Huawei Technologies G5760 GSM MOBILE PHONE User Manual
Huawei Technologies Co.,Ltd GSM MOBILE PHONE Users Manual
Users Manual
G5760
GSM Mobile Phone
User Guide
Copyright © Huawei Technologies Co., Ltd. 2009. All rights reserved.
No part of this document may be reproduced or transmitted in any form or
by any means without prior written consent of Huawei Technologies Co.,
Ltd.
The product described in this manual may include copyrighted software of Huawei
Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce,
distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign,
or sublicense the said software, unless such restrictions are prohibited by applicable laws or
such actions are approved by respective copyright holders under licenses.
Trademarks and Permissions
, , and are trademarks or registered trademarks
of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are the property of their
respective owners.
Notice
Some features of the product and its accessories described herein rely on
the software installed, capacities and settings of local network, and may
not be activated or may be limited by local network operators or network
service providers. Thus the descriptions herein may not exactly match the
product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify any information or
specifications contained in this manual without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS
REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE
SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,
BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and will obtain all necessary governmental permits and licenses
in order to export, re-export or import the product mentioned in this
manual including the software and technical data therein.
i
Table of Contents
1 Getting to Know Your Phone ................................................1
Your Phone ........................................................................................... 1
Keys and Functions ........................................................................... 2
Screen Icons ......................................................................................... 4
Using Shortcut Menu ....................................................................... 4
2 Installing and Charing ...........................................................5
Installing the SIM Card and the Battery ................................... 5
Removing the Battery and the SIM Card ................................. 6
Installing the microSD Card .......................................................... 6
Charging the Battery ........................................................................ 7
3 Getting Started .......................................................................7
Using the Stylus .................................................................................. 7
Calibrating the Screen ..................................................................... 8
Using the Function Menu .............................................................. 8
Phone Lock ........................................................................................... 9
PIN and PUK ........................................................................................ 9
Locking the Keypad .......................................................................... 9
Entertainment .................................................................................... 10
4 Call Function ........................................................................ 10
Making a Call ..................................................................................... 10
Answering a Call ............................................................................... 11
Dial healthily ...................................................................................... 11
ii
5 Text Entry ............................................................................. 12
Changing the Text Input Mode .................................................. 12
Using Keys/Virtual Keyboard ...................................................... 12
Using Dtylus ....................................................................................... 14
6 Messaging ............................................................................ 14
Writing and Sending a Text Message ..................................... 14
Writing and Sending a Multimedia Message ...................... 15
7 Contacts ................................................................................ 16
Creating a New Contact ................................................................ 16
Searching for a Contact ................................................................ 16
8 Multimedia ........................................................................... 17
Audio Player ....................................................................................... 17
Video Player ....................................................................................... 18
Camera ................................................................................................. 20
FM Radio ............................................................................................. 21
Video Recorder ................................................................................. 22
9 WAP ...................................................................................... 24
Network Settings ............................................................................. 24
Connecting to the Network ........................................................ 25
10 Bluetooth ............................................................................ 25
11 USB ...................................................................................... 26
12 Warnings and Precautions ............................................... 26
1
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone and
it is for your reference only.
1
7
3
4
5
69
10
11
12
13
8
1
Earpiece
8
# key
2
Screen
9
Charger/Headset/USB
jack
3
Navigation keys
10
Confirm key
4
Left soft key
11
Right soft key
5
Call/Answer key
12
End/Power key
2
6
Number keys
13
Volume key
7
* key
The headset is not delivered as an accessory in your
packing box. It may be available as a giveaway or need to
be purchased separately.
Keys and Functions
Press…
To…
Make a call.
Answer an incoming call.
View call logs in standby mode.
Power on or power off the phone (by pressing
and holding the key for about 3s).
End a call or reject an incoming call.
Return to the standby mode.
(Left)
Select the option displayed in the lower left
corner of the screen.
(Right)
Select the option displayed in the lower right
corner of the screen.
Display Contacts list in standby mode.
Return to the previous menu.
Display the main menu in standby mode.
Confirm a selection.
3
Press…
To…
Scroll through submenus on a menu screen or
options on an option screen.
Access the functions assigned to the keys as
shortcuts in standby mode.
Increase the volume ( ) or decrease the volume
( ) during a call.
.
Enter numbers, letters, and characters.
Call the voice mail center in standby mode (by
pressing and holding the 1 key for about 3s).
Speed-dial phone numbers in standby mode (by
pressing and holding the 2–9 keys for about 3s),
when Speed-dial is on.
Select a submenu item labeled with the
corresponding number.
In standby mode, press the key once to enter *,
twice to enter +, three times to enter P, and four
times to enter W.
Display the symbol list in any text input mode.
Enter #.
Enable or disable the meeting mode in standby
mode (by pressing and holding the key for about
3s).
Switch text input modes when editing texts.
4
Screen Icons
Icon
Indicates…
Signal strength.
GPRS signal.
The Ring alert mode is activated.
The Vib. only alert mode is activated.
The Vib. and ring alert mode is activated.
The Vib. then ring alert mode is activated.
Missed call(s).
Call forwarding is activated.
Unread text message(s).
Unread multimedia message(s).
Bluetooth is activated.
An alarm is activated.
Battery power level.
Keypad is locked.
Using Shortcut Menu
Tap
To…
Enter the main menu.
5
Tap
To…
Enter call logs.
Enter messages.
Enter contacts.
Open shortcuts.
Tap one icon and hold 2s after that you can drag
the icon to everywhere.
(In shortcuts screen, when you tap icon, it will
move function icon to Standby mode,you can also
drag it back. But if you tap , the icon can’t be
dragged back. It will switch to contacts in shortcuts
area when you slide left and right in standby
mode.)
2 Installing and Charing
Installing the SIM Card and the Battery
Ensure that the golden contact area on the SIM card is facing
downward, and the beveled corner is properly aligned with the
SIM card slot.
6
Removing the Battery and the SIM Card
Before removing the battery and the SIM card, ensure that your
phone is powered off.
Installing the microSD Card
Ensure that inserting the memory card with the golden contact
area facing up.
7
The microSD Card is not delivered as an accessory in your
packing box. It need to be purchased separately.
Charging the Battery
1. Connect the charger to the charger interface on the side of
the phone.
2. Connect the charger to a power socket. The charging starts,
with the charging icon displayed in an animated state.
When you start to charge a completely discharged
battery, the charging icon may appear on the screen
several minutes later.
3. Disconnect the charger from the power socket when the
charging icon becomes static, indicating that the battery is
fully charged.
4. Disconnect the charger from the phone.
3 Getting Started
Using the Stylus
Your phone has a screen with tactility. You can use the stylus tip
to touch the screen to select items or edit text.
Tap: Use the stylus tip to touch the screen once to select an
item or access a menu.
8
Drag: Press the stylus tip onto the screen, and then move the
stylus to scroll the menus or pages.
Calibrating the Screen
The touch of stylus tip on the screen can be responded
accurately through screen calibration.
1. In standby mode, press or , or tap ..
2. Select Settings > Phone settings >Touch settings >Pen
Calibration.
3. Tap the cross marks that appear on the screen in sequence
according to the prompts to finish adjusting the phone
display.
Using the Function Menu
1. In standby mode, press or , or tap .
2. Press to select the desired function menu.
3. Press or to display the selected menu, or tap
function menu directly to enter.
4. Press to select a submenu.
5. Press or to display the menu.
6. Press or tap Back to return to the previous menu or exit
the function menu.
7. To return to the standby mode, press .
9
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock function is disabled. You can change the
default phone lock code (1234) into any numeric string of four
to eight digits.
Do remember your phone lock code. If you forget it, contact
the service center.
PIN and PUK
The personal identification number (PIN) protects your SIM
card from unauthorized use. The PIN unblocking key (PUK) can
unlock the blocked PIN. Both PIN and PUK are delivered with
the SIM card. For details, contact your service provider.
If you enter wrong PINs for a specified number of times
consecutively, the phone asks you to enter the PUK.
If you enter wrong PUKs for a specified number of times
consecutively, the SIM card is invalidated permanently. Contact
your service provider for a new one.
Locking the Keypad
To lock the keypad, close the slide, or press and then .
To unlock the keypad, open the slide, or press then .
If the Auto keypad lock function is enabled and the phone is
idle for a preset period in standby mode, the keypad is locked
automatically.
When the keypad is locked, you can press to answer
an incoming call.
10
Entertainment
Camera: to shoot pictures or videos.
Audio player: to play the audio files stored in the phone
memory or on the microSD card.
Video player: to play the video files stored in the phone
memory or on the microSD card.
FM Radio: to listen to the radio program.
Games: to enjoy the funny games.
Java: to download and install the java applications and
games.
Photo editor: to edit photos and tile image.
Viedo recorder: to recorder videos.
Schedule FM record: to record timing for your favorite
channel.
Melody compose: to edit ringtones.
4 Call Function
Making a Call
1. In standby mode, enter the phone number.
To make an international call, press twice consecutively
to enter the plus sign (+). Then enter the international long
distance code, country code or region code, area code, and
phone number in sequence.
11
To call an extension, enter the phone number, press
three times consecutively to insert P, and then enter the
extension number.
2. Press or tap Options >Call to dial the number.
3. Press or tap Options > End single call to end the call,.
During a call, press to adjust the volume.
Answering a Call
When there is an incoming call, you can do as follows:
Press to answer it.
Press or tap Options and select Answer to answer it.
Press , or tap Reject to reject it.
If the Cover answer function is enabled, you can open the slide
to answer an incoming call.
If the Any key answer function is enabled, you can press any
key except and to answer an incoming call.
Dial healthily
When you making a call, if Dial healthily is active the phone
will vibrate as soon as the call connected or end.
1. In standby mode, press or , or tap .
2. Select Settings > General call settings > Dial healthily.
3. Select On/Off > On to activate Dial healthily.
12
5 Text Entry
Changing the Text Input Mode
The indicator of the current text input mode is displayed in the
upper left corner of the screen. You can press to change
the text input mode, also you can tap input method icon to
change into other input mode.
Press (Clear) once to delete the letter on the left of
the cursor. Press and hold (Clear) for about 3s to
clear all the letters.
In any text input mode (except the "123" mode), press
to enter a space.
Using Keys/Virtual Keyboard
Predictive Input Mode
In predictive input mode, enter a word as follows:
1. Press or tap each key only once according to the spelling
sequence of the desired word.
The phone displays the commonly used word according to
the sequence of key presses.
2. Scroll to the desired word.
3. Press or tap the word to enter it.
13
Press to display commonly used punctuations.
After you enter a word or symbol, a space will be
added automatically.
Multitap input mode
In Multitap input mode, you can press or tap a key labeled with
the desired letter once to enter the first letter on the key, twice
to enter the second letter on the key, and so on.
Press repeatedly to select and enter commonly
used punctuations.
Press once to enter a space, twice to enter 0.
Entering a Digit
In "123" input mode, you can directly press a number key
labeled with the desired digit.
In predictive and multi-tap input mode, press the number
key labeled with the desired digit repeatedly until the digit
appears on the screen.
Entering a Symbol
1. Press or tap to display the symbol list.
2. Scroll to the desired symbol.
3. Press or tap symbom to enter the symbol.
14
Using Dtylus
Tap in screen to change to touch screen input method.
You can use stylus to input any word. After input the word it will
display some relevent words in input area. If the word display in
content area is the word you want, you can go on inputting
next word, else tap the right word in input area.
Tap to change to keyboard input method.
6 Messaging
Writing and Sending a Text Message
1. In standby mode, press or , or tap .
2. Select Messages > Write message > SMS.
3. Write the message.
4. Press or tap Options and then select Done for the
following options:
Save and send: to add a recipient and send the message
with saving it.
Send only: to enter a phone number or select a recipient
from the contact list, and send the message.
Save to drafts: to save the message only.
Send to many: to add several recipients at a time and send
the message.
15
Send by groups: to add all members of a group as
recipients and send the message.
Writing and Sending a Multimedia
Message
1. In standby mode, press or , or tap .
2. Select Messages > Write message > MMS.
3. Select To, Cc, or Bcc.
Add phone numbers or email addresses to be sent, carbon
copied, or blind carbon copied to.
4. Select Subject.
Edit the subject of the message.
5. Select Edit content.
Edit the content of the message. You can add pictures, audio
and video clips, and attachments to the multimedia message.
You can also insert a new slide, preview the message, and set
the slide duration.
6. Press or tap Options and then select Done for the
following options:
Send only: to send the multimedia message.
Save and send: to send and save the multimedia message.
Save to drafts: to save the message only.
Save as template: to store as a template.
Send options: to set validity period,deliverr report,read
report,priority.
Exit: to quit editing interface.
16
Contact your service provider for the availability of the
Multimedia Messaging Service (MMS) and the method
for subscribing to this service.
Open multimedia messages with caution. Objects in
multimedia messages may contain viruses that can
damage your phone, such as malicious software.
7 Contacts
Creating a New Contact
1. In standby mode, press or , or tap .
2. Select Contacts > Add new contact.
3. Select To SIM or To phone for saving the contact.
4. Edit the contact.
5. After editing the contact, press or tap OK to save the
contact.
Searching for a Contact
1. In standby mode, press or , or tap .
2. Select Contacts > Search contact.
3. Enter the contact name.
4. Press or tap OK to search for the contact.
17
You can also select Menu > Contacts > Contacts list.
Then enter the first letter of the contact name to find the
desired contact.
8 Multimedia
Audio Player
1. In standby mode, press or , or tap .
2. Select Multimedia > Audio player.
1
Adjust the volume.
6
Enter the playing list.
2
Enter playing list.
7
Switch on or off shuffle.
3
Switch to the previous music
8
Exit audio player.
4
Stop playing the music.
9
Switch to the next music.
5
Change the play mode.
10
Play or pause the music.
18
3. Press to enter playing list. Press to select a music
file.
4. Press or tap to play the music.
When the music is being played, you can do as follows:
Press to adjust the volume.
Press to change the playing music. Press and hold 3s
to adjust the playing schedule.
Tap or to change the playing music.
Press or tap to pause the music.
Press or tap to stop playing the music.
Tap to change the play mode.
Tap to switch on or off shuffle.
Video Player
1. In standby mode, press or , or tap .
2. Select Multimedia > Video player.
19
1
Speed up or rewind.
5
Snapshooting screenshot.
2
Change playback speed.
6
Play or stop the video.
3
Enter full-screen paly mode.
7
Exit video player.
4
Enter menu options.
8
Adjust the volume.
3. Press to select a video file.
4. Press （Play）to view the video, press or tap
to play the video.
When the video is being played, you can do as follows:
Press or tap to adjust the volume.
Press to change the playing speed (only for AVI
format).
Press or tap to fast forward or rewind the
video.
Press to pause/continue the video.
20
Press (Stop) to stop playing the video.
Tap to snapshooting screenshot.
Tap to enter full-screen play mode.
Camera
1. In standby mode, press or , or tap .
2. Select Multimedia > Camera to launch the camera.
1
Set image size.
7
Set white balance.
2
Enter menu options.
8
Set delay timer.
3
Exit camera.
9
Set cont. shot.
4
Adjust EV.
10
Set scene mode.
5
Shoot a picture.
11
Set the picture quality.
6
Set effect.
In camera mode, you can do as follows:
Press to view photos, or perform relevant settings.
21
Press to adjust brightness.
Press the number keys (1, 2, 4, 5, 6, 7, 8) to perform the
corresponding settings.
Press or tap to shoot a photo.
FM Radio
The headset cable functions as an antenna as well. To ensure
good reception of radio programs, do not disconnect the
headset from the phone or severely bend the headset cable.
1. Connect a compatible headset to the phone.
2. In standby mode, press or , or tap .
3. Select Multimedia > FM radio.
1
Adjust the volume.
6
Start or stop recording.
2
Enter channel list.
7
Back to the previous.
3
Enter menu options.
8
Open or close the station.
4
Perform the settings.
9
Start or stop recording.
22
5
Auto search channel.
4. On the FM radio screen, you can do as follows:
Press to record the program; press (Stop) to stop
recording.
During the recording, press or to pause or
continue.
Press (Back) to play the radio program in the
background.
Press or tap to adjust the volume.
Tap to enter channel list.
Tap to perform other settings.
Tap to auto search channel.
Tap to open or close the station.
Tap to start or stop recording.
Press to change the channel.
Press (Options) to set the speaker, view and set the
channel list, tune, or select other options.
Video Recorder
1. In standby mode, press or , or tap .
2. Select Multimedia > Video recorder.
23
1
Set relevant parameters.
4
Zoom.
2
Start or stop recording a
video.
5
Exit the camera screen.
3
Adjust the brightness.
3. Press or tap to set relevant parameters.
4. Press or tap to start recording a video.
During the recording, press or tap to
pause/continue.
5. Press or tap to stop recording.
6. Press to adjust the brightness.
7. Press to zoom control.
9 WAP
You can access WAP sites and use WAP-based services on your
phone. To access the WAP sites through your phone, you need
to subscribe the corresponding service from the service
provider and set the relevant parameters on your phone first.
For details about the service and the charges, contact your
service provider.
Network Settings
To access the WAP sites through your phone, you need to set
the data account and WAP parameters on your phone first.
Setting the Connection Profile
1. In standby mode, press or , or tap .
2. Select Settings > Connection settings > Data account.
3. Select the network type, press (OK) or tap OK.
4. Select your service provider, press (Edit) or tap Eidt.
5. Set the account information, and press (OK) or tap OK
to save the settings.
Setting the WAP
1. In standby mode, press or , or tap .
2. Select WAP > Settings > Edit account.
3. Select your service provider, press (OK) or tap OK.
4. Activate the account.
Connecting to the Network
1. In standby mode, press or , or tap .
2. Select WAP > Input address.
3. Enter a URL address.
4. Press (Options) and select Done to access the address.
10 Bluetooth
Bluetooth connections can be set up between devices within a
maximum distance of 10 meters, and there should be no solid
obstacles between the devices..
1. In standby mode, press or , or tap .
2. Select Settings > Connection settings > Bluetooth.
3. Select Power on/off, press (On) or tap On to activate
bluetooth.
4. Select Settings to perform relevant settings.
5. After that, you can use Bluetooth to translate or receive files,
or search Bluetooth headset to listen to the music.
11 USB
After connecting to the PC with USB data cable, you phone can
be used as a USB mass storage device.
1. Connect your phone to the PC by using the USB cable.
2. Select USB config > Mass storage.
3. The phone is recognized as a USB mass storage device.
4. Read the files saved in the phone memory and on microSD
card directly.
Save the files to the corresponding folders that are
automatically created on the phone or the microSD card.
Because contents in only the default folder can be read,
do not create a folder by yourself.
12 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when it causes danger or interference with
electronic devices.
Medical Device
Power off your device and follow the rules and regulations
set forth by the hospitals and health care facilities.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Some wireless devices may affect the performance of the
hearing aids. For any such problems, consult your service
provider.
Potentially Explosive Atmospheres
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or fire, resulting in bodily injuries or even deaths.
Do not switch on the device at refueling points such as service
stations. Comply with restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas, and
chemical plants. Also, adhere to restrictions in areas where
blasting operations are in progress. Before using the device,
watch out for areas that have potentially explosive atmosphere
that are often, but not always, clearly marked. Such locations
include areas below the deck on boats, chemical transfer or
storage facilities and areas where the air contains chemicals or
particles such as grain, dust, or metal powders. Ask the
manufacturers of vehicles using liquefied petroleum gas (such
as propane or butane) if this device can be safely used in their
vicinity.
Traffic Security
Observe local laws and regulations while using the device. Also,
if using the device while driving a vehicle, please comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive
safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
Do not use your device while flying in an aircraft. Switch off
your device before boarding an aircraft. Using wireless
devices in an aircraft may be dangerous to the operation of
the aircraft, disrupt the wireless telephone network, and may
be considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp or dirty
places or places with magnetic fields. Otherwise, the circuit
may not function properly.
The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
On a thunder and stormy day, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and standby
time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
Keep the ambient temperature between 0℃ and 45℃ while
the device is being charged. Keep the ambient temperature
between -10℃ to 55℃ for using the device powered by
battery.
Preventing Hearing Damage
Listening to a headset at high volumes can damage your
hearing. Use only the minimum volume setting necessary to
hear your conversation or music.
Safety of Children
Please comply with all precautions with regard to children's
safety. Letting the child play with your device or its accessories,
which may include parts that can be detached from the device,
may prove dangerous, as it may present a choking hazard.
Make sure that small children are kept away from the device
and accessories.
Accessories
Use only the accessories delivered by manufacturer. Using
accessories of other manufacturers or vendors with this device
model might invalidate any approval or warranty applicable to
the device, might result in the non-operation of the device, and
might be dangerous.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and talk time are shorter than normal, replace the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause fire or the
charger may not function properly.
Do not connect two poles of the battery with conductors
such as metal materials, keys or jewelries. Otherwise, the
battery may be short-circuiting and may cause injuries and
burns on your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
If battery electrolyte leaks out, make sure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your eyes
with clean water immediately and consult a doctor.
If the battery is damaged, or the color changes or gets
abnormally heated while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
it may lead to battery leakage, overheating, explosion, or
fire.
If the power cable is damaged (for example, the lead is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to electric shock,
short-circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Clearing and Maintenance
The device, battery, and charger are not water-resistant Keep
them dry. Protect the device, battery and charger from water
or vapor. Do not touch the device and charger with a wet
hand. Otherwise, it may lead to short-circuit or malfunction
of the device and electric shock to the user.
Do not place your device, battery, or charger in places where
it can get damaged because of collision. Otherwise, it may
lead to battery leakage, device malfunction, overheating, fire,
or explosion. When the temperature is lower than 0℃,
performance of the battery is affected.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
Do not leave your device, battery, or charger in a very hot or
cold place. Otherwise, they may not function properly and
may lead to a fire or an explosion.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
Before you clean or maintain the device, power off the
device and disconnect it from the charger.
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
get damaged or a fire can be caused. You can clean the
device and the charger with a piece of damp and soft
antistatic cloth.
Do not dismantle the device or accessories. Otherwise,
manufacturer is not liable to pay for damages as the device
and accessories are not covered by warranty.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
RF Exposure Information (SAR)
This mobile phone meets the government’s requirements for
exposure to radio waves.
This phone is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy set
by the Federal Communications Commission of the U.S.
Government.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6W/kg. Tests for SAR are
conducted using standard operating positions accepted by the
FCC with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the
maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the poser
required to reach the network. In general, the closer you are
to a wireless base station antenna, the lower the power output.
The highest SAR value for the model phone as reported to the
FCC when tested for use at the ear is 0.373 W/kg and when
worn on the body, as described in this user guide, is 0.846 W/kg
(Body-worn measurements differ among phone models,
depending upon available enhancements and FCC
requirements.)
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirement.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and can
be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID:
QISG5760.
For body worn operation, this phone has been tested and
meets the FCC RF exposure guidelines for use with an accessory
that contains no metal and the positions the handset a
minimum of 2.0cm from the body. Use of other
enhancements may not ensure compliance with FCC RF
exposure guidelines. If you do no t use a body-worn accessory
and are not holding the phone at the ear, position the handset
a minimum of 2.0 cm from your body when the phone is
switched on.
FCC Statement
This device has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by manufacturer name: Huawei
Technologies Co., Ltd. may void the FCC authorization to
operate this device.
FCC Regulations
This mobile phone has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiated
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
The antenna(s) used for this transmitter must not be co-located
or operating in conjunction with any other antenna or
transmitter.
Version: V100R001_01 NO.: 6010217
