HP-UX Kernel Cryptographic Module 1.0
User Guide
Abstract
This document describes how to install, configure, and troubleshoot HPUX-KCM on HP-UX 11i v3 platforms. It is intended for
system and network administrators who have knowledge of operating system concepts, commands, and configuration.
HP Part Number: 5900-3288
Published: October 2013
Edition: 1
© Copyright 2013 Hewlett-Packard Development Company, L.P.
Confidential computer software. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211 and 12.212, Commercial
Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under
vendor's standard commercial license.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
UNIX is a registered trademark of The Open Group.
![](asset-3.png)
Contents
1 Overview..................................................................................................4
Supported configuration............................................................................................................4
Features provided in this release.................................................................................................4
PKCS #11 API considerations ....................................................................................................5
2 Installing HP-UX KCM..................................................................................9
3 Configuring HP-UX KCM............................................................................10
4 Troubleshooting........................................................................................11
5 Removing HP-UX KCM...............................................................................12
6 Support and other resources......................................................................13
Information to collect before contacting HP.................................................................................13
How to contact HP..................................................................................................................13
Documentation feedback.........................................................................................................13
Typographic conventions.........................................................................................................14
Index.........................................................................................................15
Glossary....................................................................................................16
Contents 3
![](asset-4.png)
1 Overview
The HP-UX Kernel Cryptographic Module ( HP-UX KCM ) is a common cryptographic library in
HP-UX Kernel. It is a library of core cryptographic algorithms, which are used by HP-UX Kernel
products.
HP-UX KCM implements FIPS 140-2 compliant algorithms for commonly used cryptographic
operations such as data encryption/decryption, sign/verify, digest, HMAC, and random number
generation.
HP-UX KCM is available in HP-UX Kernel as a dynamically loadable library with well-defined
interfaces to invoke the crypto functions. This helps to bring modularity and standardization in the
usage of crypto algorithms across the HP-UX Kernel products. HP-UX KCM is available on HP
Integrity platform running HP-UX 11iv3.
HP-UX KCM is undergoing FIPS 140-2 Level 1 validation and is currently in NIST Review Pending
state.
The interfaces supported by the library follows RSA Security Inc. PKCS#11 V.2.20 specification.
For more information on PKCS, see PKCS #11 v2.20: Cryptographic Token Interface Standard
document.
NOTE: This link will take you outside the Hewlett-Packard (HP) Web site. HP does not control
and is not responsible for information outside of HP.com.
Supported configuration
The supported configuration for HPUX-KCM is HP-UX 11i v3 for HP Integrity Servers.
Features provided in this release
This section discusses the new features available in the HP-UX KCM version 1.0.
The table below lists the FIPS 140-2 compliant algorithms, key lengths, modes, and operations
implemented by HP-UX KCM 1.0.
PurposeOperationsKey sizeFIPS algo
Symmetric key operations (FIPS-197
compliant)
Generate, Encrypt, and
Decrypt
128, 192, and 256
Mode: CBC
AES
Asymmetric key operationsGenerate key pair, Sign,
Verify, Wrap key, and
Unwrap key
2048RSA
(FIPS 186-3 and PKCS#1 v1.5 compliant)
Digest operations (FIPS 180-3 compliant)Digest256, 384, and 512SHA-2
Key-Hash Message Authentication Code
(HMAC)
Digest (with key)256, 384, and 512HMAC-SHA2
NIST SP800-90A compliant DRBGGenerate randomRNG
HP-UX KCM also implements the following algorithms, which are required for supportability purposes
even though they are not FIPS 140-2 compliant.
PurposeOperationsKey sizeNon FIPS algo
Symmetric key operationsGenerate, Encrypt, and
Decrypt
128, 192, and 256
Mode: CFB
AES
4 Overview
![](asset-5.png)
Asymmetric key operationsGenerate key pair, Sign,
Verify, Wrap key, and
Unwrap key
1024 and 1536RSA
Digest operationsDigest160SHA-1
Key-Hash Message Authentication Code
(HMAC)
Digest (with key)160HMAC-SHA1
The interfaces supported by the library follows RSA Security Inc. PKCS#11 V.2.20 specification.
For more information see, PKCS#11 specifications document.
PKCS #11 API considerations
Following are the API considerations for PKCS#11:
•In PKCS#11 terminology, KCM is a soft token used for software implementation. Hardware
related functions, data types, and features are not implemented by default.
•There is only one conceptual slot with slotID=0 and conceptual token is assumed to be present
in the slot.
•KCM does not store public or private token objects such as keys/certificates. Following are
the ramifications of this consideration:
◦KCM does not implement PIN related functions or functions that require PIN (For example,
C_Login) specified by PKCS#11.
◦Session type will be R/W user functions by default. There is no distinction between R/O
and R/W session types.
◦No distinction is made between user session and SO session. The user is considered as
logged in by default at the point of opening a session and logged out when the session
is closed.
•KCM implements CK_RV type functions and does not support CK_NOTIFY type. Hence it does
not support callback functions and events.
•Multiple thread access to a single PKCS#11 session is not supported.
•There will be limited support for objects and object related functions as per the scope of APIs
implemented by KCM. They are used only to invoke KCM supported PKCS#11 functions and
retrieve the data returned by functions.
KCM supports the following objects:
◦Data objects – CKO_DATA
◦Key objects - CKO_PUBLIC_KEY, CKO_PRIVATE_KEY, CKO_SECRET_KEY
•Table 1 (page 5) describes the mechanisms supported by HPUX-KCM.
Table 1 Mechanisms supported by HPUX-KCM
FunctionsMechanism
DeriveWrap
and
Unwrap
Gen Key or
Key Pair
DigestSR and
VR1
Sign
and
Verify
Encrypt
and
Decrypt
√CKM_RSA_PKCS_KEY_PAIR_GEN
√√√CKM_RSA_PKCS
√CKM_SHA256_RSA_PKCS
√CKM_SHA384_RSA_PKCS
PKCS #11 API considerations 5
![](asset-6.png)
Table 1 Mechanisms supported by HPUX-KCM (continued)
FunctionsMechanism
√CKM_SHA512_RSA_PKCS
√CKM_AES_KEY_GEN
√CKM_AES_CBC
√CKM_SHA_1
√CKM_SHA256
√CKM_SHA384
√CKM_SHA512
√CKM_SHA_1_HMAC
√CKM_SHA256_HMAC
√CKM_SHA384_HMAC
√CKM_SHA512_HMAC
•HPUX-KCM implements the following PKCS#11 APIs, which are relevant for the cryptographic
functions supported by KCM. Table 2 (page 6) lists the functions supported by KCM.
Table 2 Functions supported by HPUX-KCM
DescriptionFunctionCategory
Initializes CryptokiC_InitializeGeneral purpose functions
Clean up miscellaneous
Cryptoki-associated resources
C_Finalize
Obtains general information about
Cryptoki
C_GetInfo
Obtains entry points of Cryptoki library
functions
C_GetFunctionList
Obtains a list of slots in the systemC_GetSlotListSlot and token management
functions Obtains information about a particular
slot
C_GetSlotInfo
Obtains information about a particular
token
C_GetTokenInfo
Obtains a list of mechanisms supported
by a token
C_GetMechanismList
Obtains information about a particular
mechanism
C_GetMechanismInfo
Opens a connection between an
application and a particular token or
C_OpenSessionSession management functions
sets up an application callback for token
insertion
Closes a sessionC_CloseSession
Obtains information about the sessionC_GetSessionInfo
Creates an objectC_CreateObjectObject management functions
Destroys an objectC_DestroyObject
Initializes an encryption operationC_EncryptInitEncryption functions
6 Overview
![](asset-7.png)
Table 2 Functions supported by HPUX-KCM (continued)
DescriptionFunctionCategory
Encrypts single-part dataC_Encrypt
Continues a multiple-part encryption
operation
C_EncryptUpdate
Finishes a multiple-part encryption
operation
C_EncryptFinal
Initializes a decryption operationC_DecryptInitDecryption functions
Decrypts single-part encrypted dataC_Decrypt
Continues a multiple-part decryption
operation
C_DecryptUpdate
Finishes a multiple-part decryption
operation
C_DecryptFinal
Initializes a message-digesting operationC_DigestInitMessage digesting functions
Digests single-part dataC_Digest
Continues a multiple-part digesting
operation
C_DigestUpdate
Finishes a multiple-part digesting
operation
C_DigestFinal
Initializes a signature operationC_SignInitSigning and MACing functions
Signs single-part dataC_Sign
Continues a multiple-part signature
operation
C_SignUpdate
Finishes a multiple-part signature
operation
C_SignFinal
Initializes a verification operationC_VerifyInitFunctions for verifying
signatures and MACs Verifies a signature on single-part dataC_Verify
Continues a multiple-part verification
operation
C_VerifyUpdate
Finishes a multiple-part verification
operation
C_VerifyFinal
Generates a secret keyC_GenerateKeyKey management functions
Generates a public-key/private-key pairC_GenerateKeyPair
Wraps (encrypts) a keyC_WrapKey
Unwraps (decrypts) a keyC_UnwrapKey
Generates random dataC_GenerateRandomRandom number generation
functions
For more information on APIs, see PKCS#11 specifications document.
Example usage of HPUX-KCM
// pkcs11 header files
#include "pkcs11_kcm.h"
#include "pkcs11.h"
// Initialize the module. Required only once during lifetime of the application
CK_RV rv = C_Initialize( NULL_PTR );
PKCS #11 API considerations 7
// Open session. Required for every crypto operation
CK_SESSION_HANDLE hSession;
rv = C_OpenSession( 0, 0, NULL, NULL, );
// Set mechanism – type of crypto operation
CK_MECHANISM digestMechanism = { 0, NULL, 0 };
digestMechanism.mechanism = CKM_SHA256;
// Initialize crypto operation
rv = C_DigestInit( hSession, );
// prepare input and output buffers
uint8_t input[] = {'a', 'b', 'c'};
uint8_t digest[64];
uint32_t inputlen = sizeof( input );
uint64_t digestlen = sizeof( digest )
// Invoke crypto operation
rv = C_Digest( hSession, input, inputlen, digest, );
// Close crypto session
rv = C_CloseSession( hSession )
// Call this at the end of all crypto operations
rv = C_Finalize( NULL_PTR );
8 Overview
![](asset-9.png)
2 Installing HP-UX KCM
This chapter discusses the installation procedure for HPUX-KCM.
IMPORTANT: HP-UX KCM 1.0 requires approximately 1.5 MB of disk space after installation.
To install HP-UX KCM:
1. Log in as root.
2. Download HPUX-KCM from the HP Software Depot.
3. Save the HPUX-KCM depot as a local file on the target system.
For example:
in </tmp/HPUX-KCM>.depot
4. Verify the depot file on your system using the following command:
$ swlist -d @/tmp/HPUX-KCM.depot
5. If the HPUX-KCM depot file is correctly stored on the system, a message similar to the following
is displayed after executing the command:
# swlist -d @/tmp/HPUX-KCM.depot
# Initializing...
# Contacting target "my_host"...
#
# Target: my_host:/tmp/HPUX-KCM.depot
#
#
# Bundle(s):
#
HPUX-KCM A.01.00.00 HP-UX Kernel Cryptographic Module
6. Install HPUX-KCM using an interactive swinstall session or the following swinstall
command:
$ swinstall -s /tmp/HPUX-KCM.depot HPUX-KCM
The swinstall utility will install the HPUX-KCM components.
7. Verify the installation using the following command:
$ swverify HPUX-KCM
If HPUX-KCM is installed correctly on the system, the swverify command will include the
following text in the data it reports:
* Verification succeeded
9
![](asset-a.png)
3 Configuring HP-UX KCM
The products integrated with HP-UX KCM must define the install-time and run-time dependency on
HP-UX KCM. This helps to install and load KCM automatically along with the product dependent
on HP-UX KCM.
NOTE:
•Before loading HPUX-KCM modules, ensure that /stand/current/mod and /etc directories
are accessible.
•HPUX-KCM modules cannot be loaded as a static module as this is not a valid FIPS mode of
operation.
•In case a Kernel configuration containing KCM modules are saved (by using kconfig –s
), before loading the saved Kernel configuration, ensure that the KCM versions are consistent.
For example, HPUX-KCM 1.0 is installed in a system and the Kernel configuration is saved
as ‘backup’. Later KCM is upgraded to 2.0 on the same system. If for some reason, the
‘backup’ Kernel configuration is rebooted, then this leads to an inconsistent state as ‘backup’
contains HPUX-KCM 1.0, whereas the current installed version of HPUX-KCM is 2.0.
An example of defining dependency on HPUX-KCM is given below:
Install-time dependency:
myproduct.psf:
vendor
bundle
product
fileset
corequisites.HPUX-KCM.KCM.KCM-LIB,r>=A.01.00.00
end
end
Run-time dependency:
myproduct.modmeta:
module myproduct {
. . .
. . .
dependency libkcm_pkcs11
. . .
}
10 Configuring HP-UX KCM
![](asset-b.png)
4 Troubleshooting
This chapter explains some of the problem scenarios that you might encounter while working with
the HP-UX KCM.
General guidelines to troubleshoot HPUX-KCM
At the time of this release there are no issues reported with HPUX-KCM.
If any error occurs, HPUX-KCM logs the message into the syslog file. All the log messages by
HPUX-KCM are prefixed with either libkcm_core> or libkcm_pkcs11> or libkcm_nonfips>.
To verify the errors reported by HPUX-KCM, run the command:
grep libkcm_ /var/adm/syslog/syslog.log
11
![](asset-c.png)
5 Removing HP-UX KCM
This chapter discusses the procedure to remove HP-UX KCM.
To remove HPUX-KCM:
1. Verify whether HPUX-KCM is already installed by running the following command:
swlist –l bundle | grep –i kcm
If HPUX-KCM is already installed on the system, a message similar to the following is displayed:
HPUX-KCM A.01.00.00 HP-UX Kernel Cryptographic Module
2. Remove HPUX-KCM by running the following command:
swremove HPUX-KCM
12 Removing HP-UX KCM
![](asset-d.png)
6 Support and other resources
Information to collect before contacting HP
Be sure to have the following information available before you contact HP:
•Software product name
•Hardware product model number
•Operating system type and version
•Applicable error message
•Third-party hardware or software
•Technical support registration number (if applicable)
How to contact HP
Use the following methods to contact HP technical support:
•See the Contact HP worldwide website
•Use the GET HELP FROM HP link on the
HP Support Center website.
•In the United States, call +1 800 334 5144 to contact HP by telephone. This service is available
24 hours a day, 7 days a week. For continuous quality improvement, conversations might be
recorded or monitored.
Documentation feedback
HP welcomes your feedback. To make comments and suggestions about product documentation,
send a message to:
docsfeedback@hp.com
Include the document title and part number in your message. All submissions become the property
of HP.
Information to collect before contacting HP 13
Typographic conventions
The following conventions are used in this document:
Book title The title of a book. On the web, this can be a hyperlink to the book itself.
Command A command name or command phrase, for example ls -a.
[ ] Optional content in syntax.
{ } Required content in syntax.
| Character that separates items in a list of choices.
... Indication that the preceding element can be repeated one or more times.
WARNING An alert that calls attention to important information that if not understood or
followed can result in personal injury.
CAUTION An alert that calls attention to important information that if not understood or
followed can result in data loss, data corruption, or damage to hardware or
software.
IMPORTANT An alert that calls attention to essential information.
NOTE An alert that contains additional or supplementary information.
14 Support and other resources
![](asset-10.png)
Glossary
HP-UX Kernel
Cryptographic
Module (HP-UX
KCM)
Public-Key
Cryptography
Standards (PKCS)
SO: A Security
Officer user.
SR: Sign Recover
VR: Verify Recover
16 Glossary
