Huawei Technologies HG658V2 Home Gateway User Manual
Huawei Technologies Co.,Ltd Home Gateway Users Manual
User Manual
1
HG658 V2 Home Gateway
Quick Start
1 Connecting Cables
Installing the HG658 V2 on a DSL Broadband Network
In some communities, Internet service providers use telephone lines to provide
broadband access services.
If you have subscribed to digital subscriber line (DSL) broadband, you can connect
the HG658 V2 to a telephone port for Internet access.Connect your devices in the
sequence indicated in the following figure.
1 Telephone wall jack 2 Splitter 3 Telephone
4 HG658 V2b 5 Power adapter 6 Desktop computer
6
3
4
8
9
10
1
2
a
b
7
5
c
3
2
When configuring the HG658 V2 for the first time, use an Ethernet cable to
connect the HG658 V2 to a computer.
2 Powering On
To power on the HG658 V2, press its power button.
After the HG658 V2 is powered on, the HG658 V2 indicator turns on. If the indicators
do not behave as expected, ensure that everything is plugged in correctly.
3 Setting the Computer IP Address
Before logging in to the HG658 V2 web management page, set the IP address of the
computer that will be used for the login.
On Windows 7
1. Choose Start > Control Panel > Network and Internet > Network and Sharing
Center.
2. Choose Change adapter settings. Right-click Local Area Connection and
choose Properties.
3. Double-click Internet Protocol Version 4 (TCP/IPv4).
4. Select Obtain an IP address automatically and Obtain DNS server
address automatically. Click OK.
7 Set-top Box 8 Laptop computer 9 Smart Phone
10 Pad
a LINE port b PHONE port c MODEM port
3
4 Setting Network Access Parameters
Configuring an Automatical Connection to Access the
Internet
The HG658 V2 supports you to choose the proper connection mode automatically to
access the Internet, meaning you do not need to install dial-up software or perform
dial-up operations on your computer and just following the wizard page.
To set up an automatical connection to access the Internet:
1. Open a browser on your computer. In the address box, enter 192.168.1.1.
Press Enter to access the web management page.
2. On the login page, enter the login user name (user by default) and password
(HuaweiUser by default). Click Log in.
To protect against unauthorized access, change the user name and
password after the first login.
You can change the account parameters on Maintain > Account
Management page.
3. On the I want to... Start Wizard page, choose Connect automatically, and
click Next.
The HG658 V2 supports DSL uplink mode, meaning you can use the HG658
V2 with a telephone port for Internet access.
After you complete the preceding settings, check the status of the Internet indicator
light. When the Internet indicator light turns steady green, you can start browsing the
Internet.
You need to perform the preceding operations on a computer once only. The next
time you power on your computer, you can browse the Internet without performing
the same configurations.
Configuring a Wireless Account
After you complete the preceding settings, click Set Up WLAN, you will see the I
want to Set Up WLAN page used to configure the wireless account.
The default SSID and WLAN Key printed on the HG658 V2's rear panel are
unique and secure. If you do not want to change them, just turn the WLAN
switch on.
For security reasons or to make the password easy to remember, you can change
the wireless network name and password as follows:
1. On the I want to Set Up WLAN page, switch on the 2.4 GHz WLAN network.
4
2. Enter your desired SSID (WLAN name) and WLAN password.
3. Click Save.
5 Wireless Connection Setup
The wireless configuration software provided by Windows is used as an example to
describe how to set up a wireless connection .
On Windows 7
1. Choose Start > Control Panel > Network and Internet > Network and Sharing
Center > Change adapter settings. Right-click Wireless Network
Connection, and select Connect/Disconnect.
2. From the wireless network list, select the WLAN provided by the HG658 V2.
Click Connect.
3. In the displayed dialog box, enter the WLAN password and click OK.
4. In the wireless network list, check the WLAN connection status. If the status is
Connected, the computer is wirelessly connected to the HG658 V2.
6 Safety information
This section contains important information about the operation of your device. It also contains
information about how to use the device safely. Read this information carefully before using your
device.
Electronic device
Do not use your device if using the device is prohibited. Do not use the device if doing so causes
danger or interference with other electronic devices.
Interference with medical equipment
> Follow rules and regulations set forth by hospitals and health care facilities. Do not use your
device where prohibited.
> Some wireless devices may affect the performance of hearing aids or pacemakers. Consult
your service provider for more information.
> Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained
between a device and a pacemaker to prevent potential interference with the pacemaker. If
using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the
device in your front pocket.
5
Areas with flammables and explosives
> Do not use the device where flammables or explosives are stored (in a gas station, oil depot,
or chemical plant, for example). Using your device in these environments increases the risk of
explosion or fire. In addition, follow the instructions indicated in text or symbols.
> Do not store or transport the device in containers with flammable liquids, gases, or explosives.
Operating environment
> Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these
environments may result in circuit malfunctions.
> Before connecting and disconnecting cables, stop using the device and disconnect it from the
power supply. Ensure that your hands are dry during operation.
> Place the device on a stable surface.
> Keep the device away from electronic appliances that generate strong magnetic or electric
fields, such as a microwave oven or refrigerator.
> During thunderstorms, power off your device and remove all cables connected to it to protect
against lightning strikes.
> Do not use your device during thunderstorms to protect your device against any danger
caused by lightning.
> Ideal operating temperatures are 0 °C to 40 °C. Extreme heat or cold may damage your
device or accessories.
> Keep the device and accessories in a well-ventilated and cool area away from direct sunlight.
Do not enclose or cover your device with towels or other objects. Do not place the device in a
container with poor heat dissipation, such as a box or bag.
> To protect your device or accessories from fire or electrical shock hazards, avoid rain and
moisture.
> Keep the device away from sources of heat and fire, such as a heater, microwave oven,
stove, water heater, radiator, or candle.
> Do not place any object, such as a candle or a water container, on the device. If any foreign
object or liquid enters the device, immediately stop using it, power it off, and remove all cables
connected to it. Then, contact an authorized service center.
> Observe local laws and regulations, and respect the privacy and legal rights of others.
> Do not block device openings. Reserve a minimum of 10 cm around the device to dissipate
heat.
> Stop using your device or applications for a while if the device is overheated. If skin is
exposed to an overheated device for an extended period, low temperature burn symptoms,
such as red spots and darker pigmentation, may occur.
> Do not touch the device's antenna. Otherwise, communication quality may be reduced.
> Do not allow children or pets to bite or suck the device or accessories. Doing so may result in
damage or explosion.
> The device should be installed and operated with a minimum distance of 20 cm between the
radiator and your body.
6
> Keep the device in a place with good reception. The distance between the device and other
metal materials (such as metal brackets or metal doors and windows) should be greater than
25 cm and the distance between the device should be greater than 30 cm.
Child's safety
> Comply with all precautions with regard to child's safety. Letting children play with the device
or its accessories may be dangerous. The device includes detachable parts that may present
a choking hazard. Keep away from children.
Accessories
> Using an unapproved or incompatible power adapter, charger or battery may cause fire,
explosion or other hazards.
> Choose only accessories approved for use with this model by the device manufacturer. The
use of any other types of accessories may void the warranty, may violate local regulations
and laws, and may be dangerous. Please contact your retailer for information about the
availability of approved accessories in your area.
Power adapter safety
> The power plug is intended to serve as a disconnect device.
> For pluggable devices, the socket-outlet shall be installed near the devices and shall be easily
accessible.
> Unplug the power adapter from electrical outlets and the device when not in use.
> Do not drop or cause an impact to the power adapter. If it is damaged, take it to an authorized
service center for inspection.
> If the power cable is damaged (for example, the cord is exposed or broken), or the plug
loosens, stop using it at once. Continued use may lead to electric shocks, short circuits, or
fire.
> Do not touch the power cord with wet hands or pull the power cord to disconnect the power
adapter.
> Do not touch the device or the power adapter with wet hands. Doing so may lead to short
circuits, malfunctions, or electric shocks.
> If your power adapter has been exposed to water, other liquids, or excessive moisture, take it
to an authorized service center for inspection.
> Ensure that the power adapter meets the requirements of Clause 2.5 in IEC60950-1/
EN60950-1 and has been tested and approved according to national or local standards.
Cleaning and maintenance
> During storage, transportation, and operation of the device, keep it dry and protect it from
collision.
> Keep the device and accessories dry. Do not attempt to dry it with an external heat source,
such as a microwave oven or hair dryer.
> Do not expose your device or accessories to extreme heat or cold. These environments may
interfere with proper function and may lead to fire or explosion.
7
> Avoid collision, which may lead to device malfunctions, overheating, fire, or explosion.
> If the device is not going to be used for an extended period of time, power it off, and remove all
cables connected to it.
> If anything unusual occurs (for example, if the device emits smoke or any unusual sound or
smell), immediately stop using it, power it off, remove all cables connected to it, and contact
an authorized service center.
> Do not trample, pull, or excessively bend any cable. Doing so may damage the cable, causing
the device to malfunction.
> Before you clean or maintain the device, stop using it, stop all applications, and disconnect all
cables connected to it.
> Do not use any chemical detergent, powder, or other chemical agents (such as alcohol and
benzene) to clean the device or accessories. These substances may cause damage to parts
or present a fire hazard. Use a clean, soft, and dry cloth to clean the device and accessories.
> Do not place magnetic stripe cards, such as credit cards and phone cards, near the device for
extended periods of time. Otherwise the magnetic stripe cards may be damaged.
> Do not dismantle or remanufacture the device and its accessories. This voids the warranty
and releases the manufacturer from liability for damage. In case of damage, contact an
authorized service center for assistance or repair.
Disposal and recycling information
This symbol (with or without a solid bar) on the device, batteries (if included), and/or the
packaging, indicates that the device and its electrical accessories (for example, a headset, adapter,
or cable) and batteries should not be disposed of as household garbage. These items should not
be disposed of as unsorted municipal waste and should be taken to a certified collection point for
recycling or proper disposal.
For more detailed information about device or battery recycling, contact your local city office,
household waste disposal service, or retail store.
Disposal of the device and batteries (if included) is subject to WEEE Directive Recast (Directive
2012/19/EU) and Battery Directive (Directive 2006/66/EC). The purpose of separating WEEE and
batteries from other waste is to minimize the potential environmental impacts and human health
risk of any hazardous substances that may be present.
Reduction of hazardous substances
This device is compliant with the REACH Regulation [Regulation (EC) No 1907/2006] and RoHS
Directive Recast (Directive 2011/65/EU). Batteries (if included) are compliant with the Battery
Directive (Directive 2006/66/EC). For up-to-date information about REACH and RoHS compliance,
please visit the web site www.huaweidevice.com/certification.
EU regulatory conformance
Statement
8
Hereby, Huawei Technologies Co., Ltd. declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the web site www.huaweidevice.com/certification.
The following marking is included in the product:
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is used.
This device may be restricted for use, depending on the local network.
Restrictions in the 2.4 GHz band:
Norway: This subsection does not apply for the geographical area within a radius of 20 km from the
centre of Ny-Ålesund.
FCC Regulatory Compliance
FCC statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
--Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Caution: Any changes or modifications to this device not expressly approved by Huawei
Technologies Co., Ltd. for compliance could void the user's authority to operate the equipment.
This device is intended to be attached to a receiver that is not used to receive over-the-air
broadcast signals. Connection of this device in any other fashion may cause harmful interference
to radio communications and is in violation of the FCC Rules, part 15.
Consumer Information:
a)This equipment complies with Part 68 of the FCC rules and the requirements
adopted by the ACTA. On the bottom of this equipment is a label that contains,
among other information, a product identifier in the format
1622
9
US: HAUDL01BHG658V2. If requested, this number must be provided to the
telephone company.
b)An applicable certification jacks Universal Service Order Codes (USOC) for the
equipment is provided (i.e., RJ11C) in the packaging with each piece of approved
terminal equipment.
c)A plug and jack used to connect this equipment to the premises wiring and
telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA. A compliant telephone cord and modular plug is
provided with this product. It is designed to be connected to a compatible modular
jack that is also compliant. See installation instructions for details.
d)The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most but not all areas, the sum of RENs
should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total RENs, contact the local telephone
company. [For products approved after July 23, 2001, the REN for this product is part
of the product identifier that has the format
US: HAUDL01BHG658V2. The digits represented by ## are the REN without a
decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately
shown on the label.]
e)If this equipment HG658 V2 causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of service may be
required. But if advance notice isn't practical, the telephone company will notify the
customer as soon as possible. Also, you will be advised of your right to file a
complaint with the FCC if you believe it is necessary.
f)The telephone company may make changes in its facilities, equipment, operations
or procedures that could affect the operation of the equipment. If this happens the
telephone company will provide advance notice in order for you to make necessary
modifications to maintain uninterrupted service.
g) Should you experience trouble with this equipment, please contact Futurewei
Technologies, Inc. Phone: +1 469-277-5852 for repair or warranty information. If
the equipment is causing harm to the telephone network, the telephone company
may request that you disconnect the equipment until the problem is resolved.
h) Please follow instructions for repairing if any (e.g. battery replacement section);
otherwise do not alternate or repair any parts of device except specified.
i)Connection to party line service is subject to state tariffs. Contact the state public
utility commission, public service commission or corporation commission for
information.
j)NOTICE: If your home has specially wired alarm equipment connected to the
telephone line, ensure the installation of this device does not disable your alarm
equipment. If you have questions about what will disable alarm equipment, consult
your telephone company or a qualified installer.
10
k)This equipment is hearing aid compatible.
NOTICE: According to telephone company reports, AC electrical surges, typically
resulting from lightning strikes, are very destructive to telephone equipment
connected to AC power sources. To minimize damage from these types of surges, a
surge arrestor is recommended.
Applicable for Coin or Pay Phone Only
To comply with state tariffs, the telephone company must be given notification prior
to connection for customer-owned coin or credit card phone. In some states, the state
public utility commission, public service commission or corporation commission must
give prior approval of connection.
7 Obtaining More Information
Thanks for purchasing the HG658 V2 Home Gateway (HG658 V2 for short).
This quick start guide will show you how to connect your HG658 V2 to a network and
access the Internet. The figures in this guide are for reference only. The appearance
and display features may vary slightly depending on the actual product version.
For more information, visit http://consumer.huawei.com/en/.
Please visit www.huaweidevice.com/worldwide/support/hotline for recently updated
hotline and email address in your country or region.
8 Legal Notice
Copyright © Huawei Technologies Co., Ltd. 2014. All
rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT
CONSTITUTE ANY KIND OF WARRANTIES.
Privacy Policy
To better understand how we protect your personal information, please see the
privacy policy at http://consumer.huawei.com/privacy-policy.
