USB-Adapter2000
Quick Guide
USB-Adapter2000 Quick Guide
Issue: 01
Part Number: 31507680
Date: 2016-04-28
1 Overview
The USB-Adapter2000 is a module whose Bluetooth function is expanded over a USB port.
SUN2000 APP connects to a device over the USB-Adapter2000 that applies to all models
of SUN2000s.
2 Description for Use
Before using the USB-Adapter2000, ensure that the device connecting to it has
been powered on.
When you use the USB-Adapter2000 to implement the communication between
SUN2000 APP and the device, ensure that one mobile phone connects to only
one device.
Access Huawei APP store (http://appstore.huawei.com) or Google Play
( https://play.google.com), search for SUN2000, and download the SUN2000
APP software package.
When the SUN2000 APP connects to the USB-Adapter2000, USB-Adapter2000
name is displayed as HWAPPXXXXXXXX, where XXXXXXXX indicates the latter
8 digits of the USB-Adapter2000 SN.
After the USB-Adapter2000 connects to the device, see the SUN2000 APP User
Manual for details about how to operate the device.
1. Insert the USB-Adapter2000 into the USB port of the device.
2. Enable Bluetooth on the mobile phone.
3. Run SUN2000 APP.
4. Choose Select Connection Mode > Bluetooth connection.
5. Tap Search for Device, select the Bluetooth module name and connect the APP to
the USB-Adapter2000.
3 Operating Environment
Item
Range
Item
Range
Operating temperature range
–40ºC to +65ºC
Operating humidity
5%–95%
Storage temperature range
–40ºC to +80ºC
Altitude
0–4000 m
Operating temperature range
–40ºC to +80ºC
N/A
N/A
4 Performance Specifications
Item
Specifications
Item
Specifications
Product model
USB-Adapter2000-B
Bluetooth
standard
4.0LE+EDR
Dimensions
30 mm x 14 mm x 94 mm
External port
USB Type A
Weight
20 g
Protection level
IP20
Port type
USB2.0
Environmental
protection
RoHS5
Installation mode
Pluggable
Storage
environment
Dry and well-ventilated
environment without
corrosive gas
Transmission
distance (no barrier)
10 m
Certification
Complies with CE, FCC,
TELEC, BQB, and VCCI
Plastic material
PC+ABS (30%)
5 Certification Declaration
Hereby, Huawei Technologies Co., Ltd., declares that this device is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
1. This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
2. This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
3. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE
CE
FCC
CAUTION
