www.humaxdigital.com/freesat

FOXSAT-HD Satellite HD Digital Box

Receiving HDTV signals (MPEG-4 AVC/H.264 and MPEG-2)

Under 1W power consumption in standby

HDMI - digital interface for perfect transmission of picture and sound

Simultaneous playing of transmissions over HDMI, YPbPr or Scart*

Easy installation and operation

Resolution format: 1080i, 720p, 576p, 576i

DVB-S2 and DVB-S compatible

Ethernet support

Full colour, high resolution electronic program guide

Dolby digital audio output (S/PDIF)

Automatic software upgrade via satellite

Improving SDTV on a HD LCD TV

Audio description / One touch subtitle

* Some High Definition programmes or events may be protected by the broadcaster

and not available via the Component or RGB scart outputs.

High-Definition (HD) TV packs in up to 5 times as much picture detail as

standard TV, so you get crystal clear images and mind-blowing colour.G

FOXSAT-HD

Satellite HD Digital Box

Specification

System Resource

Front-end

SDRAM 256 Mbyte

Flash Memory 16 Mbyte

EEPROM 8 Kbyte

Tuner Type Satellite

Connector Type F-Type, IEC 169-24, Female

Demodulation [number of F/E set] 1, DVB-S2

Audio/Video Processing

Video Decoder [number] MPEG-2 MP@ML, MPEG4 HD HP@L3, PAL[1]

Audio Decoder [number] MPEG-1 Layer II, Dolby-AC3 Audio [1]

Front

Display 7 Segments

LED Standby on/off(Green/Red), TV(Green), Radio(Green)

Buttons Power, TV/Radio, Vol-, Vol+, CH-, CH+,

OK, Guide, Menu

Rear

SCART 1 TV, 1 VCR(RGB/YPbPr)

RF 1 Input

RCA 2 Set(1 Video, 2 Audio, 1 Component)

S/PDIF 1

HDMI HDCP version

Component Video Out 1 Set

USB Host version 1.1/2.0

LAN RJ-45 (Mac address)

Power cord Type Fixed

Specifications and functions may be changed for improvement without notice in advance.

www.humaxdigital.com/freesat

Power Supply

Input Voltage AC 90-250V (Free voltage), SMPS

Power Consumption under 1Watt

Physical Specification

Size (Width x Height x Depth) 280 x 45 x 200 mm

Weight(Net) 1.5 Kg

Accessory

RCU, Battery(AAAx2), Manual, Quick guide, Warranty Card, HDMI/RCA/SCART cable
