Page Count: 33

Models

HP 1410-8G Switch

J9559A

HP 1410-16G Switch

J9560A

HP 1410-24G-R Switch

JG708A

HP 1410-24G Switch

J9561A

HP 1410-8 Switch

J9661A

HP 1410-16 Switch

J9662A

HP 1410-24 Switch

J9663A

HP 1410-24-R Switch

JD986B

HP 1410-24-2G Switch

J9664A

Key features

Unmanaged Gigabit Ethernet and Fast Ethernet switches

Green features for low power consumption

Fanless design for silent operation

Quality of service (QoS) support

Lifetime warranty

Product overview

HP 1410 Switch Series comprises unmanaged Gigabit Ethernet and Fast Ethernet switches designed for small businesses looking for

entry-level, low-cost networking solutions that come with a lifetime warranty. The series consists of nine models with flexible

mounting options to meet different network switching needs. All models have quality of service(QoS) support and IEEE 802.3x flow

control features that provide outstanding data efficiency. Simplified plug-and-play convenience is enabled by features such as Auto-

MDIX and auto-speed negotiation. HP has innovated and combined the latest advances in silicon technology to bring you some of the

most power-efficient switches: 1410-24G-R,1410-16 and 1410-24 models are advanced IEEE 802.3az-compliant unmanaged Gigabit

and Fast Ethernet switches. The switches come with built-in green features and a lifetime warranty, making the series the right choice

for organizations seeking a networking solution that's both economical and reliable.

Features and benefits

Quality of Service

(QoS)

IEEE 802.1p prioritisation

delivers data to devices based on the priority and type of traffic

DiffServ Code Point (DSCP) support

allows real-time traffic prioritisation based on Layer 3 TOS/DSCP parameters

Connectivity

Auto-MDIX

provides automatic adjustments for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

Performance

QuickSpecs

HP 1410 Switch series

Overview

DA - 13674 North America — Version 12 — December 16, 2013

Page 1

NEW Energy-efficient Ethernet support

supports new IEEE 802.3az standard; allows lower power consumption when operated with IEEE-compliant client devices in

100 Mb/s mode only (JG708A, J9662A and J9663A switches)

Half-/full-duplex auto-negotiating capability on every port

doubles the throughput of every port

NEW Jumbo frame support

allows frames up to 9216 bytes to be switched through the network (Gigabit Ethernet models)

Mini jumbo frame support

allows frames up to 2048 bytes to be switched through the network, which supports large data transfers (J9662A and J9663A

switches)

Ease of use

Unmanaged

provides plug-and-play simplicity

Comprehensive LED display with per-port indicators

provides an at-a-glance view of status, activity, speed and full-duplex operation

Flow control

helps ensure reliable communications during full-duplex operation

Auto-speed negotiation

selects individual port speed automatically depending on client capabilities without the need for manual intervention, allowing

for simple plug-and-play operation

Flexibility

Fanless design

enables quiet operation for deployment in open spaces

NEW Internal power supply

provides operation convenience and a neat operation environment (JG708A, J9561A and JD986B switches)

Warranty and support

NEW Lifetime Warranty 2.0

advance hardware replacement for as long as you own the product with next-business-day delivery (available in most countries)†

NEW Electronic and telephone support (for Lifetime Warranty 2.0)

limited 24x7 telephone support is available from HP for the first 3 years; limited electronic and business hours telephone

support is available from HP for the complete warranty period; to reach our support centres, refer to

www.hp.com/networking/contact-support

; for details on the duration of support provided with your product purchase, refer

to

www.hp.com/networking/warrantysummary

* HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance

replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP

Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765 zl Mobility Controller

and HP Survivable Branch Communication zl Module powered by Microsoft® Lync has a five-year hardware warranty. For details, refer

to the Software license and hardware warranty statements at

www.hp.com/networking/warranty

QuickSpecs

HP 1410 Switch series

Overview

DA - 13674 North America — Version 12 — December 16, 2013

Page 2

Build To Order

: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-

Shippable solution.

HP 1410-8G Switch

J9559A

8 autosensing 10/100/1000 ports

See Configuration

Note:2

HP 1410-16G Switch

J9560A

16 autosensing 10/100/1000 ports

1U - Height

See Configuration

Note:2

HP 1410-24G-R Switch

JG708A

24 autosensing 10/100/1000 ports

1U - Height

See Configuration

Note:2

HP 1410-24G Switch

J9561A

22 autosensing 10/100/1000 ports

2 dual-personality ports; either an RJ-45 10/100/1000 port or an open mini-GBIC slot

1U - Height

See Configuration

Note:1, 3

PDU Cable NA/MX/TW/JP

J9561A #B2B

C15 PDU Jumper Cord (NA/MX/TW/JP)

PDU Cable ROW

J9561A #B2C

C15 PDU Jumper Cord (ROW)

HP 1410-8 Switch

J9661A

8 autosensing 10/100 ports

See Configuration

Note:2

HP 1410-16 Switch

J9662A

16 autosensing 10/100 ports

1U - Height

See Configuration

Note:2

HP 1410-24 Switch

J9663A

24 autosensing 10/100 ports

1U - Height

See Configuration

Note:2

HP 1410-24-R Switch

JD986B

24 autosensing 10/100 ports

1U - Height

See Configuration

Note:2

QuickSpecs

HP 1410 Switch series

Configuration

DA - 13674 North America — Version 12 — December 16, 2013

Page 3

HP 1410-24-2G Switch

J9664A

24 autosensing 10/100ports

2 autosensing 10/100/1000 ports

1U - Height

See Configuration

Note:2

Configuration Rules:

Note 1

The following Transceivers install into this switch:

HP X121 1G SFP LC SX Transceiver

J4858C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X111 100M SFP LC FX Transceiver

J9054C

Note 2

Localization required. (See Localization Menu for list.)

Note 3

Localization (Wall Power Cord) required on orders without #B2B or #B2C (PDU Power Cord). (See

Localization Menu)

Internal or External Power Supplies(Model Dependant)

Power supplies included

Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.

Transceivers

SFP Transceivers

HP X121 1G SFP LC SX Transceiver

J4858C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X111 100M SFP LC FX Transceiver

J9054C

Cables

Multi-Mode Cables

HP .5m Multi-mode OM3 LC/LC FC Cable

AJ833A

HP 1m Multi-mode OM3 LC/LC FC Cable

AJ834A

HP 2 m Multimode OM3 LC/LC FC Cable

AJ835A

HP 5 m Multimode OM3 LC/LC FC Cable

AJ836A

HP 15 m Multimode OM3 LC/LC FC Cable

AJ837A

HP 30 m Multimode OM3 LC/LC FC Cable

AJ838A

HP 50 m Multimode OM3 LC/LC FC Cable

AJ839A

HP Premier Flex LC/LC OM4 2f 1m Cbl

QK732A

QuickSpecs

HP 1410 Switch series

Configuration

DA - 13674 North America — Version 12 — December 16, 2013

Page 4

HP Premier Flex LC/LC OM4 2f 2m Cbl

QK733A

HP Premier Flex LC/LC OM4 2f 5m Cbl

QK734A

HP Premier Flex LC/LC OM4 2f 15m Cbl

QK735A

HP Premier Flex LC/LC OM4 2f 30m Cbl

QK736A

HP Premier Flex LC/LC OM4 2f 50m Cbl

QK737A

QuickSpecs

HP 1410 Switch series

Configuration

DA - 13674 North America — Version 12 — December 16, 2013

Page 5

HP 1410-8G Switch

(J9559A)

I/O ports and slots

8 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or

full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type

1000BASE-T)

Supports a maximum of 8 autosensing 10/100/1000 ports

Physical characteristics

Dimensions

6.14(w) x 3.8(d) x 0.96(h) in (15.6 x 9.65 x 2.45 cm)

Weight

0.74 lb (0.34 kg)

Memory and processor

4 Kb EEPROM capacity; packet buffer size: 192 KB

Mounting

Wall, desktop, and under-table mounting

Performance

100 Mb Latency

< 3.6 µs (LIFO 64-byte packets)

1000 Mb Latency

< 1.2 µs (LIFO 64-byte packets)

Throughput

11.9 Mpps (64-byte packets)

Switching capacity

16 Gbps

MAC address table size

4096 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

41 BTU/hr (43.26 kJ/hr)

Voltage

100 - 240 VAC

Current

1.0 A

Maximum power rating

12 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

country option.

Safety

CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950-1

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 6

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF795E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF796E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR843E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR844E)

Installation with minimum configuration, system-based pricing (U4826E)

Installation with HP-provided configuration, system-based pricing (U4830E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR816E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR817E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR818E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR819E)

3 Yr 6 hr Call-to-Repair Onsite (UW386E)

4 Yr 6 hr Call-to-Repair Onsite (UW387E)

5 Yr 6 hr Call-to-Repair Onsite (UW388E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR845E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-16G Switch

(J9560A)

I/O ports and slots

16 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or

full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type

1000BASE-T)

Supports a maximum of 16 autosensing 10/100/1000 ports

Physical characteristics

Dimensions

8.21(w) x 4.41(d) x 1.73(h) in (20.85 x 11.2 x 4.4 cm) (1U height)

Weight

1.43 lb (0.65 kg)

Memory and processor

512 Kb flash; packet buffer size: 512 KB

Mounting

Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting

Performance

100 Mb Latency

< 8.0 µs (LIFO 64-byte packets)

1000 Mb Latency

< 3.6 µs (LIFO 64-byte packets)

Throughput

23.8 Mpps (64-byte packets)

Switching capacity

32 Gb/s

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 7

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

44 BTU/hr (46.42 kJ/hr)

Voltage

100 - 240 VAC

Current

1.1 A

Maximum power rating

13 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

country option.

Safety

CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 8

Installation with minimum configuration, system-based pricing (U4826E)

Installation with HP-provided configuration, system-based pricing (U4830E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level descriptions

and product numbers. For details about services and response times in your area, please contact your local

HP sales office.

HP 1410-24G-R Switch

(JG708A)

I/O ports and slots

24 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or

full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type

1000BASE-T)

Supports a maximum of 24 autosensing 10/100/1000 ports

Physical characteristics

Dimensions

17.32(w) x 6.81(d) x 1.73(h) in (44 x 17.3 x 4.4 cm) (1U height)

Weight

6.61 lb (3 kg)

Memory and processor

1 MB flash; packet buffer size: 512 KB

Mounting

Mounts in an EIA standard 19-inch telco rack (hardware included); desktop mounting

Performance

100 Mb Latency

< 8.0 µs (LIFO 64-byte packets)

1000 Mb Latency

< 3.6 µs (LIFO 64-byte packets)

Throughput

35.7 Mpps (64-byte packets)

Switching capacity

48 Gb/s

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

5% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

5% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 16,404 ft (5 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

55 BTU/hr (58 kJ/hr)

Voltage

100 - 240 VAC

Current

0.3 A

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 9

Maximum power rating

16 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged

in, and all modules populated.

This model provides internal power supply. Please select the correct power

cord country option.

Safety

CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Notes

IEEE 802.3az Energy Efficient Ethernet protocol is supported by the HP 1410-24G-R (JG708A), HP 1410-16

(J9662A) and HP 1410-24 (J9663A) Switches.

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

Installation with minimum configuration, system-based pricing (U4826E)

Installation with HP-provided configuration, system-based pricing (U4830E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-24G Switch

(J9561A)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 10

I/O ports and slots

22 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or

full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type

1000BASE-T)

2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type

10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab 1000BASE-T Gigabit Ethernet) or an open mini-

GBIC slot (for use with mini-GBIC transceivers)

Supports a maximum of 24 Gigabit Ethernet ports

Physical characteristics

Dimensions

13.23(w) x 6.65(d) x 1.73(h) in (33.6 x 16.9 x 4.4 cm) (1U height)

Weight

2.98 lb (1.35 kg)

Memory and processor

512 Kb flash; packet buffer size: 512 KB

Mounting

Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting

Performance

100 Mb Latency

< 8.0 µs (LIFO 64-byte packets)

1000 Mb Latency

< 3.6 µs (LIFO 64-byte packets)

Throughput

35.7 Kpps (64-byte packets)

Switching capacity

48 Gb/s

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

75 BTU/hr (79.13 kJ/hr)

Voltage

100 - 127 / 200 - 240 VAC

Current

0.3/0.2 A

Maximum power rating

22 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

This model provides internal power supply. Please select the correct power

cord country option.

Safety

CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 11

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Notes

Use only supported genuine HP mini-GBICs with your switch.

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

Installation with minimum configuration, system-based pricing (U4826E)

Installation with HP-provided configuration, system-based pricing (U4830E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-8 Switch

(J9661A)

I/O ports and slots

8 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX)

Supports a maximum of 8 autosensing 10/100 ports

Physical characteristics

Dimensions

6.14(w) x 3.74(d) x 0.97(h) in (15.6 x 9.5 x 2.46 cm)

Weight

0.74 lb (0.34 kg)

Memory and processor

16 Kb EEPROM; packet buffer size: 96 KB

Mounting

Wall, desktop, and under-table mounting

Performance

100 Mb Latency

< 3.7µs (LIFO 64-byte packets)

Throughput

1.1 Mpps (64-byte packets)

Switching capacity

1.6 Gb/s

MAC address table size

1024 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 12

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

13 BTU/hr (13.72 kJ/hr)

Voltage

100 - 240 VAC

DC voltage

12 V

Current

0.3 A

Maximum power rating

3.6 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

country option.

Safety

UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF795E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF796E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR843E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR844E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR817E)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 13

3 Yr 6 hr Call-to-Repair Onsite (UW386E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR845E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-16 Switch

(J9662A)

Ports

16 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX)

Supports a maximum of 16 autosensing 10/100 ports

Physical characteristics

Dimensions

8.21(w) x 4.21(d) x 1.73(h) in (20.85 x 10.69 x 4.39 cm) (1U height)

Weight

1.43 lb (0.65 kg)

Memory and processor

16 Kb EEPROM; packet buffer size: 2 Mb

Mounting

Mounts in an EIA standard 19-inch telco rack (hardware included); wall, desktop and under-table mounting

Performance

100 Mb Latency

< 10.6 µs (LIFO 64-byte packets)

Throughput

2.3 Mpps (64-byte packets)

Switching capacity

3.2 Gb/s

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

13 BTU/hr (13.72 kJ/hr)

Voltage

100 - 240 VAC

DC voltage

12 V

Current

0.3 A

Maximum power rating

3.6 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged

in, and all modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 14

country option.

Safety

UL 60950-1; CSA C22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Notes

IEEE 802.3az Energy Efficient Ethernet protocol is supported by the HP 1410-16 (J9662A) and HP 1410-24

(J9663A) Switches only

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-24 Switch

(J9663A)

I/O ports and slots

24 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX)

Supports a maximum of 24 autosensing 10/100 ports

Physical characteristics

Dimensions

13.23(w) x 6.65(d) x 1.73(h) in (33.6 x 16.89 x 4.39 cm) (1U height)

Weight

2.98 lb (1.35 kg)

Memory and processor

16 Kb EEPROM; packet buffer size: 2 Mb

Mounting

Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 15

Performance

100 Mb Latency

< 11 µs (LIFO 64-byte packets)

Throughput

3.5 Mpps (64-byte packets)

Switching capacity

4.8 Gb/s

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

17 BTU/hr (17.93 kJ/hr)

Voltage

100-240 VAC

DC voltage

12 V

Current

0.4 A

Maximum power rating

4.8 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

country option.

Safety

UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 16

Flicker

IEC 61000-3-3

Notes

IEEE 802.3az Energy Efficient Ethernet protocol is supported by the HP 1410-24G-R (JG708A), HP 1410-16

(J9662A) and HP 1410-24 (J9663A) Switches.

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-24-R Switch

(JD986B)

I/O ports and slots

24 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX)

Supports a maximum of 24 autosensing 10/100 ports

Physical characteristics

Dimensions

17.32(w) x 6.81(d) x 1.73(h) in (44 x 17.3 x 4.4 cm)

Weight

4.41 lb (2.0 kg)

Memory and processor

8kb EEPROM; packet buffer size: 2 Mb

Mounting

Mounts in an EIA standard 19-inch telco rack (hardware included); desktop mounting

Performance

100 Mb Latency

< 11 µs (LIFO 64-byte packets)

Throughput

3.5 Mpps (64-byte packets)

Switching capacity

4.8 Gb/s

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

5% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 16,404 ft (5 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

21 BTU/hr (22 kJ/hr)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 17

Voltage

100 - 240 VAC

DC voltage

3.3 V

Current

1.1 A

Maximum power rating

3.6 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged

in, and all modules populated.

This model provides an internal power supply. Please select the correct power

cord country option.

Safety

UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-24-2G Switch

(J9664A)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 18

I/O ports and slots

24 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX)

2 RJ-45 autosensing 10/100/1000 ports; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full

only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)

Supports a maximum of 24 autosensing 10/100 ports plus 2 autosensing 10/100/1000 ports

Physical characteristics

Dimensions

13.23(w) x 6.65(d) x 1.73(h) in (33.6 x 16.89 x 4.39 cm) (1U height)

Weight

2.98 lb (1.35 kg)

Memory and processor

2 Kb EEPROM; packet buffer size: 2.5 Mb

Mounting

Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting

Performance

100 Mb Latency

< 5.6 µs (LIFO 64-byte packets)

1000 Mb Latency

< 2.2 µs (LIFO 64-byte packets)

Throughput

6.5 Mpps (64-byte packets)

Switching capacity

8.8 Gb/s

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

37 BTU/hr (39.03 kJ/hr)

Voltage

100 - 240 VAC

DC voltage

12 V

Current

0.9 A

Maximum power rating

10.8 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

country option.

Safety

UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 19

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

Standards and protocols

(applies to all products in

series)

General protocols

IEEE 802.1p Priority

IEEE 802.3ab 1000BASE-T Gigabit Ethernet over twisted pair (10/100/1000 models only)

IEEE 802.3i 10BASE-T Ethernet over twisted pair

IEEE 802.3u 100BASE-TX Fast Ethernet, 100BASE-FX with autonegotiation

IEEE 802.3x Flow Control

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 North America — Version 12 — December 16, 2013

Page 20

HP 1410 Switch series

accessories

Cables

HP 0.5 m Multimode OM3 LC/LC Optical Cable

AJ833A

HP 1 m Multimode OM3 LC/LC Optical Cable

AJ834A

HP 2 m Multimode OM3 LC/LC Optical Cable

AJ835A

HP 5 m Multimode OM3 LC/LC Optical Cable

AJ836A

HP 15 m Multimode OM3 LC/LC Optical Cable

AJ837A

HP 30 m Multimode OM3 LC/LC Optical Cable

AJ838A

HP 50 m Multimode OM3 LC/LC Optical Cable

AJ839A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

HP 1410-24G Switch (J9561A)

HP X121 1G SFP LC SX Transceiver

J4858C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X111 100M SFP LC FX Transceiver

J9054C

QuickSpecs

HP 1410 Switch series

Accessories

DA - 13674 North America — Version 12 — December 16, 2013

Page 21

NOTE:

Details are not available for all accessories. The following specifications were available at the time of publication.

HP 0.5 m Multimode OM3

LC/LC Optical Cable

(AJ833A)

Cabling

Cable type

:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of

up to 300 m

Maximum distance

:

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end

and LC duplex connectors on other end.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: 600 / 600 meters @850/1300nm

for Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber and designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 22

HP 1 m Multimode OM3

LC/LC Optical Cable

(AJ834A)

Cabling

Cable type

:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of

up to 300 m

Maximum distance

:

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end

and LC duplex connectors on other end.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 23

HP 2 m Multimode OM3

LC/LC Optical Cable

(AJ835A)

Cabling

Cable type

:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of

up to 300 m;

Maximum distance

:

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end

and LC duplex connectors on other end.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 24

HP 5 m Multimode OM3

LC/LC Optical Cable

(AJ836A)

Cabling

Cable type

:

50/125 µm core/cladding) diameter, mulitimode fiber optic, with effective

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of

up to 300 m;

Maximum distance

:

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: This specification defines the detail requirements for a tight

buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and

Ethernet assembly with LC duplex connectors on one end and LC duplex

connectors on other end.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 25

HP 15 m Multimode OM3

LC/LC Optical Cable

(AJ837A)

Cabling

Cable type

:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of

up to 300 m;

Maximum distance

:

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end

and LC duplex connectors on other end.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 26

HP 30 m Multimode OM3

LC/LC Optical Cable

(AJ838A)

Cabling

Cable type

:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of

up to 300 m;

Maximum distance

:

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end

and LC duplex connectors on other end.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 27

HP 50 m Multimode OM3

LC/LC Optical Cable

(AJ839A)

Cabling

Cable type

:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of

up to 300 m;

Maximum distance

:

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end

and LC duplex connectors on other end.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 28

HP Premier Flex LC/LC

Multi-mode OM4 2 fiber

1m Cable (QK732A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um

duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core Diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type

OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white

stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added

for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @

23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

HP Premier Flex LC/LC

Multi-mode OM4 2 fiber

2m Cable (QK733A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um

duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type

OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white

stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added

for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @

23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 29

HP Premier Flex LC/LC

Multi-mode OM4 2 fiber

5m Cable (QK734A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um

duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type

OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white

stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added

for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @

23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

HP Premier Flex LC/LC

Multi-mode OM4 2 fiber

15m Cable

(QK735A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um

duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type

OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white

stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added

for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @

23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 30

HP Premier Flex LC/LC

Multi-mode OM4 2 fiber

30m Cable

(QK736A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um

duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type

OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white

stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added

for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @

23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

HP Premier Flex LC/LC

Multi-mode OM4 2 fiber

50m Cable

(QK737A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um

duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type

OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white

stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added

for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @

23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 31

HP X121 1G SFP LC SX

Transceiver

(J4858C)

A small form-factor

pluggable (SFP) Gigabit SX

transceiver that provides a

full-duplex Gigabit solution

up to 550 m on multimode

fiber.

Ports

1 LC 1000BASE-SX port; Duplex: full only

Physical characteristics

Dimensions: 2.24(d) x 0.54(w) x 0.48(h) in. (5.69 x 1.37 x 1.22 cm)

Weight: 0.04 lb. (0.02 kg)

Transceiver form factor: SFP

Environment

Operating temperature: 32°F to 158°F (0°C to 70°C)

Operating relative humidity: 5% to 85%, noncondensing

Nonoperating/Storage temperature: -40°F to 203°F (-40°C to 85°C)

Altitude: up to 10,000 ft. (3 km)

Electrical characteristics

Power consumption typical: 0.4 W

Power consumption maximum: 0.7 W

Cabling

Type:

62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low

metal content, multimode fiber optic, complying with ITU-T G.651 and

ISO/IEC 793-2 Type A1b or A1a, respectively;

Maximum distance:

2-220 m (62.5 µm core diameter, 160 MHz*km bandwidth

2-275 m (62.5 µm core diameter, 200 MHz*km bandwidth

2-500 m (50 µm core diameter, 400 MHz*km bandwidth)

2-550 m (50 µm core diameter, 500 MHz*km bandwidth)

Cable length: 2-550m

Fiber type: Multi Mode

Services

Refer to the HP website at

www.hp.com/networking/services

for details on the

service-level descriptions and product numbers. For details about services and

response times in your area, please contact your local HP sales office.

HP X121 1G SFP LC LX

Transceiver

(J4859C)

HP X121 1G SFP LC LX

Transceiver: An SFP format

gigabit transceiver with LC

connectors using LX

technology.

Ports

1 LC 1000BASE-LX port (IEEE 802.3z Type 1000BASE-LX); Duplex: full only

Physical characteristics

Dimensions: 2.24(d) x 0.54(w) x 0.486(h) in. (5.69 x 1.37 x 1.23 cm)

Weight:0.04 lb. (0.02 kg)

Environment

Operating temperature: 32°F to 158°F (0°C to 70°C)

Operating relative humidity: 0% to 85%, noncondensing

Nonoperating/Storage temperature: -40°F to 212°F (-40°C to 100°C)

Altitude: up to 10,000 ft. (3 km)

Cabling

Type:

Either single mode or multimode; 62.5/125 µm or 50/125 µm

(core/cladding) diameter, graded-index, low metal content, multimode

fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2 Type A1b or

A1a, respectively; Low metal content, single-mode fiber-optic,

complying with ITU-T G.652 and ISO/IEC 793-2 Type B1;

Maximum distance:

2-550 m (multimode 62.5 µm core diameter, 500 MHz*km bandwidth)

2-550 m (multimode 50 µm core diameter, 400 MHz*km bandwidth)

2-550 m (multimode 50 µm core diameter, 500 MHz*km bandwidth)

2-10,000 m (single-mode fiber)

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 32

Notes

A mode conditioning patch cord may be needed in some multimode fiber

installations.

Wavelength: 1310nm

Power Consumption: < 500mW Typical

Services

Refer to the HP website at

www.hp.com/networking/services

for details on the

service-level descriptions and product numbers. For details about services and

response times in your area, please contact your local HP sales office.

HP X111 100M SFP LC FX

Transceiver

(J9054C)

Ports

1 LC 100BASE-FX port (IEEE 802.3u Type 100BASE-FX); Duplex: half or full

Physical characteristics

Dimensions

2.7(d) x 0.54(w) x 0.48(h) in. (6.86 x 1.38 x 1.22

cm)

Weight

0.06 lb. (0.03 kg)

Environment

Operating temperature

32°F to 158°F (0°C to 70°C)

Operating relative

humidity

5% to 95%

Nonoperating/Storage

temperature

-40°F to 185°F (-40°C to 85°C)

Nonoperating/Storage

relative humidity

5% to 85%

Altitude

up to 10,000 ft. (3 km)

Cabling

Cable type:

62.5/125 ìm or 50/125 ìm (core/cladding) diameter, graded-index, low metal

content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2

Type A1b or A1a, respectively;

Maximum distance:

• 2 km (full duplex) or 412 m (half duplex)

Notes

Transmitter wavelength: 1310nm

Power consumption is 1.1 watt maximum.

For supported platforms and minimum software requirements to support this

product, see the document titled "Support for the J9054B 100-FX SFP-LC

Transceiver" on the "ProCurve Mini-GBICs and SFPs" Manuals Web page.

Services

Refer to the HP website at:

www.hp.com/networking/services

for details on

the service-level descriptions and product numbers. For details about services

and response times in your area, please contact your local HP sales office.

To learn more, visit:

www.hp.com/networking

© Copyright 2010-2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without

notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products

and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial

errors or omissions contained herein.

QuickSpecs

HP 1410 Switch series

Accessory Product Details

DA - 13674 North America — Version 12 — December 16, 2013

Page 33
