HUAWEI P7-L10 Smart Phone

V100R001

Product Description

Issue

04

Date

2014-05-06

HUAWEI TECHNOLOGIES CO., LTD.

Issue 04 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies

Co., Ltd

i

Copyright © Huawei Technologies Co., Ltd. 2014. All rights reserved.

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees or

representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Change History

Version

SE

Change Description

Date

01

Lilandi

00215524

04

Lilandi

Delete typical and minimum values of battery capability.

HUAWEI XXXX Smart Phone

Product Description

Contents

Issue 04 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies

Co., Ltd

ii

Contents

1 Product Overview ......................................................................................................................... 1

1.1 Introduction ...................................................................................................................................................... 1

1.2 Appearance ....................................................................................................................................................... 1

2 Technical Specifications .............................................................................................................. 2

2.1 Hardware .......................................................................................................................................................... 2

2.2 Software ........................................................................................................................................................... 4

3 Packing List .................................................................................................................................... 7

HUAWEI XXXX Smart Phone

Product Description

1 Product Overview

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

1

1 Product Overview

1.1 Introduction

The HUAWEI Sophia-L10 is a HUAWEI developed mid-range to high-end smart phone,

based on HUAWEI Emotion 2.3 (support Android 4.4).

- HUAWEI Emotion UI 2.3, support Android 4.4

- 1.8GHz Quad-Core processor

- 5.0-inch in-cell display

- 2500mAh battery

- 16GB ROM + 2GB RAM

- Support for Near Field Communication (NFC)

- Support for Long Term Evolution (LTE) networks and Cat4 (downlink: up to 150 Mbit/s,

uplink: up to 50 Mbit/s)

- Portable Wi-Fi hotspot that complies with Wi-Fi 802.11 b/g/n

- 13 megapixel (MP) rear camera + 8 MP front camera, 4th BSI Sensor, Mini ISP

- DTS Sound

- DLNA

- Bluetooth 4.0，support BT 4.0 Bluetooth Low Energy (BLE)

- 10-Level auto face enhancement, video face enhancement

- Panoramic selfie

- Watermark Photo

- Simple UI

- Super power saving mode

HUAWEI XXXX Smart Phone

Product Description

1 Product Overview

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

1

1.2 Appearance

TBD

HUAWEI XXXX Smart Phone

Product Description

2 Technical Specifications

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

2

2 Technical Specifications

2.1 Hardware

Table 2-1 Hardware Specifications

Item

Specifications

Shape

Bar-type

LCD

- Size: 5.0 inches

- Type: 5.0-inch in-cell LCD

- Color: 16.7 M colors

- Resolution: Full High Definition (FHD) 1920×1080, 445 ppi

Color

Black/White

Dimensions

139.8 mm (L) x 68.8 mm (W) x 6.xx mm (T)

Weight

About 124 g (including the battery)

Frequency band

- UMTS Band 1 (UMTS 2100): 1920–1980 MHz (UL), 2110–2170 MHz (DL)

- UMTS Band 2 (UMTS 1900): 1850–1910 MHz (UL), 1930–1990 MHz (DL)

- UMTS Band 5 (UMTS 850): 824–849 MHz (UL), 869–894 MHz (DL)

- UMTS Band 8 (UMTS 900): 880–915 MHz (UL), 925–960 MHz (DL)

- GSM (GSM 850): 824–849 MHz (UL), 869–894 MHz (DL)

- EGSM (GSM 900): 880–915 MHz (UL), 925–960 MHz (DL)

- DCS (GSM 1800): 1710–1785 MHz (UL), 1805–1880 MHz (DL)

- PCS (GSM 1900): 1850–1910 MHz (UL), 1930–1990 MHz (DL)

- LTE FDD Band 1: 1920–1980 MHz (UL), 2110–2170 MHz (DL)

- LTE FDD Band 3: 1710–1785 MHz (UL), 1805–1880 MHz (DL)

- LTE FDD Band 7: 2500–2570 MHz (UL), 2620–2690 MHz (DL)

- LTE FDD Band 8: 880–915 MHz (UL), 925–960 MHz (DL)

- LTE FDD Band 20: 832–862 MHz (UL), 791–821 MHz (DL)

Maximum

transmit power

- GSM850/900: 32.5dBm (Power Class 4)

- GSM1800/1900: 29.5dBm (Power Class 1)

HUAWEI XXXX Smart Phone

Product Description

2 Technical Specifications

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

3

Item

Specifications

- FDL B1/B3/B7/B20/B8: 22dBm (full RB)

- UMTS B1/B2/B5/B8: 23.5dBm

Static sensitivity:

- GSM850/900: -109.5dBm

- GSM1800/1900: -108dBm

- FDL B1/B3/B7/B20/B8: -98.5dBm (10M)

- UMTS B1/B2/B5/B8: -111dBm

Network rate

- EDGE: 118.4 Kbps (UL), 236.8 Kbps (DL)

- GPRS: 40 Kbps (UL), 60 Kbps (DL)

- HSPA+: 5.76Mbit/s (UL), 42 Mbit/s (DL, Supported by UMTS Band 1 only)

- LTE Category 4: 50Mbit/s (UL), 150 Mbit/s (DL)

SIM card

interface

- Standard 6-pin SIM card interface

- Micro SIM card

External interface

Standard micro USB, 3.5 mm headset

External memory

support

microSD card (up to 32GB)

Processor

Kirin 910T, Quad core 1.8GHz CPU

Memory

- ROM: 16GB

- RAM: 2GB

- ROM User Available: about 11GB

Device control

- Illuminated capacitive soft keys with haptic feedback

- Physical Power key

- Physical volume key

GPS

GPS/AGPS/Glonass

Temperature

- Charging temperature: -10°C ~ 45°C

- Operating temperature: 0°C ~ 35°C

- Warehouse temperature: -10°C ~ 55°C

Battery

- Capability: 2500 mAh

NOTE

Standby time and talking time depend on the user operation and

network condition.

NOTE

Declared the condition for Standby mode

1. LTE: RS epre -85dBm/15KHz, DRX 128, BW 10M

2. UMTS: DL Power -80dBm, DRX 7

3. GSM 900: BCCH -82dBm, BS-PA-MFRMS 5

- UMTS network: up to 422 hours standby time; up to 14 hours talking time

- GSM network: up to 404 hours standby time; up to 22 hours talking time

- LTE network: up to 404 hours standby time

HUAWEI XXXX Smart Phone

Product Description

2 Technical Specifications

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

4

Item

Specifications

- Charging Time: 3.5 hours from supplied charger

Relative humidity

Working: 5%–95%

Camera

- Main camera: 13 MP Auto Focus (AF)

- Secondary camera: 8 MP Fixed Focus (FF)

Bluetooth

Bluetooth 4.0. Supports Bluetooth Low Energy

WiFi

802.11 b/g/n. Supports Wi-Fi hotspot

USB

USB2.0, 480Mbit/s

Power supply

- Input: 100–240V, 50/60Hz, 0.2A

- Output: 5V, 1A

Certification

CE, FCC, REACH/WEEE, ROHS, GCF, BQB, WIFI, DLNA, WHQL, Master,

Visa, IC

Sensor

- Accelerometer

- Proximity sensor

- Ambient light sensor

- Compass

- G-sensor

- Gyroscope

NFC

Support

Status indicator

Support

Flash

Support

2.2 Software

Table 2-2 Software Specifications

Item

Specifications

Operating system

Android™ 4.4

Input method

Android keyboard, HUAWEI IME

Home screen

HUAWEI Emotion UI 2.3

Browser

Android Native Browser

Voice codec

- UMTS: AMR-NB/AMR-WB

- GSM/GPRS: FR/EFR/HR/AMR-NB/AMR-WB

Messaging

- SMS

- MMS

HUAWEI XXXX Smart Phone

Product Description

2 Technical Specifications

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

5

Item

Specifications

Email

POP3/IMAP/Exchange

Multi-media

Codec Format:

- Audio Codec: MP3, MIDI, AMR-NB, AMR-WB, AAC, AAC+, eAAC+,

AAC-LC, FLAC, WMA2-9, RA

- Video Codec: MPEG-4, H.264, H.263, VP8, RV7-10,Xvid, WMV9

- Image Codec: PNG, GIF (Static only), JPEG, BMP

File Format:

- Audio File Format: *.mp3, *.mid, *.amr, *.3gp, *.mp4, *.m4a, *.wav,*.ogg,

*.ra

- Video File Format: *.3gp, *.mp4, *.m4a, *.rm, *.rmvb, *.wmv

- Image File Format: *.png, *.gif (Static only), *.jpeg, *.bmp

Streaming media

Codec Format:

- Audio Codec: AMR-NB, AAC, AAC+, eAAC+

- Video Codec: H.263, H.264, MPEG-4

File Format: *.mp4, *.3gp

Sound effect

- DTS

- Dual Mic to reduce the noise

Sofeware update

- HUAWEI On The Air (HOTA)

- Update using a microSD card

USB function

- Mass storage

- Charging

- OTG

Camera & Video

resolution

Main camera:

13 MP:

- Photo: up to 4160×3120

- Video: up to 30fps 1080p

Secondary camera:

8.0 MP:

- Photo: up to 3264×2448

- Video: up to 30fps 1080p

Photo and video

- Capture file format: *.jpg

- Recording file format: *.mp4

Digital TV

Support

Digital compass

Support digital compass based on Android

Shooting function

Panoramic shooting, 1 Second Snapshot, Real time Effects optimization, Audio

Photo, Watermark Photo, 10-Level auto face enhancement, Video face

enhancement, Panoramic selfie

HUAWEI XXXX Smart Phone

Product Description

2 Technical Specifications

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

6

Item

Specifications

Transmission

function

WiFi Direct, WiFi WPS, HUAWEI Multi-screen, DLNA

Google mobile

suite

Availability of Google applications, services, and features may vary according to

your country or carrier.

- Google Mail

- Google Search & Search by voice

- Hangouts

- Google Maps

- Google Calendar

- Google News & Weather

- YouTube

- Play Store

Feature

applications

Real time Effects optimization, Audio Photo, Watermark Photo, 10-Level auto

face enhancement, Video face enhancement, Panoramic selfie , Simple UI，

Super Power Saving Mode,

HUAWEI XXXX Smart Phone

Product Description

3 Packing List

Issue 05 (2014-01-08)

Huawei Proprietary and Confidential

Copyright © Huawei Technologies Co., Ltd

7

3 Packing List

Table 3-1 Packing List

Number

Item

Quantity

Remark

1

Handset

1

Standard

2

Battery (built-in)

1

Standard

3

Headset

1

Standard

4

Charger

1

Standard

5

USB cable

1

Standard

6

Quick Start Guide

1

Standard

7

Safety Information

1

Standard

8

Eject tool

1

Standard

9

NFC label

1

Standard

10

Warranty card

1

Optional

11

Smart leather cover

1

Optional

12

Smart Band

1

Optional

13

Engine in ear headset

1

Optional

14

BLE tag

1

Optional

15

Power Case

1

Optional

16

PC Case

1

Optional
