Huawei Technologies G2200C GSM Mobile Phone User Manual Manual
Huawei Technologies Co.,Ltd GSM Mobile Phone Manual
Manual
![](/img.php?id=1224057&img=bg2.png)
Copyright © Huawei Technologies Co., Ltd. 2009. All
rights reserved.
No part of this document may be reproduced or transmitted in any
form or by any means without prior written consent of Huawei
Technologies Co., Ltd.
The product described in this manual may include copyrighted
software of Huawei Technologies Co., Ltd and possible licensors.
Customers shall not in any manner reproduce, distribute, modify,
decompile, disassemble, decrypt, extract, reverse engineer, lease,
assign, or sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by
respective copyright holders under licenses.
Trademarks and Permissions
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
Notice
Some features of the product and its accessories described herein
rely on the software installed, capacities and settings of local
network, and may not be activated or may be limited by local
network operators or network service providers. Thus the
descriptions herein may not exactly match the product or its
accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify
any information or specifications contained in this manual without
prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and will obtain all necessary governmental permits and
licenses in order to export, re-export or import the product
mentioned in this manual including the software and technical data
therein.
i
Table of Contents
1 Getting to Know Your Phone .................................................... 1
Your Phone ..........................................................................1
SIM Card..............................................................................2
Charging the Battery ............................................................2
Keys.....................................................................................3
Screen Icons.........................................................................4
2 Getting Started ........................................................................ 5
Phone Lock ..........................................................................5
PIN and PUK ........................................................................6
WAP ....................................................................................6
Keypad Lock.........................................................................6
3 Call Functions .......................................................................... 7
Making a Call.......................................................................7
Answering a Call ..................................................................7
Rejecting/Ending a Call .........................................................7
4 Text Entry................................................................................. 8
Changing the Text Input Mode .............................................8
Entering an English Word .....................................................8
Entering a Digit ....................................................................9
Entering a Symbol ................................................................9
5 Messaging ...............................................................................9
Writing and Sending a Text Message ....................................9
Writing and Sending a Multimedia Message .......................10
6 Radio .................................................................................... 10
7 Warnings and Precautions....................................................... 12
![](/img.php?id=1224057&img=bg5.png)
1
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone and it is
for your reference only.
1 Earpiece/Speaker 3 Charger jack
2 Headset jack 4 Microphone
![](/img.php?id=1224057&img=bg6.png)
2
SIM Card
Insert your SIM card before using your phone. Remove the SIM card
and the battery only after powering off your phone.
The following figures show the installation of the SIM card.
1. Insert the SIM card. 3. Install the battery cover.
2. Insert the battery.
Charging the Battery
1. Connect the charger to an AC power socket.
2. Connect the charger to the charger jack on the phone.
3. Wait until the battery is completely charged.
During the charging, the charging icon is displaying in animation.
When the charging icon becomes static, the battery is fully
charged.
4. Disconnect the charger from the phone.
5. Disconnect the charger from the AC power socket.
![](/img.php?id=1224057&img=bg7.png)
3
Keys
z In this manual, the navigation keys of your phone are
indicated by the follow icons: , , , .
z To customize the four navigation keys as the shortcuts to
different functions, select Menu > Settings > Shortcut
Settings.
Press ... To …
z Make a call.
z Answer an incoming call.
z View call logs in standby mode.
z Power on or off the phone (by pressing and holding
the key for about 5s).
z End or reject a call.
z Return to the standby mode.
Select the option displayed in the lower left corner of
the screen.
Select the option displayed in the lower right corner
of the screen.
z Access the default shortcuts in standby mode.
z During a call, increase the volume ( ) or
decrease the volume ( ).
z Access the main menu in standby mode.
z Confirm a selection.
![](/img.php?id=1224057&img=bg8.png)
4
Press ... To …
–
z Enter digits, letters, and symbols.
z Call the voice mail center in standby mode (by
pressing the 1 key for about 3s).
z Speed-dial phone numbers in standby mode (by
pressing and holding the 2–9 keys for about 3s).
z In standby mode, press the key once to enter *,
twice to enter +, and three times to enter P.
z Enable or disable Meeting profile in standby mode
(by pressing and holding the key for about 3s).
z Enter #.
z Lock the keypad in standby mode (by pressing and
holding the key for about 3s).
Screen Icons
Icon Indicates …
Signal strength.
GPRS.
The phone is roaming.
Battery power level.
An alarm is activated.
The keypad is locked.
The Silent profile is activated.
The General profile is activated.
![](/img.php?id=1224057&img=bg9.png)
5
Icon Indicates …
The Outdoor profile is activated.
The Meeting profile is activated.
The My Profile is activated.
The headset is plugged.
Unread voice message(s).
Unread text message(s).
The SMS memory is full when the icon is red.
Unread multimedia message(s).
Unread push message(s).
The call forwarding function is enabled.
Ongoing call.
2 Getting Started
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock function is disabled. You can change the
default phone lock code (0000) into any numeric string in the range
of four to eight digits.
Do remember your phone lock code. If you forget it, contact the
service center.
![](/img.php?id=1224057&img=bga.png)
6
PIN and PUK
The personal identification number (PIN) protects your SIM card from
unauthorized use. The PIN unblocking key (PUK) can unlock the
blocked PIN. Both PIN and PUK are delivered with the SIM card. For
details, consult your service provider.
If you enter wrong PINs for a specified number of times consecutively,
the phone asks you to enter the PUK.
If you enter wrong PUKs for a specified number of times
consecutively, the SIM card is invalidated permanently. Contact your
service provider for a new one.
WAP
WAP page browsing is network dependent. To use this service, you
need to contact your network service provider, subscribe to the GPRS
service, and obtain the settings such as the WAP gateway.
Set the related parameters and then launch the browser. Then you
can surf the Internet through your phone, downloading your desired
images, ringtones, or music.
Keypad Lock
To lock the keypad in standby mode, press and hold for about
3s. When the keypad is locked, you can still press to answer
incoming calls or make emergency numbers.
To unlock the keypad in standby mode, press and then
in succession.
If the Auto Keypad Lock function is enabled and if the phone is idle
in standby mode for a specified period of time, the phone
automatically locks the keypad.
![](/img.php?id=1224057&img=bgb.png)
7
3 Call Functions
Making a Call
1. In standby mode, enter the phone number.
z To make an international call, press twice consecutively to
enter the international long distance code. Then enter the
country code or region code, area code, and phone number in
sequence.
z To call an extension, enter the phone number, press twice
consecutively to insert P, and then enter the extension number.
2. Press to dial the number.
3. Press to end the call.
z You can also make a call through call logs, contacts and
messages.
z During a call, press and to adjust the volume,
press to enable or disable the hands-free mode.
Answering a Call
To answer a call, press .
If the any-key answer function is enabled, you can press any key
(except and ) to answer the call.
Rejecting or Ending a Call
To reject or end a call, press .
![](/img.php?id=1224057&img=bgc.png)
8
4 Text Entry
Changing the Text Input Mode
The indicator of the current text input mode is displayed on the
upper left corner of the screen. You can press to change the text
input mode.
Icon Indicates …
Eng Predictive input mode
Abc, abc, and ABC Multi-tap input mode
123 Digit input mode
z Press (Delete) once to delete the character on the
left of the cursor. Press and hold (Delete) for
about 3s to clear all the characters.
z In any input mode except "123", press to enter a
space, press once to enter a comma, and press
consecutively to enter another commonly used
punctuation.
Entering an English Word
Multi-tap Input Mode
In multi-tap input mode, you can press a key labeled with the desired
letter once to enter the first letter on the key, twice to enter the
second letter on the key, and so on.
![](/img.php?id=1224057&img=bgd.png)
9
Predictive Input Mode
In predictive input mode, do as follows to enter a word:
1. Press each key only once according to the spelling sequence of
the desired word.
The phone displays the commonly used word according to the
numeric sequence of key presses.
2. Press or to scroll to the desired word.
3. Press to enter the word.
Entering a Digit
z In "123" input mode, press the number keys labeled with the
desired digits.
z In multi-tap input mode, press the number key repeatedly until
the desired digit appears on the screen.
Entering a Symbol
1. Press to display a symbol list.
2. Press , , , or to scroll to the desired symbol.
3. Press to enter the symbol.
5 Messaging
Writing and Sending a Text Message
1. Select Menu > Message > SMS > Create Message.
2. Write the message.
3. Press and then select Send.
![](/img.php?id=1224057&img=bge.png)
10
4. Add recipient(s).
You can enter the phone number, or select the recipient from the
Contacts.
5. Press to send the message.
Writing and Sending a Multimedia Message
The Multimedia Messaging Service (MMS) is network dependent. To
use this service, you need to contact your network service provider,
subscribe to the GPRS service, and obtain the settings such as the
Wireless Application Protocol (WAP) gateway and the number of the
MMS service center.
1. Select Menu > Message > MMS > New MMS.
2. Write the message.
Press and then select Add Image, Add Audio, or another
option.
3. Press and then select Send.
4. Select from the following options:
z To, Cc or Bcc: to add recipient(s).
You can enter the phone number, or select the recipient from the
Contacts.
z Sub: to edit the subject of the multimedia message.
z Send: to send the multimedia message.
6 Radio
Before using the radio, connect the headset to the phone. The
headset cable also functions as an antenna. To ensure good
reception of radio programs and sound audio quality, do not bend
the headset cable.
![](/img.php?id=1224057&img=bgf.png)
11
1. Insert the headset to the headset jack properly.
2. Choose Menu > FM Radio to activate the FM radio.
After loading, the phone plays a program.
3. On the FM Radio screen, you can do as follows:
z Press , or the control key on the headset cable to
change channels.
z Press or to adjust the volume.
z Press (Options) to tune off the FM radio, enable or
disable the loudspeaker, view the channel list, tune, delete
channels, or rename current channel.
12
7 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains information
about how to use the device safely. Read this information carefully
before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not use
the device when using the device causes danger or interference with
electronic devices.
Medical Device
z Follow rules and regulations set forth by hospitals and health care
facilities. Do not use your device when using the device is
prohibited.
z Pacemaker manufacturers recommend that a minimum distance
of 15 cm be maintained between a device and a pacemaker to
prevent potential interference with the pacemaker. If you are
using a pacemaker, use the device on the opposite side of the
pacemaker and do not carry the device in your front pocket.
z Some wireless devices may affect the performance of hearing
aids. For any such problems, consult your service provider.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas that
may have potentially explosive atmospheres include the areas where
you would normally be advised to turn off your vehicle engine.
Triggering of sparks in such areas could cause an explosion or a fire,
resulting in bodily injuries or even deaths. Do not power on your
device at refueling points such as service stations. Comply with
restrictions on the use of radio equipment in fuel depots, storage,
13
and distribution areas, and chemical plants. In addition, adhere to
restrictions in areas where blasting operations are in progress. Before
using the device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked. Such
locations include areas below the deck on boats, chemical transfer or
storage facilities, and areas where the air contains chemicals or
particles such as grain, dust, or metal powders. Ask the
manufacturers of vehicles using liquefied petroleum gas (such as
propane or butane) whether this device can be safely used in their
vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with the
following guidelines:
z Concentrate on driving. Your first responsibility is to drive safely.
z Do not talk on the device while driving. Use hands-free
accessories.
z When you have to make or answer a call, park the vehicle at the
road side before using your device.
z RF signals may affect electronic systems of motor vehicles. For
more information, consult the vehicle manufacturer.
z In a motor vehicle, do not place the device over the air bag or in
the air bag deployment area. Otherwise, the device may hurt you
owing to the strong force when the air bag inflates.
z Do not use your device while flying in an aircraft. Power off your
device before boarding an aircraft. Using wireless devices in an
aircraft may cause danger to the operation of the aircraft and
disrupt the wireless telephone network. It may also be considered
illegal.
Operating Environment
14
z Do not use or charge the device in dusty, damp, and dirty places
or places with magnetic fields. Otherwise, it may result in a
malfunction of the circuit.
z The device complies with the RF specifications when the device is
used near your ear or at a distance of 1.5 cm from your body.
Ensure that the device accessories such as a device case and a
device holster are not composed of metal components. Keep
your device 1.5 cm away from your body to meet the
requirement earlier mentioned.
z On a stormy day with thunder, do not use your device when it is
being charged, to prevent any danger caused by lightning.
z When you are on a call, do not touch the antenna. Touching the
antenna affects the call quality and results in increase in power
consumption. As a result, the talk time and the standby time are
reduced.
z While using the device, observe the local laws and regulations,
and respect others' privacy and legal rights.
z Keep the ambient temperature between 0°C and 55°C while the
device is being charged. Keep the ambient temperature between
-10°C to 55°C for using the device powered by a battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To reduce
the risk of damage to hearing, lower the headset volume to a safe
and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety. Letting
the child play with your device or its accessories, which may include
parts that can be detached from the device, may be dangerous, as it
may present a choking hazard. Ensure that small children are kept
away from the device and accessories.
Accessories
15
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to the
device, result in the non-operation of the device, and cause danger.
Battery and Charger
z Unplug the charger from the electrical plug and the device when
not in use.
z The battery can be charged and discharged hundreds of times
before it eventually wears out. When the standby time and the
talk time are shorter than the normal time, replace the battery.
z Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
z Do not connect two poles of the battery with conductors, such as
metal materials, keys, or jewelries. Otherwise, the battery may be
short-circuited and may cause injuries and burns on your body.
z Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating, fire, or
explosion.
z If battery electrolyte leaks out, ensure that the electrolyte does
not touch your skin and eyes. When the electrolyte touches your
skin or splashes into your eyes, wash your eyes with clean water
immediately and consult a doctor.
z If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery, remove
the battery immediately and stop using it. Otherwise, it may lead
to battery leakage, overheating, explosion, or fire.
z If the power cable is damaged (for example, the cord is exposed
or broken), or the plug loosens, stop using the cable at once.
Otherwise, it may lead to an electric shock, a short circuit of the
charger, or a fire.
16
z Do not dispose of batteries in fire as they may explode. Batteries
may also explode if damaged.
Cleaning and Maintenance
z The device, battery, and charger are not water-resistant. Keep
them dry. Protect the device, battery, and charger from water or
vapor. Do not touch the device or the charger with a wet hand.
Otherwise, it may lead to a short circuit, a malfunction of the
device, and an electric shock to the user.
z Do not place your device, battery, and charger in places where
they can get damaged because of collision. Otherwise, it may
lead to battery leakage, device malfunction, overheating, fire, or
explosion.
z Do not place magnetic storage media such as magnetic cards and
floppy disks near the device. Radiation from the device may erase
the information stored on them.
z Do not leave your device, battery, and charger in a place with an
extreme high or low temperature. Otherwise, they may not
function properly and may lead to a fire or an explosion. When
the temperature is lower than 0°C, performance of the battery is
affected.
z Do not place sharp metal objects such as pins near the earpiece.
The earpiece may attract these objects and hurt you when you
are using the device.
z Before you clean or maintain the device, power off the device
and disconnect it from the charger.
z Do not use any chemical detergent, powder, or other chemical
agents (such as alcohol and benzene) to clean the device and the
charger. Otherwise, parts of the device may be damaged or a fire
can be caused. You can clean the device and the charger with a
piece of damp and soft antistatic cloth.
z Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
17
Emergency Call
You can use your device for emergency calls in the service area. The
connection, however, cannot be guaranteed in all conditions. You
should not rely solely on the device for essential communications.
Certification Information (SAR)
This mobile device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the mobile device is
designed not to exceed the limits for exposure to radio waves. These
guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing Radiation
Protection (ICNIRP) and include safety measures designed to ensure
safety for all users, regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of measurement for
the amount of radio frequency energy absorbed by the body when
using a device. The SAR value is determined at the highest certified
power level in laboratory conditions, but the actual SAR level of the
device when being operated can be well below the value. This is
because the device is designed to use the minimum power required
to reach the network.
The tests are performed in positions and locations (that is, at the ear
and worn on the body) as required by the FCC for each model. For
body worn operation, this phone has been tested and meets FCC RF
exposure guidelines when the handset is positioned a minimum of
15 mm from the body with an accessory that contains no metal part.
Use of other accessories may not ensure compliance with FCC RF
exposure guidelines.
The SAR limit adopted by USA and Canada is 1.6 watts/kilogram
(W/kg) averaged over one gram of tissue. The highest SAR value
reported to the FCC and IC for this device type when tested for use
at the ear is 1.39 W/kg, and when properly worn on the body is 1.0
W/kg.
18
FCC Statement
This device has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the Federal
Communications Commission (FCC) rules.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) his device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications made to this device not expressly
approved by Huawei Technologies Co., Ltd. may void the FCC
authorization to operate this device.
Version: V100R001_01 Part Number: 6015XXX
