HP recommends Windows Vista
HP recommends Windows VistaHP recommends Windows Vista
HP recommends Windows Vista
®
®®
®
Business
BusinessBusiness
Business
1.
Volume mute button with LED indicator
13.
Touchpad buttons
2.
Volume scroll zone with up/down LED indicators
14.
Hard drive activity / HP 3D DriveGuard LED
3.
Integrated microphone
15.
Battery charging LED
4.
RJ-11/modem port
16.
Power/standby LED
5.
RJ-45/Ethernet port
17.
Wireless on/off LED
6.
USB 2.0 port
18.
Power button with LED
7.
Optical drive
19.
HP Info / HP QuickLook button with LED indicator
8.
Integrated Smart Card Reader
20.
Wireless on/off button with LED indicator
9.
HP Fingerprint Sensor
21.
HP Presentation button with LED indicator
10.
Pointstick
22.
Ambient Light Sensor
11.
Pointstick buttons
23.
Two WWAN antennas
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Overview
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 1
12.
Touchpad with scroll zone
24.
Three WLAN antennas
1.
2 USB 2.0 ports
9.
Power connector
2.
1394a port
10.
Kensington Lock slot
3.
Stereo microphone in
11.
Integrated stereo speakers
4.
Stereo headphone/line out
12.
Secure Digital (SD) slot
5.
Type I/II PC Card slot
13.
Fast Infrared port
6.
PC Card eject button
14.
Hard drive activity / HP 3D DriveGuard LED
7.
VGA/external monitor connector
15.
Battery charging LED
8.
S-Video TV out
16.
Power/standby LED
17.
Wireless on/off LED
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Overview
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 2
At A Glance
At A GlanceAt A Glance
At A Glance
Genuine Windows Vista Business*, Genuine Windows Vista Home Basic,
Genuine Windows XP Professional, or FreeDOS
ATI Mobility Radeon X2300 graphics with up to 128 MB dedicated memory (256 MB HyperMemory)
or Mobile Intel GMA X3100 graphics with up to 384 MB shared system memory
Flexible wireless connectivity options:
Integrated HP ev2210 1xEVDO-A or HP hs2300 HSDPA Broadband Wireless module (select countries only)
Integrated 802.11 a/b/g/draft-n, a/b/g, or b/g wireless LAN module
Bluetooth®
Intel® Centrino® Pro processor technology capable, with Intel Core™2 Duo processors
Designed for common image for corporate environments
Widescreen 14.1-inch diagonal display with Ambient Light Sensor and optional HP Privacy Filter
Thin, lightweight design starting at 4.5 lb/2.0 kg and 1.1-inch/29 mm thin at front
Enhanced security features including integrated Smart Card Reader, Drive Encryption for HP ProtectTools, HP Fingerprint
Sensor, TPM 1.2**
HP QuickLook on Windows Vista models for instant access to email, calendar, and contact information
Up to 160-GB 7200 rpm user-removable hard drive with HP 3D DriveGuard protection or 64-GB Solid State Drive
Enhanced reliability with HP DuraKeys and HP DuraFinish
Touch-sensitive controls for HP Info Center, HP QuickLook, wireless on/off, HP Presentation button, external volume up,
volume down, and mute
MultiBay II drive bay for swapping to a different optical drive, an optional secondary hard drive, or weight-saver
Up to 4 GB of 667-MHz DDR2 SDRAM, dual channel memory support
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
Enhanced dual pointing devices (touchpad with scroll zone and pointstick)
Type I/II PC Card slot, Secure Digital (SD) slot
* At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version will be deleted.
* TPM module disabled where not permitted by law (for example, Russia and China).
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Overview
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 3
Processors
ProcessorsProcessors
Processors
Intel Core 2 Duo Processor T7800 (2.60-GHz, 800-MHz FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7700 (2.40-GHz, 800-MHz FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7500 (2.20-GHz, 800-MHz FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7300 (2.00-GHz, 800-MHz FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7250 (2.00-GHz, 800-MHz FSB, 2-MB L2 cache)*
Intel Core 2 Duo Processor T7100 (1.80-GHz, 800-MHz FSB, 2-MB L2 cache)*
* Intel's numbering is not a measurement of higher performance.
NOTE:
NOTE: NOTE:
NOTE:
Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System
Operating SystemOperating System
Operating System
Preinstalled
PreinstalledPreinstalled
Preinstalled
Genuine Windows Vista Business
†
*
Genuine Windows Vista Home Basic*
Genuine Windows XP Professional
FreeDOS
Supported
SupportedSupported
Supported
Genuine Windows Vista Enterprise*
Genuine Windows 2000
Certified
CertifiedCertified
Certified
SuSE Linux Enterprise Desktop 10
†
At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version
will be deleted.
*
Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
and
http://www.microsoft.com/windowsvista/getready/capable.mspx
for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To
download the tool, visit
http://www.windowsvista.com/upgradeadvisor
.
Chipset
ChipsetChipset
Chipset
Mobile Intel PM965 with 800-MHz front side bus (models with discrete graphics)
or
Mobile Intel GM965 with 800-MHz front side bus (models with integrated graphics)
Intel Centrino Pro
Intel Centrino ProIntel Centrino Pro
Intel Centrino Pro
processor technology
processor technologyprocessor technology
processor technology
capable
capablecapable
capable
Intel Centrino Pro processor technology is a selectable feature that is available on units configured with
an Intel Wireless WiFi Link 4965AGN or 4965AG. It provides advances in remote manageability,
security, energy efficient performance, and wireless connectivity. Intel Active Management Technology
(AMT) offers built-in manageability and proactive security for networked notebook PCs, even when they
are powered off* or when the operating system is inoperable. It can help identify threats before they
reach the operating system, isolate infected systems, and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power
source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.
NOTE:
NOTE: NOTE:
NOTE:
Some functionality of Intel Centrino Pro, such as Intel AMT and Intel Virtualization technology,
requires additional 3rd party software in order to run. Availability of future "virtual appliances"
applications for Centrino Pro processor technology is dependant on 3rd party software providers.
Compatibility of this generation of Centrino Pro technology-based hardware with future "virtual
appliances" and Microsoft Windows Vista operating system is to be determined.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 4
Graphics
GraphicsGraphics
Graphics
Models with discrete graphics:
ATI Mobility Radeon X2300 graphics with 64 or 128 MB dedicated video memory
(256 MB HyperMemory*)
Models with integrated graphics:
Mobile Intel GMA X3100 graphics with up to 384 MB shared system memory
Microsoft DirectX9 capable
*Indicates dedicated video memory and shared system memory. Either 64MB or 128MB dedicated video
memory, depending on model.
Display
DisplayDisplay
Display
Internal
InternalInternal
Internal
14.1-inch diagonal WXGA anti-glare (1280 x 800 resolution)
14.1-inch diagonal WXGA+ anti-glare (1440 x 900 resolution)
Ambient Light Sensor
Optional HP Privacy Filter
External
ExternalExternal
External
Up to 32-bit per pixel color depth
VGA
VGAVGA
VGA
port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
DVI
DVIDVI
DVI
port in optional HP Docking Station (sold separately)
supports resolutions up to 1600 x 1200 at both full and reduced
blanking, and 1920 x 1200 at reduced blanking
NOTE:
NOTE: NOTE:
NOTE:
Resolutions are dependent upon monitor capability, and resolution
and color depth settings.
Memory
MemoryMemory
Memory
Standard
StandardStandard
Standard
512-MB, 1024-MB, 2048-MB, or 4096-MB 667-MHz DDR2 SDRAM; two
SODIMM slots supporting dual channel memory
Maximum
MaximumMaximum
Maximum
Upgradeable to 4096-MB with 2048-MB SODIMMs in slots 1 and 2
Dual-channel
Dual-channelDual-channel
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same size
and speed in both memory slots.
NOTE:
NOTE: NOTE:
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we recommend
HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the
lower memory speed. Availability of 4 GB of memory requires Windows Vista Business 64-bit or Linux.
With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system
resource requirements.
Communications
CommunicationsCommunications
Communications
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)*
56K V.92 modem**
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability
is subject to country regulatory approval.
Wireless Devices
Wireless DevicesWireless Devices
Wireless Devices
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring
support for the latest industry standards. Wireless LAN is factory configurable or available as an option
to be added later. Broadband Wireless (WWAN) requires Windows Vista Business or Windows XP
Professional and is available in select countries as a standard, factory configurable feature or as an
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 5
option to be added later. Integrated Bluetooth is also available (factory configurable only) and can be
combined with any of the supported wireless LAN and wireless WAN options.
HP ev2210
HP ev2210HP ev2210
HP ev2210
1xEVDO-A Broadband
1xEVDO-A Broadband1xEVDO-A Broadband
1xEVDO-A Broadband
Wireless Module
Wireless ModuleWireless Module
Wireless Module
Integrated WWAN module connects to the Verizon Wireless
BroadbandAccess and NationalAccess networks (US only)
Supports CDMA 1xEVDO-A, 1xRTT connections at 800 and 1900 MHz.
NOTE:
NOTE: NOTE:
NOTE:
Separately purchased Verizon Wireless service is required. For
details, go to
http://www.hp.com/go/broadbandwireless
.
Upgradeable design and two 850/900/1800/1900/2100-MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies
HP hs2300 HSDPA
HP hs2300 HSDPAHP hs2300 HSDPA
HP hs2300 HSDPA
Broadband Wireless
Broadband WirelessBroadband Wireless
Broadband Wireless
Module
ModuleModule
Module
Integrated WWAN module that provides connection to GSM, GPRS, EDGE,
UMTS, and HSDPA mobile networks in many countries. Currently supported
networks are the AT&T Broadbandconnect network in the U.S., Vodafone
networks in select countries, and roaming on AT&T and Vodafone partner
networks in more than 100 countries.
NOTE:
NOTE: NOTE:
NOTE:
Separately purchased mobile network operator service is required.
Upgradeable design and two 850/900/1800/1900/2100-MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies.
All 802.11a/b/g
All 802.11a/b/gAll 802.11a/b/g
All 802.11a/b/g
integrated wireless LAN
integrated wireless LANintegrated wireless LAN
integrated wireless LAN
options
optionsoptions
options
Wi-Fi certified
Cisco Compatible Extensions support (Version 4.0) with Microsoft Windows
XP
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi certified for WPA2, WMM
Three antennas integrated in the display enclosure
Intel Wireless WiFi Link
Intel Wireless WiFi LinkIntel Wireless WiFi Link
Intel Wireless WiFi Link
4965AGN
4965AGN4965AGN
4965AGN
Integrated support for 802.11a, b, g, and draft-n
Up to 300-mbps data rate
Intel Wireless WiFi Link
Intel Wireless WiFi LinkIntel Wireless WiFi Link
Intel Wireless WiFi Link
4965AG
4965AG4965AG
4965AG
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Intel PRO/Wireless
Intel PRO/WirelessIntel PRO/Wireless
Intel PRO/Wireless
3945BG Network
3945BG Network3945BG Network
3945BG Network
Connection
ConnectionConnection
Connection
Integrated support for 802.11 b and g
Up to 54-mbps data rate
Broadcom 4321AGN
Broadcom 4321AGNBroadcom 4321AGN
Broadcom 4321AGN
802.11a/b/g/draft-n Wi-
802.11a/b/g/draft-n Wi-802.11a/b/g/draft-n Wi-
802.11a/b/g/draft-n Wi-
Fi Adapter
Fi AdapterFi Adapter
Fi Adapter
Integrated support for 802.11a, b, g, and draft-n
Up to 300-mbps data rate
Broadcom 4311AG
Broadcom 4311AGBroadcom 4311AG
Broadcom 4311AG
802.11a/b/g
802.11a/b/g802.11a/b/g
802.11a/b/g
WiFi Adapter
WiFi AdapterWiFi Adapter
WiFi Adapter
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Broadcom 4311BG
Broadcom 4311BGBroadcom 4311BG
Broadcom 4311BG
802.11b/g
802.11b/g802.11b/g
802.11b/g
WiFi Adapter
WiFi AdapterWiFi Adapter
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54-mbps data rate
HP Integrated Module
HP Integrated ModuleHP Integrated Module
HP Integrated Module
with Bluetooth Wireless
with Bluetooth Wirelesswith Bluetooth Wireless
with Bluetooth Wireless
Technology
TechnologyTechnology
Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 6
Keyboard
KeyboardKeyboard
Keyboard
The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other
features include an integrated numeric keypad, hotkeys for instant access to power conservation,
brightness, and other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke,
and comfort-dished keycaps.
HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish and the
printed characters on the keys. HP DuraFinish helps protect the finish on the keyboard deck, graphics,
and icons from normal wear and tear.
Touch-sensitive controls
Touch-sensitive controlsTouch-sensitive controls
Touch-sensitive controls
Touch-sensitive controls provide easy access to the following features: HP Info Center, HP QuickLook,
wireless on/off, HP Presentation button, external volume up, volume down, and mute
Pointing device
Pointing devicePointing device
Pointing device
Enhanced dual pointing devices:
Touchpad with scroll zone, two pick buttons
and
Pointstick, two pick buttons
Expansion card slots
Expansion card slotsExpansion card slots
Expansion card slots
1 Type I/II PC Card slot
1 Type I/II PC Card slot1 Type I/II PC Card slot
1 Type I/II PC Card slot
Supports 32-bit CardBus and 16-bit PC Cards
Integrated Smart Card
Integrated Smart CardIntegrated Smart Card
Integrated Smart Card
Reader
ReaderReader
Reader
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Secure Digital slot
Secure Digital slotSecure Digital slot
Secure Digital slot
Supports SD (Secure Digital), MMC (MultiMedia Card)
Storage
StorageStorage
Storage
Primary Storage Device
Primary Storage DevicePrimary Storage Device
Primary Storage Device
80/120/160-GB 5400 rpm SMART SATA Hard Drive
80/120/160-GB 7200 rpm SMART SATA Hard Drive
64-GB Solid State Drive
NOTE:
NOTE: NOTE:
NOTE:
Hard drives are customer removable and will withstand multiple insertion/removal cycles. Up to
10 GB is reserved for the system recovery software.
HP 3D DriveGuard
HP 3D DriveGuardHP 3D DriveGuard
HP 3D DriveGuard
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock away from the hard drive. Uses three-axis digital
motion detection with intelligent sensitivity to help protect the hard drive
during normal use from shock and vibration. The digital accelerometer
temporarily halts all data transfer and parks the hard drive when abrupt
motion is detected.
Optical drives
Optical drivesOptical drives
Optical drives
MultiBay II (9.5-mm)
MultiBay II DVD-ROM Drive
MultiBay II DVD/CD-RW Combo Drive
MultiBay II DVD+/-RW SuperMulti DL Drive
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 7
Interfaces
InterfacesInterfaces
Interfaces
PC Card slot
PC Card slotPC Card slot
PC Card slot
One Type I/II PC Card slot
Smart Card Reader
Smart Card ReaderSmart Card Reader
Smart Card Reader
One
External monitor
External monitorExternal monitor
External monitor
One – VGA
1394a
1394a1394a
1394a
One
Stereo microphone in
Stereo microphone inStereo microphone in
Stereo microphone in
One
Stereo headphone/line
Stereo headphone/lineStereo headphone/line
Stereo headphone/line
out
outout
out
One
Power connector
Power connectorPower connector
Power connector
One
RJ-11/modem
RJ-11/modemRJ-11/modem
RJ-11/modem
One
RJ-45/Ethernet
RJ-45/EthernetRJ-45/Ethernet
RJ-45/Ethernet
One
Fast Infrared Port
Fast Infrared PortFast Infrared Port
Fast Infrared Port
One (4-Mb/s support)
IrDA 4-MB compliant; IR performance will vary depending on performance
of IR peripherals and application used.
S-video TV out
S-video TV outS-video TV out
S-video TV out
One (Support for NTSC/PAL)
USB 2.0
USB 2.0USB 2.0
USB 2.0
Three
Docking connector
Docking connectorDocking connector
Docking connector
One
Secondary battery
Secondary batterySecondary battery
Secondary battery
connector
connectorconnector
connector
One
LED status indicators
LED status indicatorsLED status indicators
LED status indicators
Fifteen
Audio
AudioAudio
Audio
High Definition Audio support w/24-bit DAC
Integrated stereo speakers
Integrated microphone
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone in
Software
SoftwareSoftware
Software
Preinstalled software with
Preinstalled software withPreinstalled software with
Preinstalled software with
Windows Vista or
Windows Vista orWindows Vista or
Windows Vista or
Windows XP
Windows XPWindows XP
Windows XP
PDF Complete
HP Backup and Recovery Manager
HP Help and Support Center
HP QuickLook (Windows Vista only)
HP OpenView Radia Management Agent
HP Universal Print Driver
HP ProtectTools Security Manager:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
Embedded Security for HP ProtectTools
HP Quick Launch Buttons
HP Wireless Assistant
Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition
(select models)
Roxio Creator 9 (for optional DVD+/-RW and DVD/CDRW drives)
Synaptics Touchpad Driver
Symantec Norton Internet Security with complimentary 60-day live update
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 8
Intervideo WinDVD – DVD Player
Additional software
Additional softwareAdditional software
Additional software
available from the web
available from the webavailable from the web
available from the web
HP Client Manager
Java Card Security for HP ProtectTools
HP Backup and Recovery
HP Backup and RecoveryHP Backup and Recovery
HP Backup and Recovery
Manager
ManagerManager
Manager
Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can
provide data and system file protection for HP business PCs to enable fast recovery if the system
becomes corrupted or if important information is accidentally deleted. HP Backup and Recovery
Manager can perform scheduled or manual backups of the entire drive or individual files and folders.
Up to 10 GB of the hard drive is reserved for the system recovery software. HP Backup and Recovery
Manager can also create software recovery CDs or DVDs (requires optional hardware).
SMBIOS Version 2.4
SMBIOS Version 2.4SMBIOS Version 2.4
SMBIOS Version 2.4
System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
HP ProtectTools Security
HP ProtectTools SecurityHP ProtectTools Security
HP ProtectTools Security
Manager
ManagerManager
Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. Modules currently available are:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
Embedded Security for HP ProtectTools
Java Card Security for HP ProtectTools
Security
SecuritySecurity
Security
Standard Features
Standard FeaturesStandard Features
Standard Features
HP ProtectTools Security Manager
HP Fingerprint Sensor
Integrated Smart Card Reader
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
TPM 1.2 Embedded Security Chip*
TPM Enhanced DriveLock*
HP Disk Sanitizer
HP 3D DriveGuard
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased
separately)
Optional Features
Optional FeaturesOptional Features
Optional Features
HP Privacy Filter
HP Privacy FilterHP Privacy Filter
HP Privacy Filter
Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor
*
NOTE:
NOTE: NOTE:
NOTE:
TPM module disabled where use is restricted by law; for example, Russia and China.
For more information on HP security solutions refer to
http://www.hp.com/go/security
.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 9
Power Supply
Power SupplyPower Supply
Power Supply
External 90-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.
Total length including external AC adapter is 12 feet (3.66 meter).
HP Fast Charge*
*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast Charge does not apply to 12-
cell Ultra-Capacity batteries.
Battery
BatteryBattery
Battery
Primary battery
Primary batteryPrimary battery
Primary battery
6-cell (55 WHr) Lithium-Ion battery
4-cell (37 WHr) Lithium-Ion battery (available only on integrated graphics
models)
Optional HP Extended
Optional HP ExtendedOptional HP Extended
Optional HP Extended
Life Battery
Life BatteryLife Battery
Life Battery
8-cell (52 WHr) high capacity Lithium-Ion battery
Optional HP Ultra-
Optional HP Ultra-Optional HP Ultra-
Optional HP Ultra-
Capacity Battery
Capacity BatteryCapacity Battery
Capacity Battery
12-cell (95 WHr) high capacity Lithium-Ion battery
Battery Life
Battery LifeBattery Life
Battery Life
6-cell Primary with integrated
6-cell Primary with integrated6-cell Primary with integrated
6-cell Primary with integrated
graphics
graphicsgraphics
graphics
6-cell Primary with discrete graphics
6-cell Primary with discrete graphics6-cell Primary with discrete graphics
6-cell Primary with discrete graphics
Primary battery
Primary batteryPrimary battery
Primary battery
Up to 6 hours
Up to 4 hours and 30 minutes
Primary battery and
Primary battery andPrimary battery and
Primary battery and
optional HP Extended Life
optional HP Extended Lifeoptional HP Extended Life
optional HP Extended Life
Battery
BatteryBattery
Battery
Up to 12 hours
Up to 9 hours
Primary battery and
Primary battery andPrimary battery and
Primary battery and
optional HP Ultra-
optional HP Ultra-optional HP Ultra-
optional HP Ultra-
Capacity Battery
Capacity BatteryCapacity Battery
Capacity Battery
Up to 15 hours and 45 minutes
Up to 12 hours
NOTE:
NOTE:NOTE:
NOTE:
The listed battery life measurements were taken on models running Microsoft Windows XP
Professional. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
System Standby Time
System Standby TimeSystem Standby Time
System Standby Time
Up to 1 week
Power Conservation
Power ConservationPower Conservation
Power Conservation
Supports enhanced Intel SpeedStep technology with Intel Core 2 Duo (allows Battery Optimized Mode,
Maximum Performance Mode, or Automatic mode)
Intel Display Power Saving technology (models with integrated graphics)
ATI PowerPlay technology (models with discrete graphics)
Hibernation
Standby
ACPI compliance
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 10
Docking and Stands
Docking and StandsDocking and Stands
Docking and Stands
HP 3-in-1 NAS Docking Station
HP Advanced Docking Station
HP Docking Station
HP Standard Monitor Stand
HP Adjustable Notebook Stand
HP External MultiBay II
HP's shared docking solutions provide simple and convenient port replication and cable management.
Features include Gigabit NIC pass through, modem pass through, legacy parallel and serial ports, S-
video TV out, USB 2.0 ports, integrated security mechanism*, integrated MultiBay II and ExpressCard**
slots. These docking solutions are compatible across multiple Business Notebook platforms enabling a
lower total cost of ownership.
* HP/Kensington Cable Lock required (purchased separately)
** HP 3-in-1 NAS Docking Station and HP Advanced Docking Station only
Service and Support
Service and SupportService and Support
Service and Support
HP Services offers limited 3- year, 1-year and 90-day warranty options depending on country;
1-year limited warranty on primary battery. On-site service and warranty upgrades are also available.
For HP Care Pack services see
http://www.hp.com/go/lookuptool
.
NOTE:
NOTE:NOTE:
NOTE:
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
.
Select Model(s)
Select Model(s)Select Model(s)
Select Model(s)
6910p
6910p6910p
6910p
GH715AW#ABA
Global
(may vary based on local
regulatory requirements)
Processor
ProcessorProcessor
Processor
Intel Core 2 Duo Processor T7300* (2.00-GHz, 800-FSB, 4-MB L2 cache)
Intel Centrino Pro
Intel Centrino ProIntel Centrino Pro
Intel Centrino Pro
processor technology
processor technologyprocessor technology
processor technology
Enabled
Operating System
Operating SystemOperating System
Operating System
Genuine Windows Vista Business**
System Memory
System MemorySystem Memory
System Memory
1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive
Hard DriveHard Drive
Hard Drive
80-GB 5400 rpm SMART SATA
Display
DisplayDisplay
Display
14.1-inch WXGA
Graphics
GraphicsGraphics
Graphics
Mobile Intel GMA X3100
Audio
AudioAudio
Audio
ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications
CommunicationsCommunications
Communications
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
56K V.92 modem
Integrated Wireless
Integrated WirelessIntegrated Wireless
Integrated Wireless
Intel Wireless WiFi Link 4965AG
Integrated Security
Integrated SecurityIntegrated Security
Integrated Security
Integrated Smart Card Reader
Drive Encryption for HP ProtectTools
HP Fingerprint Sensor
TPM 1.2***
Pointing Device
Pointing DevicePointing Device
Pointing Device
Enhanced dual pointing devices (touchpad with scroll zone and pointstick)
MultiBay II Drive
MultiBay II DriveMultiBay II Drive
MultiBay II Drive
DVD/CD-RW Combo MultiBay II Drive
Battery
BatteryBattery
Battery
6-cell (55 WHr) Lithium-Ion
Power
PowerPower
Power
External 90W adapter
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 11
Warranty
WarrantyWarranty
Warranty
3/3/0
* Intel's numbering system is not a measurement of higher performance.
** At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version
will be deleted.
*** TPM module disabled where use is restricted by law; for example, Russia and China.
6910p
6910p6910p
6910p
GH717AW#ABA
Global
(may vary based on local
regulatory requirements)
Processor
ProcessorProcessor
Processor
Intel Core 2 Duo Processor T7300* (2.00-GHz, 800-FSB, 4-MB L2 cache)
Intel Centrino Pro
Intel Centrino ProIntel Centrino Pro
Intel Centrino Pro
processor technology
processor technologyprocessor technology
processor technology
Enabled
Operating System
Operating SystemOperating System
Operating System
Genuine Windows Vista Business**
System Memory
System MemorySystem Memory
System Memory
1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive
Hard DriveHard Drive
Hard Drive
80-GB 5400 rpm SMART SATA
Display
DisplayDisplay
Display
14.1-inch WXGA
Graphics
GraphicsGraphics
Graphics
ATI Mobility Radeon X2300 with 64 MB of dedicated memory
Audio
AudioAudio
Audio
ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications
CommunicationsCommunications
Communications
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
56K V.92 modem
Integrated Wireless
Integrated WirelessIntegrated Wireless
Integrated Wireless
Intel Wireless WiFi Link 4965AG
Integrated Security
Integrated SecurityIntegrated Security
Integrated Security
Integrated Smart Card Reader
Drive Encryption for HP ProtectTools
HP Fingerprint Sensor
TPM 1.2***
Pointing Device
Pointing DevicePointing Device
Pointing Device
Enhanced dual pointing devices (touchpad with scroll zone and pointstick)
MultiBay II Drive
MultiBay II DriveMultiBay II Drive
MultiBay II Drive
DVD+/-RW SuperMulti DL Drive
Battery
BatteryBattery
Battery
6-cell (55 WHr) Lithium-Ion
Power
PowerPower
Power
External 90W adapter
Warranty
WarrantyWarranty
Warranty
3/3/0
* Intel's numbering system is not a measurement of higher performance.
** At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version
will be deleted.
*** TPM module disabled where use is restricted by law; for example, Russia and China.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 12
6910p
6910p6910p
6910p
SKU Part#
GH719AW#ABA
Global
(may vary based on local
regulatory requirements)
Processor
ProcessorProcessor
Processor
Intel Core 2 Duo Processor T7500* (2.20-GHz, 800-FSB, 4-MB L2 cache)
Intel Centrino Pro
Intel Centrino ProIntel Centrino Pro
Intel Centrino Pro
processor technology
processor technologyprocessor technology
processor technology
Enabled
Operating System
Operating SystemOperating System
Operating System
Genuine Windows Vista Business**
System Memory
System MemorySystem Memory
System Memory
1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive
Hard DriveHard Drive
Hard Drive
80-GB 7200 rpm SMART SATA
Display
DisplayDisplay
Display
14.1-inch WXGA+
Graphics
GraphicsGraphics
Graphics
ATI Mobility Radeon X2300 with 128 MB of dedicated memory
Audio
AudioAudio
Audio
ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications
CommunicationsCommunications
Communications
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
56K V.92 modem
Integrated Wireless
Integrated WirelessIntegrated Wireless
Integrated Wireless
Intel Wireless WiFi Link 4965AG
Integrated Security
Integrated SecurityIntegrated Security
Integrated Security
Integrated Smart Card Reader
Drive Encryption for HP ProtectTools
HP Fingerprint Sensor
TPM 1.2***
Pointing Device
Pointing DevicePointing Device
Pointing Device
Enhanced dual pointing devices (touchpad with scroll zone and pointstick)
MultiBay II Drive
MultiBay II DriveMultiBay II Drive
MultiBay II Drive
DVD+/-RW SuperMulti DL Drive
Battery
BatteryBattery
Battery
6-cell (55 WHr) Lithium-Ion
Power
PowerPower
Power
External 90W adapter
Warranty
WarrantyWarranty
Warranty
3/3/0
* Intel's numbering system is not a measurement of higher performance.
** At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version
will be deleted.
*** TPM module disabled where use is restricted by law; for example, Russia and China.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 13
Memory
MemoryMemory
Memory
HP 512-MB (DDR2 667 MHz) SODIMM
EM993AA
HP 1-GB (DDR2 667 MHz) SODIMM
EM994AA
HP 2-GB (DDR2 667 MHz) SODIMM
EM995AA
MultiBay II Storage
MultiBay II StorageMultiBay II Storage
MultiBay II Storage
(9.5-mm)
HP MultiBay II DVD-ROM Drive
PA849A
HP MultiBay II DVD/CD-RW Combo Drive
PA850A
HP MultiBay II DVD+/-RW SuperMulti DL Drive
PA851A
HP 80-GB 5400rpm MultiBay II Hard Drive
PH357A
Other Storage
Other StorageOther Storage
Other Storage
HP 80-GB 5400rpm Primary SATA Hard Drive
ET354AA
HP 120-GB 5400rpm Primary SATA Hard Drive
RT080AA
HP Notebooks USB Diskette Drive
DC361B
Communications
CommunicationsCommunications
Communications
Intel Wireless WiFi Link 4965AGN option kit
RT081AA#xxx
HP ev2210 1xEVDO-A Broadband Wireless Module (Verizon) (available Sept. 2007)
GM763AA#ABA
HP ev2210 1xEVDO-A Broadband Wireless Module (Sprint) (available Oct. 2007)
GM764AA#ABA
HP hs2300 HSDPA Broadband Wireless Module (AT&T) (available Sept. 2007)
GG589AA#ABA
HP hs2300 HSDPA Broadband Wireless Module (Generic) (available Oct. 2007)
GG590AA#xxx
Expansion Solutions
Expansion SolutionsExpansion Solutions
Expansion Solutions
HP Docking Station with Smart Adapter
EN488AA#xxx
HP Advanced Docking Station with Smart Adapter
EN489AA#xxx
HP 3-in1 NAS Docking Station with Smart Adapter
EM537AA#xxx
HP Standard Monitor Stand
PA507A
HP Adjustable Notebook Stand
PA508A
HP External MultiBay II
PA509A#xxx
Power
PowerPower
Power
HP 2-Bay Battery Charging Station (North America only)
DT533A#xxx
HP 2-Bay Battery Charging Station (rest of world)
EW424AA#xxx
HP 10-Bay Battery Charging Station (North America only)
DT534A#ABA
HP Battery Adapter Kit
PK402A
HP 90W Smart AC Adapter
ED495AA#xxx
HP 90W Smart Auto Adapter
ED493AA
HP 65W AC/Auto/Air Combo Smart Adapter
ED993AA#xxx
HP 6-Cell Li-Ion Primary Battery
PB994A
HP 8-cell Extended Life Battery
PB993A
HP 12-cell Ultra-Capacity Battery
EJ092AA
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Options
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 14
Carrying Cases
Carrying CasesCarrying Cases
Carrying Cases
HP Value Nylon Case
RR314AA
HP Universal Nylon Case
RR315AA
HP Executive Leather Case
RR316AA
HP Deluxe Nylon Backpack
RR317AA
HP Universal Messenger Bag
GD404AA
HP Deluxe Roller Case
GD405AA
Security
SecuritySecurity
Security
HP PC Card Smart Card Reader with Java Card
EL347AA
HP ProtectTools Java Card – 10 units
EL348AA
HP/Kensington MicroSaver Security Lock
PC766A
Input/Output Devices
Input/Output DevicesInput/Output Devices
Input/Output Devices
HP PS/2 Keyboard & Mouse Bundle
RC464AA#xxx
HP USB Keyboard & Mouse Bundle
RC465AA#xxx
HP USB/PS2 Optical 2-Button Scroll Mouse
DC369A
HP USB Optical Travel Mouse
RH304AA
HP Bluetooth PC Card Mouse
RJ316AA
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Options
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 15
667-MHz DDR2 SDRAM
Two DIMM slots supporting dual channel memory
DIMM sizes supported: 512 MB, 1024 MB, and 2048 MB
Standard Memory
Standard MemoryStandard Memory
Standard Memory
512 MB (512 MB x 1)
1024 MB (1024 MB x 1 or 512 MB x 2)
2048 MB (2048 MB x 1 or 1024 MB x 2)
4096 MB (2048 MB x 2)
Optional Memory
Optional MemoryOptional Memory
Optional Memory
Upgrades
UpgradesUpgrades
Upgrades
Support for up to 4096 MB of memory with the installation of optional DDR2 SDRAM memory kits. Both
memory slots are user accessible. Please refer to the Hardware and Software Guide for installation
procedures. Maximized dual-channel performance requires SODIMMs of the same size and speed in
both memory slots.
Up to
Up toUp to
Up to
Slot 1
Slot 1Slot 1
Slot 1 Slot 2
Slot 2Slot 2
Slot 2
1024 MB 1024 MB
Empty
1024 MB
512 MB 512 MB
1536 MB 1024 MB
512 MB
2048 MB 1024 MB 1024 MB
4096 MB 2048 MB 2048 MB
NOTE:
NOTE: NOTE:
NOTE:
This chart does not represent all possible memory configurations. Due to the non-industry
standard nature of some third-party memory modules, we strongly recommend using only HP branded
memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Availability of 4 GB of memory requires Windows Vista Business 64-bit or Linux. With
Windows 32-bit operating systems, memory above 3 GB may not all be available due to system
resource requirements.
Memory Upgrades
Memory UpgradesMemory Upgrades
Memory Upgrades
HP 512-MB (DDR2 667 MHz) SODIMM
EM993AA
HP 1024-MB (DDR2 667 MHz) SODIMM
EM994AA
HP 2048-MB (DDR2 667 MHz) SODIMM
EM995AA
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Memory
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 16
Removable Media Drive Support
Removable Media Drive SupportRemovable Media Drive Support
Removable Media Drive Support
Quantity Supported
Quantity SupportedQuantity Supported
Quantity Supported
Drive Bay
Drive BayDrive Bay
Drive Bay
MultiBay II DVD-ROM Drive
One
MultiBay II
MultiBay II DVD/CD-RW Combo
Drive*
One
MultiBay II
MultiBay II DVD+/-RW SuperMulti
DL Drive*
One
MultiBay II
* MultiBay II drives supported in the internal MultiBay II are also supported in the optional HP 3-in-1 NAS Docking Station, HP
Advanced Docking Station, or HP External MultiBay II.
Primary Storage Device
Primary Storage DevicePrimary Storage Device
Primary Storage Device
Quantity Supported
Quantity SupportedQuantity Supported
Quantity Supported
Drive Bay
Drive BayDrive Bay
Drive Bay
Hard Drives
Hard DrivesHard Drives
Hard Drives
160-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
120-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
80-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
160-GB 7200 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
120-GB 7200 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
80-GB 7200 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
Solid State Drive
Solid State DriveSolid State Drive
Solid State Drive
64-GB Solid State Drive
One
Dedicated hard drive bay
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Storage
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 17
System Unit
System UnitSystem Unit
System Unit
Dimensions
Dimensions Dimensions
Dimensions
(HxWxD)
1.1 in (at front) x 13.0 in x 9.4 in
29 mm (at front) x 330 mm x 239 mm
Weight
WeightWeight
Weight
with MultiBay II weight-saver and 4-
cell battery
4.5 lb (2.0 kg)
with MultiBay II weight-saver and 6-
cell battery
4.7 lb (2.1 kg)
with MultiBay II DVD/CDRW Combo
Drive or DVD+/-RW SuperMulti DL
Drive and 6-cell battery
5.1 lb (2.3 kg)
NOTE:
NOTE: NOTE:
NOTE:
Height varies depending upon where on the notebook the measurement is made. Starting weight
includes integrated graphics, hard drive, 512-MB memory, 802.11 wireless communications module,
and Bluetooth. Weight varies by configuration and components.
Stand-Alone Power
Stand-Alone PowerStand-Alone Power
Stand-Alone Power
Requirements
RequirementsRequirements
Requirements
(AC Power)
Nominal Operating Voltage
18.5 V
Average Operating Power
21.41 W (integrated graphics)
25.55 W (discrete graphics)
Max Operating Power
< 90 W
Temperature
TemperatureTemperature
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing
optical)
41° to 95° F (5° to 35° C) (writing
optical)
Non-operating
–4° to 140° F (–20° to 60° C)
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C)
maximum wet bulb temperature
Shock
ShockShock
Shock
Operating
125 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Random VibrationRandom Vibration
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude
AltitudeAltitude
Altitude
(unpressurized)
Operating
–50 to 10,000 ft (–15.24 to 3,048
m)
Non-operating
–50 to 40,000 ft (–15.24 to 12,192
m)
Industry Standard
Industry StandardIndustry Standard
Industry Standard
Certifications
CertificationsCertifications
Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR
®
4.0
Yes
ICES
Yes
GS
Yes
Australia / NZ A-Tick Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
MIC
Yes
BSMI
Yes
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 18
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian Compliance (ICCP)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
For accessibility information on HP products, please visit
http://www.hp.com/accessibility
.
HP 90W Smart AC
HP 90W Smart ACHP 90W Smart AC
HP 90W Smart AC
Adapter
AdapterAdapter
Adapter
Dimensions
DimensionsDimensions
Dimensions
5.24 x 2.28 x 1.1 in (13.3 x 5.8 x 2.9 cm)
Weight
WeightWeight
Weight
0.86 lb (390 g)
Input
InputInput
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.5 A at 90 VAC, 0.75 A at 180 VAC PFC
Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC
Version
Output
OutputOutput
Output
Output power
90W
DC output
18.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
ConnectorConnector
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Environmental DesignEnvironmental Design
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
EMI and SafetyEMI and Safety
EMI and Safety
Certifications
CertificationsCertifications
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B,
CISPR22 Class B, CCC, NOM-1 NYCE; MTBF- over 200,000 hours at
25°C ambient condition.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 19
Optional HP Ultra-
Optional HP Ultra-Optional HP Ultra-
Optional HP Ultra-
Capacity Battery
Capacity BatteryCapacity Battery
Capacity Battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
Weight
WeightWeight
Weight
1.77 lb (0.803 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
12-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Watt-hour Capacity
95Wh
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
Smart Adapter
3 to 4 hours
System ON
4 to 5 hours (depending on system power
consumption)
Fuel Gauge
Fuel GaugeFuel Gauge
Fuel Gauge
When pressed, LEDs light indicating level of charge remaining on battery
Optional HP Extended Life
Optional HP Extended LifeOptional HP Extended Life
Optional HP Extended Life
Battery
BatteryBattery
Battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)
Weight
WeightWeight
Weight
1.00 lb (0.455 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
8-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Watt-hour Capacity
52Wh
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
System in OFF mode or
Standby
3 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Charges the battery up to 90% within 90 minutes
when system is OFF
Fuel Gauge
Fuel GaugeFuel Gauge
Fuel Gauge
When pressed, LEDs light indicating level of charge remaining on battery
6-Cell (55WHr) Lithium-
6-Cell (55WHr) Lithium-6-Cell (55WHr) Lithium-
6-Cell (55WHr) Lithium-
Ion battery
Ion batteryIon battery
Ion battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight
WeightWeight
Weight
0.737 lb (0.335 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
6-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Watt-hour Capacity
55Wh
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
System in OFF Mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Charges the battery up to 90% within 90 minutes
when system is OFF
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 20
4-Cell (37WHr) Lithium-
4-Cell (37WHr) Lithium-4-Cell (37WHr) Lithium-
4-Cell (37WHr) Lithium-
Ion battery
Ion batteryIon battery
Ion battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight
WeightWeight
Weight
0.55 lb (0.249 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
4-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Watt-hour Capacity
37Wh
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
System in OFF Mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Charges the battery up to 90% within 90 minutes
when system is OFF
14.1-inch WXGA anti-
14.1-inch WXGA anti-14.1-inch WXGA anti-
14.1-inch WXGA anti-
glare
glareglare
glare
Active Area
Active AreaActive Area
Active Area
(W x H)
11.9 x 7.5 in (30.3 x 19.0 cm)
Diagonal Size
Diagonal SizeDiagonal Size
Diagonal Size
14.1 in (35.7 cm)
Surface Treatment
Surface TreatmentSurface Treatment
Surface Treatment
Anti-glare
Contrast Ratio
Contrast RatioContrast Ratio
Contrast Ratio
300:1 (typical)
Refresh Rate
Refresh RateRefresh Rate
Refresh Rate
60 Hz
Brightness
BrightnessBrightness
Brightness
200 nit (typical)
Pixel Resolution
Pixel ResolutionPixel Resolution
Pixel Resolution
Pitch
PitchPitch
Pitch
0.237 mm
Format
FormatFormat
Format
1280x800
Configuration
ConfigurationConfiguration
Configuration
RGB Stripe
Backlight
BacklightBacklight
Backlight
CCFL
PPI
PPIPPI
PPI
107
Viewing Angle
Viewing AngleViewing Angle
Viewing Angle
±30° Horizontal, ±10° Vertical (minimum)
14.1-inch WXGA+ anti-
14.1-inch WXGA+ anti-14.1-inch WXGA+ anti-
14.1-inch WXGA+ anti-
glare
glareglare
glare
Active Area
Active AreaActive Area
Active Area
(W x H)
11.9 x 7.5 in (30.3 x 19.0 cm)
Diagonal Size
Diagonal SizeDiagonal Size
Diagonal Size
14.1 in (35.7 cm)
Surface Treatment
Surface TreatmentSurface Treatment
Surface Treatment
Anti-glare
Contrast Ratio
Contrast RatioContrast Ratio
Contrast Ratio
300:1 (typical)
Refresh Rate
Refresh RateRefresh Rate
Refresh Rate
60 Hz
Brightness
BrightnessBrightness
Brightness
200 nit (typical)
Pixel Resolution
Pixel ResolutionPixel Resolution
Pixel Resolution
Pitch
PitchPitch
Pitch
0.210 mm
Format
FormatFormat
Format
1440 x 900
Configuration
ConfigurationConfiguration
Configuration
RGB Stripe
Backlight
BacklightBacklight
Backlight
CCFL
PPI
PPIPPI
PPI
121
Viewing Angle
Viewing AngleViewing Angle
Viewing Angle
±30° Horizontal, ±10° Vertical (minimum)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 21
Hard Drives
Hard DrivesHard Drives
Hard Drives
160-GB 7200 rpm SATA
160-GB 7200 rpm SATA160-GB 7200 rpm SATA
160-GB 7200 rpm SATA
Drive Weight
Drive WeightDrive Weight
Drive Weight
0.25 lb (113 g)
Capacity
CapacityCapacity
Capacity
160 GB
Height
HeightHeight
Height
0.37 in (9.5 mm)
Width
WidthWidth
Width
2.75 in (70 mm)
Interface
InterfaceInterface
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Transfer RateTransfer Rate
Transfer Rate
Synchronous
Synchronous Synchronous
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
Seek TimeSeek Time
Seek Time
(typical reads, including
settling)
Single Track
Single TrackSingle Track
Single Track
1 ms
Average
AverageAverage
Average
10 ms
Maximum
MaximumMaximum
Maximum
18 ms
Rotational Speed
Rotational SpeedRotational Speed
Rotational Speed
7200 rpm
Logical Blocks
Logical BlocksLogical Blocks
Logical Blocks
312,581,808
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
FeaturesFeatures
Features
ATA Security
120-GB 7200 rpm SATA
120-GB 7200 rpm SATA120-GB 7200 rpm SATA
120-GB 7200 rpm SATA
Drive Weight
Drive WeightDrive Weight
Drive Weight
0.25 lb (113 g)
Capacity
CapacityCapacity
Capacity
120 GB
Height
HeightHeight
Height
0.37 in (9.5 mm)
Width
WidthWidth
Width
2.75 in (70 mm)
Interface
InterfaceInterface
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Transfer RateTransfer Rate
Transfer Rate
Synchronous
Synchronous Synchronous
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
Seek TimeSeek Time
Seek Time
(typical reads, including
settling)
Single Track
Single TrackSingle Track
Single Track
1 ms
Average
AverageAverage
Average
10 ms
Maximum
MaximumMaximum
Maximum
18 ms
Rotational Speed
Rotational SpeedRotational Speed
Rotational Speed
7200 rpm
Logical Blocks
Logical BlocksLogical Blocks
Logical Blocks
234,441,648
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
FeaturesFeatures
Features
ATA Security
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 22
80-GB 7200 rpm SATA
80-GB 7200 rpm SATA80-GB 7200 rpm SATA
80-GB 7200 rpm SATA
Drive Weight
Drive WeightDrive Weight
Drive Weight
0.25 lb (113 g)
Capacity
CapacityCapacity
Capacity
80 GB
Height
HeightHeight
Height
0.37 in (9.5 mm)
Width
WidthWidth
Width
2.75 in (70 mm)
Interface
InterfaceInterface
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Transfer RateTransfer Rate
Transfer Rate
Synchronous
Synchronous Synchronous
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
Seek TimeSeek Time
Seek Time
(typical reads, including
settling)
Single Track
Single TrackSingle Track
Single Track
1 ms
Average
AverageAverage
Average
10 ms
Maximum
MaximumMaximum
Maximum
18 ms
Rotational Speed
Rotational SpeedRotational Speed
Rotational Speed
7200 rpm
Logical Blocks
Logical BlocksLogical Blocks
Logical Blocks
156,301,488
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
FeaturesFeatures
Features
ATA Security
160-GB 5400 rpm SATA
160-GB 5400 rpm SATA160-GB 5400 rpm SATA
160-GB 5400 rpm SATA
Drive Weight
Drive WeightDrive Weight
Drive Weight
0.22 lb (101 g)
Capacity
CapacityCapacity
Capacity
160 GB
Height
HeightHeight
Height
0.37 in (9.5 mm)
Width
WidthWidth
Width
2.75 in (70 mm)
Interface
InterfaceInterface
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Transfer RateTransfer Rate
Transfer Rate
Synchronous
Synchronous Synchronous
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
Seek TimeSeek Time
Seek Time
(typical reads, including
settling)
Single Track
Single TrackSingle Track
Single Track
3 ms
Average
AverageAverage
Average
13ms
Maximum
MaximumMaximum
Maximum
24 ms
Rotational Speed
Rotational SpeedRotational Speed
Rotational Speed
5400 rpm
Logical Blocks
Logical BlocksLogical Blocks
Logical Blocks
312,581,808
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
FeaturesFeatures
Features
ATA Security
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 23
120-GB 5400 rpm SATA
120-GB 5400 rpm SATA120-GB 5400 rpm SATA
120-GB 5400 rpm SATA
Drive Weight
Drive WeightDrive Weight
Drive Weight
0.22 lb (101 g)
Capacity
CapacityCapacity
Capacity
120 GB
Height
HeightHeight
Height
0.37 in (9.5 mm)
Width
WidthWidth
Width
2.75 in (70 mm)
Interface
InterfaceInterface
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Transfer RateTransfer Rate
Transfer Rate
Synchronous
Synchronous Synchronous
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
Seek TimeSeek Time
Seek Time
(typical reads, including
settling)
Single Track
Single TrackSingle Track
Single Track
3 ms
Average
AverageAverage
Average
13ms
Maximum
MaximumMaximum
Maximum
24 ms
Rotational Speed
Rotational SpeedRotational Speed
Rotational Speed
5400 rpm
Logical Blocks
Logical BlocksLogical Blocks
Logical Blocks
234,441,648
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
FeaturesFeatures
Features
ATA Security
80-GB 5400 rpm SATA
80-GB 5400 rpm SATA80-GB 5400 rpm SATA
80-GB 5400 rpm SATA
Drive Weight
Drive WeightDrive Weight
Drive Weight
0.22 lb (101 g)
Capacity
CapacityCapacity
Capacity
80 GB
Height
HeightHeight
Height
0.37 in (9.5 mm)
Width
WidthWidth
Width
2.75 in (70 mm)
Interface
InterfaceInterface
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Transfer RateTransfer Rate
Transfer Rate
Synchronous
Synchronous Synchronous
Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
Seek TimeSeek Time
Seek Time
(typical reads, including
settling)
Single Track
Single TrackSingle Track
Single Track
3 ms
Average
AverageAverage
Average
13 ms
Maximum
MaximumMaximum
Maximum
24 ms
Rotational Speed
Rotational SpeedRotational Speed
Rotational Speed
5400 rpm
Logical Blocks
Logical BlocksLogical Blocks
Logical Blocks
156,301,488
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
FeaturesFeatures
Features
ATA Security
Removable Storage Drives – MultiBay II
Removable Storage Drives – MultiBay IIRemovable Storage Drives – MultiBay II
Removable Storage Drives – MultiBay II
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 24
DVD-ROM Drive
DVD-ROM DriveDVD-ROM Drive
DVD-ROM Drive
Dimensions
DimensionsDimensions
Dimensions
0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight
WeightWeight
Weight
0.34 lb (155 g)
Access Times
Access TimesAccess Times
Access Times
Random
<120 ms CD
<200 ms DVD
Max Data Transfer Rate
Max Data Transfer RateMax Data Transfer Rate
Max Data Transfer Rate
24X-CD-ROM
3,600 KB/s
8X-DVD
10,800 KB/s
Transfer Mode
Transfer ModeTransfer Mode
Transfer Mode
Multiword DMA Mode 2
Interface
InterfaceInterface
Interface
EIDE
Supported Media
Supported MediaSupported Media
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-
ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R,
DVD+RW
Supported Media
Supported Media Supported Media
Supported Media
(write)
None
Max Media Capacity
Max Media CapacityMax Media Capacity
Max Media Capacity
(read)
8.5 GB
Transport
TransportTransport
Transport
Tray Loading
DVD/CD-RW Combo
DVD/CD-RW ComboDVD/CD-RW Combo
DVD/CD-RW Combo
Drive
DriveDrive
Drive
Dimensions
DimensionsDimensions
Dimensions
0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight
WeightWeight
Weight
0.45 lb (205 g)
Access Times
Access TimesAccess Times
Access Times
Random
<120 ms CD
<155 ms DVD
Max Data Transfer Rate
Max Data Transfer RateMax Data Transfer Rate
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
24X CD-RW
3,600 KB/s
Transfer Mode
Transfer ModeTransfer Mode
Transfer Mode
Multiword DMA Mode 2
Interface
InterfaceInterface
Interface
EIDE
Supported Media
Supported MediaSupported Media
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-
ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R,
DVD+RW
Supported Media
Supported Media Supported Media
Supported Media
(write)
CD-R, CD-RW
Max Media Capacity
Max Media CapacityMax Media Capacity
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
Max Media CapacityMax Media Capacity
Max Media Capacity
(write)
700 MB
Transport
TransportTransport
Transport
Tray loading
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 25
DVD+/-RW SuperMulti
DVD+/-RW SuperMultiDVD+/-RW SuperMulti
DVD+/-RW SuperMulti
DL Drive
DL DriveDL Drive
DL Drive
Dimensions
DimensionsDimensions
Dimensions
0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight
WeightWeight
Weight
0.45 lb (205 g)
Access Times
Access TimesAccess Times
Access Times
Random
<150 ms CD
<125 ms DVD
Max Data Transfer Rate
Max Data Transfer RateMax Data Transfer Rate
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
10X CD-RW
1,500 KB/s
4X DVD+R
5,400 KB/s
2.4X DVD+RW
3,240 KB/s
4X DVD-R
5,400 KB/s
2X DVD-RW
2,700 KB/s
2X DVD-RAM
2,700 KB/s
Transfer Mode
Transfer ModeTransfer Mode
Transfer Mode
Multiword DMA Mode 2
Interface
InterfaceInterface
Interface
EIDE
Supported Media
Supported MediaSupported Media
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-
ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R,
DVD+RW, DVD-RAM
Supported Media
Supported Media Supported Media
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM
Max Media Capacity
Max Media CapacityMax Media Capacity
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
Max Media CapacityMax Media Capacity
Max Media Capacity
(write)
8.5 GB
Transport
TransportTransport
Transport
Tray Loading
80-GB 5400 rpm
80-GB 5400 rpm80-GB 5400 rpm
80-GB 5400 rpm
MultiBay II Hard Drive
MultiBay II Hard DriveMultiBay II Hard Drive
MultiBay II Hard Drive
MultiBay II Drive Adapter
MultiBay II Drive AdapterMultiBay II Drive Adapter
MultiBay II Drive Adapter
Dimensions (H x W x D)
0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight
0.16 lb (72 g)
Drive Weight
Drive WeightDrive Weight
Drive Weight
0.22 lb (101 g)
Capacity
CapacityCapacity
Capacity
80 GB
Height
HeightHeight
Height
0.37 in (9.5 mm)
Width
WidthWidth
Width
2.75 in (70 mm)
Interface
InterfaceInterface
Interface
ATA-6
Transfer Rate
Transfer RateTransfer Rate
Transfer Rate
Synchronous (maximum)
100 MB/s (Drive Capability)
Seek Time
Seek TimeSeek Time
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
Rotational SpeedRotational Speed
Rotational Speed
5400 rpm
Logical Blocks
Logical BlocksLogical Blocks
Logical Blocks
156,301,488
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
41° to 131° F (5° to 55° C)
Features
FeaturesFeatures
Features
ATA Security
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 26
HP Fingerprint Sensor
HP Fingerprint SensorHP Fingerprint Sensor
HP Fingerprint Sensor
Mobile Voltage
Mobile VoltageMobile Voltage
Mobile Voltage
Operation
OperationOperation
Operation
3.0V–3.6V Single Supply
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
32° – 158°F (0° – 70°C)
Current Consumption @
Current Consumption @Current Consumption @
Current Consumption @
3.3V
3.3V3.3V
3.3V
Less than 70 mA peak imaging and scrolling
Less than 25 mA hardware finger detection
Advanced Power Management
High-Rate Image Capture
High-Rate Image CaptureHigh-Rate Image Capture
High-Rate Image Capture
Up to 240 image frames /sec
ESD Resistance
ESD ResistanceESD Resistance
ESD Resistance
IEC 61000-4-2 Level 4 (±15KV)
Detection Matrix
Detection MatrixDetection Matrix
Detection Matrix
192 x 16 Pixels
9.7 mm x 0.81 mm
500 ppi High-Resolution Images
Audio
AudioAudio
Audio
Hardware
HardwareHardware
Hardware
Implementation
ImplementationImplementation
Implementation
ADI1981HD High Definition CODEC
Touch-Sensitive Volume
Touch-Sensitive VolumeTouch-Sensitive Volume
Touch-Sensitive Volume
Controls
ControlsControls
Controls
Volume up, volume down, and mute
Full Duplex
Full DuplexFull Duplex
Full Duplex
Yes
Sound Blaster Pro
Sound Blaster ProSound Blaster Pro
Sound Blaster Pro
compatible
compatiblecompatible
compatible
Yes
Microphone In
Microphone InMicrophone In
Microphone In
Stereo
Headphone/Line Out
Headphone/Line OutHeadphone/Line Out
Headphone/Line Out
Stereo
Integrated Microphone
Integrated MicrophoneIntegrated Microphone
Integrated Microphone
Yes
Audio Output Quality
Audio Output QualityAudio Output Quality
Audio Output Quality
Frequency Response
Frequency ResponseFrequency Response
Frequency Response
20 Hz – 20 kHz
Signal to Noise Ratio
Signal to Noise RatioSignal to Noise Ratio
Signal to Noise Ratio
>85 dB
Total Harmonic Distortion
Total Harmonic DistortionTotal Harmonic Distortion
Total Harmonic Distortion
0.01%
Noise Floor
Noise FloorNoise Floor
Noise Floor
-110 dB
Play/Record Sampling
Play/Record SamplingPlay/Record Sampling
Play/Record Sampling
Rate
RateRate
Rate
(s)
8 kHz – 48kHz
DAC
DACDAC
DAC
16, 20 or 24-bit
ADC
ADCADC
ADC
16 or 20-bit
Integrated Stereo
Integrated StereoIntegrated Stereo
Integrated Stereo
Speakers
SpeakersSpeakers
Speakers
Power Rating
Power RatingPower Rating
Power Rating
2 Watts
Impedance
ImpedanceImpedance
Impedance
4 Ohms
Communications
CommunicationsCommunications
Communications
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 27
Integrated Intel Gigabit
Integrated Intel GigabitIntegrated Intel Gigabit
Integrated Intel Gigabit
Network Connection
Network ConnectionNetwork Connection
Network Connection
(10/100/1000 NIC)
Ethernet Features
Ethernet FeaturesEthernet Features
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3z and 802.3ab; IEEE
802.3 clauses 34-42)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100
Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
Power Management
Power ManagementPower Management
Power Management
ACPI compliant -- multiple power modes
Situation-sensitive features reduce power consumption
Performance Features
Performance FeaturesPerformance Features
Performance Features
TCP/IP/UDP Checksum Offload (configurable)
Manageability
ManageabilityManageability
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft
Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Intel Advanced Management Technology (iAMT)
Interface
InterfaceInterface
Interface
PCI Express x1
NIC Device Driver Name
NIC Device Driver NameNIC Device Driver Name
NIC Device Driver Name
Intel 82566MM Gigabit Network Connection
Drivers Available
Drivers AvailableDrivers Available
Drivers Available
Microsoft Windows Vista
Microsoft Windows XP
V.92 56K Data/Fax
V.92 56K Data/FaxV.92 56K Data/Fax
V.92 56K Data/Fax
Modem
ModemModem
Modem
Form Factor
Form FactorForm Factor
Form Factor
MDC 1.5 Daughtercard
Power Management
Power ManagementPower Management
Power Management
Support
SupportSupport
Support
APM Revision 1.2, ACPI
Approvals/
Approvals/Approvals/
Approvals/
Certifications
CertificationsCertifications
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part
15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE
Mark, Other Countries
Data Mode Capabilities
Data Mode CapabilitiesData Mode Capabilities
Data Mode Capabilities
V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates:
Optional symbol rates:Optional symbol rates:
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
Synchronous primary channel data signaling rates:Synchronous primary channel data signaling rates:
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 28
V.22
V.21
Bell 212A
Bell 103J
Fax Mode Capabilities
Fax Mode CapabilitiesFax Mode Capabilities
Fax Mode Capabilities
TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
Command Set
Command SetCommand Set
Command Set
V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
HP ev2210
HP ev2210HP ev2210
HP ev2210
1xEVDO-A Broadband
1xEVDO-A Broadband1xEVDO-A Broadband
1xEVDO-A Broadband
Wireless Module
Wireless ModuleWireless Module
Wireless Module
Band and Power Class
Band and Power ClassBand and Power Class
Band and Power Class
0 (North American Cellular) – Class III;
1 (North American PCS) – Class II
Wireless Protocol
Wireless ProtocolWireless Protocol
Wireless Protocol
Standards
StandardsStandards
Standards
CDMA 1x Release A;
IS-95A, IS-95B, IS-2000
Wireless Parametric
Wireless ParametricWireless Parametric
Wireless Parametric
Standards
StandardsStandards
Standards
Meets or exceeds TIA/EIA IS-98-D
Interoperability
InteroperabilityInteroperability
Interoperability
CDG 22 (TIA/EIA/IS-95-A)
CDG 53(TIA/EIA/IS-95-B)
C.S0031 (TIA/EIA/IS-2000)
CDG 64 (TIA/EIA/IS-2000)
C.S0032 (TIA/EIA/IS-866)
Frequency Band
Frequency BandFrequency Band
Frequency Band
Dual Band: 800 MHz (Cellular) and 1900 MHz (PCS)
Data Rates
Data RatesData Rates
Data Rates
(Packet Mode)
IS-856 rates up to 3.1 Mbps
IS-2000 data rates up to 1.8 Mbps
Maximum Output Power
Maximum Output PowerMaximum Output Power
Maximum Output Power
24dBm (+/-1)
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
(maximum)
500mA
Power Consumption,
Power Consumption,Power Consumption,
Power Consumption,
Sleep Mode
Sleep ModeSleep Mode
Sleep Mode
1.7mA – 3.5mA
Power Management
Power ManagementPower Management
Power Management
USB selective suspend
CDMA slotted mode sleep and dormant modes
Antenna Type
Antenna TypeAntenna Type
Antenna Type
High efficiency dual band antennae with spatial diversity, mounted in the
display enclosure
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.35 oz (10 g)
Dimensions
Dimensions Dimensions
Dimensions
(Length x
Width x Thickness)
2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)
Voltage, Operating
Voltage, OperatingVoltage, Operating
Voltage, Operating
3.3v +/- 10%
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 29
Temperature, Operating
Temperature, OperatingTemperature, Operating
Temperature, Operating
(from TIA/EIA/IS-98-D)
–22° to 140° F (–30° to 60° C) (full RF performance)
–22° to 167° F (–30° to 75° C) (reduced RF performance)
Temperature, Non-
Temperature, Non-Temperature, Non-
Temperature, Non-
operating, 96 hours
operating, 96 hoursoperating, 96 hours
operating, 96 hours
(from
MIL-STD 202 Method
108)
–40° to 185° F (–40° to 85° C)
Humidity, Non-operating
Humidity, Non-operatingHumidity, Non-operating
Humidity, Non-operating
85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
Configuration Utilities
Configuration UtilitiesConfiguration Utilities
Configuration Utilities
Verizon Wireless VZAccess Manager
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio Off;
Solid LED On – Radio On
HP hs2300 HSDPA
HP hs2300 HSDPAHP hs2300 HSDPA
HP hs2300 HSDPA
Broadband Wireless
Broadband WirelessBroadband Wireless
Broadband Wireless
Module
ModuleModule
Module
Frequency Bands and
Frequency Bands andFrequency Bands and
Frequency Bands and
Power Class
Power ClassPower Class
Power Class
850/1900/2100MHz WCDMA
Power class 3 (+24dBm)
850MHz GSM/GPRS/EDGE
900MHz GSM/GPRS/EDGE,
1800MHz GSM/GPRS/EDGE
1900MHz GSM/GPRS/EDGE
EDGE E2 power
GPRS/EDGE Multislot Class 12
GPRS PCS/DCS power class 1
GSM power class 4
Wireless Protocol
Wireless ProtocolWireless Protocol
Wireless Protocol
Standards
StandardsStandards
Standards
GPRS/EDGE: 3GPP R99 GERAN P1
WCDMA Release 5 (R5)
High-Speed Downlink Packet Access (HSDPA) 3.6Mbps
GSM Phase 2+
Wireless Parametric
Wireless ParametricWireless Parametric
Wireless Parametric
Standards
StandardsStandards
Standards
Complies with 3GPP specifications
Additional Standards
Additional StandardsAdditional Standards
Additional Standards
Compliance
ComplianceCompliance
Compliance
FCC parts 15/22/24, CE, Microsoft WHQL, R&TTE directive 1999/5/EC
(health, safety, EMC, spectrum), GCF-CC (Module), European Union
Directive 2002/95/EC (restrictions of the use of certain Hazardous
Substances (RoHS) in electronic equipment), Infrastructure Interoperability
Testing (IOT)
Data Rates
Data RatesData Rates
Data Rates
(Packet Mode)
Designed maximum data rate:
EDGE 118 kbps UL / 236 kbps DL
UMTS 384 kbps UL / 384 kbps DL
HSDPA 384 kbps UL / 3.6 Mbps DL
Chipset and Module
Chipset and ModuleChipset and Module
Chipset and Module
Qualcomm MSM6280 chipset; Sierra Wireless MC8775 module
Maximum Output Power
Maximum Output PowerMaximum Output Power
Maximum Output Power
32 dBm (+/-2) GSM/EDGE GMSK mode
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
(maximum)
800mA
Power Consumption,
Power Consumption,Power Consumption,
Power Consumption,
Sleep Mode
Sleep ModeSleep Mode
Sleep Mode
4 – 8mA
Power Management
Power ManagementPower Management
Power Management
USB Selective Suspend
sleep and standby mode
Antenna Type
Antenna TypeAntenna Type
Antenna Type
High efficiency 5- band antennae, mounted in the display enclosure
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.35 oz (10 g)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 30
Dimensions
Dimensions Dimensions
Dimensions
(Length x
Width x Thickness)
2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)
Voltage, Operating
Voltage, OperatingVoltage, Operating
Voltage, Operating
3.3v +/- 10%
Temperature, Operating
Temperature, OperatingTemperature, Operating
Temperature, Operating
–22° to 140° F (–30° to 60° C) (full RF performance)
–22° to 167° F (–30° to 75° C) (reduced RF performance)
Temperature, Non-
Temperature, Non-Temperature, Non-
Temperature, Non-
operating, 96 hours
operating, 96 hoursoperating, 96 hours
operating, 96 hours
(from
MIL-STD 202 Method
108)
–40° to 185° F (–40° to 85° C)
Humidity, Non-operating
Humidity, Non-operatingHumidity, Non-operating
Humidity, Non-operating
85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio Off;
Solid LED On – Radio On
Configuration Utilities
Configuration UtilitiesConfiguration Utilities
Configuration Utilities
Varies per country and mobile network operator
Intel PRO/Wireless
Intel PRO/WirelessIntel PRO/Wireless
Intel PRO/Wireless
3945BG Network
3945BG Network3945BG Network
3945BG Network
Connection
ConnectionConnection
Connection
Wireless LAN Standards
Wireless LAN StandardsWireless LAN Standards
Wireless LAN Standards
IEEE 802.11b
IEEE 802.11g
Interoperability
InteroperabilityInteroperability
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft Windows
2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2.4 GHz
Data Rates
Data RatesData Rates
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
ModulationModulation
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
SecuritySecurity
Security
1
11
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4).
Sub-channels
Sub-channelsSub-channels
Sub-channels
Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol
Media Access ProtocolMedia Access Protocol
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Network ArchitectureNetwork Architecture
Network Architecture
Models
ModelsModels
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
RoamingRoaming
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
Output PowerOutput Power
Output Power
(for CKK)
2
15 dBm
Output Power
Output PowerOutput Power
Output Power
(for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode
3
: 150 mW (nominal)
Sleep mode: 30 mW (max)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 31
1.
2.
3.
4.
5.
Power Management
Power ManagementPower Management
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
4
44
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna Connections
Antenna ConnectionsAntenna Connections
Antenna Connections
2 U.FL type connectors, 50 ohm nominal impedance
Range
RangeRange
Range
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.013 lb (6 g)
Dimensions
DimensionsDimensions
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
3.3V +/- 9%, 1.5V +/- 5%
Temperature
TemperatureTemperature
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
AltitudeAltitude
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
5
55
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.
Intel Wireless WiFi Link
Intel Wireless WiFi LinkIntel Wireless WiFi Link
Intel Wireless WiFi Link
4965AG
4965AG4965AG
4965AG
Wireless LAN Standards
Wireless LAN StandardsWireless LAN Standards
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability
InteroperabilityInteroperability
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft Windows
2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2.4 GHz and 5 GHz
Data Rates
Data RatesData Rates
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 32
Modulation
ModulationModulation
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
SecuritySecurity
Security
1
11
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES
(support for key sizes of 128, 192, and 256 bits), 802.1x authentication
types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows 2000 and XP only.
Sub-channels
Sub-channelsSub-channels
Sub-channels
Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol
Media Access ProtocolMedia Access Protocol
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Network ArchitectureNetwork Architecture
Network Architecture
Models
ModelsModels
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
RoamingRoaming
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
Output PowerOutput Power
Output Power
(for CKK)
2
15 dBm
Output Power
Output PowerOutput Power
Output Power
(for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Transmit: 1.6 Watts (average)
Receive: 1.1 Watts (average)
Idle mode
3
: 30 mW (average)
Radio off: 20 mW (max)
Power Management
Power ManagementPower Management
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
4
44
4
54 Mbps: -74 dBm, 6 Mbps: -90 dBm
Antenna Connections
Antenna ConnectionsAntenna Connections
Antenna Connections
2 U.FL type connectors, 50 ohm nominal impedance
Range
RangeRange
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.013 lb (6 g)
Dimensions
DimensionsDimensions
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
3.3V +/- 9%, 1.5V +/- 5%
Temperature
TemperatureTemperature
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 90% (non-condensing)
Altitude
AltitudeAltitude
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 33
1.
2.
3.
4.
5.
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
5
55
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode and on battery power.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.
Intel Wireless WiFi Link
Intel Wireless WiFi LinkIntel Wireless WiFi Link
Intel Wireless WiFi Link
4965AGN
4965AGN4965AGN
4965AGN
Wireless LAN Standards
Wireless LAN StandardsWireless LAN Standards
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft 1.02)
Interoperability
InteroperabilityInteroperability
Interoperability
Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with
Microsoft Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Tested with wireless access points from several major manufacturers
(details at
http://www.hp.com/go/notebooks/WLAN/
draft-n)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2.4 GHz and 5 GHz
Data Rates
Data RatesData Rates
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (draft): 66 possible data rates, ranging from 6 Mbps to 300 Mbps,
depending on the combination of Bandwidth, Modulation Coding Scheme,
and Guard Interval used, as defined in IEEE 802.11n (draft) specification
Modulation
ModulationModulation
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
SecuritySecurity
Security
1
11
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES
(support for key sizes of 128, 192, and 256 bits), 802.1x authentication
types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows 2000 and XP only.
Sub-channels
Sub-channelsSub-channels
Sub-channels
Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol
Media Access ProtocolMedia Access Protocol
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Network ArchitectureNetwork Architecture
Network Architecture
Models
ModelsModels
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 34
1.
2.
3.
4.
5.
Roaming
RoamingRoaming
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
Output PowerOutput Power
Output Power
(for CKK)
2
15 dBm
Output Power
Output PowerOutput Power
Output Power
(for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Transmit: 2.3 Watts (average, with two spatial streams)
Receive: 1.9 Watts (average with three receive chains)
Idle mode
3
: 30 mW (average)
Radio off: 20 mW (max)
Power Management
Power ManagementPower Management
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
4
44
4
300 Mbps: -68 dBm, 54 Mbps: -74 dBm, 6 Mbps: -90 dBm
Antenna Connections
Antenna ConnectionsAntenna Connections
Antenna Connections
3 U.FL type connectors, 50 ohm nominal impedance
Range
RangeRange
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.013 lb (6 g)
Dimensions
DimensionsDimensions
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
3.3V +/- 9%, 1.5V +/- 5%
Temperature
TemperatureTemperature
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 90% (non-condensing)
Altitude
AltitudeAltitude
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
5
55
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode and on battery power.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 35
5.
Broadcom 4311AG
Broadcom 4311AGBroadcom 4311AG
Broadcom 4311AG
802.11a/b/g WiFi
802.11a/b/g WiFi802.11a/b/g WiFi
802.11a/b/g WiFi
Adapter
AdapterAdapter
Adapter
Wireless LAN Standards
Wireless LAN StandardsWireless LAN Standards
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability
InteroperabilityInteroperability
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft Windows
2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2.4 GHz and 5 GHz
Data Rates
Data RatesData Rates
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
ModulationModulation
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
SecuritySecurity
Security
1
11
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4).
Sub-channels
Sub-channelsSub-channels
Sub-channels
Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol
Media Access ProtocolMedia Access Protocol
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Network ArchitectureNetwork Architecture
Network Architecture
Models
ModelsModels
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
RoamingRoaming
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
Output PowerOutput Power
Output Power
(for CKK)
2
17.5 dBm
Output Power
Output PowerOutput Power
Output Power
(for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
Power Management
Power ManagementPower Management
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
4
44
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
Antenna typeAntenna type
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
RangeRange
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.026 lb (12 g)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 36
1.
2.
3.
4.
5.
Dimensions
DimensionsDimensions
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
3.3v +/- 10%
Temperature
TemperatureTemperature
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
AltitudeAltitude
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
5
55
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.
Broadcom 4311BG
Broadcom 4311BGBroadcom 4311BG
Broadcom 4311BG
802.11b/g WiFi Adapter
802.11b/g WiFi Adapter802.11b/g WiFi Adapter
802.11b/g WiFi Adapter
Wireless LAN Standards
Wireless LAN StandardsWireless LAN Standards
Wireless LAN Standards
IEEE 802.11b
IEEE 802.11g
Interoperability
InteroperabilityInteroperability
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft Windows
2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2.4 GHz
Data Rates
Data RatesData Rates
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
ModulationModulation
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
SecuritySecurity
Security
1
11
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4).
Sub-channels
Sub-channelsSub-channels
Sub-channels
Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol
Media Access ProtocolMedia Access Protocol
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 37
1.
2.
3.
4.
5.
Network Architecture
Network ArchitectureNetwork Architecture
Network Architecture
Models
ModelsModels
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
RoamingRoaming
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
Output PowerOutput Power
Output Power
(for CKK)
2
17.5 dBm
Output Power
Output PowerOutput Power
Output Power
(for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
Power Management
Power ManagementPower Management
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
4
44
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
Antenna typeAntenna type
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
RangeRange
Range
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.026 lb (12 g)
Dimensions
DimensionsDimensions
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
3.3v +/- 10%
Temperature
TemperatureTemperature
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
AltitudeAltitude
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
5
55
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 38
4.
5.
Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.
Broadcom 4321AGN
Broadcom 4321AGNBroadcom 4321AGN
Broadcom 4321AGN
802.11a/b/g/draft-n WiFi
802.11a/b/g/draft-n WiFi802.11a/b/g/draft-n WiFi
802.11a/b/g/draft-n WiFi
Adapter
AdapterAdapter
Adapter
Wireless LAN Standards
Wireless LAN StandardsWireless LAN Standards
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft)
Interoperability
InteroperabilityInteroperability
Interoperability
Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with
Microsoft Windows 2000 and XP (details at
http://www.hp.com/go/notebooks/WLAN
)
Tested with wireless access points from several major manufacturers
(details at
http://www.hp.com/go/notebooks/WLAN/draft-n
)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2.4 GHz and 5 GHz
Data Rates
Data RatesData Rates
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (draft): 6, 6.5, 9, 12, 13, 13.5, 18, 19.5, 24, 26, 27, 36, 39,
40.5, 48, 52, 54, 58.5, 65, 78, 81, 104, 108, 117, 121.5, 130, 135,
162, 216, 243, 270 Mbps
Frequency Support
Frequency SupportFrequency Support
Frequency Support
20 MHz: 2.4 GHz and 5 GHz bands
40 MHz: 5 GHz band only
Modulation
ModulationModulation
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
SecuritySecurity
Security
1
11
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows 2000 and XP only.
Sub-channels
Sub-channelsSub-channels
Sub-channels
Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol
Media Access ProtocolMedia Access Protocol
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Network ArchitectureNetwork Architecture
Network Architecture
Models
ModelsModels
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
RoamingRoaming
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
Output PowerOutput Power
Output Power
(for CKK)
2
17 dBm
Output Power
Output PowerOutput Power
Output Power
(for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Idle associated: 300 mW
Idle unassociated: 150 mW
Transmit/Receive 20 MHz channel: 2.6 W (max)
Transmit/Receive 40 MHz channel: 3.3 W (max)
Power Management
Power ManagementPower Management
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
3
33
3
270 Mbps: -66dBm, 162 Mbps: -72 dBm, 54 Mbps: -72 dBm, 11 Mbps: -
85 dBm , 1 Mbps: -94 dBm
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 39
1.
2.
3.
4.
Antenna type
Antenna typeAntenna type
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
RangeRange
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor
PCI-Express MiniCard
Weight
WeightWeight
Weight
0.026 lb (12 g)
Dimensions
DimensionsDimensions
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
3.3v +/- 10%
Temperature
TemperatureTemperature
Temperature
Operating
Non-operating
14° to 149° F (–10° to 65° C)
–40° to 176° F (–40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
AltitudeAltitude
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
4
44
4
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.
HP Integrated Module
HP Integrated ModuleHP Integrated Module
HP Integrated Module
with Bluetooth Wireless
with Bluetooth Wirelesswith Bluetooth Wireless
with Bluetooth Wireless
Technology
TechnologyTechnology
Technology
Bluetooth Specification
Bluetooth SpecificationBluetooth Specification
Bluetooth Specification
2.0 Compliant
Dimensions
DimensionsDimensions
Dimensions
1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2402 to 2480 MHz
Number of Available
Number of AvailableNumber of Available
Number of Available
Channels
ChannelsChannels
Channels
79 (1 MHz) available channels
Data Rates and
Data Rates andData Rates and
Data Rates and
Throughput
ThroughputThroughput
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or
1306.9 kbps symmetric
Transmit Power
Transmit PowerTransmit Power
Transmit Power
-6 dBm to 4 dBm (Bluetooth Class II)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 40
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Power ConsumptionPower Consumption
Power Consumption
Peak (Tx) 264 mW
Peak (Rx) 231 mW
Sleep <1 mW
Antenna
AntennaAntenna
Antenna
Internally integrated within module
Range
RangeRange
Range
Up 33 ft (10 m)
Electrical Interface
Electrical InterfaceElectrical Interface
Electrical Interface
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
OS Support
OS SupportOS Support
OS Support
Genuine Windows Vista
Genuine Windows XP
Genuine Windows 2000
Bluetooth Software
Bluetooth SoftwareBluetooth Software
Bluetooth Software
Supported
SupportedSupported
Supported
Broadcom Bluetooth for Windows
Microsoft Windows XP Bluetooth Software
Link Topology
Link TopologyLink Topology
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
SecuritySecurity
Security
Full support of Bluetooth Security Provisions
Power Management
Power ManagementPower Management
Power Management
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications
CertificationsCertifications
Certifications
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Temperature
TemperatureTemperature
Temperature
Operating
-4° to 158° F (-20° to 70° C)
Non-operating
-40° to 176° F (-40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
10% to 90%
Non-operating
5% to 95%
Altitude
AltitudeAltitude
Altitude
Operating
15,000 ft (4,572 m)
Non-operating
40,000 ft (12,192 m)
Bluetooth Profiles
Bluetooth ProfilesBluetooth Profiles
Bluetooth Profiles
Supported
SupportedSupported
Supported
(with Bluetooth for Windows 4.0 software)
Serial Port Profile (SPP)*
Dial-Up Networking (DUN)*
Generic Object Exchange Profile (GOEP)
Object Push Profile (OPP)*
File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)*
Personal Area Networking Profile (PAN)*
Human Interface Device Profile (HID)*
FAX Profile (FAX)
Basic Imaging Profile (BIP)
Headset Profile (HSP)
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 41
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
*
indicates the profile is also supported by Microsoft Windows XP SP2
Environmental Data
Environmental DataEnvironmental Data
Environmental Data
Eco-Label Certifications
Eco-Label CertificationsEco-Label Certifications
Eco-Label Certifications
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these marks:
ENERGY STAR 4.0
US Federal Energy Management Program (FEMP)
Taiwan Green Mark
China Energy Conservation Program (CECP)
ECO declaration
Korean Eco Label
EPEAT Silver Rating
System Configuration
System ConfigurationSystem Configuration
System Configuration
The configuration used for the Energy Consumption and Declared Noise
Emissions data is based on a “Typically Configured Notebook”
Energy Consumption
Energy ConsumptionEnergy Consumption
Energy Consumption
115 VAC
115 VAC115 VAC
115 VAC 230 VAC
230 VAC230 VAC
230 VAC 100 VAC
100 VAC100 VAC
100 VAC
Normal Operation
13.89 W 13.86 W 13.87 W
Sleep (Energy Star low
power mode)
0.8524 W
1.028 W
0.8504 W
Off
1.258 W
1.48 W
1.225 W
Heat Dissipation*
Heat Dissipation*Heat Dissipation*
Heat Dissipation*
115 VAC
115 VAC115 VAC
115 VAC 230 VAC
230 VAC230 VAC
230 VAC 100 VAC
100 VAC100 VAC
100 VAC
Normal Operation
47.392 BTU/hr
47.29 BTU/hr
47.324 BTU/hr
Sleep
2.908 BTU/hr 3.507 BTU/hr 2.901 BTU/hr
Off
4.292 BTU/hr 5.049 BTU/hr 4.179 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
This product is in compliance with US executive order 13221, WOL (wake
on LAN) disabled.
Declared Noise Emissions
Declared Noise EmissionsDeclared Noise Emissions
Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)
Sound Power
Sound PowerSound Power
Sound Power
(LWAd, bels)
Sound Pressure
Sound PressureSound Pressure
Sound Pressure
(LpAm, decibels)
Idle
3.2
25
Operating mode (HDD)
4.7
40
Batteries
BatteriesBatteries
Batteries
This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000 ppm by weight.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 42
The battery type and chemistry used in the product is:
CR2032 (coin cell), Lithium
8 cell rechargeable Lithium-Ion battery
Additional
AdditionalAdditional
Additional
information:
information:information:
information:
This product is in compliance with the EU Restrictions of Hazardous
Substances (RoHS) Directive – 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and
ISO/IEC 15412
Input devices of this product comply with ISO 9241, part 9.
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 0% recycled materials (by wt.)
This product is greater than 95% recyclable when properly disposed of at
end of life.
Packaging Materials
External:
Corrugated / Paper – 1.0 lb (453 g)
Internal:
EPE Foam – 0.15 lb (70 g)
LDPE Bag – 0.01 lb (5 g)
The corrugated paper packaging materials contains at least 40%
recycled content.
HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury
and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and
DIN 6120 standards.
Material Usage
Material UsageMaterial Usage
Material Usage
This product does not contain any of the following substances in excess of
regulatory limits (for reference of these limits please refer to the HP General
Specification of the Environment
(
http://www.hp.com/hpinfo/globalcitizenship/
environment/supplychain/gen_specifications.html
):
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 43
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface designed to
be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and certain
retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
End-of-life Management
End-of-life ManagementEnd-of-life Management
End-of-life Management
and Recycling
and Recyclingand Recycling
and Recycling
HP offers our customers several other options for handling their aging
computers while also minimizing the impact on the environment—including
product trade-in and leasing services-in addition to recycling services.
Please go to:
http://www.hp.com/recycle
or contact your nearest HP sales office. Products returned to HP will be
recycled, recovered or disposed of in a responsible manner.
Hewlett-Packard
Hewlett-PackardHewlett-Packard
Hewlett-Packard
Corporate Environmental
Corporate EnvironmentalCorporate Environmental
Corporate Environmental
Information
InformationInformation
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Environment website
http://www.hp.com/environment
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/
environment/productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/
environment/operations/envmanagement.html
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 44
Copyright © 2007 Hewlett-Packard Development Company, L.P.
All rights reserved. Microsoft, Windows, Windows Vista and Windows XP are registered trademarks or trademarks of Microsoft
Corporation in the U.S. and/or other countries. Core 2 Duo and Celeron are registered trademarks or trademarks of Intel
Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other
countries. All other product names mentioned herein may be trademarks of their respective companies.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 45
