Huawei Technologies G1000 GSM Mobile Phone User Manual HUAWEI G1000
Huawei Technologies Co.,Ltd GSM Mobile Phone HUAWEI G1000
(HUAWEI G1000)User Manual.pdf
Copyright © Huawei Technologies Co., Ltd. 2011.
All rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
i
Contents
Your Phone ........................................................................................... 1
Keys and Functions ........................................................................... 2
Screen Icons......................................................................................... 4
Installing the SIM Card.................................................................... 5
Removing the SIM Card.................................................................. 6
Charging the Battery........................................................................ 6
Working with the Function Menus............................................. 7
Making a Call....................................................................................... 7
Answering a Call................................................................................. 8
Phone Lock ........................................................................................... 9
PIN and PUK ........................................................................................ 9
Locking the Keypad .......................................................................... 9
Changing the Text Input Modes................................................10
Multi-tap Input Mode....................................................................10
Predictive Input Mode...................................................................11
Entering a Digit.................................................................................11
Entering a Symbol ...........................................................................12
Flashlight (Optional) .......................................................................12
FM Radio (Optional) .......................................................................12
Warnings and Precautions...........................................................13
1
Features marked with “Optional” are optional. These
features may vary according to certain models.
Your Phone
The following figure shows the appearance of your phone and
it is for your reference only.
1 Earpiece 7 Flashlight
2 Screen 8 # key
3 Left soft key 9 Number keys
4 Navigation key 10 End/Power key
2
5 Call/Answer key 11 Right soft key
6 * key 12 Charger jack
Keys and Functions
Press… To…
Make a call.
Answer a call.
Access Dialed calls in standby mode.
Power the phone on or off (by pressing and
holding the key for about 3s).
End or reject a call.
Return to the standby mode.
Access Menu in standby mode.
Select a highlighted item.
Access Contacts in standby mode.
Return to the previous menu.
3
Press… To…
Turn the Flashlight on (by pressing and holding
for about 3s or by pressing twice in
standby mode).
Turn the Flashlight off ( ).
Access the Alarm clock ( ) in standby
mode.
Access Call Records ( ) in standby mode.
Access the Calculator ( ) in standby mode.
Increase the volume ( ) or decrease the
volume ( ) during a call.
-
Enter numbers, letters, and symbols.
Enter + in standby mode (by pressing and
holding the 0 key for about 3s).
Call the voicemail in standby mode (by pressing
and holding the 1 key for about 3s).
Speed-dial phone numbers in standby mode
(by pressing and holding the desired key 2–9
for about 3s).
Select a submenu item labeled with the
corresponding number.
4
Press… To…
Enter * (by pressing the key) or enter P (by
pressing and holding the key) in standby mode.
Display the symbol list in any input mode.
Enter #.
Lock the keypad in standby mode (by pressing
and holding the key for about 3s).
Switch between input methods in text editing
mode.
If the phone cannot be powered on after you press and
hold , the battery may run out of power. In that
case, charge the phone for about five minutes (during
this period, the charging icon may not be displayed on
the screen), and then power on the phone again.
Screen Icons
Icon Description
Signal strength.
New text message.
5
Roaming.
Call forwarding enabled.
Alarms enabled.
Keypad locked.
Battery power level.
Standard profile activated.
Conference profile activated.
Outdoor profile activated.
Mute profile activated.
Customize profile activated.
FM Radio activated.
Missed call(s).
Installing the SIM Card
Before installing the Subscriber Identification Module (SIM)
card, ensure that your phone is powered off. When inserting a
SIM card, ensure that the golden contact area on the SIM card
is facing downward and that the beveled edge of the SIM card
is properly aligned with that of the SIM card slot.
6
Removing the SIM Card
Before removing the SIM card, ensure that your phone is
powered off.
If the phone does not work properly or if crashes occur,
you can press and hold the battery reset button on the
right side of the SIM card slot until the phone is
powered on again.
Charging the Battery
To charge the battery, do the following:
1. Connect the charger to an alternating current (AC) power
socket.
2. Connect the charger to the charger jack on the phone.
7
3. Wait until the battery is completely charged.
When the battery is being charged, an animated charging
icon is displayed on the screen. When the charging icon
becomes static, the battery is fully charged.
4. Disconnect the charger from the phone.
5. Disconnect the charger from the AC power socket.
Working with the Function Menus
1. In standby mode, press (Menu).
2. Press to select the desired function menu.
3. Press (Select) to access the selected menu.
4. Select a submenu in either of the following ways:
Press to scroll to the desired submenu.
Press the number keys corresponding to the serial number
of the submenu.
5. Press (Select) to display the submenu.
6. Press (Back) to return to the previous menu or exit
the function menu.
To return directly to the standby mode, press .
Making a Call
1. In standby mode, enter the phone number.
8
To make an international call, press and hold to enter
the plus sign (+), and then enter the country code or region
code, area code, and phone number in sequence.
To dial an extension number, enter the phone number, press
and hold to enter P, and then enter the extension
number.
2. Press to dial the number.
3. Press to end the call.
You can also make a call through call logs, contacts,
and messages.
During a call, press to adjust the volume.
Answering a Call
When there is an incoming call, you can do as follows:
Press to answer it.
Press (Options), and then select Accept to answer it.
Press (Reject) or to reject it.
If the Any key answer function is enabled, you can press any
key except and to answer an incoming call.
9
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock function is disabled. You can change the
default phone lock code (0000) into any numeric string of four
to eight digits.
If you forget the phone code, contact your service provider.
PIN and PUK
The personal identification number (PIN) protects your SIM
card from unauthorized use. The PIN unblocking key (PUK)
unlocks a blocked PIN. Both the PIN and the PUK are provided
with the SIM card. For details, consult your service provider.
If you enter an incorrect PIN a pre-defined number of
consecutive times, the phone prompts you to enter the PUK. If
you enter an incorrect PUK a pre-defined number of
consecutive times, the SIM card becomes permanently invalid.
In that case, contact your service provider for a new SIM card.
Locking the Keypad
To lock the keypad, press and hold in standby mode for
about 3s. To unlock the keypad, press and then in
succession.
If the Keypad lock function is enabled and if the phone is in
standby mode for a preset period, the phone locks the keypad
automatically.
10
When the keypad is locked, you can press to
answer a call or make an emergency call.
Changing the Text Input Modes
The indicator of the current text input mode is displayed in the
upper left corner of the screen. You can press to change
the text input mode.
Indicator Text Input Mode
ABC, Abc and abc Multi-tap input mode
Eng Predictive input mode
123 Number input mode
You can press (Delete) once to delete the last
entered character. You can also press and hold
(Delete) for about 3s to delete all the entered characters
at once.
Multi-tap Input Mode
To enter text in multi-tap input mode, press the key labeled
with the desired letter once to enter the first letter on the key,
twice to enter the second letter on the key, and so on.
11
Press consecutively to enter commonly used
punctuations.
Press once to enter a space and twice to enter
0.
Predictive Input Mode
To enter text in predictive input mode, do the following:
1. Press each key once according to the spelling sequence of
the desired word.
The phone displays candidate words.
2. Press to scroll to the desired word.
You can press to switch a selected letter between the
upper case and the lower case.
3. Press to enter the word.
Press to display commonly used punctuations.
Press to enter a space.
Entering a Digit
In "123" input mode, directly press the number key labeled
with desired digits.
12
In multi-tap input mode, press a number key consecutively
until the desired digit appears on the screen.
Entering a Symbol
1. Press to display the symbol list.
2. Press to scroll to the desired symbol.
3. Press to enter the symbol.
Flashlight (Optional)
Your phone comes with a flashlight. You can use this feature in
the case of weak light.
To use the flashlight, do the following:
1. Select Menu > Applications > Flashlight.
2. Select On to turn the flashlight on.
3. Select Off to turn the flashlight off.
You can also turn the flashlight on by pressing and
holding the up navigation key for about 3s or by
pressing the up navigation key twice continuously. You
can also turn off the flashlight by pressing the up
navigation key once.
FM Radio (Optional)
Your phone comes with a built-in antenna. You can listen to
radio programs without a headset.
To use the FM radio, do the following:
13
1. Select Menu > Applications > FM radio to launch the FM
radio.
2. On the FM radio screen, do the following:
Press to change the channel.
Press and hold for about 3s to make the phone
automatically search for channels.
Press the number key corresponding to the serial number of
a channel to play the channel.
Press to adjust the volume.
Press (Options) to view or set the channel list, search
for channels, set a frequency, change the Radio Data System
(RDS), or turn off the FM radio.
Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or
interference with electronic devices.
14
Medical Device
Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device when using the
device is prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas, and
chemical plants. In addition, adhere to restrictions in areas
where blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats, chemical
transfer or storage facilities, and areas where the air contains
chemicals or particles such as grain, dust, or metal powders.
15
Ask the manufacturers of vehicles using liquefied petroleum
gas (such as propane or butane) whether this device can be
safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive
safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
16
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body to
meet the requirement earlier mentioned.
On a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device powered by a
battery.
17
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
the device, result in the non-operation of the device, and cause
danger.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and the talk time are shorter than the normal time, replace
the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
18
Do not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may be short-circuited and may cause injuries and
burns on your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your eyes
with clean water immediately and consult a doctor.
If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
it may lead to battery leakage, overheating, explosion, or
fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to an electric shock, a
short circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Danger of explosion if battery is incorrectly replaced. Recycle
or dispose of used batteries according to the local
regulations or reference instruction supplied with your
device.
19
Cleaning and Maintenance
The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.
Do not place your device, battery, and charger in places
where they can get damaged because of collision. Otherwise,
it may lead to battery leakage, device malfunction,
overheating, fire, or explosion.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
Do not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
Before you clean or maintain the device, power off the
device and disconnect it from the charger.
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
be damaged or a fire can be caused. You can clean the
20
device and the charger with a piece of damp and soft
antistatic cloth.
Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for the amount of radio frequency energy absorbed by the
body when using a device. The SAR value is determined at the
highest certified power level in laboratory conditions, but the
actual SAR level of the device when being operated can be well
21
below the value. This is because the device is designed to use
the minimum power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the FCC and IC for this device
type when tested for use at the ear is 1.270 W/kg, and when
properly worn on the body is 0.451 W/kg.
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,there is no
guarantee that interference will not occur in a particular
installation.If this equipment does cause harmful interference
to radio or television reception,which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
22
Consult the dealer or an experienced radio/TV technician for
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void
the FCC authorization to operate this device.
Version: 01 NO.:601060
