Huawei Technologies C2856 CDMA 1X Digital Mobile Phone User Manual C2856 user guide
Huawei Technologies Co.,Ltd CDMA 1X Digital Mobile Phone C2856 user guide
User Manual
C2856
CDMA 1X Mobile Phone
USER GUIDE
Please refer color and shape to product.
Huawei reserves the right to make changes or improvements to any of the products without prior notice.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People’s Republic of China
Tel:
+86-755-28780808
Global Hotline:
+86-755-28560808
E-mail:
mobile@huawei.com
Website:
www.huawei.com
Copyright © Huawei Technologies Co., Ltd. 2011. All rights
reserved.
No part of this document may be reproduced or transmitted in
any form or by any means without prior written consent of
Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted
software of Huawei Technologies Co., Ltd and possible
licensors. Customers shall not in any manner reproduce,
distribute, modify, decompile, disassemble, decrypt, extract,
reverse engineer, lease, assign, or sublicense the said software,
unless such restrictions are prohibited by applicable laws or
such actions are approved by respective copyright holders
under licenses.
Trademarks and Permissions
, HUAWEI, and
are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
Notice
Some features of the product and its accessories described
herein rely on the software installed, capacities and settings of
local network, and may not be activated or may be limited by
local network operators or network service providers, thus the
descriptions herein may not exactly match the product or its
accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or
modify any information or specifications contained in this
manual without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS".
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO.,
LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT,
OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,
BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED
SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import
laws and regulations and will obtain all necessary
governmental permits and licenses in order to export, re-export
or import the product mentioned in this manual including the
software and technical data therein.
Contents
1 Installing the UIM Card and the Battery ............................1
2 Charging the Battery...........................................................2
3 Getting to Know Your Phone..............................................2
4 Keys and Functions ............................................................3
5 Screen Icons ........................................................................4
6 Locking the Keypad ............................................................5
7 Call Function........................................................................5
Making a Call.......................................................................5
Answering a Call.................................................................6
8 Creating and Sending a Text Message..............................6
9 Enabling the Power Saving Mode......................................6
10 Enabling the Phone Lock .................................................7
11 PIN and PUK.......................................................................7
12 Text input............................................................................7
Entering an English Word (in "En" Mode)........................7
Entering English Letters (in "Abc" Mode)........................8
Entering a Number..............................................................8
Entering a Symbol ..............................................................9
13 Alarms ................................................................................9
14 Recording an Audio Clip.................................................10
15 Warnings and Precautions ............................................. 11
i
1 Installing the UIM Card and the
Battery
When installing the UIM card, ensure that the gold contact area
on the UIM card is facing downward and that the beveled edge
of the UIM card is properly aligned with that of the UIM card
slot.
12
34
1
2 Charging the Battery
1. Connect the charger to the charger connector of the phone.
2. Connect the charger to a power socket. Charging starts and
the charging icon is displayed in animation.
3. When the charging icon animation stops, indicating that the
charging is complete, disconnect the charger from the
phone.
3 Getting to Know Your Phone
14 1
2
3
4
5
7
9
8
10
11
12
13
6
1. Earpiece
2. Screen
3. Confirm key
4. Right soft key
5. End key
6. Number keys
7. # key
8. Microphone
9. Charger connector
10. * key
11. Call key
12. Left soft key
13. Navigation keys
14. Strap hole
Note
The preceding figure is provided for your reference only.
2
4 Keys and Functions
Press... To...
End key z Power on or off the phone (press and hold
the key).
z End or reject a call.
Call key Dial a number or answer a call.
Left soft
key
z Access the main menu in standby mode.
z Select the option displayed in the lower
left corner of the screen (directly above
the key).
Right soft
key
z Return to the previous menu or exit the
function menu from a menu screen.
z Select the option displayed in the lower
right corner of the screen (directly above
the key).
Navigation
keys
In standby mode,
z Up navigation key: access Calendar.
z Down navigation key: access Alarms.
z Left navigation key: access Messages.
z Right navigation key: access Profiles.
During a call,
z Up navigation key or Right navigation
key: increase the volume.
z Left navigation key or Down navigation
key: decrease the volume.
Confirm
key
Confirm a selection or display a menu.
3
Number
keys
z Enter numbers, letters, and symbols.
z Speed-dial phone numbers (press and
hold the desired key 2-9 in standby mode
after a phone number is assigned to the
number key).
z Access the submenu labeled with the
corresponding number.
* key Activate or deactivate the Meeting profile
(press and hold the key in standby mode).
# key Lock the keypad (press and hold the key in
standby mode).
5 Screen Icons
Icon Indicates... Icon Indicates...
Signal strength Battery power level
No signal
Code division
multiple access
(CDMA) 1X
network available.
Domestic roaming International
roaming
Call in progress Keypad locked
New message
received Memory full
Emergency
message received General profile
activated
Silence profile
activated Meeting profile
activated
4
Outdoor profile
activated My Profile
activated
Alarm on Voicemail
message received
6 Locking the Keypad
To prevent unintentional operations, you can press and hold the
# key in standby mode to lock the keypad. When the keypad is
locked, you can press the Call key to answer an incoming call
and make an emergency call.
To unlock the keypad, press the Left soft key and then the * key.
7 Call Function
Note
You can only dial emergency numbers and answer incoming
calls when the keypad is locked. Unlock the keypad to make
calls.
Making a Call
1. In standby mode, press the Number keys to enter a phone
number.
z To make an international call, press the * key twice to
enter a plus sign (+), and then enter the country or region
code, area code, and phone number in sequence.
z To dial an extension number, enter the phone number,
press the * key three times to enter P or four times to enter
T, and then enter the extension number.
2. Press the Call key to dial the number.
3. Press the End key to end the call or cancel the dialing.
5
Note
z In standby mode, you can press the Call key to access the
call log, select a desired number, and then press the Call key
again to dial the number.
z In Phonebook, select a desired number, and then press the
Call key to dial the number.
z In Inbox of Messages, select a desired message, and then
press the Call key to call the message sender.
Answering a Call
When there is an incoming call, press the Call key to answer
the call or the End key to reject the call. If the any-key answer
function is enabled, press any key except the Right soft key
and the End key to answer the call.
8 Creating and Sending a Text
Message
1. In standby mode, select Menu > Messages > Write
Message.
2. Write the message, and then select Options > Send.
3. Edit the list of message recipients.
4. Press the Confirm key to send the message.
9 Enabling the Power Saving Mode
1. In standby mode, if the screen backlight is on and if the
keypad is unlocked, press the End key to turn off the screen
backlight.
2. If the screen backlight is off and if the keypad is locked, you
can press the Left soft key or the End key to turn on the
screen backlight.
6
3. In standby mode, select Menu > Settings > Phone
Settings > Power Saving Mode > On to enable the
power-saving mode, in which the keypad backlight is off
from 09:00 to 17:00.
10 Enabling the Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled.
Select Menu > Settings > Security Settings > Phone Lock to
enable the phone lock with the following options:
z Immediate: to enable the phone lock immediately.
z Power On: to enable the phone lock when the phone is
powered on next time.
When you enable the phone lock, you are prompted to enter
the phone lock code. The default phone lock code is 0000. You
can change the code to any string of four to eight digits.
11 PIN and PUK
The personal identification number (PIN) protects your UIM
card from unauthorized use. The PIN Unlock Key (PUK) is used
to unlock a blocked PIN.
If you enter wrong PINs three times consecutively, the phone
prompts you to enter the PUK. If you enter wrong PUKs 10
times consecutively, the UIM card becomes permanently
invalidated. In this case, contact your network operator for a
replacement.
The PIN and the PUK are provided with your UIM card. For
details, contact your network operator.
12 Text input
In editing mode, press the # key to switch between text input
modes.
Entering an English Word (in "En" Mode)
To enter an English word in En mode, do the following:
7
1. Press each number key only once according to the spelling
sequence of the desired word. As you enter, the phone
attempts to predict the desired word and displays candidate
words.
2. Press the Up navigation key or the Down navigation key to
scroll to the desired word.
3. Press the Right navigation key to enter the desired word or
press the 0 key to enter the desired word followed by a
space.
Entering English Letters (in "Abc" Mode)
In "Abc" mode, press the number key labeled with the desired
letter once to enter the first letter on the key, twice to enter the
second letter on the key, and so on.
If the letter that you want to enter is on the same key as the
previous letter, enter the desired letter after the cursor appears
again or after you press the Right navigation key to move the
cursor to the right of the previous letter.
Entering a Number
z In "123" mode, press the number key labeled with the
desired digit.
z In "Abc" mode, press and hold or repeatedly press the
number key labeled with the desired number until the
number appears on the screen.
z In "En" mode, press the number key labeled with the desired
number, and then press the Up navigation key or the Down
navigation key until the number appears on the screen.
Tip
z In "En" mode, press the 0 key to enter a space. In "Abc"
mode, press the 0 key once to enter a space, twice to enter 0,
and three times to enter a linefeed.
8
z In "Abc" mode, repeatedly press the 1 key to enter a
commonly used punctuations. In "En" mode, press the 1 key
once to enter a period and twice or three times to enter a
smiley.
Entering a Symbol
1. In any text entry mode, press the * key to display the symbol
list.
2. Use the Navigation keys to scroll to the desired symbol, and
then press the Confirm key to enter the symbol. You can
also press the number key corresponding to the desired
symbol to enter the symbol.
13 Alarms
You can set a maximum of five alarms. To set an alarm, on the
main menu screen, select Tools > Alarms to access the
Alarms screen.
Enabling an Alarm
1. On the
Alarms screen, select an alarm, and then set the
alarm time, repeat days, and alarm tone.
2. Save the settings to enable the alarm.
Disabling One or All Alarms
On the Alarms screen, select an alarm and then select Off to
disable the alarm or select Cancel All to disable all alarms.
Note
z When an alarm rings, select Stop to stop the alarm. If you
select Snooze, the alarm will stop temporarily, and then ring
again after five minutes.
z You can customize the days for repeating an alarm. You can
browse the seven days in a week, and then select the days
that you want the alarm to ring.
9
14 Recording an Audio Clip
1. In standby mode, select Menu > Tools > Recorder.
2. Press the Confirm key to start recording.
3. Press the Left soft key to stop recording.
4. Press the Confirm key to play the recorded audio clip.
All recorded audio clips are stored in Menu > My Documents >
Musics > recorder.
10
15 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or
interference with electronic devices.
Medical Device
z Follow rules and regulations set forth by hospitals and health
care facilities. Do not use your device when using the device
is prohibited.
z Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio equipment
in fuel depots, storage, and distribution areas, and chemical
plants. In addition, adhere to restrictions in areas where
blasting operations are in progress. Before using the device,
watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
11
Such locations include areas below the deck on boats,
chemical transfer or storage facilities, and areas where the air
contains chemicals or particles such as grain, dust, or metal
powders. Ask the manufacturers of vehicles using liquefied
petroleum gas (such as propane or butane) whether this device
can be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
z Concentrate on driving. Your first responsibility is to drive
safely.
z Do not talk on the device while driving. Use hands-free
accessories.
z When you have to make or answer a call, park the vehicle on
the road side before using your device.
z Radio frequency (RF) signals may affect electronic systems
of motor vehicles. For more information, consult the vehicle
manufacturer.
z In a motor vehicle, do not place the device over the air bag or
in the air bag deployment area. Otherwise, the device may
hurt you owing to the strong force when the air bag inflates.
z Do not use your device while flying in an aircraft. Power off
your device before boarding the aircraft. Using wireless
devices in the aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
Operating Environment
z Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, a
malfunction of the circuit may be caused.
z The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
12
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
z On a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
z When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
z While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
z Keep the ambient temperature between 0°C and 40°C
while the device is being charged. Keep the ambient
temperature between 0°C to 40°C while the device powered
by a battery is being used.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting children play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and its
accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
13
the device, result in the non-operation of the device, and cause
danger.
Battery and Charger
z Unplug the charger from the socket and the device when the
device is not in use.
z The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and the talk time are shorter than the normal time, replace
the battery.
z Use the alternating current (AC) power supply defined in the
specifications of the charger. An improper power voltage
may cause a fire or a malfunction of the charger.
z Do not connect two poles of the battery with conductors,
such as metal materials, keys, or any jewellery. Otherwise,
the battery may get short-circuited and may cause injuries
and burns on your body.
z Do not disassemble the battery or solder the battery poles.
Otherwise, an electrolyte leakage, an overheating, a fire, or
an explosion may be caused.
z If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your skin
or eyes with clean water immediately and consult a doctor.
z If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
a battery leakage, an overheating, an explosion, or a fire
may be caused.
z If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, an electric shock, a short circuit of
the charger, or a fire may be caused.
14
z Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
z Danger of explosion if battery is incorrectly replaced.
Recycle or dispose of used batteries according to the local
regulations or reference instruction supplied with your
device.
Cleaning and Maintenance
z The device, battery, and charger are not water-resistant.
Keep them dry and protect them from water and vapor. Do
not touch the device or the charger with a wet hand.
Otherwise, a short circuit, a malfunction of the device, and
an electric shock to the user may be caused.
z Do not place your device, battery, and charger in places
where they can get damaged because of collision.
Otherwise, a battery leakage, a device malfunction, an
overheating, a fire, or an explosion may be caused.
z Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
z Do not leave your device, battery, and charger in a place
with an extremely high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
z Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
z Before you clean or maintain the device, power off the
device and disconnect it from the charger.
z Do not use any chemical detergent, powder, or other agents
(such as alcohol and benzene) to clean the device and the
charger. Otherwise, parts of the device may get damaged or
15
a fire can be caused. You can clean the device and the
charger with a piece of damp and soft antistatic cloth.
z Do not dismantle the device or accessories. Otherwise, the
warranty on the device and its accessories is rendered
invalid and the manufacturer is not liable to pay for the
damage.
Emergency Call
You can use your device for emergency calls in the service
area. The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for the amount of radio frequency energy absorbed by the body
when a device is being used. The SAR value is determined at
the highest certified power level in laboratory conditions, but
the actual SAR level of the device when the device is being
operated can be well below the value. This is because the
device is designed to use the minimum power required to reach
the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the Federal Communications
Commission (FCC) and the Industry Canada (IC) for this device
16
type when the device is tested for use at the ear is 1.14 W/kg,
and that when the device is properly worn on the body is 1.31
W/kg.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void
the FCC authorization to operate this device.
Version: V100R001C16_01 Part Number: 9672XXXX
17
