Quick Start Guide
ALP-L09
ALP-L29
TUV SUD
![](/img.php?id=3604491&img=bg2.png)
Your device at a glance
Before you start, let's take a look at your new device.
lTo power on your device, press and hold the power
button until the screen turns on.
lTo power off your device, press and hold the power
button, and then touch .
NFC
1
2
3
4
5
6
7
89
10
18
17
16
15
14
13
12
11
Secondary
microphone
Dual-tone ash
Optical proximity
sensor
Card slot
Status indicator Fingerprint scanner
Primary microphone 2
8
USB-C port
Primary microphone 1 Speaker
Power button Volume button
Earpiece Front camera
Dual-lens camera Laser sensor
Headset jack Infrared sensor
lTo force your device to restart, press and hold the
power button until your device vibrates.
1
TUV SUD
![](/img.php?id=3604491&img=bg3.png)
Getting Started
Follow the instructions in the following gures to set up
your device.
/BOP4*.
NJDSP4%
ALP-L09
/BOP4*.
/BOP4*.
/BOP4*.
or
NJDSP4%
ALP-L29
lDo not insert or remove the SIM card when your
device is powered on.
lEnsure that the card is correctly aligned and that the
card tray is level when you insert it into your device.
Be careful not to scratch your device or hurt yourself
when using the eject pin. Store the eject pin out of the
reach of children to prevent accidental swallowing or
injury.
Do not use cut or modied SIM or microSD cards with
your device as these may not be recognized and could
damage the card tray(slot).
2
TUV SUD
Dual card dual standby single
pass (only applies to ALP-L29)
Your device supports only dual card dual standby single
pass, which means you cannot use both SIM cards for calls
or data services simultaneously.
lWhen you are on a call using SIM card 1, SIM card 2
cannot be used to make or answer calls. If someone calls
SIM card 2, the caller will hear a voice message similar to
"The subscriber you dialed is out of the service area" or
"The subscriber you dialed cannot be connected for the
moment, please try again later." The actual message will
vary by service provider.
lWhen you are using SIM card 1's data service, SIM card
2's data service will be disabled.
Your device's single pass feature helps reduce power
consumption and increase your device's standby time. It is
not related to your service provider's network conditions.
It may be a good idea to contact your service provider and
subscribe to missed call reminder and related assistance
services to avoid the conicts mentioned above.
3
TUV SUD
![](/img.php?id=3604491&img=bg5.png)
For more information
If you encounter any problems while using your device, you
can obtain help from the following resources:
lVisit http://consumer.huawei.com/en/ to download user
guides, view frequently asked questions and other
information.
lVisit http://consumer.huawei.com/en/support/ for the
most up-to-date contact information for your country or
region.
Go to Settings and touch System > About phone >
Legal to view legal information for your product.
Go to Settings and touch System > About phone >
Legal > Safety information to view safety information for
your product.
Go to Settings and touch System > About phone >
Authentication info to view regulatory information for
your product.
Go to Settings and touch System > Certication logos
to view more information on certication logos for your
product.
All pictures and illustrations in this guide, including but
not limited to the product color, size, and display
content, are for your reference only. The actual
product may vary. Nothing in this guide constitutes a
warranty of any kind, express or implied.
4
TUV SUD
![](/img.php?id=3604491&img=bg6.png)
Safety Information
Please read all of the safety information carefully before
using your device to ensure its safe and proper operation
and to learn how to dispose of your device properly.
Operation and safety
l To prevent possible hearing damage, do not
listen at high volume levels for long periods.
lUsing an unapproved or incompatible power adapter,
charger, or battery may damage your device, shorten its
lifespan, or cause a re, explosion, or other hazards.
lIdeal operating temperatures are 0 °C to 35 °C. Ideal
storage temperatures are -20 °C to +45 °C.
lPacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If using a pacemaker, hold the device on the
side opposite the pacemaker and do not carry the device
in your front pocket.
lKeep the device and the battery away from excessive
heat and direct sunlight. Do not place them on or in
heating devices, such as microwave ovens, stoves, or
radiators.
lObserve local laws and regulations while using the
device. To reduce the risk of accidents, do not use your
wireless device while driving.
lWhile ying in an aircraft or immediately before
boarding, only use your device according to instructions
provided. Use of a wireless device in an aircraft may
disrupt wireless networks, present a hazard to aircraft
operation, or be illegal.
lTo prevent damage to your device's parts or internal
circuits, do not use it in dusty, smoky, damp, or dirty
environments or near magnetic elds.
5
TUV SUD
![](/img.php?id=3604491&img=bg7.png)
lWhen charging the device, make sure the power adapter
is plugged into a socket near the devices and is easily
accessible.
lUnplug the charger from electrical outlets and the device
when not in use.
lDo not use, store or transport the device where
ammables or explosives are stored (in a gas station, oil
depot, or chemical plant, for example). Using your device
in these environments increases the risk of explosion or
re.
lDispose of this device, the battery, and accessories
according to local regulations. They should not be
disposed of in normal household waste. Improper
battery use may lead to re, explosion, or other hazards.
Disposal and recycling information
The crossed-out wheeled-bin symbol on your product,
battery, literature or packaging reminds you that all
electronic products and batteries must be taken to separate
waste collection points at the end of their working lives;
they must not be disposed of in the normal waste stream
with household garbage. It is the responsibility of the user
to dispose of the equipment using a designated collection
point or service for separate recycling of waste electrical
and electronic equipment (WEEE) and batteries according
to local laws.
Proper collection and recycling of your equipment helps
ensure electrical and electronic equipment (EEE) waste is
recycled in a manner that conserves valuable materials and
protects human health and the environment, improper
handling, accidental breakage, damage, and/or improper
recycling at the end of its life may be harmful for health
and environment. For more information about where and
how to drop off your EEE waste, please contact your local
authorities, retailer or household waste disposal service or
visit the website http://consumer.huawei.com/en/.
6
TUV SUD
![](/img.php?id=3604491&img=bg8.png)
Reduction of hazardous substances
This device and its electrical accessories are compliant with
local applicable rules on the restriction of the use of certain
hazardous substances in electrical and electronic
equipment, such as EU REACH, RoHS and Batteries (where
included) regulations. For declarations of conformity about
REACH and RoHS, please visit our web site http://
consumer.huawei.com/certication.
EU regulatory conformance
Body worn operation
The device complies with RF specications when used near
your ear or at a distance of 0.50 cm from your body. Ensure
that the device accessories, such as a device case and
device holster, are not composed of metal components.
Keep the device away from your body to meet the distance
requirement.
The highest SAR value reported for this device type when
tested at the ear is
ALP-L09 0.99 W/kg
ALP-L29 0.99 W/kg
And when properly worn on the body is
ALP-L09 1.29 W/kg
ALP-L29 1.29 W/kg
Statement
Hereby, Huawei Technologies Co., Ltd. declares that this
device is in compliance with the essential requirements and
other relevant provisions of Directive 2014/53/EU.
The most recent and valid version of the DoC (Declaration
of Conformity) can be viewed at http://
consumer.huawei.com/certication.
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is
used.
This device may be restricted for use, depending on the
local network.
Restrictions in the 2.4 GHz band:
7
TUV SUD
Norway: This subsection does not apply for the
geographical area within a radius of 20 km from the centre
of Ny-Ålesund.
Restrictions in the 5 GHz band:
According to Article 10 (10) of Directive 2014/53/EU, the
packaging shows that this radio equipment will be subject
to some restrictions when placed on the market in Belgium
(BE), Bulgaria (BG), the Czech Republic (CZ), Denmark (DK),
Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain
(ES), France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia
(LV), Lithuania (LT), Luxembourg (LU), Hungary (HU), Malta
(MT), Netherlands (NL), Austria (AT), Poland (PL), Portugal
(PT), Romania (RO), Slovenia (SI), Slovakia (SK), Finland (FI),
Sweden (SE), the United Kingdom (UK), Turkey (TR),
Norway (NO), Switzerland (CH), Iceland (IS), and
Liechtenstein (LI).
The WLAN function for this device is restricted to indoor
use only when operating in the 5150 to 5350 MHz
frequency range.
Frequency Bands and Power
(a) Frequency bands in which the radio equipment
operates: Some bands may not be available in all countries
or all areas. Please contact the local carrier for more details.
(b) Maximum radio-frequency power transmitted in the
frequency bands in which the radio equipment operates:
The maximum power for all bands is less than the highest
limit value specied in the related Harmonized Standard.
The frequency bands and transmitting power (radiated
and/or conducted) nominal limits applicable to this radio
equipment are as follows:
8
TUV SUD
![](/img.php?id=3604491&img=bga.png)
ALP-L09 GSM900: 37 dBm, GSM1800: 34 dBm,
WCDMA900/ 2100: 25.7 dBm, LTE Band
1/3/7/8/20/28/34/38/40: 25.7 dBm, Wi-Fi
2.4G: 20 dBm, Bluetooth: 20 dBm, Wi-Fi 5G:
5150-5350 MHz: 23 dBm, 5470-5725 MHz:
30 dBm, NFC: 60 dBuA/m at 10m
ALP-L29 GSM900: 37 dBm, GSM1800: 34 dBm,
WCDMA900/ 2100: 25.7 dBm, LTE Band
1/3/7/20/28/34/38/40: 25.7 dBm, Wi-Fi 2.4G:
20 dBm, Bluetooth: 20 dBm, Wi-Fi 5G:
5150-5350 MHz: 23 dBm, 5470-5725 MHz:
30 dBm, NFC: 60 dBuA/m at 10m
Accessories and Software Information
Some accessories are optional in certain countries or
regions. Optional accessories can be purchased from a
licensed vendor as required. The following accessories are
recommended:
Adapters: HW-050450X00 (X represents the different plug
types used, which can be either C, U, J, E, B, A, I, R, Z or K,
depending on your region)
Batteries: HB436486ECW
Earphones: 1311-3291-3.5mm-229, MEMD1632B580C00,
NA12, EMC309-001
The product software version is ALP-L09: ALP-L09
8.0.0.66(C900) / ALP-L29: ALP-L29 8.0.0.66(C900).
Software updates will be released by the manufacturer to
x bugs or enhance functions after the product has been
released. All software versions released by the
manufacturer have been veried and are still compliant
with the related rules.
All RF parameters (for example, frequency range and
output power) are not accessible to the user, and cannot be
changed by the user.
For the most recent information about accessories and
software, please see the DoC (Declaration of Conformity) at
http://consumer.huawei.com/certication.
FCC Regulatory Compliance
Body worn operation
9
TUV SUD
![](/img.php?id=3604491&img=bgb.png)
The device complies with RF specications when used near
your ear or at a distance of 1.50 cm from your body. Ensure
that the device accessories, such as a device case and
device holster, are not composed of metal components.
Keep the device away from your body to meet the distance
requirement.
Certication information (SAR)
This device is also designed to meet the requirements for
exposure to radio waves established by the Federal
Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged
over one gram of tissue. The highest SAR value reported to
the FCC for this device type complies with this limit.
The highest SAR value reported to the FCC for this device
type when using it at the ear is
ALP-L09 X.XX W/kg
ALP-L29 X.XX W/kg
And when properly worn on the body is
ALP-L09 Y.YY W/kg
ALP-L29 Y.YY W/kg
And when using the Wi-Fi hotspot function is
ALP-L09 Z.ZZ W/kg
ALP-L29 Z.ZZ W/kg
FCC statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
10
TUV SUD
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and
receiver.
--Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Caution: Any changes or modications to this device not
expressly approved by Huawei Technologies Co., Ltd. for
compliance could void the user's authority to operate the
equipment.
11
TUV SUD
![](/img.php?id=3604491&img=bgd.png)
Legal Notice
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Android™ is a trademark of Google Inc.
LTE is a trademark of ETSI.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Huawei Technologies Co., Ltd. is under
license.
Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are
trademarks of Wi-Fi Alliance.
Privacy Policy
To better understand how we protect your personal
information, please see the privacy policy at http://
consumer.huawei.com/privacy-policy.
Copyright © Huawei Technologies Co., Ltd.
2017. All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY,
AND DOES NOT CONSTITUTE ANY KIND OF WARRANTIES.
12
TUV SUD
![](/img.php?id=3604491&img=bge.png)
底边留5mm
Please visit
http://consumer.huawei.com/en/support/hotline for
recent updated hotline and email address in your
country or region.
31509162_01
The N-Mark is a trademark or
registered trademark of NFC Forum,
Inc. in the United States and in other
countries.
TUV SUD
