HP OpenVMS Version 8.4

Release Notes

June 2010

This manual describes changes to the software; installation, upgrade,

and compatibility information; new and existing software problems and

restrictions; and software and documentation corrections.

Revision/Update Information: This is a new manual.

Software Version: OpenVMS Version 8.4 for Integrity

servers

OpenVMS Alpha Version 8.4

Hewlett-Packard Company

Palo Alto, California

Conﬁdential computer software. Valid license from HP required for possession, use or copying.

Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software

Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government

under vendor’s standard commercial license.

The information contained herein is subject to change without notice. The only warranties for HP

products and services are set forth in the express warranty statements accompanying such products

and services. Nothing herein should be construed as constituting an additional warranty. HP shall

not be liable for technical or editorial errors or omissions contained herein.

Intel and Itanium are registered trademarks of Intel Corporation or its subsidiaries in the United

States and other countries.

Java is a US trademark of Sun Microsystems, Inc.

Oracle is a US registered trademark of Oracle Corporation, Redwood City, California.

OSF and Motif are trademarks of The Open Group in the US and other countries, and UNIX is a

registered trademark of The Open Group.

Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.

X/Open is a registered trademark, and the X device is a trademark of X/Open Company Ltd. in the

UK and other countries.

ZK6677

This document was prepared using DECdocument, Version 3.3-1b.

Contents

Preface ............................................................ xv

1 OpenVMS Software Installation and Upgrade Release Notes

1.1 HP Software Technical Support Policy ............................ 1–1

1.2 General Application Compatibility Statement ...................... 1–2

1.3 Obtaining Remedial Kits ...................................... 1–3

1.4 Networking Options . . ........................................ 1–3

1.5 Disk Incompatibility with Older Versions of OpenVMS ............... 1–3

1.6 HP DECwindows Motif for OpenVMS ............................ 1–4

1.7 OpenVMS Integrity server Users ................................ 1–4

1.7.1 Storage Controllers ....................................... 1–4

1.7.2 U160 SCSI Support for rx7620 and rx8620 ..................... 1–5

1.7.3 Clearing the System Event Log on Integrity servers ............. 1–5

1.7.4 Firmware for Integrity Servers .............................. 1–6

1.7.5 Booting from the Installation DVD ........................... 1–7

1.7.6 Booting from USB or vMedia Devices . . ....................... 1–8

1.7.7 HP DECwindows Motif Release Notes . ....................... 1–8

1.7.7.1 Keyboard Support ..................................... 1–8

1.8 OpenVMS Alpha Users ....................................... 1–8

1.8.1 Firmware for OpenVMS Alpha Version 8.4 ..................... 1–8

1.8.2 Upgrade Paths . . ........................................ 1–8

1.9 Kerberos for OpenVMS ....................................... 1–10

1.10 Modifying SYSTARTUP_VMS.COM ............................. 1–12

1.11 Encryption for OpenVMS ...................................... 1–12

1.12 Upgrading HP DECram V3.n.................................. 1–12

1.13 Converting the LANCP Device Database . . ....................... 1–13

1.14 DECnet-Plus Requires a New Version ............................ 1–13

1.15 Remove TIE Kit Before Upgrade ................................ 1–14

1.16 Installation Failure of Layered Products on Alternate Devices or

Directories ................................................ 1–14

2 OpenVMS Associated Products Release Notes

2.1 Associated Product Support .................................... 2–1

2.2 HP TCP/IP Services for OpenVMS ............................... 2–2

2.3 NetBeans Version 5.5.1 Requires Latest JDK ...................... 2–2

2.4 Problem Accessing DFS Mounted Disk ........................... 2–2

2.5 HP DCE for OpenVMS Restriction (Integrity servers Only) ............ 2–2

2.6 XML-C Product Zip File ....................................... 2–3

2.7 OpenVMS e-Business and Integration Infrastructure Package . . ....... 2–3

2.8 Updates to Freeware Readme File ............................... 2–3

2.9 CMAP Files Added . . ........................................ 2–4

iii

2.10 COBOL: Changes in I/O Run-Time Diagnostics and RMS Special

Registers .................................................. 2–4

2.11 COM for HP OpenVMS (Alpha Only) . ............................ 2–4

2.11.1 COM for OpenVMS Support ................................ 2–4

2.11.2 Registry Access Error with Heavy Load of Applications . ........... 2–4

2.12 DECdfs Version 2.4 Required for OpenVMS Version 8.3 . . . ........... 2–4

2.13 DECforms Web Connector Version 3.0 (Alpha Only) ................. 2–5

2.14 DEC PL/I: RTL Support for OpenVMS ............................ 2–5

2.15 FMS Kits ................................................. 2–5

2.16 Graphical Conﬁguration Manager (Alpha Only) . . ................... 2–6

2.17 HP DECram ................................................ 2–6

2.17.1 DECram Available with OpenVMS Version 8.2 and later ........... 2–6

2.17.2 Conﬂict with DECRYPT DCL Command ....................... 2–6

2.18 HP DECwindows Motif for OpenVMS ............................ 2–6

2.18.1 New Locales Added . . . .................................... 2–7

2.18.2 User-Written Transports not Supported ....................... 2–7

2.19 HP Secure Web Server Version Support ........................... 2–7

2.20 HP Pascal for OpenVMS Alpha Systems .......................... 2–7

2.20.1 HP Pascal: Version 5.8A (or later) Required to Create STARLET

Library (Alpha Only) . . .................................... 2–8

2.20.2 Installing HP Pascal After an Upgrade (Alpha Only) . . . ........... 2–8

2.21 WEBES and SEA Support on Integrity servers . . ................... 2–8

3 General User Release Notes

3.1 SYS$GETTIM_PREC System Service Declaration ................... 3–1

3.2 Problem With F$GETSYI("RAD_CPUS") .......................... 3–1

3.3 HP Code Signing Service for OpenVMS Support . ................... 3–1

3.4 Symbolic Links Implementation Changes ......................... 3–1

3.4.1 Logical Names ........................................... 3–1

3.4.2 Audit Alarms Fixed . . . .................................... 3–2

3.5 SHOW SYSTEM/STATE=MUTEX Does not Display the Processes . . . . . . 3–2

3.6 SWB V1.1-12 Installation Warnings . . ............................ 3–3

3.7 Ctrl/P at the Console Does not Always Work ....................... 3–3

3.8 Installing Oracle Database 10g Release 2 for OpenVMS Fails .......... 3–4

3.9 Serial Port Enumeration . . .................................... 3–4

3.10 Old Firmware Cannot Translate Messages Written to the System Event

Log....................................................... 3–6

3.11 TZ Function in C RTL ........................................ 3–7

3.12 InfoServer Utility and FDDI ................................... 3–7

3.13 New Qualiﬁer for DCL Command SET PASSWORD ................. 3–7

3.14 OpenVMS Freeware CDs . . .................................... 3–7

3.14.1 Freeware Menu Unavailable (Integrity servers Only) . . ........... 3–8

3.15 DCL Commands . ............................................ 3–8

3.15.1 SHUTDOWN.COM on OpenVMS Graphics Console (Integrity servers

only) ................................................... 3–8

3.15.2 DIAGNOSE Command No Longer Supported ................... 3–8

3.15.3 MOUNT Command Restriction . . ............................ 3–8

3.16 DECmigrate Not on Open Source Tools CD ........................ 3–9

3.17 HP Secure Web Browser . . .................................... 3–9

3.17.1 Increased Memory Required ................................ 3–9

3.17.2 Installation Error on ODS-2 Disk Volume (Integrity servers Only) . . . 3–9

3.18 Documentation Corrections .................................... 3–10

3.18.1 HP OpenVMS Linker Utility Manual Update ................... 3–10

3.18.1.1 HP C++ Examples ..................................... 3–10

3.18.2 HP PCSI Utility Online help and Manual: $PRODUCT REGISTER

VOLUME Syntax Error Correction ........................... 3–10

3.18.3 iCAP Release Notes: GiCAP Functionality not Available ........... 3–10

3.18.4 POLYCENTER Software Installation Utility Developer’s Guide:

PRODUCT Command Update ............................... 3–11

3.18.5 HP OpenVMS System Manager’s Manual Update ................ 3–11

3.18.5.1 Getting Information About Devices on the System ............ 3–11

3.18.5.2 Initializing a New Volume with ODS-5 Format ............... 3–13

3.18.5.3 Converting from ODS-2 to ODS-5 . . ....................... 3–13

3.18.5.4 New Extended File Speciﬁcations Characteristics ............. 3–14

3.18.5.5 ODS-2 and ODS-5 Used Together . . ....................... 3–14

3.18.5.6 Performing Image Backups to Disk . ....................... 3–15

3.18.5.7 Mounting a Volume With Caching Disabled . . . ............... 3–16

3.18.5.8 System-Wide Statistics . . ................................ 3–16

3.18.5.9 Disabling Caching for a Volume ........................... 3–16

3.18.5.10 Understanding File System Data Caches .................... 3–17

3.18.6 HP OpenVMS RTL Library (LIB$) Manual ..................... 3–17

3.18.7 Documentation Error: LCKMGR_CPUID System Parameter ....... 3–18

3.18.8 MMG_CTLFLAGS: Documentation Error ...................... 3–18

3.18.9 HP OpenVMS System Analysis Tools Manual ................... 3–18

3.18.10 HP OpenVMS Programming Concepts Manual .................. 3–18

3.18.10.1 Saving System Dumps . . ................................ 3–18

3.19 HP OpenVMS DELTA/XDELTA Debugger Manual Update ........... 3–18

3.19.1 HP OpenVMS Version 8.2 New Features and Documentation Overview:

Librarian Utility Corrections ................................ 3–18

3.19.1.1 /REMOVE Qualiﬁer Correction ........................... 3–19

3.19.1.2 Accessing ELF Object Libraries Correction . . . ............... 3–19

3.19.2 HP OpenVMS RTL Library (LIB$) Manual Corrections ........... 3–20

3.19.2.1 HP OpenVMS RTL Library (LIB$) Manual: Rounding Rule for

LIB$CVT_DX_DX ..................................... 3–20

3.19.3 HP OpenVMS RTL Library (LIB$) Manual: Platform Restrictions . . . 3–20

3.19.4 HP OpenVMS System Manager’s Manual: IPC Commands

Restriction .............................................. 3–21

3.20 Network Update Restrictions from Version 8.2 to Version 8.2–1 . ....... 3–21

3.21 Synchronous Data Links not Supported ........................... 3–21

3.22 Duplex-Mode Mismatch Errors . ................................ 3–22

4 System Management Release Notes

4.1 SYS$TIMEZONE_RULE Logical Replaces Hyphen (-) with Caret (^) .... 4–1

4.2 Issues with Time Zone Conﬁguration ............................. 4–1

4.3 OpenVMS as a Guest Operating System on Integrity VM ............. 4–2

4.3.1 "Guest Punishment" Scenarios ............................... 4–2

4.3.2 Increased CPU Consumption After Shutdown ................... 4–4

4.3.3 OpenVMS Guest Does not Support Attached I/O Devices . . . ....... 4–4

4.3.4 Networking or Storage Interface Support ...................... 4–4

4.4 Provisioning OpenVMS Using HP SIM ........................... 4–4

4.4.1 Provisioning OpenVMS Guest Limitation ...................... 4–4

4.4.2 System Firmware . ........................................ 4–5

4.4.3 Provisioning Multiple Servers ............................... 4–5

4.4.4 Provisioning From HP SIM Central Management Server . . . ....... 4–5

4.4.5 InfoServer Name Length . . . ................................ 4–5

4.4.6 OpenVMS InfoServer and the Integrity servers on the Same LAN . . . 4–5

4.4.7 EFI Firmware ........................................... 4–5

4.4.8 Management Processor .................................... 4–5

4.4.9 OpenVMS TCP/IP Provisioning Limitation . . ................... 4–5

4.4.10 Limitation with Deploying OpenVMS on Multiple Target Servers

Simultaneously .......................................... 4–6

4.5 Insight Dynamics - Virtual Server Environment for OpenVMS ......... 4–6

4.5.1 Utilization Data Collection Fails . ............................ 4–6

4.5.2 Problem While Creating a New or Replacement Simulated System . . . 4–7

4.5.3 Utilization Data not Available for OpenVMS Sub-OS Workloads . . . . . 4–7

4.5.4 Insight Software Features not Supported on OpenVMS . ........... 4–7

4.6 Performance Enhancements .................................... 4–8

4.6.1 Enhancements to Write Bitmaps . ............................ 4–8

4.6.1.1 WBM_MSG_INT Parameter Updates ....................... 4–8

4.6.1.2 WBM_MSG_UPPER and WBM_MSG_LOWER Parameter

Updates . ............................................ 4–8

4.6.1.3 Asynchronous SetBit Messages ........................... 4–9

4.6.1.4 Reduced SetBit Messages for Sequential I/O ................. 4–9

4.6.2 Exception Handling Performance Improvements (Integrity servers

Only) .................................................. 4–9

4.6.3 Exception Handling (Integrity servers Only) . ................... 4–9

4.6.4 Image Activation (Integrity servers Only) . . . ................... 4–10

4.6.5 Global Section Creation and Deletion ......................... 4–10

4.6.6 Dedicated CPU Lock Manager . . . ............................ 4–10

4.6.7 Ctrl/T Alignment Faults .................................... 4–10

4.7 Error and Warning Messages from ACPI During Boot ................ 4–10

4.8 Large Device Name Support for Accounting Utility .................. 4–10

4.9 PAGED_LAL_SIZE New System Parameter ....................... 4–11

4.9.1 Paged Pool Lookaside Lists ................................. 4–11

4.10 2 TiB Disk Volume Support Restrictions .......................... 4–11

4.11 Conﬁguring SAS Tape Drives ................................... 4–12

4.12 External SAS Disk Device Naming . . ............................ 4–12

4.13 External Authentication . . .................................... 4–12

4.13.1 External Authentication and Password Policy ................... 4–12

4.13.2 Integrity servers External Authentication Support ............... 4–13

4.13.3 SET PASSWORD Behavior Within a DECterm Terminal Session . . . . 4–13

4.13.4 No Password Expiration Notiﬁcation on Workstations . ........... 4–13

4.13.5 Restriction in ACME_SERVER Process (Integrity servers only) . . . . . 4–13

4.14 Itanium Primary Bootstrap (IPB) Fails to Find the Valid Dump

Devices .................................................... 4–14

4.15 SHUTDOWN.COM Changes ................................... 4–14

4.16 OpenVMS Cluster Systems .................................... 4–14

4.16.1 Cluster over IP (IP Cluster Interconnect) ....................... 4–14

4.16.1.1 Software Requirements ................................. 4–14

4.16.1.2 Integrity servers Satellite Node and Bootserver in the Same

LAN................................................ 4–14

4.16.1.3 Alpha Satellite Node Requires LAN Channels With Disk

Server . . ............................................ 4–15

4.16.1.4 IPv6 Support ......................................... 4–15

4.16.1.5 Dynamic Host Conﬁguration Protocol (DHCP) or Secondary

Address Support . . . .................................... 4–15

4.16.1.6 Multiple IP Interface Conﬁguration ........................ 4–15

4.16.1.7 ifconﬁg Command Usage ................................ 4–15

4.16.1.8 Multiple Gateway Conﬁguration .......................... 4–15

4.16.1.9 Block Transfer XMIT Chaining ........................... 4–15

4.16.1.10 LANCP for Downline Load ............................... 4–16

4.16.1.11 Duplex Mismatch ...................................... 4–16

4.16.1.12 Conﬁguring a Node During Upgrade ....................... 4–16

4.16.2 OpenVMS Cluster Support for Integrity VM .................... 4–16

4.16.2.1 Cluster Interconnect for OpenVMS Guest ................... 4–16

4.16.2.2 MSCP Support for Clusters in Integrity VM Environment ...... 4–16

4.16.2.3 Online Migration Support ............................... 4–16

4.16.3 Mixed Platform Support .................................... 4–17

4.16.4 Satellite Systems using Port Allocation Class ................... 4–17

4.17 Mixed-version Cluster Compatibility of a Six-member Shadowset ....... 4–17

4.18 Backward Compatibility of a Six-member Shadowset . ............... 4–18

4.19 WBEM Services and WBEM Providers for OpenVMS . ............... 4–18

4.19.1 Increased CPU Consumption With WBEM on OpenVMS Guest ..... 4–18

4.19.2 WBEM Providers Support for OpenVMS Guest . . . ............... 4–18

4.19.3 Based on OpenPegasus 2.9 . . ................................ 4–19

4.19.4 Supports nPartitions and iCAP .............................. 4–19

4.19.5 Restart cimserver.exe to Unload Providers on OpenVMS ........... 4–19

4.19.6 Use Quotes Around Command Line Options .................... 4–19

4.20 Writing the System Dump File to an Alternate Disk . . ............... 4–19

4.21 Monitor Utility Changes ...................................... 4–19

4.21.1 Guest Operating System on Integrity VM ...................... 4–19

4.21.2 Version-to-Version Compatibility of MONITOR Data .............. 4–21

4.21.3 Playing Back Data from a Recording File ...................... 4–21

4.22 System Parameters . . ........................................ 4–21

4.23 SYS$LDDRIVER Restriction . . . ................................ 4–22

4.24 CPU_POWER_MGMT Default Value Changed ..................... 4–22

4.25 Booting A Satellite System with Reserved Memory . . . ............... 4–22

4.26 SCACP Error Counter Reports Retransmit Errors ................... 4–22

4.27 Virtual Connect ............................................. 4–23

4.27.1 Failover and RECNXINTERVAL ............................. 4–23

4.28 INITIALIZE/ERASE=INIT Before Using Media ..................... 4–23

4.29 Performance Data Collector for OpenVMS (TDC) ................... 4–23

4.30 Recovering From System Hangs or Crashes (Integrity servers Only) ..... 4–23

4.31 DECdtm/XA with Oracle 8iand 9i(Alpha Only) .................... 4–24

4.32 Device Unit Number Increased . ................................ 4–24

4.33 EDIT/FDL: Fixing Recommended Bucket Size ...................... 4–24

4.34 Using EFI$CP Utility not Recommended . . . ....................... 4–25

4.35 Error Log Viewer (ELV) Utility: TRANSLATE/PAGE Command . ....... 4–25

4.36 Cluster Compatibility Patch Kits ................................ 4–25

4.36.1 Patch Kits Needed for Cluster Compatibility ................... 4–26

4.36.2 API to Correct Incompatibility of FC and SCSI Multipath with Some

Third-Party Products ..................................... 4–27

4.36.3 DDT Intercept Establisher Routines and Device Conﬁguration

Notiﬁcation Results ....................................... 4–28

4.36.4 Cluster Performance Reduced with CI-LAN Circuit Switching ...... 4–28

4.36.5 Multipath Tape Failover Restriction . . . ....................... 4–29

4.36.6 No Automatic Failover for SCSI Multipath Medium Changers ...... 4–29

4.37 OpenVMS Galaxy (Alpha Only) . ................................ 4–29

4.37.1 Galaxy Deﬁnitions ........................................ 4–30

4.38 Multiple nPartitions on Cell-based Systems . ....................... 4–30

4.38.1 OpenVMS Graphical Conﬁguration Manager ................... 4–30

4.38.2 Galaxy on ES40: Uncompressed Dump Limitation ............... 4–30

4.38.3 Galaxy on ES40: Turning Off Fastpath ....................... 4–31

vii

4.39 Corrupted Version 2 Format Database ........................... 4–31

4.40 System Parameters .......................................... 4–31

4.40.1 New System Parameters ................................... 4–31

4.40.2 Obsolete System Parameters ................................ 4–31

4.40.3 System Parameter Changes ................................. 4–32

4.41 Terminal Fallback Facility . .................................... 4–32

4.42 User Environment Test Package (Integrity servers Only) . . ........... 4–33

4.43 Recommended Caching Methods ................................ 4–34

4.44 Analyze Utility for OpenVMS .................................. 4–34

4.44.1 Formatted Symbol Vector Correctly Shown in Data Segment ....... 4–34

4.44.2 Transfer Array Formatted in Data Segment . ................... 4–34

4.44.3 System Version Array Formatted in Dynamic Segment . ........... 4–35

4.44.4 Enhancements for the /SEGMENT Qualiﬁer .................... 4–35

4.44.5 Support for Section Escaping Added .......................... 4–35

4.45 INSTALL Utility for OpenVMS (Installing Resident Images in S2

Space) .................................................... 4–35

5 Programming Release Notes

5.1 Symbolic Debugger ........................................... 5–1

5.2 C++ Run-Time Library ........................................ 5–1

5.3 Process/Application Hangs . .................................... 5–3

5.4 AST Delivery Clariﬁcation in Programs using POSIX Threads ......... 5–3

5.5 RMS $PARSE Validation of Directory Files ........................ 5–4

5.6 No-IOLOCK8 Fibre Channel Port Drivers ......................... 5–4

5.7 C++ Compiler . . . ............................................ 5–5

5.8 Building DCE IDL C++ Applications . ............................ 5–5

5.9 Privileged Programs may Need a Recompile (Alpha Only) . . ........... 5–6

5.10 Privileged Data Structures Updates . . ............................ 5–6

5.10.1 KPB Extensions .......................................... 5–7

5.10.2 CPU Name Space ........................................ 5–7

5.10.3 64-Bit Logical Block Number (LBN) .......................... 5–7

5.10.4 Forking to a Dynamic Spinlock . . ............................ 5–7

5.10.5 UCB/DDB Updates . . . .................................... 5–8

5.10.6 PCB$T_TERMINAL Size Increase ........................... 5–8

5.10.7 Per-Thread Security Impacts Privileged Code and Device Drivers . . . . 5–8

5.11 Applications Using Floating-Point Data .......................... 5–10

5.11.1 IEEE Floating-Point Filter (Integrity servers Only) ............... 5–10

5.11.2 Ada Event Support (Integrity servers Only) . . ................... 5–10

5.11.3 C++ Language Issues (Integrity servers Only) ................... 5–11

5.12 Ada Compiler(Integrity servers Only) ............................ 5–11

5.13 Backup API: Journaling Callback Events Restriction ................ 5–11

5.14 C Programs: Compiling with CASE_LOOKUP=SENSITIVE Settings . . . . 5–11

5.15 C Run-Time Library .......................................... 5–11

5.15.1 C RTL TCP/IP Header File Updates .......................... 5–12

5.15.2 Backport Library No Longer Shipped ......................... 5–12

5.15.3 Header File <time.h> Changes . . . ............................ 5–12

5.15.4 Header File <time.h> Makes *_r Non-ANSI Functions Visible . . . . . . 5–13

5.15.5 Header File <builtins.h> _ _CMP_SWAP* and _Interlocked* Visible to

C++ ................................................... 5–13

5.15.6 Builtin _ _fci Added for Integrity servers ....................... 5–13

5.15.7 No New Entries for DECC$*.OLB Object Libraries ............... 5–13

5.16 Calling Standard and Rotating Registers (Integrity servers Only) . . . . . . 5–13

5.17 Common Data Security Architecture (CDSA) Considerations .......... 5–14

viii

5.17.1 Secure Delivery . . ........................................ 5–14

5.17.2 Installation and Initialization Considerations ................... 5–14

5.18 Debugging Modes: Avoiding CPUSPINWAIT Bugchecks .............. 5–15

5.19 Delta/XDelta Debuggers ....................................... 5–15

5.19.1 XDELTA Register Display Consideration (Integrity servers Only) .... 5–15

5.20 File Applications: Corrections to Guide to OpenVMS File Applications

.......................................................... 5–16

5.21 HP BLISS Compiler Warnings with RMS Structures (Integrity servers

Only) ..................................................... 5–16

5.22 Potential Must-Be-Zero RMS Error: Making Room for New File Options

intheFAB................................................. 5–17

5.23 HP COBOL Run-Time Library (RTL) ............................ 5–18

5.23.1 Performance Improvement of COBOL CALL Statement ........... 5–18

5.24 HP Fortran for Integrity servers ................................ 5–18

5.25 HP MACRO for OpenVMS .................................... 5–19

5.25.1 Enhancements for the Macro-32 Compiler ...................... 5–19

5.25.2 HP MACRO for OpenVMS Integrity servers .................... 5–21

5.25.3 HP MACRO for OpenVMS Alpha Systems ...................... 5–22

5.25.4 /OPTIMIZE=VAXREGS Qualiﬁer Not Supported on Integrity

servers . ................................................ 5–22

5.25.5 Floating Divide-by-Zero Error Not Raised (Integrity servers Only) . . . 5–22

5.26 Hypersort Utility ............................................ 5–23

5.26.1 Reporting a Problem to HP . ................................ 5–23

5.26.2 Large Files Restriction ..................................... 5–23

5.26.3 Hypersort and VFC Files Restriction . . . ....................... 5–23

5.26.4 /FORMAT=RECORD_SIZE Restriction . ....................... 5–23

5.26.5 Using Hypersort with Search Lists and Other Uses of Logical Names

....................................................... 5–24

5.26.6 Lack of Free Space for Work Files ............................ 5–24

5.26.7 Input Asterisk (*) Restriction ................................ 5–24

5.26.8 Optimal Working Set Extent and Page File Quota Settings . ....... 5–24

5.27 Intel Assembler (Integrity servers Only) . . . ....................... 5–24

5.28 Librarian Utility ............................................ 5–24

5.28.1 Linking Against Data-Reduced ELF Object Libraries Not

Recommended (Integrity servers Only) . ....................... 5–24

5.28.2 Failure to Insert or Replace .STB ﬁles in an Integrity servers Library

(Integrity servers Only) .................................... 5–25

5.28.3 Librarian Fails to Report Errors When Process Quota Too Low ..... 5–25

5.29 Linker Utility for OpenVMS Alpha .............................. 5–25

5.29.1 Linker Appears to Hang When Many Files Are Speciﬁed .......... 5–26

5.29.2 Change in Linker Default Behavior with Library Check . . . ....... 5–26

5.29.3 Limit of 25 Elements on Stack .............................. 5–26

5.30 Linker Utility for OpenVMS Integrity servers ...................... 5–27

5.30.1 Linker Writes Incorrect Interimage Debug Fixups into Debug Symbol

File .................................................... 5–27

5.30.2 /SELECTIVE_SEARCH Qualiﬁer Might Incorrectly Ignore Transfer

Address ................................................ 5–27

5.30.3 Maximum Number of Sections ............................... 5–28

5.30.4 Incorrect Creation Date of Shareable Images in the Map File ....... 5–28

5.30.5 Demangler Information Look Up Results in Linker Access

Violation ................................................ 5–29

5.30.6 Incorrect Secondary Messages for the NOGLOSYM Error Message . . . 5–29

5.30.7 Incorrect Information for Undeﬁned Symbols ................... 5–29

5.30.8 Incorrect UNMAPFIL Error . ................................ 5–29

5.30.9 Max Ident Length Change for Shareable Images in Map ........... 5–29

5.30.10 Linkage Type Check for Shareable Images . . ................... 5–29

5.30.11 Program Section Attribute ABS Ignored ....................... 5–30

5.30.12 Linker ACCVIOs when FP_MODE Literal Missing From Command

Line ................................................... 5–30

5.30.13 OpenVMS Integrity servers Object Module and Image File

Information Currently Unavailable ........................... 5–30

5.30.14 Differences Between the Integrity servers Linker and the Alpha

Linker ................................................. 5–30

5.30.15 LINK_ORDER Section Header Flag Not Supported ............... 5–30

5.30.16 Linking Against Data-Reduced ELF Object Libraries Not

Recommended ........................................... 5–31

5.30.17 Error in Handling Initialized Overlaid Program Sections Fixed . . . . . 5–31

5.30.18 Removal of Linker Qualiﬁers /EXPORT_SYMBOL_VECTOR and

/PUBLISH_GLOBAL_SYMBOLS . ............................ 5–32

5.30.19 Support for Longer Symbol Names in Options ................... 5–32

5.30.20 Better Use of Memory for Linker-Created Code Stubs . . ........... 5–32

5.30.21 Compiler Support for Demangled Symbol Names ................ 5–32

5.31 LTDRIVER: CANCEL SELECTIVE Restriction . . ................... 5–32

5.32 Mail Utility: Threads Restriction for Callable Mail .................. 5–33

5.33 OpenVMS System Dump Analyzer (SDA) ......................... 5–33

5.33.1 CLUE Commands Not Ported to OpenVMS Integrity servers ....... 5–33

5.34 PL/I Libraries Not Included in OpenVMS Integrity servers Version 8.2 . . . 5–33

5.35 POSIX Threads Library . . . .................................... 5–33

5.35.1 Support for Process-shared Objects ........................... 5–34

5.35.2 New Return Status for pthread_mutex_lock . ................... 5–34

5.35.3 Support for New API pthread_mutex_tryforcedlock_np . ........... 5–34

5.35.4 Stack Overﬂows During Exception Handling (Integrity servers

Only) .................................................. 5–35

5.35.5 THREADCP Command Behavior on Integrity Servers . . ........... 5–36

5.35.6 Floating-Point Compilations and Exceptions (Integrity servers

Only) .................................................. 5–36

5.35.7 C Language Compilation Header File Changes .................. 5–36

5.35.8 New Priority Adjustment Algorithm .......................... 5–37

5.35.9 Process Dumps ........................................... 5–37

5.35.10 Dynamic CPU Conﬁguration Changes ......................... 5–37

5.35.11 Debugger Metering Function Does Not Work . ................... 5–38

5.36 RTL Library (LIB$) .......................................... 5–38

5.36.1 RTL Library (LIB$) Help Omission ........................... 5–38

5.36.2 RTL Library (LIB$): Calling Standard Routines (Integrity servers

Only) .................................................. 5–38

5.37 Screen Management (SMG$) Documentation ....................... 5–39

5.38 SORT32 Utility . ............................................ 5–40

5.38.1 CONVERT Problem With DFS-Served Disks ................... 5–40

5.38.2 Temporary Work Files Not Always Deleted . . ................... 5–40

5.38.3 SORT/SPECIFICATION With Compound Conditions: Requirement

....................................................... 5–40

5.38.4 Performance Problem with Variable Length Records . . ........... 5–40

5.38.5 Work File Directories Restriction ............................ 5–41

5.39 Timer Queue Entries (TQEs) ................................... 5–41

5.40 Watchpoint Utility (Integrity servers Only) ........................ 5–41

5.41 Whole Program Floating-Point Mode (Integrity servers Only) .......... 5–41

6 Hardware Release Notes

6.1 USB Device Support . ........................................ 6–1

6.2 MP and BMC Console Restrictions (Integrity servers Only) ........... 6–2

6.2.1 Input, Output, and Error Device Restriction .................... 6–2

6.2.2 Remapping Ctrl/H to the Delete Key . . ....................... 6–2

6.3 AlphaServer 2100 . . . ........................................ 6–2

6.3.1 Console Display . . ........................................ 6–3

6.3.2 SCSI Controller Restriction . ................................ 6–3

6.4 AlphaServer 8200/8400: FRU Table Error . ....................... 6–4

6.5 AlphaServer ES47/ES80/GS1280 Systems . . ....................... 6–4

6.5.1 INIT Console Command Usage on ES47/ES80/GS1280 Soft

Partitions ............................................... 6–4

6.5.2 RAD Support . . . ........................................ 6–4

6.5.3 License Requirements ..................................... 6–4

6.5.4 STOP/CPU and Shutdown Behavior . . . ....................... 6–4

6.5.5 Setting Time at MBM ..................................... 6–5

6.6 AlphaServer GS Series Systems . ................................ 6–5

6.6.1 AlphaServer GS80/160/320 Systems: Device Restriction ........... 6–5

6.6.2 OpenVMS Galaxy License Enforcement . ....................... 6–5

6.6.3 Installing Licenses ........................................ 6–5

6.6.4 AlphaServer GS60/GS60E/GS140 Multiple I/O Port Module

Conﬁguration Restriction . . . ................................ 6–7

6.7 AlphaStation 200/400: ISA_CONFIG.DAT Changes Required . . ....... 6–7

6.8 AlphaStation 255: PCI Conﬁguration Restriction ................... 6–8

6.9 ATI RADEON 7000 Graphics (Integrity servers Only) . ............... 6–8

6.9.1 Integrity servers Graphics Support ........................... 6–8

6.9.2 Hardware Accelerated 3D Graphics Not Supported on RADEON 7000

....................................................... 6–9

6.10 ATI RADEON 7500 Graphics . . . ................................ 6–9

6.10.1 Resource Requirements .................................... 6–9

6.10.2 DECW$OPENGLSHR_RADEON.EXE Renamed to

DECW$MESA3DSHR_RADEON.EXE . . ....................... 6–10

6.10.3 Support Limitations ....................................... 6–10

6.10.4 Video Artifacts at High Refresh Rates . . ....................... 6–10

6.10.5 OpenGL Supports IEEE Arithmetic Only ...................... 6–10

6.10.6 DECwindows Server Hangs When Output Is Written to the Graphics

Console (OPA0) . . ........................................ 6–10

6.10.7 Monitor Must Be Connected During Initialization . ............... 6–11

6.10.8 Boot Reset Recommendation (Alpha Only) ...................... 6–11

6.10.9 No Overlay Planes ........................................ 6–11

6.10.10 Single Colormap . . ........................................ 6–11

6.10.11 Single Bit Depth for All Windows ............................ 6–11

6.10.12 Pixel Depth for Read/Write Color Map . . ....................... 6–12

6.10.13 Backing Store/Save Unders Not Supported for 3D Windows . ....... 6–12

6.10.14 Threads Restriction ....................................... 6–12

6.10.15 No Support for Single Buffered Visuals ....................... 6–12

6.10.16 No 3D Support for Color Index Mode . . . ....................... 6–12

6.10.17 Timer Mechanism ........................................ 6–12

6.11 DECwindows X11 Display Server (Alpha Only) ..................... 6–13

6.11.1 S3 Multihead Graphics .................................... 6–13

6.12 DIGITAL Modular Computing Components (DMCC) . ............... 6–13

6.12.1 Alpha 5/366 and 5/433 PICMG SBC Restriction . . ............... 6–13

6.12.2 Updating the SRM Console . ................................ 6–13

6.13 Digital Personal Workstation: Booting OpenVMS V7.3-1 and Higher .... 6–14

6.14 Dual-Controller HSGnn with Many LUNs Can Fail Under Heavy I/O

Load . . .................................................... 6–14

6.15 Open3D Graphics Licensing Change . ............................ 6–15

6.16 PowerStorm 300/350 PCI Graphics Support for OpenVMS . ........... 6–15

6.17 RFnn DSSI Disk Devices and Controller Memory Errors . . . ........... 6–16

6.18 RZnn Disk Drive Considerations ................................ 6–18

6.18.1 RZ25M and RZ26N Disk Drives: Recommendations . . . ........... 6–18

6.18.2 RZ26N and RZ28M Disks: Recommended Firmware Support ....... 6–19

6.18.3 RZ26L and RZ28 Disks: Required Firmware for Multihost Use . . . . . 6–19

6.18.3.1 Firmware Revision Level 442 Requirements ................. 6–19

6.18.3.2 Firmware Revision Level 442 Installation Procedure ........... 6–19

6.19 sx1000 Integrity Superdome ................................... 6–20

6.20 ZLX Graphics Boards Support ................................. 6–20

6.21 Recompiling and Relinking OpenVMS Device Drivers ................ 6–20

6.21.1 Alpha and VAX SCSI Device Drivers .......................... 6–20

6.21.2 OpenVMS Alpha Device Drivers . ............................ 6–21

6.22 Device Driver MON Version Handling ............................ 6–21

6.23 Possible Per-Threads Security Impact on Alpha Device Drivers ........ 6–21

6.24 Device IPL Setup for OpenVMS Alpha Drivers . . ................... 6–21

6.25 CRCTX Routines Enhanced ................................... 6–22

6.26 Adapter Release Notes ........................................ 6–22

6.26.1 Fibre Channel EFI Driver and Firmware Requirements ........... 6–22

6.26.2 Booting with Multiple Fibre Channel Boot Entries ............... 6–23

A Interlocked Memory Instructions (Alpha Only)

A.1 Required Code Checks . . . .................................... A–1

A.2 Using the Code Analysis Tool (SRM_CHECK) . . . ................... A–1

A.3 Noncompliant Code Characteristics . ............................ A–2

A.4 Coding Requirements ......................................... A–3

A.5 Compiler Versions ........................................... A–5

A.6 Recompiling Code with ALONONPAGED_INLINE or

LAL_REMOVE_FIRST . . . .................................... A–6

Index

Tables

1–1 Supported Versions of DECwindows Motif . . . ................... 1–4

1–2 Firmware Versions for Entry-Class Integrity Servers . . ........... 1–6

4–2 Patch Kits Required for Cluster Compatibility ................... 4–26

4–2 Patch Kits Required for Cluster Compatibility ................... 4–27

4–3 Galaxy Deﬁnitions ........................................ 4–30

4–4 TFF Character Fallback Tables . . ............................ 4–33

5–1 Macro-32 New Built-ins .................................... 5–19

6–1 Changes to Device Description Block .......................... 6–8

6–2 Supported Microcode Revision Levels ......................... 6–17

6–3 Commands for Updating Microcode in Certain DSSI Disk Devices . . . 6–18

6–4 Revision Level 442 Firmware Compatibility . ................... 6–19

A–1 Versions of OpenVMS Compilers . ............................ A–5

xii

Preface

Intended Audience

This manual is intended for all users of the HP OpenVMS for Integrity servers or

HP OpenVMS Alpha Version 8.4 operating system. Read this manual before you

install, upgrade, or use OpenVMS Version 8.4.

Document Structure

This manual contains the following chapters and appendix:

• Chapter 1 contains release notes that pertain to upgrading or installing

the OpenVMS Alpha operating system or installing the OpenVMS Integrity

servers.

• Chapter 2 contains installation and support information for OpenVMS

associated products.

• Chapter 3 contains release notes about the general use of the OpenVMS

operating system.

• Chapter 4 contains release notes speciﬁc to the OpenVMS system

management.

• Chapter 5 contains release notes that relate to programming on an OpenVMS

system, including notes for compilers, linkers, and run-time library routines.

• Chapter 6 contains information pertaining to hardware that runs on the

OpenVMS operating system and OpenVMS device support.

• Appendix A describes the proper use of interlocked memory instructions,

which is crucial for the Alpha 21264 (EV6) processor.

Notes are organized by facility or product name when applicable.

This manual contains release notes introduced in the current release and notes

from previous versions that still apply to the new release. A subheading for

each release note indicates either the version of origin (for example, V8.3) or the

version when an old note was last updated (for example, a note from Version 8.3

that was revised for Version 8.4 will be labeled with V8.4).

Notes from previous releases are published when:

• The information in the release note has not been documented in any other

printed manual in the OpenVMS documentation set, and the note is still

pertinent.

• The release note may be pertinent in multiple-version OpenVMS Cluster

systems.

DIRECTORY

and

COPY

. Omnibus

text ﬁles containing submission abstracts and other materials are available in the

[FREEWARE] directory on each disk.

The [FREEWARE]FREEWARE.COM Freeware menu system interface has been

removed from Freeware 8.0 distribution.

3.14.1 Freeware Menu Unavailable (Integrity servers Only)

V8.2

The [FREEWARE]FREEWARE.COM Freeware menu system interface on the

OpenVMS Freeware V7.0 distribution does not operate on OpenVMS Integrity

servers.

The menu system interface is expected to function on OpenVMS Alpha and on

OpenVMS VAX systems.

You can directly access the contents of the Freeware V7.0 distribution media

by using DCL commands such as DIRECTORY and COPY from an OpenVMS

Integrity servers, OpenVMS Alpha, or OpenVMS VAX system. This is the

preferred way to access the contents of the Freeware V7.0 distribution.

Information about submissions and the Freeware distribution is contained in the

ﬁle [FREEWARE]FREEWARE_README.TXT. This ﬁle is on each volume of the

Freeware V7.0 distribution, and you can view its contents by using the TYPE

command or a text editor.

3.15 DCL Commands

The following release notes pertain to DCL commands.

3.15.1 SHUTDOWN.COM on OpenVMS Graphics Console (Integrity servers

only)

Permanent Restriction

On an OpenVMS Integrity server system with a graphics console, use of

SYS$SYSTEM:SHUTDOWN.COM to stop the system may not work as expected.

The system will not stop after the "SYSTEM SHUTDOWN COMPLETE" message

and wait for a key to be typed at the console keyboard. However, it will continue

to reset as though a reboot had been requested. If the ﬁrst option in the list of

boot options is a valid boot device, the OpenVMS system will reboot.

3.15.2 DIAGNOSE Command No Longer Supported

V8.2

The DIAGNOSE command is not supported on OpenVMS Version 8.2.

3.15.3 MOUNT Command Restriction

V8.4

In a mixed-version OpenVMS cluster, an attempt to mount a volume with

/CLUSTER and /CACHE=[NO]DATA from a OpenVMS Version 8.4 system will

fail on the earlier versions of OpenVMS (%MOUNT-W-RMTMNTFAIL) with the

error condition as MOUNT-F-BADPARAM.

3–8 General User Release Notes

General User Release Notes

3.15 DCL Commands

For more information about enabling or disabling XFC while mounting a volume,

see the HP OpenVMS Version 8.4 New Features and Documentation Overview.

3.16 DECmigrate Not on Open Source Tools CD

V8.2

The OpenVMS Migration Software for VAX to Alpha (DECmigrate) is not included

on the Open Source Tools CD shipped with the OpenVMS Version 8.2 distribution

media. The software kit was included on the media for OpenVMS Version 7.3-2.

The software will continue to be available on the following website for earlier

versions of OpenVMS:

http://h71000.www7.hp.com/openvms/products/omsva/omsva.html

3.17 HP Secure Web Browser

The following notes pertain to the HP Secure Web Browser.

3.17.1 Increased Memory Required

V7.3-1

If you have an OpenVMS workstation and you are using the HP Secure Web

Browser (SWB), based on Mozilla, the minimum memory requirement is 256 MB;

however, 512 MB is highly recommended for more robust performance.

3.17.2 Installation Error on ODS-2 Disk Volume (Integrity servers Only)

V8.2

Installing the HP Secure Web Browser (CSWB) Version 1.4 for OpenVMS

Integrity servers on an ODS-2 disk volume fails with a PCSI error, as follows:

%PCSI-E-OPENIN, error opening

ODS2$DISK:[SYS0.SYSCOMMON.][CSWB.RES]SAMPLE^.UNIXPSFONTS.PROPERTIES;* as input

-RMS-E-FND, ACP file or directory lookup failed

-SYSTEM-W-BADFILEVER, bad file version number

%PCSI-E-OPFAILED, operation failed

You can continue with the installation by answering "NO" to the "Do you want to

terminate?" prompt. The installation will continue successfully.

As an alternative, you can install the HP Secure Web Browser on an ODS-5 disk

volume.

General User Release Notes 3–9

General User Release Notes

3.18 Documentation Corrections

The following sections describe corrections and additions to various manuals in

the OpenVMS documentation set.

3.18.1 HP OpenVMS Linker Utility Manual Update

V8.4

3.18.1.1 HP C++ Examples

In section 2.6.2, the following should be appended to point 7:

Note that on Integrity servers, you can use either the CXXLINK command or

invoke the OpenVMS Linker to combine your object modules into one executable

image. On OpenVMS Alpha, you must use the CXXLINK utility to link the

object modules into one executable image. On Integrity server systems, the

only beneﬁt of using CXXLINK is that CXXLINK reports non-mangled names of

undeﬁned multiply-deﬁned. It does this by intercepting Linker diagnostics and

converting mangled names reported by the Linker to their original names, using

the information in the demangler database.

3.18.2 HP PCSI Utility Online help and Manual: $PRODUCT REGISTER

VOLUME Syntax Error Correction

V8.4

The HP PCSI utility online help deﬁnes incorrect syntax of the $PRODUCT

$PRODUCT REGISTER VOLUME old-volume-label device-name

The correct syntax is as follows:

$PRODUCT REGISTER VOLUME old-logvolnam device-name

3.18.3 iCAP Release Notes: GiCAP Functionality not Available

V8.3-1H1

While running SYS$MANAGER:ICAP$CONFIG.COM, if you respond "Y" to

the "Enter (Y)es to conﬁgure this system with GiCAP support (N):" prompt, the

following message is displayed:

HP OpenVMS Industry Standard 64

Global Instant Capacity on Demand (GiCAP) configuration utility

*** GiCAP functionality is not currently available ***

***GiCAP will be enabled at a later date via an ECO kit ***

HP OpenVMS Industry Standard 64

Global Instant Capacity on Demand (GiCAP) configuration utility

*** GiCAP functionality is not currently available ***

***GiCAP will be enabled at a later date via an ECO kit ***

Also, note that in the release notes for Instant Capacity (iCAP), Chapter 2

speciﬁes GiCAP support for OpenVMS Version 8.3-1H1. This support is not

available currently, but will be available in a future update kit. For more

information, see the OpenVMS website.

3–10 General User Release Notes

General User Release Notes

3.18 Documentation Corrections

3.18.4 POLYCENTER Software Installation Utility Developer’s Guide:

PRODUCT Command Update

V8.4

In the parameters section, the producer description should be as follows:

Indicates the legal owner of the software product. This parameter must be either

a double quoted or an unquoted string.

3.18.5 HP OpenVMS System Manager’s Manual Update

V8.4

The following corrections pertain to the HP OpenVMS System Manager’s Manual,

Volume 1: Essentials.

3.18.5.1 Getting Information About Devices on the System

In section 8.3, the following examples should be replaced as follows:

The following command requests a full listing of the status of the DAD42: RRD40

device. The device is located on node IRIS in an OpenVMS Cluster environment.

$ SHOW DEVICES/FULL DAD42:

Disk DAD42: (IRIS), device type RRD40, is online, mounted, software write-locked,

file-oriented device, shareable, error logging is enabled.

Error count 0 Operations completed 146

Owner process "" Owner UIC [SYSTEM]

Owner process ID 00000000 Dev Prot S:RWPL,O:RWPL,G:RWPL,W:RWPL

Reference count 1 Default buffer size 512

Total blocks 1218000 Sectors per track 4

Total cylinders 50750 Tracks per cylinder 6

Allocation class 11

Volume label "CDBIN06JUL21" Relative volume number 0

Cluster size 3 Transaction count 1

Free blocks 15153 Maximum files allowed 152083

Extend quantity 5 Mount count 1

Mount status System Cache name "_$11$DUA21:XQPCACHE"

Extent cache size 64 Maximum blocks in extent cache 1515

File ID cache size 64 Blocks currently in extent cache 0

Quota cache size 0 Maximum buffers in FCP cache 1330

Volume status: ODS-2, subject to mount verification, file high-water marking,

write-through XQP caching enabled, write-through XFC caching enabled.

The following command requests a full informational display about each DG

device. This display shows only the ﬁrst two devices: the mounted $1$DGA5001:

device and the unmounted $1$DGA5004: device.

General User Release Notes 3–11

General User Release Notes

3.18 Documentation Corrections

$ SHOW DEVICES/FULL DG

Disk $1$DGA5001: (CEAGLE), device type HSV110, is online, mounted,

file-oriented device, shareable, device has multiple I/O paths,

served to cluster via MSCP Server, error logging is enabled.

Error count 0 Operations completed 5773

Owner process "" Owner UIC [SYSTEM]

Owner process ID 00000000 Dev Prot S:RWPL,O:RWPL,G:R,W

Reference count 1 Default buffer size 512

Current preferred CPU Id 0 Fastpath 1

WWID 01000010:6005-08B4-0001-42DC-0001-F000-0111-0000

Total blocks 20971520 Sectors per track 128

Total cylinders 1280 Tracks per cylinder 128

Host name "CEAGLE" Host type, avail AlphaServer ES40, yes

Alternate host name "CLETA" Alt. type, avail AlphaServer ES40, yes

Allocation class 1

Volume label "5001" Relative volume number 0

Cluster size 21 Transaction count 1

Free blocks 19598208 Maximum files allowed 476625

Extend quantity 5 Mount count 9

Mount status System Cache name "_$1$DGA3105:XQPCACHE"

Extent cache size 64 Maximum blocks in extent cache 1959820

File ID cache size 64 Blocks in extent cache 0

Quota cache size 0 Maximum buffers in FCP cache 3444

Volume owner UIC [SYSTEM] Vol Prot S:RWCD,O:RWCD,G:RWCD,W:RWCD

Volume Status: ODS-2, subject to mount verification, file high-water marking,

write-back XQP caching enabled, write-through XFC caching enabled.

Volume is also mounted on VMSROC, PAVER, VMSROL, CLETA, VMSJO, VMSMO, NOME,

FARKLE.

I/O paths to device 5

Path PGA0.5000-1FE1-0015-22AC (CEAGLE), primary path.

Error count 0 Operations completed 0

Path PGA0.5000-1FE1-0015-22A9 (CEAGLE).

Error count 0 Operations completed 0

Path PGB0.5000-1FE1-0015-22A8 (CEAGLE).

Error count 0 Operations completed 0

Path PGB0.5000-1FE1-0015-22AD (CEAGLE), current path.

Error count 0 Operations completed 5773

Path MSCP (CLETA).

Error count 0 Operations completed 0

Disk $1$DGA5004: (CEAGLE), device type HSV110, is online,

file-oriented device, shareable, device has multiple I/O paths,

served to cluster via MSCP Server, error logging is enabled.

Error count 0 Operations completed 0

Owner process Owner UIC [SYSTEM]

Owner process ID 00000000 Dev Prot S:RWPL,O:RWPL,G:R,W

Reference count 0 Default buffer size 512

Current preferred CPU Id 0 Fastpath 1

WWID 01000010:6005-08B4-0001-42DC-0001-F000-0120-0000

Host name CEAGLE Host type, avail AlphaServer ES40, yes

Alternate host name CLETA Alt. type, avail AlphaServer ES40, yes

Allocation class 1

3–12 General User Release Notes

General User Release Notes

3.18 Documentation Corrections

I/O paths to device 5

Path PGA0.5000-1FE1-0015-22AC (CEAGLE), primary path.

Error count 0 Operations completed 0

Path PGA0.5000-1FE1-0015-22A9 (CEAGLE).

Error count 0 Operations completed 0

Path PGB0.5000-1FE1-0015-22A8 (CEAGLE), current path.

Error count 0 Operations completed 0

Path PGB0.5000-1FE1-0015-22AD (CEAGLE).

Error count 0 Operations completed 0

Path MSCP (CLETA).

Error count 0 Operations completed 0

3.18.5.2 Initializing a New Volume with ODS-5 Format

In Section 9.3.3, the SHOW/DEVICE DKA200:/FULL command displays the

messages similar to the following:

$ SHOW DEVICE DKA200:/FULL

Disk $10$DKA200:, device type RZ74, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 155

Volume Status: ODS-5, subject to mount verification, file high-water

marking, write-back XQP caching enabled, write-through XFC caching enabled.

3.18.5.3 Converting from ODS-2 to ODS-5

In section 9.5.5.1, the SHOW DEVICE DKA200:/FULL command in the

instruction 2 should display the message similar to the following:

$ SHOW DEVICE DKA200:/FULL

Disk $10$DKA200:, device type RZ47, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 232

Volume Status: ODS-2, subject to mount verification, file high-water

marking, write-back XQP caching enabled, write-through XFC caching enabled.

In section 9.5.5.1, the SHOW DEVICE DKA300:/FULL command in the

instruction 5 displays the message similar to the following:

$ SHOW DEVICE DKA300:/FULL

Disk $10$DKA300:, device type RX74, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 155

Volume Status: ODS-5, subject to mount verification, file high-water

marking, write-back XQP caching enabled, write-through XFC caching enabled.

General User Release Notes 3–13

General User Release Notes

3.18 Documentation Corrections

3.18.5.4 New Extended File Speciﬁcations Characteristics

In section 10.1.2.1, the SHOW DEVICE command in the "Be Aware of Volume

Structure" notes displays the message similar to the following:

$ SHOW DEVICE DKA500:/FULL

Disk AABOUT$DKA500:, device type DZ25 Disk, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 155

Volume Status: ODS-5, subject to mount verification, file high-water

marking, write-back XQP caching enabled, write-through XFC caching enabled.

$ SHOW DEVICE DKA200:/FULL

Disk AABOUT$DSA200:, device type RZ25 Disk, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 232

Volume Status: ODS-2, subject to mount verification, file high-water

marking, write-back XQP caching enabled, write-through XFC caching enabled.

3.18.5.5 ODS-2 and ODS-5 Used Together

In section 10.1.2.2, the SHOW DEVICE command example in the "Error Messages

Can Vary Depending on Parse Style" notes should display the message similar to

the following:

Examples of TRADITIONAL and EXTENDED styles on an ODS-5 volume:

$ SHOW DEVICE DKA500:/FULL

Disk AABOUT$DKA500:, device type RZ25 Disk, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 155

Volume Status: ODS-5, [1] subject to mount verification, file high-water

marking, write-back XQP caching enabled, write-through XFC caching enabled.

$ SET PROCESS /PARSE_STYLE=TRADITIONAL [2]

$ OPEN /WRITE FILE z.z.z.z

%DCL-W-PARMDEL, invalid parameter delimiter - check use of special

characters \.Z\ [3]

$ SET PROCESS /PARSE_STYLE=EXTENDED [4]

$ OPEN /WRITE FILE z.z.z.z

$ [5]

1. The volume is ODS-5.

2. The parse style is set to TRADITIONAL.

3. DCL returns an error on some ODS-5 file names such as this one.

4. The parse style is set to EXTENDED.

5. DCL creates the file.

3–14 General User Release Notes

General User Release Notes

3.18 Documentation Corrections

Examples of TRADITIONAL and EXTENDED styles on an ODS-2 volume:

Disk AABOUT$DKA200:, device type RZ25 Disk, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 232

Volume Status: ODS-2, [1] subject to mount verification, file high-water

marking, write-back caching XQP enabled, write-through XFC caching enabled.

$ SET PROCESS /PARSE_STYLE=TRADITIONAL [2]

$ OPEN /WRITE FILE z.z.z.z

%DCL-W-PARMDEL, invalid parameter delimiter - check use of special

characters \.Z\ [3]

$ SET PROCESS /PARSE_STYLE=EXTENDED [4]

$ OPEN /WRITE FILE z.z.z.z

%DCL-E-OPENIN, error opening

-RMS-E-CRE, ACP file create failed [5]

-SYSTEM-W-BADFILEVER, bad file version number

1. The volume is ODS-2.

2. The parse style is set to TRADITIONAL.

3. DCL returns an error message.

4. The parse style is set to EXTENDED.

5. DCL allows the file name, but XQP returns an error.

Examples of different error messages for the same syntax error:

$ SHOW DEVICE DKA500:/FULL

Disk AABOUT$DKA500:, device type RZ25 Disk, is online, allocated, deallocate

on dismount, mounted, file-oriented device, shareable.

Error count 0 Operations completed 155

Volume Status: ODS-5, [1] subject to mount verification, file high-water

marking, write-back XQP caching enabled, write-through XFC caching enabled.

$ SET PROCESS /PARSE_STYLE=TRADITIONAL [2]

$ CREATE a^<b.c

%DCL-W-PARMDEL, invalid parameter delimiter - check use of special

characters

\^\ [3]

$ SET PROCESS /PARSE_STYLE=EXTENDED [4]

$ CREATE a^<b.c

%CREATE-E-OPENOUT, error opening a^<b.c as output

-RMS-F-SYN, file specification syntax error [5]

1. The volume is ODS-5.

2. The parse style is set to TRADITIONAL.

3. DCL returns an error message for a syntax error.

4. The parse style is set to EXTENDED.

5. RMS returns a different error message for the same syntax error.

3.18.5.6 Performing Image Backups to Disk

In section 11.15.3, the following note should be appended to the end of the section:

BACKUP does not preserve GUID signature during image restore operation of

the system disk on Integrity server systems. During restore, BACKUP calls

SETBOOT to create a new GUID signature. Hence, during image restore

operation BACKUP does not restore the original GUID signature, rather it

creates a new GUID signature. As a result of this, Integrity servers system does

not boot automatically from a disk created through an image restore operation.

General User Release Notes 3–15

General User Release Notes

3.18 Documentation Corrections

If required to boot an Integrity servers system from a disk created through an

image restore operation, you need to follow one of the method described below to

update the GUID signature of the disk:

• Use the following procedure to add or validate the boot options:

$ @SYS$MANAGER:BOOT_OPTIONS.COM

• Use the following command to update the boot block:

$ SET BOOTBLOCK /INTEGRITY <destination_disk>:[VMS$COMMON.SYS$LDR]SYS$EFI.SYS

The following corrections pertain to the HP OpenVMS System Manager’s Manual,

Volume 2: Tuning, Monitoring, and Complex Systems.

3.18.5.7 Mounting a Volume With Caching Disabled

The following paragraphs should be appended to Section 4.4.

To disable XFC, enter the following command:

MOUNT/CACHE=NODATA

This command disables only data cache (XFC) while metadata cache (XQP) is

enabled.

This example mounts a database volume labeled ORACLE_VOL1 with data cache

(XFC) disabled:

$ MOUNT DUA100: ORACLE_VOL1 /CACHE = NODATA /SYSTEM

3.18.5.8 System-Wide Statistics

In section 4.5.6.1, the following changes should be made to the foot note:

[7] Reads bypassing cache — The total number of read I/Os since system startup

that were seen by the cache but were not cached, for example, because they were

too big, or they were for volumes mounted /NOCACHE or /CACHE=NODATA, or

they speciﬁed one of the following QIO modiﬁers: IO$M_DATACHECK, IO$M_

INHRETRY, or IO$M_NOVCACHE.

[17] Write bypassing cache — The total number of write I/Os since system startup

that were seen by the cache but were not cached, for example, because they were

too big, or they were for volumes mounted /NOCACHE or/CACHE=NODATA, or

they speciﬁed one of the following QIO modiﬁers: IO$M_DATACHECK, IO$M_

ERASE, IO$M_INHRETRY, or IO$M_NOVCACHE.

3.18.5.9 Disabling Caching for a Volume

In Chapter 4, a new section "Disabling Caching for a Volume" has to be added

before Section 4.5.4, "Disabling Caching for a File".

The following text should be added to the "Disabling Caching for a Volume":

From OpenVMS Version 8.4 onwards, XFC can be dynamically enabled or

disabled or cleared for a volume using the DCL "SET VOLUME" command.

In the earlier versions, XFC caching attributes of the volume were speciﬁed

when the volume was mounted. Once the volume is mounted there is no way to

dynamically modify the XFC caching attributes. Therefore, to modify the XFC

caching attributes, the volume had to be dismounted and mounted again with the

appropriate XFC caching attributes.

3–16 General User Release Notes

General User Release Notes

3.18 Documentation Corrections

With this feature, after the volume is mounted, you can modify the XFC caching

attributes dynamically without dismounting and mounting the volume again.

Use... To...

SET VOLUME V1/CACHE=DATA To Enable XFC caching for the volume V1

SET VOLUME V1/CACHE=NODATA To Disable XFC caching for the volume V1

SET VOLUME V1/CACHE=CLEAR_

DATA

To Clear the contents of the volume V1 from

cache

SET VOLUME

V1/CACHE=(DATA,CLEAR_DATA)

To Enable XFC caching for the volume V1 and

Clear the contents of volume V1 from the cache

SET VOLUME

V1/CACHE=(NODATA,CLEAR_DATA)

To Disable XFC caching for the volume V1 and

Clear the contents of volume V1 from the cache

SHOW MEM/CACHE=(VOL=V1) To display the current XFC caching status of

the volume V1

Examples

$ SET VOLUME $DKA100/CACHE=CLEAR_DATA

This example clears the contents of the volume $DKA100 already present in

the XFC cache. The caching attributes of the volume $DKA100 is not altered.

$ SET VOLUME $DKA100/CACHE=DATA

This example enables XFC caching for the volume $DKA100. The contents of

volume $DKA100 already present in the XFC cache is not affected.

$ SET VOLUME $DKA100/CACHE=(DATA,CLEAR_DATA)

This example enables XFC caching for the volume $DKA100 and clears

contents of the volume $DKA100 already present in the XFC cache.

3.18.5.10 Understanding File System Data Caches

In Section 4.2, add the following bullet after the following paragraph:

XFC improves I/O performance and contains the following features that are not

available with VIOC:

• Dynamically enabling or disabling caching for mounted volumes

3.18.6 HP OpenVMS RTL Library (LIB$) Manual

V8.3

The LIB$SET_SYMBOL value-string is incorrectly documented in Version 8.2 of

the HP OpenVMS RTL Library (LIB$) Manual. The correct value-string is as

follows:

Trailing blanks are not removed from the value string before use. The maximum

length of value-string is 4096 characters. Integer values are not allowed;

LIB$SET_SYMBOL is intended to set string CLI symbols, not integer CLI

symbols.

General User Release Notes 3–17

General User Release Notes

3.18 Documentation Corrections

3.18.7 Documentation Error: LCKMGR_CPUID System Parameter

V8.3

The OpenVMS Performance Management manual contains several references

to the system parameter LCKMGR_CPUID as LOCKMGR_CPU. This latter

reference is incorrect and will be corrected the next time the manual is updated.

3.18.8 MMG_CTLFLAGS: Documentation Error

V8.2

There is an error in the description of Bit 1 of the MMG_CTLFLAGS system

parameter in the OpenVMS Performance Management manual. That description

should be corrected to read as follows:

"Reclamation enabled by out swapping processes that have been idle for

longer than LONGWAIT seconds. This occurs when the size of the free list

drops below the value of FREEGOAL."

3.18.9 HP OpenVMS System Analysis Tools Manual

For changes and updates to the HP OpenVMS System Analysis Tools Manual, see

Chapter 4.

3.18.10 HP OpenVMS Programming Concepts Manual

The following corrections pertain to the HP OpenVMS Programming Concepts

Manual:

3.18.10.1 Saving System Dumps

V8.3

The following changes should be made to the paragraph in Section 31.2, "Writing

a Privileged Routine (User-Written System Service)":

"As a protected image, your program does not have the entire operating system

programming environment at its disposal. Unless a module has the preﬁx SYS$

or EXE$, you must avoid calling it from an inner mode. In particular, do not

call LIB$GET_VM or LIB$RET_VM from an inner mode. You can call OpenVMS

RMS routines from executive mode but not from kernel mode."

LIB$GET_VM should be LIB$FREE_VM. You cannot call these LIBRTL routines

directly, and you cannot call any routines that might now or in the future call

these routines indirectly. This includes other routines within LIBRTL and the

user-mode C library, among other libraries.

3.19 HP OpenVMS DELTA/XDELTA Debugger Manual Update

V8.3

The HP DELTA debugger was made available on OpenVMS Integrity servers

Version 8.2-1. The HP OpenVMS DELTA/XDELTA Debugger Manual has been

revised in this release to include information about using DELTA on OpenVMS

Integrity servers.

3.19.1 HP OpenVMS Version 8.2 New Features and Documentation Overview:

Librarian Utility Corrections

The following release notes provide corrected information about the OpenVMS

Integrity servers Librarian utility.

3–18 General User Release Notes

General User Release Notes

3.19 HP OpenVMS DELTA/XDELTA Debugger Manual Update

3.19.1.1 /REMOVE Qualiﬁer Correction

In Section 4.8.2.3 of the HP OpenVMS Version 8.2 New Features and

Documentation Overview, the description of the enhanced library /REMOVE

qualiﬁer is incorrect. The correct information is as follows:

The /REMOVE qualiﬁer has been enhanced for the Integrity servers Librarian

utility. The format now allows you to specify the module instance of the symbol

to be removed. The enhanced /REMOVE qualiﬁer requests that the LIBRARY

command delete one or more entries from the global symbol table of an object

library.

3.19.1.2 Accessing ELF Object Libraries Correction

Section 4.8.3.2 of the HP OpenVMS Version 8.2 New Features and Documentation

Overview contains incorrect information. The following text replaces information

in that section:

Accessing ELF Object Libraries

ELF object modules are inherently random access modules, whereas OpenVMS

Alpha objects, text modules, and so on, are sequential. To allow random access, a

new library routine was created to map the ELF object modules into process P2

space so that applications can make random access queries. To recover virtual

address space from this mapping, another library routine was created to remove

this mapping. These new routines (LBR$MAP_MODULE and LBR$UNMAP_

MODULE) work only with ELF object libraries. These entry points are 64-bit

interfaces because they refer to P2 space.

Because of the random-access nature of ELF object ﬁles, the following operations

are not allowed on ELF object libraries:

LBR$GET_RECORD

LBR$SET_LOCATE

LBR$SET_MOVE

Because inserting modules into the library is a sequential operation, LBR$PUT_

RECORD is allowed on ELF object libraries. Because the ELF object modules are

not segmented into records, you need to provide the module’s on-disk size when

calling LBR$PUT_MODULE or upon the ﬁrst call to LBR$PUT_RECORD when

writing a module into the library.

The C code fragment in the following example illustrates how to use LBR$PUT_

RECORD to insert an object module:

bufdesc->dsc$a_pointer = &p0_buffer ;

bytes_to_transfer = module_size ;

while ( bytes_to_transfer ) {

transfer = MIN ( bytes_to_transfer ,

ELBR$C_MAXRECSIZ ) ;

bufdesc->dsc$w_length = transfer ;

status = lbr$put_record ( library_index ,

& bufdesc ,

& txtrfa ,

module_size ) ;

if ( (status & 1) == 0 )

break ;

bytes_to_transfer -= transfer ;

bufdesc->dsc$a_pointer += transfer ;

};

General User Release Notes 3–19

General User Release Notes

3.19 HP OpenVMS DELTA/XDELTA Debugger Manual Update

if ( (status & 1) == 1 )

status = lbr$put_end ( library_index ) ;

To avoid making several calls to LBR$PUT_RECORD, a new library routine,

LBR$PUT_MODULE, has been created.

3.19.2 HP OpenVMS RTL Library (LIB$) Manual Corrections

V8.2-1

The following sections provide additions and corrections to Version 8.2 of the HP

OpenVMS RTL Library (LIB$) Manual.

3.19.2.1 HP OpenVMS RTL Library (LIB$) Manual: Rounding Rule for LIB$CVT_DX_DX

V8.2-1

In the description of the LIB$CVT_DX_DX routine in the HP OpenVMS RTL

Library (LIB$) Manual, the following paragraph under ‘‘Guidelines for Using

LIB$CVT_DX_DX’’ should contain speciﬁc information about the rounding rule

that is used:

Results are always rounded instead of truncated, except for the case described

below. Note that loss of precision or range may be inherent in the destination

data type or in the NBDS destination size. No errors are reported if there is a

loss of precision or range as a result of destination data type.

This paragraph should be modiﬁed as follows:

Results are always rounded instead of truncated, except for when the source and

destination are both NBDS and no scaling is requested. That case is described

more fully in a later rule. LIB$CVT_DX_DX uses the VAX_ROUNDING rule.

Note that loss of precision or range may be inherent in the destination data

type or in the NBDS destination size. No errors are reported if there is a loss

of precision or range as a result of destination data type. For details about the

VAX_ROUNDING rule, refer to the description of CVT$CONVERT_FLOAT.

3.19.3 HP OpenVMS RTL Library (LIB$) Manual: Platform Restrictions

V8.2–1

The HP OpenVMS RTL Library (LIB$) Manual incorrectly identiﬁes the following

routines as being available on both Alpha and Integrity servers. These routines

are available only on Alpha:

• LIB$GET_CURR_INVO_CONTEXT

• LIB$GET_INVO_CONTEXT

• LIB$GET_INVO_HANDLE

• LIB$GET_PREV_INVO_CONTEXT

• LIB$GET_PREV_INVO_HANDLE

• LIB$PUT_INVO_REGISTERS

The HP OpenVMS RTL Library (LIB$) Manual also should specify that the

LIB$GET_UIB_INFO routine is available only on Integrity servers.

The routines relating to invocation contexts and invocation handles that are

Integrity servers only include the following:

• LIB$I64_CREATE_INVO_CONTEXT

• LIB$I64_FREE_INVO_CONTEXT

3–20 General User Release Notes

General User Release Notes

3.19 HP OpenVMS DELTA/XDELTA Debugger Manual Update

• LIB$I64_GET_CURR_INVO_CONTEXT

• LIB$I64_GET_CURR_INVO_HANDLE

• LIB$I64_GET_INVO_CONTEXT

• LIB$I64_GET_INVO_HANDLE

• LIB$I64_GET_PREV_INVO_CONTEXT

• LIB$I64_GET_PREV_INVO_HANDLE

For additional information about these routines, refer to the HP OpenVMS

Calling Standard.

3.19.4 HP OpenVMS System Manager’s Manual: IPC Commands Restriction

V8.2-1

Section 9.15, Using Interrupt Priority Level C (IPC), in the HP OpenVMS System

Manager’s Manual, Volume 1: Essentials incorrectly states that you can use

IPC commands on all Alpha and Integrity servers. This is not correct. The

documentation has been changed to include the following statement:

For OpenVMS Versions 8.2 and 8.2--1, you cannot use IPC commands

on Integrity servers or on ES47 or GS1280 Alpha systems if you booted

from a Graphic console.

C Prototype

int sys$putmsg (void *msgvec, int (*actrtn)(__unknown_params),

void *facnam, unsigned __int64 actprm);

Note that the return value from *actrtn is indeed checked to determine whether

or not the message is input.

The documentation source ﬁle has been corrected, and the correction will appear

in the next version of the HP OpenVMS System Services Reference Manual and in

online help.

3.20 Network Update Restrictions from Version 8.2 to Version 8.2–1

V8.2–1

OpenVMS Version 8.2–1 supports network update of the operating system from

Version 8.2 to Version 8.2–1. Network update is supported only over the core

I/O LAN cards on systems supported by OpenVMS Version 8.2. Refer to the HP

OpenVMS Version 8.2–1 for Integrity Servers Upgrade and Installation Manual

for more information.

In addition, there is also a hardware conﬁguration restriction for network

booting. Unlike Alpha consoles, where the speed and duplex setting for the

network adapter can be selected at the console, the Integrity servers console and

network boot drivers perform autonegotiation only. The network switch nearest

to the Integrity servers boot client must be set to autonegotiate for a successful

network boot. Failure to set the switch to autonegotiate may not complete the

network boot process.

3.21 Synchronous Data Links not Supported

OpenVMS does not support any synchronous data link hardware on Integrity

servers.

General User Release Notes 3–21

General User Release Notes

3.22 Duplex-Mode Mismatch Errors

V8.3

A duplex-mode mismatch condition occurs when a LAN device is operating in full-

duplex mode and the other end of the cable, typically a switch port, is operating

in half-duplex mode. The reverse is also true. A common network conﬁguration

error that results in a duplex mode mismatch condition occurs when the switch

port is set to autonegotiate the speed and duplex settings, and the LAN device is

set to a ﬁxed setting of full duplex. In this conﬁguration, autonegotiation by the

switch results in the selection of half-duplex mode and the LAN device is set to

full-duplex mode, and a duplex-mode mismatch occurs.

The consequence of a duplex-mode mismatch is typically a performance

degradation. In addition, the IEEE 802.3 speciﬁcation that describes the

autonegotiation process suggests that a duplex-mode mismatch can result in

data corruption. For most LAN devices, the only consequence of a duplex mode

mismatch is the performance degradation. For some LAN devices, packet data is

corrupted with good CRC, resulting in packet corruption undetected by the LAN

subsystem. These devices include all Broadcom-based NICs and embedded LOM

chips. On Alpha systems, these include the DEGPA, DEGXA, BCM5703 LOM on

the AlphaServer DS25, and any implementations using the dual-port BCM5704

chip. On Integrity systems, these include the A6847A, A6725A, A9782A, A9784A,

AB465A, and BCM5701 LOM on the rx2600; BCM5703 LOM on other systems;

and the A6794A.

In prior versions of OpenVMS, the LAN drivers attempt to detect the duplex-

mode mismatch condition. Once an hour while the condition exists, they issue a

console message and error log message warning of the condition.

In OpenVMS Version 8.3, the frequency of the messages is increased from once

per hour to once every 36 seconds for any Broadcom-based LAN devices. The

frequency remains at once per hour for non-Broadcom-based LAN devices. In

addition, to increase the visibility of these messages, the console messages are

sent to OPCOM and to the LANACP log ﬁle (SYS$MANAGER:LAN$ACP.LOG).

The purpose of this note is to underscore the importance of avoiding duplex-

mode mismatches, particularly when this condition results in undetected data

corruption for Broadcom-based devices.

Note that the LAN drivers detect a duplex mode mismatch condition by

monitoring device errors. The detection is not perfect, so the LAN drivers

refer to the condition as a "potential duplex-mode mismatch." Upon noticing these

messages, a system or network manager should inspect the LAN counters and

LAN device settings to ensure a duplex-mode mismatch condition does not exist.

3–22 General User Release Notes

System Management Release Notes

This chapter contains information that applies to system maintenance and

management, performance management, and networking.

For information about new features included in this version of the software, refer

to the HP OpenVMS Version 8.4 New Features and Documentation Overview.

4.1 SYS$TIMEZONE_RULE Logical Replaces Hyphen (-) with Caret

(^)

V8.4

Starting from Version 8.2 onwards, SYS$TIMEZONE_RULE logical is modiﬁed

to replace the ’-’ character with the ’^’ character. This change is done in TDF

to support DTSS. DTSS cannot handle the commonly used UNIX ’GMT-X’

timezone rules and does not support timezone rule strings that are identical to

the timezone name.

For example, the ’GMT-1’ timezone rule generates a SYS$TIMEZONE_RULE

string of ’GMT-1’. Due to the matching rule ﬁle name of ’GMT-1’ and rule string

of ’GMT-1’ caused DTSS not to function properly.

The CRTL and DTSS components are also modiﬁed to support this change.

For example, Timezone logical before this change:

"SYS$TIMEZONE_RULE" = "CET-1CEST-2,M3.5.0/02,M10.4.0/03"

Timezone logical after this change:

"SYS$TIMEZONE_RULE" = "CET^1CEST^2,M3.5.0/02,M10.4.0/03"

4.2 Issues with Time Zone Conﬁguration

V8.4

On OpenVMS Version 8.4, if you conﬁgure time zone to a zone that does not get

affected by the daylight saving time (DST) changes, it results in the following

error message on the operator’s terminal at a very high frequency:

%TDF-F-SMNSUBFAIL, Attempt to compute delta in Smithsonian time

failed, status = 001583EC, terminating.

Note

OpenVMS Version 8.4 upgrade kit is recommended only to those

customers who will be conﬁguring their time zone to a zone that gets

affected by the DST changes.

System Management Release Notes 4–1

System Management Release Notes

4.2 Issues with Time Zone Conﬁguration

Workaround

Deassign the

SYS$DST_DELTA_TIME

logical, when the error message appears on

the system.

$ DEASSIGN/EXECUTIVE_MODE/SYSTEM SYS$DST_DELTA_TIME

4.3 OpenVMS as a Guest Operating System on Integrity VM

OpenVMS Version 8.4 now supports HP Virtualization and can be installed as

a guest operating system on HP Integrity Virtual Machines (Integrity VM). For

more information about product speciﬁc limitations, see the respective product

documentation.

This section describes known problems and restrictions in OpenVMS guest on

Integrity VM.

4.3.1 "Guest Punishment" Scenarios

V8.4

Scenario 1

A problem in Integrity VM Version 4.1 Field Test Evaluation Kit for OpenVMS

Version 8.4 causes OpenVMS guests to fail with the following message displayed

on the guest’s MP console:

*** A fatal error has occurred -- VM terminated ***

**** Dumping Guest Image ****

**** Done with dump (nnnnnKbytes) ****

At the same time, the Integrity VM monitor log (found on the VM Host

in /var/opt/hpvm/common/hpvm_mon_log) must include guest punishment

information as follows:

Assertion failed mmxlate.c:nnn: PTE_TYPE(pte) == PTE_TYPE_TRPT || PTE_TYPE(pte) == PTE_TYPE_SPPT

scopeDeact EA0C000000000000

===============================================================================

Guest punishment: Virtual Machine Monitor Assertion Failed (CPUnnnnnnn)

===============================================================================

This problem occurs when a privileged hardware instruction (for example, mov r1

= psr) is executed in process space, rather than in system space (that is, in the

VMS executive).

When an application uses the $CMKRNL system service to enter kernel mode, it

can execute privileged hardware instructions in process space. The kernel mode

routines may be within the main image of the application, or within a shareable

image. To run such an application, the user must have CMKRNL privilege, or the

image must be installed: a main image with privileges, and a shareable image as

a protected shareable image.

The application may be part of OpenVMS, a local customer application, or may be

from a third-party.

If the problem occurs, a possible workaround is to install the image that performs

the privileged hardware instructions using /RESIDENT. This ensures that the

code of the image is in the system space.

4–2 System Management Release Notes

System Management Release Notes

4.3 OpenVMS as a Guest Operating System on Integrity VM

Examples

In the following examples, the image PUNISH_SHR.EXE is a protected shareable

image that uses $CMKRNL to execute privileged hardware instructions. The

image PUNISH_MAIN.EXE is an executable image that calls routines in

PUNISH_SHR.EXE. The output is as seen at the guests MP console in each

case.

a. The protected shareable image is installed without /RESIDENT:

$ set process/privilege=cmkrnl

$ install add sys$disk:[]punish_shr.exe/protect/share

$ set process/privilege=nocmkrnl

$ define/user punish_shr sys$disk:[]punish_shr.exe

$ run punish_main

Changing mode to kernel to read PSR

*** A fatal error has occurred -- VM terminated ***

**** Dumping Guest Image ****

**** Done with dump (22864Kbytes) ****

This is the VM Host view of the guest punishment in the Integrity VM

monitor log at the same instant:

Assertion failed mmxlate.c:430: PTE_TYPE(pte) == PTE_TYPE_TRPT || PTE_TYPE(pte) == PTE_TYPE_SPPT

scopeDeact EA0C000000000000

============================================================================

Guest punishment: Virtual Machine Monitor Assertion Failed (CPU2000000)

============================================================================

b. The protected shareable image is installed with /RESIDENT:

$ set process/privilege=cmkrnl

$ install add sys$disk:[]punish_shr.exe/protect/share/resident

$ set process/privilege=nocmkrnl

$ define/user punish_shr sys$disk:[]punish_shr.exe

$ run punish_main

Changing mode to kernel to read PSR

PSR = 000000100a0ae010

This problem will be ﬁxed in a future version of Integrity VM.

Scenario 2

OpenVMS guests will fail with the following message displayed on the guest’s MP

console:

*** A fatal error has occurred -- VM terminated ***

**** Dumping Guest Image ****

**** Done with dump (nnnnnKbytes) ****

The Integrity VM monitor log (found on the VM Host in

/var/opt/hpvm/common/hpvm_mon_log) must include guest punishment

information as follows:

ERROR: Could not allocate pinned memory (256 bytes)

Pinned pool: MaxChunk: 0x0000000000000000 Free: 0x0000000000000000

Pinned pool chunks:

Resource map: PinnedMemAlloc limit=0xea0a0000025e0870

Assertion failed firmware.c:94: argArray

=============================================================================

Guest punishment: Virtual Machine Monitor Assertion Failed (CPUc000000)

System Management Release Notes 4–3

System Management Release Notes

4.3 OpenVMS as a Guest Operating System on Integrity VM

=============================================================================

This problem occurs when VM Monitor runs out of memory to allocate for guests.

The workaround for this problem is to restart VM Monitor by entering the

following commands on the Host:

# /sbin/init.d/hpvm stop

# /sbin/init.d/hpvm start

This problem will be ﬁxed in a future version of Integrity VM.

4.3.2 Increased CPU Consumption After Shutdown

V8.4

OpenVMS guest has a known issue where the CPU consumption

of the Host increases, in case the guest is shutdown using the

SYS$SYSTEM:SHUTDOWN.COM command procedure using "NONE" as the

shutdown options. The CPU consumption on the Host remains high as long

as the VMS guest stays in the "P000>>>" ﬁrmware prompt. After the guest is

rebooted the Host CPU consumption returns back to normal.

The suggested workaround for this problem is to shutdown VMS guest using

"POWER_DOWN" as the shutdown options.

A known consequence of using this option is that, the virtual machine is

shutdown and has to be restarted by the MP command "pc -on" in the virtual

console or alternately enter the following command on the Host:

# hpvmstart -P <<OpenVMS guest name>>

This will be ﬁxed in a future release.

4.3.3 OpenVMS Guest Does not Support Attached I/O Devices

V8.4

The OpenVMS guest does not support attached devices such as CD/DVD burners,

media changers and tape devices. If you want to use tape devices, you can

connect them to a physical system that is in a cluster with OpenVMS guest and

TMSCP serves the tape devices.

4.3.4 Networking or Storage Interface Support

V8.4

The OpenVMS guest supports only Accelerated Virtual I/O (AVIO) interface.

Integrity VM commands allows you to conﬁgure VIO devices to a guest and these

devices may not give any apparent errors during the startup. However, VIO

devices are not part of the supported conﬁguration of a guest running OpenVMS

Operating System.

4.4 Provisioning OpenVMS Using HP SIM

The following release notes pertain to provisioning on OpenVMS.

4.4.1 Provisioning OpenVMS Guest Limitation

V8.4

Provisioning OpenVMS using HP SIM, Version 4.0 is not supported with

OpenVMS as a Guest Operating System on Integrity VM.

4–4 System Management Release Notes

System Management Release Notes

4.4 Provisioning OpenVMS Using HP SIM

4.4.2 System Firmware

V8.4

The system ﬁrmware version of BL860c and BL870c servers must be at 4.21. The

system ﬁrmware version of rx3600 and rx6600 servers must be at 4.11.

4.4.3 Provisioning Multiple Servers

V8.4

• HP SIM provisioning using InfoServer can provision up to eight servers

simultaneously.

• HP SIM provisioning using vMedia can provision only one server at a time.

4.4.4 Provisioning From HP SIM Central Management Server

V8.4

OpenVMS can be provisioned from an HP SIM Central Management Station, an

HP ProLiant server running Microsoft Windows.

4.4.5 InfoServer Name Length

V8.3-1H1

The InfoServer name must be less than 12 characters long for provisioning to

work. This is a temporary restriction.

4.4.6 OpenVMS InfoServer and the Integrity servers on the Same LAN

V8.3-1H1

The OpenVMS InfoServer and the Integrity servers must be on the same Local

Area Network (LAN) to provision the server blade.

4.4.7 EFI Firmware

V8.3-1H1

The EFI ﬁrmware for the BladeSystem must be at version 5.0 or later.

4.4.8 Management Processor

V8.4

The Management Processor must be running the Advanced iLO2 ﬁrmware.

4.4.9 OpenVMS TCP/IP Provisioning Limitation

V8.4

The TCP/IP server components BIND, LPD, LBROKER, and SMTP, if selected

to be enabled on the target server, do not start up when OpenVMS TCP/IP is

conﬁgured through Provisioning.

The workaround for this problem is to conﬁgure and restart these services

manually after conﬁguring TCP/IP with Provisioning.

System Management Release Notes 4–5

System Management Release Notes

4.4 Provisioning OpenVMS Using HP SIM

4.4.10 Limitation with Deploying OpenVMS on Multiple Target Servers

Simultaneously

V8.4

There is a known issue with the TFTP server on Infoserver, which may prevent

deploying OpenVMS Version 8.4 simultaneously on two or more target servers

when using InfoServer booting with memory disk. In this scenario, InfoServer

booting on the target server reports network errors when loading the memory

disk similar to the below trace. These errors may prevent booting the target

server successfully from InfoServer.

Shell> lanboot -dn sysmg3

Client MAC Address: 00 11 22 33 44 55

Client IP Address: 1.2.3.4

Subnet Mask: 255.255.254.0

BOOTP Server IP Address: 1.2.3.5

DHCP Server IP Address: 0.0.0.0

Boot file name: LDA30:[VMS$COMMON.SYSEXE]VMS_LOADER.EFI

Retrieving File Size.

Retrieving File (TFTP).Loading memory disk from IP 1.2.3.5

Warning - Unable to open SYS$LOADABLE_IMAGES:SYS$PLATFORM_SUPPORT.EXE, status = 0x54

*** SYSTEM MAY NOT BE BOOTABLE. Continuing...

...........

Warning - Unable to open SYS$SYSTEM:SYSBOOT.EXE, status = 0x54

*** SYSTEM MAY NOT BE BOOTABLE. Continuing...

...

Warning - Unable to open SYS$LOADABLE_IMAGES:EXCEPTION.EXE, status = 0x54

*** SYSTEM MAY NOT BE BOOTABLE. Continuing...

TFTP error, status = 8000000000000012, attempting retry

To workaround this issue, when deploying OpenVMS Version 8.4 simultaneously

on two or more target servers with Provisioning, avoid using InfoServer boot

with memory disk option as follows: In Step 2 of Provisioning in HPSIM GUI,

under the "LAN Boot Settings" section of all target servers, select the setting for

OpenVMS Version combo box as "V8.3-1H1 or below".

4.5 Insight Dynamics - Virtual Server Environment for OpenVMS

This section describes the known issues and limitations in Insight Dynamics -

Virtual Server Environment (ID-VSE) Version 4.1 for OpenVMS.

4.5.1 Utilization Data Collection Fails

V8.4

When an attempt is made to collect utilization data in Capacity Advisor for an

OpenVMS guest on Integrity VM, the operation fails and the following error

message is displayed:

The system has no workload defined. Make sure to select

Tools->VSE Management...in HP-SIM before running this command

for the first time. For HPVM Guests, please be sure that the

HPVM wbem provider is properly configured.

4–6 System Management Release Notes

System Management Release Notes

4.5 Insight Dynamics - Virtual Server Environment for OpenVMS

Workaround

1. Click Tools –> VSE Management.... The Virtualization Manager page

appears.

2. Select OpenVMS guest.

3. Select Tools –> System Information –> System Page. The System Page...

appears.

4. Select the Tools & Links tab on the System Page, and then select Edit

System Properties. The Edit System Properties page appears.

5. In the Product Description section, select the Operating System for Tool

Filtering property. Click the drop-down menu and select HP OpenVMS and

click OK to apply the changes.

After making these changes, you can return to Capacity Advisor to collect and

view utilization data proﬁle for the OpenVMS guest.

4.5.2 Problem While Creating a New or Replacement Simulated System

V8.4

When trying to create a new or replacement simulated OpenVMS system in a

Capacity Advisor Scenario, the Select OS Type in the "System Type and Size"

section does not list "OpenVMS".

Workaround

For a new or replacement OpenVMS system, select the different operating system.

To do so, follow these steps:

1. In the "System Type and Size" section, select the Select OS Type property.

2. Click the drop-down menu and select HP-UX.

3. Click OK to apply the changes.

4.5.3 Utilization Data not Available for OpenVMS Sub-OS Workloads

V8.4

The OpenVMS Utilization WBEM provider supports collecting utilization data

only for OpenVMS whole-OS workloads. It does not support sub-OS (monitored

and managed) workloads under OpenVMS. This has the following impact on

ID-VSE:

• Virtualization Manager and Capacity Advisor display utilization data for

whole-OS workloads only.

• Utilization data from sub-OS workloads running under OpenVMS cannot be

used for capacity planning in Capacity Advisor.

4.5.4 Insight Software Features not Supported on OpenVMS

V8.4

The following Insight software features are not supported on OpenVMS:

• Application Discovery

• iCAP Manager

• Process Resource Manager (PRM)

• Logical Server Management

System Management Release Notes 4–7

System Management Release Notes

4.5 Insight Dynamics - Virtual Server Environment for OpenVMS

• Virtual Connect Enterprise Manager (VCEM)

• Partition Manager

• BladeSystem Integrated Manager

• GiCAP Group Manager

• Virtual Machines Manager

• Insight Power Manager (IPM)

• VSE troubleshooting for OpenVMS Managed Nodes - This refers to ’Check

VSE CMS to Managed Node Communication...’ and ’Check VSE Managed

Node Conﬁguration...’ options under ’Diagnose’ menu -> ’Troubleshoot VSE

Management....’

• Conﬁgure VSE agents for OpenVMS - This refers to all options under the

’Conﬁgure’ menu -> ’Conﬁgure VSE agents...

• VSE Agentless data collection - This refers to all options under the ’Conﬁgure’

menu -> ’Conﬁgure VSE Agentless agents...

• Import of Capacity Advisor Data from OVPA and PMP - This refers to all

options under Optimize menu -> Capacity Advisor -> Import Capacity Advisor

Data

4.6 Performance Enhancements

V8.4

The following performance enhancements have been made to the OpenVMS

Version 8.4 release.

4.6.1 Enhancements to Write Bitmaps

V8.4

Write Bitmaps (WBM) is a feature used by OpenVMS during minimerge and

minicopy operations of Shadowing minimerge and minicopy. Information, about

which blocks on a disk are written, is transmitted to other nodes within the

cluster. The following updates have been made in this release.

4.6.1.1 WBM_MSG_INT Parameter Updates

V8.4

The WBM_MSG_INT parameter indicates the time by which a SetBit message

can be delayed when it is in buffered mode. If the SetBit buffer does not ﬁll with

SetBit messages by this time interval, then the message is sent. The parameter

is in milliseconds, however, the conversion factor used for this timer was off by

a factor of 10. Earlier, a WBM_MSG_INT value of 10 was resulting in a 100

millisecond delay when in buffered mode. This problem is corrected so that a

value of 10 now indicates only a 10 millisecond delay.

4.6.1.2 WBM_MSG_UPPER and WBM_MSG_LOWER Parameter Updates

V8.4

WBM_MSG_UPPER is the threshold used to determine if a switch should occur

to buffered message mode, when operating in single message mode. If WBM_

MSG_UPPER or more SetBit operations are done in a 100 millisecond window,

the messaging mode will be switched to buffered mode. The default value is 80.

4–8 System Management Release Notes

System Management Release Notes

4.6 Performance Enhancements

WBM_MSG_LOWER is the threshold used to determine if a switch should occur

to single message mode, when operating in buffered message mode. If WBM_

MSG_LOWER or fewer SetBit operations are done in a 100 millisecond window,

the messaging mode will be switched to single mode. The default value is 20.

4.6.1.3 Asynchronous SetBit Messages

V8.4

There can be multiple master bitmap nodes for a shadow set. Currently, SetBit

messages are sent to the multiple master bitmap nodes synchronously. Only

when the response for the SetBit message is received from the ﬁrst remote

master bitmap node, is the message sent to the next master bitmap node. When

done with all of the remote master bitmap nodes, the I/O is resumed.

SetBit messages are now sent to all multiple master bitmap nodes

asynchronously. I/O operation is resumed when the responses from all the master

bitmap nodes are received. This reduces the stall time of the I/O operation by the

write bitmap code.

4.6.1.4 Reduced SetBit Messages for Sequential I/O

V8.4

If sequential writes occur to a disk, it results in sending Setbit messages that set

sequential bits in the remote bitmap. The WBM code will now recognize where

a number of prior bits in the bitmap have already been set. In this scenario, the

WBM code will set additional bits so that if sequential writes should continue,

fewer Setbit messages are required. Assuming the sequential I/O continues,

the number of Setbit messages will be reduced by about a factor of 10 and thus

improve the I/O rate for sequential writes.

4.6.2 Exception Handling Performance Improvements (Integrity servers Only)

V8.4

The OpenVMS Version 8.4 caches the decoded unwind data. The cache is used

in the user-callable calling standard routines, during the exception handling.

These calling standard routines are also used in the RTLs, to implement

programming language constructs like the try/throw/catch constructs in C++ and

the setjmp/longjmp constructs in C programming language.

In case of unexpected errors, the cache can be disabled temporarily using the

VMS system parameter, KTK_D3. Its default value of zero enables the cache. A

value of one disables the cache. The special parameter, KTK_D3 may have been

used by HP supplied debug/test images. If you had such test images on your

system, make sure that it is reset to its default value zero. The ability to disable

the cache will be removed in the OpenVMS Version 8.4 main release.

4.6.3 Exception Handling (Integrity servers Only)

Some performance improvements have been made to exception handling for

OpenVMS Integrity server systems. The change will reduce the overhead of

exception handling in some, but not all cases of exception handling.

System Management Release Notes 4–9

System Management Release Notes

4.6 Performance Enhancements

4.6.4 Image Activation (Integrity servers Only)

During image activation and over the life of the image, paging IO brings pages

of the image into memory. On Integrity server systems, an I-cache ﬂush need

to be performed on these pages in case the page has code that is executed. This

resulted on the I-cache ﬂush occurring on many pages that would never be

executed. To avoid the I-cache ﬂush on pages that are never executed, the I-cache

is now only done on pages when an instruction is ﬁrst executed on the page. This

avoids the I-cache ﬂush on the pages that are never executed and provides an

overall system performance beneﬁt.

4.6.5 Global Section Creation and Deletion

Performance improvements have been made to areas of the operating system that

create and delete various types of global sections. The beneﬁts of the changes will

only be seen on large SMP systems as a reduction in MP Synch.

4.6.6 Dedicated CPU Lock Manager

The Dedicated CPU Lock Manager is a feature typically only turned used on

systems with 16 or more CPUs and very high locking rates. Improvements have

been made to the Dedicated CPU Lock Manager that results in an increase in the

rate at which locking operations can be performed.

4.6.7 Ctrl/T Alignment Faults

A Ctrl/T operation at a terminal resulted in a number of alignment faults. These

have been corrected for OpenVMS Version 8.4.

4.7 Error and Warning Messages from ACPI During Boot

V8.4

The following message may be displayed by VMS during boot on cell-based

machines (for example, rx8640 or rx7640):

ACPI Error (utmutex-0430): Mutex [1] is not acquired, cannot release [20071219]

The following message may be displayed by VMS during boot on certain systems

that have power management enabled (for example, an rx2660 with the latest

processors):

ACPI Warning (nseval-0250): Excess arguments - method [_OST] needs 3, found 7 [20080701]

These messages can be ignored. They will be ﬁxed in a future release.

4.8 Large Device Name Support for Accounting Utility

V8.4

The accounting utility is modiﬁed to handle long device names. It can now

display device names having seven characters or more, for example, Terminal

(TNA) of unit number >9999, MBA device of unit number >999, and other large

device names such as TNA10000:, MBA1000:, and so on.

Earlier, the utility displayed arbitrary characters if a device name exceeded seven

characters. A new accounting record version (version4) is used to write new

records into the accounting.dat ﬁle and the utility is modiﬁed appropriately to

read and display these new records.

4–10 System Management Release Notes

System Management Release Notes

4.9 PAGED_LAL_SIZE New System Parameter

PAGED_LAL_SIZE sets the maximum size, in bytes, to use the page dynamic

pool lookaside lists.

4.9.1 Paged Pool Lookaside Lists

V8.4

Paged dynamic pool now allows the use of lookaside lists to increase system

performance in some cases. It is controlled by SYSGEN parameter PAGED_LAL_

SIZE and is off (0) by default.

If the variable paged pool freelist becomes fragmented, you might beneﬁtby

enabling the use of these lookaside lists. The SYSGEN parameter PAGED_LAL_

SIZE sets the maximum size, in bytes, to use for these lookaside lists. Packets

larger than this size will still be allocated from the variable paged pool freelist. A

modest value, 512 bytes, has been found to help systems doing intensive logical

name creation and deletion operations.

Since the parameter is dynamic it can be enabled, adjusted, or disabled as

needed. If it was enabled and then lowered there might be some packets on

the paged pool lookaside lists that are no longer actively in use. These show up

as "Over-limit Lookaside Blocks" in DCL’s and SDA’s

SHOW MEMORY/POOL/FULL

command. These packets were used before but are now larger than the new

PAGED_LAL_SIZE. These packets will be used again if the SYSGEN parameter

is increased to include them, or if there is a paged pool shortage and the packets

are reclaimed from the lookaside lists.

To help prevent a runaway condition where packets on a lookaside list starts to

consume most or all of paged pool, the paged pool lookaside lists will not be used

for packets in the last quarter of paged dynamic pool. If there is a paged pool

memory shortage packets on the lookaside lists will be reclaimed as well.

If disabled, at the default value of 0, paged pool behaves as it did in previous

versions of OpenVMS, allocating and deallocating packets from the paged pool

variable freelist.

4.10 2 TiB Disk Volume Support Restrictions

V8.4

OpenVMS Version 8.4 supports disk volumes up to 2 TiB in size with the

following restrictions:

• With OpenVMS versions prior to version 8.4, there is no support for volumes

larger than 1 TiB in size or for mounting of volumes larger than 1 TiB. To

prevent accidental mounts on earlier versions of OpenVMS, the latest patches

for MOUNT will explicitly disallow mounting of volumes larger than 1 TiB on

such systems.

• The lexical function F$GETDVI( ) with items codes MAXBLOCK,

FREEBLOCKS, EXPSIZE, and VOLSIZE will return a negative number

if the value is larger than 1 TiB. This is due to the fact that DCL does 32-bit

signed integer arithmetic and comparisons. Command procedures that use

F$GETDVI( ) with these item codes may need to be modiﬁed to work with

volumes larger than 1 TiB. For more information about handling numeric

values outside the range of DCL integer representation using DCL, see the

HP OpenVMS DCL Dictionary.

System Management Release Notes 4–11

System Management Release Notes

4.11 Conﬁguring SAS Tape Drives

V8.4

SAS tape drives must be named and conﬁgured using the same commands that

are used to conﬁgure Fibre Channel tape drives. For more information, see the

section 7.5 "Fibre Channel Tape Support" in the Guidelines for OpenVMS Cluster

Conﬁgurations.

4.12 External SAS Disk Device Naming

V8.4

The external SAS drives that are served by non-Smart array controllers can be

conﬁgured as $3$DGA<UDID>, where UDID is unique device ID for the LUN.

Note that Fibre Channel disk device names use an allocation class value of 1

whereas external SAS disk device names use an allocation class value of 3 to

differentiate a SAS device from an Fibre Channel device.

4.13 External Authentication

This section contains release notes pertaining to external authentication.

External authentication is an optional feature introduced in OpenVMS Version

7.1 that enables OpenVMS systems to authenticate designated users with their

external user IDs and passwords. For detailed information about using external

authentication, see the HP OpenVMS Guide to System Security.

Note

A special note for external authentication users.

If you are using the SYS$ACM-enabled LOGINOUT.EXE and SETP0.EXE

(SET PASSWORD) images that supports external authentication, an

upgrade to higher version of OpenVMS will restore the setup.

If you are using the password policy for customized password processing,

it is necessary to restart the ACME Server after the Password Policy

shareable image is installed, and the LOAD_PWD_POLICY system

parameter is enabled.

Please see the SYS$HELP:ACME_DEV_README.TXT on how to install

the ACMELOGIN kit.

4.13.1 External Authentication and Password Policy

V8.4

If you are using external authentication to authenticate users against a source

other than the SYSUAF.DAT, and using the password policy for customized

password processing, it is necessary to restart the ACME Server after the

Password Policy shareable image is installed, and the LOAD_PWD_POLICY

system parameter is enabled.

Use the following command to restart the ACME Server:

$ SET SERVER ACME_SERVER /RESTART

4–12 System Management Release Notes

System Management Release Notes

4.13 External Authentication

4.13.2 Integrity servers External Authentication Support

V8.2

The Advanced Server for OpenVMS V7.3A ECO4 (and later) product kit contains

standalone external authentication software for Integrity servers in an OpenVMS

cluster.

If you want to enable NT LAN Manager external authentication on OpenVMS

Cluster member nodes running Integrity servers, you must copy the Integrity

servers standalone external authentication images from an Alpha system on

which the Advanced Server is installed to the Integrity servers member node, and

complete the setup as described in the Advanced Server kit release notes.

4.13.3 SET PASSWORD Behavior Within a DECterm Terminal Session

V7.2

A DECterm terminal session does not have access to the external user name

used for login and must prompt for one during SET PASSWORD operations. The

external user name defaults to the process’s OpenVMS user name. If the default

is not appropriate (that is, if the external user name and mapped OpenVMS user

name are different), you must enter the correct external user name.

The following example shows a SET PASSWORD operation initiated by a user

with the external user name JOHN_DOE. The mapped OpenVMS user name is

JOHNDOE and is the default used by the SET PASSWORD operation. In this

case, the default is incorrect and the actual external user name was speciﬁed by

the user.

$ set password

External user name not known; Specify one (Y/N)[Y]? Y

External user name [JOHNDOE]: JOHN_DOE

Old password:

New password:

Verification:

%SET-I-SNDEXTAUTH, Sending password request to external authenticator

%SET-I-TRYPWDSYNCH, Attempting password synchronization

4.13.4 No Password Expiration Notiﬁcation on Workstations

V7.1

In the LAN Manager domain, a user cannot log in once a password expires.

PC users receive notiﬁcation of impending external user password expiration and

can change passwords before they expire. However, when a user logs in from an

OpenVMS workstation using external authentication, the login process cannot

determine whether the external password is about to expire. Therefore, sites that

enforce password expiration and whose users do not primarily use PCs can choose

not to use external authentication for workstation users.

4.13.5 Restriction in ACME_SERVER Process (Integrity servers only)

The SET SERVER ACME/CONFIG=THREAD_MAX command is ignored on

Integrity servers for this release because only one worker thread is active.

System Management Release Notes 4–13

System Management Release Notes

4.13 External Authentication

Note

Do not increase the number of threads on Integrity servers. Increasing

the number of threads on Integrity servers might lead to ACME_SERVER

process crash and login failures.

4.14 Itanium Primary Bootstrap (IPB) Fails to Find the Valid Dump

Devices

V8.4

Connecting a bridged device such as, AD221, HP PCIe combo Card on the

PCI bus, where dump devices (DOSD) are conﬁgured on another HBA that is

already connected may cause the PCI bus numbering of the dump devices to be

renumbered and making it difﬁcult to ﬁnd the valid dump devices.

Workaround

After connecting a new I/O card, validate the boot/dump option. Then, refresh the

DUMP_DEV and boot device list.

4.15 SHUTDOWN.COM Changes

V8.4

SHUTDOWN.COM

is modiﬁed to execute a pre-queue system shutdown procedure

SYSHUTDWN_0010.COM if it is present. The template contains three sample

routines that can help force the queue system to shutdown and restart or failover

faster.

4.16 OpenVMS Cluster Systems

The release notes in this section pertain to OpenVMS Cluster systems.

4.16.1 Cluster over IP (IP Cluster Interconnect)

HP OpenVMS Version 8.4 is enhanced with the Cluster over IP feature. This

feature provides the ability to form clusters beyond a single LAN or VLAN

segment using industry standard Internet protocol. It also provides improved

disaster tolerant capability to OpenVMS clusters.

This section describes known problems and restrictions in Cluster over IP.

4.16.1.1 Software Requirements

V8.4

Cluster over IP is available only on OpenVMS Version 8.4 Alpha and Integrity

servers. Cluster over IP also requires HP TCP/IP services for OpenVMS, Version

5.7.

4.16.1.2 Integrity servers Satellite Node and Bootserver in the Same LAN

V8.4

An Integrity server satellite node must be in the same LAN as its boot server for

the satellite node to initialize cluster over IP successfully and to join the cluster

successfully.

It is also necessary to have LAN cluster communication between Integrity servers

satellite node and the boot server for the satellite node to be able to initialize

cluster over IP during the satellite bootup.

4–14 System Management Release Notes

System Management Release Notes

4.16 OpenVMS Cluster Systems

4.16.1.3 Alpha Satellite Node Requires LAN Channels With Disk Server

V8.4

Alpha satellite boot fails in an IP only environment. That is, while booting an

Alpha satellite, if all the nodes, including the boot servers, are using only IP

channels for cluster communication, the satellite boot fails with the following

message:

cluster-W-PROTOCOL_TIMEOUT, NISCA protocol timeout %VMScluster-I-REINIT_WAIT,

Waiting for access to the system disk server

4.16.1.4 IPv6 Support

V8.4

Cluster over IP does not support IPv6 type address for cluster communication

interface.

4.16.1.5 Dynamic Host Conﬁguration Protocol (DHCP) or Secondary Address Support

V8.4

Cluster over IP requires the addresses that are used for cluster communication,

which are static, primary address on that interface. Furthermore, IP address

used for cluster communication must not be used for Failsafe conﬁguration.

4.16.1.6 Multiple IP Interface Conﬁguration

V8.4

If you conﬁgure multiple IP interface with the same default gateway, loss of

communication on any interface may result in disrupted cluster communication

with CLUEXITS.

4.16.1.7 ifconﬁg Command Usage

V8.4

If the interface used for cluster communication is reactivated by ifconﬁg, it

results in losing cluster communication to other nodes and also results in cluexit

of nodes.

4.16.1.8 Multiple Gateway Conﬁguration

V8.4

Cluster over IP conﬁguration information is stored in the conﬁguration ﬁles,

which are loaded early in the boot time. This conﬁguration information also

includes the default route or gateway that is used by TCP/IP. Currently, only one

default route can be entered in the conﬁguration ﬁle and used during the node

bootup.

4.16.1.9 Block Transfer XMIT Chaining

V8.4

PEdriver emulates each IP interface used for cluster communication similar to

lan interface (BUS). An IP bus will have the characteristics of Xchain_Disabled

status as shown. This means that the block transfer packets transmitted through

TCP/IP are copied from the PEdriver to the TCP/IP buffers.

System Management Release Notes 4–15

System Management Release Notes

4.16 OpenVMS Cluster Systems

$ mc scacp show ip

NODEG PEA0 Device Summary 16-FEB-2009 12:29:15.92:

Device Errors + Mgt Buffer MgtMax Line Total Current

Device Type Events Status Priority Size BufSiz Speed Pkts(S+R) IP Address

------ ---- ------ ------ -------- ----- ------ ----- --------- -----------

IE0 184 Run Online 0 1394 0 N/A 1419711 15.146.235.222

XChain_Disabled

4.16.1.10 LANCP for Downline Load

V8.4

Cluster over IP requires LANCP, instead of DECnet for downline load since the

changes related to conﬁguring cluster over IP and enabling cluster over IP is

available only with CLUSTER_CONFIG_LAN.COM. This restriction will be ﬁxed

in the future release of HP Clusters.

4.16.1.11 Duplex Mismatch

V8.4

A duplex mode mismatch or a change in duplex mode from half to full on the host

duplex can result in CLUEXIT when IP is used for cluster communication. It is

recommended to check for the duplex mismatch issues to avoid cluexit.

4.16.1.12 Conﬁguring a Node During Upgrade

V8.4

If you are upgrading from prior versions to Version 8.4, you cannot enable Cluster

over IP. When upgrading it does not call CLUSTER_CONFIG[_LAN] procedure,

which is required for enabling Cluster over IP. Hence, the node joins the existing

cluster in which it is the member before upgrading.

For enabling Cluster over IP, you must call CLUSTER_CONFIG_LAN procedure

explicitly after upgrading.

This restriction will be removed in a future release.

4.16.2 OpenVMS Cluster Support for Integrity VM

V8.4

OpenVMS for Integrity servers Version 8.4 is supported as a guest operating

system on Integrity VM. OpenVMS guest can be conﬁgured in a cluster.

4.16.2.1 Cluster Interconnect for OpenVMS Guest

V8.4

OpenVMS guest can use both LAN or Cluster over IP (IPCI) to communicate with

other nodes in the cluster.

4.16.2.2 MSCP Support for Clusters in Integrity VM Environment

V8.4

MSCP is used to provide shared storage capability in cluster consisting of

OpenVMS guest systems.

4.16.2.3 Online Migration Support

V8.4

Online migration of OpenVMS guest that are part of cluster is not supported.

4–16 System Management Release Notes

System Management Release Notes

4.16 OpenVMS Cluster Systems

4.16.3 Mixed Platform Support

V8.2

• A supported production cluster containing an Integrity servers cannot

include a VAX system. VAX systems can be included in these clusters for

the purposes of development and migration with the understanding that any

problems arising from the existence of VAX systems in these clusters will

result in the need for either the VAX or Integrity servers to be removed. See

the OpenVMS Cluster Software SPD for more information.

• Currently, only two architectures are allowed for supported production

environments in an OpenVMS Cluster system. Refer to the HP OpenVMS

Version 8.2 Upgrade and Installation Manual for a list of supported cluster

conﬁgurations.

4.16.4 Satellite Systems using Port Allocation Class

V8.2

Integrity server Satellite systems that use device naming (also known as port

allocation classes) require an additional step to operate correctly in this release.

On the satellite boot server node, edit the ﬁle device:

[SYSn.SYSCOMMON.SYS$LDR]SYS$MEMORYDISK.DAT

where device is the disk that contains the satellite’s root and where nis the root

of the satellite system) and add the following line to the ﬁle:

SYS$SYSTEM:SYS$DEVICES.DAT, text

You can safely ignore the "Do Not Edit" comment at the top of the ﬁle in this

case. The list of ﬁles in SYS$MEMORYDISK.DAT is not order-dependent. This

problem is expected to be resolved for the ﬁnal release.

4.17 Mixed-version Cluster Compatibility of a Six-member

Shadowset

V8.4

OpenVMS Version 8.4 supports "Extended Membership" volume shadowing

feature. This feature allows shadowsets to have more than three and up to

six-members. This feature is enabled when a fourth member is added to the

shadowset. Following are some of the important points in a mixed-version

OpenVMS cluster:

• To use the "Extended Membership" shadowing feature, all the systems that

mount the shadowset must be running OpenVMS Version 8.4.

• If you attempt to mount a shadowset on an OpenVMS Version 8.4 system

using "Extended Memberships" shadowing feature, the mount fails if the

shadowset is already mounted on systems with prior versions of OpenVMS in

the cluster.

• If you attempt to mount a shadowset on a system that is not capable of

"Extended Memberships" shadowing feature on prior versions of OpenVMS,

the mount fails if shadowset is already mounted on an OpenVMS Version 8.4

system in the cluster using the "Extended Memberships" shadowing feature.

System Management Release Notes 4–17

System Management Release Notes

4.17 Mixed-version Cluster Compatibility of a Six-member Shadowset

• Once the shadowset has been enabled to use "Extended Memberships"

shadowing feature, the characteristic is maintained even if the membership

is reduced to less than four members. The characteristic is retained until the

shadowset is dismounted clusterwide.

• This shadowing feature is not ported onto OpenVMS VAX. If a shadowset is

mounted on OpenVMS Alpha or OpenVMS Integrity servers without enabling

this feature, the shadowset will mount on the OpenVMS VAX systems. The

Virtual Unit characteristic voting ensures compatibility.

4.18 Backward Compatibility of a Six-member Shadowset

V8.4

A new area of the Storage Control Block (SCB) of disk stores the extended

membership arrays required to support the "Extended Membership" shadowing

feature. Therefore, an attempt to mount a six-member shadowset on prior

versions of OpenVMS works only if the members are speciﬁed in the command

line.

In OpenVMS prior versions, the $MOUNT/INCLUDE qualiﬁer which is used for

reconstructing the shadowset, can ﬁnd only the existing membership list and not

the new membership area in the SCB. Hence, it does not mount any members

from the new extended membership area in the SCB.

This problem has been ﬁxed in OpenVMS Version 8.4 upgrade kit.

4.19 WBEM Services and WBEM Providers for OpenVMS

This section describes known problems and restrictions in WBEM.

4.19.1 Increased CPU Consumption With WBEM on OpenVMS Guest

V8.4

OpenVMS Guest has a known issue where the CPU consumption of the host

gradually increases with the time when WBEM is conﬁgured and running on the

guest. Due to this issue, the guest responsiveness gradually decreases with the

time, although there is no workload on the guest.

The workaround for this problem is to stop and restart WBEM on the guest when

responsiveness is slow by entering the following command:

$ @SYS$STARTUP:WBEM_SERVICES$SHUTDOWN ! Shutdown WBEM on the guest

$ @SYS$STARTUP:WBEM_SERVICES$STARTUP ! Startup WBEM on the guest

Alternately, you can reboot the OpenVMS guest when the responsiveness is slow.

4.19.2 WBEM Providers Support for OpenVMS Guest

V8.4

WBEM Providers running on OpenVMS guest does not support WBEM instance

data and event indications for CPU, Memory, Enclosure, Chassis, Fan, Power

Supply, and Management Processor, since the guest is running in a virtual

machine. This will be supported by WBEM providers running on the underlying

VM Host operating system.

4–18 System Management Release Notes

System Management Release Notes

4.19 WBEM Services and WBEM Providers for OpenVMS

4.19.3 Based on OpenPegasus 2.9

WBEM Services for OpenVMS Version 2.9 is based on the OpenPegasus 2.9 code

stream of The Open Group’s Pegasus open source project.

4.19.4 Supports nPartitions and iCAP

On cell-based systems, Version 2.0 supports local nPartitions and iCAP providers.

Only the functions and capabilities needed by these providers are supported.

4.19.5 Restart cimserver.exe to Unload Providers on OpenVMS

After entering the cimprovider -r command, you must stop and restart the

cimserver to complete the process of replacing a provider. (OpenVMS does not

support unloading a dynamically loaded image.)

4.19.6 Use Quotes Around Command Line Options

Ensure that you use quotes around a command line option to preserve its case.

For example,

Correct:

$ cimmofl "-E" "--xml"

Incorrect:

$ cimmof -E -xml

4.20 Writing the System Dump File to an Alternate Disk

V8.4

On Superdome class of servers, writing the system dump ﬁle to an alternate disk

(DOSD) does not work and the following message is displayed:

**** Unable to locate SYSDUMP.DMP on any valid DUMP_DEV device

**** Attempting to write the crash dump to the system disk

4.21 Monitor Utility Changes

The Monitor utility (MONITOR) has undergone several changes since OpenVMS

Version 7.3-2. Most of these changes are related to providing improved formatting

of the recording ﬁle and including additional class data. These changes have

introduced some compatibility issues between data collected by one version of

MONITOR that is subsequently processed by another version. This section

discusses these issues.

4.21.1 Guest Operating System on Integrity VM

V8.4

OpenVMS Integrity servers Version 8.4 supports Guest Operating System on HP

Integrity Virtual Machines (Integrity VM). When the OpenVMS Integrity servers

is running as a guest on an Integrity VM system, the monitor utility indicates the

amount of CPU time used by the guest. The Monitor also indicates the amount of

CPU time allocated to the guest by Integrity VM.

The

MONITOR MODES

and

MONITOR SYSTEM /ALL

commands provide this information.

When the system is running as a guest, the above commands display "In use

by Host" instead of "Compatibility Mode". This ﬁeld is to be interpreted as the

amount of CPU time that was unavailable to the current guest and that is being

used by the other guests or Integrity VM. The display is scaled based on the

number of vCPUs (Virtual CPUs) conﬁgured for the guest irrespective of the

actual number of physical CPUs in the host.

System Management Release Notes 4–19

System Management Release Notes

4.21 Monitor Utility Changes

$ MONITOR MODES OpenVMS Monitor Utility

+-----+ TIME IN PROCESSOR MODES

| CUR | on node VMSG7

+-----+ 5-FEB-2009 12:35:39.74

0 25 50 75 100

+----+----+----+----+

Interrupt State |

|||||

MP Synchronization |

|||||

Kernel Mode |

|||||

Executive Mode |

|||||

Supervisor Mode |

|||||

User Mode 99 |¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦

|||||

In use By Host 1 |

|||||

Idle Time |

+----+----+----+----+

$ MONITOR SYSTEM/ALL OpenVMS Monitor Utility

SYSTEM STATISTICS

on node VMSG9

5-FEB-2009 12:36:44.88

CUR AVE MIN MAX

Interrupt State 0.00 0.12 0.00 0.33

MP Synchronization 0.00 0.00 0.00 0.00

Kernel Mode 0.00 0.06 0.00 0.50

Executive Mode 0.00 0.00 0.00 0.00

Supervisor Mode 0.00 0.00 0.00 0.00

User Mode 98.33 98.03 96.50 98.50

In use By Host 1.66 1.77 1.33 3.33

Idle Time 0.00 0.00 0.00 0.00

Process Count 25.00 24.72 24.00 25.00

Page Fault Rate 0.00 10.96 0.00 47.50

Page Read I/O Rate 0.00 0.96 0.00 3.16

Free List Size 46851.00 46945.54 46850.00 47105.00

Modified List Size 317.00 316.90 316.00 317.00

Direct I/O Rate 0.00 1.37 0.00 5.50

Buffered I/O Rate 1.00 2.68 0.66 9.83

Note

The data that is displayed when

MONITOR MODES

and

MONITOR SYSTEM /ALL

commands are executed on a guest is the time that the guest spends on

the virtual CPUs.

4–20 System Management Release Notes

System Management Release Notes

4.21 Monitor Utility Changes

4.21.2 Version-to-Version Compatibility of MONITOR Data

Because the body of data MONITOR collects can change at each release, it is not

always possible to view MONITOR data collected in one version on a different

version.

The level of compatibility between releases depends on whether you examine

recorded binary data from a ﬁle (that is, playback) or live data from another

cluster node. In general, playing back recorded data provides more compatibility

than monitoring live remote data.

4.21.3 Playing Back Data from a Recording File

Each ﬁle of recorded MONITOR binary data is identiﬁed by a MONITOR

recording ﬁle-structure level ID. You can see this ID by entering the DCL

command DUMP /HEADER /PAGE on the ﬁle. The following table lists some

recent MONITOR versions and their associated structure level IDs:

Operating System Version

MONITOR Recording

File Structure ID

OpenVMS Version 7.3-2 with remedial kit1MON31050

OpenVMS Versions 8.2, 8.2-1 with remedial kit1MON01060

OpenVMS Versions 8.3, 8.3-1H1, 8.4 MON01060

1These remedial kits are proposed kits that might be issued for the sole purpose of providing improved

compatibility.

Usually, for you to be able to play back a single MONITOR recording ﬁle, the last

two digits of the structure level ID must match those of the running MONITOR

version. For example, if you are running OpenVMS Version 7.3-2, you can play

back a ﬁle from Version 7.3-2 but not one from Version 8.2.

However, MONITOR Versions 8.2 and higher are specially coded to read

recording ﬁles with structure level IDs ending in "50." In addition, a utility

in SYS$EXAMPLES, called MONITOR_CONVERT.C, converts a MONxx060 ﬁle

to a MON31050 ﬁle. This allows the resulting ﬁle to be read by versions prior

to Version 8.2. See MONITOR_CONVERT.C for instructions for building and

running the program.

Note that, even though you are allowed to play back a ﬁle, certain MONITOR

data classes within the ﬁle might not be available. This can happen if you

are using an older MONITOR version to play back a ﬁle created by a newer

MONITOR version.

Finally, note that, when you produce a multiﬁle summary from several recording

ﬁles, all 8 characters of the structure level ID from all the ﬁles must match.

4.22 System Parameters

V8.3-1H1

This release also contains the new GH_RES_CODE_S2 parameter, which speciﬁes

the size in pages of the resident 64-bit S2 space resident image code granularity

hint region.

Only images linked with the /SEGMENT=CODE=P2 qualiﬁer can have code

placed in this region. See the HP OpenVMS Linker Utility Manual and the

INSTALL utility in the HP OpenVMS System Manager’s Manual for more

information.

System Management Release Notes 4–21

System Management Release Notes

4.22 System Parameters

GH_RES_CODE has the AUTOGEN and FEEDBACK attributes.

4.23 SYS$LDDRIVER Restriction

V8.3-1H1

SYS$LDDRIVER.EXE is a freeware pseudo device driver that allows OpenVMS

operating system to create virtual disks. For OpenVMS Version 7.3-1 and

succeeding versions, this driver was placed in SYS$COMMON:[SYS$LDR] to

support the creation of the source virtual disk for mastering a CD or DVD using

CDRECORD or COPY/RECORDABLE_MEDIA. This is the only supported use

of this freeware driver. All other uses of this driver continue to be subject to the

following documented freeware usage restrictions:

OpenVMS Freeware is provided as is without a warranty. HP imposes no

restrictions on its distribution or redistribution. HP does not support services for

this software, ﬁx the software, or guarantee that it works correctly.

4.24 CPU_POWER_MGMT Default Value Changed

V8.3-1H1

The default value for the sysgen parameter CPU_POWER_MGMT has been

restored to 1 (that is to on). An improved idle power saving algorithm reduces

interrupt latency while CPU_POWER_MGMT is on.

4.25 Booting A Satellite System with Reserved Memory

V8.3-1H1

To use the SYSMAN reserved memory feature on an Integrity server satellite

system the ﬁle SYS$SYSTEM:VMS$RESERVED_MEMORY.DATA must allow

world READ+EXECUTE access. Failure to set this access protection results in

the warning when booting the satellite:

%VMS_LOADER-W-Warning: Unable to load file SYS$SYSTEM:VMS$RESERVED_MEMORY.DATA

After running SYSMAN to add memory reservations to a satellite, execute

SYS$MANAGER:CLUSTER_CONFIG_LAN.COM to set the correct protection

on the VMS$RESERVED_MEMORY.DATA ﬁle. To set the protection, from the

cluster conﬁguration procedure "Main Menu" select:

3. CHANGE a cluster member’s characteristics.

From the "CHANGE Menu" select the following:

13. Reset an IA64 satellite node’s boot environment file protections.

What is the satellite name (leave blank to use a specific device and root)?

Enter the satellite name or satellite boot device and root for the system where

you added the memory reservation. SYSMAN will be ﬁxed in a later release to

eliminate this condition.

4.26 SCACP Error Counter Reports Retransmit Errors

V8.3-1H1

If the PEA0: device on the system shows a number of errors, these errors might

be retransmit errors and not actual errors. To verify actual errors, use the

SCACP utility to conﬁrm whether there are a number of retransmits on the PEA0

channels and use the LANCP utility to identify whether any actual devices errors

4–22 System Management Release Notes

System Management Release Notes

4.26 SCACP Error Counter Reports Retransmit Errors

exist on the LAN devices that the PEdriver uses. If there are retransmits and no

devices errors, then the PEA0: device errors are likely retransmits and not actual

errors.

4.27 Virtual Connect

The following section pertain to Virtual Connect.

4.27.1 Failover and RECNXINTERVAL

V8.3-1H1

RECNXINTERVAL may have to be increased above the default of 20 to allow time

for Virtual Connect Manager failovers. This is especially true in larger clusters.

4.28 INITIALIZE/ERASE=INIT Before Using Media

V8.3-1H1

HP recommends that you issue the DCL command INITIALIZE/ERASE=INIT on

storage media prior to using them for the ﬁrst time. This eliminates any stale

data that was left from previous use by another operating system or diagnostics.

An indication of such stale data is three questions marks (???) in the console

command output, as shown in the following example:

Shell> ls fs1:\

Directory of: fs1:\

00/00/07 19:16p 1,788,984,016 ???

00/00/80 12:00a 0 ???

2 File(s) 1,788,984,016 bytes

0 Dir(s)

The problem will be corrected in a future release.

4.29 Performance Data Collector for OpenVMS (TDC)

V8.3-1H1

TDC_RT Version 2.2-107 is included in the OpenVMS Version 8.3–1H1

installation. An update to TDC Version 2.2-108 is now available from the

TDC Web site at:

http://www.hp.com/products/openvms/tdc/

TDC Version 2.2-108 corrects several issues discovered in TDC_RT Version

2.2-107. It also enables collection of internet metrics in TCPware and MultiNet

environments, adds additional metrics to several data records, and provides new

programming features and sample code in the TDC Software Developers Kit.

4.30 Recovering From System Hangs or Crashes (Integrity servers

Only)

V8.2

If your system hangs and you want to force a crash, press Ctrl/P from the console.

The method of forcing a crash dump varies depending on whether XDELTA is

loaded.

System Management Release Notes 4–23

System Management Release Notes

4.30 Recovering From System Hangs or Crashes (Integrity servers Only)

If XDELTA is loaded, pressing Ctrl/P causes the system to enter XDELTA. The

system displays the instruction pointer and the current instruction. You can force

a crash from XDELTA by entering ;C, as shown in the following example:

Console Brk at 8068AD40

8068AD40! add r16 = r24, r16 ;; (New IPL = 3)

If XDELTA is not loaded, pressing Ctrl/P a second time causes the system to

respond with the prompt ‘‘Crash? (Y/N)’’. Entering Y causes the system to crash.

Entering any other character has no effect on the system.

4.31 DECdtm/XA with Oracle 8iand 9i(Alpha Only)

V7.3-2

When you are using DECdtm/XA to coordinate transactions with the Oracle 8i/9i

XA Compliant Resource Manager (RM), do not use the dynamic registration XA

switch (xaoswd). Version 9.0.1.0.0 of the Oracle shareable library that supports

dynamic registration does not work. Always use the static registration XA switch

(xaosw) to bind the Oracle RM to the DECdtm/XA Veneer.

The DECdtm/XA V2.1 Gateway now has clusterwide transaction recovery support.

Transactions from applications that use a clusterwide DECdtm Gateway Domain

Log can now be recovered from any single-node failure. Gateway servers running

on the remaining cluster nodes can initiate the transaction recovery process on

behalf of the failed node.

4.32 Device Unit Number Increased

V8.2

In the past, OpenVMS would never create more than 10,000 cloned device units,

and unit numbers would wrap after 9999. This had become a limitation for some

devices, such as mailboxes or TCP/IP sockets.

Starting with OpenVMS Version 7.3-2, OpenVMS will create up to 32,767 devices

if the DEV$V_NNM bit is clear in UCB$L_DEVCHAR2 and if bit 2 is clear in the

DEVICE_NAMING system parameter. This does not require any device driver

change.

However, programs and command procedures that are coded to assume a

maximum device number of 9999 may need to be modiﬁed.

4.33 EDIT/FDL: Fixing Recommended Bucket Size

V7.3

Prior to OpenVMS Version 7.3, when running EDIT/FDL, the calculated bucket

sizes were always rounded up to the closest disk-cluster boundary, with a

maximum bucket size of 63. This could cause problems when the disk-cluster

size was large, but the ‘‘natural’’ bucket size for the ﬁle was small, because

the bucket size was rounded up to a much larger value than required. Larger

bucket sizes increase record and bucket lock contention, and can seriously impact

performance.

4–24 System Management Release Notes

System Management Release Notes

4.33 EDIT/FDL: Fixing Recommended Bucket Size

OpenVMS Version 7.3 or higher modiﬁes the algorithms for calculating the

recommended bucket size to suggest a more reasonable size when the disk cluster

is large.

4.34 Using EFI$CP Utility not Recommended

V8.2

The OpenVMS EFI$CP utility is presently considered undocumented and

unsupported. HP recommends against using this utility. Certain privileged

operations within this utility could render OpenVMS Integrity servers

unbootable.

4.35 Error Log Viewer (ELV) Utility: TRANSLATE/PAGE Command

V7.3-2

If a message is signaled while you are viewing a report using the /PAGE qualiﬁer

with the TRANSLATE command, the display might become corrupted. The

workaround for this problem is to refresh the display using Ctrl/W.

If you press Ctrl/Z immediately after a message is signaled, the program abruptly

terminates. The workaround for this problem is to scroll past the signaled

message before pressing Ctrl/Z.

4.36 Cluster Compatibility Patch Kits

V8.3

Before introducing an OpenVMS Version 8.2–1 system into an existing OpenVMS

Cluster system, you must apply certain patch kits (also known as remedial kits)

to your systems running earlier versions of OpenVMS. Note that these kits are

version speciﬁc.

The versions listed in Table 4–2 are supported in a warranted conﬁguration. For

more information about these conﬁgurations, see the HP OpenVMS Version 8.2–1

for Integrity Servers Upgrade and Installation Manual.

Table 4–2 lists the facilities that require patch kits and the patch kit ﬁle names.

Each patch kit has a corresponding readme ﬁle by the same name with a

.README ﬁle extension.

You can either download the patch kits from the following Web site or contact

your HP Support representative to receive the patch kits on media appropriate

for your system:

http://www2.itrc.hp.com/service/patch/mainPage.do

Note

Patch kits are periodically updated on an as-needed basis. Always use the

most recent patch kit for the facility, as indicated by the version number

in the kit’s readme ﬁle. The most recent version of each kit is the version

posted on the Web site.

System Management Release Notes 4–25

System Management Release Notes

4.36 Cluster Compatibility Patch Kits

Table 4–2 Patch Kits Required for Cluster Compatibility

Facility Patch Kit File Name

OpenVMS Alpha Version 7.3-2

Update kit with most patch kits

except those listed in this section

VMS732_UPDATE-V0600.

C RTL VMS732_ACRTL-V0100

Drivers VMS732_DRIVER-V0200

PCSI VMS732_PCSI-V0100

OpenVMS Alpha Version 8.2

VMS82A_UPDATE-V0200

DECnet-Plus for OpenVMS

Alpha ECO1

DNVOSIECO01_V821

OpenVMS Integrity servers Version 8.2

VMS82I_UPDATE-V0200

1This kit is required if you are running this software in your conﬁguration.

4.36.1 Patch Kits Needed for Cluster Compatibility

V8.2

Before introducing an OpenVMS Version 8.2 (or higher) system into an existing

OpenVMS Cluster system, you must apply certain patch kits (also known as

remedial kits) to your systems running earlier versions of OpenVMS. If you

are using Fibre Channel, XFC, or Volume Shadowing, additional patch kits are

required. Note that these kits are version speciﬁc.

The versions listed in Table 4–2 are supported in either a warranted

conﬁguration or a migration pair conﬁguration. For more information about

these conﬁgurations, refer to either HP OpenVMS Cluster Systems or the HP

OpenVMS Version 8.3 Upgrade and Installation Manual.

Table 4–2 lists the facilities that require patch kits and the patch ID names. Each

patch kit has a corresponding readme ﬁle with the same name (ﬁle extension is

.README).

You can either download the patch kits from the following web site (select the

OpenVMS Software Patches option), or contact your HP support representative to

receive the patch kits on media appropriate for your system:

http://www2.itrc.hp.com/service/patch/mainPage.do

Note

Patch kits are periodically updated on an as-needed basis. Always use the

most recent patch kit for the facility, as indicated by the version number

in the kit’s readme ﬁle. The most recent version of each kit is the version

posted on the web site.

4–26 System Management Release Notes

System Management Release Notes

4.36 Cluster Compatibility Patch Kits

Table 4–2 Patch Kits Required for Cluster Compatibility

Facility Patch ID

OpenVMS Alpha Version 7.3-2

Update kit with most patch kits

except those also listed in this

section

VMS732_UPDATE-V0600

OpenVMS VAX Version 7.3 1

Audit Server VAXAUDS01_073

Cluster VAXSYSL01_073

DECnet-Plus VAX_DNVOSIECO04-V73

DECwindows Motif VAXDWMOTMUP01_073

DTS VAXDTSS01_073

Files 11 VAXF11X02_073

MAIL VAXMAIL01_073

MIME VAXMIME01_073

MOUNT VAXMOUN01_073

RMS VAXRMS01_073

RPC VAXRPC02_073

Volume Shadowing VAXSHAD01_073

System VAXSYS01_073

1For operating guidelines when using VAX systems in a cluster, refer to Section 4.16.3.

Note that VAX systems cannot be in a cluster with Integrity servers. For a

complete list of warranted groupings within a cluster, refer to the HP OpenVMS

Version 8.3 Upgrade and Installation Manual.

4.36.2 API to Correct Incompatibility of FC and SCSI Multipath with Some

Third-Party Products

V7.3-2

OpenVMS Alpha Version 7.2-1 introduced the multipath feature, which provides

support for failover between the multiple paths that can exist between a system

and a SCSI or Fibre Channel device. OpenVMS Alpha Version 7.3-1 introduced

support for failover between Fibre Channel multipath tape devices.

This multipath feature can be incompatible with some third-party disk-caching,

disk-shadowing, or similar products. HP advises that you do not use such

software on SCSI or Fibre Channel devices that are conﬁgured for multipath

failover until this feature is supported by the producer of the software.

Third-party products that rely on altering the Driver Dispatch Table (DDT) of

either the OpenVMS Alpha SCSI disk class driver (SYS$DKDRIVER.EXE), the

OpenVMS Alpha SCSI tape class driver (SYS$MKDRIVER.EXE), or the SCSI

generic class driver (SYS$GKDRIVER) may need to be modiﬁed in order to

function correctly with the SCSI multipath feature.

System Management Release Notes 4–27

System Management Release Notes

4.36 Cluster Compatibility Patch Kits

Producers of such software can now modify their software using DDT Intercept

Establisher routines introduced in OpenVMS Alpha Version 7.3-2. For more

information about these routines, refer to the HP OpenVMS Alpha Version 7.3–2

New Features and Documentation Overview manual.

Note

If you are using a third-party disk-caching product or disk shadowing

application, refrain from using it in an OpenVMS SCSI or Fibre Channel

multipath conﬁguration until you conﬁrm that the application has been

revised using these new routines.

For more information about OpenVMS Alpha SCSI and Fibre Channel multipath

features, refer to Guidelines for OpenVMS Cluster Conﬁgurations.

4.36.3 DDT Intercept Establisher Routines and Device Conﬁguration

Notiﬁcation Results

V8.3

To ensure proper behavior of certain routines, a patch kit is required. Using those

routines without the required patch kit can result in system hangs, crashes, or

data corruption, and is not supported by HP.

For more information about these routines, see the HP OpenVMS Alpha Version

7.3–2 New Features and Documentation Overview manual.

4.36.4 Cluster Performance Reduced with CI-LAN Circuit Switching

V7.3-1

In rare cases, in an OpenVMS Cluster conﬁguration with both CI and multiple

FDDI, 100 Mb/s or Gb/s Ethernet-based circuits, you might observe that

SCS connections are moving between CI and LAN circuits at intervals of

approximately 1 minute. This frequent circuit switching can result in reduced

cluster performance and may trigger mount veriﬁcation of shadow set members.

PEdriver can detect and respond to LAN congestion that persists for a few

seconds. When it detects a signiﬁcant delay increase or packet losses on a LAN

path, the PEdriver removes the path from use. When it detects that the path has

improved, it begins using it again.

Under marginal conditions, the additional load on a LAN path resulting from

its use for cluster trafﬁc may cause its delay or packet losses to increase beyond

acceptable limits. When the cluster load is removed, the path might appear to be

sufﬁciently improved so that it will again come into use.

If a marginal LAN path’s contribution to the LAN circuit’s load class increases

the circuit’s load class above the CI’s load class value of 140 when the marginal

path is included (and, conversely, decreases the LAN circuit’s load class below

140 when the path is excluded), SCS connections will move between CI and LAN

circuits.

You can observe connections moving between LAN and CI circuits by using

SHOW CLUSTER with the CONNECTION and CIRCUITS classes added.

4–28 System Management Release Notes

System Management Release Notes

4.36 Cluster Compatibility Patch Kits

Workarounds

If excessively frequent connection moves are observed, you can use one of the

following workarounds:

• You can use SCACP or Availability Manager to assign a higher priority to the

circuit, or the port you wish to be used, thus overriding automatic connection

assignment and moving.

Examples of SCACP commands are:

$ MC SCACP

SCACP> SET PORT PNA0 /PRIORITY=2 ! This will cause circuits from local

! CI port PNA0 to be chosen over

! lower priority circuits.

SCACP> SET PORT PEA0 /PRIORITY=2 ! This will cause LAN circuits to be

! chosen over lower priority circuits.

• You can use the SCACP SHOW CHANNEL commands to determine which

channels are being switched into or out of use. Then you can use SCACP to

explicitly exclude a speciﬁc channel by assigning it a lower priority value than

the desired channels. For example:

SCACP> SET CHANNEL LARRY /LOCAL=EWB/REMOTE=EWB /PRIORITY=-2

Note that CHANNEL and LAN device priority values in the range of max,

max-1 are considered equivalent; that is, they are treated as if they both had

the maximum priority value. A difference of 2 or more in priority values is

necessary to exclude a channel or LAN device from use.

4.36.5 Multipath Tape Failover Restriction

V7.3-1

While the INITIALIZE command is in progress on a device in a Fibre Channel

multipath tape set, multipath failover to another member of the set is not

supported. If the current path fails while another multipath tape device is being

initialized, retry the INITIALIZE command after the tape device fails over to a

functioning path.

This restriction will be removed in a future release.

4.36.6 No Automatic Failover for SCSI Multipath Medium Changers

V7.3-1

Automatic path switching is not implemented in OpenVMS Alpha Version 7.3-1 or

higher for SCSI medium changers (tape robots) attached to Fibre Channel using a

Fibre-to-SCSI tape bridge. Multiple paths can be conﬁgured for such devices, but

the only way to switch from one path to another is to use manual path switching

with the SET DEVICE/SWITCH command.

This restriction will be removed in a future release.

4.37 OpenVMS Galaxy (Alpha Only)

The following sections contain notes pertaining to OpenVMS Galaxy systems.

Note that OpenVMS Galaxy is supported on OpenVMS Alpha systems only.

System Management Release Notes 4–29

System Management Release Notes

4.37 OpenVMS Galaxy (Alpha Only)

4.37.1 Galaxy Deﬁnitions

V8.2

Because the HP OpenVMS Alpha Partitioning and Galaxy Guide is not being

updated for this release, this note provides improved deﬁnitions of the word

Galaxy, which depends on context.

Table 4–3 Galaxy Deﬁnitions

Galaxy as a: Functions this way:

License Is required to create and run multiple instances of OpenVMS in a

single computer. Without this license, only one instance of OpenVMS

can be run in a single computer.

System

parameter

Sets memory sharing. GALAXY set to 1 speciﬁes that OpenVMS

instances with the parameter set in a hard partition will share

memory between soft partitions within that hard partition. (You

can run more than two soft partitions in a hard partition, and

you may not want to share memory among all of them.) Note that

this parameter only speciﬁes whether a node uses shared memory.

There is no need to use this parameter to run multiple, cooperative

instances of OpenVMS; this is achieved by console setup of the

desired conﬁguration tree. GALAXY set to 0 means that memory is

not shared (the default).

Soft partition Provides the capability of several OpenVMS instances to execute

cooperatively in a single computer so as to be able to migrate CPUs,

use APIs, share memory, and so on. Platform partitioning makes

possible the separation of resources into multiple soft partitions, each

of which can run an OS instance. A soft partition is that subset of

resources that the OS instance running in it can see and use.

4.38 Multiple nPartitions on Cell-based Systems

V8.2-1

If you have multiple nPartitions on your HP Integrity rx7620, HP Integrity

rx8620, or HP Integrity Superdome servers, and you are running a multi-

operating system environment with OpenVMS on one of the nPartitions, one

of the other operating systems might register an error or event on the System

Event Log (SEL) while OpenVMS is booting. OpenVMS holds the SEL until it

has produced a table of Field Replaceable Units (FRU), which might cause other

operating systems to register an error or an event.

4.38.1 OpenVMS Graphical Conﬁguration Manager

V8.2

The OpenVMS Graphical Conﬁguration Manager (GCM) is now supported for

AlphaServer ES47/ES80/GS1280 Galaxy conﬁgurations. Previously, only the

Graphical Conﬁguration Utility (GCU) was supported.

4.38.2 Galaxy on ES40: Uncompressed Dump Limitation

Permanent Restriction

On AlphaServer ES40 Galaxy systems, you cannot write a raw (uncompressed)

dump from instance 1 if instance 1’s memory starts at or above 4 GB (physical).

Instead, you must write a compressed dump.

4–30 System Management Release Notes

System Management Release Notes

4.38 Multiple nPartitions on Cell-based Systems

4.38.3 Galaxy on ES40: Turning Off Fastpath

Permanent Restriction

When you implement Galaxy on an AlphaServer ES40 system, you must turn off

Fast Path on instance 1. Do this by setting the SYSGEN parameter FAST_PATH

to 0 on that instance.

If you do not turn off Fastpath on instance 1, I/O on instance 1 will hang when

instance 0 is rebooted. This hang will continue until the PCI bus is reset and

instance 1 rebooted. If there is shared SCSI or Fibre Channel, I/O will hang on

the sharing nodes and all paths to those devices will be disabled.

4.39 Corrupted Version 2 Format Database

V7.3-2

If you create eight or more volatile subkeys in a key tree and then reboot a

standalone system or a cluster, the OpenVMS Registry server can corrupt a

Version 2 format Registry database when the server starts up after the reboot.

To avoid this problem, do one of the following:

• Do not use volatile keys.

• Use a Version 1 format database.

Note that Advanced Server for OpenVMS and COM for OpenVMS do not create

volatile keys.

4.40 System Parameters

The following sections contain notes related to system parameters.

4.40.1 New System Parameters

V8.3

To learn about new system parameters, see the HP OpenVMS Version 8.3 New

Features and Documentation Overview.

4.40.2 Obsolete System Parameters

V8.3

The following system parameters are marked as obsolete in OpenVMS Version

8.3:

• SMP_CPUS

• SMP_CPUSH

• IO_PREFER_CPU

• IO_PREFER_CPUS

• NPAG_AGGRESSIVE

• NPAG_GENTLE

• SCH_CTLFLAGS

• TTY_SILOTIME

• BALSETCNT

• BREAKPOINTS

System Management Release Notes 4–31

System Management Release Notes

4.40 System Parameters

• MMG_CTLFLAGS

• MULTITHREAD

• NISCS_MAX_PKTSZ

• NISCS_PORT_SERV

• SECURITY POLICY

The following new parameters replace the preceding ones:

• SMP_CPU_BITMAP

• IO_PRCPU_BITMAP

For more information about these new system parameters, see the HP OpenVMS

System Management Utilities Reference Manual or online help.

4.40.3 System Parameter Changes

V8.3

The following system parameters are changed in OpenVMS Version 8.3. For

more information, see the HP OpenVMS System Management Utilities Reference

Manual.

• BALSETCNT - wording changes

• BREAKPOINTS - now dynamic

• MMG_CTLFLAGS - additional bits deﬁned; wording changes

• MULTITHREAD - Integrity servers support added

• NISCS_MAX_PKTSZ - wording changes

• NISCS_PORT_SERV - bit deﬁnition changes

• SECURITY POLICY - Bits 13 and 14 deﬁned

• SHADOW_SYS_DISK - wording changes

• WBM_MSG_UPPER - default changed

For detailed descriptions of these parameters see the online help or the HP

OpenVMS System Management Utilities Reference Manual.

4.41 Terminal Fallback Facility

V8.2

On OpenVMS Alpha systems, the Terminal Fallback Facility (TFF) includes a

fallback driver (SYS$FBDRIVER.EXE), a shareable image (TFFSHR.EXE),

a terminal fallback utility (TFU.EXE), and a fallback table library

(TFF$MASTER.DAT).

Note

TFFSHR has been removed from IMAGELIB because it is not a

documented, user-callable interface. The image is still available in

the SYS$LIBRARY: directory.

4–32 System Management Release Notes

System Management Release Notes

4.41 Terminal Fallback Facility

To start TFF, invoke the TFF startup command procedure located in

SYS$MANAGER, as follows:

$@SYS$MANAGER:TFF$SYSTARTUP.COM

To enable fallback or to change fallback characteristics, invoke the Terminal

Fallback Utility (TFU), as follows:

$RUN SYS$SYSTEM:TFU

TFU>

To enable default fallback to the terminal, enter the following DCL command:

$SET TERMINAL/FALLBACK

OpenVMS Alpha TFF differs from OpenVMS VAX TFF in the following ways:

• On Alpha systems, the TFF fallback driver is named SYS$FBDRIVER.EXE.

On VAX systems, the TFF fallback driver is named FBDRIVER.EXE.

• On Alpha systems, TFF is capable of handling 16-bit character fallback. The

OpenVMS Alpha fallback table library (TFF$MASTER.DAT) contains four

more 16-bit character tables than the VAX library. Table 4–4 describes these

additional tables.

Table 4–4 TFF Character Fallback Tables

Table Name Base Description

BIG5_HANYU BIG5 BIG5 for CNS 11643 (SICGCC) terminal/printer

HANYU_BIG5 CNS CNS 11643 (SICGCC) for BIG5 terminal/printer

HANYU_TELEX CNS CNS 11643 for MITAC TELEX-CODE terminal

HANGUL_DS KS KS for DOOSAN 200 terminal

These tables are used mainly by the Asian region. Also, the table format was

changed due to the support of 16-bit character fallback.

• On Alpha systems, the TFU command SHOW STATISTICS does not display

the size of the fallback driver (SYS$FBDRIVER.EXE).

RT terminals are not supported by TFF.

For more information about the Terminal Fallback Facility, refer to the now

archived OpenVMS Terminal Fallback Utility Manual on the OpenVMS

documentation website:

http://www.hp.com/go/openvms/doc

Click on ‘‘Archived documents’’ in the left sidebar to link to this manual.

4.42 User Environment Test Package (Integrity servers Only)

V8.2

The User Environment Test Package (UETP) can be used with the following

cautions:

• During the load phase, there are sporadic access violations in UETMEMY01.

This does not terminate execution or really affect the validity of the run.

UETP is still useable and produces valid results.

System Management Release Notes 4–33

System Management Release Notes

4.42 User Environment Test Package (Integrity servers Only)

• The device phase currently does not complete execution due to an access

violation.

• The DECnet phase runs ﬁne. The cluster phase is still being tested. It

appears to execute properly, but there are some concerns, and the output does

not show other system names properly.

4.43 Recommended Caching Methods

Permanent Restriction

Virtual I/O Cache (VIOC) — also known as VAX Cluster Cache (VCC) — is

not available on OpenVMS Integrity servers. On Integrity servers, setting the

SYSGEN parameter VCC_FLAGS to 1 is equivalent to setting VCC_FLAGS to 0

or not loading caching at all.

HP recommends Extended File Cache (XFC) as the preferred method for caching

on both Alpha and Integrity servers. For more information about XFC, refer to

the HP OpenVMS System Manager’s Manual.

In a future release of OpenVMS Alpha, support for VIOC will be removed.

4.44 Analyze Utility for OpenVMS

The following sections describe corrected problems in the Analyze Utility for

OpenVMS.

4.44.1 Formatted Symbol Vector Correctly Shown in Data Segment

Previously, the symbol vector summary information did not indicate the segment

in which the symbol vector resided. The symbol vector was formatted only in the

dynamic segment.

This problem is ﬁxed in OpenVMS Version 8.3-1H1. The formatted symbol vector

now appears with the data segment in which it is contained. The formatted

symbol vector is embedded in data and visible in a dump of the data.

To avoid formatting the same data twice, the symbol vector is no longer shown

with the dynamic segment. To make formatting of the symbol vector easy, the

SYMBOL_VECTOR keyword is allowed for the /SEGMENT qualiﬁer. When you

specify this keyword, the resulting output is only the formatted symbol vector.

The surrounding data are not shown. To show and format all of the data, select

the segment by number.

To get equivalent output for the former command /SEGMENT=DYNAMIC for

symbol vectors, use the /SEGMENT=(DYNAMIC,SYMBOL_VECTOR) qualiﬁer.

The summary information shows the name of the data segment that contains the

symbol vector.

4.44.2 Transfer Array Formatted in Data Segment

Previously, if you selected the data segment that contained the transfer array

(either by segment number or with the ALL keyword), the transfer array was not

formatted. Information about the transfer array was shown only in the summary.

This problem is corrected in OpenVMS Version 8.3-1H1. The formatted tranfer

array now appears in the data segment.

4–34 System Management Release Notes

System Management Release Notes

4.44 Analyze Utility for OpenVMS

4.44.3 System Version Array Formatted in Dynamic Segment

System version data is in the dynamic segment. Previously, if you selected the

dynamic segment (either by segment number, or with the ALL or DYNAMIC

keyword), the system version array was not shown. Information about the system

version array was only shown in the summary.

This problem is corrected in OpenVMS Version 8.3-1H1. The formatted system

version array now appears in the dynamic segment.

4.44.4 Enhancements for the /SEGMENT Qualiﬁer

Enhancements have been made to the /SEGMENT qualiﬁer for dynamic

segments. Analyze has been enhanced to accept keywords for the

/SEGMENT=DYNAMIC qualiﬁer to provide customized information. The

keywords for selectable information are:

ALL—(Default) Formats all parts of the dynamic segment

TAGS—Formats the tag array

IMAGE_STRINGS—Formats strings of the speciﬁed image

RELOCATIONS—Formats the image relocations

FIXUPS—Formats the image ﬁxups

SYSTEM_VERSION_ARRAY—Formats the system version array

The default, /SEGMENT=ALL, formats all of the image information.

Note that formatting using the TAGS keyword includes the names of the needed

images, so you do not have to add IMAGE_STRINGS to print the names.

4.44.5 Support for Section Escaping Added

On OpenVMS V8.3, the Analyze utility did not complete when analyzing an object

module with more than 65,280 sections. Instead, it looped when attempting to

print the section header table.

This problem has been ﬁxed in OpenVMS V8.3-1H1.

4.45 INSTALL Utility for OpenVMS (Installing Resident Images in

S2 Space)

The INSTALL utility now supports installing code segments of resident images

into 64-bit S2 address space. Not all code can run in a full 64-bit address space

(P2 or S2). For example, the code must be prepared for 64-bit PCs when handling

exceptions. Also, some compilers require the /POINTER_SIZE=64 command

qualiﬁer, when generating code, suitable for a 64-bit address space.

To avoid mapping unprepared code in S2 space, the INSTALL utility by default

will continue to map the code segments in S0/S1 space. The INSTALL utility will

map code segments of resident images to S2 if two conditions are met:

• The developer explicitly conﬁrmed that the code is 64-bit ready by using the

/SEGMENT_ATTRIBUTE=CODE=P2 qualiﬁer when linking the image.

• There is sufﬁcient pre-allocated space in the resident code region in the S2

space to map the code segments. The size of the region is determined by the

system parameter GH_RES_CODE_S2 (number of pages). The default value

is set to 0. That means that by default even 64-bit ready resident images

have their code mapped in S0/S1 space.

System Management Release Notes 4–35

Programming Release Notes

This chapter provides release notes about application and system programming

on OpenVMS systems.

5.1 Symbolic Debugger

V8.4

On OpenVMS Alpha Version 8.4, when you set breakpoints the debugger will not

be able to differentiate between FORTRAN functions and declared variables of

the same name in different compilation unit.

5.2 C++ Run-Time Library

V8.3-1H1

Problems corrected in OpenVMS Version 8.3-1H1 include the following:

• The run-time library had faulty code that accessed memory just freed to

advance a pointer. In multithreaded code, another thread could reuse that

memory before the original thread could advance its pointer. This has been

ﬁxed by updating accesses prior to freeing pointers.

• A new processwide exception processing mode—

pure_unix

— has been

introduced. In this mode, non-C++ exceptions, also known as OpenVMS

conditions, cannot be caught in a C++ catch-all handler. This mode can

be requested by calling

cxxl$set_condition(condition_behavior)

with a

pure_unix

argument:

cxxl$set_condition(pure_unix);

condition_behavior enum declared in <cxx_exception.h> header

has been extended to include pure_unix member.

To demonstrate how

pure_unix

mode works, consider the following program

sample. As it is written, the program crashes with ACCVIO. If the call to

cxxl$set_condition( )

is commented out, the program outputs "caught" and

exits:

#include <stdio.h>

#include <cxx_exception.h>

void generateACCVIO() { *((int*)0) = 0; }

Programming Release Notes 5–1

Programming Release Notes

5.2 C++ Run-Time Library

int main() {

cxxl$set_condition(pure_unix);

try {

generateACCVIO();

}

catch(...) {

puts("caught"); }

}

Note

To use this new functionality you must have a new version of

cxx_exception.h

, which is included in the CXXL$ANSI_DEF.TLB

ﬁle provided with the Version 7.3 compiler (or higher).

• The run-time library sometimes failed to destruct objects of automatic storage

duration deﬁned in a function, if such a function exited via an exception that

could be caught. This problem has been ﬁxed.

• The run-time library now allows the thread cancel signal (CMA$_ALERTED)

and the thread exit signal (CMA$_EXIT_THREAD) to be caught in a

catch handler with a pointer or a reference to type CXXL$PTHREAD_

CANCEL (or CX6L$PTHREAD_CANCEL) and CXXL$PTHREAD_EXIT (or

CX6L$PTHREAD_EXIT), respectively, if catching the signals are enabled.

The new types catch these signals exclusively.

Note

To use this new functionality, you must have a new version of

cxx_exception.h

, which is included in the CXXL$ANSI_DEF.TLB

provided with the V7.3 compiler (or higher).

• The C++ RTL has changed its internal mapping of SIGTRAP from SS$_

BREAK to SS$_TBIT, to match a recent C RTL change.

• The C++ RTL used to call

std::terminate( )

when a destructor raised an

exception during stack unwinding, even if that destructor did not exit via the

exception. This problem has been ﬁxed.

• The C++ RTL used to call

std::terminate( )

, if a foreign exception (such as

a non-C++ OpenVMS condition) was raised while a C++ exception was being

processed. This behavior has been reﬁned to calling

std::terminate( )

only

if the raised OpenVMS condition also leads to unwinding the stack.

• Because OpenVMS conditions can be caught in C++ catch handlers, the

C++ RTL converts the conditions to an internal format that matches the

representation of C++ exceptions. This conversion would sometimes lead to

incorrect information being shown in the traceback. This problem has been

ﬁxed.

The following problems are ﬁxed in this version of the C++ Library (Version 7.3

and higher compiler):

• As described in

http://issues.apache.org/jira/browse/STDCXX-397

(the

Apache Software Foundation Issues website), the

_ _introsort_loop( )

function in <algorithm.cc> header has a problem which, for some input

sequences, can adversely affect performance of

std::sort

. For more

5–2 Programming Release Notes

Programming Release Notes

5.2 C++ Run-Time Library

information, see the Apache tracker for the issue STDCXX-397 at

http://issues.apache.org/jira/browse/STDCXX-397

The problem has been ﬁxed. However, for some input sequences, the ﬁx

can change the behavior of

std::sort

with regard to the relative order in

which elements that have equivalent ordering are placed into the sorted

sequence. Though this change in behavior is permissible because,

unlike

std::stable_sort

std::sort

does not guarantee any particular relative

order of elements having equivalent ordering, to avoid breaking applications

that rely on existing behaviour of

std::sort

, the ﬁx is conditionalized with

_ _RW_ FIX_APACHE_STDCXX_397 macro. The ﬁx is in effect only when the

program is compiled with this macro deﬁned.

• When compiled in standard GNU mode, the library now deﬁnes the _RWSTD_

NO_IMPLICIT_INCLUSION macro, which causes library headers to include

their respective template deﬁnition ﬁles. This is necessary because in

standard GNU mode, implicit inclusion is disabled.

Before this change, the program below would link with undeﬁned symbol

when compiled in standard GNU mode:

#include <vector>

int main() {

std::vector<int> v;

v.push_back(0);

}

• According to section 27.6.1.3

[lib.istream.unformatted]

of the C++

Standard, the following

get member

functions of the

std::basic_istream

class should call

setstate(failbit)

if no characters have been stored, as

is the case for an empty line. While on Integrity servers the functions set

failbit, on Alpha systems they do not, for example:

istream_type& get(char_type *s, streamsize n, char_type delim);

istream_type& get(char_type *s, streamsize n);

5.3 Process/Application Hangs

The following restriction applies to the LIBRTL documentation for the

lib$find_image_symbol

run-time library routine:

If your application might dynamically activate shareable images that use

pthreads (or the older CMA thread interface), the main image must be linked

with the

pthread$rtl

image.

5.4 AST Delivery Clariﬁcation in Programs using POSIX Threads

V8.3-1H1

It is possible to utilize ASTs in threaded programs. Section B.12.5 in the Guide

to the POSIX Threads Library describes some general usage notes and cautions.

However, that section does not make clear how AST delivery behaves in programs

with upcalls disabled (which is the default conﬁguration).

In a program with upcalls disabled, user-mode ASTs will interrupt whatever

thread happens to be executing at the moment that the AST is delivered.

Therefore the AST service routine cannot make any assumptions about the

context in which it executes (with respect to thread ID, stack space available, and

so on.)

Programming Release Notes 5–3

Programming Release Notes

5.4 AST Delivery Clariﬁcation in Programs using POSIX Threads

Also, note that much of the material in Section B.12.5 of the Guide describes a

possible future version of OpenVMS. The description of generalized "per-thread"

or thread-targeted ASTs represents possible future enhancements to the operating

system. In all OpenVMS releases to date, however, user-mode ASTs are treated

as if they are directed to the process as a whole.

5.5 RMS $PARSE Validation of Directory Files

V8.3-1H1

Starting with OpenVMS Version 8.3, the $PARSE service further validates

all directories named in a directory speciﬁcation to ensure that the directory

characteristic is set. In previous OpenVMS versions, attempting to use a ﬁle

with a .DIR extension that was not a directory resulted in a SS$_BADIRECTORY

error from the $OPEN service, but not necessarily from the $PARSE service. As

of Version 8.3, the error is consistently returned by the $PARSE service as long

as it is not a syntax-only $PARSE.

5.6 No-IOLOCK8 Fibre Channel Port Drivers

V8.3-1H1

Many I/O subsystem components synchronize their operations across CPUs

by using the IOLOCK8 spinlock, which has made acquiring the spinlock a

performance bottleneck. As of Version 8.3-1H1, each Fibre Channel port driver

(SYS$PGQDRIVER, SYS$PGADRIVER and SYS$FGEDRIVER) device uses

its own port-speciﬁc spinlock instead of IOLOCK8 to synchronize its internal

operations. In most conﬁgurations, this results in a signiﬁcant decrease in the

amount of time each CPU spends waiting for the IOLOCK8 spinlock as well as

some increase in the Fibre Channel I/O rate.

Some minor changes are required to any class driver that connects to one of these

new port drivers, so customers must determine whether they are running any

non-HP class drivers that will not work with them. The simplest way to do this is

to examine the output of the SDA command

CLUE SCSI/SUMMARY

and see whether

the name of any third-party class driver device appears in the device hierarchy

for an FGx0 or PGx0 port device in the "Device" column.

For more information, refer to the notes following this sample SDA session.

$ ANALYZE/SYSTEM

OpenVMS system analyzer

SDA> CLUE SCSI /SUMMARY

5–4 Programming Release Notes

Programming Release Notes

5.6 No-IOLOCK8 Fibre Channel Port Drivers

SCSI Summary Configuration:

---------------------------

SPDT Port STDT SCSI-Id SCDT SCSI-Lun Device UCB Type Rev

-------------- -------------- -------------- -------- -------- ------ ----

81624200 FGB0 8162CDC0 3 8162D240 0 GGA22 8162F380 HSV200

8162F180 1 DGA22801 8162FD40 HSV200 6100

81632900 2 DGA22802 81632AC0 HSV200 6100

816354C0 3 DGA22803 81635680 HSV200 6100

81638080 4 DGA22804 81638240 HSV200 6100

8162D400 4 8162DD80 0 GGA22 8163AC40 MRD200

8163B5C0 1 RJA22801 8163B780 RFD200 6100

8163C840 2 RJA22802 8163CA00 RFD200 6100

8163DAC0 3 RJA22803 8163DC80 RFD200 6100

8163ED40 4 RJA22804 8163EF00 RFD200 6100

Note

All of the DGA and GGA devices in this output are accessed through

the modiﬁed HP class drivers SYS$DKDRIVER and SYS$GKDRIVER

respectively, so they are safe to use with the new port drivers.

Note that even though the physical device of Type MRD200 is not an HP

qualiﬁed device, it does not present an IOLOCK8 problem because it is

accessed through a GGAx unit, indicating that it uses the modiﬁed HP

Generic class driver SYS$GKDRIVER.

The RJA devices are not controlled by a modiﬁed HP class driver so they

will not work with the new port drivers.

5.7 C++ Compiler

V8.3-1H1

C++ Version 7.2 for OpenVMS for Integrity servers predeﬁnes the macro

_ _INITIAL_POINTER_SIZE to 0, unlike C++ Version 7.1 compiler, which leaves

it undeﬁned. This is an intentional change that makes C++ Version 7.2 consistent

with the C compiler and provides support for

pointer_size

pragmas, while C++

Version 7.1 does not.

Note that this change can cause diagnostics to appear in code that compiled

cleanly with certain declarations selected by system header ﬁles that declare

pointer types. This effect is most likely to appear in applications that use starlet

headers and that compile with _ _NEW_STARLET deﬁned.

If you cannot modify the application source code to conform to the new

declarations, add the command-line qualiﬁer /UNDEF=_ _INITIAL_POINTER_

SIZE to the CXX command line to prevent the C++ Version 7.2 compiler from

predeﬁning this macro and thus causing the system headers to provide the same

declarations as with Version 7.1 of the compiler.

5.8 Building DCE IDL C++ Applications

V8.3-1H1

Building DCE IDL C++ applications on CXX Version 7.2 and higher results in

an undeﬁned symbol linker warning. This is a known issue. To overcome this

warning, contact HP Support Services to request any necessary patches.

Programming Release Notes 5–5

Programming Release Notes

5.9 Privileged Programs may Need a Recompile (Alpha Only)

V8.2

OpenVMS Alpha Version 8.2 is a major version release in which a number of

privileged data structures have changed. It may be necessary to recompile

and relink privileged applications linked with /SYSEXE that refer to internal

OpenVMS data structures or routines.

If you get a SYSVERDIF error message when you invoke an image or load a

device driver, this indicates that the privileged image or driver was compiled and

linked under a prior version of the operating system. You must then recompile

and relink the image or driver to run on OpenVMS Alpha Version 8.2.

5.10 Privileged Data Structures Updates

V8.2

OpenVMS Version 8.2 contains updates for a number of privileged data

structures. These changes apply to both Alpha and Integrity server systems.

The majority of these data structure updates are to support future scaling and

performance projects in the operating system. As a result of these changes, any

images or drivers that link against the base operating system (that is, those that

use /SYSEXE on the LINK command) might need to be recompiled and relinked

in order to run on OpenVMS Version 8.2.

The privileged data structure changes do not necessarily affect all privileged

images and drivers — only those linked with one of the speciﬁc subsystems that

has changed. For these subsystems, the major version identiﬁcation number

associated with the subsystem has been increased. The subsystems that have

changed are the following:

SYS$K_IO

SYS$K_MEMORY_MANAGEMENT

SYS$K_CLUSTERS_LOCKMGR

SYS$K_FILES_VOLUMES

SYS$K_CPU

SYS$K_MULTI_PROCESSING

SYS$K_PROCESS_SCHED

Note

On Integrity servers, these versions are reported as SYS$K_VERSION_

xxxx.

The versions of these subsystems are linked into images based on the

usage of various privileged system routines and data cells. You can use the

ANALYZE/IMAGE utility to determine with what speciﬁc subsystem a privileged

image is linked. For example:

$ ANALYZE/IMAGE IMAGE.EXE /OUTPUT=IMAGE.TXT

$ SEARCH IMAGE.TXT "SYS$K_"

If any of the versions reported match this list, OpenVMS Version 8.2 will fail to

activate the image and issue a SS$_SYSVERDIF (system version mismatch error)

for images linked on prior versions of the operating system.

5–6 Programming Release Notes

Programming Release Notes

5.10 Privileged Data Structures Updates

5.10.1 KPB Extensions

V8.2

Prior versions of OpenVMS supported the use of KPBs for kernel mode above IPL

2. To make the transition to Integrity servers easier, usage of KPBs has been

expanded for use in outer modes and all IPLs. This Alpha and Integrity servers

change allows certain code that previously had private threading packages to

make use of KPBs on both Alpha and Integrity servers. In order to support these

changes to kernel processes, some changes to the KPB structure were required.

No source changes should be necessary for existing Alpha code.

5.10.2 CPU Name Space

V8.2

OpenVMS currently has an architectural limit of a maximum CPU ID of 31.

Various internal data structures and data cells have allocated 32 bits for CPU

masks. We are increasing the amount of space allocated for these masks to 64

bits for Alpha and 1024 bits on Integrity servers to allow supporting larger CPU

IDs in a future release. The existing longword CPU mask symbols and data cells

will still be maintained.

There should be no initial impact to privileged images and drivers. However, at

some time in the future, HP will document how privileged products that refer to

CPU masks must change their code to support systems with CPU IDs greater

than 31.

5.10.3 64-Bit Logical Block Number (LBN)

V8.4

OpenVMS today supports LBNs of only 32-bits. This limits our support of a disk

volume to 2 TB. The amount of space allocated for internal LBN ﬁelds is being

increased to 64-bits to allow support for larger disk volumes in the future. The

existing longword LBN symbols will still be maintained and will be overlaid with

a quadwords symbol.

5.10.4 Forking to a Dynamic Spinlock

V8.2

In order to scale the OpenVMS operating system on large SMP systems, a

number of areas in the operating system have been using dynamic spinlocks

as opposed to the very limited number of static spinlocks. The ability to FORK

and have the fork dispatcher obtain synchronization with a dynamic spinlock is

desirable. We are adding this capability to OpenVMS Version 8.2 by extending

the size of the FKB structure and by adding a FKB$L_SPINLOCK ﬁeld to the

end of this structure. This spinlock ﬁeld is referenced only if FKB$B_FLCK

contains the value SPL$C_DYNAMIC. The FKB structure is embedded in many

other system data structures, and this change impacts the size and layout of a

large number of privileged data structures

Applications that copy the FKB$B_FLCK ﬁeld from an OpenVMS created

structure to another FKB should also consider copying the data in the FKB$L_

SPINLOCK ﬁeld.

HP recommends that privileged code check for cases of allocating FKB structures

and using a hard-coded value for the size of 32. Code should use the symbol

FKB$C_LENGTH for the size of a FKB.

Programming Release Notes 5–7

Programming Release Notes

5.10 Privileged Data Structures Updates

5.10.5 UCB/DDB Updates

V8.2

A number of updates have been made to the UCB and DDB structures.

The list of UCBs associated with a DDB is currently a singularly linked list.

When creating and deleting a UCB, this list must be walked until the appropriate

location is found. For OpenVMS Version 8.2, UCBs are now linked to the DDB

with a double linked list. In addition, the DDB maintains a seed pointer to

where the search should start when creating a new unit to allow for faster device

creation. Drivers that manipulate their unit seed pointer in a template UCB will

not be able to take advantage of the faster device creation.

Any code that manipulates the DDB list of UCBs will no longer work correctly.

HP highly recommends that you use the provided internal routines for linking

and unlinking UCBs. Code-walking the list of UCB forward continues to work

correctly.

The UCB$W_UNIT ﬁeld is currently a 16-bit word ﬁeld. There are now 32-bits

allocated for this ﬁeld. The UCB$W_UNIT ﬁeld will still be maintained, so no

source code changes are necessary. In a future release, OpenVMS might support

larger unit numbers. This would be done only for drivers that indicate they can

support this feature.

Byte and Word ﬁelds in the terminal driver’s UCB extension are now aligned on

longword boundaries.

5.10.6 PCB$T_TERMINAL Size Increase

V8.2

The Process Control Block (PCB) structure contains a ﬁeld PCB$T_TERMINAL,

which is 8 bytes to hold the device name for an interactive process (such as

LTA123:, RTA7:, NVA456: and so forth). This ﬁeld is a counted ASCII string,

with the ﬁrst byte being the length of the string and the remaining 7 bytes

holding the device name. With a 3-letter device name, only four digits can

be used to hold the unit number, and the colon would be stripped off for unit

numbers greater than 999. For OpenVMS Version 8.2, this ﬁeld has been

increased to 16 bytes to hold device names with larger unit numbers.

If you fetch this ﬁeld using a call to $GETJPI with the JPI$_TERMINAL item

code, you are not impacted, but you might want to increase the buffer passed to

the system service to hold up to 16 bytes.

5.10.7 Per-Thread Security Impacts Privileged Code and Device Drivers

Permanent Change

The method used for attaching a security proﬁle to an I/O Request Packet (IRP)

changed with Version 7.2.

In versions of OpenVMS prior to Version 7.2, the IRP structure contained the

address of the processwide Access Rights Block (ARB) security structure of the

requestor. Beginning with OpenVMS Alpha Version 7.2, the address of the new

security proﬁle structure (Persona Security Block, or PSB) was added to the IRP

as a functional replacement of the ARB address.

The I/O subsystem maintains its access to the PSB through a reference counter

within the PSB. The I/O subsystem increments this reference counter at the time

of IRP creation and decrements the counter at I/O postprocessing of that IRP.

When this counter reaches zero, the PSB structure is deallocated.

5–8 Programming Release Notes

Programming Release Notes

5.10 Privileged Data Structures Updates

Device drivers that create or clone copies of IRPs to facilitate multiple I/O

operations per request, and subsequently pass the copies to the I/O subsystem for

postprocessing, must make code changes to account for the extra references to the

PSB in these additional IRPs. This is done by passing the PSB address located in

the copied IRP to the NSA_STD$REFERENCE_PSB routine. The include ﬁle and

routine call for NSA_STD$REFERENCE_PSB is as follows:

#include <security-macros.h>

/* Increment REFCNT of PSB that is now shared by both IRPs */

nsa_std$reference_psb( irp->irp$ar_psb );

Device drivers need to make this change under the following conditions:

• If a device driver creates a new IRP by duplicating an existing IRP and

submits both the original and the duplicate IRPs for I/O postprocessing by

calling IOC_STD$SIMREQCOM or IOC_STD$DIRPOST1, the device driver

must call NSA_STD$REFERENCE_PSB sometime after duplicating the IRP,

but before submitting it for I/O postprocessing.

• If a device driver creates a new IRP by duplicating an existing IRP and

does not put the address of some procedure descriptor into the IRP$L_PID

cell in either the copy or the original IRP, and the device driver submits

both the original and the duplicate IRPs for I/O postprocessing by calling

IOC_STD$REQCOM, COM_STD$POST, COM_STD$POST_NOCNT, or

IOC_STD$POST_IRP, the device driver must call NSA_STD$REFERENCE_

PSB sometime after duplicating the IRP but before submitting it for I/O

postprocessing.

Device drivers that perform these steps are also likely to put the address of

some procedure descriptor into IRP$L_PID. Therefore, most device drivers

that duplicate IRPs should be able to function correctly on OpenVMS Version

7.2 or higher without making source changes, relinking, or recompiling.

Failure to call NSA_STD$REFERENCE_PSB in these circumstances will result

in corrupt tracking information within the PSB, which can result in system

failures.

If you make code changes in a device driver to call NSA_STD$REFERENCE_

PSB, you must recompile and relink the driver to run on OpenVMS Version 7.2 or

higher.

Several routines are used by privileged code to create OpenVMS fork execution

threads. These routines run in system context independent of any process. There

are four variations of these routines, depending on whether an immediate or

queued fork is required and on which language interface is being used:

• EXE$QUEUE_FORK

• EXE_STD$QUEUE_FORK

• EXE$PRIMITIVE_FORK

• EXE_STD$PRIMITIVE_FORK

These routines must be called at or above IPL$_RESCHED, to prevent accidental

rescheduling to a different CPU during their execution. Such a reschedule could

cause the system to hang.

In OpenVMS V7.3-1, if SYSTEM_CHECK is set to 1, these routines check the

system IPL at entry. If the IPL is below IPL$_RESCHED, the system will fail

with an SPLINVIPL bugcheck.

Programming Release Notes 5–9

Programming Release Notes

5.10 Privileged Data Structures Updates

For performance reasons, the IPL is not veriﬁed if SYSTEM_CHECK is set to

zero (the default). Incorrect code may cause the system to hang if a reschedule to

another CPU occurs during execution of these routines from process context (for

example, below IPL$_RESCHED).

5.11 Applications Using Floating-Point Data

V8.2

The Itanium® architecture implements ﬂoating-point arithmetic in hardware

using the IEEE ﬂoating-point formats, including IEEE single and IEEE double.

The Alpha hardware supports both IEEE and VAX ﬂoating-point formats. On

OpenVMS Alpha, the compilers generate code to use the VAX formats by default

with options to use the IEEE formats.

On OpenVMS Integrity servers, the compilers generate code to use the IEEE

formats by default with options to use the VAX formats. HP recommends the use

of IEEE formats on Integrity servers unless applications need to process VAX

ﬂoating-point binary data that has been generated on VAX or Alpha systems.

For details about using VAX formats on OpenVMS Integrity servers, refer to the

OpenVMS Floating-Point White Paper on the following website:

http://www.hp.com/products1/evolution/alpha_retaintrust/openvms/resources.html

5.11.1 IEEE Floating-Point Filter (Integrity servers Only)

V8.3

In order to allow ﬂoating point exceptions to conform completely with IEEE-

Std 754-1985, Intel provides a function called an IEEE ﬁlter. An application

developer who wants to use this function can place a call to this function code

within a normal OpenVMS exception handler. When an exception occurs, the

ﬁlter can decode the ﬂoating point instructions that caused the exception, as

well as decoding the IEEE rounding modes and precision, and determining the

operands that caused the exception

To obtain a copy of this ﬁlter, access the following Intel Web site and look for the

OpenVMS header:

http://www.intel.com/cd/software/products/asmo-na/eng/219748.htm

The application note available at this site explains the ﬁlter in more detail. The

example source code and the ﬁlter object library are supplied as an OpenVMS

backup save set.

Note that this ﬁlter is required only to make certain details of ﬂoating point

exceptions conform to the IEEE standard. It is not required for normal ﬂoating

point operation.

5.11.2 Ada Event Support (Integrity servers Only)

V8.3

Ada event support (SET BREAK/EVENT=ada_event, where ada_event is one

of the events described by SHOW EVENT) is enabled on OpenVMS Integrity

servers. However, this support is incomplete.

5–10 Programming Release Notes

Programming Release Notes

5.11 Applications Using Floating-Point Data

If you encounter problems with event breakpoints, switch to pthread events (SET

EVENT_FACILITY pthread) as a workaround. Note that not all Ada events have

an equivalent in the pthreads facility.

5.11.3 C++ Language Issues (Integrity servers Only)

V8.3

Condition: The debugger does note support debugging C++ programs compiled

with /OPTIMIZE.

Workaround: Compile C++ programs with /NOOPTIMIZE.

5.12 Ada Compiler(Integrity servers Only)

V8.2

GNAT Pro (Ada 83, Ada 95 and Ada 2005) is available from AdaCore. Contact

AdaCore at www.adacore.com or sales@adacore.com for more information.

5.13 Backup API: Journaling Callback Events Restriction

Permanent Restriction

If an application registers a callback routine for any of the journaling events,

it must register a callback routine for all the journaling callback events. The

following is a list of the journaling callback events:

BCK_EVENT_K_JOURNAL_OPEN

BCK_EVENT_K_JOURNAL_WRITE

BCK_EVENT_K_JOURNAL_CLOSE

Refer to the Backup API chapter in the HP OpenVMS Utility Routines Manual

for more information about registering callback routines.

5.14 C Programs: Compiling with CASE_LOOKUP=SENSITIVE

Settings

Permanent Restriction

If you are compiling C programs in a process where the characteristics were set

to CASE_LOOKUP=CASE=SENSITIVE, any #include ﬁles in your C program

speciﬁed with the .h ﬁle type (lowercase h) will not be seen and executed. In

addition, if a system #include ﬁle speciﬁes another #include ﬁle with a .h ﬁle

type, the second #include ﬁle will not be seen and an error will be generated.

To avoid this behavior, compile with case set to blind. If it is necessary to use

case=sensitive

, specify any #include ﬁles in your C programs either with no

ﬁle type (for example,

#include <stdio>

) or with an uppercase H ﬁle type (for

example,

#include <stdio.H>

Note that this does not correct the scenario where system #include ﬁles, such as

stdlib.h, in turn specify #include ﬁles with a .h ﬁle type and cause an error to be

generated.

5.15 C Run-Time Library

The following sections describe changes and corrections to the C Run-Time

Library (RTL).

Programming Release Notes 5–11

Programming Release Notes

5.15 C Run-Time Library

5.15.1 C RTL TCP/IP Header File Updates

V8.4

The C RTL ships header ﬁles for users to call TCP/IP. C RTL places the headers

into the C RTL header library (DECC$RTLDEF.TLB).

New header ﬁles are added, as appropriate for new features in TCP/IP.

SCTP.H

SCTP_UIO.H

These header ﬁles provide Stream Control Transmission Protocol (SCTP) support.

For more information on SCTP, see the HP TCP/IP Services for OpenVMS Version

5.7 Release Notes.

5.15.2 Backport Library No Longer Shipped

V8.3

Previously included with the compiler distribution kit was a C RTL backport

object library, which allowed developers on older versions of OpenVMS to use the

latest C RTL functions. This backport object library is no longer being shipped.

5.15.3 Header File <time.h> Changes

V8.3

The following problem is ﬁxed. Users who still experience this problem might

have to recompile their application to see the corrected behavior.

The C RTL

<time.h>

header ﬁle deﬁnes the

struct tm

structure and the functions

gmtime

localtime

gmtime_r

, and

localtime_r

When the calling of one these functions and the application and the C RTL

disagree about the size of

struct tm

, a user application can see data corruption or

an access violation.

The

structure has optional members for BSD extensions:

tm_gmtoff

and

tm_zone

. These are not deﬁned in the ANSI or POSIX speciﬁcations or, for

compatibility, with older compilations.

The previously mentioned functions have three different deﬁnitions in the C RTL:

• Local time (no preﬁxes)

• UTC time (after OpenVMS V7.0)

_ _UTC_ preﬁxes for no BSD extensions

_ _UTCTZ_ preﬁxes when using the BSD extensions

The _ _UTCTZ_ preﬁxed functions expect to assign only the longer

structure

with the BSD extensions deﬁned.

The problem occurs when the

<time.h>

header ﬁle and the C RTL do not agree on

the number of structure members in

struc tm

. For example, the problem occurs

with a C++ compilation using a compile-time macro implying _ANSI_C_SOURCE

(such as _POSIX_C_SOURCE), which maps the listed C RTL functions using

_ _UTC_ preﬁxes. The functions expect the shorter

data structure, but the

user program uses the longer

structure deﬁnition. The copy-back of data from

the function return tries to access data not allocated by the C RTL for the

data members. This can result in unpredictable behavior, such as an unintended

memory or access violation.

5–12 Programming Release Notes

Programming Release Notes

5.15 C Run-Time Library

In OpenVMS Version 8.3, changes are made to

<time.h>

to make sure the C RTL

selects the appropriate preﬁxing for the listed functions.

5.15.4 Header File <time.h> Makes *_r Non-ANSI Functions Visible

V8.3

The C RTL functions

ctime_r

gmtime_r

, and

localtime_r

deﬁned in the X/Open

speciﬁcation are not in the ISO/ANSI C standard and should not be visible when

compiling only for ANSI compliance. Previously in the C RTL, they were visible.

This situation is ﬁxed. Checks are added in the

<time.h>

header to make these

functions visible only when not compiling for ANSI compliance.

5.15.5 Header File <builtins.h> _ _CMP_SWAP* and _Interlocked* Visible to

C++

V8.3

The compare and swap built-ins (_ _CMP_SWAP* and _Interlocked*) in

<builtins.h>

did not include the OpenVMS Alpha C++ compiler. Because

HP C++ Version 7.1 requires them, a change in conditional compilation now

makes these built-ins visible.

5.15.6 Builtin _ _fci Added for Integrity servers

V8.3

The

<builtins.h>

header ﬁle is updated with the prototype for the new

_ _fci

built-in (a built-in for the

fc.i

instruction) now supported by the HP C compiler.

5.15.7 No New Entries for DECC$*.OLB Object Libraries

V8.3

As of OpenVMS Alpha and Integrity servers Version 8.2, no new entry points are

being added to the DECC$*.OLB object libraries. This means new C RTL entry

points do not get mapped through these libraries to preﬁxed entries. For example,

the new OpenVMS Version 8.3 entry point

crypt

, compiled with /PREFIX=NONE,

does not get mapped from

crypt

decc$crypt

5.16 Calling Standard and Rotating Registers (Integrity servers

Only)

V8.3

This note supplements information in the HP OpenVMS Calling Standard.

The Calling Standard invocation context block (ICB) (see Table 4-16 in the HP

OpenVMS Calling Standard) and mechanism vector (see Figure 8-7 and Table

8-6 in the HP OpenVMS Calling Standard) always record general, ﬂoating-point,

and predicate registers as if the register rename base (CFM.rrb) and rotating

size (CFM.sor) were both zero. That is, when rotating registers are in use, the

effects of the rotation are ignored. This is also true of the register masks used

by the LIB$I64_PUT_INVO_REGISTERS routine (see Section 4.8.3.13 in the HP

OpenVMS Calling Standard), because these masks are deﬁned in terms of ﬁelds

in the ICB structure.

Programming Release Notes 5–13

Programming Release Notes

5.16 Calling Standard and Rotating Registers (Integrity servers Only)

Previously, the supplemental access routines LIB$I64_GET_FR, LIB$I64_SET_

FR, LIB$I64_GET_GR and LIB$I64_SET_GR (see Section 4.8.4 in the HP

OpenVMS Calling Standard) improperly interpreted their register number

parameters without applying an adjustment for the effects of the register rename

base and rotating size registers. This error is corrected.

5.17 Common Data Security Architecture (CDSA) Considerations

The following notes pertain to CDSA.

5.17.1 Secure Delivery

V8.4

From Version 8.4 onwards, all OpenVMS kits including PCSI and VMSINSTAL

based kits will be signed using HP Code Signing Service (HPCSS). The signing

and validation do not use the CDSA infrastructure. A new companion ﬁle,

<full kit name>_HPC is created and is provided along with the kit. The kit is

then validated using this companion ﬁle.

A new validator, "HPBinarychecker" is installed on all OpenVMS systems to

validate the kits signed using HP Code Signing Service. For more information,

see HP OpenVMS Version 8.4 New Features and Documentation Overview.

Note that the kits that are signed prior to Version 8.4 can be validated using

CDSA on OpenVMS Version 8.4.

V8.3

Downloading of ﬁles over the Internet is becoming a requirement of OpenVMS

customers who want to use this easy and convenient method to acquire software

updates, but are wary of the security vulnerabilities. Secure Delivery makes

use of public key and digital signature technology to implement a system that

provides OpenVMS users with the ability to authenticate and validate the ﬁles

they download from OpenVMS.

Secure Delivery is fully functional with OpenVMS Version 8.3. For more

information, refer to the HP OpenVMS Version 8.3 New Features and

Documentation Overview.

5.17.2 Installation and Initialization Considerations

V8.4

Installation of CDSA is done automatically when you install the operating system.

• When a new version of CDSA is installed separately from an Operating

System upgrade, you must run the CDSA upgrade procedure:

$ @SYS$STARTUP:CDSA$UPGRADE

You should shut down any CDSA application before you run the upgrade

procedure.

It is not necessary to rerun the upgrade procedure when the system is

rebooted. You also do not need to add the upgrade procedure to the OpenVMS

startup procedures.

• Do not attempt to remove CDSA from your system. Use of the PCSI command

PRODUCT REMOVE is not supported for CDSA, even though there is an

apparent option to remove CDSA. (This option is due to the use of PCSI in

the installation.) CDSA is installed together with the operating system and is

tightly bound with it. An attempt to remove it from OpenVMS will not work

5–14 Programming Release Notes

Programming Release Notes

5.17 Common Data Security Architecture (CDSA) Considerations

cleanly and could create other undesirable effects. An attempt to remove

CDSA will result in a message similar to the following:

The following product has been selected:

HP I64VMS CDSA T2.4-315 Layered Product

Do you want to continue? [YES]

%PCSI-E-HRDREF, product HP I64VMS CDSA T2.4-315 is referenced by HP I64VMS OPENV

MS X8.4-C42

The two products listed above are tightly bound by a software dependency.

If you override the recommendation to terminate the operation, the

referenced product will be removed, but the referencing product will have

an unsatisfied software dependency and may no longer function correctly.

Please review the referencing product’s documentation on requirements.

Answer YES to the following question to terminate the PRODUCT command.

However, if you are sure you want to remove the referenced product then

answer NO to continue the operation.

5.18 Debugging Modes: Avoiding CPUSPINWAIT Bugchecks

Permanent Condition

The OpenVMS operating system has a number of special modes of operation

designed to help you debug complex hardware and software problems. In general

terms, these special modes enable an extra level of tracing, data recording,

and consistency checking that is useful in identifying a failing hardware or

software component. These modes of operation are controlled by several system

parameters: MULTIPROCESSING, POOLCHECK, BUGCHECKFATAL, and

SYSTEM_CHECK.

If you are using one of these special modes (for example, to debug a device driver

or other complex application), under certain conditions, generally related to high

I/O loads, it is possible to incur a CPUSPINWAIT bugcheck. Speciﬁcally, any

privileged code that runs for extended periods of time while holding a spinlock

can cause a CPU spinwait bugcheck. Spinlocks are used to delineate the entry

and exit points for critical sections, and should not be held continuously, as can

occur in this situation.

To prevent a CPUSPINWAIT bugcheck, either use the system default settings for

these system parameters, or reduce the loading of the system.

If you have reason to change the default settings, you can reduce the likelihood of

encountering a problem by setting the SMP_LNGSPINWAIT system parameter to

a value of 9000000.

5.19 Delta/XDelta Debuggers

The following release notes pertain to the OpenVMS Delta and XDelta debuggers

running on OpenVMS Alpha and Integrity servers.

5.19.1 XDELTA Register Display Consideration (Integrity servers Only)

V8.2

XDELTA on OpenVMS Integrity server displays general, ﬂoating-point, and

predicate registers as if the register rename base (CFM.rrb) and the rotating size

(CFM.sor) are both zero. In other words, when rotating registers are in use, the

effects of the rotation are ignored. This condition will be corrected in a future

release. See Section 5.16 for additional details.

Programming Release Notes 5–15

Programming Release Notes

5.20 File Applications: Corrections to Guide to OpenVMS File Applications

5.20 File Applications: Corrections to Guide to OpenVMS File

Applications

Permanent Correction

The following corrections will be made to the Guide to OpenVMS File Applications

if this manual is revised in the future.

• Table 1-4 is potentially confusing. In the comparison of ﬁle formats, directory

limitations are listed as 256 for ODS-2 and ODS-5 ﬁle formats. This

statement should be clariﬁed to say 256 directory levels so that users do

not think directories are limited to 256 ﬁles.

A similar table in the HP OpenVMS System Manager’s Manual has been

corrected for Version 8.2.

• In Section 6.6.3, replace the fourth paragraph (not counting the note) with

the following text:

"When you deﬁne the rooted-device logical name for use in a program

in a SET DEFAULT command, you specify that the logical name

is a concealed-device logical name by using the /TRANSLATION_

ATTRIBUTES=CONCEALED qualiﬁer with the DCL command DEFINE

or ASSIGN. To deﬁne the concealed-device logical name as a rooted-device

logical name, the root directory must contain a trailing period (.), such as

DUA22:[ROOT.] and the device speciﬁcation must be a physical device name.

The equivalence name for a rooted-device logical name must not contain other

logical names. When specifying a directory, you can use only a trailing period

for the root directory."

5.21 HP BLISS Compiler Warnings with RMS Structures (Integrity

servers Only)

Permanent Condition

Quadword alignment has been added to the BLISS macros ($xxx_DECL)

that can be used to allocate RMS user structures (for example, FAB, RAB).

Alignment faults are costly to performance—especially as processors get faster.

By implementing the alignment directly in the macros, a number of OpenVMS

utilities and user applications written in BLISS that use these macros show

improved performance.

The speciﬁc names of the macros are: $FAB_DECL, $NAM_DECL, $NAML_

DECL, $RAB_DECL, $RAB64_DECL, $XABALL_DECL, $XABDAT_DECL,

$XABFHC_DECL, $XABITM_DECL, $XABJNL_DECL, $XABKEY_DECL,

$XABPRO_DECL, $XABRDT_DECL, $XABRU_DECL, $XABTRM_DECL, and

$XABSUM_DECL.

The alignment added in the RMS macros might result in compiler warnings of

conﬂicting alignment. Programs with compiler warnings should link and execute

correctly. However, the minor source changes to eliminate the warnings are

recommended.

If you use any of these macros in a BLISS application and the declaration

includes the ALIGN attribute, the BLISS compiler issues a ‘‘conﬂicting or

multiply speciﬁed attribute’’ warning. For example, the warning is issued for the

following declaration: FAB: $FAB_DECL ALIGN(2). The compiler also issues this

warning even if quadword alignment (ALIGN(3)) is speciﬁed. You should remove

any explicit ALIGN attributes associated with these macros.

5–16 Programming Release Notes

Programming Release Notes

5.21 HP BLISS Compiler Warnings with RMS Structures (Integrity servers Only)

In addition, if any of these allocations is included in a PSECT that contains

an explicit alignment that is in conﬂict with ALIGN(3) (that is, is lower than

ALIGN(3)), the BLISS compiler issues an ‘‘align request negative or exceeds that

of psect’’ warning. For example, the warning would be issued for the following

declaration:

PSECT OWN = $OWN$ (..., ALIGN(2), ...)

OWN

FAB = $FAB_DECL, ...

If warnings on PSECT alignment are seen when recompiling a BLISS application,

the correction is to increase the alignment of the PSECT to ALIGN(3) (or higher).

In rare cases, applications may have assumptions on adjacency of data between

PSECTs. Those assumptions could be broken in making this change. Therefore,

check the code for such assumptions and make any necessary corrections.

While a number of OpenVMS utilities are written in BLISS, only a few warnings

were generated in a full OpenVMS build. Changes in OpenVMS to eliminate

warnings did not require other changes to correct assumptions. Based on this,

few user applications likely will require modiﬁcation.

5.22 Potential Must-Be-Zero RMS Error: Making Room for New File

Options in the FAB

V8.3

There is very little remaining unassigned space in the RMS user ﬁle access block

(FAB). To allow for future growth in ﬁle-processing options implemented through

the FAB, the last unassigned bit in the ﬁle-processing options ﬁeld in the

FAB

(FAB$L_FOP)

has been deﬁned as the

FAB$V_EXTEND_FOP

option. This option will

be used in the future to request and validate assignments to two new FAB ﬁelds

that span previously unused bytes in the FAB:

•

FAB$W_FOPEXT

: The FOPEXT word ﬁeld is reserved for the deﬁnition of new

ﬁle-processing options that might require implementation in the future.

•

FAB$W_RESERVED_MBZ

: The

RESERVED_MBZ

word ﬁeld is being reserved for

future use. Its usage is currently open for future deﬁnition.

In a future release, when one or more new ﬁle-processing options are

implemented, the

FAB$V_EXTEND_FOP

bit will have to be set in the

FAB$L_FOP

ﬁeld to take advantage of any new option in the

FOPEXT

ﬁeld. However, when it is

set, it will also indicate that any undeﬁned bits in the

FOPEXT

ﬁeld are clear and

FAB$W_RESERVED_MBZ

contains a zero. If these conditions are not met when this

bit is set, a fatal error

(RMS-F-FOPEXTMBZ)

will be returned to the user for any

RMS ﬁle-level service.

The addition of the

EXTEND_FOP

option is fully upwardly compatible except if a

user sets this last bit in the

FAB$L_FOP

ﬁeld by accident and either of these two

new FAB ﬁelds happens to be nonzero. Previously, RMS ignored this last bit in

the

FAB$L_FOP

ﬁeld if it was set by accident.

If the

RMS-F-FOPEXTMBZ

error is returned, you must clear either the

EXTEND_FOP

option in the

FAB$L_FOP

ﬁeld or the two new ﬁelds

(FAB$W_FOPEXT) and

FAB$W_RESERVED_MBZ

Programming Release Notes 5–17

Programming Release Notes

5.23 HP COBOL Run-Time Library (RTL)

V8.4

For OpenVMS Alpha and OpenVMS Integrity servers Version 8.4, the HP COBOL

RTL (DEC$COBRTL) has been updated to V2.9-785.

5.23.1 Performance Improvement of COBOL CALL Statement

V8.4

Performance degradation was observed on OpenVMS Integrity servers while

calling subroutines, using the COBOL CALL statement. The time taken was

much longer on OpenVMS Integrity servers than on OpenVMS Alpha.

The Run-Time Library (RTL) has been modiﬁed and the performance of the

COBOL CALL statement has signiﬁcantly improved. Now, the performance on

OpenVMS Integrity servers is comparable to OpenVMS Alpha.

5.24 HP Fortran for Integrity servers

V8.2

The HP Fortran for OpenVMS Integrity servers compiler is a port of HP Fortran

90 for OpenVMS Alpha. It runs on OpenVMS Integrity servers and produces

objects for OpenVMS Integrity server systems. The objects are linked using the

standard linker on OpenVMS Integrity servers. This compiler requires OpenVMS

Integrity servers Version 8.2 or greater.

HP Fortran for OpenVMS Integrity servers features the same command-line

options and language features as HP Fortran 90 for OpenVMS Alpha systems

with the following exceptions:

• Floating-point arithmetic

Refer to the white paper OpenVMS Floating-Point Arithmetic on the Intel®

Itanium® Architecture for essential reading. You can link to this document

from the following web site:

http://h71000.www7.hp.com/openvms/integrity/resources.html

• IEEE is the default ﬂoating-point datatype (that is, the default is

/FLOAT=IEEE_FLOAT).

• The /IEEE_MODE qualiﬁer defaults to /IEEE_MODE=DENORM_RESULTS.

• Users should pick one /FLOAT value and one /IEEE_MODE value and keep it

for the whole application.

• Only the F90 compiler is supported. The F77 compiler, previously invoked

with the /OLD_F77 qualiﬁer, is not available. Some of the functionality

contained in the Alpha F77 compiler that is not available in the Alpha

F90 compiler has been implemented in the Integrity servers F90 compiler,

including FDML and CDD support. See the Fortran V8.0 or V8.1 product

release notes for details.

• Alpha values for the /ARCH and /TUNE qualiﬁers are accepted on

the compiler invocation command for compile-and-go compatibility. An

informational message is displayed saying that they are ignored.

5–18 Programming Release Notes

Programming Release Notes

5.24 HP Fortran for Integrity servers

For more information about this release, including installation instructions, read

the Fortran V8.0 or V8.1 product release notes. To extract the release notes, set

your default to the directory that contains the Fortran PCSI kit and enter one of

the following commands:

$ PRODUCT EXTRACT RELEASE_NOTES FORTRAN ! For TXT file

$ PRODUCT EXTRACT FILE FORTRAN/SELECT=FORTRAN_RELEASE_NOTES.PS ! For PS file

5.25 HP MACRO for OpenVMS

The OpenVMS MACRO compiler compiles Macro-32 source code written for

OpenVMS VAX systems (the VAX MACRO assembler) into machine code that

runs on OpenVMS Alpha and OpenVMS Integrity servers. The following notes

pertain to the MACRO compiler.

5.25.1 Enhancements for the Macro-32 Compiler

V8.4

The Macro-32 compiler has been enhanced to include several new instruction

level built-ins for OpenVMS Alpha and OpenVMS Integrity server systems.

Table 5–1 summarizes the new built-ins added.

Table 5–1 Macro-32 New Built-ins

Built-in Operands1Description

Supported

EVAX_WH64 <AB> Generate Alpha write hint 64

instructions

Alpha

IA64_PADD1 <WQ,RQ,RQ> Generate Parallel Add instruction, single

byte form with the ﬁrst argument as the

destination and the next two arguments

as the source operands

Integrity

servers

IA64_PADD1_SSS <WQ,RQ,RQ> Generate Parallel Add instruction, single

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands. Result and both

source operands are treated as signed.

Integrity

servers

IA64_PADD1_UUS <WQ,RQ,RQ> Generate Parallel Add instruction, single

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands. Result and ﬁrst

source operand are treated as unsigned

and the second source operand is treated

as signed.

Integrity

servers

IA64_PADD1_UUU <WQ,RQ,RQ> Generate Parallel Add instruction, single

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands. Result and both

source operands are treated as unsigned.

Integrity

servers

1The built-in requires the operands, where WQ - Write Quadword, PQ - Read Quadword, AB - Address of Byte.

(continued on next page)

Programming Release Notes 5–19

Programming Release Notes

5.25 HP MACRO for OpenVMS

Table 5–1 (Cont.) Macro-32 New Built-ins

Built-in Operands1Description

Supported

IA64_PADD2 <WQ,RQ,RQ> Generate Parallel Add instruction, two

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands.

Integrity

servers

IA64_PADD2_SSS <WQ,RQ,RQ> Generate Parallel Add instruction, two

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands. Result and both

source operands are treated as signed.

Integrity

servers

IA64_PADD2_UUS <WQ,RQ,RQ> Generate Parallel Add instruction, two

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands. Result and ﬁrst

source operand are treated as unsigned

and the second source operand is treated

as signed.

Integrity

servers

IA64_PADD2_UUU <WQ,RQ,RQ> Generate Parallel Add instruction, two

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands. Result and both

source operands are treated as unsigned.

Integrity

servers

IA64_PADD4 <WQ,RQ,RQ> Generate Parallel Add instruction, four

byte form, with the ﬁrst argument as the

destination and the next two arguments

as the source operands.

Integrity

servers

IA64_MUX1 <WQ,RQ,RQ> Generate ’mux1’ instruction with the

ﬁrst argument as the destination and

the second argument as the source

operand. The third argument speciﬁes

the permutation to be performed.2

Integrity

servers

EVAX_S4ADDQ <WQ,RQ,RQ> Generates Alpha scaled quadword add

instruction.

Alpha and

Integrity

servers

IA64_LFETCH_NT1,

IA64_LFETCH_NT2,

IA64_LFETCH_NTA,

IA64_LFETCH_EXCL_NT1,

IA64_LFETCH_EXCL_NT2,

IA64_LFETCH_EXCL_NTA

<RQ,RQ> These enhanced prefetch built-ins

provide a method for specifying non-

default cache locality hints (that is,

".nt1",".nt2",and ".nta"). The ﬁrst

operand is the address to prefetch

and the second operand is for either

the reg-base-update-form or the imm-

baseupdate-form; if the operand is the

literal zero, the no-baseupdate- form will

be used.

Integrity

servers

1The built-in requires the operands, where WQ - Write Quadword, PQ - Read Quadword, AB - Address of Byte.

2A literal specifying the permutation has to be used as the third argument. The mapping of the permutations to the

literals are as follows:

• BRCST 0

• MIX 8

• SHUF 9

•ALT10

• REV 11

(continued on next page)

5–20 Programming Release Notes

Programming Release Notes

5.25 HP MACRO for OpenVMS

Table 5–1 (Cont.) Macro-32 New Built-ins

Built-in Operands1Description

Supported

All the _FAULT_variants of

the LFETCH built-in

Generates ’lfetch’ instructions with the

’fault’ completer. For example, IA64_

LFETCH_FAULT_EXCL_NT1

Integrity

servers

1The built-in requires the operands, where WQ - Write Quadword, PQ - Read Quadword, AB - Address of Byte.

For additional information about underlying instructions, see the respective

hardware architecture manuals.

5.25.2 HP MACRO for OpenVMS Integrity servers

V8.3

The following notes pertain to the HP MACRO for OpenVMS Integrity servers

compiler:

• Prior to OpenVMS Version 8.3, the compiler generated the wrong code for the

HALT instruction. On Integrity servers, the HALT instruction is implemented

using the Itanium

break

instruction with a reserved literal value of

BREAK$C_SYS_HALT

. Because of a bug in the compiler’s build environment,

the Macro-32 compiler used the wrong literal value. This problem has been

ﬁxed in Version 8.3. Any code that uses the HALT instruction should be

recompiled with the Version 8.3 compiler. For systems prior to Version 8.3,

the correct behavior can be accomplished as follows:

$BREAKDEF

IA64_HALT #BREAK$C_SYS_HALT ; Issue break instruction with correct literal

HALT ; Use HALT built-in to inform compiler that this ends the flow of control

• The compiler might optimize away instructions prior to

HALT

BPT

, and

EVAX_BUGCHK

. The optimizer does not identify these special instructions as

implicitly reading all registers by either writing a dump ﬁle or transferring

control to a debug environment. The apparently unused instructions are

removed by mistake. The compiler has to be taught about the special

behavior of these instructions. Though there is no syntax to force arbitrary

instructions to be included in the ﬁnal object ﬁle, the IA64_LD8_A built-in

can be used as a workaround. See the following Macro-32 paragraphs for

information about this built-in. In addition, specifying

/NOOPTIMIZE

preserves

the apparently unused instructions at the expense of slower and larger code.

• The compiler might optimize away apparently unused memory loads. The

compiler’s optimizer can recognize whether or not the result of a memory

load is used. If the result appears to be unused, the optimizer removes

the memory load as well. However, some code might be using the memory

load to fault a page into memory before raising IPL for example. In these

cases, the removed instruction prevents the page from being faulted into

memory, and the subsequent code at high IPL experiences a fatal page

fault at high IPL exception. Although there is no syntax to force arbitrary

instructions to be included in the ﬁnal object ﬁle, the IA64_LD8_A built-in

can be used as a workaround. The IA64_LD8_A built-in, new in Version 8.3,

generates a special form of the Itanium "ld8" instruction that also places the

fetched address into the ALAT (Advanced Load Address Table). The compiler

identiﬁes this special form of "ld8" as having a side effect and that it cannot

be removed from the ﬁnal object ﬁle even if the result appears to be unused.

The insertion of the address into the ALAT does not cause any problems or

Programming Release Notes 5–21

Programming Release Notes

5.25 HP MACRO for OpenVMS

require any additional changes. For unused memory loads that must remain

in ﬁnal object ﬁle, change them from:

MOVL (Rn),Rn

into

IA64_LD8_A Rn,(Rn),#0

HP will add new syntax to the compiler in a future release to designate

instructions that must survive to the ﬁnal object ﬁle.

For systems prior to Version 8.3, there is no IA64_LD8_A built-in. The only

workaround is to use

/NOOPTIMIZE

5.25.3 HP MACRO for OpenVMS Alpha Systems

V8.3

The compiler might optimize away apparently unused memory loads. The

compiler’s new optimizer can recognize whether or not the result of a memory

load is used. If the result appears to be unused, the optimizer removes the

memory load as well. However, some code may be using the memory load to

fault a page into memory before raising IPL for example. In these cases, the

removed instruction prevents the page from being faulted into memory, and the

subsequent code at high IPL experiences a fatal page fault at high IPL exception.

The only workaround is either to use

/NOOPTIMIZE

or revert to the prior Macro-32

compiler, which does not contain the optimization.

The new Macro-32 compiler is named

SYS$SYSTEM:MACRO.EXE

and is the default

image activated by the

DCL MACRO

command. The older compiler can be found at

SYS$SYSTEM:ALPHA_MACRO.EXE

. For the DCL command MACRO to use the older

compiler, deﬁne a MACRO logical name as follows:

$ DEFINE MACRO SYS$SYSTEM:ALPHA_MACRO.EXE

5.25.4 /OPTIMIZE=VAXREGS Qualiﬁer Not Supported on Integrity servers

V8.2

The /OPTIMIZE=VAXREGS qualiﬁer, which is supported on Alpha, is not

supported on Integrity servers. Unfortunately, all of the related code was not

removed from the command line processing. If you specify /OPTIMIZE=ALL

on Integrity servers, you will accidentally turn on the unsupported VAXREGS

optimization. A future release will correct the command line process to avoid

turning on the VAXREGS optimization.

5.25.5 Floating Divide-by-Zero Error Not Raised (Integrity servers Only)

V8.2

The Macro-32 ﬂoating-point support routines do not detect ﬂoating division by

zero. The support routines convert the VAX ﬂoating values to IEEE ﬂoating

values and perform the division. Without the check, the division produces an

IEEE NaN value. The support routines then attempt to convert the NaN value

back into a VAX ﬂoating value. That operation raises a ﬂoating invalid error.

A future release will ﬁx the support routines to properly raise the ﬂoating

divide-by-zero error.

5–22 Programming Release Notes

Programming Release Notes

5.26 Hypersort Utility

The following notes pertain to Hypersort V08-006 for OpenVMS Alpha and

OpenVMS Integrity servers Version 8.2.

As always, continue to use SORT32 as a workaround for any unresolved problems

with Hypersort or any functionality not implemented in Hypersort. Release notes

for SORT32 are in Section 5.38.

5.26.1 Reporting a Problem to HP

Permanent Condition

If you ﬁnd a problem with SORT or MERGE, execute the following commands

before you submit a problem report:

$ WRITE SYS$OUTPUT "WSEXTENT =’’F$GETJPI("","WSEXTENT")’"

$ WRITE SYS$OUTPUT "PGFLQUOTA=’’F$GETJPI("","PGFLQUOTA")’"

$ SHOW LOGICAL SORTSHR

$ SORT/STATISTICS (or MERGE/STATISTICS)

Include the output in your problem report along with the input ﬁles that

demonstrate the problem.

5.26.2 Large Files Restriction

V8.2

Hypersort V08-010 includes an improved memory allocation algorithm, but

Hypersort still sometimes hangs or ACCVIOs with large input ﬁles. To reduce

the chances of a hang or an ACCVIO, make sure to set page ﬁle quota and

working set extent as noted in Section 5.26.8. If you encounter a hang or an

ACCVIO with Hypersort, use SORT32 instead.

5.26.3 Hypersort and VFC Files Restriction

V7.3-2

Use of VFC ﬁles with Hypersort requires /FORMAT=RECORD_SIZE:n.

5.26.4 /FORMAT=RECORD_SIZE Restriction

Permanent Restriction

Hypersort supports /FORMAT=RECORD_SIZE:n for use with both SORT and

MERGE, with the following two restrictions:

• In all cases, if the command-speciﬁed RECORD_SIZE is less than the longest

record size (LRL) of any record in the input ﬁles, the records that are too

long are truncated to the RECORD_SIZE size in the sorted output ﬁle and

the diagnostic message %SORT-E-BAD_LRL is issued. In this situation,

the output ﬁle should be discarded and the sort should be rerun. The

RECORD_SIZE parameter for the SORT command should be revised to a

value appropriate to the size of the largest record as shown in the listing of a

DIR/FULL command for the input ﬁles.

• SORT and MERGE produce output sequential ﬁles from input indexed ﬁles.

The %SORT-E-BAD_LRL diagnostic message can also be issued for this case.

Programming Release Notes 5–23

Programming Release Notes

5.26 Hypersort Utility

5.26.5 Using Hypersort with Search Lists and Other Uses of Logical Names

Permanent Restriction

Hypersort does not fully support search lists and logical names used for input

ﬁles and work ﬁles. If you encounter this problem, use SORT32.

5.26.6 Lack of Free Space for Work Files

Permanent Restriction

Hypersort does not properly terminate if free space is exhausted in all available

sort work ﬁles. To avoid this problem, do one of the following:

• Allocate sufﬁcient free space for the devices used for sort work ﬁles.

• Use SORT32 to detect that work ﬁle space has been exhausted.

5.26.7 Input Asterisk (*) Restriction

Permanent Restriction

Hypersort does not support asterisk (*) as an input ﬁle speciﬁcation.

5.26.8 Optimal Working Set Extent and Page File Quota Settings

Permanent Restriction

SORT32 and Hypersort use different sorting and work ﬁle algorithms.

The relative speed of these utilities depends on the input ﬁle and the

memory/disk/CPU conﬁguration. Make sure that the working set extent is

no more than one third of the page ﬁle quota. Both SORT32 and Hypersort

perform best with a working set extent appropriate to a speciﬁc input ﬁle.

5.27 Intel Assembler (Integrity servers Only)

Permanent Restriction

All modules written in Intel assembly language must contain appropriate

unwind directives, either by automatic generation using the -Xunwind ﬂag or by

explicitly placing unwind directives into the source module. Without accurate

unwind information, the operating system’s condition handling and exception

dispatching does not work, and your program fails in unexpected ways. Programs

without accurate unwind information are not supported by OpenVMS. This is a

permanent requirement.

5.28 Librarian Utility

The following release notes pertain to the Librarian Utility and Library Service

routines.

5.28.1 Linking Against Data-Reduced ELF Object Libraries Not Recommended

(Integrity servers Only)

V8.2

DCX data-reduced ELF object libraries are not stored in contiguous space in

the library. As a result, the module cannot be directly mapped into process P2

space because data expansion must ﬁrst occur. The LBR$MAP_MODULE library

service expands and copies the module into process P2 space. This action causes

the resulting pages in P2 space to be counted against process quota.

5–24 Programming Release Notes

Programming Release Notes

5.28 Librarian Utility

The LBR$UNMAP_MODULE library service recovers those pages, but the pages

remain in a heap storage free list and continue to be counted against process

quota. For this reason, HP strongly recommends that DCX data-reduced ELF

object libraries ﬁrst be expanded before performing Linker operations.

5.28.2 Failure to Insert or Replace .STB ﬁles in an Integrity servers Library

(Integrity servers Only)

V8.2

On OpenVMS VAX and Alpha, .STB ﬁles can be stored in object libraries. On

OpenVMS Integrity servers, the Librarian does not do this. For example:

$ LIBR/CREATE OBJ$:SOME_LIBRARY OBJ$:SOME_FILE.STB

Librarian T01-23

%LIBRAR-E-NOTELFFILE, TPSSWRKD$:[TPSS.TRACE.IA64.LPIOBJ]TRACEMSG.STB;1

is not an ELF object or image file

Because .STB ﬁles are neither objects nor images, the Librarian does not

currently put them into an .OLB ﬁle on Integrity servers.

On Alpha and VAX, however, STB ﬁles are formatted as object ﬁles. On VAX,

.STB ﬁles can be used as input to the Linker. On Alpha, .STB ﬁle formats are

identical to .OBJ ﬁle format (that is, nothing distinguishes them except for the

.STB ﬁle extension). As such, the Alpha Librarian accepts the ﬁle, but it cannot

be used as input to the Linker.

On Integrity servers, the ﬁle type (ET_VMS_LINK_STB) is embedded in the .STB

ﬁle, allowing the Librarian and Linker to determine that the .STB ﬁle cannot be

processed. This is a permanent condition.

5.28.3 Librarian Fails to Report Errors When Process Quota Too Low

Permanent Restriction

The OpenVMS Alpha and Integrity servers Librarian sometimes does not inform

you of errors during compression, data reduction, or data expansion operations.

This problem occurs if the account or process in which the Librarian is running

has a low PGFLQUOTA process quota. Operation failure is not readily apparent

because the $PUTMSG system service always returns a status of SS$_NORMAL,

even when the system service fails. However, when a failure occurs, the Librarian

returns a status other than Success.

To work around this problem, increase your PGFLQUOTA before running

compression, data reduction, or data expansion operations. In addition, ensure

that your command procedures check the return status from the LIBRARY

command.

5.29 Linker Utility for OpenVMS Alpha

The following release notes pertain to the Alpha Linker Utility on all OpenVMS

platforms. For Integrity servers Linker release notes, see Section 5.30.

Programming Release Notes 5–25

Programming Release Notes

5.29 Linker Utility for OpenVMS Alpha

5.29.1 Linker Appears to Hang When Many Files Are Speciﬁed

V8.3

When the RMS_RELATED_CONTEXT linker option is on (the default is RMS_

RELATED_CONTEXT=YES) and a nonexistent ﬁle is speciﬁed in a list of ﬁles for

the LINK command, the linker’s call to LIB$FIND_FILE may take a long time to

complete and the linker may appear to hang. Depending on the number of ﬁles

being linked and the use of logical names in their speciﬁcation, the linker may

take hours to ﬁnish because LIB$FIND_FILE locates every combination of the

missing ﬁle’s preﬁx before displaying a "ﬁle not found" message. Note that you

cannot terminate the linker process by pressing Ctrl/Y after the linker has called

LIB$FIND_FILE.

To determine which ﬁle is missing, follow the steps described with the RMS_

RELATED_CONTEXT= option in the Linker Manual, Part IV, LINK Command

Reference.

5.29.2 Change in Linker Default Behavior with Library Check

V7.3-1

Previously, the linker’s check between the library and the shareable image was

too sensitive. It compared against the exact date and time, signaling LINK-I-

DATMISMCH, if no match was found. Now, however, it makes only the same

check that the image activator does: that is, it uses the GSMATCH criteria to

verify compatibility.

The old behavior (check for date and time) can be obtained by setting the logical

name LINK$SHR_DATE_CHECK.

For more information, see the /LIBRARY qualiﬁer in the Linker Manual Part IV,

LINK Command Reference.

Shareable image libraries do not contain a copy of an image. They contain the

image’s name, the image’s identiﬁcation information, and a table including the

image’s universal symbols. The identiﬁcation information is provided by the

GSMATCH=

option when the shareable image is linked. For more information, see

the

GSMATCH=

option in the Linker Manual Part IV, LINK Command Reference.

It may happen that a shareable image is relinked but that a library is not

updated. To handle such a case, the linker checks for compatibility. The linker

makes the same check that the image activator does: that is, it uses the

GSMATCH

criteria to verify compatibility.

For VAX, the linker also compares against the date and time, signaling

LINK-I-

DATMISMCH

, if they are different.

For Alpha, the initial behavior of linker was the same as the VAX linker. The

check was seen as too sensitive and the default behavior was changed to use only

the GSMATCH criteria. The old VAX behavior can be obtained by setting the

logical name

LINK$SHR_DATE_CHECK

5.29.3 Limit of 25 Elements on Stack

Permanent Restriction

Developers who are creating object ﬁles should be aware that the linker’s internal

stack is guaranteed for only 25 elements. Any calculations must be done within

this constraint.

5–26 Programming Release Notes

Programming Release Notes

5.30 Linker Utility for OpenVMS Integrity servers

The following release notes pertain to the Integrity servers Linker utility.

For Alpha Linker release notes, see Section 5.29.

5.30.1 Linker Writes Incorrect Interimage Debug Fixups into Debug Symbol

File

V8.3-1H1

In some situations, the linker creates interimage ﬁxups for the OpenVMS

debugger. The inter-image debug ﬁxup is a result of compiler-generated debug

relocations, which the linker cannot resolve. That is, the debugger requires these

ﬁxups to determine a value from a shareable image at run time. Compilers might

differ on how often they require the linker to create interimage ﬁxups for the

debugger. The C compiler rarely uses inter-image debugger ﬁxups, although the

C++ compiler often uses them. When linking such images with the /DEBUG

qualiﬁer, the linker writes the debug information followed by the interimage

debug ﬁxups. With the /NODSF qualiﬁer (the default) the information is written

correctly into the image ﬁle, but with /DSF the information is sometimes written

incorrectly into the DSF ﬁle.

For example, the DEBUG informationals and the DEBUG error in the following

sample occur because the linker has written the DSF ﬁle incorrectly:

$ RUN/DEBUG MINIREF

%DEBUG-I-INFODWARF, error reading Dwarf info: Section 0a extends outside file

%DEBUG-I-INFODWARF, error reading Dwarf info: Section 0c extends outside file

%DEBUG-I-INFODWARF, error reading Dwarf info: SHT_VMS_FIXUP section 10 size 17eb

e0 not multiple of 18

%DEBUG-I-INFODWARF, error reading Dwarf info: SHT_VMS_FIXUP section 12 size 17ec

30 not multiple of 18

OpenVMS I64 Debug64 Version V8.3-003

%DEBUG-F-ACCVIO, access violation, reason mask=00, virtual address=000000000014A

000, PC=000000007BD73100, PS=0000001B

%DEBUG-I-INITIAL, Language: C, Module: MINIREF

DBG>

The image file is not affected; it can be executed with the RUN command

without any problem:

$ RUN MINIREF

This error is corrected in the OpenVMS Version 8.3-1H1 Linker.

5.30.2 /SELECTIVE_SEARCH Qualiﬁer Might Incorrectly Ignore Transfer

Address

V8.3-1H1

If you have an Integrity server object module containing a transfer address and

you include the module in the link operation with the /SELECTIVE_SEARCH

qualiﬁer, the linker cannot ﬁnd its transfer address.

In the following example, the object module (MAIN.OBJ) contains a transfer

address but /SELECTIVE_SEARCH qualiﬁer ignores it:

$ LINK MAIN/SELECTIVE_SEARCH

%ILINK-W-USRTFR, image USER:[JOE]MAIN.EXE;1 has no user transfer address

Programming Release Notes 5–27

Programming Release Notes

5.30 Linker Utility for OpenVMS Integrity servers

This condition happens only when Integrity server object modules, meant to

provide the program’s transfer address, are included in the link operation with

the SELECTIVE_SEARCH attribute. The SELECTIVE_SEARCH attribute is

given to an object module when you specify the /SELECTIVE_SEARCH qualiﬁer

to the object module in the LINK command or in a LIBRARY command.

For example:

$ LINK MAIN/SELECTIVE_SEARCH

$ LIBRARY/INSERT LIB.OLB MAIN.OBJ/SELECTIVE_SEARCH

This problem manifests itself in one of two ways:

• The linker displays a warning message. This condition occurs if no other

object module in the link operation provides a transfer address, weak or

otherwise.

• The linker does not display a message. This condition occurs if other object

modules in the link operation provide a transfer address, weak or otherwise.

If the linker fails to properly identify the transfer address from the selectively

searched object module, it selects one from the other object modules. That

transfer address becomes the main entry point for the image. Even though

the map ﬁle does indicate the incorrect transfer module and transfer address

the linker has assigned, the problem might not become evident until you

actually run your application.

This error is corrected in the OpenVMS Version 8.3-1H1 Linker.

5.30.3 Maximum Number of Sections

V8.3-1H1

For more than 65280 sections, the ELF format uses an extended numbering

scheme, which was not implemented in the linker on OpenVMS Integrity server

Version 8.3. As a result, the number of sections that a single input object module

or shareable image can have was limited. Because the linker usually creates

the shareable images with sections, this limit also applied when you created

shareable images. In that case, ELF sections were used for exporting C++

templates or shared sections. That is, the maximum number of such interfaces in

a shareable image had to be fewer than 65280.

In the OpenVMS Version 8.3-1H1 Linker, this restriction is removed. An input

ﬁle, an object module or a shareable image can have more than 65280 sections.

5.30.4 Incorrect Creation Date of Shareable Images in the Map File

V8.3-1H1

On OpenVMS Integrity servers, shareable images sometimes showed an incorrect

creation date in the linker map. The incorrect date shown was usually 3686. This

condition occurred when the linker processed the shareable image as an input ﬁle

and then extracted the date ﬁeld, which was then shown in the map. The image

itself had the correct date that you can see from ANALYZE/IMAGE output.

This error is corrected in the OpenVMS Version 8.3-1H1 Linker.

5–28 Programming Release Notes

Programming Release Notes

5.30 Linker Utility for OpenVMS Integrity servers

5.30.5 Demangler Information Look Up Results in Linker Access Violation

V8.3-1H1

In some cases, when the linker tried to look up demangler information in a

shareable image that did not contain such information, the linker aborted with

an access violation.

This problem is corrected in the OpenVMS V8.3-1H1 Linker.

5.30.6 Incorrect Secondary Messages for the NOGLOSYM Error Message

V8.3-1H1

For the NOGLOSYM error message, the OpenVMS Version 8.3 Linker printed

the wrong relocation type and printed some information twice.

This problem is corrected in OpenVMS Version 8.3-1H1.

5.30.7 Incorrect Information for Undeﬁned Symbols

V8.3-1H1

For undeﬁned symbols, a USEUNDEF operation sometimes incorrectly showed

information twice for the same reference. The problem occurred when the

compiler generated a pair of relocations (LTOFF22X/LDXMOV) for the reference

to an undeﬁned symbol.

This problem is corrected in OpenVMS Version 8.3-1H1.

5.30.8 Incorrect UNMAPFIL Error

V8.3-1H1

If a non-ELF input ﬁle was encountered, the linker printed an INVLDHDR error

message. After an INVLDHDR error, an incorrect UNMAPFIL error message was

printed.

This problem is corrected in OpenVMS Version 8.3-1H1.

5.30.9 Max Ident Length Change for Shareable Images in Map

V8.3-1H1

In the linker map, the linker printed up to 14 characters of the ident from object

modules and shareable images. (The maximum length of an ident for an object

module is not limited; the maximum length of an ident for a shareable images is

15.)

The Version 8.3-1H1 linker now prints up to 15 characters as the maximum of

the ident for a shareable image.

5.30.10 Linkage Type Check for Shareable Images

V8.3-1H1

Previously, the linker did not check the type and linkage for symbols from

shareable images.

OpenVMS Version 8.3-1H1 Linker now performs this check.

Programming Release Notes 5–29

Programming Release Notes

5.30 Linker Utility for OpenVMS Integrity servers

5.30.11 Program Section Attribute ABS Ignored

V8.3-1H1

On Integrity servers, you cannot set the ABS attribute to a program section that

contains labels to convert its offsets to constants. The linker prints the error

message:

%ILINK-E-ILLABSPSC, absolute psect <psect-name> has non-zero length (not

allowed)

The OpenVMS 8.3-1H1 Linker ignores the ABS program section attribute and

prints the following informational message:

%ILINK-I-PSCATTIGN, psect attribute ABS is not supported for OpenVMS ELF

sections, attribute ignored

5.30.12 Linker ACCVIOs when FP_MODE Literal Missing From Command Line

V8.3-1H1

In the Version 8.3, the Integrity server Linker encountered an access violation

when the FP_MODE literal was missing on the command line.

This problem is corrected in OpenVMS Version 8.3-1H1.

5.30.13 OpenVMS Integrity servers Object Module and Image File Information

Currently Unavailable

V8.3

Information about the OpenVMS Integrity servers extension to ELF (Executable

and Linkable Format; the object module and image ﬁle format on Integrity

servers) is not available at this time. It will be provided in a future release.

For information about the Alpha or VAX object language format, see the

respective appendixes in the OpenVMS Alpha/VAX Version 7.3 OpenVMS Linker

Utility Manual, available from the documentation bookshelf at the following URL:

http://h71000.www7.hp.com/doc/os732_index.html

5.30.14 Differences Between the Integrity servers Linker and the Alpha Linker

V8.3

Be sure to read the HP OpenVMS Version 8.3 New Features and Documentation

Overview for a complete description of the differences between the OpenVMS

Integrity servers Linker and the OpenVMS Alpha Linker. The HP OpenVMS

Version 8.3 New Features and Documentation Overview also contains a description

of features that are new with the OpenVMS Integrity servers Linker.

5.30.15 LINK_ORDER Section Header Flag Not Supported

V8.2

The Linker does not support the LINK_ORDER ELF section header ﬂag.

However, unwind sections, which have this ﬂag set, are placed in the correct

order.

This ﬂag indicates that the section, if combined with other sections in the image

ﬁle, be combined in the same order as the order of the sections to which they

refer are combined. Unwind sections are handled as special cases and appear in

the correct order.

5–30 Programming Release Notes

Programming Release Notes

5.30 Linker Utility for OpenVMS Integrity servers

The following ﬁgure illustrates this concept.

Unwind

Sections

(LINK_ORDER

bit set)

Code

Sections

Combined

Code

Sections

Resulting

Combined

Unwind

Sections

refers to

VM-1134A-AI

5.30.16 Linking Against Data-Reduced ELF Object Libraries Not

Recommended

V8.2

DCX data-reduced ELF object libraries are not stored in contiguous space in

the library. As a result, the module cannot be directly mapped into process P2

space because data expansion must ﬁrst occur. The LBR$MAP_MODULE library

service expands and copies the module into process P2 space. This action causes

the resulting pages in P2 space to be counted against process quota.

The LBR$UNMAP_MODULE library service recovers those pages but the pages

remain in a heap storage free list and continue to be counted against process

quota. For this reason, HP strongly recommends that DCX data-reduced ELF

object libraries ﬁrst be expanded before performing Linker operations. This is a

permanent condition.

5.30.17 Error in Handling Initialized Overlaid Program Sections Fixed

V8.3

In previous versions of the Integrity servers linker, initialized overlaid program

sections with zeros are incorrectly seen as compatible initializations. In

OpenVMS Version 8.2 and Version 8.2-1, the Integrity servers Linker accepts

sections initialized with zeros to be compatible with sections containing nonzero

initial values. Under this condition, the order of modules in a link operation can

result in different initial values in the image.

This problem is ﬁxed in Version 8.3.

Programming Release Notes 5–31

Programming Release Notes

5.30 Linker Utility for OpenVMS Integrity servers

5.30.18 Removal of Linker Qualiﬁers /EXPORT_SYMBOL_VECTOR and

/PUBLISH_GLOBAL_SYMBOLS

V8.3

Creating a shareable image by simply exporting all global symbols does not work.

Previous Integrity servers Linker versions provide the /EXPORT_SYMBOL_

VECTOR and /PUBLISH_ GLOBAL_ SYMBOLS qualiﬁers to assist in creating

symbol vector options for all global symbols on a per-module basis. However,

using these qualiﬁers exports the same universal symbol from different images.

Because you cannot exclude exporting the same C++ template from different

images, this creates problems.

Both qualiﬁers are removed from the Version 8.3.

This problem will be ﬁxed for the Integrity servers Linker in a future release of

OpenVMS for Integrity servers.

5.30.19 Support for Longer Symbol Names in Options

V8.3

For options, the linker internal line buffer is increased to hold 2048 characters.

This allows specifying options with symbol names of the maximum supported

length of 1024 characters.

5.30.20 Better Use of Memory for Linker-Created Code Stubs

V8.3

The Integrity servers linker generates code stubs, which are visible when stepping

through the code with the OpenVMS Debugger. Code can be inserted for calls and

can have different sizes. However, the earlier linker added the code as ﬁxed-size

code sections using the maximum necessary code size.

The Version 8.3 linker writes the code stubs using the actual size. This eliminates

unused space between the stubs and might also release unused memory.

5.30.21 Compiler Support for Demangled Symbol Names

V8.3

To make symbol names unique, name mangling is used for some programming

languages. Starting with Version 8.3, the linker tries to display the demangled

names, also known as source code names. These names are used in linker

messages and, on request, in a translation table for mangled global symbols

that appears in the linker map (see HP OpenVMS Version 8.3 New Features and

Documentation Overview). This feature depends on compiler support for name

demangling.

5.31 LTDRIVER: CANCEL SELECTIVE Restriction

Permanent Restriction

In releases prior to OpenVMS Version 6.1, LTDRIVER did not set the "extended

DDT" bit; therefore, the POSIX function CANCEL SELECTIVE did not work with

LTDRIVER. This problem has been corrected, but a restriction remains.

Although this ﬁx allows $QIO reads and writes to be selectively canceled, any

$QIO done to the port driver (that is, with the IO$_TTY_PORT function modiﬁer

— such as a LAT connect $QIO) cannot be canceled with CANCEL SELECTIVE.

5–32 Programming Release Notes

Programming Release Notes

5.32 Mail Utility: Threads Restriction for Callable Mail

V7.1

OpenVMS callable mail routines are not thread-safe. Refer to the Guide to the

POSIX Threads Library for more information about calling non-thread-safe

routines within a threaded application.

Because callable mail context information is maintained on a per-process (rather

than a per-thread) basis, multiple threads performing context-based processing

must be synchronized so that only one mail context of a given type is active at

once. Otherwise, one thread could corrupt another thread’s mail operations.

On OpenVMS Alpha systems, there is an additional restriction when kernel

threads is enabled in a multithreaded environment. In this environment, callable

mail should be used only in the initial thread.

5.33 OpenVMS System Dump Analyzer (SDA)

The following notes pertain to the System Dump Analyzer (SDA).

5.33.1 CLUE Commands Not Ported to OpenVMS Integrity servers

V8.2

The following CLUE commands have not yet been ported to OpenVMS Integrity

servers and will return a message to that effect:

CLUE CALL

CLUE ERRLOG

CLUE FRU

CLUE REGISTER

5.34 PL/I Libraries Not Included in OpenVMS Integrity servers

Version 8.2

V8.2

The PL/I libraries (native and translated) are not included in OpenVMS Integrity

servers as they are in OpenVMS Alpha. The core PL/I images that are not

available in OpenVMS Integrity servers are:

[SYSLIB]DPLI$RTLSHR.EXE

[SYSMSG]PLI$MSG.EXE

[SYSLIB]PLIRTL.IIF

[SYSLIB]PLIRTL_D56_TV.EXE

Applications and shareable images that reference the PL/I library do not work

on OpenVMS Integrity servers. (Typically these are applications and shareable

images that contain code written in PL/I.) This restriction applies to both native

code and translated VAX and Alpha images.

See a related note in Section 2.14.

5.35 POSIX Threads Library

The following sections contain release notes pertaining to the POSIX Threads

Library (formerly named DECthreads).

Programming Release Notes 5–33

Programming Release Notes

5.35 POSIX Threads Library

5.35.1 Support for Process-shared Objects

V8.2

The POSIX Threads Library on OpenVMS Alpha and Integrity servers supports

process-shared mutexes and condition variables.

Note

The process-shared read-write locks for mutexes and condition variables

are supported only on Tru64 systems.

The supported pthread routines on OpenVMS are:

• pthread_condattr_getpshared

• pthread_condattr_setpshared

• pthread_mutexattr_getpshared

• pthread_mutexattr_setpshared

5.35.2 New Return Status for pthread_mutex_lock

V8.2

The POSIX Threads library pthread_mutex_lock when used with process-shared

mutexes now returns a new error status known as EABANDONED. This status

is returned only when the process has terminated while owning the mutex.

5.35.3 Support for New API pthread_mutex_tryforcedlock_np

V8.2

The POSIX Threads library supports a new API called pthread_mutex_

tryforcedlock_np. The pthread_mutex_tryforcedlock_np API takes the ownership

of abandoned process-shared mutexes.

Syntax

pthread_mutex_tryforcedlock_np(mutex);

Argument Data Type Access

mutex opaque pthread_mutex_t read

C Binding

#include <pthread.h>

int

pthread_mutex_tryforcedlock_np (

pthread_mutex_t *mutex);

Argument

mutex

Mutex to be locked.

Description

5–34 Programming Release Notes

Programming Release Notes

5.35 POSIX Threads Library

With process-shared objects, the objects such as mutexes and condition variables

can be shared among multiple processes. If a process terminates while owning a

mutex, the mutex will stay as owned by the terminated process. Hence none of

the other threads or processes can own that mutex.

However, there is an optional system service

sys$pshared_register

. Usage of

this system service makes the terminating process mark the mutexes that are

owned by it as abandoned.

In such a scenario, the call to pthread_mutex_lock would return EABANDONED

and the application could call pthread_mutex_tryforcedlock_np to get the

ownership of the abandoned mutex.

Return Values

If an error condition occurs, this routine returns an integer value indicating the

type of error. The possible return values can be:

Return Value Description

0 Successful completion

[EPERM] The mutex is no longer abandoned, and is now owned by some other

thread

[EINVAL] The mutex is not a process-shared mutex

[ENOSYS] Illegal system service called

5.35.4 Stack Overﬂows During Exception Handling (Integrity servers Only)

V8.2

Exception handling on Integrity servers requires considerably more stack space

than it does on Alpha. When porting an application from OpenVMS Alpha, if a

thread that uses exception handling does not have a generous amount of unused

stack space, the thread might experience a stack overﬂow during exception

handling on Integrity servers. Usually this appears as an improperly handled

ACCVIO that is associated with one of the following operations:

• RAISE

• pthread_cancel

• pthread_exit

• A thread has an active TRY or pthread_cleanup_push block, and an

OpenVMS condition is signaled (for example, as a hardware exception or

using LIB$SIGNAL or LIB$STOP).

If you see such a problem, try increasing the size of the stack allocated for the

thread by a small number of pages. HP recommends initially increasing the stack

by 24 KB.

The default stack size has been increased by 24KB to try to address the increased

stack usage on Integrity servers. If your application creates a large number

of threads (using the default size), the application might run out of memory

resources. If this happens, you might have to increase process quotas or make

application changes to reduce the number of threads that exist simultaneously.

Programming Release Notes 5–35

Programming Release Notes

5.35 POSIX Threads Library

5.35.5 THREADCP Command Behavior on Integrity Servers

V8.2

The DCL command THREADCP cannot be used on OpenVMS Integrity servers

to query and change the two threads-related main image header ﬂags, UPCALLS

and MULTIPLE_KERNEL_THREADS. Instead, you must use the DCL commands

SET IMAGE and SHOW IMAGE to set and show threads header ﬂags on

Integrity servers.

Alpha users should continue to use the THREADCP command.

5.35.6 Floating-Point Compilations and Exceptions (Integrity servers Only)

V8.2

Any source modules that call either of the following two old cma threads library

routines must be compiled for use on OpenVMS Integrity servers with the

/FLOAT=G_FLOAT compiler qualiﬁer (or language-speciﬁc equivalent).

cma_delay()

cma_time_get_expiration()

These routines accept only VAX-format ﬂoating-point values as arguments.

Normally, OpenVMS Integrity servers compilers default to using the IEEE

formats for ﬂoating-point values — unlike OpenVMS Alpha compilers, which

default to using VAX formats. These two cma threads routines accept only

ﬂoating-point arguments in VAX format on both Alpha and Integrity servers.

Failure to properly compile any calls to these routines may result in unexpected

exceptions being raised when IEEE format ﬂoating-point values are erroneously

passed at runtime.

5.35.7 C Language Compilation Header File Changes

V7.3-2

The following changes have been made in OpenVMS Version 7.3-2:

• INTS.H

In some prior releases of OpenVMS, the POSIX Threads C language header

ﬁle PTHREAD_EXCEPTION.H inadvertently contained a #include of the

C header ﬁle INTS.H. This has been corrected in OpenVMS Version 7.3-2.

PTHREAD_EXCEPTION.H no longer causes INTS.H to be included in a

compilation. There may be some applications whose compilation requires

the presence of INTS.H and which are erroneously relying on PTHREAD_

EXCEPTION.H to provide it.

Recompiling such application source modules on an OpenVMS Version 7.3-

2 system will result in diagnostic messages from the C compiler. These

messages identify symbols or data types (for example, int32) that originate in

INTS.H and are undeﬁned. To correct such application source modules, add a

direct #include of

<ints.h>

before the ﬁrst use of the corresponding symbols

or types.

•

timespec_t

typedef

In prior releases of OpenVMS, the POSIX Threads C language header ﬁle

PTHREAD.H contained a deﬁnition for a typedef named

timespec_t

. This is

a nonstandard symbol, which does not belong in PTHREAD.H. (This typedef

was present for historic reasons related to the contents of C RTL header ﬁles

such as TIME.H and TIMERS.H.) For OpenVMS Version 7.3-2, the standards

5–36 Programming Release Notes

Programming Release Notes

5.35 POSIX Threads Library

compliance of the C RTL and threads header ﬁles has been improved. As a

result, PTHREAD.H no longer provides the

timespec_t

typedef.

There may be some applications whose compilations require the

timespec_t

typedef, and which erroneously rely on PTHREAD.H to provide it—either

directly or indirectly (for example, by using TIS.H). If such an application

source module is recompiled on an OpenVMS Version 7.3-2 system, you may

get C compiler diagnostic messages listing

timespec_t

as an unknown symbol

or type. To correct such application source modules, either replace the uses

timespec_t

with structure

timespec

, or include the C RTL header ﬁle

TIMERS.H before the ﬁrst use of the

timespec_t

symbol.

If your application build environment uses a private copy of any older C

RTL or threads header ﬁles or an extract of them that includes the

timespec

structure or the

timespec_t

typedef (both of which are not recommended),

you may see an additional compilation error. The compiler may display

messages stating that the

timespec

structure is redeﬁned or deﬁned twice. In

such a case, revert to using the system-supplied C RTL and threads header

ﬁles, or replace the private extracts involving the

timespec

structure with an

inclusion of the system-supplied TIME.H header ﬁle.

5.35.8 New Priority Adjustment Algorithm

V7.3-2

As of OpenVMS Version 7.3-2, the adaptive thread scheduling behavior that is

described in the Guide to the POSIX Threads Library has been implemented with

a new priority adjustment algorithm. In some cases, the new algorithm should

help avoid problems that can arise when throughput-policy threads of different

priorities share synchronization objects. Priority adjustment can also improve

application throughput and overall system utilization. Priority adjustment of

threads with throughput scheduling policy is automatic and transparent.

5.35.9 Process Dumps

V7.3

If the POSIX Threads Library detects an uncorrectable serious problem at

run time (such as data structures that have been damaged by data corruption

somewhere in the application), the library may terminate the running image.

During termination, the library may trigger creation of a process dump ﬁle (which

can subsequently be used to diagnose the failure, by way of ANALYZE/PROCESS_

DUMP). The size of such a process dump ﬁle depends on the size of the process’s

address space at the time of the failure and can be quite large.

5.35.10 Dynamic CPU Conﬁguration Changes

V7.3

Starting in OpenVMS Version 7.3, the POSIX Threads Library is sensitive to

dynamic changes in the number of CPUs that are conﬁgured for a running

multiprocessor Alpha system. When use of multiple kernel threads is enabled

(by way of the LINK/THREADS_ENABLE qualiﬁer or the THREADCP command

verb) for an image, the POSIX Threads Library monitors the apparent parallelism

of an application and creates multiple kernel threads up to the number of CPUs

available. Each kernel thread can be scheduled by the OpenVMS executive to

execute on a separate CPU and, therefore, can execute simultaneously.

Programming Release Notes 5–37

Programming Release Notes

5.35 POSIX Threads Library

While an application is running, an operator can stop or start a CPU. Such a

dynamic change affects the allowable number of kernel threads that future image

activations can create. It also will now affect images that are currently executing.

When a CPU is added or removed, the threads library will query for the new

number of active CPUs, and compare this to the number of kernel threads that

the process is currently using. If there are now more CPUs than kernel threads,

the library will try to spread out the existing POSIX threads over the CPUs

(creating new kernel threads as needed, now or in the future). If there are now

fewer CPUs than kernel threads, the library will force the extra kernel threads

to hibernate, and will reschedule the POSIX threads onto the remaining kernel

threads. This will ensure that — so far as the process is concerned — there will

not be more kernel threads competing for CPU resources than are available.

5.35.11 Debugger Metering Function Does Not Work

V7.0

The metering capability of the POSIX Threads debugger does not work.

If you use the procedure to debug a running program that is described in Section

C.1.1 of the Guide to the POSIX Threads Library, your process could fail with an

ACCVIO message.

5.36 RTL Library (LIB$)

The following notes pertain to the LIB$ run-time library.

5.36.1 RTL Library (LIB$) Help Omission

V8.2

The OpenVMS Version 8.2 help ﬁle for the LIB$ run-time library is missing help

for the LIB$LOCK_IMAGE routine. The help ﬁle will be corrected in a future

release. Meanwhile, refer to the HP OpenVMS RTL Library (LIB$) Manual for a

complete description of this routine.

5.36.2 RTL Library (LIB$): Calling Standard Routines (Integrity servers Only)

V8.2

This release note clariﬁes how rotating registers are handled by the following

calling standard routines:

LIB$I64_GET_FR

LIB$I64_SET_FR

LIB$I64_GET_GR

LIB$I64_SET_GR

LIB$I64_PUT_INVO_REGISTERS

The Calling Standard invocation context block (ICB) and mechanism vector

always record general, ﬂoating-point, and predicate registers as if the register

rename base (CFM.rrb) and rotating size (CFM.sor) were both zero. In other

words, when rotating registers are in use, the effects of the rotation are

ignored. This is also true of the register masks used by the LIB$I64_PUT_

INVO_REGISTERS routine, because these masks are deﬁned in terms of ﬁelds in

the ICB structure.

5–38 Programming Release Notes

Programming Release Notes

5.36 RTL Library (LIB$)

Currently, the supplemental access routines LIB$I64_GET_FR, LIB$I64_SET_

FR, LIB$I64_GET_GR, and LIB$I64_SET_GR improperly interpret their register

number parameters without applying an adjustment for the effects of the register

rename base and rotating size registers. This is an error and will be corrected in

a future release.

In the meantime, any code that examines the general, ﬂoating-point and predicate

registers in an ICB or mechanism vector and that seeks to interpret the register

contents as it would be seen by the code during its execution must examine the

saved CFM register and apply the appropriate adjustments itself.

5.37 Screen Management (SMG$) Documentation

The following information should be added to topics in the reference section at

the end of the OpenVMS RTL Screen Management (SMG$) Manual:

V7.2

• The following statement should be added to the Condition Values Returned

section of routine SMG$DELETE_VIRTUAL_DISPLAY:

"Any condition value returned by the $DELPRC system service."

• The description of routine SMG$GET_TERM_DATA contains an error in the

Arguments section for the capability-data argument. The correction is as

follows:

access: write-only

mechanism: by reference, array reference

• The description of routine SMG$SET_OUT_OF_BAND_ASTS contains an

error in the Arguments section for the AST-argument argument. The

symbolic names in the Data Structure diagram are incorrect. The symbolic

names in the paragraph under this diagram are correct. The correct and

incorrect symbolic names are as follows:

Incorrect Correct

SMG$L_PASTEBOARD_ID SMG$L_PBD_ID

SMG$L_ARG SMG$L_USER_ARG

SMG$B_CHARACTER SMG$B_CHAR

V7.1

• In the documentation for the SMG$READ_COMPOSED_LINE routine, the

following text should be appended to the description of the ﬂags argument:

"The terminal characteristic /LINE_EDITING should be set for your terminal

for these ﬂags to work as expected. /LINE_EDITING is the default."

• The description of routine SMG$SET_KEYPAD_MODE should contain this

note:

Note

Changing the keypad mode changes the physical terminal setting. This

is a global change for all virtual keyboards, not just the virtual keyboard

speciﬁed by the keyboard-id argument.

Programming Release Notes 5–39

Programming Release Notes

5.38 SORT32 Utility

The following release notes pertain to SORT32 V08-010 for OpenVMS Alpha

and OpenVMS Integrity servers Version 8.2. For additional notes, refer to

Section 5.26.8 and Section 5.26.1.

SORT32 is recommended as a workaround for unresolved problems with

Hypersort and for functionality not implemented in Hypersort. Release notes for

Hypersort are in Section 5.26.

5.38.1 CONVERT Problem With DFS-Served Disks

V8.2

SORT, MERGE, and CONVERT operations with output directed to a UNIX-

served, DFS-mounted disk return a %SORT-E-BAD_LRL error.

To work around this restriction, do one of the following:

• Write the output ﬁle to an OpenVMS disk, and then copy the output ﬁle to

the UNIX-served, DFS-mounted disk.

• Use the CONVERT/FDL command, where the FDL speciﬁes the longest

record length (LRL) required for the output ﬁle.

5.38.2 Temporary Work Files Not Always Deleted

V7.3-2

SORT32 does not always delete temporary work ﬁles. It’s a good idea to

periodically check SYS$SCRATCH or wherever you put SORT32 work ﬁles to

see whether any undeleted work ﬁles can be deleted to free up disk space.

5.38.3 SORT/SPECIFICATION With Compound Conditions: Requirement

V7.3-1

SORT32 does not issue a diagnostic message for a compound condition in a key

speciﬁcation ﬁle unless it is enclosed in parentheses. For example:

Incorrect:

/CONDITION=(NAME=TEST1, TEST=(Field2 EQ "X") AND (Field3 EQ "A"))

Correct:

/CONDITION=(NAME=TEST1, TEST=((Field2 EQ "X") AND (Field3 EQ "A")))

5.38.4 Performance Problem with Variable Length Records

V7.3-1

SORT32 allocates ﬁxed-sized slots for sort work ﬁles based on the longest record

length (LRL) information in the input ﬁles. To improve performance, try to

set LRL information in the input ﬁles as close as possible to the actual longest

record length. Poor initial performance might be the result of sorting some ﬁles

produced by C programs, because the LRL is set higher than necessary (up to

32767).

5–40 Programming Release Notes

Programming Release Notes

5.38 SORT32 Utility

5.38.5 Work File Directories Restriction

V7.3

SORT32 work ﬁles must be redirected to directories that allow multiple ﬁle

versions that can handle the number of requested work ﬁles.

5.39 Timer Queue Entries (TQEs)

Permanent Restriction

Management of Timer Queue Entries was redesigned for OpenVMS Alpha Version

7.3-1 to provide signiﬁcantly higher performance for systems using many TQEs.

This change is transparent to nonprivileged applications.

Privileged code can no longer manipulate TQEs directly in any form. In

particular, directly accessing pointers in the TQE’s queue header (TQE$L_

TQFL/TQE$L_TQBL) causes an access violation in almost all cases. Privileged

code may continue to use the internal routines exe_std$instimq/exe$instimq and

exe_std$rmvtimq/exe$rmvtimq to enter or remove Timer Queue Entries.

5.40 Watchpoint Utility (Integrity servers Only)

V8.2

The Watchpoint Utility has not been ported to OpenVMS Integrity servers. HP

intends to port this utility in a future release.

5.41 Whole Program Floating-Point Mode (Integrity servers Only)

V8.3

On OpenVMS Alpha, the ﬂoating-point rounding behavior, exception behavior,

and precision control are deﬁned at compile time; each module is independently

compiled with its own set of ﬂoating-point behaviors. For example, one module

can be compiled with a directive that causes overﬂow calculations to signal an

overﬂow exception, and another module can be compiled with a directive that

causes overﬂow calculations to compute the value InﬁnityT rather than to signal

an exception. When these two modules are combined and run, the code in the

modules performs overﬂow calculations that were speciﬁed at compile time.

On OpenVMS Integrity servers, the ﬂoating-point rounding behavior, exception

behavior, and precision control are deﬁned at run time and are guided by the

concept of whole program ﬂoating-point mode. With whole program ﬂoating-point

mode, the module that contains the program main entry point (as determined

by the Linker) is the module that deﬁnes the default ﬂoating-point rounding

behavior, exception behavior, and precision control.

Most programs are not affected by this difference. Refer to the white paper

‘‘OpenVMS Floating-Point Arithmetic on the Intel® Itanium® Architecture’’ for

essential reading. You can link to this document from the following web site:

http://h71000.www7.hp.com/openvms/integrity/resources.html

Programming Release Notes 5–41

Hardware Release Notes

This chapter contains information about the following hardware products:

• USB Device Support (Section 6.1)

• MP and BMC Console (Section 6.2)

• AlphaServer 2100 (Section 6.3)

• AlphaServer 8200/8400 (Section 6.4)

• AlphaServer ES47/ES80/GS1280 Systems (Section 6.5)

• AlphaServer GS Series (Section 6.6)

• AlphaStation 200/400 (Section 6.7)

• AlphaStation 255 (Section 6.8)

• ATI RADEON 7000 Graphics (Section 6.9)

• ATI RADEON 7500 Graphics (Section 6.10)

• DECwindows X11 Display Server (Section 6.11)

• DIGITAL Modular Computing Components (Section 6.12)

• Digital Personal Workstation (Section 6.13)

• Dual-Controller HSGnn device (Section 6.14)

• Open3D Graphics (Section 6.15)

• PowerStorm 300/350 PCI Graphics Controller (Section 6.16)

•RFnn DSSI disk devices (Section 6.17)

•RZnn disk devices (Section 6.18)

• sx1000 Integrity Superdome (Section 6.19)

• ZLX graphics boards (Section 6.20)

A few notes about using device drivers are also included at the end of this

appendix.

6.1 USB Device Support

V8.4

OpenVMS tests and supports speciﬁc HP provided USB devices on HP Integrity

servers.

In some cases, speciﬁc third-party devices are tested and supported by OpenVMS.

For these devices, OpenVMS engineering will respond to bug reports and ﬁx

defects in driver support for them. These devices are listed in appendices of the

HP OpenVMS Systems Management Utilities Reference Manual.

Hardware Release Notes 6–1

Hardware Release Notes

6.1 USB Device Support

The nature of USB is such that in many cases broad categories of devices can

be supported by a single generic device driver. OpenVMS does not attempt

to prevent such unknown third-party devices from conﬁguring and operating.

However, we cannot guarantee correct operation of such untested devices. If a

problem occurs with such a device, it can be reported through support channels

but there is no guarantee that we will be able to correct the problem or provide

an ECO patch for it.

Should you require formal support for a third-party device a request for support

can be made through your HP account team or HP distributor.

6.2 MP and BMC Console Restrictions (Integrity servers Only)

The following notes pertain to the MP and BMC consoles.

6.2.1 Input, Output, and Error Device Restriction

V8.2

Currently, the OpenVMS operating system requires that the input, output, and

error devices for each MP or BMC console point to a single serial-line console. If

your system has an MP console, that is preferable.

If you do not boot from the designated console, a warning is sent to the VMS_

LOADER, and you might see other errors during the boot. You might also lose

output that you would normally expect to see when booting.

6.2.2 Remapping Ctrl/H to the Delete Key

V8.2

Unlike the OpenVMS operating system, which uses the character 0X7F for

DEL/RUBOUT, the MP and BMC consoles and the EFI console environment use

Ctrl/H. If you press the delete key on a VTxxx terminal, or if you press a key you

have mapped to send 0X7F in your terminal emulator, no character is deleted.

Note: The driver does not perform remapping under the following conditions:

• Terminal is in IO$_READALL state.

• Terminal is in IO$_READPBLK state.

• Terminal attribute is set to PASSALL.

• Terminal attribute is set to PASTHRU.

• Pressing Ctrl/V tells the driver to pass the next character and skip the remap

check.

6.3 AlphaServer 2100

The following sections contain information speciﬁc to the AlphaServer 2100 series

computer.

6–2 Hardware Release Notes

Hardware Release Notes

6.3 AlphaServer 2100

6.3.1 Console Display

V7.2

On AlphaServer 2100 and 2100A systems, a console display similar to the

following is normal and does not represent system errors:

P00>>>SET CONSOLE SERIAL

P00>>>INIT

VMS PALcode X5.48-112, OSF PALcode X1.35-81

starting console on CPU 0

initialized idle PCB

initializing semaphores

initializing heap

initial heap 1c0c0

memory low limit = 132000

heap = 1c0c0, 13fc0

probing hose 0, PCI

probing PCI-to-EISA bridge, bus 1

probing PCI-to-PCI bridge, bus 2

*** unable to assign PCI base address

*** bus 2, slot 7, function 0, size 00001000 (16 bit I/O)

bus 1, slot 1 -- fra -- DEFEA

bus 1, slot 2 -- vga -- Compaq Qvision

bus 1, slot 3 -- pua -- KFESA

bus 2, slot 1 -- pka -- NCR 53C810

bus 2, slot 6 -- pkb -- NCR 53C810

bus 2, slot 7 -- pkc -- DEC KZPSA

bus 0, slot 7 -- ewa -- DECchip 21041-AA

initializing keyboard

Memory Testing and Configuration Status

Module Size Base Addr Intlv Mode Intlv Unit Status

------ ----- --------- ---------- ---------- ------

0 64MB 00000000 1-Way 0 Passed

Total Bad Pages 0

Testing the System

Testing the Disks (read only)

Testing the Network

econfig: 20041 99

econfig: 20042 04

econfig: 20043 00

AlphaServer 2100A Console V4.3-130, built on Oct 26 1996 at 19:44:57

P00>>>P

Note that in the previous display, the KZPSA adapter is successfully installed

despite the error message displayed in the following lines:

*** unable to assign PCI base address

*** bus 2, slot 7, function 0, size 00001000 (16 bit I/O)

6.3.2 SCSI Controller Restriction

V6.2

The Adaptec 1740/1742 SCSI controller (PB2HA–SA) is not supported on

AlphaServer 2100 systems having more than 1 gigabyte (GB) of memory. If

the controller is connected to such a system, the following message appears on

the operator’s console:

%PKJDRVR-E- The direct DMA window does not map all of memory. Port is going OFFLINE.

Hardware Release Notes 6–3

Hardware Release Notes

6.4 AlphaServer 8200/8400: FRU Table Error

V7.2

The error log buffer size is controlled by the system parameter

ERLBUFFERPAGES, which has a maximum value of 32 pagelets. If the

Field Replaceable Unit (FRU) table exceeds this limit during a boot of the

OpenVMS Alpha operating system on an AlphaServer 8200/8400 or 4100 system,

an entry will not be written to the error log ﬁle.

6.5 AlphaServer ES47/ES80/GS1280 Systems

This section contains release notes of interest to users of AlphaServer

ES47/ES80/GS1280 systems. The note in Section 6.6.2 also applies to these

systems.

6.5.1 INIT Console Command Usage on ES47/ES80/GS1280 Soft Partitions

V8.2

Usage of the INIT console command on ES47/ES80/GS1280 soft partitions is not

supported when other instances within the hard partition are booted and running

OpenVMS. Issuing an INIT command might result in system crashes of the other

instances running OpenVMS. Shut down the other instances prior to performing

an INIT command.

While a console INIT is in progress, do not issue boot commands to other

instances within the same hard partition; wait until the INIT has completed.

6.5.2 RAD Support

V7.3-2

OpenVMS support for resource afﬁnity domains (RADs), also known as NUMA

support or awareness, has not been qualiﬁed in OpenVMS Alpha Version 7.3-2 for

the AlphaServer ES47/ES80/GS1280 systems. For more information about RAD

support, see the HP OpenVMS Alpha Partitioning and Galaxy Guide.

6.5.3 License Requirements

V7.3-2

AlphaServer ES47/ES80/GS1280 systems require a minimum of two OpenVMS

software licenses: one license for base support and one license for dual SMP

support for the ﬁrst two processors. This is a change from the previous way

of licensing OpenVMS AlphaServer SMP systems. The dual SMP licenses for

OpenVMS are included with the CPU modules when you purchase an OpenVMS

system or when you purchase additional CPU modules for an OpenVMS system.

6.5.4 STOP/CPU and Shutdown Behavior

V7.3-2

Because of hardware restrictions, any CPU on an AlphaServer

ES47/ES80/GS1280 system with an attached I/O drawer cannot be stopped

by using the DCL command STOP/CPU. In contrast, CPUs on these systems

without an attached I/O drawer can be stopped with this command.

6–4 Hardware Release Notes

Hardware Release Notes

6.5 AlphaServer ES47/ES80/GS1280 Systems

When the shutdown procedure is invoked on an ES47/ES80/GS1280 system

with an attached I/O drawer, an error message such as the following might be

displayed:

%SYSTEM-W-WRONGSTATE, CPU 5 is in the wrong state for the requested operation

You can ignore such messages. The shutdown will complete correctly.

6.5.5 Setting Time at MBM

V7.3-2

You must set the correct time and date on the MBM of an AlphaServer

ES47/ES80/GS1280 system. If you do not, OpenVMS might display an incorrect

time and date.

6.6 AlphaServer GS Series Systems

This section contains release notes of general interest to most users of the

AlphaServer GS Series systems.

6.6.1 AlphaServer GS80/160/320 Systems: Device Restriction

Permanent Restriction

Only one set of the following devices found on the legacy bus adapter is conﬁgured

and supported per partition in OpenVMS Alpha Version 7.3 or higher. These

devices include:

• Serial ports COM1 and COM2

• Parallel port

• Keyboard

• Mouse

If multiple legacy bus adapters exist, only the adapter that includes the console

port is conﬁgured and supported.

6.6.2 OpenVMS Galaxy License Enforcement

V7.3

In an OpenVMS Galaxy computing environment, the OPENVMS-GALAXY license

units are checked during system startup and whenever a CPU reassignment

between instances occurs.

If you attempt to start a CPU and there are insufﬁcient OPENVMS-GALAXY

license units to support it, the CPU will remain in the instance’s conﬁgured set

but it will be stopped. You can subsequently load the appropriate license units

and start the stopped CPU while the system is running. This is true of one or

more CPUs.

6.6.3 Installing Licenses

V7.3-1

Before you upgrade to Version 7.3-1 or higher, you should perform the following

steps to ensure that the common license database can share license units among

hard and soft partitions:

1. Calculate required units.

• Load the base OpenVMS license.

Hardware Release Notes 6–5

Hardware Release Notes

6.6 AlphaServer GS Series Systems

• Load the SMP licenses.

• Use the following command to verify that you have the correct number of

license units:

$ SHOW LICENSE /UNIT_REQUIREMENTS /CLUSTER

Note

The base OpenVMS license allows you to have only one interactive user

will require additional license units. See your HP support representative

to determine your needs.

2. Add your licenses to the common license database. For example:

$ LICENSE REGISTER license-name /ISSUER=DEC -

_$ /AUTHORIZATION=USA123456 -

_$ /PRODUCER=DEC -

_$ /UNITS=1050 -

_$ /AVAILABLITY=H -

_$ /OPTIONS=(NO_SHARE) -

_$ /CHECKSUM=2-BGON-IAMA-GNOL-AIKO

Note that you cannot use the /INCLUDE qualiﬁer with the LICENSE

3. Modify the license to override the NO_SHARE attribute of the PAKs with the

command LICENSE REGISTER /INCLUDE=(node-name-list). For example:

$ LICENSE MODIFY OPENVMS-ALPHA /INCLUDE=(NODEA, NODEB, NODEC)

4. To make OpenVMS Alpha license units available to the instance of OpenVMS

running in each partition, you must ensure that SRM environment variable

SYS_SERIAL_NUM is the same in each partition. To do so, perform the

following steps:

a. From the master console of each partition (usually on console line 0), use

the SHOW SYS_SERIAL_NUM command to display the system serial

number. For example:

P00>>>

P00>>>SHOW SYS_SERIAL_NUM

sys_serial_num G2A105

If the value of SYS_SERIAL_NUM is blank, use the SHOW SYS_

SERIAL_NUM command from the master console in each of the other

partitions to check for a nonblank system serial number.

Note

If all partition consoles show a blank value for SYS_SERIAL_NUM,

you must create a nonzero value of up to 12 characters. Ensure that

the system serial number that you create is not used on any other

AlphaServer GS80/160/320 on this OpenVMS Cluster.

6–6 Hardware Release Notes

Hardware Release Notes

6.6 AlphaServer GS Series Systems

b. Once you have determined the system serial number, use the SET SYS_

SERIAL_NUM command from the master console of each partition to

change SYS_SERIAL_NUM to the correct value. For example:

P00>>>

P00>>>SET SYS_SERIAL_NUM G2A105

You must do this in every hard partition and in every soft partition.

5. In order for the OpenVMS Cluster license database to be updated correctly,

HP recommends that you completely shut down and reboot all OpenVMS

Cluster common nodes. A rolling upgrade type of boot does not correctly

update the common license database.

Note

If your system is part of an OpenVMS Cluster that shares a common

license database, anytime you reconﬁgure the number of hard or soft

partitions on your AlphaServer GS80/160/320, you must make sure that

all partitions have the same SYS_SERIAL_NUM.

For partitionable machines that are sharing NO_SHARE licenses across

partitions, it is possible to see the following error text on system bootup.

%LICENSE-E-NOAUTH, DEC OPENVMS-ALPHA use is not authorized on this node

-LICENSE-F-EXCEEDED, attempted usage exceeds active license limits

-LICENSE-I-SYSMGR, please see your system manager

Startup processing continuing...

This error text can be safely ignored. The text is displayed when someone has

logged into a system that is sharing the OPENVMS-ALPHA PAK and they are

then in use. This will be ﬁxed in a future release.

6.6.4 AlphaServer GS60/GS60E/GS140 Multiple I/O Port Module Conﬁguration

Restriction

V7.2-1

AlphaServer GS60/GS60E/GS140 conﬁgurations with more than a single I/O Port

Module, KFTHA-AA or KFTIA-AA, might experience system failures.

When upgrading OpenVMS Galaxy and non-Galaxy AlphaServer 8200/8400

conﬁgurations with multiple I/O Port Modules to GS60/GS60E/GS140 systems,

customers must install one minimum revision B02 KN7CG-AB EV6 CPU (E2063-

DA/DB rev D01) module as described in Compaq Action Blitz # TD 2632.

For complete details about this restriction and its solution, refer to Compaq

Action Blitz # TD 2632.

6.7 AlphaStation 200/400: ISA_CONFIG.DAT Changes Required

V7.1

Customers conﬁguring ISA devices on AlphaStation 200/400 Family systems

must change their SYS$MANAGER:ISA_CONFIG.DAT ﬁle, so that the node

information for each device appears at the end of each device description block.

Hardware Release Notes 6–7

Hardware Release Notes

6.7 AlphaStation 200/400: ISA_CONFIG.DAT Changes Required

Warning

For upgrades from OpenVMS Version 6.2 or 7.0 systems, this change

must be made before starting the upgrade procedure.

Table 6–1 shows the changes to the device description block.

Table 6–1 Changes to Device Description Block

Before Version 7.1 After Version 7.1

[AUA0] [AUA0]

NAME=AU NAME=AU

NODE=3 DRIVE=SYS$MSBDRIVER

DRIVER=SYS$MSBDRIVER IRQ=9

IRQ=9 DMA=(0,1)

DMA=(0,1) PORT=(388:4,530:8)

PORT=(388:4.530:8) NODE=3

6.8 AlphaStation 255: PCI Conﬁguration Restriction

V7.1

The OpenVMS Alpha operating system does not support PCI option cards

conﬁgured in PCI slot 0 on any AlphaStation 255 series systems.

PCI slot 0 is the lowest physical PCI option slot on AlphaStation 255 series

systems. The interrupt signal for this slot is shared with the built-in Ethernet

port. Because the OpenVMS Alpha operating system does not currently permit

PCI devices to share an interrupt line, a PCI device installed in slot 0 will not

function correctly or may cause errors to occur with the built-in Ethernet port. As

a result of this restriction, AlphaStation 255 series systems support a maximum

of two PCI option cards, conﬁgured in slot 1 and slot 2.

6.9 ATI RADEON 7000 Graphics (Integrity servers Only)

V8.2

The following release notes pertain to using the embedded ATI RADEON 7000

graphics adapter on OpenVMS Integrity servers.

Note: The resource requirements described in Section 6.10.1 also apply to the

embedded ATI RADEON 7000 graphics adapter.

6.9.1 Integrity servers Graphics Support

V8.2

The Graphics option supported on OpenVMS Integrity servers are:

• ATI Radeon 7500 PCI

• ATI Radeon 7000 PCI (Embedded and Pluggable)

• ATI RN50 PCI

6–8 Hardware Release Notes

Hardware Release Notes

6.9 ATI RADEON 7000 Graphics (Integrity servers Only)

6.9.2 Hardware Accelerated 3D Graphics Not Supported on RADEON 7000

V8.2

Hardware accelerated 3D (OpenGL) rendering is not supported on the embedded

Radeon 7000 PCI adapter.

6.10 ATI RADEON 7500 Graphics

V7.3-2

The following notes describe resource requirements, enhancements, ﬁxes, and a

few restrictions for ATI RADEON 7500 graphics. If you want to consult the HP

DECwindows Motif for OpenVMS documentation set, in particular Managing

DECwindows Motif for OpenVMS Systems, you can link to this document and

others from the following website:

http://www.hp.com/go/openvms/doc

Note that starting with OpenVMS Version 8.2, the license to use 3D support is

included as part of the OpenVMS license. For details, refer to Section 6.15.

6.10.1 Resource Requirements

Support for RADEON graphics requires the following system-wide resources:

• 2 global sections

• 296 KB of global memory

In addition, each RADEON card requires the following:

• 3 global sections

• 16 MB plus 1 page of global memory

• 16 MB plus 1 page of buffer object space (32-bit System Space Windows)

The global sections are charged against the GBLSECTIONS system resource, and

the 16+ megabytes of global memory are charged against the GBLPAGES and

GBLPAGFIL resources.

For example, a single RADEON card requires the following:

• 5 global sections

• 16MB+8KB+296KBglobal memory

These numbers equate to the following values:

GBLSECTIONS 5

GBLPAGES 33376 (GBLPAGES is in units of 512-byte pagelets.)

GBLPAGFIL 2086 (GBLPAGFIL is in units of 8192-byte Alpha pages.)

A 4-card conﬁguration requires the following:

• 14 global sections

• 296 KB + 4*16 MB + 4*8 KB = 64 MB + 328 KB global memory

These numbers equate to the following values:

GBLSECTIONS 14

GBLPAGES 131728 (GBLPAGES is in units of 512-byte pagelets.)

Hardware Release Notes 6–9

Hardware Release Notes

6.10 ATI RADEON 7500 Graphics

GBLPAGFIL 8233 (GBLPAGFIL is in units of 8192-byte Alpha pages.)

6.10.2 DECW$OPENGLSHR_RADEON.EXE Renamed to

DECW$MESA3DSHR_RADEON.EXE

V8.2

The shareable library SYS$LIBRARY:DECW$OPENGLSHR_RADEON.EXE has

been renamed to SYS$LIBRARY:DECW$MESA3DSHR_RADEON.EXE to reﬂect

that this library was built from the Mesa 3D code base. The API and functionality

remain the same as in previous releases. The logical name DECW$OPENGLSHR

is deﬁned to point to the shareable library using the new ﬁle speciﬁcation.

6.10.3 Support Limitations

V7.3-2

The following functionality is not supported:

• S-Video output

• Digital output

• Dual-head operation

If you connect monitors to both the DVI port and the analog VGA (CRT) port,

you will get identical video output on both screens. This is called cloned

video. True dual-head operation, with independent video displays on each

port, will be supported in a future release.

6.10.4 Video Artifacts at High Refresh Rates

V8.2

At high resolutions (for example, 1920x1440 and 2048x1536) and high refresh

rates, and under heavy load conditions, video artifacts might occur on some

individual RADEON cards or monitors. If you see such artifacts, try using a

lower refresh rate.

6.10.5 OpenGL Supports IEEE Arithmetic Only

V8.2

The OpenGL library supports only IEEE ﬂoating point format; VAX ﬂoating point

is not supported. Use the /FLOAT=IEEE_FLOAT option to compile applications.

6.10.6 DECwindows Server Hangs When Output Is Written to the Graphics

Console (OPA0)

V8.2

If output is written to the graphics console (OPA0) after DECwindows has started,

the DECwindows server hangs and the screen freezes. Pressing CTRL/F2 allows

the DECwindows server to run again.

Instead of writing messages directly to OPA0, HP recommends using OPCOM

and the Console Window application to display messages that normally would be

written to the console. To enable this application, edit the command procedure

SYS$MANAGER:DECW$PRIVATE_APPS_SETUP.COM and add the following

global symbol deﬁnition:

$ DECW$CONSOLE_SELECTION == "WINDOW"

6–10 Hardware Release Notes

Hardware Release Notes

6.10 ATI RADEON 7500 Graphics

If you do not have SYS$MANAGER:DECW$PRIVATE_APPS_SETUP.COM, you

can create this command procedure from SYS$MANAGER:DECW$PRIVATE_

APPS_SETUP.TEMPLATE.

After editing SYS$MANAGER:DECW$PRIVATE_APPS_SETUP.COM, restart

DECwindows with the following command:

$ @SYS$MANAGER:DECW$STARTUP RESTART

6.10.7 Monitor Must Be Connected During Initialization

The RADEON 7500 graphics card has two video output ports: one for digital and

one for analog. The digital interface is not currently supported. However, using a

digital-to-analog adapter, you can plug an analog monitor into the digital port and

get the identical output that you get using the analog port. If you use the digital

port, the monitor must be attached before the system is powered up in order for

the port to function correctly.

6.10.8 Boot Reset Recommendation (Alpha Only)

HP recommends that the console variable

boot_reset

be set to ON.

6.10.9 No Overlay Planes

Hardware overlay planes are not supported.

6.10.10 Single Colormap

The RADEON 7500 graphics controller supports only one hardware colormap.

Keep this in mind if you change to the 8-bit color depth, where the default visual

is PseudoColor. Attempting to use more than one PseudoColor colormap at a time

causes colormap ﬂashing.

Note

3D (OpenGL) rendering is not supported on 8-bit PseudoColor visuals.

(See also Section 6.10.16.)

Applications should not install or deinstall colormaps themselves. The

window manager should perform these actions. However, the application

is responsible for providing the window manager with hints about which

colormaps to install or deinstall. You provide this information using the Xlib

function XsetWMColormapWindows( ). This function sets the WM_COLORMAP_

WINDOWS property for a given window.

6.10.11 Single Bit Depth for All Windows

When you are using the RADEON 7500 card, all windows created on a particular

head must have the same bit depth. The RADEON 7500 card supports bit depths

of 8, 16, and 24 bits per pixel on any graphics head, but once the DECwindows

server establishes a bit depth on a particular head, only windows or visuals with

that bit depth can be created.

Hardware Release Notes 6–11

Hardware Release Notes

6.10 ATI RADEON 7500 Graphics

6.10.12 Pixel Depth for Read/Write Color Map

By default, the RADEON 7500 provides a pixel depth of 24 planes with a read-

only, TrueColor color map. Some applications, such as DECwindows Paint,

require a read/write color map. If Paint is run with a read-only color map, it fails

with the following error message:

Error: Visual Not Supported

Supported Visuals are {PseudoColor, GrayScale, StaticGray}

To use a read/write color map, edit the ﬁle SYS$MANAGER:DECW$PRIVATE_

SERVER_SETUP.COM (or, if this ﬁle does not exist, create it from

SYS$MANAGER:DECW$PRIVATE_SERVER_SETUP.TEMPLATE) and add

the following logical name deﬁnition to the ﬁle:

$ DEFINE/EXECUTIVE/SYSTEM/NOLOG DECW$SERVER_PIXEL_DEPTH 8,8,8,8,8,8,8,8

Then restart DECwindows using the following command:

$ @SYS$MANAGER:DECW$STARTUP RESTART

This change sets the pixel depth to 8 planes (on up to 8 graphics cards, which

allows for a multiple-card conﬁguration) and allows the server to provide a

PseudoColor visual.

6.10.13 Backing Store/Save Unders Not Supported for 3D Windows

The implementation of backing store and save unders in the RADEON 7500 X11

server does not support 3D windows.

6.10.14 Threads Restriction

The RADEON 7500 OpenGL library for OpenVMS is not thread safe. However,

OpenGL can be used in a multithreaded program if the use of OpenGL is

restricted to a single thread within the program.

6.10.15 No Support for Single Buffered Visuals

The RADEON 7500 DECwindows server exports only double buffered visuals.

For single buffering, users must select a double buffered visual and call

glDrawBuffer( GL_FRONT )

in their application.

6.10.16 No 3D Support for Color Index Mode

Even though 8-bit visuals are supported for 2D operations when the DECwindows

server is started with bit depth = 8, OpenGL rendering is not supported on 8-bit

visuals.

6.10.17 Timer Mechanism

Under certain circumstances, it is possible for a process to be interrupted while it

owns the hardware lock, resulting in an apparent DECwindows server hang.

A timer mechanism has been implemented to detect this situation and to rectify

it by forcing an image exit in the suspended process — or, in some instances, by

deleting the process.

The timer mechanism can be conﬁgured using the following two logicals, which

should be speciﬁed in the DECW$PRIVATE_SERVER_SETUP.COM ﬁle:

• DECW$DRM_TIMER_PERIOD (Default: 5.0 seconds)

Speciﬁes the duration of the clock tick in seconds; a ﬂoating-point value.

• DECW$DRM_TIMEOUT (Default: 6)

6–12 Hardware Release Notes

Hardware Release Notes

6.10 ATI RADEON 7500 Graphics

Speciﬁes the number of clock ticks that are allowed to elapse before a timeout

occurs and the DECwindows server seizes control of the RADEON card.

The default values are chosen to minimize the impact of the timer on the

performance of graphics applications. If you want to reduce the length of time

before the DECwindows server begins responding again, you can do so by

decreasing the value of DECW$DRM_TIMER_PERIOD.

A process can be interrupted while holding the hardware lock under either of the

following conditions:

• The process is remotely logged in with its terminal displayed on a different

system.

• The process is a subprocess that has been suspended or terminated by

another process in such a way that normal exit handling does not occur.

If neither of these conditions is likely to occur in your conﬁguration, you can

disable the timer mechanism entirely by setting the timer period to zero:

$ DEFINE/SYSTEM DECW$DRM_TIMER_PERIOD 0

Whenever you change the value of DECW$DRM_TIMER_PERIOD, you must

either restart the DECwindows server or reboot the system for the changes to

take effect. To restart the DECwindows server, use the following command:

$ @SYS$STARTUP:DECW$STARTUP RESTART

6.11 DECwindows X11 Display Server (Alpha Only)

This section contains release notes pertaining to the DECwindows X11 display

server for OpenVMS Alpha systems.

6.11.1 S3 Multihead Graphics

Permanent Restriction

Alpha computers equipped with S3 Trio32 or Trio64 graphics cards support

single-screen display only. Multihead graphics are not supported.

6.12 DIGITAL Modular Computing Components (DMCC)

This section contains release notes pertaining to DMCC.

6.12.1 Alpha 5/366 and 5/433 PICMG SBC Restriction

Permanent Restriction

The KZPDA SCSI Controller and the PBXGA Graphics Card cannot be placed

in a slot behind the bridge on the DIGITAL Modular Computing Components

(DMCC) Alpha 5/366 and 5/433 PICMG SBCs.

6.12.2 Updating the SRM Console

Permanent Restriction

To update the SRM console on the Alpha 4/233 (21064a), 4/266 (21164a), 5/366,

and 5/433 DMCC systems, you must choose either the SRM console or the

AlphaBIOS setup. You can store only one console.

• If you are running OpenVMS on these systems, update only the SRM console.

Hardware Release Notes 6–13

Hardware Release Notes

6.12 DIGITAL Modular Computing Components (DMCC)

• If you are running Windows NT on these systems, update only the AlphaBIOS

setup.

If you accidentally update both the SRM and the AlphaBIOS consoles, you will

enter the AlphaBIOS Setup menu, and you will not have the option to return to

the SRM console. The only way to exit the AlphaBIOS Setup menu and return

to the SRM console is to use a Firmware Update Utility located at the following

Internet site:

ftp://ftp.digital.com/pub/Digital/Alpha/firmware/index.html

6.13 Digital Personal Workstation: Booting OpenVMS V7.3-1 and

Higher

V7.3-1

If you are using the Digital Personal Workstation 433au, 500au, and 600au series

systems, you can boot OpenVMS Version 7.3-1 or higher from an IDE CD if the

controller chip is a Cypress PCI Peripheral Controller. You cannot boot OpenVMS

on a Digital Personal Workstation au series system from an IDE CD with an Intel

Saturn I/O (SIO) 82378 chip in your conﬁguration. You must use a SCSI CD, if

the Intel SIO chip is present.

To determine which IDE chip you have in your conﬁguration, enter the following

SRM console command:

SHOW CONFIGURATION

If you see Cypress PCI Peripheral Controller, you can boot OpenVMS.

If you see Intel SIO 82378, you will need to use and boot from a SCSI CD.

6.14 Dual-Controller HSGnn with Many LUNs Can Fail Under Heavy

I/O Load

V7.3-2

A combination of improvements in driver performance and faster systems has

uncovered a limit to the amount of I/O that a dual-controller HSGnn storage

array conﬁgured with a relatively large number of LUNs can handle. When this

limit is reached, it is possible for the array to be kept so busy processing I/O that

it is unable to complete the normal periodic synchronization between controllers,

causing a controller hang or failure and a loss of host access to some or all LUNs

until a manual controller reset is performed. In the case of such a controller

failure, the Last Failure Codes most likely to be reported on the HSG console are

01960186, 01942088, and 018600A0.

Most HSGnn devices will continue to run with no problems. If your site

experiences an HSG controller hang or failure when a heavy load is applied and

the HSG has more than approximately 24 LUNs conﬁgured, you may be able to

avoid future hangs or failures by reconﬁguring the controller with fewer LUNs or

distributing I/O so that the HSG is not so heavily loaded.

This issue is being investigated by the appropriate HP engineering groups.

6–14 Hardware Release Notes

Hardware Release Notes

6.15 Open3D Graphics Licensing Change

V8.2

The 3D graphics display capability has traditionally been licensed separately

from the OpenVMS operating system. Since its initial offering, the Open3D

layered product has required a separately orderable license. When Open3D

software began shipping as part of the OpenVMS operating system, the 3D

graphics display feature continued to be a separately licensed capability. An

example of this licensing is Open3D licensing to support 3D graphics display with

the 3X-PBXGG-AA ATI RADEON 7500 PCI 2D/3D graphics adapter.

Starting with OpenVMS Version 8.2, the 3D graphics display feature is licensed

with the operating system for both AlphaServers and Integrity servers. Therefore,

the Open3D license is not available for Version 8.2 of OpenVMS. Previous

versions of OpenVMS still require the Open3D license to be installed on the

system for 3D display operation.

HP will continue to support 3D device drivers shipped with OpenVMS Version

7.3-2 under standard contract or Mature Product Support, depending on your

support agreement. Device drivers for the following adapters have shipped with

Version 7.3-2 of OpenVMS:

• PowerStorm 300 and 350 PCI graphics adapters (SN-PBXGD)

• ATI RADEON 7500 PCI and AGP graphics adapters (3X-PBXGG)

These adapters will continue to run 3D graphics display under OpenVMS Version

8.2 but will no longer require a license. In addition, the following 2D graphics

adapters continue to be supported with OpenVMS Version 8.2:

• ELSA Gloria Synergy (SN-PBXGK)

• 3Dlabs Oxygen VX1 (SN-PBXGF)

The ATI RADEON 7500 PCI graphics adapter will be supported on OpenVMS

Integrity servers Version 8.2 in the near future. Testing is currently in progress.

An announcement will be posted on the following website when support for this

graphics card is available:

http://h71000.www7.hp.com/new/

6.16 PowerStorm 300/350 PCI Graphics Support for OpenVMS

V8.2

For release notes on the PowerStorm 300/350 PCI graphics controller support

for a Compaq Workstation running OpenVMS Alpha, refer to the PowerStorm

300/350 OpenVMS Graphics Release Notes Version 2.0. These documents, release

notes, and installation guides are shipped with the graphics cards.

Open3D License No Longer Checked

Starting with OpenVMS Version 8.2, the license to use 3D (OpenGL) support is

included as part of the OpenVMS license. See Section 6.15 for details.

Hardware Release Notes 6–15

Hardware Release Notes

6.16 PowerStorm 300/350 PCI Graphics Support for OpenVMS

Deﬁning the DECW$OPENGL_PROTOCOL Logical

When you run a 3D graphics application and display output to a system with a

PowerStorm 350/300 graphics card, you must make sure the DECW$OPENGL_

PROTOCOL logical is deﬁned as follows on the system on which you are running

the application:

$ DEFINE DECW$OPENGL_PROTOCOL DECW$OPENGL_PROTOCOL_V11

Problem Fixed

Previously, the P350 would sometimes fail to reinitialize properly on session exit.

This problem has been ﬁxed by two modiﬁcations:

• A call to vmsCloseScreen has been added to the device-speciﬁc riCloseScreen

function (which is called, for example, at CDE session exit), causing the

channel to the GB device to be deassigned and allowing the driver to

reinitialize the board properly.

• The pixel converter resynchronization algorithm in the device driver has been

greatly improved.

6.17 RFnn DSSI Disk Devices and Controller Memory Errors

V6.2

A problem exists with the microcode for earlier versions of RF31T, RF31T+, RF35,

RF35+, RF73, and RF74 DSSI disk devices. The problem can cause data loss,

and occurs when reading data from one of these devices, if the device has had a

controller memory error (also known as an error detection and correction (EDC)

error). The error could have been induced by a virtual circuit closure or faulty

hardware.

HP advises customers with any of these devices to check their microcode revision

levels. If the microcode revision levels are lower than the numbers shown in

Table 6–2, HP recommends that you update the microcode.

The microcode for all models, except RF31T, RF31T+, and RF35+, is provided on

the latest OpenVMS binary distribution CD.

The RF_VERS utility, a utility program that displays the microcode revision level

of the DSSI disk devices, is also provided on the CD. Instructions both for using

the utility program and for updating the microcode are provided in this section.

Note

If you have an RF31T, RF31T+, or RF35+ disk drive with a version of

microcode that is not supported (see Table 6–2), and if you have a support

contract, contact your HP support representative. Otherwise, contact your

authorized reseller.

The earliest supportable revision levels of the DSSI disk microcode are shown in

Table 6–2.

6–16 Hardware Release Notes

Hardware Release Notes

6.17 RFnn DSSI Disk Devices and Controller Memory Errors

Table 6–2 Supported Microcode Revision Levels

Device Type Minimum Level with Supported Microcode

RF31T T387E

RF31T+ T387E

RF35 T392D

RF35+ T392D

RF36 V427P

RF73 T392D

RF74 V427P

To display the microcode revision level of your DSSI disk devices, perform the

following steps:

1. Log in to the SYSTEM account or another account that has the CMKRNL,

DIAGNOSE, and SYSPRV privileges.

2. Enter the following commands:

$ SET PROCESS /PRIVILEGE=(DIAGNOSE,CMKRNL,SYSPRV)

$ SHOW DEVICE FYA0:

On VAX systems, if the SHOW DEVICE command produces an error, enter

the following commands:

$ RUN SYS$SYSTEM:SYSGEN

SYSGEN> CONN FYA0/NOADAP

SYSGEN> ^Z

On Alpha systems, if the SHOW DEVICE command produces an error, enter

the following commands:

$ RUN SYS$SYSTEM:SYSMAN

SYSMAN> IO CONNECT FYA0: /NOADAP

SYSGEN> ^Z

The following is an example of the display produced by the RF_VERS utility:

Program Name: RF_VERS

Revision Level: V1.2s

NOTICE: This program does not currently support the RF72 or any

HSDxx controllers. See next version for support.

DSSI disks currently on this system as seen by RF_VERS

Device Node Status Hardware Firmware

Name Name Type Version

_$22$DIA7: R4JL2I mounted RF73 T387A

_$22$DIA6: R4I0BG mounted RF73 T387A

_$22$DIA8: R4XLWE mounted RF73 T387A

_$22$DIA2: R4FCZK mounted RF73 T387A

_$22$DIA3: R4CKCG mounted RF73 T387A

_$22$DIA4: R4ZKUE mounted RF73 T387A

_$22$DIA9: R4GYYI mounted RF73 T387A

_$22$DIA1: R4XRYI mounted RF73 T387A

Hardware Release Notes 6–17

Hardware Release Notes

6.17 RFnn DSSI Disk Devices and Controller Memory Errors

To update the microcode in your device, use the appropriate command for your

device and platform from Table 6–3.

Caution

Back up the disk before updating the microcode.

Table 6–3 Commands for Updating Microcode in Certain DSSI Disk Devices

Device Type Platform Command

RF35 Alpha $RUN SYS$ETC:RF35_T392F_DEC_ALPHA.EXE

RF35 VAX $RUN SYS$ETC:RF35_T392F_DEC.EXE

RF36 Alpha $RUN SYS$ETC:RF36_V427P_DEC_ALPHA.EXE

RF36 VAX $RUN SYS$ETC:RF36_V427P_DEC.EXE

RF73 Alpha $RUN SYS$ETC:RF73_T392F_DEC_ALPHA.EXE

RF73 VAX $RUN SYS$ETC:RF73_T392F_DEC.EXE

RF74 Alpha $RUN SYS$ETC:RF74_V427P_DEC_ALPHA.EXE

RF74 VAX $RUN SYS$ETC:RF74_V427P_DEC.EXE

Caution

Do not delete SCSI_INFO.EXE, RF_VERS.EXE, or any of the ﬁles listed

in Table 6–3. If these ﬁles are deleted, VMSKITBLD.COM (on VAX) will

not be able to ﬁnd them. Similarly, on Alpha systems, the PRODUCT

INSTALL commands in AXPVMS$PCSI_INSTALL and AXPVMS$PCSI_

INSTALL_MIN will fail.

6.18 RZnn Disk Drive Considerations

The following notes describe issues related to various RZ disk drives.

6.18.1 RZ25M and RZ26N Disk Drives: Recommendations

V7.1

During the testing of HP supported SCSI disk drives on conﬁgurations with

DWZZAs and long differential SCSI buses, two drives, RZ25M and RZ26N, were

found to have bus phase problems. For this reason, do not use these drives in

conﬁgurations where the differential bus length connecting DWZZAs equals or

exceeds 20 meters.

This recommendation applies only to the RZ25M and RZ26N drives. All other

disk drives that are listed as supported in the OpenVMS SPD can be used in

conﬁgurations to the full bus lengths of the SCSI-2 speciﬁcation.

6–18 Hardware Release Notes

Hardware Release Notes

6.18 RZnn Disk Drive Considerations

6.18.2 RZ26N and RZ28M Disks: Recommended Firmware Support

V6.2-1H3

The minimum ﬁrmware revision level recommended for RZ26N and RZ28M disks

is Revision 0568.

If the latest ﬁrmware revision level is not used with these disks, multiple

problems can occur.

6.18.3 RZ26L and RZ28 Disks: Required Firmware for Multihost Use

V6.2

If you install RZ26L or RZ28 disks on a multihost SCSI bus in an OpenVMS

Cluster, the disk’s minimum ﬁrmware revision is 442.

The following sections describe a procedure that you can use to update the

ﬁrmware on some RZ26L and RZ28 drives. This procedure can only be used with

drives that are directly connected to a SCSI adapter on a host system. Drives

that are attached through an intelligent controller (such as an HSZ40 or KZPSC)

cannot be updated using this procedure. Refer to the intelligent controller’s

documentation to determine whether an alternative ﬁrmware update procedure

exists.

Important Note

Only certain RZ26L and RZ28 ﬁrmware revisions can be safely upgraded

to ﬁrmware revision level 442. Refer to Section 6.18.3.1 to determine if

your disks are capable of being upgraded to ﬁrmware revision level 442.

If your disk is capable of supporting ﬁrmware revision level 442, use the

RZTOOLS utility that is described in Section 6.18.3.2 to update the disk’s

ﬁrmware.

6.18.3.1 Firmware Revision Level 442 Requirements

Only the combinations of disk drives and ﬁrmware revision levels listed in

Table 6–4 are capable of being upgraded safely to ﬁrmware revision level 442.

Performing the update procedure on any other combination can permanently

damage the disk.

Table 6–4 Revision Level 442 Firmware Compatibility

Disk Drive Firmware Revision Disk File Name

RZ26L 440C RZ26L_442D_DEC.FUP

RZ28 441C or D41C

435 or 436

RZ28_442D_DEC2104.FUP

RZ28P4_442C_DEC.FUP

6.18.3.2 Firmware Revision Level 442 Installation Procedure

If you determine that your disk requires revision level 442 ﬁrmware and it is

capable of being upgraded safely, use the following procedure to update the

ﬁrmware. (See Table 6–4 for the ﬁle name of the disk you are upgrading.)

Hardware Release Notes 6–19

Hardware Release Notes

6.18 RZnn Disk Drive Considerations

$ RZTOOLS_ALPHA :== $SYS$ETC:RZTOOLS_ALPHA

$ RZTOOLS_ALPHA DKB500 /LOAD=SYS$ETC:filename.FUP

Read in 262144 bytes.

Current FW version - X440C

Upgrading to - DEC0

Loading code ......

New code has been sent to the drive.

6.19 sx1000 Integrity Superdome

V8.3

The HP Integrity Superdome cannot boot as a satellite over the Core I/O LAN

card. When you specify the LAN card as a boot option to BOOT_OPTION.COM

and you then shut down the operating system, the LAN card does not appear in

EFI. The problem will be ﬁxed in a future release of the ﬁrmware.

6.20 ZLX Graphics Boards Support

V8.2

The following families of graphics controller boards are not supported on

OpenVMS Version 8.2:

• ZLX-M Series (PixelVision): ZLX-M1 (PMAGC-AA), ZLX-M2 (PMAGC-BA)

• ZLX-L Series (PixelVision Lite): ZLX-L1 (PMAGC-DA), ZLX-L2 (PMAGC-EA)

• ZLXp-L Series (PixelVision PCI): ZLXp-L1 (PBXGC-A), ZLXp-L2 (PBXGC-B)

As of OpenVMS Version 8.2, only 2D support, using the base 2D capabilities

shipped with OpenVMS, is provided for the following families of graphics

controller boards. Please do not install Open3D to obtain 2D support for the

following:

• ZLX-E Series (FFB): ZLX-E1 (PMAGD-AA), ZLX-E2 (PMAGD-BA), ZLX-E3

(PMAGD-CA)

• ZLXp-E Series (TGA): ZLXp-E1 (PBXGA-A), ZLXp-E2 (PBXGA-B), ZLXp-E3

(PBXGA-C)

• ZLX2-E Series (TGA2): PowerStorm 3D30 (PBXGB-AA), PowerStorm 4D20

(PBXGB-CA)

6.21 Recompiling and Relinking OpenVMS Device Drivers

The following sections contain release notes pertaining to recompiling and

relinking OpenVMS device drivers.

For related release notes, see Section 5.10.

6.21.1 Alpha and VAX SCSI Device Drivers

V7.3-1

All OpenVMS Alpha SCSI device drivers from previous versions of OpenVMS

must be recompiled and relinked to run correctly on OpenVMS Version 7.3-1 or

higher.

If you have an OpenVMS Alpha SCSI driver that you are upgrading from a

version prior to OpenVMS Alpha 7.0, see Section 6.21.2.

6–20 Hardware Release Notes

Hardware Release Notes

6.21 Recompiling and Relinking OpenVMS Device Drivers

Note that for OpenVMS Version 7.1 all OpenVMS VAX SCSI device drivers

required recompiling and relinking. OpenVMS VAX device drivers that were

recompiled and relinked to run on OpenVMS Version 7.1 will run correctly on

OpenVMS Version 7.3 or higher.

6.21.2 OpenVMS Alpha Device Drivers

V7.1

Device drivers that were recompiled and relinked to run on OpenVMS Alpha

Version 7.0 do not require source-code changes and do not have to be recompiled

and relinked to run on OpenVMS Alpha Version 7.1 and higher. (Note that

Alpha SCSI drivers, however, must be recompiled and relinked as described in

Section 6.21.1.)

Device drivers from releases prior to OpenVMS Alpha Version 7.0 that were not

recompiled and relinked for OpenVMS Alpha Version 7.0 must be recompiled and

relinked to run on OpenVMS Alpha Version 7.1 and higher.

OpenVMS Alpha Version 7.0 included signiﬁcant changes to OpenVMS Alpha

privileged interfaces and data structures. As a result of these changes, device

drivers from releases prior to OpenVMS Alpha Version 7.0 may also require

source-code changes to run correctly on OpenVMS Alpha Version 7.0 and higher.

For more details about OpenVMS Alpha Version 7.0 changes that may require

source changes to customer-written drivers, refer to the HP OpenVMS Guide to

Upgrading Privileged-Code Applications.

6.22 Device Driver MON Version Handling

V7.3

As of OpenVMS Version 7.3, when SYSTEM_CHECK is enabled, device driver

images with names of the form SYS$nnDRIVER_MON.EXE will be automatically

loaded by the system loader. If a corresponding _MON version does not exist, the

system will use the default image name: SYS$nnDRIVER.EXE.

6.23 Possible Per-Threads Security Impact on Alpha Device Drivers

V7.2

See Section 5.10.7 for information about how possible per-thread security impacts

OpenVMS Alpha device drivers.

6.24 Device IPL Setup for OpenVMS Alpha Drivers

V6.2

Alpha hardware platforms that support PCI, EISA, and ISA buses deliver I/O

device interrupts at different IPLs, either 20 or 21. The IPL at which device

interrupts are delivered can change if you move the device from one platform to

another. This is a problem if the driver declares its device IPL to be 20, and then

that driver is executed on a machine that delivers I/O device interrupts at IPL

21.

The simplest solution to this problem is for PCI, EISA, and ISA device drivers to

use IPL 21. This works correctly on platforms that deliver I/O device interrupts

at IPL 20 and on platforms that deliver I/O device interrupts at IPL 21.

Hardware Release Notes 6–21

Hardware Release Notes

6.25 CRCTX Routines Enhanced

V7.1-2

The system routines that you can use to manage the Counted Resource Context

Block (CRCTX) data structure have been improved. The following routines now

set and check the status (CRCTX$V_ITEM_VALID) of the CRCTX data structure:

• IOC$DEALLOC_CRCTX

• IOC$ALLOC_CNT_RES

• IOC$DEALLOC_CNT_RES

• IOC$LOAD_MAP

These routines have changed as follows:

If you call IOC$DEALLOC_CRCTX with a valid CRCTX status (CRCTX$V_

ITEM_VALID set to 1), the service returns a bad status. If the SYSBOOT

parameter SYSTEM_CHECK is set, the system will fail. This prevents users

from deallocating a CRCTX when they have valid resources that have not been

deallocated.

You must call IOC$ALLOC_CNT_RES with an invalid CRCTX status (CRCTX$V_

ITEM_VALID set to 0). If you call this routine with a valid status, OpenVMS

assumes that you will lose the resources mapped by this CRCTX. OpenVMS does

not allocate new resources and returns a bad status. If SYSTEM_CHECK is set,

the system will fail. IOC$ALLOC_CNT_RES sets the valid bit before it returns.

IOC$DEALLOC_CNT_RES must be called with a valid CRCTX (CRCTX$V_

ITEM_VALID set to 1). If you call IOC$DEALLOC_CNT_RES with an invalid

CRCTX, OpenVMS assumes that the other parameters are not valid, and returns

a bad status. If SYSTEM_CHECK is set, the system will fail. IOC$DEALLOC_

CNT_RES clears the valid bit before it returns.

IOC$LOAD_MAP must be called with a valid CRCTX. If it is called with

an invalid CRCTX (CRCTX$V_ITEM_VALID set to 0), it assumes that the

other parameters are also invalid, and returns a bad status. If the SYSBOOT

parameter SYSTEM_CHECK is set, the system will fail.

These improvements indicate to device support and privileged-code application

developers whether they need to deallocate scatter gather registers, which are

treated by OpenVMS as generic resources. If the CRCTX$V_ITEM_VALID bit is

set, IOC$DEALLOC_CNT_RES still needs to be called.

6.26 Adapter Release Notes

V8.2-1

The following sections provide release notes for adapters supported with

OpenVMS Version 8.2–1.

6.26.1 Fibre Channel EFI Driver and Firmware Requirements

OpenVMS Version 8.3 for Integrity servers requires that the HP A6826A 2 GB

Fibre Channel host-based adapter and its variants have the following minimum

version: EFI driver: 1.47 RISC ﬁrmware: 3.03.154; HP AB378A and AB379A 4

GB Fibre Channel host-based adapter have the following minimum version: EFI

driver: 1.05 RISC ﬁrmware: 4.00.70.

6–22 Hardware Release Notes

Hardware Release Notes

6.26 Adapter Release Notes

To determine the latest, currently supported versions of the RISC ﬁrmware and

EFI driver, see the README text ﬁle provided on the HP IPF Ofﬂine Diagnostics

and Utilities CD. To locate this ﬁle, navigate to the (\eﬁ\hp\tools\io_ cards\fc2)

directory for the 2 GB Fibre Channel HBA or \eﬁ\hp\tools\io_ cards\fc4 for

the 4 GB HBA. To update the driver and ﬁrmware, execute the

fcd_update2.nsh

or the

fcd_update4.nsh

, depending on your HBA type. Instructions for obtaining

the Ofﬂine Diagnostics and Utilities CD are included in the HP OpenVMS Version

8.3 Upgrade and Installation Manual.

6.26.2 Booting with Multiple Fibre Channel Boot Entries

On cell-based systems and newer entry-level systems, the ﬁrst ﬁbre channel

boot entry list is the only valid boot entry. To boot from the other Fibre Channel

Integrity servers system disk, go to the EFI Shell and execute "search all", exit

the EFI Shell, then select the speciﬁed boot entry. This is also required when

booting multi-member shadowed system disk.

Hardware Release Notes 6–23

Interlocked Memory Instructions (Alpha Only)

The Alpha Architecture Reference Manual, Third Edition (AARM) describes

strict rules for using interlocked memory instructions. The Alpha 21264

(EV6) processor and all future Alpha processors are more stringent than their

predecessors in their requirement that these rules be followed. As a result, code

that has worked in the past, despite noncompliance, could fail when executed on

systems featuring the 21264 processor and its successors. Occurrences of these

noncompliant code sequences are believed to be rare. Note that the 21264

processor is not supported on versions prior to OpenVMS Alpha Version 7.1-2.

Noncompliant code can result in a loss of synchronization between processors

when interprocessor locks are used, or can result in an inﬁnite loop when an

interlocked sequence always fails. Such behavior has occurred in some code

sequences in programs compiled on old versions of the BLISS compiler, some

versions of the MACRO–32 compiler and the MACRO–64 assembler, and in some

HP C and C++ programs.

The affected code sequences use LDx_L/STx_C instructions, either directly in

assembly language sources or in code generated by a compiler. Applications most

likely to use interlocked instructions are complex, multithreaded applications or

device drivers using highly optimized, hand-crafted locking and synchronization

techniques.

A.1 Required Code Checks

OpenVMS recommends that code that will run on the 21264 processor be checked

for these sequences. Particular attention should be paid to any code that does

interprocess locking, multithreading, or interprocessor communication.

The SRM_CHECK tool has been developed to analyze Alpha executables for

noncompliant code sequences. The tool detects sequences that may fail, reports

any errors, and displays the machine code of the failing sequence.

A.2 Using the Code Analysis Tool (SRM_CHECK)

The SRM_CHECK tool can be found in the following location on the OpenVMS

Alpha Version 7.3-2 Operating System CD:

SYS$SYSTEM:SRM_CHECK.EXE

To run the SRM_CHECK tool, deﬁne it as a foreign command (or use the

DCL$PATH mechanism) and invoke it with the name of the image to check. If

a problem is found, the machine code is displayed and some image information

is printed. The following example illustrates how to use the tool to analyze an

image called myimage.exe:

$ define DCL$PATH []

$srm_check myimage.exe

Interlocked Memory Instructions (Alpha Only) A–1

Interlocked Memory Instructions (Alpha Only)

A.2 Using the Code Analysis Tool (SRM_CHECK)

The tool supports wildcard searches. Use the following command line to initiate a

wildcard search:

$ srm_check [*...]* -log

Use the -log qualiﬁer to generate a list of images that have been checked. You

can use the -output qualiﬁer to write the output to a data ﬁle. For example, the

following command directs output to a ﬁle named CHECK.DAT:

$ srm_check ’file’ -output check.dat

You can use the output from the tool to ﬁnd the module that generated the

sequence by looking in the image’s MAP ﬁle. The addresses shown correspond

directly to the addresses that can be found in the MAP ﬁle.

The following example illustrates the output from using the analysis tool on an

image named SYSTEM_SYNCHRONIZATION.EXE:

** Potential Alpha Architecture Violation(s) found in file...

** Found an unexpected ldq at 00003618

0000360C AD970130 ldq_l R12, 0x130(R23)

00003610 4596000A and R12, R22, R10

00003614 F5400006 bne R10, 00003630

00003618 A54B0000 ldq R10, (R11)

Image Name: SYSTEM_SYNCHRONIZATION

Image Ident: X-3

Link Time: 5-NOV-1998 22:55:58.10

Build Ident: X6P7-SSB-0000

Header Size: 584

Image Section: 0, vbn: 3, va: 0x0, flags: RESIDENT EXE (0x880)

The MAP ﬁle for system_synchronization.exe contains the following:

EXEC$NONPAGED_CODE 00000000 0000B317 0000B318 ( 45848.) 2 ** 5

SMPROUT 00000000 000047BB 000047BC ( 18364.) 2 ** 5

SMPINITIAL 000047C0 000061E7 00001A28 ( 6696.) 2 ** 5

The address 360C is in the SMPROUT module, which contains the addresses

from 0-47BB. By looking at the machine code output from the module, you can

locate the code and use the listing line number to identify the corresponding

source code. If SMPROUT had a nonzero base, you would need to subtract the

base from the address (360C in this case) to ﬁnd the relative address in the

listing ﬁle.

Note that the tool reports potential violations in its output. Although SRM_

CHECK can normally identify a code section in an image by the section’s

attributes, it is possible for OpenVMS images to contain data sections with those

same attributes. As a result, SRM_CHECK may scan data as if it were code, and

occasionally, a block of data may look like a noncompliant code sequence. This

circumstance is rare and can be detected by examining the MAP and listing ﬁles.

A.3 Noncompliant Code Characteristics

The areas of noncompliance detected by the SRM_CHECK tool can be grouped

into the following four categories. Most of these can be ﬁxed by recompiling

with new compilers. In rare cases, the source code may need to be modiﬁed. See

Section A.5 for information about compiler versions.

• Some versions of OpenVMS compilers introduce noncompliant code sequences

during an optimization called "loop rotation." This problem can be triggered

only in C or C++ programs that use LDx_L/STx_C instructions in assembly

language code that is embedded in the C/C++ source using the ASM function,

A–2 Interlocked Memory Instructions (Alpha Only)

Interlocked Memory Instructions (Alpha Only)

A.3 Noncompliant Code Characteristics

or in assembly language written in MACRO–32 or MACRO–64. In some

cases, a branch was introduced between the LDx_L and STx_C instructions.

This can be addressed by recompiling.

• Some code compiled with very old BLISS, MACRO–32, DEC Pascal, or DEC

COBOL compilers may contain noncompliant sequences. Early versions of

these compilers contained a code scheduling bug where a load was incorrectly

scheduled after a load_locked.

This can be addressed by recompiling.

• In rare cases, the MACRO–32 compiler may generate a noncompliant code

sequence for a BBSSI or BBCCI instruction where there are too few free

registers.

This can be addressed by recompiling.

• Errors may be generated by incorrectly coded MACRO–64 or MACRO–32 and

incorrectly coded assembly language embedded in C or C++ source using the

ASM function.

This requires source code changes. The new MACRO–32 compiler ﬂags

noncompliant code at compile time.

If the SRM_CHECK tool ﬁnds a violation in an image, you should recompile the

image with the appropriate compiler (see Section A.5). After recompiling, you

should analyze the image again. If violations remain after recompiling, examine

the source code to determine why the code scheduling violation exists. Then

make the appropriate changes to the source code.

A.4 Coding Requirements

The Alpha Architecture Reference Manual describes how an atomic update of

data between processors must be formed. The Third Edition, in particular, has

much more information on this topic. This edition details the conventions of the

interlocked memory sequence.

Exceptions to the following two requirements are the source of all known

noncompliant code:

• There cannot be a memory operation (load or store) between the LDx_L (load

locked) and STx_C (store conditional) instructions in an interlocked sequence.

• There cannot be a branch taken between an LDx_L and an STx_C instruction.

Rather, execution must "fall through" from the LDx_L to the STx_C without

taking a branch.

Any branch whose target is between an LDx_L and matching STx_C creates

a noncompliant sequence. For instance, any branch to "label" in the following

example would result in noncompliant code, regardless of whether the branch

instruction itself was within or outside of the sequence:

LDx_L Rx, n(Ry)

...

label: ...

STx_C Rx, n(Ry)

Therefore, the SRM_CHECK tool looks for the following:

• Any memory operation (LDx/STx) between an LDx_L and an STx_C

• Any branch that has a destination between an LDx_L and an STx_C

Interlocked Memory Instructions (Alpha Only) A–3

Interlocked Memory Instructions (Alpha Only)

A.4 Coding Requirements

• STx_C instructions that do not have a preceding LDx_L instruction

This typically indicates that a backward branch is taken from an LDx_L to

the STx_C Note that hardware device drivers that do device mailbox writes

are an exception. These drivers use the STx_C to write the mailbox. This

condition is found only on early Alpha systems and not on PCI-based systems.

• Excessive instructions between an LDx_L and an STxC

The AARM recommends that no more than 40 instructions appear between

an LDx_l and an STx_C. In theory, more than 40 instructions can cause

hardware interrupts to keep the sequence from completing. However, there

are no known occurrences of this.

To illustrate, the following are examples of code ﬂagged by SRM_CHECK.

** Found an unexpected ldq at 0008291C

00082914 AC300000 ldq_l R1, (R16)

00082918 2284FFEC lda R20, 0xFFEC(R4)

0008291C A6A20038 ldq R21, 0x38(R2)

In the above example, an LDQ instruction was found after an LDQ_L before

the matching STQ_C. The LDQ must be moved out of the sequence, either by

recompiling or by source code changes. (See Section A.3.)

** Backward branch from 000405B0 to a STx_C sequence at 0004059C

00040598 C3E00003 br R31, 000405A8

0004059C 47F20400 bis R31, R18, R0

000405A0 B8100000 stl_c R0, (R16)

000405A4 F4000003 bne R0, 000405B4

000405A8 A8300000 ldl_l R1, (R16)

000405AC 40310DA0 cmple R1, R17, R0

000405B0 F41FFFFA bne R0, 0004059C

In the above example, a branch was discovered between the LDL_L and STQ_C.

In this case, there is no "fall through" path between the LDx_L and STx_C, which

the architecture requires.

Note

This branch backward from the LDx_L to the STx_C is characteristic of

the noncompliant code introduced by the "loop rotation" optimization.

The following MACRO–32 source code demonstrates code where there is a "fall

through" path, but this case is still noncompliant because of the potential branch

and a memory reference in the lock sequence:

getlck: evax_ldql r0, lockdata(r8) ; Get the lock data

movl index, r2 ; and the current index.

tstl r0 ; If the lock is zero,

beql is_clear ; skip ahead to store.

movl r3, r2 ; Else, set special index.

is_clear:

incl r0 ; Increment lock count

evax_stqc r0, lockdata(r8) ; and store it.

tstl r0 ; Did store succeed?

beql getlck ; Retry if not.

A–4 Interlocked Memory Instructions (Alpha Only)

Interlocked Memory Instructions (Alpha Only)

A.4 Coding Requirements

To correct this code, the memory access to read the value of INDEX must ﬁrst

be moved outside the LDQ_L/STQ_C sequence. Next, the branch between the

LDQ_L and STQ_C, to the label IS_CLEAR, must be eliminated. In this case,

it could be done using a CMOVEQ instruction. The CMOVxx instructions are

frequently useful for eliminating branches around simple value moves. The

following example shows the corrected code:

movl index, r2 ; Get the current index

getlck: evax_ldql r0, lockdata(r8) ; and then the lock data.

evax_cmoveq r0, r3, r2 ; If zero, use special index.

incl r0 ; Increment lock count

evax_stqc r0, lockdata(r8) ; and store it.

tstl r0 ; Did write succeed?

beql getlck ; Retry if not.

A.5 Compiler Versions

Table A–1 contains information about versions of compilers that might generate

noncompliant code sequences and the recommended minimum versions to use

when you recompile.

Table A–1 Versions of OpenVMS Compilers

Old Version Recommended Minimum Version

BLISS V1.1 BLISS V1.3

DEC Ada V3.5 HP Ada V3.5A

DEC C V5.x DEC C V6.0

DEC C++ V5.x DEC C++ V6.0

DEC COBOL V2.4, V2.5, V2.6 COBOL V2.8

DEC Pascal V5.0-2 DEC Pascal V5.1-11

MACRO–32 V3.0 V3.1 for OpenVMS Version 7.1-2

V4.1 for OpenVMS Version 7.2

MACRO–64 V1.2 See below.

Current versions of the MACRO–64 assembler might still encounter the loop

rotation issue. However, MACRO–64 does not perform code optimization by

default, and this problem occurs only when optimization is enabled. If SRM_

CHECK indicates a noncompliant sequence in the MACRO–64 code, it should

ﬁrst be recompiled without optimization. If the sequence is still ﬂagged when

retested, the source code itself contains a noncompliant sequence that must be

corrected.

Alpha computers with 21264 processors require strict adherence to the

restrictions for interlocked memory sequences for the LDx_L and STx_C

instructions described in the Alpha Architecture Reference Manual, Third Edition.

To help ensure that uses of interlocked memory instructions conform to the

architectural guidelines, additional checking has been added to Version 3.1 of the

MACRO–32 Compiler for OpenVMS Alpha.

The Alpha Architecture Reference Manual, Third Edition describes the rules

for instruction use within interlocked memory sequences in Section 4.2.4. The

MACRO–32 for OpenVMS Alpha Version 3.1 compiler observes these rules in the

code it generates from MACRO–32 source code. However, the compiler provides

EVAX_LQxL and EVAX_STxC built-ins, which allow these instructions to be

written directly in source code.

Interlocked Memory Instructions (Alpha Only) A–5

Interlocked Memory Instructions (Alpha Only)

A.5 Compiler Versions

The MACRO–32 Compiler for OpenVMS Alpha Version 4.1 now performs

additional code checking and displays warning messages for noncompliant code

sequences.

A.6 Recompiling Code with ALONONPAGED_INLINE or

LAL_REMOVE_FIRST

Any MACRO–32 code on OpenVMS Alpha that invokes either the

ALONONPAGED_INLINE or the LAL_REMOVE_FIRST macro from the

SYS$LIBRARY:LIB.MLB macro library must be recompiled on OpenVMS Version

7.2 or higher to obtain a correct version of these macros. The change to these

macros corrects a potential synchronization problem that is more likely to be

encountered on newer processors, starting with Alpha 21264 (EV6).

Note

Source modules that call the EXE$ALONONPAGED routine (or any of its

variants) do not need to be recompiled. These modules transparently use

the correct version of the routine that is included in this release.

A–6 Interlocked Memory Instructions (Alpha Only)

Index

Ada compiler, 5–11

adapter release notes, 6–22

AlphaServer 2100

console display, 6–3

SCSI controller restriction, 6–3

AlphaServer 4100

FRU table restriction, 6–4

AlphaServer 8200 systems

FRU table restriction, 6–4

AlphaServer 8400 systems

FRU table restriction, 6–4

AlphaServer ES47/ES80/GS1280 systems

INIT console command usage on soft partitions,

6–4

license requirement, 6–4

RAD support, 6–4

setting time at MBM, 6–5

STOP/CPU and shutdown behavior, 6–4

AlphaServer GS Series systems

device restriction, 6–5

multiple I/O port restriction, 6–7

AlphaStation 200/400

ISA_CONFIG.DAT changes required, 6–7

AlphaStation 255

PCI conﬁguration restriction, 6–8

ANALYZE, 4–34

API

pthread_mutex_tryforcedlock_np, 5–34

Applications support for current release, 2–1

Associated products

Software Public Rollout Reports, 2–1

versions supported for current release, 2–1

AST delivery

POSIX, 5–3

ATI RADEON 7000 graphics, 6–8

hardware accelerated 3D graphics not

supported, 6–9

ATI RADEON 7500 graphics, 6–9 to 6–13

DECW$OPENGLSHR_RADEON.EXE renamed,

6–10

DECwindows server hangs, 6–10

OpenGL supports IEEE arithmetic only, 6–10

video artifacts at high refresh rates, 6–10

Backport library, 5–12

Backup API

journaling events, 5–11

BL860c and BL870c servers, 4–5

BLISS

See HP BLISS compiler

BMC console restrictions (Integrity servers only),

6–2

BUGCHECKFATAL system parameter, 5–15

<builtins.h>

changes, 5–13

C++ compiler

See HP C++ compiler

C++ Run-time Library

corrections, 5–1

CANCEL SELECTIVE function, improved use

with LTDRIVER, 5–32

C compiler

See HP C compiler

CDSA, 5–14

cell-based systems

multiple nPartitions on, 4–30

Circuit switching

and reduced performance, 4–28

CLUE commands

not ported to Integrity servers, 5–33

Cluster compatibility kits, 4–26

Clusters

See OpenVMS Cluster systems

CMAP ﬁles

new, 2–4

COBOL RTL

See HP COBOL RTL

COM for OpenVMS

error with heavy load of applications, 2–4

support, 2–4

Common Data Security Architecture

See CDSA

Compilers

noncompliant code, A–1, A–5

Index–1

Conﬁguring SAS tape drives, 4–12

C programs

compiling and case sensitivity, 5–11

CPUSPINWAIT bugcheck, 5–15

CPU_POWER_MGMT default, 4–22

CRCTX routines enhanced, 6–22

C RTL, 5–11 to 5–13

backport library, 5–12

<builtins.h>

changes, 5–13

DECC$*.OLB libraries frozen

, 5–13

_ _fci

built-in added, 5–13

<time.h>

changes, 5–12

C Run-Time Library

See C RTL

Ctrl/H key sequence

remapping to DEL (Integrity servers only), 6–2

Ctrl/P, 3–3

Data-reduced ELF object libraries

linking against, 5–31

DCE for OpenVMS, 2–2

DCL commands, 3–8

DDB structure

updates, 5–8

DDT Intercept Establisher Routines

device conﬁguration, 4–28

DECC$*.OLB libraries frozen, 5–13

DECdfs for OpenVMS

Version 2.4 required, 2–4

DECdtm

Oracle 8i,9i, 4–24

DECforms Web Connector

running on OpenVMS Version 7.3-1 and higher,

2–5

DECmigrate

not on V8.2 Open Source Tools CD, 3–9

DECnet/OSI

See DECnet-Plus for OpenVMS

DECnet for OpenVMS, 1–3

DECnet-Plus for OpenVMS, 1–3

new version required, 1–13

DEC PL/I, 2–5

DECram

See HP DECram

DECRAM

conﬂict with DECRYPT command, 2–6

DECwindows Motif

See HP DECwindows Motif

DECwindows X11 display server, 6–13

graphics boards support, 6–20

Delete key

requires remapping (Integrity servers only),

6–2

Delta/XDelta debuggers, 5–15

Device conﬁguration, 4–28

Device drivers

IPL setup, 6–21

MON version handling, 6–21

per-thread security impact, 6–21

recompiling and relinking, 6–20 to 6–21

SCSI, 6–20

DEVICE_NAMING system parameter, 4–24

DIAGNOSE command

not supported, 3–8

DIGITAL Modular Computing Components

(DMCC)

KZPDA controller and PBXGA graphics card,

6–13

updating the SRM console, 6–13

Digital Personal Workstation, 6–14

Documentation changes and corrections

Guide to OpenVMS File Applications, 5–16

LIB$ help omission, 5–38

OpenVMS Performance Management, 3–18

OpenVMS RTL Screen Management (SMG$)

Manual, 5–39

Documentation corrections, 3–10

using IPC commands, 3–21

DSSI disk devices

microcode revision levels, 6–16

Dual-controller HSGnn

failure, 6–14

Dynamic CPU conﬁguration

POSIX Threads Library, 5–37

EDIT/FDL

ﬁxing recommended bucket size, 4–24

EFI$CP utility

use not recommended, 4–25

EFI driver, 6–22

ELV

See Error Log Viewer (ELV) utility

Error Log Viewer (ELV) utility, 4–25

Error Message from ACPI, 4–10

EV6 Alpha processor, A–1

Extended DDT bit

problem corrected, 5–32

Extended File Cache (XFC), 4–34

External authentication, 4–12

Integrity servers support, 4–13

password expiration notiﬁcation, 4–13

SET PASSWORD command, 4–13

External SAS disk device, 4–12

Index–2

F$GETSYI("RAD_CPUS"), 3–1

Fast Path

turning off, for Galaxy on ES40, 4–31

_ _fci

built-in added, 5–13

Fibre Channel, 5–4, 6–23

compatibility kits, 4–26

multipath failover restriction for tape devices,

4–29

Firmware

for Alpha servers, 1–8

for Integrity servers, 1–6

ﬁrmware, EFI, 4–5

Floating-point data

considerations for applications, 5–10

FMS kits, 2–5

Fortran

See HP Fortran

Freeware, 3–7

menu unavailable on OpenVMS Integrity

servers, 3–8

Galaxy

deﬁnitions, 4–30

Graphical Conﬁguration Manager (GCM)

supported for Galaxy, 4–30

Graphical Conﬁguration Utility (GCU), 4–30

Graphics

support for Integrity servers, 6–8

Graphics boards support, 6–20

Hard partition, 4–30

HP BLISS compiler

consequences of noncompliant code, A–1

warnings (Integrity servers only), 5–16

HP C++ compiler

consequences of noncompliant code, A–1

HP C compiler

consequences of noncompliant code, A–1

HP COBOL RTL, 5–18

HP Code Signing Service for OpenVMS, 5–14

HPCSS support, 3–1

HP DECram, 2–6

command conﬂict between DECRAM and

DECRYPT, 2–6

removal before upgrade (Alpha only), 1–12

ships as a SIP on V8.2, 2–6

Version 2.5 (VAX only), 2–6

HP DECwindows Motif

keyboard support restrictions (Integrity

servers), 1–8

user-written transport support, 2–7

HP DECwindows Motif (cont’d)

version support, 1–4

HP Fortran

for Integrity servers, 5–18

HP MACRO for OpenVMS, 5–19

ﬂoating divide-by-zero error not raised

(Integrity servers only), 5–22

on Alpha systems, 5–22

on Integrity servers, 5–21

/OPTIMIZE=VAXREGS qualiﬁer not supported

on Integrity servers, 5–22

HP Secure Web Browser

increased memory requirement, 3–9

installation error on ODS-2 (Integrity servers

only), 3–9

HP Secure Web Server

support, 2–7

HP SIM, provisioning from, 4–5

HP SSL

Startup commands for Encrypt and SSL, 1–12

HSGnn

failure, 6–14

Hypersort utility, 5–23 to 5–24

IDE CD, 6–14

ID-VSE for OpenVMS, 4–6

simulated OpenVMS systems, 4–7

sub-OS workloads, 4–7

utilization data, 4–6

IEE Floating Point

ﬁlter (Integrity servers only), 5–10

INIT console command

usage on ES47/ES80/GS1280 soft partitions,

6–4

Insight software

features not supported, 4–7

Installation and upgrade information

networking options, 1–3

Installation error

HP Secure Web Browser, 3–9

installing oracle database 10g Release 2, 3–4

INSTALL utility

installing resident images, 4–35

Integrity servers

ﬁrmware, 1–6

Integrity VM

Guest Punishment Scenarios, 4–2

Intel Assembler (Integrity servers only), 5–24

Interlocked memory instructions, A–1

Invocation context block, 5–38

IPC Commands, 3–21

Index–3

Kerberos

Kerberos for OpenVMS, 1–10

KPB extensions, 5–7

LANCP

converting device database after upgrading

(Alpha only), 1–13

LAN Drivers

duplex mode mismatch errors, 3–22

Large device name support, 4–10

Layered product

fails to install, 1–14

LIB$GET_CURR_INVO_CONTEXT

documentation correction, 3–20

LIB$GET_INVO_CONTEXT

documentation correction, 3–20

LIB$GET_INVO_HANDLE

documentation correction, 3–20

LIB$GET_PREV_INVO_CONTEXT

documentation correction, 3–20

LIB$GET_PREV_INVO_HANDLE

documentation correction, 3–20

LIB$GET_UIB_INFO

documentation correction, 3–20

LIB$I64_GET_FR, 5–38

LIB$I64_GET_GR, 5–38

LIB$I64_PUT_INVO_REGISTERS, 5–38

LIB$I64_SET_FR, 5–38

LIB$I64_SET_GR, 5–38

LIB$LOCK_IMAGE

missing from help, 5–38

LIB$PUT_INVO_REGISTERS

documentation correction, 3–20

LIBRARIAN

See Librarian Utility, 3–18

Librarian utility, 3–18, 5–24

error reporting problem, 5–25

linking against data-reduced ELF object

libraries (Integrity servers restriction),

5–24

restrictions with .STB ﬁles (Integrity servers

only), 5–25

Library utility

corrected information

/accessing ELF object libraries, 3–19

/REMOVE, 3–19

LIBRTL

Calling Standard routines (Integrity servers

only), 5–38

Licenses, 4–25

Licensing issues, 6–5 to 6–7

Linker for OpenVMS Alpha, 5–25 to 5–26

change in behavior with library check, 5–26

hangs when processing many ﬁles, 5–26

limit of 25 elements on stack, 5–26

RMS_RELATED_CONTEXT option, 5–26

Linker for OpenVMS Integrity servers, 5–27 to

5–32

created code stubs, 5–32

data-reduced ELF object libraries, 5–31

demangled symbol names, 5–32

differences from OpenVMS Alpha Linker, 5–30

/EXPORT_SYMBOL_VECTOR removed, 5–32

initialized overlaid program sections, 5–31

LINK_ORDER section header ﬂag, 5–30

longer symbol names in options, 5–32

/PUBLISH_GLOBAL_SYMBOLS removed,

5–32

LINK_ORDER ELF section header ﬂag, 5–30

local area network, 4–5

Locales

new, 2–7

LTDRIVER restriction, 5–32

MACRO–32 compiler

consequences of noncompliant code, A–1

recompiling code, A–6

MACRO–64 assembler

consequences of noncompliant code, A–1

MACRO for OpenVMS

See HP MACRO for OpenVMS

Mail utility (MAIL)

problem when callable mail used with kernel

threads, 5–33

Microcode revision levels

commands for updating, 6–18

on DSSI disk devices, 6–16

Migration software, 1–14

MMG_CTLFLAGS system parameter, 3–18

Monitor utility changes, 4–19

MP console restrictions (Integrity servers only),

6–2

Multipath failover

Fibre Channel tape device restriction, 4–29

tape robots, 4–29

multiple nPartitions

on cell-based systems, 4–30

multiple servers, provisioning, 4–5

MULTIPROCESSING system parameter, 5–15

name length, InfoServer, 4–5

NetBeans

Requires Java Standard Edition, Development

Kit v 1.4.2-7, 2–2

Index–4

Network

update restrictions, 3–21

Network options, 1–3

New Return Status

pthread_mutex_lock, 5–34

Noncompliant code, A–1, A–2

Open3D graphics

controller boards support, 6–20

licensing change, 6–15

OpenVMS

ENCRYPT and DECRYPT commands, 1–12

OpenVMS Calling Standard

rotating registers, 5–13

OpenVMS Cluster systems, 4–14 to 4–29

compatibility kits, 4–26

compatibility kits for mixed versions, 4–26

patch kits, 4–25

performance reduced with CI-LAN switching,

4–28

rolling upgrades, 1–9

SCSI multipath failover, 4–27

OpenVMS Debugger

Ada event support, 5–10

C++ language issues, 5–11

OpenVMS DELTA/XDELTA Debugger

update to manual, 3–18

OpenVMS Galaxy, 4–29 to 4–31

and ES40

turning off Fast Path, 4–31

uncompressed dump limitation, 4–30

license enforcement, 6–5

OpenVMS Integrity servers

booting from DVD, 1–7

OpenVMS Performance Management

documentation correction, 3–18

OpenVMS Registry

Version 2 format database corruption, 4–31

OpenVMS System Dump Analyzer

CLUE commands not ported to Integrity

servers, 5–33

Parameters, 4–21

Partition

hard, 4–30

soft, 4–30

Pascal

reinstalling after an upgrade (Alpha), 2–8

V5.8A required to create STARLET library

(Alpha only), 2–8

Patch kits

required for mixed-version OpenVMS Cluster

system, 4–26

Patch kits for cluster compatibility, 4–25

PCB$T_TERMINAL

size increase, 5–8

PCI conﬁguration restriction, 6–8

PEdriver

response to LAN congestion, 4–28

performance

COBOL CALL, 5–18

Performance, 4–9

Performance Enhancements, 4–8

Ctrl/T alignment faults, 4–10

dedicated CPU lock manager, 4–10

exception handling, 4–9

global section and creation and deletion, 4–10

image activation, 4–10

Per-thread security

impact on device drivers, 5–8

impact on privileged code, 5–8

PGFLQUOTA problems, 5–25

PL/I

libraries not included in Integrity servers, 5–33

RTL support, 2–5

POOLCHECK system parameter, 5–15

Port driver $QIO

restriction, 5–32

POSIX Threads Library, 5–33 to 5–38

debugger metering does not work, 5–38

dynamic CPU conﬁguration, 5–37

ﬂoating-point exceptions (Integrity servers

only), 5–36

pthread_mutex_lock, 5–34

pthread_mutex_tryforcedlock_np, 5–34

stack overﬂows during exception handling

(Integrity servers only), 5–35

Support for Process-shared Objects, 5–34

THREADCP command behavior for Integrity

servers, 5–36

PowerStorm 300/350 PCI graphics support, 6–15

Open3D license no longer checked, 6–15

Privileged data structures

64-bit logical block number, 5–7

CPU name space, 5–7

forking to a dynamic spinlock, 5–7

KPB extensions, 5–7

PCB$T_TERMINAL size increase, 5–8

per-thread security impact on, 5–8

UCB/DDB updates, 5–8

updates to, 5–6 to 5–8

provisioning

OpenVMS Guest limitation, 4–4

OpenVMS using HP SIM, 4–4

system ﬁrmware, 4–5

pthread_mutex_lock

New Return Status, 5–34

pthread_mutex_tryforcedlock_np

API, 5–34

Index–5

Recompiling programs

for Alpha, 5–6

Remedial kits

obtaining, 1–3

required for mixed-version OpenVMS Cluster

system, 4–26

restriction

SYS$LDDRIVER, 4–22

RF73 and RFnn disks, controller memory errors,

6–16

RMS

FAB, 5–17

Rotating registers, 5–38

Run-time library routines, 3–20

rx7620 server, 1–4

rx8620 server, 1–4

RZnn disk drives, 6–18 to 6–20

satellite system, 4–22

SCSI controllers

restrictions on AlphaServer 2100 systems, 6–3

SCSI device drivers, 6–20

SCSI multipath incompatibility, 4–27

SDA

See OpenVMS System Dump Analyzer

serial port enumeration, 3–4

Servers

rx7620, 1–4

rx8620, 1–4

Superdome, 1–4

SET DEVICE/SWITCH command, 4–29

SET PASSWORD command, 4–13

SHUTDOWN.COM, 4–14

SMG$

documentation corrections, 5–39

Software Public Rollout Reports, 2–1

SORT32 utility, 5–24, 5–40 to 5–41

SPLINVIPL bugcheck, 5–9

SRM_CHECK tool, A–1

storage controllers

restriction, 1–4

Superdome

sx1000, 6–20

Superdome server, 1–4

Support policy for software, 1–1

sx1000 chipset, 1–4

sx1000 Superdome, 6–20

symbolic debugger, 5–1

symlinks implementation, 3–1

SYS$GETTIM_PREC System Service, 3–1

SYS$SYSTEM:SHUTDOWN.COM command, 3–8

SYSGEN, 4–22

SYSMAN, 4–22

System crashes

recovery from (Integrity servers only), 4–23

System disk

incompatibility with older systems, 1–3

System Event Analyzer (SEA) utility

support on Integrity servers, 2–8

System Event Log (SEL)

clearing on Integrity servers, 1–5

System hangs

recovery from (Integrity servers only), 4–23

System parameters, 4–31 to 4–32

BUGCHECKFATAL, 5–15

changes, 4–32

DEVICE_NAMING

used to increase device unit number

maximum, 4–24

MMG_CTLFLAGS documentation error, 3–18

MULTIPROCESSING, 5–15

new parameters, 4–31

obsolete parameters, 4–31

POOLCHECK, 5–15

SYSTEM_CHECK, 5–15

System service changes, 5–1

SYSTEM_CHECK system parameter, 5–15

Tape robots

automatic multipath failover, 4–29

TCP/IP server components

BIND, LPD, LBROKER, and SMTP, 4–5

TCP/IP Services for OpenVMS, 1–3

Terminal Fallback Facility (TFF), 4–32

restrictions, 4–33

TFF

See Terminal Fallback Facility

THREADCP command

behavior for Integrity servers, 5–36

2 TiB disk volume support restrictions, 4–11

TIE kit, 1–14

<time.h>

changes, 5–12

Timer queue entries (TQEs), 5–41

Time zone conﬁguration, 4–1

TQEs

See Timer queue entries

Translated Image Environment

See TIE kit, 1–14

TZ function, 3–7, 4–22

U160 SCSI Support

rx7620, rx8620, 1–5

Index–6

UCB structure

updates, 5–8

Upgrade

paths, 1–8

USB

device support, 6–1

validation, 5–4

VAX Cluster Cache

See Virtual I/O Cache

VCC

See Virtual I/O Cache

VIOC

See Virtual I/O Cache

virtual connect, 4–23

failover, 4–23

Virtual I/O Cache

not available on Integrity servers, 4–34

superseded by XFC, 4–34

Volume Shadowing for OpenVMS

compatibility kits, 4–26

Watchpoint utility, 5–41

WEBES

support on Integrity servers, 2–8

Whole-program ﬂoating-point mode (Integrity

servers only), 5–41

Write Bitmaps, 4–8

write messages, 3–6

XA, 4–24

XFC

See Extended File Cache

ZLX graphics boards support, 6–20

Index–7
