2008HUV4213-GandHUV4213-GXP

Owner’sManual

GasolineUtilityVehicles

NOTICE

Warrantyinformationappearsattheendofthismanual.Nootherwarranties,expressorimplied,arecontainedherein.

Yourauthorizedrepresentativecheckedthevehiclebeforeitwasdeliveredtoyouandwillprovideyouacopyofthe

completedvehiclewarrantyregistrationform.

Husqvarnaisnotliableforerrorsinthismanualorforincidentalorconsequentialdamagesthatresultfromthe

useofthematerialinthismanual.

Thismanualcontainsproprietaryinformationthatisprotectedbycopyright.Allrightsarereserved.Nopartofthis

manualmaybephotocopied,reproduced,ortranslatedtoanotherlanguagewithoutthewrittenconsentofHusqvarna.

Theinformationcontainedinthisdocumentissubjecttochangewithoutnotice.

Husqvarnareservestherighttomakedesignchangestovehicleswithoutobligationtomakethesechangeson

unitspreviouslysold.

ThesevehiclesdonotconformtoFederalMotorVehicleSafetyStandardsforautomobilesortoFMVSS500for

low-speedvehicles,andarenotequippedforoperationonpublicstreets,roads,orhighways.

Copyright©2007

2008HUV4213-GandHUV4213-GXPOwner’sManualPage1

FOREWORD

ThankyouforchoosingHusqvarna,aworldleaderinoutdoorproducts.Youhavechosenthenestutilityvehicleon

themarket.PleaseprotectyourinvestmentandensurethatyourHusqvarnavehicleprovidesyearsofreliable,superior

performancebyreadingandfollowingthemaintenanceinstructionsinthismanual.

Yourcomfortandsafetyareimportanttous,soweurgeyoutoreadandfollowthestep-by-stepoperatinginstructions

andsafetyprecautionsinthismanual.Theseinstructionsmustbefollowedinordertoavoidtheriskofseverepersonal

injury.Ifyourentorloanyourvehicletoothers,werecommendthatyouaskthemtoreadthismanualbeforethey

operatethevehicle.

Husqvarnaproductsarebackedbyacustomersupportsystemdesignedtoofferyoufast,courteousservice.Inthe

eventthatyourHusqvarnavehicleneedsrepairsorservice,werecommendthatyourlocalauthorizedHusqvarna

representativeperformthem.ForthenameandaddressoftheHusqvarnarepresentativenearestyou,logontoour

websiteatwww.usa.husqvarna.com.Ifyouwouldprefertowritetous,directyourletterto:Husqvarna,Attention:

MarketingServices,7349StatesvilleRd.,Charlotte,NC28269USA.YourlocalauthorizedHusqvarnarepresentative

canalsoprovidetechnicaladvice,parts,andservicemanuals.

Wehopeyouwillconsiderthisowner’smanualapermanentpartofyourHusqvarnavehicle.Ifyousellthevehicle,

pleaseincludethemanualsothatthenextownerwillhavetheimportantoperating,safety,andmaintenance

informationitcontains.Translatedowner’smanualscanbedownloadedfromtheHusqvarnawebsiteat

www.usa.husqvarna.com.Belowisaquickreferencetableofitemsthatwillhelpyoumaintainthisvehicle.Theseparts

canbepurchasedfromyourauthorizedHusqvarnadealer.

REGULARMAINTENANCEITEMSPERIODICMAINTENANCEITEMS

EngineOilFilter

(P/N6030000-06)

Battery

(P/N6030000-02)

EngineAirFilter

(P/N6030000-04)

SparkPlugO.H.V.

(P/N6030000-07)

EngineFuelFilter

(P/N6030000-08)

SpringTune-UpKit

(P/N6030000-05)

BatteryTerminalProtectorSpray

(P/N6030000-03)

DryMolyLube

(P/N6030000-01)

Page22008HUV4213-GandHUV4213-GXPOwner’sManual

TABLEOFCONTENTS

SafetyDecalandFeatureIdentication..................................................................................................................4

PracticeSafety.....................................................................................................................................................7

Proposition65–StateofCalifornia........................................................................................................................7

SafetyDetails.......................................................................................................................................................8

GeneralWarnings.................................................................................................................................................9

ModelIdentication.............................................................................................................................................10

ControlsandIndicators........................................................................................................................................11

SeatLatchandAdjustment.................................................................................................................................16

Pre-OperationandDailySafetyChecklist.............................................................................................................17

DrivingInstructions.............................................................................................................................................18

BedLatchandPropRod.....................................................................................................................................21

FrontShockAbsorbers.......................................................................................................................................21

LoadingandUnloading.......................................................................................................................................22

TowingwiththeVehicle.......................................................................................................................................23

TransportingonaTrailer.....................................................................................................................................23

Storage..............................................................................................................................................................24

Maintenance......................................................................................................................................................26

PeriodicServiceSchedule...................................................................................................................................27

PeriodicLubricationSchedule.............................................................................................................................29

MasterCylinder.................................................................................................................................................30

EngineOil..........................................................................................................................................................31

FuelingInstructions.............................................................................................................................................35

Battery...............................................................................................................................................................36

CleaningtheVehicle...........................................................................................................................................38

Accessories........................................................................................................................................................38

SubsequentOwnerRegistration..........................................................................................................................39

VehicleSpecications.........................................................................................................................................40

Warranties..........................................................................................................................................................42

2008HUV4213-GandHUV4213-GXPOwner’sManualPage3

SafetyDecalandFeatureIdentication

SAFETYDECALANDFEATUREIDENTIFICATION

Thefollowingpagescontainsafetydecalandfeatureidenticationinformation.Fordetailedinformationonspecic

features,readtheappropriatesectioninthismanual.

Page42008HUV4213-GandHUV4213-GXPOwner’sManual

SafetyDecalandFeatureIdentication

HUV4213-G/4213-GXP

347

5

3

9

7

1

11

8

2

12

13

14

4

6

16

15

10

1101553901Decal,BedLoadingWarning(oncargobedorseat

back)9102224301Decal,OperatingInstructions(onsteeringwheel)

2101609401Decal,CrushAreaWarning(behindseat,near

cargobed)10SerialNumber

3101825102Decal,On/Off/StartKeySwitch(abovekeyswitch)11FuelShut-OffValve

4101960201Decal,VehicleLoadingInstructions(below

instrumentpanel)12LowOilWarningLight

5102029101Decal,RolloverWarning(oninstrumentpanel)13AcceleratorPedal

6102044601Decal,YoungDriverWarning(oninstrumentpanel)14BrakePedal

7102046601Decal,DifferentialLockWarning(betweenseats)15FuelGauge

8102224001Decal,RotatingPartsWarning(onframe)16LightSwitch

2008HUV4213-GandHUV4213-GXPOwner’sManualPage5

SafetyDecalandFeatureIdentication

HUV4213-G/4213-GXP

348

2

9

8

10

7

4

11

3

6

5

12

1

11011553Decal,TrailerHitchTongueWeightNotice(on

trailer/receiverhitch)7102459301Decal,BedLatchWarning(onvehiclebody,below

bedlatch)

2101547601Decal,GasolineFuelWarning(atfuellloron

frame,nearfueltank)8Forward/ReverseControl

3101915201Decal,FrameGround/GovernorWarning(on

vehicleframenearbattery)9ParkBrake

4101960501Decal,RotatingParts/HotManifoldWarning(on

engine,starter/generator,andtransaxle)10Choke

5102231601Decal,WinchSafetyWarning(onvehiclebody,

belowseat)11BedLatch

6102345901Decal,DiodeSafetyWarning(onvehicleframe,

neardiode)12ReceiverHitch

Page62008HUV4213-GandHUV4213-GXPOwner’sManual

PracticeSafety

PRACTICESAFETY

399

Figure1PracticeSafety

Safetysignslikeyouseeabovemayatrstseemshocking,buttheirimpactismildcomparedwiththereality

ofseverepersonalinjury.

Yoursafetyandsatisfactionareoftheutmostimportancetous.Thatiswhybeforeoperatingthevehicle,weurge

youtoreviewtheinformationinthismanual.UnderstandandbecomefamiliarwiththeDANGER,WARNING,and

CAUTIONstatementsandproceduresitcontains,alongwiththesafetydecalsthatareafxedtoyourvehicle.

Taketimetounderstandthelanguageofsafety.Itisalanguagethatcansaveyourlife.

PROPOSITION65–STATEOFCALIFORNIA

WARNING

•Thisproductcontainsoremitschemicalsorsubstancesthathavebeendeterminedbythestateof

Californiatocausecancerandbirthdefectsorotherreproductiveharm.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage7

SafetyDetails

SAFETYDETAILS

WARNING

•Thisowner’smanualshouldbereadcompletelybeforeattemptingtodriveorservicethevehicle.

Failuretofollowtheinstructionsinthismanualcouldresultinpropertydamage,severepersonal

injury,ordeath.

Itisimportanttonotethatsomevitalstatementsthroughoutthismanualandonthedecalsafxedtothevehicleare

precededbythewordsDANGER,WARNING,orCAUTION.Foryourprotection,werecommendthatyoutakespecial

noticeofthesesafetyprecautions.Safetyprecautionsareessentialandmustbefollowed.

Ifanyoftheoperationorsafetydecalsonthevehiclebecomedamaged,havebeenremoved,orcannotbeeasilyread,

theyshouldbereplacedimmediatelytoavoidpossiblepropertydamage,personalinjury,ordeath.Contactyourdealer.

DANGER

•ADANGERindicatesanimmediatehazardthatwillresultinseverepersonalinjuryordeath.

WARNING

•AWARNINGindicatesanimmediatehazardthatcouldresultinseverepersonalinjuryordeath.

CAUTION

•ACAUTIONwiththesafetyalertsymbolindicatesahazardorunsafepracticethatcouldresultin

minorpersonalinjury.

CAUTION

•ACAUTIONwithoutthesafetyalertsymbolindicatesapotentiallyhazardoussituationthatcould

resultinpropertydamage.

Page82008HUV4213-GandHUV4213-GXPOwner’sManual

GeneralWarnings

1

2

(Viewedfrompassengersideofvehicle)

1.Removenegativebatterycable.

2.Removepositivebatterycable.

Connectbatterycablesinreverseorder.

1

Figure2BatteryCableRemoval

GENERALWARNINGS

Thefollowingsafetystatementslistedmustbeheededwheneverthevehicleisbeingoperated,repaired,orserviced.

SeeSafetyDecalandFeatureIdenticationonpage4.Otherspecicsafetystatementsappearthroughout

thismanualandonthevehicle.

DANGER

•Battery–Explosivegases!Donotsmoke.Keepsparksandamesawayfromthevehicleandservice

area.Ventilatewhenchargingoroperatingvehicleinanenclosedarea.Wearafullfaceshieldand

rubbergloveswhenworkingonornearbatteries.

•Gasoline–Flammable!Explosive!Donotsmoke.Keepsparksandamesawayfromthevehicleand

servicearea.Serviceonlyinawell-ventilatedarea.

•Donotoperateengineinanenclosedareawithoutproperventilation.Theengineproducescarbon

monoxide,whichisanodorless,deadlypoison.

•Thevehiclewillnotprovideprotectionfromlightning,yingobjects,orotherstorm-relatedhazards.If

caughtinastormwhiledrivingaHusqvarnavehicle,exitthevehicleandseekshelterinaccordance

withapplicablesafetyguidelinesforyourlocation.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage9

ModelIdentication

WARNING

•Followtheproceduresexactlyasstatedinthismanual,andheedallDANGER,WARNING,and

CAUTIONstatementsinthismanualaswellasthoseonthevehicle.

•Donotleavechildrenunattendedonvehicle.

•Priortoleavingthevehicleunattendedorservicingthevehicle,settheparkbrake,placethe

Forward/ReversehandleintheNEUTRALposition,turnthekeyswitchtotheOFFposition,andremove

thekey.Chockthewheelswhenservicingthevehicle.

•Improperuseofthevehicleorfailuretoproperlymaintainitcouldresultindecreasedvehicle

performance,severepersonalinjury,ordeath.

•Anymodicationorchangetothevehiclethataffectsthestabilityorhandlingofthevehicle,or

increasesmaximumvehiclespeedbeyondfactoryspecications,couldresultinseverepersonal

injuryordeath.

•Checkthevehicleforproperlocationofallvehiclesafetyandoperationdecalsandmakesuretheyare

inplaceandareeasytoread.

•Forvehicleswithcargobeds,removeallcargobeforeraisingthebedorservicingthevehicle.Ifthe

vehicleisequippedwithaproprod,ensurethatitissecurelyengagedwhilebedisraised.Donot

closebeduntilallpersonsareclearofcargobedarea.Keephandsclearofallcrushareas.Donot

dropcargobed;lowergentlyandkeepentirebodyclear.Failuretoheedthiswarningcouldresultin

severepersonalinjuryordeath.

•Onlytrainedtechniciansshouldserviceorrepairthevehicle.Anyonedoingevensimplerepairsor

serviceshouldhaveknowledgeandexperienceinelectricalandmechanicalrepair.Theappropriate

instructionsmustbeusedwhenperformingmaintenance,service,oraccessoryinstallation.

•Toavoidunintentionallystartingthevehicle:

–Disconnectbatterycables,negative(–)cablerst(Figure2).

–Disconnectthesparkplugwirefromthesparkplug.

•Frameground–Donotallowtoolsorothermetalobjectstocontactframewhendisconnectingbattery

cablesorotherelectricalwiring.Donotallowapositivewiretotouchthevehicleframe,engine,or

anyothermetalcomponent.

•Wearsafetyglassesorapprovedeyeprotectionwhenservicingthevehicle.Wearafullfaceshieldand

rubbergloveswhenworkingonornearbatteries.

•Donotwearlooseclothingorjewelrysuchasrings,watches,chains,etc.,whenservicingthevehicle.

•Useinsulatedtoolswhenworkingnearbatteriesorelectricalconnections.Useextremecautionto

avoidshortingofcomponentsorwiring.

MODELIDENTIFICATION

TheserialnumberofeachHUV4213vehicleisprintedonabarcodedecalmountedontheframedirectlyabovethe

acceleratorpedal(Example:SH0501-583947)(Figure3).Thereisalsoasecondserialnumberdecalmountedon

thefrontbodyframebehindtheinstrumentpanel.Theinstrumentpanelmustberemovedtoviewthisdecal.See

followingNOTE.

NOTE:Havethevehicleserialnumberavailablewhenorderingpartsormakinginquiries.

Page102008HUV4213-GandHUV4213-GXPOwner’sManual

ControlsandIndicators

SERIAL NUMBER

HH0601-583947

7349 ST ATESVILLE RD.

CHARLOTTE, NC 28269

47

Figure3SerialNumber

CONTROLSANDINDICATORS

SeeGeneralWarningsonpage9.

WARNING

•Beforeallowinganyonetodrivethevehicle,makesurethedriverisfamiliarwithallcontrolsand

operatingprocedures.

•Donottamperwiththegovernor.Doingsowillvoidthewarranty,aswellasdamagetheengineand

othercomponents,andcouldresultinpropertydamage,personalinjury,ordeathduetounsafe

speeds.

•DonotshifttheForward/Reversehandlewhilethevehicleisinmotion.

•EnginemustbeatidlebeforeshiftingtheForward/Reversehandle.Failuretodosomayresultin

injurytoinattentivepassengersand(or)damagetothevehicle.

•Toavoidinjurytoaninattentivepassengerordamagetothevehicle,alwaysbringthevehicletoafull

stopbeforeshiftingtheForward/Reversehandle.

•Toavoidunintentionallystartingorrollingthevehicle,settheparkbrake,placetheForward/Reverse

handleintheNEUTRALposition,turnthekeyswitchtotheOFFposition,andremovethekeywhen

leavingthevehicle.

•Withthedifferentiallockengaged,vehicleturningfunctionsaregreatlyreduced.Topreventlossof

vehiclecontrolwhendifferentiallockisengaged,donotoperatevehicleatspeedsgreaterthanhalf

throttleandusecautionwhenattemptingtoturnthevehicle.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage11

ControlsandIndicators

KEYSWITCH

Thekeyswitchismountedontheinstrumentpaneltotherightofthesteeringcolumn(Figure4).Ithasthreepositions:

OFF,ONandSTART.T ostartthevehicle,placetheForward/ReversehandleintheNEUTRALpositionandturnthe

keypasttheONpositiontotheSTARTpositionandholduntiltheengineisrunningsmoothly.Releasethekeyandit

willreturntotheONpositionandtheengineshouldidle.Theenginewillcontinuetoidleuntilthekeyisturnedtothe

OFFposition.SeefollowingWARNING,CAUTIONandNOTE.

164

Figure4KeySwitch-Key-StartVehicleShown

WARNING

•Movingparts!Keepclearoftheenginecompartmentwhiletheengineisrunning.

CAUTION

•Donot“rev”theengineforlongperiodsoftimewhiletheForward/ReversehandleisintheNEUTRAL

position.Failuretoheedthiscautioncouldresultindamagetotheunitizedtransaxle.

•DonotshifttheForward/Reversehandlewhiletheacceleratorpedalispressed.Shiftthehandle

onlywhenthevehicleisatacompletestop.Failuretoheedthiscautioncouldresultindamageto

theunitizedtransaxle.

NOTE:ThekeycanberemovedonlywhenthekeyswitchisintheOFFposition.

FORWARD/REVERSECONTROL

TheForward/Reversehandleislocatedontheseatsupportpanel(Figure5).Thehandlehasthreedistinctpositions:

F(FORWARD),N(NEUTRAL),andR(REVERSE).Rotatethehandletowardsthedriver(FORWARD)tooperatethe

vehicleintheforwarddirection,ortowardsthepassenger(REVERSE)tooperatethevehicleinreverse.Theengine

canbestartedonlywhenthehandleisinthestraightupposition(NEUTRAL).Theenginemustbeatidlebefore

shiftingtheForward/Reversehandle.SeeprecedingWARNINGandCAUTION.

Husqvarnavehiclesoperateatareducedspeedinreverse.Thereversebuzzerwillsoundasawarningwhenthe

Forward/ReversehandleisintheREVERSEposition.

Page122008HUV4213-GandHUV4213-GXPOwner’sManual

ControlsandIndicators

F N R

159

Figure5Forward/ReverseHandle

ACCELERATORPEDAL

Theacceleratorpedalisthepedalontheright,withthewordGOmoldedintoit(Figure6).

WiththeenginerunningandtheForward/ReversehandleintheFORWARDorREVERSEposition,vehiclespeed

willincreaseastheacceleratorpedalispressed.Whentheacceleratorpedalisreleased,itwillreturntotheoriginal

positionandtheenginewillidle.SeeprecedingWARNINGandCAUTION.

160

Figure6AcceleratorandBrakePedals

161

Figure7BrakePedal

2008HUV4213-GandHUV4213-GXPOwner’sManualPage13

ControlsandIndicators

BRAKEPEDAL

ThebrakepedalisthelargepedalontheleftwiththewordSTOPmoldedintoit(Figure6).T osloworstopthe

vehicle,pressthebrakepedal(Figure7).

PARKBRAKE

Theparkbrakehandleislocatedbetweenthedriverandpassengerseats.T oengagetheparkbrake,rstapply

pressuretothebrakepedal,thenpullupontheparkbrakehandleuntilhandlelatchesintoplace.T odisengage,pull

uponthehandleandpressthebuttonontheendofthehandle.Pushhandledown.SeefollowingWARNING.

WARNING

•Theparkbrakehasmultiplelockingpositionsandshouldbermlylockedtopreventvehiclefrom

rolling.

LOCKOUTCAM

Thekey-startvehicleisequippedwithalockoutcamthatallowstheenginetobestartedonlywhenthe

Forward/ReversehandleisintheNEUTRALposition.Thelockoutcam(yellow)islocatedonthebackofthe

Foward/Reversehandleinsidetheenginecompartment(Figure8).

NOTE:Besurethecamisinthecorrectposition.Thecamshouldactivatethelimitswitchonlywhenthe

Forward/ReversehandleisintheNEUTRALposition.

8

Figure8CorrectPositionforKey-startVehicleLockout

Cam

CHOKE

Thechokeislocatedontheseatsupportpanelbelowandtotheleftofthedriver’sleftknee.Ifthevehicleishard

tostartincoolorcoldtemperatures,activatechoke:Pullthechokehandleouttoactivate.Releasethehandle

whentheenginebeginstorunsmoothly(Figure9).

Page142008HUV4213-GandHUV4213-GXPOwner’sManual

ControlsandIndicators

162

Figure9Choke

163

Figure10DifferentialLock

DIFFERENTIALLOCK

WARNING

•Withthedifferentiallockengaged,vehicleturningfunctionsaregreatlyreduced.Topreventlossof

vehiclecontrolwhendifferentiallockisengaged,donotoperatevehicleatspeedsgreaterthanhalf

throttleandusecautionwhenattemptingtoturnthevehicle.

•Disengagedifferentiallockonpavedsurfaces.

Thedifferentiallockisusedtoprovidebettertractionattherearwheelswhennecessary.Engagingthedifferentiallock

willtransferpowertobothrearwheelssimultaneously(Figure10).

1.Toengagethedifferentiallock,slowthevehicletonomorethanhalfthrottleandpulldifferentiallockhandle

towardthebackofthevehicle.Thedifferentiallockwillengagewhenpowertobothrearwheelsisrequired.

2.Todisengagethedifferentiallock,cometoacompletestop,thenpushlevertowardfrontofvehicle.

LOWOILWARNINGLIGHT

Thevehicleisequippedwithalowoilwarninglight,locatedontheinstrumentpaneljusttotherightofthesteering

columnandkeyswitch(Figure11).Ifthewarninglightcomeson,oilshouldbecheckedandaddedtotheengineas

necessarybeforecontinuingtousethevehicle.Thevehicleshouldneverbedrivenwhenthelowoilwarninglight

remainson.Ifthewarninglightgoesonandoff,thevehiclemaybedriven,butoilshouldbeaddedattherst

opportunity.Iftheoilleveliscorrectandthewarninglightstayson,haveatrainedtechniciancheckthevehicle.

SeefollowingCAUTION.

CAUTION

•Failuretoaddoilimmediatelywhenthelowoilwarninglightstaysonmayresultinpermanent

enginedamage.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage15

SeatLatchandAdjustment

164

Figure11LowOilWarningLight

FUELGAUGE/HOURMETER

Afuelgaugeandhourmeterarehousedtogetheratthelowerleftcorneroftheinstrumentpanel.Thefuelgauge

operateswhenthekeyswitchisintheONposition,andallowstheoperatortomonitorthefuellevelinthevehicle.The

hourmeteroperatesonlywhentheengineisrunning,andshouldbeusedonlybytrainedtechnicianstotrackvehicle

usageanddeterminewhenperiodicserviceproceduresarerequired.SeePeriodicServiceScheduleonpage27.

HEADLIGHTCONTROL

Theheadlightcontrolislocatedonthefrontinstrumentpanelbetweenthefuelgauge/hourmeterandsteeringcolumn.

Pulltheheadlightcontrolknobouttoturntheheadlightsonandpushtheknobintoturntheheadlightsoff.

NOTE:Usingtheheadlightsforextendedperiodsoftimewithouttheenginerunning,orwiththeengineidling,will

dischargethebattery.

LIGHTBARCONTROL

Thelightbarcontrolisatoggleswitchlocatedontheinstrumentpanelaboveandslightlyleftoftheheadlightcontrol

knob.Placethetoggleswitchintheupperpositiontoilluminatethelightbarlightsandinthelowerpositiontoturnthe

lightbarlightsoff.

SEATLATCHANDADJUSTMENT

Theseatsarehingedtoalloweasyaccesstotheenginecompartment.Alatchattherearofeachseatbottomkeeps

theseatfrommovingonitshingeswhilethevehicleisinoperation.T odisengagethelatch,grasptheseatbackand

pullrmlyinaforward/upwarddirectionuntilthelatchreleases.Toengagetheseatlatch,pushdownrmlyontheseat

backuntiltheseatlocksintoplace.SeefollowingWARNING.

Page162008HUV4213-GandHUV4213-GXPOwner’sManual

Pre-OperationandDailySafetyChecklist

Thebucketseatsonallvehiclesareadjustableandcanbemovedforwardorbackwardtoaccommodatethedriver

orpassenger.Toadjustaseat:

1.Removetheseatfromthevehicle.

2.Removethefourboltsandwashersfromthebottomoftheseatmountingplate.

3.Alignthemountingplateholeswithholesintheseattoachievethedesiredseatposition.

4.Installwashersandboltsandtightento96in-lb(10.8N·m).

5.Reinstallseatinvehicle.

WARNING

•Makesureseathingesandlatcharesecurelyengagedbeforeoperatingvehicle.

PRE-OPERATIONANDDAILYSAFETYCHECKLIST

EachHusqvarnavehiclehasbeenthoroughlyinspectedandadjustedatthefactory;however,uponreceivingyournew

vehicle(s),youshouldbecomefamiliarwithitscontrols,indicators,andoperation.Carefullyinspecteachvehicleto

ensurethatitisinproperworkingconditionbeforeacceptingdelivery.

Usethefollowingchecklistasaguidetoinspectthevehicle.Thischecklistshouldbeuseddailytoensurethat

thevehicleisinproperworkingconditionandinconjunctionwiththePerformanceInspectiononpage17andthe

PeriodicServiceScheduleonpage27.AnyproblemsshouldbecorrectedbyaHusqvarnadistributor/dealerora

trainedtechnician.

•General:Allthepartsshouldbeinplaceandproperlyinstalled.Besurethatallnuts,bolts,andscrewsaretight.

Checkhoseclampsfortighttandthestarterbeltfortightness.

•Safetyandinformationdecals:Checktoensurethatallsafetyandinformationdecalsareinplace.SeeSafety

DecalandFeatureIdenticationonpage4.

•Tires:Checkforpropertirepressure.Visuallyinspecttiresforwear,damage,andproperinationonadailybasis.

SeeVehicleSpecicationsonpage40.

•Battery:Beforeusingvehicleforthersttime,checkelectrolytetoensureitisattheproperlevel(Figure26).

Checkbatteryposts.Wiresshouldbetightandfreeofcorrosionandbatteryshouldbefullycharged.

•Engine:Checkforproperengineoillevel.SeeEngineOilonpage31.

•Fuel:Checkfuellevel.SeeFuelingInstructionsonpage35.Checkfueltank,lines,fuelcap,pump,fuellters,

andcarburetorforfuelleakageonadailybasis.

•Exhaustsystem:Checkforleaks.

•Hydraulicbrakes:Checkuidlevel.FillwithDOT5brakeuidonly.SeeMasterCylinderonpage30.

•PerformanceInspection:Inspectasinstructed.SeePerformanceInspectiononpage17.

WARNING

•Besuretheplastichasbeenremovedfromtheseatbottombeforeoperatingthevehicle.Failuretodo

somayresultinare,propertydamage,personalinjury,ordeath.

PERFORMANCEINSPECTION

Afteryouhavefamiliarizedyourselfwiththevehiclecontrolsandhavereadandunderstoodthedrivinginstructions,

takethevehicleforatestdrive.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage17

DrivingInstructions

Usethefollowingchecklist,inconjunctionwiththePre-OperationandDailySafetyChecklist,asaguidetoinspectthe

vehicleandcheckdailyforproperoperation.AnyproblemsshouldbecorrectedbyaHusqvarnadistributor/dealerora

trainedtechnician.

•Forward/Reverseshifter:Checkforproperoperation.SeeControlsandIndicatorsonpage11.

•Brakes:Besurethebrakesfunctionproperly.Whenbrakepedalisfullypressedundermoderatepressure,it

shouldnotgomorethanhalfwaytotheoorboard,andvehicleshouldcometoasmooth,straightstop.Ifthebrake

pedalgoesmorethanhalfwaytotheoorboard,orifthevehicleswervesorfailstostop,havethebrakesystem

checkedandadjustedasrequired.Whenbrakepedalisfullypressedunderheavypressure,pedalshouldfeelrm

andfootpadshouldbeaminimumof2inches(5.1cm)fromoorboard.Brakeadjustmentmustbemaintainedso

thebrakepedalcannotbepressedtotheoorboardunderanycircumstance.

•Parkbrake:Applymoderatepressuretoparkbrakehandle.T ensionshouldincreaseasthehandleispulled.When

latched,theparkbrakeshouldlockthewheelsandholdthevehiclestationary(onaninclineof20%orless).

•Reversebuzzer:ThereversebuzzershouldsoundasawarningwhentheForward/Reversehandleisinthe

REVERSEposition.

•Steering:Thevehicleshouldbeeasytosteerandshouldnothaveanyplayinthesteeringwheel.

•Acceleratorforpedal-startvehicle:WiththekeyswitchintheONpositionandtheForward/Reversehandleinthe

FORWARDposition,astheacceleratorpedalispressed,theengineshouldstartandthevehicleshouldaccelerate

smoothlytofullspeed.Whenthepedalisreleaseditshouldreturntotheoriginalpositionandtheenginestop.

Husqvarnavehiclesoperateatreducedspeedinreverse.

•Acceleratorforkey-startvehicle:AfterstartingtheenginewiththekeyswitchandplacingtheForward/Reverse

handleintheFORWARDposition,thevehicleshouldacceleratesmoothlytofullspeedastheacceleratorpedalis

pressed.Whentheacceleratorpedalisreleaseditshouldreturntotheoriginalpositionandtheengineshouldidle.

•Governor:Checkmaximumvehiclespeed.Itshouldoperateinforwardat17-19mph(27-31km/h)onalevel

surface.

•Differentiallockcable:Withthewheelsatrest,pullthedifferentiallockhandletowardtherearofthevehicle

(lockedposition).Thedifferentiallockarmattheotherendofthecableshouldmoveapproximatelyone-halfinch

(12.7mm)downward.Whenthedifferentiallockhandleisplacedbackintotheunlockedposition,thedifferential

lockarmshouldmoveapproximatelyone-halfinch(12.7mm)upward.

•General:Listenforanyunusualnoisessuchassqueaksorrattles.Checkthevehicle’srideandperformance.

HaveaHusqvarnadealeroratrainedtechnicianinvestigateanythingunusual.

DRIVINGINSTRUCTIONS

WARNING

•Onlylicenseddriversshouldbeallowedtodrivethevehicle.

•Beforeallowinganyonetodrivethevehicle,makesurethedriverisfamiliarwithallcontrolsand

operatingprocedures.

•Nooneundertheageof16yearsshouldbeallowedtodrivethevehicle.

•Nomorethanonepersonperbucketseatatonetime,ortwopersonsperbenchseat.

•Donotallowridersinthecargobed.

•Fornightuse,thevehiclemustbeequippedwithheadlights,taillights,andreectors.

•Thevehicleisnotspeciallyequippedforhandicappedpersons:

–Besureallpersonscanproperlyoperatethevehiclepriortoallowingthemtodrivethevehicle.

WARNINGCONTINUEDONNEXTPAGE

Page182008HUV4213-GandHUV4213-GXPOwner’sManual

DrivingInstructions

WARNING

–Besureallpassengersarecapableofsecuringthemselvesinavehiclebeforeallowingthemto

rideinone.

•DonotshifttheForward/Reversehandlewhilethevehicleisinmotion.

•StopthevehiclebeforeshiftingtheForward/Reversehandle.Enginemustbeatidlebeforeshifting

theForward/Reversehandle.Failuretodosomayresultininjurytoinattentivepassengersand

(or)damagetothevehicle.

•Tohelpavoidbeingstruck,donotstandinfrontoforbehindthevehicle.

•Donotleavechildrenunattendedonvehicle.

•Operatethevehiclefromthedriverseatonly.

•Tohelppreventfallsfromthevehicle,remainseatedandholdontoseathandlesatalltimes.Driver

shouldkeepbothhandsonthesteeringwheelwhenthevehicleisinmotion.

•Tohelppreventthepossibilityofseriousinjury,keepentirebodyinsidevehicle.

•Tohelppreventvehiclefromoverturning,driveslowlyinturns.

•Tohelppreventvehiclefromoverturning,driveslowlystraightupanddownslopes.Avoiddriving

thevehicleonslopesexceeding20%incline.

•Avoidstoppingaloadedvehicleonahill.Ifaloadedvehiclemustbestoppedonahill,avoidsudden

startsorrollingbackwardsandstoppingsuddenly.Failuretoheedthiswarningcouldresultinthe

vehicleoverturning.

•Tohelpavoidpossibleinjurytoinattentivepassengersand(or)damagetothevehicle,avoidsudden

starts,suddenstopsandabruptturns.

•Tohelpavoidthepossibilityoflosingcontroloforoverturningthevehicle,reducespeedforadverse

drivingconditionssuchaswetgrassorroughterrain.

•Donotusethevehicleonpublicroads.Itisneitherdesignednorintendedforstreetuseandshould

notbelicensedforuseonpublicroads.

•Thevehicleshouldbedriveninonlyspeciedareasbytrainedoperators.

•Neverattemptjumps.

•Donotdrivewhileundertheinuenceofalcohol,drugs,ormedications.

•Usebrakestoreducespeedwhencoastingdownhill.

Nooneshoulddrivethevehiclewithoutrstbeinginstructedintheproperoperationanduseofvehiclecontrols.An

experiencedoperatorshouldaccompanyeachrst-timedriveronatestdrivebeforeallowingthedrivertooperate

thevehiclealone.

Toensuresafeoperationofthevehicle,followexactlyandinorder,allofthefollowingprocedures.Readand

understandallinstructionspriortodrivingthevehicle.

STARTINGTHEVEHICLE

1.Readsafetywarningsoninstrumentpanelandvehicleloadinginformationlocatedabovepedals.

2.Besureload,ifany,issecure.

3.Studyandunderstandcontrols.

4.Besurepassengerisseatedandholdingontohandhold.Drivershouldhavebothhandsonthesteeringwheel.

5.Makesurewheelsareturnedindesireddirectionandthatnothingisobstructingvehicle’spath.

6.MakesuretheForward/ReversehandleisintheNEUTRALposition.

7.Pressandholdthebrakepedal.

8.TurnthekeyallthewaytotheSTARTpositionandhold,activatingthechokeasnecessary,untiltheenginehas

started.TheenginewillidlewiththeForward/ReversehandleintheNEUTRALposition.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage19

DrivingInstructions

9.Releaseparkbrake.

10.Keepingbrakeengaged,placetheForward/Reversehandleindesiredposition(F=forwardorR=reverse).

Enginemustbeatidlebeforemovingtheshifthandle.Abuzzerwillsoundasawarningwhenthevehicleisin

theREVERSEposition.

11.Releasebrakepedalandslowlypressacceleratorpedal.Astheacceleratorpedalispressed,speedwillincrease

untilfullspeedisreached.SeefollowingWARNING.

WARNING

•Operatormustcontrolvehiclespeedwhengoingdownhill.

•NevershiftvehicleoutoftheFORWARDpositionwhilegoingdownhill.Ifyoudo,youwillnotbeable

toshiftintotheREVERSEpositionorbackintotheFORWARDpositionuntilstopped.

•Pressthebrakepedalasnecessaryandpresstheacceleratorpedalpartiallywhendescendingahill.

Withtheacceleratorpedalpartiallypressed,thegovernorwillcausetheenginetoassistthebrakesin

controllingdownhillspeed.

STOPPINGTHEVEHICLE

Tostopthevehicle,releasetheacceleratorpedalandpressthebrakepedaluntilthevehiclecomestoacompletestop.

SeefollowingWARNINGandCAUTION.

WARNING

•Drivingthroughwatermayaffectthebrakes.Afterdrivingthroughwater,checkeffectivenessofthe

brakesbygentlypressingthebrakepedal.Ifthevehicledoesnotslowdownatthenormalrate,

continuetopressthebrakepedaluntilthebrakesdryoutandnormalperformancereturns.

CAUTION

•Whenstoppedonahill,usethebrakepedaltoholdyourposition.Donotusetheacceleratorpedal

toholdposition.

PARKINGANDLEAVINGTHEVEHICLE

1.Afterstoppingvehicle,sethandbrakeuntilitlocks.Makesureitisfullyengaged.Thiswillpreventthevehicle

fromrolling.

2.TurnthekeyswitchtotheOFFpositionandplacetheForward/ReversehandleintheNEUTRALposition.

Removethekeyandturnthefuelshut-offvalvetotheclosed(OFF)positionwhenthevehicleisnotinuse

(Figure14,Page25).SeealsoFigure24onpage36.

Page202008HUV4213-GandHUV4213-GXPOwner’sManual

BedLatchandPropRod

BEDLATCHANDPROPROD

SeeGeneralWarningsonpage9.

DANGER

•Usecautionwhenworkingunderbed.Besureproprodissecure.Otherwisethebedwillfall,resulting

inseverepersonalinjuryordeath.

WARNING

•Forvehicleswithcargobeds,removeallcargobeforeraisingthebedorservicingthevehicle.Ifthe

vehicleisequippedwithaproprod,ensurethatitissecurelyengaged.Donotclosebeduntilall

personsareclearofcargobedarea.Keephandsclearofallcrushareas.Donotdropcargobed;

lowergentlyandkeepentirebodyclear.Failuretoheedthiswarningcouldresultinseverepersonal

injuryordeath.

Thebedlatch(Figure12)hasanautomaticallyengagingproprodandproprodtrack(Figure13)asstandardfeatures.

Toliftthebed,pullthebedlatchhandletowardtherearofthevehicleandliftthebed.Theproprodwillcometorestin

oneofthenotchesintheproprodtrack.T oclosethebed,liftthebedsothattheproprodisnolongersupportedinone

ofthetracknotches.Pushtheproprodtowardthefrontofthevehicletofreeitfromthetracknotchandgentlylower

thebed.DONOTdropthebed.SeeprecedingDANGER,WARNING,andfollowingNOTE.

NOTE:Thevehicleisequippedwithanautomaticallyengagingproprod(Figure13),unlessequippedwiththe

electricbedliftaccessory.

83A

Figure12BedLatch

84

Figure13PropRod

FRONTSHOCKABSORBERS

Thevehiclearrivesfromthefactorywiththefrontcoil-overshockspre-adjustedforoptimumvehicleperformance.We

donotrecommendadjustingtheshockabsorbersunlessthevehiclewillbeequippedwithacabenclosure.Inthat

event,pleaserefertothecabinstallationinstructionsfortheshockabsorberadjustmentprocedure.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage21

LoadingandUnloading

LOADINGANDUNLOADING

WARNING

•Firmlyengageparkbrakebeforeloadingvehicle.

•Donotallowridersinthecargobed.

•Reducevehicleloadandspeedwhendrivingupordownslopesoronuneventerrain.

•Donotexceedratedvehiclecapacity.Ratedcapacityisforlevelsurfacesonly.

•Overloadingcanaffectvehiclehandlingorcausecomponentfailure,resultinginlossofcontrolof

vehicleandpossibleseverepersonalinjuryordeath.

•Donotloadtailgate.Thetailgateshouldbeintheuprightpositionandlatchedsecurelywhilethe

vehicleisinmotion.

•Tohelpavoidshiftingvehicleloadandpossiblyoverturningthevehicle,avoidsuddenstarts,sudden

stopsandabruptturns.Makesurecargoiswellsecured.

•Avoidtop-heavyloads.Thecenterofgravityofloadshouldneverexceed15inches(38cm)above

thebottomofthecargobed.

•Thecargo’scenterofgravitymayaffecthandling,steering,andbrakingofthevehicle.

•Unloadcargobedbeforeraisingvehiclewithalift,hoist,orjack.

•Avoidstoppingonahillwhenloaded.Ifyoumuststoponahill,avoidsuddenstarts,orrolling

backwardsandstoppingsuddenly.Failuretoheedthiswarningmaycausevehicletooverturn,

possiblyresultinginseverepersonalinjury.

•Reducespeedandavoidsuddenstopswhenbackingup.Failuretodosomaycausethevehicle

tooverturnoripoverbackwards.

Centerandsecurecargoasfarforwardaspossibleinthecargobed.Donotoverloadthevehicle.Seethefollowing

chartforvehiclecapacities.

HUV4213

Maximumpayloadcapacity

(Cargobedloadplusgrosstrailerweight)

800lb.(363kg)

Maximumvehiclecapacity

(Cargoload,passengers,plusgrosstrailerweight)

1200lb.(545kg)

Maximumgrossvehicleweight

(Fullyloadedvehicle,includingaccessories)

2381lb.(1080kg)

Maximumpassengercapacity

(Operatorandpassenger)

400lb.(181kg)

Trailertongueweight150lb.force(667N)

Maximumpayloadcapacitymustbereducedaccordinglywhenanyoptionoraccessoryisinstalledonthevehicle.See

followingNOTE.

NOTE:AstandardHUV4213vehiclewithacabaccessoryweighing235lb.(107kg)mustreduceitsmaximum

payloadcapacityby235lb.(107kg).

Page222008HUV4213-GandHUV4213-GXPOwner’sManual

TowingwiththeVehicle

TOWINGWITHTHEVEHICLE

WARNING

•Donottowavehicleortraileronpublicstreetsorhighways.

•Normalvehicleoperatingspeedshouldbereducedwhentowing.

•Extremecautionshouldbeusedwhentowing.

•Donotallowridersinthevehicleortrailerbeingtowed.

•Avoidsuddenstarts,suddenstops,andtightturnswhentowing.

•Avoidstoppingonahillwhentowing.Ifyoumuststoponahill,avoidsuddenstarts,orrolling

backwardsandstoppingsuddenly.Failuretoheedthiswarningmaycausevehicletooverturn,

possiblyresultinginseverepersonalinjury.

TowinganotherHUV4213vehicleoratrailercanhaveadverseeffectsonvehiclehandling.Beespeciallycautious

whentowingotherequipment.Seetheprecedingchartforvehiclecapacities.

Parkingthevehiclewithatraileronahillshouldbeavoided.Ifyoumustparkonahill,applybrakesandhave

someonechocktiresoftrailer.Brakesshouldbereleasedtoallowchockstoabsorbloadoftrailer.Aftertireshave

beenchocked,engageparkbrake.

TRANSPORTINGONATRAILER

WARNING

•Turnthefuelshut-offvalvetotheclosed(OFF)position(Figure14).

•Donotallowridersinthetrailerbeingtowed.

•Avoidsuddenstarts,suddenstops,andtightturnswhentowing.

•Avoidstoppingonahillwhentowing.Ifyoumuststoponahill,avoidsuddenstarts,orrolling

backwardsandstoppingsuddenly.Failuretoheedthiswarningcouldcausethevehicletooverturn,

possiblyresultinginseverepersonalinjury.

•Reducenormaldrivingspeedwhentransportingavehicleonatrailer.

•Foruseonpublicroads,thetrailermustmeetallfederal,state,andlocalrequirementssuchas

taillights,brakelights,etc.

•NevertowaHusqvarnavehiclebehindapassengervehicleortruckonapublicroadunlessitis

onanapprovedtrailer.

•Thevehicletobetransportedshouldbetiedsecurelytothetrailer,withtheForward/Reversehandlein

theNEUTRALposition,thekeyswitchintheOFFposition,andtheparkbrakermlyengaged.

•Becauseoftheaddedlengthofthetrailer,usecautionwhenmakingturns.

•Donottransportthevehicleonatrailerwithaloadinthevehiclecargobed.

•Removethevehiclewindshieldandsecuretheseatsbeforetransportingonatrailer.

Ifthevehiclemustbetransportedoverlongdistancesoronpublichighways,itshouldbetransportedonanapproved

trailerthathasanapprovedloadratingof2000lb.(908kg)pervehiclebeingtransported.

NOTE:Atwo-cartrailershouldberatedat2x2000lb.=4000lb.(2x908kg=1816kg).

2008HUV4213-GandHUV4213-GXPOwner’sManualPage23

Storage

STORAGE

SeeGeneralWarningsonpage9.

DANGER

•Donotattempttodrainfuelwhentheengineishotorwhileitisrunning.

•Besuretocleanupanyspilledgasolinebeforeoperatingthevehicle.

•Storefuelinanapprovedfuelcontaineronly.Storeinawell-ventilatedareaawayfromsparks,open

ames,heaters,orheatsources.

•Keepfueloutofthereachofchildren.

•Donotsiphonfuelfromthevehicle.

WARNING

•TurnthekeyswitchtotheOFFposition,removethekey,andleavetheForward/Reversehandlein

theNEUTRALpositionduringstorage.Thisistopreventunintentionallystartingthevehicleora

rehazard.

•Turnthefuelshut-offvalvetotheclosed(OFF)position(Figure14).

•Donotattempttochargefrozenbatteriesorbatterieswithbulgedcases.Discardthebattery.Frozen

batteriescanexplode.

CAUTION

•Batteriesinalowstateofchargewillfreezeatlowtemperatures.

PREPARINGTHEVEHICLEFOREXTENDEDSTORAGE

1.Unloadthevehiclesothattiresaresupportingonlytheweightofthevehicle.

2.Storevehicleinacool,dryplace.Thiswillminimizebatteryself-discharge.Ifthebatteryappearstobeweak,

haveitchargedbyatrainedtechnician.Useanautomotive-type12-voltbatterychargerratedat10ampsorless.

Checkelectrolytelevelafterchargingandadddistilledwaterifnecessary.

3.MakesurethekeyswitchisintheOFFpositionandtheForward/ReversehandleisintheNEUTRALposition.

Chockthewheels.

4.Accesstheenginecompartment.SeeWARNING“Forvehicleswithcargobeds...”inGeneralWarnings

onpage9.

5.Liftthefrontpassengersideseat.

6.Draincarburetorandsealthefueltank.

6.1.PlacetheForward/ReversehandleintheNEUTRALposition.Turnthefuelshut-offvalvetotheclosed

(OFF)position(Figure14)andruntheengineuntilfuelremaininginthecarburetorandfuellinesis

depletedandtheenginestalls.

6.2.Loosen,butdonotremove,thecarburetordrainscrewanddrainfuelremaininginbowlintoasmall,clean

container,thenpourthefuelfromthecontainerintovehiclefueltank.Tightenthecarburetordrainscrew.

6.3.Fillfueltanktoabout1inch(2.5cm)fromtopoffueltankand,followingmanufacturer’sdirections,adda

commerciallyavailablefuelstabilizer(suchasSta-Bil®).

6.4.Disconnectfuelventlinefromfueltankventnipple.

6.5.Plugthefueltankventnipplesothatitisairtight.Werecommendusingaslip-onvinylcap.

Page242008HUV4213-GandHUV4213-GXPOwner’sManual

Storage

7.Disconnectthebatterycables,negative(–)cablerst.SeeWARNING“Toavoidunintentionallystarting...”in

GeneralWarningsonpage9.

8.Batteriesshouldbecleanandfreeofcorrosion.Washtopsandterminalsofbatterieswithasolutionofbaking

sodaandwater(1cup(237mL)bakingsodaper1gallon(3.8L)ofwater).Rinsesolutionoffbatteries.Donot

allowthissolutiontoenterthebatteries.Besureterminalsaretight.Lettheterminalsdryandthencoatthemwith

BatteryTerminalProtectorSpray(P/N6030000-03).

1

2

3

1.FuelShut-offValve

2.Closed(OFF)

3.Open(ON)

NOTE:Whenselectingvalveposition,ensurethatitisfully

openedorfullyclosed.

449

Figure14FuelShut-offValve

9.Toprotecttheengine,removesparkplugandpour1/2ounce(14.2mL)ofSAE10weightoilintotheengine

throughthesparkplughole.Rotateenginecrankshaftbyhandseveraltimesandtheninstallthesparkplug

andtightento20ft-lb(27N·m).

10.Lowerthepassengersideseatandlowerthecargobed.

11.Adjusttirestorecommendedtirepressure.SeeVehicleSpecicationsonpage40.

12.Performsemiannualperiodiclubrication.SeePeriodicLubricationScheduleonpage29.

13.Thoroughlycleanfrontbody,rearbody,seats,cargobed,enginecompartment,andundersideofvehicle.

14.Donotengagetheparkbrake.Chockthewheelstopreventthevehiclefromrolling.

RETURNINGTHESTOREDVEHICLETOSERVICE

1.MakesurethekeyswitchisintheOFFpositionandtheForward/ReversehandleisintheNEUTRALposition.

Chockthewheels.

2.Raisethecargobedtoaccesstheengineandbattery.SeeWARNING“Forvehicleswithcargobeds...”in

GeneralWarningsonpage9.

3.Liftthefrontpassengerseat.

4.Restorefuelsystemtooperation(Figure24).

2008HUV4213-GandHUV4213-GXPOwner’sManualPage25

Maintenance

4.1.Removeplugfromfueltankvent.

4.2.Connectventtubetofueltankvent.

5.Connectbatterycables,positive(+)cablerst,andtightenterminalsto144in-lb(16N·m).Coatterminalswith

BatteryTerminalProtectorSpray(P/N6030000-03).

6.Completelyopenthefuelshut-offvalve(Figure14).Makesurethevalveisfullyopen.Apartiallyclosedfuel

shut-offvalvecombinedwiththeuseofthechokecanresultinafouledsparkplugandenginefailure.

7.PlacetheForward/ReversehandleintheNEUTRALposition.Cranktheengineuntilfuelispumpedintothe

carburetorandfuellinesandtheenginestarts.Turntheengineoff.SeefollowingNOTE.

NOTE:Duetotheoiladdedtotheengineinpreparationforstorage,enginemaysmokeexcessivelyforashort

timewhenitisrunforthersttimeafterstorage.

8.Lowerthepassengersideseatandlowerthecargobed.

9.Adjusttirestorecommendedtirepressure.SeeVehicleSpecicationsonpage40.

10.PerformthePre-OperationandDailySafetyChecklistonpage17.

MAINTENANCE

SeeGeneralWarningsonpage9.

Toensuretrouble-freevehicleperformance,followanestablishedpreventivemaintenanceprogram.Regular

maintenancecanpreventvehicledowntimeandexpensiverepairsthatresultfromneglect.UsethePre-Operationand

DailySafetyChecklistonpage17andthefollowingPeriodicServiceScheduleandPeriodicLubricationScheduleto

keepthevehicleinproperworkingcondition.

Anyvehiclenotfunctioningcorrectlyshouldnotbeuseduntilitisrepaired.Thiswillpreventfurtherdamagetothe

vehicleandavoidthepossibilityofinjuryduetounsafeconditions.

ContactyourlocalHusqvarnadealerforrepairs,semiannualandannualperiodicservice.

WARNING

•Onlytrainedtechniciansshouldserviceorrepairthevehicle.Anyonedoingevensimplerepairsor

serviceshouldhaveknowledgeandexperienceinelectricalandmechanicalrepair.Theappropriate

instructionsmustbeusedwhenperformingmaintenance,service,oraccessoryinstallation.

•Ifanyproblemsarefoundduringscheduledinspectionorservice,donotoperatevehicleuntilrepairs

aremade.Failuretomakenecessaryrepairscouldresultinre,propertydamage,severepersonal

injury,ordeath.

•Donotwearlooseclothingorjewelry,suchasrings,watches,chains,etc.,whenservicingvehicle.

•TurnthekeyswitchtotheOFFposition,removethekey,placetheForward/Reversehandleinthe

NEUTRALposition,andchockthewheelspriortoservicingthevehicle.

•Movingparts:Donotattempttoservicevehiclewhileengineisrunning.

•Hot!Donotattempttoservicehotengineorexhaustsystem.Failuretoheedthiswarningcould

resultinsevereburns.

•Forvehicleswithcargobeds,removeallcargobeforeraisingthebedorservicingthevehicle.If

thevehicleisequippedwithaproprod,ensurethatitissecurelyengaged.Donotclosebeduntil

allpersonsareclearofcargobedarea.Keephandsclearofallcrushareas.Donotdropcargobed;

lowergentlyandkeepentirebodyclear.Failuretoheedthiswarningcouldresultinseverepersonal

injuryordeath.

•Donotworkonvehiclepowertrainorundercargobedwhenitisloaded.

•Turnthefuelshut-offvalvetotheclosed(OFF)position(Figure14).

WARNINGCONTINUEDONNEXTPAGE

Page262008HUV4213-GandHUV4213-GXPOwner’sManual

PeriodicServiceSchedule

WARNING

•Tohelpavoidunintentionallystartingthevehicle:

–Disconnectbatterycables,negative(–)cablerst(Figure2).

–Disconnectthesparkplugwirefromthesparkplug.

•Ifwiresareremovedorreplacedmakesurewiringandwireharnessareproperlyroutedandsecured.

Failuretoproperlyrouteandsecurewiringcouldresultinvehiclemalfunction,propertydamage,

personalinjury,ordeath.

•Liftonlyoneendofthevehicleatatime.Useasuitableliftingdevice(chainhoistorhydraulicoor

jack)with1000lb.(454kg)minimumliftingcapacity.Donotuseliftingdevicetoholdvehicleinraised

position.Useapprovedjackstandsofproperweightcapacitytosupportthevehicleandchock

thewheelsthatremainontheoor.Whennotperformingatestorserviceprocedurethatrequires

movementofthewheels,lockthebrakes.

PERIODICSERVICESCHEDULE

SeeGeneralWarningsonpage9.

WARNING

•Service,repairs,andadjustmentsmustbemadeperinstructionsintheappropriatemaintenance

andservicemanual.

•Ifanyproblemsarefoundduringscheduledinspectionorservice,donotoperatevehicleuntilrepairs

aremade.Failuretomakenecessaryrepairscouldresultinre,propertydamage,severepersonal

injury,ordeath.

NOTE:Ifthevehicleisconstantlysubjectedtoheavyuseorsevereoperatingconditions,thesepreventive

maintenanceproceduresshouldbeperformedmoreoftenthanrecommendedinthePeriodicServiceand

LubricationSchedules.

BoththePeriodicServiceScheduleandthePeriodicLubricationSchedulemustbefollowedtokeepvehiclein

optimumoperatingcondition.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage27

PeriodicServiceSchedule

PERIODICSERVICESCHEDULE

REGULARINTERVALSERVICE

Pre-OperationandDailySafetyChecklistSeePre-OperationandDailySafety

Checklistonpage17.

Dailyservicebyowner

PerformanceInspectionSeePerformanceInspectiononpage17.

Checkengineoillevel;changeasrequired.

SeePeriodicLubricationScheduleonpage

29.

EngineCheckenginecoolingairintake;visually

inspectunshroudedareaaroundengine

exhaustforgrassanddebrisandcleanif

necessary.

TiresCheckairpressureandadjustifnecessary.

SeeVehicleSpecicationsonpage40.

Monthlyservicebyownerortrained

technician

GeneralvehicleWashenginecompartmentandundersideof

vehicle.Donotwashenginewhenhot.

Battery

Cleanterminalsandwashdirtfromcasing;

checkelectrolytelevel.Adddistilledwaterif

necessary.Seepage36.

Frontwheelalignmentandtoe-in

Checkandadjustifnecessary.SeeSteering

andFrontSuspensionSectioninthe

appropriatemaintenanceandservice

manual.

ElectricalwiringandconnectionsCheckfortightnessanddamage

Inspectmastercylinder,wheelcylinders,brake

lines,andhosesfordamageorleakage.

Checkparkbrakecablesfordamage;replace

ifnecessary.

Semiannualservicebytrainedtechnician

only(orevery50hoursofoperation,

whichevercomesrst)

Brakesystem

Checkbrakeshoesanddrums;replaceif

necessary.SeeWheelBrakeAssemblies

Sectionintheappropriatemaintenance

andservicemanual.

Checkforleaksaroundgaskets,llplugs,etc.

EngineInspect,cleanandgapsparkplug;replaceif

necessary.

Checkairlterelement;cleanorreplaceif

necessary.

Engineairintakesystem

Checkclampsfortightness;checkhosefor

cracks.

Annualservicebytrainedtechnicianonly

(orevery100hoursofoperation,whichever

comesrst)

GeneralvehicleCheckforloosehardwareandtightenif

necessary.

Twoyearservicebytrainedtechnicianonly

(orevery200hoursofoperation,whichever

comesrst)

FuelltersReplace.Disposeofusedltersproperly.See

EngineOilAndFilterChangeonpage31.

Page282008HUV4213-GandHUV4213-GXPOwner’sManual

PeriodicLubricationSchedule

PERIODICLUBRICATIONSCHEDULE

PERIODICLUBRICATIONSCHEDULE

REGULARINTERVALSERVICELUBRICATION

POINTSRECOMMENDEDLUBRICANT

Brakepedalshaftbearings

1

DryMolyLube(P/N6030000-01)

Acceleratorpushrodpivots,mounts,

andshiftercablepivots

2

DryMolyLube(P/N6030000-01)

Semiannuallybyowneror

trainedtechnician(orevery50

hoursofoperation,whichever

comesrst)Frontsuspension(2ttings)ChassisLube(EPNLGIGrade2)

Check/lltransaxletopluglevel

29oz.(.85liters)80-90Wt.API

ClassGL-3or80-90Wt.AGMAClass

5EPgearlubricant

Annuallybytrainedtechnician

only(orevery100hoursof

operation,whichevercomes

rst)Inspectfrontwheelbearings(Repack

asnecessary)ChassisLube(EPNLGIGrade2)

Firstchange100hours–

additionalchangeevery200

hoursofoperationorannually,

whichevercomesrst

Changeengineoilandoillter

32oz.(0.95liter)withoutlter;38

oz.(1.12liters)withlter.SeeOil

Viscosityonpage34.

2

4

1

6

2

2

3

5

3

5

2

2

1

167

Figure15LubricationPoints

2008HUV4213-GandHUV4213-GXPOwner’sManualPage29

MasterCylinder

MASTERCYLINDER

1

2

3

1.FullLevel2.SafeLevel3.LowLevel

168

Figure16BrakeFluidReservoir

Themastercylinderislocatedunderthepassengerseattowardthecenterofthevehicle(Figure16).Raiseor

removetheseattocheckthebrakeuidlevel.

Whencheckingthebrakeuid,alsoinspectthefollowing:

•Thepresenceofbrakeuidontheexteriorsurfaceofthemastercylinderindicatesaleak.

•Theventholesinthereservoircovershouldbecleanandopen.

•Thereservoirdiaphragmshouldnothaveholesorotherdamage.

BRAKEFLUID

Brakeuidlevelshouldbewithin1/4-inch(6mm)fromtopofreservoir(Figure16).Also,brakeuidshouldbeclean

withnoresidueinbottomofreservoirorotherevidenceofcontamination.

CAUTION

•UseonlyDOT–5(silicone)brakeuid.Useofanyothertypebrakeuidisnotrecommended.

Page302008HUV4213-GandHUV4213-GXPOwner’sManual

EngineOil

ENGINEOIL

Eventhoughthelowoilwarninglightontheinstrumentpanelshouldilluminateifoilbecomeslow,theengineoillevel

shouldbecheckedmonthly.Thevehicleshouldbeonalevelsurfacewhencheckingoil.Donotoverllwithoil.

ENGINEOILLEVELCHECK

1.Removetheoilleveldipstickfromtheoilllertubeandwipeoilfromdipstick(Figure17).Seefollowing

CAUTION.

CAUTION

•Donotremovedipstickwhileengineisrunning.

2.Checkoilbyfullyinsertingthedipstickintotheoilllertubeandimmediatelyremovingit.

3.Iftheoillevelisatorbelowthelowlevelmarkonthedipstickgauge,addoiluntilthelevelisbetweenlow

andfulllevels(safelevel).

1

3

2

1.FullLevel2.SafeLevel3.LowLevel

169

Figure17EngineOilLevelCheck

ENGINEOILANDFILTERCHANGE

Engineoilandoilltershouldbechangedaftertherst100hoursofoperation.Afterthat,theyshouldbechanged

every200hoursofoperationorannually,whichevercomesrst.

1.TurnthekeyswitchtotheOFFposition,thenremovethekey.PlacetheForward/Reversehandleinthe

NEUTRALposition.Chockthefrontwheels.

2.Accesstheenginecompartment.SeefollowingWARNING.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage31

EngineOil

WARNING

•Forvehicleswithcargobeds,removeallcargobeforeraisingthebedorservicingthevehicle.Ifthe

vehicleisequippedwithaproprod,ensurethatitissecurelyengagedwhilebedisraised.Donot

closethebeduntilallpersonsareclearofcargobedarea.Keephandsclearofallcrushareas.Do

notdropcargobed;lowergentlyandkeepentirebodyclear.Failuretoheedthiswarningcould

resultinseverepersonalinjuryordeath.

3.Disconnectthebatterycables,negative(–)cablerst.SeeWARNING“Toavoidunintentionallystarting...”in

GeneralWarningsonpage9.

4.Positionapandesignedforoilchangesunderthefrontdrainplug(Figure18).

5.Usea14mmsocketorwrenchtoremovethedrainplug,turningitcounterclockwise,andallowtheengine

oiltodrainintothepan.

WARNING

•Donotattempttochangeengineoilwhentheengineishotorevenwarm.Engineoilcancause

skinburns.

•Wearsafetyglassesorapprovedeyeprotectionwhenservicingthevehicle.Wearrubbergloveswhen

handlingoildrainplug,oillter,andoildrainpan.

6.Cleantheoildrainplugthreadswithsolventtoremoveoilandoilresidue.Makesurethatthecompression

washerremainsonthedrainplug.

7.Usea14mmsocketorwrenchandreplacethefrontoildrainplug,turningitclockwise,andtightento18ft-lb

(24.4N·m).

1

3

2

1.Drainpan2.Drainplug3.Oillter

25

Figure18EngineOilDrainPlugandPan

8.Placeaoorjackundertherearreceiverhitchwherethehitchandbodyframearefastened.Liftthevehiclebody

slightly,allowingthefrontoftheenginetotiltslightlydownward.Thiswillallowtheoilltermoreclearanceunder

theelectricalcomponentbox(Figure19).

9.Relocatetheoildrainpantoapositionundertheengineoillter(Figure20).

Page322008HUV4213-GandHUV4213-GXPOwner’sManual

EngineOil

10.Removetheengineoillter,turningitcounterclockwise,allowingtheresidualoilinthelterportandlterto

drainintotheoildrainpan.SeefollowingNOTE

NOTE:Anoildripguardcanbeusedtopreventexcessoilfromdrippingintotheenginebaseplace.Useanempty

quart(oneliter)containerandcutthebottomoffatanangle,thenslidetheopenareaofthecontainerupand

undertheoillterpriortoremoving.Positiontheportoftheplasticcontainersooilwillbedirectedintotheoil

pan(Figure20,Page33).Adripguardcanbemadebyfoldingapieceofcardboard,thinmetal,orplastic

undertheoillterformingachanneltodirectthelterportoilintothedrainpan.

Disposeofusedoilaccordingtotheenvironmentallawsandregulationsforyourarea.

11.Useaclean,lint-freeragandwipetheoilltermountingbracketsurfacecleanwheretheoilltergasketseats.

12.Installanewoillter(P/N6030000-06)ontotheengineoillterport.ApplyalightcoatofwhitelithiumNLGI

Number2grease(DowCorning®BR2-Plusorequivalent)ornewengineoiltotherubbersealaroundtheoutside

surfaceofthelterbeforeattachingittotheoillterport(Figure21).Thiswillhelpsealtheltertotheoillter

mountingbracket.SeefollowingNOTE.

NOTE:UseonlyHusqvarnaoillters(P/N6030000-06)designedforthisengine.

1

3

2

1.SnubberBracket2.Snubber3.CompressDown

171

Figure19CompressSnubberDownward

26

Figure20RemoveEngineOilFilter

2008HUV4213-GandHUV4213-GXPOwner’sManualPage33

EngineOil

27

Figure21CoatRubberSeal

172

Figure22AddEngineOil

13.Tightentheoillterbyhanduntiltight.Donotuseabandwrenchorchannellockpliertotighten.

14.Lowerthevehicleandremovetheoorjackfromundertherearofthevehicle.

15.Removethedipstickandaddengineoilintothedipstickport.Useafunnelorpourspouttodirecttheoilintothe

dipstickport(Figure22).Withlterchange,theenginerequires38ounces(1.12liters)ofoilperchange.Referto

oilviscosityguidelinesforselectionofoilgrade(Figure23).Replacethedipstick.

16.Connectthebatterycables,positive(+)cablerst,andtightenterminalsto144in-lb(16N·m).Coatterminalswith

BatteryTerminalProtectorSpray(P/N6030000-03).

17.Lowerthecargobed.SeeWARNING“Forvehicleswithcargobeds...”inGeneralWarningsonpage9.

18.WiththeForward/ReversehandleintheNEUTRALposition,startandruntheengineforafewminutes.Observe

boththedrainplugandtheoillterfromunderthevehicleandwatchforoilleaks.Ifleaksappear,beginwithstep

1andrepeattheappropriatestepforeitherorbothitemstocorrecttheproblem.

19.Removethedipstickandchecktheengineoilasanalstep.Replacethedipstick.

OILVISCOSITY

Choosetheviscosityaccordingtothetemperatureasindicatedbytheoilviscositychart(Figure23).

SAE 5 W-30

SAE 10W-30/ SAE 10W-40

SAE 30

SAE 40

213

Figure23OilViscosityChart

Page342008HUV4213-GandHUV4213-GXPOwner’sManual

FuelingInstructions

NOTE:Usingmulti-gradeoils(5W-20,10W-30,and10W-40)willincreaseoilconsumption.Checkoillevelmore

frequentlywhenusingthem.

FUELINGINSTRUCTIONS

SeeGeneralWarningsonpage9.

DANGER

•TurnthekeyswitchtotheOFFpositionbeforefueling.

•Donotpourfuelintothefueltankwhentheengineishotorwhileitisrunning.

•Tohelpavoidelectricarccausedbystaticelectricity,thefuelstorage/pumpingdevicemustbe

grounded.Ifthepumpisnotgrounded,thevehiclemustbegroundedtothepumpbeforeandduring

thefuelingoperation.

•Ifvehiclehasanall-weatherenclosureinstalled,besurethefueltankisproperlyventedasshown

(Figure24).

•Tohelpavoidthepossibilityofre,cleanupanyspilledfuelbeforeoperatingthevehicle.

CAUTION

•Toallowforexpansion,donotllhigherthan2.54cm(oneinch)fromthetopofthefueltank.Avoid

spillingfuel.

1.Removethepassengerseat.

2.Removefuelcapandlltankwithfreshunleadedgasolineonly.SeeprecedingDANGERandCAUTION.

NOTE:Wheneverpossible,avoidusingoxygenatedfuelsandfuelsthatareblendedwithalcohol.Vehiclestobe

storedforextendedperiodsshouldbepreparedforstorageasinstructed.SeePreparingtheVehiclefor

ExtendedStorageonpage24.

3.Replacefuelcapontank.Ensurecapistightenedsecurely.

4.Cleananyspilledfuelfromthetanktopandaroundthetankarea.

5.Replacepassengerseat.

WARNING

•Makesureseathingesandlatcharesecurelyengagedbeforeoperatingvehicle.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage35

Battery

1

4

5

3

2

1.VentTube2.ToCarburetor3.Vent4.FuelShut-offValve

5.FuelTank

173

Figure24FuelTank

BATTERY

SeeGeneralWarningsonpage9.

DANGER

•Battery–Explosivegases!Donotsmoke.Keepsparksandamesawayfromthevehicleandservice

area.Ventilatewhenchargingoroperatingvehicleinanenclosedarea.Wearafullfaceshieldand

rubbergloveswhenworkingonornearbatteries.

•Tools,wiresandmetalobjectscancausesparkswhenshortedacrossabattery.Followallinstructions

carefullywhenworkingwithbatteries.

•Chargebatteryinawell-ventilatedareaonly.

•Battery–Poison!Containsacid!Causessevereburns.Avoidcontactwithskin,eyesorclothing.

Antidotes:

–External:Flushwithwater.Callaphysicianimmediately.

–Internal:Drinklargequantitiesofmilkorwaterfollowedwithmilkofmagnesiaorvegetable

oil.Callaphysicianimmediately.

–Eyes:Flushwithwaterfor15minutes.Callaphysicianimmediately.

WARNING

•Donotjump-startadeadbatteryusinganotherbatteryandjumpercables.

Thebatteryinthevehicleisa12-volt,low-maintenancebatterythatrequiresinfrequentchecks(Figure25).Electrolyte

levelshouldbecheckedsemiannually.

1.TurnthekeyswitchtotheOFFpositionandremovethekey.PlacetheForward/ReversehandleintheNEUTRAL

position.Chockthewheels.

Page362008HUV4213-GandHUV4213-GXPOwner’sManual

Battery

2.Accesstheenginecompartment.SeeWARNING“Forvehicleswithcargobeds...”inGeneralWarnings

onpage9.

3.Tiltthebedandensurethattheproprodisproperlyengaged.

4.Disconnectthebatterycables,negative(–)cablerst.SeeWARNING“Toavoidunintentionallystarting...”in

GeneralWarningsonpage9.

5.Useaatbladescrewdriver,andcarefullyremovethebatterycellcapsfromthebattery(Figure25).See

followingWARNING.

WARNING

•Wearsafetyglassesorapprovedeyeprotectionwhenservicingthevehicle.Wearafullfaceshieldand

rubbergloveswhenworkingonornearbatteries.

6.Carefullychecktheelectrolytelevelandadddistilledwaterifnecessary.Donotllabovedesignatedllline.

Replacebatterycellcaps.

7.Cleanbothbatteryterminalswithasolutionofbakingsodaandwater(1cup(237mL)bakingsodapergallon(3.8

L)ofwater).Rinsethoroughly.Donotallowthissolutiontoenterthebattery.Tightenbatteryterminalsto144

in-lb(16N·m).LettheterminalsdryandthenspraythemwithBatteryT erminalProtectorSpray(P/N60300

00-03).SeefollowingCAUTION.

WARNING

•Ifbatterywireterminalsaredamagedorcorroded,replaceorcleanthemasnecessary.Failureto

dosomaycausethemtooverheatduringoperationandcouldresultinre,propertydamage,or

personalinjury.

1

3

2

1.LevelIndicator2.Cap3.Plates

Electrolytelevelatleast1/2inch(13MM)aboveplatesortolevel

indicator.

180

Figure25Battery

22

Figure26BatteryElectrolyteLevel

Besurebatteryhold-downclampisproperlytightened.Tightento144in-Ib(16N·m).Alooseclampmayallowthe

batterytobecomedamagedfromvibrationorjarring.

Ifbatteryappearsweak,haveitchargedbyatrainedtechnician.Thebatteryshouldneverbeleftdischargedany

longerthanabsolutelynecessary(donotleavedischargedovernight).

2008HUV4213-GandHUV4213-GXPOwner’sManualPage37

CleaningtheVehicle

CLEANINGTHEVEHICLE

EachvehicleisequippedwithanABS/DRacrylicfrontbodyandanall-aluminumrearbody.TheHUV4213hasa

powder-coatedsteelcargobed.Usecommercialautomotivecleaningsolutionswithaspongeorsoftclothfornormal

cleaning.Agardenhoseatnormalresidentialwaterpressureisadequate.T oremoveoxidationordiscolorationfrom

aluminum,useacommerciallyavailablealuminumcleanerpasteandnegrade(No.00)steelwool.

Husqvarnadoesnotrecommendanytypeofpressurewashingorsteamcleaning.Suchaprocesswillexpose

electricalcomponentstomoisture.Moistureenteringelectricalcomponentscanresultinwaterdamageand

subsequentcomponentfailure.

Usenon-abrasivewaxproducts.Batteryacid,fertilizers,tars,asphalt,creosote,paint,orchewinggumshouldbe

removedimmediatelytopreventpossiblestains.

ThefrontbodyismadeofanABS/DRacryliccapmaterialsimilartothematerialusedtomanufacturehottubsand

shower/tubunits.Cleaningandrepairtechniquesforthefrontbodyarethesameasthoseusedonconventional

acrylicsheet.UsecleaningandpolishingproductsavailableatanyhardwarestorewhereABS/DRacrylic(hottubs

andshower/tubunits)aresold.

Theseatsofthevehiclewilllastlongerwithpropercleaning.Useasolutionof10%liquidsoapandwarmwaterapplied

withasoftcloth.Forimbeddeddirt,asoftbristlebrushmaybeused.Forheavysoiling,difcultstains,orscratches,

blemishes,orotherbodydamage,seetheappropriatemaintenanceandservicemanual.SeefollowingNOTE.

NOTE:Disposeofwastewaterproperly.

ACCESSORIES

ThereisacompletelineofaccessoryequipmentavailablefromHusqvarnaandourdealers/distributors.Youcanobtain

thenameandphonenumberofyourclosestHusqvarnacontactbyvisitingourwebsiteatwww.usa.husqvarna.com.

Careshouldbetakenthattheseaccessoriesareproperlyinstalledbytrainedtechnicians,andthattheyareusedinthe

mannerforwhichtheyweredesigned.SeefollowingWARNING.

WARNING

•Customcabassemblies,canopytops,weatherproofenclosures,andwindshieldswillnotprotect

occupantsfromyingobjects.

•Ifthevehicleisequippedwithanelectricpoweredbedlift,removethebedbeforeservicingthe

bedliftsystem.

ELECTRICWINCHACCESSORY

Ifyourvehicleisequippedwithanelectricwinch,readandfollowallmanufacturersafetywarningsandinstructionsin

thewinchoperatormanual,aswellasthefollowingWARNINGandCAUTIONstatements.Makesureawinchwarning

decalisafxedtothevehicleontheseatsupportpanelnexttothereceptaclefortheremoteoperationswitch.See

SafetyDecalandFeatureIdenticationonpage4.

ThewinchkitavailablefromHusqvarnaincludesaremoteoperationswitch,whichenablestheoperatortomoveaway

fromthevehicleandcable.SeefollowingWARNINGandCAUTION.

WARNING

•Beforebeginningawinchoperation:

–TurnthekeyswitchtotheOFFposition,putForward/ReversehandleintheNEUTRALposition,

andengagetheparkbrake.

–Donotusewinchwhilepersonsareseatedonthevehicle.

•Standtothesideandawayfromthevehicletooperatewinch.

Page382008HUV4213-GandHUV4213-GXPOwner’sManual

SubsequentOwnerRegistration

CAUTION

•Useofthewinchforanextendedperiodoftimecoulddischargethebattery.Keepwinchoperations

asshortaspossible,anddrivethevehicleforseveralminutesafterthewinchoperationtorecharge

thebattery.

SUBSEQUENTOWNERREGISTRATION

Intheeventavehicleisboughtasausedvehicle,westronglyurgethenewownertoregisterthevehiclewith

Husqvarna.Thiswillenableustocontactyouiftheneedarises.Pleasesendyourname,address,andserialnumber

ofthevehicletoHusqvarna,7349StatesvilleRd.,Charlotte,NC28269,Attention:VehicleRegistration.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage39

VehicleSpecications

VEHICLESPECIFICATIONS

SPECIFICATIONSHUV4213-GXPHUV4213-G

POWERSOURCE

Engine:4-cycleOHV,400cc,13.0maximumHP@3600RPM(perSAEJ1940/1349),

single-cylinder,air-cooled,withpressurelubricationsystem•

Fuelsystem:Side-draftcarburetorwithoatbowl,xedjets,fuellters,andimpulsefuel

pump•

Governor:Automaticground-speedsensing,internallygearedinunitizedtransaxle•

Ignition:TransistorelectronicignitionwithelectronicRPMlimiter•

Unitizedtransaxle:Fullysynchronizedforwardandreversewithneutral(14.9:1forward,

20.5:1reverse)anddifferentiallockfeature•

Electricalsystem:12-volt,500ccaat0°F(-17.8°C),650at32°F(0°C).105-minute

reservecapacityand35-ampchargingcapacity•

Torqueconverter:Automatic,variable-speed,drytype•

STEERING/SUSPENSION/BRAKES

Steering:Self-adjustingrackandpinion,Ackerman•

Suspension:

Front:IndependentA-armswithcoil-overshocks

Rear:Semi-independentsuspensionwithmulti-leafspringsanddualhydraulicshocks

•

Brakes:Hydraulicbrakesystem–self-adjustingdrumbrakesoneachwheelwithseparate

hand-operatedparkbrake•

BODY/CHASSIS

Frame/Chassis:TwinI-Beamweldedaluminum•

Sideandrearbody:Allaluminum•

Cargobed:Powder-coatedsteel•

Frontbody:ABS/DRacryliccap•

Tires:23x10.50–12tubeless,4-plyratedloadrange,frontandrear•

DIMENSIONS/WEIGHT

Overalllength(boxbedconguration)123.4in.(313.4cm)

Overallwidth54in.(137cm)

Overallheight(atlightbar)75in.(187.5cm)

Wheelbase80in.(203cm)

Groundclearance:

underdifferentialunderfootplatform

6.6in.(17cm)11.4in.(29cm)

Frontwheeltread43in.(109cm)

Rearwheeltread44.5in.(111cm)

Weight(dry):

withall-terraintreadwithturftread

1106lb.(493.4kg)

1066lb.(477.2kg)

1063.5lb.(482.4kg)

1027.8lb.(466.2kg)

Forwardspeed17-19mph(27-31km/h)

GovernedRPM:FE400Engine3850(±30)RPM

Page402008HUV4213-GandHUV4213-GXPOwner’sManual

VehicleSpecications

SPECIFICATIONSHUV4213-GXPHUV4213-G

Curbclearancecircle(diameter)24ft.1in.(734cm)

Turningradius(perSAEJ695)139.6in.(355cm)

Intersectingaisleclearance112.2in(285cm)

Floorboardheight17in.(43cm)

Seatheight35in.(89cm)

Loadbedheight31.1in.(79cm)

Loadbedsize(boxbedinsidedimensions)

48.0x49.8x10.9in.

(121.4x126.4x27.6cm)

(15.3cubicfeet)

Loadbedsize(atbeddimensions)

46.9x48.3in.

(119x123cm)

Vehicleratedcapacity(levelsurfaceonly)1200lb.(544kg)

Bedloadcapacity(levelsurfaceonly)800lb.(363kg)

Standardseatingcapacity2

LIQUIDCAPACITIES

Enginecrankcasewithoutlter32oz.(0.95liters)

Enginecrankcasewithlter38oz.(1.12liters)

Unitizedtransaxle29oz.(0.85liters)

Mastercylinder8oz.(240ml)

Fueltank7gallons(26.5liters)

TIREPRESSURE

All-terraintread(standard)

Front:7-11psi(0.48-0.76Bars)

Rear:14-18psi(0.97-1.24Bars)

Turftread(optional)

Front:12-16psi(0.83-1.10Bars)

Rear:16-20psi(1.10-1.38Bars)

TraksMaxIItread(optional)

Front:14-16psi(0.97-1.10Bars)

Rear:18-20psi(1.24-1.38Bars)

2008HUV4213-GandHUV4213-GXPOwner’sManualPage41

Warranties

WARRANTIES

HUSQVARNA®LIMITEDTWOYEARWARRANTYFOR2008TRANSPORTATIONAND

UTILITYVEHICLES

1.WARRANTY:

Husqvarna,INC.,("Husqvarna")herebywarrantstotheOriginalRetailPurchaserthatitsnew2008Model

TransportationandUtilityVehiclespurchasedfromHusqvarnaoranauthorizeddealershallbefreefromdefects

inmaterialandworkmanshipundernormaluseandserviceasatransportationorutilityvehiclefortheperiods

statedbelow,subjecttotheprovisions,limitationsandexclusionscontainedinthislimitedwarranty.

LIMITEDTWOYEAR/2000HOURWARRANTY:Theengineassembly,unitizedtransaxleassembly(gasoline

vehicle),starter/generator(gasolinevehicle),motor,transaxleassembly(electricvehicle),mainframeassembly,

boxbedhydraulicdumpkit,CustomCabassemblyanddoors,andDrivingRangeProtectiveEnclosureare

warrantedwithrespecttopartsandlaboragainstdefectsinmaterialandworkmanshipforaperiodoftwoyearsor

2000hoursofoperation,whicheverrstoccurs,fromthedateofpurchase.

LIMITEDONEYEAR/1000HOURWARRANTY:Allremainingcomponentsofthevehiclenotspecied

otherwise,thePortableRefreshmentCenter,andallotheroriginalequipmentoptionsandaccessoriessupplied

byHusqvarnaarewarrantedwithrespecttopartsandlaboragainstdefectsinmaterialandworkmanshipfora

periodofoneyearor1000hoursofoperation,whicheverrstoccurs,fromthedateofpurchase.

Thislimitedwarrantycoversmaterial,workmanshipandrepairlaborcostastothoseitemsspecicallylisted

abovefortheperiodsspecied.SuchrepairlaborshallbeperformedonlybyHusqvarna,itsauthorizeddealers,

oraserviceagencyapprovedbyHusqvarna.

IFTHEWARRANTYREGISTRATIONFORMISNOTCOMPLETEDANDRETURNEDTOHUSQVARNA

ATTHETIMEOFTHEORIGINALRETAILSALE,PURCHASERMUSTPROVIDEPROOFOFDATEOF

PURCHASEWITHANYWARRANTYCLAIM.

2.EXCLUSIONS:

ExcludedfromanyHusqvarnawarrantyareallfuses,lters,decals(exceptsafetydecals),sparkplugs,light

bulbs,lubricants,trimpieces,seats,routinewearitemssuchasthechargerplugandreceptacle,brakeshoes,

belts,brushes,bushings,drivebuttons,enginemounts,matsandpads,maintenanceadjustments,cosmetic

deterioration,anditemswhichdeteriorateorfailduetoexposureorordinarywearandtear.Batteries,battery

charger,onboardcomputer,andsolid-statespeedcontrollerarecoveredunderseparateHusqvarnawarranties.

AlsoexcludedfromanyHusqvarnawarrantyisdamagetoavehicleorcomponentresultingfromacauseother

thanadefectincludingunreasonableorunintendedstrainoruse,improperinstallationofaccessories,installation

ofpartsoraccessoriesthatarenotoriginalequipment,overloading,accident,alteration,abuseorneglect.

Transportationexpensesforwarrantyservicesarealsoexcludedfromthiswarranty.

3.VOIDINGOFWARRANTY:

THISANDANYOTHERWARRANTYSHALLBEVOIDIFTHEVEHICLEISABUSEDORUSEDINAN

UNINTENDEDMANNERORSHOWSINDICATIONSTHATITHASBEENALTEREDINANYWAY ,INCLUDING,

BUTNOTLIMITEDTO,MODIFICATIONOFTHESPEEDGOVERNOR,BRAKINGSYSTEM,STEERING,

TRANSAXLE,OROTHEROPERATINGSYSTEMSOFTHEVEHICLETOCAUSEITTOPERFORMOUTSIDE

HUSQVARNASPECIFICATIONS.THEWARRANTYISLIKEWISEVOIDIFTHEVEHICLEINVOLVEDSHOWS

INDICATIONSTHATREASONABLEORNECESSARYMAINTENANCEASOUTLINEDINTHEOWNER’S

MANUALANDMAINTENANCEANDSERVICEMANUALWASNOTPERFORMEDATTHETIMEANDIN

THEMANNERSPECIFIEDINSUCHMANUALS.

4.SOLEREMEDY:

Husqvarna’sliabilityunderthislimitedwarranty,orinanyactionwhetherbaseduponwarranty,contract,

negligence,strictproductliabilityorotherwise,shallbetherepairorreplacement,atHusqvarna’soption,ofthe

vehicleorcomponentthereofthatHusqvarnadeemstobedefective.Replacementshallmeanfurnishing,during

theapplicablelimitedwarrantyperiod,anewvehicleorfactory-reconditionedvehicleorcomponentthereofthatis

identicalorreasonablyequivalenttothewarrantedproductorcomponentatnocosttothepurchaser.Repairshall

meanremedyingadefectinthevehicleorcomponentthereofatnocosttothepurchaserduringtheapplicable

limitedwarrantyperiod.IfHusqvarnaelectstorepairthevehicle,itmayprovidefactory-reconditionedpartsor

components.AllpartsandcomponentsreplacedunderwarrantyshallbecomethepropertyofHusqvarna.

Page422008HUV4213-GandHUV4213-GXPOwner’sManual

Warranties

5.HOWTOMAKEAWARRANTYCLAIM:

Tomakeawarrantyclaimunderthislimitedwarranty,youmustpresentthevehicleordefectivecomponenttoan

authorizedHusqvarnadealer.

6.DISCLAIMER:

THISLIMITEDWARRANTYISEXCLUSIVE.HUSQVARNAMAKESNOOTHERWARRANTYOFANY

KIND,EXPRESSEDORIMPLIED.ANYIMPLIEDWARRANTIESOFMERCHANTABILITYORFITNESS

FORAPARTICULARPURPOSEWHICHEXCEEDTHEOBLIGATIONSORTIMELIMITSSTATEDINTHIS

WARRANTYAREHEREBYDISCLAIMEDBYHUSQVARNAANDEXCLUDEDFROMTHISWARRANTY.THE

PURCHASERANDHUSQVARNAEXPRESSLYAGREETHATTHEREMEDYOFTHEREPLACEMENTOR

REPAIROFTHEDEFECTIVEVEHICLEORCOMPONENTTHEREOFISTHESOLEREMEDYOFTHE

PURCHASER.HUSQVARNAMAKESNOOTHERREPRESENTATIONORWARRANTYOFANYKIND,AND

NOREPRESENTATIVE,EMPLOYEE,ORDEALEROFHUSQVARNAHASTHEAUTHORITYTOMAKEOR

IMPLYANYREPRESENTATION,PROMISEORAGREEMENT,WHICHINANYWAYVARIESTHETERMS

OFTHISWARRANTY .

7.NOCONSEQUENTIALDAMAGES:

INNOEVENTSHALLHUSQVARNABELIABLEFORANYINCIDENTALORCONSEQUENTIALDAMAGES

INCLUDING,BUTNOTLIMITEDTO,LOSSRELATEDTOPROPERTYOTHERTHANTHEVEHICLE,LOSS

OFUSE,LOSSOFTIME,INCONVENIENCE,ORANYOTHERECONOMICLOSS.

Somestatesallowneitherlimitationonthedurationofanimpliedwarrantynorexclusionsorlimitationofincidental

orconsequentialdamages.Therefore,theabovelimitationsorexclusionsmaynotapplytoyou.

Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrights,whichvaryfromstatetostate.

8.INFORMATION:

ForfurtherinformationcontactWARRANTYSERVICES,HUSQVARNAFOREST&GARDEN,

7349ST A TESVILLEROAD,CHARLOTTE,NC28269

9.WARNING:

Anymodicationoralterationofanyvehiclebeyondfactoryspecications,includingthosethataffecttheweight

distribution,stability,orspeedofthevehicle,cancauseseriouspersonalinjuryordeath.

2008HUV4213-GandHUV4213-GXPOwner’sManualPage43

Warranties

CALIFORNIAEMISSIONCONTROLWARRANTYSTATEMENT

YournewHusqvarna("Husqvarna")vehicleenginecomplieswithboththeU.S.EPAandStateofCaliforniaemission

regulations.However,theuseofgasolinepoweredgolfcarsinareasofCaliforniathatdonotattainthefederalozone

standardsisillegal.PleaserefertotheAirResourcesBoardinformationathttp://www.arb.ca.gov/enf/enf.htmfor

compliance.

YOURWARRANTYRIGHTSANDOBLIGATIONS:

TheCaliforniaAirResourcesBoard("CARB")andHusqvarnaarepleasedtoexplaintheemissioncontrolsystem

warrantyonyour2008vehicleengine.InCalifornia,newsmalloff-roadengines(SORE)mustbedesigned,builtand

equippedtomeettheState’sstringentanti-smogstandards.Husqvarnamustwarranttheemissioncontrolsystem

onthevehicleenginefortheperiodsoftimelistedbelowprovidedtherehasbeennoabuse,neglectorimproper

maintenanceofyoursmalloff-roadengine.Youremissioncontrolsystemmayincludepartssuchasthecarburetoror

fuel-injectionsystem,theignitionsystem,andcatalyticconverter.Alsoincludedmaybehoses,belts,connectorsand

otheremission-relatedassemblies.Whereawarrantableconditionexists,Husqvarnawillrepairyourvehicleengine

atnocosttoyouincludingdiagnosis,partsandlabor.

MANUFACTURER’SWARRANTYCOVERAGE:

Thisemissioncontrolsystemiswarrantedfortwoyears.Ifanyemission-relatedpartonyourequipmentisdefective,

thepartwillberepairedorreplacedbyHusqvarna.

OWNER’SWARRANTYRESPONSIBILITIES:

-Asthevehicleengineowner,youareresponsiblefortheperformanceoftherequiredmaintenancelistedinyour

owner’smanual.Husqvarnarecommendsthatyouretainallreceiptscoveringmaintenanceonyourvehicleengine,but

Husqvarnacannotdenywarrantysolelyforthelackofreceiptsorforyourfailuretoensuretheperformanceofall

scheduledmaintenance.

-Asthevehicleengineowner,youshouldhoweverbeawarethatHusqvarnamaydenyyouwarrantycoverageif

vehicleengineoraparthasfailedduetoabuse,neglect,impropermaintenanceorunapprovedmodications.

-YouareresponsibleforpresentingvehicleenginetoaHusqvarnadistributioncenterassoonasaproblemexists.

Thewarrantyrepairsshouldbecompletedinareasonableamountoftime,nottoexceed30days.

-Ifyouhaveanyquestionsregardingyourwarrantyrightsandresponsibilities,youshouldcontactWARRANTY

SERVICES,HUSQVARNAFOREST&GARDEN,

7349 ST A TESVILLEROAD,CHARLOTTE,NC28269.

HUSQVARNAEXPLANATIONOFEMISSIONCONTROLWARRANTY:

1.WARRANTY:

HusqvarnawarrantstotheultimatepurchaserandeachsubsequentpurchaserthattheSOREorequipmentis

designed,builtandequippedsoastoconformwithallapplicableregulations;andfreefromdefectsinmaterialsand

workmanshipthatcausethefailureofawarrantedparttobeidenticalinallmaterialrespectstothatpartasdescribedin

Husqvarnasapplicationforcertication.Thewarrantyperiodbeginsonthedatetheengineorequipmentisdelivered

toanultimatepurchaserorrstplacedintoservice.Thewarrantyperiodistwoyears.

2.COVERAGE:

Subjecttocertainconditionsandexclusionsasstatedbelow,thewarrantyonemission-relatedpartsisasfollows:

(1)Anywarrantedpartthatisnotscheduledforreplacementasrequiredmaintenanceinthewritteninstructions

supplied,iswarrantedforthewarrantyperiodstatedabove.Ifthepartfailsduringtheperiodofwarrantycoverage,the

partwillberepairedorreplacedbyHusqvarnaaccordingtosubsection(4)below.Anysuchpartrepairedorreplaced

underwarrantywillbewarrantedfortheremainderoftheperiod.

(2)Anywarrantedpartthatisscheduledonlyforregularinspectioninthewritteninstructionssuppliediswarranted

forthewarrantyperiodstatedabove.Anysuchpartrepairedorreplacedunderwarrantywillbewarrantedforthe

remainingwarrantyperiod.

(3)Anywarrantedpartthatisscheduledforreplacementasrequiredmaintenanceinthewritteninstructionssuppliedis

warrantedfortheperiodoftimebeforetherstscheduledreplacementdateforthatpart.Ifthepartfailsbeforethe

rstscheduledreplacement,thepartwillberepairedorreplacedbyHusqvarnaaccordingtosubsection(4)below.

Anysuchpartrepairedorreplacedunderwarrantywillbewarrantedfortheremainderoftheperiodpriortotherst

scheduledreplacementpointforthepart.

(4)Repairorreplacementofanywarrantedpartunderthewarrantyprovisionshereinmustbeperformedatawarranty

station*atnochargetotheowner.

Page442008HUV4213-GandHUV4213-GXPOwner’sManual

Warranties

(5)Notwithstandingtheprovisionsherein,warrantyservicesorrepairswillbeprovidedatallofourdistributioncenters

thatarefranchisedtoservicethesubjectenginesorequipment.

(6)Theengineorequipmentownerwillnotbechargedfordiagnosticlaborthatisdirectlyassociatedwithdiagnosisof

adefective,emission-relatedwarrantedpart,providedthatsuchdiagnosticworkisperformedatawarrantystation*.

(7)Husqvarnaisliablefordamagestootherengineorequipmentcomponentsproximatelycausedbyafailureunder

warrantyofanywarrantedpart.

(8)Throughouttheengineorequipmentwarrantyperiodstatedabove,Husqvarnawillmaintainasupplyofwarranted

partssufcienttomeettheexpecteddemandforsuchparts.

(9)Anyreplacementpartmaybeusedintheperformanceofanywarrantymaintenanceorrepairsandmustbe

providedwithoutchargetotheowner.SuchusewillnotreducethewarrantyobligationsofHusqvarna.

(10)Add-onormodiedpartsthatarenotexemptedbytheAirResourcesBoardmaynotbeused.Theuseofany

non-exemptedadd-onormodiedpartsbytheultimatepurchaserwillbegroundsfordisallowingawarrantyclaims.

Husqvarnawillnotbeliabletowarrantfailuresofwarrantedpartscausedbytheuseofanon-exemptedadd-onor

modiedpart.*Husqvarna,itsauthorizeddealers,oraserviceagencyapprovedbyHusqvarna.

ITEMSCOVEREDBYTHISWARRANTY:

Therepairorreplacementofanywarrantedpartotherwiseeligibleforwarrantycoveragemaybeexcludedfrom

suchwarrantycoverageifHusqvarnademonstratesthattheengineorequipmenthasbeenabused,neglected,or

improperlymaintained,andthatsuchabuse,neglect,orimpropermaintenancewasthedirectcauseoftheneedfor

repairorreplacementofthepart.Thatnotwithstanding,anyadjustmentofacomponentthathasafactoryinstalled,

andproperlyoperating,adjustmentlimitingdeviceisstilleligibleforwarrantycoverage.Thefollowingemission

warrantypartslistarecovered:

SYSTEMSCOVEREDPARTSDESCRIPTION

FuelMeteringCarburetorassembly,fuelinjectionpump,fuelinjectionnozzle,fuel

regulator

ExhaustCatalyticConverter,ExhaustManifold

AirInductionAirlterhousing,airlter*,crankcasebreathertube

IgnitionFlywheelmagneto,ignitionpulsegenerator,ignitioncoilassembly,

ignitioncontrolmodule,sparkplugcap,sparkplug*

PositiveCrankcaseVentilation(PCV)SystemPCVvalve,oilllercap

EvaporativeSystemFuelT ank,FuelCap,FuelLines,FuelLineFittings,Clamps,Pressure

ReliefValves,PurgeValves,VaporHoses,CarbonCanister,Canister

MountingBrackets,CarbonCanisterPurgePortConnector

Misc.PartsBelts,hosing,tubing,ttings,seals,gaskets,clamps,andswitches

associatedwiththeabovesystems

Emission-relatedpartswillvarybetweenvehicles;therefore,certainvehiclesmaynotincludeallofthelistedparts

ormayincludeequivalentparts.

3.EXCLUSIONS:

Excludedfromthiswarrantyisdamagetoavehicleorcomponentresultingfromacauseotherthanadefectincluding

unreasonableorunintendedstrainoruse,improperinstallationofaccessories,installationofpartsoraccessories

thatarenotoriginalequipment,overloading,accident,alteration,abuseorneglect.Thiswarrantycoversonlythose

failuresresultingfromdefectsinmaterialorworkmanship.

Transportationexpensesforwarrantyservicesarealsoexcludedfromthiswarranty.

4.VOIDINGOFWARRANTY:

THISANDANYOTHERWARRANTYSHALLBEVOIDIFTHEVEHICLEISABUSEDORUSEDINANUNINTENDED

MANNERORSHOWSINDICATIONSTHATITHASBEENALTEREDINANYWAY ,INCLUDING,BUTNOTLIMITED

TO,MODIFICATIONOFTHESPEEDGOVERNOR,BRAKINGSYSTEM,STEERING,TRANSAXLE,OROTHER

OPERATINGSYSTEMSOFTHEVEHICLETOCAUSEITTOPERFORMOUTSIDEHUSQVARNASPECIFICATIONS.

THEWARRANTYISLIKEWISEVOIDIFTHEVEHICLEINVOLVEDSHOWSINDICATIONSTHATREASONABLEOR

2008HUV4213-GandHUV4213-GXPOwner’sManualPage45

Warranties

NECESSARYMAINTENANCEASOUTLINEDINTHEOWNERSMANUALANDMAINTENANCEANDSERVICE

MANUALWASNOTPERFORMEDATTHETIMEANDINTHEMANNERSPECIFIEDINSUCHMANUALS.

5.NOCONSEQUENTIALDAMAGES:

InnoeventshallHusqvarnabeliableforanyincidentalorconsequentialdamagesincluding,butnotlimitedto,loss

relatedtopropertyotherthanthevehicle,lossofuse,lossoftime,inconvenience,oranyothereconomicloss.This

warrantyisapplicableonlywheretheCaliforniaorU.S.EPAemissioncontrolsystemwarrantyregulationisineffect.

6.HOWTOMAKEAWARRANTYCLAIM:

Tomakeawarrantyclaimunderthislimitedwarranty,youmustpresentthevehicleordefectivecomponentto

anauthorizedHusqvarnadealerorsendthedefectivecomponent,freightprepaid,toWARRANTYSERVICES,

HUSQVARNAFOREST&GARDEN,

7349 Statesville ROAD,CHARLOTTE,NC28269.

IFTHEWARRANTYREGISTRATIONFORMISNOTCOMPLETEDANDRETURNEDTOHUSQVARNAATTHE

TIMEOFTHEORIGINALRETAILSALE,PURCHASERMUSTPROVIDEPROOFOFDATEOFPURCHASEWITH

ANYWARRANTYCLAIM.

Page462008HUV4213-GandHUV4213-GXPOwner’sManual

PublicationPartNumber6030043-23

EditionCode0707C0608B

103372939
