MediaQ M210 OTT HDMI Dongle Quick Start
Copyright © Huawei Technologies Co., Ltd. 2013. All rights
reserved. This document is for reference only and does not
constitute a warranty of any kind, express or implied.
What's in the box
If any of the following items are missing, please contact your vendor.
Item Quantity Item Quantity
MediaQ M210 1Remote control 1
Power adapter 1USB power cable 1
HDMI cable 1AAA battery 2
Quick Start Guide 1Safety Information and
Warranty Card 1
1 Getting started
After you connect the cables, power on the M210. Use the TV's remote
control to switch to HDMI input. The TV then displays the M210 interface.
Connecting to a wireless network
Make sure that your Wi-Fi router is powered on and functioning properly.
Connection option 1 : Choose
Settings > Wireless & networks > Wi-Fi , select
your router's wireless network, and enter the password if prompted.
Connection option 2: If your router supports WPS, choose Settings > Wireless
& networks > Wi-Fi, and select WPS. Within 2 minutes, press and hold the
WPS button on your router until the WPS indicator on the router begins to blink.
USB
Your M210 at a glance
Connecting cables
1. Connecting to a TV: Insert the M210's HDMI out plug into the TV's HDMI
in port. To prevent the TV from blocking the M210's wireless reception,
connect the M210 to an HDMI port on the outside edge of the TV. As
shown in Figure 1, insert the M210 into a position marked with √ instead
of one with X.
3 FAQs
1. I can't directly insert the M210 to my TV's HDMI in. What can I do?
Use an M210 HDMI extension cable.
2. I connected my TV to the M210, but nothing is displayed. What can
I do?
Make sure all cables are connected correctly and your TV is switched to
HDMI input. If this problem occurs when you fi rst use the M210, your TV
resolution may be too low or the M210 may be in standby mode. In the
latter case, press on the remote control to wake up the M210.
3. I connected the M210 to my TV, but the image is not displaying
properly. I am experiencing issues, such as incorrect video ratio,
color distortion, or color bars. What can I do?
Make sure that the M210 is securely connected to the HDMI port of
your TV. Choose Settings > Devices > Display. Select an appropriate
resolution for your TV. If the problem persists, video settings, such as the
saturation and contrast of the TV and M210 may be imbalanced. In this
case, adjust the settings to appropriate values.
4. After I connected the M210 to my TV, the image is displaying
properly but I cannot hear any sounds. What can I do?
Check that your TV and M210 are not muted and the volume has not
been turned down too low.
5. After I connected the M210 to my TV, I can hear sounds but I am not
getting any images. What can I do?
This is normal behavior if you are playing audio programs like music. If
you are not playing audio programs, the brightness of your TV or M210
may be set too low. If this happens, restart the M210 and increase the
brightness.
6. What can I do if my remote control is not responsive?
Check that the batteries have suffi cient power and are installed correctly.
Stay within 8 meters of the M210. If the problem persists, see the next
question (number 7).
7. I replaced my remote control but the new one does not work. How
do I fi x it?
Restart the M210. When the M210 is starting, the TV fi rst displays the
Huawei logo then the startup animation. While the animation is displayed,
press and hold OK and on the remote control simultaneously for 5
seconds. Release the buttons before the home screen is displayed. If the
problem persists, restart the M210 and try again.
8. What can I do if I cannot connect to a wireless network?
Make sure you have entered the correct password for the wireless
network and your router is working properly.
9. How do I improve my M210's wireless reception?
Make sure that the TV is not blocking the M210 and place the M210 near
the wireless router. Use a device, such as a Wi-Fi repeater, to extend the
wireless range. Keep your M210 away from devices that may interfere
with it, for example, microwaves, electromagnetic ovens, and other
devices with microwave radiation.
10.
How do I reset the M210?
Choose
Settings >
Personal and select
Factory data reset .
196721964_01
2. Connecting to a power supply: Connect the smaller end of the USB cable
to the M210's micro USB port and the other end to the TV's USB port.
See method 1 in Figure 2.
Power port HDMI out
Figures in this guide are for your reference only. The actual
products may vary.
Power port Connects to a USB power cable.
HDMI out Connects to an HDTV or HD display.
Figure 1
Figure 2
Method 2
Front view Rear view
• WPS is a convenient way to set up a wireless connection.
• Each router's WPS button may function differently. For details,
refer to the specifi c router's user guide.
The TV or display must support 720p or higher.
2 Remote control
Optional remote control devices
In addition to the dedicated remote control, you can use a Bluetooth 4.0
mouse or keyboard.
• When you use a mouse as a remote control, the left mouse button
functions as the Confi rm button and the right button as Return.
• When you use a keyboard as a remote control, the Enter key functions as
the Confi rm button, Esc as Return, and up, down, left, and right keys as
Navigation.
OK
Open the Menu
OK button
Back/ Home button
Volume down/up
Play/Pause
Navigation buton
Function button
Enter standby mode
or wake up
• Press to return to
the previous screen
• Press and hold to
return to the main
menu
Bluetooth remote control
Install batteries in the remote control and use it to control the M210 via
Bluetooth.
After the M210 enters standby mode, wait at least 6 seconds before pressing
the to wake it up again.
See onscreen
instructions.
• The remote control uses two AAA batteries.
• The remote control enters sleep mode to save power if it has been
idle for more than 30 minutes. There might be a slight 2 second
delay before it becomes responsive again after it wakes up.
For more information
Please visit www.huaweidevice.com/worldwide/support/hotline for recently
updated hotline and email address in your country or region.
If your TV does not have an HDMI port on any of its edges, you
can use an M210 HDMI extension cable to connect the M210 to
your TV. For maximum signal reception, the M210 should not be
blocked by the TV.
• Built-in wireless module: Enables the M210 to connect to a Wi-Fi network.
• Built-in Bluetooth module: Connects to a mouse, keyboard, speaker,
remote control, game controller.
The M210 is compatible with most mainstream wireless keyboards
and mice available on the market. However, the Logitech V470 Mouse
and Logitech Tablet Keyboard are recommended (not for iPad).
If the M210 is not working properly after being connected to the
TV's USB port, the power supply from the TV's USB port may
be insuffi cient. In this case, use the 5 V 1 A power adapter. See
method 2 in Figure 2.
Method 1
Connecting to a Bluetooth device
Make sure Bluetooth is enabled on the Bluetooth device (not including
Bluetooth remote controls).
Choose
Settings > Wireless & networks > Bluetooth . Select Search
for devices then the desired Bluetooth device, and enter the password if
prompted.
