Huawei Technologies U8867Z HSPA/UMTS/GPRS/GSM/EDGE Mobile Phone with BT User Manual Normal
Huawei Technologies Co.,Ltd HSPA/UMTS/GPRS/GSM/EDGE Mobile Phone with BT Normal
User Manual
Contents
i
1 Read Before Proceeding .......................................................1
1.1 Safety Precautions....................................................................... 1
1.2 Personal Information and Data Security ...................................... 2
1.3 Legal Notice................................................................................. 3
2 Getting Started.......................................................................6
2.1 Key Functions at Your Fingertips................................................. 6
2.2 Important Information About the Battery...................................... 7
2.3 Power Saving Tips ...................................................................... 7
2.4 Power On or Off Your Mobile Phone ........................................... 8
2.5 Using the Touchscreen................................................................ 9
2.6 Locking and Unlocking the Screen .............................................. 9
2.7 Home Screen............................................................................. 10
2.8 Application Screen..................................................................... 15
2.9 Using a microSD Card ............................................................... 15
3 Calling..................................................................................16
3.1 Making a Call ............................................................................. 16
3.2 Answering or Rejecting a Call.................................................... 17
3.3 Other Operations During a Call ................................................. 19
3.4 Using the Call log....................................................................... 19
3.5 Direct Connect Call.................................................................... 20
3.6 Alerts.......................................................................................... 21
3.7 DC Group Calls.......................................................................... 22
3.8 Direct Connect Settings ............................................................. 25
3.9 Interrupt Request ....................................................................... 26
3.10 Missed DC Event ..................................................................... 26
3.11 Concurrency ............................................................................ 26
3.12 Using Airplane Mode ............................................................... 28
4 Contacts...............................................................................28
ii
4.1 Opening the Contacts Application ............................................. 28
4.2 Importing Contacts from a USIM Card....................................... 28
4.3 Adding a Contact ....................................................................... 29
4.4 Adding a Contact to Your Favorites........................................... 29
4.5 Searching for a Contact ............................................................. 29
4.6 Editing a Contact ....................................................................... 29
4.7 Communicating with Your Contacts........................................... 30
4.8 Deleting a Contact ..................................................................... 30
4.9 Backing Up and Synchronizing Contacts................................... 31
4.10 Joining and Separating Contacts............................................. 31
4.11 Sending Contacts .................................................................... 32
5 Using the Onscreen Keyboard.............................................33
5.1 Displaying the Keyboard............................................................ 33
5.2 Customizing Keyboard Settings................................................. 36
6 Messaging ...........................................................................36
6.1 SMS and MMS........................................................................... 36
6.2 Email.......................................................................................... 38
7 Getting Connected...............................................................41
7.1 Mobile Networks ........................................................................ 41
7.2 Wi-Fi .......................................................................................... 41
7.3 Sharing Your Phone’s Data Connection .................................... 42
7.4 Browser...................................................................................... 43
7.5 Bluetooth.................................................................................... 45
8 Entertainment ......................................................................46
8.1 Taking Photos and Recording Videos ....................................... 46
8.2 Using the Gallery ....................................................................... 48
8.3 Enjoying Music........................................................................... 49
8.4 Listening to the FM Radio.......................................................... 50
9 Google Services ..................................................................51
iii
9.1 Creating a Google Account........................................................ 51
9.2 Gmail ......................................................................................... 52
9.3 Talk ............................................................................................ 53
9.4 Maps .......................................................................................... 55
9.5 YouTube .................................................................................... 56
9.6 Play Store .................................................................................. 56
10 Synchronizing Information .................................................58
10.1 Managing Your Accounts......................................................... 58
10.2 Customizing Your Account Synchronization............................ 60
11 Using Other Applications ...................................................61
11.1 AppInstaller.............................................................................. 61
11.2 Calendar .................................................................................. 61
11.3 File Manager............................................................................ 63
11.4 Clock........................................................................................ 65
11.5 Calculator................................................................................. 66
11.6 Notepad ................................................................................... 66
12 Managing Your Mobile Phone ...........................................67
12.1 Setting the Date and Time ....................................................... 67
12.2 Setting the Display................................................................... 67
12.3 Setting Ringers ........................................................................ 68
12.4 Setting Phone Services ........................................................... 69
12.5 Configuring Text-to-Speech..................................................... 69
12.6 Protecting Your Mobile Phone ................................................. 70
12.7 Managing Applications............................................................. 71
12.8 Resetting Your Mobile Phone .................................................. 72
13 Appendix............................................................................73
13.1 Warnings and Precautions....................................................... 73
13.2 FAQs........................................................................................ 79
1
1 Read Before Proceeding
1.1 Safety Precautions
Please read the safety precautions carefully to ensure the correct use of your mobile
phone.
Do not crash, throw, or puncture your mobile phone. Avoid the
falling, squeezing, and bending of your mobile phone.
Do not use your mobile phone in a moist environment, such as the
bathroom. Prevent your mobile phone from being soaked or washed
in liquid.
Do not switch on your mobile phone when it is prohibited to use
phones or when the phone may cause interference or danger.
Do not use your mobile phone while driving.
Follow any rules or regulations in hospitals and health care facilities.
Switch off your mobile phone near medical apparatus.
Switch off your mobile phone in aircraft. The phone may cause
interference to control equipment of the aircraft.
Switch off your mobile phone near high-precision electronic devices.
The phone may affect the performance of these devices.
Do not attempt to disassemble your mobile phone or its accessories.
Only qualified personnel are allowed to service or repair the phone.
2
1.2 Personal Information and Data
Security
The use of some functions or third-party applications on your device could result in
your personal information and data being lost or becoming accessible to others.
Several measures are recommended to help you protect personal and confidential
information.
• Place your device in a safe area to prevent it from unauthorized use.
• Set your device screen to lock and create a password or unlock pattern to open it.
Do not place your mobile phone or its accessories in containers with
a strong electromagnetic field.
Do not place magnetic storage media near your mobile phone.
Radiation from the phone may erase the information stored on them.
Do not put your mobile phone in a high-temperature place or use it in
a place with flammable gas such as a gas station.
Keep your mobile phone and its accessories away from children. Do
not allow children to use your mobile phone without guidance.
Use only approved batteries and chargers to avoid the risk of
explosions.
Observe any laws or regulations on the use of wireless devices.
Respect others’ privacy and legal rights when using your wireless
device.
Strictly follow the relevant instructions of this manual while using the
USB cable. Otherwise your mobile phone or PC may be damaged.
3
• Periodically back up personal information kept on your USIM card, memory card,
or stored in your device memory. If you change to a different device, be sure to
move or delete any personal information on your old device.
• If you are worried about viruses when you receive messages or emails from a
stranger, you can delete them without opening them.
• If you use your device to browse the Internet, avoid websites that might pose a
security risk to avoid theft of your personal information.
• If you use services such as Wi-Fi tether or Bluetooth, set passwords for these
services to prevent unauthorized access. When these services are not in use, turn
them off.
• Install or upgrade device security software and regularly scan for viruses.
• Be sure to obtain third-party applications from a legitimate source. Downloaded
third-party applications should be scanned for viruses.
• Install security software or patches released by Huawei or third-party application
providers.
• Some applications require and transmit location information. As a result, a third-
party may be able to share your location information.
• Your device may provide detection and diagnostic information to third-party
application providers. Third party vendors use this information to improve their
products and services.
• If you have concerns about the security of your personal information and data,
please contact mobile@huawei.com.
1.3 Legal Notice
Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any
means without prior written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted software of Huawei
Technologies Co., Ltd. and possible licensors. Customers shall not in any manner
reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse
engineer, lease, assign, or sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by respective copyright
holders.
4
Trademarks and Permissions
, , and are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
WOW HD, SRS and the symbol are trademarks of SRS Labs, Inc. WOW HD
technology is incorporated under license from SRS Labs, Inc.
WOW HD™ significantly improves the playback quality of audio, delivering a dynamic
3D entertainment experience with deep, rich bass and high frequency clarity for crisp
detail.
Android is a trademark of Google Inc.
Other trademarks, product, service and company names mentioned are the property
of their respective owners.
Notice
Some features of the product and its accessories described herein rely on the
software installed, capacities and settings of local network, and therefore may not be
activated or may be limited by local network operators or network service providers.
Thus the descriptions herein may not match exactly the product or its accessories you
purchase.
Huawei Technologies Co., Ltd. reserves the right to change or modify any information
or specifications contained in this manual without prior notice and without any liability.
Third-Party Software Statement
Huawei Technologies Co., Ltd. does not own the intellectual property of the third-party
software and applications that are delivered with this product. Therefore, Huawei
Technologies Co., Ltd. will not provide any warranty of any kind for these third-party
software and applications. Neither will Huawei Technologies Co., Ltd. provide support
to customers who use these third-party software and applications, nor be responsible
or liable for the functions of these third-party software and applications.
Third-party software and applications services may be interrupted or terminated at
any time. Huawei Technologies Co., Ltd. does not guarantee that any content or
service would be maintained for any period during its availability. Third-party service
providers provide content and services through network or transmission tools outside
of the control of Huawei Technologies Co., Ltd. To the greatest extent permitted by
applicable law, it is explicitly stated that Huawei Technologies Co., Ltd. shall not
5
compensate or be liable for services provided by third-party service providers, or the
interruption or termination of third-party contents or services.
Huawei Technologies Co., Ltd. shall not be responsible for the legality, quality, or any
other aspects of any software installed on this product, or for any uploaded or
downloaded third-party works, such as texts, images, videos, or software. Customers
shall bear the risk for any and all effects, including incompatibility between the
software and this product, which result from installing software or uploading or
downloading the third-party works.
This product uses the open-source Android™ platform. Huawei Technologies Co.,
Ltd. has made necessary changes to the platform. Therefore, this product may not
support all the functions that are supported by the standard Android platform or may
be incompatible with third-party software. Huawei Technologies Co., Ltd. shall not be
liable for any of such situation.
DISCLAIMER OF WARRANTIES
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS
REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
LIMITATIONS OF LIABILITY
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT
SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST
PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED
SAVINGS.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY
FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS
SUCH A LIMITATION) OF HUAWEI TECHNOLOGIES CO., LTD. ARISING FROM
THE USE OF THE PRODUCT DESCRIBED IN THIS DOCUMENT SHALL BE
LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF
THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations and
be responsible to obtain all necessary governmental permits and licenses in order to
6
export, re-export or import the product mentioned in this manual including the
software and technical data therein.
2 Getting Started
All the pictures in this guide are for your reference only. Your phone’s actual
display features may be different to those described here, depending on its
software version.
2.1 Key Functions at Your Fingertips
• Press and hold to power on your mobile phone.
• Press and hold to open the
Phone options
menu.
• Press to lock the screen when your mobile phone is active.
Touch to open the menu on an active screen.
• Touch to return to the Home screen.
• Touch and hold to show the most recently used applications.
• Touch to return to the previous screen or exit the application
you are running.
• Touch to hide the keyboard.
Touch to search for content on your mobile phone, or on the
web using Google.
• Press to turn the speaker phone on or off during a call.
• Press to turn Direct Connect speaker mode on or off.
7
2.2 Important Information About the
Battery
• If the battery has not been used for a long time, you may not be able to power on
your mobile phone immediately after you begin charging the battery. Allow the
battery to charge for a few minutes with the phone powered off before attempting
to power the phone on.
• As it ages, the battery’s performance will degrade, in particular it will not hold charge
as it did when it was new. When the battery life becomes noticeably shorter than
usual after being charged properly, replace the battery with a new one of the same
type.
• Using data services increases the power consumption of the phone and will
therefore reduce the length of time that the phone can be used between battery
charges.
• The time required to fully charge the battery depends on the ambient temperature
and the age of the battery.
• When the battery power is low, the phone will alert you and display a message.
When the battery power is almost exhausted, your phone will power off
automatically.
2.3 Power Saving Tips
The longevity of battery power depends on the network to which you connect, and
how you use your mobile phone.
Try the following to conserve battery power:
Volume keys
• Press to adjust the voice or speaker volume during a call
• Press to adjust the speaker volume while using the music
player or other applications.
• Press to adjust the incoming notification volume, such as
ringtone volume and Alert volume.
Direct
Connect key Push to use Direct Connect.
8
• When your mobile phone is not in use, turn off the screen backlight.
• Reduce the time it takes for your screen backlight to turn off when your phone is
idle.
• Lower the screen brightness.
• Turn off Bluetooth when you are not using it. Only make your phone visible to other
Bluetooth devices when you need to establish a Bluetooth connection.
• Turn off Wi-Fi when you are not using it.
• Turn off your phone’s GPS receiver when you are not using it.
• Lower the volume.
• Close power-draining programs, when you do not need them.
• Turn off the data service.
2.4 Power On or Off Your Mobile Phone
2.4.1 Powering On Your Mobile Phone
Press and hold . The first time you power on your phone, you will be asked to
sign in to your account and set up your mobile phone.
If personal identification number (PIN) protection is enabled on your mobile
phone, you must enter your PIN before using the mobile phone.
2.4.2 Setting Up Your Mobile Phone
The first time you power on your mobile phone, the phone displays a setup wizard to
help you set up the phone.
The setup wizard helps you:
• Create or sign in to your account
• Make some initial decisions about how you want to use your mobile phone
2.4.3 Powering Off Your Mobile Phone
1. Press and hold to open the
Phone options
menu.
2. Touch
Power off
.
3. Touch
OK
.
9
2.5 Using the Touchscreen
2.5.1 Touchscreen Actions
•
Touch
: Tap the screen with your finger to select an item, confirm a selection, or
start an application.
•
Touch and hold
: Touch an item with your finger and do not release it until the
mobile phone responds. For example, to open the options menu for the active
screen, touch and hold the screen until the menu appears.
•
Flick
: Move your finger either vertically or horizontally across the screen.
•
Drag
: Touch and hold the desired item with your finger. To move an item, drag the
item to any part of the screen. You can drag an icon to move or delete it.
2.5.2 Rotating Your Mobile Phone Screen
The orientation of most screens will change to landscape or portrait view when you
rotate your phone sideways.
On the Home screen, touch >
Settings
>
Display
>
Auto-rotate screen
to disable this function.
2.6 Locking and Unlocking the Screen
2.6.1 Locking the Screen
• When your phone is on, press to lock the screen. When the screen is locked,
you can still receive messages and calls.
• If your phone is idle for a while, the screen will lock automatically.
2.6.2 Unlocking the Screen
1. Press to wake up the screen.
2. Drag the lock icon from left to right to unlock the screen.
10
If you have set up a screen unlock pattern, you will be prompted to draw the
pattern on the screen to unlock it.
2.7 Home Screen
Touch and hold a shortcut until the mobile phone vibrates, you can then drag it
to your desired location or move it to the trash. You can also drag an icon from
another area of the screen to the shortcut position.
10:23
Touch to view all your applications.
Shortcuts
Notification bar:
Displays reminders and phone status icons.
Flick down to open the notification panel.
Display area:
Main display area of the phone.
Home screen and extension indicator
11
2.7.1 Notification and Status Icons
Signal strength No signal
Connected to GPRS
mobile network GPRS in use
Connected to EDGE
mobile network EDGE in use
Connected to 3G mobile
network 3G in use
Roaming Airplane mode
Bluetooth on Receiving location data
from GPS
Vibration mode Alarm enabled
Call muted Charging battery
Battery full Battery extremely low
Call in progress Missed call
Call in progress with a
Bluetooth headset used New mail from Gmail
New text or multimedia
message
Problem with text or
multimedia message
delivery
New chat message New email
12
2.7.2 Notification Panel
Your mobile phone will notify you when you receive a new message or there is an
upcoming event. The notification panel also informs you of alarms and settings. Open
the notification panel to see your network operator or to view a message, reminder, or
event notification.
New voicemail Connected to a PC
Open Wi-Fi network
available Upcoming event
Uploading Downloading
Phone storage space is
getting low Connected to a VPN
Preparing the mircoSD
card
More undisplayed
notifications
Synchronizing data Synchronization failed
Portable Wi-Fi hotspot on USB tethering on
DC call in progress DC group call in progress
DC Speaker off DC Loudspeaker ON
Missed DC call Missed DC Group call
Missed Alert Missed DC Group invite
DC service not available
13
Opening the Notification Panel
1. When a new notification icon appears on the notification bar, place your finger on
the notification bar and flick down to open the notification panel.
You can also open the notification panel from the Home screen: Touch >
Notifications
to open the panel.
2. On the panel, you can:
• Touch a notification to open the related application.
• Touch
Clear
to clear all notifications.
Closing the Notification Panel
Touch and hold the bottom of the panel. Then flick up to close it.
2.7.3 Viewing Other Parts of the Home Screen
On the Home screen, touch >
Home settings
>
Advanced settings
>
Screen number
to set the number of extended screens.
Flick your finger left or
right across the Home
screen.
Touch to view thumbnails
of the Home screen and its
extensions. Touch a thumbnail
to open the screen.
10:23 10:23
14
2.7.4 Customizing the Home Screen
Adding a New Home Screen Item
1. Touch and hold a blank area on the Home screen until the
Add to home screen
menu is displayed.
You can also touch >
Add
on the Home screen to display the
Add to
home screen
menu.
2. Select an item to add it to the Home screen.
Moving a Home Screen Item
1. Touch and hold an item on the Home screen until the item expands in size and the
mobile phone vibrates.
2. Without lifting your finger, drag the item to the desired position on the screen, and
then release it.
Removing a Home Screen Item
1. Touch and hold an item on the Home screen until the item expands and the mobile
phone vibrates.
2. Without lifting your finger, drag the item to the trash can. When the item and the
trash can turn red, the item is ready to be removed.
3. Release the item to remove it from the Home screen.
2.7.5 Service Shortcuts
1. Open the notification bar.
2. Touch at the top of the screen to switch data services on or off.
You can also touch , , or to turn the corresponding services
on or off.
2.7.6 Setting a Home Screen Animation
1. On the Home screen, touch >
Home settings
>
Animation
.
2. Select an animation, and then touch
Save
.
15
2.7.7 Changing the Wallpaper
1. On the Home screen, touch >
Wallpaper
.
2. Touch the following menu items to select a picture and set it as the wallpaper:
•
Gallery
•
Live wallpapers
•
Wallpapers
2.7.8 Changing the Theme
1. On the Home screen, touch >
Home settings
.
2. Do any of the following:
• Touch
Theme
to select a theme.
• Touch
Application icons
to select a series of application icons.
3. Touch
Save
.
2.8 Application Screen
The Application screen holds icons for all of the applications on your phone. You can
touch on the Home screen to open the application screen.
2.8.1 Moving Icons on the Application Screen
1. On the application screen, touch .
2. Touch and hold the icon you want to move on the application screen.
3. Without lifting your finger, drag the icon to the desired location, and then release it.
To move more icons, repeat steps 2 and 3.
4. Touch or to save.
2.9 Using a microSD Card
2.9.1 Using the microSD Card as a USB Mass Storage
To transfer all your favorite music and pictures from your PC to your mobile phone’s
microSD card, set the microSD card as a USB mass storage.
16
1. Connect your mobile phone to your PC with the USB cable provided. Your PC will
detect the microSD card as a removable storage device.
2. Open the notification bar, and then touch
USB connected
.
3. Touch
Turn on USB storage
in the dialog box that opens to confirm that you want
to transfer files.
You can now transfer files from your PC to your mobile phone’s microSD card.
When your microSD card acts as a USB mass storage, your mobile phone will
not use this memory space. Ensure that you follow the correct procedures to
disconnect the USB mass storage device (your mobile phone) from the PC
when you have finished transferring files.
2.9.2 Removing the microSD Card
1. On the Home screen, touch >
Settings
.
2. Scroll down the screen, and then touch
Storage
>
Unmount SD card
.
3. Carefully remove the microSD card.
3 Calling
To make a phone call, you can dial a number using the keypad or touch a number
saved in your contact list, on a webpage, or in other places. When you are in a call,
you can answer other incoming calls or redirect them to your voicemail. You can also
set up conference calls with several participants.
3.1 Making a Call
To make a call, you can use the
Phone
application, or select a number from
Contacts
or
Call log
.
When you are in a call, you can touch to use other functions. To return to the call
screen, flick the notification bar down and touch
Current call
.
Be careful not to block the microphone at the bottom of your phone if you want
your voice heard by the other parties in a call.
17
3.1.1 Making a Call with the Phone Application
Your mobile phone supports the SmartDial function, that is, when you touch numbers
on the dialer, the phone automatically searches among your contacts and lists the
matching results ordered according to the accuracy of the match. If no contacts match
the information entered, the phone will not display any result.
1. On the Home screen, touch >
Phone
to display the dialer.
If you are already working with
Contacts
or
Call log
, touch the
Phone
tab.
2. Touch the appropriate number keys to enter the phone number.
3. Touch to initiate the call.
During a call, touch
Dialpad
to enter other numbers on the dialpad.
3.1.2 Making a Call from Contacts
1. On the Home screen, touch >
Contacts
to display the contact list.
If you are already working with
Phone
or
Call log
, touch the
Contacts
tab.
2. In the list, touch the contact you want to call.
3. Touch to dial the phone number.
3.1.3 Making a Call from Call log
1. On the Home screen, touch >
Phone
>
Call log
.
If you are already working with
Contacts
or
Phone
, touch the
Call log
tab.
2. Touch to the right of the log entry to dial.
If you touch and hold a log entry, the options menu will open.
3.2 Answering or Rejecting a Call
3.2.1 Answering an Incoming Call
When you receive a phone call, the incoming call screen opens. If you have
previously saved the caller’s number in
Contacts
, the caller's name and number are
displayed. If the caller’s number is not saved in
Contacts
, the caller’s number is
displayed.
18
Drag to the right to answer the call.
3.2.2 Ending a Call
During a call, touch
End
to hang up.
3.2.3 Rejecting an Incoming Call
Drag to the left to reject the call.
19
3.3 Other Operations During a Call
3.3.1 Making a Conference Call
If you receive a new call while you are already in a call, you can add the second call to
the call you are in. This feature is known as conference calling. You can also set up a
conference call with multiple callers.
Contact your network operator to ask if conference calls are supported and, if
yes, how many parties can participate.
1. To initiate a conference call, dial the number of the first participant. After you have
connected to the first participant, keep the connection open, touch
Add call
.
2. Enter the phone number of the next person you want to invite for the conversation
and touch , or select someone from your
Call log
or
Contacts
. The first
participant is automatically placed on hold while you do this.
3. Once you have connected to the second person, touch
Merge calls
to begin the
conference call.
4. To end the conference call and disconnect from everyone, touch
End
.
3.3.2 Switching Between Calls
If you receive a new call while you are already in a call, you can switch between the
two calls.
1. While you are in the first call and the second call comes in, answer the incoming
call, and then touch
Swap
.
2. The current call is placed on hold and you are connected to the first call.
3.4 Using the Call log
The
Call log
contains a list of calls that you have dialed, received, and missed. You
can use the call log to find a recently called number quickly or add a number from the
call log to your contact list.
3.4.1 Adding an Entry to Contacts
1. If you are already working with
Phone
or
Contacts
, touch the
Call log
tab.
2. Touch and hold the entry you want to add to your
Contacts
.
20
3. Touch
Add to contacts
in the options menu.
4. Touch
Create new contact
or scroll through the contact list and touch an existing
contact name.
3.5 Direct Connect Call
With Direct Connect (DC), you can instantly talk to another Direct Connect user or
group of users with the push of a button.
3.5.1 Dialing Direct Connect Numbers
A Direct Connect number follows the format as below:
There are three parts to a Direct Connect number. For example:
xxx*xxxxx*xxxxx
or
xx*xxxxx*xx
. You must have all three parts when calling iDEN or 3G users. Here
x
represents any digit from 0 to 9. And each part is separated by an asterisk. A Direct
Connect number contains a maximum of 15 characters (including asterisks).
3.5.2 Making Direct Connect Calls
1. Touch >
Phone
to display the dialer.
2. Enter a Direct Connect number.
3. Push the Direct Connect button on the left side of your phone. Begin talking after
your phone plays the Chirp sound.
4. Release the Direct Connect button to listen. The call will end automatically if no
party speaks for several seconds.
You can also go to
Contacts
or
Call log
, and then select any Direct Connect
user to place the call to that user.
Last Call Notification
Upon completion of a Direct Connect call or a DC Group call, the Last Call Notification
screen will appear. It shows the contact name or number on the last call, and the date
and time of the call. The screen can be cleared by touching the indicated soft key, or
it will disappear after a period of time. Push the Direct Connect button from the last call
screen will attempt a restart of the last call indicated.
21
3.5.3 Answering Direct Connect Calls
1. When you receive a Direct Connect call, your phone will play an incoming Direct
Connect call notification. Then the caller may begin speaking, or simply wait for you
to respond to the notification.
2. After the caller finishes speaking, or releases the Direct Connect button, you will
hear a tone to indicate that the floor is now open and you may speak.
3. Push the Direct Connect button on the left side of your phone. Begin talking after
your phone plays the Chirp sound.
4. Release the Direct Connect button to listen. The call will end automatically if no
party speaks for several seconds.
3.6 Alerts
Alerts let you notify others that you want to communicate with using Direct Connect.
When a user receives an Alert, an incoming Alert tone will be played and the caller ID
(name and Direct Connect number) will be displayed.
3.6.1 Sending Alerts
1. Touch >
Phone
to display the dialer.
2. Enter a Direct Connect number.
3. Touch
Send Alert
icon.
4. When prompted, push the Direct Connect button to send the Alert.
You can send an Alert from the
Call log
or
Contacts
. Touch an entry with a
Direct Connect number, and then touch
Send Alert
.
3.6.2 Responding to an Alert
Answering an Alert
Push the Direct Connect button. This will start a Direct Connect call to the sender.
Ignoring an Alert
Touch
Ignore
to ignore the Alert.
22
Storing an Alert in Notifications
If you do not respond to an Alert, the Alert will be removed from your screen and will
be placed as a missed Alert icon in the Notification bar.
3.6.3 Using the Alert Notification
1. Open the Notification panel.
2. Select the missed Alert. This will take you to the call log entry for missed Alert. You
can either place a Direct Connect call or send another Alert to the sender.
3.7 DC Group Calls
A DC Group call is a Direct Connect call with more than one Direct Connect user.
3.7.1 Creating DC Groups
1. Touch >
Contacts
>
DC Groups
.
2. Touch >
Create DC Group
.
3. Touch
Enter number
to enter contacts to be added.
You must add two or more contacts, or you can select two or more contacts from
Contacts
or
Call log
.
4. Touch >
Save DC Group
.
5. Enter the group name.
6. Touch
Done
to save the group.
3.7.2 Adding Group Members
You can use the
Add members
function to add participants to an active Direct
Connect call or DC Group call.
1. Touch >
Contacts
>
DC Groups
.
2. Touch and hold the group to which you want to add members.
3. Touch
Edit DC Group
.
4. Touch
Add members
.
23
5. Select members to add, and then touch
Add
.
You can push the Direct Connect button to start the DC Group call immediately
without saving the group.
6. Touch
Done
to save the group.
Adding a Member to DC Groups Stored in Contacts
1. Touch and hold the contact you want to add to a group.
2. Touch
Add to DC Group
.
3. Select the groups to which you want to add the contact.
4. Touch
Add
3.7.3 Viewing the DC Group Details
1. Touch >
Contacts
>
DC Groups
.
2. Touch the group you want to view. Then you can do the following:
• Touch and hold a contact, you can make a Direct Connect call, send an Alert,
or remove it from the group.
• Save an unknown number to
Contacts
.
• Touch , you can make a DC Group call, send an Invitation, edit the group,
or delete the group.
3.7.4 Removing a Member from a DC Group
1. Touch >
Contacts
>
DC Groups
.
2. Touch and hold the group from which you want to remove members.
3. Touch
Edit DC Group
.
4. Touch to remove the contact from the group.
5. Touch
Done
to save the group.
3.7.5 Deleting a DC Group from Contacts
1. Touch >
Contacts
>
DC Groups
.
2. Touch >
Delete DC Groups
.
3. Select groups which you want to delete.
24
4. Touch
Delete
to confirm.
3.7.6 Making DC Group Calls
1. From
DC Groups
or
Call log
tabs, touch the DC Group call icon.
2. Push the Direct Connect button to start the DC Group call.
3.7.7 Answering DC Group Calls
Proceed as if answering a Direct Connect call from one user.
Only one person at a time may speak on a DC Group call.
3.7.8 Sending a DC Group Call Invitation
You can send a DC Group Invitation to inform multiple Direct Connect users that you
want to include them in a group call. The users you invite can join or decline by
following prompts on the phone.
1. Touch >
Contacts
>
DC Groups
.
2. Touch a DC Group to open it.
3. Touch >
Invite
.
4. Push the Direct Connect button to send an Invitation to all the members in the
group.
3.7.9 Responding to a DC Group Call Invitation
When you receive a DC Group call Invitation, you can either touch
Join
to join the DC
Group call or touch
Ignore
to ignore the Invitation if you do not want to join the DC
Group call.
3.7.10 Attempting to Join a DC Group Call After it has Ended
If you attempt to join a DC Group call after it has ended, a message will display.
• If you push the Direct Connect button, the DC Group call will begin.
• If you touch
Invite
, another message will display. You can push the Direct Connect
button to send an Invitation.
• If you touch
Dismiss
, then no operation will be performed.
25
3.8 Direct Connect Settings
Touch >
Settings
>
DC settings
᷍
and then you can control how your phone
handles Direct Connect calls, DC Group calls, and so on.
•
One touch DC
: Set the Direct Connect button behavior.
•
Exiting DC Group call I initiated
: Select the check box to allow the call to continue
when you exit a DC Group call you initiated.
•
Add member to ongoing call
: Select the check box to allow a member to add a
contact to a Direct Connect or DC Group call.
•
Blocked DC list
: View and modify the list of users you have blocked from making
a Direct Connect call to you.
•
Invitation ringtone
: Set your default incoming DC Group Invitation ringtone.
•
Invitation timeout
: Set the length of time you want the Invitation ringtone to play.
•
Alert ringtone
: Set your default Alert ringtone.
•
Alert timeout
: Set the length of time you want your Alert ringtone to play.
•
My DC Number
: View your DC number.
•
DC button backlight
: Select the check box to turn on the Direct Connect button
light on incoming DC events.
•
Vibrate for missed DC Events
: Select the check box to make your mobile phone
vibrate for the missed DC events.
3.8.1 Setting One Touch DC
One touch DC
allows you to quickly access Direct Connect contacts when the Direct
Connect button is pushed from the Home screen.
1. Touch >
Settings
>
DC settings
>
One touch DC
.
2. Select one of the following items:
•
Off
•
Call log
•
Last call
•
Contacts
26
3.9 Interrupt Request
3.9.1 Sending an Interrupt Request
1. During a Direct Connect call or a DC Group call, when another party is speaking
and you want to speak, then you can touch
Interrupt
to send a message to the
speaker that you want to talk.
2. If the Interrupt was sent successfully, you will get a successful message.
3. After the speaker releases the Direct Connect button, you can push and hold the
Direct Connect button to talk.
3.9.2 Responding to an Interrupt Request
During a Direct Connect call or a DC Group call, when you are speaking, you may
receive an Interrupt Request from other party in the call. This is to inform you that the
other party wants to speak.
Releases the Direct Connect button to open floor for the requesting party to speak.
3.10 Missed DC Event
If you are on a call and missed a Direct Connect call, a DC Group call, an Alert, or an
Invitation, icons will display in the notification bar. You can open the notification panel
to select a missed event notification, and then you can respond to the event.
3.11 Concurrency
3.11.1 Receiving a Voice Call During a Direct Connect Call
When you receive a voice call during a Direct Connect call, you can drag the icon on
the screen left or right to answer or reject it. If you answer the voice call, the Direct
Connect call will end.
3.11.2 Receiving a Direct Connect Call During a Voice Call
When you receive a Direct Connect call during a voice call, the phone displays the
missed Direct Connect call screen. Touch
Ignore
to continue with the voice call; touch
Hold voice call
to put the voice call on hold, a message displays, and then you can
do the following:
27
• Push and hold the Direct Connect button to make a Direct Connect call.
• Touch
Send Alert
, a message displays, and then you can push the Direct Connect
button to send an Alert.
• Touch
Resume voice call
to return to the voice call.
If you do not respond to the missed Direct Connect call screen, then the
notification will disappear after several seconds.
3.11.3 Receiving a DC Group Call During a Voice Call
When you receive a DC Group call during a voice call, the phone displays the missed
DC Group call screen. Touch
Ignore
to continue with the voice call; touch
Hold voice
call
to put the voice call on hold, a message displays, and then you can do the
following:
• Push and hold the Direct Connect button to make a Direct Connect call to join the
group call
• Touch
Invite
, a message displays, and then you can push the Direct Connect
button to send an Invitation to the group members.
• Touch
Resume voice call
to return to the voice call.
3.11.4 Receiving an Alert During a Voice Call
When you receive an Alert during a voice call, the phone displays the incoming Alert
screen. Touch
Ignore
to continue with the voice call; touch
Hold voice call
to put the
voice call on hold, a message displays, and then you can do the following:
• Push and hold the Direct Connect button to make a Direct Connect call.
• Touch
Send Alert
, a message displays, and then you can push the Direct Connect
button to send an Alert.
• Touch
Resume voice call
to return to the voice call.
3.11.5 Receiving an Invitation During a Voice Call
When you receive an Invitation during a voice call, the phone displays the missed
Invitation screen. Touch
Ignore
to continue with the voice call; touch
Hold voice call
to put the voice call on hold, a message displays, and then you can do the following:
• Touch
Join
to join the DC Group call.
• Touch
Resume voice call
to return to the voice call.
28
3.11.6 Converting a Direct Connect Call to a Voice Call
When a quick Direct Connect call turns into a longer conversation, the phone supports
the switch between a Direct Connect call and a voice call.
During a Direct Connect call, if you have saved the voice call number of the other party
on the phone, touch >
Convert to voice call
to convert the Direct Connect call
to a voice call.
3.12 Using Airplane Mode
Some locations may require you to turn off your phone’s wireless connections. Rather
than powering off your phone, you can place it in
Airplane mode
.
1. Press and hold .
2. Touch
Airplane mode
in the options menu.
4 Contacts
The
Contacts
application enables you to save and manage information such as
phone numbers and addresses of your contacts. After you save contact information
on your mobile phone, you have easy access to the people with whom you want to
communicate.
4.1 Opening the Contacts Application
If you have not yet added any contacts to your mobile phone,
Contacts
displays a
message with hints on how to start adding contacts information.
On the Home screen, touch >
Contacts
to open the
Contacts
application.
All of your contacts are displayed alphabetically in a list that you can scroll through.
4.2 Importing Contacts from a USIM Card
1. In the contact list, touch >
More
>
Import/Export
.
2. Touch
Import from USIM card
.
3. Wait for the USIM card contents to be loaded. Select the contacts you want to
import or touch
Select all
to select all contacts.
29
4. Touch
Copy
.
5. If you have more than one account on your phone, touch the account into which
you want to import the contacts.
4.3 Adding a Contact
1. In the contact list, touch >
New contact
.
2. If you have more than one account with contacts, touch the account to which you
want to add the contact.
3. Enter the contact's name, and then add detailed information such as phone
number and address.
4. When you are finished, touch
Done
to save the contact information.
4.4 Adding a Contact to Your Favorites
• Touch and hold the contact you want to add to
Favorites
. Then touch
Add to
favorites
.
• Touch a contact, and then touch the star to the right of the contact’s name. The star
turns gold.
4.5 Searching for a Contact
1. In the contact list, touch >
Search
.
2. Enter the name of the contact you wish to search for. As you type, contacts with
matching names appear below the search box.
On the contact list screen, you can touch a letter on the right to display contacts
starting with the touched letter.
4.6 Editing a Contact
You can make changes to the information you have stored for a contact at any time.
1. In the contacts list, touch and hold the contact whose details you want to edit, and
then touch
Edit contact
in the options menu.
30
2. Touch the category of contact information you wish to change: name, phone
number, email address, or any other information you recorded earlier.
3. Make the desired changes to the contact information, and then touch
Done
. To
cancel all of your changes, touch
Cancel
.
4.7 Communicating with Your Contacts
From the
Contacts
or
Favorites
tab, you can quickly call or send a text (SMS) or
multimedia (MMS) message to a contact’s default phone number. You can also open
details to view a list of all the ways you can communicate with that contact. This
section describes how to communicate with a contact when you view your contacts
list.
4.7.1 Using Quick Contact for Android
1. Touch the contact's picture or picture frame (if you have not assigned a picture to
the contact) to open Quick Contact for Android.
2. Touch the icon for the way you want to communicate with the contact.
The icons available depend on the information you have entered for the contact,
the applications installed on your phone, and the accounts you have.
4.7.2 Communicating with a Contact
1. In the contacts list, touch the contact that you want to communicate with.
2. On the contact’s details screen, touch the icon to the right of the number to call or
send messages.
4.8 Deleting a Contact
1. In the contacts list, touch and hold the contact that you want to delete, and then
touch
Delete contact
in the options menu.
2. Touch
OK
to confirm that you want to delete the contact.
31
4.9 Backing Up and Synchronizing
Contacts
You can back up contacts from your phone to a microSD card, or synchronize phone
contacts with a server using your Google account.
4.9.1 Using a microSD Card to Back Up Contacts
Backing Up Contacts
1. In the contact list, touch >
More
>
Import/Export
.
2. Touch
Export to SD card
in the displayed menu.
3. Touch
OK
to export your phone contact's information to the installed microSD card.
You can copy the .vcf files backed up on the microSD card to your computer. The files
are stored in the root directory of the microSD card.
Restoring Contacts
1. In the contact list, touch >
More
>
Import/Export
.
2. Touch
Import from SD card
in the displayed menu.
If there is more than one .vcf files saved on the microSD card, you can choose to
restore one, multiple, or all the of them.
4.9.2 Using a Google Account to Synchronize Contacts
You can synchronize contacts using your Google account. For details, see Changing
an Account’s Synchronization Settings.
4.10 Joining and Separating Contacts
You may have duplicate contacts if you import contacts by:
• Adding an account, such as a Gmail account.
• Using the social networking services such as Facebook or Twitter.
• Using other methods, such as exchanging emails.
To avoid duplication, join two or more contacts together to form a single contact.
Availability of Facebook or Twitter may vary depending on your country or
32
carrier. Please use them according to local laws and regulations.
4.10.1 Joining Contacts
1. On the Home screen, touch >
Contacts
.
2. Touch a duplicated contact, and then touch >
Edit contact
.
3. Touch >
Join
.
4. Select the contact to be joined to combine two duplicate contacts.
Two contacts will be joined together and displayed as one contact. Touch the contact
to view the joined information. You can see that the contact is joined together by two
contacts. You can also combine more than two contacts.
4.10.2 Separating Contacts
If contact information from different sources was joined together in error, you can
separate the contacts.
1. On the Home screen, touch >
Contacts
.
2. Touch the joint contact to be separated, and then touch >
Edit contact
.
3. Touch >
Separate
.
4. Select
OK
.
The joint contact is then separated into two contacts displayed separately in
Contacts
.
4.11 Sending Contacts
You can send contacts as a .vcf file via Bluetooth or Email.
1. In the contacts list, touch >
More
>
Send contacts
.
2. Select contacts that you want to send.
3. Touch
Send
.
4. Select the way you prefer to send the contacts you have selected, for example
Bluetooth or Email.
You can send one contact by another way. Touch and hold a contact, touch
Send contact
, and then select the way you prefer to send.
33
5 Using the Onscreen Keyboard
5.1 Displaying the Keyboard
To enter text, use the onscreen keyboard. Some applications open the keyboard
automatically. In others, touch a text field to open the keyboard.
Touch to hide the keyboard.
Touch and hold a text field to open the
Edit text
menu.
5.1.1 Choosing an Input Method
1. Touch and hold a text field until the
Edit text
menu is displayed.
2. Touch
Select input method
.
3. Select the input method.
5.1.2 Using the Swype Keyboard
q w e
#
_(&
!/?
$:;”
)
r t y u i o p
a s d f g h j k
z x c v b n m
.
+!=
l
EN
=
+
123 ,-
Touch once to capitalize the next letter you type.
Touch twice for all caps.
Touch and hold to get helpful tips.
Touch to change from text mode to symbol/number mode.
Touch to insert a space.
Touch to delete a character
to the left of the cursor.
Touch and hold to delete all
characters to the left of the
cursor.
’
34
The keyboard layout may vary slightly depending on the field where you are
entering text. The previous figure is provided for your reference only.
5.1.3 Using the Android Keyboard
The keyboard layout may vary slightly depending on the field where you are
entering text. The previous figure is provided for your reference only.
q w e
#
_(&
!
/?
$:;”
)
r t y u i o p
a s d f g h j k
z x c v b n m
+!=
l
EN
=
+
123
q w e
#
_(&
!
/?
$:;”
)
r t y u i o p
a s d f g h j k
z x c v b n m
+!=
l
EN
=
+
123
bay
To enter a word, just drag your
finger over the letters in the word.
I’ll
To capitalize, go above the
keypad.
To enter apostrophes in common
words drag through the ‘n’.
To enter double letters, circle the
letter.
q w e r t y u i o p
a s d f g h j k
z x c v b n m
.
?123
l
Touch once to capitalize the next letter you type.
Touch twice to capitalize all letters to be entered.
Touch to change from the text mode to the symbol/number mode.
Touch to enter text by voice.
Touch to insert a space.
Touch to delete a character
to the left of the cursor.
Touch and hold to delete all
characters to the left of the
cursor.
......
Touch to select or set input method.
:-)
...
35
On the Home screen, touch >
Settings
>
Language & keyboard
>
Android keyboard
>
Voice input
to turn on or turn off voice input.
5.1.4 Using the Landscape Keyboard
If you find the keyboard inconvenient or difficult to use, turn your mobile phone
sideways. The screen will display the keyboard in landscape orientation, providing
you with a wider keyboard layout.
5.1.5 Using the Phone Keypad
Press and to switch between input modes. In different input modes, the
cursor is displayed in different forms, as described in the following table.
Cursor: To enter the character printed at the top of a key,
press first and then the desired key.
Cursor:
To enter only the characters printed at the top of
keys, press twice before typing. Press
again to switch back to the main characters printed
on keys.
Cursor: To enter one uppercase letter, press first and
then the desired key.
Cursor: To enter only uppercase letters, press twice
before typing. Press again to input lowercase
letters.
To delete a character, press . Press and hold
the key to delete more characters quickly.
To start a new line, press .
36
5.2 Customizing Keyboard Settings
1. On the Home screen, touch >
Settings
>
Language & keyboard
.
2. In
Keyboard settings
, select an input method to customize the keyboard settings.
6 Messaging
The
Messaging
application allows you to exchange text messages (SMS) and
multimedia messages (MMS) with anyone using an SMS-or-MMS-capable phone.
With the
Email
application you can read and send emails.
6.1 SMS and MMS
6.1.1 Opening Messaging
Touch >
Messaging
.
6.1.2 Creating and Sending a Text Message
1. Touch >
Messaging
>
New message
.
2. Enter a phone number or a contact's name in the
To
field, or touch to select a
contact from
Contacts
.
As you enter the phone number or the contact's name, the phone displays
possible matches from your contacts. Select a contact from the list of possible
matches or continue entering.
After you select a contact or finish entering a number, add a comma and you can
enter another recipient. You can also touch a previously entered contact again
to edit or delete it.
3. Touch the composition text box to start entering your message.
4. When you are ready to send the message, touch .
Sent and received messages will be displayed in a message thread, grouping
together the messages in a conversation.
37
6.1.3 Creating and Sending a Multimedia Message
You can use multimedia messages to make everyday communications very special.
You can record a message and send it as an audio file, sing 'Happy Birthday' and
send it to friend, or send a slideshow of photographs of a special event. The
possibilities are endless.
1. Touch >
Messaging
>
New message
.
2. Enter a phone number in the
To
field, or touch to select a contact from
Contacts
.
3. Touch the composition text box to start entering your message.
4. Touch to display the options panel.
• Touch
Add subject
to add the message subject. Your mobile phone is now in
multimedia message mode.
• Touch
Add
to add a picture, music, or video file.
5. When the message is ready to be sent, touch .
On the message editing screen, you can also touch , and then select your
desired files to add.
You can select a media file (music, video or picture) and send it as an attachment
in a multimedia message. In
File Manager
, touch and hold a media file, and then
touch
Share
>
Messaging
.
Adding a Slideshow
If you want to attach more than one file to your message, use the
Slideshow
option.
1. On the message editing screen, touch to display the options panel.
2. Touch
Add
>
Slideshow
, and then select a slide to start editing it.
3. Touch and then touch
More
>
Add slide
to add more slides.
4. Touch
Done
to finish composing your message and return to the multimedia
message screen.
5. To alter your multimedia message, touch the slideshow on the multimedia
message screen. When the message is ready to be sent, touch
Send
.
38
6.1.4 Opening and Viewing a Multimedia Message
1. In the message list, touch the message thread you wish to view.
2. Touch the multimedia message to view the message.
6.1.5 Replying to a Message
1. In the message list, touch a text or multimedia message thread to open it.
2. Touch the text box to compose your message. Once finished, touch .
You can also do the following to reply to a message: Touch >
Multiselect
,
select one or more message threads, and touch
Reply
.
6.1.6 Copying a Text Message to Notepad or Calendar
1. In the message list, touch a text message thread to open it.
2. Touch and hold one of the messages, and then touch
Copy message to
.
3. Touch
Notepad
or
Calendar
to save it as a note or an event.
For information about how to use
Notepad
or
Calendar
, see the relevant sections of
this guide.
6.1.7 Customizing Message Settings
In the message list, touch , and then touch
Settings
to customize the message
settings.
6.2 Email
Your mobile phone also puts email at your fingertips. With your phone's
Email
application, you can use your email account with Yahoo!, AOL, or other popular email
services on your phone.
6.2.1 Adding an Email Account
When using the
Email
application for the first time, you must configure an email
account. The Email setup wizard helps you to configure your account. A number of
popular email systems are supported. You can work with the same email service that
you use on your PC or you can select another email service.
39
1. On the Home screen, touch >
Email
.
2. In the email system list, select a system, or select
Others
.
3. To customize your email settings, follow the onscreen instructions, and then touch
Next
.
4. Enter the account name and the name you want other people to see when they
receive an email from you.
5. Touch
Done
.
Adding Other Email Accounts
1. After creating your initial email account, touch on the
Inbox
screen, and then
touch
More
>
Accounts
to access the accounts screen.
2. Touch on the accounts screen, and then touch
Add account
to create
another email account.
When adding an additional email account, you have the option to use the new
account to send all outgoing messages.
6.2.2 Viewing an Email Message
1. On the accounts screen, touch the email account you want to use.
2. Access a folder, and then touch the message that you want to view.
6.2.3 Saving an Email Attachment
1. On the accounts screen, touch the email account you want to use.
2. Touch the email message you want to view.
3. Touch
Save
next to the attachment in the email.
4. Select a path for saving the attachment and touch
Save
.
6.2.4 Creating and Sending an Email Message
1. On the accounts screen, touch the email account you want to use.
2. On the
Inbox
screen, touch , and then touch
Compose
in the options panel.
3. In the
To
field, enter the recipients’ name or email address.
40
4. Enter the subject of your message and compose the message.
To send an attachment with the message, touch , and then touch
Add
attachment
.
5. When you are finished, touch
Send
.
If you are not ready to send the message, touch
Save as draft
or touch to
save the message as a draft.
6.2.5 Replying to an Email Message
1. On the accounts screen, touch the email account you want to use.
2. Touch the email message to which you want to reply.
3. Touch
Reply
or
Reply all
to reply to the email message.
6.2.6 Deleting an Email Account
1. On the accounts screen, touch and hold the email account you want to delete.
2. Touch
Remove account
.
3. Touch
OK
.
6.2.7 Changing Email Account Settings
You can change a number of account settings, including how often you check for
emails, how you are notified of a new mail, and details about the servers the account
uses to send and receive mails.
Your account’s incoming and outgoing settings depend on the kind of email
service you are using. You can enter the necessary details manually, although
you may need to contact your email service provider to obtain the correct
information.
1. Touch >
Email
.
2. On the accounts screen, touch and hold the email account you want to change.
3. Touch
Account settings
.
4. Change
General settings
,
Notification settings
, or
Server settings
.
41
7 Getting Connected
7.1 Mobile Networks
Your mobile phone will be automatically configured to use your network operator’s
2G/3G service (if available) when you turn on the phone for the first time. Note that the
USIM card must be inserted (some CDMA mobile phones have an integrated UIM
card and do not need a separate UIM card)
7.1.1 Checking the Network Connection
1. Touch >
Settings
.
2. Touch
Wireless & networks
>
Mobile networks
.
3. Touch
Network operators
or
Access Point Names
to check the network
connection.
Your mobile phone will automatically read the access point settings from the
USIM card (if any). For this reason, do not change the access point parameters;
otherwise, you might not be able to access network resources.
7.1.2 Turning on the Data Service
1. Touch >
Settings
.
2. Touch
Wireless & networks
>
Mobile networks
.
3. Select the
Data enabled
check box to turn on the data connection.
7.2 Wi-Fi
Wi-Fi gives you wireless access to broadband Internet. To use Wi-Fi on your mobile
phone, you must have an access to wireless access points (hotspots). Obstacles that
block the Wi-Fi signal will reduce its strength.
7.2.1 Turning On Wi-Fi
1. Touch >
Settings
.
2. Touch
Wireless & networks
, and then select the
Wi-Fi
check box to turn on Wi-Fi.
42
7.2.2 Connecting to a Wireless Network
1. After turning on Wi-Fi, touch >
Settings
.
2. Touch
Wireless & networks
>
Wi-Fi settings
. You will see a list of detected Wi-Fi
networks in the
Wi-Fi networks
section.
3. Touch a Wi-Fi network to connect to it.
• If you select an open network, you will be automatically connected to the
network.
• If you select a network that is secured with Wired Equivalent Privacy (WEP)
and connect to it for the first time, enter the password as prompted, and then
touch
Connect
. If you connect to a secured wireless network that you have
already used, you will not be prompted to enter the password again unless you
have reset your mobile phone to its default settings.
On the
Wi-Fi settings
screen, touch
Add Wi-Fi network
to add a new Wi-Fi
network.
7.3 Sharing Your Phone’s Data
Connection
You can share your mobile phone's data connection with a single computer via a USB
cable: USB tethering. You can share your mobile phone's data connection with a
number of devices at the same time, by turning your phone into a portable Wi-Fi
hotspot.
7.3.1 Installing the USB tethering Driver
If your computer is running Windows 7 or a recent distribution of some flavors of Linux
(such as Ubuntu), you typically do not need to prepare your computer for tethering.
But if you are running an earlier version of Windows or another operating system, you
may need to prepare your computer to establish a network connection via USB.
Install the
USB tethering
driver in the following steps:
1. Connect a USB cable to a computer. The computer will automatically recognize the
phone.
2. Choose
Start
>
My Computer
, and then double-click
Mobile Partner
.
43
3. Open the
drivers
folder and then open the
usbnet_driver_win2k_xp
folder.
Double-click the link
DownloadActiveSync.url
.
4. Download and install
ActiveSync 4.5
or a later version.
5. After the installation, you are able to use USB tethering.
7.3.2 Sharing Your Phone’s Data Connection via USB
To use USB tethering in different operating systems, you may need to prepare your
computer to establish a network connection via USB.
You cannot share your mobile phone’s data connection and access its microSD
card via USB at the same time.
1. Touch >
Settings
.
2. Touch
Wireless & networks
>
Tethering and Mobile HotSpot
.
3. Select the
USB tethering
check box to share your data connection.
7.3.3 Sharing Your Phone’s Data Connection as a Portable
Wi-Fi Hotspot
1. Touch >
Settings
.
2. Touch
Wireless & networks
>
Tethering and Mobile HotSpot
.
3. Select the
Mobile HotSpot
check box to share your data connection.
When
Mobile HotSpot
is selected, you can touch
Mobile HotSpot settings
to
change its network name or secure it.
7.4 Browser
Your mobile phone comes with an Internet browser pre-installed.
7.4.1 Opening the Browser
Touch >
Browser
to open the home page.
When known or open Wi-Fi networks and mobile data networks are available at
the same time, your phone will preferably select a Wi-Fi network for Internet
access.
44
Touch to open the browser options menu and perform one of the following
operations:
•
New window
: Touch to open a new window.
•
Bookmarks
: Touch to display bookmarks.
•
Windows
: Touch to view thumbnails of open browser windows. You can switch to
another browser window or open a new one on this screen.
•
Refresh
: Touch to refresh the current webpage.
•
Forward
: Touch to browse the next web page.
•
More
: Touch to open other menus and perform operations such as searching,
selecting text, downloading, or setting options.
7.4.2 Opening a Webpage
1. In a browser window, touch the URL field at the top of the screen.
2. Use the keyboard to enter a webpage address. You can touch to enter the
web page address by voice.
3. As you enter the address, matching webpage addresses will appear on the screen.
If you see the address you want, touch it and go directly to that webpage or
complete entering your desired webpage.
7.4.3 Managing Bookmarks
You can store as many bookmarks as you want on your mobile phone.
Adding a Bookmark
1. In a browser window, go to the webpage you want to save as a bookmark.
2. Touch , and then touch
Bookmarks
>
Add
.
3. Edit the bookmark name and then touch
OK
.
Opening a Bookmark
1. In a browser window, touch , and then touch
Bookmarks
.
On the
Bookmarks
screen, touch the
History
tab to view the pages you have
visited, or touch the
Most visited
tab to view the pages you have visited most
frequently.
2. Touch the bookmark of the website you want to open.
45
7.4.4 Customizing Browser Settings
Customize the browser to suit your browsing style. Use
Browser
to set page content,
privacy, and security preferences. In a browser window, touch , and then touch
More
>
Settings
.
7.5 Bluetooth
Your mobile phone has Bluetooth, which allows you to create a wireless connection
with other Bluetooth devices so you can share files with your friends, talk hands-free
with a Bluetooth headset, or even transfer photos from your phone to your PC.
If you are using Bluetooth, remember to stay within 10 meters (33 feet) of the other
Bluetooth devices to which you want to connect. Be aware that obstacles like walls or
other electronic equipment may interfere with your Bluetooth connection.
7.5.1 Turning On Bluetooth
1. Touch >
Settings
.
2. Touch
Wireless & networks
, and then select the
Bluetooth
check box to turn on
Bluetooth. When Bluetooth is turned on, the Bluetooth icon appears in the
notification bar.
3. Touch
Bluetooth settings
, and then select the
Discoverable
to make your
mobile phone visible to other Bluetooth devices.
7.5.2 Pairing with and Connecting to a Bluetooth Device
Your mobile Bluetooth lets you do the following:
• Hands Free Profile (HFP): allows you to use a hands-free Bluetooth device.
• Headset Profile (HSP): allows you to use a mono Bluetooth headset.
• Object Push Profile (OPP): allows you to transfer files over a Bluetooth connection.
• Advanced Audio Distribution Profile (A2DP): allows you to use a stereo Bluetooth
headset.
• A/V Remote Control Profile (AVRCP): allows you to control audio playing using a
Bluetooth headset remotely.
Before you use Bluetooth, pair your mobile phone with another Bluetooth device as
follows:
46
1. Ensure that the Bluetooth function on your mobile phone is enabled.
2. On the Home screen, touch >
Settings
>
Wireless & networks
>
Bluetooth
settings
. Your mobile phone will then scan for Bluetooth devices in range.
3. Touch the device you want to pair your mobile phone with.
4. If required, enter the pairing password to complete the connection.
7.5.3 Sending Files via Bluetooth
With Bluetooth, you can share pictures, videos, or music files with your family and
friends. To send files via Bluetooth:
1. Touch and hold the file to be sent in your mobile phone or SD card. The active
options menu is displayed.
2. Touch
Share
, then
Bluetooth
to select a paired device.
7.5.4 Disconnecting from or Unpairing with a Bluetooth Device
1. Touch >
Settings
>
Wireless & networks
>
Bluetooth settings
.
2. Navigate to the
Bluetooth devices
section, and then touch and hold the device to
which you are connected.
3. Touch
Unpair
to disconnect from the device.
8 Entertainment
In addition to being a communication device and personal assistant, your mobile
phone also provides you with a multitude of entertainment possibilities. You can take
photos, create videos and audio clips, and download and listen to music.
8.1 Taking Photos and Recording Videos
The camera is a combination of camera and camcorder that you can use to shoot and
share pictures and videos.
8.1.1 Opening Your Camera
• Touch
> Camera
to open the camera. The camera opens in landscape
mode, ready to take a picture or record a video.
47
• Touch to close the camera.
Capture Screen
On the capture screen, touch to show the capture panel.
8.1.2 Taking a Photo
1. Open your camera application and switch it to camera mode.
2. If necessary, change the camera settings. The preview changes as you change
the settings.
3. Frame your photo within the photo capture screen.
4. Touch to take your photo.
Photos taken are displayed for a moment. You can take another photo or review your
photos.
8.1.3 Viewing Your Photos
1. After taking a photo, a thumbnail of the photo you have just taken is shown in the
upper right corner of the capture screen. Touch the thumbnail to view it.
2. Touch the onscreen button to do any of the following:
• Touch
Share
to send the photo in a message or post it online.
• Touch
Delete
to delete the photo.
• Touch
More
>
Set as
to set the photo as a contact icon or the wallpaper.
3
5
Touch to customize the camera settings.
Thumbnail of the
last photo. Touch
to preview the
photos or videos.
Slide up to record
videos; slide down
to take photos.
Touch to take a
photo.
48
8.1.4 Recording a Video
1. Open the camera application, and then switch it to camcorder mode.
2. If necessary, change the camcorder settings.
3. Frame the scene with which you want to start your video.
4. Touch to start recording a video.
5. Touch to stop recording.
8.1.5 Viewing Your Videos
1. After recording a video, a thumbnail of the video you have just recorded is shown in
the upper right corner of the capture screen. Touch the thumbnail to view it.
2. Touch the onscreen buttons to do any of the following:
• Touch
Share
to send the video in a message or post it online.
• Touch
Delete
to delete the video.
On the video playback screen, touch the controls to fast-forward or rewind or to
play or pause the video.
3. If you want to view more videos, flick your finger left or right across the screen.
8.2 Using the Gallery
Your
Gallery
application can automatically search for pictures and videos on your
mobile phone and microSD card. Use
Gallery
to sort photos and videos into folders,
view and edit pictures, watch videos, and set a picture as wallpaper or as a photo for
a contact.
8.2.1 Opening the Gallery
On the Home screen, touch >
Gallery
.
The
Gallery
application categorizes your pictures and videos by storage location and
displays these files in folders. Touch a folder to view the pictures or videos inside.
8.2.2 Viewing a Picture
1. In
Gallery
, touch the folder that contains the pictures you want to view.
2. Touch the picture to view it in full-screen mode.
49
3. Touch the screen. Then the zoom panel appears. You can zoom in or zoom out on
the picture.
The picture viewer supports the automatic rotation function. When you rotate
your mobile phone, the picture adjusts itself to the rotation.
8.2.3 Rotating a Picture
1. When viewing a picture, touch to display the operations panel.
2. Touch
More
.
3. Select either
Rotate Left
or
Rotate Right
. The picture is saved with the new
orientation.
8.2.4 Cropping a Picture
1. When viewing a picture, touch to display the operation panel, and then touch
More
>
Crop
.
2. Use the cropping tool to select the portion of the picture to crop.
• Drag from the inside of the cropping tool to move it.
• Drag an edge of the cropping tool to resize the image.
• Drag a corner of the cropping tool to resize the image.
3. Touch
Save
to save the cropped picture. Touch
Discard
to discard the changes.
8.3 Enjoying Music
You can download music files to your PC or insert a CD and copy the files to your
microSD card so you can listen to music on your mobile phone.
8.3.1 Copying Music to the microSD Card
1. Connect the phone to your computer with a USB cable and mount the microSD
card.
2. On the PC, navigate to the USB drive and open it.
3. Create a folder in the root directory of the microSD card (for example,
Music
).
4. Copy the music from your computer to the folder you have created.
50
5. After copying music, unmount or eject the drive as required by your PC’s operating
system to safely remove the mobile phone.
6. Disconnect the mobile phone from the PC.
8.3.2 Opening the Media Library
Touch >
Music
to display the media library.
The
Music
application organizes your music files by storage location. It contains four
tabs:
Artists
,
Albums
,
Songs
and
Playlists
.
8.3.3 Playing Music
1. Touch a category on the music library screen.
2. Touch the song you want to play.
When you are listening to music, touch , to use another application. Your music
continues to play. To return to the music controls, open the notification panel and then
touch the song.
8.3.4 Adding Music to a Playlist
1. Touch a category on the music library screen.
2. In the list that appears, select the song you want to add to the playlist.
3. Touch and hold the song, and then touch
Add to playlist
in the options menu.
• Touch
Current playlist
to add the song to an existing playlist.
• Touch
New
to create a playlist and add the song to it.
8.3.5 Playing a Playlist
1. Touch the
Playlists
tab on the music library screen.
2. Touch and hold the playlist you want to play.
3. Touch
Play
to play the playlist.
8.4 Listening to the FM Radio
The FM radio lets you listen to FM radio programs on your mobile phone. Since the
FM radio uses the provided wired stereo headset as its antenna, before opening the
application, connect the headset to your phone’s the audio jack.
51
8.4.1 Opening the FM Radio
1. On the Home screen, touch >
FM Radio
to open the application.
2. The first time you open FM radio, touch
Auto tuning
, which automatically scans for
available FM channels, saves them as presets, and plays the first FM channel
found.
8.4.2 Tuning the FM Radio
Open the
FM Radio
application, and then do the following:
• Touch or to tune the radio to the previous or next channel.
• Slide the knob left or right to perform precision tuning. When a channel is found,
touch , then
Save channel
. Enter the channel name, touch
OK
, and then
select an empty channel to save the new channel to the channel list.
• Touch >
Auto tuning
to scan automatically for available FM channels.
9 Google Services
Availability of Google applications, services, and features may vary according to
your country or carrier. Please follow local laws and regulations to use them.
When you turn on your mobile phone for the first time, touch a Google services such
as
Talk
,
Gmail
, or
Play Store
, and you will be prompted to sign in to your Google
account.
Ensure that your mobile phone has an active data connection (3G/GPRS)
before you sign in to your Google account.
If you already have a Google account, touch
Sign in
and enter your username and
password.
9.1 Creating a Google Account
If you do not have a Google account, you can create one:
1. After reading the setup information, touch
Next
.
2. Touch
Create
.
52
3. Enter the first name, last name, and user name for your Google account, and then
touch
Next
. The mobile phone will connect to a Google server to check whether the
username is available. If the username you entered is already in use, you will be
prompted to choose another one or select one from a list.
4. Enter and confirm your Google account password.
5. Select a security question from the drop-down menu, and then enter the answer.
6. Touch
Create
.
7. When the
Google Terms of Service
screen appears, touch
I agree, Next
.
8. Enter the characters that appear on the screen, and then touch
Next
.
To use another Google account, go to the
Accounts & sync settings
screen,
and touch
Add account
to select which type of accounts you want to add.
9.2 Gmail
Gmail
is Google’s web-based email service. When you first set up your phone, you
may have configured it to use an existing
Gmail
account or create a new account.
The first time you open the
Gmail
application on your phone, your
Inbox
will contain
the messages from your
Gmail
web account.
9.2.1 Opening Gmail
On the Home screen, touch >
Gmail
. The
Inbox
mail list appears. Any emails
you decide to keep on your mobile phone will go to your
Inbox
folder.
9.2.2 Switching Between Accounts
1. In the mail list, touch , and then touch
Accounts
.
2. Touch the account that contains the email you want to read.
9.2.3 Creating and Sending an Email
1. In the mail list, touch , and then touch
Compose
.
53
2. Enter the message recipient’s email address in the
To
field. If you are sending the
email to several recipients, separate the email addresses with commas. You can
add as many message recipients as you want.
If you want to send a copy (Cc) or a blind copy (Bcc) of the email to other
recipients, touch , and then touch
Add Cc/Bcc
.
3. Enter the email subject and write your email.
If you want to add a picture attachment, touch , and then touch
Attach
to
select the picture you want to attach.
4. After writing your email, touch .
9.2.4 Replying to or Forwarding an Email
1. In the mail list, touch the email that you want to reply to or forward.
2. Touch to reply. You can also touch , and then touch
Reply
,
Reply all
, or
Forward
.
3. Do one of the following:
• If you selected
Reply
or
Reply all
, enter your message.
• If you selected
Forward
, specify the message recipients and add any
additional text you want to include in the forwarded message.
4. Touch to send, or touch to save as a draft.
9.2.5 Searching for an Email
1. In the mail list, touch , and then touch
Search
.
2. Enter the search keywords in the box, and then touch .
9.2.6 Customizing Your Gmail Settings
In the mail list, touch , and then touch
More
>
Settings
to customizing your
Gmail
.
9.3 Talk
Talk
is Google’s instant messaging service. You can use it to communicate in real
time with other people using
Talk
on a phone or on the web.
54
9.3.1 Opening Talk
On the Home screen, touch >
Talk
to open the application.
Your
Talk
account is based on the Google account you set up with your mobile
phone.
9.3.2 Adding a Friend
1. In the friends list, touch , and then touch
Add friend
.
2. Enter the
Talk
instant messaging ID or Gmail address of the friend you want to add.
3. Touch
Send invitation
.
9.3.3 Accepting an Invitation
1. If you have invited anyone to chat or if someone else has invited you to chat, this
information will appear in the friends list.
2. Touch a pending invitation, and then touch
Accept
.
9.3.4 Starting a Chat
1. In the friends list, touch a friend's name in the friends list.
2. Use the onscreen keyboard to enter text and chat with your friend.
3. After entering your message, touch
Send
.
9.3.5 Setting Notifications for New Instant Messages
Whenever you receive an instant message, your mobile phone can play a sound,
vibrate, or display an icon. To set up one of these handy notifications, start in the
friends list, and then touch . Then touch
Settings
. Now choose from one of the
following:
IM
notifications
Select the check box to receive a notification on the
notification bar when you receive an instant message.
Select
ringtone
Touch to choose the ringtone used for a new instant
message. You will hear a short sample of the ringtone when
you select it. To turn the ringtone off, select
Silent
.
55
9.3.6 Signing out of Talk
On the friends list screen, touch , and then touch
Sign out
to quit
Talk
.
9.4 Maps
Maps
lets you find your current location, view real-time traffic conditions (depending
on availability in your locale), and get detailed directions to various destinations. You
can view satellite images, traffic maps, or other kinds of maps of your current or other
locations.
9.4.1 Enabling the Location Service
Before you open
Maps
to find your location or search for places of interest, you must
enable the location service.
1. On the Home screen, touch >
Settings
.
2. Touch
Location & security
.
3. In the
My Location
section, select the
Use wireless networks
check box, the
Use
GPS satellites
check box, or both.
9.4.2 Opening Maps
On the Home screen, touch >
Maps
to open the application.
9.4.3 Searching for Places of Interest
1. On the map, touch , and then touch
Search
.
2. Enter the place you want to search for in the search box, and then touch the Search
icon.
3. Your search results will then be displayed. Touch a place you are interested in and
the application will show where it is on the map.
Vibrate
Select the check box to make your mobile phone vibrate
when you receive a new instant message.
56
9.4.4 Getting Directions
1. While viewing a map, touch , and then touch
Directions
.
2. Enter the starting point in the first text box, and then enter your destination in the
second text box.
3. Touch the icon for car, public transit, or walking directions.
4. Touch
Get directions
. Your directions will appear in a list.
5. Touch a direction item on the list to show it on the map.
6. When you finish viewing or following the directions, touch , and then touch
Clear Map
to reset the map.
9.5 YouTube
YouTube
is Google’s free online video streaming service for watching, searching for,
and uploading videos.
9.5.1 Opening YouTube
On the Home screen, touch >
YouTube
. You will then see the YouTube screen.
9.5.2 Searching for a Video
1. On the
YouTube
screen, touch , and then touch
Search
.
2. Enter a search keyword, and then touch the Search icon.
3. You will see a number of search results displayed below the notification bar. Scroll
through the results and touch a video to watch it.
9.5.3 Sharing a Video
From the video list on the
YouTube
screen, select a video clip and touch to
share the video.
9.6 Play Store
Android Play store provides direct access to applications and games which you can
download and install on your phone.
57
9.6.1 Opening Play Store
1. On the Home screen, touch >
Play Store
.
2. When you open
Play Store
for the first time, the
Google Play Terms of Service
window will appear. Touch
Accept
to continue.
9.6.2 Searching for Applications
There are a few different ways to find applications on the
Play Store
home screen,
including:
• Featured applications
• List of games
• Search function
• My apps
9.6.3 Installing an Application
1. In the
Play Store
, select a category, and then touch the application you want to
download. On the application details screen, you can view more information about
this application, such as its cost, overall rating, user comments, and similar
applications. When scrolling down, you can also view developer's information
including other applications from the same developer and the link to the developer's
website. In addition, you can send the developer an email.
2. To install the application, touch
Download
>
Accept & download
(if it is free) or
touch the button with a price (if it is not free), and confirm your download or
purchase.
3. To check the progress of a download, open the notification panel. Most applications
are installed within seconds. To stop an application from downloading, touch the
cross (×).
After the application has been downloaded and installed on your mobile phone, the
content download icon appears in the notification bar.
If you want to install a non-Play Store application, touch >
Settings
>
Applications
, and then select the
Unknown sources
check box to allow
installation of the non-Play Store application.
58
9.6.4 Uninstalling an Application
1. On the
Play Store
screen, touch >
My Apps
.
2. Touch the application you want to uninstall, and then touch
Uninstall
.
3. When prompted, touch
OK
to remove the application from your mobile phone.
10 Synchronizing Information
Some applications on your mobile phone give you access to the same personal
information that you can add, view, and edit on your computer. If you add, change, or
delete your information in any of these applications on the web, the updated
information also appears on your mobile phone.
This is made possible through over-the-air data synchronization. The process occurs
in the background and does not interfere with use of your mobile phone. When your
phone is synchronizing, a data synchronization icon will be shown in the notification
bar.
10.1 Managing Your Accounts
You can synchronize contacts, email, and other information on your mobile phone
with multiple Google accounts or other kinds of accounts, depending on the
applications installed on your mobile phone.
For example, you can start by adding your personal Google account, so your
personal email, contacts, and calendar are always available. You could then add a
work account, so your work-related emails and work contacts are handy. If you like,
you may add multiple Google accounts or other accounts.
10.1.1 Adding an Account
When you add an account, the
Contacts
application compares contacts from the
newly synchronized account with contacts from your existing mobile phone accounts
and attempts to merge duplicates into a single entry in
Contacts
. While it is presented
as a single contact entry, the contact data itself is not merged.
1. On the Home screen, touch >
Settings
>
Accounts & sync
. The screen
displays your current synchronization settings and a list of your current accounts.
In some cases, you may need to obtain account details from IT support. For
59
example, you may need to know the account’s domain or server address.
2. Touch
Add account
.
3. Touch the kind of account to add.
4. Follow the onscreen steps to enter the required and optional information about the
account. Most accounts require a username and password, but the details depend
on the kind of account and the configuration of the service to which you are
connecting.
5. Configure the account. Depending on the kind of account, you may be asked to
configure what kind of data you want to synchronize to the mobile phone, to name
the account, and for other details. When you are finished, the account is added to
the list on the
Accounts & sync settings
screen.
10.1.2 Adding an Exchange Account
1. On the Home screen, touch >
Settings
>
Accounts & sync
.
2. Touch
Add account
>
Corporate
.
3. Follow the instructions and enter the required information about the exchange
account you want to add. For details, contact the server administrator.
4. Touch
Next
to display the
Account options
screen. Configure the
synchronization settings for this account.
5. Touch
Next
to finish configuring the account settings. If emails are not
synchronized properly, contact the server administrator.
10.1.3 Removing an Account
You can remove an account, deleting it and all information associated with it from your
mobile phone, including email, contacts, settings, and so on. You cannot, however,
remove some accounts, such as the first account you signed into on the mobile
phone. If you attempt to remove certain accounts, all personal information associated
with it will be deleted.
You can only remove the first Google Account by resetting the phone to factory
defaults.
1. On the
Accounts & sync settings
screen, touch the account to be deleted.
2. Touch
Sign Out
.
3. Confirm that you want to remove the account.
60
10.2 Customizing Your Account
Synchronization
You can configure background data use and synchronization options for all the
applications on your phone. You can also configure what kind of data you synchronize
for each account.
For some accounts, synchronization is bi-directional; changes that you make to the
information on your mobile phone are made to the copy of that information on the
web. Some accounts support only one-way synchronization; the information on your
mobile phone is read-only.
10.2.1 Configuring General Synchronization Settings
On the
Accounts & sync settings
screen, do the following:
• Select or clear the
Background data
check box to control whether applications
and services can transmit data when you are not working with them directly (that is,
when they are running in the background).
If you clear this option,
Gmail
stops receiving new mails,
Calendar
stops
synchronizing events, and so on, until you refresh them.
• Select or clear the
Auto-sync
check box to control whether changes you make to
information on the phone or on the web are automatically synchronized with each
other.
For example, when this option is selected, changes that you make in
Contacts
on the phone are automatically made in Google Contacts on the web.
10.2.2 Changing an Account’s Synchronization Settings
1. On the
Accounts & sync settings
screen, select
Background data
and
Auto-
sync
.
2. Touch the account for which you want to change the synchronization settings. The
data and synchronization screen opens, displaying a list of the kinds of information
the account can synchronize.
3. Select the items you want to synchronize from the list. Your phone will automatically
synchronize the selected items.
61
11 Using Other Applications
11.1 AppInstaller
You can use this installer to install more than one applications at a time.
11.1.1 Install Applications
1. On the Home screen, touch >
AppInstaller
. Then the installer will scan and
display all the applications (.apk files) in the microSD card.
2. In the applications list, select applications you want to install.
You can touch , and then touch
Deselect all
or
Select all
to select and
deselect all applications.
3. Touch >
Install
.
The applications you select will be installed in your phone.
11.2 Calendar
Use
Calendar
to create and manage events, meetings, and appointments.
Depending on your synchronization settings, the calendar on your phone can be
synchronized with the internet-based calendar you use.
11.2.1 Opening Calendar
On the Home screen, touch >
Calendar
to open the application.
When you add a Google Account that includes a calendar service to your phone,
you can access Google calendar: Touch , and then touch
More
>
Calendars
.
11.2.2 Creating an Event
1. In any calendar view, touch , and then touch
New event
to open the
Event
details
screen.
If you have more than one calendar, select the calendar where you want to save
62
the event.
2. Enter the event name.
• If there is a time frame for the event, touch
From
and
To
to set the beginning
and end times of the event.
• If the event is a special occasion such as a birthday or a day-long activity, set
the date for
From
and
To
, and then select the
All day
check box.
3. Enter the location of the event and a description.
4. Specify in
Repetition
whether the event recurs and, if it does, how frequently, and
then set the time for your event reminder in
Reminders
.
5. Touch
Done
.
To quickly create an event in the day, week, or month view, touch and hold an
empty time slot, and then touch
New event
. A new event details screen will
appear with the selected time slot and date in the
From
and
To
fields.
11.2.3 Setting an Event Reminder
1. In any calendar view, touch an event to view its details or an event summary.
2. Touch the
Add reminder
button to add a reminder, or touch the reminder’s “-”
button to delete an existing reminder.
3. Touch the reminder time, and then, from the list displayed, touch the length of time
before the event when you want to be reminded. When the time comes, you will
receive a notification about the event.
11.2.4 Setting Synchronization and Display
The Calendars screen displays all the calendars you have added or subscribed to for
each account that is configured to synchronize events to your phone, organized by
account. (Calendars for accounts you have configured not to synchronize Calendar
events are not included in the list.)
1. In any calendar view, touch . Then touch
More
>
Calendars
.
2. Touch the icon next to a calendar to change whether it is synchronized and
whether it is displayed.
You remain subscribed to Calendars that you configure not to store on the
phone and can still work with them with Google Calendar on the web, or using
other calendar services.
63
3. Touch
OK
.
11.2.5 Customizing Calendar Settings
In any calendar view, touch . Then touch
More
>
Settings
and choose from the
following:
•
Hide declined events
: Select to hide events for which you have declined
invitations.
•
Set alerts & notifications
: Touch to set event reminders to alert you, to send you
a notification, or to turn off event notifications on your mobile phone.
•
Select ringtone
: Touch to select the ringtone to sound when you receive an event
reminder.
•
Vibrate
: Select to vibrate the mobile phone when you receive an event notification.
•
Default reminder time
: Touch to select the default time before an event for event
reminders to occur.
11.3 File Manager
File Manager
is like having a pocket-sized personal assistant (PA), letting you
organize, edit, and delete files and folders.
11.3.1 Opening File Manager
On the Home screen, touch >
File Manager
to open the application.
11.3.2 Creating a Folder
1. On the
File Manager
screen, access the directory in which you want to create a
new folder.
2. Touch to open the options panel, and then touch
New folder
.
3. Enter the name of the new folder in the text box.
4. Touch
Save
.
11.3.3 Moving or Copying a File
1. On the
File Manager
screen, touch to show the options panel, and then
touch
Multiselect
.
64
2. Touch the file or folder you want to move or copy. When a file or a folder is selected,
a check mark will appear.
To select or unselect all files, touch
Select all
or
Unselect all
.
3. Touch
Cut
or
Copy
.
4. Select the path where you want the file to be copied or moved. Touch to open
the options panel, and then touch
Paste
to move or copy the file to the selected
path.
11.3.4 Searching for a File
1. On the
File Manager
screen, touch a folder to access the directory where the file
you want is located.
2. Touch to open the options panel, and then touch
Search
.
3. Write a key word of the name of your file in the search box.
4. Touch next to the search box. Your mobile phone will start the search.
5. A list of search results will be displayed. Touch a file in the list to open it.
6. Touch
New search
for a new search or touch the back key to return to the file
manager screen.
11.3.5 Compressing or Extracting Files
Your phone supports compressing and extracting files.
You can only compress files and folders into .zip files, but can extract both .zip
and .rar files.
Compressing Files
1. On the
File Manager
screen, touch , and then touch
Multiselect
.
2. Select the files or folders you want to compress. When a file is selected, a check
mark will appear.
To select or unselect all files, touch
Select all
or
Unselect all
.
3. Touch
Compress
.
4. Edit the save path and the name of the target file, and then touch
OK
to start
compressing the files and folders.
65
Extracting a File
1. Touch and hold a compressed file.
2. Touch
Extract
.
3. Edit the save path for the extracted files.
4. Touch
OK
to start extracting.
11.3.6 Viewing Your Memory Status
On the
File Manager
screen, touch to open the options panel, and then touch
Memory Status
. The memory management screen will be displayed. This screen
allows you to view the memory status and available memory on your mobile phone
and microSD card.
11.4 Clock
In addition to displaying the date and time, the
Clock
application displays information
about the weather and your phone. You can also use
Clock
to turn your mobile
phone into an alarm clock.
11.4.1 Opening the Clock
On the Home screen, touch >
Clock
to open the application.
Clock
opens with the date and time displayed on your Home screen wallpaper, along
with your local weather and other useful information.
11.4.2 Opening the Alarms
On the
Clock
screen, touch to open the
Alarms
.
Adding an Alarm
1. On the alarm list screen, touch
Add alarm
.
2. Set the alarm, and then touch
Done
.
Setting an Alarm
1. On the alarm list screen, touch one of the alarms on the screen.
2. Touch
Time
to set the time of the alarm.
3. Touch
Repeat
to set the days when you want the alarm to sound.
66
4. Touch
Ringtone
to select a ringtone for the alarm.
5. Select the
Vibrate
check box to enable the phone to vibrate, in addition to playing
the ringtone.
6. Touch
Label
to enter a name for the alarm.
7. Touch
Done
.
The alarm clock still works when the phone is powered off.
Customizing Alarm Settings
On the alarm list screen, touch , and then touch
Settings
.
11.5 Calculator
Use
Calculator
to solve simple arithmetic problems or use its advanced operators to
solve more complex equations.
11.5.1 Opening Calculator
On the Home screen, touch >
Calculator
to open the application.
11.5.2 Switching Between Basic and Advanced panel
On the
Calculator
screen, flick the screen to the right or left to switch between
Advanced panel
and
Basic panel
.
11.6 Notepad
Notepad
features a simple text processor. In the note list, you can add, edit, and
delete notes.
1. On the Home screen, touch >
Notepad
to open the application.
2. Touch , and then touch
Add note
to create a note.
3. Touch >
OK
to save the note.
67
12 Managing Your Mobile Phone
To configure your mobile phone, touch >
Settings
.
12.1 Setting the Date and Time
When your mobile phone is using the date and time settings provided
automatically by the network, you cannot manually set the date, time, and time
zone.
1. On the
Settings
screen, touch
Date & time
.
2. Clear the
Automatic
check box.
3. Touch
Set date
. On the set date screen, touch or to adjust the date,
month, and year, and then touch
Set
when the configuration is complete.
4. Touch
Select time zone
, and then select the desired time zone from the list. Scroll
the list to view more time zones.
5. Touch
Set time
. On the set time screen, touch or to adjust the hour and
minute. Touch
Set
when the configuration is complete.
6. Select or clear the
Use 24-hour format
check box to switch between 24-hour and
12-hour formats.
7. Touch
Select date format
to select how you want the date to display on your
mobile phone.
12.2 Setting the Display
12.2.1 Adjusting the Screen Brightness
1. On the
Settings
screen, touch
Display
>
Brightness
.
If you want to adjust the screen brightness manually, first clear the
Automatic
brightness
checkbox.
2. Drag the slider left to make the screen darker, or right to make it brighter.
3. Touch
OK
to save the adjustment.
68
12.2.2 Adjusting the Time Before the Screen Turns Off
If your mobile phone is idle for several minutes, it will turn off the screen to save battery
power. To set a longer or shorter idle time:
1. On the
Settings
screen, touch
Display
>
Screen timeout
.
2. Select the duration you want the screen to be illuminated.
12.3 Setting Ringers
12.3.1 Turning On Silent Mode
1. On the
Settings
screen, touch
Sound
.
2. Select the
Silent mode
check box to silence all sounds except alarms, and music
and video media.
12.3.2 Adjusting the Volume
You can adjust the volume while on the Home screen or on most of the application
screens (such as the screen displayed during a call or when playing music or videos).
Press the Volume keys to adjust volume to the level you desire. You can also adjust
the volume from the settings screen.
1. On the
Settings
screen, touch
Sound
>
Volume
.
2. Drag the slider left to make the volume lower, or right to make it higher.
3. Touch
OK
to save the adjustment.
12.3.3 Changing the Phone Ringtone
1. On the
Settings
screen, touch
Sound
>
Phone ringtone
.
2. In the displayed list, select an option:
•
Ringtone
: Select a preinstalled ringtone. The ringtone plays when selected.
•
Music
: Select the music stored in the phone or on the microSD card. The
music plays when selected.
3. Touch
OK
.
12.3.4 Changing the Message Ringtone
1. On the Home screen, touch >
Messaging
.
69
2. In the message list, touch >
Settings
>
Select ringtone
.
3. In the displayed list, select an option:
•
Ringtone
: Select a preinstalled ringtone. The ringtone plays when selected.
•
Music
: Select the music stored in the phone or on the microSD card. The
music plays when selected.
4. Touch
OK
.
12.4 Setting Phone Services
12.4.1 Customizing Call Settings
Mobile phone service providers offer different services such as call forwarding, call
waiting, fixed dialing numbers, and voicemail. You can customize many of these
services if they are part of your calling plan.
On the
Settings
screen, touch
Call settings
to customize your call functions.
12.4.2 Turning on Data Roaming
1. On the
Settings
screen, touch
Wireless & networks
>
Mobile networks
.
2. Select the
Data roaming
check box.
Accessing data services while roaming may incur additional charges. Ask your
wireless service provider about data roaming fees.
12.4.3 Switching off the Data Service
1. On the
Settings
screen, touch
Wireless & networks
>
Mobile networks
.
2. Clear the
Data enabled
check box.
12.5 Configuring Text-to-Speech
Use the Text-to-Speech settings to configure the Android text-to-speech synthesizer,
for applications that can take advantage of this feature.
12.5.1 Installing Voice Data
1. On the
Settings
screen, touch
Voice input & output
>
Text-to-speech settings
>
Install voice data
.
70
2. If your mobile phone does not have speech synthesizer data installed, connect to
Android Play Store and let it guide you through the process of downloading and
installing the data.
3. Follow the instructions to install the voice data.
12.5.2 Adjusting the Speech Rate
1. On the
Settings
screen, touch
Voice input & output
>
Text-to-speech settings
>
Speech rate
.
2. Select a speed at which the text is to be spoken.
12.6 Protecting Your Mobile Phone
12.6.1 Turning on Your SIM Card PIN
1. On the
Settings
screen, touch
Location & security
>
Set up SIM card lock
.
2. Select the
Lock SIM card
check box.
3. Use the keyboard to enter the PIN, and then touch
OK
.
4. To change the PIN at any time, touch
Change SIM PIN
.
You can dial emergency numbers any time from your mobile phone.
12.6.2 Protecting Your Mobile Phone with a Screen Lock
To keep your data more secure, lock the screen and/or require a screen unlock
pattern every time your mobile phone is turned on or wakes up from sleep mode.
1. On the
Settings
screen, touch
Location & security
>
Set up screen lock
>
Pattern
.
2. Flick your finger vertically, horizontally or diagonally, connect at least four dots in
any order you choose. Lift your finger from the screen when you are finished.
You must drag your finger between the dots on the screen to create the pattern,
not simply touch individual dots.
3. Your mobile phone will record the pattern. Touch
Continue
.
4. When prompted, draw the screen unlock pattern again, and then touch
Confirm
.
To change your unlock screen pattern, touch
Location & security
>
Change screen
lock
.
71
12.6.3 Protecting Your Mobile Phone with a Numeric PIN
You can set up a numeric PIN to lock your phone.
1. On the
Settings
screen, touch
Location & security
>
Set up screen lock
>
PIN
.
2. Enter at least four characters.
3. Touch
Continue
.
4. Enter the same characters again and touch
OK
.
To change your PIN, touch
Location & security
>
Change screen lock
.
12.6.4 Unlocking Your Mobile Phone If You Forget the Screen
Lock Pattern
If you have already created a Google account, you can unlock your mobile phone
using the following methods.
• After you have entered the wrong sequence five times, a
Forgot pattern?
button
will appear. Touch this button to enter the Google account interface. After you have
entered your Google account password, you will be able to reset the unlock pattern.
• After you have entered the wrong pattern twenty times, you will be taken directly to
the Google account interface. After you have entered your Google account
password, you will be able to reset the unlock pattern.
12.7 Managing Applications
12.7.1 Viewing an Installed Application
1. On the
Settings
screen, touch
Applications
>
Manage applications
.
2. In the applications list, do either of the following:
• Touch , and then touch
Sort by size
. Then touch an application to view its
details.
• Touch an application directly to view its details.
12.7.2 Uninstalling an Application
You cannot uninstall the applications that are pre-installed on the system.
1. On the
Settings
screen, touch
Applications
>
Manage applications
.
72
2. Touch an application, and then touch
Uninstall
.
12.7.3 Moving an Application to the microSD Card
Some applications are designed to be stored on your phone’s USB storage or
microSD card (depending on the model of your phone), rather than in its internal
storage. Others are designed so you can change where they are stored. You may find
it helpful to move large applications off your internal storage, to make more room for
other applications that do not offer the option.
1. On the
Settings
screen, touch
Applications
>
Manage applications
.
2. Touch an application in the list. Then touch
Move to SD card
to move the bulk of
the application from the phone’s internal storage.
The
Storage
section of the application’s details screen shows details about the
memory used by the application. If the application can be moved, the
Move to SD
card
button is active.
Touch
Move to phone
to move the application back to the phone’s internal storage.
12.7.4 Ways to Free Up Your Mobile Phone Memory
• Move files and email attachments to the microSD card.
• In
Browser
, clear all temporary Internet files and Browser history information.
• Move applications to the microSD card.
• Uninstall any downloaded programs that you no longer use.
• Reset your mobile phone.
12.8 Resetting Your Mobile Phone
12.8.1 Backing Up My Data
You can use your Google account to back up your mobile phone’s settings to Google
servers. If you replace your mobile phone, the settings you have backed up will be
transferred to the new mobile phone the first time you sign in to your Google account.
1. On the
Settings
screen, touch
Privacy
.
2. Select the
Back up my data
check box.
73
12.8.2 Restoring Factory Data
If you reset your phone to its factory settings, all of your personal data stored on the
phone, including information about your Google account, any other accounts that you
have configured, your system and application settings, and any applications you have
installed will be erased. Resetting the phone does not erase any system updates you
have downloaded. Using the check box provided, you can also select to erase all the
data stored on the phone’s internal SD card, which includes files that you have
downloaded or copied there, such as music or photos.
1. On the
Settings
screen, touch
Privacy
>
Factory data reset
.
2. When prompted, touch
Reset phone
, and then touch
Erase everything
. The
mobile phone resets the settings to the original factory settings, and then restarts.
13 Appendix
13.1 Warnings and Precautions
This section contains important information pertaining to the operating instructions of
your device. It also contains information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not use the device when
using the device causes danger or interference with electronic devices.
Medical Device
• Follow rules and regulations set forth by hospitals and health care facilities. Do not
use your device when using the device is prohibited.
• Pacemaker manufacturers recommend that a minimum distance of 15 cm be
maintained between a device and a pacemaker to prevent potential interference
with the pacemaker. If you are using a pacemaker, use the device on the opposite
side of the pacemaker and do not carry the device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive atmosphere, and
comply with all signs and instructions. Areas that may have potentially explosive
74
atmospheres include the areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause an explosion or a fire,
resulting in bodily injuries or even deaths. Do not power on your device at refueling
points such as service stations. Comply with restrictions on the use of radio equipment
in fuel depots, storage, and distribution areas, and chemical plants. In addition, adhere
to restrictions in areas where blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive atmospheres that are often,
but not always, clearly marked. Such locations include areas below the deck on boats,
chemical transfer or storage facilities, and areas where the air contains chemicals or
particles such as grain, dust, or metal powders. Ask the manufacturers of vehicles
using liquefied petroleum gas (such as propane or butane) whether this device can be
safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In addition, if using the
device while driving a vehicle, comply with the following guidelines:
• Concentrate on driving. Your first responsibility is to drive safely.
• Do not talk on the device while driving. Use hands-free accessories.
• When you have to make or answer a call, park the vehicle at the road side before
using your device.
• RF signals may affect electronic systems of motor vehicles. For more information,
consult the vehicle manufacturer.
• In a motor vehicle, do not place the device over the air bag or in the air bag
deployment area. Otherwise, the device may hurt you owing to the strong force
when the air bag inflates.
• Do not use your device while flying in an aircraft. Power off your device before
boarding an aircraft. Using wireless devices in an aircraft may cause danger to the
operation of the aircraft and disrupt the wireless telephone network. It may also be
considered illegal.
Operating Environment
• Do not use or charge the device in dusty, damp, and dirty places or places with
magnetic fields. Otherwise, it may result in a malfunction of the circuit.
• The device complies with the RF specifications when the device is used near your
ear or at a distance of 1.5 cm from your body. Ensure that the device accessories
75
such as a device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body to meet the
requirement earlier mentioned.
• On a stormy day with thunder, do not use your device when it is being charged, to
prevent any danger caused by lightning.
• When you are on a call, do not touch the antenna. Touching the antenna affects the
call quality and results in increase in power consumption. As a result, the talk time
and the standby time are reduced.
• While using the device, observe the local laws and regulations, and respect others'
privacy and legal rights.
• Keep the ambient temperature between –10°C and 4°C while the device is being
charged. Keep the ambient temperature between –10°C to °C for using the
device powered by a battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To reduce the risk of
damage to hearing, lower the headset volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety. Letting the child play with
your device or its accessories, which may include parts that can be detached from the
device, may be dangerous, as it may present a choking hazard. Ensure that small
children are kept away from the device and accessories.
Accessories
Choose only batteries, chargers, and accessories approved for use with this model by
the device manufacturer. The use of any other type of battery, charger, or accessory
may invalidate any warranty for the device, may be in violation of local rules or laws,
and may be dangerous. Please contact your dealer for information about the
availability of approved batteries, chargers, and accessories in your area.
Battery and Charger
• Unplug the charger from the electrical plug and the device when not in use.
• The battery can be charged and discharged hundreds of times before it eventually
wears out. When the standby time and the talk time are shorter than the normal
time, replace the battery.
76
• Use the AC power supply defined in the specifications of the charger. An improper
power voltage may cause a fire or a malfunction of the charger.
• Do not connect two poles of the battery with conductors, such as metal materials,
keys, or jewelries. Otherwise, the battery may be short-circuited and may cause
injuries and burns on your body.
• If battery electrolyte leaks out, ensure that the electrolyte does not touch your skin
and eyes. When the electrolyte touches your skin or splashes into your eyes, wash
your eyes with clean water immediately and consult a doctor.
• If there is a case of battery deformation, color change, or abnormal heating while
you charge or store the battery, remove the battery immediately and stop using it.
Otherwise, it may lead to battery leakage, overheating, explosion, or fire.
• If the power cable is damaged (for example, the cord is exposed or broken), or the
plug loosens, stop using the cable at once. Otherwise, it may lead to an electric
shock, a short circuit of the charger, or a fire.
• Do not dispose of batteries in fire as they may explode. Batteries may also explode
if damaged.
• Do not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, expose to fire, explosion or other
hazard.
• Avoid dropping the device or battery. If the device or battery is dropped, especially
on a hard surface, and the user suspects damage, take it to a qualified service
center for inspection.
• Improper battery use may result in a fire, explosion or other hazard.
• Promptly dispose of used batteries in accordance with local regulations.
• The device should only be connected to products that bear the USB-IF logo or
have completed the USB-IF compliance program.
Cleaning and Maintenance
• The device, battery, and charger are not water-resistant. Keep them dry. Protect
the device, battery, and charger from water or vapor. Do not touch the device or the
charger with a wet hand. Otherwise, it may lead to a short circuit, a malfunction of
the device, and an electric shock to the user.
77
• Do not place your device, battery, and charger in places where they can get
damaged because of collision. Otherwise, it may lead to battery leakage, device
malfunction, overheating, fire, or explosion.
• Do not place magnetic storage media such as magnetic cards and floppy disks
near the device. Radiation from the device may erase the information stored on
them.
• Do not leave your device, battery, and charger in a place with an extreme high or
low temperature. Otherwise, they may not function properly and may lead to a fire
or an explosion. When the temperature is lower than 0°C, performance of the
battery is affected.
• Do not place sharp metal objects such as pins near the earpiece. The earpiece
may attract these objects and hurt you when you are using the device.
• Before you clean or maintain the device, power off the device and disconnect it
from the charger.
• Do not use any chemical detergent, powder, or other chemical agents (such as
alcohol and benzene) to clean the device and the charger. Otherwise, parts of the
device may be damaged or a fire can be caused. You can clean the device and the
charger with a piece of damp and soft antistatic cloth.
• Do not dismantle the device or accessories. Otherwise, the warranty on the device
and accessories is invalid and the manufacturer is not liable to pay for the damage.
• If the device screen is broken by colliding with hard objects, do not touch or try to
remove the broken part. In this case, stop using the device immediately, and then
contact an authorized service center in time.
Emergency Call
You can use your device for emergency calls in the service area. The connection,
however, cannot be guaranteed in all conditions. You should not rely solely on the
device for essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As recommended by
international guidelines, the device is designed not to exceed the limits for exposure to
radio waves. These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing Radiation Protection
78
(ICNIRP) and include safety measures designed to ensure safety for all users,
regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of measurement for the amount of
radio frequency energy absorbed by the body when using a device. The SAR value
is determined at the highest certified power level in laboratory conditions, but the
actual SAR level of the device when being operated can be well below the value. This
is because the device is designed to use the minimum power required to reach the
network.
The SAR limit adopted by USA and Canada is 1.6 watts/kilogram (W/kg) averaged
over one gram of tissue. The Highest SAR value reported to the FCC and IC for this
device type when tested for use at the ear is 0.367 W/kg, when properly worn on body
is 0.861 W/kg, and when using Wi-Fi hotspot function is 1.130 W/Kg.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Caution
Changes or modifications made to this device not expressly approved by
Huawei Device USA. may void the FCC authorization to operate this device.
79
13.2 FAQs
More FAQs are available at the following website:
http://www.huaweidevice.com/worldwide/faq.do?method=index
.
How Can I Use a microSD Card to Import Contacts to My Phone from a
Different Mobile Phone?
Your mobile phone only supports contact files in the
.vcf
format.
1.
Save the contacts you want to import to your mobile phone to a microSD
card as a
.vcf
file.
2.
Insert the microSD card into your mobile phone and find the
.vcf
file
using
File Manager
.
3.
Touch the
.vcf
file. The phone displays a message asking whether you
want to import the contacts.
4.
Touch
OK
to import the contacts.
Compatibility problems may occur with
.vcf
files created by different mobile
phones and certain contact information may be lost after contacts are imported.
How Can I Use HiSuite to Import Contacts to My Phone from a Different
Mobile Phone?
Your mobile phone only supports contact files in the
.vcf
format.
1.
Save the
.vcf
file containing the contact information you want to import
to a PC.
2.
On the Home screen, touch >
Settings
>
Applications
>
Development
>
USB debugging
.
3.
Use a USB cable to connect your phone to the PC.
4.
Visit
http://www.huaweidevice.com/worldwide
to download and
install HiSuite.
5.
Open HiSuite and follow the instructions to complete the installation.
6.
Open HiSuite after the installation is complete. Click
Contacts
> .
Follow the instructions and select the
.vcf
file you want to import.
7.
Disconnect your mobile phone from the PC after the contacts have been
imported.
80
How Do I Set a Song As a Phone Ringtone?
In
Music
, touch and hold the song to be set as ringtone, and then touch
Use as
phone ringtone
.
How Do I Prevent Automatic Change of Screen Orientation When Rotating My
Phone?
On the Home screen, touch >
Settings
>
Display
>
Auto-rotate screen
to
disable the function.
How Do I Set an Unlock Pattern?
On the Home screen, touch >
Settings
>
Location & security
>
Set up screen
lock
>
Pattern
.
How Can I Change the Input Method?
Touch and hold the area where you write text and then select the input method you
prefer.
How Do I Stop the Song Playing in the Background?
Touch the notification bar, flick downwards to open the notifications panel, touch the
music playing notification to go to the music playing screen, and then stop playing the
song.
How Do I Return to the Call Screen?
While in a call, if you’re on another screen, you can touch the notification bar, and flick
downwards to open the notifications panel. Then touch the current call notification to
return to the call screen.
How Do I Create an Application Shortcut on the Home Screen?
Touch and hold an application icon on the application screen until the Home screen is
displayed. Then drag the icon to where you want to place it and release your finger.
How Do I Hide the Keyboard?
Touch to hide the keyboard.
How Do I Forward a Message?
Touch and hold a message, and then touch
Forward
in the menu that opens.
