Huawei Technologies G6006B GSM Mobile Phone User Manual HUAWEI G6006B User Mannul
Huawei Technologies Co.,Ltd GSM Mobile Phone HUAWEI G6006B User Mannul
(HUAWEI G6006B) User Mannul_update
Copyright © Huawei Technologies Co., Ltd. 2011.
All rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
i
Contents
1 Getting to Know Your Phone ................................................1
Your Phone ........................................................................................... 1
Keys and Functions ........................................................................... 2
Screen Icons......................................................................................... 4
2 Getting Started .......................................................................5
Installing SIM Cards and the Battery......................................... 5
Removing the Battery and SIM Cards....................................... 5
Installing a microSD Card............................................................... 6
Charging the Battery........................................................................ 6
Working with the Main Menu ...................................................... 7
Automatically Switching Between Profiles.............................. 7
Phone Lock ........................................................................................... 8
Mass Storage ....................................................................................... 9
PIN and PUK ........................................................................................ 9
Locking the Keypad ........................................................................10
Entertainment....................................................................................11
3 Voice Services ...................................................................... 12
Making a Call.....................................................................................12
Answering a Call...............................................................................12
4 Text Input ............................................................................. 13
Changing the Text Input Mode..................................................13
Multi-Tap Input Mode ...................................................................14
ii
Predictive Input Mode...................................................................14
Number Input Mode ......................................................................15
Entering Symbols .............................................................................15
5 Messaging ............................................................................ 16
Writing and Sending a Text Message .....................................16
Writing and Sending a Multimedia Message......................16
6 Phonebook ........................................................................... 18
Creating a Contact ..........................................................................18
Searching for a Contact ................................................................18
Setting the Preferred Storage.....................................................19
Copying Contacts ............................................................................19
7 Ebook Reader ....................................................................... 20
8 Games.................................................................................... 21
9 Camera.................................................................................. 21
10 Audio Player....................................................................... 21
11 FM Radio ............................................................................ 22
12 File Manager ...................................................................... 23
13 Services............................................................................... 24
Network Settings .............................................................................24
Selecting a SIM Card ......................................................................25
Connecting to a Network.............................................................25
14 STK ...................................................................................... 26
15 Warnings and Precautions ............................................... 26
1
1 Getting to Know Your Phone
Your Phone
1 Earpiece 11 Headset jack
2 Screen 12 Sym key
3 Left soft key 13 Input switch key
4 Audio player key 14 Enter key
5 Call/Answer key 15 Delete key
6 Keypad 16 End/Power key
7 Fn key 17 Message key
8 A/a key 18 Right soft key
9 Space key 19 OK/Confirm key
10 Charger jack 20 Navigation keys
The figure above shows the appearance of your phone
and is provided only for your reference.
2
Keys and Functions
Press… To…
z Make a call from the SIM1 or SIM2 card in
standby mode.
z Answer a call.
z View call logs of SIM1 and SIM2 cards in
standby mode.
z Power on or power off the phone (by
pressing and holding the key for about 3s).
z End or reject a call.
z Return to standby mode.
z Access the main menu in standby mode.
z Select a highlighted item.
z Access Contacts in standby mode.
z Return to the previous menu.
Access Audio player in standby mode.
Access Messaging in standby mode.
z Access the main menu in standby mode.
z Confirm a selection.
Scroll to the desired icon in the main menu
(by pressing , , , and ).
3
Press… To…
–
–
z Enter numbers, letters, and symbols.
z Call the voicemail in standby mode (by
pressing and holding the 1 key for about 3s).
z Select a submenu (by pressing the
corresponding number key).
Enter a space in text editing mode.
z Lock the keypad in standby mode (by
pressing and holding the key for about 3s).
z Switch between input methods in text editing
mode.
Switch between upper and lower case in text
editing mode.
z Access FM radio in standby mode (by
pressing and holding the key for about 3s).
z Display the Select symbol list in text editing
mode.
4
Screen Icons
Icon Indicates…
/
Signal strength.
/ New text messages.
/ New multimedia messages.
/ Call forwarding enabled.
Missed calls.
Alarms enabled.
Keypad locked.
Battery power level.
General profile activated.
Meeting profile activated.
Outdoor profile activated.
Headset connected to the phone.
5
2 Getting Started
Installing SIM Cards and the Battery
You can install two Subscriber Identification Module (SIM) cards
in the phone at the same time. When inserting a SIM card,
ensure that the golden contact area on the SIM card is facing
downward and that the beveled edge of the SIM card is
properly aligned with that of the SIM card slot.
Removing the Battery and SIM Cards
Before removing the battery and SIM cards, ensure that your
phone is powered off.
6
Installing a microSD Card
Before installing or removing a microSD card, power off
the phone. Once the phone is powered on, it will indicate
whether the microSD card has been installed properly.
You can install a microSD card to expand the memory capacity
of your phone. When inserting the microSD card, ensure that
the golden contact area on the microSD card is facing
downward.
Charging the Battery
To charge the battery:
1. Connect the charger to the phone.
2. Connect the charger to a power socket.
7
3. Wait until the battery is fully charged.
While the battery is charging, the charging icon is animated.
When the charging icon animation stops, the battery is fully
charged.
4. Disconnect the charger from the power socket and then
from the phone.
Working with the Main Menu
1. In standby mode, press (Menu) to access the
main menu.
2. Use to scroll to the desired submenu, and then
press to access the submenu.
3. Press or to scroll to an option, and then press
(OK) or to select the option.
4. Press (Back) to return to the previous menu.
To return to the standby mode, press .
Automatically Switching Between Profiles
You can set your phone to activate different profiles at different
times. The phone can automatically switch between profiles up
to three times per day.
1. Select Menu > User profiles > Profile Switch Timing.
8
2. Scroll to a time, and then press (Edit) to select
the profile to be activated at the specified time.
3. Press (Done) to save the settings.
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. Once the phone lock is
enabled, you are required to enter the phone code each time
you power on the phone.
To enable the phone lock:
1. Select Menu > Settings > Security settings > Phone
security > Phone lock.
2. Enter the phone code, and then press (OK).
You can change the default phone code (1234) to any numeric
string of four to eight digits.
To change the phone code:
1. Select Menu > Settings > Security settings > Phone
security > Change password.
2. Enter the old phone code, and then press (OK).
3. Enter the new phone code, and then press (OK).
4. Enter the new phone code again to confirm it.
If you forget the phone code, contact the service provider.
9
Mass Storage
When the phone is connected to a PC through a USB cable, the
options including Mass storage are displayed on the phone
screen.
When you select Mass storage, you can manage the files
stored on the phone and the microSD card.
The microSD card and the phone memory appear as removable
disks on the PC. You can perform the following operations:
1. Double-click a disk to open it.
2. Copy, paste or delete files on a disk.
3. Disconnect the phone from the PC.
z Ensure that you connect and disconnect the USB cable
properly.
z Do not use format command attempts to format the
phone memory on a PC; otherwise, it may lead to
permanent damage.
z The USB cable supports both data transfers and
charging functions.
PIN and PUK
The personal identification number (PIN) protects your SIM
card from unauthorized use. The PIN unblocking key (PUK)
unlocks a blocked PIN. Both the PIN and the PUK are provided
with the SIM card. For details, contact your service provider.
SIM1 and SIM2 PINs are configured separately.
To enable the PIN lock:
10
1. Select Menu > Settings > Security settings > SIM1or
SIM2 security settings > PIN lock.
2. Enter the PIN, and then press (OK).
3. If you enter an incorrect PIN a pre-defined number of
consecutive times, the phone prompts you to enter the PUK.
4. If you enter an incorrect PUK a pre-defined number of
consecutive times, the SIM card becomes permanently
invalid. In that case, contact your service provider for a new
SIM card.
Locking the Keypad
To lock the keypad, press and hold in standby mode for
3s. To unlock the keypad, press (Unlock) and then
.
If the Auto keypad lock function is enabled and if the phone is
in standby mode for a preset period, the phone locks the
keypad automatically.
To enable the Auto keypad lock function, select Menu >
Settings > Security settings > Auto keypad lock, scroll to a
period, and then press (OK) to select the period.
When the keypad is locked, you can press to
answer a call or make an emergency call.
11
Entertainment
z Camera: to take pictures.
z Image viewer: to view pictures stored on the phone or the
microSD card.
z Audio player: to play audio clips stored on the phone or the
microSD card.
z Sound recorder: to record audio clips.
z FM radio: to listen to the radio.
z Games: to enjoy games.
12
3 Voice Services
Making a Call
1. In standby mode, enter the phone number.
z To make an international call, press to enter the plus
sign (+), and then enter the country or region code, area
code, and phone number in sequence.
z To call an extension, enter the phone number, press to
enter P, press and then press to enter W, and then
enter the extension number.
2. Press to dial the number.
3. Press to end the call.
z You can also make calls from call logs, contacts, and
messages.
z During a call, you can press or to adjust
the volume.
Answering a Call
When there is an incoming call:
z Press to answer the call.
13
z Press (Options), and then select Answer to
answer the call.
z Press to reject the call.
z Press (Silent) to mute the speaker, and then
press (Reject) to reject the call.
z Press (Silent) to mute the speaker, press
(Options), and then select Answer to answer the
call.
If the Any key answer function is enabled, you can press any
key except and to answer a call.
4 Text Input
Changing the Text Input Mode
The indicator of the current text input mode is displayed in the
upper left corner of the screen. You can press to change
the text input mode.
Indicator Text Input Mode
abc Multi-tap input mode
eZi abc Predictive input mode
123 Number input mode
14
z You can press (Clear) or once to delete
the last entered character. You can also press and hold
(Clear) for 3s to clear all the entered
characters at once, or press and hold to delete the
entered characters one by one.
z In any text input mode, press to enter a
space.
z In any text input mode, press to start a new
paragraph.
z When the input language is English, press to
switch between upper and lower case.
Multi-Tap Input Mode
In multi-tap input mode, press the key labeled with the desired
letter.
Predictive Input Mode
To enter a word in predictive input mode:
1. Press each key once according to the spelling sequence of
the desired word.
The phone displays candidate words.
2. Press or to scroll left or right, and press
or to turn pages.
3. Press to select the desired word.
15
Number Input Mode
In number mode, press the key labeled with the desired digit.
Entering Symbols
To enter a symbol with the QWERTY keypad in any input mode:
Using to Enter a Symbol
To enter a desired symbol in text editing mode:
z To enter only one symbol, press once and then the key
labeled with the desired symbol.
z To enter multiple symbols, press twice and then the keys
labeled with the desired symbols.
Using to Enter a Symbol
To enter a desired symbol in text editing mode:
1. Press to display the symbol list.
2. Press or to scroll left or right, and press
or to scroll up or down.
3. Press to select the desired symbol.
16
5 Messaging
Writing and Sending a Text Message
1. Select Menu > Messaging > Write message > Text
Message; or in standby mode, press , and then select
Write message > Text Message.
2. Write the message.
3. Press (Options), and then select Send to.
4. Select Enter number, and then enter the phone number of a
recipient; or select Add from Phonebook, and then add a
recipient from the phonebook.
To add multiple recipients, repeat this step.
5. Scroll to the recipient, and then press to send the
message or press (Options) for the following
options:
z Send: to send the message to the recipient.
z Save to Drafts: to save the message to Drafts and exit the
message editing screen.
Writing and Sending a Multimedia
Message
1. Select Menu > Messaging > Write message > Multimedia
message; or in standby mode, press , and then select
Write message > Multimedia message.
17
2. Write the message.
3. Press (Options) for the following options:
z Add picture: to add a picture to the message.
z Add sound: to add an audio clip to the message.
z Add subject: to add a subject to the message.
4. In message editing screen, press (Options). Then
select Send to, or press .
5. Select Enter recipient to input the phone numbers of the
recipients manually, or select Add from Phonebook to add
the desired contacts from the phonebook.
6. Highlight a recipient, and then press to directly send
the message; or press (Options) for the sending
options as follows:
z Send: to send the message.
z Change to Cc: to copy the message to the recipient.
z Change to Bcc: to blind copy the message to the recipient.
z Save to Drafts: to save the message to Drafts.
18
z You can contact your service provider for the availability
of the Multimedia Messaging Service (MMS) and the
method for subscribing to the service.
z Your phone supports a multimedia message of a
maximum size of 300 KB.
z Open multimedia messages with caution. Objects in
multimedia messages may contain malicious software
(such as viruses) that can damage your phone.
6 Phonebook
Creating a Contact
1. Select Menu > Contacts > Add new contact.
2. Select To SIM1 /SIM 2 or To phone for saving the contact.
3. Enter the contact information, and then press .
4. When the phone asks you whether to save the information,
press (Yes).
Searching for a Contact
1. Select Menu > Contacts.
2. Enter the first letter of the contact name.
3. Press or to scroll to the desired contact.
19
Setting the Preferred Storage
You can set the storage where you want to save new contacts.
1. Select Menu > Contacts.
2. Press (Options), and then select Phonebook
settings > Preferred storage.
3. Scroll to SIM1, SIM2, Phone, or All as desired.
4. Press (OK) to select the preferred storage.
Copying Contacts
You can copy contacts to the phone, SIM1 card or SIM2 card.
Copying One Contact
1. Select Menu > Contacts.
2. Press or to scroll to the desired contact.
3. Press (Options), and then select Copy.
4. Select To ph on e, To SIM1, or To SIM2 to copy the contact
to the desired location.
Copying All Contacts
1. Select Menu > Contacts.
2. Press (Options), and then select Phonebook
settings > Copy contacts.
3. Press or to scroll to the desired option, such as
From Phone or From SIM1.
20
4. Press (OK) to copy all contacts to the desired
location.
7 Ebook Reader
Your phone supports ebooks in .txt format.
1. Select Menu > Organizer > Ebook reader to display the
bookshelf.
The phone automatically adds ebooks stored in Ebook on
the microSD card to the bookshelf.
2. Scroll to the desired ebook.
3. Press (Options), and then select Open ebook to
start reading the ebook.
You can also press (Options), and then select
Global settings to configure settings such as Font size,
Scroll by, and Alignment.
4. Press (Back) to stop reading the ebook.
z When reading an ebook, you can press and
to turn pages.
z It is recommended that you store ebooks in Ebook on
the microSD card. When you open an ebook stored in
a folder other than Ebook, the phone automatically
moves the ebook to Ebook so that you can find it
easily next time your want to open it.
21
8 Games
For your entertainment purpose, your phone is provided with
Smash and Puzzle to play. Select Menu > Games > Games
settings to set the Sound effect and Volume .
9 Camera
The phone is equipped with a digital camera.
1. Select Menu > Multimedia > Camera.
2. On the picture taking screen, press to view
pictures or configure relevant settings.
3. Focus the camera on the scene, and then press to take
a picture.
4. Press (Back) to save the picture; or press
(Options), and then select Delete to delete the
picture.
10 Audio Player
The audio player plays audio clips that are stored in My music
on the microSD card. It is recommended that you listen to
22
audio clips with the headset so that you can enjoy enhanced
sound quality.
1. Select Menu > Multimedia > Audio player; or press
in standby mode to access Audio player.
2. Press to start playing audio clips.
When audio clips are being played:
z Press and to adjust the volume.
z Press and to switch between audio clips.
z Press the button on the headset cable to switch between
audio clips.
z Press (List) to view the audio clip list, and then
press (Options) to configure the relevant
settings.
3. Press to pause or resume.
11 FM Radio
Your phone is equipped with a built-in antenna, so you can
enjoy the radio programs though the loudspeaker. The headset
cable also functions as an antenna. Connect the headset to the
phone.
1. Select Menu > Multimedia > FM radio; or in standby mode,
press and hold for 3s.
23
2. When listening to the radio:
z Press to pause or continue.
z Press and to adjust the volume.
z Press or to adjust the frequency in steps of 0.1
MHz.
z Press and hold or , and then release the key to
switch to an adjacent channel.
z Press a number key to switch to the corresponding channel
on the Channel list.
z Press the button on the headset cable to switch between
channels.
z Press (Options) to view or edit the channel list,
manually set a frequency, automatically search for and save
channels, and configure the relevant settings.
When listening to the radio, you can press
(Options) to record an audio clip or append a new audio
clip to the original one.
12 File Manager
You can use File manager to organize files stored on your
phone and microSD card. You can view photos, enjoy music and
ebooks from File manager.
24
13 Services
You can access Wireless Application Protocol (WAP) sites and
use WAP-based services on your phone. To access WAP sites,
you must subscribe to the corresponding service from your
service provider and set the relevant parameters on your phone.
For details about the service and the charges, contact your
service provider.
Network Settings
To access WAP sites, set your data account and WAP
parameters first.
Setting the Connection Profile
1. Select Menu > Settings > Data account.
2. Press (Options), and then select Add PS
account.
3. Set the parameters based on the information provided by
your service provider.
4. Press (OK) to save the settings.
If the data account provided by your service provider
already exists, you do not need to create a data account.
25
Setting the WAP Profile
1. Select Menu > Services > Internet > Settings > Data
account.
2. Select SIM1 or SIM2.
3. Select your service provider, press (OK) to select
an data account.
Selecting a SIM Card
Only one SIM card can be used to connect to the Internet at a
time.
To select a SIM card:
1. Select Menu > Services > Internet > Settings > Select
SIM.
2. Scroll to SIM1, SIM2, or Always ask as desired.
3. Press (OK) to select the SIM card.
Connecting to a Network
1. Press Menu > Services > Internet > Input address.
2. Enter a Uniform Resource Locator (URL).
3. Press (Options), and then select Done to access
the address.
It's recommended that you should clear cache regularly
to ensure a better function experience.
26
14 STK
The SIM Tool Kit (STK) function is a value-added service
provided by your service provider; it can be used to send text
messages, view news, and access other applications. For more
information, contact your service provider.
15 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or
interference with electronic devices.
Medical Device
z Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device when using the
device is prohibited.
z Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
27
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas, and
chemical plants. In addition, adhere to restrictions in areas
where blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats, chemical
transfer or storage facilities, and areas where the air contains
chemicals or particles such as grain, dust, or metal powders.
Ask the manufacturers of vehicles using liquefied petroleum
gas (such as propane or butane) whether this device can be
safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
z Concentrate on driving. Your first responsibility is to drive
safely.
28
z Do not talk on the device while driving. Use hands-free
accessories.
z When you have to make or answer a call, park the vehicle at
the road side before using your device.
z RF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
z In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
z Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
Operating Environment
z Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
z The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
z On a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
29
z When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
z While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
z Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device powered by a
battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
the device, result in the non-operation of the device, and cause
danger.
30
Battery and Charger
z Unplug the charger from the electrical plug and the device
when not in use.
z The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and the talk time are shorter than the normal time, replace
the battery.
z Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
z Do not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may be short-circuited and may cause injuries and
burns on your body.
z Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
z If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your eyes
with clean water immediately and consult a doctor.
z If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
it may lead to battery leakage, overheating, explosion, or
fire.
z If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
31
cable at once. Otherwise, it may lead to an electric shock, a
short circuit of the charger, or a fire.
z Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
z Danger of explosion if battery is incorrectly replaced. Recycle
or dispose of used batteries according to the local
regulations or reference instruction supplied with your
device.
Cleaning and Maintenance
z The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.
z Do not place your device, battery, and charger in places
where they can get damaged because of collision. Otherwise,
it may lead to battery leakage, device malfunction,
overheating, fire, or explosion.
z Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
z Do not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
32
z Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
z Before you clean or maintain the device, power off the
device and disconnect it from the charger.
z Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
be damaged or a fire can be caused. You can clean the
device and the charger with a piece of damp and soft
antistatic cloth.
z Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
33
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for the amount of radio frequency energy absorbed by the
body when using a device. The SAR value is determined at the
highest certified power level in laboratory conditions, but the
actual SAR level of the device when being operated can be well
below the value. This is because the device is designed to use
the minimum power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the Federal Communications
Commission (FCC) and the Industry Canada (IC) for this device
type when it is tested for use at the ear is 1.340 W/kg, and that
when it is properly worn on the body is 1.320 W/kg.
The SAR limit also adopted by Europe is **W/kg averaged over
10 grams of tissue. The highest SAR value for this device type
when tested at the ear is** W/kg, and when properly worn on
the body is ** W/kg.
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate RF
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. There is, however, no guarantee that
interference will not occur in a particular installation.If this
34
equipment does cause harmful interference to radio or
television reception,which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio or TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void
the FCC authorization to operate this device.
EU Regulatory Conformance
Hereby, Huawei Technologies Co., Ltd. declares that this device
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the Web site
www.huaweidevice.com/certification.
35
Notice: Observe the national local regulations in the location
where the device is to be used. This device may be restricted for
use in some or all member states of the European Union (EU).
Version: 01 NO.:6010858
