Notice

Co., Ltd.

1No part of this manual may be reproduced or

transmitted in any form or by any means without

prior written consent of Huawei Technologies

Co., Ltd.

Trademarks

3 and HUAWEI are trademarks of Huawei

Technologies Co., Ltd. All other trademarks and

trade names mentioned in this manual are the

property of their respective holders.

Notice

5The information in this manual is subject to

change without notice. Every effort has been

made in the preparation of this manual to ensure

accuracy of the contents, but all statements,

information, and recommendations in this

manual do not constitute the warranty of any

kind, expressed or implied.

Huawei Technologies Co., Ltd.

Address:

6Administration Building, Huawei Technologies

Co., Ltd., Bantian, Longgang District, Shenzhen,

P. R. China

Postal Code: 518129

Website: http://www.huawei.com

Table of Contents 1

Introduction 1

Packing List ................................................1

Front View ..................................................1

Rear View...................................................2

Screen Icons ..............................................3

Introduction to Menus.................................3

Installation 4

Installing the Battery...................................4

Installing the SIM Card ...............................4

Installing the Power Adapter ......................5

Installing the Indoor Antenna......................5

Connecting the FWT to a PC .....................5

Mounting the FWT......................................6

Validating....................................................6

Basic Operations 7

Making or Answering Calls.........................7

Operations During a Voice Call ..................7

Text Input ...................................................7

Contacts 9

Making Calls from Contacts .......................9

Searching for a Contact..............................9

Groups........................................................9

Other Operations......................................10

Messages 11

Text Messages.........................................11

Voice Mail Number ...................................13

Common Phrases .................................... 13

Delete All.................................................. 13

Call Log 14

Making Calls from Call Log ...................... 14

Other Operations ..................................... 14

Tools 15

Alarms...................................................... 15

Calendar ..................................................15

Calculator ................................................. 15

World Time............................................... 15

Profiles 16

Selecting a Profile .................................... 16

Editing a Profile........................................ 16

Settings 17

Phone settings .........................................17

Display Settings ....................................... 17

Call Settings............................................. 17

Network.................................................... 18

Security .................................................... 19

Warnings and Precautions 20

1Table of Contents

Introduction

1Introduction

Packing List

Note

• Select either an indoor or an outdoor antenna

according to the local radio signal strength.

• To access the Internet, you need to purchase

the required data suite. For more information,

consult your local sales agent.

Front View

Note

The figures are only for your reference. The

actual color and shape are subject to the deliv-

ered product.

Item Quantity

Main unit, handset, and coiled cord 1

Power adapter 1

Antenna (Optional) 1

Battery (Rechargeable) 1

Certificate of Quality 1

User Guide 1

Item Description

1 Screen Display information.

2 Left soft key Select the option displayed on the

lower left corner of the screen.

3 Scroll keys Access the shortcut screen in standby

mode.

4 Right soft key Select the option displayed on the

lower right corner of the screen.

5 OK key Access the main menu in standy

mode.

6 Shortcut keys Speed dial a phone number.

910

Rear View

7 Call/Redial

key

•Make or answer a call.

•View dialed calls in standby mode.

8 Antenna Receive signals.

9 # key • Press and hold it to switch between

the silent and normal profiles.

•Switch on/off the input mode of T9.

•Mark/unmark a record.

10 Headset key Activate the headset.

11 Handsfree

key

•Make/answer a call without lifting the

handset.

• Cancel the dialing that is in hands-

free mode.

• End the call that is in handsfree

mode.

12 End key • End a call or reject an incoming call.

•Press and hold it to power on or off.

• Return to the standby mode.

13 * key •Press and hold it to lock the

keyboard in standby mode.

• Switch between different input meth-

ods in text input mode.

14 Number keys Enter numbers and characters.

Item Description

No. Item NO. Item

1Wall-mounting brack-

ets 2Headset port

3Main unit spiral cord

jack

4Battery container

5 SIM card slot 6Battery port

7Data port

65 4

Screen Icons

Introduction

Screen Icons Introduction to Menus

Your FWT provides an extensive range of functions.

You can use these functions by navigating the follow-

ing menus: Contacts, Messages, Call log, Tools,

Profiles and Settings.

1In the standby mode, press left soft key or to

display the main menu.

2Press or to move around the menus,

and then press left soft key or to select

items.

3If the menu contains further submenus, repeat

Step 2.

4Use the selected function according to the

prompts on the screen.

5Select Back to return to the previous menu.

6Press to return to the standby mode.

Icon Description Icon Description

Calling No service

Alarm clock is on Hands-free mode

Message received Powered by the

power adapter

Voice message

received

Battery power level

In a 3G network. In a 2G network

Headset mode Keypad lock

Network signal

strength In silent profile.

Line 2 is selected

2Installation

Note

Before installing or removing the battery, indoor

antenna or SIM card, switch off the FWT and

disconnect the FWT from the power adapter. To

prevent lighting from injuring human body,

remove the outdoor antenna too.

Installing the Battery

Note

• When the ambient temperature exceeds the

temparature allowed for charging, the system

will stop charging the battery.

• When the power adapter is in use, the FWT

will automatically charge the battery and stop

it after the battery is fully charged.

• Take the battery out of the FWT if the FWT is

left unused for a long period.

• Make sure that the battery has been charged

for more than 8 hours before it supplies

power for the FWT at the first time. The

charging time depends on the environmental

temperature and the age of the battery.

• For a battery that is not in use for a long time,

you need to activate it, that is, charge and

discharge the battery for two to three times.

Insert the connection cable of the battery into the bat-

tery port, make sure the insert direction is correct,

and then place the battery into the battery container.

Installing the SIM Card

Note

The SIM card is easily to be damaged by scars

on the contact area or overbending, so you

should insert or remove it gently.

Insert the card to the card slot. Put the side with the

bevelled corner of the card backwards and the side

with the contact area of the card downwards. Make

sure the card is completely inserted into the slot.

Installing the Power Adapter

Installation

Installing the Power Adapter

1Make sure that the FWT is switched off.

2Insert one end of the power adapter into the DC

input port, and the other end into the power sup-

ply jack.

In normal condition, use an external power adapter

and a battery. Use the battery only in the case that

the electricity fails and the external power adapter is

unavailable. If the battery level is low, the communi-

cation may be affected. It is recommended that you

charge the battery for 15 minutes before making or

receiving calls.

Installing the Indoor Antenna

1Make sure that the FWT is switched off.

2Align the indoor antenna with the antenna port

on the FWT host in the correct direction, and

then screw the antenna. Make sure the connec-

tion is secure.

Connecting the FWT to a PC

Note

• Switch the FWT off and then disconnect it

from the power adapter before connecting.

• Use the data service suite provided by the

manufacturer.

The FWT can be connected to a PC to provide data

services. You can also maintain and debug the FWT

on the PC. You need to purchase the data service

suite. For details, consult your local agent.

Mounting the FWT

Horizontal Mounting

Place the FWT on a flat surface. Select a cool and

ventilated site for the FWT to dissipate the heat.

Vertical Mounting

1Pull out the handset retaining clip from the slot

and turn it around. Then push it back so that the

handset will not fall down when FWT is placed

vertically.

2According to the distance between the two

hooks (about 7.7cm), hammer two nails into the

wall and leave a 3-mm space at the end of nails.

3Snap the hooks to the nails.

Validating

1Press and hold to power on your FWT.

2The power icon appears normally. The

signal strength icon appears normally.

3If you can make a call, it indicates that the FWT

is installed correctly.

7.7cm

Basic Operations

3Basic Operations

Making or Answering Calls

Making a Voice Call

1Enter or edit a number in one of the following

ways:

• Enter a phone number through the keypad.

• Select a number from Call Log.

• Select a number from Contacts.

2Press to dial.

3Press to end the call.

Answering or Rejecting a Call

•In standby mode, press , , or lift the

handset to answer a call. Press to end the call.

•In handsfree mode, press , or lift the

handset to answer a call. Press to end the call.

•Under headset mode, press , or lift the

handset to answer a call. Press to end a call.

Operations During a Voice Call

During a voice call, you can select Options to per-

form the operations.

Text Input

Note

• Press * key to switch between input methods.

• Press # key to enable or disable T9 method.

• Press 1 key to display the list of symbol.

• Press right soft key to delete the letter in front

of the cursor.

T9 Input Method

Press each key carrying the desired letter once, and

then the predictive text scheme will present the avail-

Text Input

able words composed by the letters you have entered

in the drop-down list.

Traditional Input Method

When T9 input method is off, you can use the tradi-

tional input method. Repeatedly press the key that

carries the letter to be entered when it appears on the

screen.

"123" Numeric Input Method

In a text editing screen, press and hold the character/

number keys to enter corresponding numeric charac-

ters.

You can also press successively the * key to switch to

the "123" numeric input method, and enter corre-

sponding numeric characters by pressing the charac-

ter/number keys.

Symbol Input Method

Your FWT provides an independent symbol input

method.

For example, to enter ":" with the symbol input

method, you can just press the scroll keys to select

":" from the symbol list and then press .

Inputting Different Languages

In a text editing screen, select Options>Input lan-

guage to set the language for the text.

Contacts

4Contacts

Making Calls from Contacts

1In the Contacts screen, select Phone or SIM.

2Select a contact and select Options > Voice

call. Alternatively, you can select Edit before

call to edit the number before making the call.

Searching for a Contact

1In the Contacts screen, select Phone or SIM.

2Select Options > Search.

3Select Options > Search, and then enter the

contact name. The contact will be displayed.

In the Phone or SIM screen, enter a string contained

in the contact name. Then the contacts whose names

contain this string are displayed.

Groups

Adding/Deleting Group Members

1In the Contacts screen, select Groups.

2Select a group and press to view the details.

3Select Options > Add. Select a contact and

press . The member you add will be dis-

played in the group member list.

To delete a group member, select a member from the

group member list, and then select Options >

Delete.

Managing a Group

1In the Contacts screen, select Groups.

2Select a group and select Options for the follow-

ing options.

•Details: view the details of a group

•Rename: change the name of a group

Other Operations

•Create message: send a text message to all

members of a group

•Delete: delete a group and all members of the

group

Note

You cannot rename or delete any group preset

in your FWT.

Other Operations

In the Contacts screen, select Phone or SIM . Then

select Options for the following options.

•Details: view the details of a contact

•Edit before call: edit the number before making a call

•Create message: send a message to the selected con-

tact

•New: create a new contact

•Voice call: make a voice call

•Search: enter the contact name you are searching for

•Copy to SIM/Copy to phone: copy one or more con-

tacts from your FWT to the SIM card or from your SIM

card to the FWT

•Copy Marked To Phone/Copy Marked To SIM: copy

the marked contacts to the FWT or to the SIM card

•Speed Dial Number: assign often-used numbers to

speed dialing keys "2" to "9"

•Delete: delete the selected contact

•Mark/Unmark: mark/unmark a record or all records in

your FWT and SIM card

•Settings: sort the contacts in the FWT and the SIM

card or to set an alert before saving

In Contacts screen, select one of the following

options.

•Phone: view the contacts in the FWT

•SIM: view the contacts in the SIM card

•Groups: view the groups of the contacts

•Copy all: copy all the contacts from your FWT to the

SIM card or from your SIM card to the FWT

•Delete all: delete all the contacts from your FWT or

from your SIM card

•Memory status: view the memory status of both your

FWT and SIM card

Messages

5Messages

Text Messages

The maximum number of English letters in a single

text message is 160. If the characters you entered

exceed this limit, the text is divided into two or more

continuous messages when it is sent.

Creating a Text Message

1Select Messages > Write SMS from the menu .

2In the message editing screen, select Options:

•Send: send the message

•Insert number: insert a phone number saved in

the FWT or the SIM card

•Common phrases: speed up the text entry

•T9 Switch: enable or disable T9 input method

•Input mode: select the input method

•Input language: select an input language

3After editing, press to access Edit num-

bers.

• Enter the phone number, and then press to

send the message.

• Select Options > Groups or Contacts to choose

a number and send the message.

• Select Options > Save to drafts to save the mes-

sage.

SMS Mailboxes

Inbox

You can save the received messages in Inbox.

1Select Messages > Inbox to view the

messages and then press to view the

details.

a read message in the SIM card memory

an unread message in the SIM card memory

a read message in the FWT memory

an unread message in the FWT memory

a message report

Text Messages

2Reply or call back.

•Press to reply with a text message.

• Press to call back by a voice call.

3select Options for the following operations.

•Reply: reply the message

•Forward: forward the message

•Edit before call: edit the number

•Save number: save the numbers retrieved from

an SMS to the FWT or SIM memory or an existing

entry in the contacts

•Delete: delete the message

Drafts

The Draft box is used to store the messages that you

save and that fail to be sent.

Sent

The Sent box is used to store the messages that are

sent.

1Select Messages > Sent to select a message

and to view the details.

2Forward or make a call.

•Press to forward a text message.

•Press to make a voice call.

SMS Settings

1Select Messages > Settings on the menu.

2Set the parameters related to messages:

a text message saved to the FWT.

a text message saved to the SIM card.

a text message that are sent and saved to

the FWT.

a text message that are sent and saved to

the SIM card.

Voice Mail Number

Messages

•Message center: You can set your FWT to

retrieve the message center number from the SIM

card or the FWT. If you delete the information by

accident, contact your service provider.

•Valid period: The time within which a message

can be kept in the message center after it is sent.

•Auto save: You can set that the message is

saved automatically to Sent after it is sent.

•Save to: To set the position for saving messages.

•Status report: You can set it to On or Off. If you

set it to On, the network send you the report on

whether the message reaches the recipient.

•Concatenated SMS: You can set it to On or Off. If

you set it to Off, you cannot edit and send mes-

sages longer than the limit of a single SMS.

Voice Mail Number

You need to apply for the voice mail services from

your network operator. After setting the correct num-

ber provided by your network operator, after press

and hold the 1 key in standby mode, the FWT dials

the voice mail number automatically.

You can select Messages > Settings> Voice Mail

number to set the number.

Common Phrases

Your FWT is preset with some commonly used

phrases for automatical replying and sending mes-

sages when you are answering a call.

You can select Messages > Settings> Common

phrases to edit the phrases.

Delete All

You can select Messages > Delete all to delete the

messages in Inbox, Sent or Drafts.

6Call Log

The last dialed calls, received calls and missed calls

are saved automatically.

Making Calls from Call Log

1Select Call Log and then press the up/down

scroll key to switch between Missed, Recived

and Dialed.

2Select a record. Press to make a voice call.

3Select Options for the following options.

•Edit before call: edit the number before making a

call

•Create Message: send a SMS

•Save number: save the number of the selected

record to the FWT, the SIM card, or an existing

contact

•Voice Call: make a voice call

•Details: view the details of the selected record

•Delete: delete the selected record

•Mark/Unmark: mark/unmark a record or all

records

Other Operations

Calls Status

Select Call Log > Calls status to display the infor-

mation about voice calls, and data services. In the

voice call, and data screen, you can select Reset to

clear all records.

Delete All

Select Call Log > Delete all to delete the records of

All calls, Missed, Received, or Dialed.

Tools

7Tools

Alarms

Setting Alarm Clocks

Select an alarm. Press , and then you can set it.

Prompt Interface for an Alarm

When it is time for an alarm clock to ring, the tone

sounds and a prompt is displayed. Press any key to

stop it, or select snooze or stop the prompt.

If your FWT is powered off, the alarm can still ring.

When it rings, you can choose to power on the FWT.

Stopping the Alarm Clock

Select an alarm clock from the list, and press the left

soft key to deactivate it.

Calendar

Select Tools > Calendar and select Options. You

can perform the Go to... operation to go to a certain

date directly from the month view screen.

Calculator

Select Tools > Calculator on the main menu.

• Press the numeric keys to enter the figures.

• Press the scroll key to enter the operators.

• Press the left soft key to clear.

• Press the right soft key to exit Calculator.

•Press the # key to enter a radix point.

• Press to enter an equal mark.

World Time

Select Tools > World Time on the main menu.

You can view the time of important cities around the

world. To switch among the time zones, press the left/

right scroll key.

If the daylight saving time (DST) is used in your city,

you need to set the FWT to DST. Then, you can get

the right local time. To set the FWT to DST, switch to

the desired time zone and then select Options > Set

Time Zone.

8Profiles

Selecting a Profile

1In the Profiles screen, select a profile.

2Activate the selected profile.

• Press to activate it.

• Select Options and select On to activate it.

Editing a Profile

1In the Profiles screen, select a profile.

2Select Options and select Edit to set it.

•Voice call tone: Select a ring tone for incoming

calls.

•Message tone: Select a message tone.

•Tone volume: Adjust the volume of rings.

•Key tone volume: Adjust the volume of keys.

•Prompt tone volume: Adjust the volume of

prompts.

•On-off tone: Activate or deactivate the power-on

and power-off tones.

Note

• You can select a profile, and then select

Options and select Rename to change the

name of the profile.

• You cannot rename any profile preset in your

FWT.

Settings

9Settings

Note

Please use an external power adapter and a

battery together when you set the FWT.

Phone settings

In the Settings screen, select Phone settings.

•Phone Language: Select a language. You can also

select Auto to set it to be the same as the language

that is used in your SIM card.

•Input Language: Set the language used to enter text.

•Date and Time: Change the system time for the FWT.

•Date Format: Change the display format of the date.

•Shortcuts: Assign the frequently used functions to the

keys as shortcut keys.

•Keypad lock period: After enabling the auto keypad

lock function, you can set the keypad lock period. If

there is no operation on the FWT within a preset period

of time, the keypad is locked automatically. You can

press the * key, then press to unlock the keypad.

Note

If the FWT is not used for a long time with no

adapter or battery, you may need to set the time

after switching the FWT on.

Display Settings

In the Settings screen, select Display Settings.

•Contrast：Set the contrast level of the display.

•Backlight time: Set the delay time of backlight.

•Greeting message: Enter a greeting message that

appears on the screen when you power on your FWT.

Call Settings

Minute Alert

If the function is activated, your FWT notifies you of

the call duration by giving an alert several seconds

before the end of each minute.

Auto Dial

If the function is activated, the number you key in is

dialed automatically at the time you set.

Call Forwarding

When you can not to answer the phone or you want

to forward a call, you can use this function.

Network

Call Barring

You can restrict and allow all outgoing calls by acti-

vating this function.

Call Waiting

When you are in a conversation, you can answer a

third call by activating this function.

The function is network-dependent. For more infor-

mation, consult your service provider.

Calling ID

This function allows you to select whether to display

your number on the phone of the party who calls you.

The function is network-dependent. For more infor-

mation, consult your service provider.

Select Line

It is used to set the call line for your FWT. Two

options are available: Line 1 and Line 2.

My Number

With this function, you can save your own numbers

on the SIM card. You can select Options to edit or

delete the records.

Call Barring Password

This function is used to change the password for call

barring. Select Call barring password from the Call

settings screen. Now you can change the call bar-

ring password.

Note

The old call barring password is provided by

your network operator if it is the first time for

you to change the password.

Network

You can change the settings for the network. Select

Settings > Network for following options: Mode,

Select network.

Security

Settings

Security

You can change settings related to the FWT security.

Select Security from Settings, and select the follow-

ing security setting items:

Reset

This option is used to reset user configurations of the

FWT settings to the factory settings.

Password lock

This option is used to enable or disable Phone lock

and PIN lock.

Change password

1Select Security > Change password.

2Select one item.

3Enter the old password (The initial phone pass-

word is 0000.)

4Enter a new password.

5Enter the new password again to confirm.

Note

• To modify the PIN code, you must set PIN

lock to On first.

• If you enter the wrong PIN or PIN2 for three

times, the SIM card is locked. You need the

PUK or PUK2 code to unlock the SIM card. If

you enter the wrong PUK or PUK2 code for

10 times in total, the SIM card is locked per-

manently.

• The PUK or PUK2 code is delivered with the

SIM card. If you do not receive the code or

forget it, contact your service provider.

10Warnings and Precautions

To use the FWT correctly and safely, read the following cautions and let

your children know these before using the FWT.

Basic Cautions

•According to the packing list, check items in the package box to make

sure that they are complete and undamaged.

•Before installing and using the FWT, read this user guide carefully

Electronic Device

Power off your FWT when it is close to high-precision electronic devices.

The FWT may affect the performance of these devices.

Such devices include hearing aids, pacemakers, fire alarm systems, auto-

matic gates, and other automatic-control devices. If you are using an elec-

tronic medical device, consult the device manufacturer and confirm

whether the radio waves affect the operation of the electronic device.

Hospital

Pay attention to the following points in hospitals or health care facilities:

•Do not take your FWT into the operating room (OR), intensive care unit

(ICU), or coronary care unit (CCU).

• Power off your FWT when it is close to medial devices.

•Observe any instructions wherever the use of wireless device is prohib-

ited.

Traffic Safety

•Do not use your FWT while driving. Secure the FWT on its holder. Do

not place the FWT on the seat or other places where it can get loose in a

sudden stop or collision.

•Observe the rules and regulations of airline companies. Power off your

FWT before boarding an aircraft.

Operating Environment

•Do not place magnetic storage media such as magnetic cards and

floppy disks near the FWT. Radiation from the FWT may erase the infor-

mation stored on them.

• Do not put your FWT, battery, or other accessories in containers with

strong magnetic field, such as the induction cooker and microwave

oven. Otherwise, circuit failure, fire, or explosion may result.

• Do not place or use the FWT, the battery or the power adapter near any

heat sources such as fire or a heater; or places with flammable gases;

or areas with electrical appliances that give out heat. Otherwise, it will

cause fire, explosion and breakdown of the FWT.

• Because the FWT needs to eliminate heat during working, put the FWT

and the power supply in a ventilated and shadowy place. Never airproof

the FWT or put something on it or place it near water, fire as well as

inflammable and explosive materials.

• Because the FWT contains precision devices, you should put it in a dry

place and away from moist materials.

• Before cleaning the FWT, please power off the FWT, and then discon-

nect the power supply and take out the battery. Before moving the FWT,

please disconnect the external power supply.

• Do not subject your FWT, battery, and power adapter to serious collision

or shock. Otherwise, battery leakage, FWT malfunction, overheating,

fire, or explosion may result.

• Do not place sharp metal objects such as pins near the earpiece. The

earpiece may attract these objects and hurt you when you are using the

FWT.

• Do not place the FWT in the area over the air bag or in the air bag

deployment area. Otherwise, the FWT may hurt you owing to the strong

force when the air bag inflates.

• In raining and lightning, disconnect the power adapter from external

power supply and power off the FWT, In this case, if the outdoor antenna

is used, do not touch the FWT and antenna.

• Put your FWT, battery, and power adapter in places beyond the reach of

children. Do not allow children to use the FWT, battery, or power adapter

without guidance.

Warnings and Precautions

• Do not touch the antenna when a call is going on. Touching the antenna

may affect call quality and cause the FWT to operate at a power level

higher than needed.

• The network signal condition will directly affect the quality and stability of

the call. Consequently, you should place the FWT in a place where it can

receive network signal well. Do not put FWT in a building with an iron or

metal roof. The distance between FWT and other metal materials (such

as metal brackets or metal doors and windows) should be greater than

25 cm and the distance between FWTs should be greater than 30 cm.

• Do not open the chassis in any case and the device should be main-

tained by a qualified maintenance department.

• Without permission, you are not allowed to modify the architecture and

security design of FWT. You must bear any consequence resulted from

the operation without permission.

• Your FWT is designed to conform to the authoritative international radio

frequency (RF) specifications. Use FWT accessories approved by Hua-

wei only.

• The antenna(s) used for this transmitter must be installed to provide a

separation distance of at least 20cm from all persons.

•Please observe the national local regulations in the location where prod-

uct is to be used. This product may be restricted for use in some or all

countries of European Union.

Emergency Call

You can use your FWT for emergency calls. However, connections in all

conditions cannot be guaranteed. You should never rely solely on the FWT

for essential communications.

Battery

•If the battery fluid gets into eyes, do not rub them. Wash with clean water

and seek medical assistance immediately.

• If the battery fluid contacts skin or cloth, wash with clean water immedi-

ately to avoid irritation to the skin.

• Do not dispose of the battery in fire. Otherwise, the battery may ignite or

explode.

• When installing the battery on your FWT, do not push the battery by

force lest battery fluid leak out or the battery crack.

• Do not connect two poles of the battery with metallic materials such as

cables.

• Do not disassemble the battery or solder the battery poles. Otherwise,

fluid leakage, overheating, fire, or explosion may result.

• If there is battery leakage, smoke, or strange smell, stop using the bat-

tery and keep it away from open flame to avoid fire or explosion.

• Disconnect the power adapter and take out the battery when the FWT is

not used for a long time.

• Do select its self-contained complete battery and power adapter; other-

wise, the FWT may be spoiled. Huawei Technologies Co., Ltd is not

responsible for any consequences caused by using non-standard batter-

ies or power supplies. Dispose of used batteries according to the

instructions.

•Dispose of the battery according to local laws or regulations.

Power Adapter

•Use AC power as specified for the power adapter. Any violation of this

rule may result in fire or malfunction of the power adapter.

• Do not short-circuit the power adapter. Short-circuiting the power

adapter may cause fire or malfunction of the power adapter.

• Remove the dust on the power plug regularly.

• Do not use worn-out power cords. Otherwise, electric shock, short-

circuiting of the power adapter, or fire may result.

• Do not put the power adapter near the container filled with liquid such as

water. If the liquid comes into the power adapter, electrical leakage or

other faults may result.

• If the liquid such as water comes into the power adapter accidentally,

remove the plug of the power adapter from the socket immediately.

• Disconnect the power adapter from the socket before cleaning or main-

taining it. Otherwise, electric shock or short-circuiting of the battery or

power adapter may result.

• Ensure the plug of the power adapter is properly inserted into the power

socket when charging the battery. Improper insertion may result in elec-

tric shock, fire, or explosion.

•Do not place any heavy object on the power cord of the power adapter.

Do not damage, change, or pluck the power cord.

Using the USB Cable

When using the USB cable, observe the following requirements. Other-

wise, the FWT or PC may fail.

• When the USB cable is used to connect the FWT to a PC, connect the

USB cable with the FWT first.

• When the FWT communicates with a PC, do not disconnect the USB

cable with the FWT, or the PC may fail.

• When disconnecting the USB cable, disconnect it from the PC first.

Environmental Protection

Please abide by the local laws in disposing of the package materials of

your FWT, consumed batteries and used FWT, and try to recycle them.

Regulatory information

The following approvals and notices apply in specific regions as noted.

EU Declaration of Conformity

according to the Radio Equipment and Telecommunications Terminal

Equipment Directive 1999/5/EC

For the following equipment

Product: Fixed Wireless Terminal

Type Designation/Trademark: Neo 3000/VODAFONE

Manufacturer's Name: Huawei Technologies Co.,Ltd.

Manufacturer's Address: Bantian, Longgang District, Shenzhen, 518129,

Guangdong, P. R. China.

is herewith confirmed to comply with the requirements set out in the Coun-

cil Directive1999/5/EC for radio equipment and telecommunications termi-

nal equipment. For the evaluation of the compliance with this Directive, the

following standards were applied:

Safety: EN 60950-1:2006

Health: EN 50383:2002; EN 50385:2002;

EMC: EN 301 489-1 V1.6.1; EN 301 489-24 V1.3.1; EN 301 489-7 1.3.1;

Radio: EN 301 908-1 V3.2.1: 2007; EN 301 908-2 V3.2.1; EN 301 511

V9.0.2;

Responsible for making this declaration is the: Manufacturer.

Version: V100R001_01 Part Number: 31018972

Huawei ETS6630 User Manual EN

Navigation menu

Versions of this User Manual:

Views

Navigation
