Huawei Technologies ETS8321 GSM 850/1900 Mobile Phone User Manual
Huawei Technologies Co.,Ltd GSM 850/1900 Mobile Phone
User Manual
ETS8121 8321
Cordless Phone
Copyright © 2008 Huawei Technologies Co., Ltd.
and other Huawei trademarks are the trademarks or registered trademarks of Huawei Technologies Co., Ltd.
in the People’s Republic of China and certain other countries. All other trademarks mentioned in this manual are the
property of their respective holders. The information in this manual is subject to change without notice. Every effort
has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information,
and recommendations in this manual do not constitute the warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China
Tel: +86-755-28780808 Global Hotline: +86-755-28560808
E-mail: mobile@huawei.com Website: www.huawei.com
1
Your Cordless Phone
Earpiece
# Key
Key
End/Power Key
Microphone
Number Keys
Left Soft Key
Send Key
Screen
Right Soft Key
Navigation Key
Charger Interface
Headset Jack
Note
z This is a sketch. Your cordless phone may be different.
It is subject to your actual one.
z To achieve the optimal effect, use the cordless phone
away from the charger stand.
2
Keys and Functions
Press
… To…
z View the dialed calls in the standby mode.
z Make or answer a call.
z Power on the cordless phone by pressing and
holding it.
z Power off the cordless phone by pressing and
holding it in standby mode.
z End a call or reject an incoming call.
z Return to the home screen.
Select the option displayed on the lower left corner of
the screen.
Select the option displayed on the lower right corner of
the screen.
z In the standby mode, press Navigation key to access
the shortcut screen.
z During a call, press left key or right key to adjust
the volume of the earpiece.
Number
Keys
z Enter numbers and characters.
z Speed-dial cordless phone numbers in the standby
mode (by pressing and holding the 1-9 keys).
z Select a submenu item labeled with the
corresponding number.
* key z Perform different operations for different functions
of the cordless phone.
z Unlock the keypad in the standby mode (by press
Menu and then press * key).
3
Press
… To…
# key z Perform different operations for different functions
of the cordless phone.
z Lock the keypad in the standby mode (by pressing
and holding it).
Screen Icons
Icon Description Icon Description
Network signal strength Battery power level
Calling Alarm clock is on
z Message received
z Memory for messages is
full, when the icon is
blinking
Keypad is locked
/ Remind by sound /
Without sound remind
Remind by vibration
4
Menu Tree
Messages Phone Book Call History
1. Write
2. Inbox
3. Outbox
4. Draft
5. VoiceMail
6. Settings
7. Memory Status
1. Name List
2. Add New
3. Speed Dials
4. Memory Status
1. Missed Calls
2. Answered
Calls
3. Outgoing Calls
Applications Phone
Settings
4. Alarm
1. Profiles
2. Call settings
3. Time & Data
4. Languages
5. Network
Service
6. Security
7. Version
8. Key Guard
9. Safe Code
5
Installing the SIM Card and Battery
Make sure that the golden area on the SIM card is facing downwards
and the cut-off edge is correctly fit to that of the card holder.
Charging the Battery
1. Connect the cordless phone to the charger stand.
2. Connect one power adapter connector to the charger stand.
3. Connect the charger to an AC power socket. During the charging,
the animation of charging icon is displayed.
4. When the cordless phone is fully charged, disconnect the charger
from the AC power socket first. Then disconnect the charger stand
from the charger.
5. When the charging icon becomes static, the cordless phone is
fully charged.
Using the Function Menu
1. In the standby mode, press to display the Menu interface.
2. Press Up or Down key to scroll in the menu.
3. Press to display the menu.
4. Display the submenu in either of the ways:
6
z Press Up or Down key to scroll to a submenu item and press
to select the submenu.
z Press the Number key corresponding to the number of a submenu
to select it.
5. Press to return to the previous menu or return to the home
screen.
6. Press to return to the home screen.
Making a Call
1. In the standby mode, enter a phone number.
2. Press to dial the number.
3. Press to end the call.
Note
z When the cordless phone is locked, enter the lock code to
unlock the cordless phone first; otherwise, you can only
make emergency calls or answer calls.
z In the standby mode, press to view the dialed
calls. Select a record and press to dial this
number.
z Select a contact from the cordless phonebook and press
to call this contact.
z During a call, press OK key to switch the Hands free.
Answering a Call
When there is an incoming call, you can press or to
answer it, or press to reject it.
7
If the any-key answer function is enabled, you can press any key
except and to answer an incoming call.
Cordless phone Lock
The cordless phone lock protects your cordless phone from
unauthorized use. The default cordless phone lock code is 000000.
You can change it into any numeric string of 4 to 8 digits.
If the cordless phone lock is enabled, you need to enter the correct
cordless phone lock code when you power on the cordless phone.
PIN and PUK
The personal identity number (PIN) protects your SIM card from
unauthorized use. The PIN unblocking key (PUK) can unblock the
blocked PIN. Both the PIN and PUK are delivered with the SIM card.
For details, consult your service provider.
If you enter wrong PINs three times consecutively, the cordless
phone asks you to enter the PUK code.
If you enter wrong PUKs ten times, the SIM card is invalidated
permanently. Contact your service provider for a new card.
Locking the Keypad
In the standby mode, press and hold to lock the keypad. When
the keypad is locked, you can press or to answer an
incoming call or make emergency calls.
You can press and to unlock the keypad.
When the keyguard function is enabled, if there is no operation on
the cordless phone for a preset period, the keypad is locked
automatically.
8
Changing the Text Input Modes
The indicator of the current text input mode is displayed on the
screen. In the editing mode, press to change the input mode.
Note z In the editing mode, press once to delete the letter
on the left of the cursor. Press and hold to delete
all the entered letters.
z In the "eZiEn" input mode, press to enter a space.
In the "ABC", "Abc" or "abc" input mode, press
once to enter a space, twice to enter "0".
z In the"ABC", "Abc" or "abc" input mode, press
repeatedly to select and enter the commonly used
punctuations. In the "eZiEn" input mode, press
repeatedly to enter a full stop.
Entering English (eZiEn)
In the "eZiEn" input mode, do the follows to enter the English letters:
1. Press each desired key once corresponding to the sequence of the
word. Then the cordless phone displays the commonly used words
according to the numeric sequence of key presses.
2. Press Up or Down key to scroll to the desired word.
3. Press Left or Right key to select the word. Press to enter
the word and a space.
Entering English (ABC, Abc or abc)
In the "ABC", "Abc" or "abc" input mode, you can press a key
labeled with the desired letters once to enter the first letter on the key,
twice to enter the second letter on the key, and so on.
9
Note If the letter you want to enter is on the same key as the
previous one, you can enter the latter one only after the
cursor appears again or after you press the Right key to
move the cursor to the next space.
Entering Numbers
1. In the "123" input mode, press a key labeled with the desired
number.
2. In the "ABC", "Abc" or "abc" input mode, press a key
continuously or press and hold it until the desired number appears
on the screen.
3. In the "eZiEn" input mode, press a key and then press the Down
navigation key to select desired number.
Entering Symbols
1. In any input mode, press to display a symbol list.
2. Press Up or Down Key to select the desired symbol.
3. Press the corresponding number key to enter the symbol.
10
Warnings and Precautions
Electronic Device
z Power off your cordless phone near high-precision electronic devices.
The cordless phone may affect the performance of these devices.
z Such devices include hearing aids, pacemakers, fire alarm systems,
automatic gates, and other automatic-control devices. If you are using
an electronic medical device, consult the device manufacturer to
confirm whether the radio wave affects the operation of this device.
z Pacemaker manufacturers recommend that a minimum separation of
15cm be maintained between a mobile cordless phone and a
pace-maker to avoid potential interference with the pace-maker. To
achieve this use the cordless phone on the opposite ear to your
pacemaker and do not carry it in a breast pocket.
Hospital
Pay attention to the following points in hospitals or health care facilities:
z Do not take your cordless phone into the operating room (OR),
intensive care unit (ICU), or coronary care unit (CCU).
z Do not use your cordless phone at places for medical treatment where
cordless phone use is prohibited.
z When using your cordless phone near someone who is suffering from a
heart disease, turn down the ring tone volume properly so that it does
not affect the person.
Area with Inflammables and Explosives
In any area with inflammables and explosives, power off your cordless
phone and do not take out, install or charge the battery, to avoid explosion
and fire. Areas with inflammables and explosives include, but are not
limited to:
z Gas station
z Area for storing fuels (such as the bunk under the deck of a ship)
z Device/Vehicle for transporting and storing fuels or chemical products
z Area with chemical substances and particles (such as: granule, dust,
metal powder) in the air
z Area with the sign of "Explosives"
z Area with the sign of "Power off bi-direction wireless equipment"
11
z Area where it is generally suggested to stop the engine or a vehicle
Traffic Safety
z Please observe local laws and regulations on cordless phone use. Do
not use your cordless phone while driving to avoid traffic accident.
z Secure the cordless phone on its holder. Do not place the cordless
phone on the seat or other places where it can get loose in a sudden
stop or collision.
z Use the cordless phone after the vehicle stops at a safe place.
z If your cordless phone supports the hands-free function, or the cordless
phone can be used with earphones, or there is any vehicle-mounted
equipment with hands-free function, use them in emergency.
z Do not place the cordless phone over the air bag or in the air bag
outspread area. Otherwise, the cordless phone may hurt you owing to
the strong force when the air bag inflates.
z Observe the rules and regulations of airline companies. When boarding
or approaching a plane, power off the cordless phone and take out the
battery. In areas where cordless phone use is prohibited, power off the
cordless phone. Otherwise, the radio signal of the cordless phone may
disturb the plane control signals. Power off your cordless phone before
boarding an aircraft.
Storage Environment
z Do not place magnetic storage media such as magnetic cards and
floppy disks near the cordless phone. Radiation from the cordless
phone may erase the information stored on them.
z Do not put your cordless phone, battery, or other accessories in
containers with strong magnetic field, such as an induction cooker and
a microwave oven. Otherwise, circuit failure, fire, or explosion may
occur.
z Do not leave your cordless phone, battery, or charger in a very hot or
cold place. Otherwise, malfunction of the products, fire, or explosion
may occur.
z Keep the ambient temperature between 0℃ and 45 while the battery ℃
is being charged. Keep the ambient temperature between –20℃ and
60 for storing the battery. If the ambient temperature is too low ℃
(especially below 0 ) or too high, the capacity and life of the battery ℃
will be reduced.
12
z Do not place sharp metal objects such as pins near the earpiece. The
earpiece may attract these objects and hurt you when you are using the
cordless phone.
z Do not subject your cordless phone, battery, and charger to serious
collision or shock. Otherwise, battery leakage, cordless phone
malfunction, overheating, fire, or explosion may occur.
z Do not put your cordless phone in the back pocket of your trousers or
skirt, to avoid cordless phone damage while seated.
Children Safety
z Put your cordless phone, battery, and charger in places beyond the
reach of children. Do not allow children to use the cordless phone,
battery, or charger without guidance.
z Do not allow children to put the battery in mouth, for electrolyte in the
battery is poisonous.
z Do not allow children to touch the small fittings. Otherwise, suffocation
or gullet jam can be caused if children swallow the small fittings.
Operating Environment
z The cordless phone, battery, and charger are not water-resistant. Keep
them dry. Protect the cordless phone, battery and charge from water or
vapor. Do not touch the cordless phone with a wet hand. Otherwise,
short-circuit and malfunction of the product or electric shock may occur.
z Do not use the cordless phone in dusty, damp and dirty places or places
with magnetic field. Otherwise, malfunction of the circuit may occur.
z Do not power on or off the cordless phone when it is near your ears to
avoid negative impact on your health.
z When carrying or using the cordless phone, keep the antenna at least
one inch (2.5 centimeters) away from your body, to avoid negative
impact on your health caused by radio frequency leakage.
z If you feel uncomfortable (such as falling sick or qualm) after playing
games on your cordless phone for a long time, please go to see a
doctor immediately.
z On a thunder stormy day, do not use your cordless phone outdoors or
when it is being charged.
z Do not touch the antenna when a call is going on. Touching the antenna
may affect call quality and cause the cordless phone to operate with
more power. As a result, the talk time and standby time are shortened.
13
z The cordless phone may interfere with nearby TV sets, radios and PCs.
z In accordance with international standards for radio frequency and
radiation, use cordless phone accessories approved by the
manufacturer only.
z While using the mobile cordless phone, observe the local laws and
regulations, and respect others' privacy and legal rights.
Clearing and Maintenance
z Before you clean or maintain the cordless phone, power off the cordless
phone and disconnect it from the charger. Otherwise, electric shock or
short-circuit of the battery or charger may occur.
z Do not use any chemical detergent, powder, or other chemical agent
(such as alcohol and benzene) to clean the cordless phone and the
charge. Otherwise, part damage or a fire can be caused. You can clean
the cordless phone and the charger with a piece of soft antistatic cloth
that is a little wet.
z Do not scratch the shell of the cordless phone. Otherwise, the shed
coating may cause skin allergy. Once it happens, stop using the
cordless phone at once and go to see a doctor.
z Keep the plug dry when you clean it, to prevent fire.
z If the cordless phone or any of its fittings does not work, turn to the local
authorize service center for help.
z Do not dismantle the cordless phone or accessories. Only an
authorized service center is allowed to maintain the cordless phone.
Environment Protection
z Please observe the local regulations regarding the disposal of your
packaging materials, exhausted battery and old cordless phone and
please promote their recycling. Do not dispose of exhausted battery or
old cordless phone in municipal waste or fire. Otherwise, explosion may
occur.
z This HUAWEI device complies with Directive 2002/95/EC on the
restriction of the use of certain hazardous substances in electrical and
electronic equipment.
Emergency Call
You can use your cordless phone for emergency calls. However,
connections in all conditions cannot be guaranteed. You should never rely
solely on the cordless phone for essential communications.
14
Battery
z Use the battery approved by the manufacturer only. Otherwise,
explosion may occur.
z Do not dispose of the battery in fire. Otherwise, the battery may ignite or
explode.
z Do not connect two poles of the battery with conductors such as cables,
jewelries or any other metal material. Otherwise, the battery is
short-circuited and it may burn your body.
z Do not disassemble the battery or solder the battery poles. Otherwise
fluid leakage, overheating, fire, or explosion may occur.
z If there is battery leakage, smoke, or strange smell, stop using the
battery and keep it away from open flame to avoid fire or explosion.
Then turn to an authorized maintenance engineer for help.
z If the battery fluid contacts your skin or cloth, wash with clean water
immediately to avoid irritation to the skin.
z If the battery fluid gets into eyes, do not rub your eyes. Otherwise, your
eyes can be hurt. Wash with clean water and go to see a doctor
immediately.
z If there is battery deformation, color change or abnormal heating while
you charge or store the battery, take it out immediately and stop using it.
Otherwise, battery leakage, overheating, explosion, or fire may occur.
z When installing the battery, do not push the battery by force lest battery
fluid leak out or the battery crack.
z Do not take out the battery when the cordless phone is turned on.
z If you do not use the battery for a long time, store it in normal
temperature after charging.
Charger
z Use the charger approved by the cordless phone manufacturer only.
Any violation of this rule may result in fire or malfunction of the charger.
z The socket-outlet shall be installed near the equipment and shall be
easily accessible.
z Do not short-circuit the charger. Short-circuiting the charger may cause
fire or malfunction of the charger.
z If the power cord is damaged (for example, the lead is exposed or
broken), or the plug becomes loose, stop using the cable at once.
Otherwise, electric shock, short-circuit of the charger, or fire may occur.
15
z Keep the charger dry. Once water or other liquid leaks into the charger,
electrical leakage or other faults may occur.
z Do not use the charger in a dusty and damp environment. Keep the
power cord away from any heating appliance.
z Ensure the charger is properly plugged into the power socket properly
when charging the battery. Improper insertion may result in electric
shock, fire, or explosion. To unplug the charger, pull the plug off rather
than tear the power cord.
z Use the AC power supply defined in the specifications of the charger.
An improper power voltage can cause fire or malfunction of the charger.
z Do not place any heavy object on the power cord of the charger. Do not
damage, change, or pluck the power cord. Otherwise electric shock or
fire may occur.
z When you are charging the battery with the charger, do not touch the
plug, power cord or the charger with a wet hand. Otherwise, electric
shock can be caused.
z Once the liquid such as water leaks into the charger, remove the plug of
the charger from the socket immediately. Otherwise, overheating, fire
and other malfunction may occur.
Specific Absorption Rate (SAR)
Your wireless device is a radio transmitter and receiver. It is designed not
to exceed the limits for exposure to radio waves recommended by
international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety margins
designed to assure the protection of all persons, regardless of age and
health.
The guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for wireless devices is 2.0 W/kg
and the highest SAR value for this device when tested complied with this
limit.
Body Worn Operation
Important safety information regarding radiofrequency radiation (RF)
exposure
To ensure compliance with RF exposure guidelines the device must be
used with a minimum of 1.5 cm separation from the body.
Failure to observe these instructions could result in your RF exposure
exceeding the relevant guideline limits.
16
Regulatory Information
The following approvals and notices apply in specific regions as noted.
CE Approval (European Union)
The wireless device is approved to be used in the member states of the EU.
The wireless device is in compliance with the essential requirements and
other relevant provisions of the Radio and Telecommunications Terminal
Equipment Directive 1999/5/EC (R&TTE Directive).
Federal Communications Commission Notice (United States): Before a
wireless device model is available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the limit established by the
government-adopted requirement for safe exposure.
The SAR limit adopted by the USA and Canada is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The highest SAR value reported to the
FCC for this device type was compliant with this limit.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Version: V100R001_01 Part Number: 3101
