Contents
- 1. Users Manual 1 of 2
- 2. Users Manual 2 of 2
Users Manual 2 of 2
36 Using the Quick Menu
36 Settings
38 Audio Options
39 Category Sort
39 Pay Per View
40 Find By
41 Date & Time
41 Favorites
43 Caller ID & Messages
44 Parental Controls
Chapter 3
UsingtheQuickMenu
Press MENU on your remote to easily access DIRECTV features. Once the Quick
Menu is displayed, use the UP and DOWN arrows to highlight a desired menu item,
then press SELECT to access that item. Some menu items will display a submenu,
others will take you directly to a new screen. To remove the Quick Menu at any time,
press MENU again.
Settings
Selecting Settings in the Quick Menu displays a submenu of items that lets you
customize, adjust and keep track of your DIRECTV viewing experience.
Setup
The Setup item in the Quick Menu displays the Setup screen, where you can access
the Info & Test, Satellite Setup, Audio Setup, Display Setup, Access Card and System
Reset screens.
The Quick Menu
Using the Quick Menu
36
Info & Test
TheSystemInfooptionletsyouviewthecurrentsysteminformation.TheSystem
Test option lets you run a test on the tuner, access card, receiver ID and phone line.
Satellite
This option is useful if your DIRECTV DVR [NAME TBD] has lost signal strength,
oryouneedtorealignyoursatellitedish.
Access Card
Follow the onscreen directions to replace your access card. You will need your old
and new access cards to complete this process. (Note: DIRECTV will provide new
access cards and instructions when necessary.)
Reset
From here you can reset the receiver, reset to factory defaults, or reset everything.
Scheduler
This feature gives you an overview of and access to all the programs you’ve set to
Autotune or purchase. You can also set up priorities for conflicts that may occur when
recording episodic programs.
Setting
s
Chapter 3 37
Favorites
CheckthecurrentstatusofyourFavorites list(s) by clicking here, and make changes if
you like. See page 43 for more details.
Parental Controls
Check the current restrictions of your Parental Controls by clicking here, and make
any adjustments. See page 45 for more details.
Audio Options
Some programs have alternate audio available (such as other language tracks or Dolby
Digital). This option only appears in the Quick Menu over Live TV when the current program
has alternate audio. You can set the default so that whenever a program has alternate
audio available, it automatically plays this audio, or you can change the alternate
audio temporarily for the program you are watching. In either case, press MENU
whileinLiveTV,then:
To change the default audio,fromtheQuickMenu,selectSettings, select Setup, then
select Audio in the left menu and follow the onscreen instructions.
The Quick Menu
Audio Options
38
Category Sort
This feature lets you temporarily arrange the Guide to list only programs in a
particularcategorysuchasMovies,SportsorNews.
WhileintheGuide,fromtheQuickMenu,selectCategory Sort.Tofurthernarrow
your search, select the category you want, then select a subcategory if you wish. To
quickly move through the Category Search results, use the RED or GREEN key on
your remote to advance or reverse in 90-minute increments.
PressGUIDEtoreturntotheregularGuide,orEXITtoreturntoliveTV.
Pay Per View
ThisoptionenablesyoutocheckoutDIRECTVPayPerViewlistingsbycategory.
While in the Guide, press MENU, then select Pay Per View. You will see three choices
for sorting the listings. Choose All to display all current pay per view programs.
Movies willgiveyoulistingsofallcurrentmoviesavailable.PickSpecial Events to see
specific events such as sports, comedy specials and more. The Guide will update with
matching programs.
Category So
rt
Chapter 4 39
Find By
Wouldyouliketolocateaparticularprogram,movieorsportseventyouwantto
see—evenshowsstarringafavoriteactor,orgameswithyourfavoriteteam?Find by
offers some easy ways to spot just what you want to watch.
Press MENU, then select Find by.YoucanfindaprogrambyTitle, Person, Keyword
or Channel. Your search will be quicker if you narrow your search by selecting
subcategories; just follow the onscreen instructions. Once you’ve found a program
you’re after, all you have to do is highlight and select the title to display when the
program is on.
Recent Finds
If you’d like to repeat a previous search, select Recent Finds, then select your search to
view matching programs. In Recent Finds,youcanselectMark & Delete in the Quick
Menu to delete any Finds you no longer want.
The Quick Menu
Find By
40
Date & Time
ThisoptiongivesyouaconvenientwaytolookseveraldaysaheadintheGuide,
without having to scroll through pages of programs.
Favorites
Favorites allows you to set up special, customized Guide that shows only those
channels you choose. So you can have easy access to the channels you like best, or
perhaps a grouping of family channels just for the kids.
When you’re using a Favorites list, the Guide will only display those channels you’ve
chosen — and you’ll also only see those channels when you change channels using
CHANUP/DOWNonyourremote.
Keep in mind, no matter what Favorites list you’re currently using, you can still
always access any channel you receive by keying in its channel number on your
remote.Youcanalsoeditordeletealistatanytime.
Date & Tim
e
Chapter 3 41
Channels I Get
In addition to displaying all channels or creating lists of favorite channels, you
can also set your DIRECTV Receiver to display only the channels that are in your
current subscription package.
To see the channels you receive, select ChansIGetfromtheleftmenuoftheFavorites
screen. To set ChansIGetas your current channel list, select the Set Current menu
item from the Favorites screen, then change the Current Favorites option list to Chans
IGet.
Note
Keep in mind, when you search with Find by, only those programs slated to air within the Guide’s
number of days of programming supported by your receiver will appear on your list.
The Quick Menu
Favorites
42
Caller ID & Messages
This feature lets you get messages from DIRECTV. If you have Caller ID service*,
you can also view phone calls you’ve received or turn call notification on or off. Press
MENU to display the Quick Menu, select Caller ID & Msgs, then select Edit Settings.
Select either Caller ID or Messages from the left menu, as desired.
Caller ID
The Call Log tab displays up to 25 recent incoming calls. Highlight and select a name
to delete that listing from your log.
The Notification tab lets you turn the notification feature on or off. When the
Notification option is on, you’ll see a notice on your TV screen whenever a call comes
in.
Note
* You must subscribe to Caller ID service through your local telephone company, and your
DIRECTV Receiver must be connected to a phone line.
Caller ID & Message
s
Chapter 3 43
DIRECTV Messages
This feature lets you view a listing of current DIRECTV messages waiting for you.
Simply highlight and select a message in the list to read, then you’ll have the choice
to keep or delete it. The messages icon will appear brightly on your channel banner
whenever there’s any new or unread message in your Inbox.
Parental Controls
Parental Controls enables parents to place certain restrictions on just who’s watching
what, and require a passcode to view restricted programming. Whether it’s for mature
content or spending amounts, you’re always able to keep limitations where you want
them for the whole family.
Press MENU to display the Quick Menu, SELECT Parental Controls, then Edit
Settings, and you’ll see the current status showing any restrictions. The system default
is “unlocked” for all categories.
The Quick Menu
Parental Controls
44
Ratings
Here you can set rating limits for Movies and TV:
1) SELECT Ratings.
2) MovetotherighttoSELECTtheanothertab.Note:YoucanuseREDor
GREEN to cycle tabs.
Movies
Highlight and select the Movies tab, then set the overall rating limit you wish to
impose Brief descriptions of the ratings appear for your guidance.
TVPrograms
SELECT the TV tab, then highlight and select the TV rating you desire. You can also
set ratings for particular content (for example, Fantasy Violence, Dialogue), each of
which is described when highlighted.
TIP
SELECT
For ratings limits and channel
blocks, as well as most
other checkbox-type items,
pressing SELECT toggles the
item on and off when setting
them up.
Parental Contro
ls
Chapter 3 45
Other Shows
Toblockprogrammingthathasnorating—suchasnewsandsportsandshowswitha
rating of “None” — select the Other tab.
Channel Blocks
You can block viewing of a certain channel or channels from this menu.
SELECT Chan Blocks in the left menu, then scroll down the channel list to SELECT
those you wish to block, or key in channel numbers for quicker access. Use Block All
or Allow All to save time if you wish to affect a large number of channels.
Spending
From the left menu, SELECT Spending, then set your preferred spending limit
for any single pay per view purchase. Simply key in the amount using the numbers on
your remote.
Hours
From the left menu, SELECT Hours, then set your preferred hours during which
TV can be viewed. You can set hours based on “school nights” and weekend nights
—Monday-Thursday,Friday-Saturday,andSunday.
The Quick Menu
Parental Controls
46
Now, lock it
Once you’ve set the restrictions you want, choose Lock Now fromtheleftmenu.
You’ll be directed to create a passcode (which you’ll want to make easy enough to
remember, but hard enough that the little ones won’t guess it!). This passcode will be
your entry to unlocking and adjusting limitations in the future.
An onscreen message will appear whenever anyone tries to tune to a channel or
program that has been restricted, or attempts to spend or watch beyond limitations
set. He or she will not be allowed to proceed without the passcode. Using your
passcode, you can easily override the limits.
Let me in…!
Temporarily or permanently unlocking a restriction is easy. To temporarily unlock a
particular program:
1) When any controls are currently activated, Unlock Now will appear if you try to
tune to a restricted program.
2) Select Unlock Now andenterthepassword.
Formoreunlockoptions:
1) PressMENU,thenSELECTParental Controls.
TIP
Locked UnlockedTemporarily
Unlocked
The Parental Control icon in
the Channel Banner will tell
you if the receiver is locked,
temporarily unlocked, or
unlocked.
Parental Contro
ls
Chapter 3 47
2) Various options for removing restrictions temporarily or permanently will appear.
Select one and enter your password.
Also note: If you have Parental Controls set and temporarily unlocked, turning the
receiver power off will relock the box. If anyone tries to unlock restrictions using an
invalid passcode, there’s a time delay that’s added with each additional attempt to
discourage them.
To change your passcode at any time:
1) Press MENU, SELECT Parental Controls,thenEdit Settings.
2) Scroll down to Passcode and press SELECT.
3) Enter your old password, then enter a new one twice to confirm.
The Quick Menu
Parental Controls
48
50 Troubleshooting
59 Limited 90-Day Warranty
64 Product Information
65 DIRECTV PROTECTION PLAN
68 FCC Customer Information
72 Index
Chapter 4
Troubleshooting
Many problems can be corrected by performing a simple reset of the DIRECTV® Receiver. If you
experience the image freezes, audio freezes or blank screen, or the system won’t respond to front
panel button or remote control, try one of these:
Press the red RESET button behind the access card panel door on the front of the
DIRECTV Receiver, then wait for program guide information to be acquired.
If the problems persist, try unplugging the power cord of the DIRECTV Receiver for 15
seconds, then plug it in again.
Running the System Test (later in this section) can also help you diagnose and solve many
common problems.
System Upgrades
Your DIRECTV Receiver is able to receive upgrades or modifi cations to some of its features and
functions. ese modifi cations will occur automatically, usually at times when the receiver would
likely be turned off . If your receiver is on when an upgrade or modifi cation is sent, you may
experience a disruption in reception for a minute or two. Your reception should return to normal
Note
If preferred, you can have an Authorized Service Representative visit your home for a fee, to set up your digital
satellite receiver and instruct you on its operation. For details about this service, call 1-800-DIRECTV or visit
DIRECTV.com.
Youcanfindadditional
troubleshooting help at
DIRECTV.com.
TIP
Troubleshooting
Other Information
50
after the modifi cation is complete. Your receiver must be plugged in to AC power and have a
working phone connection to receive any upgrades. Do not unplug your receiver while an upgrade
is in progress. Please consult the Upgrade Menu to fi nd a schedule of upgrades or modifi cations
planned by DIRECTV.
DIRECTV Receiver or TV Problems
Progress bar freezes during Satellite Data Acquisition
is is normal. e progress bar times out after two minutes. If your screen is still blank for a few
minutes after the progress bar times out, follow these steps to restart your receiver:
1) Press the red RESET button behind the access panel door on the front of the
DIRECTV Receiver.
2) Wait for program guide information to be acquired.
Wrong picture, blue screen, snow or black/blank picture
e DIRECTV Receiver and most TVs and VCRs let you toggle between video sources. If you don’t
see the signal you think you should be seeing, try using these buttons to toggle between the signals:
Press the TV/VCR button on the VCR remote or on the VCR’s front panel.
Press the TV INPUT button on the DIRECTV remote control.
If problems persist, turn off all equipment that is connected to your TV, wait a few minutes,
then turn the DIRECTV Receiver back on.
51
Chapter 4
Troubleshooting
Problems with Caller ID
You must subscribe to Caller ID service through your local phone company.
Also, check to be sure your Caller ID feature is turned on (see page 46).
If you are plugging your receiver to a wireless phone jack, note that it typically does not transmit Caller ID
information and you may need a special wireless phone jack to use with Caller ID service. See the user’s manual
that came with the wireless phone jack to see if it transmits Caller ID information. If it doesn’t, either connect the
phone line directly to a standard wall-mount phone jack or install a wireless phone jack that transmits Caller ID
information.
DIRECTV Receiver will not turn on
Check to make sure the power cord is plugged into the DIRECTV Receiver and the wall outlet.
Check the wall receptacle (or extension cord) to make sure it is “live” by plugging in
something else.
Make sure the remote control is on DIRECTV mode, and press TV POWER ON.
Press TV POWER ON, then press it a second time.
Check batteries in remote control.
Be sure remote control is pointed at remote sensor, and front of receiver is not blocked.
Unplug the receiver. Wait fi ve minutes. Plug it in again.
Troubleshooting
Other Information
52
Turns off while playing
Electronic protection circuit may have been activated because of a power surge. Wait 30 seconds, then turn on
again.
Unplug DIRECTV Receiver for a few minutes, then plug back in. If this happens frequently, the voltage in your
house may be abnormally high or low.
Consider using a surge protector or line conditioner.
If your TV turns off while playing, and other lights/appliances in your house do too, you may have blown a circuit
breaker or be experiencing a power outage.
Consult an electrician if the problem is frequent or severe, especially if other household appliances or electronics
are aff ected.
DIRECTV Receiver turns on or changes channels unexpectedly
An Autotune may have been activated. See page 32.
Your TV’s timer may have been activated.
Check your TV owner’s manual.
Blank screen
Check that all components connected to the input jacks are turned on.
Try another channel.
Your DIRECTV Receiver may be hooked up incorrectly to the TV. Press the INFO button on the front panel
Chapter 4 53
Troubleshooting
of the DIRECTV Receiver to see if the channel banner appears. If it does not, check the Setup and Connections
section for instructions about connecting your satellite receiver.
If the DIRECTV Receiver is connected to the RF input of your TV, makes sure that the TV channel matches the
3/4 RF switch on the back panel.
Press the TV INPUT key on the remote to make sure your TV input is set to the TV input your DIRECTV
Receiver is connected to.
Press the POWER button on the front of the DIRECTV Receiver.
Press the red RESET button behind the door on the front panel of the
DIRECTV Receiver.
Temporary loss of the satellite signal or Searching for Satellite Signal message
Your satellite system may be experiencing rain fade, a temporary loss of the satellite signal due to unusually heavy
rain clouds or rainfall. Rain fade is usually brief, lasting only as long as the heavy rain cloud condition persists.
Your dish may be blocked. Check that something is not blocking the dish.
Partial programming loss/channels missing from the Guide/channel is in the Guide but can’t tune to
Your satellite dish antenna may be incorrectly confi gured. Check the dish type set in your receiver’s preferences
and change if necessary. Press the MENU key on the remote control, then select Settings, then Setup. In the next
menu, select Satellite, then Repeat Satellite Dish Setup. Follow the steps. From the Satellite Dish Type screen, make
sure the proper dish type is selected (round, oval with a dual LNB or oval with a triple LNB).
Troubleshooting
Other Information
54
e channels might be excluded from the Favorites list currently in use. Press MENU on the remote, select
Favorites, then All Channels, or enter the channel number manually.
My video and audio are out of sync.
Try changing channels.
Press LIST, then EXIT.
If neither of those work, restart your DIRECTV Receiver. Press MENU, press SELECT on Settings, then
SELECT Setup. Select the Reset item from the left menu and follow the onscreen instructions.
My DIRECTV Receiver is “frozen” on a single frame of a TV picture.
If you are on a Pay Per View channel, watching the free portion of a program, the free portion may be completed.
You must buy the program to continue watching.
If that doesn’t work, restart your DIRECTV Receiver. Press MENU, press SELECT on Settings, then SELECT
Setup. Select the Reset item from the left menu and follow the onscreen instructions.
Chapter 4 55
Troubleshooting
Remote Control Problems
Problems with the remote control
Check that nothing is between the remote control and the remote sensor.
Make sure the remote control is in DIRECTV mode. Slide the mode switch to the DIRECTV position so the
remote will control the DIRECTV Receiver.
Check the batteries in the remote control. ey may be weak, dead or installed incorrectly. Try replacing batteries.
If you’re entering a channel number that is less than four digits long, the receiver might wait two seconds before
tuning to the channel. Press ENTER after entering a channel number to tune immediately.
If you are trying to operate a device other than the DIRECTV Receiver that you have programmed the remote
to control, make sure you fi rst slide the input switch to the corresponding device (DVD player, VCR, etc.). e
indicator light for the component you’re trying to control should light up when you press a valid key for that
component. If it doesn’t, make sure the input switch is clicked into the correct position.
A remote control indicator light starts fl ashing. Reset to factory default and reprogram your remote. See page
24.
e batteries in the remote control are running low and should be replaced soon. (Note that when you replace the batteries,
you may have to reprogram your remote to control other devices.)
Note
IfyourTVisconnectedwithjustcoaxialcables,youmusttunetoChannel3or4,assetwiththe3/4switchontheback
of your DIRECTV Receiver box.
Troubleshooting
Other Information
56
Chapter 4 57
Troubleshooting
Fine-Tuning the Signal
If you self-installed your satellite dish antenna, you may have already used Guided Setup to fi nd the dish-pointing
coordinates, acquire and fi ne-tune the signal and run a system test. If you need to run Guided Setup again, select
Settings from the Quick Menu, then select Guided Setup. Next, press SELECT on Satellite, then select Repeat Satellite
S e t u p .
Running the System Test
e System Test allows you to run a basic diagnostics check on your DIRECTV Receiver. If you are experiencing any
trouble with your receiver, run the system test. It will also allow you to get your access card and receiver ID numbers
or to initiate diagnostic procedures on your digital satellite receiver.
First make sure that:
All connections — jacks, cables, etc. — are in place correctly (see Chapter Two,
Getting Connected, for more information)
ere are batteries in the remote control, and they are working correctly
e access card is installed in the DIRECTV Receiver.
Follow these steps to run the diagnostics system test on your DIRECTV Receiver.
1) Turn on your TV and the DIRECTV Receiver.
2) Slide the mode switch to the DIRECTV position to put the remote control in satellite receiver-controlling mode,
then press MENU to bring up the Quick Menu.
3) Select Settings.
4) Select S e t u p , then Info & Test.
5) Use arrow keys to highlight the System Test tab, then press SELECT on Run Test.
6) If your system does not pass the system test, check any of these potential trouble areas: cabling, pointing the
satellite dish, phone connection and access card.
7) If you continue to have problems, call DIRECTV Customer Service at 1-800-DIRECTV.
You should run a system test several times before concluding that there is a problem. Occasional fl uctuations in the
phone line or satellite signal can give temporary false readings.
Troubleshooting
Other Information
58
Chapter 4 59
Troubleshooting
Limited 90-Day Warranty
DIRECTV warrants your DIRECTV Receiver (Model Number: D11) and any included accessories against defects in
materialorworkmanshipforaperiodofninety(90)daysafterthedateofpurchase.
Who is Covered?
You must have proof of purchase to receive warranty service. A sales receipt or other document showing that you
purchased the product is considered proof of purchase. THIS LIMITED WARRANTY EXTENDS ONLY TO
THEORIGINALCONSUMERPURCHASERORANYPERSONRECEIVINGTHEDIRECTVRECEIVER
ASAGIFTFROMTHEORIGINALCONSUMERPURCHASERANDTONOOTHERPURCHASEROR
TRANSFEREE.THISWARRANTYDOESNOTEXTENDTOCOMMERCIALUSERS.THISPRODUCT
IS NOT AUTHORIZED FOR USE OUTSIDE THE UNITED STATES AND ANY SUCH USE VOIDS THIS
WARRANTY.
What is Covered?
Warranty coverage begins the day you purchase the product. For ninety (90) days from the purchase date, at the option of
DIRECTV, the DIRECTV Receiver will be repaired or replaced with a new, repaired, refurbished or comparable product
(whichever is deemed necessary) if it becomes defective or inoperative. is exchange is done without charge to you for parts
and labor. You will be responsible for the cost of shipping to and from the location designated by DIRECTV. If DIRECTV
cannot reasonably repair or replace the Receiver then DIRECTV may, at its sole discretion, refund the price you paid for
the product or the current retail price of the product.
All products, including replacement products, are covered only for the original warranty period. When the warranty on
the original product expires, the warranty on the replacement product also expires. After ninety (90) days from the date of
purchase, you pay for the replacement of all parts, and for all labor charges.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU.
What is Excluded?
Your warranty does NOT cover:
Labor charges for installation or setup of the product.
Installation, performance of, or repair of: audio/video cabling, telephone line, or accessory attachments used with the
product.
Product replacement because of misuse, accident, lightning damage, unauthorized repair, or other cause not within the
control of DIRECTV.
Incidental or consequential damages resulting from the product. SOME STATES DO NOT ALLOW THE
EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY
NOT APPLY TO YOU.
Any modifi cations or other changes to the product, including but not limited to software or hardware modifi cation
in any way other than as expressly authorized by DIRECTV will void this limited warranty. Except in the case of
Limited 90-Day Warranty
Other Information
60
Chapter 4 61
Limited 90-Day Warranty
hardware or software provided by DIRECTV, installing software modifi cations, “hacks” or utilizing service access or
“back doors” will void this limited warranty.
Reception transmission problems caused by signal conditions, telephone line, or cable or antenna systems outside the
unit.
A product that has been modifi ed or adapted to enable it to operate in any country other than the country for which it
was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifi cations.
A product used for commercial or institutional purposes.
DIRECTV makes no warranty that the access connection will be a local (not long distance) phone call.
e continued provisioning of any of the programming and other services delivered through the Receiver including but
not limited to television programming, show information, program guide data, and scheduling information.
Make Sure You Keep...
Please keep your sales receipt or other document showing proof of purchase. Attach it to this User Guide and keep both
nearby. Also keep the original box and packing material in case you need to return your product.
Before Requesting Repair Service...
Please check the troubleshooting section of this guide. is may save you a call to DIRECTV Customer Care.
To Get Warranty Service...
Warranty service will be provided by DIRECTV. If you believe you need service for your Receiver, contact DIRECTV at
1-800-DIRECTV. A representative will go through a diagnostic checklist with you. If it is determined that the product
needs to be returned for service or exchanged, you will receive a return authorization number. e representative will give
you complete shipping details.
To Get Out-of-Warranty Service...
To obtain out-of- warranty service contact DIRECTV at 1-800-DIRECTV for information on the possibility of and any
costs for repair or replacement of out-of- warranty products.
ALL WARRANTIES IMPLIED BY LAW, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY LIMITED TO THE DURATION OF THIS
EXPRESS LIMITED WARRANTY.
WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A.,
THIS EXPRESS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
GUARANTEES, AGREEMENTS AND SIMILAR OBLIGATIONS OF DIRECTV. REPAIR OR REPLACEMENT
AS PROVIDED IN THIS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY. IN NO EVENT WILL DIRECTV BE LIABLE FOR ANY AMOUNT GREATER THAN THE
Limited 90-Day Warranty
Other Information
62
Chapter 4 63
Limited 90-Day Warranty
RETAIL PRICE OF THE DIRECTV RECEIVER. DIRECTV SHALL NOT BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THE
DIRECTV RECEIVER.
SOME STATES DO NOT ALLOW LIMITATIONS ON WARRANTIES, SO THE ABOVE LIMITATIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER
RIGHTS WHICH VARY FROM STATE
TO STATE.
DIRECTV, Inc.
2230 E. Imperial Hwy
El Segundo, CA 90245
1-800-DIRECTV
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers in case you need them. ese numbers are located on the product.
Model No. ___________________________________________________________________
Serial No. ____________________________________________________________________
Purchase Date: ________________________________________________________________
Dealer/Address/Phone: _________________________________________________________
Access Card: _________________________________________________________________
Receiver ID: __________________________________________________________________
Product Information
Other Information
64
Chapter 4 65
DIRECTV PROTECTION PLAN
DIRECTV PROTECTION PLAN
Protect your DIRECTV®SystemwiththeDIRECTVPROTECTIONPLAN.Foralowmonthlyfee,theDIRECTV
PROTECTION PLAN covers the components of your DIRECTV System, giving you peace of mind and
comprehensive support to ensure that you and your family enjoy nonstop DIRECTV®entertainment.
DIRECTVPROTECTIONPLANBenefits
Your DIRECTV Limited Warranty provides certain remedies for this receiver during the stated coverage term. The
DIRECTV PROTECTION PLAN provides comprehensive coverage for your DIRECTV System, including:
In-home service calls when needed 24-hour Technical Support
Power surge related repairs Dish antenna realignments
Cables, switches, and associated wiring
throughout home
Replacement of defective equipment (if
problem can not be resolved over the phone) *
Defective remote control replacements Allpartsandlaborforrepair
Get ALL THAT FOR JUST $5.99 a month for accounts with standard DIRECTV Receivers and only $7.99 a
month for accounts with DIRECTV® DVR, DIRECTV HD Receivers, or DIRECTV DVRs [NAME TBD] with
UltimateTV Service. This one low monthly fee covers every DIRECTV component and receiver on your account.
Sign up for the DIRECTV PROTECTION PLAN Today
If you have standard DIRECTV Receiver(s), visit DIRECTV.com and SIGN IN using the simple steps below or call
1-800-DIRECTV.
1. SIGNINwithyourusernameandpassword,orclickonthe“Registernow”linkandgothroughtheeasysteps,
then continue with Step 2.
2. SELECT Option B, and then click the “Next” button at the bottom of the page.
3. SCROLL down to Step 3 (Add Additional Services) and SELECT “DIRECTV PROTECTION PLAN,” then
CLICK on the “Next” button.
4. REVIEW your change and CLICK on the “Accept These Changes” button.
If you have a DIRECTV® Receiver, DIRECTV HD Receiver, or DIRECTV Receiver with UltimateTV Service,
please call 1-800-DIRECTV to sign up.
DIRECTV PROTECTION PLAN
Other Information
66
Chapter 4 67
Section Title
DIRECTV PROTECTION PLA
N
The DIRECTV PROTECTION PLAN is offered by AIG Warranty Guard and underwritten by New Hampshire
Insurance Company on behalf of DIRECTV where authorized by law. Certain limitations apply. Pricing, terms
and conditions of the DIRECTV PROTECTION PLAN are subject to change. Full terms and conditions will be
mailed to you prior to service billing and are available at DIRECTV.com. (Note: Annual payment option no longer
available.)
*Afeeof$49forstandardIRDequipment,$249forDIRECTVDVR,DIRECTVDVR[NAMETBD]orUltimateTV
equipment, or $400 for HD equipment will be charged to your DIRECTV bill if the defective equipment that we are
replacingforyouisnotreturnedwithin30calendardays.Theplanwillprovideareturnboxforthedefectiveequipment
and even pick up the shipping costs. You’ll receive replacement equipment in about 72 hours.
Note
68
FCC Customer Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Responsible Party:
DIRECTV, Inc.
2230 E. Imperial Hwy
El Segundo, CA 90245
1-800-DIRECTV
Trade Name: DIRECTV
Type of Equipment: DIRECTV Satellite Receiver
Model Number: D11
Federal Communications Commission (FCC): This equipment complies with both Part 15 and Part 68 of the FCC
rules.
Your DIRECTV Receiver complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
FCC Customer Information
Other Information
Chapter 4 69
FCC Customer Information
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However there is no guarantee that
interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradio
or television reception, which can be determined by removing and applying power to the equipment, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving satellite dish antenna.
Increase the separation between the equipment and the DIRECTV Receiver.
Connect the equipment into an outlet on a circuit diff erent from that to which the DIRECTV Receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The user may find the following booklet, prepared by the Federal Communications Commission, helpful: “How
to Identify and Resolve Radio and TV Interference Problems.” This booklet is available from the U.S. Government
Printing Office, Washington, DC. To meet FCC requirements, only peripherals (computer input/output devices,
terminals, printers, etc.) certified to comply with Class B limits may be attached to this device. Operation with
non-certifiedperipheralsislikelytoresultininterferencetoradioandTVreception.TomeetFCCrequirements,
shielded cables are required to connect the device to a personal computer, peripheral, or other Class B certified
device.
70
This equipment complies with Part 68 of the FCC Rules and the requirements adopted by ACTA. On the back of
this equipment is a label that contains a product identifier in the format US:AAAEQ##TXXXX. If requested,
this information must be provided to your telephone company. A plug and jack used to connect this equipment to
thepremiseswiringandtelephonenetworkmustcomplywiththeapplicableFCCPart68rulesandrequirements
adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be
connected to a compatible modular jack that is also compliant. See installation instructions for details.
The REN is used to determine the number of devices that may connect to a telephone line. Excessive RENs on a
telephonelinemayresultinthedevicesnotringinginresponsetoanincomingcall.Inmostbutnotallareas,the
sum of the RENs should not exceed five (5.0).
To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact
your local telephone company. The REN for this product is part of the product identifier that has the format US:
AAAEQ##TXXXX. The digits represented by ## are the REN without the decimal point (e.g., 03 is a REN of 0.3).
If this DIRECTV Receiver causes harm to the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be required. But if advance notice isn’t practical, the
telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a
complaintwiththeFCCifyoubelieveitisnecessary.
FCC Customer Information
70
Other Information
Chapter 4 71
FCC Customer Information
Thetelephonecompanymaymakechangesinitsfacilities,equipment,operationsorproceduresthatcouldaffect
the proper functioning of your equipment. If they do, you will be notified in advance in order for you to make
necessary modifications to maintain uninterrupted service. Connection to party line service is subject to state
tariffs. Contact the state public utility commission, public service commission or corporation commission for
information.
If trouble is experienced with this unit, for repair or warranty information, please contact DIRECTV Customer
Care at the address and phone number listed below. If the equipment is causing harm to the network, the telephone
company may request that you disconnect the equipment until the problem is resolved.
DIRECTV, Inc.
2230 E. Imperial Hwy
El Segundo, CA 90245
1-800-DIRECTV
DO NOT DISASSEMBLE THIS EQUIPMENT. It does not contain any user-serviceable components.
WerecommendtheinstallationofanACsurgearresterintheACoutlettowhichthisequipmentisconnected.
Telephone companies report that electrical surges, typically lightning transients, are very destructive to customer
terminal equipment connected to AC power sources.
