Huawei Technologies HG531V1 300Mbps Wireless ADSL2+Router User Manual
Huawei Technologies Co.,Ltd 300Mbps Wireless ADSL2+Router
User Manual
1
HG531 V1 300Mbps Wireless ADSL2+ Router
Quick Start
1 Connecting Cables
If you have subscribed to digital subscriber line (DSL) broadband, you can connect
the HG531 V1 to a telephone port for Internet access.
Follow the steps in the following figure to connect devices properly.
When configuring the HG531 V1 for the first time, use an Ethernet cable to
connect the HG531 V1 to a computer.
1 Telephone wall jack 2 Splitter 3 Telephone
4 Desktop computer 5 Power adapter 6 Set-top Box
7 Laptop computer 8 Smart Phone 9 Pad
a LINE port b MODEM port c PHONE port
MODEM
PHONE
LINE
1
23
4
5
6
7
8
9
a
b
c
2
2 Powering On
To power on the HG531 V1, press its power button.
After the HG531 V1 is powered on, the HG531 V1 indicator turns on. The following
table lists how the indicators behave when the HG531 V1 is operating correctly. If the
indicators do not behave as expected, ensure that everything is plugged in correctly.
Indicator Expected State Description
Power Steady green The HG531 V1 is powered on.
ADSL
Blinking green A DSL connection is being activated.
Steady green A digital subscriber line (DSL) connection has been
set up and activated.
Internet
Blinking green The HG531 V1 is connected to the Internet in router
mode, and data is being transmitted.
Steady green The HG531 V1 is connected to the Internet in router
mode, but no data is being transmitted.
Off
The HG531 V1 is in router mode, but not connected
to the Internet.
The HG531 V1 is in bridge mode.
WLAN
Blinking green The HG531 V1 has WLAN enabled, and data is
being transmitted.
Steady green The HG531 V1 has WLAN enabled, but is not
transmitting data.
WPS
Blinking green
The HG531 V1 is attempting to connect to a
wireless client over the WLAN using the WPS
function.
The WPS indicator blinks for 120 seconds or less.
Steady green
The HG531 V1 is connected to a wireless client,
such as a computer with a wireless network
adapter, over the WLAN using the Wi-Fi Protected
Setup (WPS) function.
The WPS indicator is steady on for 300 seconds.
3
3 Setting Dial-Up Connection Parameters
Configuring a Dial-Up Connection to Access the Internet
The HG531 V1 works in bridge mode by default. You need to install and configure a
dial-up connection on your computer, and perform it each startup.
Before setting dial-up connection parameters, verify that the HG531 V1 is correctly
connected to your computer and you have the dial-up connection account name and
password provided by your Internet service provider (ISP). This section
demonstrates how to set up a Point-to-Point Protocol over Ethernet (PPPoE)
connection on Windows.
On Windows 7
1. Choose Start > Control Panel > Network and Internet > Network and
Sharing Center.
2. Under Change your networking settings, click Set up a new connection
or network.
3. In the Set Up a Connection or Network window, select Connect to the
Internet and click Next.
4. Click Broadband (PPPoE).
5. In User name and Password, enter the dial-up connection account name
and password provided by your ISP. In Connection name, name the dial-up
connection. Select or deselect Allow other people to use this connection.
Then click Connect.
6. Return to the Network and Sharing Center page. Click Change adapter
settings. Right-click the icon for the dial-up connection you just set up and
choose Create Shortcut from the shortcut menu. In the displayed dialog box,
click Yes.
LAN1 ~
LAN4
Blinking green The LAN port is connected to an Ethernet device
with a network cable, and data is being transmitted.
Steady green
The LAN port is connected to an Ethernet device
(such as a computer) with a network cable, but no
data is being transmitted.
Indicator Expected State Description
4
On Windows Vista
1. Choose Start > Control Panel > Network and Internet > Network and
Sharing Center.
2. Click Set up a connection or network.
3. In the displayed window, select Connect to the Internet and click Next.
4. Click Broadband (PPPoE).
5. In User name and Password, enter the dial-up connection account name
and password provided by your ISP. In Connection name, name the dial-up
connection. Select or deselect Allow other people to use this connection.
Then click Connect.
6. Return to the Network and Sharing Center page, Click Manage network
connections. Right-click the icon for the dial-up connection you just set up
and choose Create Shortcut from the shortcut menu. In the displayed dialog
box, click Yes.
On Windows XP
1. Choose Start > Control Panel > Network and Internet Connections >
Network Connections.
2. Under Network Tasks, click Create a New Connection.
3. In the Network Connection Wizard dialog box, click Next.
4. Select Connect to the Internet and click Next.
5. Select Set up my connection manually and click Next.
6. Select Connect using a broadband connection that requires a user name
and password and click Next.
7. In ISP Name, name the dial-up connection. Click Next.
8. Select Anyone's use or My use only and click Next.
9. Enter the dial-up connection account name and password provided by your
ISP and click Next.
10. Select Add a shortcut to this connection to my desktop and click Finish.
After you successfully set up a PPPoE connection, a dial-up connection icon is
displayed on your computer desktop.
To connect to the Internet, double-click the dial-up connection icon. In the displayed
dialog box, click Connect.
5
Configuring a Wireless Account
Before you log in to the HG531 V1 web management page, ensure that the computer
used for the login is connected to the HG531 V1 and has been configured to
automatically obtain an IP address or assigned with a static IP address.
The HG531 V1 provides an intuitive web management page where you can view or
set the HG531 V1 parameters. After you log in to the web management page, you will
see a configuration wizard page used to configure the wireless account.
The default SSID and WLAN Key printed on the HG531 V1's rear panel are
unique and secure. If you do not want to change them, click Next.
For security reasons or to make the password easy to remember, you can change
the wireless network name and password as follows:
1. Open a browser. In the address box, enter 192.168.1.1. Press Enter.
2. Enter the login user name (user by default) and password (user by default).
Click Login.
3. On the Quick Configure Router: Wireless Network page, enter your
desired WLAN name and password in WLAN SSID and Key, and click Next.
4 Wireless Connection Setup
The wireless configuration software provided by Windows is used as an example to
describe how to set up a wireless connection.
Before setting wireless connection, find the SSID and WLAN Key printed on the label
on the HG531 V1's rear panel.
On Windows 7
1. Click in the lower right corner of your desktop.
2. From the wireless network list, select the WLAN provided by the HG531 V1.
Click Connect.
3. In the displayed dialog box, enter the WLAN password and click OK.
4. In the wireless network list, check the WLAN connection status. If the status is
Connected, the computer is wirelessly connected to the HG531 V1.
On Windows Vista
1. Choose Start > Control Panel > Network and Internet > Network and
Sharing Center > Manage wireless networks.
6
2. In the Connecting to a network window, double-click the WLAN provided by
the HG531 V1.
3. In the displayed dialog box, enter the password and click Connect.
4. In the wireless network list, check the WLAN connection status. If the status is
Connected, the computer is wirelessly connected to the HG531 V1.
On Windows XP
1. Click in the lower right corner of your desktop.
2. From the wireless network list, select the WLAN provided by the HG531 V1.
Click Connect.
3. In the displayed dialog box, enter the WLAN password and click Connect.
4. In the wireless network list, check the WLAN connection status. If the status is
Connected, the computer is wirelessly connected to the HG531 V1.
5 Security Maintenance Guide
Changing the Web Management Page User Name and
Password
The correct user name and password are required to log in to the web management
page. Regular changes to the web management page user name and password can
effectively prevent unauthorized users from logging in and modifying important
parameters.
1. Log in to the web management page.
2. In the navigation tree, choose Maintenance > Account.
3. In New user name, enter your desired user name.
4. In Current password, enter the currently used password.
5. In New password, enter the new password you specified. In Confirm
password enter the new password again.
6. Click Submit.
When modify password successfully, the page will jump to the login page, enter the
new user name and password to log in.
7
If you forget the password , you can press and hold the Reset button for 6
seconds or more, then the user name and password of the Web
management page will back to factory value. This operation will make your
own configuration data lost, please perform this operation with caution.
Changing Your WLAN Name and Password
WLAN access requires the WLAN name and password. To improve your WLAN
security, regularly change your WLAN name and password.
1. Log in to the web management page.
2. In the navigation tree, choose Basic > WLAN.
3. On the displayed page, enable your WLAN.
4. On the Wireless Settings area, enter your desired WLAN name and
password in SSID and WPA pre-shared key, and click Submit.
6 Safety information
This section contains important information about the operation of your device. It also
contains information about how to use the device safely. Read this information
carefully before using your device.
Electronic device
Do not use your device if using the device is prohibited. Do not use the device if doing
so causes danger or interference with other electronic devices.
Interference with medical equipment
> Follow rules and regulations set forth by hospitals and health care facilities. Do
not use your device where prohibited.
> Some wireless devices may affect the performance of hearing aids or
pacemakers. Consult your service provider for more information.
> Pacemaker manufacturers recommend that a minimum distance of 15 cm be
maintained between a device and a pacemaker to prevent potential interference
with the pacemaker. If using a pacemaker, hold the device on the side opposite
the pacemaker and do not carry the device in your front pocket.
Areas with flammables and explosives
> Do not use the device where flammables or explosives are stored (in a gas
station, oil depot, or chemical plant, for example). Using your device in these
environments increases the risk of explosion or fire. In addition, follow the
instructions indicated in text or symbols.
8
> Do not store or transport the device in containers with flammable liquids, gases,
or explosives.
Operating environment
> Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the
device in these environments may result in circuit malfunctions.
> Before connecting and disconnecting cables, stop using the device and
disconnect it from the power supply. Ensure that your hands are dry during
operation.
> Place the device on a stable surface.
> Keep the device away from electronic appliances that generate strong magnetic
or electric fields, such as a microwave oven or refrigerator.
> During thunderstorms, power off your device and remove all cables connected
to it to protect against lightning strikes.
> Do not use your device during thunderstorms to protect your device against any
danger caused by lightning.
> Ideal operating temperatures are 0 °C to 40 °C. Extreme heat or cold may
damage your device or accessories.
> Keep the device and accessories in a well-ventilated and cool area away from
direct sunlight. Do not enclose or cover your device with towels or other objects.
Do not place the device in a container with poor heat dissipation, such as a box
or bag.
> To protect your device or accessories from fire or electrical shock hazards, avoid
rain and moisture.
> Keep the device away from sources of heat and fire, such as a heater,
microwave oven, stove, water heater, radiator, or candle.
> Do not place any object, such as a candle or a water container, on the device. If
any foreign object or liquid enters the device, immediately stop using it, power it
off, and remove all cables connected to it. Then, contact an authorized service
center.
> Observe local laws and regulations, and respect the privacy and legal rights of
others.
> Do not block device openings. Reserve a minimum of 10 cm around the device
to dissipate heat.
> Stop using your device or applications for a while if the device is overheated. If
skin is exposed to an overheated device for an extended period, low
temperature burn symptoms, such as red spots and darker pigmentation, may
occur.
> Do not touch the device's antenna. Otherwise, communication quality may be
reduced.
> Do not allow children or pets to bite or suck the device or accessories. Doing so
may result in damage or explosion.
96722330_02
9
> The device should be installed and operated with a minimum distance of 20 cm
between the radiator and your body.
> Keep the device in a place with good reception. The distance between the
device and other metal materials (such as metal brackets or metal doors and
windows) should be greater than 25 cm and the distance between the device
should be greater than 30 cm.
Child's safety
> Comply with all precautions with regard to child's safety. Letting children play
with the device or its accessories may be dangerous. The device includes
detachable parts that may present a choking hazard. Keep away from children.
Accessories
> Using an unapproved or incompatible power adapter, charger or battery may
cause fire, explosion or other hazards.
> Choose only accessories approved for use with this model by the device
manufacturer. The use of any other types of accessories may void the warranty,
may violate local regulations and laws, and may be dangerous. Please contact
your retailer for information about the availability of approved accessories in
your area.
Power adapter safety
> The power plug is intended to serve as a disconnect device.
> For pluggable devices, the socket-outlet shall be installed near the devices and
shall be easily accessible.
> Unplug the power adapter from electrical outlets and the device when not in use.
> Do not drop or cause an impact to the power adapter. If it is damaged, take it to
an authorized service center for inspection.
> If the power cable is damaged (for example, the cord is exposed or broken), or
the plug loosens, stop using it at once. Continued use may lead to electric
shocks, short circuits, or fire.
> Do not touch the power cord with wet hands or pull the power cord to disconnect
the power adapter.
> Do not touch the device or the power adapter with wet hands. Doing so may lead
to short circuits, malfunctions, or electric shocks.
> If your power adapter has been exposed to water, other liquids, or excessive
moisture, take it to an authorized service center for inspection.
> Ensure that the power adapter meets the requirements of Clause 2.5 in
IEC60950-1/EN60950-1 and has been tested and approved according to
national or local standards.
Cleaning and maintenance
> During storage, transportation, and operation of the device, keep it dry and
protect it from collision.
10
> Keep the device and accessories dry. Do not attempt to dry it with an external
heat source, such as a microwave oven or hair dryer.
> Do not expose your device or accessories to extreme heat or cold. These
environments may interfere with proper function and may lead to fire or
explosion.
> Avoid collision, which may lead to device malfunctions, overheating, fire, or
explosion.
> If the device is not going to be used for an extended period of time, power it off,
and remove all cables connected to it.
> If anything unusual occurs (for example, if the device emits smoke or any
unusual sound or smell), immediately stop using it, power it off, remove all
cables connected to it, and contact an authorized service center.
> Do not trample, pull, or excessively bend any cable. Doing so may damage the
cable, causing the device to malfunction.
> Before you clean or maintain the device, stop using it, stop all applications, and
disconnect all cables connected to it.
> Do not use any chemical detergent, powder, or other chemical agents (such as
alcohol and benzene) to clean the device or accessories. These substances
may cause damage to parts or present a fire hazard. Use a clean, soft, and dry
cloth to clean the device and accessories.
> Do not place magnetic stripe cards, such as credit cards and phone cards, near
the device for extended periods of time. Otherwise the magnetic stripe cards
may be damaged.
> Do not dismantle or remanufacture the device and its accessories. This voids
the warranty and releases the manufacturer from liability for damage. In case of
damage, contact an authorized service center for assistance or repair.
Disposal and recycling information
This symbol (with or without a solid bar) on the device, batteries (if
included), and/or the packaging, indicates that the device and its
electrical accessories (for example, a headset, adapter, or cable) and
batteries should not be disposed of as household garbage. These items
should not be disposed of as unsorted municipal waste and should be
taken to a certified collection point for recycling or proper disposal.
For more detailed information about device or battery recycling, contact your local
city office, household waste disposal service, or retail store.
Disposal of the device and batteries (if included) is subject to WEEE Directive Recast
(Directive 2012/19/EU) and Battery Directive (Directive 2006/66/EC). The purpose of
separating WEEE and batteries from other waste is to minimize the potential
environmental impacts and human health risk of any hazardous substances that may
be present.
Reduction of hazardous substances
This device is compliant with the REACH Regulation [Regulation (EC) No 1907/
2006] and RoHS Directive Recast (Directive 2011/65/EU). Batteries (if included) are
11
compliant with the Battery Directive (Directive 2006/66/EC). For up-to-date
information about REACH and RoHS compliance, please visit the web site
www.huaweidevice.com/certification.
EU regulatory conformance
Statement
Hereby, Huawei Technologies Co., Ltd. declares that this device is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the web site www.huaweidevice.com/
certification.
The following marking is included in the product:
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is used.
This device may be restricted for use, depending on the local network.
Restrictions in the 2.4 GHz band:
Norway: This subsection does not apply for the geographical area within a radius of
20 km from the centre of Ny-Ålesund.
FCC Regulatory Compliance
FCC statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
0979
12
this device must accept any interference received, including interference that may
cause undesired operation.
Caution: Any changes or modifications to this device not expressly approved by
Huawei Technologies Co., Ltd. for compliance could void the user's authority to
operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter. This equipment should be installed
and operated with a minimum distance of 20 centimeters between the radiator and
your body.
FCC-PART 68
> This equipment complies with Part 68 of the FCC rules and the requirements
adopted by the ACTA. On the back of this equipment is a label that contains,
among other information, a product identifier in the format US:
HAUDL01BHG531V1
> It uses the following USOC jacks: RJ-45, RJ11.
> A plug and jack used to connect this equipment to the premises wiring and
telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA.
> A compliant telephone cord and modular plug is provided with this product. It is
designed to be connected to a compatible modular jack that is also compliant.
See installation instructions for details. If this equipment, the 300Mbps Wireless
ADSL2+ Router , causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of service
may be required. But if advance notice isn’t practical, the telephone company
will notify the customer as soon as possible. Also, you will be advised of your
right to file a complaint with the FCC if you believe it is necessary.
> The telephone company may make changes in its facilities, equipment,
operations or procedures that could affect the operation of the equipment. If this
happens the telephone company will provide advance notice in order for you to
make necessary modifications to maintain uninterrupted service.
> If trouble is experienced with this equipment, 300Mbps Wireless ADSL2+
Router, for repair or warranty information. please contact: Futurewei
Technologies, Inc. Phone: +1 469-277-5852
> If the equipment is causing harm to the telephone network, the telephone
company may request that you disconnect the equipment until the problem is
resolved.
> If your home has specially wired alarm equipment connected to the telephone
line, ensure the installation of this device. does not disable your alarm
equipment. If you have questions about what will disable alarm equipment,
consult your telephone company or qualified installer.
> Connection to party line service is subject to state tariffs. Contact the state public
utility commission, public service commission or corporation commission for
information.
13
Electrical Safety Advisory
Telephone companies report that electrical surges, typically lightning transients, are
very destructive to customer terminal equipment connected to AC power sources.
This has been identified as a major nationwide problem.
Therefore it is advised that this equipment be connected to AC power through the use
of a surge arrestor or similar protection device.
Warnings: This is a Class B product. In a domestic environment this product may
cause radio interference, in which case the user may be required to take adequate
measures. Adequate measures include increasing the physical distance between
this product and other electrical devices.
7 Obtaining More Information
Thanks for purchasing the HG531 V1 300Mbps Wireless ADSL2+ Router (HG531 V1
for short).
This quick start guide will show you how to connect your HG531 V1 to a network and
access the Internet. The figures in this guide are for reference only. The appearance
and display features may vary slightly depending on the actual product version.
For the full user guide, visit http://consumer.huawei.com/en/. Enter HG531 V1 in the
website search box and press Enter.
Please visit www.huaweidevice.com/worldwide/support/hotline for recently updated
hotline and email address in your country or region.
8 Legal Notice
Copyright © Huawei Technologies Co., Ltd. 2013. All
rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any means
without prior written consent of Huawei Technologies Co., Ltd. and its affiliates
("Huawei").
The product described in this manual may include copyrighted software of Huawei
and possible licensors. Customers shall not in any manner reproduce, distribute,
modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or
sublicense the said software, unless such restrictions are prohibited by applicable
laws or such actions are approved by respective copyright holders.
Trademarks and Permissions
, , and are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
14
Other trademarks, product, service and company names mentioned may be the
property of their respective owners.
Notice
Some features of the product and its accessories described herein rely on the
software installed, capacities and settings of local network, and therefore may not be
activated or may be limited by local network operators or network service providers.
Thus, the descriptions herein may not exactly match the product or its accessories
which you purchase.
Huawei reserves the right to change or modify any information or specifications
contained in this manual without prior notice and without any liability.
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS
REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT
SHALL HUAWEI BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE,
DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS REGARDLESS OF
WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY
FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH
A LIMITATION) OF HUAWEI ARISING FROM THE USE OF THE PRODUCT
DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE AMOUNT PAID BY
CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations and
be responsible to obtain all necessary governmental permits and licenses in order to
export, re-export or import the product mentioned in this manual including the
software and technical data therein.
Privacy Policy
To better understand how we protect your personal information, please see the
privacy policy at http://consumer.huawei.com/privacy-policy.
