User Manual
Quick Start Guide
VKY-L09
VKY-L29
1
Your device at a glance
Thank you for choosing a HUAWEI P10 PLUS smartphone.
•
To power on your device, press and hold the power button
until your device vibrates and the screen turns on.
•
To power off your device, press and hold the power button,
and then touch .
To force your device to restart, press and hold the power
button until your device vibrates.
• Do not remove your device's pre-fitted screen protector,
which guards against scratches and abrasion.
Dual-lens camera
Secondary
microphone
Dual-tone
flash
Laser sensor
Headset jack
Infrared sensor
Earpiece
Optical proximity
sensor
Ambient light
sensor
Front camera
Status indicator
Card slot
fingerprint
scanner
USB-C port
Volume
button
Power
button
Speaker
Primary microphone
2
Inserting and removing cards
Follow the instructions in the following figures to set up your
device.
• Do not insert or remove the card tray when your device is
powered on.
• Ensure that the card is correctly aligned and that the card
tray is level when you insert it into your device.
Be careful not to scratch your device or hurt yourself when
using the SIM eject pin. Store the SIM eject pin out of the
reach of children to prevent accidental swallowing or
injury.
Caution
Do not use cut or modified micro-SIM or microSD cards
with your device as these may not be recognized and could
damage the card tray.
NJDSP4%
VKY-L09
NJDSP4%
0S
VKY-L29
3
Dual card dual standby single pass
This description should only be used in conjunction with
the VKY-L29.
Your phone supports only dual card dual standby single pass,
which means you cannot use both SIM cards for calls or data
services simultaneously.
•
When you are on a call using SIM card 1, SIM card 2 cannot
be used to make or answer calls. If someone calls SIM card
2, the caller will hear a voice message similar to "The
subscriber you dialed is out of the service area" or "The
subscriber you dialed cannot be connected for the
moment, please try again later." The actual message will
vary by service provider.
•
When you are using SIM card 1's data service, SIM card 2's
data service will be disabled.
Your phone's single pass feature helps reduce power
consumption and increase your phone's standby time. It is not
related to your service provider's network conditions.
It may be a good idea to contact your service provider and
subscribe to missed call reminder and related assistance services
to avoid the conflicts mentioned above.
4
For more information
If you encounter any problems while using your phone, you can
obtain help from the following resources:
Log on to the official Huawei website. You can:
•
Visit http://consumer.huawei.com/cn/ to download user
guides, view frequently asked questions, and use emulators
to test out Huawei products.
•
Visit http://consumer.huawei.com/en/support/hotline for
the most up-to-date contact information for your country
or region.
Go to
Settings
and touch
About phone
>
Legal
information
to view legal information for your product.
Go to
Settings
and touch
About phone
>
Legal
information
>
Safety information
to view safety information
for your product.
Go to
Settings
and touch
About phone
>
Regulatory
information
to view regulatory information for your product.
Go to
Settings
and touch
About phone
>
Certification
logos
to view more information on certification logos for your
product.
All pictures and illustrations in this guide, including but not
limited to the phone color, size, and display content, are for
your reference only. The actual product may vary. Nothing
in this guide constitutes a warranty of any kind, express or
implied.
5
Safety Information
Please read all of the safety information carefully before using
your device to ensure its safe and proper operation and to learn
how to dispose of your device properly.
Operation and safety
•
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
•
Using an unapproved or incompatible power adapter,
charger, or battery may damage your device, shorten its
lifespan, or cause a fire, explosion, or other hazards.
•
Ideal operating temperatures are 0 °C to 35 °C. Ideal
storage temperatures are -20 °C to +45 °C.
•
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If using a pacemaker, hold the device on the
side opposite the pacemaker and do not carry the device in
your front pocket.
•
Keep the device and the battery away from excessive heat
and direct sunlight. Do not place them on or in heating
devices, such as microwave ovens, stoves, or radiators.
•
Observe local laws and regulations while using the device.
To reduce the risk of accidents, do not use your wireless
device while driving.
•
While flying in an aircraft or immediately before boarding,
only use your device according to instructions provided.
Use of a wireless device in an aircraft may disrupt wireless
networks, present a hazard to aircraft operation, or be
illegal.
6
•
To prevent damage to your device's parts or internal
circuits, do not use it in dusty, smoky, damp, or dirty
environments or near magnetic fields.
•
When charging the device, make sure the power adapter is
plugged into a socket near the devices and is easily
accessible.
•
Unplug the charger from electrical outlets and the device
when not in use.
•
Do not use, store or transport the device where flammables
or explosives are stored (in a gas station, oil depot, or
chemical plant, for example). Using your device in these
environments increases the risk of explosion or fire.
•
Dispose of this device, the battery, and accessories
according to local regulations. They should not be disposed
of in normal household waste. Improper battery use may
lead to fire, explosion, or other hazards.
Disposal and recycling information
The crossed-out wheeled-bin symbol on your product, battery,
literature or packaging reminds you that all electronic products
and batteries must be taken to separate waste collection points
at the end of their working lives; they must not be disposed of
in the normal waste stream with household garbage. It is the
responsibility of the user to dispose of the equipment using a
designated collection point or service for separate recycling of
waste electrical and electronic equipment (WEEE) and batteries
according to local laws.
Proper collection and recycling of your equipment helps ensure
electrical and electronic equipment (EEE) waste is recycled in a
manner that conserves valuable materials and protects human
7
health and the environment, improper handling, accidental
breakage, damage, and/or improper recycling at the end of its
life may be harmful for health and environment. For more
information about where and how to drop off your EEE waste,
please contact your local authorities, retailer or household
waste disposal service or visit the website http://
consumer.huawei.com/en/.
Reduction of hazardous substances
This device and any electrical accessories are compliant with
local applicable rules on the restriction of the use of certain
hazardous substances in electrical and electronic equipment,
such as EU REACH, RoHS and Batteries (where included)
regulations, etc. For declarations of conformity about REACH
and RoHS, please visit our web site
http://consumer.huawei.com/certification.
EU regulatory conformance
Body worn operation
The device complies with RF specifications when used near your
ear or at a distance of 0.50 cm from your body. Ensure that the
device accessories, such as a device case and device holster, are
not composed of metal components. Keep the device away
from your body to meet the distance requirement.
The highest SAR value reported for this device type when tested
at the ear is 0.89 W/kg, and when properly worn on the body is
0.76 W/kg.
Statement
Hereby, Huawei Technologies Co., Ltd. declares that this device
is in compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU.
The most recent and valid version of the DoC (Declaration of
Confirmation) can be viewed at
http://consumer.huawei.com/certification.
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is used.
This device may be restricted for use, depending on the local
network.
8
Restrictions in the 2.4 GHz band:
Norway
: This subsection does not apply for the geographical
area within a radius of 20 km from the centre of Ny-Ålesund.
Restrictions in the 5 GHz band:
According to Article 10 (10) of Directive 2014/53/EU, the
packaging shows that this radio equipment will be subject to
some restrictions when placed on the market in Belgium (BE),
Bulgaria (BG), the Czech Republic (CZ), Denmark (DK), Germany
(DE), Estonia (EE), Ireland (IE), Greece (EL), Spain (ES), France
(FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV), Lithuania
(LT), Luxembourg (LU), Hungary (HU), Malta (MT), Netherlands
(NL), Austria (AT), Poland (PL), Portugal (PT), Romania (RO),
Slovenia (SI), Slovakia (SK), Finland (FI), Sweden (SE), the United
Kingdom (UK), Turkey (TR), Norway (NO), Switzerland (CH),
Iceland (IS), and Liechtenstein (LI).
The WLAN function for this device is restricted to indoor use
only when operating in the 5150 to 5350 MHz frequency range.
Frequency Bands and Power
(a) Frequency bands in which the radio equipment operates:
Some bands may not be available in all countries or all areas.
Please contact the local carrier for more details.
(b) Maximum radio-frequency power transmitted in the
frequency bands in which the radio equipment operates: The
maximum power for all bands is less than the highest limit value
specified in the related Harmonized Standard.
The frequency bands and transmitting power (radiated and/or
conducted) nominal limits applicable to this radio equipment are
as follows: GSM 900: 37 dBm, GSM 1800: 34 dBm, WCDMA
900/2100: 25.7 dBm, LTE Band 1/3/7/8/20/28/38/40: 25.7 dBm,
Wi-Fi 2.4G: 20 dBm, Bluetooth: 20 dBm,Wi-Fi 5G: 5150-5350
MHz: 23 dBm, 5470-5725 MHz: 30dBm, NFC: 60 dBuA/m at
10m.
Accessories and Software Information
It is recommended that the following accessories should be
used:
Adapters: HW-050450X00
,
(X represents the different plug
types used, which can be either C, U, J, E, B, A, I, R, Z or K,
depending on your region)
9
Batteries: HB386589ECW
Earphones: 1311-3291, MEMD1632B580C00, EMC309-001,
NA12
The product software version is VKY-L09: D189-
L09C432B083\VKY-L29: D189-L29C432B083
.
. Software
updates will be released by the manufacturer to fix bugs or
enhance functions after the product has been released. All
software versions released by the manufacturer have been
verified and are still compliant with the related rules.
All RF parameters (for example, frequency range and output
power) are not accessible to the user, and cannot be changed by
the user.
For the most recent information about accessories and
software, please see the DoC (Declaration of Confirmation) at
http://consumer.huawei.com/certification.
FCC Regulatory Compliance
Body worn operation
The device complies with RF specifications when used near your
ear or at a distance of 1.50 cm from your body. Ensure that the
device accessories, such as a device case and device holster, are
not composed of metal components. Keep the device away
from your body to meet the distance requirement.
Certification information (SAR)
This device is also designed to meet the requirements for
exposure to radio waves established by the Federal
Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported to the FCC
for this device type complies with this limit.
The highest SAR value reported to the FCC for this device type
when using at the ear is 1.44 W/kg, and when properly worn on
the body is 0.53 W/kg, and when using the Wi-Fi hotspot
function is 1.03 W/Kg.
FCC statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
10
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Caution:
Any changes or modifications to this device not
expressly approved by Huawei Technologies Co., Ltd. for
compliance could void the user's authority to operate the
equipment.
Industry Canada compliance
Body worn operation
The device complies with RF specifications when used near your
ear or at a distance of 1.50 cm from your body. Ensure that the
device accessories, such as a device case and device holster, are
not composed of metal components. Keep the device away
from your body to meet the distance requirement.
The highest SAR value reported to the IC for this device type
when using at the ear is 1.44 W/kg, and when properly worn on
the body is 0.53 W/kg.
IC Statement
This device complies with CAN ICES-3 (B)/NMB-3(B).
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and
11
(2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Restrictions in the 5 GHz band:
Within the 5.15 to 5.25 GHz band, UNII devices will be restricted
to indoor operations to reduce any potential for harmful
interference to co-channel Mobile Satellite System (MSS)
operations.
Conformité à Industrie Canada
Fonctionnement sur soi
L'appareil respecte les spécifications RF s'il est utilisé près de
votre oreille ou à une distance de 1,50 cm de votre corps.
Assurez-vous que les accessoires de l'appareil, comme un étui
ou un porte-étui, ne contiennent pas de métal. Gardez l'appareil
loin de votre corps afin de satisfaire à l'exigence relative à la
distance.
La valeur maximale de DAS signalée à IC pour ce type d'appareil
lors de l'utilisation à l'oreille est de 1,44 W/kg. Lorsqu'il est
correctement porté sur le corps, cette valeur est de 0,53 W/kg,
et lorsqu'il est utilisé avec la fonction d'accès sans fil (Wi-Fi),
cette valeur est de 1,03 W/kg.
Déclaration d'Industrie Canada
Cet appareil est conforme à la norme CAN ICES-3 (B)/NMB-3 (B).
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. Son
fonctionnement est soumis aux conditions suivantes : (1)
l'appareil ne doit pas causer d'interférence et (2) l'appareil doit
accepter toute interférence, y compris une interférence pouvant
entraîner un fonctionnement non désiré.
Restrictions dans la bande de 5 GHz
Dans la bande de 5,15 à 5,25 GHz, les appareils UNII seront
restreints aux opérations intérieures pour réduire toute
possibilité d'interférence pouvant nuire aux opérations du
Système satellite mobile dans le même canal (MSS).
12
Legal Notice
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Android™ is a trademark of Google Inc.
LTE is a trademark of ETSI.
The
Bluetooth
®
word mark and logos are registered trademarks
owned by
Bluetooth SIG, Inc.
and any use of such marks by
Huawei Technologies Co., Ltd. is under license.
Wi-Fi
®
, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are
trademarks of Wi-Fi Alliance.
Privacy Policy
To better understand how we protect your personal
information, please see the privacy policy at
http://consumer.huawei.com/privacy-policy.
Copyright © Huawei Technologies Co., Ltd.
2017. All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND
DOES NOT CONSTITUTE ANY KIND OF WARRANTIES.
底边留5mm
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS
Licensing Limited. DTS, the Symbol, & DTS and
the Symbol together are registered
trademarks, and DTS Sound is a trademark of
DTS, Inc. © DTS, Inc. All Rights Reserved.
Note: Remember the Google account your phone
last logged in to.
During an untrusted factory settings restoration or
microSD card–based update, Google's anti-theft
mechanism requires you to enter the Google account
your phone last logged in to on the startup
navigation screen for identity authentication. Your
phone can properly power on only after the identity
authentication passes.
Model: VKY-L09
VKY-L29
31508053_01
Please visit
http://consumer.huawei.com/en/support/hotline for
recent updated hotline and email address in your
country or region.
The N-Mark is a trademark or registered
trademark of NFC Forum, Inc. in the United
States and in other countries.
