Huawei Technologies U5760 UMTS Mobile Phone User Manual User Guide
Huawei Technologies Co.,Ltd UMTS Mobile Phone User Guide
User Guide
![](/img.php?id=2396756&img=bg1.png)
Quick Start Guide
Orinoquia
U5760
![](/img.php?id=2396756&img=bg2.png)
Copyright © Industria Electrónica Orinoquia S.A. 2014. All
rights reserved.
No part of this manual may be reproduced or transmitted in any
form or by any means without prior written consent of Industria
Electrónica Orinoquia S.A.
The product described in this manual may include copyrighted
software of Industria Electrónica Orinoquia S.A. and possible
licensors. Customers shall not in any manner reproduce, distribute,
modify, decompile, disassemble, decrypt, extract, reverse engineer,
lease, assign, or sublicense the said software, unless such restrictions
are prohibited by applicable laws or such actions are approved by
respective copyright holders.
Trademarks and Permissions
and Orinoquia are trademarks or
registered trademarks of Industria Electrónica Orinoquia S.A.
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
Industria Electrónica Orinoquia S.A. is under license.
Other trademarks, product, service and company names mentioned
may be the property of their respective owners.
Notice
Some features of the product and its accessories described herein
rely on the software installed, capacities and settings of the local
network, and therefore may not be activated or may be limited by
local network operators or network service providers.
Thus, the descriptions herein may not exactly match the product or
its accessories which you purchase.
Industria Electrónica Orinoquia S.A. reserves the right to change or
modify any information or specifications contained in this manual
without prior notice and without any liability.
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
EVENT SHALL INDUSTRIA ELECTRÓNICA ORINOQUIA S.A. BE LIABLE
FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE, DATA,
GOODWILL SAVINGS OR ANTICIPATED SAVINGS REGARDLESS OF
WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO
LIABILITY FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW
PROHIBITS SUCH A LIMITATION) OF INDUSTRIA ELECTRÓNICA
ORINOQUIA S.A. ARISING FROM THE USE OF THE PRODUCT
DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE AMOUNT
PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and be responsible to obtain all necessary governmental
permits and licenses in order to export, re-export or import the
product mentioned in this manual including the software and
technical data therein.
![](/img.php?id=2396756&img=bg5.png)
Safety Precaution
Please read these safety precautions carefully before operating your
phone.
Do not crush, throw, or puncture your phone. Avoid
dropping, squeezing, or bending it also.
Your phone is not meant for use in a damp
environment, such as the bathroom. Do not
submerge your phone in liquid of any sort and avoid
getting your phone wet.
Avoid using your mobile phone in areas where it may
cause interference or present a hazard. Follow local
laws and regulations.
Avoid using your phone while driving. Your safety
should always be your top priority.
Follow any rules or regulations in hospitals and health
care facilities. Power off your phone near any medical
apparatus.
Power off your phone in an aircraft. The phone may
interfere with the aircraft's control equipment and
navigation system.
Power off your phone near high-precision electronic
devices. The phone may affect the performance of
these devices.
![](/img.php?id=2396756&img=bg6.png)
Do not attempt to disassemble your phone or its
accessories. Only qualified personnel are allowed to
service or repair the phone.
Do not place your phone or its accessories in
containers with a strong electromagnetic field.
Do not place magnetic storage media near your
phone. Radio waves from the phone may erase the
information stored on them.
Do not expose your phone to extreme temperatures
or use it at a location with flammable materials, such
as a gas station.
Keep your phone and its accessories away from
children. Do not allow young children to use your
phone without adult supervision.
Use only approved batteries and chargers to avoid
the risk of explosions.
Observe any laws or regulations on the use of
wireless devices. Respect the privacy and legal rights
of others when using your phone.
To prevent damage to your phone or your computer,
follow all instructions pertaining to the USB cable.
![](/img.php?id=2396756&img=bg7.png)
1
1 Your Phone
1 Earpiece 2 Screen
3 Confirm key 4 Left soft key
5 Call/Answer key 6 Music key
7 Number keys 8 * key
9 Microphone 10 # key
![](/img.php?id=2396756&img=bg8.png)
2
11 Back key 12 End/Power key
13 Right soft key 14 Navigation keys
15 Camera 16 Loudspeaker
17 Headset jack 18 Charger jack/USB
port
![](/img.php?id=2396756&img=bg9.png)
3
2 Installing the SIM Card and Battery
Before you begin to use your phone, a SIM card must be inserted.
Follow the steps laid out below to insert your SIM card into the
phone.
Power off your phone before attempting to remove the battery or SIM card.
a
b
![](/img.php?id=2396756&img=bga.png)
4
3 Inserting the microSD Card
a
b
b
a
4 Charging the Battery
When the battery icon changes to or the charging animation
becomes static, the battery is fully charged.
If the battery has not been used for a long time or if the battery
power is completely depleted, the charging icon may take
several minutes to appear after you start charging.
![](/img.php?id=2396756&img=bgb.png)
5
5 Keys and Functions
In this guide, the navigation keys of the phone are indicated by , ,
, , , .
Press
To
Select the option displayed in the lower left corner of
the screen.
Select the option displayed in the lower right corner of
the screen.
Dial a number or answer a call.
Access call logs in standby mode.
Power the phone on or off (press and hold the key
for about 3 seconds).
End or reject a call.
Return to standby mode.
Turn the backlight on or off in standby mode.
Start the music.
![](/img.php?id=2396756&img=bgc.png)
6
Press
To
In text input mode, delete the character to the left
of the cursor. Press and hold the key for 3 or more
seconds to clear all the characters to the left of the
cursor.
Return to the previous menu.
Confirm a selection.
Access the functions assigned to the navigation keys in
standby mode.
–
Enter numbers, letters, and symbols in text input
mode.
Call voicemail in standby mode (press and hold
for about 3 seconds).
Speed-dial phone numbers in standby mode (press
and hold the keys – for about 3
seconds).
Enter
*
,
+
,
P
or
W
when entering phone numbers.
Enable or disable the
Meeting
profile in standby
mode (press and hold the key for about 3 seconds).
![](/img.php?id=2396756&img=bgd.png)
7
Press
To
Enter
#
.
Lock the keypad in standby mode (press and hold
the key for about 3 seconds).
6 Text Input
Changing the Text Input Mode
The current text input mode indicator is displayed in the upper right
corner of the text input screen. To switch between the text input
modes, press .
Entering a Word
In multi-tap input mode, press the number key labeled with the
desired letter once to enter the first letter on the key, twice to enter
the second letter on the key, and so on.
In predictive input mode:
1. Press each key according to the spelling sequence of the desired
word. The phone displays candidate words that may be spelt by
the keystroke sequence.
2. Press to scroll to the desired word.
3. Press to enter the desired word, or to enter the
word followed by a space.
Entering a Number
In 123 input mode, press the key labeled with the desired
![](/img.php?id=2396756&img=bge.png)
8
number.
In any input mode other than 123 input mode, press and hold
the number key for about 3 seconds to enter the desired number.
Entering a Symbol
1. In any input mode, press to display the symbol list.
2. Press to scroll to the desired symbol.
3. Press to enter the symbol.
7 Creating a Contact
1. Select Menu > Contacts > Create Contact.
2. Edit the contact information.
3. Press or to save the contact.
8 Making and Answering a Call
In standby mode, press the number keys - to enter
a phone number, and then press to dial the number.
When you receive an incoming call, press to answer it, or
to reject it.
9 Creating and Sending a Message
1. Select Menu > Messages > Create Message.
2. Enter a phone number, or press and then select the recipient
from Contacts.
3. Edit the message. You can select Options > Insert Object to add
picture, audio, video or other attachments to the message.
![](/img.php?id=2396756&img=bgf.png)
9
4. Select Options > Send to send the message.
10 Camera
Select Menu > Multimedia > Camera, and press to take a photo.
On the Camera screen, press (Options) to configure
camera settings.
To view your photos, select Options > Go to Album.
To set the default storage location, select Options > Settings >
Storage Location.
11 Playing Music
Select a music file from the playlist and press to play it.
While the music is playing:
Press to pause or continue playing.
Press to play the next song. Press and hold for about
3 seconds to fast-forward the song.
Press to play the previous song. Press and hold for
about 3 seconds to rewind the song.
Press to display the currently active playlist.
Press to display the media library.
Press (Minimize), , or to exit the music
playback screen. The song will continue to play in the
background.
Select Options > Exit to exit the music player.
![](/img.php?id=2396756&img=bg10.png)
10
12 Locking the Keypad
To lock the keypad, press and hold for about 3 seconds in
standby mode. When the keypad is locked, you can still press
to answer a call or make an emergency call.
To unlock the keypad, press then .
13 Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. To enable or disable the phone
lock, select Menu > Settings > Security > Phone Lock. Once you
enable the phone lock, you must enter the password.
The default password to unlock your phone is 1234, and it can be
changed to any numeric string of four to eight digits in length. You
can select Menu > Settings > Security > Change Phone Lock Code to
change the passcode.
![](/img.php?id=2396756&img=bg11.png)
11
14 Safety Information
This section contains important information about the operation of
your device. It also contains information about how to use the
device safely. Read this information carefully before using your
device.
Electronic device
Do not use your device if using the device is prohibited. Do not use
the device if doing so causes danger or interference with other
electronic devices.
Interference with medical equipment
Follow rules and regulations set forth by hospitals and health
care facilities. Do not use your device where prohibited.
Some wireless devices may affect the performance of hearing
aids or pacemakers. Consult your service provider for more
information.
Pacemaker manufacturers recommend that a minimum distance
of 15 cm be maintained between a device and a pacemaker to
prevent potential interference with the pacemaker. If using a
pacemaker, hold the device on the side opposite the pacemaker
and do not carry the device in your front pocket.
Protecting your hearing when using a headset
Using a headset at high volumes may damage your hearing. To
reduce this risk, lower the headset volume to a safe and
comfortable level.
12
Exposure to high volumes while driving may cause distraction
and increase your risk of an accident.
Areas with flammables and explosives
Do not use the device where flammables or explosives are stored
(in a gas station, oil depot, or chemical plant, for example). Using
your device in these environments increases the risk of explosion
or fire. In addition, follow the instructions indicated in text or
symbols.
Do not store or transport the device in containers with
flammable liquids, gases, or explosives.
Traffic security
Observe local laws and regulations while using the device. To
reduce the risk of accidents, do not use your wireless device
while driving.
Concentrate on driving. Your first responsibility is to drive safely.
Do not hold the device while driving. Use hands-free accessories.
When you must make or answer a call, pull off the road safely
and park the vehicle first.
RF signals may affect the electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
Do not place the device over the air bag or in the air bag
deployment area in a motor vehicle. Doing so may hurt you
because of the strong force when the air bag inflates.
Do not use your device while flying in an aircraft or immediately
before boarding. Using wireless devices in an aircraft may disrupt
13
wireless networks, present a hazard to aircraft operation, or be
illegal.
Operating environment
Avoid dusty, damp, or dirty environments. Avoid magnetic fields.
Using the device in these environments may result in circuit
malfunctions.
Do not use your device during thunderstorms to protect your
device against any danger caused by lightning.
Ideal operating temperatures are 0°C to 35°C. Ideal storage
temperatures are -20°C to 70°C. Extreme heat or cold may
damage your device or accessories.
Do not expose your device to direct sunlight (such as on a car
dashboard) for prolonged periods.
To protect your device or accessories from fire or electrical shock
hazards, avoid rain and moisture.
Keep the device away from sources of heat and fire, such as a
heater, microwave oven, stove, water heater, radiator, or candle.
Do not place sharp metal objects, such as pins, near the earpiece
or speaker. The earpiece may attract these objects and result in
injury.
Stop using your device or applications for a while if the device is
overheated. If skin is exposed to an overheated device for an
extended period, low temperature burn symptoms, such as red
spots and darker pigmentation, may occur.
Do not touch the device's antenna. Otherwise, communication
14
quality may be reduced.
Do not allow children or pets to bite or suck the device or
accessories. Doing so may result in damage or explosion.
Observe local laws and regulations, and respect the privacy and
legal rights of others.
Child's safety
Comply with all precautions with regard to Child Safety. Letting
children play with the device or its accessories may be dangerous.
The device includes detachable parts that may present a choking
hazard. Keep away from children.
The device and its accessories are not intended for use by
children. Children should only use the device with adult
supervision.
Accessories
Using an unapproved or incompatible power adapter, charger or
battery may cause fire, explosion or other hazards.
Choose only accessories approved for use with this model by the
device manufacturer. The use of any other types of accessories
may void the warranty, may violate local regulations and laws,
and may be dangerous. Please contact your retailer for
information about the availability of approved accessories in your
area.
Charger safety
For pluggable devices, the socket-outlet shall be installed near
the devices and shall be easily accessible.
15
Unplug the charger from electrical outlets and the device when
not in use.
Do not drop or cause an impact to the charger.
If the power cable is damaged (for example, the cord is exposed
or broken), or the plug loosens, stop using it at once. Continued
use may lead to electric shocks, short circuits, or fire.
Do not touch the power cord with wet hands or pull the power
cord to disconnect the charger.
Do not touch the device or the charger with wet hands. Doing so
may lead to short circuits, malfunctions, or electric shocks.
If your charger has been exposed to water, other liquids, or
excessive moisture, take it to an authorized service center for
inspection.
Ensure that the charger meets the requirements of Clause 2.5 in
IEC60950-1/EN60950-1 and has been tested and approved
according to national or local standards.
Connect the device only to products with the USB-IF logo or with
USB-IF compliance program completion.
Battery safety
Do not connect battery poles with conductors, such as keys,
jewelry, or other metal materials. Doing so may short-circuit the
battery and cause injuries or burns.
Keep the battery away from excessive heat and direct sunlight.
Do not place it on or in heating devices, such as microwave
ovens, stoves, or radiators. Batteries may explode if overheated.
16
Do not attempt to modify or remanufacture the battery, insert
foreign objects into it, or immerse or expose it to water or other
liquids. Doing so may lead to fire, explosion, or other hazards.
If the battery leaks, ensure that the electrolyte does not make
direct contact with your skins or eyes. If the electrolyte touches
your skins or splashes into your eyes, immediately flush with
clean water and consult a doctor.
In case of battery deformation, color change, or overheating
while charging or storing, immediately stop using the device and
remove the battery. Continued use may lead to battery leakage,
fire, or explosion.
Do not put batteries in fire as they may explode. Damaged
batteries may also explode.
Dispose of used batteries in accordance with local regulations.
Improper battery use may lead to fire, explosion, or other hazards.
Do not allow children or pets to bite or suck the battery. Doing
so may result in damage or explosion.
Do not smash or pierce the battery, or expose it to high external
pressure. Doing so may lead to a short circuit or overheating.
Do not drop the device or battery. If the device or battery is
dropped, especially on a hard surface, and may be damaged.
If the device standby time shortens significantly, replace the
battery.
Cleaning and maintenance
Keep the device and accessories dry. Do not attempt to dry it
17
with an external heat source, such as a microwave oven or hair
dryer.
Do not expose your device or accessories to extreme heat or cold.
These environments may interfere with proper function and may
lead to fire or explosion.
Avoid collision, which may lead to device malfunctions,
overheating, fire, or explosion.
Before you clean or maintain the device, stop using it, stop all
applications, and disconnect all cables connected to it.
Do not use any chemical detergent, powder, or other chemical
agents (such as alcohol and benzene) to clean the device or
accessories. These substances may cause damage to parts or
present a fire hazard. Use a clean, soft, and dry cloth to clean the
device and accessories.
Do not place magnetic stripe cards, such as credit cards and
phone cards, near the device for extended periods of time.
Otherwise the magnetic stripe cards may be damaged.
Do not dismantle or remanufacture the device and its accessories.
This voids the warranty and releases the manufacturer from
liability for damage. In case of damage, contact an authorized
service center for assistance or repair.
If the device screen is broken in a collision, immediately stop
using the device. Do not touch or attempt to remove the broken
parts. Promptly contact an authorized service center.
18
Emergency calls
The availability of emergency calls is subject to your cellular network
quality, service provider policy, and local laws and regulations. Never
rely solely on your device for critical communications like medical
emergencies.
Environmental protection
The device and its accessories (if included), such as the power
adapter, headset, and battery should not be disposed of with
household garbage.
Disposal of the device and its accessories is subject to local
regulations. Support proper collection and recycling.
FCC Regulatory Compliance
Body worn operation
The device complies with RF specifications when used near your ear
or at a distance of 1.5 cm from your body. Ensure that the device
accessories, such as a device case and device holster, are not
composed of metal components. Keep the device away from your
body to meet the distance requirement.
Certification information (SAR)
This device is also designed to meet the requirements for exposure
to radio waves established by the Federal Communications
Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged over one
gram of tissue. The highest SAR value reported to the FCC for this
device type complies with this limit.
19
The highest SAR value reported to the FCC for this device type when
using at the ear is 1.489 W/kg, and when properly worn on the
body is 1.325 W/kg.
FCC statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
20
undesired operation.
Caution: Any changes or modifications to this device not expressly
approved by Industria Electrónica Orinoquia S.A. for compliance
could void the user's authority to operate the equipment.
