Huawei Technologies AM08 Bluetooth Speaker User Manual
Huawei Technologies Co.,Ltd Bluetooth Speaker
User Manual
1. Power button
Switch the power button to turn the SWAN on or off.
2. Volume up key 5. Volume down key
* To increase the SWAN volume, touch or touch and hold . To decrease the
SWAN volume, touch or touch and hold .
3. Previous 6. Next
* To play the previous or next song in a playlist on a paired Bluetooth device, touch
or .
* When the SWAN is pairing with a Bluetooth device, touch or to switch
between voice instructions and alert tones.
4. Bluetooth pair key
* When music is playing, touch to pause or resume the playback.
* When a call comes in, touch to answer the call or touch and hold to dismiss
the call. To end the call, touch again.
When you are in a call in handsfree mode, touch and hold to switch from the
AM08 handsfree mode to the phone mode. To switch back, set the answer mode on
your phone to Bluetooth.
* When you are not in handsfree mode, touch and hold to disconnect the AM08
from its paired Bluetooth device. The SWAN is then ready to pair with another
device.
7. Microphone
Connecting your AM08 to Bluetooth devices
I. Connecting to one Bluetooth device
After you turn the AM08 on, it automatically searches for nearby Bluetooth
devices and enters standby mode. On the device you want to pair with the AM08,
turn on Bluetooth. After the AM08 is found on the device, touch HUAWEI AM08 to
pair it with the AM08.
Note: On some Bluetooth devices, you may need to enter a password to set up a
connection. The default password is 0000.
The next time you turn on the AM08, it automatically searches for and pairs with
the Bluetooth device that it paired with previously. If no such devices are found,
your AM08 will remain in standby mode.
II. Connecting to two Bluetooth devices
The first time you pair the AM08 with two Bluetooth devices, do the following:
1. Pair the AM08 with a Bluetooth device.
2. Touch and hold to disconnect from the device and enable the AM08 to
enter the ready-to-pair mode.
3. On the second Bluetooth device, search for and pair with the AM08.
4. On the first Bluetooth device, search for and pair with the AM08.
Note: The AM08 can work with only one Bluetooth device at a time. If you have two
Bluetooth devices paired, pause all operations on one device to have the AM08
run the operations on the other device.
If you do not clear the pairing information from two previously used devices, your
AM08 will connect to them automatically when both are available.
Note:
Some Bluetooth devices do not support the Advanced Audio Distribution Profile
(A2DP) and cannot use the AM08 to play media files. For media playback
software incompatible with the AM08 will not allow the , ,and keys to
work. Before using the AM08, make sure you have compatible Bluetooth devices
and media playback software.
Please visit http://consumer.huawei.com/en/support/hotline/ for recently updated
hotline and email address in your country or region.
Model: AM08
II. Indicators and port
1
2
3
4
7
6
5
Bottom view Top view
HUAWEI Bluetooth Speaker
4
5
2
3
1
Getting to know your AM08
The AM08 is a Bluetooth-capable device that lets you play music wirelessly from
other Bluetooth devices. It automatically searches for nearby Bluetooth devices
after you power it on. The AM08 can be paired with two Bluetooth devices
simultaneously, but can work with one device at a time. When paired with your
phone, the AM08 functions as a speaker and microphone when you are on a call in
handsfree mode.
Before you start using your SWAN, let's take a look at its features and learn how to
use them.
I. Power button and keys
User Guide
AM08
1. Key indicator
This indicator turns on after the SWAN turns on or when you perform an operation.
It will turn off when the AM08 is inactive for a short while.
2. Bluetooth pairing indicator
When the AM08 is pairing with another device, this indicator blinks quickly. If the
pairing fails, this indicator blinks slowly. If the AM08 successfully pairs with the
device, this indicator turns off.
3. Breath indicator
When the AM08 is on, this indicator blinks slowly. When a call comes in, this
indicator blinks quickly.
4. Charging indicator
When the AM08 is charging, this indicator turns on. After the battery is fully
charged, this indicator turns off.
5. Charging port
This port connects the AM08 to a power adapter (5 V output) through a USB
cable. You may also connect the AM08 to a computer’s USB port to charge the
battery.
Safety information
This section contains important information about the operation of your device. It
also contains information about how to use the device safely. Read this
information carefully before using your device.
Operating environment
* The device supports a transmission distance of up to 10 meters. It is
recommended that you place your Bluetooth device within a 10-meter range from
the speaker.
* Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the
device in these environments may result in circuit malfunctions.
* Ideal operating temperatures are 10℃ to 35℃. Ideal storage temperatures are
-10℃ to 40℃. Extreme heat or cold may damage your device or accessories.
* Do not expose your device to direct sunlight (such as on a car dashboard) for
prolonged periods.
* To protect your device or accessories from fire or electrical shock hazards, avoid
rain and moisture.
* Keep the device away from sources of heat and fire, such as a heater,
microwave oven, stove, water heater, radiator, or candle.
* Do not place sharp metal objects, such as pins, near the earpiece or speaker.
The earpiece may attract these objects and result in injury.
* Do not allow children or pets to bite or suck the device or accessories. Doing so
may result in damage or explosion.
* Observe local laws and regulations, and respect the privacy and legal rights of
others.
Child's safet
* Comply with all precautions with regard to child's safety. Letting children play
with the device or its accessories may be dangerous. The device includes
detachable parts that may present a choking hazard. Keep away from children.
* The device and its accessories are not intended for use by children. Children
should only use the device with adult supervision.
Battery safety
* The device has a built-in, non-removable battery. Do not attempt to remove the
battery, otherwise the device may be damaged. To replace the battery, take the
device to an authorized service center.
* If the device has not been used for a long time, charge the battery before you
turn on the device.
Cleaning and maintenance
* Keep the device and accessories dry. Do not attempt to dry it with an external
heat source, such as a microwave oven or hair dryer.
* Do not expose your device or accessories to extreme heat or cold. These
environments may interfere with proper function and may lead to fire or explosion.
* Avoid collision, which may lead to device malfunctions, overheating, fire, or
explosion.
* Before you clean or maintain the device, stop using it, stop all applications, and
disconnect all cables connected to it.
* Do not use any chemical detergent, powder, or other chemical agents (such as
alcohol and benzene) to clean the device or accessories. These substances may
cause damage to parts or present a fire hazard. Use a clean, soft, and dry cloth to
clean the device and accessories.
* Do not dismantle or remanufacture the device and its accessories. This voids
the warranty and releases the manufacturer from liability for damage. In case of
damage, contact an authorized service center for assistance or repair.
Disposal and recycling information
try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Caution: Any changes or modifications to this device not expressly approved by
Huawei Technologies Co., Ltd. for compliance could void the user's authority to
operate the equipment.
Legal Notice
Copyright © Huawei Technologies Co., Ltd. 2015. All rights reserved.
Trademarks and Permissions
, , and are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
The Bluetooth word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Huawei Technologies Co., Ltd.
is under license.
Other trademarks, product, service and company names mentioned may be the
property of their respective owners.
Hereby, Huawei Technologies Co., Ltd. declares that this device is in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC.
For the declaration of conformity, visit the web site
http://consumer.huawei.com/certification.
The following marking is included in the product:
This device may be operated in all member states of the EU.
--Observe national and local regulations where the device is used.
--This device may be restricted for use, depending on the local network.
FCC Regulatory Compliance
FCC RF warning statement: The device has been evaluated to meet general RF
exposure requirement. The device can be used in portable exposure condition
without restriction.
FCC statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
This symbol (with or without a solid bar) on the device, batteries (if
included), and/or the packaging, indicates that the device and its electrical
accessories (for example, a headset, adapter, or cable) and batteries
should not be disposed of as household garbage. These items should not
be disposed of as unsorted municipal waste and should be taken to a certified
collection point for recycling or proper disposal.
For more detailed information about device or battery recycling, contact your local
city office, household waste disposal service, or retail store.
Disposal of the device and batteries (if included) is subject to WEEE Directive
Recast (Directive 2012/19/EU) and Battery Directive (Directive 2006/66/EC). The
purpose of separating WEEE and batteries from other waste is to minimize the
otential environmental impacts and human health risk of any hazardous
substances that may be present.
Reduction of hazardous substances
This device is compliant with the REACH Regulation [Regulation (EC) No
1907/2006] and RoHS Directive Recast (Directive 2011/65/EU). Batteries (if
included) are compliant with the Battery Directive (Directive 2006/66/EC). For
up-to-date information about REACH and RoHS compliance, please visit the web
site http://consumer.huawei.com/certification.
EU regulatory conformance
Statement
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS
REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT
SHALL HUAWEI BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOSS OF PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS
REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY
FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS
SUCH A LIMITATION) OF HUAWEI ARISING FROM THE USE OF THE
PRODUCT DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE
AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.
Privacy Policy
To better understand how we protect your personal information, please see the
privacy policy at http://consumer.huawei.com/privacy-policy.
®
Note:
Before using the AM08 for the first time, charge it for 2 or 3 hours.
When the battery level is critically low, the AM08 automatically turns off. If this
happens, charge the battery for a while and switch the power button to the off
position then the on position to turn on the AM08.
6011773_01
IC statement
- English: "
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device."
- French:"
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement."
