Huawei Technologies M318A CDMA 1X Digital Mobile Phone User Manual
Huawei Technologies Co.,Ltd CDMA 1X Digital Mobile Phone
User Manual
M318
CDMA 1X Mobile Phone
Safety Precautions
Before using the phone, read safety precautions and inform your
children about using the phone correctly and safely. For details,
see "Warnings and Precautions."
Do not switch on your
phone when using the
phone is prohibited or
when using the phone may
cause interference or
danger.
Do not place your
phone or the
accessories in
containers with strong
electromagnetic field.
Do not use your phone
while driving. Do not place magnetic
storage media near
your phone. Radiation
emitted from the
phone may erase the
information stored on
the magnetic storage
media.
Follow the rules or
regulations set forth by the
hospitals and health care
facilities. Switch off your
phone near medical
apparatus.
Do not place your
phone near a
high-temperature
area. .Do not place
your phone where it
can come in contact
with flammable gas
such as a gas station.
Switch off your phone in
an aircraft. The phone may
cause interference to
control signals of the
aircraft.
Keep your phone and
its accessories away
from children. Do not
allow children to use
your phone without
guidance.
Switch off your phone
near high-precision
electronic devices. The
phone may affect the
performance of these
devices.
Use only the approved
batteries and chargers
to avoid explosion.
Do not attempt to
disassemble your phone or
its accessories. Only
qualified personnel are
allowed to service or
repair the phone.
Observe the laws or
regulations on using
the phone. Respect
others’ privacy and
legal rights when using
your phone.
Copyright © 2007 Huawei Technologies Co., Ltd.
All Rights Reserved
No part of this manual may be reproduced or transmitted in any
form or by any means without prior written consent of Huawei
Technologies Co., Ltd.
Trademarks
and other Huawei trademarks are the trademarks or
registered trademarks of Huawei Technologies Co., Ltd. in the
People’s Republic of China and certain other countries.
All other trademarks mentioned in this manual are the property of
their respective holders.
Notice
The information in this manual is subject to change without notice.
Every effort has been made in the preparation of this manual to
ensure accuracy of the contents, but all statements, information,
and recommendations in this manual do not constitute the
warranty of any kind, express or implied.
About your device
The wireless phone cited in this guide is approved for use on the
CDMA 800 and 1900 networks. The HUAWEI M318 also
receives signals from the GPS location. For more information
about networks, consult your service provider.
Shared memory
The available features in the device share the memory: inbox,
outbox, drafts, contacts, schedules, applications, and images,
sounds, and voice folder in Gallery. Use of one or more of these
features reduces the available memory for the remaining features
that share the memory.
Conventions
Term Conventions
This manual refers to HUAWEI M318 CDMA 1X mobile phone
as "the phone" or "your phone".
Operation Conventions
Operation Meaning
Press and
hold Press a key for two to three seconds and then release
it.
Press Press a key and release it quickly.
GUI Conventions
Format Meaning
Bold Any string displayed on the phone screen is in
boldface, such as "Menu".
> Multi-level menus are spearated by ">". For
example, "Menu > Messages" indicates "Messages"
is the submenu of "Menu".
Symbols
Symbol Description Meaning
Caution Warnings and precautions for operations
Note Complementary descriptions for
operations
Table of Contents
1 Getting to Know Your Phone................................... 1
Your Phone............................................................................ 1
Keys and Functions ............................................................... 2
Screen Icons .......................................................................... 3
Interfaces............................................................................... 4
LED Indicator........................................................................ 4
2 Getting Started .......................................................... 5
Installing the Battery ............................................................. 5
Charging the Battery.............................................................. 5
Powering On/Off the Phone................................................... 6
Using the Function Menu ...................................................... 6
3 Voice Services ............................................................ 7
Making a Call........................................................................ 7
Answering a Call................................................................... 7
Operations During a Call....................................................... 8
4 Text Entry................................................................ 10
Text Input Modes................................................................. 10
Entering English.................................................................. 10
Entering Digits .....................................................................11
Entering Symbols .................................................................11
5 Message .................................................................... 12
Writing and Sending a Message .......................................... 12
Reading a Message.............................................................. 13
i
6 Contacts.................................................................... 14
Adding a Contact................................................................. 14
Searching for a Contact ....................................................... 14
7 Alarm Clock............................................................. 15
Enabling an Alarm Clock .................................................... 15
Disabling an Alarm Clock ................................................... 16
8 Security..................................................................... 17
Enabling/Disabling the Phone Lock.................................... 17
Changing the Phone Lock Code .......................................... 17
9 Recorder................................................................... 18
Recording a Sound Clip....................................................... 18
Playing a Sound Clip........................................................... 18
10 TTY Operation...................................................... 20
Using the TTY Device......................................................... 20
Setting the TTY Mode......................................................... 20
11 Menu Commands .................................................. 21
12 Troubleshooting..................................................... 30
13 Warnings and Precautions ................................... 32
ii
1 Getting to Know Your Phone
Your Phone
Earpiece
Confirm Key
End / Power Key
# Key
Microphone
Screen
Left Soft Key
Talk/Send Key
Number Keys
Right Soft Key
Charger Interface
/ Data Cable Connector
/ Headset Jack
Key
*
Clear Key
Navigation Keys
1
Keys and Functions
Press… To…
z Make a call.
z View All calls in the standby mode.
z Answer an incoming call.
z Power on or off the phone (by pressing and
holding it for about two seconds).
z End a call.
z Return to the standby mode.
z Display Menu in the standby mode.
z Select the highlighted item.
z Access the @metro option in the standby mode.
z Return to the previous menu.
z Display Menu in the standby mode.
z Confirm a selection.
z Access: Contacts ( ), @metro ( ),
MetroWEB ( ), or Messages (); or access
Create Message ( ) (by pressing and holding it
for about two seconds) in the standby mode.
z Increase the volume ( or ); decrease the
volume ( or ) during a call.
…
z Enter numbers, letters, and symbols.
z Call the voice mail center in the standby mode (by
pressing and holding the 1 key).
z Speed-dial phone numbers in the standby mode
(by pressing and holding the 2–9 keys).
z Select a submenu item labeled with the
corresponding number.
2
Press… To…
z Enter the *, +, P and T symbols.
z Display a symbol list in any input mode.
z Enable or disable the silence mode (by pressing
and holding the key for about two seconds in the
standby mode).
z Enter the # symbol.
z Change input modes when editing texts.
Delete characters in the editing mode or an item in
an application.
Screen Icons
Icon Description
Indicates the signal strength. The more the bars are, the
stronger the signal is.
There is an incoming call; a call is being set up; or the
phone is in conversation.
The voice privacy function is enabled.
The phone is in the roaming status.
A new message is received.
The memory for messages is full.
An urgent message is received.
A new voice mail is received.
The PUSH message inbox is full.
A new PUSH message is received.
3
Icon Description
The AGPS indicator mode is 911 Only.
The AGPS indicator mode is Location On.
The alert type is Ring.
The alert type is Ring & Vibration.
The alert type is Vibration.
The alert type is Silence.
An alarm clock is set.
Indicates the battery power level. The more the bars
are, the higher the remaining battery level is.
The battery power level is extremely low.
Interfaces
Interface Description
Charger interface
/Data cable connector
/Headset jack
It is at the bottom of your phone. You can
connect the travel charger, headset or data
cable to it.
LED Indicator
There is an LED indicator on the flip cover. The functions of the
indicator are as follows:
z Blinking when the phone is charging.
z Blinking when there is an incoming call or a new SMS, and
when the alarm or calendar alerts.
z Steady on when the charging completes.
z Blinking when you open or close the flips, if the flip tone is
enabled.
4
2 Getting Started
Installing the Battery
1. 3.
2.
a
b
b
Charging the Battery
To charge the battery, do as follows:
1. Connect the travel charger to the charger interface at the bottom
of your phone.
2. Connect the charger to an AC power socket.
During the charging process, the icon on the upper right
corner of the screen is in an animated status.
3. Wait until the phone is completely charged.
If becomes static, the battery is completely charged.
4. Disconnect the charger from the AC power socket.
5. Disconnect the charger from the phone.
5
z Do not use a damaged battery or charger.
z Before using the travel charger, ensure that the battery is
installed in your phone.
Powering On/Off the Phone
z When the phone is powered off, press and hold to power it
on.
z When the phone is powered on, press and hold to power it
off.
Using the Function Menu
To use the function menus, do as follows:
1. In the standby mode, press (Menu).
2. Press to select the desired function menu.
3. Press (Select) or to display the selected menu.
4. Display the submenu in either of the following ways:
z Press to select a submenu, and then press (Select) or
to display the selected submenu.
z Press the number key corresponding to the serial number of a
submenu to display the submenu.
5. Press (Back) to return to the previous menu or exit the
function menu.
To return to the standby mode, press .
6
3 Voice Services
Making a Call
1. In the standby mode, enter the phone number.
z To make an international call, press twice to enter the
international long distance code of "+". Then, enter the number
to be dialed in the "country code + region code + phone
number" format.
z To call a number through an extension, press three times to
insert "P", or press four times to insert "T" between the
phone number and the extension.
2. Press to dial the number.
3. Press or (End) to end the call.
z In the standby mode, press to select the required
number from All Calls. Then, press to dial the
number.
z When the phone is locked, enter the lock code to unlock
the phone first; otherwise, you can only make
emergency calls or answer calls.
z Select a contact from the phonebook and press to
dial.
z Select a message in the inbox and press to dial.
Answering a Call
When there is an incoming call, you can press , (Answer)
or to answer it; or press to reject it.
7
z When there is an incoming call, you can press (Silence) to
mute the speaker, and then press (Reject) again to reject it.
If the phone is in the Silence mode, you can press (Reject)
to reject it.
z If the any-key answer function is enabled, you can press any
key except and to answer an incoming call.
z If the headset auto-answer function is enabled, and the headset
is connected to the phone, the incoming call is answered
automatically.
You can set any-key answer function in the Settings > Call
Settings > Answer Mode, and set the headset auto-answer
function in the Settings > Call Settings > Headset Auto
Answer.
Operations During a Call
During a call, you can press or to increase the volume,
press or to decrease the volume and press to enable
or disable the speaker during a call.
Press (Options), and you can select the following options:
z Mute/Unmute: Allows you to mute or unmute your voice
during a call.
At first, the option is Mute. If you select it, the other party
cannot hear your voice during the call.
If you access the Options menu again, the option is Unmute. If
you select it, the other party can hear your voice again.
This function is available only after the call is set up. You
cannot mute/unmute the ringtone.
z Save Number: Allows you to save the phone number to
Contacts.
z Contacts: Allows you to enter the Contacts menu.
z Messages: Allows you to enter the Messages menu.
8
z Call Memo: Allows you to enter the Call Memo menu.
z Voice Privacy: Allows you to protect your calls from being
overheard. You can choose either of the two modes, Standard
and Enhanced. The Voice Privacy function is network
dependent.
z TTY Setup: Allows you to set the TTY mode.
9
4 Text Entry
Text Input Modes
The indicator of the current input mode is displayed on the upper
left corner of the screen. You can press to change the input
modes.
Indicator Text Input Mode Indicator Text Input Mode
En Smart English Abc Alphabetical Text
123 Number - -
z Press once to delete the letter on the left of the
cursor. Press and hold for about two seconds to
delete all the letters at a time. You can press
(Back) to return to the previous screen.
z In any text input mode, the current editing status is
displayed on the upper right corner of the screen,
including the maximum length of a message and
remaining letters that can be entered.
Entering English
Alphabetical Text Input ("Abc")
The alphabetical text input allows you to enter English letters. You
can press a number key labeled with required letters once to enter
the first letter on the key, twice to enter the second letter on the
key, and so on.
If the letter you want to enter is on the same key as the previous
one, you can enter the latter only after the cursor appears again, or
after you move the cursor to the next space.
10
In the "Abc" input mode:
z You can press once to enter a space, twice to enter "0".
z You can press repeatedly to enter the commonly used
punctuations.
Smart English Input ("En")
The "En" input mode recognizes commonly used words according
to the numeric sequence of key presses. It requires only one key
press for each letter in the word that you are entering. If more than
one word shares the same numeric sequence, then the "En" input
mode provides the most commonly used words. Among the
possible words, you can press to select the required word.
You can press once to enter a full stop and press to
enter a space.
Entering Digits
In different input modes, you can enter numbers as follows:
z In the "123" input mode, you can directly press number keys
labeled with required digits.
z In the "Abc" input mode, you can press the number key
repeatedly until the required digit appears on the screen.
z In the "En" input mode, you can press the number key and then
press until the required digit appears on the screen.
Entering Symbols
You can enter a symbol as follows:
1. Press once to display a symbol list, and press twice to
display a network symbol list.
2. Press to view the symbols.
3. Press the number key to enter the corresponding symbol.
11
5 Message
Writing and Sending a Message
1. In the standby mode, choose Menu > Messages > Create
Message. You can also access the Create Message menu by
pressing and holding for about two seconds in the standby
mode.
2. Write the message.
You can press (Options) for the following options:
z Send: Allows you to send the message.
z Save: Allows you to save the message as a draft.
z Insert Quick Text: Allows you to edit the message based on a
template.
z Insert Contact: Allows you to insert the phone number of a
contact into a message from Contacts.
z Priority: Allows you to set the priority for messages. The
message priority function is network dependent.
z Callback Number: Allows you to set the callback number.
The callback number is sent to the message recipient by default.
You can set it to either your phone number or other numbers.
When the recipient receives your message, the callback number
can be viewed for calling back.
Select On and enter the phone number.
z When entering the number(s) of the recipients, you can choose
Options > Contacts to select the number of one contact in
Contacts, or choose Options > Group List to select the
numbers of a group of contacts.
In the text editing screen, press to send the message
directly.
12
Reading a Message
To read a message stored in the inbox, do as follows:
1. In the standby mode, choose Menu > Messages > Inbox.
2. Press to select a message.
3. Press to view the message.
4. Press (Options) to select the following options:
z View: Allows you to view the message.
z Reply: Allows you to edit a message and reply the message
sender.
z Delete: Allows you to delete the message.
z Delete Multiple: Allows you to delete multiple messages at a
time.
z Forward: Allows you to forward the message.
z Extract: Allows you to extract the number contained in the
message, or the number of the message sender. You can select
Edit before call, Call or Save the number.
In the message viewing screen, press to reply the
message directly.
13
6 Contacts
Adding a Contact
1. In the standby mode, choose Menu > Contacts > Add New.
2. Press to enter Name, and then press (OK).
3. Enter the necessary information in the fields: Mobile Number,
Home Number, Office Number, and Fax Number (at least
one number field is required.). You can enter the email of a new
contact and select the Group, Notes, and Custom Tone for the
contact.
4. Press (Save) to save the information. The new contact is
saved to Contacts.
Searching for a Contact
1. In the standby mode, choose Menu > Contacts > Search.
2. Enter the name you want to search, and press (Search).
3. Press to view the contact, or press (Options) for the
following options:
z View: Allows you to view the contact.
z Edit: Allows you to modify the contact.
z Add New: Allows you to add a new contact to Contacts.
z Send Message: Allows you to write and send a message to this
contact.
z Delete: Allows you to delete the contact.
z Call: Allows you to make a call to the contact.
z Edit Before call: Allows you to modify the number before you
call the number.
14
7 Alarm Clock
After the alarm clock is enabled, the phone notifies you at the
preset time if the phone is powered on. You can set up to five
alarm clocks.
Enabling an Alarm Clock
1. In the standby mode, choose Menu > Tools > Alarms.
2. Press to select an alarm clock, and then press to set
the alarm.
3. Press to set the time, and then press again to confirm.
z Press to set the time.
z Enter the time directly.
4. Press to set the alarm ringtone.
Press to select the ringtone, and press (Select) or
to confirm.
5. Press to select the alerting mode:
z Once: The alarm clock alerts once.
z Everyday: The alarm clock alerts once a day.
z Custom: The alarm clock alerts at a specified time.
6. Press (Save) to save the settings, with displaying a prompt
to confirm.
15
z When the alarm clock alerts, press (Stop)to stop
the alarm. Alternatively, press (Snooze) to snooze
it for five minutes, after which the alarm alerts again.
z If the alarm clock is unattended when it alerts, it stops
temporarily and alerts again five minutes later. It alerts
for five times before it finally stops.
Disabling an Alarm Clock
1. In the standby mode, choose Menu > Tools > Alarms.
2. Press to select an enabled alarm clock.
3. Press (Off) to disable the alarm clock.
Choose Menu > Tools > Alarms > Cancel All to disable
all alarm clocks.
16
8 Security
Enabling/Disabling the Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock function is disabled. You can change the
default phone lock code (the last four digits of your phone number)
to any numeric string in the range of 4 to 8 digits.
1. In the standby mode, choose Menu > Settings > Security
Settings > Phone Lock.
2. Select one of the following phone lock modes:
z Immediate: Lock the phone immediately.
z Power On: Enable the phone lock when the phone is powered
on the next time.
z Off: Disable your phone lock.
In the standby mode, press (Unlock), and enter the
phone lock code to unlock the phone; or press (SOS) to
make an emergency call.
Changing the Phone Lock Code
You can change the default or the current phone lock code into
any numeric string in the range of 4 to 8 digits. Do remember your
phone lock code. If you forget it, contact the service center.
1. In the standby mode, choose Menu > Settings > Security
Settings > Change Phone Code.
2. Enter the correct phone lock code and press (OK).
3. Enter a new phone lock code and press (OK).
4. Re-enter the new phone lock code and press (OK).
17
9 Recorder
Recording a Sound Clip
1. In the standby mode, choose Menu > Tools > Recorder.
2. Press to start recording.
3. Press (Back) to stop recording, with displaying a prompt
to confirm.
4. Press (Yes) to save the sound clip to Voice Folder.
Press (No) to return to the earlier menu.
z When recording a sound clip, you can press stop
recording, and the sound clip saves to Voice Folder
automatically.
to
z When recording a sound clip, place the microphone of
your phone close to the sound source for a better
recording effect.
Playing a Sound Clip
1. In the standby mode, choose Menu > Tools > Recorder.
2. Press to view the Voice Folder.
3. Press to select a sound clip. Then, press (Options)
for the following options:
z Play: Allows you to play the sound clip.
z Set As Incoming Call Tone: Allows you to set the sound clip as
the ringtone.
z Delete: Allows you to delete the sound clip.
z Rename: Allows you to rename the sound clip.
18
z File Info: Allows you to view the format, size, date, and time of
the sound clip.
z Delete All: Allows you to delete all sound clips.
You can also access the Voice Folder by choosing Menu >
Gallery > Voice Folder.
19
10 TTY Operation
Using the TTY Device
The Teletypewriter (TTY) is a typewriting device. By connecting
the phone to the TTY device, you can use the TTY functions to
send/receive messages.
When you use the TTY function, do as follows:
1. Connect the TTY device to the headset jack of the phone and set
the phone to the TTY mode.
2. Make or answer calls as normal.
3. When the call is put through, use the TTY device to send or
receive the letters.
4. Press or (End) to end the call.
Setting the TTY Mode
When you set your phone to the TTY mode, the phone works in
this mode unless you disable this mode.
1. In the standby mode, choose Menu > Settings > Phone
Settings > TTY Setup.
2. Press to select the TTY mode, and then press (Select)
or to confirm.
z Voice: The standard voice speaking mode and the listening
mode.
z TTY: Transmit and receive the TTY characters.
z VCO: Receive TTY characters but transmit by speaking into the
microphone.
z HCO: Transmit TTY characters but receive by listening to the
earpiece.
20
11 Menu Commands
Messages
Voice Mail Allows you to receive voice mails.
You can also clear the voice mail notifications.
Create
Message Allows you to write and send a message.
Inbox Allows the phone to store the received messages and
delivery reports.
You can view, reply, delete, and forward messages in
Inbox. You can save the numbers extracted from the
messages or make calls.
Outbox Allows the phone to save the messages successfully
sent to Outbox and save the messages failed to be
sent to Drafts, if you choose Messages > Settings >
Send Settings > Auto Save > Send & Save.
You can edit, delete, resend, and forward the
messages in Outbox.
Drafts Allows the phone to store draft messages and the
messages failed to be sent.
You can edit, send, and, delete the messages in the
Drafts.
Quick Text Allows you to edit up to 10 phrases.
Group List Allows you to set up to 10 groups of recipients, each
of which can contain up to 100 contacts.
21
Settings Send Settings:
z Auto Save: Allows you to select the following
items, including Send Only (to send the message
without saving) and Send & Save (to send the
message and save it in Outbox automatically).
z Priority: Allows you to set the priority of
messages sent to the recipients. The priorities are
Normal, Interactive, Urgent, and Emergency.
The message priority function is network
dependent.
z Delivery Report: Allows you to receive a
message delivery report from the short message
service center (SMSC).
z Callback Number: Allows you to set the callback
number. For details, see "Message" on page 12.
z Signature: Allows you to set your signature. The
signature is displayed at the end of the sent
messages.
z Deferred Delivery: Allows you to set the time for
deferring the message delivery from the SMSC to
the recipient with four available options:
Immediate, After 12 Hours, After 1 Day, and
After 3 Days.
z Validity Period: Allows you to set the validity
period of messages, the time during which
messages failed to be sent are saved at SMSC
before deleting.
Auto Delete: If enabled, allows the phone to delete
the messages sent earlier automatically to store new
messages when the message memory is full. If
disabled, the phone cannot receive new messages
when the memory is full.
22
Statistics: Allows you to view the number of the
sent and the received messages, and the time when
you last clear the statistics. You can press
(Clear) to clear all the statistics.
Memory Status: Allows you to view the status of
memory for messages (the memory used and the
total memory). The phone can save up to 100
messages.
Delete All Allows you to delete messages in the inbox, outbox,
drafts, or delete all messages.
Contacts
Search Allows you to find a phone number from Contacts.
Add New Allows you to add new contacts to the phonebook.
The phone memory can save up to 500 contacts.
Groups Allows you to add the contacts to a group. You can
set up to 10 groups.
Allows you to view, rename the group, and set the
group ringtone.
Speed Dial Allows you to make a call by pressing only one
number key (by pressing and holding the 2-9 keys).
Management Delete Multiple: Allows you to delete multiple
contacts at a time.
Memory Status: Allows you to check the entire
space and the remaining space for contacts in the
phone. The phone can save up to 500 contacts.
Call Log
23
All Calls
Missed Calls
Received
Calls
Dialed Calls
Allows you to view, save, and delete call records (up
to 20), send messages, save number, or make calls to
the corresponding numbers.
Call Memo Allows you to enter the Call Memo menu.
Call Duration Allows you to view the duration of the last call,
received calls, dialed calls, total calls, and last clear
time.
@Metro
Allows you to browse and download applications from network
provider’s server. Allows you to choose your favorite services, such
as downloading rings, pictures, and games. For more information
about this function, consult your service provider. This function may
cost the extra charge.
MetroWEB
Allows your phone to access the specified services provided by
network service providers. Allows you to enjoy the mobile life easily.
For example, you can browse the Internet and download your
favorite pictures, ringtones, video clips, or music. For more
information about this function, consult your service provider.
Gallery
Images Allows the phone to store pictures in the bmp, jpg,
png, gif, and bci format. Allows you to view,
rename, set a picture as wallpaper, delete, delete all,
and view the information of the pictures.
Sounds Allows the phone to store music in the mid, mp3,
24
Voice Folder
Memory
Status
and qcp format.
Allows the phone to store and play audio files
recorded by the phone. Allows you to set an audio
file as the incoming ringtone, rename an audio file,
delete an audio file, and view the information of the
audio files.
Allows you to check the used, free, and total space
of the phone.
Settings
Display
Settings Wallpaper: Allows you to set a picture in the phone
as the wallpaper.
Themes: Allows you to set a theme in the phone.
Backlight: Allows you to set the backlight of the
screen and the keypad.
Banner: Allows you to enable or disable the banner.
If you select On, you can edit the banner.
Alert Settings Volume: Allows you to set the volume: press
or to increase the volume, and press or
to decrease the volume:
z Ring: Allows you to set the volume of ringtones.
z Voice: Allows you to set the voice volume during
calls.
z Key: Allows you to set the volume of pressing the
keys.
Alert Type: Allows you to select the ring mode,
including Ring, Vibration, Ring & Vibration, and
Silence.
25
Sound Settings:
z Incoming Call Tone: Allows you to select a
ringtone for incoming calls.
z Message Tone: Allows you to select a ringtone for
messages.
z Key Tone: Allows you to select a tone when you
press the keys.
z Flip Tone: Allows you to select a flip tone.
z Power On/Off Tone: Allows you to enable or
disable the tone for powering on/off.
Date & Time Idle Display: Allows you to select Date & Time,
Time, Date, or None to display on the idle screen
Date Format: Allows you to set the date format to
DD-MM-YYYY, MM-DD-YYYY, or
YYYY-MM-DD.
Time Format: Allows you to set the time format to
a 12-hour clock or a 24-hour clock.
Call Settings Answer Mode: Allows you to set the answer mode
to By Send Key, By Flip Open, or By Any Key
(The any-key answer function allows you to answer
an incoming call by pressing any key except
and ).
Minute Alert: Notifies you of the call duration by
generating an alert 15 seconds, 10 seconds or 5
seconds before end of each minute (by selecting 45
Seconds, 50 Seconds, or 55 Seconds), if enabled.
Voice Privacy: Allows you to set the privacy mode,
including Standard and Enhanced.
Call Timer: Displays the duration of the current
call.
26
Ring Setup: Allows you to set the ringing
component when the headset is connected. You can
select Only From phone or Only From Headset.
Headset Auto Answer: Allows the headset to
answer the call automatically when no one answers
the call in 2 Seconds, 5 Seconds, or 10 Seconds, if
enabled.
Roaming
Settings System Mode: Allows you to select metroPCS
Only or Automatic as the current network of the
phone.
Roaming Alert: Allows you to enable or disable the
roaming alert.
Phone
Settings Language: Allows you to select the language.
Auto Power On/Off: Allows you to set a time for
powering on/off the phone. Then, the phone powers
on/off at the preset time automatically.
Set NAM: Allows you to select the NAM
parameters, including NAM1 and NAM2. For more
information about this function, consult your service
provider.
TTY Setup: Allows you to use an optional TTY
device with your phone to send and receive calls.
Four options are available: Voice, TTY, VCO, and
HCO.
Location: Allows the phone to inform the network
about the location where it is being used. Then, the
network can search out the location of your phone.
z Location On: Your phone accepts the location
request at any time.
z 911 Only: The phone does not send location
information unless you call the emergency number
911.
27
Security
Settings Phone Lock: Protects the phone from unauthorized
use, if enabled.
z Immediate: Lock the phone immediately.
z Power On: Enable the phone lock when the phone
is powered on next time.
z Off: Disable your phone lock.
Change Phone Code: Allows you to change the
default phone lock code (the last four digits of your
phone number) into any numeric string in the range
of 4 to 8 digits.
Restrict Outgoing Calls: Allows the phone to
restrict the outgoing calls except the emergency
calls, if enabled.
Restore
Factory
Settings
Allows you to restore the phone to the factory
settings after you enter the correct phone code.
Tools
Recorder Allows you to use the recorder. For details, see
"Recorder" on page 18.
Alarms Allows the phone to alert according to the specified
mode at the preset time. You can set up to five alarm
clocks.
Scheduler Allows the phone to store your appointments (up to
20) so that the phone reminds you at the specified
time.
28
Calculator Allows you to calculate arithmetic expressions.
The calculator supports fractional arithmetic. You
can press to select different operators; press
to enter a decimal point; press to enter +/–;
press to perform the calculation; press
(CE) to clear the contents displayed on the
calculator.
Stopwatch Allows the phone to record the time.
Phone Info
My Number Allows you to view your own phone number.
Version Info Allows you to view the version information.
29
12 Troubleshooting
If you encounter any problem when using your phone, try to
rectify the problem according to the following table. If the
problem persists, contact the service provider or the dealer.
Problem Ensure that…
The battery cannot be
charged. The charger is properly connected
to your phone and the power
socket.
The phone cannot be
powered on. The battery power is sufficient.
The battery is properly installed.
Press and hold .
You cannot make a call
except an emergency call.
z The phone number is correct.
z You are in the network service
area.
z You have not enabled the call
restriction function.
Bad call quality. z The signal strength is strong
enough.
z If you are staying indoors,
move close to a window.
During a call, the other side
cannot hear your voice. The microphone is not covered.
The signal strength is not
strong enough or your
phone is often off line.
z The antenna is in a good
condition.
z Move close to a place with
strong signal strength.
30
Problem Ensure that…
Your phone displays "No
service found", "Service
unavailable" or "Network
problem".
z You are not in an area with
weak magnetic field (in a
tunnel or surrounded by
buildings). If so, move to
another area and try again.
z Do not visit the service option
without obtaining authorization
from your service provider.
31
13 Warnings and Precautions
Electronic Device
z Power off your phone near high-precision electronic devices.
The phone may affect the performance of these devices.
z Such devices include hearing aids, pacemakers, fire alarm
systems, automatic gates, and other automatic-control devices.
If you are using an electronic medical device, consult the device
manufacturer to confirm whether the radio wave affects the
operation of this device.
z Pacemaker manufacturers recommend that a minimum
separation of 15 cm be maintained between a mobile phone and
a pace-maker to avoid potential interference with the
pace-maker. To achieve this, use the phone on the opposite ear
to your pacemaker and do not carry the phone in a front pocket.
z RF signals may affect improperly installed or inadequately
shield electronic systems in motor vehicles such as electronic
fuel injection system, electronic antiskid braking system,
electronic speed control system, air bag system. For more
information, check with the manufacturer or its representative
of your vehicle or any equipment that has been added.
Hospital
Pay attention to the following points in hospitals or health care
facilities:
z Do not carry your phone into the operating room (OR),
intensive care unit (ICU), or coronary care unit (CCU).
z Do not use your phone at places for medical treatment where
using the phone is prohibited.
z When using your phone near a heart patient, reduce the ring
tone volume or vibration properly so that it does not affect the
person.
32
Area with Inflammables and Explosives
In any area stored with inflammables and explosives, power off
your phone and do not take out, install or charge the battery, to
avoid explosion and fire. Areas stored with inflammables and
explosives include the following, but are not limited to the
subsequent list:
z Gas station
z Area for storing fuels (such as the bunk under the deck of a
ship)
z Device/Vehicle for transporting and storing fuels or chemical
products
z Area stored with chemical substances and particles (such as:
granule, dust, metal powder) in the air
z Area indicated with the "Explosives" sign
z Area indicated with the "Power off bi-direction wireless
equipment" sign
z Area where it is generally suggested to stop the engine or a
vehicle
Traffic Safety
z Observe local laws and regulations on using the phone. Do not
use your phone while driving to avoid accident.
z Secure the phone on its holder. Do not place the phone on the
seat or other places where it can fall in a jerk or collision.
z Use the phone after the vehicle stops at a safe place.
z If your phone supports the hands-free function, or the phone can
be used with earphones, or there is any vehicle-mounted
equipment with hands-free function, use them in emergency.
z Do not place the phone over the air bag or in the air bag
outspread area. Otherwise, the phone may hurt you owing to the
strong force when the air bag inflates.
33
z Observe the rules and regulations of airline companies. When
boarding or approaching a plane, power off the phone and take
out the battery. In areas where using the phone is prohibited,
power off the phone. Otherwise, the radio signal of the phone
may interfere with the plane control signals. Power off your
phone before boarding an aircraft.
Storage Environment
z Do not place magnetic storage media such as magnetic cards
and floppy disks near the phone. Radiation from the phone may
erase the information stored on them.
z Do not place your phone, battery, or other accessories in
containers with strong magnetic field, such as an induction
cooker, and a microwave oven. Otherwise, circuit failure, fire,
or explosion may occur.
z Do not leave your phone, battery, or charger in a very hot or
cold place. Otherwise, malfunction of the products, fire, or
explosion may occur.
z Keep the ambient temperature between 0℃ and 45 while the ℃
battery is being charged. Keep the ambient temperature between
–20 ℃to 60℃ for storing the battery. If the ambient temperature
is considerably low (especially below 0℃) or considerably high,
the capacity and life of the battery is reduced.
z Do not place sharp metal objects such as pins near the earpiece.
The earpiece may attract these objects and hurt you when you
are using the phone.
z Do not place your phone, battery, and charger in contact with
serious collision or shock. Otherwise, battery leakage, phone
malfunction, overheat, fire, or explosion may occur.
z Do not place your phone in the rear pocket of your trousers or
skirt, to avoid phone damage while seated.
34
Children Safety
z Place your phone, battery, and charger in places beyond the
reach of children. Do not allow children to use the phone,
battery, or charger without guidance.
z Do not allow children to put the battery in mouth, for electrolyte
in the battery is poisonous.
z Do not allow children to touch the small components. Otherwise,
suffocation or gullet jam can be caused if children swallow the
small components.
Operating Environment
z The phone, battery, and charger are not water-resistant. Keep
them dry. Protect the phone, battery and charge from water or
vapor. Do not touch the phone with a wet hand. Otherwise,
short-circuit and malfunction of the product or electric shock
may occur.
z Do not use the phone in dusty, damp, and dirty places or places
with magnetic field. Otherwise, malfunction of the circuit may
occur.
z Do not power on or off the phone when it is close to your ears
to avoid health hazards.
z When carrying or using the phone, keep the antenna at least one
inch (2.5 cm) away from your body, to avoid health hazards
caused by radio frequency leakage.
z If you feel uncomfortable (such as falling sick or qualm) after
playing games on your phone for a long time, consult a doctor
immediately.
z On a thunder stormy day, do not use your phone outdoors or
when it is being charged.
z Do not touch the antenna when you are on a call. Touching the
antenna may affect call quality and cause the phone to operate
with more power. As a result, the talk time and standby time are
shortened.
35
z The phone may interfere with nearby TV sets, radios, and PCs.
z In accordance with international standards for radio frequency
and radiation, use phone accessories approved by the
manufacturer only.
z While using the mobile phone, observe the local laws and
regulations, and respect others' privacy and legal rights.
z Some parts of your phone may be made of glass. This glass
could break if the product is dropped on a hard surface or
receives a substantial impact. If glass breaks, do not touch or
attempt to remove. Stop using your phone until the glass is
replaced by an authorized maintenance engineer.
Clearing and Maintenance
z Before you clean or maintain the phone, power off the phone
and disconnect it from the charger. Otherwise, electric shock or
short-circuit of the battery or charger may occur.
z Do not use any chemical detergent, powder, or other chemical
agent (such as alcohol and benzene) to clean the phone and the
charge. Otherwise, part damage or a fire can be caused. You can
clean the phone and the charger with a damp piece of soft
antistatic cloth.
z Do not scratch the shell of the phone. Otherwise, the shed
coating may cause skin allergy. Once it happens, stop using the
phone at immediately and consult a doctor.
z Keep the plug dry when you clean it, to prevent fire.
z If the phone or any of its fittings does not work, turn to the local
authorize service center for help.
z Do not dismantle the mobile phone or accessories. Only an
authorized service center is allowed to maintain the mobile
phone.
36
Environment Protection
z Please observe the local regulations regarding the disposal of
your packaging materials, exhausted battery, and old phone and
promote their recycling. Do not dispose of exhausted battery or
old phone in municipal waste or fire. Otherwise, explosion may
occur.
z This HUAWEI device complies with Directive 2002/95/EC on
the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
z : This symbol indicates that the equipment carrying this
mark must NOT be thrown into general waste but should be
collected separately and properly recycled under local
regulations.
Emergency Call
You can use your phone for emergency calls. The connections in
all conditions cannot however be guaranteed. You should never
rely solely on the phone for essential communications. When
making an emergency call, provide all the necessary information
as accurately as possible. Your phone may be the only means of
communication at the scene of an accident. Do not end the call
until given permission to do so.
Battery
z Use the battery approved by the manufacturer only. Otherwise,
explosion may occur.
z Do not dispose of the battery in fire. Otherwise, the battery may
ignite or explode.
z Do not connect two poles of the battery with conductors such as
cables, jewelries, or any other metal material. Otherwise, the
battery may be subjected to short circuit and it may burn your
body.
37
z Do not disassemble the battery or solder the battery poles.
Otherwise fluid leakage, overheat, fire, or explosion may occur.
z If there is battery leakage, smoke, or strange smell, stop using
the battery and keep it away from open flame to avoid fire or
explosion. Then, turn to an authorized maintenance engineer for
help.
z If the battery fluid contacts your skin or cloth, wash with clean
water immediately to avoid irritation to the skin.
z If the battery fluid splashes into eyes, do not rub your eyes.
Otherwise, your eyes can be hurt. Wash with clean water and
consult a doctor immediately.
z If there is battery deformation, color change, or abnormal
heating while you charge or store the battery, remove the battery
immediately and stop using it. Otherwise, battery leakage,
overheating, explosion, or fire may occur.
z When installing the battery, do not exert force on the battery,
otherwise battery fluid leaks out or the battery cracks.
z Do not remove the battery when the phone is turned on.
z If you do not use the battery for a long time, store it in normal
temperature after charging.
z If your phone or battery has been submerged in water, do not
use it until you take it to an authorized maintenance engineer for
help. Do not attempt to dry it with an external heat source, such
as microwave oven.
Charger
z Use the charger approved by the phone manufacturer only. Any
violation of this rule may result in fire or malfunction of the
charger.
z Do not short-circuit the charger. Short-circuiting the charger
may cause fire or malfunction of the charger.
z If the power cord is damaged (for example, the lead is exposed
or broken), or the plug loosens, stop using the cable at once.
38
Otherwise, electric shock, short-circuit of the charger, or fire
may occur.
z Keep the charger dry. When water or other liquid leaks into the
charger, electrical leakage, or other faults may occur.
z Do not use the charger in a dusty and damp environment. Keep
the power cord away from any heating appliance.
z Ensure the charger is properly plugged into the power socket
properly when charging the battery. Improper insertion may
result in electric shock, fire, or explosion. To unplug the charger,
pull the plug off rather than tear the power cord.
z Use the AC power supply defined in the specifications of the
charger. An improper power voltage can cause fire or
malfunction of the charger.
z Do not place any heavy object on the power cord of the charger.
Do not damage, change, or pluck the power cord. Otherwise
electric shock or fire may occur.
z When you are charging the battery with the charger, do not
touch the plug, power cord or the charger with a wet hand.
Otherwise, electric shock can be caused.
z When the liquid such as water leaks into the charger, remove the
plug of the charger from the socket immediately. Otherwise,
overheating, fire, and other malfunction may occur.
Certification Information (SAR)
THIS DEVICE MEETS THE GOVERNMENT'S
REQUIREMENTS FOR EXPOSURE TO RADIO FREQUENCY
ELECTROMAGNETIC FIELD.
Your mobile phone is a low-power radio transmitter and receiver.
When it is turned on, it emits low levels of radio frequency energy
(also known as radio waves or radio frequency fields).
Governments around the world have adopted comprehensive
international safety guidelines, developed by scientific
organizations, e.g. International Commission on Non-Ionizing
39
Radiation Protection (ICNIRP) and Institute of Electrical and
Electronics Engineers Inc. (IEEE), through periodic and thorough
evaluation of scientific studies. These guidelines establish
permitted levels of radio wave exposure for the general population.
The levels include a safety margin designed to assure the safety of
all persons, regardless of age and health, and to account for any
variations in measurements.
Specific Absorption Rate (SAR) is the unit of measurement for the
amount of radio frequency energy absorbed by the body when
using a mobile phone. The SAR value is determined at the highest
certified power level in laboratory conditions, but the actual SAR
level of the mobile phone while operating can be well below the
value. This is because the mobile phone is designed to use the
minimum power required to reach the network.
All models of Huawei’s mobile phones are designed to meet radio
frequency exposure guidelines. Before a phone model is available
for selling to the public, it must be tested and certified by the
Federal Communications Commission (FCC), ensuring that it does
not exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed in
positions and locations (that is, at the ear and worn on the body) as
required by the FCC for each model. For body worn operation,
this phone has been tested and meets FCC RF exposure guidelines
when the handset is positioned a minimum of 15 mm from the
body with an accessory that contains no metal part. Use of other
accessories may not ensure compliance with FCC RF exposure
guidelines.
The SAR limit adopted by the USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the FCC and IC for this device type
when tested for use at the ear is 1.204 W/kg, and when properly
worn on the body is 0.551 W/kg.
40
The SAR limit adopted by the CNIRP is 2.0 W/kg over one gram
of tissue. The value guarantees a safe distance to protect mobile
phone users and the difference caused by measurement errors.
Under different test requirements and frequency, the value varies.
Statement
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
z This device may not cause harmful interference.
z This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
z Consult the dealer or an experienced radio/TV technician for
help.
Warning: Changes or modifications made to this equipment not
expressly approved by HUAWEI may void the FCC authorization
to operate this equipment.
41
Version: V100R001C45_01 Part Number: 31018223
42
