Quick Start Guide
Y530
1
Getting to know your phone
Thank you for choosing the HUAWEI smartphone.
First, let's take a look at a few basics:
Press and hold the power button to power on your
phone. After your phone is powered up, you can use the
power button to turn the screen off and on.
Headset jack
Power
Volume
key
Status
indicator
Front
camera
Earpiece
Back
Home
Menu
Charger/Data port
2
Preparing your phone
To insert a SIM card, the battery and a microSD card
please perform the few steps shown in the following
figures.
Remove the battery cover
Insert the microSD card (optional)
1
3
Insert the SIM card
2
3
Your phone is shipped with the battery partially charged.
It is recommended that you fully charge the battery
before using it for the first time.
4
5
Insert the battery
Charge the battery
6
Close the battery cover
a
b
4
Locking and unlocking the screen
When you are not using your phone, press the power
button to turn off the screen.
After being idle for a specified period of time, your phone
automatically locks its screen.
Follow the onscreen instructions and drag to unlock
the screen or open an application.
5
Managing contacts
Touch to open People.
From the contact list, touch > Manage contacts to
import contacts from the SIM card, microSD card, or
another Bluetooth device.
Touch the Groups tab page to group your contacts for
easier management.
Create
contact
6
Making a call
Touch to open the dialer.
You can dial a phone number directly or touch to
choose a contact.
You can also touch a phone number in places like
messages, email and webpages to make a call.
To answer an incoming call, drag to .
**********
7
Sending messages
Touch to open Messaging.
Adding a photo or audio clip to a text message turns it
into a multimedia message.
You can also save attachments from multimedia
messages.
Happy birthday!
Attach file
8
Taking a photo or video
Touch to open Camera.
In photo mode, let your camera focus automatically or
touch the screen to focus the camera. Then touch to
take a photo. In video mode, frame the scene and touch
to record a video.
View photos
and videos
taken
A
Switch betwe
photo and
video modes
9
Listening to music
Touch to open Play Music.
You can copy songs to your phone and immerse yourself
with extraordinary audio experience anytime.
You can play songs by name, artist, album and more.
Progress
bar
Playlist
screen
Music player
controls
Back
10
Surfing the web
Touch to open Browser.
You can start surfing the web right away using your
phone's browser and stay on ball with up-to-date news
and information.
Your browser supports multi-page browsing. Touch
to switch between pages.
consumer.huawei.com/en
12
Safety information
This section contains important information about the operation
of your device. It also contains information about how to use the
device safely. Read this information carefully before using your
device.
Electronic device
Do not use your device if using the device is prohibited.
Do not use the device if doing so causes danger or
interference with other electronic devices.
Interference with medical equipment
• Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device where
prohibited.
• Some wireless devices may affect the performance of
hearing aids or pacemakers. Consult your service
provider for more information.
• Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and
a pacemaker to prevent potential interference with the
pacemaker. If using a pacemaker, hold the device on the
side opposite the pacemaker and do not carry the device
in your front pocket.
Protecting your hearing when using a headset
• To prevent possible hearing damage, do not
listen at high volume levels for long periods.
• Using a headset at high volumes may damage your
hearing. To reduce this risk, lower the headset volume
to a safe and comfortable level.
• Exposure to high volumes while driving may cause
distraction and increase your risk of an accident.
13
Areas with flammables and explosives
• Do not use the device where flammables or explosives
are stored (in a gas station, oil depot, or chemical plant,
for example). Using your device in these environments
increases the risk of explosion or fire. In addition, follow
the instructions indicated in text or symbols.
• Do not store or transport the device in containers with
flammable liquids, gases, or explosives.
Traffic security
• Observe local laws and regulations while using the
device. To reduce the risk of accidents, do not use your
wireless device while driving.
• Concentrate on driving. Your first responsibility is to
drive safely.
• Do not hold the device while driving. Use hands-free
accessories.
• When you must make or answer a call, pull off the road
safely and park the vehicle first.
• RF signals may affect the electronic systems of motor
vehicles. For more information, consult the vehicle
manufacturer.
• Do not place the device over the air bag or in the air bag
deployment area in a motor vehicle. Doing so may hurt
you because of the strong force when the air bag
inflates.
• Do not use your device while flying in an aircraft or
immediately before boarding. Using wireless devices in
an aircraft may disrupt wireless networks, present a
hazard to aircraft operation, or be illegal.
Operating environment
• Avoid dusty, damp, or dirty environments. Avoid
magnetic fields. Using the device in these environments
may result in circuit malfunctions.
• Do not use your device during thunderstorms to protect
your device against any danger caused by lightning.
14
• Ideal operating temperatures are 0 °C to 35 °C. Ideal
storage temperatures are -20 °C to 70 °C. Extreme heat
or cold may damage your device or accessories.
• Do not expose your device to direct sunlight (such as on
a car dashboard) for prolonged periods.
• To protect your device or accessories from fire or
electrical shock hazards, avoid rain and moisture.
• Keep the device away from sources of heat and fire,
such as a heater, microwave oven, stove, water heater,
radiator, or candle.
• Do not place sharp metal objects, such as pins, near the
earpiece or speaker. The earpiece may attract these
objects and result in injury.
• Stop using your device or applications for a while if the
device is overheated. If skin is exposed to an overheated
device for an extended period, low temperature burn
symptoms, such as red spots and darker pigmentation,
may occur.
• Do not use your device's camera flash directly in the
eyes of people or pets. Otherwise temporary loss of
vision or damage to the eyes may occur.
• Do not touch the device's antenna. Otherwise,
communication quality may be reduced.
• Do not allow children or pets to bite or suck the device
or accessories. Doing so may result in damage or
explosion.
• Observe local laws and regulations, and respect the
privacy and legal rights of others.
Child's safety
• Comply with all precautions with regard to child's
safety. Letting children play with the device or its
accessories may be dangerous. The device includes
detachable parts that may present a choking hazard.
Keep away from children.
• The device and its accessories are not intended for use
by children. Children should only use the device with
adult supervision.
15
Accessories
• Using an unapproved or incompatible power adapter,
charger or battery may cause fire, explosion or other
hazards.
• Choose only accessories approved for use with this
model by the device manufacturer. The use of any other
types of accessories may void the warranty, may violate
local regulations and laws, and may be dangerous.
Please contact your retailer for information about the
availability of approved accessories in your area.
• Use only the following listed AC Adapters/Power
Supplies: HUAWEI: HW-050055E1W,
HW-050055B1W,HW-050055U1W,HW-050055A1W.
Charger safety
• For pluggable devices, the socket-outlet shall be
installed near the devices and shall be easily accessible.
• Unplug the charger from electrical outlets and the
device when not in use.
• Do not drop or cause an impact to the charger.
• If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using it at
once. Continued use may lead to electric shocks, short
circuits, or fire.
• Do not touch the power cord with wet hands or pull the
power cord to disconnect the charger.
• Do not touch the device or the charger with wet hands.
Doing so may lead to short circuits, malfunctions, or
electric shocks.
• If your charger has been exposed to water, other
liquids, or excessive moisture, take it to an authorized
service center for inspection.
• Ensure that the charger meets the requirements of
Clause 2.5 in IEC60950-1/EN60950-1/UL60950-1 and
has been tested and approved according to national or
local standards.
16
• Connect the device only to products with the USB-IF
logo or with USB-IF compliance program completion.
Battery safety
• Do not connect battery poles with conductors, such as
keys, jewelry, or other metal materials. Doing so may
short-circuit the battery and cause injuries or burns.
• Keep the battery away from excessive heat and direct
sunlight. Do not place it on or in heating devices, such as
microwave ovens, stoves, or radiators. Batteries may
explode if overheated.
• Do not attempt to modify or remanufacture the battery,
insert foreign objects into it, or immerse or expose it to
water or other liquids. Doing so may lead to fire,
explosion, or other hazards.
• If the battery leaks, ensure that the electrolyte does not
make direct contact with your skins or eyes. If the
electrolyte touches your skins or splashes into your eyes,
immediately flush with clean water and consult a
doctor.
• In case of battery deformation, color change, or
overheating while charging or storing, immediately stop
using the device and remove the battery. Continued use
may lead to battery leakage, fire, or explosion.
• Do not put batteries in fire as they may explode.
Damaged batteries may also explode.
• Dispose of used batteries in accordance with local
regulations. Improper battery use may lead to fire,
explosion, or other hazards.
• Do not allow children or pets to bite or suck the battery.
Doing so may result in damage or explosion.
• Do not smash or pierce the battery, or expose it to high
external pressure. Doing so may lead to a short circuit or
overheating.
• Do not drop the device or battery. If the device or
battery is dropped, especially on a hard surface, it may
be damaged.
17
• If the device standby time shortens significantly, replace
the battery.
Cleaning and maintenance
• Keep the device and accessories dry. Do not attempt to
dry it with an external heat source, such as a microwave
oven or hair dryer.
• Do not expose your device or accessories to extreme
heat or cold. These environments may interfere with
proper function and may lead to fire or explosion.
• Avoid collision, which may lead to device malfunctions,
overheating, fire, or explosion.
• Before you clean or maintain the device, stop using it,
stop all applications, and disconnect all cables
connected to it.
• Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean
the device or accessories. These substances may cause
damage to parts or present a fire hazard. Use a clean,
soft, and dry cloth to clean the device and accessories.
• Do not place magnetic stripe cards, such as credit cards
and phone cards, near the device for extended periods
of time. Otherwise the magnetic stripe cards may be
damaged.
• Do not dismantle or remanufacture the device and its
accessories. This voids the warranty and releases the
manufacturer from liability for damage. In case of
damage, contact an authorized service center for
assistance or repair.
• If the device screen is broken in a collision, immediately
stop using the device. Do not touch or attempt to
remove the broken parts. Promptly contact an
authorized service center.
Emergency calls
The availability of emergency calls is subject to your
cellular network quality, service provider policy, and local
18
laws and regulations. Never rely solely on your device for
critical communications like medical emergencies.
Environmental protection
• The device and its accessories (if included), such as the
power adapter, headset, and battery should not be
disposed of with household garbage.
• Disposal of the device and its accessories is subject to
local regulations. Support proper collection and
recycling.
Disposal and recycling information
This symbol (with or without a solid bar) on the
device, batteries (if included), and/or the packaging,
indicates that the device and its electrical accessories (for
example, a headset, adapter, or cable) and batteries
should not be disposed of as household garbage. These
items should not be disposed of as unsorted municipal
waste and should be taken to a certified collection point
for recycling or proper disposal.
For more detailed information about device or battery
recycling, contact your local city office, household waste
disposal service, or retail store.
Disposal of the device and batteries (if included) is subject
to WEEE Directive Recast (Directive 2012/19/EU) and
Battery Directive (Directive 2006/66/EC). The purpose of
separating WEEE and batteries from other waste is to
minimize the potential environmental impacts and human
health risk of any hazardous substances that may be
present.
19
Reduction of hazardous substances
This device is compliant with the REACH Regulation
[Regulation (EC) No 1907/2006] and RoHS Directive
Recast (Directive 2011/65/EU). Batteries (if included) are
compliant with the Battery Directive (Directive 2006/66/
EC). For up-to-date information about REACH and RoHS
compliance, please visit the web site
www.huaweidevice.com/certification.
EU regulatory conformance
Body worn operation
The device complies with RF specifications when used
near your ear or at a distance of 1.5 cm from your body.
Ensure that the device accessories, such as a device case
and device holster, are not composed of metal
components. Keep the device away from your body to
meet the distance requirement.
Certification information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver.
As recommended by international guidelines, the device
is designed not to exceed the limits for exposure to radio
waves. These guidelines were developed by the
International Commission on Non-Ionizing Radiation
Protection (ICNIRP), an independent scientific
organization, and include safety measures designed to
ensure the safety of all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of
measurement for the amount of radio frequency energy
absorbed by the body when using a device. The SAR
value is determined at the highest certified power level in
laboratory conditions, but the actual SAR level during
20
operation can be well below the value. This is because
the device is designed to use the minimum power
required to reach the network.
The SAR limit adopted by Europe is 2.0 W/kg averaged
over 10 grams of tissue, and the highest SAR value for
this device complies with this limit.
The highest SAR value reported for this device type when
tested at the ear is 0.649 W/kg, and when properly worn
on the body is 0.604 W/kg.
Statement
Hereby, Huawei Technologies Co., Ltd. declares that this
device is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the web site
www.huaweidevice.com/certification.
The following marking is included in the product:
This device may be operated in all member states of the
EU.
Observe national and local regulations where the device is
used.
This device may be restricted for use, depending on the
local network.
Restrictions in the 2.4 GHz band:
Norway: This subsection does not apply for the
geographical area within a radius of 20 km from the
centre of Ny-Ålesund.
21
FCC Regulatory Compliance
Body worn operation
The device complies with RF specifications when used near
your ear or at a distance of 1.5 cm from your body. Ensure
that the device accessories, such as a device case and
device holster, are not composed of metal components.
Keep the device away from your body to meet the
distance requirement
.
Certification information (SAR)
This device is also designed to meet the requirements for
exposure to radio waves established by the Federal
Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged
over one gram of tissue. The highest SAR value reported
to the FCC for this device type complies with this limit.
The highest SAR value reported to the FCC for this device
type when using at the ear is 0.447 W/kg, and when
properly worn on the body is 0.927 W/kg, and when using
the Wi-Fi hotspot function is 0.927 W/Kg
.
FCC statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
22
to try to correct the interference by one or more of the
following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and
receiver.
--Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV
technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Caution: Any changes or modifications to this device not
expressly approved by Huawei Technologies Co., Ltd. for
compliance could void the user's authority to operate the
equipment.
23
Personal Information and Data
Security
The use of some functions or third-party applications on
your device could result in your personal information and
data being lost or becoming accessible to others. Several
measures are recommended to help you protect personal
and confidential information.
• Place your device in a safe area to prevent it from
unauthorized use.
• Set your device screen to lock and create a password or
unlock pattern to open it.
• Periodically back up personal information kept on your
SIM/UIM card, memory card, or stored in your device
memory. If you change to a different device, be sure to
move or delete any personal information on your old
device.
• If you are worried about viruses when you receive
messages or emails from a stranger, you can delete
them without opening them.
• If you use your device to browse the Internet, avoid
websites that might pose a security risk to avoid theft of
your personal information.
• If you use services such as Wi-Fi tether or Bluetooth, set
passwords for these services to prevent unauthorized
access. When these services are not in use, turn them
off.
• Install or upgrade device security software and regularly
scan for viruses.
• Be sure to obtain third-party applications from a
legitimate source. Downloaded third-party applications
should be scanned for viruses.
• Install security software or patches released by Huawei
or third-party application providers.
• Some applications require and transmit location
information. As a result, a third-party may be able to
share your location information.
24
• Your device may provide detection and diagnostic
information to third-party application providers. Third
party vendors use this information to improve their
products and services.
• If you have concerns about the security of your personal
information and data, please contact
mobile@huawei.com.
25
Legal Notice
Copyright © Huawei Technologies Co., Ltd.
2013. All rights reserved.
No part of this manual may be reproduced or transmitted
in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd. and its affiliates
("Huawei").
The product described in this manual may include
copyrighted software of Huawei and possible licensors.
Customers shall not in any manner reproduce, distribute,
modify, decompile, disassemble, decrypt, extract, reverse
engineer, lease, assign, or sublicense the said software,
unless such restrictions are prohibited by applicable laws
or such actions are approved by respective copyright
holders.
Trademarks and Permissions
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Android™ is a trademark of Google Inc.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Huawei Technologies Co., Ltd. is under
license.
Other trademarks, product, service and company names
mentioned may be the property of their respective
owners.
Notice
Some features of the product and its accessories
described herein rely on the software installed, capacities
26
and settings of local network, and therefore may not be
activated or may be limited by local network operators or
network service providers.
Thus, the descriptions herein may not exactly match the
product or its accessories which you purchase.
Huawei reserves the right to change or modify any
information or specifications contained in this manual
without prior notice and without any liability.
Third-Party Software Statement
Huawei does not own the intellectual property of the
third-party software and applications that are delivered
with this product. Therefore, Huawei will not provide any
warranty of any kind for third party software and
applications. Neither will Huawei provide support to
customers who use third-party software and applications,
nor be responsible or liable for the functions or
performance of third-party software and applications.
Third-party software and applications services may be
interrupted or terminated at any time, and Huawei does
not guarantee the availability of any content or service.
Third-party service providers provide content and services
through network or transmission tools outside of the
control of Huawei. To the greatest extent permitted by
applicable law, it is explicitly stated that Huawei shall not
compensate or be liable for services provided by third-
party service providers, or the interruption or termination
of third-party contents or services.
Huawei shall not be responsible for the legality, quality, or
any other aspects of any software installed on this
product, or for any uploaded or downloaded third-party
works in any form, including but not limited to texts,
images, videos, or software etc. Customers shall bear the
risk for any and all effects, including incompatibility
27
between the software and this product, which result from
installing software or uploading or downloading the
third-party works.
This product is based on the open-source Android™
platform. Huawei has made necessary changes to the
platform. Therefore, this product may not support all the
functions that are supported by the standard Android
platform or may be incompatible with third-party
software. Huawei does not provide any warranty or
representation in connect with any such compatibility and
expressly excludes all liability in connection with such
matters.
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE,
DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS
REGARDLESS OF WHETHER SUCH LOSSES ARE
FORSEEABLE OR NOT.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT
APPLY TO LIABILITY FOR PERSONAL INJURY TO THE
EXTENT APPLICABLE LAW PROHIBITS SUCH A
LIMITATION) OF HUAWEI ARISING FROM THE USE OF
THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE
28
LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR THE
PURCHASE OF THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or
import laws and regulations and be responsible to obtain
all necessary governmental permits and licenses in order
to export, re-export or import the product mentioned in
this manual including the software and technical data
therein.
Privacy Policy
To better understand how we protect your personal
information, please see the privacy policy at
http://consumer.huawei.com/privacy-policy.
Model: HUAWEI Y530-U00
Please visit
www.huaweidevice.com/worldwide/support/hotline
for recently updated hotline and email address in your
country or region.
