Huawei Technologies U2801-5 UMTS/GPRS/GSM/EDGE Mobile Phone with BT User Manual

Huawei Technologies Co.,Ltd UMTS/GPRS/GSM/EDGE Mobile Phone with BT

User Manual

Copyright © Huawei Technologies Co., Ltd. 2012. All rights
reserved.
No part of this document may be reproduced or transmitted in
any form or by any means without prior written consent of
Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted
software of Huawei Technologies Co., Ltd. and possible licensors.
Customers shall not in any manner reproduce, distribute, modif y,
decompile, disassemble, decrypt, extract, reverse engineer, lease,
assign, or sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by
respective copyright holders under licenses.
Trademarks and Permissions
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
Notice
Some features of the product and its accessories described herein
rely on the software installed, capacities and settings of local
network, and may not be activated or may be limited by local
network operators or network service providers. Thus the
descriptions herein may not exactly match the product or its
accessories you purchase.
Huawei Technologies Co., Ltd. reserves the right to change or
modify any information or specifications contained in this manual
without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN
NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE
FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA,
GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws
and regulations and will obtain all necessary governmental permits
and licenses in order to export, re-export or import the product
mentioned in this manual including the software and technical
data therein.
Safety Precautions
Please read the safety precautions carefully to ensure the correct
use of your mobile phone.
Do not crash, throw, or puncture your mobile phone.
Avoid the falling, squeezing, and bending of your mobile
phone.
Do not use your mobile phone in a moist environment,
such as the bathroom. Prevent your mobile phone from
being soaked or washed in liquid.
Do not switch on your mobile phone when it is
prohibited to use phones or when the phone may cause
interference or danger.
Do not use your mobile phone while driving.
Follow any rules or regulations in hospitals and health
care facilities. Switch off your mobile phone near
medical apparatus.
Switch off your mobile phone in aircraft. The phone may
cause interference to control equipment of the aircraft.
Switch off your mobile phone near high-precision
electronic devices. The phone may affect the
performance of these devices.
Do not attempt to disassemble your mobile phone or its
accessories. Only qualified personnel are allowed to
service or repair the phone.
Do not place your mobile phone or its accessories in
containers with a strong electromagnetic field.
Do not place magnetic storage media near your mobile
phone. Radiation from the phone may erase the
information stored on them.
Do not put your mobile phone in a high-temperature
place or use it in a place with flammable gas such as a
gas station.
Keep your mobile phone and its accessories away from
children. Do not allow children to use your mobile
phone without guidance.
Use only approved batteries and chargers to avoid the
risk of explosions.
Observe any laws or regulations on the use of wireless
devices. Respect others' privacy and legal rights when
using your wireless device.
Strictly follow the relevant instructions of this manual
while using the USB cable. Otherwise your mobile phone
or PC may be damaged.
i
Contents
1 Getting Started ................................................................ 1
SIM/USIM Card and Battery ............................................... 1
microSD Card .................................................................... 1
Charging the Battery ......................................................... 2
Your Phone ....................................................................... 3
Keys and Functions ............................................................ 4
Screen Icons ...................................................................... 6
Power Saving Mode........................................................... 8
2 Voice Services .................................................................. 9
Making a Call .................................................................... 9
Answering a Call ............................................................. 10
Options During a Call....................................................... 10
3 Text Inp ut ...................................................................... 10
Entering English............................................................... 11
Entering Digits ................................................................. 12
Entering Symbols ............................................................. 12
4 Messaging ..................................................................... 12
5 Contacts ......................................................................... 13
Creating a Contact .......................................................... 13
Searching for a Contact ................................................... 13
6 Multimedia .................................................................... 13
Camera ........................................................................... 13
Sound Recorder ............................................................... 14
Music Player .................................................................... 14
7 USB ................................................................................ 15
Installing PC Suite ............................................................ 15
Using the Phone as a Modem .......................................... 16
ii
USB disk .......................................................................... 16
8 Bluetooth ....................................................................... 17
Using a Bluetooth Headset .............................................. 17
Transferring Data ............................................................. 17
9 Access the Internet ........................................................ 18
Setting the Connection Profile ......................................... 18
Connecting to the Network ............................................. 18
10 Security ........................................................................ 19
Locking the Keypad ......................................................... 19
Phone Lock ..................................................................... 19
PIN and PUK.................................................................... 19
11 Warnings and Precautions ........................................... 20
1
1 Getting Started
SIM/USIM Card and Battery
The SIM/USIM card contains personal information such as your
phone number, contacts, messages, and secret codes.
Before using the phone, install a SIM/USIM card on the phone.
Power off the phone before removing the SIM/USIM card or the
battery.
The following figures show the installation of the SIM/USIM card
and the battery.
2
1
Handle and store the SIM/USIM card with care.
Do not bend or scratch the SIM/USIM card.
Keep the SIM/USIM card away from static electricity, water, or dirt.
microSD Card
Your phone supports a microSD card (memory card) with a
capacity up to 8 GB.
The following figure shows the installation of the microSD card.
2
Charging the Battery
Although the lithium battery of the mobile phone can be used
immediately after being unpacked from the gift box, a new
battery performs best after being fully charged and discharged for
3 times.
The following figure shows how to charge your battery.
When the icon is displayed or the charging animation becomes
static, the battery is fully charged.
If the battery has not been used for a long time or if the battery runs
out of power, the charging icon may appear several minutes later after
you start charging the battery.
3
Your Phone
The following figure shows the appearance and different parts of
your phone and is for your reference only.
1 Earpiece 2 Screen
3 Navigation keys 4 Left soft key
5 Speaker key 6 Call/Answer key
7 Number keys 8 * key
9 Headset jack 10 Charger jack
11 # key 12 End/Power key
13 Clear key 14 Right soft key
15 Confirm key
4
Keys and Functions
In this guide, the navigation keys of your phone are indicated by the
following icons: , , , and .
Press... To...
Make a call.
Answer a call.
View call logs in standby mode.
Power the phone on or off (press and hold the
key for about 3 seconds).
End or reject a call.
Return to standby mode.
Turn the keypad light on or off in standby mode.
Select the option displayed in the lower left corner of
the screen.
Select the option displayed in the lower right corner
of the screen.
Enable or disable the speaker during a call.
5
Press... To...
In text input mode, delete the character on the
left of the cursor. Press and hold the key for
about 3 seconds to clear all the characters on the
left of the cursor.
Delete a selected item.
Confirm a selection.
To set the standby screen mode, select Menu >
Settings > Display > Standby screen.
If Standby screen is set to Shortcut, press or
to select a shortcut, and then press to
access the function.
If Standby screen is set to Concise mode, access
the functions assigned to the navigation keys in
standby mode.
-
Enter numbers, letters, and symbols.
Call voicemail in standby mode (press and hold
the 1 key for about 3 seconds).
Speed-dial phone numbers in standby mode
(press and hold the 2-9 keys for about 3 seconds).
6
Press... To...
Enter * (press the key once), + (press the key
twice), P (press the key three times), or W (press
the key four times) when entering phone
numbers.
Enable or disable the Meeting profile in standby
mode (press and hold the key for about 3
seconds).
Enter #.
Lock the keypad in standby mode (press and hold
the key for about 3 seconds).
Screen Icons
Icon Indicates...
Signal strength.
Battery level.
Charging.
2G network available.
The phone is receiving and sending data through 2G
network.
7
Icon Indicates...
3G network available.
The phone is receiving and sending data through 3G
network.
New text messages.
New multimedia messages.
The memory for saving the text messages is full.
The memory for saving the multimedia messages is
full.
New emergency messages.
New voicemail available.
Missed calls.
General profile activated.
Silent profile activated.
Meeting profile activated.
Outdoor profile activated.
8
Icon Indicates...
My profile 1 activated.
My profile 2 activated.
Alarms enabled.
Music is being played in the background.
Bluetooth turned on.
Bluetooth headset connected.
Headset connected.
microSD card installed.
The phone is outside of your coverage area
(roaming).
Power Saving Mode
Select Menu > Settings > Phone > Power-saving mode to
enable or disable this function. If the power-saving mode is
enabled, the keypad backlight will be off from 9:00 to 17:00.
9
2 Voice Services
Making a Call
1. In standby mode, enter a phone number.
To make an international call, press twice to enter the
plus sign (+). Then enter the country or region code, area
code, and phone number.
To call an extension number, enter the phone number, press
three times to enter P or four times to enter W, and
enter the extension number.
2. Press to dial the number.
3. Press to end the call.
If you enter P between the phone number and the extension number,
after the phone number is connected, the phone automatically dials
the extension number.
If you enter W between the phone number and the extension number,
after the phone number is connected, the phone prompts you to
choose whether to dial the extension number.
You can also make a call from call logs, contacts, and messages.
10
Answering a Call
When there is an incoming call:
Press or to answer the call.
Press (Silence) to mute the ring volume, and then
press (Reject) to reject the call.
Press to reject the call.
If the Any key answer function is enabled, you can press any
key except and to answer the call.
If the Headset auto-answer function is enabled and if a
headset is connected to the phone, the phone automatically
answers the call.
Options During a Call
During the call, you can:
Press to turn the speaker on or off.
Press to mute or unmute the microphone. If the
microphone is muted, the other party cannot hear you.
Press and to adjust the volume.
3 Text Input
The current text input mode indicator is displayed in the upper
right corner of the screen. Press to switch between text
input modes.
11
Press once to delete the character on the left of the cursor, or
press and hold to delete all the characters on the left of the
cursor.
When editing a message, select Options > Text input settings to
change the input language, enable or disable the first letter capitalized
or predictive input mode.
In any input mode (except the "123" input mode), press to
enter a space, and press to display the commonly used symbol
list.
Entering English
In multi-tap input mode, press the key labeled with the desired
letter once to enter the first letter on the key, twice to enter the
second letter, and so on.
Press once to enter a space, twice to enter a newline character,
and three times to enter 0.
In predictive input mode:
1. Press each key once according to the spelling sequence of the
desired word. The phone displays candidate words.
2. Press or to scroll to the desired word.
3. Press to enter the desired word.
12
Entering Digits
In "123" input mode, simply press the number keys labeled
with the desired digits.
In other input modes, press and hold the number key for about
3 seconds to enter the desired digit.
Entering Symbols
To enter symbols:
1. Press to display the symbol list.
2. Press to scroll to the desired symbol.
3. Press to enter the desired symbol.
4 Messaging
Contact your service provider to determine the availability of the
Multimedia Messaging Service (MMS) and how to subscribe to the
service.
Open multimedia messages with caution. Objects in multimedia
messages may contain viruses and malicious software that can damage
your phone.
1. Select Menu > Messages > Create message.
2. Add recipients by entering the phone numbers, or pressing
and then selecting the recipients from contacts.
3. Edit the message. You can press , and then add pictures,
audio clips, and other attachments.
4. Select Options > Send to send the message.
13
5 Contacts
Creating a Contact
1. Select Menu > Contact > Create contact.
2. Enter the contact information.
3. Press (Save) to save the contact.
If the default storage location is the SIM/USIM card, you can only edit the
name and the phone number. To set the default storage location, select
Menu > Contact > Options > Manage contacts > Default storage
location.
Searching for a Contact
1. Select Menu > Contact.
2. Enter the contact name, or the first several letters of a contact
name.
3. Press and to scroll to the contact.
6 Multimedia
Camera
To use the camera, select Camera, and press to take a
picture.
You can press (Options) to configure relevant settings.
Press and to scroll to an item.
Press to select the item.
14
Press and to change the settings.
Sound Recorder
Select Menu > Entertainment > Recorder to display the sound
recorder, and then press to start recording an audio clip.
During the recording, press to pause or continue, or press
to stop recording the audio clip and save it.
Music Player
Creating a Playlist
1. Select Menu > Entertainment > Music > Options > Media
library > Playlist.
2. Select Options > Create to create a playlist. If there is no
playlist, press (Create) to create a playlist.
3. Add or edit the playlist name.
4. Select the playlist, press to open it.
5. Press (Add) to add audio files to the playlist.
Playing Music
Select Menu > Entertainment > Music to display the music
player.
Select a file, and press to play it. During the playback, you
can:
Press to pause or continue.
Press and to adjust the volume.
15
Press to switch to the previous file, or press and hold
to fast-forward a song.
Press to switch to the next file, or press and hold to
rewind a song.
Press to exit the music player screen and play the
music in the background.
7 USB
Connect your phone to a PC with the USB cable, double click My
Computer, find the disk named ORINOQUIA and double click it.
A dialog box will appear on your PC.
Select your desired function in the dialog box:
Conexión Orinoquia: use the phone as a USB modem.
Herramienta Orinoquia: use the phone through PC Suite on
the PC.
Transferencia de Archivos: use the phone as a USB mass
storage device.
If the PC cannot recognize your phone, restart the PC, and then retry.
If the dialog box does not appear, open My Computer and find the
driver for the phone (appears as a CD driver).
Installing PC Suite
PC Suite helps you perform most of the phone operations on a PC.
To download the latest PC Suite software, go to
16
http://www.huaweidevice.com, and then search for the desired
software.
To install the PC Suite:
1. Run the installation program.
2. Follow the wizard to complete the installation.
3. Restart your PC for the installation to take effect.
Using the Phone as a Modem
The USB modem driver and management program runs
automatically when you use the USB modem function for the first
time. Follow the wizard to complete installation.
After installation, start the management program, set up a
connection, and then access the Internet.
For details, contact your network service provider.
Only the Windows 2000, Windows XP, 32-bit and 64-bit versions of
Windows Vista, and Windows 7 operating systems support the
function.
USB disk
Your phone can be used as a USB mass storage device. You can
save files to the microSD card.
When you are using the USB disk function, other USB functions
are unavailable.
17
8 Bluetooth
Your phone supports Bluetooth. You can synchronize files
between your phone and a PC, transfer data between your phone
and other Bluetooth devices, and talk on the phone using a
Bluetooth headset.
Select Menu > Settings > Connectivity > Bluetooth, and then
switch on or off the Bluetooth.
Using a Bluetooth Headset
A Bluetooth headset is not included in the product package and
must be purchased separately.
1. Select Search for devices to search for the Bluetooth devices.
2. Select your Bluetooth headset from the list.
3. Press (Select).
4. Enter the password of the Bluetooth headset to pair the
headset with your phone. When the Bluetooth headset is
connected to your phone, the headset icon is displayed on the
standby screen, indicating that you can use the headset.
Transferring Data
Select Search for devices to search for available Bluetooth
devices, and then pair your phone with the desired device. Then
you can transfer data between your phone and the Bluetooth
device.
When you pair your phone with the device for the first time, a
password is required.
18
9 Access the Internet
Setting the Connection Profile
Before accessing the Internet using your phone, set up your
account first. Generally, the account has been preset on your
phone and you only need to activate the account. If no accounts
are found on your phone, contact your service provider for the
account information, and then create an account. To activate an
account:
1. Select Menu > Browser > Settings > Network settings.
2. Scroll to the desired account.
3. Press to activate the account.
Connecting to the Network
You can browse webpages on your phone after setting the
connection profile. To access a webpage, you can:
Select Menu > Browser > Open homepage to display the
home page.
Select Menu > Browser > Open new page, and enter a
website address.
Select Menu > Browser > Bookmarks, and select one from
the list.
Select Menu > Browser > History, and select one from the list.
19
10 Security
Locking the Keypad
In standby mode, press and hold for about 3 seconds to
lock the keypad. When the keypad is locked, you can press
to answer a call or make an emergency call.
To unlock the keypad, press then in quick
succession. If the Auto keypad lock function is enabled, the
phone will lock the keypad automatically after being idle in
standby mode for a pre-defined period.
Phone Lock
The phone lock protects your phone from unauthorized use and
factory settings restoration. By default, the phone lock is disabled.
Once the phone lock is enabled, you must enter a passcode each
time you power on the phone.
The preset passcode is 000000. You can select Menu >
Settings > Security > Change phone lock code to change the
passcode to any numeric string of four to eight digits. Do
remember your passcode. If you forget it, contact the service
center.
PIN and PUK
The personal identification number (PIN) protects your SIM/USIM
card from unauthorized use. The PIN unblocking key (PUK) unlocks
a blocked PIN. Both the PIN and the PUK are provided with the
SIM/USIM card. For details, contact your service provider.
20
If you enter the incorrect PIN a specified number of times, the
phone prompts you to enter the PUK.
If you enter the incorrect PUK a specified number of times, the
SIM/USIM card will become permanently invalid. If this occurs,
contact your service provider for a new SIM/USIM card.
11 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains information
about how to use the device safely. Read this information carefully
before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not use
the device when using the device causes danger or interference
with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and health
care facilities. Do not use your device when using the device is
prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on the
opposite side of the pacemaker and do not carry the device in
your front pocket.
21
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas that
may have potentially explosive atmospheres include the areas
where you would normally be advised to turn off your vehicle
engine. Triggering of sparks in such areas could cause an
explosion or a fire, resulting in bodily injuries or even deaths. Do
not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio equipment in
fuel depots, storage, and distribution areas, and chemical plants.
In addition, adhere to restrictions in areas where blasting
operations are in progress. Before using the device, watch out for
areas that have potentially explosive atmospheres that are often,
but not always, clearly marked. Such locations include areas below
the deck on boats, chemical transfer or storage facilities, and areas
where the air contains chemicals or particles such as grain, dust,
or metal powders. Ask the manufacturers of vehicles using
liquefied petroleum gas (such as propane or butane) whether this
device can be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive safely.
Do not talk on the device while driving. Use hands-free
accessories.
22
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles. For
more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag or
in the air bag deployment area. Otherwise, the device may hurt
you owing to the strong force when the air bag inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless devices
in an aircraft may cause danger to the operation of the aircraft
and disrupt the wireless telephone network. It may also be
considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may result
in a malfunction of the circuit.
The device complies with the RF specifications when the device
is used near your ear or at a distance of 1.5 cm from your body.
Ensure that the device accessories such as a device case and a
device holster are not composed of metal components. Keep
your device 1.5 cm away from your body to meet the
requirement earlier mentioned.
On a stormy day with thunder, do not use your device when it
is being charged, to prevent any danger caused by lightning.
23
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the standby
time are reduced.
While using the device, observe the local laws and regulations,
and respect others' privacy and legal rights.
Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device powered by a battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset volume
to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may be
dangerous, as it may present a choking hazard. Ensure that small
children are kept away from the device and accessories.
Accessories
Choose only batteries, chargers, and accessories approved for use
with this model by the device manufacturer. The use of any other
type of battery, charger, or accessory may invalidate any warranty
for the device, may be in violation of local rules or laws, and may
be dangerous. Please contact your dealer for information about
24
the availability of approved batteries, chargers, and accessories in
your area.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of times
before it eventually wears out. When the standby time and the
talk time are shorter than the normal time, replace the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
Do not connect two poles of the battery with conductors, such
as metal materials, keys, or jewelries. Otherwise, the battery
may be short-circuited and may cause injuries and burns on
your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating, fire,
or explosion.
If battery electrolyte leaks out, ensure that the electrolyte does
not touch your skin and eyes. When the electrolyte touches
your skin or splashes into your eyes, wash your eyes with clean
water immediately and consult a doctor.
25
If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise, it
may lead to battery leakage, overheating, explosion, or fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the cable
at once. Otherwise, it may lead to an electric shock, a short
circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Danger of explosion if battery is incorrectly replaced. Recycle or
dispose of used batteries according to the local regulations or
reference instruction supplied with your device.
Cleaning and Maintenance
The device, battery, and charger are not water-resistant. Keep
them dry. Protect the device, battery, and charger from water
or vapor. Do not touch the device or the charger with a wet
hand. Otherwise, it may lead to a short circuit, a malfunction of
the device, and an electric shock to the user.
Do not place your device, battery, and charger in places where
they can get damaged because of collision. Otherwise, it may
lead to battery leakage, device malfunction, overheating, fire,
or explosion.
26
Do not place magnetic storage media such as magnetic cards
and floppy disks near the device. Radiation from the device
may erase the information stored on them.
Do not leave your device, battery, and charger in a place with
an extreme high or low temperature. Otherwise, they may not
function properly and may lead to a fire or an explosion. When
the temperature is lower than 0°C, performance of the battery
is affected.
Do not place sharp metal objects such as pins near the earpiece.
The earpiece may attract these objects and hurt you when you
are using the device.
Before you clean or maintain the device, power off the device
and disconnect it from the charger.
Do not use any chemical detergent, powder, or other chemical
agents (such as alcohol and benzene) to clean the device and
the charger. Otherwise, parts of the device may be damaged or
a fire can be caused. You can clean the device and the charger
with a piece of damp and soft antistatic cloth.
Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all conditions.
You should not rely solely on the device for essential
27
communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is designed
not to exceed the limits for exposure to radio waves. These
guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing Radiation
Protection (ICNIRP) and include safety measures designed to
ensure safety for all users, regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of measurement for
the amount of radio frequency energy absorbed by the body when
using a device. The SAR value is determined at the highest
certified power level in laboratory conditions, but the actual SAR
level of the device when being operated can be well below the
value. This is because the device is designed to use the minimum
power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6 watts/kilogram
(W/kg) averaged over one gram of tissue. The highest SAR value
reported to the FCC and IC for this device type when tested for
use at the ear is 1.21 W/kg, and when properly worn on the body
is 1.20 W/kg.
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
28
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However,there is no guarantee that interference will not occur in a
particular installation.If this equipment does cause harmful
interference to radio or television reception,which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
29
Changes or modifications made to this device not expressly approved by
Huawei Technologies Co., Ltd. may void the FCC authorization to operate
this device.
Version: 01 Part Number: 31010xxx

Navigation menu
