QuickSpecs hp SANworks Network View v2.0B

DA-10852 North America — Version 9 — August 1, 2002 1

PRODUCT DESCRIPTION/OVERVIEW

HP SANworks Network View is a SAN management application providing a consolidation point for storage network visualization, monitoring and

configuration. SAN devices, their Fibre Channel interconnects, and associated status are automatically discovered and displayed in an intuitive

topographical network map. SAN device management is made easy by double clicking on a device icon. System performance bottlenecks are identified

for proactive resolution and planning. A JAVA applet based design allows remote SAN management from any web browser. Network View is easily

installed on the Management Appliance and because it is an appliance application; host operating system integration is not a necessity.

CUSTOMER BENEFITS

• Consolidation and integration point for managing all storage networked devices

• Reduced IT resource needs through consolidation

• Remote access from any network or internet connected PC

• At-a-glance visualization of storage fabric and associated status

• Proactive SAN availability monitoring

• Proactive SAN and storage array performance monitoring for system bottleneck resolution

• Management and monitoring of numerous HP and third party devices

• Operating system agnostic without the need for a server-client-agent setup

• Easy installation and setup

• Integration into network management tools through the Management Appliance

• Scalable for future storage network growth

SOFTWARE FEATURES/FUNCTIONALITY

• Automated in-band and out-of-band device discovery

• Graphical SAN topology mapping of all Fibre Channel connected devices and their interconnects

• Graphical status display

• Automated SAN availability monitoring and notification via e-mail and text pager when faults arise

• SNMP trap forwarding

• Custom notification set up

• Performance monitoring and graphical trending of numerous switch and HP StorageWorks RAID arrays, Modular arrays, Enterprise Virtual arrays,

performance metrics

• Launch capability for all browser enabled device management tools

• Support for numerous HP and third party devices

HARDWARE SUPPORT

Network View supports the following hardware devices running the software, firmware, or driver versions listed in the software pre-requisite section.

Support is defined as capability for device discovery and monitoring.

• Management Appliance

• HP StorageWorks Fibre Channel Storage Hub 12 (with management option)

• HP StorageWorks Modular Data Router

• HP StorageWorks Network Storage Router Model M2402

QuickSpecs hp SANworks Network View v2.0B

DA-10852 North America — Version 9 — August 1, 2002 2

HARDWARE SUPPORT (continued)

• Fibre Channel switches:

Fibre Channel Switches Part Numbers

HP StorageWorks Fibre Channel SAN Switch/8 158222-B21

HP StorageWorks Fibre Channel SAN Switch/16 158223-B21

HP StorageWorks Fibre Channel SAN Switch 2/16 240602-B21

HP StorageWorks Fibre Channel SAN Switch 8-EL 176219-B21

HP StorageWorks Fibre Channel SAN Switch 16-EL 212776-B21

HP StorageWorks Fibre Channel SAN Switch 2/8-EL 258707-B21

HP StorageWorks Fibre Channel SAN Switch 2/16-EL 283056-B21

HP StorageWorks SAN Switch Integrated/32 230616-B21

HP StorageWorks SAN Switch Integrated/64 230617-B21

HP StorageWorks Core Switch 2/64 254508-B21

HP StorageWorks Fibre Channel Arbitrated Loop Switch 8 (FC-AL) 177862-B21

Brocade SilkWorm Models 2400, 2800, 2050, 2250, 3800, 6400, 0r 12000 Contact Brocade for part number information

HP StorageWorks director 2/64 286809-b21

HP StorageWorks edge switch 2/16 286811-B21

HP StorageWorks edge switch 2/32 286810-B21

McData ED-5000 or 6064 Director Contact McData for part number information

McData 3216 Fabric Switch Contact McData for part number information

McData 3232 Fabric Switch Contact McData for part number information

HP StorageWorks Modular Storage Array Fabric Switch 6 218232-B21

• RAID Storage Systems:

− HP StorageWorks RAID Array 4100

− HP StorageWorks Modular Array 6000 Fibre Channel

− HP StorageWorks RAID Array 8000 Fibre Channel

− HP StorageWorks Modular Array 8000/Enterprise Modular Array 12000 Fibre Channel

− HP StorageWorks Enterprise Storage Array 12000 Fibre Channel

− HP StorageWorks Enterprise Modular Array 16000 Fibre Channel

− HP StorageWorks Enterprise Virtual Array

− HP StorageWorks Modular SAN Array 1000

− EMC Symmetrix systems using the Sym API 4.2 or 4.3

• Server/host systems and associated Host Bus Adapters (HBAs): for discovery and monitoring purpose

Server/Host Systems Associated HBAs Part Numbers

Windows NT (Intel) & Windows 2000 (Intel) HP StorageWorks 2 Gb, 64-bit/66 MHz PCI-to-Fibre Channel Host Bus

Adapter for Windows/NT, Windows 2000 (msa1000 only) 245299-B21

Windows NT (Intel) & Windows 2000 (Intel) HP StorageWorks 64-bit/33 MHz PCI-to-Fibre Channel Host Bus Adapter 176479-B21

Windows NT (Intel) & Windows 2000 (Intel) HP StorageWorks 32-bit/33 MHz PCI-to-Fibre Channel Host Bus Adapter 380574-001

Windows NT (ProLiant) and Windows 2000

(ProLiant) HP StorageWorks 64-bit/66 MHz PCI-to-Fibre Channel Host Bus Adapter 120186-B21

Windows 2000 for Datacenter HP StorageWorks 64-bit/33 MHz PCI-to-Fibre Channel Host Bus Adapter 176479-B21

Tru64 UNIX (Alpha) HP StorageWorks 2 Gb, 64-bit/66 MHz PCI-to-Fibre Channel Host Adapter for

Tru64 UNIX and HP OpenVMS (HSG80 only) 261329-B21

Tru64 UNIX (Alpha) HP StorageWorks 64-bit/33 MHz PCI-to-Fibre Channel Host Bus Adapter 168794-B21

Tru64 UNIX (Alpha) HP StorageWorks 32-bit/33 MHz PCI-to-Fibre Channel Host Bus Adapter 380574-001

Solaris HP StorageWorks 32-bit PCI-to-Fibre Channel Host Bus Adapter for Solaris 380576-001

Solaris HP StorageWorks 64-bit SBus-to-Fibre Channel Host Bus Adapter for Solaris 123503-001

OpenVMS (Alpha) HP StorageWorks 2 Gb, 64-bit/66 MHz PCI-to-Fibre Channel Host Adapter for

Tru64 UNIX and OpenVMS (HSG80 only) 261329-B21

OpenVMS (Alpha) HP StorageWorks 64-bit/33 MHz PCI-to-Fibre Channel Host Bus Adapter 380574-001

OpenVMS (Alpha) HP StorageWorks 32-bit/33 MHz PCI-to-Fibre Channel Host Bus Adapter 168794-B21

HP-UX HP StorageWorks 64-bit/66 MHz PCI-to-Fibre Channel Host Bus Adapter 218409-B21

AIX HP StorageWorks 64-bit/66 MHz PCI-to-Fibre Channel Host Bus Adapter 197819-B21

NetWare (Intel) HP StorageWorks 64-bit/66 MHz PCI-to-Fibre Channel Host Bus Adapter 120186-B21

QuickSpecs hp SANworks Network View v2.0B

DA-10852 North America — Version 9 — August 1, 2002 3

SOFTWARE PREREQUISITES

• Management Appliance running Open SAN Manager (OSM) version 1.0C

• Fibre Channel Switches and Routers:

− If using HP StorageWorks 1 Gb Fibre Channel SAN Switches, firmware version 2.1.9m or 2.6

− If using HP StorageWorks 2 Gb Fibre Channel SAN Switches, firmware version 3.02f

− If using HP StorageWorks Core Switch 2/64, firmware 4.0c

− If using Brocade SilkWorm Models 2400, 2800, 2050, 2250, or 6400, firmware versions 2.1.9m, 2.2.1, 2.4.1f, or 2.6c

− If using Brocade SilkWorm Model 3800, firmware version 3.02f

− If using Brocade 12000, firmware version 4.0c

− If using HP StorageWorks Fibre Channel Arbitrated Loop Switch 8 (FC-AL), firmware version 1.00-G03

− If using HP StorageWorks director 2/64, firmware version 2.0

− If using HP Storage edge switches, firmware version 2.0

− If using McData ED-5000 Director, firmware version 1.2.02 pass 6

− If using McData 6064 Director, firmware version 2.0 EFCM v6.0

− If using McData 3216 or 3232 Fabric Switch, firmware version 2.0

− If using HP StorageWorks Fibre Channel Storage Hubs, firmware version 4.00-g06

− If using HP StorageWorks Modular Data Routers, firmware version 1187

− If using HP StorageWorks Network Storage Router Model M2402, firmware version 4.02aw

− If using HP StorageWorks Modular Storage Array Fabric Switch 6, firmware version 101G06

• RAID Storage Systems:

− If using HP StorageWorks Enterprise Virtual Array

 VCS version 2.0

 OSM version 1.0C SP2

− If using HP StorageWorks RAID Storage Systems

 ACS version 8.6-1 or 8.7

 OSM version 1.0C SP4

− If using HP StorageWorks RAID Array 4100

 Sub-system firmware J51

 Controller firmware 2.6

− If using HP StorageWorks Modular SAN Array 1000

 Sub-system firmware 1.78

 Controller firmware 1.14

− If using EMC Symmetrix, those that support Sym API 4.2 & 4.3

• Browser Support: Client PC systems browsing to the Management Appliance require the following OS/browser versions:

Client Systems Browser Browser Version

Windows 2000 Internet Explorer v5.01 & v5.5

Windows 2000 Netscape v4.79

Windows NT v4.0 Internet Explorer v5.5

Windows NT v4.0 Netscape v4.79

Solaris Netscape v4.78

Tru64 UNIX Netscape v4.78

QuickSpecs hp SANworks Network View v2.0B

DA-10852 North America — Version 9 — August 1, 2002 4

SOFTWARE PREREQUISITES (continued)

Host Agent Support: Network View requires host agent installation for Fibre Channel HBA (host bus adapter) discovery and monitoring purpose only. The

following table lists supported host operating systems and HBA firmware versions. Installable agents are provided with the Network View CD.

Server/Host

Systems OS Versions Associated HBAs HBA Part

Number HBA Firmware

Versions HBA Driver

Versions

Windows 2000 SP2 HP StorageWorks 2 Gb, 64-bit/66 MHz

PCI-to-Fibre Channel Host Adapter for

Windows/NT, Windows 2000 (msa1000

only)

245299-B21 3.82a1 with boot

BIOS 1.60a5 5-4.81a9

Windows 2000 SP2 HP StorageWorks 64-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 176479-B21 3.82a1

5-4.81a9

Windows 2000 SP2 HP StorageWorks 32-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 380574-001 3.20x7 5-4.52a9

Windows 2000

(ProLiant only) SP2 HP StorageWorks 64-bit/66 MHz PCI-to-

Fibre Channel Host Bus Adapter 120186-B21

No Firmware 5.4.6.63

Windows NT v4.0 SP6a HP StorageWorks 2 Gb, 64-bit/66 MHz

PCI-to-Fibre Channel Host Adapter for

Windows/NT, Windows 2000 (msa1000

only)

245299-B21 3.82a1 4-4.81a9

Windows NT v4.0 SP6a HP StorageWorks 64-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 176479-B21 3.82a1

4-4.81a9

Windows NT v4.0 SP6a HP StorageWorks 32-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 380574-001 3.20x7 4-4.52a9

Windows NT

(ProLiant only) v4.0 SP6a HP StorageWorks 64-bit/66 MHz PCI-to-

Fibre Channel Host Bus Adapter 120186-B21 No Firmware 4.19.0.63

Windows 2000

for Datacenter v2.0 HP StorageWorks 64-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 176479-B21 3.81a1 5-4.52a9

Tru64 UNIX v5.1, v5.1A HP StorageWorks 2 Gb, 64-bit/66 MHz

PCI-to-Fibre Channel Host Adapter for

Tru64 UNIX and OpenVMS (HSG80 only)

261329-B21 3.81A4 1.32A

Tru64 UNIX v4.0F, v4.0G, v5.0a,

v5.1, v5.1a HP StorageWorks 64-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter for Tru64 168794-B21 3.81a4

1.29

Tru64 UNIX v4.0F, v4.0G, v5.0a,

v5.1, v5.1a HP StorageWorks 32-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 380574-001 3.20x7 1.29

Solaris v2.6, v7 or v8

(See Note 1) HP StorageWorks 32-bit PCI-to-Fibre

Channel Host Bus Adapter for Solaris 380576-001 3.03 2.5.9

Solaris v2.6, v7 or v8

(See Note 1) HP StorageWorks 64-bit SBus-to-Fibre

Channel Host Bus Adapter for Solaris 123503-001 13.3.7 2.5.9

OpenVMS v7.3, 7.3-1 HP StorageWorks 2 Gb, 64-bit/66 MHz

PCI-to-Fibre Channel Host Adapter for

Tru64 UNIX and OpenVMS (HSG80 only)

261329-B21 3.81A4 Embedded in OS

OpenVMS v7.3, 7.3-1 HP StorageWorks 64-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 168794-B21 3.81a4 Embedded in OS

OpenVMS v7.3, 7.3-1 HP StorageWorks 33-bit/33 MHz PCI-to-

Fibre Channel Host Bus Adapter 380574-001 3.20x7 Embedded in OS

HP-UX v11.0 HP StorageWorks 64-bit/66 MHz PCI-to-

Fibre Channel Host Bus Adapter for HP-UX 216409-B21 1.4 2.5.8

AIX v4.3.2, v4.3.3 HP StorageWorks 64-bit/66 MHz PCI-to-

Fibre Channel Host Bus Adapter for AIX 197819-B21 2.01.19 1.5.14.14, 1.5.15.1

NetWare v4.2, v5.1, v6.0 HP StorageWorks 64-bit/66 MHz PCI-to-

Fibre Channel Host Bus Adapter 120186-B21 No Firmware CPQFC.HA

M 2.52

Note 1:

The following patches need to be installed for the Solaris operating system:

Solaris v2.6: 105181-23, 105210-33, 105284-37, 105568-21, 105591-09, 105633-49, 105669-10, 106040-15, 106125-10, 106841-01, 106842-09,

107733-09, 108091-03.

Solaris v7: 106980-10, 107636-03, 106541-11, 107544-03, 109104-01, 106950-09, 106327-08, 106300-09, 107081-20.

Solaris v8: 108940-07.

The order of patch installation is dictated by the patch dependencies as documented by Sun Microsystems for each patch. Patches can be

obtained from http://access1.sun.com. However, patch 109104 −* is no longer available from access1. This is because Sun has rolled the

functionality of 109104 into the latest kernel patch (106541-16). If a patch is not found or not up to the latest revision, a warning message is

displayed. In the case of the 109104 patch, the warning message can be safely ignored if 106541-16 or greater is installed.

QuickSpecs hp SANworks Network View v2.0B

DA-10852 North America — Version 9 — August 1, 2002 5

HARDWARE PREREQUISITES

• Management Appliance

DISTRIBUTION MEDIA

This product is distributed on an individual product CD-ROM.

DOCUMENTATION

The Network View documentation consists of the following:

• Installation Guide

• Releases Notes

• Quickspecs

• User’s Guide

• Online Help

SOFTWARE LICENSING

The Network View is licensed by the number of available Fibre Channel switch ports in the SAN being managed by the Network View product. The

licenses are sold in increments of 64, 128, 256, and 512 Fibre Channel switch ports. Licenses are additive allowing license combinations that more

closely match the number of available Fibre Channel switch ports in the SAN. Switch port amount can be applied to numerous fabrics.

Upgrade licenses are for version 1.0 to version 2.0A upgrades only and cannot be used for switch port upgrades.

Switch port licenses are additive.

This software is furnished only under a license. For more information about HP licensing terms and policies, contact your local HP office.

SOFTWARE PRODUCT SERVICES

• Software Support (Stand-alone software advisory and remedial software telephone support)

• Software product subscription (New version license rights, and Media and documentation distribution service)

• Installation services

These software product services are sold under HP CarePaq Services program and via customized service contracts.

• CarePaq for software provides telephone support and License Right to new license version to provide all updates.

• CarePaq for software is available for sale at any time and, as opposed to hardware CarePaq’s, the commencement date will be the purchase date.

Proof of purchase may be required.

• CarePaq services are prepaid services for easy budgeting.

For additional information on Software Product Services and CarePaq, as well as orderable part numbers, please refer to the URL listed below:

Software Product Services.

For additional CarePaq (hardware & software and installation support) information for European and other countries, as well as orderable part numbers,

please refer to the URL listed below and select the country of your choice CarePaqs.

If you have specific questions about availability or how to obtain services contact your local HP representative. Contact information for your local area

can be found at Support.

Maintenance releases, bug fixes and software patches will be available at no charge to customers on the HP support website at SANworks Support.

SOFTWARE WARRANTY

HP warrants that the Software will perform substantially as described in the documentation accompanying the Software for a period of ninety (90) days

from delivery.

An upgrade to the 90 days software conformance to warranty of Network View to (1 or 3) full year of 9 hours by 5 days (or 24x7) software advisory and

remedial software telephone support, new version license rights, and media and documentation distribution service is available as CarePaq service.

QuickSpecs hp SANworks Network View v2.0B

DA-10852 North America — Version 9 — August 1, 2002 6

ORDER INFORMATION

Part Numbers Description

235904-B24 Network View v2.0B, 64 Switch Port License, Media, and Documentation

235905-B24 Network View v2.0B, 128 Switch Port License, Media, and Documentation

236073-B24 Network View v2.0B, 256 Switch Port License, Media, and Documentation

236074-B24 Network View v2.0B, 512 Switch Port License, Media, and Documentation

261761-B23 Network View Upgrade License v2.0B, 64 Switch Port, Media, and Documentation

261762-B23 Network View Upgrade License v2.0B, 128 Switch Port, Media, and Documentation

261763-B23 Network View Upgrade License v2.0B, 256 Switch Port, Media, and Documentation

261764-B23 Network View Upgrade License v2.0B, 512 Switch Port, Media, and Documentation

265665-B22 SAN Management Bundle

283051-B21 Non-Disruptive HSG80

283052-B21 Enterprise Disaster Tolerant

PHYSICAL DATA

The shipping dimensions are the same for all part numbers.

Shipping Dimensions

Height 9.25 in/23.5 cm

Width 8.25 in/20.96 cm

Depth 1.25 in/3.18 cm

Weight 3 lb/1.36 kg

© 2002 Compaq Information Technologies Group, LP.

Compaq, the Compaq logo, CarePaq, OpenVMS, SANworks, StorageWorks and Tru64 are trademarks of Compaq Information Technologies Group, L.P. in

the U.S. and/or other countries. Windows NT is a registered trademark or trademark of Microsoft Corporation in the U.S. and/or other countries. Intel is a

registered trademark or trademarks of Intel Corporation in the U.S. and/or other countries. UNIX is a registered trademark or trademark of The Open Group in

the U.S. and/or other countries. NetWare is a registered trademark or trademark of Novell Inc., in the U.S. and/or other countries. Sun and Solaris are

registered trademarks or trademarks of Sun Microsystems Inc. in the U.S. and other countries. All other product names mentioned herein may be trademarks

of their respective companies.

Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided “as is” without warranty of any kind and

is subject to change without notice. The warranties for Compaq products are set forth in the express limited warranty statements accompanying such

products. Nothing herein should be construed as constituting an additional warranty.
