Huawei Technologies C3500 CDMA 1X Digital Mobile Phone User Manual

Huawei Technologies Co.,Ltd CDMA 1X Digital Mobile Phone

User Manual

Copyright © 2009 Huawei Technologies Co., Ltd.
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form
or by any means without prior written consent of Huawei
Technologies Co., Ltd.
Trademarks
and other Huawei trademarks are the trademarks or registered
trademarks of Huawei Technologies Co., Ltd. in the People’s
Republic of China and certain other countries.
All other trademarks mentioned in this manual are the property of
their respective holders.
Notice
The information in this manual is subject to change without notice.
Every effort has been made in the preparation of this manual to
ensure accuracy of the contents, but all statements, information, and
recommendations in this manual do not constitute the warranty of
any kind, express or implied.
i
Table of Contents
1 Your Phone.....................................................................................1
2 Keys and Functions........................................................................3
3 Screen Icons....................................................................................5
4 Menu Tree ......................................................................................6
5 Installing the Battery.....................................................................7
6 Charging the Battery.....................................................................7
7 Using the Function Menu..............................................................7
8 Making a Call.................................................................................8
9 Answering a Call............................................................................9
10 Recording a Voice Clip ...............................................................9
11 Switching On the Radio ............................................................10
12 Playing Music.............................................................................10
13 Phone Lock.................................................................................11
14 Locking the Keypad...................................................................11
15 Changing the Text Input Modes ..............................................11
16 Entering English (En)................................................................12
17 Entering English (Abc)..............................................................12
18 Entering Spanish........................................................................13
19 Entering Numbers .....................................................................13
20 Entering Symbols.......................................................................13
21 Warnings and Precautions........................................................14
1 Your Phone
*Key
Speaker #Key
Charger Interfac
End/Power Key
Confirm Key
Right Soft Key
Earpiece
Left Soft Key
Talk/Send Key
Number Keys
Screen
Clear Kye
e
Music Key
1
Headset Jack
2
2 Keys and Functions
Press… To…
z Power on or off the phone (by pressing and holding
it).
z End a call or reject an incoming call.
z Return to the standby mode.
z View the call log in the standby mode.
z Make or answer a call.
z Display the Menu interface in the standby mode.
z Confirm a selection.
Select the option displayed on the lower left corner of
the screen.
Select the option displayed on the lower right corner of
the screen.
z Display the Profiles interface ( ), the Messages
interface ( ), the Create Message interface (by
pressing and holding ), the Brew interface
(), and the FM Radio interface ( ) in the
standby mode.
z Increase the volume ( or ) or decrease the
volume ( or ) during a call.
3
Press… To…
z Enter numbers, letters, and symbols.
z Access the voice mailbox in the standby mode (by
pressing and holding the 1 key).
z Speed-dial phone numbers in the standby mode (by
pressing and holding the 2–9 keys).
z Select a submenu item labeled with the
corresponding number.
z Enter the * symbol.
z Enable or disable the Meeting profile (by pressing
and holding it).
z Provide different functions according to the phone
features being used.
z Enter the # symbol.
z Lock the keypad in the standby mode (by pressing
and holding it).
z Provide different functions according to the phone
features being used.
z Launch the Media Player.
z Minimize or exit the Media Player.
z Delete items, such as pictures, sounds, and contacts.
z Delete letters in edit mode.
4
3 Screen Icons
Icon Description Icon Description
Network signal strength Battery power level
No network signal Calling
CDMA 1X network Alarm clock on
Domestic roaming General profile
Overseas roaming Silence profile
Memory for messages full Meeting profile
Call privacy enabled Outdoor profile
New message My Profile
New message
Voice mail received Voice mail received
Keypad locked
The earpiece
function
5
4 Menu Tree
6
1 Search
2 Search By Location
3 Add New
4 Groups
5 Speed Dial
6 My Number
7 Management
MessagesMessages
1 Create Message
2 Inbox
3 Outbox
4 Drafts
5 Voice Mail
6 Quick Text
7 Settings
8 Delet All
Call Log
1 All Calls
2 Missed Calls
3 Received Calls
4 Dialled Calls
5 Call Memo
6 Call Duration
Call LogCall Log
1 All Calls
2 Missed Calls
3 Received Calls
4 Dialled Calls
5 Call Memo
6 Call Duration
1 General
2 Silence
3 Meeting
4 Outdoor
5 My Profile 1
6 My Profile 2
(Options when no
channel saved)
1 Automatic Tuning
2 Manual Tuning
3 Fine Tuning
4 Set Frequency
(Options when some
channels saved)
1 Switch Off
2 Speaker On/Off
3 Start Record
4 Tuning
5 Delete Channel
6 Rename Channel
Radio Radio
You can consult your
service provider for
more information about
this function. This
function may involve
extra charges.
Profiles
6 World Clock
7 Gallery
1 Recorder
2 Alarms
3 Scheduler
4 Calculator
5 Stopwatch
Tools
6 World Clock
7 Gallery
1 Recorder
2 Alarms
3 Scheduler
4 Calculator
5 Stopwatch
ToolsTools
1 Display Settings
2 Date & Time
3 Call Settings
4 Phone Settings
5 Security Settings
6 Restore Factory
Settings
SettingsSettings
Contacts
Music Player
Brew Brew
5 Shuffl
6 Loop
7 Equalizer
1 To background
2 Playing queue
3 Playlist
4 Stop e
5 Installing the Battery
6 Charging the Battery
1. Connect the charger to the charger interface at the bottom of your
phone.
2. Connect the charger to an alternating current (AC) power socket.
3. During the charging, the charging icon is displaying in animation.
4. When the charging icon becomes static, the phone is fully charged.
Disconnect the charger from the AC power socket.
5. Disconnect the charger from the phone.
7 Using the Function Menu
1. In the standby mode, press (Menu) to display the Menu
interface.
2. Press to scroll to a menu item.
3. Press (Select) or to display the menu.
4. Do the following to display the submenu:
7
z Press to scroll to a submenu item and press (Select)
or to display the submenu.
z Press the number key corresponding to the number of a submenu
to display it.
5. Press (Back) to return to the previous menu or quit the
function menu.
Alternatively, press to return to the standby mode.
8 Making a Call
1. In the standby mode, enter a phone number.
z To make an international call, press twice to enter the
international long distance code of "+". Then enter the number to
be dialled, in the format of "country code + region code + phone
number".
z To call a number with an extension, press three times to
insert "P" or press four times to insert "T" between the
phone number and the extension.
2. Press to dial the number.
3. Press to end the call.
8
Note
z When the phone is locked, enter the lock code to unlock
the phone first; otherwise, you can make only emergency
calls or answer calls.
z In the standby mode, press to view the call log.
Select a record and press to dial.
z Select a contact from the phonebook and press to
dial.
z Select a message from the inbox and press to dial.
9 Answering a Call
When there is an incoming call, press , (Answer), or
to answer it, press (Silence) to mute it and then press
(Reject) to reject it, or press to reject it.
z If the Any Key Answer function is enabled, press any key
(except or ) to answer an incoming call.
z If the Headset Auto Answer function is enabled, and the headset
is connected to the phone, the incoming call is answered
automatically.
z If the headset is connected to the phone, you can press the button
on the headset cable to answer or end a call.
10 Recording a Voice Clip
1. In the standby mode, select Menu > Tools > Recorder.
2. Press to start recording.
3. Press (Stop) or to stop recoding.
4. Press to play the voice clip.
9
All the voice clips are saved in the Menu > Tools > Gallery > Voice
Folder.
11 Switching On the Radio
1. Insert the headset to the headset jack properly.
2. In the standby mode, select Menu > Radio.
3. Press to tune the channel.
4. Press to adjust the volume.
12 Playing Music
1. In the standby mode, do the follows to add a playlist:
z Select Menu > Music Player, press ( Option) > Playlist
and ( Add) to add new playlist. (If playlist already exist,
select a playlist, and then press key to select Add New
Playlist.)
z Enter the name of the playlist, and press (OK).
z Press (Add) > From My Files or From Playlists to add
songs.
z Press (Option) > Add to save the settings.
2. In the standby mode, select Menu > Media Player to access the
media player.
3. Press to select a playlist.
4. Press (Option) > Play to play music.
5. Press to minimize or access the player.
10
13 Phone Lock
The phone lock protects your phone from unauthorized use. The
default phone lock code is 1234. You can change it into any numeric
string of 4 to 8 digits.
If the phone lock is enabled, you need to enter the correct phone lock
code when the phone is powered on or in the standby mode.
14 Locking the Keypad
In the standby mode, press and hold to lock the keypad.
When the keypad is locked, press to answer incoming calls or
make emergency calls.
You can press (Unlock) and to unlock the keypad.
When the keyguard function is enabled, if there is no operation on
the phone for a preset period in the standby mode, the keypad is
locked automatically.
15 Changing the Text Input Modes
The indicator of the current text input mode is displayed on the
screen. Press to change the input mode.
11
Note z In the editing mode, press (Clear) once to delete
the letter on the left of the cursor. Press and hold
(Clear) to delete all the letters at a time.
z In the "En" or "Smsp" input mode, press to enter a
space. In the "Abc" or "Es" input mode, press once
to enter a space and twice to enter 0.
z In the "Abc" or"Es" input mode, press repeatedly
to select and enter the commonly-used punctuations. In
the "En" or "Smsp" input mode, press repeatedly
to enter a full stop or smiley.
16 Entering English (En)
In the "En" input mode, do the following to enter the English letters:
1. Press each key only once according to the spelling sequence of
the desired word. Then the phone displays the commonly used
words according to the numeric sequence of key presses.
2. Press to scroll to the desired word.
3. Press to switch the selected characters between upper
case and lower case.
4. Press or to enter the word.
Press to enter the word and a space.
17 Entering English (Abc)
In the "Abc" input mode, you can press a key labeled the desired
letters once to enter the first letter on the key, twice to enter the
second letter on the key, and so on.
12
When you enter letters, press to switch between the
uppercase and lowercase of the highlighted letter.
If the letter you want to enter is on the same key as the previous one,
enter the latter only after the cursor appears again or after you press
to move the cursor to the next space.
18 Entering Spanish
You can enter Spanish words in the "Smsp" or "Es" input mode.
Spanish input mode is similar to English input mode. For details, see
"Entering English (En)" and "Entering English (Abc)".
19 Entering Numbers
z In the "123" input mode, press a key labeled the desired number.
z In the "Abc" or "Es" input mode, press a key repeatedly or press
and hold it until the desired number appears on the screen.
z In the "En" or "Smsp" input mode, press a key and then press
until the desired number appears on the screen. Or press
and hold a key until the desired number appears on the screen.
20 Entering Symbols
1. In any input mode, press to display a symbol list.
2. Press or to scroll to the desired symbol.
3. Press the numeric key to enter the symbol.
13
14
21 Warnings and Precautions
Electronic Device
z Power off your phone near high-precision electronic devices. The
phone may affect the performance of these devices.
z Such devices include hearing aids, pacemakers, fire alarm
systems, automatic gates, and other automatic control devices. If
you are using an electronic medical device, consult the device
manufacturer to confirm whether the radio wave affects the
operation of this device.
z Pacemaker manufacturers recommend that a minimum distance of
15cm be maintained between a mobile phone and a pacemaker to
avoid potential interference with the pacemaker. To achieve this,
use the phone on the opposite ear to your pacemaker and do not
carry it in a breast pocket.
Hospital
Pay attention to the following points at hospitals or health care
facilities:
z Do not take your phone into the operating room (OR), intensive
care unit (ICU), or coronary care unit (CCU).
z Do not use your phone at places for medical treatment where
phone use is prohibited.
z When using your phone near someone who is suffering from a
heart disease, turn down the ring tone volume or vibration
properly so that it does not affect the person.
Area with Inflammables and Explosives
In any area with inflammables and explosives, power off your phone
and do not take out, install or charge the battery, to avoid explosion
and fire. Areas with inflammables and explosives include, but are not
limited to the following:
z Gas station
15
p)
z hicle for transporting and storing fuels or chemical
z particles (such as granule,
z "Power off bi-directional wireless
z re it is generally suggested to stop the engine of a
v
z Do not
z the seat
z
z
may hurt you owing to the strong force
z
gnals. Power off your phone before boarding
a
z Area for storing fuels (such as the bunk under the deck of a shi
Device/ve
products
Area with chemical substances and
dust and metal powder) in the air
z Area with the sign of "Explosives"
Area with the sign of
equipment"
Area whe
ehicle
Traffic Safety
Please observe local laws and regulations on phone use.
use your phone while driving to avoid traffic accident.
Secure the phone on its holder. Do not place the phone on
or other places where it can get loose in a sudden stop or
collision.
z Use the phone after the vehicle stops at a safe place.
If your phone supports the hands-free function, or the phone can
be used with earphones, or there is any vehicle-mounted
equipment with hands-free function, use them in emergency.
Do not place the phone over the air bag or in the air bag outspread
area. Otherwise, the phone
when the air bag inflates.
Observe the rules and regulations of airline companies. When
boarding or approaching a aircraft, power off the phone and take
out the battery. In areas where phone use is prohibited, power off
the phone. Otherwise, the radio signal of the phone may disturb
the aircraft control si
n aircraft.
16
z
y
z
and life
z
z charger to serious
c erwise, battery leakage, phone malfunction,
z skirt,
le seated.
z ildren to put the battery in mouth, for electrolyte
n
Storage Environment
Do not place magnetic storage media such as magnetic cards and
floppy disks near the phone. Radiation from the phone may erase
the information stored on them.
z Do not put your phone, battery, or other accessories in containers
with strong magnetic field, such as an induction cooker and a
microwave oven. Otherwise, circuit failure, fire, or explosion ma
occur.
Do not leave your phone, battery, or charger in a very hot or cold
place. Otherwise, malfunction of the products, fire, or explosion
may occur.
Keep the ambient temperature b
z etween 0°C and 45°C while the
battery is being charged. Keep the ambient temperature between
–20°C and 60°C for storing the battery. If the ambient temperature
is too low (especially below 0°C) or too high, the capacity
of the battery will be reduced.
Do not place sharp metal objects such as pins near the earpiece.
The earpiece may attract these objects that can hurt you when you
are using the phone.
Do not subject your phone, battery, and
ollision or shock. Oth
overheat, fire, or explosion may occur.
Do not put your phone in the back pocket of your trousers or
to avoid phone damage whi
Children Safety
Put your phone, battery, and
z charger at places beyond the reach of
children. Do not allow children to use the phone, battery, or
charger without guidance.
Do not allow ch
i the battery is poisonous.
17
z
z
duct or electric shock may
z
ay
z
on your health.
) away from your body, to avoid negative
z
diately.
en
z
a may affect call quality and cause the phone to operate
e are
T rby TV sets, radios and PCs.
Do not allow children to touch the small fittings. Otherwise,
suffocation or gullet jam can be caused if children swallow the
small fittings.
Operating Environment
The phone, battery, and charger are not water-resistant. Keep
them dry. Protect the phone, battery and charger from water or
vapor. Do not touch the phone with a wet hand. Otherwise,
short-circuit and malfunction of the pro
occur.
Do not use the phone in dusty, damp and dirty places or places
with magnetic field. Otherwise, malfunction of the circuit m
occur.
Do not power on or off the phone when it is near your ears to
avoid negative impact
z When carrying or using the phone, keep the antenna at least one
inch (2.5 centimeters
impact on your health caused by radio frequency leakage.
If you feel uncomfortable (such as falling sick or qualm) after
playing games on your phone for a long time, please go to see a
doctor imme
z On a thunder stormy day, do not use your phone outdoors or wh
it is being charged.
Do not touch the antenna when a call is going on. Touching the
antenn
with more power. As a result, the talk time and standby tim
shortened.
z he phone may interfere with nea
z In accordance with international standards for radio frequency and
radiation, use phone accessories approved by the manufacturer
only.
z While using the mobile phone, observe the local laws and
regulations, and respect others' privacy and legal rights.
18
z nd
z
d the
. You can
ating
z
ed service center is allowed to maintain the mobile phone.
z
sted battery and old phone, and please
C on the
re certain hazardous substances in electrical
Clearing and Maintenance
Before you clean or maintain the phone, power off the phone a
disconnect it from the charger. Otherwise, electric shock or
short-circuit of the battery or charger may occur.
Do not use any chemical detergent, powder, or other chemical
agent (such as alcohol and benzene) to clean the phone an
charge. Otherwise, part damage or a fire can be caused
clean the phone and the charger with a piece of soft antistatic
cloth that is a little wet.
z Do not scratch the shell of the phone. Otherwise, the shed co
may cause skin allergy. Once it happens, stop using the phone at
once and go to see a doctor.
z Keep the plug dry when you clean it, to prevent fire.
z If the phone or any of its fittings does not work, turn to the local
authorized service center for help.
Do not dismantle the mobile phone or accessories. Only an
authoriz
Environment Protection
Please observe the local regulations regarding the disposal of your
packaging materials, exhau
promote their recycling. Do not dispose of exhausted battery or
old phone in municipal waste or fire. Otherwise, explosion may
occur.
This HUAWEI device complies with Directive 2002/95/E
z
striction of the use of
and electronic equipment.
z : This symbol indicates that the equipment carrying this mark
m wn into general waste but should be collected
ust NOT be thro
separately and properly recycled under local regulations.
19
Y
on
z
z age, smoke, or strange smell, stop using the
z d contacts your skin or cloth, wash with clean
z your eyes. Otherwise,
e a
y, take it out immediately and
st Otherwise, battery leakage, overheat, explosion, or
z est
uid leak out or the battery crack.
z e, store it in normal
temperature after charging.
Emergency Call
u can use your phon
o e for emergency calls. However, connections
in all conditions cannot be guaranteed. You should never rely solely
the phone for essential communications.
Battery
z Use the battery approved by the manufacturer only. Otherwise,
explosion may occur.
z Do not dispose of the battery in fire. Otherwise, the battery may
ignite or explode.
Do not connect two poles of the battery with conductors such as
cables, jewelries or any other metal material. Otherwise, the
battery is short-circuited and it may burn your body.
z Do not disassemble the battery or solder the battery poles.
Otherwise fluid leakage, overheat, fire, or explosion may occur.
If there is battery leak
battery and keep it away from open flame to avoid fire or
explosion. Then turn to an authorized maintenance engineer for
help.
If the battery flui
water immediately to avoid irritation to the skin.
If the battery fluid gets into eyes, do not rub
your eyes can be hurt. Wash with clean water and go to se
doctor immediately.
z If there is battery deformation, color change or abnormal heating
while harge or store the batter
you c
op using it.
fire may occur.
When installing the battery, do not push the battery by force l
battery fl
z Do not take out the battery when the phone is turned on.
If you do not use the battery for a long tim
20
z
y
r
ay
z
may occur.
he
W the charger, do not touch
eaks into the charger, remove the
Charger
Use the charger approved by the phone manufacturer only. Any
violation of this rule may result in fire or malfunction of the
charger.
z Do not short-circuit the charger. Short-circuiting the charger ma
cause fire or malfunction of the charger.
z If the power cord is damaged (for example, the lead is exposed o
broken), or the plug becomes loose, stop using the cable at once.
Otherwise, electric shock, short-circuit of the charger, or fire m
occur.
Keep the charger dry. Once water or other liquid leaks into the
charger, electrical leakage or other faults
z Do not use the charger in a dusty and damp environment. Keep
the power cord away from any heating appliance.
z Ensure the charger is properly plugged into the power socket
when charging the battery. Improper insertion may result in
electric shock, fire, or explosion. To unplug the charger, pull t
plug off rather than tear the power cord.
z Use the AC power supply defined in the specifications of the
charger. An improper power voltage can cause fire or malfunction
of the charger.
z Do not place any heavy object on the power cord of the charger.
Do not damage, change, or pluck the power cord. Otherwise
electric shock or fire may occur.
z hen you are charging the battery with
the plug, power cord or the charger with a wet hand. Otherwise,
electric shock can be caused.
z Once the liquid such as water l
plug of the charger from the socket immediately. Otherwise,
overheating, fire and other malfunction may occur.
21
,
y
d
to the FCC that it
t
Certification Information (SAR)
THIS DEVICE MEETS THE GOVERNMENT'S REQUIREMENTS
FOR EXPOSURE TO RADIO FREQUENCY
ELECTROMAGNETIC FIELD.
Your mobile phone is a low-power radio transmitter and receiver.
When it is turned on, it emits low levels of radio frequency energy
(also known as radio waves or radio frequency fields).
Governments around the world have adopted comprehensive
international safety guidelines, developed by scientific organizations
e.g. ICNIRP (International Commission on Non-Ionizing Radiation
Protection) and IEEE (Institute of Electrical and Electronics
Engineers Inc.), through periodic and thorough evaluation of
scientific studies. These guidelines establish permitted levels of radio
wave exposure for the general population. The levels include a safet
margin designed to assure the safety of all persons, regardless of age
and health, and to account for any variations in measurements.
Specific Absorption Rate (SAR) is the unit of measurement for the
amount of radio frequency energy absorbed by the body when using
a mobile phone. The SAR value is determined at the highest certifie
power level in laboratory conditions, but the actual SAR level of the
mobile phone while operating can be well below the value. This is
because the mobile phone is designed to use the minimum power
required to reach the network.
All models of Huawei's mobile phone are designed to meet radio
frequency exposure guidelines. Before a phone model is available for
sale to the public, it must be tested and certified
does not exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed in positions
and locations (that is, at the ear and worn on the body) as required by
the FCC for each model. For body worn operation, this phone has
been tested and meets FCC RF exposure guidelines when the handse
is positioned a minimum of 15 mm from the body with an accessory
that contains no metal part. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
22
gram
value
d IC for this device type when tested for use at
er one gram of
e
alled and used in accordance with the
radio e
n
n between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The SAR limit adopted by the USA and Canada is 1.6 watts/kilo
(W/kg) averaged over one gram of tissue. The highest SAR
reported to the FCC an
the ear is 1.16 W/kg, and when properly worn on the body is 0.888
W/kg.
The SAR limit adopted by the CNIRP is 2.0 W/kg ov
tissue. The value guarantees a safe distance to protect mobile phon
users and the difference caused by measurement errors. Under
ferent test requirements and frequency, the value v
dif aries.
Statement
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
z This device may not cause harmful interference.
z This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This equipment generates, uses and can radiate radio frequency
energy and, if not inst
instructions, may cause harmful interference to
communications. However, there is no guarantee that interferenc
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which ca
determined by turning the equipment off
be and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
z Reorient or relocate the receiving antenna.
z Increase the separatio
z
z
23
Warning: Changes or modifications made to this equipment not
expressly approved by HUAWEI may void the FCC authorization to
operate this equipment.

Navigation menu
