Huawei Technologies U9200 Ascend P1; HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with BT User Manual

Huawei Technologies Co.,Ltd Ascend P1; HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with BT

User Manual

1
Copyright © Huawei Technologies Co., Ltd. 2012. All
rights reserved.
Trademarks and Permissions
, and are trademarks or registered trademarks
of Huawei Technologies Co., Ltd.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
Android is a trademark of Google Inc.
DISCLAIMER OF WARRANTIES
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS
IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, ARE MADE IN RELATION TO
THE ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
LIMITATIONS OF LIABILITY
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO EVENT SHALL HUAWEI TECHNOLOGIES
CO., LTD. BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST
PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.
English
EN
2
Getting to Know Your Phone
1
Figures in this guide are provided for your reference
only. Depending on the software version, your
phone's user interface may be different from the user
interface shown in the gures.
4
5
2
16
7
8
3
9
10
11
12
13
14
1 Earpiece 2 Headset jack
3 Charger jack/USB port 4 USIM card slot
5 Secondary camera 6 Status indicator
7 Power key 8 microSD card slot
9 Microphone 10 Camera
11 Noise reduction microphone 12 Flash unit
13 Volume keys 14 Speaker
• Press and hold to power on your phone.
• Press and hold to display the options menu from
where you can power off the phone and perform
some shortcut operations.
• Press to lock the screen when your phone is active.
• Press and hold for 10 or more seconds to forcibly
power off the phone.
• Touch to return to the previous screen.
• Touch to exit the current application.
• Touch to return to the Home screen.
• Touch to display the current screen's options menu
(some screens have no menu).
EN
3
Installing SIM and microSD Cards
Install the USIM card or microSD card as shown in the
following diagram. Power off your phone before installation.
Install a USIM card
Standard USIM card dimensionsᷛ
25mmx15mmx0.76mm(DxWxH)
1
The micro SD card is
an optional accessory
Install a microSD card
2
• Your phone supports only standard USIM cards.
Using a non-standard USIM card may cause
damage to your phone.
• Do not install or remove a USIM card when your
phone is powered on.
EN
4
Charging Your Phone
Your mobile phone has an internal rechargeable
battery. Do not attempt to open the battery cover
and replace the battery by yourself. To replace the
battery, contact Huawei or an authorized service
provider.
When charging your phone while it is powered on, the battery
is fully charged when the battery icon changes to .
Use the charger provided with your phone. If the
phone has not been used for a long time or if the
battery charge is fully depleted, the phone may not
power on immediately after the charger is plugged
in. Please charge the battery for a while before
attempting to power on the phone.
EN
5
Battery status indicator
Status indicator
Steady green: The phone is charging and the
battery level is high or full.
Steady yellow: The phone is charging and the
battery level is higher than 10%.
Steady red: The phone is charging and the battery
level is low.
Blinking red: The battery level is low and the phone
needs to be charged.
Powering Your Phone On or Off
Powering Your Phone On
Press and hold the key to power on your phone. If this is
the rst time you have powered on the phone, congure its
initial settings. If your SIM card is PIN-protected, enter the
personal identication number (PIN) to use the phone.
Powering Your Phone Off
Press and hold the Power key to display the options menu,
and touch "Power off" to power your phone off.
If your phone malfunctions or cannot be properly
powered off, press and hold the Power key for at
least 10 seconds to forcibly power off your phone.
EN
6
Using the Touchscreen
Touch: Touch the screen to select an
option or start an application.
Touch and hold: Touch and hold the
screen or text being edited to display
the available options menu.
Slide: Quickly drag your nger across
the screen vertically or horizontally.
Drag: Touch and hold an item, and then
drag it to the desired location on the screen.
For example, on the Home screen, you can
move an icon by dragging it to another
location or remove an icon by dragging it to
the trash can.
Finding the User Guide
For more information about how to use your phone, please
read the user guide. You can nd the user guide by visiting
the Web site: http://www.huaweidevice.com/worldwide.
Operating Environment
• ThedevicecomplieswiththeRFspecicationswhenthe
device is used near your ear or at a distance of 1.5 cm
from your body. Ensure that the device accessories such
as a device case and a device holster are not composed
of metal components. Keep your device 1.5 cm away from
your body to meet the requirement earlier mentioned.
• Keep the ambient temperature between –10°C and 45°C
while the device is being charged. Keep the ambient
temperature between –10°C to 45°C for using the device
powered by a battery.
EN
7
Certication Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver.
As recommended by international guidelines, the device
is designed not to exceed the limits for exposure to radio
waves. These guidelines were developed by the independent
scienticorganizationInternationalCommissiononNon-
Ionizing Radiation Protection (ICNIRP) and include safety
measures designed to ensure safety for all users, regardless
of age and health.
TheSpecicAbsorptionRate(SAR)istheunitof
measurement for the amount of radio frequency energy
absorbed by the body when using a device. The SAR value
isdeterminedatthehighestcertiedpowerlevelinlaboratory
conditions, but the actual SAR level of the device when being
operated can be well below the value. This is because the
device is designed to use the minimum power required to
reach the network.
The SAR limit adopted by USA and Canada is 1.6 watts/
kilogram (W/kg) averaged over one gram of tissue. The
Highest SAR value reported to the FCC and IC for this device
type when tested for use at the ear is 0.745 W/kg, when
properly worn on body is 1.020 W/kg, and when using Wi-Fi
hotspot function is 1.290 W/kg.
The SAR limit also adopted by Europe is 2.0 W/kg averaged
over 10 grams of tissue. The highest SAR value for this
device type when tested at the ear is 0.573 W/kg, and when
properly worn on the body is 0.540 W/kg.
EN
