Bluetooth® 221 Headset
Important information
Important information on safe and efficient
operation. Read this information before using your
headset.
This product is CE, FCC, BQB marked. Please note
that this product uses radio frequency bands not
available for use within some areas of the EU. This
product is intended to be used in Austria, Belgium,
Denmark, Finland, France, Germany, Greece,
Ireland, Italy, Luxembourg, The Netherlands,
Portugal, Spain, Sweden, United Kingdom and
within EFTA in Iceland, Norway and Switzerland.
Users are not permitted to make changes or modify
the device in any way. Changes or modifications
not expressly approved by the party responsible for
compliance could void the user's authority to
operate the equipment.
Introduction
Bluetooth
® headset is a lightweight wireless device
utilizing
Bluetooth
® wireless technology. The
headset contains a microphone and a receiver. It
provides hands-free communication using mobile
phones, and the power is provided by a Lithium Ion
rechargeable battery.
Any device that you want to use with this
Bluetooth
®
headset must be compatible with
Bluetooth
®
technology version 1.1 or above. The device must
also support the same profiles as the headset.
Package Contents
1. One Bluetooth headset. 2. One adaptor
3. One user guide 4. One neck strap
5. One ear hook
Wearing preference
Left Side Right Side
1. The headset can be worn on both sides. Just
plug the ear hook from the preferred side on
the headset, and put the receiver in the ear.
2. The ear hook is slightly flexible so that you can
adjust it to fit the contour of your ear. The
angle and depth are also adjustable for
wearing comfort.
Bluetooth
® Headset Features
1. Charging port
2. Talk/Volume Down button
3. Talk/Volume Up button
4. LED indication
5. Microphone
6. Ear hook
7. Ear hook socket (Back of the headset)
8. Speaker (Back of the headset)
Preparing to use your
Bluetooth
® headset
1. Charging and battery time
It is our recommendation to charge the headset for
8 hours before first use.
A. Connect the adaptor to an electrical outlet.
B. Open the charging port cover and then plug
the adaptor's connector into the charging
port.
C. While charging, the blue LED light will stay
solid on; after charging is completed, the
LED will flash once every 5 seconds. Then
unplug the adaptor's connector from the
headset and disconnect the adaptor from the
electrical outlet. Close the charging port
cover.
D. Charging time is about 2.5-4 hours.
2. Pairing procedure
Before using your headset for the first time, you
must pair it with a
Bluetooth
® mobile phone or audio
gateway.
A. With your headset turned off, press and hold
the Talk/Volume Up button for 7 seconds
until the blue LED flashes rapidly, indicating
that the headset is in pairing mode
B. Use your phone’s menu to search for
Bluetooth
® audio devices. The phone should
indicate it has found the "HH221" headset.
Select this.
C. When asked for a passkey, enter: “1234”.
Your phone will confirm that pairing has been
successful
D. If pairing does not occur as expected, turn off
both the phone and the headset and wait 10
seconds before repeating steps A - C
Turning your headset ON and OFF
1. To switch your headset ON, press the
Talk/Volume Up button for about 5 seconds
until the blue LED turns solid on. Press
briefly once more to link your headset to
your mobile phone.
2. To switch your headset OFF, press the
Talk/Volume Up button for 3 seconds until
the LED flashes, and then the headset will
turn off.
Answering a call
If there is an incoming call, a ring tone will sound in
your headset; you can press either the Talk/Volume
Up or Talk/ Volume Down button on headset to
answer the call.
If your cell phone supports auto-answering, the
headset will take the incoming call automatically
and you don't need to press any button.
Making a call with the headset by voice dialing
If your Bluetooth phone supports voice dial, you
can use this feature with the headset. Please refer
to your phone's user guide for more information on
voice dial.
①
②
③
④
⑤
⑥
![](/img.php?id=541221&img=bg2.png)
1. Voice dial function on your phone must be
turned on and voice tags must be stored.
2. On the headset, press either the Talk/Volume
Up or Talk/Volume Down button once.
3. A short tone will prompt you and you can
speak the “voice tag” that was stored in the
phone’s voice dial phone book.
4. The phone automatically dials the contact
you’ve selected, and you can see the details
of the call on the phone display.
5. When connected, you can communicate
normally using the headset.
Making a call from the mobile phone keypad
1. Dial the phone number using the keypad on
the mobile phone.
2. To send the call, press the phone's
SEND/CALL key.
3. The call will then be transferred automatically
to the headset when connection is made.
Ending a call from the headset
To end a call, press and hold the Talk/Volume Up
button for 5 seconds. Or you can end the call from
the keypad on the phone. When the other party
hangs up the phone, the call ends automatically.
Rejecting an incoming call
To reject an incoming call, press and hold the
Talk/Volume Up button for 5 seconds on the
headset.
Note: This function only works on
Bluetooth
®
phones that support Hands-free profile.
Call transfer
When in conversation, you may transfer voice from
headset to phone. Press the Talk/Volume Down
button for 5 seconds to make the transfer. For
some mobile phones, you can short press the
Talk/Volume Down button the transfer back to the
headset.
Note: This function only works on
Bluetooth
®
phones that support Hands-free profile
Last number redial
When the headset is in standby condition (not in
conversation), click the Talk/Volume Up button
twice within 1 second, and your phone will redial
the last number that you called.
Note: This function only works on
Bluetooth
®
phones that support Hands-free profile
Receiver volume control
The headset has 7 pre-set volume levels. To
increase the volume, press the Talk/Volume Up
button; to decrease the volume, press the
Talk/Volume Down button.
You may also use phone's volume up/down buttons
to adjust the headset volume.
Battery status and Low battery alert
Battery status:
Each time you turn on the headset, the LED will
show the battery status. If the battery is in normal
condition, blue LED will be solid on for 5 seconds; if
the battery is low, it will flash for 5 seconds.
Low battery warning:
The headset battery needs recharging when you
hear a warning tone from the headset every 20
seconds. Once the low battery warning starts, there
will be a 5-minute talk time left.
Storage of headset
1. Always store the headset safely.
2. Avoid storage at high temperatures (above
600C/1340F) such as in a hot vehicle or in direct
sunlight. (Storage at high temperature can degrade
performance and reduce battery life.)
3. Do not expose the headset or any of its supplied
parts to rain or other liquids.
Bluetooth
® headset specification
Bluetooth
® Ver.1.2 compliant
Distance 30 Feet (10 meters)
Weight 13.15 grams
Typical standby time up to 110 hours
Typical talk time up to 4 hours
Typical re-charge time 2½ - 4 hrs (8 hrs before
first use)
Battery type Li-ion rechargeable
battery
NOTE: Talk time and standby time are varied
according to different mobile phones.
Federal Communications Commission (FCC)
Statement
15.21
You are cautioned that changes or modifications
not expressly approved by the part responsible for
compliance could void the user’s authority to
operate the equipment.
15.105(b)
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that changes or modifications
not expressly approved by the party responsible for
compliance could void your authority to operate the
equipment.
![](/img.php?id=541221&img=bg3.png)
FCC RF Radiation Exposure Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. End users must follow the specific
operating instructions for satisfying RF exposure
compliance. This transmitter must not be
co-located or operating in conjunction with any
other antenna or transmitter.
Notice: Any changes or modification not expressly
approved by the party responsible could void the
user's authority to operate the device.
