Huawei Technologies C2931 CDMA 1X Digital Mobile Phone User Manual
Huawei Technologies Co.,Ltd CDMA 1X Digital Mobile Phone
user manual
C2931
CDMA 1X Mobile Phone
User Guide
Please refer color and shape to product.
Huawei reserves the right to make changes or improvements to
any of the products without prior notice.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129,
People’s Republic of China
Tel: +86-755-28780808 Global Hotline: +86-755-28560808
E-mail: mobile@huawei.com Website: www.huawei.com
Copyright © Huawei Technologies Co., Ltd. 2011.
All rights reserved.
No part of this document may be reproduced or transmitted in
any form or by any means without prior written consent of
Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted
software of Huawei Technologies Co., Ltd and possible licensors.
Customers shall not in any manner reproduce, distribute, modify,
decompile, disassemble, decrypt, extract, reverse engineer, lease,
assign, or sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by
respective copyright holders under licenses.
Trademarks and Permissions
, , and are trademarks or registered trademarks
of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
Notice
Some features of the product and its accessories described herein
rely on the software installed, capacities and settings of local
network, and may not be activated or may be limited by local
network operators or network service providers. Thus the
descriptions herein may not exactly match the product or its
accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or
modify any information or specifications contained in this manual
without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN
NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR
ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA,
GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws
and regulations and will obtain all necessary governmental permits
and licenses in order to export, re-export or import the product
mentioned in this manual including the software and technical
data therein.
i
Contents
1 Get to Know Your Phone ................................................. 1
Installing the UIM Card and the Battery ................................... 1
Charging the Battery ............................................................... 2
Your Phone ............................................................................. 3
Keys and Functions ................................................................. 4
Screen Icons ........................................................................... 7
2 Getting Started ................................................................ 8
Powering On/Off the Phone .................................................... 8
Locking the Keypad ................................................................ 8
Phone Lock ............................................................................. 8
PIN and PUK ........................................................................... 9
Shortcuts ................................................................................ 9
Power Saving Mode ................................................................ 9
3 Voice Services ................................................................ 10
Making a Call........................................................................ 10
Answering a call ................................................................... 10
4 Text Input ...................................................................... 11
Text Input Mode ................................................................... 11
Entering English .................................................................... 11
Entering a Number ................................................................ 12
Entering a Symbol ................................................................. 12
5 Creating and Sending a Messages .................................. 13
6 Contacts ......................................................................... 13
Creating a Contact ................................................................ 13
Searching for a Contact......................................................... 13
7 FM Radio ....................................................................... 14
Swithching on the Radio ....................................................... 14
ii
Listening to the Radio ........................................................... 14
8 Tools .............................................................................. 15
Recorder ............................................................................... 15
Alarms .................................................................................. 15
Torch .................................................................................... 15
9 Warnings and Precautions ............................................. 16
1
1 Get to Know Your Phone
The preceding figure is provided for your reference only. The appearance
of the actual product that you have purchased may differ slightly from that
shown.
Installing the UIM Card and the Battery
Install your User Identity Module (UIM) card before using your
phone. Remove the UIM card and the battery only after powering
off the phone.
b
a
2
Charging the Battery
Although the lithium battery of the mobile phone can be used
immediately after being unpacked from the gift box, a new
battery performs best after being fully charged and discharged for
3 times.
The following figure shows how to charge your battery.
1. Connect the charger to the phone's charger jack.
2. Plug the charger into a power outlet.
3. Wait until the battery is fully charged.
While the battery is charging, the charging icon blinks. When
the charging icon stops blinking, the battery is fully charged.
4. Unplug the charger from the power outlet and from the phone.
3
Your Phone
1
14
2
3
6
5
7
10
8
9
11
14 15
12
13
1
Earpiece
2
Screen
3
Confirm key
4
Left soft key
5
Call/Answer key
6
Number keys
7
* key
8
# key
9
End/Power key
10
Right soft key
11
Navigation keys
12
Strap hole
13
Torch
14
Headset jack
15
Charger jack
4
Keys and Functions
In this guide, your phone's navigation keys are indicated by the following
icons: , , and .
Press…
To…
Make a call.
Answer a call.
View the call log in standby mode.
Power the phone on or off (press and hold the
key for about 3 seconds).
End or reject a call.
Turn the phone backlight on or off in standby
mode.
Return to standby mode.
Left soft
key
Select the option displayed directly above the key, in
the lower left corner of the screen.
Right soft
key
Select the option displayed directly above the key, in
the lower right corner of the screen.
5
Press…
To…
Access the corresponding functions assigned to
the navigation keys in standby mode.
Scroll through menu options.
Increase the volume (press or ) or
decrease the volume (press or ) during a
call.
Confirm a selection.
through
Enter numbers, letters, and symbols.
Call your voicemail in standby mode (press and
hold key).
Speed-dial phone numbers in standby mode
(press and hold — keys for about 3
seconds if speed dial numbers are assigned).
Select an option labeled with the corresponding
number.
6
Press…
To…
Enter * (press the key once), + (press the key
twice), P (press the key three times), or T (press
the key four times) when entering phone
numbers.
Enable or disable the Meeting profile in standby
mode (press and hold the key for about 3
seconds).
Display the symbol list in editing mode.
Enter #.
Lock the keypad in standby mode (press and hold
the key for about 3 seconds).
Switch between text input methods in editing
mode.
7
Screen Icons
图标
说明
图标
说明
Signal strength.
Battery level.
Domestic roaming
state.
International roaming
state.
Calling state.
Keypad locked.
Message received
(yellow icon).
Voice mail message
received.
Urgent message
received.
Memory for messages
full (orange icon).
General profile
activated.
Silence profile
activated.
Meeting profile
activated.
Outdoor profile
activated.
My Profile 1 profile
activated.
My Profile 2 profile
activated.
Alarm enabled.
Headset connected.
8
2 Getting Started
Powering On/Off the Phone
Press and hold for about 3 seconds, powering on or off
the phone.
If Auto Power On/Off function is enabled, the phone will power
on/off automatically in preset time.
You can select Menu > Settings > Phone Settings > Auto
Power On/Off to set the power on/off time.
Locking the Keypad
In standby mode, press and hold for about 3 seconds to
lock the keypad. When the keypad is locked, you can press
to answer a call or make an emergency call.
To unlock the keypad, press (Unlock) then in quick
succession.
If the Auto Keyguard function is enabled, the phone will lock the
keypad automatically after being idle in standby mode for a pre-
defined period. You can select Menu > Settings > Phone
Settings > Auto Keyguard to set the function.
Phone Lock
Phone Lock protects your phone from unauthorized use and
factory settings restoration.
By default, the Phone Lock is disabled. You can select Menu >
Settings > Security Settings > Phone Lock to enable or disable
Phone Lock.
9
The preset phone code is 0000. You can select Menu >
Settings > Security Settings > Change Phone Code to change
the phone code to any numeric string of four to eight digits. Do
remember your phone code. If you forget it, contact the service
center.
PIN and PUK
The personal identification number (PIN) protects your SIM/USIM
card from unauthorized use. The PIN unblocking key (PUK) unlocks
a blocked PIN. Both the PIN and the PUK are provided with the
SIM/USIM card. For details, contact your service provider.
If you enter the incorrect PIN a specified number of times, the
phone prompts you to enter the PUK.
If you enter the incorrect PUK a specified number of times, the
SIM/USIM card will become permanently invalid. If this occurs,
contact your service provider for a new SIM/USIM card.
Shortcuts
You can select Menu > Settings > Phone Settings > Shortcuts
to set the corresponding functions to .
Press , , and in standby mode to access the
preset function menus.
Power Saving Mode
Select Menu > Settings > Phone Settings > Power Saving
Mode to enable or disable this function.
If the power saving mode is enabled, the keypad backlight will be
off from 9:00 to 17:00.
10
3 Voice Services
Making a Call
1. In standby mode, enter a phone number.
To make an international call, press twice to enter the
plus sign (+). Then enter the country or region code, area
code, and phone number.
To call an extension number, enter the phone number, press
three times to enter P or four times to enter T, and
enter the extension number.
2. Press to dial the number.
3. Press to end the call.
You can also make a call from Contacts , Call Log, or Messages.
Answering a call
When there is an incoming call, press to answer the call or
to reject it.
If you select Menu > Settings > Call Settings > Answer Mode >
By Any Key, you can press any key except and to
answer the call.
11
4 Text Input
Text Input Mode
The current text input mode indicator is displayed in the upper left
corner of the screen. Press to switch between text input
modes.
Indicator
Text Input Mode
Abc\ABC\abc
Multi-tap input modes
En\EN\en
Predictive input modes
123
Number input modes
In editing mode, press (Clear) once to delete the last character
entered, or press and hold for about 3 seconds to delete all the
characters.
Entering English
Press to enter a space, press and hold for about 3 secondes to enter
"0". Press to switch between upper case mode, lower case mode,
and capitalization of the first letter mode.
12
Multi-Tap Input Mode
In multi-tap input mode, press the key labeled with the desired
letter once to enter the first letter on the key, twice to enter the
second letter, and so on.
If the letter that you want to enter is on the same key as the
previous letter, enter the desired letter after the cursor appears
again or after you press to move the cursor to the right of
the previous letter.
Predictive Input Mode
1. Press each key once according to the spelling sequence of the
desired word. The phone displays candidate words.
2. Press or to scroll to the desired word.
3. Press to enter the desired word or press key to enter
the desired word followed by a space.
Entering a Number
In number input modes, simply press the number key labeled
with the desired number.
In multi-tap input mode, press and hold the number key
labeled with the desired number, or repeatedly press it until the
number appears on the screen.
In predictive input mode, press the number key labeled with
the desired number, and press or until the number
appears on the screen.
Entering a Symbol
In any text input mode, press to display the symbol list.
13
Press to scroll to the desired symbol, and press to
enter it.
In any input mode except the number input mode, press in
quick succession to display the commonly used symbol list.
5 Creating and Sending a Messages
1. Select Menu > Messages > Create Message.
2. Write the message.
3. press or select Options > Send.
4. Add recipients by entering the phone numbers, or select the
recipients from Contacts.
5. Press to send the message.
6 Contacts
Creating a Contact
1. Select Menu > Contacts > Add New.
2. Enter the contact information.
3. Press (Save) or to save the contact.
Searching for a Contact
1. Select Menu > Contacts > Search.
2. Enter the contact name, or the first several letters of a contact
name.
3. Press or to scroll to the contact.
14
7 FM Radio
The headset cable functions as an antenna as well. To ensure good
reception of radio programs, do not disconnect the headset from the
phone or severely bend the headset cable.
Swithching on the Radio
Select Menu > Radio to display the radio screen. The phone plays
the program on the channel that you listened to last time.
When you listen to the radio for the first time, because no channel
is saved on the list, you need to press (Options) and
search for channels as follows:
Automatic Tuning: The phone performs automatic tuning,
and then saves the channels found to the channel list.
Manual Tuning: Press and to search channels and
save to the channel list.
Fine Tuning: Adjust the frequency with a precision of 0.1MHz.
Set Frequency: Enter a channel frequency and press to
listen to the program.
Listening to the Radio
When listening to a radio program, you can perform the following
operations:
Press to enable or disable the Speaker.
Press or to adjust the volume.
Press or to switch between channels.
15
Press (Hide) or , return to standby mode, and
the radio is playing in the background.
Select Options > Switch Off to switch off the radio.
8 Tools
Recorder
1. Select Menu > Tools > Recorder.
2. Press to start recording. Press to pause or continue
recording.
3. Press (Stop) to stop recording. The sound clip is
automatically saved to the recorders folder of the default
storage.
4. Press to play the sound clip.
When recording a sound clip, keep the microphone of your phone near
the sound source for a better recording effect.
Alarms
1. Select Menu > Tools > Alarms to access the alarm screen.
2. Select an alarm, and then press to set the alarm time,
repeat days, and alarm tone.
3. Press (Save) to save the settings.
4. Press to enable or disable the alarm.
Torch
Select Menu > Tools > Torch, and press or to turn on
16
or off the torch.
9 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains information
about how to use the device safely. Read this information carefully
before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not use
the device when using the device causes danger or interference
with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and health
care facilities. Do not use your device when using the device is
prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on the
opposite side of the pacemaker and do not carry the device in
your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas that
may have potentially explosive atmospheres include the areas
where you would normally be advised to turn off your vehicle
17
engine. Triggering of sparks in such areas could cause an
explosion or a fire, resulting in bodily injuries or even deaths. Do
not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio equipment in
fuel depots, storage, and distribution areas, and chemical plants.
In addition, adhere to restrictions in areas where blasting
operations are in progress. Before using the device, watch out for
areas that have potentially explosive atmospheres that are often,
but not always, clearly marked. Such locations include areas below
the deck on boats, chemical transfer or storage facilities, and areas
where the air contains chemicals or particles such as grain, dust,
or metal powders. Ask the manufacturers of vehicles using
liquefied petroleum gas (such as propane or butane) whether this
device can be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles. For
more information, consult the vehicle manufacturer.
18
In a motor vehicle, do not place the device over the air bag or
in the air bag deployment area. Otherwise, the device may hurt
you owing to the strong force when the air bag inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless devices
in an aircraft may cause danger to the operation of the aircraft
and disrupt the wireless telephone network. It may also be
considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may result
in a malfunction of the circuit.
The device complies with the RF specifications when the device
is used near your ear or at a distance of 1.5 cm from your body.
Ensure that the device accessories such as a device case and a
device holster are not composed of metal components. Keep
your device 1.5 cm away from your body to meet the
requirement earlier mentioned.
On a stormy day with thunder, do not use your device when it
is being charged, to prevent any danger caused by lightning.
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the standby
time are reduced.
While using the device, observe the local laws and regulations,
19
and respect others' privacy and legal rights.
Keep the ambient temperature between 0℃ and 40℃ while
the device is being charged. Keep the ambient temperature
between 0℃ to 40℃ for using the device powered by a
battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset volume
to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may be
dangerous, as it may present a choking hazard. Ensure that small
children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to the
device, result in the non-operation of the device, and cause danger.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of times
before it eventually wears out. When the standby time and the
20
talk time are shorter than the normal time, replace the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
Do not connect two poles of the battery with conductors, such
as metal materials, keys, or jewelries. Otherwise, the battery
may be short-circuited and may cause injuries and burns on
your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating, fire,
or explosion.
If battery electrolyte leaks out, ensure that the electrolyte does
not touch your skin and eyes. When the electrolyte touches
your skin or splashes into your eyes, wash your eyes with clean
water immediately and consult a doctor.
If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise, it
may lead to battery leakage, overheating, explosion, or fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the cable
at once. Otherwise, it may lead to an electric shock, a short
circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
21
Danger of explosion if battery is incorrectly replaced. Recycle or
dispose of used batteries according to the local regulations or
reference instruction supplied with your device.
Cleaning and Maintenance
The device, battery, and charger are not water-resistant. Keep
them dry. Protect the device, battery, and charger from water
or vapor. Do not touch the device or the charger with a wet
hand. Otherwise, it may lead to a short circuit, a malfunction of
the device, and an electric shock to the user.
Do not place your device, battery, and charger in places where
they can get damaged because of collision. Otherwise, it may
lead to battery leakage, device malfunction, overheating, fire,
or explosion.
Do not place magnetic storage media such as magnetic cards
and floppy disks near the device. Radiation from the device
may erase the information stored on them.
Do not leave your device, battery, and charger in a place with
an extreme high or low temperature. Otherwise, they may not
function properly and may lead to a fire or an explosion. When
the temperature is lower than 0°C, performance of the battery
is affected.
Do not place sharp metal objects such as pins near the earpiece.
The earpiece may attract these objects and hurt you when you
are using the device.
Before you clean or maintain the device, power off the device
22
and disconnect it from the charger.
Do not use any chemical detergent, powder, or other chemical
agents (such as alcohol and benzene) to clean the device and
the charger. Otherwise, parts of the device may be damaged or
a fire can be caused. You can clean the device and the charger
with a piece of damp and soft antistatic cloth.
Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all conditions.
You should not rely solely on the device for essential
communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is designed
not to exceed the limits for exposure to radio waves. These
guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing Radiation
Protection (ICNIRP) and include safety measures designed to
ensure safety for all users, regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of measurement for
the amount of radio frequency energy absorbed by the body when
23
using a device. The SAR value is determined at the highest
certified power level in laboratory conditions, but the actual SAR
level of the device when being operated can be well below the
value. This is because the device is designed to use the minimum
power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6 watts/kilogram
(W/kg) averaged over one gram of tissue. The highest SAR value
reported to the FCC and IC for this device type when tested for
use at the ear is 1.17 W/kg, and when properly worn on the body
is 0.905 W/kg.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void the
FCC authorization to operate this device.
Version: V100R001C02_01
Part Number: 9672xxxx
