Users Manual

C3308

CDMA 1X Mobile Phone

and other Huawei trademarks are the trademarks or registered trademarks of Huawei Technologies Co., Ltd.

in the People’s Republic of China and certain other countries. All other trademarks mentioned in this manual are the

property of their respective holders. The information in this manual is subject to change without notice. Every effort

has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information,

and recommendations in this manual do not constitute the warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China

Tel: +86-755-28780808 Global Hotline: +86-755-28560808

E-mail: mobile@huawei.com Website: www.huawei.com

Your Phone

Screen

Earpiece

Navigation Keys

Left Soft Key

Talk/Send Key

Right Soft Key

End / Power Key

# Key

Key

Number Keys

Charger Interface

/ Data Cable Connector

Confirm Key

Microphone

/Headset jack

Clear Key

Keys and Functions

Press… To…

z View All calls in the standby mode.

z Make a call or answer an incoming call.

z Power on or off the phone (by pressing and holding it).

z End a call.

z Return to the standby mode.

z Display the Menu interface in the standby mode.

z Select an item.

z Perform the function shown on the lower right corner

of the screen.

z Display Menu in the standby mode.

z Select the highlighted item.

z Perform the function shown on the lower right corner

of the screen.

z View the Contacts in the standby mode.

z Return to the previous menu.

z In the standby mode, access Profiles ( ); Brew

(); Alarms ( ); Messages () or Create

Message () (by pressing and holding it).

z During a call, increase volume ( ); or decrease the

volume ( ).

Press… To…

z Enter numbers and letters.

z Access Voice mail in the standby mode (by pressing

and holding the 1 key).

z Speed-dial a phone number in the standby mode (by

pressing and holding the 2-9 keys).

z Select a submenu item labeled with the corresponding

number.

z Enter the *, +, P, T symbols.

z Activate or deactivate the Meeting profile (by

pressing and holding it).

z Provide different functions according to the phone

features being used.

z Enter the # symbol.

z Provide different functions according to the phone

features being used.

In the editing mode,

z Delete a letter on the left of the cursor.

z Clear all the letters at a time (by press and hold it).

Screen Icons

Icon Meaning Icon Meaning

Network signal

strength

The My Profile is

activated

No network signal Message received

Icon Meaning Icon Meaning

CDMA 1X 2000

network is activated

Memory for messages

full(Icon blinks)

Domestic roaming

A new voice mail is

received

Overseas roaming

A new emergent

message is received

Calling… Alarm clock on

Voice privacy function

is activated Battery power level

The General profile is

activated Open Hands-free

The Silence profile is

activated

The Meeting profile is

activated

The Outdoor profile is

activated - -

Menu Tree

Radio

1 Creat Message

2 Inbox

3 Outbox

4Drafts

5Voice Mail

6 Templates

7Recipient List

8 My Folder

9 Settings

0 Delete All

Brew

1 Display Settings

2 Date & Time

3 Call Settings

4 Phone Settings

5 Security Settings

6Restore Factory

Settings

1 Search

2Search By Location

3 Add New

4 Groups

5 Speed Dail

6 My Number

7 Management

1 Recorder

2Alarms

3 Schedules

4Calculator

5 Stopwatch

6 World Clock

7 Gallery

8X Kid

9 Gulper

Settings

1 All Calls

2 Missed Calls

3 Received Calls

4 Dialled Calls

5Call Memo

6 Call Duration

Call Log

Messages Tools

Contacts

(Options when no channel saved)

1 Automatic Turning

2 Manul Turning

3 Fine Turning

4 Set Frequency

(Options when some channels saved)

1Switch Off 4Turning

2 Speaker On 5 Delete Channel

3 Start Record 6 Rename Channel

1General

2Silence

3Meeting

4 Outdoor

5My Profile1

6My Profile2

Profiles

Consult your service

Provider for more

Information about

This function.

Installing the Battery

1. 2. 3.

External Screen

Your phone has an external screen on the outside of the flip. When

you close the phone, the external screen indicates the following:

z Time and date

z Incoming calls and message received

z Alarm clock on

z Battery power level

z Network signal strength

z Current profile

Charging the Battery

1. Connect the travel charger to the charger interface at the bottom

of your phone.

2. Connect the charger to an AC power socket.

During the charging, the icon on the upper right corner of the

screen is in an animated status. If the phone is powered off during

charging, the icon is displayed on the external screen of the

phone.

3. Wait until the phone is fully charged.

If becomes static, the battery is fully charged.

4. Disconnect the charger from the AC power socket.

5. Disconnect the travel charger from your phone.

Using the Function Menu

To use the function menus, do as follows:

1. In the standby mode, press (Menu).

2. Press , to select the desired function menu.

3. Press (Select)or OK to display the selected menu.

Display the submenu in either of the ways:

z Press to select a submenu and then press (Select) or OK to

display the selected submenu.

z Press the number key corresponding to the serial number of a

submenu to display the submenu.

4. Press (Back)to return to the previous menu or quit the

function menu.

5. Press to return to the standby mode.

Making a Call

1. In the standby mode, enter a phone number.

z To make an international call, press twice to enter the

international long distance code of "+". Then enter the number to

be dialed, in the format of "country code + region code + phone

number".

z To call a number with an extension, press three times to insert

"P" or press four times to insert "T" between the phone

number and the extension.

2. Press to dial the number.

3. Press or (End) to end the call.

Note z In the standby mode, press to view the All Calls.

Select a record and press to dial.

z Select a contact from the Contacts and press to

dial.

Answering a Call

When there is an incoming call, press , (Answer), OK ,to

answer it, press (Silence) to mute the phone, or press to

reject it.

z If the any key answer function is enabled, press any key (except

or ) to answer an incoming call.

z If the headset auto answer function is activated, and the headset is

connected to the phone, the incoming call is answered

automatically.

Note If the headset is connected to the phone, you can press the

utton on the headset cable to answer or end a call.

Phone Lock

The phone lock protects your phone from unauthorized use. The

default phone lock code is "1234". You can change it into any

numeric string of 4 to 8 digits.

If the phone lock is enabled, you need to enter the correct phone lock

code when the phone is powered on.

Changing the Text Input Modes

The indicator of the current text input mode is displayed on the

screen. When no letters are selected in the input field, press to

change the input mode. When letters are selected, press to change

the letters between lowercase and uppercase.

Note z In the editing mode, press once to delete the letter

on the left of the cursor. Press and hold to delete

all the letters at a time.

z In the "en" input mode, press to enter a space. In the

"abc" input mode, press once to enter a space and

twice to enter 0.

z In the "abc" input mode, press repeatedly to

select and enter the commonly-used punctuations. In the

"en" input mode, press to enter a full stop or

smiley.

Entering English(En)

In the "En" input mode, do the following to enter the English letters:

1. Press each desired key once corresponding to the sequence of the

letters. Then the phone displays the commonly-used words

according to the numeric sequence of key presses.

2. Press to scroll to the desired word.

3. Press or OK to enter the word.

Press to enter the word and a space.

Entering English(Abc)

In the "Abc" input mode, press a key labeled the desired letters once

to enter the first letter on the key, twice to enter the second letter on

the key, and so on.

Entering Numbers

In the "123" input mode, press a key labeled with the desired

number.

z In the "abc" input mode, press a key continuously or press and

hold it until the desired number appears on the screen.

z In the "en" input mode, press a key and then press until the

desired number appears on the screen or pressing and hold the key

until the desired number appears.

Note If the letter you want to enter is on the same key as the

previous one, enter the latter only after the cursor appears

again or after you press to move the cursor to the next

space.

Entering Spanish

You can enter Spanish words in the Spanish text input mode.

Traditional Spanish text input and smart Spanish text input are

similar to traditional English text input and smart English input.

For details, see "Entering English(En)" on page10.

Entering Symbols

1. In any input mode, press to display a symbol list;

press twice ,to display a network symbol list.

2. Press to scroll to the desired symbol.

3. Press the numeric key to enter the symbol.

Warnings and Precautions

Electronic Device

z Power off your phone near high-precision electronic devices. The phone may

affect the performance of these devices.

z Such devices include hearing aids, pacemakers, fire alarm systems, automatic

gates, and other automatic-control devices. If you are using an electronic

medical device, consult the device manufacturer to confirm whether the radio

wave affects the operation of this device.

z Pacemaker manufacturers recommend that a minimum separation of 15cm be

maintained between a mobile phone and a pace-maker to avoid potential

interference with the pace-maker. To achieve this use the phone on the

opposite ear to your pacemaker and do not carry it in a breast pocket.

Hospital

Pay attention to the following points in hospitals or health care facilities:

z Do not take your phone into the operating room (OR), intensive care unit

(ICU), or coronary care unit (CCU).

z Do not use your phone at places for medical treatment where phone use is

prohibited.

z When using your phone near someone who is suffering from a heart disease,

turn down the ring tone volume or vibration properly so that it does not affect

the person.

Area with Inflammables and Explosives

In any area with inflammables and explosives, power off your phone and do not

take out, install or charge the battery, to avoid explosion and fire. Areas with

inflammables and explosives include, but are not limited to:

z Gas station

z Area for storing fuels (such as the bunk under the deck of a ship)

z Device/Vehicle for transporting and storing fuels or chemical products

z Area with chemical substances and particles (such as: granule, dust, metal

powder) in the air

z Area with the sign of "Explosives"

z Area with the sign of "Power off bi-direction wireless equipment"

z Area where it is generally suggested to stop the engine or a vehicle

Traffic Safety

z Please observe local laws and regulations on phone use. Do not use your

phone while driving to avoid traffic accident.

z Secure the phone on its holder. Do not place the phone on the seat or other

places where it can get loose in a sudden stop or collision.

z Use the phone after the vehicle stops at a safe place.

z If your phone supports the hands-free function, or the phone can be used with

earphones, or there is any vehicle-mounted equipment with hands-free

function, use them in emergency.

z Do not place the phone over the air bag or in the air bag outspread area.

Otherwise, the phone may hurt you owing to the strong force when the air bag

inflates.

z Observe the rules and regulations of airline companies. When boarding or

approaching a plane, power off the phone and take out the battery. In areas

where phone use is prohibited, power off the phone. Otherwise, the radio

signal of the phone may disturb the plane control signals. Power off your

phone before boarding an aircraft.

Storage Environment

z Do not place magnetic storage media such as magnetic cards and floppy disks

near the phone. Radiation from the phone may erase the information stored on

them.

z Do not put your phone, battery, or other accessories in containers with strong

magnetic field, such as an induction cooker and a microwave oven. Otherwise,

circuit failure, fire, or explosion may occur.

z Do not leave your phone, battery, or charger in a very hot or cold place.

Otherwise, malfunction of the products, fire, or explosion may occur.

z Keep the ambient temperature between 0℃ and 45 while the battery is ℃

being charged. Keep the ambient temperature between –20℃ and 60 for ℃

storing the battery. If the ambient temperature is too low (especially below

0 ) or too high, the capacity and life of the battery will be reduced.℃

z Do not place sharp metal objects such as pins near the earpiece. The earpiece

may attract these objects and hurt you when you are using the phone.

z Do not subject your phone, battery, and charger to serious collision or shock.

Otherwise, battery leakage, phone malfunction, overheat, fire, or explosion

may occur.

z Do not put your phone in the back pocket of your trousers or skirt, to avoid

phone damage while seated.

Children Safety

z Put your phone, battery, and charger in places beyond the reach of children.

Do not allow children to use the phone, battery, or charger without guidance.

z Do not allow children to put the battery in mouth, for electrolyte in the battery

is poisonous.

z Do not allow children to touch the small fittings. Otherwise, suffocation or

gullet jam can be caused if children swallow the small fittings.

Operating Environment

z The phone, battery, and charger are not water-resistant. Keep them dry.

Protect the phone, battery and charge from water or vapor. Do not touch the

phone with a wet hand. Otherwise, short-circuit and malfunction of the

product or electric shock may occur.

z Do not use the phone in dusty, damp and dirty places or places with magnetic

field. Otherwise, malfunction of the circuit may occur.

z Do not power on or off the phone when it is near your ears to avoid negative

impact on your health.

z When carrying or using the phone, keep the antenna at least one inch (2.5

centimeters) away from your body, to avoid negative impact on your health

caused by radio frequency leakage.

z If you feel uncomfortable (such as falling sick or qualm) after playing games

on your phone for a long time, please go to see a doctor immediately.

z On a thunder stormy day, do not use your phone outdoors or when it is being

charged.

z Do not touch the antenna when a call is going on. Touching the antenna may

affect call quality and cause the phone to operate with more power. As a result,

the talk time and standby time are shortened.

z The phone may interfere with nearby TV sets, radios and PCs.

z In accordance with international standards for radio frequency and radiation,

use phone accessories approved by the manufacturer only.

z While using the mobile phone, observe the local laws and regulations, and

respect others' privacy and legal rights.

Clearing and Maintenance

z Before you clean or maintain the phone, power off the phone and disconnect it

from the charger. Otherwise, electric shock or short-circuit of the battery or

charger may occur.

z Do not use any chemical detergent, powder, or other chemical agent (such as

alcohol and benzene) to clean the phone and the charge. Otherwise, part

damage or a fire can be caused. You can clean the phone and the charger with

a piece of soft antistatic cloth that is a little wet.

z Do not scratch the shell of the phone. Otherwise, the shed coating may cause

skin allergy. Once it happens, stop using the phone at once and go to see a

doctor.

z Keep the plug dry when you clean it, to prevent fire.

z If the phone or any of its fittings does not work, turn to the local authorize

service center for help.

z Do not dismantle the mobile phone or accessories. Only an authorized service

center is allowed to maintain the mobile phone.

Environment Protection

z Please observe the local regulations regarding the disposal of your packaging

materials, exhausted battery and old phone and please promote their recycling.

Do not dispose of exhausted battery or old phone in municipal waste or fire.

Otherwise, explosion may occur.

z This HUAWEI device complies with Directive 2002/95/EC on the restriction

of the use of certain hazardous substances in electrical and electronic

equipment.

z : This symbol indicates that the equipment carrying this mark must NOT

be thrown into general waste but should be collected separately and properly

recycled under local regulations.

Emergency Call

You can use your phone for emergency calls. However, connections in all

conditions cannot be guaranteed. You should never rely solely on the phone for

essential communications.

Battery

z Use the battery approved by the manufacturer only. Otherwise, explosion may

occur.

z Do not dispose of the battery in fire. Otherwise, the battery may ignite or

explode.

z Do not connect two poles of the battery with conductors such as cables,

jewelries or any other metal material. Otherwise, the battery is short-circuited

and it may burn your body.

z Do not disassemble the battery or solder the battery poles. Otherwise fluid

leakage, overheat, fire, or explosion may occur.

z If there is battery leakage, smoke, or strange smell, stop using the battery and

keep it away from open flame to avoid fire or explosion. Then turn to an

authorized maintenance engineer for help.

z If the battery fluid contacts your skin or cloth, wash with clean water

immediately to avoid irritation to the skin.

z If the battery fluid gets into eyes, do not rub your eyes. Otherwise, your eyes

can be hurt. Wash with clean water and go to see a doctor immediately.

z If there is battery deformation, color change or abnormal heating while you

charge or store the battery, take it out immediately and stop using it.

Otherwise, battery leakage, overheat, explosion, or fire may occur.

z When installing the battery, do not push the battery by force lest battery fluid

leak out or the battery crack.

z Do not take out the battery when the phone is turned on.

z If you do not use the battery for a long time, store it in normal temperature

after charging.

Charger

z Use the charger approved by the phone manufacturer only. Any violation of

this rule may result in fire or malfunction of the charger.

z Do not short-circuit the charger. Short-circuiting the charger may cause fire or

malfunction of the charger.

z If the power cord is damaged (for example, the lead is exposed or broken), or

the plug becomes loose, stop using the cable at once. Otherwise, electric

shock, short-circuit of the charger, or fire may occur.

z Keep the charger dry. Once water or other liquid leaks into the charger,

electrical leakage or other faults may occur.

z Do not use the charger in a dusty and damp environment. Keep the power

cord away from any heating appliance.

z Ensure the charger is properly plugged into the power socket properly when

charging the battery. Improper insertion may result in electric shock, fire, or

explosion. To unplug the charger, pull the plug off rather than tear the power

cord.

z Use the AC power supply defined in the specifications of the charger. An

improper power voltage can cause fire or malfunction of the charger.

z Do not place any heavy object on the power cord of the charger. Do not

damage, change, or pluck the power cord. Otherwise electric shock or fire

may occur.

z When you are charging the battery with the charger, do not touch the plug,

power cord or the charger with a wet hand. Otherwise, electric shock can be

caused.

z Once the liquid such as water leaks into the charger, remove the plug of the

charger from the socket immediately. Otherwise, overheating, fire and other

malfunction may occur.

Certification Information (SAR)

THIS DEVICE MEETS THE GOVERNMENT'S REQUIREMENTS

FOR EXPOSURE TO RADIO FREQUENCY

ELECTROMAGNETIC FIELD.

Your mobile phone is a low-power radio transmitter and receiver. When it is

turned on, it emits low levels of radio frequency energy (also known as radio

waves or radio frequency fields).

Governments around the world have adopted comprehensive international safety

guidelines, developed by scientific organizations, e.g. ICNIRP (International

Commission on Non-Ionizing Radiation Protection) and IEEE (Institute of

Electrical and Electronics Engineers Inc.), through periodic and thorough

evaluation of scientific studies. These guidelines establish permitted levels of

radio wave exposure for the general population. The levels include a safety

margin designed to assure the safety of all persons, regardless of age and health,

and to account for any variations in measurements.

Specific Absorption Rate (SAR) is the unit of measurement for the amount of

radio frequency energy absorbed by the body when using a mobile phone. The

SAR value is determined at the highest certified power level in laboratory

conditions, but the actual SAR level of the mobile phone while operating can be

well below the value. This is because the mobile phone is designed to use the

minimum power required to reach the network.

All models of Huawei's mobile phone are designed to meet radio frequency

exposure guidelines. Before a phone model is available for sale to the public, it

must be tested and certified to the FCC that it does not exceed the limit

established by the government-adopted requirement for safe exposure. The tests

are performed in positions and locations (that is, at the ear and worn on the body)

as required by the FCC for each model. For body worn operation, this phone has

been tested and meets FCC RF exposure guidelines when the handset is

positioned a minimum of 15 mm from the body with an accessory that contains

no metal part. Use of other accessories may not ensure compliance with FCC RF

exposure guidelines.

The SAR limit adopted by the USA and Canada is 1.6 watts/kilogram (W/kg)

averaged over one gram of tissue. The highest SAR value reported to the FCC and

IC for this device type when tested for use at the ear is 0.502 W/kg, and when

properly worn on the body is 0.381 W/kg.

The SAR limit adopted by the CNIRP is 2.0W/kg over one gram of tissue. The

value guarantees a safe distance to protect mobile phone users and the difference

caused by measurement errors. Under different test requirements and frequency,

the value varies.

Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. Operation is subject to the condition that this device does not cause

harmful interface.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

z Reorient or relocate the receiving antenna.

z Increase the separation between the equipment and receiver.

z Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

z Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications made to this equipment not expressly

approved by HUAWEI may void the FCC authorization to operate this

equipment.

Version: V100R001C03_01 Part Number: 31018020

Huawei Technologies C3308 CDMA 1X Mobile Phone User Manual

Huawei Technologies Co.,Ltd CDMA 1X Mobile Phone

Users Manual

Navigation menu

Namespaces

Views

Navigation
