Huawei Technologies HG530 Home Gateway User Manual HG530
Huawei Technologies Co.,Ltd Home Gateway HG530
(HG530) User Manual
![](/img.php?id=1281460&img=bg1.png)
HUAWEI HG530 Home Gateway
User Guide
HUAWEI TECHNOLOGIES CO., LTD.
![](/img.php?id=1281460&img=bg2.png)
HUAWEI HG530 Home Gateway
V100R001
User Guide
Issue 01
Date 2010-03-23
Part Number 202168
Huawei Technologies Co., Ltd. provides customers with comprehensive
technical support and service. Please feel free to contact our local office
or company headquarters.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: terminal@huawei.com
![](/img.php?id=1281460&img=bg3.png)
Copyright © Huawei Technologies Co., Ltd. 2010. All
rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means
without prior written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted software of Huawei
Technologies Co., Ltd and possible licensors. Customers shall not in any manner
reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse
engineer, lease, assign, or sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by respective copyright
holders under licenses.
Trademarks and Permissions
, , and
are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are the property of
their respective owners.
Notice
Some features of the product and its accessories described herein rely on the software
installed, capacities and settings of local network, and may not be activated or may be
limited by local network operators or network service providers. Thus the descriptions
herein may not exactly match the product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify any information or
specifications contained in this manual without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS
REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE
SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,
BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations and will
obtain all necessary governmental permits and licenses in order to export, re-export or
import the product mentioned in this manual including the software and technical data
therein.
Contents
1 Warnings and Precautions ....................................................................... 2
2 Getting Started .......................................................................................... 8
3 Setting the Network-Access Parameters ................................................. 8
3.1 Accessing the Network Through the Embedded PPP Dial-Up Software on
the HG530 ...........................................................................................................8
3.2 Accessing the Network Through the PPP Dial-Up Software on Your
Computer .............................................................................................................9
4 Configuring the Wireless Network Connection.................................... 10
5 Configuring the HG530 .......................................................................... 12
5.1 Changing the Administrator Password Used for Logging In to the
Web-Based Configuration Utility......................................................................12
5.2 Enabling or Disabling the Wireless Network Function ..............................13
5.3 Changing the Wireless Network Name and the Access Password .............13
5.4 Changing the IP Address Used for Logging In to the Web-Based
Configuration Utility .........................................................................................14
5.5 Restoring Default Settings..........................................................................14
6 FAQs......................................................................................................... 16
7 Appendix.................................................................................................. 19
7.1 Indicators....................................................................................................19
7.2 Interfaces and Buttons................................................................................20
7.3 Default Settings..........................................................................................21
7.4 Technical Specifications.............................................................................21
i
![](/img.php?id=1281460&img=bg5.png)
1 Warnings and Precautions
Thank you for purchasing the HUAWEI HG530 Home Gateway (hereinafter referred to
as the HG530).
To use the device properly and safely, read these warnings and precautions carefully
and strictly observe them during operation. Unless otherwise specified, the term
"device" refers to the device and its accessories.
Basic Requirements
z During storage, transportation, and operation of the device, keep it dry and prevent
it from colliding with other objects.
z Do not dismantle the device. In case of any fault, contact an authorized service
center for assistance or repair.
z Without authorization, no organization or individual can change the mechanical,
safety, or performance design of the device.
z When using the device, observe all applicable laws and regulations and respect the
legal rights of other people.
Environmental Requirements for Using the Device
z Before connecting and disconnecting cables, stop using the device, and then
disconnect it from the power supply. Ensure that your hands are dry during
operation.
z Keep the device far from sources of heat and fire, such as a heater or a candle.
z Keep the device far from electronic appliances that generate strong magnetic or
electric fields, such as a microwave oven or a refrigerator.
z Place the device on a stable surface.
z Place the device in a cool and well-ventilated indoor area. Do not expose the device
to direct sunlight. Use the device in an area with a temperature ranging from 0°C to
40°C.
z Do not block the openings on the device with any object. Reserve a minimum space
of 10 cm around the device for heat dissipation.
z Do not place any object (such as a candle or a water container) on the device. If any
foreign object or liquid enters the device, stop using the device immediately, power
it off, remove all the cables connected to it, and then contact an authorized service
center.
2
z During thunderstorms, power off the device, and then remove all the cables
connected to it to prevent it from getting damaged due to lightning strikes.
Precautions for Using Wireless Devices
z When using the device, ensure that the antenna of the device is at least 20 cm away
from all persons.
z Do not use the device where using wireless devices is prohibited or may cause
interference or danger.
z The radio waves generated by the device may interfere with the operation of
electronic medical devices. If you are using any electrical medical device, contact
its manufacturer for the restrictions on the use of the device.
z Do not take the device into operating rooms, intensive care units (ICUs), or
coronary care units (CCUs).
Areas with Inflammables and Explosives
z Do not use the device where inflammables or explosives are stored, for example, in
a gas station, oil depot, or chemical plant. Otherwise, explosions or fires may occur.
In addition, follow the instructions indicated in text or symbols.
z Do not store or transport the device in the same box as inflammable liquids, gases,
or explosives.
Accessory Requirements
z Use only the accessories supplied or authorized by the device manufacturer.
Otherwise, the performance of the device may get affected, the warranty for the
device or the laws and regulations related to telecommunications terminals may
become null and void, or an injury may occur.
z Do not use the power adapter if its cable is damaged. Otherwise, electric shocks or
fires may occur.
z Ensure that the power adapter meets the specifications indicated on the device
nameplate.
z Ensure that the power adapter meets the requirements of Clause 2.5 in
IEC60950-1/EN60950-1 and it is tested and approved according to national or local
standards.
Safety of Children
Keep the device and its accessories out of the reach of children. Otherwise, they may
damage the device and its accessories by mistake, or they may swallow the small
components of the device, causing suffocation or other dangerous situations.
3
![](/img.php?id=1281460&img=bg7.png)
Maintenance
z If the device is not used for a long time, power it off, and then remove all the cables
connected to it.
z If any exception occurs, for example, if the device emits any smoke or unusual
sound or smell, stop using the device immediately, power it off, remove all the
cables connected to it, and then contact an authorized service center.
z Do not trample, pull, or overbend any cable. Otherwise, the cable may get damaged,
causing malfunction of the device.
z Before cleaning the device, stop using it, power it off, and then remove all the
cables connected to it.
z Use a clean, soft, and dry cloth to clean the device shell. Do not use any cleaning
agent or spray to clean the device shell.
Disposal and Recycling Information
T his symbol on the device (and any included batteries) indicates
that the device (and any included batteries) should not be
disposed of as normal household garbage. Do not dispose of your
device or batteries as unsorted municipal waste. The device (and
any batteries) should be handed over to a certified collection
point for recycling or proper disposal at the end of its life.
For more detailed information about the recycling of the device
or batteries, contact your local city office, the household waste
disposal service, or the retail store where you purchased this
device.
The disposal of this device is subject to the Waste from Electrical
and Electronic Equipment (WEEE) Directive of the European
Union. The purpose for separating WEEE and batteries from
other waste is to minimize any environmental impact and health
hazard due to the presence of hazardous substances.
Reduction of Hazardous Substances
This device is compliant with the EU Registration, Evaluation, Authorisation and
Restriction of Chemicals (REACH) Regulation (Regulation No 1907/2006/EC of the
European Parliament and of the Council) and the EU Restriction of Hazardous
Substances (RoHS) Directive (Directive 2002/95/EC of the European Parliament and
of the Council). For more information about the REACH compliance of the device,
4
visit the Web site www.huaweidevice.com/certification. You are recommended to visit
the Web site regularly for up-to-date information.
EU Regulatory Conformance
This device should be installed and operated with a minimum distance of 20 cm
between the antenna and all persons.
Български: С настоящето Huawei Technologies Co., Ltd. декларира, че
този уред съответства на основните изисквания и другите разпоредби на
Директива 1999/5/EC.
Česky: Huawei Technologies Co., Ltd., tímto prohlašuje, že toto zařízení je ve shodě se
základními požadavky a dalšími souvisejícími opatřeními směrnice 1999/5/EC.
Dansk: Huawei Technologies Co., Ltd. erklærer hermed at denne enhed er i
overensstemmelse med de obligatoriske krav og andre relevante bestemmelser i
direktiv 1999/5/EF.
Nederlands: Hierbij verklaart Huawei Technologies Co., Ltd. dat dit apparaat in
overeenstemming is met de essentiële eisen en de andere relevante bepalingen van
richtlijn 1999/5/EC.
English: Hereby, Huawei Technologies Co., Ltd. declares that this device is in
compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC.
Eesti: Käesolevaga kinnitab Huawei Technologies Co., Ltd., et see seade vastab
Direktiivi 1999/5/EÜ põhinõudmistele ja teistele asjakohastele määrustele.
Suomi: Huawei Technologies Co., Ltd. vakuuttaa täten, että tämä laite on
yhdenmukainen direktiivin 1999/5/EY olennaisten vaatimusten ja direktiivin muiden
asiaankuuluvien lausumien kanssa.
Français (Européen) : Le fabricant déclare que ce produit est conforme aux exigences
essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Deutsch: Huawei Technologies Co., Ltd. erklärt hiermit, dass dieses Produkt die
erforderlichen Bestimmungen und andere relevante Verordnungen der Richtlinie
1999/5/EG einhält.
Ελληνικά: Δια της παρούσης η Huawei Technologies Co., Ltd. δηλώνει ότι αυτή η
συσκευή συμμορφώνεται με τις βασικές απαιτήσεις και άλλες σχετικές διατάξεις της
οδηγίας 1999/5/Ε.Κ.
Magyar: Jelen nyilatkozaton keresztül a Huawei Technologies Co., Ltd. kijelenti, hogy
a készülék megfelel az EC/5/1999 Irányelv összes lényeges követelményének és
vonatkozó előírásának.
5
![](/img.php?id=1281460&img=bg9.png)
Gaeilge: Fograíonn Huawei Technologies Co., Ltd leis seo go bhfuil an fheiste seo i
gcomhlíonadh leis na fíor-riachtanais agus na forálacha eile maidir le Treoir
1999/5/AE.
Italiano: Col presente documento, Huawei Technologies Co., Ltd. dichiara che questo
dispositivo è conforme ai requisiti essenziali e alle altre disposizioni applicabili della
Direttiva 1999/5/CE.
Latviski: Ar šo Huawei Technologies Co., Ltd. paziņo, ka šī ierīce atbilst Direktīvas
1999/5/EC pamatprasībām un piemērojamajiem nosacījumiem.
Lietuviškai: Šiuo Huawei Technologies Co., Ltd. praneša, kad šis įtaisas atitinka
Direktyvos 1999/5/EC pagrindinius reikalavimus ir taikomas sąlygas.
Malti: Hawnhekk, Huawei Technologies Co., Ltd. tiddikjara li dan it-tagħmir hu
konformi mal-ħtiġijiet essenzjali u provvedimenti rilevanti oħrajn ta’ Direttiva
1999/5/KE.
Polski: Wymieniona w tym dokumencie firma Huawei Technologies Co., Ltd.
deklaruje, że niniejsze urządzenie spełnia zasadnicze wymagania w zakresie zgodności
oraz inne odnośne postanowienia Dyrektywy 1999/5/EC.
Português (Europeu) : Deste modo, a Huawei Technologies Co., Ltd. declara que este
dispositivo está em conformidade com os requisitos essenciais e outras provisões
relevantes da Directiva 1999/5/CE.
Română: Prin prezenta Huawei Technologies Co., Ltd. declară că acest dispozitiv este
conform cu cerinţele esenţiale şi alte prevederi relevante ale directivei 1999/5/CE.
Slovenčina: Huawei Technologies Co., Ltd. týmto vyhlasuje, že zariadenie je v súlade
so základnými požiadavkami a inými relevantnými predpismi Smernice 1999/5/ES.
Slovenščina: Huawei Technologies Co., Ltd. izjavlja, da je ta naprava v skladu z
bistvenimi zahtevami in drugimi ustreznimi določbami Direktive 1999/5/ES.
Español (Europeo) : Con el presente documento, Huawei Technologies Co., Ltd.
declara que este dispositivo cumple con los requisitos esenciales y con las demás
disposiciones correspondientes de la Directiva 1999/5/CE.
Svenska: Huawei Technologies Co., Ltd. förklarar härmed att denna produkt
överensstämmer med de grundläggande kraven och andra relevanta föreskrifter i
direktiv 1999/5/EG.
For the declaration of conformity, visit the Web site
www.huaweidevice.com/certification.
Notice: Observe the national local regulations in the location where the device is to be
used. This device may be restricted for use in some or all member states of the
European Union (EU).
6
![](/img.php?id=1281460&img=bga.png)
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
The antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by
Huawei Technologies Co., Ltd. may void the FCC authorization to operate this device.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.This equipment
complies with FCC radiation exposure limits set forth for an uncontrolled environment.
To maintain compliance with FCC RF exposure compliance requirements, please avoid
direct contact to the transmitting antenna during transmitting. End users must follow
the specific operating instructions for satisfying RF exposure compliance.
The shell of the device may be hot after the device is running for a long
time, which will not affect the function of the HG622.
6
![](/img.php?id=1281460&img=bgb.png)
2 Getting Started
After you connect the cables, please press down the ON/OFF button on the side of the
HG530 to power on the HG530.
After you power on the HG530, the Power indicators turns on and the ADSL indicator
blinks (for less than three minutes), which indicates that the HG530 is being activated.
After the ADSL indicator blinking, the Power and ADSL indicators keep solid on,
which indicates that the HG530 is working properly.
3 Setting the Network-Access Parameters
3.1 Accessing the Network Through the
Embedded PPP Dial-Up Software on the HG530
If you select this method for accessing the network, the HG530 starts to set up a dial-up
connection automatically after the startup. You can access the network after you power
on your computer. You do not need to install any special dial-up software on your
computer or perform dial-up operations on your computer. To configure the HG530 and
your computer for the network access, do as follows:
Step 1 Verify the HG530 and the PC have connected properly, and the PC has
obtained the IP address.
Step 2 Log in to the Web-based configuration utility of the HG530.
1. Launch the Internet Explorer on your computer. Enter http://192.168.1.1
in the address bar, and then press Enter.
2. In the displayed dialog box, enter the user name and the password, and
then click OK.
By default, both the user name and the password are admin. After the user name and
the password are verified, you can access the Web-based configuration utility.
Step 3 Enable the embedded dial-up function.
1. In the navigation tree on the left of the Web-based configuration utility,
choose Basic > WAN Setting.
2. Select a PVC number, such as 1, from the PVC drop-down combo box.
3. Enter the VPI and VCI that are provided by the network operator in the
VPI and VCI text boxes.
8
![](/img.php?id=1281460&img=bgc.png)
4. Select Yes from the Active drop-down combo box and select Routing
5.
6. ssword that are provided by the network
word text boxes, and keep the default
You need to perform the preceding operations on a computer once only. The next time
when you power on your computer, you can surf the Internet without any configuration.
from the Mode drop-down combo box.
Select PPPoE from the Encapsulation drop-down combo box.
Enter the user name and pa
operator in the Username and Pass
settings of other parameters.
7. Click Submit to save the settings.
After you complete the preceding settings, you can surf the Internet.
3.2 Accessing the Network Through the PPP
Dial-Up Software on Your Computer
If you select this method for accessing the network, you need to install and configure
the dial-up software on your computer. In addition, you need to perform dial-up
igure the HG530 and your
ection 3.1 "Accessing the Network Through the Embedded PPP Dial-Up
rop-down
re is pre-installed on certain computer operating systems. To
create a d
an example):
o display the New
4. then click Next.
ord, and then click Next.
Name, and
7. .
the dial-up connection, and then click Next.
operations on your computer upon each startup. To conf
computer for the network access, do as follows:
Step 1 Set the working mode of the HG530 to Bridge.
For details, refer to the procedure for enabling the embedded dial-up function described
in Step 2 in s
Software on the HG530" Note that Bridge is selected from the Mode d
combo box.
Step 2 Install and configure the PPP dial-up software on your computer.
The PPP dial-up softwa
ial-up connection, do as follows (taking the Windows XP operating system as
1. Choose Start > All Programs > Accessories > Communications >
Network Connections.
2. Click Create a new connection in Network Tasks t
Connection Wizard window, and then click Next.
3. Select Connect to the Internet, and then click Next.
Select Set up my connection manually, and
5. Select Connect using a broadband connection that requires a user
name and passw
6. Enter the name (as desired) of the dial-up connection in ISP
then click Next.
Select Anyone's use or My use only, and then click Next
8. Enter the user name and password provided by the network operator and
used for
9
![](/img.php?id=1281460&img=bgd.png)
9. Select Add a shortcut to this connection to my desktop, and then click
e network connection is created, to access the network,
double-click the icon for the dial-up connection, and then click Connect in the
g the Wireless Network
Finish.
An icon for the dial-up connection is displayed on the desktop of your computer.
You need to perform the preceding operations only once for creating a network
connection. After th
displayed dialog box.
4 Configurin
Connection
I less
computer to t
f a wire network adapter is installed on your computer, you can connect you
he HG530 through a wireless connection.
by different companies vary from
each other. For details, see the installation guide provided by the
The hardware installation methods and driver installation methods of
wireless network adapters provided
wireless network adapter provider.
Setting Up a Wireless Connection Through the WPS Button
The HG530 supports the Wi-Fi Protected Setup (WPS) function. If your network
adapter also supports the WPS function, you can use the WPS function to set up a
connectio
Step 1 function, and set the wireless network name and
WP
figuration utility,
n combo
rop-down combo box.
the settings.
wireless connection between your PC and the HG530 quickly. To set up a wireless
n, do as follows:
Enable the wireless network
access password of the HG530, do as follows (taking the authentication type
A-PSK as an example):
1. In the navigation tree on the left of the Web-based con
choose Basic > Wireless Lan.
2. Select the Enable option button of Access Point.
3. Enter a wireless network name in the SSID text box.
4. Select WPA-PSK from the Authentication Type drop-dow
box.
5. Select AES from the Encryption d
6. Enter an access password in the Pre-Shared Key text box.
7. Click Submit to save
Step 2 Press the WPS button of the HG530 to enable the HG530 to enter the WPS
negotiation state.
10
Step 3 Enable the WPS negotiation function of the wireless network adapter on your
PC within two minutes, and then wait for a moment (typically 10s and at most
120s).
The WPS indicator of the HG530 becomes on from the blinking
the HG530 is connected to your PC through the WLAN.
state, indicating that
This state lasts 300s. Then the
unction, you can set up a wireless
set up a wireless
system of your
wireless
Step 2
To set the wi cess password, do as follows (taking the
authentic
,
n combo
Step 3
2.
nt
WPS indicator turns off.
Setting Up a Wireless Connection Manually
If your network adapter does not support the WPS f
connection between your PC and the HG530 manually. To manually
connection, use either of the following methods:
z Use the tool provided by your network adapter.
For details, see the user guide of your network adapter.
z Use the wireless configuration software provided by the operating
PC.
This section takes Windows XP as an example and describes how to set up a
connection between your PC and the HG530 manually, do as follows:
Step 1 Log in to the Web-based configuration utility.
Set the wireless network name and access password of the HG530.
reless network name and the ac
ation type WPA-PSK as an example):
1. In the navigation tree on the left of the Web-based configuration utility
choose Basic > Wireless Lan.
2. Select the Enable option button of Access Point.
3. Enter a wireless network name in the SSID text box.
ntication Type drop-dow
4. Select WPA-PSK from the Authe
box.
5. Select AES from the Encryption drop-down combo box.
6. Enter an access password in the Pre-Shared Key text box.
7. Click Submit to save the settings.
Enable the wireless configuration service provided by Windows XP.
1. Right-click My Computer, and then choose Manage from the shortcut
menu.
In the Computer Management window, choose Computer
Management (Local) > Services and Applications >Services.
3. From the services listed in the right pane of the Computer Manageme
window, right-click Wireless Zero Configuration, and then choose
Properties from the shortcut menu.
11
![](/img.php?id=1281460&img=bgf.png)
4. In the Wireless Zero Configuration Properties (Local Computer)
Step 4 Con etwork connection on your computer.
k
4. e my wireless network settings.
t corner of the window.
hat is preset in
After the password is verified, Connected appears on the icon of the wireless network
is connected to the
8. Close the Wireless Network Connection dialog box.
9. In the Wireless Network Connection Properties dialog box, click OK.
dialog box, check whether Service status is Started. If not, click the
Start button.
5. Click OK to close the dialog box. Then, close the Computer
Management window.
figure the wireless n
1. Choose Start > All Programs > Accessories > Communications >
Network Connections.
dow, right-click Wireless Networ
2. In the Network Connections win
Connection to display a shortcut menu, and then choose Properties from
the shortcut menu.
3. In the Wireless Network Connection Properties dialog box, select
Wireless Networks.
Select Use Windows to configur
5. Click View Wireless Networks.
6. Select the wireless network that is configured in Step 2, and then click
Connect in the lower righ
7. In the displayed dialog box, enter the access password t
Step 2, and then click Connect.
in the wireless network list, which indicates that the computer
HG530 through a wireless connection.
5 Configuring the HG530
5.1 Changing the Administrator Password Used
for Logging In to the Web-Based Configuration
Utility
For safety reasons or to make the password easy to remember, you can change the
administrator password for login after logging in to the Web-based configuration
utility.
Step 2
To change the pa word, do as follows: ss
Step 1 Log in to the Web-based configuration utility.
Choose Tools > System Management in the navigation tree to display the
system management page.
12
![](/img.php?id=1281460&img=bg10.png)
Step 3 Click to display a dialog box.
Step 4 Enter the old password in the Old Password text box. Enter the new
password in the New Password text box. Then enter the new password again
in the Retype to confirm text box for confirmation.
Step 5 Cli
After you ch
logging in t
configuration
ck Submit to save the settings.
ange the password successfully, the current page jumps to the page for
o the Web-based configuration utility. To log in to the Web-based
utility, enter the new password, and then click OK.
u can
restore the default settings of the HG530 by pressing and holding the
Reset button for over six seconds. Then, the user name and password that
st. Therefore, use this function with caution.
If you forget the user name or password that has been changed, yo
are used for logging in to the Web-based configuration utility are restored
to default values. After you restore the default settings, however, your
customized data is lo
5.2 Enabling or Disabling the Wireless
Network Function
You can quickly enable or disable the wireless network function by pressing the
WLAN button on the HG530. To enable the wireless network function, press and hold
the WLAN button for over one second, and then release the button. You can disable the
wireless network function in the same way. The WLAN indicato
wireless network function is enabled.
r shows whether the
ti hrough the
rk function, do
Step 1 Log in to the Web-based configuration utility.
In addi on, you can enable or disable the wireless network function t
Web-based configuration utility. To enable or disable the wireless netwo
as follows:
Step 2 In the navigation tree on the left, choose Basic > Wireless Lan.
Step 3 Select the Enable or Disable option button of Access Point.
Step 4 Click Submit to save the settings.
Changing the Wireless Network Name and
5.3
the Access Password
To chan e the name and access password for the wireless ngetwork, do as follows
th
Step 1 Log in to the Web-based configuration utility.
(taking e authentication type WPA-PSK as an example):
13
![](/img.php?id=1281460&img=bg11.png)
Step 2 In the navigation tree on the left, choose Basic > Wireless Lan.
tication Type drop-down combo box.
Sel
Step 6 En
Step 7 Cli
Step 3 Enter a wireless network name in the SSID text box.
Step 4 Select WPA-PSK from the Authen
Step 5 ect TKIP from the Encryption drop-down combo box.
ter an access password in the Pre-Shared Key text box.
ck Submit to save the settings.
application, refer to the operation guide provided by the application
provider.
The WPS applications may vary with different types of wireless network
adapters. For details about the configuration and operations of the WPS
5.4 Changing the IP Address Used for Logging
In to the Web-Based Configuration Utility
e
To change the IP address, do as follows:
navigation tree to display the LAN
E
en
Step 4 C
To mak the login IP address easy to remember, you can change the IP address after
logging in to the Web-based configuration utility.
Step 1 Log in to the Web-based configuration utility.
Step 2 Choose Basic > LAN Setting in the
settings page.
Step 3 nter a new IP address as desired in the Main IP Address text box. Then,
ter a subnet mask in Main Subnet Mask.
lick Submit to save the settings.
ge the IP
address successfully, you need to launch the Internet Explorer, and then
enter the new IP address in the address bar. Ensure that the IP address of
the computer is in the same network segment as that of the HG530 so that
the computer can access the Web-based configuration utility.
To log in to the Web-based configuration utility after you chan
5.5 Restoring Default Settings
14
![](/img.php?id=1281460&img=bg12.png)
After you restore the default settings, your customized data is lost.
Therefore, use this function with caution.
You can quickly restore the default settings of the HG530 by pressing the Reset button
on the rear panel. To restore the default settings, press and hold the Reset button for
s
you can r iguration
o the Web-based configuration utility, do as
tep 3 Click Restart.
After the preceding operations, the current page jumps to the login page. You can log in
to the Web-based configuration utility by entering the default user name and password
that are admin.
over six econds after the HG530 is powered on, and then release the button. In addition,
estore the default settings of the HG530 through the Web-based conf
utility. T restore the default settings through
follows:
Step 1 Log in to the Web-based configuration utility, and then choose Tools >
Reboot in the navigation tree to display the reboot page.
Step 2 Select Factory Default Settings.
S
15
![](/img.php?id=1281460&img=bg13.png)
6 FAQs
How can I quickly enable or disable the wireless network function?
Press and hold the WLAN button for over one second, and then release the button to
enable or disable the wireless network function. The WLAN indicator shows
whether the wireless network function is enabled.
How can I quickly restore the default settings of the terminal?
To restore the default settings, press and hold the Reset button on the rear panel for
over six seconds after the HG530 is powered on, and then release the button.
What can I do if I cannot access the Internet through the terminal?
Step 1 Check whether the Power indicator on the terminal is solid on.
If the Power indicator is off, perform further checks as follows:
1. Ensure that the terminal is turned on.
2. Ensure that electricity comes from the socket and that the power input
from the socket meets the requirements described on the label of the
terminal power adapter. If the voltage is unsteady, for example, if the
voltage is too high or too low, do not use the terminal. Wait until the
voltage restores to its normal level, and then use the terminal.
3. Ensure that the terminal is properly connected to the socket through
the power adapter.
If the Power indicator is still off, contact an authorized maintenance center.
Step 2 After powering on the terminal, wait for about three minutes. Then, check
whether the ADSL indicator on the terminal is solid on.
If the ADSL indicator blinks for a long time, perform further checks as follows:
1. Ensure that telephone lines are properly connected. Pay special
attention to the connections between the telephone lines and the
splitter.
2. Ensure that the terminal or telephone lines are far from the electric
appliances that generate strong magnetic or electric fields. Replace
telephone lines when necessary.
If the ADSL indicator still blinks and does not turn solid on, contact your network
operator.
Step 3 Check whether the LAN indicator of the terminal is on.
If the LAN indicator is off, perform further checks as follows:
1. Ensure that the network adapter of the computer is enabled.
2. Ensure that the network cable between the terminal and the computer
16
is properly connected. Remove and then insert the network cable or
replace the network cable when necessary.
If the LAN indicator is still off, contact an authorized maintenance center.
Step 4 Check whether the driver for the network adapter is properly installed.
Take a computer that runs Windows XP as an example. To check whether
the driver for the network adapter is installed, do as follows:
1. On the desktop, right-click My Computer, and then choose Manage.
2. In the navigation tree of the Computer Management window,
choose Device Manager.
3. In the right pane of the Computer Management window, click
Network adapters to view the information about the network adapter
of the computer.
If no network adapter is found or if a question mark (?) or an exclamation mark (!) is
displayed next to the icon of the network adapter, you can infer that the driver for
the network adapter is not properly installed. In this case, re-install the driver for the
network adapter of the computer.
Step 5 Ensure that you have entered the correct user name and user password that
are required by the PPP dial-up software.
The user name and the user password are provided by your network operator.
Step 6 Check whether you can use the PPP dial-up software to dial successfully.
If you cannot use the PPP dial-up software to dial successfully, perform further
checks as follows:
1. Stop the PPP dial-up software and then power off the terminal. After
five minutes, power on the terminal, and then use the PPP dial-up
software to dial again.
2. Restore the default settings of the terminal.
If the problem persists, contact your network operator.
Step 7 Check whether the proxy server of the Web browser is correctly
configured. Take the Internet Explorer installed on a computer that runs
Windows XP as an example. To check whether the proxy server of the
Web browser is correctly configured, do as follows:
1. Launch the Internet Explorer.
2. Choose Tools > Internet Options.
3. In the Internet Options dialog box, click the Connections tab.
4. In the Local Area Network (LAN) settings group box, click LAN
Settings.
5. In the Proxy server group box of the Local Area Network (LAN)
Settings dialog box, ensure that the Use a proxy server for your
LAN (These settings will not apply to dial-up or VPN
connections). check box is cleared.
17
![](/img.php?id=1281460&img=bg15.png)
Step 8 Try to access multiple Web sites to check whether the terminal can access
these Web sites.
If the terminal still cannot access Web sites, contact your network service
provider.
What can I do if Web pages often cannot be displayed during Web page browsing
and can be displayed after the terminal is restarted?
Step 1 Ensure that the terminal and other devices, such as telephones or fax
machines, are connected to telephone lines through a splitter.
For details about how to install a splitter, see the related description in the manual.
Step 2 Ensure that telephone lines are properly connected.
If the telephone lines are improperly connected, the stability of the network
connection is affected.
Step 3 Check the positions of your terminal and your computer. Ensure that they
are far from electric appliances, such as microwave ovens, refrigerators,
or cordless telephones, that generate strong magnetic or electric fields.
If the problem persists, contact your service provider.
What can I do if sometimes the terminal cannot access the Internet through a WLAN
connection or if the WLAN connection is unsteady?
Step 1 Check the positions of your terminal and your computer. Ensure that they
are far from the electric appliances, such as microwave ovens,
refrigerators, or cordless telephones, that generate strong magnetic or
electric fields.
Step 2 Place your terminal in an open area.
Although radio signals can pass through obstacles, the transmission effects of
WLAN radio signals are affected if radio signals pass through too many obstacles,
such as cement or wooden walls.
Step 3 Place your computer close to your terminal.
If your computer is far from your terminal, the effects of the WLAN are affected.
Step 4 Place your terminal and computer in another direction.
Step 5 Do not use your terminal to access the WLAN during thunderstorms.
After a broadband terminal is installed, does Internet access degrade call quality or
do telephone calls lower the Internet access rate?
No. The terminal uses the frequency division multiplexing (FDM) and splitter
technologies to separate voice signals from data signals. Although the two types of
signals are transmitted through one telephone line, they are carried by different
frequency bands. Therefore, they do not interfere with each other. In this case, you
18
![](/img.php?id=1281460&img=bg16.png)
can make a telephone call and access the Internet simultaneously, without degrading
call quality or lowering the Internet access rate.
7 Appendix
7.1 Indicators
Indicator Status Used to…
On The HG530 is powered on. Power
Off The HG530 is powered off.
Blinking The HG530 is being activated.
On The HG530 is activated.
ADSL
Off The HG530 is powered off.
Blinking z The HG530 works in routing mode.
z The WAN connection is set up.
z Data is being transmitted.
On z The HG530 works in routing mode.
z The WAN connection is set up.
z No data is being transmitted.
Internet
Off z The HG530 works in bridge mode or in routing mode.
z No WAN connection is set up.
Blinking z The wireless network function is enabled.
z Data is being transmitted through the WLAN.
On z The wireless network function is enabled.
z No data is being transmitted through the WLAN.
WLAN
Off The wireless network function is disabled.
19
![](/img.php?id=1281460&img=bg17.png)
Indicator Status Used to…
Blinking The HG530 is attempting to set up a wireless connection
with a wireless client (such as a PC on which a wireless
network adapter is installed) through the WPS function.
This state lasts no more than 120s.
On A wireless connection is set up between the HG530 and a
wireless client through the WPS function.
This state lasts 300s.
WPS
Off The WPS function is disabled.
Blinking Data is being transmitted through the Ethernet interface.
On The Ethernet connection is set up.
LAN1 –
LAN4
Off The Ethernet connection is not set up.
7.2 Interfaces and Buttons
No. Description
1 WLAN button, which is used to enable or disable wireless network function
quickly.
2 WPS button, which is used to enable the WPS negotiation function.
3 Power button, which is used to power on or off the HG530.
4 Power interface, which is used to connect the HG530 to the power adapter.
5 Reset button, which is used to restore the factory settings of the HG530.
6 – 9 LAN interfaces, which are used to connect the HG530 to the Ethernet
interface on the computer.
10 DSL interface, which is used to connect HG530 to the MODEM interface on
the splitter or to the telephone jack on the wall.
20
![](/img.php?id=1281460&img=bg18.png)
7.3 Default Settings
Parameter Setting
IP address of the LAN interface 192.168.1.1
Subnet mask of the LAN interface 255.255.255.0
User name used for logging in to the
Web-based configuration utility
admin
Password used for logging in to the
Web-based configuration utility
admin
DHCP server function Enable
Wireless network function Enable
7.4 Technical Specifications
Item Specification
Power supply 12 V DC, 0.5 A
Power
consumption
< 6 W
Ambient
temperature for
operation
0°C to 40°C (32°F to 104°F)
Ambient humidity
for operation
5% to 95%, non-condensing
Dimensions (L ×
W × H)
156.4 mm % 52 mm % 124.3 mm
Weight About 245 g
ADSL standards ITU G.992.1 (G.dmt) Annex A
ITU G.994.1 (G.hs)
ITU ANSI T1.413 Issue 2
ADSL2 standard ITU G.992.3 (G.dmt.bis) Annex A
ITU G.992.3 (G.dmt.bis) Annex L
ADSL2+ standard ITU G.992.5 (G.dmt.bitplus) Annex A
Standards
WLAN standard 802.11b, 802.11g, 802.11n (2.4 GHz)
21
![](/img.php?id=1281460&img=bg19.png)
Item Specification
G.dmt
T1.413
z Maximum downlink rate: 8 Mbit/s
z Maximum uplink rate: 896 kbit/s
DSL transmission
rates
G.992.5 (ADSL2+) z Maximum downlink rate: 24 Mbit/s
z Maximum uplink rate: 1024 kbit/s
802.11b 1 Mbit/s, 2 Mbit/s, 5.5 Mbit/s, and 11
Mbit/s
802.11g 6 Mbit/s, 9 Mbit/s, 12 Mbit/s, 18
Mbit/s, 24 Mbit/s, 36 Mbit/s, 48 Mbit/s,
54 Mbit/s
Wireless
transmission rates
802.11n 6.5 Mbit/s, 13.0 Mbit/s, 13.5 Mbit/s,
19.5 Mbit/s, 26.0 Mbit/s, 27.0 Mbit/s,
39.0 Mbit/s, 40.5 Mbit/s, 52.0 Mbit/s,
54.0 Mbit/s, 58.5 Mbit/s, 65.0 Mbit/s,
81.0 Mbps, 108.0 Mbit/s, 117.0 Mbit/s,
121.5 Mbit/s, 135.0 Mbit/s
22
HUAWEI TECHNOLOGIES CO., LTD.
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
www.huawei.com
Part Number: 202168
