Huawei Technologies CAG-L23 Smart Phone User Manual Quick Start Guide
Huawei Technologies Co.,Ltd Smart Phone Quick Start Guide
User manual
Quick Start Guide
Model：CAG-L03
CAG-L23
Smart Phone
CAG-L23
Your device at a glance
Before you start, let's take a look at your new device.
lTo power on your device, press and hold the power
button until the screen turns on.
lTo power off your device, press and hold the power
button, and then touch .
1
2
3
4
45
6
7
12
11
10
9
8
Rear camera Speaker
Light sensor Microphone
Micro-USB port Power button
Volume button Earpiece
Status indicator Front camera
Flash Headset jack
lTo force your device to restart, press and hold the
power button until your device vibrates.
1
Getting Started
Follow the instructions in the following figures to set up
your device.
2
1
3
4
CAG-L03
Micro
SIM
1
23
4
CAG-L23
Micro
SIM
Micro
SIM
lDo not insert or remove the SIM card when your
device is powered on.
Do not use cut or modified SIM or microSD cards with
your device as these may not be recognized and could
damage the card tray (slot).
2
Dual card dual standby single
pass (only applies to CAG-L23)
Your device supports only dual card dual standby single
pass, which means you cannot use both SIM cards for calls
or data services simultaneously.
lWhen you are on a call using SIM card 1, SIM card 2
cannot be used to make or answer calls. If someone
calls SIM card 2, the caller will hear a voice message
similar to "The subscriber you dialed is out of the service
area" or "The subscriber you dialed cannot be connected
for the moment, please try again later." The actual
message will vary by service provider.
lWhen you are using SIM card 1's data service, SIM card
2's data service will be disabled.
Your device's single pass feature helps reduce power
consumption and increase your device's standby time. It is
not related to your service provider's network conditions.
It may be a good idea to contact your service provider and
subscribe to missed call reminder and related assistance
services to avoid the conflicts mentioned above.
3
For more information
If you encounter any problems while using your device, you
can obtain help from the following resources:
lVisit http://consumer.huawei.com/en to view device
information, frequently asked questions and other
information.
lVisit http://consumer.huawei.com/en/support for the most
up-to-date contact information for your country or region.
Go to Settings and touch System > About phone > Legal
information to view legal information for your product.
Go to Settings and touch System > About phone > Legal
information > Safety information to view safety
information for your product.
Go to Settings and touch System > About phone >
Authentication info to view regulatory information for your
product.
Go to Settings and touch System > Certification logos to
view more information on certification logos for your
product.
All pictures and illustrations in this guide, including but
not limited to the product color, size, and display
content, are for your reference only. The actual
product may vary. Nothing in this guide constitutes a
warranty of any kind, express or implied.
4
Safety Information
Please read all of the safety information carefully before
using your device to ensure its safe and proper operation
and to learn how to dispose of your device properly.
Operation and safety
l To prevent possible hearing damage, do not
listen at high volume levels for long periods.
lUsing an unapproved or incompatible power adapter,
charger, or battery may damage your device, shorten its
lifespan, or cause a fire, explosion, or other hazards.
lIdeal operating temperatures are 0 °C to 35 °C. Ideal
storage temperatures are -20 °C to +45 °C.
lPacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and
a pacemaker to prevent potential interference with the
pacemaker. If using a pacemaker, hold the device on the
side opposite the pacemaker and do not carry the device
in your front pocket.
lKeep the device and the battery away from excessive
heat and direct sunlight. Do not place them on or in
heating devices, such as microwave ovens, stoves, or
radiators.
lObserve local laws and regulations while using the
device. To reduce the risk of accidents, do not use your
wireless device while driving.
lWhile flying in an aircraft or immediately before
boarding, only use your device according to instructions
provided. Use of a wireless device in an aircraft may
disrupt wireless networks, present a hazard to aircraft
operation, or be illegal.
lTo prevent damage to your device's parts or internal
circuits, do not use it in dusty, smoky, damp, or dirty
environments or near magnetic fields.
lWhen charging the device, make sure the power adapter
is plugged into a socket near the devices and is easily
accessible.
lUnplug the charger from electrical outlets and the device
when not in use.
5
lDo not use, store or transport the device where
flammables or explosives are stored (in a gas station, oil
depot, or chemical plant, for example). Using your
device in these environments increases the risk of
explosion or fire.
lDispose of this device, the battery, and accessories
according to local regulations. They should not be
disposed of in normal household waste. Improper battery
use may lead to fire, explosion, or other hazards.
FCC Regulatory Compliance
Body worn operation
The device complies with RF specifications when used
near your ear or at a distance of 1.50 cm from your body.
Ensure that the device accessories, such as a device case
and device holster, are not composed of metal
components. Keep the device away from your body to meet
the distance requirement.
Certification information (SAR)
This device is also designed to meet the requirements for
exposure to radio waves established by the Federal
Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged
over one gram of tissue. The highest SAR value reported to
the FCC for this device type complies with this limit.
The highest SAR value reported to the FCC for this device
type when using it at the ear is
CAG-L03 1.01 W/kg
CAG-L23 1.01 W/kg
And when properly worn on the body is
CAG-L03 0.63 W/kg
CAG-L23 0.63 W/kg
And when using the Wi-Fi hotspot function is
CAG-L03 1.35 W/kg
CAG-L23 1.35 W/kg
FCC statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
6
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and
receiver.
--Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Caution: Any changes or modifications to this device not
expressly approved by Huawei Technologies Co., Ltd. for
compliance could void the user's authority to operate the
equipment.
7
Legal Notice
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Android™ is a trademark of Google Inc.
LTE is a trademark of ETSI.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Huawei Technologies Co., Ltd. is under
license.
Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are
trademarks of Wi-Fi Alliance.
Privacy Policy
To better understand how we protect your personal
information, please see the privacy policy at http://
consumer.huawei.com/privacy-policy.
Copyright © Huawei Technologies Co., Ltd.
2018. All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE
ONLY, AND DOES NOT CONSTITUTE ANY KIND OF
WARRANTIES.
