Huawei Technologies ES8100 GSM Mobile Phone User Manual TempConfidential ES8100 Use manual 20120120
Huawei Technologies Co.,Ltd GSM Mobile Phone TempConfidential ES8100 Use manual 20120120
TempConfidential_(ES8100)Use manual_20120120
Copyright © Huawei Technologies Co., Ltd. 2011.
All rights reserved.
No part of this document may be reproduced or transmitted in
any form or by any means without prior written consent of
Huawei Technologies Co., Ltd.The product described in this
manual may include copyrighted software of Huawei
Technologies Co., Ltd. and possible licensors. Customers shall
not in any manner reproduce, distribute, modify, decompile,
disassemble, decrypt, extract, reverse engineer, lease, assign, or
sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by
respective copyright holders.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
Notice
Some features of the product and its accessories described
herein rely on the software installed, capacities and settings of
local network, and therefore may not be activated or may be
limited by local network operators or network service providers.
Thus the descriptions herein may not match exactly the product
or its accessories you purchase.
ii
Huawei Technologies Co., Ltd. reserves the right to change or
modify any information or specifications contained in this
manual without prior notice and without any liability.
Third-Party Software Statement
Huawei Technologies Co., Ltd. does not own the intellectual
property of the third-party software and applications that are
delivered with this product. Therefore, Huawei Technologies Co.,
Ltd. will not provide any warranty of any kind for these
third-party software and applications. Neither will Huawei
Technologies Co., Ltd. provide support to customers who use
these third-party software and applications, nor be responsible
or liable for the functions of these third-party software and
applications.Third-party software and applications services may
be interrupted or terminated at any time. Huawei Technologies
Co., Ltd. does not guarantee that any content or service would
be maintained for any period during its availability.
Third-party service providers provide content and services
through network or transmission tools outside of the control of
Huawei Technologies Co., Ltd. To the greatest extent permitted
by applicable law, it is explicitly stated that Huawei
Technologies Co., Ltd. shall not compensate or be liable for
services provided by third-party service providers, or the
interruption or termination of third-party contents or services.
Huawei Technologies Co., Ltd. shall not be responsible for the
legality , quality, or any other aspects of any software installed
on this product, or for any uploaded or downloaded third-party
works, such as texts, images, videos, or software. Customers
shall bear the risk for any and all effects, including
incompatibility between the software and this product, which
result from installing software or uploading or downloading the
third-party works.
This product uses the open-sourced Android™ platform.
Huawei Technologies Co., Ltd. has made necessary changes to
ii
the platform. Therefore, this product may not support all the
functions that are supported by the standard Android platform
or may be incompatible with third-party software. Huawei
Technologies Co., Ltd. shall not be liable for any of such
situation.
DISCLAIMER OF WARRANTIES
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
LIMITATIONS OF LIABILITY
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO EVENT SHALL HUAWEI TECHNOLOGIES CO., LTD. BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.THE
MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO
LIABILITY FOR PERSONAL INJURY TO THE EXTENT APPLICABLE
LAW PROHIBITS SUCH A LIMITATION) OF HUAWEI
TECHNOLOGIES CO., LTD. ARISING FROM THE USE OF THE
PRODUCT DESCRIBED IN THIS DOCUMENT SHALL BE LIMITED
TO THE AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE
OF THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or import
laws and regulations and be responsible to obtain all necessary
governmental permits and licenses in order to export, re-export
or import the product mentioned in this manual including the
software and technical data therein.
ii
Personal Information and Data Security
The use of some functions or third-party applications on your
device could result in your personal information and data being
lost or
becoming accessible to others. Several measures are
recommended to help you protect personal and confidential
information.
Place your device in a safe area to prevent it from
unauthorized use.
Set your device screen to lock and create a password or
unlock pattern to open it.
Periodically back up personal information kept on your
SIM/USIM card, memory card, or stored in your device
memory. If you change to a different device, be sure to move
or delete any personal information on your old device.
If you are worried about viruses when you receive messages
or emails from a stranger, you can delete them without
opening them.
If you use your device to browse the Internet, avoid websites
that might pose a security risk to avoid theft of your
personal information.
If you use services such as Wi-Fi tether or Bluetooth, set
passwords for these services to prevent unauthorized access.
When these services are not in use, turn them off.
Install or upgrade device security software and regularly
scan for viruses.
Be sure to obtain third-party applications from a legitimate
source. Downloaded third-party applications should be
scanned for viruses.
Install security software or patches released by Huawei or
third-party application providers.
ii
Some applications require and transmit location information.
As a result, a third-party may be able to share your location
information.
Your device may provide detection and diagnostic
information to third-party application providers. Third party
vendors use this information to improve their products and
services.
If you have concerns about the security of your personal
information and data, please contact mobile@huawei.com.
i
Contents
1 Getting Started ......................................................................... 1
Appearance .......................................................................................1
Setting Up Your Phone..................................................................3
Powering Your Phone On or Off ................................................5
Using the Touchscreen ..................................................................5
Locking and Unlocking the Screen ...........................................6
Home screen.....................................................................................7
Using a microSD Card.................................................................12
2 Calling ......................................................................................13
Making a Call................................................................................. 13
Answering and Rejecting a Call............................................... 15
Other Operations During a Call .............................................. 16
Using Call Log ...............................................................................17
Using Airplane Mode..................................................................17
3 Contacts...................................................................................18
Opening the Contacts Application.........................................18
Importing Contacts from a SIM Card.................................... 18
Adding a Contact ......................................................................... 19
Searching for a Contact ............................................................. 19
Editing a Contact.......................................................................... 20
Communicating with Your Contacts...................................... 20
Deleting a Contact.......................................................................21
ii
4 Using the Onscreen Keyboard............................................. 21
Displaying the Keyboard Panel................................................ 22
Choosing an Input Method ......................................................22
Customizing Keyboard Settings.............................................. 23
5 Message...................................................................................24
SMS and MMS...............................................................................24
Email ................................................................................................. 27
6 Getting Connected................................................................. 30
Mobile Networks..........................................................................30
Wi-Fi ................................................................................................. 31
Browser ............................................................................................ 32
Bluetooth ........................................................................................ 33
7 Entertainment......................................................................... 36
Taking Photos and Recording Videos ................................... 36
Using the Gallery .......................................................................... 38
Enjoying Music..............................................................................40
Listening to the FM Radio.........................................................42
8 Google Services...................................................................... 43
Creating a Google Account ......................................................43
Using Gmail....................................................................................44
Using Talk........................................................................................ 47
Using Maps .................................................................................... 48
Using Market ................................................................................. 49
9 Synchronizing Information .................................................. 51
Managing Your Accounts .......................................................... 52
iii
Customizing Your Account Synchronization....................... 53
10 Using Other Applications ................................................... 55
Using the Google Calendar ......................................................55
Using the Alarm............................................................................57
Using Audio Recorder................................................................. 59
Using the File Manager.............................................................. 60
Using Calculator ...........................................................................61
Using RichPad................................................................................ 61
11 Managing Your Phone ........................................................ 61
Setting the Date and Time........................................................ 62
Setting the Display ...................................................................... 62
Setting Ringers.............................................................................. 63
Setting Phone Services...............................................................64
Protecting Your Phone ............................................................... 65
Managing Applications..............................................................66
Resetting Your Phone .................................................................67
12 Warnings and Precautions................................................. 67
1
Some features are optional and are marked accordingly.
Features that are optional may vary depending on the
service provider. For details, contact your service
provider.
1 Getting Started
Appearance
Phone at a Glance
1 Earpiece 7 Search key
2 Volume keys 8 Camera
3 Screen 9 Power key
4 Menu key 10 Headset jack
2
5 Back key 11 Charging/Data
interface
6 Home key 12 Speaker
All the figures in this guide are for your reference only.
The actual appearance and display features depend on
the mobile phone you purchase.
Key Functions at Your Fingertips
Press… To…
Power key
Press to power your phone on.
Press and hold to open the Phone
options menu.
Press to lock the screen when your phone
is powered on.
Back key
Touch to return to the previous screen.
Touch to exit any application you are
running.
Menu key
Touch to open the menu on an active screen.
3
Setting Up Your Phone
Installing the SIM Cards
1. Remove the battery cover.
2. Insert the subscriber identity module (SIM) cards as shown in
the figure.
When inserting a SIM card, ensure that the gold contact
area faces down.
Installing the Battery
1. Remove the battery cover.
2. Insert the battery at a downward angle (a) and move it
slightly forward until it snaps into place at (b).
4
3. Replace the battery cover.
Charging the Battery
Ensure that the battery is inserted into the phone correctly
before charging.
1. Connect the USB cable that came with your mobile phone to
the charger.
2. Connect the other end of the USB cable to your phone. Then,
to start charging, plug the charger into an electrical outlet.
Important Information About the Battery
If the battery has not been used for a long time, you may not
be able to power on your mobile phone immediately after
you begin charging the battery. Allow the battery to charge
for a few minutes with the phone powered off before
attempting to power the phone on.
Over time, the battery will not hold a charge for as long as it
did when it was new. When the battery life becomes
noticeably shorter than usual after being charged properly,
replace the battery with a new one of the same type.
5
Using data services increases demand on the battery and
will reduce the length of time it can hold a charge.
The time required to charge the battery depends on the
environmental temperature and the age of the battery.
When the battery power level is low, the phone plays an
alert and displays a prompt. When battery power is almost
exhausted, your phone will power off automatically.
Powering Your Phone On or Off
Powering Your Phone On
Press the Power key to power your phone on.
If personal identification number (PIN) protection is
enabled on your phone, you must enter your PIN before
using the phone.
Powering Your Phone Off
1. Press and hold the Power key to open the Phone options
menu.
2. Touch Power off > OK.
Using the Touchscreen
Touchscreen Actions
Touch: Tap the screen with your finger to select an item,
confirm a selection, or start an application.
Touch and hold: Touch an item with your fingertip and
continue to press down until your phone responds. For
6
example, to open the options menu for the active screen,
touch the screen and hold down until the menu appears.
Flick: Move your finger across the screen either vertically or
horizontally. For example, flick left or right to switch between
pictures.
Drag: Touch and hold the desired item with your finger.
Drag the item to any part of the screen. You can drag an icon
to move or delete it.
Rotating Your Phone Screen
The orientation of most screens will rotate with the phone as
you turn it from upright to sideways and back again.
Locking and Unlocking the Screen
Locking the Screen
When your phone is on, press the Power key to lock the
screen. When the screen is locked, you can still receive
messages and calls.
If you leave your mobile phone undisturbed for a while, the
screen will lock automatically.
Unlocking the Screen
Press the Power key to wake up the screen. Then drag the lock
icon right to unlock the screen.
7
If you have set up a screen unlock pattern, you will be
prompted to draw the pattern on the screen to unlock it.
Home screen
1. Notification bar: Displays notifications and status icons for
your mobile phone. Flick down to open the notification
panel.
2. Display area: Shows the menu icon.
8
3. Home screen and extension indicator: Indicates the
number of home screen extensions.
Notifications and Status Information
Notification and Status Icons
Icon Indicates…
Call in progress
Call in progress using a Bluetooth device
Missed call
New calendar reminder
Preparing the mircoSD card
/ Roaming
/ Signal strength
/ Airplane mode
Bluetooth on
Connected to a Wi-Fi network
Speaker on
Sound off
Vibration mode
9
Icon Indicates…
Microphone off
Battery full
Extremely low battery
Charging battery
Music playing
Alarm enabled
New email
New message
Notification Panel
Your mobile phone will notify you when you receive a new
message or there is an incoming event. The notification panel
also informs you of alarms and settings. For example, you will
be notified when Call forwarding is activated. Open the
notification panel to see your network operator or to view a
message, reminder, or event notification.
Opening the Notification Panel
1. When a new notification icon appears on the notification bar,
touch and hold the notification bar, and flick down to open
the notification panel.
2. On the notification panel, you can:
10
Touch a notification to open the relevant application.
Touch Clear to clear all notifications.
Closing the Notification Panel
Touch and hold the bottom of the panel. Then flick up or touch
to close.
Adding a Home Screen Item
1. Touch and hold the blank area on the Home screen until the
Select action menu is displayed.
2. Select an item to add it to the Home screen.
Moving a Home Screen Item
1. Touch and hold an item on the Home screen until the item
enlarges and the phone vibrates.
2. Without lifting your finger, drag the item to the desired
position on the Home screen, and then release your finger.
Removing a Home Screen Item
1. Touch and hold an item on the Home screen until the item
enlarges and the phone vibrates.
2. Without lifting your finger, drag the item to the trash can.
3. When the item turn red, release your finger to remove it
from the Home screen.
Widgets
A widget works as a shortcut to let you preview or use an
application. Several widgets have been installed on your phone
by default. You can download more widgets from Android
Market.
To add a widget to the Home screen:
11
1. Touch and hold the blank area on the Home screen to open
the Select action menu.
2. Touch Add widgets to open the Choose widget menu.
3. Touch the widget you want to add to the Home screen.
Folders
Adding a Folder to the Home screen
1. Touch and hold the blank area on the Home screen to open
the Select action menu. Touch Add folder to open the
Select folder menu.
2. Select the folder you want to add to the Home screen.
Renaming a Folder on the Home screen
1. On the Home screen, touch the folder you want to rename
to open it. Touch and hold the title bar of the folder to open
the Rename folder dialog box.
2. In Folder name, enter the new folder name, and touch OK.
Changing the Wallpaper
1. On the Home screen, touch , and touch Wallpaper to
open the Select wallpaper from menu.
2. Do any of the following:
Touch Gallery to select a picture and set it as the wallpaper.
Touch Live Wallpapers to select a picture and set it as the
wallpaper.
Touch Wallpapers to select a picture and set it as the
wallpaper.
12
Using a microSD Card
Installing the microSD Card
1. Remove the battery cover.
2. Insert the microSD card into the card slot as shown in the
figure.
When inserting the microSD card, ensure that the gold
contact area faces down.
Using the microSD Card as USB Mass Storage
To transfer all your favorite music and pictures from your PC to
your phone’s microSD card, set the microSD card as USB mass
storage.
1. Connect your phone to your PC with the USB cable provided.
Your PC will detect the microSD card as a removable storage
device.
2. Touch Turn on USB storage in the dialog box that opens to
confirm that you want to transfer files. You can now transfer
files from your PC to your phone’s microSD card.
13
When your microSD card functions as USB mass storage,
your phone will not use this memory space.
Removing the microSD Card
1. Touch > Settings.
2. Scroll down the screen, and touch SD card & phone storage
> Unmount SD card.
3. Touch OK to remove the microSD card.
2 Calling
To make a phone call, you can dial a number using the dialer or
touch a number saved in your contact list, on a web page, or in
a document. When you are in a call, you can answer other
incoming calls or redirect them to your voicemail. You can also
set up conference calls with several participants.
Your phone is Dual-SIM, Dual-Standby. When you are in a
call using one SIM card, the other SIM card is out of
service and you cannot use it to receive other calls.
Making a Call
To make a call, you can use the Phone application, or select a
number from Contacts or Call log.
14
When you are in a call, you can touch to return to the
Home screen and use other functions. To return to the calling
screen, flick the notification bar down and touch Current call.
Do not block the microphone at the bottom of your
phone if you want your voice heard by the other parties
in a call.
Making a Call with the Dialer
1. Touch > Phone to display the dialer. If you are already
working with Contacts or Call log, touch the Phone tab.
2. Touch the appropriate number keys to enter the phone
number.
3. Touch or to initiate the call.
Making a Call from Contacts
1. Touch > Contacts to display the contact list. If you are
already working with Phone or Call log, touch the Contacts
tab.
2. In the list, touch the contact you want to call.
3. Touch and then select SIM1 or SIM2 to dial the phone
number.
Making a Call from Call Log
1. Touch > Phone > Call log to display the call log. If you
are already working with Contacts or Phone, touch the Call
log tab.
15
2. Touch the log entry you want to call.
If you touch and hold the log entry, a menu containing
multiple options will open.
Answering and Rejecting a Call
Answering a Call
When you receive a phone call, the incoming call screen opens.
If you have previously saved the caller's number in Contacts,
the caller's name and number are displayed. If the caller's
number is not saved in Contacts, the caller's number is
displayed.
Drag to to answer the call.
Ending a Call
During a call, touch to hang up.
16
Rejecting a Call
Drag to to reject the call.
Other Operations During a Call
Making a Conference Call
If you receive a new call while you are already in a call, you can
add the second call to the call you are in. This feature is known
as conference calling. You can also set up a conference call with
multiple callers.
Contact your network operator to learn whether
conference calls are supported and if yes, how many
parties can participate.
1. To initiate a conference call, dial the number of the first
participant. After you have connected to the first participant,
touch More > Add call.
2. Enter the phone number of the next person you want to
invite for the conversation and call icon, or select someone
from your Call log or Contacts. The first call is automatically
placed on hold while you do this.
3. Once you have connected to the second person, touch
More > Merge call to begin the conference call.
4. To add more people, touch More > Add call and repeat
steps 2 and 3.
5. To disconnect someone from the call or to privately talk to
someone, touch More > Manage conference call.
17
6. To end the conference call and disconnect from everyone,
touch .
Switching Between Calls
If you are already in a call and a second call comes in, you can
drag to to place the first call on hold and connect to
the second call.
Using Call Log
Call log contains a list of calls that you have dialed, received, or
missed. You can use Call log to quickly find a recently called
number or add an incoming number to your contact list.
Adding an Entry to Contacts
1. Touch > Contacts > Call log to display the call log.
2. Touch and hold the entry you want to add to Contacts.
3. In the displayed menu, touch Add to contacts.
4. Touch Create new contact or add to existing. If you select to
add to existing, scroll through the contact list and touch an
existing contact name.
Using Airplane Mode
Some locations may require you to turn off your phone’s
wireless connections. Rather than powering your phone off, you
can place it in Airplane mode.
1. Press and hold the power key to open the Phone options
menu.
2. Touch Airplane mode.
18
3 Contacts
The Contacts application enables you to save and manage
information such as phone numbers and addresses of your
contacts. After you save contact information on your phone,
you have easy access to the people with whom you want to
communicate.
Opening the Contacts Application
If you have not yet added any contacts to your phone, Contacts
displays a message with hints on how to start adding contact
information.
To open the Contacts application:
On the home screen, touch > Contacts.
On the home screen, touch , and touch the Contacts
tab.
All your contacts are alphabetically displayed in a list that you
can scroll through. Each contact is followed by a phone number
that you have set as the contact’s default phone number.
Importing Contacts from a SIM Card
1. Open the contact list, touch , and touch More >
Import/Export > Import from SIM1/ Import from SIM2.
2. Touch and select Import all to import the contact list or
touch and hold a selected contact and then touch Import to
import a contact.
19
3. Wait for the SIM card contents to be loaded. If you have
touched Import all, all contacts saved on your SIM card are
imported.
Adding a Contact
1. Open the contact list, touch and touch New contact.
2. In Contact type menu, touch Phone, SIM1 card or SIM2
card to select the storage where you want to save the
contact.
3. Enter the contact's name, and add detailed information such
as the contact’s phone number or Email.
4. When you are finished, touch Done to save the contact
information.
Adding a Contact to Your Favorites
To add a contact to your Favorites, open the contact list, and
do any of the following:
Touch and hold the contact you want to add to Favorites.
Then touch Add to favorites.
Touch a contact, and then touch the star next to the
contact’s name to make the star turn gold.
Only the contact store on your phone can be set to
favorite contacts.
Searching for a Contact
1. Open the contact list, touch , and touch Search.
20
You can also open the contact list, and touch .
2. Enter the name of the contact you want to search for. As you
type, contacts with matching names appear below the
search box.
Editing a Contact
You can make changes to the information you have stored for a
contact at any time.
1. Open the contact list, touch and hold the contact whose
details you want to edit, and touch Edit contact in the
displayed menu. You can also touch , and then touch Edit
contact while viewing a contact’s details.
2. Touch the text field where you want to make a change, such
as First name, Last name, Phone or Email.
3. Make the desired changes to the contact information, and
touch Done. To cancel all changes you made to the contact
information, touch Revert.
Communicating with Your Contacts
From the Contacts or Favorites tab, you can quickly call or
send a text (SMS) or multimedia message (MMS) to a contact’s
default phone number. You can also open details to view a list
of all the ways you can communicate with that contact. This
section describes how to communicate with a contact when you
are viewing your contacts list.
21
Connecting Quickly with Your Contact
1. Touch the contact's picture or picture frame (if you have not
assigned a picture to the contact) to open Quick Contact for
Android, which allows you to quickly initiate a connection to
your contacts.
2. Touch the icon for the way you want to communicate with
the contact.
The icons available depend on the information you have
entered for the contact, the applications installed on
your phone, and the accounts you have.
Communicating with a Contact
1. Open the contact list, and touch the contact that you want
to communicate with.
2. On the contact’s details screen, touch or to send
a message or make a call to the contact.
Deleting a Contact
1. Open the contact list, touch and hold the contact that you
want to delete, and touch Delete contact in the displayed
menu.
2. Touch OK to confirm that you want to delete the contact.
4 Using the Onscreen Keyboard
22
Displaying the Keyboard Panel
To enter text, use the onscreen keyboard. Some applications
automatically open the keyboard. In others, touch the text field
where you want to enter text to open the keyboard.
To hide the keyboard, touch .
Touch and hold a text field to open the Edit text menu.
Choosing an Input Method
1. Touch and hold a text field until the Edit text menu is
displayed.
2. Touch Input method.
3. Select the desired method. The onscreen keyboard is
automatically displayed.
Using the Android Keyboard
1. Touch to change from uppercase to lowercase.
2. Touch to change from text mode to symbol/ number mode.
23
3. Touch to insert a space in your text.
4. Touch to delete the character to the left of the cursor.
Touch and hold to delete all characters to the left of the cursor.
Using the Landscape Keyboard
If you find the keyboard inconvenient or difficult to use, turn
your phone sideways. The screen will display the keyboard in
landscape orientation, providing you with a wider keyboard
layout.
Customizing Keyboard Settings
Touch > Settings > Language & keyboard > Android
keyboard to customize Android keyboard settings.
Vibrate on keypress
Select to set the phone to vibrate each time you touch a key on
the onscreen keyboard.
Sound on keypress
Select to play a brief sound each time you touch a key on the
onscreen keyboard.
Auto-capitalization
Select to set the onscreen keyboard to automatically capitalize
the first letter of the first word after a period, the first word in a
text field, and each word in name fields.
Input languages
Select the input languages.
Quick fixes
Select to correct common spelling mistakes as you type.
24
Show suggestions
Select to display suggested words as you type.
Auto-complete
Select to automatically enter a suggested word, highlighted in
orange in the strip above the keyboard, when you enter a space
or punctuation.
5 Message
The Message application allows you to exchange text and
multimedia messages with anyone using a phone supporting
the Short Message Service (SMS) and the Multimedia
Messaging Service (MMS). With the Email application you can
receive and send emails.
SMS and MMS
Opening Message
On the home screen, touch .
On the home screen, touch > Messaging.
Sending a Text Message
1. Touch > Messaging, then touch New message.
2. Enter a phone number in To, or touch to select a
contact from Contacts.As you enter the phone number,
matching contacts appear. You can touch a suggested
recipient or continue entering the phone number.
25
3. Touch Type to compose to start writing your message.While
writing the message, you can touch to save the
message as a draft in your message list. To continue writing
the message, touch the message.
4. When you finish the message, touch SIM1 or SIM2 to send
the message.
The message list opens, and your name appears in the list,
followed by the message you just sent. Responses appear in the
window. As you view and send additional messages, a message
thread is created.
Sending a Multimedia Message
1. Touch > Messaging, then touch New message.
2. Enter a phone number in To, or touch to select a
contact from Contacts.
3. Touch Type to compose to start writing your message.
If you want to enter a smiley, touch when writing the
message and then touch Insert smiley.
4. Touch , and touch Add subject to add the message
subject. Your phone is now in multimedia message mode.
5. Touch , and touch Attach to add a picture, audio file, or
video file to the message.
6. When you finish the message, touch SIM1 or SIM2 to send
the message.
26
Adding a Slideshow
If you want to attach more than one file to your message, use
the Slideshow option.
1. On the message-editing screen, touch , and then touch
Attach.
2. In the displayed menu, touch Slideshow, select a slide and
start to edit it.
3. To add and edit another slide, touch and touch More >
Add slide in the displayed menu.
While editing the slide, you can touch the yellow arrow icons to
switch between slides.
4. Touch Done to finish composing your message and return
to the multimedia message screen.
5. To alter your multimedia message, touch Edit on the
multimedia message screen. When the message is ready to
be sent, select SIM1 or SIM2 to send the message.
Opening and Viewing a Multimedia Message
1. Open the message list, and touch the message thread to
open it.
2. Touch the multimedia message to view the message.
3. Flick up or down to view the previous or next slide.
Replying to a Message
1. Open the message list, and touch a text or multimedia
message thread to open it.
2. Touch Type to compose to compose your message.
27
3. When the message is finished, touch SIM1 or SIM2 to send
the message.
Customizing Message Settings
Open the message list, touch , and touch Settings to
customize message settings.
Email
Your phone also puts email at your fingertips. With your
phone’s Email application, you can add versions of Yahoo!, AOL,
and other popular email services to your phone. These types of
email accounts are known as POP3 or IMAP.
Adding an Email Account
When using the Email application for the first time, you must
configure an email account. The email setup wizard helps you
to configure your account. A number of popular email systems
are supported, you can work with the same email service as you
use on your PC or you can select another email service.
1. Touch > Email.
2. To customize your email settings, follow the onscreen
instructions, and touch Next. If you want to set the email
server yourself, touch Manual setup.
When you touch Manual setup, contact your email
service
provider for the settings required for setting up your
account if you do not know what they are.
28
3. Enter the account name and the name you want other
people to see when they receive an email from you.
4. Touch Done.
Your phone will use the email account to access your email
server. You can use your phone to send and receive emails.
After the initial setup, your Email application opens to display
the contents of your Inbox.
Adding Another Email Account
1. After creating your initial email account, touch on the Inbox
screen, and touch then select Accounts to access the
account list.
2. Touch , and touch Add account to create another email
account.
When adding an additional email account, you have the
option to use the new account to send all outgoing
messages.
Viewing an Email
1. Open the account list, and touch the email account you want
to use.
2. Select a folder, and touch the message that you want to
view.
Sending an Email
1. Open the account list, and touch the email account you want
to use.
2. On the Inbox screen, touch , and touch Compose.
29
3. In To, enter the recipient’s name or email address.
4. Enter the subject of your message and compose the
message. To send an attachment with the message, touch
, and then touch Add attachment.
5. When you are finished, touch Send.
If you are not ready to send the message, touch Save as draft
or touch to save the message as a draft.
Replying to an Email
1. Open the account list, and touch the email account you want
to use.
2. Touch the email to which you want to reply.
3. Touch Reply or Reply all to reply to the email.
Deleting an Email Account
1. Open the account list, touch and hold the email account you
want to delete.
2. Touch Remove account > OK.
Changing Email Account Settings
You can change a number of account settings, including how
often you check for emails, how you are notified of a new email,
and details about the servers the account uses to send and
receive emails.
Your account’s incoming and outgoing settings depend
on the type of email service you are using: IMAP or
POP3. You can manually enter the necessary details,
although you may need to contact your email service
provider to obtain the correct information.
30
1. Touch > Email.
2. In the accounts list, touch and hold the email account you
want to change.
3. Touch Account settings.
4. Change General settings, Notification settings or Server
settings.
6 Getting Connected
Mobile Networks
Your phone will be automatically configured to use your
network provider’s GPRS/3G/EDGE service (if available) when
you turn on the phone for the first time. Note that the SIM card
must be inserted.
Checking the Network Connection
1. Touch > Settings > Wireless & networks > Mobile
networks.
2. Touch SIM1or SIM2.
3. Touch Network operators to check the network connection.
Your phone will automatically read the access point
settings from your SIM card (if any). For this reason, do
not change the access point; otherwise, you might not
be able to access network resources.
31
Wi-Fi
Wi-Fi gives you wireless access to broadband Internet. To use
Wi-Fi on your phone, you must have an access to wireless
access points. Obstacles that block the Wi-Fi signal will reduce
the signal strength.
Turning Wi-Fi On
1. Touch > Settings > Wireless & networks.
2. Touch Wi-Fi to turn Wi-Fi on.
Connecting to a Wireless Network
1. After turning Wi-Fi on, touch > Settings > Wireless &
networks > Wi-Fi settings.
2. A list of detected Wi-Fi networks is displayed under Wi-Fi
networks.
3. Touch a Wi-Fi network to connect to it.
If you select an open network, you will be automatically
connected to the network.
If you select a network that is secured with Wired Equivalent
Privacy (WEP) and connect to the network for the first time,
enter the password as prompted, and touch Connect. If you
connect to a secured wireless network that you have already
used, you will not be prompted to enter the password again
unless you have reset your phone to its default settings.
On the Wi-Fi settings screen, touch Add Wi-Fi network
to add a new Wi-Fi network.
32
Browser
Your phone comes with an pre-installed Internet browser.
Opening the Browser
Touch > Browser to open the home page. Touch to
open the browser-related menu or the following options:
New window: Touch to open a new window.
Exit: Touch to exit the Browser.
Windows: Touch to view thumbnails of open browser
windows. You can switch to another browser window or
open a new one.
Refresh: Touch to refresh the current web page.
Forward: View the previous page you just return to current
page.
More: Touch to open other menus and perform operations
such as selecting text, Bookmarks, or configuring settings.
Opening a Web Page
1. In a browser window, touch the URL field at the top of the
screen.
2. Use the keyboard to enter a web page address.
3. As you enter the address, matching web page addresses will
appear on the screen. If you see the address you want, touch
it to directly go to that web page or complete entering the
address of your desired web page.
Setting the Home Page
1. In a browser window, touch .
33
2. Touch More > Settings > Set home page.
3. Enter the address of the desired home page, and touch OK.
Managing Bookmarks
You can store as many bookmarks as you want on your mobile
phone.
Adding a Bookmark
1. In a browser window, go to the web page you want to save
as a bookmark.
2. Touch , and touch More > Add bookmarks.
3. Edit the bookmark name and touch OK.
Opening a Bookmark
1. In a browser window, touch , and touch More >
Bookmarks. On the Bookmarks screen, touch the History
tab to view the pages you have visited. Or touch the Most
visited tab to view the pages you have visited most
frequently.
2. Touch the bookmark of the website you want to open.
Customizing Browser Settings
To customize the browser to suit your browsing style, and use
Browser to set page content, privacy, and security preferences,
in a browser window, touch , and then touch More >
Settings.
Bluetooth
Your phone supports Bluetooth, which allows you to create a
wireless connection with other Bluetooth devices so you can
34
share files with your friends, talk hands-free using a Bluetooth
headset, or even transfer photos from your phone to your PC.
If you are using Bluetooth, remember to stay within 10 meters
(33 feet) of other Bluetooth devices to which you want to
connect. Be aware that obstacles like walls or other electronic
equipment may interfere with your Bluetooth connection.
Turning Bluetooth On
1. Touch > Settings > Wireless & networks.
2. Select Bluetooth to turn Bluetooth on. When Bluetooth is
turned on, the Bluetooth icon appears in the notification bar.
3. Touch Bluetooth settings, and select Discoverable to make
your phone visible to other Bluetooth devices.
Pairing with and Connecting to another
Bluetooth Device
Your phone provides the following Bluetooth profiles:
Hands-Free Profile (HFP): allows you to use a hands-free
Bluetooth device.
Headset Profile (HSP): allows you to use a mono Bluetooth
headset.
Object Push Profile (OPP): allows you to transfer files over a
Bluetooth connection.
Advanced Audio Distribution Profile (A2DP): allows you to
use a stereo Bluetooth headset.
Audio/Video Remote Control Profile (AVRCP): allows you to
control audio playing using a Bluetooth headset remotely.
Before using Bluetooth, pair your phone with another Bluetooth
device as follows:
35
1. Ensure that the Bluetooth function on your phone is turned
on.
2. Touch > Settings > Wireless & networks > Bluetooth
settings > Scan for devices. Your phone scans for
Bluetooth devices in range.
3. Touch the device you want to pair with your phone.
4. Enter the pairing password to complete the connection.
Sending Files via Bluetooth
Using Bluetooth, you can share pictures, videos, or music files
with your family and friends. To send files via Bluetooth:
1. Touch > ES File Explorer.
2. Touch and hold the file to be sent.
3. In the displayed menu, touch Share > Bluetooth to select a
paired device.
Disconnecting from or Unpairing with another
Bluetooth Device
1. Touch > Settings > Wireless & networks >
Bluetooth settings.
2. Under Bluetooth devices, touch and hold the connected
device you want to disconnect form.
3. Touch Unpair to disconnect from the device.
36
7 Entertainment
In addition to being a communication device and personal
assistant, your phone also provides you with a multitude of
entertainment possibilities. You can take photos, create audio
and video clips, and download and listen to music.
Taking Photos and Recording Videos
The camera is a combination of camera and camcorder that you
can use to shoot and share pictures and videos.
Opening Your Camera
Touch > Camera to open the Camera application. The
camera opens in landscape mode, ready to take a picture.
Touch on the capture screen to close the camera.
Capture Screen
37
Before taking a photo, touch the capture screen to zoom in or
out on a scene.
1. Touch to customize the camera settings.
2. Thumbnail of the last photo. Touch to preview photos or
videos.
3. Drag to switch between camera mode and camcorder mode.
4. Touch to take a photo (in camera mode) or shoot a video (in
camcorder mode).
Taking a Photo
1. Open your Camera application and switch it to camera
mode.
2. If necessary, change the camera settings. The preview image
changes as you change the settings.
3. Frame the scene within the capture screen.
4. Touch to take a photo.
Photo taken are displayed for a moment. You can take another
photo or preview your photos.
Viewing Your Photos
1. After taking a photo, a thumbnail of the photo you have just
taken is shown in the upper right corner of the capture
screen. Touch the thumbnail to view it.
2. Touch the onscreen button to do any of the following:
Touch Delete to delete the photo.
Touch Share to send the photo in a message or post it
online.
38
Touch More > Set as to set the photo as a wallpaper or a
contact icon.
3. If you want to view more photos, touch the screen, and flick
right or left.
Recording a Video
1. Open the Camera application, and switch it to camcorder
mode.
2. If necessary, change the camcorder settings.
3. Frame the scene with which you want to start your video.
4. Touch to start recording a video.
5. Touch to stop shooting. You can record another video
or preview your videos.
Viewing Your Videos
After recording a video, a thumbnail of the video you have just
recorded is shown in the upper right corner of the capture
screen. Touch the thumbnail to view it.
Using the Gallery
Your Gallery application can automatically search for pictures
and videos on the microSD card. Use Gallery to sort photos
and videos into folders, view and edit pictures, watch videos,
and set a picture as the wallpaper or as a photo for a contact.
Opening the Gallery
Touch > Gallery.
39
The Gallery application categorizes your pictures and videos by
storage location and displays these files in folders. Touch a
folder to view the pictures or videos inside.
Viewing a Picture
1. Open the Gallery, and touch the folder that contains the
pictures you want to view.
2. Touch a picture to view it in full-screen mode. When viewing
a picture in full-screen mode, flick the picture left or right to
view the next or previous picture.
3. Touch the screen.
4. Then the zoom panel appears. You can zoom in or zoom out
on the picture.
The picture viewer supports the automatic rotation
function.
When you rotate your phone, the picture adjusts itself to
the rotation.
Rotating a Picture
1. When viewing a picture, touch to display the operation
panel.
2. Touch More.
3. Select either Rotate Left or Rotate Right. The picture is
saved with the new orientation.
Cropping a Picture
1. When viewing a picture, touch to display the operation
panel, and touch More > Crop.
40
2. Use the cropping tool to select the portion of the picture to
crop.
Drag from the inside of the cropping tool to move the
image.
Drag an edge of the cropping tool to resize the image.
Drag a corner of the cropping tool to resize the image
without changing the aspect ratio.
3. Touch Save to save the cropped picture, or touch Discard to
discard the changes.
Enjoying Music
You can download music files to your PC or insert a CD in your
PC’s optical disc drive and copy the files to your microSD card
so that you can listen to music on your phone.
Copying Music to the microSD Card
1. Install your microSD card on your phone, and connect your
phone to your PC with a USB cable.
2. On the PC, navigate to the USB drive and open it.
3. Create a folder in the microSD card’s root directory (for
example, Music).
4. Copy the music files from your PC to the folder you have
created.
5. After copying the music files, unmount or eject the USB
drive as required by your PC’s operating system to safely
remove your phone from your PC.
6. Disconnect your phone from your PC.
41
Opening the Music Library
Touch > Music to display the music library.
The Music library automatically scans for music stored on your
microSD card and displays them in Artists, Albums, Songs and
Playlists.
Playing Music
1. Open the music library and touch the Artists, Albums,
Songs or Playlists tab to select a way to view your music.
2. Touch the music file you want to play.
When playing music, touch to return to the
previous screen and play music in the background. To
return to the music playing screen, open the notification
panel and touch the playing music.
Music Playing Screen
3
1. Touch to control music playing.
42
2. Touch to turn shuffle on or off.
3. Touch to set repeat mode.
Adding Music to a Playlist
1. Open the music library, and touch the Artists, Albums,
Songs or Playlists tab to select a way to view your music.
2. Flick up or down to navigate through the displayed music
files.
3. Touch and hold the music file you want to add to the playlist,
and touch Add to playlist.
Touch Current playlist to add the music file to an existing
playlist.
Touch New to create a playlist and add the music file to it.
Playing Music in a Playlist
1. Open the music library, and touch the Playlists tab.
2. Touch and hold the playlist you want to play.
3. Touch Play to play the playlist.
Listening to the FM Radio
The FM Radio application lets you listen to FM radio programs
on your phone. Since the application uses the provided wired
stereo headset as its antenna, before opening the application,
connect the headset to your phone’s headset jack.
Opening the FM Radio
Touch > FM Radio to open the application.
43
Tuning the FM Radio
Open the FM Radio application, and touch to do the
following:
Touch Search to automatically scan for available FM
channels.
Touch RDS settings to enable Alternative frequency.
8 Google Services
When you turn your phone on for the first time, touch a
Google service such as Talk, Gmail, or Market, and you will be
prompted to sign in to your Google account.
Ensure that your phone has an active data connection
(3G/GPRS) before you sign in to your Google account.
If you already have a Google account, touch Sign in and
enter your username and password.
Creating a Google Account
If you do not have a Google account, you can create one as
follows:
1. After reading the setup information, touch Next.
2. Touch Create.
3. Enter the first name, last name, and user name for your
Google account, and touch Next. The phone will connect to
the Google server to check whether the username is
available. If the username you entered is already in use, you
44
will be prompted to choose another one or select one from
a list.
4. Enter and confirm your Google account password.
5. Select a security question from the drop-down list, and enter
the answer.
6. Touch Create.
7. When the Google Terms of Service screen appears, touch I
agree, Next.
8. Enter the characters that appear on the screen, and touch
Next.
To use another Google account, go to the Accounts &
sync settings screen, and touch Add account to select
which type of accounts you want to add.
Using Gmail
Gmail is Google’s web-based email service. When you first set
up your phone, you may have configured it to use an existing
Gmail account or create an account. The first time you open the
Gmail application on your phone, your Inbox will contain the
messages from your Gmail web account.
Opening Gmail
Touch > Gmail. The Inbox email list appears. Any emails
you decide to keep on your phone will go to your Inbox folder.
Switching Between Accounts
1. In the email list, touch , and touch Accounts.
45
2. Touch the account that contains the email you want to read.
Creating and Sending an Email
1. In the email list, touch , and touch Compose.
2. Enter the recipient’s email address in To. If you are sending
the email to several recipients, separate the email addresses
with commas. You can add as many recipients as you want. If
you want to send a copy (Cc) or a blind copy (Bcc) of the
email to other recipients, touch , and then touch Add
Cc/Bcc.
3. Enter the email subject and write your email.
If you want to add a picture attachment, touch , and then
touch Attach to select the picture you want to attach.
4. After writing your email, touch Send.
Replying To or Forwarding an Email
1. In the email list, touch the email that you want to reply to or
forward, then touch in the upper right corner of the
screen.
2. Touch Reply, Reply all, or Forward.
3. Do one of the following:
If you selected Reply or Reply all, enter your message.
If you selected Forward, specify the recipients and add any
additional text you want to include with the forwarded
message.
4. Touch Send.
46
Searching for an Email
1. In the email list, touch , and touch Search.
2. Enter the search keywords in the search box, and touch .
Customizing Your Gmail Settings
1. In the email list, touch , and touch More > Settings.
2. Configure the following settings:
Signature: Touch to enter a signature that is appended at
the end of all your emails.
Confirm actions: Select to display a confirmation message
when you want to delete an email.
Batch operations: Select to simultaneously perform an
operation, such as archiving or deleting, on a batch of
emails.
Clear search history: Touch to delete the history of previous
message searches.
Labels: Touch to select which Gmail labels to be
synchronized with your web-based Gmail account.
Email notifications: Select to display a notification icon on
the notification bar when you receive an email.
Select ringtone: Touch to select a ringtone for a new email.
A short sample of the ringtone will play when you select it. If
you prefer no ringtone to play when you receive a new email,
touch Silent. Then touch OK to confirm your ringtone
selection.
Vibrate: Select to set your phone to vibrate when you
receive a new email.
47
Using Talk
Talk is Google’s instant messaging service. You can use it to
communicate in real time with other people on your phone or
on the web.
Opening Talk
Touch > Talk to open the Talk application.
Your Talk account is based on the Google account you
set up with your phone.
Adding a Friend
1. Open the friend list, touch , and touch Add friend.
2. Enter the Talk instant messaging ID or Google email address
of the friend you want to add.
3. Touch Send invitation.
Accepting or Rejecting an Invitation
1. If you have invited anyone to chat or if someone else has
invited you to chat, an invitation will appear in the friend list.
2. Touch a pending invitation, then touch Accept or Cancel.
Starting a Chat
1. Open the friend list, touch a friend’s name to open a chat
window.
2. After entering your message, touch Send.
3. To close the chat, touch > End chat.
48
Setting Notifications for New Instant Messages
Whenever you receive an instant message, your phone plays a
sound, vibrates, or displays an icon. To set up one of these
handy notifications, open the friend list, and touch . Then
touch Settings and choose from the following:
IM notifications: Select to receive a notification in the
notification bar when you receive an instant message.
Select ringtone: Touch to select a ringtone for a new instant
message. You will hear a short sample of the ringtone when
you select it. To turn the ringtone off, select Silent.
Vibrate: Select to set your phone to vibrate when you receive
a new instant message.
Signing Out of Talk
Open the friend list, touch , and touch Sign out to quit Talk.
Using Maps
Maps lets you find your current location, view real-time traffic
conditions (depending on availability in your locale), and get
detailed directions to various destinations. You can view
satellite images, traffic maps, or other kinds of maps of your
current or other locations.
Enabling the Location Source
Before you open Maps to find your location or search for
places of interest, you must enable "location source".
1. Touch > Settings.
2. Touch Location & security.
3. Under My Location, select Use wireless networks, Use GPS
49
satellites, or both.
Opening Maps
Touch > Maps to open the application.
Searching for Places of Interest
1. Open the Maps application, touch , and touch Search.
2. Enter the place you want to search for in the search box, and
touch the search icon. The search results will then be
displayed.
3. Touch a place you are interested in. The application shows
where it is on the map.
Getting Directions
1. While viewing a map, touch , and touch Directions.
2. Enter the starting point in the first text box, and your
destination in the second.
3. Touch the icon for car, public transit, or walking directions.
4. Touch Go. The directions appear in a list.
5. Touch a direction item on the list to show it on the map.
6. When you finish viewing or following the directions, touch
and select More > Clear Map to reset the map.
Using Market
Android Market provides direct access to applications and
games which you can download and install on your phone.
Opening Market
1. Touch > Market.
2. When you open Market for the first time, the Android
Market Terms of Service window will appear. Touch Accept
50
to continue.
Searching for Applications
You can find applications on the Market home screen from:
Featured applications: Flick up or down to view more.
List of applications grouped by categories and subcategories:
You can sort the applications by popularity (from the most
to the least) or by date (from the newest to the oldest).
List of games.
Search function.
Your downloads.
Installing an Application
If you want to install a non-Market application, touch
> Settings > Applications, and select Unknown
sources to allow installation of the non-Market
application.
1. Open the Market application, and touch Apps.
2. Touch a category, then touch the application you want to
download.
3. On the item details screen, read more about the application,
including its cost, overall rating, and user comments. If you
scroll down to About the developer, you can see other
applications from the same developer, or link to the
developer's website.
4. To install the application, touch Install and then touch OK,
whichever is displayed.
5. To check the progress of a download, open the notification
panel. Most applications are installed within seconds. To
51
stop an application from being downloaded, touch the
application and touch Cancel download.
6. After the application has been downloaded and installed on
your phone, the content download icon appears in the
notification bar.
Uninstalling an Application
1. Open the Market application, touch Download.
2. Touch the application you want to uninstall, and then touch
Uninstall.
3. When prompted, touch OK to remove the application from
your phone.
4. Select the reason for removing the application, and then
touch OK.
9 Synchronizing Information
Some applications on your phone give you access to the same
personal information that you can add, view, and edit on your
PC. If you add, change, or delete your information in any of
these applications on the web, the updated information also
appears on your phone.
This is made possible through over-the-air data synchronization.
The process occurs in the background and does not interfere
with use of your phone. When your phone is synchronizing, a
data synchronization icon will appear in the notification bar.
52
Managing Your Accounts
You can synchronize contacts, email, and other information on
your phone with multiple Google accounts or other kinds of
accounts, depending on the applications installed on your
phone.
For example, you can start by adding your personal Google
account, so your personal emails, contacts, and calendar are
always available. You can then add a work account, so your
work-related emails and work contacts are handy. If you like,
you may add multiple Google accounts or other accounts.
Adding an Account
1. Touch > Settings > Accounts & sync. The screen
displays your current synchronization settings and a list of
your current accounts.
In some cases, you may need to obtain account details
from an IT support. For example, you may need to know
the account’s domain or server address.
2. Touch Add account.
3. Touch the kind of account to add.
4. Follow the onscreen steps to enter the required and optional
information about the account. Most accounts require a
username and password, but the details depend on the kind
of account and the configuration of the service to which you
are connecting.
5. Configure the account. Depending on the kind of account,
you may be asked to configure what kind of data you want
53
to synchronize to the phone, to name the account, and for
other details. When you are finished, the account is added to
the list on the Accounts & sync settings screen.
Removing an Account
You can remove an account, deleting it and all information
associated with it from your phone, including emails, contacts,
settings, and so on. You cannot, however, remove some
accounts, such as the first account you signed into on the
phone. If you attempt to remove certain accounts, all personal
information associated with it will be deleted.
1. On the Accounts & sync settings screen, touch the account
to be deleted.
2. Touch and select Remove account.
3. Confirm that you want to remove the account.
Customizing Your Account
Synchronization
You can configure background data use and synchronization
settings for all the applications on your phone. You can also
configure what kind of data you synchronize for each account.
Some applications, such as Contacts and Gmail, can
synchronize data from multiple accounts. Others, such as
Calendar, synchronize data only from the first Google account
you signed into on your phone, or from an account specifically
associated with the applications.
For some accounts, synchronization is bi-directional; changes
that you make to the information on your phone are made to
the copy of that information on the web. Some accounts
54
support only one-way synchronization; the information on your
phone is read-only.
Configuring General Synchronization Settings
On the Accounts & sync settings screen, do the following:
Select or clear Background data to control whether
applications and services can transmit data when you are
not directly working with them (that is, when they are
running in the background).
If you clear Background data, the Gmail application stops
receiving new mail, the Google Calendar stops
synchronizing events, and so on, until you touch Refresh or
send an email.
Select or clear Auto-sync to control whether changes you
make to information on the phone or on the web are
automatically synchronized with each other.
For example, when Auto-sync is selected, changes that you
make in Contacts on the phone are automatically made in
Google Contacts on the web.
Changing an Account’s Synchronization Settings
1. On the Accounts & sync settings screen, touch the account
whose synchronization settings you want to change. The
data and synchronization screen opens, displaying a list of
the kinds of information the account can synchronize.
2. Select the items to be synchronized to your phone.
3. Select or clear the data you want to synchronize to the
phone.
55
10 Using Other Applications
Using the Google Calendar
Use the Google Calendar application to create and manage
events, meetings, and appointments. Depending on your
synchronization settings, the calendar on your phone can be
synchronized with the Internet-based calendar you use.
Opening the Calendar
Touch > Google Calendar to open the application.
Calendar Panel
Touch to have the flowing options:
1. Switch to Day view.
2. Switch to Agenda view.
56
3. Switch to Week view.
4. Switch to Month view.
Creating an Event
1. In any calendar view, touch and select More >New
event to open the Event details screen.
2. Enter the event name.
If there is a time frame for the event, touch From and To to
set the beginning and end times of the event.
If the event is a special occasion such as a birthday or a
day-long activity, set the date for From and To, and select
All day.
3. Enter the location of the event and a description.
4. If you have more than one calendar, select the calendar
where you want to save the event.
5. Set the time of your event reminder in Reminders, and
specify in Repetition whether the event recurs and if it does,
how frequently.
6. Touch Done.
To quickly create an event in Day, Week, or Month view, touch
and hold an empty time slot, and touch New event. A new
event details screen will appear with the selected time slot and
date in From and To.
Setting an Event Reminder
1. In any agenda view, touch an event to view its details or
event summary.
2. Touch Add reminder “+” button to add a reminder. Or touch
the reminder’s “-” button to delete it.
57
3. Touch the reminder time, and then touch the length of time
before the event when you want to be reminded. When the
time comes, you will receive a notification about the event.
Customizing Calendar Settings
In any calendar view, touch , touch More > Settings, and
then choose from the following:
Hide declined events: Select to hide events for which you
have declined invitations.
Set alerts & notifications: Touch to set event reminders to
alert you, to send you a notification, or to turn off event
notifications on your phone.
Select ringtone: Touch to select the ringtone to sound when
you receive an event reminder.
Vibrate: Select to vibrate the mobile phone when you
receive an event notification.
Default reminder time: Touch to select the default time
before an event for event reminders to occur.
Using the Alarm
You can set a new alarm or modify an existing alarm.
Opening Alarm
Touch > Clock and touch to open the Alarm
application.
Alarm List Screen
58
1. Touch to add an alarm.
2. Touch to enable or disable an alarm.
Adding an Alarm
1. On the alarm list screen, touch Add alarm.
2. Set the alarm, and touch Done.
Setting an Alarm
1. On the alarm list screen, touch one of the alarms on the
screen.
2. In the time display area, flick up or down to set the time of
the alarm.
3. Touch Ringtone to select a ringtone for the alarm.
4. Select Vibrate to set the phone to vibrate, in addition to
playing the ringtone.
59
5. Touch Repeat to set the days when you want the alarm to
sound.
6. Touch Label to enter a name for the alarm.
7. Touch Done.
Using Audio Recorder
The Sound Recorder application is useful for quickly recording
your thoughts. You can also use the application to record your
voice and set it as a ringtone.
Audio Recorder Screen
1. Shows the recording duration.
2. Touch to start recording an audio clip.
3. Touch to pause or play back the recorded audio clip.
4. Touch to stop recording and enter a name for the recorded
audio clip.
60
Recording an Audio Clip
1. Touch > Sound Recorder to open the application.
2. Touch the start button to start recording.
3. Record your desired message.
4. Touch the stop button to stop recording.
Using the File Manager
Like a pocket-sized personal assistant (PA), the ES File Explorer
application lets you organize, edit and delete files or folders.
Opening File Manager
Touch > ES File Explorer to open the application.
Creating a Folder
1. On the ES File Explorer, access the directory in which you
want to create a folder.
2. Touch and select New > Folder, and then enter the
name of the new folder.
3. Touch OK.
Moving or Copying a File or Folder
4. Touch Cut or Copy to cut or copy the file or the folder.
5. Select the path where you want the file to be copied or
moved. Touch and hold the file, then touch Paste to move or
copy the file or the folder to the selected path.
61
Using Calculator
Use the Calculator application to solve simple arithmetic
problems or use its advanced operators to solve more complex
equations.
Opening Calculator
Touch > Calculator to open the application.
Switching Between Basic and Advanced panels
On the Calculator screen, flick right or left to switch between
Advanced panel and Basic panel.
Using RichPad
The RichPad application features a simple text processor. In the
note lists, you can add, edit, and delete notes.
1. Touch > RichPad to open the application.
2. Touch + in the upper right corner of the screen to create a
note.
3. After the note is saved, you can to share or delete it.
11 Managing Your Phone
To configure your phone, touch > Settings.
62
Setting the Date and Time
By default, your phone automatically uses the date, time, and
time zone provided by the network.
When your phone is using the date and time settings
automatically provided by the network, you cannot
manually set the date, time, and time zone.
1. On the Settings screen, touch Date & time.
2. Clear Automatic.
3. Touch Set date. In the displayed dialog box, touch + or – to
adjust the month, date, and year. Then touch Set when the
configuration is complete.
4. Touch Select time zone. In the displayed list, select the
desired time zone. Flick up and down to navigate through
the list and view more time zones.
5. Touch Set time. In the displayed dialog box, touch + or – to
adjust the hour and minute. Then touch Set when the
configuration is complete.
6. Select or clear Use 24-hour format to use 24-hour or
12-hour format.
7. Touch Select date format to select how you want the date
to display on your phone.
Setting the Display
Adjusting the Screen Brightness
1. On the Settings screen, touch Display > Brightness.
63
2. Drag the slider left to make the screen darker, or right to
make it brighter.
3. Touch OK to save the adjustment.
Adjusting the Time Before the Screen Turns Off
If your phone is idle for several minutes, it will turn the screen
off to save battery power. To set a longer or shorter idle time:
1. On the Settings screen, touch Display > Screen timeout.
2. Select the duration you want the screen to be illuminated.
Setting Ringers
Turning Silent Mode On
1. On the Settings screen, touch Audio profiles.
2. Select Silent mode to silence all sounds except media and
alarms.
Adjusting the Volume
You can adjust the volume from the home screen or any
application screen (except during a call or when playing music
or videos). Press the Volume keys to adjust the volume to the
level you desire.
You can also adjust the volume as follows:
1. On the Settings screen, touch Audio profiles and select a
profile you want to edit, then touch Volume> Ringtone.
2. Drag the slider left to make the volume lower, or right to
make it higher.
3. Touch OK to save the adjustment.
64
On the Volume screen, if you do not select Use incoming call
volume for notifications, you can separately set the incoming
call volume and the notification volume.
Changing the Phone Ringtone
1. On the Settings screen, touch Audio profiles and select a
profile you want to edit, then touch Phone ringtone.
2. Touch the ringtone you want to use, then touch OK. The
ringtone plays when selected.
To set a music file as the ringtone, open the Music
application, and hold the file name, and select Use as
phone ringtone.
Setting Your Phone to Vibrate for Incoming Calls
1. On the Settings screen, touch Audio profiles and select a
profile you want to edit.
2. If you select Vibrate, it will vibrate phone for incoming call.
Setting Phone Services
Customizing Call Settings
Your phone service provider offers different services such as call
forwarding, call waiting, fixed dialing numbers, and voicemail.
You can customize many of these services if they are part of
your calling plan.
On the Settings screen, touch Call settings to customize your
call settings.
Turning Data Roaming on
1. On the Settings screen, touch Wireless & networks >
Mobile networks.
65
2. Select SIM1 or SIM2, and then select Data roaming.
3. On the ES File Explorer screen. Touch and hold the file you
want to move or copy, or touch and hold the folder you
want to move.
Protecting Your Phone
Turning Your SIM Card PIN on
1. On the Settings screen, touch Location & security > Set up
SIM card lock.
2. Select SIM1 or SIM2, then select Lock SIM card.
3. Use the keyboard to enter the PIN, and touch OK.
4. To change the PIN at any time, touch Change SIM PIN.
You can dial emergency numbers any time from your
mobile phone.
Protecting Your Phone with a Screen Lock
To keep your data more secure, lock the screen and/or require a
screen unlock pattern every time your phone is turned on or
wakes up from sleep mode.
1. On the Settings screen, touch Location & security > Set up
screen lock > Pattern.
2. On the change unlock pattern screen, touch Next.
3. Flick your finger horizontally, vertically, or diagonally,
connect at least four dots in any order you select. Lift your
finger from the screen when you are finished.
66
You must drag your finger between the dots on the screen to
create the pattern and not simply touch individual dots.
4. Your phone will record the pattern. Touch Continue.
5. When prompted, draw the screen unlock pattern again, and
touch Confirm.
Clear Use visible pattern if you do not want the unlock pattern
to be displayed on the screen when you unlock the screen.
To change your screen unlock pattern, touch Location &
security > Change screen lock.
Managing Applications
Viewing an Installed Application
1. On the Settings screen, touch Applications > Manage
applications.
2. In the applications list, do any of the following:
Touch , and touch Sort by size. Then touch an
application to view its details.
Select Downloaded, Running, All, or On SD card from the
options menu. Then touch an application to view its details.
Directly touch an application to view its details.
Uninstalling an Application
1. On the Settings screen, touch Applications > Manage
applications.
2. Touch the application you want to remove from your phone.
Then touch Uninstall.
Ways to Free Up Your Phone Memory
Open Browser, and clear all temporary Internet files and
67
browser history information.
Uninstall any downloaded programs that you no longer use.
Factory date reset your phone.
Resetting Your Phone
Restoring Factory Data
If you reset your phone to the settings that were configured at
the factory, all of your personal data stored on the phone,
including information about your Google account, any other
accounts, your system and application settings, and any
applications you have downloaded will be erased. Resetting the
phone does not erase any system software updates you’ve
downloaded or any files on your microSD card, such as music
or photos.
1. On the Settings screen, touch Privacy > Factory data reset.
2. When prompted, touch Reset phone, then touch Erase
everything. The phone resets to the original factory settings,
and then restarts.
12 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
68
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or
interference with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device when using the
device is prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas, and
chemical plants. In addition, adhere to restrictions in areas
where blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats, chemical
69
transfer or storage facilities, and areas where the air contains
chemicals or particles such as grain, dust, or metal powders.
Ask the manufacturers of vehicles using liquefied petroleum
gas (such as propane or butane) whether this device can be
safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive
safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
70
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
On a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device powered by a
battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
71
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
the device, result in the non-operation of the device, and cause
danger.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and the talk time are shorter than the normal time, replace
the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
Do not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may be short-circuited and may cause injuries and
burns on your body.
72
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your eyes
with clean water immediately and consult a doctor.
If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
it may lead to battery leakage, overheating, explosion, or
fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to an electric shock, a
short circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Danger of explosion if battery is incorrectly replaced. Recycle
or dispose of used batteries according to the local
regulations or reference instruction supplied with your
device.
Cleaning and Maintenance
The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.
73
Do not place your device, battery, and charger in places
where they can get damaged because of collision. Otherwise,
it may lead to battery leakage, device malfunction,
overheating, fire, or explosion.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
Do not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
Before you clean or maintain the device, power off the
device and disconnect it from the charger.
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
be damaged or a fire can be caused. You can clean the
device and the charger with a piece of damp and soft
antistatic cloth.
Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
74
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for the amount of radio frequency energy absorbed by the
body when using a device. The SAR value is determined at the
highest certified power level in laboratory conditions, but the
actual SAR level of the device when being operated can be well
below the value. This is because the device is designed to use
the minimum power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the FCC and IC for this device
type when tested for use at the ear is 1.280 W/kg, and when
properly worn on the body is 1.170 W/kg.
75
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,there is no
guarantee that interference will not occur in a particular
installation.If this equipment does cause harmful interference
to radio or television reception,which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
76
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void
the FCC authorization to operate this device.
Version: 01 NO.:
