operating

Non-operating

0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 34

Configuration Utility

Microsoft Windows 2000 or XP

Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager

Broadcom Wireless Configuration Utility (required for Cisco

Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager

LED Activity

LED Off – Radio OFF; Solid LED On – Radio ON

Check latest software/driver release for updates on supported security features.

Maximum output power may vary by country according to local regulations.

In Power Save Polling mode.

Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

and a packet error rate of 10% for 802.11a/g (OFDM modulation).

WLAN supplier's client utility is required for Cisco Compatible Extensions support with

Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party

software supplicants.

HP Integrated Module

with Bluetooth

Wireless Technology

Bluetooth Specification

2.0 Compliant

Dimensions

1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)

Frequency Band

2402 to 2480 MHz

Number of Available

Channels

79 (1 MHz) available channels

Data Rates and

Throughput

3 Mbps data rate; throughput up to 2.17 Mbps

Synchronous Connection Oriented links up to 3, 64 kbps, voice

channels

Asynchronous Connection Less links 2178.1 kbps/177.1 kbps

asymmetric or 1306.9 kbps symmetric

Transmit Power

-6 dBm to 4 dBm (Bluetooth Class II)

Receiver Sensitivity

Better than -80 dBM at 0.1 % raw bit error rate

Power Consumption

Peak (Tx) 264 mW

Peak (Rx) 231 mW

Sleep <1 mW

Antenna

Internally integrated within module

Range

Up 33 ft (10 m)

Electrical Interface

USB 2.0 compliant

Microsoft Windows Plug and Play compliant

OS Support

Genuine Windows Vista

Genuine Windows XP

Genuine Windows 2000

Bluetooth Software

Supported

Broadcom Bluetooth for Windows

Microsoft Windows XP Bluetooth Software

Link Topology

Point to Point, Multipoint Pico Nets up to 7 slaves

Security

Full support of Bluetooth Security Provisions

Power Management

Microsoft Windows ACPI, and USB Bus Support

Self configurable to optimize power conservation in all operating modes,

including Standby, Hold, Park, and Sniff

Certifications

All necessary regulatory approvals for supported countries, including:

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 35

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

UL, CSA, and CE Mark

Temperature

Operating

-4° to 158° F (-20° to 70° C)

Non-operating

-40° to 176° F (-40° to 80° C)

Humidity

Operating

10% to 90%

Non-operating

5% to 95%

Altitude

Operating

15,000 ft (4,572 m)

Non-operating

40,000 ft (12,192 m)

Bluetooth Profiles

Supported

(with Bluetooth for Windows 4.0 software)

Serial Port Profile (SPP)*

Dial-Up Networking (DUN)*

Generic Object Exchange Profile (GOEP)

Object Push Profile (OPP)*

File Transfer Profile (FTP)

Synchronization Profile (SYNC)

Hard Copy Cable Replacement (HCRP)*

Personal Area Networking Profile (PAN)*

Human Interface Device Profile (HID)*

FAX Profile (FAX)

Basic Imaging Profile (BIP)

Headset Profile (HSP)

Hands Free Profile (HFP)

Advanced Audio Distribution Profile (A2DP)

indicates the profile is also supported by Microsoft Windows XP SP2

Environmental Data

Eco-Label

Certifications

This product has received or is in the process of being certified to the

following approvals and may be labeled with one or more of these

marks:

US Federal Energy Management Program (FEMP)

ECO declaration

Korean Eco Label

EPEAT Silver Rating

System Configuration

The configuration used for the Energy Consumption and Declared Noise

Emissions data is based on a “Typically Configured Notebook”

Energy Consumption

115 VAC 230 VAC 100 VAC

Normal Operation

18.05 W 19.49 W 12.19 W

Sleep (Energy Star low

power mode)

1.261 W 1.281 W 1.261 W

Off

1.563 W

1.57 W

1.563 W

Heat Dissipation*

115 VAC 230 VAC 100 VAC

Normal Operation

61.586 BTU/hr 66.499 BTU/hr 41.592 BTU/hr

Sleep

4.302 BTU/hr

4.37 BTU/hr

4.302 BTU/hr

Off

5.332 BTU/hr 5.356 BTU/hr 5.332 BTU/hr

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 36

* Heat dissipation is calculated based on the measured watts, assuming

the service level is attained for one hour.

This product is in compliance with US executive order 13221, WOL

(wake on LAN) disabled.

Declared Noise

Emissions

(in accordance with ISO

7779 and ISO 9296)

Sound Power

(LWAd, bels)

Sound Pressure

(LpAm, decibels)

Idle

3.1

Operating mode (HDD)

3.1

Batteries

This product complies with ISO standards:

EU Directive 91/ 157/ EEC

EU Directive 93/ 86/ EEC

EU Directive 98/ 101/ EEC

Batteries used in the product do not contain:

Mercury greater the 5ppm by weight

Cadmium greater than 10ppm by weight

Lead greater than 4000 ppm by weight.

The battery type and chemistry used in the product is:

CR2032 (coin cell), Lithium

8 cell rechargeable Lithium-Ion battery

Additional

information:

This product is in compliance with the EU Restrictions of Hazardous

Substances (RoHS) Directive – 2002/95/EC.

This HP product is designed to comply with the Waste Electrical and

Electronic Equipment (WEEE) Directive – 2002/96/EC.

Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and

ISO/IEC 15412

Input devices of this product comply with ISO 9241, part 9.

Plastics parts weighing over 25 grams used in the product are marked

per ISO 11469 and ISO1043.

This product contains 0% recycled materials (by wt.)

This product is greater than 92% recyclable when properly disposed of

at end of life.

Packaging Materials

External:

Corrugated / Paper – 2.25 lb (1019 g)

Internal:

EPE Foam – 0.15 lb (70 g)

LDPE Bag – 0.04 lb (19.44 g)

The corrugated paper packaging materials contains at least 40%

recycled content.

HP follows these guidelines to decrease the environmental impact of

product packaging:

Eliminate the use of heavy metals such as lead, chromium,

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 37

mercury and cadmium in packaging materials.

Eliminate the use of ozone-depleting substances (ODS) in

packaging materials.

Design packaging materials for ease of disassembly.

Maximize the use of post-consumer recycled content materials in

packaging materials.

Use readily recyclable packaging materials such as paper and

corrugated materials.

Reduce size and weight of packages to improve transportation

fuel efficiency.

Plastic packaging materials are marked according to ISO 11469

and DIN 6120 standards.

Material Usage

This product does not contain any of the following substances in excess

of regulatory limits (for reference of these limits please refer to the HP

General Specification of the Environment

(

http://www.hp.com/hpinfo/globalcitizenship/

environment/supplychain/gen_specifications.html

Asbestos

Certain Azo Colorants

Certain Brominated Flame Retardants – may not be used as

flame retardants in plastics

Cadmium

Chlorinated Hydrocarbons

Chlorinated Paraffins

Formaldehyde

Halogenated Diphenyl Methanes

Lead carbonates and sulfates

Lead and Lead compounds

Mercuric Oxide Batteries

Nickel – finishes must not be used on the external surface

designed to be frequently handled or carried by the user.

Ozone Depleting Substances

Polybrominated Biphenyls (PBBs)

Polybrominated Biphenyl Ethers (PBBEs)

Polybrominated Biphenyl Oxides (PBBOs)

Polychlorinated Biphenyl (PCB)

Polychlorinated Terphenyls (PCT)

Polyvinyl Chloride (PVC) – except for wires and cables, and

certain retail packaging has been voluntarily removed from most

applications.

Radioactive Substances

Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

End-of-life

Management and

Recycling

HP offers our customers several other options for handling their aging

computers while also minimizing the impact on the

environment—including product trade-in and leasing services-in

addition to recycling services.

Please go to:

http://www.hp.com/recycle

or contact your nearest HP sales office. Products returned to HP will be

recycled, recovered or disposed of in a responsible manner.

Hewlett-Packard

Corporate

Environmental

Information

For more information about HP's commitment to the environment:

Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Environment website

http://www.hp.com/environment

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 38

environment/productdesign/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/

environment/operations/envmanagement.html

Microsoft Corporation in the U.S. and/or other countries. Core 2 Duo and Celeron are registered trademarks or trademarks of

Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S.

and other countries. All other product names mentioned herein may be trademarks of their respective companies.

The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The

warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing

herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or

omissions contained herein.

QuickSpecs

HP Compaq 8710w Mobile Workstation

Technical Specifications

DA - 12731 Worldwide QuickSpecs — Version 8 — 9.5.2007

Page 39

Hp 8710W Users Manual Compaq Mobile Workstation

8710w to the manual 4a49b568-4750-45e8-adc1-e496ef9c8b22

Navigation menu

Versions of this User Manual:

Views

Navigation
