Contents
HP ENVY 110 e-All-in-One D411 series Help
Get to know the HP ENVY 110 series
- Printer parts
- Control panel features
How do I?
Print
Copy and scan
Use Web Services
Send and receive faxes with eFax
Work with cartridges
Connectivity
- Add the HP ENVY 110 series to a network
- Tips for setting up and using a networked printer
Solve a problem
Technical information
Index

HP ENVY 110 e-All-in-One D411

series

Contents

1 HP ENVY 110 e-All-in-One D411 series Help...................................................................................................................3

2 Get to know the HP ENVY 110 series

Printer parts..........................................................................................................................................................................5

Control panel features..........................................................................................................................................................6

3 How do I?............................................................................................................................................................................9

4Print

Print photos........................................................................................................................................................................11

Print documents.................................................................................................................................................................12

Print labels and envelopes.................................................................................................................................................13

Select Print Media..............................................................................................................................................................14

Load media.........................................................................................................................................................................14

Recommended papers for photo printing ..........................................................................................................................15

Recommended papers for printing and copying.................................................................................................................16

Tips for print success..........................................................................................................................................................16

5 Copy and scan

Copy text or mixed documents...........................................................................................................................................19

Scan to a computer, USB drive, or memory card...............................................................................................................21

Tips for copy and scan success.........................................................................................................................................22

6 Use Web Services

Print from anywhere with HP ePrint...................................................................................................................................23

Print Apps...........................................................................................................................................................................24

Visit the HP ePrintCenter website......................................................................................................................................24

7 Send and receive faxes with eFax

Set up the printer for faxing (required)...............................................................................................................................25

Send a fax..........................................................................................................................................................................26

Receive a fax......................................................................................................................................................................26

Fax Settings........................................................................................................................................................................26

Fax Issues and Questions..................................................................................................................................................26

8 Work with cartridges

Check the estimated ink levels...........................................................................................................................................27

Replace the cartridges.......................................................................................................................................................27

Order ink supplies..............................................................................................................................................................29

Clean cartridges.................................................................................................................................................................29

Clean for back of page ink smearing..................................................................................................................................29

Clean paper feed................................................................................................................................................................29

Cartridge warranty information...........................................................................................................................................30

Tips for working with ink.....................................................................................................................................................30

9 Connectivity

Add the HP ENVY 110 series to a network........................................................................................................................31

Tips for setting up and using a networked printer..............................................................................................................33

10 Solve a problem

Get more help.....................................................................................................................................................................35

Unable to print....................................................................................................................................................................35

Resolve print quality issues................................................................................................................................................37

Resolve copy and scan issues...........................................................................................................................................37

Clear a paper jam...............................................................................................................................................................37

Troubleshooting print carriage jams...................................................................................................................................38

HP support..........................................................................................................................................................................39

Contents

11 Technical information

Notice.................................................................................................................................................................................41

Specifications.....................................................................................................................................................................41

Environmental product stewardship program.....................................................................................................................44

Regulatory notices..............................................................................................................................................................49

Regulatory wireless statements.........................................................................................................................................52

Index........................................................................................................................................................................................55

Contents

1 HP ENVY 110 e-All-in-One D411 series

Help

For information about the HP ENVY 110 series, see:

• Get to know the HP ENVY 110 series on page 5

• How do I? on page 9

• Print on page 11

• Copy and scan on page 19

• Use Web Services on page 23

• Work with cartridges on page 27

• Connectivity on page 31

• Solve a problem on page 35

• Technical information on page 41

• HP support on page 39

HP ENVY 110 e-All-in-One D411 series Help 3

HP ENVY 110 e-All-in-One D411

series Help

Chapter 1

4 HP ENVY 110 e-All-in-One D411 series Help

HP ENVY 110 e-All-in-One D411

series Help

2 Get to know the HP ENVY 110 series

•Printer parts

•Control panel features

Printer parts

•Front view of the printer

Get to know the HP ENVY 110 series 5

Get to know the HP ENVY 110

series

1Lid

2Lid backing

3Glass

4 Access door (closed)

5 On button. Touch once to turn on or turn off your printer. When the printer is off, a small amount of power is still

used. To completely remove power, turn off the printer, then unplug the power cord.

6 Paper tray (closed)

7 Wireless LED

8 Output tray extender. Comes out automatically when printing or copying, then stows automatically.

9 Color graphics display (also referred to as the display)

10 USB flash drive slot

11 Memory card slots

12 Printer access door (open)

13 Paper path cover

14 Squeeze buttons for removing paper path cover

15 Paper-width guides

16 Paper tray (out)

17 Print cartridge carriage

18 Print cartridges (installed)

19 Port for connecting with a USB cable to a computer, instead of wireless connection. Some features are available

only with a wireless network connection.

20 Power connection. Use only the power cord supplied by HP.

Control panel features

The touch screen display shows menus, photos, and messages. You can touch and drag your finger horizontally

to scroll through photos and vertically through list menus.

NOTE: eFax may not be available in all countries/regions.

Chapter 2

6 Get to know the HP ENVY 110 series

Get to know the HP ENVY 110

series

1Home: Returns to the Home screen, the screen that is displayed when you first turn on the printer.

2Get More: If Web Services are enabled, takes you to the Internet for downloading more Apps.

3Back: Returns to the previous screen on the display.

4Photo: Opens the Photo menu. From there, you can view and print photos, connect to Snapfish, reprint a printed photo,

or save photos to a USB flash drive or a memory card.

5Copy: Opens the Copy menu where you can preview your copy, edit for size and darkness, select black or color, and

select the number of copies. You can also change settings to make 2-sided copies, or select size, quality, and paper

type.

6Scan: Opens the Scan menu, where you can select a destination for your scan.

7eFax: Opens the eFax internet fax service. Send and receive faxes without fax hardware or a phone line. Internet

connection and Web Services required.

8Cancel: Stops the current operation.

9Apps: Provide quick and easy access to pages to print from the Web, such as maps, coupons, coloring pages, puzzles,

and more.

10 Help: Shows information on the display to assist in the current operation.

11 Setup: Opens the Setup menu with a list of other menus from which you can change product settings and perform

maintenance functions. Setup menus include Network, Web, Tools, and Preferences.

12 Ink Status: Opens the Ink Status dashboard, showing estimated ink levels by cartridge.

13 Apps Manager: Opens the Apps Manager where you can manage settings or remove Apps.

14 Wireless: Opens the Wireless Menu with options for setting up a wireless connection, testing the connection, and

turning wireless on and off.

15 Web Services: Opens the Web Services menu with options for enabling or turning off Web Services and ePrint,

checking for product updates, and configuring other web settings.

Control panel features 7

Get to know the HP ENVY 110

series

Chapter 2

8 Get to know the HP ENVY 110 series

Get to know the HP ENVY 110

series

3 How do I?

This section contains links to commonly performed tasks, such as printing photos, scanning, and making copies.

•

Load media on page 14

•

Clear a paper jam on page 37

•

Replace the cartridges on page 27

•

Copy text or mixed documents on page 19

•

Print Apps on page 24

•

Scan to a computer, USB drive, or memory card

on page 21

•

Print from anywhere with HP ePrint on page 23

•

Get more help on page 35

•

Send and receive faxes with eFax on page 25

How do I? 9

How do I?

Chapter 3

10 How do I?

How do I?

4Print

Print documents on page 12

Print photos on page 11

Print labels and envelopes on page 13

Print from anywhere with HP ePrint on page 23

Print Apps on page 24

Related topics

• Load media on page 14

Tips for print success on page 16

Print photos

•Print photos from a memory card

•Print photos saved on your computer

Print photos from a memory card

1. Load photo paper into the paper tray.

2. Insert a memory card into the slot.

3. On the Home screen, touch Photo to display the Photo Menu.

4. On the Photo Menu, touch View & Print to display the Photo Menu.

5. Touch Select All if you wish to print all the photos on the memory card. Or, touch and drag your finger to

scroll through the photos. Tap those you wish to select.

6. Touch the up and down arrow to display the number of photos to print.

7. Touch Edit to select options to edit the selected photos. You can rotate a photo, crop, turn Photo Fix on and

off, adjust brightness, or choose a color effect.

Print 11

8. Touch Print to preview the selected photos for printing. Touch Settings to adjust layout, paper type, red eye

removal, auto align, or date stamp. You can save any new settings as defaults. Touch Settings again to

close menus without making any selections.

9. Touch Print to begin printing. The control panel will rise and the output tray extender will automatically come

out. After you remove your prints, the extender will automatically stow out of view.

Print photos saved on your computer

Most print settings are automatically handled by the software application. You need to change the settings

manually only when you change print quality, print on specific types of paper or transparency film, or use special

features.

To print a photo on photo paper

1. Make sure the output tray is open.

2. Remove all paper from the input tray, and then load the photo paper with side to be printed on facing down.

NOTE: If the photo paper you are using has perforated tabs, load photo paper so that tabs are on top.

See Load media on page 14 for more information.

3. On the File menu in your software application, click Print.

4. Make sure the product is the selected printer.

5. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup,

Printer, or Preferences.

6. Select the appropriate options.

•On Layout tab select Portrait or Landscape orientation.

•On Paper/Quality tab select the appropriate paper size and paper type from the Paper Size and Media

drop-down lists.

• Click Advanced to select the appropriate output quality from the Printer Features list.

NOTE: For maximum dpi resolution, use Print Quality settings to select Photo Paper and Best Quality.

Make sure you are printing in color. Then select the Advanced tab and select Yes in the Enable

Maximum dpi setting.

7. Click OK to return to the Properties dialog box.

8. Click OK, and then click Print or OK in the Print dialog box.

NOTE: Do not leave unused photo paper in the input tray. The paper might start to curl, which could reduce

the quality of your printout. Photo paper should be flat before printing.

Print documents

Most print settings are automatically handled by the software application. You need to change the settings

manually only when you change print quality, print on specific types of paper or transparency film, or use special

features.

Chapter 4

12 Print

To print from a software application

1. Make sure the output tray is open.

2. Make sure you have paper loaded in the input tray.

See Load media on page 14 for more information.

3. From your software application, click the Print button.

4. Make sure the product is the selected printer.

5. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup,

Printer, or Preferences.

6. Select the appropriate options.

•On Layout tab select Portrait or Landscape orientation.

•On Paper/Quality tab select the appropriate paper size and paper type from the Paper Size and Media

drop-down lists.

• Click Advanced to select the appropriate output quality from the Printer Features list.

7. Click OK to close the Properties dialog box.

8. Click Print or OK to begin printing.

Related topics

• Load media on page 14

Tips for print success on page 16

Print labels and envelopes

With the HP ENVY 110 series, you can print on a single envelope, a group of envelopes, or label sheets

designed for inkjet printers.

To print a group of addresses on labels or envelopes

1. Print a test page on plain paper first.

2. Place the test page on top of the label sheet or envelope, and hold both up to the light. Check the spacing for

each block of text. Make adjustments as needed.

3. Load the labels or envelopes into the paper tray.

CAUTION: Do not use envelopes with clasps or windows. They can get stuck in the rollers and cause

paper jams.

4. Slide paper-width guides inward against the stack of labels or envelopes until the guides stop.

5. Select the appropriate options.

•On Paper/Quality tab select a Plain paper type.

• Click the Advanced button, and select the appropriate envelope size from the Paper Size drop down

menu.

6. Click OK, and then click Print or OK in the Print dialog box.

Print labels and envelopes 13

Select Print Media

The HP ENVY 110 series printer is designed to work well with most types of office media. Use HP media for

optimum print quality. Visit the HP Web site at www.hp.com for more information about HP media.

HP recommends plain papers with the ColorLok logo for printing and copying of everyday documents. All papers

with the ColorLok logo are independently tested to meet high standards of reliability and print quality, and

produce documents with crisp, vivid color, bolder blacks and dry faster than ordinary plain papers. Look for

papers with the ColorLok logo in a variety of weights and sizes from major paper manufacturers.

To purchase HP papers, go to Shop for Products and Services and select ink, toner and paper.

Load media

Do one of the following

•Load A4 or 8 1/2 x 11 inch paper

◦Pull out paper tray.

Slide paper-width guides outward. Remove any other media previously loaded.

Insert stack of paper into center of paper tray with short edge forward and print side down. Push stack

forward inside tray until it stops.

Slide paper-width guides inward until they stop at edge of paper.

Close paper tray.

•Load 10 x 15 cm (4 x 6 inch) paper

◦Pull out paper tray.

Slide paper-width guides outward. Remove any other media previously loaded.

Insert stack of paper into center of paper tray with short edge forward and print side down. Push stack

forward inside tray until it stops.

Slide paper-width guides inward until they stop at edge of paper.

Chapter 4

14 Print

Close paper tray.

•Load envelopes

◦Pull out paper tray.

Slide paper-width guides outward. Remove any other media previously loaded.

Insert stack of envelopes into center of paper tray with short edge forward and print side down. Push

stack forward inside tray until it stops.

Slide paper-width guides inward until they stop at edge of paper.

Close paper tray.

Related topics

• Tips for print success on page 16

Related topics

• Your printer is protected on page 23

How to get started with ePrint on page 23

Visit the HP ePrintCenter website on page 24

Your printer is protected

To help prevent unauthorized email, HP assigns a random email address to your printer, never publicizes this

address, and by default does not respond to any sender. ePrint also provides industry-standard spam filtering

and transforms email and attachments to a print-only format to reduce the trheat of a a virus or other harmful

content. However, the ePrint service does not filter emails based on content, so it cannot prevent objectionable or

copyrighted material from being printed.

Go to the HP ePrintCenter website for more information and specific terms and conditions: www.hp.com/go/

ePrintCenter.

How to get started with ePrint

To use ePrint, you first need to have your printer connected wirelessly to a network and Web Services enabled.

You will also need to create an ePrintCenter account if you do not already have one.

Use Web Services 23

Use Web Services

To get started with ePrint

1. Turn on wireless connection

a. Touch the Wireless icon to display the Wireless status dashboard. If a wireless connection has already

been set up, details like SSID and IP will be shown.

b. If the wireless network connection has not already been made, touch Settings, then run the Wireless

Setup Wizard.

If wireless network connection details like SSID and IP are displayed but the connection is off, touch

Settings, then touch Wireless Connection and On to turn on the wireless connection.

2. Enable Web Services

a. Touch Web Services to display the Web Services status dashboard.

Touch Settings to display the Web menu.

b. If Web Services is not already on, touch Web Services, then touch On to turn on Web Services.

Touch Accept to accept terms of use and connect to the Web Services Server.

3. Enable ePrint

a. Touch Web Services to display the Web Services status dashboard.

b. Touch Settings to display the Web menu.

c. If ePrint is not already on, touch ePrint, then touch On to turn on ePrint.

Print Apps

Print pages from the web without using a computer with Apps, a free service from HP. You can print coloring

pages, calendars, puzzles, recipes, maps, and more, depending on the apps available in your courntry/region.

You need to have web services enabled to use Apps.

NOTE: Apps are offered on an availability basis to HP ENVY 110 e-All-in-One D411 series owners. HP and

its third-party content providers may, from time to time, make additional apps available, enhance, modify and

eliminate existing apps in accordance with our Terms of Use (www.hp.com/go/ePrintCenter).

Go to the HP ePrintCenter website for more information and specific terms and conditions: www.hp.com/go/

ePrintCenter.

Use Apps

1. Select print apps from the Apps Favorites bar on the home screen.

2. Touch Get More on the Home screen to connect to the Internet and add apps.

3. Touch the Apps Manager icon on the Home screen to work with your My Favorites list, remove apps, and

manage settings.

Manage Apps

1. Remove Apps.

▲Touch the Apps Manager icon in the top-center of the Home screen to open the Apps Manager menu.

2. Manage Apps Settings.

a. Touch My App Settings .

b. Touch Postal Code and follow the prompts to set the postal code to use with your Apps.

▲Touch Time Zone and follow the prompts to set the time zone to use with your Apps.

Visit the HP ePrintCenter website

Use HP’s free ePrintCenter website to set up increased security for ePrint and specify the email addresses that

are allowed to send email to your printer. You can also get Product Updates, more Print Apps, and other free

services.

Go to the HP ePrintCenter website for more information and specific terms and conditions: www.hp.com/go/

ePrintCenter.

Chapter 6

24 Use Web Services

Use Web Services

7 Send and receive faxes with eFax

The HP ENVY 110 e-All-in-One D411 series printer faxes without a phone line. The printer sends and receives

faxes using eFax®, a web-based faxing service. This service is free when you send up to 20 pages and receive

up to 20 pages per month.

If you want to send or receive more pages per month, you can upgrade to the eFax Plus® service, and your

account is charged a monthly fee.

When you use eFax®, your document is scanned by the printer, sent wirelessly to the eFax® server, and then on

to the receiving fax number.

To use the eFax® brand service, the printer must have an Internet connection and Web Services must be

enabled so the printer can communicate with eFax's® server.

Before you can use eFax® with your printer, you must perform the simple setup procedures described below.

This one-time setup allows the printer to communicate with eFax's® server using your eFax® account information

whenever you send and receive faxes.

Click here for more information about eFax®.

NOTE: eFax may not be available in all countries/regions.

Set up the printer for faxing (required)

1. Touch eFax on the printer Home screen to display the eFax® home screen.

2. Touch Register, then touch the Web Services checkbox to enable Web Services.

3. Create an account by following the onscreen instructions.

4. Touch Terms and Conditions to read the eFax® brand services agreement, then touch the I agree

checkbox and click OK.

5. After connecting with the eFax® server, you are assigned the eFax® number that appears on the screen.

6. Touch Continue, and the eFax® home screen displays your eFax® number and a number entry keypad for

sending faxes.

NOTE: Although the area code may not be local to you, you do not incur any long-distance charges

when sending and receiving faxes with this number.

Set up your printer with an existing eFax® number

1. Touch eFax on the printer Home screen to display the eFax® home screen. Enter your existing eFax®

number in the area indicated below Already have an eFax® number?

2. Enter the personal identification number (PIN) code for this account.

NOTE: If you’ve forgotten your PIN, touch the indicated area to have it sent to the email address

associated with your eFax® number.

3. Touch Enable to continue. Your eFax® number and PIN code is sent to eFax® for verification. After they are

verified, your existing eFax® number is displayed on the eFax® home screen and you are ready for faxing.

NOTE: If eFax® cannot verify the eFax® number and PIN you entered, log in to your eFax brand

account at www.efax.com and review your account information. You cannot fax using this number until the

eFax® account information is verified on the printer.

4. After connecting with the eFax® server, you are assigned the eFax® number that appears on the screen.

5. Touch OK, and the eFax® home screen displays your eFax® number and a number entry keypad for sending

faxes.

Send and receive faxes with eFax 25

Send and receive faxes with eFax

Send a fax

Send a Fax

1. Touch eFax on the printer Home screen to display the eFax® home screen.

2. Lift the printer’s lid and place the first page of your original document print side down on the scanner glass,

aligning it with the right front corner.

3. If you are sending the fax inside your own country, proceed to the next step. If you are sending the fax

outside of your country, touch this option on the screen. This ensures that the appropriate international dialing

codes are used.

4. Enter the fax number on the keypad and touch Start. Your document is scanned. When scanning is

complete, you are asked if you have more pages to fax.

5. If you have more pages to fax, touch Yes, remove your first original from the scanner glass and replace it with

the next one.

If you do not have more pages to fax, touch No. Your fax is sent. Once it has been successfully sent to

eFax's® server, you are notified with a message. Touch OK to acknowledge the message and continue.

To cancel your fax, touch Back.

Print a confirmation report of faxes you have sent

1. Touch Sent Faxes on the bottom of the screen.

2. Touch the checkbox next to the fax(es) you want included in the report.

3. Touch Print Confirmation.

Receive a fax

Provide your eFax® number to anyone who needs to send you a fax.

When a fax is received, it is printed automatically.

Fax Settings

Touch Settings at the bottom of the eFax® home screen to display the Fax Settings.

Fax Issues and Questions

•For questions and answers about the eFax® brand service, touch Settings/FAQs on the eFax® home screen

•For other information about the eFax® brand service go to www.efax.com.

•eFax® is a registered trademark of j2 Global Communications, Inc. in the U.S. and internationally.

Chapter 7

26 Send and receive faxes with eFax

Send and receive faxes with eFax

8 Work with cartridges

•Check the estimated ink levels

•Replace the cartridges

•Order ink supplies

•Clean cartridges

•Clean for back of page ink smearing

•Clean paper feed

•Cartridge warranty information

•Tips for working with ink

Check the estimated ink levels

Touch the Ink Status icon at the top of the Home screen to display the estimated ink levels.

NOTE: 1 If you have installed a refilled or remanufactured cartridge, or a cartridge that has been used in

another printer, the ink level indicator might be inaccurate or unavailable.

NOTE: 2 Ink level warnings and indicators provide estimates for planning purposes only. When you receive

a low-ink warning message, consider having a replacement cartridge available to avoid possible printing

delays. You do not have to replace the cartridges until the print quality is unacceptable.

NOTE: 3 Ink from the cartridges is used in the printing process in a number of different ways, including in the

initialization process, which prepares the product and cartridges for printing, and in printhead servicing, which

keeps print nozzles clear and ink flowing smoothly. In addition, some residual ink is left in the cartridge after it

is used. For more information, see www.hp.com/go/inkusage.

Related topics

• Order ink supplies on page 29

Tips for working with ink on page 30

Replace the cartridges

To replace the cartridges

1. Check that power is on.

2. Remove cartridge.

a. Open access door.

Wait for print carriage to move to center of product.

b. Lift up lid on print cartridge, then remove it from slot.

Work with cartridges 27

Work with cartridges

3. Insert new cartridge.

a. Remove cartridge from packaging.

b. Place new cartridge in slot at an angle under the opened lid.

c. Squeeze the lid closed as the cartridge slides into place.

d. Close access door.

Chapter 8

28 Work with cartridges

Work with cartridges

Related topics

• Order ink supplies on page 29

Tips for working with ink on page 30

Order ink supplies

To find out the correct number for replacement cartridges, open the printer access door and check the label.

Cartridge information and links to online shopping appear on ink alert messages. In addition, you can find

cartridge information and order online by visiting www.hp.com/buy/supplies.

NOTE: Ordering cartridges online is not supported in all countries/regions. If it is not supported in your

country/region, contact a local HP reseller for information about purchasing cartridges.

Clean cartridges

If print quality is unacceptable, and the problem is not low ink levels or non-HP ink, try cleaning the cartridges.

To clean the cartridges

1. From the Home screen, touch Settings to display the Setup menu.

2. In the Setup menu, touch Tools.

3. In the Tools Menu, touch Clean Cartridges.

4. If the print quality looks acceptable, touch Done. Otherwise, touch Second-level Clean to do a more

thorough cleaning.

Related topics

• Order ink supplies on page 29

Tips for working with ink on page 30

Clean for back of page ink smearing

If the backs of printouts show smeared ink, try cleaning areas of the printer where ink can build up. This process

takes several minutes to complete. Full-size paper needs to be loaded and will be moved automatically during the

cleaning. A blank page is ejected when the process is complete.

To clean for back of page smearing

1. From the Home screen, touch Settings to display the Setup menu.

2. In the Setup menu, touch Tools.

3. In the Tools menu, touch Back of Page Smear Cleaning.

4. Load full-size plain paper in the paper tray and touch OK.

Related topics

• Order ink supplies on page 29

Tips for working with ink on page 30

Clean paper feed

If false 'Out of paper' messages appears, or you have other paper feeding problems, try cleaning the paper feed.

The process takes several minutes to complete. You need to empty the paper tray before starting the cleaning.

To clean the paper feed

1. From the Home screen, touch Settings to display the Setup menu. In the Setup menu, touch Tools.

2. In the Tools menu, touch Paper Feed Cleaning.

3. Remove all the paper from the paper tray. Touch OK.

Clean paper feed 29

Work with cartridges

Related topics

• Order ink supplies on page 29

Tips for working with ink on page 30

Cartridge warranty information

The HP cartridge warranty is applicable when the product is used in its designated HP printing device. This

warranty does not cover HP ink products that have been refilled, remanufactured, refurbished, misused, or

tampered with.

During the warranty period the product is covered as long as the HP ink is not depleted and the end of warranty

date has not been reached. The end of warranty date, in YYYY/MM format, may be found on the product as

indicated:

For a copy of the HP Limited Warranty Statement, see the printed documentation that came with the product.

Tips for working with ink

Use the following tips to work with ink cartridges:

•To check the estimated ink levels, touch the Ink Status icon on the Home screen.

•Use the correct print cartridges for your printer. For a list of compatible cartridges, open the access door and

check the label.

•Insert the ink cartridges into the correct slots. Match the color and icon of each cartridge to the color and icon

for each slot. Make sure the cartridge lid is closed on each cartridge.

•Use genuine HP ink cartridges. Genuine HP ink cartridges are designed for and tested with HP printers to

help you produce great results, time after time.

•Consider getting replacement ink cartridges when you receive an ink alert message. This avoids possible

printing delays. You do not need to replace the ink cartridges until print quality becomes unacceptable.

Chapter 8

30 Work with cartridges

Work with cartridges

9 Connectivity

•Add the HP ENVY 110 series to a network

•Tips for setting up and using a networked printer

Add the HP ENVY 110 series to a network

•WiFi Protected Setup (WPS)

•Wireless with a router (infrastructure network)

•Install the software for a network connection

WiFi Protected Setup (WPS)

To connect the HP ENVY 110 series to a wireless network using WiFi Protected Setup (WPS), you will need the

following:

❑A wireless 802.11 network that includes a WPS-enabled wireless router or access point.

❑A desktop computer or laptop with either wireless networking support, or a network interface card (NIC). The

computer must be connected to the wireless network that you intend to install the HP ENVY 110 series on.

To connect the HP ENVY 110 series using WiFi Protected Setup (WPS)

▲Do one of the following:

Use Push Button (PBC) method

a. Select setup method.

❑Touch Setup.

❑Touch Network.

❑Touch WiFi Protected Setup.

❑Touch Push Button.

b. Set up wireless connection.

❑Touch Start.

❑Press and hold the button on WPS-enabled router or other networking device to activate WPS.

NOTE: The product begins a timer for approximately two minutes in which the corresponding

button on the networking device needs to be pressed.

❑Touch OK.

c. Install software.

Use PIN method

a. Select setup method.

❑Touch Setup.

❑Touch Network.

Connectivity 31

Connectivity

❑Touch WiFi Protected Setup.

❑Touch PIN.

b. Set up wireless connection.

❑Touch Start.

The device displays a PIN.

❑Enter PIN on WPS-enabled router or other networking device.

NOTE: The product begins a timer for approximately two minutes in which the PIN needs to be

entered on the networking device.

❑Touch OK.

c. Install software.

Wireless with a router (infrastructure network)

To connect the HP ENVY 110 series to an integrated wireless WLAN 802.11 network, you will need the following:

❑A wireless 802.11 network that includes a wireless router or access point.

❑A desktop computer or laptop with either wireless networking support, or a network interface card (NIC). The

computer must be connected to the wireless network that you intend to install the HP ENVY 110 series on.

❑Broadband Internet access (recommended) such as cable or DSL.

If you connect the HP ENVY 110 series on a wireless network that has Internet access, HP recommends that

you use a wireless router (access point or base station) that uses Dynamic Host Configuration Protocol

(DHCP).

❑Network name (SSID).

❑WEP key or WPA Passphrase (if needed).

To connect the printer with the Wireless Setup Wizard

1. Write down your network name (SSID) and WEP key or WPA passphrase.

2. Start Wireless Setup Wizard.

▲Touch Wireless Setup Wizard.

3. Connect to wireless network.

▲Select your network from the list of detected networks.

4. Follow prompts.

5. Install software.

Related topics

• Install the software for a network connection on page 32

Install the software for a network connection

Use this section to install the HP ENVY software on a computer connected to a network. Before you install the

software, make sure you have connected the HP ENVY 110 series to a network. If the HP ENVY 110 series has

not been connected to a network, follow the onscreen instructions during the software installation to connect the

product to the network.

NOTE: Installation time can vary depending on your operating system, the amount of available space, and

the processor speed of your computer.

To install the Windows HP ENVY Software on a networked computer

1. Quit all applications running on your computer.

2. Insert the installation CD that came with the product into the CD-ROM drive on your computer and follow the

onscreen instructions.

NOTE: If the HP ENVY 110 series is not connected to a network, run the Wireless Setup Wizard from

the Network menu on the HP ENVY 110 series.

Chapter 9

32 Connectivity

Connectivity

3. If a dialog box about firewalls appears, follow the instructions. If you see firewall pop-up messages, you must

always accept or allow the pop-up messages.

4. On the Connection Type screen, select an appropriate option, and then click Next.

The Searching screen appears as the Setup program searches for the product on the network.

5. On the Printer Found screen, verify that the printer description is correct.

If more than one printer is found on the network, the Printers Found screen appears. Select the product you

want to connect.

6. Follow the prompts to install the software.

When you have finished installing the software, the product is ready for use.

7. To test your network connection, go to your computer and print a self-test report to the product.

Tips for setting up and using a networked printer

Use the following tips to set up and use a networked printer:

•When setting up the wireless networked printer, make sure your wireless router or access point is powered

on. The printer searches for wireless routers, then lists the detected network names on the display.

•To verify the wireless connection, check the wireless icon at the top of the Home screen. If the icon is colored,

the wireless connection is on. Touch the icon to display the Wireless status dashboard. Touch Settings to

display the Network menu, with options for setting up a wireless connection or turning on the wireless

connection, if already set up.

•If your computer is connected to a Virtual Private Network (VPN), you need to disconnect from the VPN

before you can access any other device on your network., including the printer.

•Learn how to find your network security settings. Click here to go online for more information.

•Learn about the Network Diagnostic Utility and other troubleshooting tips. Click here to go online for more

information.

•Learn how to change from a USB to wireless connection. Click here to go online for more information.

•Learn how to work with your firewall and anti-virus programs during printer setup. Click here to go online for

more information.

Tips for setting up and using a networked printer 33

Connectivity

Chapter 9

34 Connectivity

Connectivity

10 Solve a problem

This section contains the following topics:

•Get more help

•Unable to print

•Resolve print quality issues

•Resolve copy and scan issues

•Clear a paper jam

•Troubleshooting print carriage jams

•HP support

Get more help

You can find more information and help about your HP ENVY 110 series by entering a keyword in the Search

field in the top left of the help viewer. Titles of related topics for both local and online topics will be listed.

Click here to go online for more information.

Unable to print

Make sure that the printer is turned on and that there is paper in the tray. If you are still unable to print, try the

following in order:

1. Check for error messages and resolve.

2. Turn printer off, then back on again.

3. Verify that the product is not paused or offline.

To verify that the product is not paused or offline

NOTE: HP provides a Printer Diagnostic Utility that can automatically fix this issue.

Click here to go online for more information. Otherwise, follow the steps below.

a. Depending upon your operating system, do one of the following:

•Windows 7: From the Windows Start menu, click Devices and Printers.

•Windows Vista: From the Windows Start menu, click Control Panel, and then click Printers.

•Windows XP: From the Windows Start menu, click Control Panel, and then click Printers and

Faxes.

b. Double-click the icon for your product to open the print queue.

c. On the Printer menu, make sure there are no check marks next to Pause Printing or Use Printer

Offline.

d. If you made any changes, try to print again.

4. Verify that the product is set as the default printer.

To verify that the product is set as the default printer

NOTE: HP provides a Printer Diagnostic Utility that can automatically fix this issue.

Click here to go online for more information. Otherwise, follow the steps below.

Solve a problem 35

Solve a problem

a. Depending upon your operating system, do one of the following:

•Windows 7: From the Windows Start menu, click Devices and Printers.

•Windows Vista: From the Windows Start menu, click Control Panel, and then click Printers.

•Windows XP: From the Windows Start menu, click Control Panel, and then click Printers and

Faxes.

b. Make sure the correct product is set as the default printer.

The default printer has a check mark in a black or green circle next to it.

c. If the wrong product is set as the default printer, right-click the correct product and select Set as Default

Printer.

d. Try using your product again.

5. Restart the print spooler.

To restart the print spooler

NOTE: HP provides a Printer Diagnostic Utility that can automatically fix this issue.

Click here to go online for more information. Otherwise, follow the steps below.

a. Depending upon your operating system, do one of the following:

Windows 7

• From the Windows Start menu, click Control Panel, System and Security, and then Administrative

Tools.

• Double-click Services.

• Right-click the Print Spooler, and then click Properties.

•On the General tab, next to Startup type, make sure that Automatic is selected.

• If the service is not already running, under Service status, click Start, and then click OK.

Windows Vista

• From the Windows Start menu, click Control Panel, System and Maintenance, Administrative

Tools.

• Double-click Services.

• Right-click the Print Spooler service, and then click Properties.

•On the General tab, next to Startup type, make sure that Automatic is selected.

• If the service is not already running, under Service status, click Start, and then click OK.

Windows XP

• From the Windows Start menu, right click My Computer.

• Click Manage, and then click Services and Applications.

• Double-click Services, and then select Print Spooler.

• Right-click Print Spooler, and click Restart to restart the service.

b. Make sure the correct product is set as the default printer.

The default printer has a check mark in a black or green circle next to it.

c. If the wrong product is set as the default printer, right-click the correct product and select Set as Default

Printer.

d. Try using your product again.

6. Restart the computer.

7. Clear the print queue.

To clear the print queue

NOTE: HP provides a Printer Diagnostic Utility that can automatically fix this issue.

Click here to go online for more information. Otherwise, follow the steps below.

Chapter 10

36 Solve a problem

Solve a problem

a. Depending upon your operating system, do one of the following:

•Windows 7: From the Windows Start menu, click Devices and Printers.

•Windows Vista: From the Windows Start menu, click Control Panel, and then click Printers.

•Windows XP: From the Windows Start menu, click Control Panel, and then click Printers and

Faxes.

b. Double-click the icon for your product to open the print queue.

c. On the Printer menu, click Cancel all documents or Purge Print Document, and then click Yes to

confirm.

d. If there are still documents in the queue, restart the computer and try printing again after the computer

has restarted.

e. Check the print queue again to make sure it is clear, and then try to print again.

If the above solutions do not resolve the problem, click here for more online troubleshooting.

Resolve print quality issues

Find the latest information and help for print quality problems with your HP ENVY 110 series, online:

Click here to go online for more information.

Resolve copy and scan issues

Find the latest information and help for copying and scanning problems with your HP ENVY 110 series, online:

•Learn how to troubleshoot copy failures. Click here to go online for more information.

•Learn how to troubleshoot scan failures. Click here to go online for more information.

Clear a paper jam

Clear a paper jam.

To clear a paper jam

1. Press the Cancel button on the control panel to try to clear the jam automatically. If this does not work, clear

the paper jam manually.

2. Locate the paper jam by lifting open the printer access door.

Clear jam from input/output area

• Gently pull the paper out. Close the access door.

Clear a paper jam 37

Solve a problem

Clear jam from paper path

• Squeeze together the two buttons on the paper path cover and remove the cover. Gently pull out the

jammed paper. Replace the paper path cover. Close the access door.

Clear jam from duplexer path

• Squeeze together the two buttons on the paper path cover and remove the cover. Gently pull out the

jammed paper. Replace the paper path cover. Close the access door.

3. Press OK on the control panel to continue the current job.

Click here to go online for more information.

Troubleshooting print carriage jams

The cartridge access door must be closed to begin printing. Check the printer and try printing again. If you are still

having a problem, an object may be blocking the print carriage and preventing it from moving.

If your printer is new, make sure you remove all of the packing material inside the carriage area. If your printer is

not new, check the carriage area for foreign objects that may have fallen into the printer, such as pet hair or

paper clips.

Try the following solutions to resolve the issue.

Solution 1: Make sure that the printer is turned on

1. Look at the Power button located on the printer. If it is not lit, the printer is turned off. Make sure the power

cord is firmly connected to the printer and plugged into a power outlet. Press the Power button to turn on the

printer.

2. Try using your printer again.

Solution 2: Unblock the print carriage

1. Make sure the printer is on.

CAUTION: Make sure the printer is on before disconnecting the power cord as described in step 2.

Failure to disconnect the power cord from the rear of the unit can cause damage when removing jammed

paper.

2. Disconnect the power cord from the back of the printer.

3. If you're using a USB connection, disconnect the USB cable from the back of the printer.

4. Open the cartridge access door.

Chapter 10

38 Solve a problem

Solve a problem

5. Remove any paper or object that might be restricting the print carriage. If the printer is new, remove any

packing material.

6. Reconnect only the power cord. If the printer does not turn on automatically, press the Power button.

NOTE: The printer might need to warm up for two minutes or less. Lights might flash, and the print

carriage might move during this time.

7. Use your hand to gently move the carriage all the way to the left and right to ensure the carriage moves

freely. If it does not move freely, paper or other objects may still be blocking the carriage movement. Continue

to clear the carriage area until the print carriage moves freely.

NOTE: Moving the print carriage will cause a Carriage Jam error to appear on the display. Press OK to

continue.

8. If you're using a USB connection, reconnect the USB cable.

9. Close the cartridge access door.

NOTE: You may have to press the Power button again to reset the printer.

10. Try using your printer again.

Click here to go online for more information.

HP support

•Register your printer

•HP support by phone

•Additional warranty options

By taking just a few quick minutes to register, you can enjoy quicker service, more efficient support, and product

support alerts. If you did not register your printer while installing the software, you can register now at http://

www.register.hp.com.

HP support by phone

Phone support options and availability vary by product, country/region, and language.

This section contains the following topics:

•Phone support period

•Placing a call

•After the phone support period

HP support 39

Solve a problem

Phone support period

One year of phone support is available in North America, Asia Pacific, and Latin America (including Mexico). To

determine the duration of phone support in Europe, the Middle East, and Africa, go to www.hp.com/support.

Standard phone company charges apply.

Placing a call

Call HP support while you are in front of the computer and the product. Be prepared to provide the following

information:

•Product name (HP ENVY 110 e-All-in-One D411 series)

•Serial number (located on the back or bottom of the product)

•Messages that appear when the situation occurs

•Answers to these questions:

◦Has this situation happened before?

◦Can you re-create it?

◦Did you add any new hardware or software to your computer at about the time that this situation began?

◦Did anything else occur prior to this situation (such as a thunderstorm, product was moved, etc.)?

For the most current HP list of telephone support numbers and call costs information, see www.hp.com/support.

After the phone support period

After the phone support period, help is available from HP at an additional cost. Help may also be available at the

HP online support Web site: www.hp.com/support. Contact your HP dealer or call the support phone number for

your country/region to learn more about support options.

Additional warranty options

Extended service plans are available for the HP ENVY 110 series at additional costs. Go to www.hp.com/support,

select your country/region and language, then explore the services and warranty area for information about the

extended service plans.

Chapter 10

40 Solve a problem

Solve a problem

11 Technical information

The technical specifications and international regulatory information for the HP ENVY 110 series are provided in

this section.

For additional specifications, see the printed documentation that came with the HP ENVY 110 series.

This section contains the following topics:

•Notice

•Specifications

•Environmental product stewardship program

•Regulatory notices

•Regulatory wireless statements

Notice

Specifications

Technical specifications for the HP ENVY 110 series are provided in this section. For complete product

specifications, see the Product Data Sheet at www.hp.com/support.

System requirements

Software and system requirements are located in the Readme file.

For information about future operating system releases and support, visit the HP online support Web site at

www.hp.com/support.

Environmental specifications

•Allowable operating temperature range: Main printer: 5 to 40 degrees C (41 to 104 degrees F) Removable

display: -10 to 40 degrees C (14 to 104 degrees F)

•Allowable operating temperature range: 5 ºC to 40 ºC (41 ºF to 104 ºF)

•Humidity: 15% to 80% RH non-condensing; 28 ºC maximum dewpoint

•Non-operating (Storage) temperature range: -20 to 60 degrees C (-4 to 140 degrees F)

•In the presence of high electromagnetic fields, it is possible the output from the HP ENVY 110 series may be

slightly distorted

•HP recommends using a USB cable less than or equal to 3 m (10 feet) in length to minimize injected noise

due to potential high electromagnetic fields

Technical information 41

Technical information

Print resolution

Draft mode

•Color Input/Black Render: 300x300dpi

•Output (Black/Color): Automatic

Normal mode

•Color Input/Black Render: 600x300dpi

•Output (Black/Color): Automatic

Plain-Best mode

•Color Input/Black Render: 600x600dpi

•Output: 600x1200dpi (Black), Automatic (Color)

Photo-Best mode

•Color Input/Black Render: 600x600dpi

•Output (Black/Color): Automatic

Max DPI mode (with supported types of HP photo paper)

•Color Input/Black Render: 1200x1200dpi

•Output: Automatic (Black), 4800x1200 optimized dpi (Color)

To learn more about the printer resolution, see the printer software.

Paper specifications

Type Paper weight Input tray

Output tray

†

Photo tray

Plain paper 16 to 24 lb. (60 to 90

gsm)

Up to 125 (20 lb. paper) 50 (20 lb. paper) n/a

Legal paper 16 to 24 lb. (60 to 90

gsm)

Up to 125 (20 lb. paper) 10 (20 lb. paper) n/a

Cards Up to 75 lb. (281 gsm) Up to 60 25 Up to 20

Envelopes 20 to 24 lb. (75 to 90

gsm)

Up to 15 15 n/a

Transparency film n/a Up to 40 25 n/a

Labels n/a Up to 40 25 n/a

5 x 7 inch (13 x 18 cm) Photo

paper

Up to 75 lb (281 gsm)

(236 gsm)

Up to 40 25 Up to 20

4 x 6 inch (10 x 15 cm) Photo

paper

Up to 75 lb. (281 gsm)

(236 gsm)

Up to 40 25 Up to 20

8.5 x 11 inch (216 x 279 mm)

Photo paper

Up to 75 lb. (281 gsm) Up to 40 25 n/a

* Maximum capacity.

† Output tray capacity is affected by the type of paper and the amount of ink you are using. HP recommends emptying the

output tray frequently. FAST DRAFT print quality mode requiresthe extender tray to be extended and the end tray rotated

up. Without the end tray rotated up, both letter and legal-sized paper will fall on the first sheet.

NOTE: For a complete list of supported media sizes, see the printer driver.

Two-sided printing accessory paper specifications - all regions except Japan

Type Size Weight

Paper Letter: 8.5 x 11 inches

Executive: 7.25 x 10.5 inches

16 to 24 lb. (60 to 90 gsm)

Chapter 11

42 Technical information

Technical information

Type Size Weight

A4: 210 x 297 mm

B5 (ISO): 176 x 250 mm B5 (JIS): 182 x

257 mm

Brochure paper Letter: 8.5 x 11 inches

A4: 210 x 297 mm

Up to 48 lb. (180 gsm)

Two-sided printing accessory paper specifications - Japan only

Type Size Weight

Paper Letter: 8.5 x 11 inches

Executive: 7.25 x 10.5 inches

A4: 210 x 297 mm

A5: 148 x 210 mm

B5 (ISO): 176 x 250 mm B5 (JIS): 182 x

257 mm

60 to 90 g/m

(16 to 24 lb.)

Brochure paper Letter: 8.5 x 11 inches

A4: 210 x 297 mm

Up to 180 g/m

(48 lb. bond)

Cards and photos 4 x 6 inches

5 x 8 inches

10 x 15 cm

A6: 105 x 148.5 mm

Hagaki: 100 x 148 mm

Up to 200 g/m

(110 lb. index)

Alignment skew

•.006 mm/mm on plain paper (2nd side)

NOTE: Media type availability varies by country/region.

Print specifications

•Print speeds vary according to the complexity of the document

•Panorama-size printing

•Method: drop-on-demand thermal inkjet

•Language: PCL3 GUI

Copy specifications

•Digital image processing

•Maximum number of copies varies by model

•Copy speeds vary according to the complexity of the document and model

•Maximum copy enlargement ranging from 200-400% (depends on model)

•Maximum copy reduction ranging from 25-50% (depends on model)

Ink cartridge yield

Visit www.hp.com/go/learnaboutsupplies for more information on estimated cartridge yields.

Scan specifications

•Image editor included

•Twain-compliant software interface

•Resolution: up to 1200 x 2400 ppi optical (depends on model); 19200 ppi enhanced (software)

For more information about ppi resolution, see the scanner software.

•Color: 48-bit color, 8-bit grayscale (256 levels of gray)

•Maximum scan size from glass: 21.6 x 29.7 cm (8.5 x 11.7 inches)

(continued)

Specifications 43

Technical information

Environmental product stewardship program

Hewlett-Packard is committed to providing quality products in an environmentally sound manner. Design for

recycling has been incorporated into this product. The number of materials has been kept to a minimum while

ensuring proper functionality and reliability. Dissimilar materials have been designed to separate easily.

Fasteners and other connections are easy to locate, access, and remove using common tools. High priority parts

have been designed to access quickly for efficient disassembly and repair.

For more information, visit HP’s Commitment to the Environment Web site at:

www.hp.com/hpinfo/globalcitizenship/environment/index.html

This section contains the following topics:

•Eco-Tips

•Paper use

•Plastics

•Material safety data sheets

•Recycling program

•HP inkjet supplies recycling program

•Power consumption

•Auto Power-Off

•Set the Energy Save Mode

•Disposal of waste equipment by users in private households in the European Union

•Chemical Substances

•Battery disposal in the Netherlands

•Battery disposal in Taiwan

•Attention California users

•EU battery directive

Eco-Tips

HP is committed to helping customers reduce their environmental footprint. HP has provided the Eco-Tips below

to help you focus on ways to assess and reduce the impact of your printing choices. In addition to specific

features in this product, please visit the HP Eco Solutions web site for more information on HP’s environmental

initiatives.

www.hp.com/hpinfo/globalcitizenship/environment/

Your product's Eco features

•Duplex printing: Use Paper-saving Printing to print two-sided documents with multiple pages on same

sheet to reduce paper usage.

•Smart Web printing: The HP Smart Web Printing interface includes a Clip Book and Edit Clips window

where you can store, organize, or print clips you have gathered from the Web.

•Energy Savings information: To determine the ENERGY STAR® qualification status for this product, see

Power consumption on page 45.

•Recycled Materials: For more information regarding recycling of HP products, please visit:

www.hp.com/hpinfo/globalcitizenship/environment/recycle/

Paper use

This product is suited for the use of recycled paper according to DIN 19309 and EN 12281:2002.

Plastics

Plastic parts over 25 grams are marked according to international standards that enhance the ability to identify

plastics for recycling purposes at the end of product life.

Material safety data sheets

Material safety data sheets (MSDS) can be obtained from the HP Web site at:

Chapter 11

44 Technical information

Technical information

www.hp.com/go/msds

Recycling program

HP offers an increasing number of product return and recycling programs in many countries/regions, and partners

with some of the largest electronic recycling centers throughout the world. HP conserves resources by reselling

some of its most popular products. For more information regarding recycling of HP products, please visit:

www.hp.com/hpinfo/globalcitizenship/environment/recycle/

HP inkjet supplies recycling program

HP is committed to protecting the environment. The HP Inkjet Supplies Recycling Program is available in many

countries/regions, and lets you recycle used print cartridges and ink cartridges free of charge. For more

information, go to the following Web site:

www.hp.com/hpinfo/globalcitizenship/environment/recycle/

Power consumption

Hewlett-Packard printing and imaging equipment marked with the ENERGY STAR® logo is qualified to the U.S.

Environmental Protection Agency’s ENERGY STAR specifications for imaging equipment. The following mark will

appear on ENERGY STAR qualified imaging products:

Additional ENERGY STAR qualified imaging product model information is listed at: www.hp.com/go/energystar

Auto Power-Off

Auto Power-Off is automatically enabled by default when you turn on the printer. When Auto Power-Off is

enabled, the printer will automatically turn off after two hours of inactivity to help reduce energy use. Auto Power-

Off is automatically disabled when the printer establishes a wireless connection with a network router or when

you enable alarms or calendar reminders. You can change the Auto Power-Off setting from the control panel.

Once you change the setting , the printer will maintain the setting that you choose. Auto Power-Off turns the

printer off completely, so you must use the power button to turn the printer back on.

To enable or disable Auto Power-Off

1. From the Home screen, touch Setup.

2. Touch Preferences.

3. Scroll through the options, and then touch Set Auto-off.

4. Touch On or Off.

5. Touch Yes to confirm your selection or No to keep your current setting.

TIP: If you are printing through a wireless connection over a network, Auto Power-Off should be disabled to

ensure that print jobs do not get lost. Even when Auto Power-Off is disabled, the user-adjustable Energy

Saver Mode helps reduce energy use.

Environmental product stewardship program 45

Technical information

Set the Energy Save Mode

The HP ENVY 110 series Energy Save Mode reduces energy use by entering a sleep mode after 5 minutes of

inactivity. The time to sleep mode can be extended to 10 or 15 minutes.

NOTE: This feature is on by default and cannot be turned off.

To set Energy Save Mode

1. Touch the Setup icon.

2. Touch Preferences.

3. Scroll through the options and touch Energy Save Mode.

4. Touch the desired time interval (5, 10 or 15 minutes).

Chapter 11

46 Technical information

Technical information

Disposal of waste equipment by users in private households in the European

Union

Environmental product stewardship program 47

Technical information

Chemical Substances

HP is committed to providing our customers with information about the chemical substances in our products as

needed to comply with legal requirements such as REACH (Regulation EC No 1907/2006 of the European

Parliament and the Council). A chemical information report for this product can be found at: www.hp.com/go/

reach.

Battery disposal in the Netherlands

Battery disposal in Taiwan

Attention California users

The battery supplied with this product may contain perchlorate material. Special handling may apply. For more

information, go to the following Web site:

www.dtsc.ca.gov/hazardouswaste/perchlorate

Chapter 11

48 Technical information

Technical information

EU battery directive

Regulatory notices

The HP ENVY 110 series meets product requirements from regulatory agencies in your country/region.

This section contains the following topics:

Regulatory notices 49

Technical information

•Regulatory model identification number

•FCC statement

•VCCI (Class B) compliance statement for users in Japan

•Notice to users in Japan about the power cord

•Notice to users in Korea

•Noise emission statement for Germany

•European Union Regulatory Notice

Regulatory model identification number

For regulatory identification purposes, your product is assigned a Regulatory Model Number. The Regulatory

Model Number for your product is SNPRH-1101. This regulatory number should not be confused with the

marketing name (HP ENVY 110 e-All-in-One D411 series, etc.) or product numbers (CN517, etc.).

FCC statement

Chapter 11

50 Technical information

Technical information

VCCI (Class B) compliance statement for users in Japan

Notice to users in Japan about the power cord

Notice to users in Korea

Noise emission statement for Germany

European Union Regulatory Notice

Products bearing the CE marking comply with the following EU Directives:

•Low Voltage Directive 2006/95/EC

•EMC Directive 2004/108/EC

•Ecodesign Directive 2009/125/EC, where applicable

CE compliance of this product is valid only if powered with the correct CE-marked AC adapter provided by HP.

If this product has telecommunications functionality, it also complies with the essential requirements of the

following EU Directive:

•R&TTE Directive 1999/5/EC

Compliance with these directives implies conformity to applicable harmonized European standards (European

Norms) that are listed in the EU Declaration of Conformity issued by HP for this product or product family and

available (in English only) either within the product documentation or at the following web site: www.hp.com/go/

certificates (type the product number in the search field).

The compliance is indicated by one of the following conformity markings placed on the product:

Regulatory notices 51

Technical information

For non-telecommunications products and for EU

harmonized telecommunications products, such

as Bluetooth® within power class below 10mW.

For EU non-harmonized telecommunications

products (If applicable, a 4-digit notified body

number is inserted between CE and !).

Please refer to the regulatory label provided on the product.

The telecommunications functionality of this product may be used in the following EU and EFTA countries:

Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece,

Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway,

Poland, Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland, and United Kingdom.

The telephone connector (not available for all products) is intended for connection to analogue telephone

networks.

Products with wireless LAN devices

•Some countries may have specific obligations or special requirements about the operation of Wireless LAN

networks such as indoor use only or restrictions of the channels available. Please make sure that the country

settings of the wireless network are correct.

France

•For 2.4-GHz Wireless LAN operation of this product, certain restrictions apply: This product may be used

indoors for the entire 2400-MHz to 2483.5-MHz frequency band (channels 1 to 13). For outdoor use, only the

2400-MHz to 2454-MHz frequency band (channels 1 to 7) may be used. For the latest requirements, see

www.arcep.fr.

The point of contact for regulatory matters is:

Hewlett-Packard GmbH, Dept./MS: HQ-TRE, Herrenberger Strasse 140, 71034 Boeblingen, GERMANY

Regulatory wireless statements

This section contains the following regulatory information pertaining to wireless products:

•Exposure to radio frequency radiation

•Notice to users in Brazil

•Notice to users in Canada

•Notice to users in Taiwan

•European Union Notice

Chapter 11

52 Technical information

Technical information

Exposure to radio frequency radiation

Notice to users in Brazil

Notice to users in Canada

Notice to users in Taiwan

Regulatory wireless statements 53

Technical information

European Union Notice

Chapter 11

54 Technical information

Technical information

Index

Symbols/Numerics

10 x 15 cm photo paper

specifications 42

after the support period 40

buttons, control panel 6

control panel

buttons 6

features 6

copy

specifications 43

customer support

warranty 40

envelopes

specifications 42

environment

Environmental product stewardship

program 44

environmental specifications 41

interface card 31, 32

labels

specifications 42

legal paper

specifications 42

letter paper

specifications 42

network

interface card 31, 32

paper

specifications 42

phone support 39

phone support period

period for support 40

photo paper

specifications 42

specifications 43

printer found screen, Windows 33

recycle

ink cartridges 45

regulatory notices

regulatory model identification

number 50

wireless statements 52

scan

scan specifications 43

security

network, WEP key 32

system requirements 41

technical information

copy specifications 43

environmental specifications 41

paper specifications 42

print specifications 43

scan specifications 43

system requirements 41

transparencies

specifications 42

warranty 40

Index

Hp Envy 110 E All In One Printer D411A Users Manual D411 Series

Hp-D411-Users-Manual-544974 hp-d411-users-manual-544974

D411 to the manual 2162275e-de83-41ae-b0ef-74f224a5ca88

Navigation menu

Versions of this User Manual:

Views

Navigation
