Huawei Technologies G5520 GSM Mobile Phone User Manual s
Huawei Technologies Co.,Ltd GSM Mobile Phone s
Users Manual
![](/img.php?id=1771748&img=bg1.png)
G5520
GSM Mobile Phone
User Guide
![](/img.php?id=1771748&img=bg2.png)
Copyright © Huawei Technologies Co., Ltd. 2012. All
rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
![](/img.php?id=1771748&img=bg3.png)
i
Contents
1 Getting to Know Your Phone .............................................. 1
Your Phone ........................................................................................1
Keys and Functions .........................................................................2
Indicator Light ..................................................................................5
Screen Icons ......................................................................................5
2 Getting Started ..................................................................... 7
Installing the SIM Card and Battery ..........................................7
Removing the Battery and SIM Card ........................................7
Installing and Removing a microSD Card ...............................8
Charging the Battery......................................................................9
Phone Lock ........................................................................................9
PIN and PUK................................................................................... 10
Locking and Unlocking the Keypad ....................................... 11
Entertainment ................................................................................ 11
3 Voice Services ..................................................................... 13
Dual-Card Management ............................................................ 13
Making a Call ................................................................................. 13
Answering a Call ........................................................................... 14
4 Text Input ........................................................................... 15
Changing the Text Input Mode ............................................... 15
Entering a Word ............................................................................ 16
Entering a Digit ............................................................................. 17
![](/img.php?id=1771748&img=bg4.png)
ii
Entering a Symbol ........................................................................ 17
5 File Manager....................................................................... 17
6 Phonebook ......................................................................... 18
Creating a Contact ....................................................................... 18
Searching for a Contact ............................................................. 19
Setting a Speed Dial Number .................................................. 19
7 Games.................................................................................. 20
8 Messaging .......................................................................... 20
9 Multimedia ......................................................................... 21
Camcorder ...................................................................................... 21
Image Viewer ................................................................................. 23
Video Player ................................................................................... 24
Audio Player ................................................................................... 24
Sound Recorder ............................................................................ 25
FM Radio (optional) .................................................................... 26
10 Organizer .......................................................................... 27
Ebook Reader ................................................................................ 27
Calculator ........................................................................................ 28
Calendar .......................................................................................... 28
Tasks .................................................................................................. 28
Alarm ................................................................................................ 29
World Clock .................................................................................... 29
Flashlight ......................................................................................... 29
![](/img.php?id=1771748&img=bg5.png)
iii
11 Settings ............................................................................. 29
Phone Settings .............................................................................. 29
Security Settings ........................................................................... 30
12 Connectivity ..................................................................... 31
Bluetooth (optional) .................................................................... 31
Internet Services ........................................................................... 32
13 Profiles .............................................................................. 33
14 Chat Function ................................................................... 33
15 Warnings and Precautions .............................................. 34
![](/img.php?id=1771748&img=bg6.png)
1
Features marked with "optional" are optional. These
features may vary according to service providers. For
details, contact your service provider.
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone.
1
Earpiece
10
Right soft key
2
Screen
11
Navigation keys
![](/img.php?id=1771748&img=bg7.png)
2
3
Left soft key
12
Indicator light
4
Call/Answer key
13
Speaker
5
Number keys
14
Camera
6
* key
15
Headset jack
7
# key
16
Charger jack/Universal
serial bus (USB) port
8
Confirm key
17
Flashlight
9
End/Power key
Keys and Functions
Press…
To…
Make a call.
Answer a call.
View Dialled calls in standby mode.
Power the phone on or off (press and
hold the key for about 3 seconds).
End or reject a call.
Return to standby mode.
Turn the screen on or off in standby
mode.
(Left soft key)
Select the option displayed in the lower
left corner of the screen.
Unlock the keypad (must also press the
right soft key immediately after).
![](/img.php?id=1771748&img=bg8.png)
3
Press…
To…
(Right soft key)
Select the option displayed in the lower
right corner of the screen.
Confirm a selection.
Scroll through submenus on a menu
screen or options on an option screen.
Scroll through the widgets (press )
on the home screen.
Access the functions assigned to the
navigation keys (press ) in
standby mode.
NOTE
To assign a function to a navigation key,
select Menu > Settings > Phone
settings > Shortcuts > Dedicated key.
![](/img.php?id=1771748&img=bg9.png)
4
Press…
To…
through
Enter numbers, letters, and symbols.
Call voicemail in standby mode (press
and hold the 1 key for about 3 seconds).
Speed dial phone numbers in standby
mode (set a number key from 2 to 9 as a
speed dial key first and press and hold it
for about 3 seconds.)
Select an option labeled with the
corresponding number.
Turn the flashlight on or off in standby
mode (press and hold the 0 key for
about 3 seconds).
Enter * (press the key once), + (press the
key twice), p (press the key three times),
or w (press the key four times) in
standby mode.
Display the symbol list in editing mode.
Switch between the Meeting profile and
current profile in standby mode (press
and hold the key for about 3 seconds).
Enter #.
Switch between text input modes in
editing mode.
Lock the keypad in standby mode (press
and hold the key for about 3 seconds).
![](/img.php?id=1771748&img=bga.png)
5
Indicator Light
Color
Status
Indicates…
Red
Steady
The battery is charging and the battery
level is low.
Blinking
The battery level is low.
Orange
Steady
The battery is charging and the battery
level is between 15% and 90%.
Green
Steady
The battery is charging and nearly full or
is already full.
Blinking
You have missed calls, unread messages
(SMS, MMS, email, voice mail, and SNS),
missed alarms, or calendar reminders.
Screen Icons
Icon
Indicates…
/
Signal strength.
Battery level.
/
New text messages.
New multimedia messages.
/
Call divert enabled.
![](/img.php?id=1771748&img=bgb.png)
6
Icon
Indicates…
Headset connected.
(optional)
Bluetooth turned on.
/
Missed calls.
Alarms enabled.
Keypad locked.
Ring only enabled.
Vib. only enabled.
Vib. and ring enabled.
Vib. then ring enabled.
Silent profile activated.
microSD card inserted.
![](/img.php?id=1771748&img=bgc.png)
7
2 Getting Started
Installing the SIM Card and Battery
When installing the subscriber identification module (SIM) card,
ensure that the gold contact area faces down, and that the
beveled edge of the SIM card aligns with that of the SIM card
slot.
The phone supports two SIM cards, and you can select
Menu > Settings > Dual SIM settings > Dual SIM open
to enable dual-SIM mode. When this mode is enabled, you
can use two SIM cards at one time.
Removing the Battery and SIM Card
Before removing the battery and SIM card, ensure that your
phone is powered off.
![](/img.php?id=1771748&img=bgd.png)
8
Installing and Removing a microSD Card
Before installing or removing a microSD card, power the
phone off.
You can expand your phone's memory capacity by installing a
microSD card with a capacity of up to 8 GB.
When installing a microSD card, ensure that the gold contact
area faces down, and that the beveled edge of the microSD
card aligns with that of the microSD card slot.
![](/img.php?id=1771748&img=bge.png)
9
Charging the Battery
1. Connect the small end of the USB cable to the phone's
charger jack and the large end to the charger.
2. Connect the charger to a power outlet.
3. Wait until the battery is fully charged.
While the battery is charging, the charging icon blinks. When
the charging icon stops blinking, the battery is fully charged.
4. Unplug the charger from the power outlet and the USB cable
from the phone.
Phone Lock
The phone lock protects your phone from unauthorized use.
The preset password to unlock your phone is 1234. By default,
the phone lock is disabled. Once you enable the phone lock,
you must enter the password each time you power on the
phone.
To enable the phone lock:
![](/img.php?id=1771748&img=bgf.png)
10
1. In standby mode, select Menu > Settings > Security
settings > Phone security > Phone lock.
2. Enter the preset password.
To change the preset password:
1. In standby mode, select Menu > Settings > Security
settings > Phone security > Change password.
2. Enter the preset password.
3. Enter a new password.
The password must be a numeric string between four and
eight digits.
4. Enter the new password again to confirm it.
If you forget the password, contact your service provider.
PIN and PUK
The personal identification number (PIN) protects your SIM
card from unauthorized use.
If you incorrectly enter the PIN a specified number of times, the
PIN is blocked and the phone prompts you to enter the PIN
unblocking key (PUK). If this occurs, enter the PUK to unblock
the blocked PIN.
If you incorrectly enter the PUK a specified number of times,
the SIM card will become permanently invalid, and you must
contact your service provider for a new SIM card.
Both the PIN and the PUK are provided with the SIM card. For
details, contact your service provider.
To enable the PIN lock:
![](/img.php?id=1771748&img=bg10.png)
11
1. In standby mode, select Menu > Settings > Security
settings > SIM 1/SIM 2 security > PIN lock.
2. Enter the PIN, and press (OK) or .
Locking and Unlocking the Keypad
To lock the keypad, press and hold for 3 seconds in
standby mode. To unlock the keypad, press (Unlock),
then (OK).
If the Auto keypad lock function is enabled, the phone will
automatically lock the keypad after being idle in standby mode
for a pre-defined period.
When the keypad is locked, you can press to
answer a call, as well as (Options) or , and
then Answer. You can also press to make an
emergency call.
Entertainment
In addition to being a communication device, your phone also
serves as an entertainment center by providing you with the
following applications:
Games: play games.
Camcorder: take pictures or record videos.
Image viewer: view pictures stored in the phone memory or
microSD card.
Video player: play video files stored in the phone memory
or microSD card.
![](/img.php?id=1771748&img=bg11.png)
12
Audio player: play audio files stored in the phone memory
or microSD card.
Sound recorder: record audio clips.
FM radio: listen to radio programs over the FM frequency.
Ebook reader: read ebooks stored in the phone memory or
microSD card.
AppStore: browse through and download applications.
FaceBook: connect with family and friends.
![](/img.php?id=1771748&img=bg12.png)
13
3 Voice Services
Dual-Card Management
Your phone supports dual-card dual-standby mode, but the
two SIM cards cannot be used simultaneously. When you are
making a call or using data services with one SIM card, the
other SIM card becomes unavailable, that is, no incoming calls
can be received and the data services cannot be used.
Making a Call
1. In standby mode, enter a phone number.
To make an international call, press twice to enter
the plus sign (+). Then enter the country or region code,
area code, and phone number.
To call an extension number, enter the switchboard number,
press three times to enter p, and enter the
extension number.
2. Press or and select SIM1/SIM2 voice call to call
the number.
3. Press to end the call.
![](/img.php?id=1771748&img=bg13.png)
14
You can also make calls from the call history,
phonebook, or messages.
During a call, you can use to adjust the in-call
volume. You can also press (Options) and
select Volume, and then press .
Answering a Call
When there is an incoming call:
Press to answer the call.
Press (Options) or , and select Answer to
answer the call.
Press (Silent) to mute the ringtone, and press
(Reject) or to reject the call.
If the Silent profile is activated, press (Reject) or
to reject the call.
If the Any key answer function is enabled, you can press any
key except and to answer a call.
![](/img.php?id=1771748&img=bg14.png)
15
4 Text Input
Changing the Text Input Mode
The current text input mode indicator is displayed in the upper
left corner of the screen. Press to switch between text
input modes.
Indicator
Text Input Mode
ABC, abc, ES, and
es
Multi-tap input modes
S ABC and S abc
Predictive input modes
123
Number input mode
![](/img.php?id=1771748&img=bg15.png)
16
In any text input mode, press (Clear) to
delete the last character entered, or press and hold
(Clear) for about 3 seconds to delete all the
characters entered.
In multi-tap input mode, repeatedly press
to select and enter commonly used symbols, and
press once to enter a space and twice to
enter 0.
In predictive input mode, press to display
commonly used symbols, and press to
enter a space.
In any text input mode, press to access the
symbol list.
Entering a Word
To enter a word in multi-tap input mode, repeatedly press
the key labeled with each letter in the word until the desired
letter is displayed on the screen. Then repeat this process
until the full word is displayed.
To enter a word in predictive input mode:
1. Press each key once according to the spelling sequence of
the desired word.
The phone displays candidate words that may be spelt by
the keystroke sequence.
![](/img.php?id=1771748&img=bg16.png)
17
2. Use to scroll to the desired word, and press
to turn pages.
3. Press (Select) or to enter the word.
Entering a Digit
In number input mode, press the number key labeled with
the desired digit.
In multi-tap input mode, repeatedly press the number key
labeled with the desired digit until it is displayed. You can
also press and hold the number key labeled with the desired
digit until it is displayed.
In predictive input mode, press the number key labeled with
the desired digit once, and press to scroll to the
desired digit.
Entering a Symbol
1. Press to display the symbol list.
2. Use to scroll to the desired symbol.
3. Press (OK) or to enter the symbol.
5 File Manager
The File manager application lets you manage files and folders
stored in the phone memory or microSD card.
![](/img.php?id=1771748&img=bg17.png)
18
To manage files and folders:
1. Select Menu > File manager.
2. Use to scroll to the desired folder, and press
to open the folder, or press (Options) for the
following options:
Open: open the folder.
New folder: create a folder.
Rename: rename the folder.
Delete: delete the folder.
Sort by: sort folders by name, type, time modified, or size.
3. Use to scroll to the desired file, and press to
open the file or press (Options) for additional
operations.
The operations applicable to files may be different from
those applicable to folders.
6 Phonebook
Creating a Contact
1. In standby mode, select Menu > Phonebook > Add new
contact.
2. Press and select To SIM1, To SIM2 or To Phone to
select the location that you want to use to save the contact.
3. Enter the name and phone number of the contact.
![](/img.php?id=1771748&img=bg18.png)
19
4. Press or (Options) and select Save to save the
contact.
To choose a different storage location, select
Menu > Phonebook > Options > Phonebook
settings > Preferred storage and select All.
You can edit Email address, Caller picture, and
Caller ringtone only when you save contacts to the
phone memory.
Searching for a Contact
1. In standby mode, select Menu > Phonebook.
2. Enter the first letter of the contact name.
3. Use to scroll to the desired contact.
Setting a Speed Dial Number
1. In standby mode, select Menu > Phonebook.
2. Press (Options), and select Phonebook settings >
Speed dial > Status > On.
3. Select Set numbers, and set one of the 2–9 keys as a speed
dial key.
4. Enter the number that you want to assign to the speed dial
key.
In standby mode, you can press and hold the speed dial key
to speed-dial the number.
![](/img.php?id=1771748&img=bg19.png)
20
7 Games
This phone comes with three built-in games. Select Menu >
Games to select a game.
8 Messaging
To send a message:
1. In standby mode, select Menu > Messaging > Write
message.
2. Write the message.
You can also add pictures, audio files, video files, or other
attachments to the message and send it as a multimedia
message.
3. Enter a recipient's phone number or press (Options),
and select Add recipient to add a recipient from
Phonebook.
Repeat this step to add more recipients.
4. Press (Options), and select Send > From
SIM1/From SIM2 to send the message.
You can also press (Options) to select Input
method, Smart input method, New Cstar word, and
others.
![](/img.php?id=1771748&img=bg1a.png)
21
Contact your service provider to determine the
availability of the Multimedia Messaging Service
(MMS) and how to subscribe to the service.
Open multimedia messages with caution. Objects in
multimedia messages may contain viruses and
malicious software that can damage your phone.
9 Multimedia
Camcorder
Camera:
1. In standby mode, select Menu > Multimedia > Camcorder.
2. Press to view the photo album or configure the
camera settings.
3. Frame the picture you want to take on the viewfinder screen,
and press to take the picture.
4. After taking the picture:
Press , and select Forward to send the picture or
Delete to delete the picture.
Press to exit the camera.
![](/img.php?id=1771748&img=bg1b.png)
22
All the pictures are stored in Photos on your phone or
microSD card depending on which storage you have set
as the preferred storage for pictures. You can select
Menu > File manager > Phone/Memory card >
Photos to access these pictures and perform operations,
such as Rename and Delete, on them.
Video Recorder
1. In standby mode, select Menu > Multimedia > Camcorder.
2. Press to switch to video recorder or press and
select Switch to > Video recorder.
Press to switch to camera or press and select
Switch to > Camera.
3. Press to view the video player and configure video
settings.
4. Frame the scene you want to take on the viewfinder screen,
and press to begin recording the video.
5. When recording the video:
Press or to pause or continue.
Press to stop recording.
After recording the video, press to play or delete
it. You can also send it via a multimedia message (video
file cannot exceed 300 KB) or Bluetooth.
![](/img.php?id=1771748&img=bg1c.png)
23
Image Viewer
The Image viewer application lets you manage your pictures.
To manage pictures:
1. Select Menu > Multimedia > Image viewer.
2. Use to scroll to the desired picture, and press to
view the picture or press (Options) for the following
options:
View: view the picture.
Image information: display detailed information about the
picture.
Browse style: browse the picture in list or matrix style.
Send: send the picture to other devices via multimedia
message or Bluetooth.
Use as: use the picture as wallpaper, screen saver, or contact
picture.
Rename: rename the picture.
Delete: delete the picture.
Sort by: sort pictures by name, type, time modified, or size.
Mark several: select and mark one or more pictures to
delete, copy, move or send.
Delete all files: delete all pictures.
Storage: view pictures stored in the phone memory or
microSD card.
![](/img.php?id=1771748&img=bg1d.png)
24
Video Player
1. In standby mode, select Menu > Multimedia > Video
player.
2. Use to scroll to a video file.
3. Select Options > Play.
While playing the video file:
Use to adjust the volume.
Use to rewind or fast-forward.
Press to pause or continue.
Press to switch between the full and standard
screens.
4. Press (Stop) to stop playing the video file.
All the video files are stored in Videos on your phone or
microSD card depending on which storage you have set
as the preferred storage for video files. You can select
Menu > File manager > Phone/Memory card >
Videos to access these video files and perform
operations, such as Rename and Delete on them.
Audio Player
1. In standby mode, select Menu > Multimedia > Audio
player.
2. Press (List), and select a music file.
![](/img.php?id=1771748&img=bg1e.png)
25
3. Select Options > Play.
While playing the music file:
Use to adjust the volume.
Press to skip to the previous or next music file, or
press and hold to rewind or fast-forward through the
music file.
Press to pause or continue.
All the music files are stored in My Music on your phone
or microSD card depending on which storage you have
set as the preferred storage for music files. You can
select Menu > File manager > Phone/Memory card >
My Music to access these music files and perform
operations, such as Rename and Delete on them.
Sound Recorder
The Sound recorder application lets you record audio.
To record audio:
1. Select Menu > Multimedia > Sound recorder.
2. Press (Options) and select New record, or press
to start recording.
While recording, you can press or
(Pause/Continue) to pause or continue.
3. Press (Stop) to stop recording and save the
recorded audio.
![](/img.php?id=1771748&img=bg1f.png)
26
To play the recording:
1. Press to play the audio.
When playing the audio, press or to adjust
the volume.
2. Press (Options) for additional operations.
FM Radio (optional)
The headset cable also functions as the FM radio antenna when
the radio is turned on. To ensure good radio reception, do not
disconnect the headset from the phone or severely bend the
headset cable.
To listen to the radio:
1. Connect a compatible headset to the phone.
2. In standby mode, select Menu > Multimedia > FM radio.
When the FM radio is turned on, the phone plays the
program on the current channel.
3. On the FM radio screen:
Press (Options), and select Auto search to
automatically search for and save channels.
Use to adjust the volume.
Press (Options) and select Record to record the
current program.
When recording, press or (Pause/Continue) to
pause or continue recording. Press (Stop) to stop
recording, edit the filename, and choose whether to save it.
![](/img.php?id=1771748&img=bg20.png)
27
Press (Options) and select Settings to configure
settings such as Background play, Audio quality and
Record storage.
4. Press to pause or stop FM radio, and press
(Back) to exit the application.
10 Organizer
Ebook Reader
1. In standby mode, select Menu > Organizer > Ebook reader
to display the bookshelf.
The phone automatically adds the ebooks stored in the
default storage location (phone or microSD card) to the
bookshelf.
2. Select an ebook.
3. Press to open the ebook.
While reading the ebook, press (Options) for
options such as Full screen on/off, Find, Jump to, Add
bookmark, Go to bookmark, Delete bookmark, Auto
scroll on/off and Close.
4. Press (Back) to close the ebook.
When reading an ebook, use to turn pages,
and use to change lines.
![](/img.php?id=1771748&img=bg21.png)
28
Calculator
The Calculator application lets you perform a variety of
mathematical operations. The accuracy of certain decimals is
limited, and the calculator can only be used for simple
calculations.
Calendar
The Calendar application lets you view dates, edit schedules,
and set alerts. If you create a memo in the schedule for a
particular date, that date will be highlighted. To view all memos
for a day, press to select the date. Press (Options)
for the following options:
View: check memos for that specified day.
View all: check all memos.
Add event: enter Type, Start, End, Subject, Alarm, Repeat,
Location, and Details. Press or (Select/Edit) to
edit, or press (Save) or to save and exit.
Delete event: clear memos in All, Overdue, or Specific
period.
Jump to date: enter and jump to a date.
Go to today: go to today.
Go to weekly view: display a weekly view of the calendar.
Tasks
The Tasks application lets you record important events.
![](/img.php?id=1771748&img=bg22.png)
29
Alarm
The Alarm application lets you set alarms to ring at specified
times.
World Clock
The World clock application lets you look up the local times of
cities around the world with respect to their time zones. Use
to view different time zones. Press or (Options)
to select Daylight saving time for foreign city.
Flashlight
The Flashlight application lets you shine a bright light.
In standby mode, select Menu > Organizer > Flashlight,
press or (OK) to turn the flashlight on or off.
In standby mode, press and hold to turn the
flashlight on or off.
11 Settings
Phone Settings
Select Menu > Settings > Phone settings.
Configure the following settings:
Time and date: set the home city, time, date, format, and
time zone.
![](/img.php?id=1771748&img=bg23.png)
30
Schedule power on/off: set the time at which the phone
will power on or off automatically.
Language: set the display language.
Pref. input method: set the preferred input method.
Display: set the wallpaper, screen saver, time, date, and LCD
backlight.
Themes: set the phone's theme.
Shortcuts: set the shortcuts style, menu, and dedicated key.
Auto update time: set whether to turn auto update time on.
Security Settings
Changing PIN
To change the PIN, enable PIN lock first, and do the following:
1. Select Menu > Settings > Security settings > SIM 1/SIM 2
security > Change PIN.
2. Enter the PIN, and press or (OK).
3. Enter a new PIN, and press or (OK).
4. Re-enter the new PIN to confirm.
Changing PIN2
PIN2 is the personal identification number used for special
functions provided by the network, such as billing.
SIM1 PIN2 and SIM2 PIN2 are configured separately.
To change PIN2, do the following:
1. Select Menu > Settings > Security settings > SIM 1/SIM 2
security > Change PIN2.
![](/img.php?id=1771748&img=bg24.png)
31
2. Enter PIN2, and press or (OK).
3. Enter a new PIN2, and press or (OK).
4. Re-enter the new PIN2 to confirm.
12 Connectivity
Bluetooth (optional)
Your phone supports Bluetooth. You can synchronize files
between your phone and a computer, transfer data between
your phone and other Bluetooth devices, and talk on the phone
using a Bluetooth headset.
1. In standby mode, selecting Menu > Settings >
Connectivity > Bluetooth > Power > On to turn on
Bluetooth.
2. Select My device > Search new device to search for
available Bluetooth devices.
3. Scroll to the desired Bluetooth device, and press
(Pair) or .
When you pair your phone with the device for the first time,
a password is required.
4. Use the Bluetooth device to talk on the phone or transfer
data with your phone.
![](/img.php?id=1771748&img=bg25.png)
32
Internet Services
You can use your phone to access Wireless Application Protocol
(WAP) sites and use WAP-based services. To browse WAP pages,
you must subscribe to the data service from your service
provider and configure your phone's relevant settings.
Setting Up Your Data Account
Before accessing WAP sites on your phone, set up your data
account as follows:
1. In standby mode, select Menu > Services > Internet
service > Settings > Data account.
2. Select your service provider.
Your account settings are provided by your service provider.
3. Press (OK) or to save the settings.
Accessing a WAP Site
1. In standby mode, select Menu > Services > Internet
service > Search or Input URL.
2. Enter the Uniform Resource Locator (URL) of the desired WAP
site.
3. Press (Options), and select Go to to access the WAP
site.
You can create and edit bookmarks so that you can
quickly access your favorite WAP sites.
![](/img.php?id=1771748&img=bg26.png)
33
13 Profiles
Your phone provides you with various profiles: General, Silent,
Meeting, Outdoor, and My style. You can customize the
ringtone and other settings for each profile depending on the
environment and need. You can activate or deactivate a profile.
To customize a profile:
1. Select Menu > Profiles.
2. Use to scroll to the desired profile, and press
to select the profile or press (Options) for the
following options (except Silent and Meeting):
Activate: activate the profile.
Customize: set the alert type, ring type, SIM1/2 incoming
call, ringtone volume, SIM1/2 message, message volume,
keypad tone, keytone volume, power on/off, and system
alert.
Reset: Reset to default settings.
In the My style profile, you may Rename the profile
name.
14 Chat Function
The FaceBook application is a social networking service (SNS)
that lets you connect with family and friends.
![](/img.php?id=1771748&img=bg27.png)
34
To use Facebook, select Menu > FaceBook, and enter your
email and password. You will then be connected to Facebook
and redirected to its homepage.
Check GPRS settings before using this application.
Before saving the chat history, ensure that a
microSD card has been inserted to the phone.
From the Facebook registration page, press
to delete an entered phone number.
15 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or
interference with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device when using the
device is prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
![](/img.php?id=1771748&img=bg28.png)
35
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas, and
chemical plants. In addition, adhere to restrictions in areas
where blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats, chemical
transfer or storage facilities, and areas where the air contains
chemicals or particles such as grain, dust, or metal powders.
Ask the manufacturers of vehicles using liquefied petroleum
gas (such as propane or butane) whether this device can be
safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
![](/img.php?id=1771748&img=bg29.png)
36
Concentrate on driving. Your first responsibility is to drive
safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
![](/img.php?id=1771748&img=bg2a.png)
37
On a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device powered by a
battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
![](/img.php?id=1771748&img=bg2b.png)
38
the device, result in the non-operation of the device, and cause
danger.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and the talk time are shorter than the normal time, replace
the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
Do not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may be short-circuited and may cause injuries and
burns on your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your eyes
with clean water immediately and consult a doctor.
If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
![](/img.php?id=1771748&img=bg2c.png)
39
it may lead to battery leakage, overheating, explosion, or
fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to an electric shock, a
short circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Danger of explosion if battery is incorrectly replaced. Recycle
or dispose of used batteries according to the local
regulations or reference instruction supplied with your
device.
Notice: For pluggable equipment, the socket-outlet shall be
installed near the equipment and shall be easily accessible.
Cleaning and Maintenance
The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.
Do not place your device, battery, and charger in places
where they can get damaged because of collision. Otherwise,
it may lead to battery leakage, device malfunction,
overheating, fire, or explosion.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
![](/img.php?id=1771748&img=bg2d.png)
40
Do not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
Before you clean or maintain the device, power off the
device and disconnect it from the charger.
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
be damaged or a fire can be caused. You can clean the
device and the charger with a piece of damp and soft
antistatic cloth.
Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
![](/img.php?id=1771748&img=bg2e.png)
41
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for the amount of radio frequency energy absorbed by the
body when using a device. The SAR value is determined at the
highest certified power level in laboratory conditions, but the
actual SAR level of the device when being operated can be well
below the value. This is because the device is designed to use
the minimum power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the FCC and IC for this device
type when tested for use at the ear is 0.878 W/kg, and when
properly worn on the body is 1.290 W/kg.
The SAR limit also adopted by Europe is 2.0 W/kg averaged
over 10 grams of tissue. The highest SAR value for this device
type when tested at the ear is 0.795 W/kg, and when properly
worn on the body is 1.450 W/kg.
![](/img.php?id=1771748&img=bg2f.png)
42
Disposal and Recycling Information
This symbol on the device (and any included batteries)
indicates that they should not be disposed of as normal
household garbage. Do not dispose of your device or batteries
as unsorted municipal waste. The device (and any batteries)
should be handed over to a certified collection point for
recycling or proper disposal at the end of their life.
For more detailed information about the recycling of the device
or batteries, contact your local city office, the household waste
disposal service, or the retail store where you purchased this
device.
The disposal of this device is subject to the Waste from
Electrical and Electronic Equipment (WEEE) directive of the
European Union. The reason for separating WEEE and batteries
from other waste is to minimize the potential environmental
impacts on human health of any hazardous substances that
may be present.
Reduction of Hazardous Substances
This device is compliant with the EU Registration, Evaluation,
Authorisation and Restriction of Chemicals (REACH) Regulation
(Regulation No 1907/2006/EC of the European Parliament and
of the Council) and the EU Restriction of Hazardous Substances
(RoHS) Directive (Directive 2002/95/EC of the European
![](/img.php?id=1771748&img=bg30.png)
43
Parliament and of the Council). For more information about the
REACH compliance of the device, visit the Web site
www.huaweidevice.com/certification. You are recommended to
visit the Web site regularly for up-to-date information.
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
![](/img.php?id=1771748&img=bg31.png)
44
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void
the FCC authorization to operate this device.
EU Regulatory Conformance
Hereby, Huawei Technologies Co., Ltd. declares that this device
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the web site
www.huaweidevice.com/certification.
Notice: Observe the national local regulations in the location
where the device is to be used. This device may be restricted for
use in some or all member states of the European Union (EU).
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by Huawei Technologies Co., Ltd. is under license. Other
trademarks and trade names are those of their respective
owners.
