HUAWEI F203
Fixed Wireless Terminal
USER GUIDE
Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted software of Huawei Technologies Co.,
Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify,
decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said
software, unless such restrictions are prohibited by applicable laws or such actions are approved by
respective copyright holders under licenses.
Trademarks and Permissions
, HUAWEI, and are trademarks or registered trademarks of Huawei Technologies Co.,
Ltd.
Other trademarks, product, service and company names mentioned are the property of their
respective owners.
Notice
Some features of the product and its accessories described herein rely on the software installed,
capacities and settings of local network, and may not be activated or may be limited by local network
operators or network service providers, thus the descriptions herein may not exactly match the
product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications
contained in this manual without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY
APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,
RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI
TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL
OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations and will obtain all
necessary governmental permits and licenses in order to export, re-export or import the product
mentioned in this manual including the software and technical data therein.
1
Your Fixed Wireless Terminal
1
2
3
4
5
6
7
8910
Note:
The figures of the FWT (Fixed Wireless Terminal) are only for your reference, please refer
color and shape to product.
No. Item Description
1 Left soft key Select the option displayed on the lower left corner of the screen.
2 Scroll keys y Access the shortcut screen in standby mode.
y Adjust the microphone and the earpiece volume during a call.
3 Right soft key Select the option displayed on the lower right corner of the screen.
4
OK key
y Access the main menu in standby mode.
y Select the option displayed on the lower left corner of the display
screen.
5
End key
y End a call or reject an incoming call.
y Power on or off the FWT in standby mode (by pressing and holding
it).
y Return to the standby mode.
2
No. Item Description
6 Call/Redial key
y Make or answer a call.
y View the call history in standby mode.
7
Hands-free key
y Activate/deactivate the hands-free mode in standby mode.
y Cancel the dialing, when dialing a number in the hands-free mode.
y End the current call during a call in the hands-free mode.
8 # key
y Lock the keypad in standby mode (by pressing and holding it).
y Switch between different input modes in editing mode.
9
* key
y Activate/deactivate the quiet profile in standby mode (by pressing
and holding it).
y Access the symbol screen in editing mode.
10
Number keys
y Number keys from 0 to 9: Enter numbers and characters.
y Number keys from 1 to 9: Press and hold a key to speed dial a
phone number in standby mode.
Screen Icons
Icon Description Icon Description
Network signal strength / Calling / No service
Alarm clock is on Hands-free mode
Message received Powered by the power adapter
Voice message received Battery power level
1
Menu Tree
Phone Book Messages CallHistory
1. Search
2. Add New
3. Groups
4. Speed Dial
5. Copy All（Optional）
6. Delete All
7. My Phone Num
8. Memory Status
1. Write Message
2. Inbox
3. Outbox
4. Draft
5. Voice Mail
6. Message Settings
7. Delete All
1. Missed Calls
2. Received Calls
3. Dialed Calls
4. Call Duration
5. Delete All
Recorder (Optional) Fun&Utility Profiles
1. Guest
Announcements
2. Recorder Settings
1. Alarm
2. Schedule
3. Calculator
4. Stopwatch
5. World Clock
6. Line Game
7. Smash Game
1. General
2. Outdoor
3. Quiet
Settings FM Radio (Optional)
1. Display
2. Call Settings
3. Phone Settings
4. Security
Installing the UIM Card (Optional)
Consult the service provider whether the UIM card is needed.
Power off the FWT and remove the power supply cable, and install the UIM card as shown. Make
sure that the golden contact on the UIM card is facing downwards.
2
Installing the Battery
Power off the FWT and remove the power supply cable, and install the battery as shown. Make sure
that the battery cord plug matches the battery jack. Do not insert the battery reversely.
Using the Power Adapter and Charging the Battery
Connect one end of the power adapter cable to the FWT and the other to the power socket.
Note:
y Remove the battery if the FWT is left unused for a long period.
y If the battery has not been used for a long time or the battery is exhausted, the screen of
the FWT may not function when you charge the battery again. This is normal. After the
battery is being charged for a while, you can power on the FWT for use.
y In normal conditions, the FWT depends on the power adapter for power supply and will
use the battery only in the case that the electricity has failed and the power adapter is
unavailable. As the battery can supply power only for a limited period, you must make
sure that the battery has been fully charged before putting it into use.
Using the Menu
1. In standby mode, press Left soft key to display the main menu.
2. Press Up/Down key to select a menu item.
3. Press Left soft key to display submenu.
4. Access the submenu in either of the ways:
y Press Up/Down key to scroll to a submenu item and press Left soft key to access it.
y Press the number key corresponding to the number of a submenu to access it.
5. Press Right soft key to return to the previous menu or return to the home screen.
6. Press End key to return to the standby mode.
3
Making a Call
1. In standby mode, enter a phone number.
2. Press Call key to dial the number.
3. Press End key to end the call.
Note:
y In standby mode, press Call key to view the call history. Select a record and press Call
key to dial this number.
y Select a phone number from the phonebook and press Call key to call this contact.
Answering a Call
When there is an incoming call, press Call key, Hands-free key, Left soft key or pick up the handset
to answer it. Press End key to reject it.
If the any-key answer function is activated, you can press any key except Right soft key and End
key to answer an incoming call.
Setting the Quiet Mode
y Method 1: In standby mode, press and hold the * key to activate/deactivate the quiet mode.
y Method 2: Choose Menu > Profiles > Quiet to activate the quiet mode.
Creating a Message
1. Choose Menu > Messages > Write Message.
2. Write the message.
3. Press Left soft key to select Send or Send&Save.
4. Insert recipients. Do the following:
y Enter the phone number directly.
y Insert a contact from the phone book.
y Insert group.
5. Press Left soft key to send a message.
Viewing a Message
The inbox stores received messages.
1. Choose Menu > Messages > Inbox.
2. Press Up/Down key to scroll the messages.
3. Press Left soft key to view the message.
4. Press Left soft key to reply, delete, or forward a short message, or call or save the phone
number of a message.
Changing Text Input Modes
In editing mode, the current text input mode is displayed. Press the # key to change the input mode.
Note:
y In the editing mode, press Right soft key once to delete the letter on the left of the cursor.
4
Press and hold Right soft key to delete all the entered letters.
y In the "ABC" "Abc" or "abc" input mode, press 0 once to enter a space, press 0 for two
consecutive times to enter a "0", and press 0 for three consecutive times to start a new
line.
y In the "ABC" "Abc" or "abc" input mode, press 1 repeatedly to select and enter the
commonly used punctuations.
Entering English (ABC, Abc or abc)
In "ABC" "Abc" or "abc" input mode, press number keys to enter English letters.
If the letter you want to enter is on the same key as the previous one, you can enter the letter only
after the cursor appears again or after you move the cursor to the next space.
If you hope the initial letter is capitalized, you need to change the input mode into "Abc" manually
before you enter the word.
Intelligent Input (eZiEn)
In " eZiEn" input mode, press number keys to enter English words.
1. According to the word to be entered, press the corresponding number keys once, and the FWT
makes out the candidate words.
2. Press Up/Down key or press * repeatedly to select the word.
3. Press Left/Right key to confirm your selection. The word is displayed in the input area.
Alternatively, press the 0 key to confirm your selection and enter a space behind the word.
Entering Numbers
In the "123" input mode, press a key labeled with the desired number.
Entering Symbols
1. In any input mode, press the * key to display a symbol list.
2. Press Up/Down key to scroll up or down the symbol list.
3. Press the corresponding number key to enter the symbol.
Using the Voice Caller ID Function (Optional)
You can use the Voice Caller ID function so that you can hear a voice caller ID when there is an
incoming call.
1. Choose Menu > Settings > Call Settings > Voice Caller ID.
2. Press Up/Down key to enable or disable the Voice Caller ID function.
Using the Recorder (Optional)
You can use the recorder so that the FWT can automatically answer an incoming call and record the
voice of a caller.
Note:
y When the FWT is recording the voice of the caller, you can press Right soft key to
answer the call. In this case, the FWT stops recording without saving the recorded clip.
y When the list of recorded clips is full, the FWT automatically deletes old clips.
5
Playing a Recorded Clip
1. Choose Menu > Recorder > Guest Announcements.
2. Press Up/Down key to select the recorded clip.
3. The FWT automatically plays the recorded clip.
Enabling or Disabling the Recorder
1. Choose Menu > Recorder > Recorder Settings > Recorder On/Off.
2. Press Up/Down key to enable or disable the recorder.
Setting the Auto Answer Function
1. Choose Menu > Recorder > Recorder Settings > Auto Answer.
2. Press Up/Down key to select the interval between the ringing of the FWT and the automatic
answer of the phone.
Enabling or Disabling the Recording Monitoring Function
When the FWT is recording the voice of a caller, you can listen to the recording and determine
whether to answer the call.
1. Choose Menu > Recorder > Recorder Settings > Recording Monitoring.
2. Press Up/Down key to enable or disable the Recording Monitoring function.
FWT Lock
The FWT lock protects your FWT from unauthorized use. The default FWT lock code is 000000. You
can change it into any numeric string of 4 to 8 digits.
When the FWT is locked, enter the lock code to unlock the FWT first; otherwise, you can only make
emergency calls or answer calls.
PIN and PUK (Optional)
The personal identity number (PIN) protects your UIM card from unauthorized use. The PIN
unblocking key (PUK) can unblock the blocked PIN. If you enter wrong PIN codes for multiple times,
your UIM card is locked. In this case, you need to enter the PUK code to unlock the UIM card. Both
the PIN and PUK are delivered with the UIM card. For details, consult your service provider.
Keypad Lock
In standby mode, press and hold the # key to lock the keypad.
In standby mode, press Left soft key and then press the * key to unlock the keypad.
In standby mode, if the automatic keypad lock function is enabled and the standby time exceeds the
preset period, the keypad will be automatically locked.
Warnings and Precautions
This section contains important information pertaining to the operating instructions of your device. It
also contains information about how to use the device safely. Read this information carefully before
using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not use the device when using the device
6
causes danger or interference with electronic devices.
Medical Device
y Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device
when using the device is prohibited.
y Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between
a device and a pacemaker to prevent potential interference with the pacemaker. If you are using a
pacemaker, use the device on the opposite side of the pacemaker and do not carry the device in
your front pocket.
y Some wireless devices may affect the performance of hearing aids. For any such problems,
consult your service provider.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive atmosphere, and comply with all signs
and instructions. Areas that may have potentially explosive atmospheres include the areas where you
would normally be advised to turn off your vehicle engine. Triggering of sparks in such areas could
cause an explosion or a fire, resulting in bodily injuries or even deaths. Do not power on your device
at refueling points such as service stations. Comply with restrictions on the use of radio equipment in
fuel depots, storage, and distribution areas, and chemical plants. In addition, adhere to restrictions in
areas where blasting operations are in progress. Before using the device, watch out for areas that
have potentially explosive atmospheres that are often, but not always, clearly marked. Such locations
include areas below the deck on boats, chemical transfer or storage facilities, and areas where the air
contains chemicals or particles such as grain, dust, or metal powders. Ask the manufacturers of
vehicles using liquefied petroleum gas (such as propane or butane) whether this device can be safely
used in their vicinity.
Traffic Security
y Do not use your device while driving, and observe the local laws and regulations.
y Do not use your device while flying in an aircraft. Power off your device before boarding an aircraft.
Using wireless devices in an aircraft may cause danger to the operation of the aircraft and disrupt
the wireless telephone network. It may also be considered illegal.
Operating Environment
y Do not use or charge the device in dusty, damp, and dirty places or places with magnetic fields.
Otherwise, it may result in a malfunction of the circuit.
y On a stormy day with thunder, do not use your device, to prevent any danger caused by lightning.
y When you are on a call, do not touch the antenna. Touching the antenna affects the call quality and
results in increase in power consumption. As a result, the talk time and the standby time are
reduced.
y Use accessories authorized by the manufacturer. Using unauthorized accessories will render the
warranty null and void.
y Because the device needs to disperse heat during working, place the device and the power supply
in a ventilated and shady place. Never cover the device, put objects on it, or place it near water, fire
as well as inflammable and explosive materials.
y This device should be installed and operated with a minimum distance of 20 cm between the
antenna and all persons.
y Keep the ambient temperature between -10°C and 45°C while the device is being charged. Keep
the ambient temperature between -10°C to 55°C for using the device powered by a battery.
Safety of Children
Comply with all precautions with regard to children's safety. Letting the child play with your device or
its accessories, which may include parts that can be detached from the device, may be dangerous, as
it may present a choking hazard. Ensure that small children are kept away from the device and
accessories.
7
Accessories
Use the accessories delivered only by the manufacturer. Using accessories of other manufacturers or
vendors with this device model may invalidate any approval or warranty applicable to the device,
result in the non-operation of the device, and cause danger.
Battery and Charger
y Unplug the charger from the electrical plug and the device when not in use.
y Do not connect two poles of the battery with conductors, such as metal materials, keys, or
jewelries. Otherwise, the battery may be short-circuited and may cause injuries and burns on your
body.
y Do not disassemble the battery or solder the battery poles. Otherwise, it may lead to electrolyte
leakage, overheating, fire, or explosion.
y If battery electrolyte leaks out, ensure that the electrolyte does not touch your skin and eyes. When
the electrolyte touches your skin or splashes into your eyes, wash your eyes with clean water
immediately and consult a doctor.
y If there is a case of battery deformation, color change, or abnormal heating while you charge or
store the battery, remove the battery immediately and stop using it. Otherwise, it may lead to
battery leakage, overheating, explosion, or fire.
y If the power cable is damaged (for example, the cord is exposed or broken), or the plug loosens,
stop using the cable at once. Otherwise, it may lead to an electric shock, a short circuit of the
charger, or a fire.
y Do not dispose of batteries in fire as they may explode. Batteries may also explode if damaged.
y Danger of explosion if battery is incorrectly replaced. Recycle or dispose of used batteries
according to the local regulations or reference instruction supplied with your device.
Cleaning and Maintenance
y The device, battery, and charger are not water-resistant. Keep them dry. Protect the device, battery,
and charger from water or vapor. Do not touch the device or the charger with a wet hand.
Otherwise, it may lead to a short circuit, a malfunction of the device, and an electric shock to the
user.
y Do not place your device, battery, and charger in places where they can get damaged because of
collision. Otherwise, it may lead to battery leakage, device malfunction, overheating, fire, or
explosion.
y Do not place magnetic storage media such as magnetic cards and floppy disks near the device.
Radiation from the device may erase the information stored on them.
y Do not leave your device, battery, and charger in a place with an extreme high or low temperature.
Otherwise, they may not function properly and may lead to a fire or an explosion.
y Do not place sharp metal objects such as pins near the earpiece. The earpiece may attract these
objects and hurt you when you are using the device.
y Before you clean or maintain the device, power off the device and disconnect it from the charger.
y Do not use any chemical detergent, powder, or other chemical agents (such as alcohol and
benzene) to clean the device and the charger. Otherwise, parts of the device may be damaged or a
fire can be caused. You can clean the device and the charger with a piece of damp and soft
antistatic cloth.
y Do not dismantle the device or accessories. Otherwise, the warranty on the device and
accessories is invalid and the manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service area. The connection, however, cannot be
guaranteed in all conditions. You should not rely solely on the device for essential communications.
8
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,there is no guarantee that interference
will not occur in a particular installation.If this equipment does cause harmful interference to radio or
television reception,which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Warning: Changes or modifications made to this device not expressly approved by Huawei
Technologies Co., Ltd. may void the FCC authorization to operate this device.
Version: V100R001_01 Part Number: 96720XXX
