Huawei Technologies G5726 GSM Mobile Phone User Manual G5726 User Guide 01 English
Huawei Technologies Co.,Ltd GSM Mobile Phone G5726 User Guide 01 English
User Guide-20110330
Copyright © Huawei Technologies Co., Ltd. 2011.
All rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
i
Contents
1 Getting to Know Your Phone ................................................4
Your Phone ........................................................................................... 4
Keys and Functions ........................................................................... 5
Screen Icons......................................................................................... 7
2 Getting Started .......................................................................8
Installing SIM Cards and the Battery......................................... 8
Removing the Battery and the SIM Card................................. 8
Installing a microSD Card............................................................... 9
Charging the Battery........................................................................ 9
Working with the Main Menu ....................................................10
Reorganizing the Main Menu.....................................................10
Phone Lock .........................................................................................11
Mass Storage .....................................................................................12
PIN and PUK ......................................................................................13
Locking the Keypad ........................................................................14
Entertainment....................................................................................14
3 Voice Services ...................................................................... 15
Making a Call.....................................................................................15
Answering a Call...............................................................................15
4 Text Input ............................................................................. 16
Changing the Text Input Mode..................................................16
ii
Entering a Letter in Multi-Tap Input Mode...........................17
Entering a Word in Predictive Input Mode...........................17
Entering a Digit in Number Input Mode ...............................17
Entering Symbols .............................................................................18
5 Messaging ............................................................................ 18
Writing and Sending a Text Message .....................................18
Writing and Sending a Multimedia Message......................19
6 Phonebook ........................................................................... 20
Creating a Contact ..........................................................................20
Searching for a Contact ................................................................21
Setting the Preferred Storage.....................................................21
Copying Contacts ............................................................................21
7 Video Recorder .................................................................... 22
8 Video Player ......................................................................... 22
9 Sound Recorder ................................................................... 23
10 Camera................................................................................ 24
11 Audio Player....................................................................... 25
12 FM Radio ............................................................................ 25
13 Java Applications .............................................................. 27
14 Services............................................................................... 29
Network Settings .............................................................................29
Connecting to a Network.............................................................30
15 Bluetooth............................................................................ 31
Synchronizing Data.........................................................................31
iii
Connecting a Bluetooth Headset to Your .............................31
Phone....................................................................................................31
Transferring Data .............................................................................32
16 STK ...................................................................................... 33
17 Warnings and Precautions ............................................... 34
4
1 Getting to Know Your Phone
Your Phone
1 Earpiece 7 # key
2 Screen 8 End/Power key
3 Left soft key 9 Right soft key
4 Call/Answer key 10 OK/Confirm key
5 Number key 11 Navigation keys
6 * key
5
The figure above shows the appearance of your phone
and is provided only for your reference.
Keys and Functions
Press… To…
Make a call from the SIM card in standby mode.
Answer a call.
View call logs of SIM card in standby mode.
Power on or power off the phone (by pressing
and holding the key for about 3s).
End or reject a call.
Return to the standby mode.
Access the main menu in standby mode.
Select a highlighted item.
Access Call history in standby mode.
Return to the previous menu.
Access Service in standby mode.
Confirm a selection.
6
Press… To…
Scroll to the desired icon in main menu (by
pressing , , , and ).
Access the desired shortcut menu by pressing
, , , or in standby mode.
Access the next menu on a submenu screen (by
pressing ).
Return to the previous menu on a submenu
screen (by pressing ).
–
Enter numbers, letters, and symbols.
Call the voicemail in standby mode (by pressing
and holding the 1 key for about 3 seconds).
Select a submenu (by pressing the
corresponding number key).
Enter * (by pressing the key once), + (by pressing
the key twice), P (by pressing the key three
times), and W (by pressing the key four times) in
standby mode.
Display the symbol list in any text entry mode.
Enter #.
Enable or disable the Silent in standby mode (by
pressing and holding the key for about 3s).
Switch between input methods in text editing
mode.
7
Screen Icons
Icon Indicates…
Signal strength.
New text messages.
New multimedia messages.
Call forwarding enabled.
Missed calls.
New voicemail messages.
Enabled alarms.
Keypad locked.
Battery power level.
General or Indoor activated.
Meeting profile activated.
Outdoor profile activated.
Headset connected to the phone.
8
2 Getting Started
Installing SIM Cards and the Battery
You can install a Subscriber Identification Module (SIM) card in
the phone. When inserting a SIM card, ensure that the golden
contact area on the SIM card is facing downward and that the
beveled edge of the SIM card is properly aligned with that of
the SIM card slot.
Removing the Battery and the SIM Card
Before removing the battery and the SIM card, ensure that your
phone is powered off.
9
Installing a microSD Card
Before installing or removing a microSD card, power off
the phone. Once the phone is powered on, it will indicate
whether the microSD card has been installed properly.
You can install a microSD card to expand the memory capacity
of your phone. When inserting the microSD card, ensure that
the golden contact area on the microSD card is facing
downward.
Charging the Battery
To charge the battery, do the following:
1. Connect the smaller end of the USB cable to the charger jack
of the phone and the larger end to the charger.
2. Connect the charger to a power socket.
10
3. Wait until the battery is fully charged.
During the charging, the charging icon is displayed in
animation. When the charging icon becomes static, it
indicates that the battery is fully charged.
4. Disconnect the charger from the power socket and then
from the phone.
Working with the Main Menu
1. In standby mode, press (Menu) to access the main
menu.
2. Press to scroll to the desired submenu, and then press
to access the submenu.
3. Press or to scroll to an option, and then press
(OK) or to access the option.
4. Press (Back) to return to the previous menu.
To return to the standby mode, press .
Reorganizing the Main Menu
You can reorganize the main menu. For example, you can hide
or move a submenu.
11
1. In standby mode, press (Menu) to access the main
menu.
2. Select a submenu, and then press (Options) for the
following options:
Go to: to access the selected submenu.
Hide: to remove the selected submenu from the main menu
screen.
To show the submenu again, select Menu > Settings, press
(Options), select Go to to access the submenu, then
select Phone settings > Mainmenu settings, select the
desired submenu, and then press (Show).
Move: to change the location of the selected submenu on
the main menu screen.
To move the submenu, scroll to it, select Options > Move,
scroll to the desired location, and then press (Ok).
Back: to return to the main menu.
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. Once the phone lock is
enabled, you are required to enter the phone code each time
you power on the phone.
To enable the phone lock, do the following:
1. Select Menu > Settings > Security settings > Phone lock.
2. Enter the phone code, and then press (Ok).
12
You can change the default phone code (1234) to any numeric
string of four to eight digits.
To change the phone code, do the following:
1. Select Menu > Settings > Security settings > Change
password > Phone password.
2. Enter the old phone code, and then press (Ok).
3. Enter the new phone code, and then press (Ok).
4. Enter the new phone code again to confirm it.
If you forget the phone code, contact the service provider.
Mass Storage
When the phone is connected to a personal computer (PC)
through a USB cable, options such as Mass storage are
displayed on the phone screen.
When you select Mass storage, you can manage the files
stored in the phone memory and on the microSD card.
The microSD card and the phone memory are displayed as
removable disks on the PC. You can perform the following
operations:
Double-click a disk to open it.
Copy, paste, or delete files on a disk.
Disconnect the phone from the PC.
13
Ensure that you connect and disconnect the USB cable
properly.
Do not run the formatting command on the PC to
format the phone memory. Otherwise, the phone
memory may get permanently damaged.
You can transfer data and charge the battery by
connecting the phone to the PC through the USB
cable.
PIN and PUK
The personal identification number (PIN) protects your SIM
card from unauthorized use. The PIN unblocking key (PUK)
unlocks the blocked PIN. Both the PIN and the PUK are
provided with the SIM card. For details, contact your service
provider.
To enable the SIM lock function, do the following:
1. Select Menu > Settings > Security settings > SIM lock.
2. Enter the PIN, and then press (Ok).
If you enter wrong PINs a specified number of times
consecutively, the phone prompts you to enter the PUK.
If you enter wrong PUKs a specified number of times
consecutively, the SIM card becomes permanently invalid. In
that case, contact your service provider for a new SIM card.
14
Locking the Keypad
If the Auto keypad lock function is enabled and if the phone is
in standby mode for a preset period, the phone locks the
keypad automatically.
In standby mode, press (Unlock) and then (OK) to
unlock the keypad.
To enable the Auto keypad lock function, select Menu >
Settings > Security settings > Auto keypad lock, scroll to a
preset duration, and then press (OK) to select the
duration.
When the keypad is locked, you can press to
answer a call or make an emergency call.
Entertainment
Camera: to take pictures.
Image viewer: to view the pictures stored in the phone
memory or on the microSD card.
Audio player: to play the audio clips stored in the phone
memory or on the microSD card.
Video player: to play the video clips stored in the phone
memory or on the microSD card.
Sound recorder: to record audio clips.
Video recorder: to record video clips.
FM radio: to listen to the radio.
15
Games: to play games.
Java: to run Java applications.
3 Voice Services
Making a Call
1. In standby mode, enter the phone number.
To make an international call, press to enter the plus
sign (+), and then enter the country or region code, area
code, and phone number in sequence.
To call an extension, enter the phone number, press
three times to enter P, and then enter the extension number.
2. Press to dial the number.
3. Press to end the call.
You can also make calls through call logs, contacts, and
messages.
During a call, you can press or to adjust
the volume.
Answering a Call
When there is an incoming call, do the following:
Press to answer the call.
16
Press (Options), and then select Answer to answer
the call.
Press to reject the call.
Press (Silent) to mute the speaker, and then press
(Reject) to reject the call.
Press (Silent) to mute the speaker, press
(Options), and then select Answer to answer the call.
If the Any key answer function is enabled, you can press any
key except and to answer a call.
4 Text Input
Changing the Text Input Mode
The indicator of the current text input mode is displayed in the
upper left corner of the screen. You can press to change
the text input mode.
Indicator Text Input Mode
abc, ABC Multi-tap input mode
eZiabc, eZiABC Predictive input mode
123 Number input mode
17
You can press (Clear) once to delete the last
entered character. You can also press and hold
(Clear) for 3s to clear all the entered characters at a
time.
In any text input mode, press to enter a space.
In any text input mode, press to display the
symbol list.
Entering a Letter in Multi-Tap Input Mode
In multi-tap input mode, press the key labeled with the desired
letter.
Entering a Word in Predictive Input Mode
In predictive input mode, do the following to enter a word:
1. Press each key once according to the spelling sequence of
the desired word.
The phone displays the candidate words.
2. Press or to scroll left or right, and press or
to turn pages.
3. Press to enter desired word.
Entering a Digit in Number Input Mode
In number input mode, press the number key labeled with the
desired number.
18
Entering Symbols
1. Press to display the symbol list.
2. Press or to scroll left or right, and press or
to scroll up or down.
3. Press to enter the symbol.
5 Messaging
Writing and Sending a Text Message
1. Select Menu > Messaging > Write message.
2. Write the message.
3. Press (Options), and then select Send to.
4. Select Enter recipient, and then enter the phone number of
a recipient; or select Add from Phonebook, and then add a
recipient from the phonebook.
To add multiple recipients, repeat this step.
5. Scroll to the desired recipient, and then press to send
the message or press (Options) for the following
options:
Send: to send the message to the recipient.
Save: to save the message to Drafts and exit the message
editing screen.
19
Writing and Sending a Multimedia
Message
1. Select Menu > Messaging > Write message.
2. Write the message.
3. Press (Options) for the following options:
Switch to MMS: to change from a text message to a
multimedia message.
If you select Add picture, Add sound, Add video, or Add
subject,the message automatically changes from a text
message to a multimedia message.
Add picture: to add a picture to the message.
Add sound: to add an audio clip to the message.
Add video: to add a video clip to the message.
Add subject: to add a subject to the message.
You can also add slides to the message, preview the
message, and set the playing interval between two slides.
4. On the message-editing screen, press ; or press
(Options), and then select Send to.
5. Select Enter recipient, and then enter the phone number of
a recipient; or select Add from Phonebook, and then add a
recipient from the phonebook.
To add multiple recipients, repeat this step.
6. Scroll to the desired recipient, and then press to send
the message or press (Options) for the following
options:
20
Send: to send the message to the recipient.
Change to Cc: to copy the message to the recipient.
Change to Bcc: to blind copy the message to the recipient.
Save to Drafts: to save the message to Drafts and exit the
message editing screen.
You can contact your service provider for the availability
of the Multimedia Messaging Service (MMS) and the
method for subscribing to the service.
Your phone supports a multimedia message of a
maximum size of 300 KB.
Open multimedia messages with caution. Objects in
multimedia messages may contain viruses (such as
malicious software) that can damage your phone.
6 Phonebook
Creating a Contact
1. Select Menu > Phonebook > Add new contact.
2. Select To SIM or To phone for saving the contact.
3. Enter the contact information.
4. Press (Options), and then select Done.
5. When the phone asks you whether to save the information,
press (Yes).
21
Searching for a Contact
1. Select Menu > Phonebook.
2. Enter the first letter of the contact name.
3. Press or to scroll to the desired contact.
Setting the Preferred Storage
You can set the storage where you want to save new contacts.
1. Select Menu > Phonebook.
2. Press (Options), and then select Phonebook
settings > Preferred storage.
3. Scroll to SIM, Phone, or Both as desired.
4. Press (OK) to select the preferred storage.
Copying Contacts
You can copy contacts to the phone, the SIM card, or a file.
Copying One Contact
1. Select Menu > Phonebook.
2. Press or to scroll to the desired contact.
3. Press (Options), and then select Copy.
4. Select To ph on e, To SIM or To file to copy the contact to
the desired location.
Copying Multiple Contacts
1. Select Menu > Phonebook.
22
2. Press (Options), and then select Phonebook
settings > Copy contacts.
3. Press or to scroll to the desired option, such as
SIM to phone or Phone to SIM.
4. Press (OK) to copy contacts to the desired location.
7 Video Recorder
To record a video clip, do the following:
1. Select Menu > Multimedia > Video recorder.
2. In video recording mode, do the following:
Press to configure the relevant settings.
Press to start recording or pause.
Press or to adjust brightness.
Press to zoom in or to zoom out.
Press to stop recording and save the video clip as
prompted.
8 Video Player
The video player plays downloaded or recorded video clips that
are stored in the Videos folder in File manager of Phone or
Memory card.
23
To play a video clip, do the following:
1. Select Menu > Multimedia > Video player.
2. Press and to select a video clip.
3. Press (Options), and then select Play to play the
video clip.
When the video clip is being played, you can do the
following:
Press or to adjust the volume.
Press to rewind the video clip or to fast-forward
the video clip.
Press to pause or continue.
4. Press to stop playing the video clip.
Only files in .mp4 and .3gp formats are supported. Files
in other formats may fail to be played.
9 Sound Recorder
The sound recorder functions as a digital recorder.
To record an audio clip, do the following:
1. Select Menu > Multimedia > Sound recorder.
2. Press (Options), and then select New record to
record an audio clip.
24
During the recording, you can press (Pause or Cont.)
or to pause or continue.
3. Press (Stop) to stop recording the audio clip, and
then save the recorded clip as prompted.
10 Camera
The phone is equipped with a built-in 1.3-megapixel
complementary metal-oxide-semiconductor (CMOS) camera.
1. Select Menu > Multimedia > Camera.
2. On the picture taking screen, do the following:
Press to view pictures or configure relevant settings.
Press or to adjust brightness.
Press to zoom in or to zoom out.
Press the 1, 2, 4, 6, and 7 keys to configure the
corresponding settings quickly.
Press to switch to the simplified mode.
3. Focus the camera on the scene, and then press to take a
picture.
4. Press (Back) to save the picture; or press
(Options), and then select Delete to delete the picture.
25
11 Audio Player
The audio player plays audio clips that are stored in My music
in the phone memory or on the microSD card. It is
recommended that you listen to audio clips by using the
headset so that you can enjoy enhanced quality sound.
1. Select Menu > Multimedia > Audio player.
2. Press to start playing audio clips.
When audio clips are being played, you can do the
following:
Press and to adjust the volume.
Press and to switch between audio clips.
Press the button on the headset cable to switch between
audio clips.
Press (List) to view the audio clip list, and then press
(Options) to configure the relevant settings.
3. Press to pause or continue.
4. Press to stop playing audio clips.
12 FM Radio
The headset cable also functions as an antenna. To ensure
reception of radio programs, do not disconnect the headset
from the phone or bend the headset cable with strength.
26
1. Connect the headset to the phone.
2. Select Menu > Multimedia > FM radio.
When listening to the radio, you can do the following:
Press to pause or continue.
Press or to adjust the volume.
Press or to adjust the frequency at a precision
of 0.1 MHz.
Press and hold or , and then release the key to
switch to an adjacent channel.
Press to auto search and save channels.
Press a number key to switch to the corresponding channel
based on Channel list.
Press the button on the headset cable to switch between
channels.
Press (Options), and then select Record to record a
radio program.
Press (Options) to view or edit the channel list,
manually set a frequency, automatically search for and save
channels, and configure the relevant settings.
27
13 Java Applications
You can install third-party Java applications to expand the
capabilities of your phone.
Not all Java applications are compatible with your
phone. If you have trouble in installing or running a
Java application, press to return to the standby
mode, and then remove the application from your
phone.
Certain Java applications require network connections.
Therefore, ensure that the General Packet Radio
Service (GPRS) connection is properly set up.
Installing a Java Application
To install a Java application on your phone, do the following:
1. Select a Java installation file in .jar or .jad format from Phone
or Memory card, press (Options), and then select
Install to start the installation.
2. Press (Yes ) to confirm the certification information.
3. Select Phone or Memory card to install the Java application.
When the installation is successful, the message “Installed” is
displayed.
Running a Java Application
To run a Java application, do the following:
28
1. Select Menu > Java.
2. Select a Java application, and then press (Options).
3. Select Launch to run the Java application.
Deleting or Removing a Java Application
To delete or remove a Java application installed on your phone,
do the following:
1. Select Menu > Java.
2. Select a Java application, and then press (Options).
3. Select Delete to delete the application.
4. Press (Yes ) to confirm the certification information.
When the Java application is deleted, the message “Deleted”
is displayed.
29
14 Services
You can access Wireless Application Protocol (WAP) sites and
use WAP-based services on your phone. To access WAP sites on
your phone, you need to subscribe to the corresponding
service from your service provider and set the relevant
parameters on your phone.
For details about the service and the charges, contact your
service provider.
Network Settings
To access WAP sites on your phone, you need to set your data
account and WAP parameters first.
Setting the Connection Profile
1. Select Menu > Settings > Connectivity > Data account.
2. Press (Options), and then select Add.
3. Set the parameters based on the information provided by
your service provider.
4. Press (OK) to save the settings.
If the data account provided by your service provider
already exists, you do not need to create a data account.
30
Setting the WAP profile
1. Select Menu > Services > Internet service > Settings >
Profiles.
2. Select Add new.
3. Set the Internet parameters based on the information
provided by your service provider.
4. Press (Done) to save the settings.
5. Select your service provider, press (Options), and
then select Activate.
If the profile supported by your service provider already
exists, select the profile, press (Options), and then
select Activate.
Connecting to a Network
1. Press Menu > Services > Internet service > Input address.
2. Enter a Uniform Resource Locator (URL) address.
3. Press (Options), and then select Done to access the
address.
31
15 Bluetooth
By using the Bluetooth function, you can synchronize data
between a PC and your phone, exchange data with other
Bluetooth devices, and connect a Bluetooth headset to your
phone.
You can turn on the Bluetooth function by configuring
Bluetooth settings.
Synchronizing Data
Before synchronizing data between a PC and your phone,
ensure that the PC supports the Bluetooth function and that the
operating system of the PC is Windows 2000 or Windows XP.
1. Select Menu > Bluetooth > Power > On to turn on the
Bluetooth function.
2. Start the Bluetooth driver on the PC.
3. Pair the PC with the phone.
4. Synchronize data between the PC and the phone.
Connecting a Bluetooth Headset to Your
Phone
1. Select Menu > Bluetooth > Power > On to turn on the
Bluetooth function.
32
2. Select Search audio device to search for available Bluetooth
headsets.
3. Scroll to the desired Bluetooth headset, and then press
(Pair).
4. Enter the password for pairing the Bluetooth headset with
your phone.
When the Bluetooth headset is connected to your phone, the
headset icon is displayed on the standby screen, indicating that
you can use the headset.
No Bluetooth headset is included in the product
package. If you want to use a Bluetooth headset, you
need to purchase it individually.
Transferring Data
1. Select Menu > Bluetooth > Power > On to turn on the
Bluetooth function.
2. Select My device > Search new device to search for
available Bluetooth devices.
3. Scroll to the desired Bluetooth device, and then press
(Pair).
When the Bluetooth device is connected to your phone for
the first time, you need to enter the password for pairing the
device with your phone.
4. Exchange data between your phone and the Bluetooth
device.
33
16 STK
The SIM Tool Kit (STK) function is a value-added service
provided by your service provider, and you can use it to send
text messages, view news, and use other applications. For more
information, contact your network operator.
34
17 Warnings and Precautions
This chapter contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using it is prohibited. Do not use the
device if using it causes danger or interference with other
electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device if using it is
prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between an electronic
device and a pacemaker to prevent potential interference
with the pacemaker. If you are using a pacemaker, use the
device on the opposite side of the pacemaker and do not
carry the device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
35
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in injuries or even deaths. Do
not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas, and
chemical plants. In addition, adhere to restrictions in areas
where blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats, chemical
transfer or storage facilities, and areas where the air contains
chemicals or particles such as grain, dust, or metal powders.
Ask the manufacturers of vehicles using liquefied petroleum
gas (such as propane or butane) whether this device can be
safely used in their vicinity.
Traffic Safety and Regulations
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive
safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle on
the road side before using your device.
36
Radio frequency (RF) signals may affect electronic systems of
motor vehicles. For more information, consult the vehicle
manufacturer.
In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
During thunderstorms, do not use your device when it is
being charged, to prevent any danger caused by lightning.
During a call, do not touch the antenna. Touching the
antenna affects the call quality and results in increase in
37
power consumption. As a result, the talk time and the
standby time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device.
Prevention of Hearing Damage
Using a headset at high volume may damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety. The
device and its accessories may include parts that present a
choking hazard for children. Ensure that small children are kept
away from the device and its accessories.
Accessories
Use the accessories provided by the device manufacturer only.
Using third-party accessories with this device may invalidate
any guarantee or warranty applicable to the device, result in
malfunction of the device, and cause danger.
Battery and Charger
Unplug the charger from the power socket and the device
when the charger is not in use.
38
The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and the talk time are shortened, replace the battery.
Use the alternating current (AC) power supply defined in the
specifications of the charger. An improper power voltage
may cause a fire or a malfunction of the charger.
Do not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may short-circuit and cause injuries and burns on
your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. If the electrolyte touches
your skin or splashes into your eyes, wash your eyes with
clean water immediately and consult a doctor.
If the battery is deformed, changes color, or is abnormally
heated while you charge or store the battery, remove the
battery immediately and stop using it. Otherwise, it may lead
to battery leakage, overheating, explosion, or fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or if the plug loosens, stop using the
cable immediately. Otherwise, it may lead to an electric
shock, a short circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
39
There is a danger of explosion if the battery is incorrectly
replaced. Recycle or dispose of used batteries according to
the local regulations or instructions provided with your
device.
Cleaning and Maintenance
The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.
Do not place your device, battery, and charger in places
where they can get damaged because of collision. Otherwise,
it may lead to battery leakage, device malfunction,
overheating, fire, or explosion.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
Do not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
Before cleaning or maintaining the device, power off the
device and disconnect it from the charger.
40
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
get damaged or a fire may be caused. You can clean the
device and the charger with a piece of damp and soft
antistatic cloth.
Do not dismantle the device or its accessories. Otherwise,
the warranty on the device and the accessories becomes
invalid and the manufacturer is not liable to pay for the
damage.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for RF energy absorbed by the body when the device is being
41
used. The SAR value is determined at the highest certified
power level in laboratory conditions, but the actual SAR level of
the device when the device is being operated can be well below
the value. This is because the device is designed to use the
minimum power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the Federal Communications
Commission (FCC) and the Industry Canada (IC) for this device
type when it is tested for use at the ear is 1.150 W/kg, and that
when it is properly worn on the body is 1.000 W/kg.
The SAR limit also adopted by Europe is 2.0 W/kg averaged
over 10 grams of tissue. The highest SAR value for this device
type when it is tested at the ear is 0.773 W/kg, and that when it
is properly worn on the body is 0.485 W/kg.
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate RF
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. There is, however, no guarantee that
interference will not occur in a particular installation.If this
equipment does cause harmful interference to radio or
television reception,which can be determined by turning the
42
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio or TV technician
for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void
the FCC authorization to operate this device.
EU Regulatory Conformance
Huawei Technologies Co., Ltd. hereby declares that this device
complies with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the Web site
www.huaweidevice.com/certification.
43
Notice: Observe the national and local regulations in the
location where the device is to be used. This device may be
restricted for use in some or all member states of the European
Union (EU).
Version: 01 NO.: 6010511
