HG531 V1 300Mbps Wireless

ADSL2+ Router

Product Description

Issue 203275_01

HUAWEI TECHNOLOGIES CO., LTD.

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

No part of this document may be reproduced or transmitted in any form or by any means without

prior written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other

trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the commercial contract made

between Huawei and the customer. All or partial products, services and features described in this

document may not be within the purchased scope or the usage scope. Unless otherwise agreed by

the contract, all statements, information, and recommendations in this document are provided ”AS

IS“ without warranties, guarantees or representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in

the preparation of this document to ensure accuracy of the contents, but all statements, information,

and recommendations in this document do not constitute the warranty of any kind, express or

implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: mobile@huawei.com

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

Contents

1 Overview............................................................................................................................... 4

1.1 Introduction to the HG531 V1 ............................................................................................................. 4

1.2 Hardware Features ............................................................................................................................... 5

1.3 Network Architecture ........................................................................................................................... 8

2 Functional Features ............................................................................................................. 9

2.1 High-bandwidth ADSL2+ Upstream Link ........................................................................................... 9

2.2 WLAN Function ................................................................................................................................... 9

2.3 WPS Function ...................................................................................................................................... 9

2.4 Routing Function .................................................................................................................................. 9

2.5 IPv6 Function ....................................................................................................................................... 9

2.6 Flexible QoS Policies ......................................................................................................................... 10

2.7 Standardized TR-069 Management .................................................................................................... 10

2.8 Convenient and Secure Configuration and Management ................................................................... 10

3 Technical Specifications .................................................................................................. 11

3.1 Interface Features ............................................................................................................................... 11

3.2 Security Features ................................................................................................................................ 12

3.3 Routing & Bridged Features .............................................................................................................. 12

3.4 QoS Features ...................................................................................................................................... 13

3.5 ATM Features ..................................................................................................................................... 13

3.6 Network Management ........................................................................................................................ 13

3.7 Power Supply Specifications .............................................................................................................. 13

3.8 Physical Specifications ....................................................................................................................... 14

3.9 Environmental Specifications ............................................................................................................ 14

4 Acronyms and Abbreviations ......................................................................................... 15

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

1 Overview

1.1 Introduction to the HG531 V1

Figure 1-1 Appearance of the HG531 V1

HG531 V1 300Mbps Wireless ADSL2+ Router (hereinafter referred to as the HG531

V1) is a type of Asymmetrical Digital Subscriber Line (ADSL) terminal. At the

network side, it provides ADSL2+ for rapid Internet access and high-speed broadband

access.

For users, it provides an 802.11b/g/n interface and four Ethernet interfaces. After

connecting to a PC, STB, notebook computer, or another terminal, users can enjoy

data, voice, and a range of other services.

The HG531 V1 boasts powerful routing and bridging functions and supports

NAT/firewall technology, with flexible network configuration and QoS policies.

Moreover, the unit provides quality guarantees for latency-sensitive voice services and

for video services susceptible to packet loss. Using the HG531 V1, users can enjoy

high-speed and high-quality broadband services at home.

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

As a broadband network terminal, the HG531 V1 is an extension of an operator's

broadband network. HG531 V1 provides powerful remote maintenance and

administration functions. It supports the latest TR-069 terminal management standards

and remote upgrades, thus facilitating large-scale deployment and maintenance.

1.2 Hardware Features

1.2.1 Interfaces and Buttons

Figure 1-2 Interfaces and buttons on the HG531 V1

3 4 5

WLAN/

WPS

Table 1-1 Interfaces and buttons on the HG531 V1

No. Description

1 Reset button, which is used to restore the factory settings of the HG531

V1.

2 On/Off button, which is used to power on or off the HG531 V1.

3 Power interface, which is used to connect the HG531 V1 to the power

adapter.

4 LAN interfaces, which are used to connect the HG531 V1 to the Ethernet

interface on the computer.

5 ADSL interface, which is used to connect HG531 V1 to the MODEM

interface on the splitter or to the telephone jack on the wall.

6 ~ 9  WLAN button, which is used to enable or disable wireless network

function quickly.

 WPS button, which is used to enable the WPS negotiation function.

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

1.2.2 Indicators

Figure 1-3 Indicators on the HG531 V1

Table 1-2 Indicators on the HG531 V1

Indicator Used to…

Power Steady on The HG531 V1 is powered on.

Off The HG531 V1 is powered off or faulty.

ADSL Blinking The HG531 V1 is being activated through ADSL.

Steady on The HG531 V1 is activated through ADSL.

Off The HG531 V1 is powered off.

Internet Steady on  The HG531 V1 is working in routing mode.

 The WAN connection is set up.

 No data is being transmitted.

Blinking  The HG531 V1 is working in routing mode.

 The WAN connection is set up.

 Data is being transmitted.

Off  The HG531 V1 is working in bridging mode.

 The HG531 V1 is working in routing mode, but

the connection to the WAN has not been set up.

 The HG531 V1 is powered off.

WLAN Steady on The WLAN connection is set up, but no data is being

transmitted.

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

Blinking The WLAN connection is set up, and data is being

transmitted.

Off The WLAN function is disabled.

WPS Blinking A wireless client, such as a computer installed with a

wireless network adapter, is connecting to the HG531

V1 using the WPS function. This process lasts for no

longer than 120 seconds.

Off The WPS function is disabled or faulty.

LAN1 ~

LAN4

Steady on The HG531 V1 is connected to a device properly.

Blinking Data is being transmitted between the HG531 V1 and

the device connected.

Off No connection is set up on the port.

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

1.3 Network Architecture

Figure 1-4 shows the location of the HG531 V1 in the network.

Figure 1-4 Networking diagram of the HG531 V1

Copper pair Ethernet USB Wi-Fi

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

2 Functional Features

2.1 High-bandwidth ADSL2+ Upstream Link

With an embedded high-performance ADSL2+ network processor, the HG531 V1 can

bring more abundant service experiences to users.

2.2 WLAN Function

The HG531 V1 provides high-speed, secure, and convenient wireless network access,

and supports 802.11n (2.4 GHz), 802.11b, 802.11g. It can implement the network

access at a high speed by using a powerful built-in antenna. The IEEE 802.11n

supports the MIMO 2*2 technology and the access rate can reach 300Mbit/s.

2.3 WPS Function

The HG531 V1 provides the WPS2.0 function. A wireless connection can be set up

between the computer and the HG531 V1 conveniently and securely.

2.4 Routing Function

The HG531 V1 provides the Routing function. An address can be obtained by

embedded PPP dialer and DHCP of the home gateway.

2.5 IPv6 Function

The HG531 V1 provides the IPv6 function. It supports the IPv4 & IPv6 dual stack

mode and the DS-Lite mode. Other modes can be customized.

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

2.6 Flexible QoS Policies

The HG531 V1 supports multiple methods of traffic classification, and supports the

PQ and WFQ queue scheduling. thus ensuring that the data transmission of various

services using different policies and that end users can enjoy quality video and audio

services.

2.7 Standardized TR-069 Management

The HG531 V1 is completely compatible with the TR-069 standard defined by the

Digital Subscriber Line (DSL) Forum. Providing complete remote management and

diagnostic functions, it can implement the zero configuration solution. In addition, the

HG531 V1 can carry out customized service provisioning conveniently through

automatic upgrade based on the service provisioning process. Hence operation and

maintenance cost can be greatly reduced.

2.8 Convenient and Secure Configuration and

Management

The HG531 V1 supports the TR-069 remote management, provides a Web-based

configuration interface, and ensures secure use of the Web-based configuration utility

through password verification.

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

3 Technical Specifications

3.1 Interface Features

3.1.1 DSL Interface

Multiple DSL Standards

- ADSL2+

Supports G.992.5 (G.dmt.bitplus) Annex A

Supports G.992.5 (G.dmt.bitplus) Annex M

- ADSL2

Supports G.992.3 (G.dmt.bis) Annex A

Supports G.992.3 (G.dmt.bis) Annex L

Supports G.992.3 (G.dmt.bis) Annex M

- ADSL

− Supports G.992.1 (G.dmt)

− Supports G.994.1 (G.hs)

− Supports ANSI T1.413 Issue 2

Other Features

- Supports multiple permanent virtual channels (most 8 PVCs)

- Supports manual configuration of PVC parameters

3.1.2 Ethernet Interface

- Provision of four 10/100 M adaptive Ethernet interfaces

- Supports IEEE 802.3 and IEEE 802.3u standard

- Supports line Auto MDI and MDIX Auto-sensing

3.1.3 WLAN Interface

- Supports 802.11g, 802.11b, 802.11n (2.4 GHz)

- Supports WPS2.0 (PBC mode and PIN mode)

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

- Supports SSID hiding

- Supports multiple SSIDs (4 SSIDs)

- Supports Open System, WPA-PSK and WPA2-PSK security

- Supports 64/128 digits WEP encryption

- Supports TKIP encryption

- Supports AES encryption

- Supports WMM (Wi-Fi Multimedia)

- Supports enable or disable the WLAN function by press WLAN button or config

the Web-based utility

- WLAN Rates:

− 802.11b: Up to 11 Mbit/s

− 802.11g: Up to 54 Mbit/s

− 802.11n (with 2T2R antenna used) : Up to 300.0 Mbit/s

3.2 Security Features

- Supports powerful wireless network security

- Supports IP/MAC address filtering

- Supports port/URL filtering

- Supports ACL

- Supports DMZ

- Supports the PAP (RFC 1334) ,CHAP (RFC 1994) and the default PAP/CHAP

adaptive

- Prevents DoS attacks such as the SYN flooding, ICMP flooding and ARP attack

3.3 Routing & Bridged Features

- Supports NAT, NAPT (RFC1631, RFC2663, RFC2766, RFC3022, RFC3489)

and ALG expansion

- Supports RIP v1 (RFC1058), RIP v2 (RFC1389, RFC1723, RFC2453)

- Supports multiple PVC working mode:

− IPOA (RFC2684 Routed)

− IPOE (RFC2684 Bridged Static IP, RFC2684 Bridged DHCP Client)

− PPPoE (RFC1661, RFC2516)

− PPPoA (RFC1661, RFC2364)

- Supports DHCP server, DHCP client, DHCPv6 Server, DHCPv6 Client and

DHCP relay

- Supports DNS client and DNS relay

- Supports IGMP proxy and IGMP snooping

- Supports IPv6

− Supports IPv4 and IPv6 dual-stack

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

− Supports DS-Lite

3.4 QoS Features

- Support multiple methods of traffic classification based on:

− LAN interface and WLAN SSID

− IP address (source and destination address)

− Ports (source ports and destination ports) at the fourth layer

− Mac address (source and destination address)

− 802.1p

− VLAN and 802.1q

− Differentiated Services Code Point (DSCP)

− Protocol (TCP, UDP, ICMP)

- Support for re-marking the result of traffic classification based on:

− 802.1p

− DSCP

− TOS/IPP

- Support for queuing methods based on priorities (up to four queues):

− Priority queuing (6 PQs)

− Weighted Fair Queuing (4 WFQs)

3.5 ATM Features

- Supports LLC-SNAP and VC-MUX

- Supports OAM F5

- Supports AT M OAM F5 loop

- Supports multiple ATM QoS service levels (CBR, rt-VBR, nrt-VBR, UBR with

PCR, UBR without PCR)

3.6 Network Management

- Supports TR-069 and upgrading through TR-069

- Supports Views system logs

- Supports remote and local web configuration and management

3.7 Power Supply Specifications

- Product power supply: 12 V DC, 0.5 A

- Product power consumption: < 5 W

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

3.8 Physical Specifications

- Dimensions (W × L × H): 31.5 mm  118 mm  100 mm

- Product weight: about 360 g

3.9 Environmental Specifications

- Ambient temperature for operation: 0°C to 40°C (32°F to 104°F)

- Relative humidity for operation: 5% to 95%, non-condensing

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

4 Acronyms and Abbreviations

ADSL Asymmetrical Digital Subscriber Line

ADSL2+ Asymmetrical Digital Subscriber Line 2 plus

AES Advanced Encryption Standard

ATM Asynchronous Transfer Mode

CBR Constant Bit Rate

DHCP Dynamic Host Configuration Protocol

DNS Domain Name System

DoS Denial of Service

DSCP Differentiated Services Code Point

DSL Digital Subscriber Line

HTTP Hyper Text Transport Protocol

IP Internet Protocol

IPTV Internet Protocol Television

LAN Local Area Network

MAC Media Access Control

NAPT Network Address and Port Translation

NAT Network Address Translation

nrt-VBR non-real-time Variable Bit Rate

OSS Operations Support System

PC Personal Computer

PPPoA Point-to-Point Protocol over ATM

PPPoE Point-to-Point Protocol over Ethernet

PQ Priority Queue

HG531 V1 300Mbps Wireless ADSL2+ Router

Product Description

Huawei Proprietary and Confidential

PVC Permanent Virtual Channel

QoS Quality of Service

RIP Routing Information Protocol

rt-VBR real-time Variable Bit Rate

SSID Service Set Identifier

STB set-top box

TKIP Temporal Key Integrity Protocol

ToS Type of Service

WAN Wide Area Network

WEP Wired Equivalent Privacy

WLAN Wireless Local Area Network

WPA Wi-Fi Protected Access

WPS Wi-Fi Protected Setup

WFQ Weighted Fair Queue

Huawei HG531 V1 300Mbps Wireless ADSL2 Router Product Description

HG531 V1 300Mbps Wireless ADSL2+ Router Product Description

Navigation menu

Versions of this User Manual:

Views

Navigation
