Huawei Technologies V830I HSDPA/UMTS/GPRS/GSM Mobile Phone with BT User Manual

Huawei Technologies Co.,Ltd HSDPA/UMTS/GPRS/GSM Mobile Phone with BT

User Guide

Make the most of now.
Vodafone 830i Mobile Phone
User Guide
Notice
Copyright ¤ 2008 Huawei Technologies Co.
Ltd.
All Rights Reserved
1Your Vodafone 830i is made exclusively for
Vodafone by Huawei Technologies.
2No part of this manual may be reproduced or
transmitted in any form or by any means without
prior written consent of Huawei Technologies
Co. Ltd.
3
Trademarks
4VODAFONE, the Vodafone logos are trade
marks of the Vodafone Group. Other product and
company names mentioned herein may be trade
marks of their respective owners.
5
Notice
6The information in this manual is subject to
change without notice. Every effort has been
made in the preparation of this manual to ensure
accuracy of the contents, but all statements,
information, and recommendations in this
7manual do not constitute a warranty of any kind,
expressed or implied.
8Read the safety precautions carefully to ensure
that you use wireless device in a correct and
safe manner. For details, see the section "Warn-
ings and Precautions".
Huawei Technologies Co. Ltd.
Branch Address:
9Huawei Technologies Deutschland GmbH,
Am Seestern 24, Dusseldorf, Germany
10 Postal Code: 40547
Head Office Address:
11 Administration Building, Huawei Technologies
Co. Ltd., Bantian, Longgang District,
12 Shenzhen, P. R. China
13 Postal Code: 518129
Website: http://www.huawei.com
14
Read the Safety Information section of
this user guide on page 44.
Do not use hand-held while driving.
For body-worn operation maintain a
separation of 1.5 cm.
Small parts may cause a choking
hazard.
This device may produce a loud sound.
Keep away from pacemakers and other
personal medical devices.
Switch off when instructed in hospitals
and medical facilities.
Switch off when instructed in aircrafts
and airports.
Do not use while re-fuelling.
This device may produce a bright or
flashing light.
Do not dispose of in a fire.
Avoid contact with magnetic media.
Avoid Extreme Temperatures
Avoid contact with liquid, keep dry.
Do not try and disassemble.
Do not rely on this device for
emergency communications.
Safety Precautions
15
16 Specific Absorption Rate (SAR)
17 Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits
for exposure to radio waves recommended by
international guidelines. These guidelines were
developed by the independent scientific
organisation ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
18 The guidelines use a unit of measurement
known as the Specific Absorption Rate, or SAR.
The SAR limit for mobile devices is 2 W/kg and
the highest SAR value for this device when
tested at the ear was 0.624 W/kg*. As mobile
devices offer a range of functions, they can be
used in other positions, such as on the body as
described in this user guide**.
19 As SAR is measured utilising the device's
highest transmitting power, the actual SAR of
this device while operating is typically below that
indicated above. This is due to automatic
changes to the power level of the device to
ensure it only uses the minimum power required
to communicate with the network.
20 * The tests are carried out in accordance with
EN 50360:2001; EN 50361:2001.
21 ** Please see page 44 about body worn
operation.
22 Please read the safety precautions carefully to
ensure the correct and safe use of your wireless
device. For detailed information, refer to the
23 section “Warnings and Precautions”.
24
25
Switch off in explosive environments.
Only use approved accessories.
.
1
Table of Contents 1
Getting to Know Your Phone 1
Packing List................................................1
Your Phone ................................................1
Home Screen .............................................3
Introduction to the Menu.............................4
Getting Started 5
Loading the SIM Card ................................5
Unloading the SIM Card.............................5
Charging the Battery ..................................6
Powering On/Off.........................................8
Call Service 9
Making or Answering Calls.........................9
Operations During a Voice Call................10
Operations During a VideoCall...............11
Calls .........................................................12
Text Input 13
T9£ Input Method.....................................13
Traditional Input Method ..........................13
"123" Numeric Input Method ....................14
Symbol Input Method ...............................14
Input Different Languages........................14
Contacts 15
Making Calls from the Contacts ...............15
Searching for a Contact............................15
Other Operations......................................15
Groups......................................................16
Messaging, Email 17
Messages.................................................17
Email........................................................19
Broadcast Inbox.......................................21
Templates ................................................21
Music 22
Vodafone music .......................................22
Recently Played.......................................22
Music Library............................................22
Organiser & Tools 23
Alarms......................................................23
Calendar ..................................................23
Task .........................................................23
Memo.......................................................23
Synchronise .............................................24
Calculator.................................................24
Unit Converter..........................................24
Currency Converter..................................25
Voice Recorder ........................................25
World Time...............................................25
Stopwatch ................................................25
Timer........................................................25
Service Dial Number ................................25
My Files 26
Web, Applications, Mobile TV 27
Web..........................................................27
Applications..............................................27
Table of Contents
2
Mobile TV .................................................27
Entertainment 28
Games......................................................28
CameraVideo Camera............................28
Connections 30
USB..........................................................30
Bluetooth£................................................34
Settings 37
Phone settings..........................................37
Display settings ........................................37
Message settings .....................................38
Call settings..............................................38
Video call .................................................40
Contact settings........................................40
Connectivity..............................................40
Device management ...............................41
Network ...................................................41
JavaTM settings ........................................41
Security ...................................................41
License setting .........................................42
Streaming settings....................................43
Warnings and Precautions 44
RF Exposure ............................................44
Distraction ................................................47
Product Handling......................................47
Electrical safety ........................................49
Interference ..............................................50
Explosive environments ...........................51
Environmental Protection.........................51
Acronyms and Abbreviations 52
Appendix 53
1
1Getting to Know Your Phone
Your Vodafone 830i phone can operate in virtually all
countries, automatically switching between
WCDMA/HSDPA 900/2100 and GSM/GPRS 900/
1800/1900 networks. This allows you to enjoy
communication wherever you use your mobile phone.
Note The services supported by your phone
should be also supported by the network
from where you use the phone. For details,
please contact your local Vodafone cus-
tomer care centre. Note that you can also
access information on Vodafone services at
www.vodafone.com.
Packing List
Your phone package box contains the following:
One Vodafone 830i mobile phone
One travel charger
One Li-ion battery
One User Guide
One stereo headset (Optional)
One USB data cable (Optional)
Your Phone
Camera
Camera
Earpiece/
speaker
Screen Battery cover
Volume keys
Camera shortcut key
• Press this key to activate
the camera in the standby
mode..
Charger connector/Cable
connector/Headset JackMemory card
Your Phone
2
Clear key
• In the editing mode, press this key to
delete a character before the cursor.
Scroll key
• Press this key to scroll through a menu.
• In standby mode,
press the up scroll key to access Quick Menu,
press the down scroll key to access Contacts,
press the left scroll key to access the New SMS
screen, and then press the right scroll key to
access My Files.
Left function key
• Press this key to activate the function indicated
at the left of the prompt bar.
• In standby mode, press this key to access the
main menu.
Send key
• Press this key to make or answer a call.
• Press this key to access the Calls screen in
standby mode. Right function key
• Press this key to activate the function indicated
at the right of the prompt bar on the screen.
• In standby mode, press this key to access
Vodafone live!.
OK key
• Press this key to start the selected function
in the menu.
• In standby mode, press this key to access
the main menu. Power/End key
• Press this key to end an ongoing call or reject an
incoming call.
• Press this key to return to the home screen.
• Press and hold it to power on or power off the
phone
Character/Number keys
• Use to enter numbers or characters.
• Press and hold the # key to switch to the silent
profile from the current profile.
Music key
• In standby mode, press this key to access the
music menu.
Home Screen
3
Getting to Know Your Phone
1
Home Screen
Icon bar
This area displays the phone status. The following
table illustrates the icons that may appear on this bar.
Icon Description
Indicates signal strength. The more hori-
zontal bars that appear, the stronger the
signal.
The phone is currently in a GSM
network.
Icon bar
Prompt bar
To display the operations and the function
options.
Desktop
To display the operations currently available.
The phone is currently in a WCDMA
network.
The phone is currently in a HSDPA
network.
Bluetooth is enabled.
Forwarding all incoming voice calls to
line 1.
Call line 2 is enabled currently.
Forwarding all incoming voice calls to
line 2.
The phone is in a call.
Alarm clock is enabled.
You have new text messages.
You have new multimedia messages.
You have new PUSH messages.
You have new emails.
Icon Description
Introduction to the Menu
4
Introduction to the Menu
Your phone provides an extensive range of functions.
You can use these functions by navigating the follow-
ing menus: Web, Email, Applications, Music, Mes-
saging, My Files, Entertainment, Contacts, Organiser
& Tools, Mobile TV, Calls and Settings.
1In standby mode, press to display the main
menu.
2Press the scroll key to scroll through the menu,
and then press to select the desired item.
3If the menu contains further submenus, repeat
step 2.
4Use the selected function according to the
prompts on the screen.
5Select Back to return to the previous menu.
Press to return to the standby mode.
You have new voice mails.
You are using the roaming service.
The normal profile is activated.
The headset is plugged in.
Your PC connects to the Internet
through your phone.
Indicates power level of the battery.
Icon Description
5
2Getting Started
Loading the SIM Card
Load your SIM card before using your phone. To use
the SIM card properly, please read the following
instructions carefully.
Note Keep the SIM card out of the reach of chil-
dren.
The SIM card and its metal contacts can be
easily damaged by scratching or bending.
Ensure care when you carry, load or remove
it.
Always disconnect the charger from the
phone before loading or removing the SIM
card.
To load the SIM card, do as follows:
1Position the card at the card slot entrance, mak-
ing sure it is facing the same way as shown in
the diagram below, with the notched corner at
the down left. Then slide in as shown.
2Fit the battery into the battery slot on back of the
phone. Press the battery down until it clicks into
place.
3Slide the back cover to the phone.
Unloading the SIM Card
Only unload the SIM card and the battery after pow-
ering off your phone. Otherwise, your phone may be
damaged.
To unload the SIM card:
Charging the Battery
6
1Unload the back cover out of the phone.
2Please unload the battery according to the fol-
lowing picture.
3Press the SIM card with one finger and slide it
out of the slot.
Charging the Battery
Before charging the battery, please read the following
precautions carefully.
Note When you charge the battery for the first time,
please charge it for a minimum of 12 hours.
The battery discharges even while not being
used. If you have not used it for a long time,
please recharge it first.
The charging time depends on the environ-
mental temperature and the age of the bat-
tery.
Do not strike, throw or cause any kind of vio-
lent shock to the battery, otherwise liquid
leakage, body damage, overheating, explo-
sion or fire may occur.
The battery can be recharged but eventually
wears out. If the battery lasts for a shorter
time period than usual after being charged
normally, replace it with a battery of the same
type.
Charge the battery by using the charger sup-
plied with your phone.
Charging the Battery
7
2
Getting Started
Before charging the battery with a cable charger,
ensure that the battery has been properly loaded into
your phone. To charge the battery, do as follows:
1Insert the plug of the charger into the connector
of the phone as shown in the following figure.
2Plug in the connector of the charger to a power
socket.
Note The plug of the charger is in trapezium
shape. Reversely inserting the plug may
damage the mobile phone and charger. The
connection methods of USB data cable and
headset are the same as the charger.
When the battery power level is very low, the
phone makes alert sounds and displays a
prompt. When the battery power level is too
low, the phone will power off automatically.
When the battery is being charged, the charg-
ing indicator blinks continuously. When the
charging indicator stops blinking, it indicates
that the battery is full.
Loading/Removing a Memory
Card
The Vodafone 830i phone supports a memory card
(micro-SD) with a capacity up to 2 GB.
1Insert the memory card into the slot, as shown in
the following figure.
2To remove a memory card, press the memory
card gently. Now the memory card will pop up
automatically. Then take it out as shown in the
following figure.
With metallic contact upward
Powering On/Off
8
Powering On/Off
Powering On
Ensure that the SIM card is in your phone and that
the battery has been charged.
Press and hold to power on your phone.
Powering Off
Press and hold to power off your phone.
Access Codes
For setting and changing the access codes, please
refer to "Settings/Security" on page 41.
ƹPhone Password
The phone password is used to protect your phone
from unauthorized use. The phone password is
preset as 0000 for your Vodafone 830i phone.
ƹPIN
The personal identification number (PIN) code is
used to protect your SIM card from unauthorized use.
The PIN code is usually provided when you get the
SIM card from Vodafone. If you have not received a
PIN code or if you have forgotten it, contact your local
Vodafone customer care centre.
ƹPIN2
Some SIM cards provide a PIN2 code. Some special
functions such as the "Fixed Dialer Number" are not
available until you enter the PIN2 code. At the same
time, your SIM card should support these functions.
ƹPUK
To unlock a locked SIM card, you need to enter the
PIN Unblocking Key (PUK) code. The PUK code is
usually provided when you get the SIM card from
Vodafone. If you have not received a PUK code or if
you have forgotten it, contact your local Vodafone
customer care centre.
ƹPUK2
Some SIM cards provide a PUK2 code that is used to
unlock a locked PIN2 code. The PUK2 code is usu-
ally provided when you get the SIM card from
Vodafone. If you have not received a PUK2 code or if
you have forgotten it, contact your local Vodafone
customer care centre.
9
3Call Service
Making or Answering Calls
Making a Voice or Video Call
You can make a video call to other person whose
phone also supports video calls.
1Enter or edit a phone number in one of the fol-
lowing ways:
Enter a phone number through the keypad.
Select a number from the Calls screen.
Select a number from the Contacts screen.
2To make a voice call or video call.
Press to make a voice call.
Select Options > Call > Video Call to make a
video call.
3Press to end the call.
Note To delete a wrong number, press once to
delete the digit to the left of the cursor.
Making Voice Calls Using SDN
You can make a voice call through speed dialing.
Select Contacts > Options > Advanced > Speed
dial number to set the speed dialing number(SDN).
To make a call by SDN, press and hold the number
key until the phone dials the corresponding phone
number.
Answering or Rejecting Calls
The following describes how to answer or reject a call
in different answer modes:
Operation Description
Answer a
call
If the answer mode is Any key,
press any key except .
If the answer mode is Send key,
press .
If the answer mode is Slide up,
slide the phone.
If the headset is in use, press the
control key on the headset.
Reject a call Press or select Options > Reject.
Operations During a Voice Call
10
Note When the phone is closed and there is no
ongoing call, you can press and hold the cam-
era key to mute the ringtone of an incoming
call. You can also press and hold the volume
keys to reject the call.
You can also set the auto answer mode to Immedi-
ate answer,Text message or Recorded voice. For
details, refer to “Settings/Call settings/Auto Answer”.
Operations During a Voice Call
Icon Description
: A call is ongoing.
: The call is on hold.
Operations
During a voice call, you can select Options to per-
form the following operations.
Hold active call/Resume: To hold or resume the
call during a call.
End: To end all calls,the active call,the current
call or the on hold call.
Handsfree/Earpiece: To switch between the
Handsfree and the Earpiece modes during a call.
Start recording/Stop recording: to record or stop
recording the conversation.
Other applications: To access the Contacts
screen, the Messaging screen, the Calls screen or
the Calendar screen.
Answer/Reject: Your phone allows you to handle
two calls simultaneously. During a call, if there is a
new incoming call, select Options > Answer to
answer it or select Options > Reject to reject it.
Swap: To swap between calls during a 3-party call.
End a call Press to end the call
Reply by
message
To send a predefined message to the
caller.
Operation Description
Operations During a Video Call
11
3
Call Service
Conference call/Private call: To switch to the con-
ference call during a 3-party call or to talk with a
party privately during a conference call.
Operations During a VideoCall
Icon Description
Operations
During a video call, you can press to hold the call
and send a preset file to the other party. You can
press again to resume the call. Before you use
the function, you can preset a file in Settings/Video
call/Send image.
During a video call, you can select Options to per-
form the following operations.
Switch camera off/on: To forbid or allow the video
from your side.
Switch to outer/inner camera: To switch between
the main lens and the assistant lens.
Picture mode: To switch display.
Image quality: To set the image quality to fine qual-
ity or more smooth.
Play file: To play a media file.
Switch to handsfree/earpiece:Switch between
the loudspeaker mode and the earpiece mode.
Start recording: To record a video clip. A recorded
video clip is saved to the My Files/Videos direc-
tory.
Other applications: To access the Contacts
screen, the Messaging screen, the Calls screen or
the Calendar screen.
Icon Description
Press the up or down scroll key to adjust
the brightness.
Press the left or right scroll key to zoom
in or zoom out.
Press the volume keys to adjust the vol-
ume.
/Press to switch between the loud-
speaker mode and the earpiece mode.
Calls
12
Calls
The recently dialed calls, received calls and missed
calls are saved automatically.
Select Calls in the main menu and then press the
left/right scroll key to select All calls ,Missed ,
Received or Dialed . Then select Options for
the following options.
Send message: To send a message or MMS.
Save number: To save the number of the selected
record.
Call: To make a voice call or a video call.
Delete: To delete the selected record.
Mark/Unmark: To mark/unmark a record or all
records.
Advanced: To set the display mode of all records
or view calls status.
13
4Text Input
You can use the keypad to enter alphanumeric char-
acters and symbols. For example, you can add
entries to the contacts, write messages or schedule
events on the calendar.
Note While entering text:
Press to switch between input methods.
Press and hold the key to enable or dis-
able the T9 input mode.
Press to display the symbols list.
Press and hold the key to set the input
language.
Press to delete the letter before the cur-
sor.
T9£ Input Method
With the T9 input method, you can easily and quickly
enter words. T9 is a predictive text entry mode. Press
the relevant key that corresponds to the desired letter
and T9 will offer you candidate words.
Press each key carrying the desired letter once, and
then the predictive text scheme will present the can-
didate words composed by the letters you have
entered in the drop-down menu.
For example, to enter the word "good" with the T9
input method, follow these steps.
1Press successively the keys , , , and
which "g", "o", "o", and "d" belong to, and the
candidate words "good", "home" etc. composed
by these letters will be shown in the drop-down
menu.
2Use the up/down scroll key to select "good".
Note Press repeatedly and you will see "T9 abc",
"T9 Abc" and "T9 ABC" on the upper left corner
of the screen successively. It indicates the
words to be entered will be in lower case, first
letter capitalized or in upper case.
Traditional Input Method
When T9 input method is off, you can use the tradi-
tional input method for entering alphabetic charac-
ters. Repeatedly press the key that carries the letter
to be entered when it appears on the screen.
For example, to enter the word "Hello" with the tradi-
tional input method, follow these steps.
"123" Numeric Input Method
14
1Press that carries "h" repeatedly and all let-
ters carried by this key will be displayed succes-
sively on the screen. You can scroll through this
list and select the character you want. Stop when
you see an "h" on the screen.
2After entering the first letter, you can directly
press another key (except ) to enter the next
letter. If the next desired letter is on the same
key as the current one, wait until the cursor
appears to the right of the current letter and then
you can enter the next one.
3Enter "e", "l", "l" and "o" in the same way.
Note Press repeatedly and you will see "abc",
"Abc" or "ABC" on the upper left corner of the
screen successively. It indicates the words to
be entered will be in lower case, first letter capi-
talized or in upper case.
"123" Numeric Input Method
In a text editing screen, press and hold the character/
number keys to enter corresponding numeric charac-
ters. You can also press successively the key to
switch to the "123" numeric input method, and enter
corresponding numeric characters by pressing the
character/number keys.
Symbol Input Method
You can press to display the symbols list and then
select symbols to input.
You can also press to input the commonly-used
symbols in a text editing screen.
Input Different Languages
In a text editing screen, Press and hold the key to
set the language for the text.
15
5Contacts
Contacts enables you to save and manage such
information as phone numbers and addresses of your
contacts. You can save such information in your
phone or your SIM card.
Making Calls from the Contacts
You can make a voice/video call with a contact
selected from the contacts list.
1In the Contacts screen, press the left/right scroll
key to select Contacts.
2Select a contact and select Options > Call.
Then, you can select Voice Call or Video Call to
make a call.
Searching for a Contact
You can find a contact from the contacts list easily
and quickly by using this function on the Contacts
screen. Select Options >Advanced >Search
contacts, and then enter the contact name you are
searching for. The contact is displayed.
You can also use quick search in the contacts list
screen. You can find a contact by entering the initials
of the first name or the last name of the contact. For
example, to find a contact named "Alice Green",
enter the initials "a" or "g". This contact is displayed in
the candidate list.
Other Operations
In the Contacts screen, select Options for the fol-
lowing options.
View: To view the detailed information of the con-
tact.
Call: To make a voice call or a video call.
Send message: To send a message or Email to the
selected contact.
Send contact: To send a contact to other devices
supporting Message or Bluetooth.
Add new contact: To create a new contact.
Delete: To delete the selected contact.
Mark/Unmark: To mark/unmark a record or all
records in your phone and SIM card.
Advanced: To access the advanced options.
Settings: To set the default contact list displayed in
the contact screen, to sort the contacts on the
Contacts screen.
Groups
16
Memory status: To view the memory status of both
your phone and SIM card.
Groups
Adding/Deleting Group Members
1In the Contacts screen, press the left/right scroll
key to select Groups.
2Select a group and press OK key to view the
details.
3Select Options >Add contact. Select a contact
and press Add. The member you added is dis-
played in the group member list.
To delete a group member, select a member from the
group member list, and then select Options >
Remove.
Managing a Group
In the Contacts screen, press the left/right scroll key
to select Groups. Select a group and select Options
for the following options: details, rename, send mes-
sage and remove all members.
17
6Messaging, Email
Messages
The maximum content for a single text message is
160 characters. If the characters you enter exceed
this limit, the text is divided into two or more continu-
ous messages when it is sent.
Creating a Message
With this option, you can create new SMS, MMS.
1Select Messaging >Create message in the
main menu to access the SMS or MMS editing
screen.
2During editing a message, you can press down
scroll key to add attachment files.
3Press left/right scroll key to switch, then press
OK key to select file from My Files or preview
the message.
4After editing the message, select OK key to add
a recipient’s number.
5Press OK key to send the message.
Messages Mailboxes
The phone provides four mailboxes for messages,
namely, Inbox, Drafts, Outbox, Sent.
ƹInbox
You can save the received messages in Inbox.
Icons in Inbox
Viewing Messages in Inbox
1Select Messaging > Inbox.
Icon Description
a read SMS or a read message report
an unread SMS or an unread message
report
a read MMS
an unread MMS
A read Push message
An unread Push message
Messages
18
2Press the up/down scroll key to view the mes-
sages and then press OK key to view the details.
3You can select Options for the following opera-
tions.
Play: To play the multimedia message.
Reply: To reply the message.
Forward: To forward the message.
Delete: To delete the message.
Call sender: To call the message sender by a
voice call or a video call.
Info.: To view the details of the message.
Save picture: To save the picture of the MMS.
Save as template: To save this message as a
template.
ƹDrafts
The Draft box is used to save the messages you cre-
ated and saved.
Icons in Drafts
: A text message saved to the phone.
: A multimedia message saved to the phone.
: A postcard message saved to the phone.
Viewing and Editing Messages in the Draft
1Select Messaging > Drafts.
2Press the up/down scroll key to select a mes-
sage and press OK key to edit it.
ƹSent
Sent is used to save the messages that have been
sent successfully.
Icons in Sent
: A text message has been sent.
: A multimedia message has been sent.
Viewing Messages in Sent
1Select Messaging > Sent.
2Press the up/down scroll key to select a mes-
sage and press OK key to view the details.
3You may select Options the following opera-
tions.
Forward: To forward the message.
Delete: To delete the message.
Save as template: To save this message as a
template.
Email
19
Messaging, Email
6
ƹOutbox
Outbox is used to save the messages that failed to
be sent.
Icons in Outbox.
: A message that fails to be sent.
Viewing and Editing Messages in the Outbox
1Select Messaging > Outbox.
2Press the up/down scroll key to select a mes-
sage and press OK key to edit it.
Message Settings
You can change the message settings by performing
the following steps.
1Select Messaging > Settings > SMS & MMS
from the main menu.
2Set the parameters related to messages.
Email
Before sending an email, please set an email account
first. For details, please refer to "Email Settings" on
page 21.
Creating an Email
1Select Email >Create Email from the main
menu to access the email editing screen.
2Select To and press OK key. Select Enter recip-
ient or Add from Contacts to select an email
address.
3In the email editing screen, select Subject and
press OK key to edit the contents.
4In the email editing screen, select the Message
text box to edit the content.
5In the email editing screen, select Options >
Add attachment to attach picture, music, video,
eBook, or etc.
6In the email editing screen, select Options >
Send to send the email.
Mailboxes
Your Phone provides five mailboxes for email,
namely, Inbox, Drafts, Sent, Outbox and Blocked.
Email
20
ƹInbox
All Emails received are saved in the Inbox.
Icons in Inbox
: A read email.
: An unread email.
Viewing and Editing Emails in Inbox
1Select an email and press OK key to view the
content.
2In the Details screen, select Options for the fol-
lowing operations:
View: To view the content.
Reply: To reply to the email sender.
Reply all: To reply to the email sender and all
email receivers except the replier.
Forward: To forward the selected email.
Delete: To delete the selected email.
ƹDrafts
The saved new emails are saved in the Drafts.
Icon in Drafts
: Emails to be sent.
Viewing and Editing Emails in Drafts
1Select the desired email in the Drafts and press
OK key to access the editing screen.
2Edit the related information. For details, perform
the same operations as in creating an email.
ƹSent
The emails sent to server are saved in the sent box.
Icon in Sent
: A read email.
Viewing and Editing Emails in Sent
1Select an email and press OK key to view the
details.
2You may select Options to perform the same
operations as those of the Inbox.
ƹOutbox
Those emails which failed to be sent are retained in
the Outbox.
Icon in Outbox
: Emails failed to send.
Broadcast Inbox
21
Messaging, Email
6
Viewing and Editing Emails in Outbox
1Select an email and press OK key to access the
editing screen.
2Edit the related information. For details, perform
the same operations as in creating an email.
ƹBlocked
The blocked emails are saved in this folder. You can
select Email>Email Wizard to set the blocking con-
ditions.
Email Settings
1Select Email>Email Wizard and select an
account.
2The related account information contains: Gen-
eral,Incoming,Outgoing and Online help.
3Return to the Account screen. Select Options >
Set as default to activate this account.
After completing all settings, press Back.
Note For the account settings, contact your local
Vodafone customer care centre.
Broadcast Inbox
The broadcast messages are saved in the broadcast
inbox. You can select Messaging > Settings >
Broadcast to set the broadcast message.
Templates
You can save the frequently-used SMS or MMS as
template for your convenience.
22
7Music
Music enables you to manage your music files easily
and conveniently.
Vodafone music
In the Vodafone music, you can find a great variety of
music to download onto your mobile phone.
Recently Played
Select this option, you can play the recently played
music file.
Music Library
You can play various music files, including those sup-
plied with the phone, recorded by using the phone,
downloaded from the Internet, and attached to email.
In music library, you can add the music files in the
handset or memory card to the playlists.
Screen Operations During Playing
During playing the music file, you can perform the fol-
lowing operations on the music file.
Operation Description
Press the up scroll key to access the
playlist.
Press the down scroll key to go back to
the beginning of the current music file.
Press the right scroll key to access the
next music file. Press and hold the right
scroll key to fast forward the current
music file.
Press the left scroll key to access the
last music file. Press and hold the left
scroll key to fast backward the current
music file.
/Press OK key to pause the playing.
Press OK key again to resume the play-
ing.
Press the volume keys to adjust the vol-
ume.
23
8Organiser & Tools
This function provides you with various helpful tools.
You can select Organiser & Tools from the main
menu.
Alarms
Setting Alarm Clocks
Enter alarm function, you can select one alarm from
the list, and then press OK key to set an alarm clock.
Alarm Prompt
When it is time for an alarm clock to ring, the selected
alarm tone is played and a prompt is displayed. You
can stop the ringing and snooze by pressing any key
(except left function key and power key), or by closing
or opening your phone.
If your phone is powered off, the alarm clock will still
ring. When the alarm rings, you can choose to power
on the phone.
Stopping the Alarm Clock
Select an alarm clock from the list, and press the left
function key or power key to deactivate it.
Calendar
Enter calendar function, you can select Options >
New to create the schedule events for the current
day. The schedule prompt is the same with alarm
prompt. In the calendar view screen, you can select
Options > View to view the events.
Task
The tasks are classified into three kinds: pending,
done, and all tasks. You can define up to 1000 tasks
on your phone.
To define a new task, press OK key or select
Options > New on the Tasks screen. The task
prompt is the same with alarm prompt.
Memo
You can store important events on your phone. You
can save up to 100 such memos.
On the Memo screen, you can perform the following
operations: edit, new, delete, send by Message or
Bluetooth, view the memory status and delete all.
Synchronise
24
Synchronise
You can synchronise contacts with your personal
phone book in the Vodafone network. Before use the
synchronise function, you may need to set a profile.
1To create a profile, select Options > New to cre-
ate a profile.
2Press the scroll key to switch between Synchro-
nise Items,Server Setting, and Network Pro-
file.
3In the Synchronise Items screen, select the
item to be synchronised and press OK key to
confirm it. Then, enter the Database name,
User name, and Password of the synchronisa-
tion items.
4In the Server Setting screen, enter Server
Address,User name,Password.
5In the Network profile screen, enter the proxy
server address and the port. Then, enter the net-
work access point and select a desired profile.
6Return to the previous menu and select Options
>Synchronise to start synchronising.
Note This service is not available in all networks. For
details, contact your local Vodafone customer
care centre.
Calculator
You can perform addition, subtraction, multiplication,
division and extraction operations on your phone.
Press the scroll key to enter the operators.
Press the left function key to clear.
Press the right function key to exit Calculator.
Press to enter a radix point.
Press to delete the character to the left.
Press to perform extraction.
Press OK key to enter an equal mark.
Unit Converter
You can convert units of length and weight between
different systems on your phone. Press the up/down
scroll key to switch between the setup items and
press the left/right scroll key to select weight or
Currency Converter
25
Organiser & Tools
8
length. Select CE to clear the numeric values you
entered.
Currency Converter
You can convert a value from one currency to another
using your phone. Press the up/down scroll key to
switch between the setup items. Press to clear
the numeric values you entered.
Voice Recorder
You can record voices or sounds on your phone.
Record/Pause: During recording, press OK key to
pause, and press OK key again to resume.
Stop and save: During recording, press the left
function key to stop recording. The audio file is
saved in My Files\Music automatically.
Play an audio file instantly: After recording is com-
plete, select Option > Play to play the audio file.
World Time
You can view the time of important cities around the
world. To switch among the time zones, press the left/
right scroll key.
Stopwatch
You can use the stop watch function. On the
Stopwatch screen, you can perform the following
operations: start, save, pause, continue, reset.
Timer
You can set a timer for up to 99 hours and 59 min-
utes. After you have set it, the timer is displayed on
the home screen.
Service Dial Number
You can contact your local Vodafone customer care
centre by dialing this number.
26
9My Files
You can select My Files from the main menu. My
Files enables you to manage the Pictures, Ring-
tones, Music, Videos, Themes, and Others files con-
veniently.
Select Pictures, Ringtones, Music or Videos
folder. You can perform the following operations on
files.
View: To view the picture file.
Send: To send the selected file by MMS, email or
Bluetooth.
Set as: To set a picture as thumbnail of a contact or
the wallpaper.
Rename: To rename the selected file.
Delete: To delete the selected file.
Sort: To sort the selected file by name, by date or
by size.
Mark/Unmark: To select one or more files or cancel
the selection.
Advanced: To access the advanced options.
Play: To play a selected file.
Play via Bluetooth: To play a selected sound file
with the Bluetooth headset.
Set as ringtone: To set a ringtone as voice call
tone, video call tone, specific contact tone message
tone or Email tone.
Note Some sound files are protected by Digital
Rights Management (DRM), and may not be
able to be used as a ringtone.
Select Others, Themes folder.
Others: you can save other kind of file in this folder.
Themes: All themes that you download are saved
in this folder.
Memory status: To view the memory status of your
phone.
When the phone detects and recognises the memory
card, Memory card is displayed as a tab on the top
of the My Files screen.
27
10Web, Applications, Mobile TV
Web
The built-in browser makes it easy to browse the
Vodafone live! portal. You can access the Vodafone
live! by selecting Web from the main menu.
Applications
Select Applications from the main menu. You can
run applications, download more applications and
access the web function.
Vodafone live!
ƹOpen homepage
Select Open homepage to browse the homepage.
When browsing, you can press the scroll keys to
select a link you want to access. The selected link is
highlighted. Press OK key to access the link.
ƹOpen new page
Access the Open new page screen, and then you
can enter the address of the page to be accessed.
ƹBookmarks
With this option, you can save and edit the informa-
tion of the websites that you often access.
Some bookmarks have been preset by Vodafone for
you on the phone.
ƹSettings
These are preset for you to use the Vodafone ser-
vice.
Download applications
Downloaded applications are saved to the Applica-
tions directory.
You may select Options to do the same operations
as those of Games on page 28.
Mobile TV
Select Mobile TV from the main menu. You can
access the preset link. The link has been preset by
Vodafone for you on the phone.
28
11Entertainment
Games
In the main menu, select Entertainment >Games.
Vodafone offers a great choice of games for your
mobile phone. To download one of these to the
phone or memory card, select Download Games.
CameraVideo Camera
In the main menu, select Entertainment >Camera
to start the camera. You can also press the camera
key to start the camera.
In the camera viewfinder screen, press the right scroll
key to switch to the video camera function.
Operations in the Viewfinder Screen
In the viewfinder screen, you can:
In the viewfinder screen, select Options to display
the tool bar or select Back to close the tool bar. This
tool bar is used to set the parameters of the camera
or the video camera.
Operations After Taking a Picture
In the viewfinder screen, you can press OK key to
take a picture. Pictures taken are auto saved to the
My Files/Pictures directory.
After taking a picture, you can select left function
key for the following operations.
Send: To send the picture through MMS, postcard,
email or Bluetooth.
Go to gallery: To open Pictures folder in My files.
Set as: To set the picture as the wallpaper or the
image of a contact.
Delete: To delete the picture.
Icon Operation
Press the up/down scroll key to adjust
the brightness.
Press the volume keys to adjust the
focus.
/When the camera is started, press the
right scroll key to switch to the video
camera function (when the tool bar is
closed).
Icon Operation
Camera/Video Camera
29
Entertainment
11
Edit: To edit the picture.
Operations During Recording
In the video camera viewfinder screen, you can press
OK key to start recording the video.
During the recording, you can perform the following
operations.
Pause/Continue: To pause and then to start record-
ing again.
Cancel: To cancel the recording.
30
12Connections
Your phone provides you with many data communi-
cation functions. You can access the Connectivity
screen by selecting Settings from the main menu.
Note You phone supports plug and play function.
The PC assistant installation programme and
USB driver are embedded in the mobile
phone.
The Vodafone PC Options software supplied
on your phone will run automatically after you
connect your phone to the PC by using the
USB cable.
USB
You can synchronise data between your phone and
PC, surf the Internet with your phone and read the
memory card by USB cable.
!
䄺ਞ
!
Warning
To help prevent damage to your phone and
PC when using the USB Cable please follow
these guidelines. To connect your phone with
a PC through USB cable, first connect the
USB connector to your phone, and then con-
nect the other end of the cable to the PC. To
disconnect your phone from the PC, first dis-
able the Vodafone PC Assistant, then discon-
nect the USB connector from the PC, and
finally disconnect the USB cable from your
phone.
If the PC cannot recognise your phone when
connecting through the USB cable, power off
and restart the PC and then retry.
Please do not plug the USB cable in and out
of your phone frequently.
Synchronising your phone with PC
Assistant
Your phone supports the synchronisation requests
from a PC to your phone. With a USB cable and PC
Assistant, your phone can communicate with a PC.
To operate the USB-based synchronisation with your
phone, do as follows.
1Select Settings > Connectivity > Modem from
the main menu of your phone and set the port to
Modem via USB
2Connect the data cable to your Vodafone 830i
device.
USB
31
Connections
12
3Connect the other end of the data cable to your
PC. The USB driver is embedded in your phone.
4If the Found new hardware wizard is shown,
select Cancel: this may happen more than once.
5If asked to restart the PC, select NO.
6The Vodafone PC Options software supplied on
your phone will run automatically. Wait for the
Dialog box to appear (this may take up to 30 sec-
onds). Buttons showing PC Assistant and
Vodafone Mobile Connect via the phone
should be displayed *.
7Select the PC assistant button.
8Follow the guide to complete the PC assistant
installation for the first time.
9When this has finished, wait for modem driver to
appear in the modem list on your PC (this can be
found by clicking on start, then control panel,
then phone and modem options, then modems.
"Vodafone Mobile Adapter - 3G Modem" should
appear). It may take up to 60 seconds for this to
appear.
10 You may be asked to restart the PC. This time,
select Yes.
11 After restarting the PC, run the PC Assistant
software on your PC. Now you can operate the
USB based synchronisation.
For details of the operation, refer to the Help of
the PC Assistant.
Synchronising your phone with Win-
dows Media Player
Your phone supports the synchronisation requests
between Windows Media Player 11 and your phone.
With a USB cable and MTP Transfer, your phone can
communicate with a Windows Media Player 11.
You need to install the Windows Media Player 11
before using this function. Then, do as follows.
1Connect your phone to the PC by using the USB
cable.
USB
32
2The Vodafone PC Options software supplied on
your phone will run automatically. And then
select Music transfer on PC.
3Select Yes on your phone to switch to the MTP
mode.
4Start the Windows Media Player 11, and you can
synchronize files and playlists between the PC
and mobile phone.
During the process of transmitting files, the fol-
lowing operations are not allowed.
Load or remove the micro-SD card.
Pull out the USB cable.
Select Exit to quit MTP on the phone.
Note Windows XP SP2 and Windows Vista are sup-
ported.
Accessing the Internet by USB
Connecting your phone to the PC with the USB cable
enables the PC to use the phone as a modem. This
helps to set up a dial-up connection to the Internet.
There are two methods to access the internet by
using the USB cable: use the Vodafone PC Assistant
supplied with your Vodafone 830i to load and run the
Vodafone Mobile Connect via the phone internet con-
nectivity software, or use the Windows operating sys-
tem to set the service.
Only Windows 2000, Windows XP and Windows
Vista are supported.
How to connect to the Internet via "Vodafone
Mobile Connect via the phone":
1Select Settings > Connectivity > Modem from
the main menu of your phone and set the port to
Modem via USB.
2Connect the data cable to your Vodafone 830i
device.
3Connect the other end of the data cable to your
PC.
4Wait for the Dialog box to appear (this may take
up to 30 seconds). Buttons showing PC Assis-
tant and Vodafone Mobile Connect via the
phone should be displayed *.
USB
33
Connections
12
5Select Vodafone Mobile Connect via the
phone button.
6Follow the prompts.
7When this has finished, wait for modem driver to
appear in the modem list on your PC (this can be
found by clicking on start, then control panel,
then phone and modem options, then modems.
"Vodafone Mobile Adapter - 3G Modem" should
appear). It may take up to 60 seconds for this to
appear.
8You may be asked to restart the PC. This time,
select Yes.
9After restarting the PC, the Vodafone Mobile
Connect via the phone should be ready to use.
Note * If the dialog box does not appear in step 4,
please disconnect the cable from the PC and
then the Vodafone 830i. Then reconnect the
cable to the Vodafone 830i and then the PC.
The dialog box should appear after this activity.
If the dialog box still does not appear, please
disconnect and reconnect the cable as above
using a different USB port on the PC. Once the
dialog box appears, continue from step (5).
micro-SD Card Reader
You can read the files saved in the micro-SD card by
using a USB cable.
To use the micro-SD card reader, do as follows.
1Insert the micro-SD card to your phone.
2Connect your phone to the PC by using the USB
cable.
3Found New Hardware is displayed on your PC,
and an icon for the mobile memory drive
appears.
4The Vodafone PC Options software supplied on
your phone will run automatically. And then
select File Transfer.
You can read the files saved in the micro-SD
card directly.
Note The function of micro-SD card reader and the
other functions using the USB cable are
Bluetooth£
34
incompatible. If you enable the micro-SD card
reader, other functions using the USB
cable are unavailable.
Bluetooth£
You may use the built-in Bluetooth function of your
phone to synchronise data between a PC and your
phone, or use the built-in modem of your phone to
access the Internet with a PC, or exchange data with
other Bluetooth devices. You can also talk by using
the Bluetooth headset or Bluetooth loudspeaker.
Note The Bluetooth function supported by your
Phone meets the requirements of Bluetooth
Specification 1.2. It can work successfully only
if you use it with compatible Bluetooth devices.
For more information, refer to the user manuals
of related devices, or consult the manufacturer
of related devices.
Bluetooth-Based Synchronisation
Your phone can respond to data synchronisation
requests from a PC. To operate the Bluetooth syn-
chronisation with your phone, your PC needs to sup-
port Bluetooth function.
1Install the PC Assistant supplied on your phone.
2Select Settings >Connectivity > Bluetooth >
Switch On/Off > On to enable the Bluetooth
function.
3Run the driver software for Bluetooth on the PC,
and pair the phone. After the PC detects and
recognises the Vodafone 830i serial port service,
activate the Bluetooth serial port service on the
phone.
4Run the PC Assistant on the PC.
5You can now operate the synchronisation. For
details of the operation, refer to the Help of the
PC Assistant.
Bluetooth-Based Data Transfer
You can exchange data between your Bluetooth
phone and other Bluetooth devices. If you want to
exchange data between your phone and another
Bluetooth£
35
Connections
12
device, that device must support Bluetooth and the
Bluetooth function must be enabled.
1Select Switch On/Off > On from the Bluetooth
settings list to enable the Bluetooth device.
2Select Devices from the Bluetooth settings list.
Select Search to search a Bluetooth device.
When a Bluetooth device is found for the first
time, authentication is required.
Now you can exchange data between your phone
and the other Bluetooth device.
Bluetooth-Based Internet Access
Connecting your phone to a PC through Bluetooth
function enables the PC to use the phone as a
modem. This helps to set up a dial-up connection to
the Internet. (This is particularly useful for laptop.)
You can create Bluetooth-based Internet access
through the PC Assistant supplied with your phone,
or the built-in Internet wizard of the Windows operat-
ing system, or the Internet wizard supplied with the
Bluetooth drive suite of the PC.
Note Windows 2000, Windows XP and Windows
Vista are supported.
ƹAccessing the Internet using the Vodafone
Mobile Phone PC Assistant
To access the Internet by Bluetooth using the PC
Assistant, make sure that your PC supports the Blue-
tooth function and your SIM card supports the Inter-
net access service.
1Select Settings > Connectivity >Modem and
set the port to Modem via Bluetooth.
2Select Settings > Connectivity > Bluetooth >
Switch On/Off > On.
3Make sure that Bluetooth modem is in Device
Manager/Modem of your PC. Run the driver
program for Bluetooth on your PC, and then pair
the Vodafone 830i phone. After the PC has
detected the Vodafone dial-up network service,
you can activate this service.
4Install the PC Assistant supplied with your
phone.
Bluetooth£
36
5Run the Vodafone Dialup Internet on the PC to
access the Internet.
ƹOther Bluetooth Operations
You can perform the basic settings for the Bluetooth
functions.
Select Settings > Connectivity > Bluetooth for the
following operations.
Switch On/Off: To set the Bluetooth device to On
or Off. Bluetooth shall be turned off as default.
Turning Bluetooth on shall NOT automatically set
the state as being discoverable.
My devices: To view all detected Bluetooth
devices. Or to search for new Bluetooth devices.
Visibility: To set whether your phone can be found
by other devices when the Bluetooth function is
enabled. Bluetooth shall be set to non-discoverable
as default.
Device name: To rename your phone.
My device information: To view the detailed infor-
mation of your phone.
37
13Settings
You can access the Settings screen by selectingSet-
tings from the main menu.
Phone settings
You can change the settings of the phone.
Date and Time: To set the system date and time
format of the phone. If you have removed the bat-
tery from the mobile phone, you may need set the
time after switching on the mobile phone.
Profiles: To select different profiles for the phone to
suit different environmental situations.
Phone language: To set the phone language. you
can select Auto. This option is used to set the
phone language to be the same as that used in
your SIM card.
Input language: To set the language used to enter
text.
Sound: To change the settings for the current pro-
file. You can also select Phone settings > Profiles
to set the sounds for the phone.
Keypad tone: To set the keypad tone of the phone.
Keypad lock period: You can set the keypad lock
period. If there is no operation on the phone within
a preset period of time, the keypad is locked auto-
matically. You can press left function key and right
function key in turn to unlock the keypad.
Shortcuts: To assign the frequently used functions
to the scroll keys as shortcut keys.
Auto On and OFF: To set your phone to power on
or off automatically.
Note In the standby mode, you can press and hold
to switch the current profile to the silent pro-
file. If the current profile is offline, you cannot
use this function.
Display settings
You can change the settings for the phone display.
Wallpaper: To set the wallpaper layout for the
home screen.
Themes: To set the theme of the phone.
Brightness: To set the brightness of the screen.
Keypad backlight: To turn the keypad backlight on
or off.
Backlight time: To set the backlight delay time for
the screen.
Message settings
38
Intermittently alert: To turn the alert on or off.
Greeting message: To enter a greeting message
that appears on the screen when you power on
your phone.
Goodbye message: To enter a message that
appears on the screen when you power off your
phone.
Message settings
You can change the message settings including SMS
& MMS, Email, Push messages, Broadcast, and
Common phrases. For detailed information, refer to
"Messaging, Email" on page 17.
Call settings
You can change the settings for making calls.
Call forwarding
This option is used to forward incoming calls.
1In the main screen, select Settings >Call set-
tings > Call forwarding.
2Select the forwarding condition from All calls, If
unreachable,If busy, and If unanswered.
3Then select the forwarding type from Voice call,
Fax call,Data and Video call and All services.
4Select Options > Activate/Deactivate to enable
or disable the service. You can also select
Check status to check the status of call forward-
ing service.
Call barring
This option is used to set the call barring mode for the
phone.
Select Call settings > Call barring for the following
options:
ƹCall barring:
1Select the barring condition from All outgoing
calls,Intl. calls,Intl. calls except home,All
incoming calls, and Incoming calls when
abroad.
2Then select the barring type from Voice call,
Fax call,Data and Video call, and All services.
Call settings
39
Settings
13
3Select Options > Activate/Deactivate to enable
or disable the service. You can also select
Check status to check the status of call barring
service.
ƹDisable All
Select one type from Voice call,Fax call,Data and
video call and All services, and then enter the call
barring password. Press OK key to cancel all call bar-
ring services of each type.
ƹCall barring password
This function is used to change the password for call
barring. Select Call barring password from the Call
barring screen. Then you can change the call barring
password.
Note The old call barring password is provided by
your network operator if it is the first time for
you to change the password.
Call waiting
This option is used to enable or disable the call wait-
ing function. You can also view whether the call wait-
ing function is enabled by checking the status.
The call waiting function is network-dependent. For
more information, contact your local Vodafone cus-
tomer care centre.
Save unknown number
This function is used to prompt whether to save the
number after a call ends.
Auto redial
This function is used to auto redial the dialed number
if the dialing failed.
Answer mode
It is used to set the mode for answering an incoming
call. Three options are available: Any key,Send key
and Slide up.
Auto Answer
This option is used to select auto answering for
incoming calls. Four options are available: Immedi-
ate answer,Text message,Recorded voice and
Disable.
Video call
40
Caller ID
This options allows you to select whether to display
your phone number on the phone of the party who
you called. If select Auto, whether your phone num-
ber will be shown on the called phone depends on
the network.
Select line
This option is used to set the call line for your phone.
Two options are available: Line 1 and Line 2.
My number
This function can be used to save your own phone
numbers on the SIM card. You can select Options to
edit or delete the records.
Video call
You can change the settings for the Video Call func-
tion.
Picture mode: To set the picture mode during a
video call.
Image quality: To set the image quality for video.
Switch Camera off: To open or close the video
channel during a video call.
Audio off: To open or close the audio channel dur-
ing a video call.
Auto voice call: To enable the auto voice call
function. The phone auto makes a voice call, when
the other party's phone does not support the video
call service.
Send image: To select a file and send it to the other
party when you hold a video call.
Auto answer: To auto answer an incoming video
call. You can enable or disable this function.
Contact settings
This option is used to set the default contact list
displayed in the contact screen, to sort the contacts
on the Contacts screen.
Connectivity
The data connection function provides several data
communication functions. You can synchronise data
between your phone and a PC through a USB cable
Device management
41
Settings
13
or Bluetooth. Your PC can use the built-in modem of
your phone to access the Internet. For detailed infor-
mation, refer to "Connections" on page30.
Device management
You can synchronise your device settings with net-
work server in the Vodafone network.
Network
You can change the settings for the network. Four
options are available: Mode,Select network,Cell
information, and Operator list.
JavaTM settings
This option is used to set the volume and vibration of
games.
Security
You can change the settings related to the phone
security.
Select Security from Settings to display the follow-
ing security setting items.
Reset settings
This option is used to reset your phone to the factory
settings.
Password lock
This option is used to enable or disable the "Phone
lock" and "PIN lock".
1Select Security >Password lock.
2Select one item from Phone lock and PIN lock.
3Press the up/down scroll key to select On or Off.
Phone lock: Enter the phone password.
PIN lock: If the desired status is the same as
the current status, just press OK key. Con-
versely, you need to select the desired status
and then enter the PIN code.
Change password
You can modify the phone password and PIN code.
License setting
42
1Select Security >Change password.
2Select one item from Phone password, PIN
code, and PIN2 code.
3Enter the old password (The initial phone pass-
word of the Vodafone 830i is 0000).
4Enter a new password.
5Enter the new password again to confirm.
Note To modify the PIN code, you must set the
"PIN locked" to "On" first.
If you enter the wrong PIN or PIN2 three
times, the SIM card is locked. You need the
PUK or PUK2 code to unlock the SIM card. If
you enter the wrong PUK or PUK2 code 10
times in total, the SIM card is locked perma-
nently.
PUK or PUK2 code are delivered with the
SIM card. If you have not received one or
have forgotten it, contact your local Vodafone
customer care centre.
Fixed dialer number
If your SIM card supports the Fixed Dialer Num-
ber(FDN) function, you can set the limit for phone
numbers.
Select Security > Fixed dialer number for the fol-
lowing options.
Deactivated / Activated: To disable or enable the
FDN function, you need to enter the correct PIN2
code.
My Fixed Dial Numbers: To create, edit or delete
the fixed dialer numbers, you need to enter the cor-
rect PIN2 code.
License setting
Select Settings > License setting. Enter the correct
phone password and press OK key to confirm, and
you can select Roaming network and Delete all
licenses.
Digital Rights Management (DRM) can protect the
digital content from piracy and protect the provider’s
interests. The digital content includes JavaTM applica-
tions and multimedia content such as images, audio
Streaming settings
43
Settings
13
and video. If the protected content cannot be
accessed, it indicates that the corresponding license
is overdue or used up.
Streaming settings
You can change the settings for the Streaming.
44
14Warnings and Precautions
RF Exposure
General Statement on RF energy
Your phone contains a transmitter and a receiver.
When it is ON, it receives and transmits RF energy.
When you communicate with your phone, the system
handling your call controls the power level at which
your phone transmits.
Body worn operation
Important safety information regarding radio
frequency radiation (RF) exposure.
To ensure compliance with RF exposure guidelines
the phone must be used with a minimum of 1.5 cm
(0.6 inch) separation from the body.
Failure to observe these instructions could result in
your RF exposure exceeding the relevant guideline
limits.
Limiting exposure to radio frequency
(RF) fields
For individuals concerned about limiting their
exposure to RF fields, the World Health Organisation
(WHO) provides the following advice:
Precautionary measures: Present scientific informa-
tion does not indicate the need for any special pre-
cautions for the use of mobile phones. If individuals
are concerned, they might choose to limit their own or
their children's RF exposure by limiting the length of
calls, or using 'hands-free' devices to keep mobile
phones away from the head and body.
Further information on this subject can be obtained
from the WHO home page http://www.who.int/peh-
emf WHO Fact sheet 193: June 2000.
Regulatory information
The following approvals and notices apply in specific
regions as noted.
EU Declaration of Conformity
RF Exposure
45
14
Warnings and Precautions
according to the Radio Equipment and Telecommuni-
cations Terminal Equipment Directive 1999/5/EC
For the following equipment
Product: WCDMA/GPRS/GSM Mobile Phone With
Bluetooth
Type Designation/Trademark: V830i/VODFONE;
Vodafone 830i/VODAFONE
Manufacturer's Name: Huawei Technologies Co.,Ltd.
Manufacturer's Address: Bantian, Longgang District,
Shenzhen, 518129, Guangdong, P. R. China.
is herewith confirmed to comply with the require-
ments set out in the Council Directive1999/5/EC for
radio equipment and telecommunications terminal
equipment. For the evaluation of the compliance with
this Directive, the following standards were applied:
Safety: EN 60950-1:2001 First Edition+A11:2004
Health: EN 50360:2001; EN 50361:2001;
EMC: EN 301 489-1 V1.6.1; EN 301 489-24 V1.3.1;
EN 301489-7 1.3.1; EN 301489-17 1.2.1;
Radio: EN 301 511 V9.0.2; EN 301 908-1 V2.2.1; EN
301 908-2 V2.2.1; EN 300 328 V1.7.1;
Responsible for making this declaration is the: Manu-
facturer.
RF Exposure
46
FCC Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equip-
ment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the follow-
ing measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is con-
nected.
Consult the dealer or an experienced radio/TV
technician for help.
This device complies with Part 15 of the FCC Rules
and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this
equipment not expressly approved by HUAWEI may
void the FCC authorization to operate this equipment.
Distraction
47
14
Warnings and Precautions
Distraction
Driving
Full attention must be given to driving at all times in
order to reduce the risk of an accident. Using a phone
while driving (even with a hands free kit) causes
distraction and can lead to an accident. You must
comply with local laws and regulations restricting the
use of wireless devices while driving.
Operating machinery
Full attention must be given to operating the
machinery in order to reduce the risk of an accident.
Product Handling
General Statement on handling and
use
You alone are responsible for how you use your
phone and any consequences of its use.
You must always switch off your phone whenever the
use of a phone is prohibited. Use of your phone is
subject to safety measures designed to protect users
and their environment.
Always treat your phone and its accessories with
care and keep it in an clean and dust-free place.
Do not expose your phone or its accessories to
open flames or lit tobacco products.
Do not expose your phone or its accessories to
liquid, moisture or high humidity.
Do not drop, throw or try to bend your phone or its
accessories.
Do not use harsh chemicals, cleaning solvents, or
aerosols to clean the device or its accessories.
Do not paint your phone or its accessories.
Do not attempt to disassemble your phone or its
accessories, only authorised personnel must do so.
Do not expose your phone or its accessories to
extreme temperatures, minimum - 40 and
maximum + 70 degrees Celsius.
Please check local regulations for disposal of
electronic products.
Product Handling
48
Do not carry your phone in your back pocket as it
could break when you sit down.
Small children
Do not leave your phone or its accessories within the
reach of small children or allow them to play with it.
They could hurt themselves or others, or could
accidentally damage the phone.
Your phone contains small parts with sharp edges
that may cause an injury or which could become
detached and create a choking hazard.
Demagnetisation
To avoid the risk of demagnetisation, do not allow
electronic devices or magnetic media close to your
phone for a long time.
Electrostatic discharge (ESD)
Do not touch the SIM card's metal connectors.
Antenna
Do not touch the antenna unnecessarily.
Normal use position
When placing or receiving a phone call, hold your
phone to your ear, with the bottom towards your
mouth or as you would a fixed line phone.
Air bags
Do not place a phone in the area over an air bag or in
the air bag deployment area. Store the phone safely
before driving your vehicle.
Seizures/Blackouts
The phone is capable of producing bright flashing
lights.
Electrical safety
49
14
Warnings and Precautions
Repetitive Motion Injuries
To minimise the risk of RSI, when texting or playing
games with your phone:
Do not grip the phone too tightly.
Press the buttons lightly.
Make use of the special features in the handset
which minimise the number of buttons which have
to be pressed, such as message templates and
predictive text.
Take lots of breaks to stretch and relax.
Emergency calls
The phone, like any wireless phone, operates using
radio signals, which cannot guarantee connection in
all conditions. Therefore, you must never rely solely
on any wireless phone for emergency
communications.
Loud noise
This phone is capable of producing loud noises which
may damage your hearing.
Phone heating
Your phone may become warm during charging and
during normal use.
Electrical safety
Accessories
Use only approved accessories.
Do not connect with incompatible products or
accessories.
Take care not to touch or allow metal objects, such as
coins or key rings, to contact or short-circuit the
battery terminals.
Connection to a Car
Seek professional advice when connecting a phone
interface to the vehicle electrical system.
Faulty and Damaged Products
Do not attempt to disassemble the phone or its
accessories.
Interference
50
Only qualified personnel must service or repair the
phone or its accessories.
If your phone or its accessory has been submerged in
water, punctured, or subjected to a severe fall, do not
use it until you have taken it to be checked at an
authorised service centre.
Interference
General statement on interference
Care must be taken when using the phone in close
proximity to personal medical devices, such as
pacemakers and hearing aids.
Pacemakers
Pacemaker manufactures recommend that a
minimum separation of 15 cm be maintained between
a mobile phone and a pacemaker to avoid potential
interference with the pacemaker. To achieve this use
the phone on the opposite ear to your pacemaker
and do not carry it in a breast pocket.
Hearing Aids
People with hearing aids or other cochlear implants
may experience interfering noises when using
wireless devices or when one is nearby.
The level of interference will depend on the type of
hearing device and the distance from the interference
source, increasing the separation between them may
reduce the interference. You may also consult your
hearing aid manufacturer to discuss alternatives.
Medical devices
Please consult your doctor and the device
manufacturer to determine if operation of your phone
may interfere with the operation of your medical
device.
Hospitals
Switch off your wireless device when requested to do
so in hospitals, clinics or health care facilities. These
requests are designed to prevent possible
interference with sensitive medical equipment.
Explosive environments
51
14
Warnings and Precautions
Aircraft
Switch off your wireless device whenever you are
instructed to do so by airport or airline staff.
Consult the airline staff about the use of wireless
devices on board the aircraft, if your device offers a
'flight mode' this must be enabled prior to boarding an
aircraft.
Interference in cars
Please note that because of possible interference to
electronic equipment, some vehicle manufacturers
forbid the use of mobile phones in their vehicles
unless a handsfree kit with an external antenna is
included in the installation.
Explosive environments
Petrol stations and explosive
atmospheres
In locations with potentially explosive atmospheres,
obey all posted signs to turn off wireless devices such
as your phone or other radio equipment.
Areas with potentially explosive atmospheres include
fuelling areas, below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air
contains chemicals or particles, such as grain, dust,
or metal powders.
Blasting Caps and Areas
Turn off your mobile phone or wireless device when
in a blasting area or in areas posted turn off 'two-way
radios' or 'electronic devices' to avoid interfering with
blasting operations.
Environmental Protection
Please observe the local regulations regarding the
disposal of your packaging materials, exhausted bat-
tery and old phone and please promote their recy-
cling. Do not dispose of an exhausted battery or old
phone in municipal waste.
: This symbol indicates that the equipment carry-
ing this mark must NOT be thrown into general waste
but should be collected separately and properly recy-
cled under local regulations.
52
15Acronyms and Abbreviations
DRM Digital Rights Management
FDN Fixed Dial Number
GPRS General Packet Radio Service
GSM Global System for Mobile communica-
tion
OTA Over-The-Air
PIN Personal Identification Number
PLMN Public Land Mobile Network
PUK PIN Unblocking Key
SD Secure Digital Card
SAR Specific Absorption Rate
STK SIM Tool Kit
URL Universal Resource Locator
USB Universal Serial Bus
WAP Wireless Application Protocol
WCDMA Wideband Code Division Multiple
Access
53
16Appendix
The Vodafone 830 supports image files, video files
and audio files of many formats. For details, see the
following table.
File type Formats
Image JPG, PNG, BMP, GIF, BCI, WBMP, SVG,
and SVGZ.
Audio MP3, AAC/AAC+, AMR, MID, WAV
(ADPCM), MMF, QCP, and XMF/DLS.
Video 3GP,MP4, 3G2, and PMD.

Navigation menu
